1
LCD
display
Function
keys
WIRELESS 915 MHz WEATHER STATION
Hanging
hole
Battery
compartment
Foldout
stand
WS-9257U-IT
INTRODUCTION
Congratulations on purchasing this weather station with wireless 915 MHz transmission of outdoor
temperature/humidity, and display of indoor temperature/humidity and air pressure. It also
functions as a normal clock with calendar display and alarm setting. In addition, weather forecast,
sunrise/ sunset time as well as the moon phase are shown. This innovative product is ideal for use
in the home or office.
FEATURES
The weather station
Instruction Manual
2
12 hour time display (seconds displayed by pressing the SUN key)
Weekday, date and month display (year only in setting mode)
Daylight saving time (DST) function selectable
Daily alarm function
Weather forecast with weather tendency indicator
Temperature display in degree Fahrenheit (°F)
Indoor temperature display with MIN/MAX recordings
Outdoor temperature display with MIN/MAX recordings, time and date
All MIN/MAX recordings can be reset
Indoor and outdoor humidity display in RH%
Display of relative or absolute air pressure
Relative air pressure inHg with adjustable reference value
Relative air pressure history for the past 12 hours
Display of sunrise time, sunset time and sun duration time in 93 USA cities and 6 Canadian
cities
Display 8 moon phase icons with indicator throughout the year
LCD contrast setting
Low battery indicators
Table standing/wall mounting
3
The outdoor thermo-hygro transmitter
Remote transmission of outdoor temperature and humidity to weather station
by 915 MHz
Alternately display the outdoor temperature and humidity on LCD
Wall mounting case
Mounting at a sheltered place. Avoid direct rain and sunshine
INITIAL SET UP
DO NOT MIX OLD AND NEW BATTERIES.
DO NOT MIX ALKALINE, STANDARD, OR RECHARGEABLE BATTERIES
1. Insert the batteries into the Temperature transmitter. Keep the transmitter 5-10 feet
from the Weather Station during set up.
2. Within 45 seconds, insert batteries into the Weather Station. Once the batteries are
in place all segments will light up briefly. The time will be displayed as 12:00. If this
is not displayed within 80 seconds, remove the batteries from both units for 2
minutes and start again from step 1.
3. The weather station will start receiving data from the transmitter. The outdoor
temperature and signal reception icon will be displayed. If this is not displayed
4
within 80 seconds, remove the batteries from both units for 2 minutes and start
again from step 1.
4. Allow the weather station and the transmitter to remain 5-10 feet apart for 15
minutes after set up to establish a strong connection.
5. To ensure sufficient 915 MHz transmission after set up, the distance between the
transmitter mounted outside and the weather station inside should not exceed 330
feet (100 meters) distance (open air, no obstructions).
6. Test the weather station and the transmitter in the positions they will be located for one
hour before permanently mounting. If the outdoor temperature signal goes to dashes restart
from step 1 and try a new location.
HOW TO INSTALL AND REPLACE BATTERIES IN THE THERMO-HYGRO
TRANSMITTER
The outdoor thermo-hygro transmitter uses 2 x AAA, IEC LR3, 1.5V batteries. To
install and replace the batteries, please follow the steps below:
1. Remove the cover.
2. Insert batteries, observing the correct polarity (see marking).
3. Replace the battery cover on the unit.
5
HOW TO INSTALL AND REPLACE BATTERIES IN THE WEATHER STATION
Note: Always wait for 2 minutes after removing the batteries before reinserting, otherwise start
up and transmission problems may occur. In the event of changing batteries in any of the units, all
units need to be reset by following the setting up procedures.
BATTERY CHANGE
FUNCTION KEYS
Weather station:
The weather station has five easy to use function keys:
It is recommended to replace the batteries in all units regularly to ensure optimum
accuracy of these units (Battery life See Specifications below).
Please participate in the preservation of the environment. Return used
batteries to an authorized depot.
The weather station uses 2 x C, IEC LR14, 1.5V batteries. To
install and replace the batteries, please follow the steps
below:
1. Remove the cover at the back of the weather station.
2. Insert batteries, observing the correct polarity (see
marking).
