Miele H 4120, H 4150, H 4140, H 4160, H 4220 User Manual

Operating instructions

Ovens and cookers
H 4120, H 4220,
H 4130, H 4230,
H 4140, H 4240,
H 4150, H 4250,
H 4160, H 4260

To avoid the risk of accidents or
damage to the appliance it is
essential to read these operating instructions
before it is installed or used for the
first time.

G

M.-Nr. 06 234 900

Contents

Description of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Baking tray, grill pan and rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Roasting filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Anti-splash tray. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting the time of day for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Cleaning and heating up for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Description of the oven systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Using the oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Function selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Temperature selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using the oven. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Rapid heat-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Pre-heating the oven. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Cooking ready-meals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Clock/Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Q, P and O buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

The display and triangle V in the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Setting the time of day . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Minute minder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

To set the minute minder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

To cancel the time set for the minute minder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Programming cooking durations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Switching the cooking programme off automatically . . . . . . . . . . . . . . . . . . . . 26

Switching the oven on and off automatically . . . . . . . . . . . . . . . . . . . . . . . . . . 27

The end of a cooking programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

To check and change an entered time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

To delete cooking times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

2

Contents

Altering oven settings v . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Time of day display (P I) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Buzzer (P 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Baking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Baking chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Roasting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Roasting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Grilling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Grill chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Defrosting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Cooking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Cooking ready-meals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Examples of ready-meals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Gentle bake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Appliance front and control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Baking tray, grill pan, anti-splash tray (if fitted), racks and runners . . . . . . . . . 49

Roasting filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

PerfectClean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Catalytic enamel surfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Oven interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

To remove the oven door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

To dismantle the oven door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

To refit the door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

To remove the runners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

To remove the catalytic back panel, side liners (if fitted) and roof liner . . . . . . 60

Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Extra accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Electrical connection UK, IRL, ZA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Electrical connection AUS,NZ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Installing the cooker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Installing the oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

3

Description of the appliance

H 4120 E, H 4220 E, H 4130 E, H 4230 E

Control panel

a Controls for front left and back left

cooking zones*

b Function selector*
c Temperature selector*
d Temperature indicator light y
e Indicator light for cooking zones z
f Controls for front right and back right

cooking zones*

4

Oven interior

g Heating element for top heat and

grilling with catalytic enamelled roof
liner

h Air inlet for fan
i Catalytic enamelled back panel
j Shelf levels 1, 2, 3, 4
k Oven door

* retractable at the 0 setting,

depending on model

H 4120 B, H 4220 B, H 4130 B, H 4230 B

Description of the appliance

Control panel

a Function selector *
b Temperature selector *
c Temperature indicator light y

Oven interior

d Heating element for top heat and

grilling with catalytic enamelled roof
liner

e Air inlet for fan
f Catalytic enamelled back panel
g Shelf levels 1, 2, 3, 4
h Oven door

* retractable at the 0 setting,

depending on model

5

Description of the appliance

H 4140 E, H 4240 E, H 4150 E, H 4250 E, H 4160 E KAT, H 4260 E KAT

Control panel

a Controls for front left and back left

cooking zones*

b Indicator light for cooking zones z
c Function selector *
d Clock/timer with O, Q and P

buttons

e Temperature selector *
f Temperature indicator light y
g Controls for front right and back right

cooking zones*

6

Oven interior

h Heating element for top heat and

grilling with catalytic enamelled roof
liner

i Air inlet for fan
j Catalytic enamelled back panel
k Shelf levels 1, 2, 3, 4
l Oven door

* retractable at the 0 setting,

depending on model

Description of the appliance

H 4140 B, H 4240 B, H 4150 B, H 4250 B, H 4160 B KAT, H 4260 B KAT

Control panel

a Function selector *
b Clock/timer with O, Q and P

buttons

c Temperature selector *
d Temperature indicator light y

Oven interior

e Heating element for top heat and

grilling with catalytic enamelled roof
liner

f Air inlet for fan
g Catalytic enamelled back panel
h Shelf levels 1, 2, 3, 4
i Oven door

* retractable at the 0 setting,

depending on model

7

Description of the appliance

Features

Oven controls

In addition to operating the various
cooking programmes to bake, roast
and grill, the electronic controls on
models with a clock/timer also offer the
following features:

Clock display

–

Minute minder

–

Timer to automatically switch cooking

–

programmes off, or on and off

– Settings can be customised

Cooling system

As soon as the oven is switched on, a
cooling fan is automatically engaged.
The cooling fan mixes hot air from the
oven cavity with cool room air before
venting it out into the kitchen through
vents located between the appliance
door and the control panel.

The cooling fan will continue to run for a
while after the oven has been switched
off to prevent any humidity building up
in the oven, on the control panel or on
the oven housing unit.
When the temperature in the oven has
fallen sufficiently, the cooling fan will
switch off automatically.

PerfectClean treated surfaces

The following surfaces are all treated
with PerfectClean enamelling:

Oven interior

–

Runners

–

Baking tray

–

Grill pan

–

Rack

–
PerfectClean enamelled surfaces have

very good anti-stick properties and are
much easier to keep clean than
conventional enamel, if cleaned
regularly.
See "Cleaning and care" for more
information.

Catalytic enamelled surfaces

The back panel, roof liner and side
liners (if fitted) are coated with dark
grey catalytic enamel. Soiling from oil
and fat is burnt off these surfaces when
very high temperatures are used in the
oven.

This makes it easier to keep
inaccessible areas of the oven clean.
See "Cleaning and care" for more
information.

Retractable controls

Depending on model, the controls are
retractable at the 0 position.

Press them to release or retract them.

Do not push them in from any other
position as this would break them.

8

Description of the appliance

Oven interior lighting

The oven lighting is located either in the
oven roof or in the right-hand side
panel, depending on model.

Catalyser

Models H 4160 and H 4260 have a
catalyser fitted into the oven’s
ventilation system.

It filters fat from the escaping vapours
and thus reduces cooking smells.

Energy efficiency rating
according to EN 50304

These appliances are rated energy
efficiency class A in accordance with
EN 50304. Tests were carried out using:

– Fan plus on ovens H 4120 to H 4250.
– Gentle bake on ovens H 4160 and

H 4260.

Accessories

The following accessories are supplied
with this oven.

These and other accessories are also
available to order from the Miele Spare
Parts Department or your Miele Dealer.
See "Extra accessories" further on in
this booklet for more details.

Baking tray, grill pan and rack

The baking tray, grill pan and rack are
fitted with non-tip safety notches which
prevent them being pulled right out
when they only need to be partially
pulled out.

When pushing the tray, pan and rack
back in, always ensure that the
safety notches are at the rear of the
oven (see illustration).

The tray, pan and rack can then only be
taken out of the oven by raising them
upwards and then pulling them out.

9

Description of the appliance

Roasting filter

The roasting filter must be fitted in front
of the fan when cooking anything fatty,
or where food is likely to splatter, e.g.
when open roasting or grilling meat.

The droplets of fat caught up in the
circulating air are deposited on the
roasting filter. This helps to keep the
oven and the area behind the interior
back panel cleaner.

Do not use the roasting filter when
baking. This would increase the
times needed for baking and give
uneven browning results.

Anti-splash tray

(depending on model)

or roasting.
The juices from the food being cooked
collect under the anti-splash tray. This
prevents them from spitting and making
the oven dirty. The juices can then be
used for making gravy and sauces.

Handle

(depending on model)

The handle makes it easier to take the
baking tray, grill pan and rack out of the
oven, or to put them into it.
The two prongs at the top go inside the
pan, rack or tray and the U-shaped
supports underneath.

The anti-splash tray should be placed
in the deep-sided grill pan when grilling

10

Hob

For models with integrated hob controls
a separate set of instructions is
supplied with the hob, covering its
installation and use.

Caring for the environment

Disposal of the packing
material

The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.

Ensure that any plastic wrappings,
bags etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation!

Rather than just throwing these
materials away, please ensure they are
offered for recycling.

Disposal of your old appliance

Old appliances contain materials which
can be recycled. Please contact your
dealer, your local waste collection
centre or scrap merchant about
potential recycling schemes.

Ensure that the appliance presents no
danger to children while being stored
for disposal.
See the appropriate section in the
"Warning and Safety instructions".

11

Warning and Safety instructions

Technical safety

This appliance complies with all
relevant legal safety requirements.
Improper use of the appliance can,
however, present a risk of both
personal injury and material
damage.

To avoid the risk of accidents and
damage to the appliance, please
read these operating instructions
carefully before installation and
before using it for the first time. They
contain important notes on
installation, safety, operation and
care of the appliance.

Keep these instructions in a safe
place and pass them on to any
future user.

Correct usage

This appliance is intended for

domestic use to cook food, and in
particular to bake, roast, defrost, cook,
dry fruit etc, and to grill.
Any other usage is at the owner’s risk
and could be dangerous. The
manufacturer cannot be held liable for
damage caused by incorrect or
improper use of the appliance.

This appliance is not a toy! To

avoid the risk of injury, do not allow
children to play on or near it or to play
with the controls. Supervise its use by
older children, the elderly or infirm. If
allowing older children to use the
appliance without supervision, please
ensure that they are aware of how the
oven works and understand the
dangers of improper use.

the voltage and frequency correspond
to the rating on the data plate,
otherwise the appliance could be
damaged. Consult a competent person
if in doubt.

when continuity is complete between it
and an effective earthing system which
complies with local and national safety
regulations. It is most important that this
basic safety requirement is present and
regularly tested, and where there is any
doubt the household wiring system
should be inspected by a qualified
electrician.
The manufacturer cannot be held liable
for the consequences of an inadequate
earthing system (e.g. electric shock).

electrical components are accessible.

Tampering with electrical connections
or components and mechanical parts is
highly dangerous to the user and can
cause operational faults.

Before connecting the appliance to
the mains supply, make sure that

The electrical safety of this
appliance can only be guaranteed

The appliance must be built in
before operation to ensure that no

Never open the casing of the
appliance.

12

Warning and Safety instructions

Installation, maintenance and

repair work may only be carried out
by a suitably qualified and competent
person in accordance with national and
local safety regulations.
Repairs and other work by unqualified
persons could be dangerous. The
manufacturer cannot be held liable for
unauthorised work.

