Jaguar Fpace 2016 Owner's Manual
ALL-NEW JAGUAR F-PACE
THE ART OF PERFORMANCE
Every day we push performance to its limit. Our performance. Our cars' performance.
We innovate, we engineer, we design. We master rules and then break them.
Only to push further. Past the limits of convention. This is when performance becomes art.
Jaguar. The Art of Performance.
CONTENTS
INTRODUCTION
The Concept of the F-PACE 06
The F-PACE – The Facts 08
DESIGN
Exterior Principles 10
Exterior Detail 12
Interior Choice 15
Interior Space 18
Practicality 20
PERFORMANCE
Engines 22
Advanced Aerodynamics 24
Lightweight Aluminum Architecture 27
Chassis and Suspension 28
Tested to the Extreme 30
DRIVING TECHNOLOGY
Advanced Driving Dynamics 33
All Surface Progress Control 34
Advanced Drivetrain Technology 37
Torque Vectoring 38
Stability and Control 41
Head-Up Display 43
Activity Key 45
INFOTAINMENT
Jaguar InControl Technologies 46
InControl Touch
TM
InControl Touch Pro
TM
49
Audio 52
ASSISTANCE & EFFICIENCY
Advanced Driver Assistance 54
Ecient Technologies 56
PERSONALIZATION
First Edition 59
The F-PACE – Your Choice 60
Choose your Engine 62
Choose your Model & Packages 64
Choose your Color 72
Choose your Wheels 74
Choose your Interior 76
Choose your Jaguar Accessories 88
Technical Specifications 92
Dimensions 94
JAGUAR WORLD
Jaguar Experience 96
The World of Jaguar 98
Glossary and Legal Information 100
51
Scan to find out more about the All-New Jaguar F-PACE.
VEHICLE SHOWN: F-PACE FIRST EDITION IN CAESIUM BLUE
SOME OF THE VEHICLES FEATURED IN THE PHOTOGRAPHS THROUGHOUT THIS
BROCHURE ARE EUROPEAN MODELS AND MAY NOT BE AVAILABLE IN NORTH AMERICA.
PLEASE CONSULT YOUR LOCAL JAGUAR RETAILER FOR SPECIFIC MODEL AVAILABILITY.
INTRODUCTION
THE CONCEPT
OF THE F-PACE
The F-PACE is inspired by the acclaimed C-X17 concept vehicle. It takes
the pure Jaguar DNA of legendary performance, handling and luxury.
Then it adds space and practicality.
Technologically advanced to the core, the F-PACE is the most practical
Jaguar sports car. It combines enhanced driving exhilaration with
eciency
experience and keep you connected. The F-PACE has the capability
for every road and the capacity for every day. It is the latest in a bloodline
of beautiful, exciting cars. The F-PACE is a Jaguar for you, a Jaguar
for your family.
VEHICLE SHOWN: F-PACE FIRST EDITION IN CAESIUM BLUE
IMAGES SHOWN FOR ILLUSTRATIVE PURPOSES ONLY AND MAY NOT BE TO EXACT US SPECIFICATION.
Disclaimers apply. Please see page 100 for further details.
INTRODUCTION
06
|
7
. All enhanced by technologies that improve your driving
THE F-PACE – THE FACTS
BEST IN CLASS
5 YEARS 60, 000 MILES
Performance, handling and refinement. Practicality, capability and eciency7.
EFFICIENCY
The F-PACE is designed and engineered for maximum eciency7.
Low friction technologies, a lightweight body structure and
streamlined aerodynamics all contribute to help achieve low fuel
economy and a drag coecient from 0.36**.
PRACTICALITY
The rear knee and leg room in the F-PACE is exceptionally
spacious and has a 40:20:40 seating configuration for greater
flexibility. Cargo space is generous at 33.5 cu.ft., with carefully
considered dimensions designed to maximize its usability.
COVERAGE
JAGUAR ELITECARE
Enjoy your Jaguar with complete peace of mind.
The F-PACE is now backed by the Best-In-Class Jaguar EliteCare*,
our exceptional 5 years / 60,000 mile coverage program including
New Vehicle Limited Warranty, Complimentary Scheduled Maintenance,
Roadside Assistance and InControl Remote & ProtectTM.
VEHICLE SHOWN: F-PACE PRESTIGE IN GLACIER WHITE WITH OPTIONAL FEATURES FITTED
*Class is cars sold by luxury automobile brands and claim is based on total package of warranty,
maintenance and other coverage programs. For complete details regarding Jaguar EliteCare coverage,
visit JAGUARUSA.COM, call 1.800.4.JAGUAR or visit your local Jaguar Retailer.
