Getinge Sterilizer User manual

GETINGE SIGNATURE SERVICE

QUICK REFERENCE
EQUIPMENT PARTS GUIDE

THE GETINGE GROUP is a leading global provider of
equipment and systems that contribute to quality
enhancement and cost efficiency within healthcare and life
sciences. Equipment, services and technologies are supplied
under the brands ARJO for patient hygiene, patient handling
and wound care, GETINGE for infection control and
prevention within healthcare and life science and MAQUET for
surgical workplaces, cardiopulmonary and critical care.

To order a printed copy of the Getinge 2006 Quick Reference,

use item number PGHC.

Table Of Contents

Sterilizer Controls 3

M/C II 3
PACS-2000 / 3000 4

Sterilizers

VINTAGE STERILIZERS 5
3500 SERIES 7
3600 SERIES 13
6900 SERIES 17
4200 (MPS) SERIES 19
100 SERIES 21
200 SERIES 23
400/500 SERIES 25
700 SERIES 27
800 SERIES 29

Warming Cabinets

5520/5525/5530 33
5540/5545/5550 34
5524/5618/5624 35

20-30-36KW Steam Generators
Washers

CASTLE 7515 39
CASTLE 7538 39
CASTLE 7550 40
2415 SONIC / RINSER DRYER 41
2460-UC SONIC CLEANER 43
2460-RD RINSER DRYER 44
GE FANUC CONTROLS 45
GE VERSAMAX CONTROLS 46
EAGLE SIGNAL 190+ CONTROLS 46
76-7700 CART WASHERS 47
78-7900 CART WASHERS 55
7642, 7652, 7662 INDEX WASHERS 59
7622 – CR22 DECONTAMINATOR 67
7626 – CR26 DECONTAMINATOR 71
4656 DISINFECTOR (DECOMAT) 75
46-X DISINFECTOR (PACS-300) 79
8666 DISINFECTOR (DECOMAT) 81
8666 DISINFECTOR (PACS-300) 87

5

33

37
39

1

Table Of Contents

MAQUET 1130/1131/1420/1425/1532/1533

RO Water Systems 89

HS-200 BOILER MATE 89
HS-450-PT 90
HS-1000 91
HS-2400 92
HS-4800 93
HS-9600 94
HS-15000 95

Surgical Tables 97

MAQUET 1132.0XX ALPHASTAR 97
MAQUET 1133.0XX ALPHAMAX 98

SHAMPAINE / ALM ST004 101
CMAX 105

Surgical Lights 107

ALM PRISMATIC ECL / PRC 107
ALM ANGENIEUX 108
ALM PRISMALIX (PRX) 109
ALM X'TEN & AXCEL 110
ALM ENERGIX (WPS II) CONTROLS 110
LDR (CONCEALED LIGHTING BOX) 111
21st CENTURY SERIES 112
HERAEUS 2000 SERIES 113
HERAEUS CITY SERIES 114
HERAEUS BLUE 30 & 80 114
CASTLE 2000 SERIES 115
CASTLE 2500-2900 SERIES 115
CASTLE 2300-2400 SERIES 116
GETINGE/CASTLE 500-700 116

Manuals / Literature 117

M/C STERILIZERS 117
PACS-2000 STERILIZERS 118
PACS-3000 STERILIZERS 119
STEAM GENERATORS/ANCILLARY 119
SONIC CLEANERS/RINSER DRYERS 120
WASHERS 120
WARMING CABINETS & AERATORS 121
OPERATING TABLES/LIGHTS 121

99

2

Sterilizer Controls

M/C CONTROLS

Power Supply Board (M/CII) 511411
Display Board 68950
Control Board 513427
Pressure Transducer M/C I 61301605830
Pressure Transducer M/C II 61301605830
RTD Temperature Probe (With Fittings) 530660

Solid-State Relays

AC Input (Yellow) 86407
AC Output (Black) 86408
DC Input (White) 518127
DC Output (Red) 56039

2.5 Amp (3600 Door) 69089

Batteries

Data Logger / Message Ctr 9V 86983
M/C I 8V 89280
M/C II 8V 511427

Circuit Breakers

2.0A White 86595

5.0A Orange 87489

7.5A White 86998
15A White 86596

Message Center 513973

Printer Mechanism 536079
Paper Roll (8) Per Pkg. 61301600005
Ribbon Cassette 61301600006

Upgrades from MCII to PACS 2000 or 3000 are available.

3

Sterilizer Controls

PACS 2000 CONTROLS

Pressure Transducer 61301600636
Seal For Pressure Transducer 61301609008
RTD Temperature Probe 61301600638
CM1 Board (2A2U) 61301600314
CPU Board (2A1U) 61301600313
Input / Output Board (2A3U ) 61301600263

Calibration Test Plug (Chamber, 8 pin) 61301602452
Calibration Test Plug (Jacket, 9 pin) 61301602453
Calibration Test Plug (Above Combined) 61301602980

Thermal Paper (10 Rolls) 61301601272
Take-Up Core (1) COBEX (Black) 61301603761
Take-Up Core (1) Cyber (White) 61301601611
Printer,Thermal (New, COBEX)** 61301603760
Dark Cover (Paper Compartment Door) 61301605881

** If the printer has a toggle switch or a single black button
for "Feed" & "Re-Print", order the replacement package

61301604246.

PACS 3000 CONTROLS

On/Off Panel Switch (Green) 61301608437
Liquid Level Sensor W/Term 61301601173
RTD Temperature Probe 61301600638
RTD Load Probe 61301600231
Pressure Transducer 61301600636
Seal For Pressure Transducer 61301609008
PCB, CPU, - 1U 61301608297
PCB, CMI, - 2U 61301600314
OP 30 Assy., Display Panel 61301608168
PCB, EMI Filter, 18 VAC., - 4U 61301600312
PCB Assy., I/O I/F - 3U 61301600263
Printer, Thermal, RS-232, 24 VAC 61301603760
Thermal Paper (10 Rolls) 61301601272
Take-Up Core (1) 61301603761

4

3200, 3400, ELECTRILOK

Sterilizers

STRAIGHTLINE (RADIAL ARM DOORS)

Door Gaskets For Sentry & 3000 Series (Also Fits T-60)

1624 Cylindrical (Red or Grey) 44599
1616 Rectangular " 44600
2020 Rectangular " 44602
2036 Cylindrical "

44601

STRAIGHTLINE VERTIGLIDE 3100, 3300

Door Gaskets See 3500 Series (Page 5)

Door Components

The cable assembly listed below is for the door system
using 2 cylindrical counter weights.

Cable
Sleeve
Thimble

Door Switch 87318

Door Gaskets

D-Shape (Blue or Red) 60864
V-Shape (Red)

Door Components

Door Motor (W/brk’t. Replaces 52083) 536846
Door Motor Capacitor 60788
Relay 120VAC,DPDT 68949
Cam Switch ("Open", "Closed", "Sealed") 513384

59851
58367
58368

517452

Emergency Crank Handle

26518

5

Sterilizers

This page is left blank intentionally.

6

Controls

(See M/C II Controls Page 3)

Door Operation Components

Sterilizers

3500 SERIES

Door Gaskets
1616 Original (Blue)

U-Shape (Green) 513966
Oversize (Grey) 517738

2020 Original (Blue)

U-Shape (Blue) 513967
Oversize (Grey) 517739

Pressure Switch (Door Gasket) 517492
Door Closed Switch (New Style)* 517458
Door Closed Switch (Old Style)* 511410
Door Cable (New W/Turnbuckle & Eye) 511400
Door Handle (Lexan) 511780

*The old style switch is separate from the cord. The new
style switch consists of the cord and the switch as one
molded assembly.