3. Replace the compartment cover.
6
SET key
+ key
MIN/MAX key
ALARM key
SUN key
SET key
Press and hold for 2 seconds to enter manual setting modes: LCD contrast, DST ON/OFF,
manual time setting, calendar and relative air pressure value
To stop the alarm sound
To exit alarm setting mode and country/state/city setting mode
To toggle between relative and absolute air pressure value display
+ key
To increase/change values in setting modes
To stop the alarm sound
MIN/MAX key
To switch among the display of MIN/MAX outdoor temperatures and MIN/MAX indoor
temperatures
To decrease/change values in setting modes
7
Press and hold the key for 2 seconds to reset ALL indoor/outdoor minimum/maximum
temperature recordings to current readings
To stop the alarm sound
ALARM key
To activate/deactivate the alarm and display alarm time
Press and hold for 2 seconds to enter the alarm setting mode
To stop the alarm sound
To exit manual setting mode and country/state/city setting mode
SUN key
To switch among the display of date (normal mode), seconds, sun duration and city
Press and hold for 2 seconds to enter country/state/city setting mode
To stop the alarm sound
To exit manual setting mode and alarm setting mode
LCD SCREEN
The LCD screen is split into 3 main sections displaying the information for indoor and outdoor
data, time, moon phase, calendar, sunrise/sunset time, weather forecast and air pressure.
8
Alarm icon
Moon phase
indicator
Weather
forecast icon
Weekday
Weather
tendency
indicator
Time
Low battery
indicator
(transmitter)
Sunrise
time
Sunset
time
Outdoor data
signal reception
indicator *
Outdoor
temperature
in °F
Air pressure
history bar
graph
Indoor
temperature
in °F
Indoor
humidity
display in RH%
Outdoor
humidity
display in
RH%
Relative and
absolute air
pressure
display
Low battery
indicator
(weather
station)
Outdoor MIN/MAX
temperature display
*When the signal is successfully received by the weather station, the Outdoor reception icon will
be switched on. (If not successful, the icon will not be shown in LCD) So the user can easily see
9
whether the last reception was successful (icon on) or not (icon off). On the other hand, the
Digit flashing
flashing of the icon shows that a reception is being done now.
MANUAL SETTINGS
The following settings can be changed when pressing the SET key:
LCD contrast setting
Daylight Saving Time (DST) ON/OFF
Manual time setting
Calendar setting
Relative air pressure value setting
Press and hold the SET key for about 2 seconds to advance to the setting mode:
LCD CONTRAST SETTING
The LCD contrast can be set within 8 levels, from LCD 0 to LCD 7 (Default is LCD 3):
1. The digit starts flashing.
2. Press the + or MIN/MAX key to select the level of contrast desired.
10
3. Press the SET key to confirm and enter the “Daylight Saving Time setting” or exit the
Hour (flashing)
Flashing
Minutes (flashing)
setting mode by pressing the ALARM key or SUN key.
DAYLIGHT SAVING TIME SETTING
The daylight saving time (DST) function can be set ON/OFF. Default setting is “ON”:
1. “ON” will flash on the LCD with "dSt" displayed.
2. Use the + or MIN/MAX key to turn the daylight saving time function ON or OFF.
3. Confirm with the SET key and enter the “Manual Time setting” or exit the setting mode by
pressing the ALARM key or SUN key.
MANUAL TIME SETTING
11
To set the clock:
Month. Date
Year
1. The hour digit will start flashing.
2. Use the + key to increase or MIN/MAX key to decrease the value. Keep holding the key
allows the value to advance faster.
3. Confirm with the SET key and enter minute setting.
4. The minute will be flashing. Use the + key to increase or MIN/MAX key to decrease the
value. Keep holding the key allows the value to advance faster.
5. Confirm with the SET key and enter the “Calendar Setting” or exit the setting mode by
pressing the ALARM key or SUN key.
CALENDAR SETTING
1. The year digits will start flashing. Use the + key to increase or MIN/MAX key to decrease
the value. The range runs from 2011 to 2025 (default is 2011). Keep holding the key allows
the value to advance faster.
2. Press the SET key to confirm and enter the month setting mode.
12
3. The month digit will be flashing. Use the + key to increase or MIN/MAX key to decrease the
Flashing
value. Press the SET key to enter date setting. Keep holding the key allows the value to
advance faster.
4. The date digit will be flashing. Use the + key to increase or MIN/MAX key to decrease the
value. Keep holding the key allows the value to advance faster.
5. Confirm with the SET key and enter the “Relative Air Pressure Value Setting”, or exit the
setting mode by pressing the ALARM key or SUN key.
Note:
Weekday is displayed accordingly above the time in short form (from Monday to Sunday): MO /
TU / WE / TH / FR / SA / SU.