**Engine and model dependent.
Disclaimers apply. Please see page 100 for further details.
INTRODUCTION
08
|
*
CAPABILITY
The F-PACE matches your practical driving needs and the demands of your
lifestyle. Available in All Wheel Drive as standard, performance can be enhanced
across an even wider range of conditions. Capabilities can be further enhanced
by All Surface Progress Control system5, a low speed cruise control that helps
the F-PACE to cope with low traction situations.
PERFORMANCE
Discover exhilarating driving experiences across the entire F-PACE range. Our highly ecient
performance engines oer a balance between economy and power. Engines include the 2.0 liter
4 cylinder 180HP Turbocharged Diesel from the Ingenium range, the 3.0 liter 340HP Supercharged
Gas engine and the 3.0 liter V6 380HP Supercharged Gas engine that can reach a limited top
speed of 155mph with 0-60mph acceleration as low as 5.1 seconds8.
REFINEMENT
Our cars have an unrivalled reputation for comfort and
a smooth, quiet ride. Thanks to its sti body structure,
advanced suspension and aerodynamic design, the F-PACE
showcases the supreme refinement of the Jaguar brand.
HANDLING
The advanced chassis and suspension system is an evolution of the configuration
used on the F-TYPE sports car. This robust system is lightweight to ensure
the F-PACE delivers true sports handling. The Electronic Power Assisted Steering
(EPAS) software is specially tuned for optimum feedback and control, while the
All Wheel Drive system uses the F-TYPE-derived, unique Intelligent Driveline
Dynamics software for an agile feel and to minimize understeer5. The F-PACE
always drives, feels and handles like a Jaguar.
DESIGN
EXTERIOR PRINCIPLES
F-TYPE INSPIRED STYLING PURITY OF FORM
Visually inspired by the F-TYPE, the Jaguar F-PACE is a performance SUV that
has the DNA of a sports car. Its powerful, agile looks make it utterly distinctive
and give it a head-turning road presence. From the hood bulge to the pronounced
rear haunches, the F-PACE reinvents the energy, strength and purity of form
of the F-TYPE.
VEHICLE SHOWN: F-PACE R-SPORT IN ITALIAN RACING RED WITH OPTIONAL FEATURES FITTED
DESIGN
10
|
EXTERIOR DETAIL
ADAPTIVE LED HEADLAMPS*
Even at night, the F-PACE is instantly recognizable thanks to its available Adaptive LED headlamps* complementing
the signature 'J' Blade Daytime Running Lamps. Adding to the commanding on-road presence, Adaptive LED
headlamps* produce an intensity of light that is close to daylight, helping your eyes to distinguish objects more
easily. At the rear, full LED tail lamps echo the distinctive design of the F-TYPE.
*Fitment dependent on derivative.
VEHICLE SHOWN: F-PACE FIRST EDITION IN CAESIUM BLUE
IMAGES SHOWN FOR ILLUSTRATIVE PURPOSES ONLY AND MAY NOT BE TO EXACT US SPECIFICATION.
DESIGN
12
|
INTERIOR CHOICE
SPORTS COMMAND DRIVING POSITION EXTENSIVE PERSONAL CHOICE
The F-PACE interior blends sportiness and elegance to create the latest in contemporary design. Our extensive
range of premium materials, handpicked leathers and sophisticated finishes, gives the F-PACE one of the most
comprehensive interior choices. This is your perfect opportunity to create a space that reflects your individual style.
Take personalization to the next level with optional Configurable interior mood lighting*. The system highlights
the finest interior design details with soft pools of light in a choice of ten dierent colors. The F-PACE can create
an ambience to match your mood. The modern interior design means essential controls are intuitive to use
and always close at hand. A high center console and the Sports Command driving position help the driver feel
connected and secure. Slender roof pillars and a large windshield mean all-round visibility is excellent.
*Fitment is derivative dependent.
VEHICLE SHOWN: F-PACE PORTFOLIO WITH SIENA TAN PERFORATED WINDSOR LEATHER SEATS.
IMAGES SHOWN FOR ILLUSTRATIVE PURPOSES ONLY AND MAY NOT BE TO EXACT US SPECIFICATION.
DESIGN
15
|
INTERIOR SPACE
PANORAMIC ROOF OPTIMIZED REAR SPACE
VEHICLE SHOWN PREVIOUS PAGE: F-PACE R-SPORT FEATURING JET/RED PERFORATED TAURUS LEATHER SPORTS SEATS WITH RED CONTRAST STITCH.
