HP LaserJet 1150 Service Manual

hp LaserJet 1150 and hp LaserJet 1300 series

service manual

Part number Q1334-90928 Edition 1, 4/2003 Printed in USA

Warranty

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with respect to this information. HEWLETT-PACKARD SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Hewlett-Packard shall not be liable for any direct, indirect, incidental, consequential, or other damage alleged in connection with the furnishing or use of this information.

NOTICE TO U.S. GOVERNMENT USERS: RESTRICTED RIGHTS COMMERCIAL COMPUTER SOFTWARE: “Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c) (1)(ii) of the Rights in Technical Data Clause at DFARS 52.227-7013.”

Trademark Credits

Microsoft, Windows, and MSDOS are U.S. registered trademarks of Microsoft Corporation.

TrueType is a U.S. trademark of Apple Computer, Inc.

All other products mentioned herein may be trademarks of their respective companies.

Safety Information

WARNING!

Potential Shock Hazard

Always follow basic safety precautions when using this product to reduce risk of injury from fire or electric shock.

1 Read and understand all

instructions in the user guide.

2 Observe all warnings and

instructions marked on the product.

3 Use only a grounded

electrical outlet when connecting the printer to a power source. If you do not know whether the outlet is grounded, check with a qualified electrician.

4 Do not touch the contacts

on the end of any of the sockets on the printer. Replace damaged cords immediately.

5 Unplug this product from

wall outlets before cleaning.

6 Do not install or use this

product near water or when you are wet.

7 Install the product securely

on a stable surface.

8 Install the product in a

protected location where no one can step on or trip over the power cord and the power cord will not be damaged.

9 If the product does not

operate normally, see the online user guide.

10 Refer all servicing

questions to qualified personnel.

Information regarding FCC Class B, Parts 15 and 68 requirements can be found in the user guide.

Hewlett-Packard Company 11311 Chinden Boulevard Boise, Idaho 83714 U.S.A.

Figures

Tables

1 Product information

Chapter contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Hardware description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Firmware description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Product specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Model and serial numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Overview of printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Front and side view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Back and side view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Warranty statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Extended warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Limited warranty for print cartridge life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Print cartridge information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Print cartridge date stamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Refilled print cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

HP LaserJet printing supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

HP printing supplies returns and recycling program information . . . . . . . . . 25

Material safety data sheet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

2 Installation and operation

Chapter contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Operating environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Identifying printer components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Printer control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Control panel light patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Selecting media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Loading media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Printer output paths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

ENWW Contents iii

3 Maintenance

Chapter contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Life expectancies of components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

User-replaceable parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Replacing the printer pickup roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Replacing the printer separation pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Cleaning the equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Cleaning the print path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Cleaning the print cartridge area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Cleaning the printer pickup roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Cleaning the printer separation pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

4 Operational overview

Chapter contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Basic functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Formatter system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

EconoMode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

MEt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Enhanced I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

PJL overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Printer functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Engine control unit/power system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Image formation system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Printer paper-feed system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Jam detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Basic sequence of operation (formatter-to-printer) . . . . . . . . . . . . . . . . . . . . 71

5 Removal and replacement

Chapter contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Removal and replacement strategy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Required tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Before performing service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Print cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Parts removal order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Differences between the printers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Locating the printer differences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Left side cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Back cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Right side cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Top cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Control panel assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Front cover assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

iv Contents ENWW

Internal assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Transfer roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Formatter (hp LaserJet 1300 series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Formatter (hp LaserJet 1150 printer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Laser/scanner assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Fuser assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Output rollers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

E-label assembly (hp LaserJet 1300 only) . . . . . . . . . . . . . . . . . . . . . . . . . 109

Motor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Solenoid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Fan assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Right plate assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Pickup assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Pickup roller shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Paper lift plate assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Left plate assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Bottom assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

ECU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Paper feed assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Paper-feed roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

6 Troubleshooting

Chapter contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Basic troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Control panel light messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Fatal error secondary messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Accessory error secondary messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

Checking the print cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

Solving image-quality problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Solving paper-feed problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Functional checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Engine test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Half self-test functional check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