RELATIVE AIR PRESSURE VALUE SETTING
The default relative air pressure value is 29.91 inHg. This can be manually set to another value
within the range of 28.30 – 30.80 inHg for a better reference.
1. The current relative air pressure value will start flashing.
2. Use the + key to increment and MIN/MAX key to decrement the value. Keep holding the
key allows the value to advance faster.
3. Confirm with the SET key and go back to normal mode.
13
Country code (flashing)
LOCATION SETTNG FOR SUNRISE/SUNSET TIME
The weather station will automatically update the sunrise, sunset and sun duration time at 00:00,
based on the city location, the date, time and DST settings.
1. Press and hold the SUN key for 2 seconds to enter the Location setting mode.
2. The short form of country name will start flashing. Use the + key or MIN/MAX key to select
the country.
Note:
See the Country / State / City codes list at the end of this handbook: 2 countries / 99 cities
can be chosen from.
Every country/city is displayed in short code (default country is USA). The states
abbreviations are in brackets ( ) for USA.
14
State code (flashing)
City code (flashing)
Country code (flashing)
To select a US state and city:
1. Once “USA” has been selected, press the SUN
key to enter the state setting.
2. The state code (2 letters abbr. ) will start flashing.
Press the + or MIN/MAX key to select the state.
3. After the state has been selected, press the SUN
key to enter the city setting.
4. The 3 letters city abbr. will start flashing. Use the
+ key or MIN/MAX key to select the city.
5. Confirm with the SUN key. The city’s sunrise, sun
duration and sunset time will be displayed in a
few seconds.
15
Sunset time of
selected city
Sunrise time of
selected city
Sun duration
(hours : minutes)
Sunset icon
Sunrise icon
6. Press the SUN key twice to go back to normal date display.
7. User can exit the setting mode by pressing the SET key or ALARM key without saving the
changes.
16
Country code (flashing)
City code (flashing)
To select a Canadian city:
1. Once “CAN” has been selected, press the SUN
key to enter the city setting.
2. The city code (3 letters abbr.) will start flashing.
Press the + or MIN/MAX key to select the city.
3. Confirm with the SUN key. The city’s sunrise, sun
duration and sunset time will be displayed in a few
seconds.
17
Alarm time (flashing)
Alarm indicator (ON)
Sunset time of
selected city
Sunrise time of selected city
Sun duration
(hours : minutes)
Sunset icon
Sunrise icon
4. Press the SUN key twice to go back to normal date display.
5. User can exit the setting mode by pressing the SET key or ALARM key without saving the
changes.
ALARM SETTING
To set the daily alarm:
1. Press and hold ALARM key for 2 seconds until the alarm time shown.
18
2. The hour digit will be flashing. Press the + key or MIN/MAX key to adjust the hour.
3. Press ALARM key once and minute digit will be flashing. Press + key or MIN/MAX key to
set the minute.
4. Press ALARM key once to confirm the setting, or exit the setting mode by pressing the SET
key or SUN key.
Note:
To activate/deactivate the alarm function, press the ALARM key once. The display of the alarm
icon represents that the alarm is "ON".
Note:
The duration of alarm sounding is 2 minutes. Press any key will stop the alarm sound.
TO EXIT SETTING MODE
To exit the setting mode, wait for automatic timeout to return to normal time display.
DISPLAY OF SUN DURATION TIME
1. In normal date mode, press the SUN key twice to display the sun duration time (total
number of hours of sunlight on the day).
2. Press the SUN key again will display the selected city. (See “LOCATION SETTNG FOR
SUNRISE/SUNSET TIME”)
3. Press the SUN key again to go back to normal date display.
THE MOON PHASE
The weather station displays 8 different moon phase icons. The current moon phase is indicated
with a bar segment according to the set calendar.
19
New
Moon
Waning
Crescent
First
Quarter
Waxing
Gibbous
Waxing
Crescent
Last
Quarter
Full
Moon
Waning
Gibbous
Sun
Sun with cloud
Cloud with rain
A bar segment
indicates the current
moon phase
WEATHER FORECASTING ICONS
Weather icons can be displayed in any of the following combinations:
For every sudden or significant change in the air pressure, the weather icons will update
accordingly to represent the change in weather. If the icons do not change, then it means either
the air pressure has not changed or the change has been too slow for the Weather station to
register. However, if the icon displayed is a sun or raining cloud, there will be no change of icon if
the weather gets any better (with sunny icon) or worse (with rainy icon) since the icons are already
at their extremes.