VEHICLE SHOWN THIS PAGE: F-PACE PORTFOLIO FEATURING SIENA TAN PERFORATED WINDSOR LEATHER SEATS WITH SIENA TAN TONAL STITCH.
IMAGES SHOWN FOR ILLUSTRATIVE PURPOSES ONLY AND MAY NOT BE TO EXACT US SPECIFICATION.
The Sliding Panoramic roof brings the outside in by giving everyone superb views of the sky, allowing fresh air into the cabin whenever
you want it. For greater privacy and to reduce excessive heating under intense sunlight, every panoramic roof is fitted with an electric
blind as standard.
In the back, there's space for three adults to sit comfortably side by side. Rear leg and knee room are 37.2 inches and 2.6 inches respectively.
Throughout the car you'll find neatly placed, versatile storage. There are useful pockets for smartphones and other small items either
side of the center console, as well as below the Touch-screen.
DESIGN
19
|
PRACTICALITY
CARGO SPACE FLEXIBLE SEATING
The F-PACE has a cargo capacity of 33.5 cu.ft.† The space is made even more versatile by the rear
seats 40:20:40 configuration. They can be folded completely, or folded individually, in a variety
of combinations, to accommodate both occupants and awkward items such as skis. With the rear
seats folded flat, the total loadspace is an impressive 63.5 cu.ft.
The loadspace floor is reversible and can be switched, in an instant, from luxury carpet to an
easy-clean, rubberised surface – perfect for damp or muddy equipment. Transferring items into
and out of the F-PACE is made easier by the low loading height and wide opening.
Gesture Tailgate is available as an option on the F-PACE. With Gesture Tailgate you don't even have
to touch the car when your hands are full – simply present your foot under one of the rear flanks
and the tailgate opens or closes.‡
40:20:40
33.5 cu.ft.†
†Below the loadspace cover.
‡Requires Jaguar Smart Key System with Keyless Entry and Push Button Start.
VEHICLE SHOWN: F-PACE R-SPORT IN ITALIAN RACING RED, FEATURING JET/RED PERFORATED TAURUS LEATHER SPORTS SEATS WITH RED CONTRAST STITCH.
OPTIONAL FEATURES FITTED
DESIGN
20
|
40:20:40
40:20:40 40:20:40
63.5 cu.ft.
DESIGN
21
|
PERFORMANCE
ENGINES
RESPONSIVE ENGINES EFFICIENCY AND PERFORMANCE
The F-PACE is oered with a choice of refined, ecient diesel or gas engines7 – all delivering
a dynamic driving experience and responsive Jaguar performance. The engines are equipped
with Stop/Start technology and smart regenerative charging – harvesting kinetic energy from
braking to charge the battery – for maximum economy, especially during city driving.
INGENIUM DIESEL ENGINE
318 lb.ft. of Torque
Disclaimers apply. Please see page 100 for further details.
PERFORMANCE
22
|
The F-PACE is oered with the 2.0 liter 4 cylinder 180HP Turbocharged Diesel from our
Ingenium range. Ingenium is the new breed of engine designed by Jaguar Land Rover for
eortless performance, refinement and eciency7. With advanced technology and all-aluminum
construction, Ingenium delivers impressive fuel consumption. Typically, 44 lbs lighter than
equivalent previous generation engines, Ingenium is intrinsically more ecient.
And intelligent too – computer controlled, adaptive engine cooling only engages as required.
The latest generation variable geometry turbocharger maximizes peak power for low speed
torque and responsiveness that is uniform, progressive and avoids lag. Internal friction –
the enemy of performance and eciency – is 17 percent lower in the Ingenium range than
previous generation engines.
GAS ENGINES
0-60mph from 5.1 sec
The gas engines oer power and responsiveness throughout the rev range,
while improving eciency7. Shared with the F-TYPE, the 3.0 liter V6 Supercharged
gas engine is available in both 340HP and 380HP versions. At 380HP the engine
is capable of 0-60mph in as low as 5.1 sec8. This all-aluminum engine delivers instant
access to high levels of torque at all engine speeds, and a unique soundtrack.
The 3.0 liter V6 Supercharged Gas engine has been adapted for the specific
requirements of the F-PACE. A Roots-type twin vortex supercharger is mounted
in the 'V' between the two rows of cylinders for compact dimensions. Supercharging
provides linear delivery of power and maximizes responsiveness. This results
in performance matching much larger engines, while optimizing economy and
reducing emissions.
