11-600001B MAC 10-10 12/70 to 05/72 IPL 92374 Page 1 of 19
www.ktoutdoor.com
Accessories
K&T Saw Shop 606-678-9623 or 606-561-4983
11-600001B MAC 10-10 12/70 to 05/72 IPL 92374 Page 2 of 19
www.ktoutdoor.com
Accessories
Ref # Part Number DescriptionQty
63541 Bar - 16" Mac 10
62556N Chain Asy - 16" PM 358
86780N Chain Asy - 16" PM 378
87143N Chain Asy - 16" SM 378
89909N Chain Asy - 16" SPR 378G
89502 Bar - 16" Mac 10
89521N Chain Asy - 16" PM 350
91090A Bar - 16" Sprocket Nose
87301N Chain Asy - 16" SM 370
88167N Chain Asy - 16" PM 370G
69210 Piston Asy - .020 in. oversize
62813 Ring Set - Piston .020 in. oversize
69211 Piston Asy - .030 in. oversize
62812 Ring Set - Piston .030 in. oversize
84453 Kit - Piston Tool
86330 Kit - Spike
102388 Screw - Hx hd 10-24 x 5/8
101191 Nut - Hx 10-24
90258 Kit - Tune Up
86419 Guide - Timing
69191 Kit - Pressure Test Adapter
91226 Wrench - Flywheel
63746 Wrench/Screwdriver
68863 Kit - Pancake Reed Muffler
89431 Kit - Spark Arrester Screen
85933 Kit - Spark Arrester Screen
63097 Spark Plug (Standard)
63432 Spark Plug (Cooler)
92896 Guard - Bar 16"
93284 Case - Carrying
K&T Saw Shop 606-678-9623 or 606-561-4983
11-600001B MAC 10-10 12/70 to 05/72 IPL 92374 Page 3 of 19
www.ktoutdoor.com
Carburetor Assembly
K&T Saw Shop 606-678-9623 or 606-561-4983
11-600001B MAC 10-10 12/70 to 05/72 IPL 92374 Page 4 of 19
www.ktoutdoor.com
Carburetor Assembly
Ref # Part Number DescriptionQty
85720 Carburetor Assy1
1 67501 Screw - Pump cover4
2 83760 Cover - Pump1
3 67495 Gasket - Cover1
4 67498 Diaphragm - Check valve1
5 83114 Diaphragm - Fuel pump1
6 47690 Screw - Plate3
7 83762 Plate - Throttle1
8 67489 Clip - Shaft1
9 67486 Shaft Assy - Throttle1
10 85981 Spring - Throttle shaft1
11 67490 Plate - Choke1
12 67488 Shaft Assy - Choke1
13 100302 Ball - Choke friction1
14 67504 Spring - Choke friction1
15 68104 Needle - High speed1
16 68105 Needle - Idle1
17 68106 Screw - Idle speed1
18 67502 Spring - Needle1
19 70798 Screw - Diaphragm cover4
20 83761 Cover - Diaphragm1
21 67499 Diaphragm - Metering1
22 67496 Gasket - Diaphragm1
23 67500 Screw - Lever pin1
24 67508 Pin - Lever1
25 67509 Lever - Metering1
26 67503 Spring - Lever1
27 67491 Valve - Needle1
28 71690 Plug - 3/81
29 69506 Plug - 5/161
30 83758 Kit - Valve & Seat Assy1
31 67507 Screen - Fuel1
67482 Gasket Set
83764 Repair Kit
K&T Saw Shop 606-678-9623 or 606-561-4983
11-600001B MAC 10-10 12/70 to 05/72 IPL 92374 Page 5 of 19
www.ktoutdoor.com
Chain Brake Assembly
K&T Saw Shop 606-678-9623 or 606-561-4983
11-600001B MAC 10-10 12/70 to 05/72 IPL 92374 Page 6 of 19
www.ktoutdoor.com
Chain Brake Assembly
Ref # Part Number DescriptionQty
91278 CHAIN BRAKE Assembly1
1 102500 Screw - Pan hd 10-24 x 1/21
2 91273 Washer - Special1
3 91251A Lever Assembly1
4 91239 Spring1
5 91235A Latch Assembly1
6 105738 Screw - Skt hd 1/4-20 x 7/81
7 91274 Washer - Special2
8 91238A Band1
9 91249 Housing Assembly1
10 110527 Screw - Fil hd 10-24 x 2-3/41
11 110264 Washer - #101
12 61705 Nut - Bar adjusting1
13 100002 Washer - #101
14 102067 Nut - Hx 10-241
15 91246 Pin - Lever pivot1
16 91245 Washer - Thrust1
K&T Saw Shop 606-678-9623 or 606-561-4983