Plumbing Components

Safety Valve (40 lbs) 61301604180
Check Valve 3/4” (ASCO) 513363

Rebuild 513369

Check Valve 3/8" (ASCO) 513361

Rebuild 513369

Strainer 3/4” 36355

Replacement Screen 513448
Steam Trap 1/2” (Jacket & Chamber) 61301602492
"Air In" Filter 61301600303
Mini-Valve (Black Knob) 11929
Stone Filter Disc 61301613275
Baffle Stud Repair Kit (Requires 3) 530625
Water Ejector 59858

61301605017

61301605016

Chamber Drain Screen (Pin Trap)
3525 Drain Screen 87212

7

07181

Sterilizers

All listed solenoid valves have green molded coils. To
change from a coil with a blue casing to a green molded coil,
order one of the following:

4' Cord 517360

6' Cord 517361

8' Cord 517362

10' Cord 517363

3522 VALVES

1SV Steam To Chamber

Coil 517300

Rebuild 61301601739
2SV Chamber Drain (Rubber Diaphragm)

Coil N/A

Rebuild 54190
2SV Chamber Drain (Steel Diaphragm)

Coil 517303

Rebuild 61301600443
5SV Cooling Water

Coil 517299

Rebuild 68164
6SV Water to Ejector

Coil 517301

Rebuild 56161
5/6SV Cooling/Water to Ejector (Dual)

Coil 517301

Rebuild 61301601738
8SV Steam to Jacket

Coil 517300

Rebuild 61301601739
10/11SV Door Seal/Unseal (Brass)

Coil 517299

Rebuild 68164
10/11SV Door Seal/Unseal (Stainless)

Coil 517303

Rebuild 61301600442

517339

N/A

541581

517338

517349

517356

517339

517338

541582

8

Sterilizers

3523 VALVES

1SV Steam To Chamber (Steel Diaphragm)

Coil 517303

Rebuild 61301600443
2SV Chamber Drain (Rubber Diaphragm)

Coil N/A

Rebuild 54190
2SV Chamber Drain (Steel Diaphragm)

Coil 517303

Rebuild 61301600443
3SV Air In

Coil 517305

Rebuild 60301601740
4SV Multitherm Bypass

Coil 517300

Rebuild 60301601739
5SV Cooling Water

Coil 517301

Rebuild 517298
6SV Water to Ejector

Coil 517301

Rebuild 56161
5/6SV Cooling/Water to Ejector (Dual)

Coil 517301

Rebuild 61301601738
7SV Multitherm

Coil 517299

Rebuild 61301601739
8SV Steam to Jacket

Coil 517300

Rebuild 61301601739
10/11SV Door Seal/Unseal (Brass)

Coil 517299

Rebuild 68164
10/11SV Door Seal/Unseal (Stainless)

Coil 517303

Rebuild 61301600442

541581

N/A

541581

517347

517339

517354

517348

61301601577

517353

517339

517338

541582

9

Sterilizers

3533 VALVES

1SV Steam To Chamber

Coil 517300

Rebuild 60301601739
2SV Chamber Drain (Rubber Diaphragm)

Coil N/A

Rebuild 54190
2SV Chamber Drain (Steel Diaphragm)

Coil 517303

Rebuild 61301600443
3SV Air In

Coil 517305

Rebuild 61301601740
5SV Cooling Water

Coil 517299

Rebuild 68164
6SV Water to Ejector

Coil 517301

Rebuild 56161
5/6SV Cooling/Water to Ejector (Dual)

Coil 517301

Rebuild 61301601738
8SV Steam to Jacket

Coil 517300

Rebuild 61301601739
10/11SV Door Seal/Unseal (Brass)

Coil 517299

Rebuild 68164
10/11SV Door Seal/Unseal (Stainless)

Coil 517303

Rebuild 61301600442

517339

N/A

541581

517347

517338

517349

517356

517339

517338

541582

10

Sterilizers

3525 VALVES

1SV Steam To Chamber

Coil 517300

Rebuild 61301601739
2SV Chamber Drain (Rubber Diaphragm)

Coil N/A

Rebuild 54190
2SV Chamber Drain (Steel Diaphragm)

Coil 517303

Rebuild 61301600443
2DV Drain Diaphragm

Diaphragm Rebuild 517153
6SV Water to Ejector

Coil 517301

Rebuild 56161
10/11SV Door Seal/Unseal (Brass)

Coil 517299

Rebuild 68164
10/11SV Door Seal/Unseal (Stainless)

Coil 517303

Rebuild 61301600442
12SV Pilot Air to Drain Diaphragm SS

Coil 517303

Rebuild 61301600442
13SV Spray Water

Coil 517301

Rebuild 54187
14SV Detergent

Coil N/A

Rebuild (plunger) 21513
16SV Vent

Coil 517300

Rebuild 61301601739

517339

N/A

541581

37829

517349

517338

541582

541582

517343

14029

517339

11

Sterilizers

This page is left blank intentionally.

12

Sterilizers

3600 SERIES

Controls (See M/C II Controls Page 3)

Door Gasket (Red)
Door Gasket (Blue)

Door Operation Components

Hall Effect Position Switch 5V 518083

Power Door

Chamber Press Switch 530931
Door Motor & Cord 539384

Manual Door

Air Cylinder 541577
Water Cylinder 518146
Hook Cylinder Side (Water Only) 518386

Refer to the valves list for the solenoid and diaphragm.

Plumbing Components

Safety Valve (40 lbs) 56913
1/2” Check (ASCO) 513362

Rebuild 513369
Check Valve 3/4” (ASCO) 513363

Rebuild 513369
Check Valve 1" (ASCO) 513699

Rebuild 513700
Strainer 3/4” 36355

Replacement Screen 513448
Strainer 1” 50952

Replacement Screen 513449
Steam Trap 1/2” 61301602492
Steam Trap 3/4" 23614

Rebuild 27557
"Air In" Filter (Needs 2) 61301600303
Heat Exchanger (Brass 5 X 14) 66783
Water Ejector 60699

536651
61301602425

Chamber Drain Screen (Pin Trap)

13

23815

Sterilizers

All listed solenoid valves have green molded coils. To
change from a coil with a blue casing to a green molded coil,
order one of the following:

4' Cord 517360

6' Cord 517361

8' Cord 517362

10' Cord 517363

3622 VALVES

1SV Steam To Chamber

Coil 517304

Rebuild 61301604084
2SV Chamber Drain

Coil 517304

Rebuild 61301604084
3SV Air In (Steel Diaphragm)

Coil 517303

Rebuild 61301600443
5/6SV Wtr. To Drn & Ejector (Dual)

Coil 517301

Rebuild 61301601738
7SV Multitherm

Coil 517300

Rebuild 61301601739
8SV Steam to Jacket

Coil 517299

Rebuild 54186

Manual Doors
12SV Air To Door Cylinder

Coil 517303

Rebuild 68381
12SV Water To Door Cylinder

Coil 517303

Rebuild 61301601837
Diaphragm Valve (Safety Shut-Off)

Rebuild 61301603671

4 Way Valve (Air Only)
4 Way Valve (Water Only)

61301604083

61301604083

541581

517356

517339

517342

517357

541627

61301605027

541576
517523

14

Sterilizers

3633 VALVES

1SV Steam To Chamber

Coil 517304

Rebuild 61301604084
2SV Chamber Drain

Coil 517304

Rebuild 61301604084
3SV Air In (Steel Diaphragm)

Coil 517303

Rebuild 61301600443
4SV Multitherm Bypass

Coil 517300

Rebuild 61301601739
5/6SV Wtr. To Drn & Ejector (Dual)

Coil 517301

Rebuild 61301601738
7SV Multitherm

Coil 517300

Rebuild 61301601739
8SV Steam to Jacket

Coil 517299

Rebuild 54186

Manual Doors
12SV Air To Door Cylinder

Coil 517303

Rebuild 68381
12SV Water To Door Cylinder

Coil 517303

Rebuild 61301601837
Diaphragm Valve (Safety Shut-Off)

Rebuild 61301603671

4 Way Valve (Air Only)
4 Way Valve (Water Only)

61301604083

61301604083

541581

517339

517356

517339

517342

517357

541627

61301605027

541576
517523

15

Sterilizers

This page is left blank intentionally.