Drum rotation functional check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

Heating element check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

High-voltage power supply check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

Paper path check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Service mode functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

NVRAM initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Cold reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164

PJL software commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

ENWW v

Troubleshooting tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

Internal reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

Repetitive image defect ruler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

Main wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Locations of connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Locations of LEDs, jumpers, and switches . . . . . . . . . . . . . . . . . . . . . . . . . 175

7 Parts and diagrams

Chapter contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Ordering parts and supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Related documentation and software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

How to use the parts lists and diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Common hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Assembly locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Internal assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Internal components (1 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Internal components (2 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

Left side plate assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Right side plate assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Electrical components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196

Paper pickup assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Paper feed guide assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

Fuser assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Alphabetical parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

Numerical parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208

Index

vi Contents ENWW

Figures

Figure 1. HP LaserJet 1150 printer label (220 volt) . . . . . . . . . . . . . . . . . . . . . . . 19

Figure 2. HP LaserJet 1300 printer label (110 volt) . . . . . . . . . . . . . . . . . . . . . . . 19

Figure 3. HP LaserJet 1300 printer label (220 volt) . . . . . . . . . . . . . . . . . . . . . . . 19

Figure 4. Front and side view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Figure 5. Back and side view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 6. Dimensions of printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Figure 7. Printer control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 8. Light status legend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Figure 9. Output bin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Figure 10. Straight-through output door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Figure 11. Basic configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Figure 12. Printer unit functional block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Figure 13. ECU loads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Figure 14. Overview of laser/scanner operation . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Figure 15. High-voltage power supply circuit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Figure 16. Image formation block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Figure 17. Printer path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Figure 18. Solenoid, photosensors, and switches . . . . . . . . . . . . . . . . . . . . . . . . . 70

Figure 19. General timing diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Figure 20. Removing the print cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Figure 21. Printer differences (front) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Figure 22. Printer differences (left side). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Figure 23. Printer differences (right side) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Figure 24. Removing the left side cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Figure 25. Removing the back cover (1 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Figure 26. Removing the back cover (2 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Figure 27. Removing the right side cover (1 of 3) . . . . . . . . . . . . . . . . . . . . . . . . . 84

Figure 28. Removing the right side cover (2 of 3) . . . . . . . . . . . . . . . . . . . . . . . . . 85

Figure 29. Removing the right side cover (3 of 3) . . . . . . . . . . . . . . . . . . . . . . . . . 86

Figure 30. Removing the top cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Figure 31. Removing the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Figure 32. Removing the front cover (1 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Figure 33. Removing the front cover (2 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Figure 34. Removing the print cartridge door (1 of 2) . . . . . . . . . . . . . . . . . . . . . . 91

Figure 35. Removing the print cartridge door (2 of 2) . . . . . . . . . . . . . . . . . . . . . . 92

Figure 36. Removing the front guide assembly (1 of 3). . . . . . . . . . . . . . . . . . . . . 93

Figure 37. Removing the front guide assembly (2 of 3). . . . . . . . . . . . . . . . . . . . . 94

Figure 38. Removing the front guide assembly (3 of 3). . . . . . . . . . . . . . . . . . . . . 95

Figure 39. Removing the transfer roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Figure 40. Removing the HP LaserJet 1300 series formatter (1 of 2) . . . . . . . . . . 97

Figure 41. Removing the HP LaserJet 1300 series formatter (2 of 2) . . . . . . . . . . 98

ENWW Figures vii

Figure 42. Removing the HP LaserJet 1150 printer formatter (1 of 2). . . . . . . . . . 99

Figure 43. Removing the HP LaserJet 1150 printer formatter (2 of 2). . . . . . . . . 100

Figure 44. Removing the laser/scanner (1 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . 101

Figure 45. Removing the laser/scanner (2 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . 102

Figure 46. Removing the fuser assembly (1 of 4) . . . . . . . . . . . . . . . . . . . . . . . . 103

Figure 47. Removing the fuser assembly (2 of 4) . . . . . . . . . . . . . . . . . . . . . . . . 104

Figure 48. Removing the fuser assembly (3 of 4) . . . . . . . . . . . . . . . . . . . . . . . . 105