The icons displayed forecasts the weather in terms of getting better or worse and not necessarily
sunny or rainy as each icon indicates. For example, if the current weather is cloudy and the rainy
icon is displayed, it does not mean that the product is faulty because it is not raining. It simply
means that the air pressure has dropped and the weather is expected to get worse but not
necessarily rainy.
20
Note:
After setting up, readings for weather forecasts should be disregarded for the next 12-24 hours.
This will allow sufficient time for the Weather station to collect air pressure data at a constant
altitude and therefore result in a more accurate forecast.
Common to weather forecasting, absolute accuracy cannot be guaranteed. The weather
forecasting feature is estimated to have an accuracy level of about 75% due to the varying areas
the Weather station has been designed for use. In areas that experience sudden changes in
weather (for example from sunny to rain), the Weather station will be more accurate compared to
use in areas where the weather is stagnant most of the time (for example mostly sunny).
If the Weather station is moved to another location significantly higher or lower than its initial
standing point (for example from the ground floor to the upper floors of a house), discard the
weather forecast for the next 12-24 hours. By doing this, the Weather Station will not mistake the
new location as being a possible change in air-pressure when really it is due to the slight change
of altitude.
WEATHER TENDENCY INDICATOR
Working together with the weather icons is the weather tendency indicator (located on the left of
the weather icons). When the arrow points upwards, it means that the air pressure is increasing
and the weather is expected to improve, but when arrow points downwards, the air pressure is
dropping and the weather is expected to become worse.
Taking this into account, one can see how the weather has changed and is expected to change.
For example, if the indicator is pointing downwards together with cloud and sun icons, then the
last noticeable change in the weather was when it was sunny (the sun icon only). Therefore, the
next change in the weather will be cloud with rain icons since the indicator is pointing downwards.
21
Note:
Air pressure trend over the last 12 hours
Air pressure unit in inHg
Once the weather tendency indicator has registered a change in air pressure, it will remain
permanently visualized on the LCD.
AIR PRESSURE HISTORY (ELECTRONIC BAROMETER WITH BAROMETRIC
PRESSURE TREND)
The right side of the second section on the LCD shows the air pressure history bar graph.
The bar graph indicates the air pressure history trend over the past 12 hours in 7
steps (+0.15, +0.09, +0.03, 0, -0.03, -0.09, and –0.15 inHg) at the points 0, -3, -6, -9 and -12
hours. The “0h” represents the current full hour air pressure recording. The left column shows the
unit in “inHg” (0, ±0.03, ±0.09, ±0.15). The “0” in the middle of this scale is equal to the current
pressure and each change (±0.03, ±0.09, ±0.15) represents how high or low, in “inHg” scale, the
past pressure was compared to the current pressure.
If the bars are rising it means that the weather is getting better due to the increase of air pressure.
If the bars go down, it means the air pressure has dropped and the weather is expected to get
worse from the present time “0h“.
22
Note:
Indoor temperature
in °F
Indoor humidity
in RH%
Outdoor
temperature
in °F
Outdoor
humidity in
RH%
Reception
symbol
For accurate barometric pressure trends, the weather station should operate at the same
altitude for recordings (i.e. it should not be moved from the ground to the second floor of the
house). When the unit is moved to a new location, discard readings for the next 12 hours.
DISPLAY OF INDOOR TEMPERATURE/HUMIDITY DATA
The indoor temperature and humidity are measured automatically and displayed on the first
section of the LCD.
DISPLAY OF OUTDOOR TEMPERATURE/HUMIDITY DATA
The last section of the LCD display shows the outdoor temperature and humidity and a reception
symbol.
23
DISPLAY OF INDOOR/OUTDOOR MAXIMUM AND MINIMUM RECORDS
Outdoor
temperature in F
Recorded
MIN/MAX outdoor
temperature time
Recorded
MIN/MAX outdoor
temperature date
Press the MIN/MAX key several times to view the MIN/MAX indoor temperature, and MIN/MAX
outdoor temperature sequentially.
Date and time of recordings will be shown for outdoor temperature data.
RESETTING THE MAXIMUM/MINIMUM RECORDS
To reset the MIN/MAX records, press and hold the MIN/MAX key for 2 seconds. This will reset
ALL minimum and maximum temperature records to current readings.