16

6900 SERIES

Controls

(See M/C II Controls Page 3)

Door Operation Components

Sterilizers

Door Gasket Original Round (Green)

U-Shaped (Green)

Oversized (Grey)

"Door Closed" Internal Switch (1S/4S) 61301605325
"Door Jammed" Internal Switch (3S/6S) 61301605325
"Door Opened" Switch (2S/5S) 50982
Door Lift Screw 40458
Door Lift Nut (Brass) 40460
Timing Belt 47392
Motor Only 533596
Mounting Brackets (Need 2) 536663
Pressure Switch 517493
"U"-Bracket For New Style Pressure Sw 517494

Plumbing Components

Safety Valve (40 lbs) 56913
Check Valve 1/4” (Stainless Steel) 66838
Check Valve 3/8” 19112
Check Valve 3/4" Inline (Conbraco) 08045
Check Valve 1" Inline (Conbraco) 21815
Check Valve 1-1/4" Inline 14882
Strainer 1” 50952

Replacement Screen 513449
Steam Trap 3/4" 23614

Rebuild 27557
"Air In" Filter (Needs 2) 61301600303

Spray Arms

Outer Spinner Bearing (Short - 1/2") 41135
Inner Spinner Bearing (Long-3/4") 41136
End Plug 536958
Set Screw For End Plug E5008

40441
513968
517553

17

Sterilizers

6900 AMPS VALVES

1SV Steam To Chamber

Coil 517299

Rebuild 54186
22SV Trap Drain (Steel Diaphragm)

Coil 517303

Rebuild (Plunger) 61301600443

30M Chamber Drain (Ball Valve)
3SV Air In

Coil 517299

Rebuild 54186
6SV Water to Ejector

Coil 517301

Rebuild 54187
14SV Detergent

Coil N/A

Rebuild (Plunger) 21513
15SV Steam To Sump (Steel Diaphragm)

Coil 517303

Rebuild (Plunger) 61301600443
17SV Hot Water

Coil 517301

Rebuild 61301601818
26SV Cold Water

Coil 517301

Rebuild 61301601818
27SV Condenser Water

Coil 517301

Rebuild 54198
28SV Special Water

Coil 517301

Rebuild 61301601818
3-Way Air (SS) 541582

Coil 517302

Rebuild 54188

517342

541581

61301604372
517342

517343

14029

541581

517341

517341

517340

517341

18

4200 (MPS) SERIES

Controls

(See M/C II Controls Page 3)

Door Operation Components

Sterilizers

Door Gasket D-Shape (Blue or Red)

V-Shape (Red)

Door Safety Bellows & Housing (MPS) 35789
Door Motor (W/brk’t. Replaces 52083) 536846
Door Motor Capacitor 60788
Relay 120VAC,DPDT 68949
Cam Switch ("Open", "Closed", "Sealed") 513384
Hook Lift Lever 27900

Plumbing Components

Safety Valve (40 lbs) 56916
Check Valve 3/4” (ASCO) 513363

Rebuild 513369
Check Valve 3/4” Inline (Conbraco) 08045
Check Valve 1" (ASCO) 513699

Rebuild 513700
Check Valve 11/2” Inline (Conbraco) 61301602477
Strainer 3/4” 36355

Replacement Screen 513448
Strainer 1” 50952

Replacement Screen 513449
Steam Trap 3/8” 68722
Steam Trap 3/4" 23614

Rebuild 27557
"Air In" Filter (Needs 2) 61301600303
1/4” Air Reg. 32696
Water Ejector (42" Unit) 66784
Water Ejector (76" Unit) 66762

Chamber Drain Screen (Pin Trap)

60866
517453

36690

19

Sterilizers

All listed solenoid valves have green molded coils. To
change from a coil with a blue casing to a green molded coil,
order one of the following:

4' Cord 517360

6' Cord 517361

8' Cord 517362

10' Cord 517363

4200 MPS VALVES

1SV Steam To Chamber (Steel Diaphragm)

Coil 517303

Rebuild 61301600443
2SV Pilot Air to Drain Diaphragm SS

Coil 517303

Rebuild 61301600442
2DV Drain Diaphragm

Rebuild 517154
3SV Air In (Steel Diaphragm)

Coil 517303

Rebuild 61301600443
5SV Cooling Water

Coil 517301

Rebuild 54187
6SV Water to Ejector (42")

Coil 517301

Rebuild 61301601818
6SV Pilot Air to Water Diaphragm SS (76")

Coil 517303

Rebuild 61301600442
6DV Water Diaphragm (76" Only)

Rebuild 517153
8SV Steam to Jacket

Coil 517299

Rebuild 54186

541581

541582

37831

541581

517343

517341

541582

37829

517342

20

Controls

(See PACS-2000 Controls Page 4)

Door Operation Components

Sterilizers

100 SERIES

Door Gaskets
1616 Original (Blue)

U-Shape (Green) 513966

Oversize (Grey) 517738
2020 Original (Blue)

U-Shape (Blue) 513967

Oversize (Grey) 517739

Gasket Pressure Switch 61301600350
Door Switch (3S,7S) Center Mount 61301601670
Door Cable (W/Turnbuckle & Eye) 511400
Door Handle 511780

Plumbing Components

Safety Valve (40 lbs) 61301604180
Check Valve 3/4” (ASCO) 513363

Rebuild 513369
Check Valve 3/8 (ASCO) 513361

Rebuild 513369
Strainer 3/4” 36355

Replacement Screen 513448
Drain Temp Switch 539126
Float Switch "Water In Drain" 61301601173
Steam Trap 1/2” (Jacket & Chamber) 61301602492
"Air In" Filter 61301600303
Mini-Valve (Black Knob) 11929
Stone Filter Disc 61301613275
Baffle Stud Repair Kit (Requires 3) 530625
Water Ejector 59858

61301605017

61301605016

Chamber Drain Screen (Pin Trap)

07181

21

Sterilizers

100 SERIES VALVES

1SV Steam To Chamber

Coil 61301600154

Rebuild 61301601739
2SV Chamber Drain

Coil 61301600157

Rebuild 61301600443
3SV Air In

Coil 61301600156

Rebuild 61301601740
4SV Multitherm Valve

Coil 61301600154

Rebuild 61301601739
5/6SV Cooling/Water to Ejector (Dual)

Coil 61301600153

Rebuild 61301601738
7SV Multitherm

Coil 61301600157

Rebuild 61301601742
8SV Steam to Jacket (Black Coil)

Coil 61301604049

Rebuild N/A
8SV Steam to Jacket (Green Coil)

Coil 61301600154

Rebuild 61301601739
10,11,12,13SV Door Seal/Unseal

Coil 61301600153

Rebuild 61301601737
Black to Green Coil Cord Adapter 61301609802

61301601697

61301601701

61301601698

61301601697

61301601696

61301601700

61301609872

61301601697

61301601695

22

Sterilizers

200 SERIES

Controls (See PACS-2000 Controls Page 4)

Door Gasket

Door Operation Components

Door Plate Switch 61301602316
Hall Effect Position Switch 61301600639

Power Door

Chamber Press Switch 530931
Door Motor 539384
Door Motor Capacitor 518162
Door Motor Relay 61301601073

Manual Door

Air Cylinder 541577

Refer to the valves list for the solenoid and diaphragm.

