OWNER'S MANUAL

FRIDGE&

FREEZER

Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times.

EN	ENGLISH	ES	ESPAÑOL	IT	ITALIANO	PL	POLSKI	SR	SRPSKI
BG	БЪЛГАРСКИ	ET	EESTI	LT	LIETUVIŲ	PT	PORTUGUÊS	SV	SVENSKA
CZ	ČEŠTINA	FI	SUOMI	LV	LATVIEŠU	RO	ROMÂNĂ
DA	DANSK	FR	FRANÇAIS	MK	МАКЕДОНСКИ	SK	SLOVENČINA
DE	DEUTSCH	HR	HRVATSKI	NL	NEDERLANDS	SL	SLOVENŠČINA
EL	ΕΛΛΗΝΙΚΆ	HU	MAGYAR	NO	NORSK	SQ	SHQIP

www.lg.com

MFL70584311	Refer to the owner's manual on LG website for more detailed information.
Rev.01_150219	Copyright © 2019 LG Electronics Inc. All Rights Reserved
	Copyright © 2019 LG Electronics Inc. All Rights Reserved

TABLE OF CONTENTS	This manual may contain images or
	content different from the model you
	purchased.
	This manual is subject to revision by the
	manufacturer.
SAFETY INSTRUCTIONS .......................................................		3
IMPORTANT SAFETY INSTRUCTIONS....................................................		3
INSTALLATION ......................................................................		10
Dimensions and Clearances.....................................................................		10
Ambient Temperature ...............................................................................		10
OPERATION ...........................................................................		11
Notes for Operation ..................................................................................		11
Fresh Converter ( * ).................................................................................		12
Fresh Vegetable Drawer ( * )	....................................................................	12
SMART FUNCTIONS .............................................................		13
Using LG SmartThinQ Application............................................................		13
Using Smart Diagnosis™ .........................................................................		14
MAINTENANCE......................................................................		15
Notes for Cleaning....................................................................................		15
Disposal of Your Old Appliance ................................................................		15

SAFETY INSTRUCTIONS

The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance.

The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below.

This symbol is displayed to indicate matters and operations that can cause risk. Read the part with this symbol carefully and follow the instructions in order to avoid risk.

WARNING

This indicates that the failure to follow the instructions can cause serious injury or death.

CAUTION

This indicates that the failure to follow the instructions can cause the minor injury or damage to the product.

IMPORTANT SAFETY INSTRUCTIONS

WARNING

To reduce the risk of explosion, fire, death, electric shock, injury or scalding to persons when using this product, follow basic precautions, including the following:

Children in the Household

••This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

••If the appliance is equipped with a lock (some models only), keep the key out of reach of children.

For use in Europe:

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

Installation

••This appliance should only be transported by two or more people holding the appliance securely.

••Ensure that the socket outlet is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre.

••This appliance is equipped with a power cord having an equipment-grounding conductor and a grounding power plug. The power plug must be plugged into an appropriate socket outlet that is installed and grounded in accordance with all local codes and ordinances.

••If the power cord is damaged or the hole of the socket outlet is loose, do not use the power cord and contact an authorized service centre.

••Do not plug the appliance into a multi socket adapter which does not have a power cable (mounted).

••Do not modify or extend the power cable.

••The appliance should be connected to a dedicated power line which is separately fused.

••Do not use a multi socket outlet which is not properly grounded (portable). In case of using a properly-grounded multi socket outlet (portable), use the multi socket outlet with the current capacity of the power code rating or higher and use the multi socket outlet only for the appliance.

••Install the appliance in a place where is easy to unplug the power plug of the appliance.

••Be careful not to point the power plug up or let the appliance lean against the power plug.

••Install the appliance on a firm and level floor.

••Do not install the appliance in a damp and dusty place. Do not install or store the appliance in any outdoor area, or any area that is subject to weathering conditions such as direct sunlight, wind, rain, or temperatures below freezing.

••Do not place the appliance in direct sunlight or expose it to the heat from heating appliances such as stoves or heaters.

••Be careful not to expose the rear of the appliance when installing.

••Be careful not to let the appliance door fall during assembly or disassembly.

••Be careful not to pinch, crush, or damage the power cable during assembly or disassembly of the appliance door.

••Do not connect a plug adapter or other accessories to the power plug.

Operation

••Do not use the appliance for any purpose (storage of medical or experimental materials or shipping) other than any domestic household food storage use.

••Unplug the power plug during a severe thunderstorm or lightening or when not in use for a long period of time.

••Do not touch the power plug or the appliance controls with wet hands.

••Do not bend the power cable excessively or place a heavy object on it.

••If water penetrates electrical parts of the appliance, disconnect power plug and contact an LG Electronics customer information centre.

••Do not place hands or metallic objects inside the area emitting the cold air, cover or heat releasing grille on the back.

••Do not apply excessive force or impact to the back cover of the appliance.

••Do not put animals, such as pets into the appliance.

••Be careful of nearby children when you open or close the appliance door. The door may bump the child and cause injury.

••Avoid the danger of children getting trapped inside the appliance. A child trapped inside the appliance can cause suffocation.