PERFORMANCE
23
|
ADVANCED AERODYNAMICS
LOW DRAG INCREASED STABILITY
The aerodynamic performance of the F-PACE is a key function of its body design and supports an impressive drag coecient from Cd 0.36*.
The result is that the F-PACE really is as sleek as it looks. Highly advanced aerodynamics reduce fuel consumption and wind noise while adding
to high speed stability and driver confidence. The innovative, lightweight underbody design is as important as the body you can see. The smooth
underbody surfaces manage airflow to optimize cooling of the engine and brakes as well as helping to minimize drag, reduce turbulence and
increase eciency. As air reaches the back of the F-PACE, the car's sharply angled rear corners and integrated spoiler limit pressure dierences
forming in the wake of the car for improved fuel economy.
*Engine and model dependent.
VEHICLE SHOWN: F-PACE PRESTIGE IN GLACIER WHITE WITH OPTIONAL FEATURES FITTED
PERFORMANCE
24
|
LIGHTWEIGHT
ALUMINUM ARCHITECTURE
STRONG RIGID 80% ALUMINUM*
Jaguar has been at the forefront of aluminum car construction for more than a decade. Our latest innovation
is the Lightweight Aluminum Architecture that provides the foundations for the F-PACE. We use aluminum
where possible because it creates a sti, strong and, most importantly, lighter architecture. The architecture's
incredible strength oers excellent protection to all occupants, while its reduced weight enhances handling
and braking. Aluminum has also been used to form the body sides, hood and front wings of the F-PACE.
The reduced weight of the structure is distributed with a near perfect 50:50** balance for a sporting
performance and an impeccable ride.
*Aluminum content based on volume for body structure excluding doors, hood and tailgate.
**Model and engine dependent.
PERFORMANCE
27
|
ALUMINUM FRONT KNUCKLE
Designed to optimize stiness and strength, the lightweight
aluminum front knuckle helps improve the agility,
responsiveness and refinement for sports car inspired control.
CHASSIS AND SUSPENSION
Disclaimers apply. Please see page 100 for further details.
SUPERB RIDE
AND HANDLING
Underpinning the F-PACE is an evolution of the F-TYPE chassis and suspension
system – it oers a unique balance between agility and ride comfort. This ensures
that the F-PACE feels like a true Jaguar and is a pleasure to drive or be driven in.
In combination with this suspension, the sti body structure and the use of lightweight
acoustic damping materials create supreme refinement.
UNIQUE SUSPENSION
TECHNOLOGY
PERFORMANCE
28
|
INTEGRAL LINK REAR SUSPENSION
Integral Link suspension allows the F-PACE to realize a perfect
combination of a refined, luxurious ride and sharp, responsive handling.
The system separates and independently manages the lateral,
longitudinal and vertical forces acting on the suspension for enhanced
control and comfort. Many components are forged or hollow-cast
in aluminum – the optimum production techniques for strong,
lightweight suspension.
*Standard on F-PACE S and F-PACE First Edition,
optional on other models.
ALUMINUM DOUBLE FRONT
WISHBONE SUSPENSION
Considered by Jaguar as the best configuration for a front
suspension system, the aluminum double wishbone design
is modeled closely on the F-TYPE for precise handling
and control.
ADAPTIVE DYNAMICS*
The optional Adaptive Dynamics system delivers both precise dynamics
and a supple, luxurious ride by monitoring wheel position and body
movements. The system constantly monitors conditions and adjusts
the dampers to provide the optimum balance between comfort and
refinement at all times7.
SUSPENSION
We create unique algorithms to represent the strains
and stress equivalent to 155,000 miles or ten years
of driving on our state-of-the-art rig.
COLD CLIMATE
-40°F in our cold climate chamber ensures that when
the F-PACE is hard at work outside in freezing conditions,
everything on the inside is working for your total comfort.
TESTED TO THE EXTREME
-40°F TO 122°F FROM THE ARCTIC TO DUBAI
From the Arctic Circle and the mountains of China to the sands of Dubai and coast to coast in North America, the F-PACE has seen almost
everything the world's roads can throw at it. Then we brought the F-PACE home to our UK testing facilities and things got really tough…
PERFORMANCE
30 |30
|
HOT TESTING
In the hot room temperatures can soar up to 122°F.
We can recreate wind speeds of up to 150mph
and roads speeds as high as 155mph. There's nowhere
you can take the F-PACE that it hasn't been already.
Loading...