During installation, maintenance

and repair work, the appliance
must be disconnected from the mains
electricity supply. The appliance is only
completely isolated from the electricity
supply when:

– the mains fuse is withdrawn,
– or the screw-out fuse is removed (in

countries where this is applicable),

– or it is switched off at the isolator.

Ensure that current is not supplied to
the appliance until after maintenance
or repair work has been carried out.

Do not connect the appliance to

the mains electricity supply by an
extension lead.
Extension leads do not guarantee the
required safety of the appliance (e.g.
danger of overheating).

This equipment may only be used

in mobile installations such as
ships, caravans, aircraft etc. if a risk
assessment of the installation has been
carried out by a suitably qualified
engineer.

Use

Caution, danger of burning.
High temperatures are produced by
the oven.

Great care should be taken to

ensure that small children do not
touch the appliance when it is being
used. Children’s skin is far more
sensitive to high temperatures than that
of adults.
External parts of the oven such as the
door glass, handle vent and control
panel can become quite hot.

Keep all pans out of the reach of
children. Turn pan handles inwards
away from the edge of the hob. Danger
of burning or scalding.

Children should not be left alone or

unattended in an area where an
oven is in use. They should never be
allowed to sit or stand on any part of
the oven or play with it.
Do not store items of interest to children
in cabinets above an oven. Children
climbing on to the oven to reach these
could be seriously injured.

Use oven gloves when placing

food in the oven, turning or
removing it and when adjusting oven
shelves etc. in a hot oven.
When working with "Conventional"
heating or when grilling, the element in
the roof of the oven and the roof liner
become very hot, and there is a danger
of being burnt.

13

Warning and Safety instructions

Do not use plastic containers.
These melt at high temperatures

and could damage the oven.

Do not heat up unopened tins or

jars of food in the oven. Pressure
can build up and they may explode,
resulting in injury or damage.

Do not push pots and pans around

on the oven floor, as this could
damage the surface.

Do not lean or sit on an open oven

door, or place heavy items on it.
This could damage the appliance. The
oven door can support a maximum load
of 15 kg.

Make sure that nothing gets

trapped between the door and the
oven.

Cover any food which is left in the

oven to be kept hot. Any moisture
in the food could lead to corrosion
damage in the oven. This also prevents
the food from drying out.

If you wish to complete a cooking

process using the residual heat in
the oven, do not switch the appliance
off.
Leave the function selector at the
position set and turn the temperature
selector to the lowest setting.

Do not switch the appliance off until the
food has been removed. Moisture in the
oven could lead to condensation
forming on the control panel and
surrounding kitchen furniture and drops
of moisture collecting under the
worktop.

Condensation can:
– damage the housing unit / worktop.
– lead to corrosion in the oven.
On models fitted with a catalyser, it

could also result in deposits remaining
in the catalyser, causing an unpleasant
smell to arise the next time the
appliance is switched on.

Bake larger frozen products, such

as pizzas, on baking paper on the
rack itself or in the pizza pan (see
"Extra accessories").
Placing them on the baking tray or in
the grill pan can cause the metal to
distort, and this distortion will increase
with each subsequent use.
Frozen food such as oven chips or
croquette potatoes can, however, be
cooked on the baking tray or in the grill
pan.

14

Warning and Safety instructions

Never add water to food on a hot

baking tray or grill pan or directly
onto food in a hot oven. The steam
created could cause serious burns or
scalding and the sudden change in
temperature can damage the enamel.

Never line the floor of the oven with

aluminium foil when using
Conventional heat A or Gentle bake
x.
Do not place a dish, tin, baking tray or
grill pan on the floor of the oven.

If using a grill pan made by a different
manufacturer, make sure that there is a
gap of at least 6 cm between the
bottom of the pan and the floor of the
oven.
If these instructions are not observed
the bottom heat will be blocked. This
can cause permanent damage to the
floor of the oven.

Protective aluminium foil panels are

available in retail outlets which are
supposed to protect the oven cavity
from soiling and reduce the need for
cleaning. If used, cooking and baking
times will increase considerably.
They can also cause damage to the
appliance (e.g. by blocking the heat).

General notes

Never leave the appliance

unattended when cooking with oil
or fats, as these are a fire hazard if
allowed to overheat.

Do not use the oven to heat up the

room. Due to the high temperatures
radiated, objects left near the oven
could catch fire.

Always ensure that food is

sufficiently cooked or reheated.
Many factors will affect the overall
cooking time, including the size and
amount of food, its temperature,
changes to the recipe and the shape
and size of cooking container. Some
foods may contain micro-organisms
which are only destroyed by thorough
cooking at temperatures over 70 °C for
a minimum of 10 minutes. Therefore
when cooking or reheating foods, e.g.
poultry, it is particularly important that
food is fully cooked through. If in doubt
select a longer cooking or reheating
time.
It is important that the heat is allowed to
spread evenly throughout the food
being cooked. This can be achieved by
stirring and/or turning the food during
cooking.

15

Warning and Safety instructions

When using kitchen appliances

connected to sockets near the
oven, ensure that the cable cannot get
trapped in a hot oven door, which could
melt the cable insulation. Danger of
electric shock.

Never use a steam cleaner to clean

the appliance. The steam could
reach electrical components and cause
a short circuit.

If using alcohol in your recipes,

high temperatures can cause the
alcohol to vaporise and even to ignite
on the hot heating elements.
Alcohol should be burnt off before the
dish is placed in the oven to avoid this
danger.

In countries where there are areas

which may be subject to infestation
by cockroaches or other vermin, pay
particular attention to keeping the
appliance and its surroundings in a
clean condition at all times. Any
damage which may be caused by
cockroaches or other vermin will not be
covered by the appliance guarantee.

Disposal of your old appliance

Before throwing an old appliance

away it must first be made
unusable. Switch off and disconnect it
from the power supply, cut off the cable
directly behind the appliance and
render any plug useless. This should
be done by a competent person. If
connected to an isolator switch,
disconnection should be carried out by
an electrician to avoid the risk of
accidents.

The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.

16

Depending on model, the oven is
supplied with the controls pushed in.
They have to be released before the
oven can used.

Before using for the first time

m

V

Setting the time of day for the
first time

On models with a clock/timer you also
have to set the time of day before the
oven can be used.

The time can only be entered when
the function selector is at "0".

In the display:
– the clock symbol m (time of day) will

light up,

– and "I2:00" and triangle V

underneath the m symbol will start
flashing.

Use the P or O button to enter the

^

hour first of all.
Press the Q button.

^

This confirms the hour and the minutes
will then start to flash.

^ Use the P or O button to enter the

minutes.

^ Press the Q button to confirm the

minutes.

Once the clock has been set, the
current time of day will show in the
display and the colon will flash.

17

Before using for the first time

Cleaning and heating up for
the first time

Before use, please remove

- any stickers from the floor of the
oven, baking trays, grill pan etc.

- any cork spacers at the sides
above the oven cavity.

See "Cleaning and care" for more
information.

Before using the oven for the first time

take all accessories out of the oven

–

and wash them.

– then heat the oven up once with

nothing in it. New ovens have slight
smell on first use and this will
dissipate the smells before you use it
to cook any food.

Before heating it up it is a good idea

^

to wipe the oven out with a damp
cloth first. This way any dust or bits of
packaging that may have
accumulated in the oven cavity
during storage and unpacking will be
removed.

Press and release the function

^

selector and the temperature
selector.

Turn the function selector to Rapid

^

heat-up Ä.
Use the temperature selector to

^

select the highest temperature.

Heat the empty oven up for at least
an hour.
Please ensure that the kitchen is well
ventilated during this operation.
Close doors to other rooms to
prevent the smell spreading
throughout the house.

18

On models with a clock/timer, you can
set this procedure to finish
automatically, see the appropriate
section.

^

Wait until the oven has cooled down
to room temperature.

^

Then wipe out the oven cavity with a
solution of hot water and mild
detergent and then dry it thoroughly
with a clean cloth.

Leave the oven door open until the
oven interior is completely dry.

Description of the oven systems

Fan plus Y

This system works by the circulation of
heated air.

A fan situated on the back wall of the
oven sucks in the air, heats it over a
ring element and blows the heated air
through the carefully spaced openings
in the rear panel of the oven.

The oven does not usually need to be
pre-heated as the heated air reaches
the food straight away.
Exception: Pre-heating may be
necessary for foods which cook in less
than 20 minutes and for foods such as
puff pastry and yeast mixtures where
instant heat is required to make them
rise quickly.
When using Fan plus, you can bake
and roast on different levels at the same
time.
Lower temperatures can be used than
with Conventional heating, as the Fan
plus system circulates the heated air
throughout the oven.

Rapid heat-up Ä

With Rapid heat-up, the grill element,
bottom heating element and fan all
switch on at the same time so that the
oven reaches the required temperature
as quickly as possible. The temperature
indicator light will go out when the
pre-selected temperature has been
reached. The function selector must
then be turned to the function you wish
to use for cooking.

Conventional A

With the conventional method of
heating, radiant heat is directed onto
the food from above and below. It is
useful where a fairly long cooking time
is required and a deep colour and good
rise are needed.

It is usually necessary to pre-heat the
oven when using this method.

Gentle bake x

With Gentle bake the grill and the
bottom heating elements will be
switched on.

It is suitable for soufflés and gratins
where a crispy finish is required.

Grill n

Pre-heat the grill for at least 5 minutes
with the oven door closed before
grilling.

The grill is ready for use when it glows
red a few minutes after being switched
on.

Grill with the oven door closed.

Fan grill N

Pre-heat the grill for at least 5 minutes
with the oven door closed before
grilling.

The hot air from the grill is distributed
over the food by the fan on the rear wall
of the oven. This enables a lower
temperature to be selected than for
conventional grilling.

Grill with the oven door closed.

19

Using the oven

Controls

The oven is operated with the function
selector and the temperature selector.

Function selector

Use the function selector to select the
required oven function.

The function selector can be turned
clockwise or anti-clockwise.

Do not attempt to turn it all the way
round in either direction as this will
damage the selector.