Figure 49. Removing the fuser assembly (4 of 4) . . . . . . . . . . . . . . . . . . . . . . . . 106

Figure 50. Removing the output rollers (1 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Figure 51. Removing the output rollers (2 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Figure 52. Removing the e-label assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Figure 53. Removing the motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Figure 54. Removing the solenoid (1 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Figure 55. Removing the solenoid (2 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Figure 56. Removing the fan (1 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Figure 57. Removing the fan (2 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Figure 58. Removing the right plate assembly (1 of 3) . . . . . . . . . . . . . . . . . . . . 115

Figure 59. Removing the right plate assembly (2 of 3) . . . . . . . . . . . . . . . . . . . . 116

Figure 60. Removing the right plate assembly (3 of 3) . . . . . . . . . . . . . . . . . . . . 117

Figure 61. Removing the pickup assembly (1 of 3) . . . . . . . . . . . . . . . . . . . . . . . 118

Figure 62. Removing the pickup assembly (2 of 3) . . . . . . . . . . . . . . . . . . . . . . . 119

Figure 63. Removing the pickup assembly (3 of 3) . . . . . . . . . . . . . . . . . . . . . . . 120

Figure 64. Removing the pickup roller shaft (1 of 2) . . . . . . . . . . . . . . . . . . . . . . 121

Figure 65. Removing the pickup roller shaft (2 of 2) . . . . . . . . . . . . . . . . . . . . . . 122

Figure 66. Removing the paper lift plate assembly . . . . . . . . . . . . . . . . . . . . . . . 124

Figure 67. Removing the left plate assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Figure 68. Removing the ECU (1 of 5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Figure 69. Removing the ECU (2 of 5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Figure 70. Removing the ECU (3 of 5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Figure 71. Removing the ECU (4 of 5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Figure 72. Removing the ECU (5 of 5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Figure 73. Removing the paper feed assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Figure 74. Removing the paper-feed roller (1 of 5) . . . . . . . . . . . . . . . . . . . . . . . 133

Figure 75. Removing the paper-feed roller (2 of 5) . . . . . . . . . . . . . . . . . . . . . . . 134

Figure 76. Removing the paper-feed roller (3 of 5) . . . . . . . . . . . . . . . . . . . . . . . 135

Figure 77. Removing the paper-feed roller (4 of 5) . . . . . . . . . . . . . . . . . . . . . . . 135

Figure 78. Removing the paper-feed roller (5 of 5) . . . . . . . . . . . . . . . . . . . . . . . 136

Figure 79. Reinstalling the paper-feed roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Figure 80. Control panel location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Figure 81. Engine test switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Figure 82. Locating connectors for the heating element check . . . . . . . . . . . . . . 159

Figure 83. Print cartridge high-voltage connection points (right side) . . . . . . . . . 160

Figure 84. Print cartridge high-voltage connection points (left side) . . . . . . . . . . 160

Figure 85. High-voltage connector assembly (right side) . . . . . . . . . . . . . . . . . . 161

Figure 86. High-voltage connector assembly (left side). . . . . . . . . . . . . . . . . . . . 161

Figure 87. Overriding SW301 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Figure 88. Self-test page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

viii Chapter - Figures ENWW

Figure 89. Repetitive image defect ruler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

Figure 90. Main wiring (1 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Figure 91. Main wiring (2 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Figure 92. Optional paper feeder wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

Figure 93. Locations of printer connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Figure 94. Locations of LEDs, jumpers, and switches . . . . . . . . . . . . . . . . . . . . . 175

Figure 95. Assembly locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Figure 96. Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Figure 97. Internal components (1 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Figure 98. Internal components (2 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

Figure 99. Left side plate assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Figure 100. Right side plate assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Figure 101. Electrical components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196

Figure 102. Paper pickup assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Figure 103. Paper feed guide assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

Figure 104. Fuser assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

ENWW ix

x Chapter - Figures ENWW

Tables

Table 1. Physical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Table 2. Environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Table 3. Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Table 4. Performance of HP LaserJet 1150 printer . . . . . . . . . . . . . . . . . . . . . . 17

Table 5. Performance of HP LaserJet 1300 series printer . . . . . . . . . . . . . . . . . 17