24
LOW BATTERY INDICATORS
Low battery indicator will show on the LCD when the batteries of weather station or transmitter
require changing.
THERMO-HYGRO TRANSMITTER
The reception distance of the thermo-hygro transmitter may be affected by the temperature. At
cold temperatures the transmitting distance may be decreased. Please bear this in mind when
placing the transmitter.
915 MHz RECEPTION
The weather station should receive the outdoor data within 80 seconds after set-up. If the outdoor
data is not received 80 seconds after setting up (or the outdoor temperature shows “- - -” during
normal operation), please check the following points:
1. The distance of the weather station or transmitter should be at least 5 to 6.5 feet (2 –3
meters) away from any interfering sources such as computer monitors or TV sets.
2. Avoid positioning the weather station onto or in the immediate proximity of metal window
frames.
3. Using other electrical products such as headphones or speakers operating on the same
signal frequency (915 MHz) may prevent correct signal transmission and reception.
4. Neighbors using electrical devices operating on the 915 MHz signal frequency can also
cause interference.
Note:
When the 915 MHz signal is received correctly, do not re-open the battery cover of either the
transmitter or weather station, as the batteries may spring free from the contacts and force a false
25
reset. Should this happen accidentally then reset all units (see Setting up above) otherwise
transmission problems may occur.
The transmission range is about 330 feet / 100 meters from the transmitter to the weather station
(in open space). However, this depends on the surrounding environment and interference levels. If
no reception is possible despite the observation of these factors, all system units have to be reset
(see Setting up).
POSITIONING THE WEATHER STATION:
The weather station comes complete with a foldout stand that gives
the option of table standing or wall mounting.
To wall mount:
1. Fix a screw into the desired wall, leaving the head extended out by
about 0.2” (5mm).
2. Using the weather station hanging hole, carefully hang it onto the
screw.
26
Note:
Always ensures that the unit locks onto the screw head before releasing.
POSITIONING THE THERMO-HYGRO TRANSMITTER:
The thermo-hygro transmitter can be placed on any flat surface or wall mount
using the bracket which doubles as a stand or wall mount base.
To wall mount:
1. Secure the bracket onto a desired wall using the screws and plastic anchors.
2. Clip the transmitter onto the bracket.
Note:
Before permanently fixing the transmitter wall base, place all units in the desired
locations to check that the outdoor temperature/humidity readings are receivable. In
event that the signal is not received, relocate the units or move them slightly as this
may help the signal reception.
27
CARE AND MAINTENANCE:
Extreme temperatures, vibration and shock should be avoided as these may cause damage
to the unit and give inaccurate forecasts and readings.
When cleaning the display and casings, use a soft damp cloth only. Do not use solvents or
scouring agents as they may mark the LCD and casings.
Do not submerge the unit in water.
Immediately remove all low powered batteries to avoid leakage and damage. Replace only
with new batteries of the recommended type.
Do not make any repair attempts to the unit. Return them to their original point of purchase
for repair by a qualified engineer. Opening and tampering with the unit may invalidate their
guarantee.
Do not expose the units to extreme and sudden temperature changes, this may lead to
rapid changes in forecasts and readings and thereby reduce their accuracy.
SPECIFICATIONS
Temperature measuring range:
Indoor : 14.1ºF to 139.8ºF with 0.2ºF resolution (“OF.L” displayed if outside this range)
Outdoor : -39.8ºF to +139.8ºF with 0.2ºF resolution (“OF.L” displayed if outside this range)
Humidity measuring range:
Indoor humidity range : 20% to 95% with 1% resolution
(Display “- -“ if temperature is OL.F; display “19%“ if < 20% and
Outdoor humidity range : 1% to 99% with 1% resolution (Display “- -“ if outside temperature
“96%” if > 95%)
is OF.L; display 1% if < 1% and 99% if > 99%)
28
Data checking intervals:
Indoor checking interval : every 16 seconds
Outdoor reception : every 4 seconds
Air pressure checking interval : every 1 minute
Transmission range : up to 330 feet / 100 meters (open space)
Power consumption (Alkaline batteries recommended) :
Weather station : 2 x C, IEC LR14, 1.5V
Battery life : Approx. 24 months
Temperature transmitter : 2 x AAA, IEC, LR3, 1.5V
Battery life : Approx. 12 months
Dimensions (L x W x H)
Weather station : 7.4” x 1.32” x 7.4” / 188 x 33.7 x 188 mm
Temperature transmitter : 1.41” x 0.62” x 4.03” / 36 x 16 x 102.6 mm
WARRANTY INFORMATION
La Crosse Technology, Ltd provides a 1-year limited warranty on this product against
manufacturing defects in materials and workmanship.