Light H/v

–

For switching on the oven light
independently.
Depending on model, oven settings
can also be changed when the
function selector is at this position.
See "Altering oven settings".

Conventional A

–

For long, slow baking or traditional
recipes, e.g. fruit cake, casseroles.

Gentle bake x

–

For cooking dishes that require a
crispy finish, e.g. soufflés and
gratins.

– Grill n

For grilling fish and cuts of meat
such as chops, steaks, and kebabs.
Grill with the oven door closed.

– Rapid heat-up Ä

For reducing the heating up time and
for pre-heating the oven.
Also useful for cooking ready made
meals.

–

Fan plus Y
For baking or cooking on several
levels at the same time.

–

Fan grill N
For grilling thick cuts, e.g. rolled
meat, poultry.
Grill with the oven door closed.

20

Using the oven

Temperature selector

The temperature can be freely selected
within the given range.

The temperature selector must only
be turned in a clockwise direction as
far as it will go and then back again.
Do not attempt to turn it the wrong
way, or all the way round, as this will
damage the selector.

element switches on again
automatically.

Using the oven

Place the food in the oven.

^

Turn the function selector to the

^

required function.

The oven interior light comes on.

Use the temperature selector to set

^

the required temperature.

The oven starts to heat up and the
cooling fan switches on.

^ Take the food out of the oven when it

is ready.
Turn the function selector and the
temperature selector back to the "0"
position.

The cooling fan will continue to run for a
while after the oven has been switched
off to prevent any humidity building up
in the oven, on the control panel or on
the oven housing unit.
When the temperature in the oven has
fallen sufficiently, the cooling fan will
switch off automatically.

On models with a clock/timer, the oven
can be set to switch off, or to switch on
and off, automatically. See appropriate
section.

The temperature indicator light y will
come on as soon as a temperature is
selected. It remains alight while the oven
is heating up.

When the pre-selected temperature is
reached, the heating element switches
itself off. When the temperature falls
below that selected, the heating

21

Using the oven

Rapid heat-up

Rapid heat-up Ä can be used to:

pre-heat the oven,

–

heat up ready-meals.

–

Pre-heating the oven

Most dishes can be placed in a cold
oven. They will then make use of the
heat produced during the heating-up
phase.

It is only necessary to pre-heat the oven
in certain instances.

With Fan plus Y
– Pre-heat the oven for foods which

cook in less than 20 minutes and for
foods such as puff pastries and
yeast mixtures where instant heat is
required to make them rise quickly.

With Conventional A heating
– Pre-heat the oven where a fairly long

cooking time is required and a deep
colour and good rise are needed.

To pre-heat the oven:

Select Rapid heat-up Ä.

^

Use the temperature selector to set

^

the required temperature.

The oven will start to heat up.

When the temperature indicator

^

light y goes out for the first time, set
the oven function you require for
continued cooking or baking, and
place the food in the oven.

Cooking ready-meals

Rapid heat-up Ä can be used on its
own for cooking ready-meals such as
pizzas, lasagne, garlic bread etc. See
"Cooking ready meals".

When using Rapid heat-up to cook
ready meals you do not need to change
to another function during cooking.

Rapid heat-up Ä is not suitable for
traditional baking or cooking.

Do not use Rapid heat-up Ä to
pre-heat the oven when baking
delicate items such as pizzas,
biscuits and small cakes. Otherwise
they will get brown too quickly.

22

Clock/Timer

Depending on model, your oven is
fitted with a clock/timer.

The clock/timer can:

show the time of day,

–

be used as a minute minder,

–

switch the oven off, or on and off

–

automatically.

Controls

The clock/timer is operated via:

the Q, P and O buttons, and

–
– the display.

Q, P and O buttons

The Q button is used to select the
symbol for the clock/timer setting you
wish to select or change.

l Minute minder
m Time of day

g Duration of a cooking programme
) End of a cooking programme

The O button is used to shorten the
time.

The P button is used to lengthen the
time.

Entries made are shown in the display.

The display and triangle V in the
display

lmg)

V

When the Q button is pressed, the

symbols for the clock/timer settings

that can be entered light up in the
display.

Press the Q button repeatedly until
triangle V is underneath the required
symbol in the display.

The display will vary depending on
which symbol triangle V is underneath:

– the time of day m,
– the minute minder time set l,
– the duration g of a cooking

programme,

–

the end ) of a cooking programme.

When triangle V
–

is flashing under a symbol, the time
for that setting can be entered or
changed.

–

is lit up under a symbol, the time for
that symbol will be displayed, but
changes cannot be made to it.

23

Clock/Timer

Whilst triangle V is flashing, use the

O or P buttons immediately to make
any changes to the setting selected:

The P button increases the value

–

shown.
The O button reduces the value

–

shown.

Triangle V will flash for approx.
5 seconds.
Settings can only be changed using
the O or P buttons while it is
flashing.
If this period has elapsed you, will
need to call up the required symbol
again by pressing the Q button.

Each press on the O or P button alters
the time in one-minute steps.

Holding the button pressed in for
longer, speeds up the change in the
display.

Setting the time of day

When the appliance is first
connected to the power supply, or
after a power cut, "I2:00" will flash in
the display.

The time of day can only be entered
if the function selector is at "0".

Turn the function selector to "0".

^

lm

V

^ Press the Q button repeatedly until

triangle V is underneath the m
symbol in the display.

^ Whilst triangle V is flashing, use the

O or P button to enter the hour and

confirm by pressing the Q button.

24

The minutes and triangle V will flash.

^

Now use the O or P button to enter
the minutes, and confirm by pressing
the Q button.

As soon as the m symbol goes out, the
time set is saved and the colon starts to
flash.

Clock/Timer

Minute minder

The minute minder can be used to time
any activity in the kitchen, e.g. boiling
eggs.

You can enter a time of up to a
maximum of 12 hours.

You can set the minute minder at the
same time as another timed
programme, e.g. as a reminder to stir a
dish or add seasoning etc.

To set the minute minder

lm

V

^ Call up the l symbol (minute

minder) by pressing the Q button.

"0:00" appears in the display.

At the end of the set time

the l symbol flashes for approx.

–

1 minute.
"0:00" lights up for approx. 1 minute.

–

a buzzer sounds five times, if it is

–

switched on (see "Altering oven
settings v").

To cancel the time set for the
minute minder

Call up the l symbol by pressing the

^

Q button.

Triangle V under the symbol must
be flashing.

^ Use the O button to set the minute

minder time to "0:00".

^

Use the P button to enter the
required time in hours:minutes whilst
triangle V is flashing.

The time entered counts down in
minutes.
The last minute is shown in seconds.

The l symbol continues to be visible
as a reminder that the minute minder is
working.

The minute minder time will be visible
counting down in the display, as long
as triangle V is underneath the l
symbol.

25

Clock/Timer

Programming cooking
durations

On appliances with a clock/timer you
can programme cooking durations so
that the oven switches off, or on and off
automatically.

You can set the timing for a cooking
function, by selecting one of the
symbols and entering a time.

It is a good idea to set the oven to
switch on and off automatically for
roasting.

When baking, the oven should not be
set to start a long time off. Otherwise
batter or dough will dry out, and raising
agents will lose their effectiveness.

Switching the cooking programme
off automatically

You can enter a cooking duration of up
to a maximum of 12 hours.

When you enter a cooking duration, the
oven will switch off automatically after
the duration entered has elapsed.

To do this:

Place the food in the oven.

^

Select your cooking function and set

^

a temperature.

The oven light will come on and the
oven will heat up.

lmg)

V

Press the Q button repeatedly until
triangle V is underneath the g
(cooking duration) symbol in the
display.

26

"0:00" appears in the display.

^

Whilst triangle V is flashing, enter
the required duration in hours and
minutes using the P button.

If no other symbol is selected, the
cooking duration will be seen counting
down in the display.

Clock/Timer

Switching the oven on and off
automatically

To use the automatic switch-on and
switch-off functions on the oven, both
the cooking duration and the end time
must be entered.

For example:
The time now is 10:45; you want a dish
with a cooking duration of 90 minutes to
be ready at 13:30.

Place the food in the oven.

^

Select your cooking function and set

^

a temperature.

The oven light will come on and the
oven will heat up.

Now enter the cooking duration:

lmg)

V

^

Press the Q button repeatedly until
triangle V is underneath the g
(cooking duration) symbol in the
display.

"0:00" appears in the display.

Then set the end time:

lmg)

V

Press the Q button repeatedly until

^

triangle V is underneath the )
(end time) symbol in the display.

The time of day plus the cooking
duration entered appear in the display
(10:45 + 1:30 = 12:15).

lmg)

V

^ Use the P button to change the end

time from 12:15 to 13:30.

The oven light and heating will switch
off as soon as triangle V goes out.
The end time will now show in the
display as long as the triangle is not
moved to under another symbol.

As soon as the start time (13:30 - 1:30
= 12:00) is reached, the oven light will
switch on, and the oven will heat up.

lmg)

V

^

Whilst triangle V is flashing, enter
the required duration in hours and
minutes (1:30) using the P button.

27

Clock/Timer

The end of a cooking
programme

At the end of the cooking duration

the oven heating switches off

–

automatically.
the cooling fan will continue to run for

–

a while.
the g symbol flashes.

–

a buzzer sounds five times, if it is

–

switched on (see section "Altering
oven settings v").

^ Turn the function selector and the

temperature selector to "0".

The buzzer will stop and the symbols in
the display will go out.

^ Remove the food from the oven.
If the function selector is not moved, the

buzzer (if switched on) will sound every
five minutes as a reminder that the
programme has finished.
This reminder continues for up to
30 minutes.

To check and change an
entered time

It is possible to check or change times
entered for a cooking programme at
any time by calling up the relevant
symbol.

To check

Call up the symbol for the time to be

^

checked.

l

The minute minder time remaining will
show in the display.

m

The time of day will show in the display.

g

The display shows the cooking duration
set or the duration remaining if the
programme has started.

)

The programme end time is displayed.

To change

28

^

Call up the symbol for the time to be
changed.

^

Use the P or O button to alter the
time.

To delete cooking times

^

Turn the function selector to "0".

If there is a power cut, all data entered
will be deleted.

The following settings can be changed:

the time of day display

–

the buzzer.

