Inventory of Contents 3
Quick Setup 4-8
Detailed Setup Guide
Battery Installation 9-11
Setting the Time 11-12
Selecting Units of
Measurement
Features
Minimum and Maximum
Temperatures
Resetting Minimum and
Maximum Temperatures
Additional remote
temperature sensors
(optional)
Mounting 17-18
Troubleshooting 19-20
Maintenance and Care 21
Specifications 22-23
Warranty Information 24-28
12-13
13
13-14
14-16
2
INVENTORY OF CONTENTS
1.
The indoor temperature station (Figure
1)
2.
The remote temperature sensor (TX6U)
and mounting bracket. (Figure 2)
3.
3 each, 1/2” Philips screws.
4.
One strip of double sided adhesive tape.
5.
Instruction Manual and Warranty Card.
Figure 1
ADDITIONAL EQUIPMENT
(not included)
1.
1 Philips screwdriver.
2.
2 Fresh AAA 1.5V batteries.
3.
2 Fresh AA 1.5V batteries.
Figure 2
3
QUICK SETUP
Hint: Use good quality Alkaline
Batteries and avoid rechargeable
batteries.
1. Have the indoor
temperature station and
remote temperature sensor
3 to 5 feet apart.
2. Batteries should be out of
both units for 10 minutes.
3. Place the batteries into the
remote temperature
sensor first then into the
indoor temperature station.
(All remote temperature sensors must be
started before the indoor temperature
station)
4. DO NOT PRESS ANY
BUTTONS FOR 15
MINUTES.
4
In this time the indoor temperature
station and remote temperature sensor
will start to talk to each other and the
display will show both the indoor
temperature and an outdoor temperature.
If the indoor temperature station does
not display both temperatures after the
10 minutes please retry the set up as
stated above. After both indoor and
outdoor temperatures are displayed for
15 minutes you can place your remote
temperature sensor outdoors and set
your time.
The remote temperature sensor should
be placed in a dry, shaded area. The
remote temperature sensor has a range
of 80 feet. Any walls that the signal
will have to pass through will reduce
distance. An outdoor wall or window
will have up to 20 feet of resistance and
an interior wall will have up to 10 feet
5
of resistance. Your distance plus
resistance should not exceed 80 ft. in a
straight line.
NOTE: Fog and mist will not harm
your remote temperature sensor but
direct rain must be avoided.
To complete the set up of your indoor
temperature station after the 15 minutes
have passed please follow the steps
below.
1. Press and hold the “SET/CH”
button for 5 seconds.
Note: A “12h” or “24h” will appear
to the left of the time. (“12h” for
AM/PM, “24h” for military time)
a. To change between “12h”
and “24h” press and
release the “MIN/MAX”
button.
6
b. When you have your
choice shown on the
display press and release
the “SET/CH” button
once.
2. Degree Fahrenheit will now show.
a. To change between
Fahrenheit and Celsius,
press and release the
“MIN/MAX” button.
b. When you have your
choice shown on the
display press and release
the “SET/CH” button
once.
3. An hour will now be flashing.
a. Press and release the
“MIN/MAX” button until
the correct hour is shown.
Note: When in the 12h mode
there is “PM” displayed under
7
the word TIME when in the
PM hours. During the AM
hours this area will be blank.
b. When the correct hour is
shown, press and release
the “SET/CH” button
once.
4. A minute will now be flashing.
a. Press and release the
“MIN/MAX” button until
the correct minutes are
displayed.
Press and release the “SET/CH”
button once more and you are done.
8
DETAILED SETUP GUIDE
I.
BATTERY INSTALLATION
A.
REMOTE TEMPERATURE
SENSOR
1.
Remove the mounting bracket.
2.
Remove battery cover
3.
Observing the correct polarity, install
2 AA batteries—make sure they do not
spring free, or start-up problems may
occur. Replace cover.
9