Table 6. Print operating acoustical emissions specifications . . . . . . . . . . . . . . . 18

Table 7. Skew specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Table 8. HP hardware product numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Table 9. Control panel light messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Table 10. Media types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Table 11. Life expectancies of components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Table 12. Basic sequence of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Table 13. Basic troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Table 14. Control panel lights legend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Table 15. Control panel light messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Table 16. Fatal error secondary messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Table 17. Accessory error secondary messages . . . . . . . . . . . . . . . . . . . . . . . . 147

Table 18. Solving print image-quality problems . . . . . . . . . . . . . . . . . . . . . . . . . 149

Table 19. Solving paper-feed problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Table 20. NVRAM PJL factory variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Table 21. Switch functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Table 22. Technical support websites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Table 23. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

Table 24. Common fasteners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Table 25. Printer assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Table 26. Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Table 27. Internal components (1 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Table 28. Internal components (2 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Table 29. Electrical components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Table 30. Paper pickup assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

Table 31. Fuser assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

Table 32. Alphabetical parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

Table 33. Numerical parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208

ENWW Tables xi

xii Chapter - Tables ENWW

Product information

Chapter contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Hardware description . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Firmware description . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Product specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 16

Model and serial numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Overview of printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Front and side view . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Back and side view . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Warranty statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Extended warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Limited warranty for print cartridge life . . . . . . . . . . . . . . . . . . 24

Print cartridge information . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Print cartridge date stamp . . . . . . . . . . . . . . . . . . . . . . 24

Refilled print cartridges . . . . . . . . . . . . . . . . . . . . . . . . . 25

HP LaserJet printing supplies. . . . . . . . . . . . . . . . . . . . 25

ENWW Chapter contents 13

Introduction

The HP LaserJet 1150 and 1300 series printers are designed to print documents easily with the laser-quality you have come to expect from an HP LaserJet printer.

Hardware description

The printer provides 1200 dot-per-inch (dpi) printing.

The HP LaserJet 1150 prints 18 pages per minute (ppm) on lettersize paper or 17 ppm on A4. The HP LaserJet 1300 prints 20 ppm on letter-size paper or 19 ppm on A4. With 600 x 2 (Fast Res 1200) printing resolution, these printers have exceptional text and graphics print quality. The simple control panel and improved paper handling make this product very easy to use.

The printer’s main input tray has a 250-sheet capacity for continuous, multiple-page printing. Manual, single-sheet printing is possible through the priority input tray. Both trays are center-justified for all supported paper sizes. The printer output bin holds up to 125 sheets.

The printer has a very fast first-page-out, at less than 10 seconds. The formatter board contains 8 MB of ROM, 8 MB of RAM, and an embedded 32-bit Coldfire V3 processor. The HP LaserJet 1300 has one DIMM slot available for DIMM expansion (supporting an 8 MB, 16 MB, 32 MB, or 64 MB DIMM).

The printer engine has a 1,000 average (10,000 peak) page-permonth duty cycle. The standard print cartridge life is 2,500 pages, and, for the HP LaserJet 1300 series, the high capacity print cartridge life is 4,000 pages.

The HP LaserJet 1300n printer is network ready with an HP Jetdirect 200m print server included.

14 Chapter 1 - Product information ENWW

Firmware description

The firmware in the printer includes:

z Host-based and PCL 5e printing

z Enhanced PCL 6 with status readback (HP LaserJet 1300 only)

z 80 TrueType™ fonts, plus Cyrillic, Greek, Hebrew, and Arabic

z Pixel placement, mosaic characters

z Memory Enhancement technology (MEt) with hardware

compression and decompression

The printer firmware also has Resolution Enhancement technology (REt) and EconoMode functionality.