–

The altered settings are retained
after a power cut.

Time of day display (P I)

The time of day display can be
switched on or off.

When the time of day display is
switched off and the function selector is
turned to the "0" position, the display
remains dark. The time of day
continues to run in the background.
It reappears when the function selector
is turned to one of the functions.

To alter the setting:
^ Turn the function selector to the "Light

H/v" position, and press the Q
button.

Altering oven settings v

"P I" will appear in the display.

Press the Q button.

^

The following appears in the display:
–"S 0", if the time of day display is

switched off.

–"S I", if the time of day display is

switched on.

^

Use the P or O button to scroll
between the "I" and "0" settings.

^

Press the Q button.
This confirms your entry.
Depending on the setting selected, the

time of day will either show in the
display or the display will remain dark
when the function selector is turned to
"0".

29

Altering oven settings v

Buzzer (P 2)

There is a choice of 3 different tones or
alternatively, the buzzer can be
switched off.

To alter the setting:

Turn the function selector to the "Light

^

H / v" position, and press the Q
button.

"P I" will appear in the display.

Press the P or O button.

^

"P 2" will appear in the display.
^ Press the Q button.

Use the P or O button to scroll

^

through the settings from "0" to "3".
The corresponding buzzer will sound

as you do so.

Press the Q button to confirm the

^

setting you wish to select.
The buzzer will now sound at the

setting selected (or not at all if you have
switched it off) at the end of a cooking
programme or minute minder time.

The following appears in the display:
–

"S 0", if the buzzer is switched off.

–

"S I", if the buzzer is switched to the
quiet setting.

–

"S 2", if the buzzer is switched to the
medium setting.

–

"S 3", if the buzzer is switched to the
loud setting.

30

Baking

The following settings are
recommended for baking:

Fan plus Y

–

Conventional A

–

Bakeware

For the best baking results make sure
that you chose bakeware in a material
suitable for the particular heating
system.

Fan plus Y

Most types of heat-resistant tins or
dishes are suitable.

Conventional A

The following baking tins give an even,
brown result: Dark metal, aluminium or
enamel tins with a matt finish. Heat
resistant glass and ceramic dishes can
also be used.

Avoid bright, shiny metal tins. These
reflect heat, which means that the heat
does not penetrate to the food
effectively, resulting in uneven or poor
browning.
In some cases the cakes might not
cook properly. Place the tin or dish
directly on the non-tip rack in the oven.
Use one shelf position only.

Fan plus Y

Several shelf levels can be used at

the same time for baking. The
recommended positions are:

1 tray = 1st shelf level from

the bottom

2 trays = 1st and 3rd shelf level from

the bottom

3 trays = 1st, 2nd and, 4th shelf level

from the bottom

When baking moist biscuits, cakes
or bread, do not bake on more than
two levels.

Remember to remove the roasting
filter from in front of the opening on
the back wall. Otherwise baking
times will be longer and results
uneven.

With Fan plus Y, the baking
temperature required is lower than
with Conventional A. Refer to the
baking charts and cookery book
supplied with your oven.

31

Baking

Conventional A

Only use dark baking tins with a
matt finish.
Bright, shiny tins give an uneven or
pale result, and in some cases the
cakes might not cook properly.

Place tins centrally on the rack on shelf

level 1 or 2.

Older recipes and cookery books

New guidelines (German standard
DIN 44547 has been replaced by
European standard EN 60350) have led
to slight adjustments in oven
temperature settings.

The recipes in the cookery book
supplied with your oven include these
new adjusted temperatures for cooking
with Conventional heat.

However, if using an older recipe or
cookbook, set the oven temperature for
Conventional 10° C lower than that
recommended.
The cooking duration does not need to
be changed.

Tips on baking

Refer to the baking chart and the
cookery book supplied with this
oven for suggestions of
temperatures, shelf levels and times.

Place cakes in rectangular tins with
the longer side across the width of the
oven for optimum heat distribution and
even results.

When baking cakes with fresh fruit
toppings and tall sponge cakes place
the tin in the grill pan to catch any
spillages and keep the oven cleaner.

When baking anything with a high salt
content (such as pretzels), they must
be placed on baking parchment. High
concentrations of salt can damage
PerfectClean surfaces.

32

Frozen food

When baking frozen products such as
cakes, pizza and baguettes, use the
lowest temperature quoted on the
manufacturer’s packaging. Place such
items on baking parchment directly on
the rack or in the pizza pan (extra
accessory). Placing them on the baking
tray or in the grill pan can cause the
metal to distort. This distortion would
increase with subsequent use.

Frozen foods such as oven chips or
potato croquettes can be cooked on a
baking tray or in the grill pan. Place
these types of frozen foods on baking
parchment and select the lowest
temperature quoted on the
manufacturer’s packaging.

Baking

Handling and preparing food
correctly is essential for maintaining
good health.

Only bake cakes, pizza, chips etc
until they are golden brown. Do not
overcook them.

To achieve even results without
over-browning the food

always select the lowest tempera

–

ture given in the recipe/cooking
instructions on the packaging. Do
not set a temperature higher than
that recommended. Increasing the
temperature may reduce the cooking
time, but will lead to uneven
browning. In some cases food might
not cook properly.

– Check if the food is cooked at the

end of the shortest time quoted.
To check if a cake is ready, insert a
wooden skewer into the centre.
It is ready if the skewer comes out
clean, without dough or crumbs
sticking to it.

-

The cooling fan will continue for a while
after switching off the oven.

Always remove all accessories, trays
and racks which are not being used,
when using the oven to get the best
cleaning results and to keep
cleaning of the trays to the minimum.

33

Baking chart

Fan plus Y

Temp.

in °C

Creamed mixture

Sponge cake
Ring cake
Foam cake (tray)

1)

Marble, nut cake (tin)
Fresh fruit cake, with filling (tray)
Fresh fruit cake (tray)
Fresh fruit cake (tin)
Flan base
Small cakes

Sponge mix

Sponge cake (3 to 6 eggs)
Sponge cake (2 eggs)
Swiss roll

1) 3)

1) 3)

1) 3)

1) 3)

(tray)

1) 3)

1) 3)

150 - 170
150 - 170
150 - 170
150 - 170
150 - 170
150 - 170
150 - 170
150 - 170
150 - 170

160 - 180
160 - 180
160 - 180

Rubbed in mixture

Tart / flan base
Streusel cake
Small cakes
Cheesecake
Apple pie
Apricot tart, with filling
Swiss apple pie

1)

1) 3)

(tray)

2)

1)

150 - 170
150 - 170
150 - 170
150 - 170
150 - 170
150 - 170
190 - 210

Yeast mixtures and quark dough

Guglhupf
Streusel cake
Fresh fruit cake (tray)
Stollen
White bread
Wholegrain bread 2)
Pizza (tray)
Onion tart

1) 3)

1)

Apple turnovers

Choux pastry
Puff pastry

1) 3)

, Eclairs 160 - 180 1, 3

1)

150 - 170
150 - 170
160 - 180
150 - 170
160 - 180
170 - 190
170 - 190
170 - 190
150 - 170

170 - 190 1, 3

Meringues1), Macaroons 120 - 140 1, 3

Unless otherwise stated, the times given are for an oven which has not been pre-heated.
With a pre-heated oven shorten times by up to 10 minutes.

Recommended

shelf level

5)

1
1
1
1
1
1
1
1

4)

1, 3

1
1
1

1
1

4)

1, 3

1
1
1
1

1
1
1
1
1
1
1
1

4)

1, 3

4)

4)

4)

Time

in mins.

60 - 70
65 - 80
25 - 40
60 - 80
45 - 50
35 - 45
55 - 65
25 - 30
20 - 25

25 - 35
20 - 25
20 - 25

20 - 25
45 - 55
15 - 25
70 - 90
50 - 70
55 - 75
25 - 35

50 - 60
35 - 45
40 - 50
45 - 65
40 - 50
50 - 60
35 - 45
35 - 45
25 - 30

30 - 40
20 - 25
25 - 50

1) Pre-heat the oven when using Conventional A .

2) Pre-heat the oven when using Fan Plus Y and Conventional A.

3) Do not use Rapid heat-up Ä during the heating-up phase.

4) Take baking trays out of the oven at different times if the food is sufficiently browned before
the specified time has elapsed.

5) The shelf levels are counted from the bottom of the oven upwards (1 = lowest; 4 = highest).

34

Temp.

in °C

Conventional A

Recommended

shelf level 5)

Baking chart

Time

in mins.

150 - 170
170 - 190
170 - 190
150 - 170
170 - 190
170 - 190
160 - 180
170 - 190
170 - 190

170 - 190
170 - 190
180 - 200

170 - 190
170 - 190
170 - 190
170 - 190
170 - 190
170 - 190
220 - 240

160 - 180
170 - 190
180 - 200
160 - 180
180 - 200
190 - 210
190 - 210
180 - 200
160 - 180

180 - 200 2 25 - 35
190 - 210 2 15 - 25
120 - 140 2 25 - 50

1
1
2
1
2
2
1
1
2

1
1
2

2
2
2
1
1
1
1

1
2
2
2
1
2
1
1
2

60 - 70
65 - 80
25 - 40
60 - 80
45 - 50
35 - 45
55 - 65
20 - 25
12 - 20

20 - 35
15 - 20
12 - 16

15 - 20
45 - 55
10 - 20
70 - 90
45 - 65
55 - 75
25 - 35

50 - 60
35 - 45
40 - 50
45 - 65
40 - 50
50 - 60
30 - 40
25 - 35
25 - 30

The information given in this chart is intended only as a guide.

35

Roasting

We recommend using Fan plus Y for
roasting.

Conventional A can also be used.

Fan plus Y:
When roasting on the rack or in an
open tin make sure the roasting filter
is fitted in front of the fan in the back
of the oven before starting.

We recommend roasting in a covered
pot , as

– this ensures that sufficient stock

remains for making gravy.

–

and the oven stays cleaner, too.

Roasting containers

Any heat-proof containers can be used:
roasting pans with a lid, made from
earthenware, cast iron, ovenproof china
or glass, and roasting foil are all
suitable.

Miele also offer Gourmet oven dishes
with lids which are ideal for roasting
and cooking larger quantities of food.