••Do not place heavy or fragile objects, containers filled with liquid, combustible substances, flammable objects (such candles, lamps, etc.), or heating devices (such as stoves, heaters, etc.) on the appliance.

••If there is a gas leakage (isobutane, propane, natural gas, etc.), do not touch the appliance or power plug and ventilate the area immediately. This appliance uses a refrigerant gas

(isobutane,R600a). Although it uses a small amount of the gas, it is still combustible gas. Gas leakage during appliance transport, installation or operation can cause fire, explosion or injury if sparks are caused.

••Do not use or store flammable or combustible substances (ether, benzene, alcohol, chemical, LPG, combustible spray, insecticide, air freshener, cosmetics, etc.) near the appliance.

••Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.

••Fill with potable water only into icemaker or dispenser water tank.

••Do not damage the refrigerant circuit.

••Do not place any electronic appliance (such as heater and mobile phone) inside the appliance.

Maintenance

••Disconnect the power cord before cleaning the appliance or replacing the inside lamp (where fitted).

••Securely plug the power plug in the socket outlet after completely removing any moisture and dust.

••Never unplug the appliance by pulling on the power cable. Always grip the power plug firmly and pull straight out from the socket outlet.

••Do not spray water or inflammable substances (toothpaste, alcohol, thinner, benzene, flammable liquid, abrasive, etc.) over the interior or exterior of the appliance to clean it.

••Do not clean the appliance with brushes, cloths or sponges with rough surfaces or which are made of metallic material.

••Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.

••Do not use a hair drier to dry the inside of the appliance or place a candle inside to remove the odours.

••Do not use mechanical devices or other means to accelerate the defrosting process.

Disposal

•When discarding the appliance, remove the door gasket while leaving the shelves and baskets in place and keep children away from the appliance.

•Dispose of all packaging materials (such as plastic bags and styrofoam) away from children. The packaging materials can cause suffocation.

Technical Safety

•Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

•Do not use electrical appliances inside the refrigerator.

•The refrigerant and insulation blowing gas used in the appliance require special disposal procedures. Consult with service agent or a similarly qualified person before disposing of them.

•Refrigerant leaking out of the pipes could ignite or cause an explosion.

•The amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance.

•Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.

•This appliance is intended to be used in household and similar applications only. It should not be used for commercial, or catering purposes, or in any mobile application such as a caravan or boat.

•Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

Risk of Fire and Flammable Materials

This symbol alerts you to flammable materials that can ignite and cause a fire if you do not take care.

•This appliance contains a small amount of isobutane refrigerant (R600a), but it is also combustible. When transporting and installing the appliance, care should be taken to ensure that

no parts of the refrigerating circuit are damaged.

•If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes. In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance is used should correspond to the amount of refrigerant used. The room must be 1 m² in size for every 8 g of R600a refrigerant inside the appliance.

•When positioning the appliance, ensure the supply cord is not trapped or damaged.

•Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.

CAUTION

To reduce the risk of minor injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following:

Installation

•Do not tilt the appliance to pull or push it when transporting.

•Make sure not to get a body part such as a hand or foot stuck while moving the appliance.

Operation

•Do not touch frozen food or the metal parts in the freezer compartment with wet or damp hands. It may cause frostbite.

•Do not place glass containers, bottles or cans (especially those containing carbonated drinks) in the freezer compartment, shelves or ice bin that will be exposed to temperatures below freezing.

•The tempered glass on the front side of the appliance door or the shelves can be damaged by an impact. If it is broken, do not touch it with hands.

•Do not hang from the appliance doors, storage room, shelf or climb up into it.

•Do not store an excessive amount of water bottles or containers for side dishes on the door baskets.

•Prevent animals from nibbling on the power cable or water hose.

•Do not open or close the appliance door with excessive force.

•If the hinge of the appliance door is damaged or operates improperly, stop using the appliance and contact an authorized service centre.

•Do not clean glass shelves or covers with warm water when they are cold.

•Never eat frozen foods immediately after they have been taken out in the freezer compartment.

•Make sure not to get a hand or foot stuck upon opening or closing the appliance door.

Maintenance

•Do not insert the shelves upside down. The shelves may fall.

•To remove frost from the appliance, contact an LG Electronics customer information centre.

INSTALLATION

Dimensions and Clearances

Too small of a distance from adjacent items may result in the degradation of freezing capability and increased electricity costs. Allow over 50 mm of clearance from each adjacent wall when installing the appliance.

G F E

B
	H
C	Type A
C

G F E

Type B

			Type A				Type B
	Pocket Handle			Bar Handle		Pocket Handle		Bar Handle
					Size [mm]
A	595	595		595	595	595	595	595	595
B	1860	2030		1860	2030	1860	2030	1860	2030
C	675	675		712	712	682	682	718	718
D	9	9		9	9	15	15	15	15
E	667	667		667	667	667	667	667	667
F	-	-		703	703	-	-	703	703
G	1124	1124		1124	1124	1130	1130	1130	1130
H	995	995		995	995	995	995	995	995

Ambient Temperature

•The appliance is designed to operate within a limited range of ambient temperatures, depending on the climate zone.