Plumbing Components

Safety Valve (45 lbs) 61301601576
Check Valve 3/4” (ASCO) 513363

Rebuild 513369
Strainer 3/4” 36355

Replacement Screen 513448
Strainer 1” 50952

Replacement Screen 513449
Drain Temp Switch 539126
Float Switch "Water In Drain" 61301601173
Steam Trap 1/2” (Jacket) 61301602492
Steam Trap 3/4" (Chamber) 23614

Rebuild 27557
Steam Trap 3/4" (Chamber HC/LS Only ) 61301603751

Rebuild 61301603755
"Air In" Filter (Needs 2) 61301600303
Heat Exchanger (Brass 5 X 14) 66783
Water Ejector 60699

61301600108

Chamber Drain Screen Assy. (Pin Trap)

Replacement Screen 61301600512

23

61301604624

Sterilizers

200 SERIES VALVES

1SV Steam To Chamber

Coil 61301600157

Rebuild 61301600443
2SV Chamber Drain

Coil 61301600429

Rebuild 61301604084
3SV Air In

Coil 61301600157

Rebuild 61301600443
5/6SV Cooling/Water to Ejector (Dual)

Coil 61301600153

Rebuild 61301601738
8SV Steam to Jacket

Coil 61301600157

Rebuild 54186

Manual Doors Only
12SV Air To Door Cylinder (Manual Door)

Coil 61301600157

Rebuild 61301601837
Diaphragm Valve (Safety Shut-Off)

Rebuild 61301603671
4 Way Valve 541576

61301601701

61301601702

61301601701

61301601696

61301603374

61301601836

61301605027

24

Controls

(See PACS-3000 Controls Page 4)

Door Operation Components

Sterilizers

400/500 SERIES

Door Gaskets
400 Series Blue Gasket With Red Stripe

Convert From Graphite Kit
500 Series Blue Gasket With Red Stripe

Convert From Graphite Kit 61301609373

Door "Not Closed" Switch 3S/7S 61301608277

Power Door Components

Door "Opened" Switch 61301608277
Door Motor 61301601143
Capacitor, Door Motor Run 2.5 MFD 61301608490
Resistor, PWR, 50W, 400 Ohm 61301608173
Relay, DPDT 24VAC 61301601073

Plumbing Components

Safety Valve (45 lbs) 61301608100
Check Valve 3/4” (ASCO) 513363

Rebuild 513369
Check Valve 3/8 (ASCO) 513361

Rebuild 513369
Strainer 3/4” 36355

Replacement Screen 513448
Drain Temp Switch 539126
Float Switch "Water In Drain" 61301601173
Steam Trap 1/2” (Jacket) 61301602492
Steam Trap 3/8” (Drip Leg) 68722
"Air In" Filter 61301600303
Mini-Valve (Black Knob) 11929
Water Ejector 59858

61301609895
61301609371
61301609896

Chamber Drain Screen (Pin Trap)
Secondary Chamber Bleed Drain Screen 61301608303

25

61301608230

Sterilizers

400/500 SERIES VALVES

1-8-10-12SV Chmbr,Jckt, Door (Green Coil)

Coil 61301600154

Rebuild 61301601739
1-8-10-12SV Chmbr,Jckt, Door (Black Coil)

Coil 61301604049

Rebuild N/A
2SV Chamber Drain

Coil 61301600157

Rebuild 61301600443
3SV Air In (Green Coil)

Coil 61301600156

Rebuild 61301608453
3SV Air In (Black Coil)

Coil 61301609452

Rebuild 61301609451
5/6SV Wtr. To Drn & Ejector (Dual)

Coil 61301600153

Rebuild 61301601738
5SV Cooling Water (Black Coil)

Coil 61301608962

Rebuild 61301608963
6SV Water To Ejector (Black Coil)

Coil N/A

Rebuild 61301609505
14SV Secondary Drain (Green Coil)

Coil 61301600153

Rebuild 61301601737
14SV Secondary Drain (Black Coil)

Coil 61301608962

Rebuild 61301608963

61301601697

61301609872

61301601701

61301608423

61301609450

61301601696

61301608583

61301609315

61301601695

61301608583

Black to Green Coil Cord Adapter 61301609802

26

Sterilizers

700 SERIES

Controls (See PACS-3000 Controls Page 4)

Door Gasket (Blue)

Convert From Graphite Kit 61301609375

Door Operation Components

Door Position Switch DPST 6A. ANCR 61301602316
Door Position Switch 10A NO/NC Snap 61301608795

Door Motor Control Board 90VDC 61301608595
Clutch (Torque Coupler) 61301608991
Relay, 3PDT 24VAC 61301608830
Relay, Latch ,MAG,DPDP,24VAC 61301604716

Plumbing Components

Safety Valve (45 lbs) 61301608100
Check Valve 3/4” (ASCO) 513363

Rebuild 513369
Check Valve 3/8 (ASCO) 513361

Rebuild 513369
1” Strainer 50952

Replacement Screen 513449
Drain Temp Switch 539126
Float Switch "Water In Drain" 61301601173
Steam Trap 1/2” (Jacket) 61301602492
Steam Trap 3/8” (Drip Leg) 68722
1/4” Air Reg. 32696
Heat Exchanger 61301608571
"Air In" Filter (Needs 2) 61301600303
Mini-Valve (Black Knob) 11929
Water Ejector 60699

Chamber Drain Screen (Pin Trap)
Secondary Chamber Bleed Drain Screen 61301608303

61301609366

61301608230

27

Sterilizers

700 SERIES VALVES

1SV Steam To Chamber (Green Coil)

Coil 61301600157

Rebuild 54186
1SV Steam To Chamber (Black Coil)

Coil 61301604049

Rebuild N/A
2V Chamber Drain (Pneumatic)

Actuator Seal Kit 61301608964

Rebuild 61301608965
3V Air In (Pneumatic)

Actuator Seal Kit 61301608964

Rebuild 61301608965
5/6SV Wtr. To Drn & Ejector (Dual)

Coil 61301600153

Rebuild 61301601738
5SV Cooling Water (Black Coil)

Coil 61301609378

Rebuild 61301608853
6SV Water To Ejector (Black Coil)

Coil N/A

Rebuild 61301609505
8SV Steam to Jacket (Green Coil)

Coil 61301600157

Rebuild 54186
8SV Steam to Jacket (Black Coil)

Coil 61301604049

Rebuild N/A
10/12SV Door Seal/Unseal (Green Coil)

Coil 61301600154

Rebuild 61301601739
10/12SV Door Seal/Unseal (Black Coil)

Coil 61301604049

Rebuild N/A
14SV Secondary Drain

Coil 61301608962

Rebuild 61301608963
Air Pilot Valve (3/2 .250, 24V) VALTE0013

61301603374

61301609872

61301608458

61301608458

61301601696

61301608852

61301609315

61301603374

61301609872

61301601697

61301609872

61301608583

28

Sterilizers

800 SERIES

Controls (See PACS-3000 Controls Page 4)

Door Gasket (Blue)

Convert From Graphite Kit 61301609903

Door Operation Components

Door Gasket Pressure Switch 30-60 PSI 61301608845
"Door Open-Decel-Swing-In" Switch 61301608795
"Door Closed" Switch (3/7S) 61301602316
"Slide Out" Door Switch (25/26S) 61301608277
Door Motor Control Board 90VDC 61301608595
Clutch (Torque Coupler) 61301608991
Relay, DPDT 24VAC 61301601073
Relay, Latch ,MAG,DPDP,24VAC 61301604716

Plumbing Components

Safety Valve (45 lbs) 61301601576
Check Valve 3/4” (ASCO) 513363

Rebuild 513369
Check Valve 3/8 (ASCO) 513361

Rebuild 513369
1” Strainer 50952

Replacement Screen 513449
Drain Temp Switch 539126
Float Switch "Water In Drain" 61301601173
Steam Trap 1/2” (42" Only) 61301602492
Steam Trap 3/4” (76" Only) 61301603751