Place the roasting pan on the rack into
a cold oven.

Exception:
Pre-heat at the temperature suggested
when roasting beef.

Shelf levels

Use shelf level 1 for roasting.
Exception:

With Conventional A use shelf level 2
for

- poultry up to 1 kg,

- roast beef,

- and fish.

36

Roasting

Temperature

Please refer to the Roasting chart for
suggested temperatures.

Do not select a higher temperature than
that advised. The meat will become
brown, but will not be cooked properly.

With Fan plus Y, a temperature
setting of 40 °C lower than for
Conventional A is sufficient.

For cuts which weigh 3 kg or more,
select a temperature approx. 10 °C
lower than that given in the roasting
chart.
Roasting will take longer at the lower
temperature, but will be more even.

For roasting directly on the rack,
select a temperature that is about 20 °C
lower than for roasting in a covered pot.

When roasting on the rack, place the
rack and anti-splash tray over the grill
pan.

Older recipes and cookery books

New guidelines (German standard
DIN 44547 has been replaced by
European standard EN 60350) have led
to slight adjustments in oven
temperature settings.

The recipes in the cookery book
supplied with your oven include these
new adjusted temperatures for cooking
with Conventional heat.

However, if using an older recipe or
cookbook, set the oven temperature for
Conventional 10° C lower than that
recommended.
The cooking duration does not need to
be changed.

37

Roasting

Calculating the roasting time

The roasting time will depend on the
type of meat, the size and thickness of
the cut.

The traditional British method is to allow
15 to 20 minutes per lb/454 grammes,
according to type of meat, plus approx.
20 minutes, adjusting the length of time
as roasting proceeds to obtain the
required result. Alternatively, multiply
the height of the joint by the time per
cm for the type of meat:

Beef/venison . . . . . . . . . 15-18 mins/cm

Pork/lamb/veal . . . . . . . . 12-15 mins/cm

Sirloin . . . . . . . . . . . . . . . . 8-10 mins/cm

e.g. Beef 8 cm thick
8 x 15 minutes per cm = 120 mins

Tips on roasting

Browning only occurs towards the end

of roasting time. Remove the lid about
halfway through the roasting time if a
more intensive browning result is
required.

After the roasting process is finished

take the roast out of the oven, wrap in
aluminium foil and leave to stand for
about 10 minutes.
This helps retain juices when the meat
is carved.

Pot roasting

Season the meat and place in the pot.
Add some knobs of butter or margarine
or a little oil or cooking fat. Add about

1

/8litre of water when roasting a large,
lean joint of meat (2-3 kg) or roasting
poultry with a high fat content.

Roasting on the rack

Place the anti-splash tray in the grill
pan and then place the rack on top.
Season the meat and place on the rack.

Roasting poultry

For a crisp finish, baste the poultry ten
minutes before the end of cooking time
with slightly salted water.

Frozen meat

Do not roast deep frozen meat. Meat
should be thoroughly defrosted
before roasting.

38

Roasting chart

Food Recom-

mended

shelf

6)

level

Fan plus Y

Temperature

in °C

2)

1)

Time

in mins.

Conventional A

Temperature

in °C

2)

1) 5)

Time

in mins.

Roast beef (approx. 1 kg) 1 170 - 190 100 - 120 190 - 210 100 - 120
Beef fillet, approx. 1 kg

3)

1 190 - 210 45 - 55 - -

Venison (approx. 1 kg) 1

4)

180 - 200 90 - 120 190 - 210 90 - 120

Pork, joint (approx. 1 kg)

1 170 - 190 100 - 120 200 - 220 100 - 120

Pork, joint (approx. 2 kg)

1 150 - 170 160 - 180 180 - 200 150 - 170
Ham joint (approx. 1 kg) 1 170 - 190 60 - 70 200 - 220 60 - 70
Meat loaf (approx. 1 kg) 1 160 - 180 70 - 80 190 - 210 70 - 80
Veal (approx. 1.5 kg) 1

4)

170 - 190 100 - 120 190 - 210 100 - 120
Leg of lamb (approx. 1.5 kg) 1 170 - 190 90 - 120 200 - 220 90 - 120
Rack of lamb, approx. 1.5 kg
Poultry (0.8 - 1 kg) 1

3)

1 170 - 190 50 - 60 190 - 210 50 - 60

4)

170 - 190 60 - 70 190 - 210 60 - 70
Poultry (approx. 2 kg) 1 170 - 190 90 - 110 190 - 210 90 - 110
Poultry (approx. 2 kg) 1 170 - 190 110 - 130 190 - 210 110 - 130
Poultry (approx. 4 kg) 1 160 - 180 150 - 180 180 - 200 150 - 180
Whole fish (approx. 1.5 kg) 1

4)

160 - 180 35 - 55 190 - 210 35 - 55

Unless otherwise stated, the times given are for an oven which has not been pre-heated.

1) Use the roasting filter.

2) Temperature in a covered pot
If open roasting, set the temperatures 20 °C lower.

3) Pre-heat the oven when using Fan plus Y and Conventional A.

4) Use the 2nd shelf level from the bottom for Conventional A.

5) We recommend Fan plus Y for roasting, however Conventional A can also be used.

6) The shelf levels are counted from the bottom of the oven upwards (1 = lowest; 4 = highest)

The information given in this chart is intended only as a guide.

39

Grilling

Grill with the oven door closed.
If you grill with the door open, hot air
will escape from the oven instead of
being cooled automatically by the
cooling fan. Control elements on the
oven could get hot. Danger of
burning.

Grill settings

Grill n

For grilling thin cuts and for browning
food.

Put the roasting filter in front of the
fan in the back of the oven when
grilling.

squeeze a little lemon juice over the
fish.

Grilling on the rack

^ Assemble the rack on the grill pan

and use the anti-splash tray as
illustrated.

^ Place the food on the rack.

Fan grill N

For grilling larger items, e.g. rolled
meat, poultry.

Put the roasting filter in front of the
fan in the back of the oven when
grilling.

Preparing food for grilling

Clean, wipe dry and season with
pepper and herbs. Do not season meat
with salt before grilling as this draws
the juices out.

Add a little oil if necessary. Do not use
other types of fat as they can get too
dark, burn and cause smoke.

Clean fish in the normal way. To
enhance the taste, add a little salt or

40

^ Select the grill setting and set a

temperature.

^ Pre-heat the grill for at least

5 minutes with the door shut before
grilling.

^

Place the grill pan under the grill and
shut the door.

For thin cuts use shelf level 3 or 4
For thicker cuts use shelf level 1 or 2

^

Most items should be turned half way
through cooking.

Grilling

Temperature

For thin cuts of meat
(e. g. chops or steak). . . maximum (n)

For grilling larger items,

(e. g. rolled meat, poultry) . . . . . 240 °C

See the grill chart for more information.
To grill thicker pieces of food more

gradually after an initial high
temperature, continue grilling at a lower
temperature setting to allow the food to
cook through to the centre.

Grilling times

– Flat pieces of fish and meat usually

take about 6 – 8 minutes per side,
depending on their texture.

– Thicker pieces take a little longer.
– With rolled meats allow approx.

10 minutes per cm diameter.

Tips on grilling

It is best to grill food of a similar
thickness at the same time so that the
grilling time for each item does not vary
too greatly.

One way of finding out how far through
a piece of meat has been cooked is to
press down on it with a spoon:

If there is very little resistance to the

–

pressure of the spoon, it is still red on
the inside (“rare”).

If there is some resistance the inside

–

will be pink (“medium”).

– If there is great resistance, it is

throughly cooked through (“well
done”).

41

Grill chart

Pre-heat the grill for at least 5 minutes with the door shut before grilling.

Food to be grilled Recom-

mended

shelf

4)

level

Temp.

in °C

Grill n

1)

Total grilling

time

in mins.

2)

Fan grill N

Temp.

in °C

1)

Total grilling

time

in mins.

Thin cuts

Steaks 3 or 4

3)

n 10 – 16 220 10 – 16

Kebabs 3 240 25 – 30 220 25 – 30
Chicken kebabs 3 240 20 – 25 200 – 220 20 – 25
Cutlets/schnitzel 3 or 4
Liver 3 or 4
Burgers 3 or 4
Sausages 3 or 4
Fish fillet 3 or 4
Trout 3 or 4
Toast 3 or 4
Cheese toast 3 or 4
Tomatoes 3 or 4

3)

3)

3)

3)

3)

3)

3)

3)

3)

n 12 – 18 220 18 – 20
n 8 – 12 220 10 – 14
n 14 – 20 220 16 – 20
n 10 – 15 220 8 – 12
n 12 – 16 220 12 – 16
n 16 – 20 220 20 – 25
n 2 – 4 220 3 – 5
n 7 – 9 220 4 – 6
n 6 – 8 220 6 – 8

Peaches 3 n 6 – 8 220 7 – 10

Thicker cuts

Chicken

2 – – 200 – 220 50 – 60

(approx. 1 kg)
Rolled meat,

1 – – 200 75 – 85

C 7 cm, (approx. 1 kg)
Piece of pork

1 – – 200 100 – 120

(approx. 1 kg)
Sirloin,3)(approx. 1 kg) 1 – – 250 25 – 35

2)

1) Use the roasting filter when grilling.

2) Turn half way through the grilling time.

3) Select the appropriate shelf level for the thickness of the food.

4) The shelf levels are counted from the bottom of the oven upwards (1 - lowest; 4 = highest)

The information given in this chart is intended only as a guide.

42

You can also use the oven for
defrosting.

To defrost select Fan plus Y with a
maximum temperature of 50 °C.

For defrosting meat and delicate foods,
use the lowest possible temperature
(30 °C).

Please note:

Where possible remove the

–

packaging and put the food to be
defrosted on a baking tray or into a
dish.

– All meat and poultry should be fully

defrosted before cooking. Do not use
the liquids from defrosting.

– When defrosting poultry, put it on the

rack over the grill pan to catch the
defrosted liquid so that the meat is
not lying in this liquid.

Defrosting

Do not refreeze food once it has
thawed.

It is particularly important to observe
food hygiene rules when defrosting
poultry. Do not use the liquid from
the defrosted poultry. Pour it away,
and wash the tray, the sink and your
hands. Danger of salmonella.