•The internal temperature could be affected by the location of the appliance, the ambient temperature, the frequency of door opening and so on.

•The climate class can be found on the rating label.

Climate Class	Ambient Temperature Range ºC
SN (Extended Temperate)	+10	- +32
N (Temperate)	+16	- +32
ST (Subtropical)	+16	- +38
T (Tropical)	+16	- +43 / +10 - +43*

*Australia, India, Kenya

NOTE

The appliances rated from SN to T are intended to be used at an ambient temperature between 10 ºC and 43 ºC.

OPERATION

Notes for Operation

•Users should keep in mind that frost can form. If the door is not closed completely, if the humidity is high during the summer, or if the freezer door is opened frequently.

•Ensure there is sufficient space between food stored on the shelf or door basket to allow the door to close completely.

•Opening the door lets warm air enter the appliance, and may cause the internal temperature to rise.

•If you are leaving the appliance turned off for an extended period of time, remove all food and unplug the power cord. Clean the interior, and leave the doors slightly ajar to prevent mold from growing in the appliance.

•Avoid refreezing any food which has been completely thawed. Freezing any food which has been completely thawed again will lower its taste and nutrition.

•Do not wrap and store vegetables with newspaper. Printing material of newspaper or other foreign substances may smear and contaminate food.

•Do not overfill the appliance.Cold air can not circulate properly if the appliance is overfilled.

•If you set an excessively low temperature for food, it may become frozen. Do not set a temperature lower than the required temperature for the food to be stored correctly.

•For more space, you can remove bottle rack, egg tray, ice tray and fresh converter drawer.

Suggestion for Energy Saving

•Ensure there is sufficient space between stored foods. This allows cold air to be circulated evenly and lowers electricity bills.

•Store hot food only after it has cooled in order to prevent dew or frost.

•When storing food in the freezer compartment, set the freezer temperature lower than the temperature indicated on the food.

•Do not put food near the temperature sensor of the fridge compartment. Keep a distance of at least 3 cm from the sensor.

•Note that a temperature rise after defrosting has a permissible range in the appliance specifications. If you wish to minimise the impact this may have on the food storage due to a temperature rise, seal or wrap the stored food in several layers.

•The automatic defrosting system in the appliance ensures that the compartment remains free of ice buildup under normal operating conditions.

Storing Foods Effectively

•Store frozen food or refrigerated food inside sealed containers.

•Check the expiration date and label (storage instructions) before storing food in the appliance.

•Do not store food for a long period of time

(more than four weeks) if it spoils easily at a low temperature.

•Place the refrigerated food or frozen food in each fridge or freezer compartment immediately after purchasing.

Max Freezing Capacity

•The Express Freeze function will set the freezer to its maximum freezing capacity.This generally takes up to 24 hours and automatically switches off.

•If the maximum freezing capacity is to be used, Express Freeze must be switched on for seven hours before fresh produce is placed in the freezer compartment.

Maximum Storage

•To get better air circulation, insert all drawers.

•If large quantities of food are to be stored, all the freezer drawers shall be taken out of the appliance and the food shall be stacked directly on the freezer shelves in the freezer compartment.

NOTE

•To remove the drawers, first pick the food out of drawers. Then use the handle of drawers, pull out the drawers carefully. It may cause injury.

•The shape of each drawer may be different, insert in the right position.

Setting the Temperature

This sets the fridge temperature or freezer temperature.

•Press the Fridge button or Freezer button to adjust the temperature.

•The temperature can be adjusted.

−Fridge : from 1 °C to 7 °C

−Freezer : from -15 °C to -23 °C

•The initial temperature is set.

−Fridge : 3 °C

−Freezer : -18 °C

The actual inner temperature varies depending on the food status, as the indicated setting temperature is a target temperature, not actual temperature within the appliance.

NOTE

•The default temperature setting may vary depending on the appliance.

•Wait until 2 or 3 hours have passed after connecting the appliance to the outlet before storing food in the appliance.

•For ice making in normal climates, the freezer temperatures should be set to -18 °C or colder.

High Temperature Alarm

When the freezer temperature goes too high due to power failure, the freezer temperature LED lamp blinks and an alarm sounds.

•Press the Freezer button to stop.

•If the temperature is sufficiently cold, the blinking and alarm will automatically stop.

•This function operates:

−When the refrigerator is turned on.

−When the freezer compartment gets too warm.

−When there is a power outage that lasts for a long period of time.

−When large amounts of warm food are placed in the freezer compartment.

−When the freezer door is left open for too long or too frequently.

Fresh Converter ( * )

As a chill compartment, the temperature in the fresh converter can be controlled by sliding the lever 1 , where located in front of compartment, in either direction.

When keeping vegetables after setting up Meat or Fish, the cold injury may occur.

2For storing vegetables.(Recommended)

3For storing fish.

4For storing meat.

NOTE

•( * ) : This feature varies depending on the model purchased.

Fresh Vegetable Drawer ( * )

Vegetable compartment can adjust the humidity by moving the knob 1 .

2For storing vegetables.(Recommended)

3For storing fruit.

NOTE

•( * ) : This feature varies depending on the model purchased.

+ 27 hidden pages