Rebuild 61301603755
1/4” Air Reg. 32696
Heat Exchanger 61301608571
"Air In" Filter (Needs 2) 61301600303
Water Ejector (42" Unit) 60699
Water Ejector (76" Unit) 66762

Chamber Drain Screen (Pin Trap)
Secondary Chamber Bleed Drain Screen 61301608303

61301609559

61301609474

29

Sterilizers

800 SERIES 42" VALVES

1SV Steam To Chamber (Green Coil)

Coil 61301600157

Rebuild 54186
1SV Steam To Chamber (Black Coil)

Coil 61301604049

Rebuild N/A
2SV Chamber Drain (Pneum)

Actuator Seal Kit 61301609379

Rebuild 61301609893
3SV Air In (Pneum)

Actuator Seal Kit 61301608964

Rebuild 61301608965
5SV Cooling Water

Coil 61301609378

Rebuild 61301608853
6SV Water to Ejector

Coil N/A

Rebuild 61301609505
8SV Steam to Jacket (Green Coil)

Coil 61301600157

Rebuild 54186
8SV Steam to Jacket (Black Coil)

Coil 61301604049

Rebuild N/A
10/12SV Door Seal/Unseal (Green Coil)

Coil 61301600157

Rebuild 54186
10/12SV Door Seal/Unseal (Black Coil)

Coil 61301604049

Rebuild N/A
14SV Secondary Drain

Coil 61301608962

Rebuild 61301608963

Air Pilot Valve (Head & Tail) VALTE0012
Air Pilot Valve (3/2 .250, 24V) VALTE0013
Black to Green Coil Cord Adapter 61301609802

61301603374

61301609872

61301609873

61301608458

61301608852

61301609315

61301603374

61301609872

61301603374

61301609872

61301608583

30

Sterilizers

800 SERIES 76" VALVES

1SV and 8SV Solenoids to Pneum. Pkg.
1V Steam to Chamber (Pneum)

Actuator Seal Kit 61301608964

Rebuild 61301609904
2SV Chamber Drain (Pneum)

Actuator Seal Kit 61301609379

Rebuild 61301609894
3SV Air In (Pneum)

Actuator Seal Kit 61301608964

Rebuild 61301608965
5SV Cooling Water (Black Coil)

Coil 61301604049

Rebuild N/A
6V Water to Ejector (Pneum)

Actuator Seal Kit 61301608964

Rebuild 61301608965

8SV Solenoid
8V Steam to Jacket (Pneum)

Actuator Seal Kit 61301608964

Rebuild 61301609904
10/12SV Door Seal/Unseal (Green Coil)

Coil 61301600157

Rebuild 54186
10/12SV Door Seal/Unseal (Black Coil)

Coil 61301604049

Rebuild N/A
14SV Secondary Drain (Black Coil)

Coil 61301604049

Rebuild N/A

Air Pilot Valve (Head & Tail) VALTE0012
Air Pilot Valve (3/2 .250, 24V) VALTE0013
Black to Green Coil Cord Adapter 61301609802

61301609925
61301609884

61301609874

61301608458

61301609872

61301608458

See 1SV
61301609884

61301603374

61301609872

61301609872

31

Sterilizers

This page is left blank intentionally.

32

Warming Cabinets

5520/5525/5530

Controls

Display Board (Obs.Order MP-126C) 61301603218
Heater, 120V/500W 69093
Temp Sensor (2 lead) 69200
Temp Sensor (3 Lead) 517296
Circuit Breaker, 10A 69110
Circuit Breaker, 20A 69109
Power Supply Assy. 69155
Transformer 69090
Fan, 120V 69094
Potentiometer 60768
Overheat Thermostat 212° N.O. 69107
Relay, 45A (Heater) 514107
Relay, 2.5A (Fan) 61301605584
Switch, Door 69249

Misc. Components

Door Gasket (Perimeter) 69037
Shelf / Compartment Gasket 69216
Knob 69237
Foot (5530) 14813
Foot , Screw E5210
Catch, Magnetic (On Door) 60624
Door Handle 12" 69056
Door Handle 18" 69865

33

Warming Cabinets

5540/5545/5550

Controls

Display Board (Obs.Order MP-126D) 61301602894
Overheat Thermostat 212° N.O. 69107
Fuse, 3A 72441
Fuse, .25A 69425
Heater, 120V/500W 69093
Fan, 120V 69094
Circuit Breaker, 10A 69110
Circuit Breaker, 20A 69109
Power Supply Board 513013
Transformer (24V) 69090
Temp. Probe 518407
Relay,45A (Heater) 514107
Relay, 2.5A (Fan) 61301605584
Thermostat, 212 69107
Door Switch 69249

Misc. Components

Door Gasket (Perimeter) 69037
Shelf / Compartment Gasket 69216
Catch, Magnetic (On Door) 60624
Door Handle 12" 69056
Door Handle 18" 69865

34

Warming Cabinets

5524/5618/5624

Temperature Probe 61301600624
Display / CPU Board 61301600382
Power Supply Board (6 pin J2 Connector) 61301601841

If original power supply has a 7 pin J2 connector, order the
package 61301604375.

Stand-Off For Power Supply Board 61301605229
Solid State Relays – Fan & Heater (4) 61301605300
Printed Circuit Board Cont/Display 61301600382
Fuse, 12A, 2FU, Full size Warmer (115V) 61301600840
Fuse, 5A, 2FU, Half Size Warmer (115V) 61301601452
Fuse, 6.25A, 2FU, Full Size Warmer (230V) 61301600841
Fuse, 3A, 2FU, Half Size Warmer (230V) 67621
Fuse Holder (Set Of 12) 87848
Fan, Full & Half Size (115V) Internal 61301600439
Fan, Full & Half Size (230V) Internal 61301600440
Fan, Flat Pak (Top, Back Of Unit) 115V 61301602603
Fan, Flat Pak (Top, Back Of Unit) 230V 61301602604
Heater, Full & Half Size (115V) 61301600474
Heater, Full & Half Size (230V) 61301600611
6' Optional Power Cord Kit 61301605436
New Style Hinge Kit (To Convert From Old) 61301603505
Shelf Support Clip 910312600
New Style Hinge Only 912032200

Warming Cabinet Serial No. w/ "SW" Use The Following

5618/5624 Side Gasket (Qty.2) 61301603370
5524 Side Gasket (Qty.2) 61301603368
5524/5618/5624 Center Gasket (Qty.2) 61301603369

Warming Cabinet Serial No. w/ "SZ" Use The Following

5524/5618/5624 Gasket (By The Foot) R4065

35

Warming Cabinets

This page is left blank intentionally.