–

Fish does not need to be fully
defrosted before cooking. Defrost so
that the surface is sufficiently soft to
take herbs and seasoning.

43

Cooking

We recommend using the following
oven settings:

Fan plus Y

–

Conventional A

–
Cooking containers made of ovenproof

glass and china, and earthenware are
all suitable. They should have
heat-resistant handles and knobs.

Put the rack in on shelf level 1 and

^

place the dish on the rack.
Select your cooking function and

^

set a temperature.

Fan plus Y . . . . . . . . . . . 170 - 190 °C

Conventional A. . . . . . . . . 180 - 200 °C

Cooking durations

Casseroles . . . . . . . . . . . . 70 - 90 mins.

Gratins/bakes . . . . . . . . . . 40 - 60 mins.

Tips

Cover dishes which are to be cooked

in their own juice and/or steam, e.g.
potatoes or vegetables, so that they do
not dry out. If you do not have a lid, use
aluminium foil or damp cooking
parchment.

Cook without a lid when a crusty finish
or topping is required, e.g. for meat or
au gratin dishes.

You can also stack one pot on top of
another. Invert the lid of the bottom pot
and place the top pot on it. Place any
dish which needs to be browned on
top.

44

Cooking ready-meals

The Rapid heat-up Ä function can be
used on its own for cooking
ready-meals (see chart) such as pizza,
lasagne, garlic bread, etc.

Select Rapid heat-up Ä.

^

Select a temperature.

^

When the temperature indicator light

^

y goes out, place the dish in the
pre-heated oven.

You do not need to select another
function for cooking.

Observe recommended temperatures,
cooking times and position in the oven
given on the manufacturer’s packaging.

Cooking

Only use one level of the oven when
cooking ready-meals using this
function. If more than one shelf level
is required, select Fan plus Y.

Cook frozen desserts and pizza on
baking paper on the rack rather than
on a baking tray or in the grill pan.
Cooking large frozen items on a
baking tray or in the grill pan can
cause the metal to distort. This
distortion would increase with each
subsequent use.
Frozen foods such as oven chips or
croquette potatoes can, however, be
cooked on the baking tray or in the
grill pan.

45

Cooking

Examples of ready-meals

Food Temp.

Potato, pasta or
vegetable bake

Lasagne, cannelloni 190 1 or 2* 35 - 40 Remove the lid
Filled baguette,

Panino 200 1 or 2 * 12 - 15
Pre-cooked pizza 200 1 or 2 * 12 - 20 Place on baking paper,

Pre-cooked mini pizza 220 1 or 2 * 8 - 10 Place on baking paper,

Potato pancakes,
Rösti, croquettes

Pretzels 220 1 or 2 * 12 - 15 Place on baking paper,

in °C

250 1 or 2 * 20 - 25 Place in a suitable dish

220 1 or 2 * 12 - 20 Place on baking paper,

Recommended shelf

level, from the bottom

Time

in mins.

Notes

Place on baking paper,

directly on the rack

directly on the rack

directly on the rack

directly on the rack

directly on the rack

* Please follow the manufacturer’s instructions on the packaging.

Rapid heat-up Ä is not suitable for traditional baking or cooking.

Gentle bake

The Gentle bake x function is ideal for gratins and bakes which require a crispy
finish.

Food Temp.

in °C

Lasagne 200 45 - 60 1
Potato bake 190 55 - 65 1
Vegetable bake 190 55 - 65 1
Pasta bake 190 40 - 50 1

Time in mins. Recommended shelf level,

from the bottom

The table contains just a few examples. For other recipes, use the temperature
and time settings given for Conventional top and bottom heat.

46

Cleaning and care

Appliance front and control
panel

Clean the door handle and the control
elements regularly, preferably after
each use. This will help to prevent
grease and other deposits adhering to
surfaces and becoming difficult to
remove.

All external surfaces and controls can

^

be cleaned using warm water with a
little washing-up liquid applied with a
soft sponge or cloth.

Wipe the surfaces dry using a soft

^

cloth.

E-Cloth

A microfibre "E-Cloth" is available from
the Miele UK Spare Parts Department,
which is suitable for cleaning surfaces
such as stainless steel, glass, plastic
and chrome without the use of
chemicals.

To prevent the risk of scratches and
damage to the surface structure of
glass, stainless steel and aluminium
fronted appliances, pay particular
attention to the following cleaning
instructions.

Glass fronted appliances

The appliance front and controls are
susceptible to scratches and
abrasions.

abrasive sponges, e.g. pot scourers

–

or sponges which have been
previously used with abrasive
cleaning agents,

oven sprays.

–

Aluminium fronted appliances

Aluminium is affected by the way that
light falls on it, by the surrounding
environment and by the angle you
observe it from.

Aluminium surfaces and controls
may suffer discolouration or damage
if soiling, acids or alkaline
substances are left on them for too
long.
Remove these straight away.

The appliance front and controls are
susceptible to scratches and
abrasions.

Avoid:
–

cleaning agents containing soda,
acids or chlorides,

–

abrasive cleaning agents, e.g.
powder cleaners and cream
cleaners,

–

abrasive sponges, e.g. pot scourers
or sponges which have been
previously used with abrasive
cleaning agents,

–

stainless steel cleaners,
Avoid:
–

abrasive cleaning agents, e.g.
powder cleaners and cream
cleaners,

–

cleaning agents containing

descaling agents,

–

dishwasher detergent,

–

oven sprays.

47

Cleaning and care

Stainless steel fronted
appliances

The appliance front and controls are
susceptible to scratches and abrasion.

Please observe the cleaning
instructions for

stainless steel surfaces,

–

stainless steel coloured controls.

–

Stainless steel surfaces

Stainless steel surfaces can be cleaned
using a Miele E-Cloth or with a
proprietary non-abrasive cleaning
agent designed specifically for use on
stainless steel. N.B. Do not use
stainless steel cleaning agents on the
controls.

Avoid:
– cleaning agents containing soda,

acids or chlorides,

– abrasive cleaning agents, e.g.

powder cleaners and cream
cleaners,

Stainless steel coloured controls

The controls may suffer
discolouration or damage if soiling is
left on them for too long. Remove
soiling straight away.

Avoid:

cleaning agents containing soda,

–

acids or chlorides,

abrasive cleaning agents, e.g.

–

powder cleaners and cream

cleaners,

– abrasive sponges, e.g. pot scourers

or sponges which have been

previously used with abrasive

cleaning agents,

– stainless steel cleaners,
– oven sprays.

–

abrasive sponges, e.g. pot scourers
or sponges which have been
previously used with abrasive
cleaning agents.

To help prevent re-soiling, a proprietary
conditioning agent for stainless steel
can also be used.
Apply sparingly with an even pressure
following the direction of the grain.

48

Accessories

Always remove all accessories, trays
and racks which are not being used
when using the oven to get the best
results and to keep cleaning of the
trays to a minimum.

Baking tray, grill pan, anti-splash tray
(if fitted), racks and runners

The surfaces of these have been
treated with PerfectClean enamel.

Please refer to the section
"PerfectClean" for information on
cleaning and care.

Roasting filter

Clean in a solution of hot water and a
little washing-up liquid or in the
dishwasher.

Cleaning and care

If cleaned in the dishwasher, results are
better if the filter is placed horizontally
in the basket.
Some dishwasher detergents may
cause the surface of the metal filter to
discolour. This discolouration will not
affect the functioning of the filter in any
way.

49

Cleaning and care

PerfectClean

Before using for the first time remove
any stickers from PerfectClean
surfaces.

The enamelled surfaces of the oven
interior, baking tray, grill pan, anti-splash
tray (if fitted), rack and side supports
have been treated with a special type of
enamelling called "PerfectClean".

This surface has very good anti-stick
properties which is much easier to keep
clean than conventional oven enamel, if
cleaned regularly.

Food can be taken off it more easily
and soiling from baking and roasting is
easier to remove.

The following notes on cleaning and
care should ensure that the anti-stick
and easy clean properties of
PerfectClean last for many years.

PerfectClean surfaces can be treated
as you would treat glass. If you are
unsure whether a particular cleaning
product is suitable for PerfectClean
consider whether you could clean a
window pane with the product without
damaging it.

Food can be sliced or cut up on the
PerfectClean surface in the same way
as on a baking tray with conventional
enamel.

Allow the oven and any accessories
to cool down before cleaning.
Danger of burning!

Normal soiling

Clean as soon as possible after each
use with a dishcloth, soft sponge (such
as the Vileda sponge supplied with
ovens in the UK) or a soft nylon brush,
and a solution of hot water and a little
washing-up liquid. The longer soiling is
left the harder it may become to
remove.

Stubborn soiling

Stubborn soiling e.g. from roasting may
need to be soaked first with a damp
sponge to loosen it and if necessary a
scraper suitable for glass surfaces can
be used to remove it.

After cleaning rinse thoroughly with
clean water. The water must run off the
surface easily. Any residual cleaning
agents will hinder this effect.

Using oven sprays on very stubborn
soiling

Some oven cleaners contain strong
alkalines and / or abrasive
materials. Because the enamel is
designed to be easily cleaned the use
of these cleaners is not recommended.
However if you still cannot get the
surface clean, an oven cleaner can be
used for a couple of minutes only.
Do not attempt to use on a hot oven or
accessories. Allow the PerfectClean
surfaces to cool down to room
temperature before applying oven
sprays!

50

Cleaning and care

Remove the catalytic back panel,
roof liner and side liners (if fitted)
before using oven sprays. The
chemicals used in oven sprays will
damage catalytic enamel rendering
it ineffective.

Apply a spray oven cleaner to the
soiled areas. Leave to take effect for a

couple of minutes only!

If necessary use a soft sponge (e.g. a
Vileda sponge), soft nylon brush or a
scraper suitable for glass surfaces to
loosen the soiling.

Repeat the process if necessary.
After cleaning rinse thoroughly with

clean water and then dry thoroughly.

Important

For optimum performance of the
PerfectClean enamel it is important to
clean the oven and accessories after
each use.