This limited warranty begins on the original date of purchase, is valid only on products purchased
and used in North America and only to the original purchaser of this product. To receive warranty
service, the purchaser must contact La Crosse Technology, Ltd for problem determination and
service procedures. Warranty service can only be performed by a La Crosse Technology, Ltd
authorized service center. The original dated bill of sale must be presented upon request as proof
of purchase to La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service
center.
29
La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as
stipulated herein, with new or reconditioned parts or products if found to be defective during the
limited warranty period specified above. All replaced parts and products become the property of
La Crosse Technology, Ltd and must be returned to La Crosse Technology, Ltd.
Replacement parts and products assume the remaining original warranty, or ninety (90) days,
whichever is longer. La Crosse Technology, Ltd will pay all expenses for labor and materials for
all repairs covered by this warranty. If necessary repairs are not covered by this warranty, or if a
product is examined which is not in need or repair, you will be charged for the repairs or
examination.
The owner must pay any shipping charges incurred in getting your La Crosse Technology, Ltd
product to a La Crosse Technology, Ltd authorized service center.
Your La Crosse Technology, Ltd warranty covers all defects in material and workmanship with the
following specified exceptions: (1) damage caused by accident, unreasonable use or neglect
(including the lack of reasonable and necessary maintenance); (2) damage occurring during
shipment (claims must be presented to the carrier); (3) damage to, or deterioration of, any
accessory or decorative surface; (4) damage resulting from failure to follow instructions contained
in your owner’s manual; (5) damage resulting from the performance of repairs or alterations by
someone other than an authorized La Crosse Technology, Ltd authorized service center; (6) units
used for other than home use (7) applications and uses that this product was not intended or (8)
the products inability to receive a signal due to any source of interference.
This warranty covers only actual defects within the product itself, and does not cover the cost of
installation or removal from a fixed installation, normal set-up or adjustments, claims based on
30
misrepresentation by the seller or performance variations resulting from installation-related
circumstances.
LA CROSSE TECHNOLOGY, LTD WILL NOT ASSUME LIABILITY FOR INCIDENTAL,
CONSEQUENTIAL, PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED WITH THE
OPERATION OR MALFUNCTION OF THIS PRODUCT. THIS PRODUCT IS NOT TO BE USED
FOR MEDICAL PURPOSES OR FOR PUBLIC INFORMATION. THIS PRODUCT IS NOT A
TOY. KEEP OUT OF CHILDREN’S REACH.
This warranty gives you specific legal rights. You may also have other rights specific to your
State. Some States do no allow the exclusion of consequential or incidental damages therefore
the above exclusion of limitation may not apply to you.
For warranty work, technical support, or information contact:
Contact Support: 1-608-782-1610
La Crosse Technology
2817 Losey Blvd. S.
La Crosse, WI 54601
31
Product Info and Support:
www.lacrossetechnology.com/9257
Product Registration:
www.lacrossetechnology.com/support/register
The complete instruction manual is available at:
www.lacrossetechnology.com/9257
Le manuel d'instruction complet est disponible sur:
www.lacrossetechnology.com/9257