36

20-30-36KW Steam Generators

Universal Components

Element Gasket 49943
Element Bolts(6) 49944
3-Pole Contactor 3PH 49938
4-Pole Contactor Single Phase 51012
Sight Glass With O-Rings 9-3/4” 62790
Sight Glass With O-Rings 7-7/8" 49958
Sight Glass Valves (Pair) 49957
Angled Sight Glass Valves 61250
Spark Plug Probe 49940
Probe Insulator 68308
1/4" Feed Water Solenoid Valve (CAS-20) 61245
1/2" Feed Water Solenoid Valve (CAS-30) 536586
3/8 NPT Check Valve 19112
1/2"NPT Check Valve 19114
100 PSIG Safety Valve 49949
Pressure Control (Operating) 49947
Pressure Control ( Hi Limit W/man reset) 49948
Pressure Gauge 49941
Level Control Board 68307

Elements CAS-20 C,D,E (17 inch)

240 V 1ph 20KW 513944
208 V 3ph 20KW 513950
240 V 3ph 20KW 513946
380 V 3ph 20KW 513947
415 V 3ph 20KW 513943
480 V 3ph 20KW 513948
600 V 3ph 20KW 513945

Elements CAS-20A&AF (12 inch)

240 V 1ph 20KW 49935
240 V 3ph 20KW 49934
208 V 3ph 20KW 55967
380 V 3ph 20KW 68770
480 V 3ph 20KW 68718
Wire Assy From Contactor To Elements (1) 531065

37

20-30-36KW Steam Generators

Elements CAS-30/36

12KW

208 V 3ph 12KW 536522

240 V 1ph 12KW 536523

240 V 3ph 12KW 536524

380 V 3ph 12KW 536575

415 V 3ph 12KW 536576

480 V 3ph 12KW 536577

600 V 3ph 12KW 536578

18KW

208 V 3ph 18KW 536515

240 V 1ph 18KW 536516

240 V 3ph 18KW 536517

380 V 3ph 18KW 536518

415 V 3ph 18KW 536519

480 V 3ph 18KW 536520

600 V 3ph 18KW 536521

NOTE: Elements for all boilers ship with gasket, sealer
and 6 Bolts

PROBES

1-1/2" 531032
5" 61243
5-3/4" 61241
6-3/8" 61242

PUMPS

30 & 36 KW Pump & Motor 536585
Procon Pump 58630

Motor 58629
Teel Pump 49952
CAS-30C Pump 1.6GPM 61301608522
Plastic Flo-Jet Pump 513957

38

CASTLE 7515

CASTLE 7538

Washers

Fuse - 3A 72441
Fuse - .25A 69425
Battery - 1.5V (D) 60670
Battery Backup 530473
Det. & San. Pump Tube 511898
Viton Diaph. (Use w Tec-San) 61301600664
EPDM Diaph. (Use w Tec-Wash III) 61301600663
Post Bearing - Top Spinner 530721
Post Bearing - Bottom Spinner 530722
Spinner - Top & Bottom 541534
Spinner Cap 530720
Spray Nozzle 69657
Circulating Pump Repair Pkg. 68393
Dolly Wheels 536588
Door Gasket 69628

Rinse Agent Replacement Tube – 21” 511898
Det. Replacement Tube – 16” 511899
Mist Eliminator Gasket 530743
Sump Drain Cyl. Assy. 78499
Replacement Stopper 72084
Flex Duct 60” 517178
Replacement Clamp 517181
Mixing Valve Gasket 531121
Nozzle - Lower Spray (Angle) 86247
Nozzle - Spray Arm (V Jet) 530657
Nozzle – Condenser (Atomizer) 78496
Spray Arm Post spinner 78355
Spray Arm (hub assy) 78387
Bearing 78356
Washer 78532
Nut 78359
End Cap 530658
Door Gasket 78392

Wiper 78637

39

Washers

CASTLE 7550

Controls

Door Solenoids 125VDC (4&5 Sol.) 536271
SSR’s 523329
EPROM 531086
1 RTD (Wash) 531131
2 RTD (Dry) 531132
Door Switches 533174

Plumbing

Water Valve - (1,2,3 Sol) 533318

Coil 517301
Rebuild 72505

Steam Valve - Valve (6 Sol.) 517342

Coil 517299
Rebuild 54186

Cooling Water Valve (7 Sol.) 517343

Coil 517301
Rebuild 54187

Vapor Condenser Valve (8 Sol.) 541582

Coil 517302
Rebuild 54188

Sump Drain Valve - Valve (9 Sol.) 533319

Coil 517303
Rebuild 530860

Seal, Cover, Flap (In 5A Flange) 61301601037

Misc. Components

Detergent Wands (3) 533228
Single Wand 533158
Plastic Spinner Arm Nut 531126
Plastic Spinner Arm Bushing 531127
Squeeze Tubing Peristaltic Pump (21”) 511898
Filter, Air, 7550 533241
Complete Door Assy. 531099
Door Spring 536506
Door Gasket 531038

40

Washers

2415 SONIC / RINSER DRYER

Controls

Switch, Momentary 2002030

Lense, Amber ("LID") 2024010
Lense, Amber ("FILL") 2024011
Lense, Amber ("DRAIN") 2024012

Switch, Alternating 2002019

Lense, Red ("POWER") 2024013

Lense, Amber ("DEGAS") 2024009
Fuse 1-3/4 A Fast Blow 2003053
Fuse 3A Fast Blow 2003038
Fuse 10A Fast Blow 2003045
Fuse 15A Fast Blow 2003047
Relay, 3PDT 2006005
Generator (500W) 2026000
Timer Kit (Silver Face to Black Face) 61301602255

Timer Only (Black Face) 61301602222
Contactor (2 pole) 2007003
Timer 180 sec. Delay 2005001
Heater Strip 2030016
Level Probe 49833
Isolation Transformer 541513

Lid Components

Lid Limit Switches 2002001
Gear Motor 5101005
Electric Brake 2025008
Torque Limiter Gear Motor 536029

Misc. Components

Det. Strainer 9000023
Det. Sol. Valve (1/4") 3001039
Water Sol. Valve (1/2") 3001036
Gasket Material R3892
Injector 3023002
1/4" Needle Valve 3005021
2" Drain Valve 3002015
2" Hose (Specify Length) R3893
5/8" Rubber Tubing (Specify Length) 3013027
1/4" Plastic Tubing (Specify Length) R3839

41

Washers

This page is left blank intentionally.

42

Washers

2460-UC SONIC CLEANER

Controls

Digital Timer SS20TIME0015
Controller, PLC-20 I/O SS20PLC-0033
Light, Green SS20LIGH0010
Light, Red SS20LIGH0011
Circuit Breaker,20AMP,2 Pole SS20CIRC0001
Sonic Generator 1200W,40KHZ SSKS4012
Heater 500WATT,120V SS20HEAT0003
Switch, Rocker "Drain" SS10SWIT0021
Thermostat (Heater) TS1 SS20TEMP0001
Overheat Thermostat (Heater) TS2 SS20TEMP0009
Float Switch (Water Level) SS20LEVE0005

Lid Operation Components

Lid Lift Cylinder SS40PNEU0024
4 Way Valve (Water To Lid Cylinders) SS30VALV0400
Valve, Flow Adj. (Lid Speed) SS40PNEU0100
Tubing, 1/4" SS40TUBE0019
Pressure Regulator (Water To Cylinders) SS40REGU0008
Lid Gasket Replacement Kit SS11116-53-15
Switch, Magnetic (Lid Closed & Footswitch) SS20SWIT0025

Magnet SS20MISC0022
Proximity Switch (Detergent Level) SS20PROX0007
Switch, Front Panel Plunger SS20SWIT0005
Kick Plate SS13649
Latch, Front Panel Locking SS40LATC0004
Detergent Bottle Cap SS13689
Check Valve 1/2" SS30VALV0022
Spring (Lid) SS40MISC0100

Misc. Components

Valve, Hot Water 1/2" SS30VALV0200
Lift Roller SS12939
Check Valve 1/8" SS30VALV0023
Detergent Pump SS30PUMP0036

43

Washers

2460-RD RINSER DRYER

Controls

Digital Timer SS20TIME0015
Controller, PLC-20 I/O SS20PLC-0033
Light, Green SS20LIGH0010
Light, Red SS20LIGH0011
Circuit Breaker 30A SS20CIRC0002
Thermocouple (Temp Probe) SS20TEMP2008
Water Ejector (Detergent Injector) SS30PUMP0105
Thermostat (Overtemp) TS1 SS20TEMP0023

Lid Operation Components

Lid Lift Cylinder SS40PNEU0024
4 Way Valve (Water To Lid Cylinders) SS30VALV0400
Valve, Flow Adj. (Lid Speed) SS40PNEU0100
Tubing, 1/4" SS40TUBE0019
Pressure Regulator (Water To Cylinders) SS40REGU0008
Lid Gasket Replacement Kit SS11116-53-15
Switch, Magnetic (Lid Closed & Footswitch) SS20SWIT0025