The surfaces will become harder to
clean and the anti-stick properties
will deteriorate if soiling is not
removed after each use and allowed
to build-up. In extreme cases
cleaning may even become
impossible.

The following cause lasting damage
to the surface structure and reduce
the anti-stick effect and must not be
used on PerfectClean surfaces:

– abrasive cleaning agents
– wire wool or metal scourers
– pot scourers
– oven cleaning pads
– sponges and cloths which have

previously been used with
abrasive cleaning agents.

– oven spray must not be used in a

hot oven or left on for too long.

– items coated with PerfectClean

enamelling must not be cleaned
in a dishwasher.

Note

Soiling such as spilt juices and cake
mixtures are best removed whilst the
oven or tray is still warm. Exercise
caution, make sure the oven is not hot ­danger of burning!

Spilt fruit juices may cause lasting
discolouration of the surfaces and
roasting can cause matt areas to
appear. Clean these following the
instructions given above and do not try
and use force to remove them! This
discolouration is permanent but will not
affect the efficiency of the enamel.

When baking items with a high salt
content (e.g. continental pretzels) place
them on baking parchment in the
baking tray or grill pan. Sodium
deposits can cause lasting
discolouration to PerfectClean
surfaces.

51

Cleaning and care

Catalytic enamel surfaces

The removable back panel, side panels
(if fitted) and roof liner are coated with a
dark grey catalytic enamel.

During fan operated cooking,
circulating air in the oven deposits oil
and fat splashes predominantly on the
back panel of the oven. These splashes
are burnt off when the temperature of
the oven reaches over 200°C during
baking or roasting. The higher the
temperature the more effective the
process.

The oven and accessories should be
cleaned after each use. Otherwise
further baking and roasting will cause
the deposits to bake on even harder
and cleaning may become difficult and
in extreme cases impossible.

Cleaning by hand

Allow the oven to cool down before
cleaning. Danger of burning!

Catalytic enamelled panels should be

^

cleaned using a solution of hot water
with a little washing-up liquid applied
with a soft nylon brush.

Do not use abrasive cleaning agents,
hard brushes, scouring pads or cloths,
steel wool, knives or other abrasive
materials and do not use oven spray on
catalytic enamel as the chemicals used
in oven sprays will damage catalytic
enamel rendering it ineffective.

If using oven sprays on PerfectClean
oven surfaces the catalytic back panel,
roof liner and side liners (if fitted) must
first be removed from the oven.

52

Cleaning and care

To clean at high temperatures

Before cleaning the catalytic panels
using high temperatures, make sure
that all PerfectClean surfaces have
been cleaned as previously
described. Otherwise, the high
temperatures can cause deposits to
become baked on to the
PerfectClean surfaces and become
impossible to remove.

If, after manual cleaning, the oven is
still heavily soiled, heating it to a high
temperature will help remove further
soiling caused by oil and grease
splashes from the catalytic surfaces.

Note that deposits of spices, syrups
and similar substances are not
removed by this process. These should
be removed while fresh by hand with a
mild solution of hot water and
washing-up liquid applied with a soft
brush.

Take all accessories out of the oven.

^

Turn the oven selector to Fan plus

^

Y.
Turn the temperature selector to the

^

highest setting.
Run the oven for approx. 1 hour. The

^

length of time will depend on the
level of soiling.

On ovens with a clock/timer it is a good
idea to set the finish time for the
process using the timer. This way you
will not forget to switch the oven off at
the end.

Any remaining soiling will gradually
disappear with each subsequent use of
the oven at high temperatures.

Should the catalytic enamelling on
the back panel, side panels or the
roof liner become ineffective through
improper use or heavy soiling, a
replacement can be obtained from
your Miele dealer or the Miele Spare
Parts dept.

53

Cleaning and care

Oven interior

To make cleaning easier you can

remove the oven door,

–

dismantle the oven door,

–

take out the runners,

–

and take out the back panel, side

–

liners (if fitted) and roof liner.

To remove the oven door

Please note: the oven door is heavy.
It should be gripped firmly at the
sides when being removed or
refitted.

The oven door is connected to the oven
by hinges.

Open the door fully.

^

To release the locking clamps on the

^

hinges turn them upwards as far as
they will go until they are at an angle.
See illustration.

Do not attempt to take the door off
the hinge guides when it is in a
horizontal position. The guides will
close, and damage the appliance.
Danger of injury.

^ Then lift the door upwards as far as it

will go.

Before removing the door, the locking
clamps on both hinges have to be
released.

54

^ Hold the door securely at both sides

and lift upwards off the hinge guides.

Do not lift the door off by the handle.
The handle could break and
damage the glass.

Make sure that you lift the door off
equally on both sides.

Cleaning and care

To dismantle the oven door

The oven door has seals on all sides to
protect it from moisture ingress.

If, however, condensate has worked its
way in between the glass panes, the
door can be dismantled in order to
clean in between the panes.

Do not use scouring agents, hard
sponges or brushes to clean the
glass panes.
These could damage the surface.

Do not use an oven spray. This will
damage the surface of the
aluminium surrounds.

Ensure that the glass panes are
inserted the correct way round after
cleaning as each side of the pane
has a different coating. Those facing
the oven interior have a
heat-reflective coating.

To avoid the risk of breakage, it is
advisable to place the panes on a
table protected by a soft cloth (e.g.
a towel).

55

Cleaning and care

Always remove the oven door before
dismantling it.

Place the door on a protective

^

surface (e.g. on a table cloth) to
prevent it getting scratched. The
door handle should line up with the
edge of the table. Make sure the
glass lies flat and does not get
broken during cleaning.

Gently lift the inner pane up and out.

^

^

Unscrew the Torx screws, and
remove the guides, trim and seal.

56

^

Pull the pane forwards to remove it.

Take care when doing this to prevent
loosening the sealing strips which are
fixed to the top end of the pane on the
right and left near the guides. These
sealing strips prevent the pane slipping
when it is in its frame.

Clean the glass panes and other

^

parts and then put the oven door
back together again.

^ Push the middle pane into the frame

almost to the end. The material (M-)
number printed on the pane must be
legible in the bottom right hand
corner (see illustration). Fit the
sealing strip into position, then push
the pane in as far as it will go.

Cleaning and care

Fit the side seals for the inner pane in

^

the grooves provided.

^

Insert the inner pane with the printed
text facing downwards.
Be careful that the side seals do not
slip and that the pane is pushed in as
far as possible.

57

Cleaning and care

^ Fit the trim with the seal in front of the

glass panes.

Make sure that the seal is sitting
correctly to prevent any steam
penetrating inside the door.

To refit the door

^ Hold the door securely at both sides

and carefully fit it back onto the hinge
guides.

^

Put the guides back in position, then
tighten the screws in the trim.

58

Make sure that the door goes back
on straight.

Cleaning and care

Open the door fully.

^

Flip both locking clamps back up as

^

far as they will go into a horizontal
position.
Make sure that the notches on the
locking clamps hook into the slots on
the door as illustrated.

It is essential that the locking clamps
lock securely when the door is
re-fitted after cleaning. Otherwise
the door could work loose from the
hinges, resulting in damage to the
door.

To remove the runners

Make sure the oven heating
elements are switched off and cool.
Danger of burning.

^ Pull on the fixing knob to release it.

^

Remove the runners.

Reassemble in the reverse order,
carefully ensuring all parts are correctly
in place.

59

Cleaning and care

To remove the catalytic back panel,
side liners (if fitted) and roof liner

Make sure the oven heating
elements are switched off and cool.
Danger of burning.

The catalytic panels and liners can be
removed for cleaning if necessary.

– Back panel

Remove the runners.

^

^ Loosen the screws in the back panel

and take it out.

– Roof liner

Remove the runners.

^

Unscrew the wing nut.

^

Lower the top heating element
carefully. Do not use force to pull it
down as this can cause the element
to break.

^ Take out the roof liner.
Reassemble in the reverse order,

carefully ensuring all parts are correctly
in place.

The oven must not be used without
the back panel fitted.
This could cause considerable
injury.

Reassemble in the reverse order,
carefully ensuring all parts are correctly
in place.

60

– Side liners

(depending on model)

^

Remove the runners.

^

Lift the side liners up slightly before
removing them.

Reassemble in the reverse order,
carefully ensuring all parts are correctly
in place.

When reassembling the catalytic side
liners, ensure they sit correctly.

^ Ease the back lug into the opening in

the rear wall panel.

Cleaning and care

^

Lift the front locating hole on to the
guide pin behind the collar.

^

Put the runners back into place.

61

Problem solving guide

Installation, maintenance and repairs
may only be carried out by suitably
qualified and competent persons in
accordance with local and national
safety regulations.
Repairs and other work by
unqualified persons could be
dangerous, and the manufacturer
will not be held liable for
unauthorised work.

Some minor problems can be corrected
without contacting the Miele Service
Department.

What to do if . . .

. . . the oven does not heat up

Check whether,
^ the function selector and the

temperature selector have been set
at the function and temperature
required.

Light in the roof:

^ Unscrew the lamp cover and the

seal.

^ Change the lamp.

When purchasing a new lamp, take
the old one with you to make sure
you obtain the correct replacement
(230 V, 25 W, E 14, heat resistant to
300 °C).

^ Screw the lamp cover and the seal

back on again.

^

the mains fuse has blown. If it has,
contact a qualified electrician or the
Miele Service Department.

. . the heating works but not the oven

lighting

The lamp needs changing.

^

Disconnect the appliance from the
electricity supply. Switch off and
unplug at the socket, or remove the
fuse, or switch off at the isolator as
appropriate.

Depending on model, the light is either
in the oven roof or in the right side wall.

62

Reassemble in the reverse order,
carefully ensuring all parts are correctly
in place.

Problem solving guide

Light in the side wall:

Remove the runners and side liners

^

(if fitted).

^ Lift the lamp cover from its retainers.
^ Change the lamp.

When purchasing a new lamp, take
the old one with you to make sure
you obtain the correct replacement
(230 V, 25 W, E 14, heat resistant to
300 °C)

^ Push the lamp cover back into its

retainers, and replace the runners
and side liners (if fitted).

Reassemble in the reverse order,
carefully ensuring all parts are correctly
in place.