ENWW Introduction 15

Product specifications

Table 1. Physical specifications

Category Specification

Height 253 mm (10 inches)

Depth 486 mm (19.1 inches)

Width 415 mm (16.3 inches)

Weight (cartridge installed)

Table 2. Environmental specifications

Category Specification

Operating environment (printer plugged into an AC outlet)

Storage environment (printer not plugged into an AC outlet)

8.5 kg (18.6 lb)

z Temperature: 10° to 32.5° C (50° to 90.5° F) z Humidity: 20% to 80% relative humidity

(no condensation)

z Temperature: 0° to 40° C (32° to 104° F) z Humidity: 10% to 80% relative humidity

(no condensation)

16 Chapter 1 - Product information ENWW

Table 3. Power specifications

Category Specification

Power requirements

z 110 Vac (± 10%), 60 (± 3) Hz; 127 Vac

(± 10%), 60 (± 2) Hz

-Or-

z 220 Vac (± 10%), 50/60 (± 2) Hz z 240 Vac (± 10%), 50 (± 2) Hz

Note Power sources are not

interchangeable.

Power consumption (during printing)

Power consumption (idle)

Power consumption (off)

Minimum recommende d circuit capacity

320 W

7 W

0 W

4.5 A at 115 V

2.4 A at 230 V

Table 4. Performance of HP LaserJet 1150 printer

Category Specification

Print resolution 1200 dpi

Print speed 18 ppm (Letter)

17 ppm (A4)

Table 5. Performance of HP LaserJet 1300 series printer

Category Specification

Print resolution 1200 dpi

Print speed 20 ppm (Letter)

19 ppm (A4)

ENWW Introduction 17

Table 6. Print operating acoustical emissions specifications

Category Specification

Sound Power Level,

(1 bel = 10 decibels)

WAd

Sound Pressure Level, L

(operator position)

pAm

Sound Pressure Level,

(bystander position)

pAm

6.3 Bels(A)

63 dB(A)

Table 7. Skew specifications

Category Specification

Print skew—left 0.8% (2 mm over 250 mm in length) for

cut-sheet media)

1.5% (3.3 mm over 220 mm in length) for cut-sheet media

0.87 (1.65 mm over 190 mm in width) for cut-sheet media

Print skew—right 1.5% (3.3 mm over 220 mm in width) for

envelopes, postcards, A5, and cut-sheet media

Cut-sheet leading edge skew

0.87% (1.6 mm over 190 mm in width)

18 Chapter 1 - Product information ENWW

Model and serial numbers

The model number and serial number are listed on an identification label located on the inside of the print cartridge door. The serial number contains information about the country/region of origin, revision level, production code, and production number of the printer. The label also contains power rating and regulatory information.

Figure 1. HP LaserJet 1150 printer label (220 volt)

Figure 2. HP LaserJet 1300 printer label (110 volt)

Figure 3. HP LaserJet 1300 printer label (220 volt)

ENWW Model and serial numbers 19

Overview of printer

Front and side view

Figure 4. Front and side view

1 Printer output bin

2 Long media extension

3 Print cartridge door

4 Ready light

5 Go button and light

6 Attention light

7 Main input tray

8 Priority input tray

20 Chapter 1 - Product information ENWW

Back and side view

Figure 5. Back and side view

9 Fuser pressure release levers

10 Straight-through output door

11 On/off switch

12 Power receptacle

13 USB port

14 Parallel port (HP LaserJet 1150 printer)

LIO connectivity slot (HP LaserJet 1300 series)

15 HP Jetdirect print server (HP LaserJet 1300n printer only)

16 Parallel LIO adaptor (HP LaserJet 1300 series)

ENWW Overview of printer 21

Warranty statement

DURATION OF WARRANTY: One year from date of purchase.

1 HP warrants to you, the end-user customer, that HP hardware, accessories, and

supplies, will be free from defects in materials and workmanship after the date of

purchase, for the period specified above. If HP receives notice of such defects

during the warranty period, HP will, at its option, either repair or replace products

which prove to be defective. Replacement products may be either new or

like-new.

2 HP warrants to you that HP software will not fail to execute its programming

instructions after the date of purchase, for the period specified above, due to

defects in material and workmanship when properly installed and used. If

HP receives notice of such defects during the warranty period, HP will replace

software media which does not execute its programming instructions due to such

defects.

3 HP does not warrant that the operation of HP products will be uninterrupted or

error free. If HP is unable, within a reasonable time, to repair or replace any

product to a condition as warranted, you will be entitled to a refund of the

purchase price upon prompt return of the product.