Magnet SS20MISC0022
Proximity Switch (Detergent Level) SS20PROX0007
Switch, Front Panel Plunger SS20SWIT0005
Kick Plate SS13649
Latch, Front Panel Locking SS40LATC0004
Detergent Bottle Cap SS13689
Check Valve 1/2" SS30VALV0022
Spring (Lid) SS40MISC0100

Misc. Components

Valve, Hot Water 1/2" SS30VALV0200
Lift Roller SS12939
Check Valve 1/8" SS30VALV0023

44

GE FANUC CONTROLS

Washers

Power Supply IC693PWR321 2031027

Battery P0020693
CPU 313, 5 Slot Base 400406
CPU 331 OBSOLETE – Replaced by CPU 350
CPU 350 IC693CPU350 * 2031029
CPU 341 IC693CPU341 * 401239
EPROM for CPU 313/331 * 400907
Base Unit, 10 Slot (includes new battery) 2031028
ASCII Module HE693ASC224x 400518
Thermocouple Module HE693THM446x 2031034
Thermocouple w/fitting 401126
Thermocouple Wire 2023030
Blank Module IC693ACC310 2031033
DC Input/AC Output Module IC693MDR390 2031031
AC Input/AC Output Module IC693MAR590 2031032
DC Input Module IC693MDL634 400756
AC Output Module IC693MDL940 400575
Touch Screen 5” B/W * 2031035
Touch Screen 6” Color * 2031036
Interface cable for Touch Screen 400190
Ribbon cable for Touch Screen Y960479
Printer, Syntest 400868
Printer Paper 400924

*Must specify program number and washer serial number

45

Washers

GE VERSAMAX CONTROLS

Power Supply (120VAC) IC200PWR102 61301605230
CPU * P0021225
Thermocouple Module IC200ALG630 P0021189
Input Module, 24VDC, 32PT IC200MDL650 61301605120
IC200MDL330 61301605122
Carrier, I/O Box Style IC200CHS022 P0021226
Carrier, I/O Connector Style IC200CHS003 P0021227
Power Supply, 24VDC, 6.5A 61301605123

EAGLE SIGNAL 190+ CONTROLS

DAD/M 2031011
Controller, 190+ 2031009
Memory Transport Module * 2031023
Battery Module 400875
Expander Board 2031010
AC Input Module 2031018
DC Input Module 2031020
AC Output Module 2031019
DC Output Module 2031021
Thermocouple Module 2031024
Thermocouple w/fitting 401126
Thermocouple Wire 2023030
Printer, Digitec 2034001
Printer Paper 2034005
Take Up Reel OBSOLETE

*Must specify program number and washer serial number

46

Washers

76-7700 / CF-4C/CS-6F CART WASHER

Controls See GE FANUC, VERSAMAX or

EAGLE SIGNAL 190+ Controls (Pages 45 & 46)

Switches

Power/Reset Switch (Allen Bradley only. Parts for GE
switches no longer available)

Switch, Selector, 2 position, Green 2002047

Light Unit 2015060

Lamp, LED, 120V (Long Lasting) 2015040

Block, Contact, N.O. 2009010
Start, PB, Green, Non-Illum 2002046
Stop, PB, Red, Non-Illum 400174

Indicators

Indicator, Red 2015045
Indicator, Blue 2015050
Indicator, Yellow 2015055
Indicator, Green 2015070
Lamp, LED, 120V (Long Lasting) 2015040

Misc. Controls

Board, Liquid Level Control 2011000
Relay, Floor Tilt Control (1CR)(120V) 400181
Relay, Floor Tilt Control (2&3CR)(24VDC) 2006009
Capacitor, Floor Tilt Actuator 401071
Alarm 2025004
Rectifier 2025003
Transformer, 120V/24v, .5KVA 2010002
Transformer, 240-480/120-240, 1.5KVA 2010017
Transformer, 120/120, .5KVA 2010019

47

Washers

76-7700 / CF-4C/CS-6F CART WASHER Cont.

Door

Gasket, Top/Non-Hinge (Order 10')
Gasket, Hinge Side (Order 7') 400163
Latch, Brixon 7001011
Handle, Door Latch 7001010
Hinge 7002006

Cam, Hinge, Female 7002008

Cam, Hinge, Male 7002009

Switch, Proximity, 12mm (Grey Cable)
Must Order 400980 & Yellow Cable below.

Switch, Proximity, (Yellow Cable) 400980

Cable, Yellow (7600) Y960789

Cable, Yellow (7700) Y960788
Switch, Mechanical w/Actuator 2002063
Threshold Seal Y940230
Locking Strip, Gasket 400705
Tool, Locking Strip 9000025
Decal, “Push To Exit” 2019044
Window On Door, Lexan Y950508

Gasket, Door Window Y950509

Interior Light

Bulb, 25W Fluorescent 401267
Receptacle, Lamp, Porcelain 2018010
Window For Interior Light, Lexan Y950312

Gasket, Interior Light Window Y950311

3021015

OBSOLETE

48

Washers

76-7700 / CF-4C/CS-6F CART WASHER Cont.

Motor Overloads

Wash Pump 5HP, 208/240V 2008007
Wash Pump 7-1/2HP, 208/240V 2008008
Wash Pump 5HP, 480V 2008005
Wash Pump 7-1/2HP, 480V 2003057
Drying Blower, 208V 2008004
Drying Blower, 240V 2008003
Drying Blower, 480V 2008002

Contactors

Wash Pump 5HP 2007004
Wash Pump 7-1/2HP 2007012
Drying Blower 2007000
Manifold Drive 2007000

Fuses
Wash Pump Fuses (1F-3F)

20A 208V/240V 2003011

25A 2003012

15A 2003032
Wash Pump (1F-3F), 7-1/2HP, 480V – 20A 2003057
Dryer Blower (4F-6F), 208V – 7A 2003006
Dryer Blower (4F-6F), 240V – 15A 2003010
Dryer Blower (4F-6F), 480V – 6A 2003054
Manifold Motor (7F) – 7A 2003006
Exhaust Blower (8F), (Optional) – 15A 2003010
Fuse (14F) – 1A 2003036
Fuse (15F) – 15A 2003047
Fuse (16F) – 2A 2003037
Fuse (17F-23F) – 4A 400303
Fuse (24F), 7600 – 2.5A 400972
Fuse (25F-27F) – 1/2A 2003035
Fuse (28F) – 1A 2003036
Fuse (29F-30F) – 10A 2003059

49

Washers

76-7700 / CF-4C/CS-6F CART WASHER Cont.

Old Style Booster Heater

Booster Heater, Graham, Heliflow 3016000

Gasket Kit 9114001
Pressure Gauge 8003003
Temperature Gauge 2012006
Pressure Relief Valve 3005011
Steam Valve, 1-1/2” 3001052

Rebuild Kit 9101004
Trap, Steam, 1/2” 3006008
Trap, Steam, 3/4” 3006009
Check Valve, 1/2” 3003000
Check Valve, 3/4” 3003001

New Style Booster Heater

Booster Heater Kit
(Replaces old ITT Flat Plate) B010364

Heat Exchanger Only B010180
Steam Valve, 1” 3001051

Rebuild Kit 9101009
Trap, Steam, 3/4” 3006009
Trap, Steam, 1/2”, Brass Angle STEAM0001
Check Valve, 3/4” 3003001
Vacuum Breaker, 3/4” 3005028
Water Valve, 1” 3001045

Rebuild Kit 9101048

50

Washers

76-7700 / CF-4C/CS-6F CART WASHER Cont.