...a noise can be heard after baking,
roasting or grilling

This is not a fault.
The cooling fan continues to run for a
while after the oven has been switched
off to prevent any humidity building up
in the oven, on the control panel or on
the oven housing unit. When the
temperature has fallen sufficiently, the
fan switches off automatically.
It will switch off sooner if the oven door
is opened partially or fully.

. . . cakes and biscuits are not cooked
properly after following the times
given in the chart

Check whether,

^ the correct temperature was set.
^ there has been a change to the

recipe. The addition of more liquid or
more eggs makes a moister mix
which would need longer to cook.

^ the roasting filter was left in front of

the fan when baking with Fan
plus Y. If this was the case, baking
times might need to be lengthened
by approx. 10 to 15 minutes.

63

Problem solving guide

. . . cakes or biscuits are unevenly
browned

There will always be a slight
unevenness. Product information
sheets give a percentage result for
standard browning tests. These refer to
results for one tray.

If browning is very uneven, check
when baking with Fan plus Y:

whether the temperature was set too

–

high,
whether the roasting filter was in

–

place,

– whether the correct shelf level was

used.

when baking with Conventional A:
– the colour and composition of the

baking tins being used. Light
coloured, shiny, or thin walled tins
are less suitable,

– whether the correct shelf level was

used.

. . . spots like rust appear on the
catalytic surfaces

When roasting on the rack, the
circulating air sometimes picks up
spices, which are then deposited on
the oven interior walls. These residues
are not removed by catalytic cleaning,
and should be removed while fresh with
a mild solution of hot water and
washing up liquid applied with a soft
brush.

. . . there has been a power cut and
instead of the time of day, "I2:00" and
triangle V underneath the m symbol
are flashing in the clock/timer display

All pre-set times have been deleted
because of the power cut.

^ Enter the time of day again, and any

other pre-set data.

..."0:00" appears in the clock/timer
display when the Q button has been
used to switch off the buzzer

This is not a fault.
The time of day will reappear shortly.

64

After sales service

In the event of any faults which you
cannot remedy yourself, please contact

your Miele Dealer

–
or

the Miele Service Department

–

(see back cover for contact details).

When contacting your Dealer or the
Service Department, please quote the
model and serial number of your
appliance.

These are shown on the data plate,
visible below the oven interior, with the
door fully open.

For appliances with hob controls,
please also quote the model and serial
number of your hob.

Please note that telephone calls may
be monitored and recorded to
improve our service.

65

Extra accessories

The following accessories are available
at extra cost from your Miele dealer or
the Miele Spare Parts Department.

Telescopic baking carriage

The telescopic baking carriage with 4
shelf levels can be drawn right out of
the oven giving a good overview of
cooking in progress.

Telescopic runners

The telescopic runners provide three
shelf levels.
Each shelf level can be drawn right out
of the oven individually to give a good
overview of cooking in progress.

Pizza pan

66

This circular pan is suitable for cooking
pizzas, flat cakes made with yeast or
whisked mixtures, sweet and savoury
tarts, baked desserts, and can also be
used for deep frozen cakes and pizzas.

Extra accessories

Baking stone

The baking stone is ideal for items
which need a well baked base such as
pizza, quiche, bread, bread rolls and
savoury snacks.

The baking stone is made from heat
retaining fire brick and is glazed.
Place it directly on the rack.

A paddle made of untreated wood is
supplied with it for placing food on the
baking stone and taking it off.

Gourmet oven dish

It is available in two sizes:
HUB 61-22:

W x D x H = 38 x 22 x 8.6 cm

for 8-10 servings

HUB 61-35:
W x D x H = 38 x 35 x 8.6

for 16-20 servings

A lid is available separately.

Catalytic side liners

These are fitted behind the runners in
the sides of the oven and help keep the
oven walls clean.

When ordering please state the model
number of your oven and whether it is
fitted with side runners, telescopic
runners or a baking carriage.

The gourmet oven dish can be placed
in the oven directly on the runners. It
has non-tip safety notches like the oven
tray to prevent it being pulled out too
far.
The dish has a special protective
anti-stick coating.

67

Electrical connection UK, IRL, ZA

For extra safety it is advisable to install
All electrical work should be
undertaken by a suitably qualified
and competent person in strict
accordance with national and local
safety regulations.
Installation, repairs and other work
by unqualified persons could be
dangerous. The manufacturer
cannot be held liable for
unauthorised work.
Ensure power is not supplied to the
appliance until after installation or
repair work has been carried out.

a residual current device with a trip

current of 30 mA (in accordance with

DIN VDE 0664, VDE 0100 Section 739).

When switched off there must be an

all-pole contact gap of 3 mm in the

isolator switch (including switch, fuses

and relays acc. to EN 60 335).

Important U.K.

This appliance is supplied with a 3-core

cable for connection to a single phase

230-240 V 50 Hz supply.

The voltage and connected load are
given on the data plate, visible below
the oven interior, with the oven door
open. Ensure that these match the
household mains supply. Please quote
these data, and the model and serial
number when contacting the Miele Ser­vice dept.

Connection of this appliance should be
made via a suitable isolator, which
complies with national and local safety
regulations, and the on/off switch
should be easily accessible after the
appliance has been built in.

If the switch is not accessible after
installation (depending on country) an
additional means of disconnection must
be provided for all poles.

The wires are coloured in accordance

with the following code:

Green/yellow = earth

Blue = neutral

Brown = live

In other countries check these details

with your supplier.

WARNING

THIS APPLIANCE MUST BE

EARTHED

68

Electrical connection UK, IRL, ZA

Cooker with integrated hob controls

"E" model

This is not available in all countries.

For some countries the version of the

cooker with integral hob controls is

supplied for connection to a 3N ~ 400 V

power supply.

Any adaptations must only be carried

out in consultation with the relevant

Miele Service Dept.

Possible combinations:

Miele built-in cookers may only be

combined with hobs and their

respective control units as specified by

Miele for use with that cooker.

Contact your Miele Dealer for further

information on suitable combinations.

69

Electrical connection UK, IRL, ZA

IRL

The voltage and rated load are given
on the data plate, visible when the oven
door is open. Please ensure that these
match the household mains supply.

The appliance is supplied with a 3-core
cable for connection to a 230-240 volt
50 Hz supply.

The fuse rating is 32 amps for the
"E"-model with hob.

The fuse rating is 16 amps for the
"B"-model.

The wires are coloured in accordance
with the following code:

Green/yellow = earth
Blue = neutral
Brown = live

ZA

Data relating to electrical connection

will be found on the data plate, visible

when the oven door is open. Make sure

that these figures comply with the main

voltage. Connection should be made

via a suitable isolator which complies

with national and local regulations.

The appliance is supplied with a 3-core

cable for connection to a 230-240 volt

50 Hz supply.

The fuse rating is 20 amps for the

"B"-model.

The wires are coloured in accordance

with the following code:

Green/yellow = earth

Blue = neutral

Brown = live

WARNING
THIS APPLIANCE MUST BE
EARTHED.

70

WARNING

THIS APPLIANCE MUST BE

EARTHED.

Electrical connection AUS,NZ

All electrical work should be
undertaken by a competent person
in strict accordance with national
and local safety regulations.

The voltage and rated load are given
on the data plate, visible when the oven
door is open. Please ensure that these
match the household mains supply.
Please quote these data, and the model
and serial number when contacting the
Miele Service dept.

Connection of this appliance should be
made via a suitable isolator which
complies with national and local
regulations, and which is accessible
after the appliance has been built in.

Connection diagram

WARNING
THIS APPLIANCE MUST BE
EARTHED.

Test marks . . . . . . . . . . Electrical safety

. . . . . . . . . . . . . . . . . . . . . . C-Tick Mark

Electrically suppressed

according to. . . . . . . . . . . AS/NZS 1044

71

Electrical connection AUS,NZ

AUS:

Underbench oven

The underbench oven is suitable for
connection to an a.c. single phase
240 V, 50 Hz electricity supply.

The minimum fuse rating according to
"maximum demand" is 32 amps with
hob.

Possible combination:

Miele underbench ovens may only be
combined with hobs as specified by
Miele for use with that oven.

Wall oven

The wall oven is suitable for connection
to an a.c. single phase 240 V, 50 Hz
electricity supply.

The fuse rating is 16 A.

NZ:

Underbench oven

The underbench oven is suitable for

connection to an a.c. single phase

230 V, 50 Hz electricity supply.

The minimum fuse rating according to

"maximum demand" is 32 amps with

hob.

Possible combination:

Miele underbench ovens may only be

combined with hobs as specified by

Miele for use with that oven.

Wall oven

The wall oven is suitable for connection

to an a.c. single phase 230 V, 50 Hz

electricity supply.

The fuse rating is 16 A.

72

Installing the cooker

The oven must be built in before it
can be used. Otherwise it poses an
electric shock hazard.

Important: Do not fit insulation
material inside housing unit. This
would hinder the intake of air to the
appliance.

Before connecting the appliance to
the mains you must disconnect the
power supply to the cooker point.
Follow the connection diagram
supplied with the cooker.

Connect the cooker cable to the

^

isolator.
Align the cooker in front of the base

^

unit.
Connect the hob plugs to the socket

^

on the cooker.

^ Push the appliance into the base unit

and align it.

^

Open the appliance door, and use
two screws to secure it to the side
walls of the housing unit through the
holes in the trim.

^

Reconnect the power supply to the
isolator switch.

73

Installing the oven

The appliance must not be operated
until it has been correctly installed in
its housing unit. Otherwise it poses
an electric shock hazard.

Important: Do not fit insulation
material inside the housing unit. This
would hinder the intake of air to the
appliance.

Turn off the mains electricity supply
to the isolator.

Connect the mains cable to the

^

isolator.
Push the appliance into the oven

^

housing unit and align it.

74

^

Open the oven door and using two
screws secure it to the side walls of
the housing unit through the holes in
the oven trim.

^

Reconnect the power supply to the
isolator switch.

75

Alteration rights reserved / 22 / 2504

(H 4120, H 4220, H 4130, H 4230, H 4140, H 4240, H 4150, H 4250, H 4160, H 4260)

This paper consists of cellulose which has been bleached without the use of chlorine.

M.-Nr. 06 234 900 / 00

en-GB