4 HP products may contain remanufactured parts equivalent to new in performance

or may have been subject to incidental use.

5 Warranty does not apply to defects resulting from (a) improper or inadequate

maintenance or calibration, (b) software, interfacing, parts, or supplies not

supplied by HP, (c) unauthorized modification or misuse, (d) operation outside of

the published environmental specifications for the product, or (d) improper site

preparation or maintenance.

6 HP MAKES NO OTHER EXPRESS WARRANTY OR CONDITION WHETHER

WRITTEN OR ORAL. TO THE EXTENT ALLOWED BY LOCAL LAW, ANY

IMPLIED WARRANTY OR CONDITION OR MERCHANTABILITY,

SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE IS

LIMITED TO THE DURATION OF THE EXPRESS WARRANTY SET FORTH

ABOVE. Some countries/regions, states, or provinces do not allow limitations on

the duration of an implied warranty, so the above limitation or exclusion might not

apply to you. This warranty gives you specific legal rights and you might also have

other rights that vary from country/region to country/region, state to state, or

province to province.

22 Chapter 1 - Product information ENWW

7 TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS

WARRANTY STATEMENT ARE YOUR SOLE AND EXCLUSIVE REMEDIES.

EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL HP OR ITS SUPPLIERS

BE LIABLE FOR LOSS OF DATA OR FOR DIRECT, SPECIAL, INCIDENTAL,

CONSEQUENTIAL (INCLUDING LOST PROFIT OR DATA), OR OTHER

DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. Some

countries/regions, states, or provinces do not allow the exclusion or limitation of

incidental or consequential damages, so the above limitation or exclusion may not

apply to you.

FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND, THE

WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT TO THE

EXTENT LAWFULLY PERMITTED, DO NOT EXCLUDE, RESTRICT OR

MODIFY AND ARE IN ADDITION TO THE MANDATORY STATUTORY RIGHTS

APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.

Extended warranty

For the latest information on HP SupportPack options available for the HP LaserJet 1150 and 1300 series printers, see http://lookup.supportpack.hp.com HP hardware product number for the product. See table 8 for these product numbers.

Table 8. HP hardware product numbers

. You will need the

Product Product number

HP LaserJet 1150 Q1336A

HP LaserJet 1300 Q1334A

HP LaserJet 1300n Q1335A

Optional 250-sheet paper feeder for the HP LaserJet 1300 series

ENWW Warranty statement 23

Q2485A

Limited warranty for print cartridge life

This HP print cartridge is warranted to be free from defects in materials and workmanship for cartridge life (until the HP toner is depleted).

Your HP toner is depleted when you begin to see faded or light type on your printed page. HP will, at HP’s option, either replace products which prove to be defective or refund your purchase price.

The warranty does not cover cartridges which have been refilled, are emptied, abused, misused, or tampered with in any way.

This limited warranty gives you specific legal rights. You may have other rights which vary from state to state, province to province, and country/region to country/region.

To the extent allowed by applicable law, in no event shall HewlettPackard Company be liable for any incidental, consequential, special, indirect, punitive, or exemplary damages or lost profits from any breach of this warranty or otherwise.

In the event that your product proves to be defective, please return it to place of purchase with a written description of the problem.

Print cartridge information

The print cartridge is designed to simplify replacement of the major consumable parts. The print cartridge contains the printing mechanism and a supply of toner.

At five percent page coverage, the standard print cartridge for the HP LaserJet 1150 and 1300 printers will print approximately 2,500 pages. The actual page yield obtained by a customer depends upon factors such as the percentage of coverage on the pages printed, toner density setting, EconoMode, and environmental conditions (temperature and humidity).

Print cartridge date stamp

Some HP LaserJet print cartridge packages are stamped with an alphanumeric date code. This code represents a 30-month period beyond the date of production in order to facilitate efficient inventory

24 Chapter 1 - Product information ENWW

management processes between HP and its resellers. It does not serve as an indication of toner life or relate in any way to warranty terms and conditions.