El manual de instrucciones completo está disponible en:
www.lacrossetechnology.com/9257
32
List of Country / State / City Codes
USA = UNITED STATES OF
AMERICA
ALABAMA (AL)
MONTGOMERY = MGM
MOBILE = MOB
ARKANSAS (AR)
LITTLE ROCK = LIT
ARIZONA (AZ)
PHOENIX = PHX
CALIFORNIA (CA)
FRESNO = FAT
LOS ANGELES = LAX
REDDING = ROD
SAN DIEGO = SAN
SAN FRANCISCO = SFO
COLORADO (CO)
DENVER = DEN
DURANGO = DRO
GRAND JUNCTION = GJT
PUEBLO = PUB
DISTRIC OF COLUMBIA (DC)
WASHINGTON = DCA
FLORIDA (FL)
JACKSONVILLE = JAX
MIAMI = MIA
ORLANDO = ORL
TALLAHASSEE = TLH
TAMPA = TPA
GEORGIA (GA)
ATLANTA = ATL
HAWAII (HI)
HONOLULU = HNL
IOWA (IA)
DES MOINES = DSM
DAVENPORT = DVN
IDAHO (ID)
BOISE = BOI
ILLINOIS (IL)
CHICAGO = ORD
SPRINGFIELD = SPI
33
INDIANA (IN)
EVANSVILLE = EVV
INDIANAPOLIS = IND
KANSAS (KS)
DODGE CITY = DDC
WICHITA = K32
TOPEKA = TOP
KENTUCKY (KY)
LEXINGTON = LEX
LOUISIANA (LA)
NEW ORLEANS = NEW
SHREVEPORT = SHV
MASSACHUSETTS (MA)
BOSTON = BOS
MAINE (ME)
AUGUSTA = AUG
CARIBOU = CAR
MICHIGAN (MI)
DETROIT = DET
ROGERS CITY = PZQ
MINNESOTA (MN)
DULUTH = DLH
INTERNATIONAL FALLS = INL
MISSOURI (MO)
JEFFERSON CITY = JEF
MISSISSIPI (MS)
JACKSON = JAN
MONTANA (MT)
BILLINGS= BIL
HELENA = HLN
NORTH CAROLINA (NC)
CHARLOTTE = CLT
RALEIGH = RDU
NORTH DAKOTA (ND)
BISMARCH = BIS
FARGO = FAR
NEBRASKA (NE)
LINCOLN = LNK
SIDNEY = SNY
NEW HAMPSHIRE (NH)
CONCORD = CON
NEW JERSEY (NJ)
TRENTON = TTN
NEW MEXICO (NM)
34
ALBUQUERQUE = ABQ
NEVADA (NV)
LAS VEGAS = LAS
RENO = RNO
NEW YORK (NY)
BUFFALO = BUF
NEW YORK CITY = JFK
SYRACUSE = SYR
OHIO (OH)
CLEVELAND = CLE
COLUMBUS = CMH
OKLAHOMA (OK)
OKLAHOMA CITY = OKC
TULSA = TUL
OREGON (OR)
MEDFORD = MFR
PORTLAND = PDX
PENNSYLVANIA (PA)
HARRISBURG = CXY
PITTSBURGH = PIT
SCRANTON = SCR
SOUTH CAROLINA (SC)
CHARLSTON = CHS
COLUMBIA = CUB
SOUTH DAKOTA (SD)
SIOUX FALLS = FSD
RAPID CITY = RAP
TENNESSEE (TN)
NASHVILLE = BNA
KNOXVILLE = DKX
MEMPHIS = MEM
TEXAS (TX)
AMARILLO = AMA
AUSTIN = AUS
BROWNSVILLE = BRO
DALLAS / FT. WORTH = DFW
EL PASO = ELP
HOUSTON = HOU
ODESSA = ODO
SAN ANTONIO = SAT
UTAH (UT)
SALT LAKE CITY = SLC
VIRGINIA (VA)
LYNCHBURG = LYH
35
NORFOLK = ORF
VERMONT (VT)
BURLINGTON = BTV
WASHINGTON (WA)
SEATTLE = SEA
SPOKANE = SFF
WISCONSIN (WI)
GREEN BAY = GRB
LA CROSSE = LSE
WEST VIRGINIA (WV)
CHARLESTON = CRW
WYOMING (WY)
CASPER = CPR
CA = CANADA
CALGARY = ALB
OTTAWA = OTT
QUEBEC = QUE
TORONTO = TOR
VANCOUVER = VAN
WINNEPEG = WIN
36
FCC ID: OMO-M-15 (transmitter)
FCC DISCLAIMER
RF Exposure mobile:
The internal / external antennas used for this mobile transmitter must provide a separation distance of at
least 20 cm (8 inches) from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter."
Statement according to FCC part 15.19:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Statement according to FCC part 15.21:
Modifications not expressly approved by this company could void the user's authority to operate the
equipment.
Statement according to FCC part 15.105:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
37
Reorient or relocate the receiving antenna.
EJMA9257L210
Printed in China
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
All rights reserved. This handbook must not be reproduced in any form, even in excerpts, or duplicated or
processed using electronic, mechanical or chemical procedures without written permission of the publisher.
This handbook may contain mistakes and printing errors. The information in this handbook is regularly
checked and corrections made in the next issue. We accept no liability for technical mistakes or printing
errors, or their consequences.
All trademarks and patents are acknowledged.
Loading...