Refilled print cartridges

While Hewlett-Packard does not prohibit the use of refilled print cartridges during the warranty period or while the printer is under a maintenance contract, it is not recommended for the following reasons:

z Repairs resulting from the use of refilled print cartridges are not

covered under Hewlett-Packard warranty or maintenance contracts.

z Hewlett-Packard has no control or process to ensure that a

refilled print cartridge functions at the high level of reliability of a new HP LaserJet print cartridge. Hewlett-Packard also cannot predict the long term reliability effect on the printer from using different toner formulations found in refilled cartridges.

z The print quality of HP LaserJet print cartridges influences the

customer’s perception of the printer. Hewlett-Packard has no control over the actual print quality of a refilled print cartridge.

HP LaserJet printing supplies

In many countries/regions, this product’s printing supplies (such as print cartridge, drum, and fuser) can be returned to Hewlett-Packard through the HP printing supplies returns and recycling program. This easy-to-use, free takeback program is available in over 48 countries/regions. Multilingual program information and instructions are included in every new HP print cartridge and consumables package.

HP printing supplies returns and recycling program information

Since 1990, the HP printing supplies returns and recycling program has collected millions of used print cartridges that otherwise might have been discarded in the world’s landfills. The HP LaserJet print cartridges and consumables are collected and bulk-shipped to our resource and recovery partners who disassemble the print cartridge. After a thorough quality inspection, selected parts are reclaimed for use in new print cartridges. Remaining materials are separated and converted into raw materials for use by other industries to make a variety of useful products.

ENWW Print cartridge information 25

U.S. recycling returns

For a more environmentally responsible return of used print cartridges and consumables, Hewlett-Packard encourages you to use bulk returns. Simply bundle two or more print cartridges together and use the single, prepaid, pre-addressed label that is supplied in the package. For more information in the U.S., call (800) 340-2445 or visit the HP LaserJet supplies Web site at http://www.hp.com/recycle

Non-U.S. recycling returns

Non-U.S. customers should call the local HP sales and service office or visit the http://www.hp.com/recycle

website more information regarding availability of the HP printing supplies returns and recycle program.

For more information

For more information on the following HP environmental programs, see http://www.hp.com/go/environment

z Product environmental profile sheet for this and many related HP

products

z HP's commitment to the environment

z HP's environmental management system

z HP's end-of-life product return and recycling program

z Material safety data sheets

Material safety data sheet

Material safety data sheets (MSDS) can be obtained by contacting the HP LaserJet supplies website at http://www.hp.com/go/msds

26 Chapter 1 - Product information ENWW

Installation and

operation

Chapter contents

Operating environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Identifying printer components . . . . . . . . . . . . . . . . . . . . . . . . 29

Printer control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Control panel light patterns. . . . . . . . . . . . . . . . . . . . . . 30

Selecting media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Loading media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Printer output paths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

ENWW Chapter contents 27

Operating environment

Place the printer on a sturdy, level surface in a well-ventilated, dustfree area that meets the following environmental requirements:

z temperature: 10° to 32.5° C (50° to 90.5° F)

z humidity: 20% to 80% relative humidity (no condensation)

z away from direct sunlight, open flames, and ammonia fumes

z sufficient space around the printer to allow for proper access and

ventilation

643 mm (25.3 inches)

253 mm (10.0 inches)

Figure 6. Dimensions of printer

28 Chapter 2 - Installation and operation ENWW

Identifying printer components

Printer control panel

The printer control panel has two lights and one lighted button. These lights produce patterns that identify the printer status.

Figure 7. Printer control panel

z GO button and light—Prints demo pages. (To print a demo page

or to continue printing while in manual feed mode, press and release the G

z Ready light—Indicates that the printer is ready to print.

z Attention light—Indicates that the main input tray is empty, print

cartridge door is open, print cartridge is missing, or other errors.

O button.)

Ready light (green)

Go button and

light (green)

Attention light (amber)

ENWW Identifying printer components 29

Control panel light patterns

Light off

Light on

Light blinking

Figure 8. Light status legend

Note For detailed information on solving problems indicated by control panel

lights, see “Errors” on page 142.

Table 9. Control panel light messages

Light status

Condition of the printer Action

Ready

The printer is ready to print.

Processing

The printer is receiving or processing data.

No action is necessary. To print a demo page, press and release the the printer control panel.

Wait for the job to print.

GO button on

30 Chapter 2 - Installation and operation ENWW

+ 192 hidden pages