Dryer / Exhaust

Motor, Dryer Blower 5101010
Blower, Dryer 4001000
Coil, Steam, Air Heating 3016006
Coil, Condenser (3 Coils Needed) B020657
Motor, Damper 5101003
Hose, Blower Intake, 9” 3013033
Filter, Air Intake 9000034
Tubing, Condenser Drain, 3/4” Urebrade 3013025

Floor Lift Mechanism

Actuator, 3” Stroke (7600) 2038001
Actuator, 3” Stroke (7700) 2038002
Switch, Limit 511410
Cable, SS, 1/8” (By The Foot) 1011001
Pulley, cable 1011005
Clamp, cable 1011004
Thimble, 1/8” Cable 401343

Manifold / Drive

Motor, Manifold Drive 5101002
Hose, Manifold (By The Foot) R3896
Clamp, Manifold Hose 3015007
Wear Sleeve, Push Pin, Manifold, Short X740037
Wear Sleeve, Push Pin, Manifold, Long X740038
Push Bar Assembly (7600) Y780010-52
Push Bar Assembly (7700) Y940182
Idler Assembly Z830041
Bearing, Idler Sprocket 400117
Sprocket, Idler 6001008
Torque Limiter, 3/4” 6003001
Coupling, Torque Limiter 6003000
Bearing, Flange 6004009
Seal, Manifold Drive Shaft 9207000
Bearing, Drive Shaft, Nylon 6004017
Attachment, Chain w/Link X960176
Chain, Manifold Drive, SS (By The Foot) 6002004

51

Washers

76-7700 / CF-4C/CS-6F CART WASHER Cont.

Plumbing

Valve, Steam, 1 1/2”
(Sump, Booster Heater-Graham) 3001052

Kit, Rebuild 9101004

Coil 9101052
Valve, Steam, 1”

(Drying Steam, Booster Heater-ITT) 3001051

Kit, Rebuild 9101009

Coil 9101051
Valve, Water, 1” (Sump Fill) 3001045

Kit, Rebuild 9101048

Coil 9101049
Valve, Water, 3/4”

(Condenser Water, Non-Vented Option) 3001046

Kit, Rebuild 9101003

Coil 9101049
Valve, Water, 1/2”

(Condenser Water, Drying System) 3001044

Kit, Rebuild 9101008

Coil 9101049
Trap, Steam, 3/4” (Drying Coil) 401112
Trap, Steam, 3/4”
(Sump, Booster Heater, Steam Supply) 3006009
Vacuum Breaker, 1/2” 3005029
Vacuum Breaker, 3/4” 3005028
Valve, Check, 1/2” 3003000
Valve, Check, 3/4” 3003001
Tubing, Dryer Condenser Drain, 3/4” 3013025

52

Washers

76-7700 / CF-4C/CS-6F CART WASHER Cont.

Sump

Coil, Sump Heating, 76001, 2, 3 W950262
Coil, Sump Heating, 76004, 5 W950158
Spark Plug, Water Level Probe 2011002
Electrode, Water Level Probe

1/2” Long Y820134-1

3” Long Y820134-15
Bulkhead Fitting, 90 Deg., Deterg/Rinse 400113
Dispenser, Detergent/Rinse,
4100 Beta (7600/7700) 3020002
Multi-Time Timer 9112003
Squeeze Tube 9112006
Drain Valve Y830020

Sump Capacities

7600-1 64” Chamber 45 gal
7600-2 72” Chamber 50 gal
7600-3 80” Chamber 55 gal
7600-4 98” Chamber 55 gal
7600-5 112” Chamber 65 gal
7700 60 gal

53

Washers

This page is left blank intentionally.

54

Washers

78-7900A CART WASHER

Controls See GE FANUC, VERSAMAX Controls

(Pages 45 & 46)

Switches

Power/Reset Switch (Allen Bradley only. Parts for GE
switches no longer available)

Switch, Selector, 2 position, Green 401086

Block, Contact, N.O. 401092

Light Unit 401109

Lamp, LED, 120V (Long Lasting) 400768

Door

Gasket, Top/Non-Hinge (Order 10')
Gasket, Hinge Side (Order 7') 400163
Latch, Brixon 7001011
Handle, Door Latch 7001010
Hinge 7002006

Cam, Hinge, Female 7002008

Cam, Hinge, Male 7002009
Switch, Proximity 61301605134

Cable 61301605136
Decal, “Push To Exit” 2019044
Window On Door, Lexan Y950508

Gasket, Door Window Y950509

Interior Light

Bulb, 25W Fluorescent 401267
Receptacle, Lamp, Porcelain 2018010
Window For Interior Light, Lexan Y950312

Gasket, Interior Light Window Y950311

55

3021015

Washers

78-7900A CART WASHER Cont.

Motor Overloads 7800 208V*

Wash Pump (1M) 61301605168
Rinse Pump & Dryer Motor (15M-2M) 61301605164
Recirc. Pump (14M) 61301605167

Motor Overloads 7800 480V*

Wash/Recirc Pumps-Manifold (1-2-14M) 61301605164
Rinse Pump (15M) 61301605163
Dryer Motor (2M) 61301605162

Motor Overloads 7900 208V*

Wash & Recirc. Pump (1-14M) 61301605169
Rinse Pump & Dryer Motor (2-3-15M) 61301605164
Manifold (4M) 61301605165

Motor Overloads 7900 480V*

Wash Pump (1M) 61301605169
Wash Pump/Dryer (2-3-15M) 61301605164
Recirc. Pump/Manifold (4-14M) 61301605165

Motor Contactors 7800 208V*

Wash Pump (1M) 61301605159
Rinse Pump/ Dryer/Manifold (2-4-15M) 61301605154
Recirc. Pump (14M) 61301605158

Motor Contactors 7800 480V*

Wash Pump (1M) 61301605157
Recirc/Rinse Pump/Dryer/Mani (2-14-15M) 61301605154

Motor Contactors 7900 208V*

Wash Pump (1M) 61301605160
Rinse Pump & Dryer Motor (2-3-15M) 61301605154
Recirc Pump (14M) 61301605159
Manifold (4M) 61301605155

Motor Contactors 7900 480V*

Wash Pump (1M) 61301605160
Recirc/Rinse Pump/Dryer (2-3-14-15M) 61301605154
Manifold (4M) 61301605155

*Refer to manual for other supply voltages

56

Washers

78-7900A CART WASHER Cont.

Dryer / Exhaust

Motor, Dryer Blower 5101010
Coil, Steam, Air Heating D030073
Hose,9” 3013033
Dryer Gasket B040038

Floor Lift Mechanism

Actuator, 3” Stroke (7800) 2038001
Actuator, 3” Stroke (7900) 2038002
Proximity, Limit 61301605134
Cable, SS, 1/8” (By The Foot) 1011001
Pulley, Cable 1011005
Clamp, Cable 1011004
Thimble, 1/8” Cable 401343

Manifold / Drive

Motor, Manifold Drive 5101002
Hose, Manifold (By The Foot) R3896
Clamp, Manifold Hose 3015007
Wear Sleeve, Push Pin, Manifold, Short X740037
Wear Sleeve, Push Pin, Manifold, Long X740038
Push Bar Assembly (7800 ONLY) Y780010-52
Push Bar Assembly (7900 ONLY) Y940182
Attachment, Chain w/Link X960176
Chain, Manifold Drive, SS (By The Foot) 6002004

57

Washers

78-7900A CART WASHER Cont.

Plumbing

Valve, Steam, 1 1/2” 3001052

Kit, Rebuild 9101004

Coil 9101052
Valve, Steam, 1” 3001051

Kit, Rebuild 9101009

Coil 9101051
Valve, Water, 1” 3001045

Kit, Rebuild 9101048

Coil 9101049
Valve, Water, 1/2” 3001044

Kit, Rebuild 9101008

Coil 9101049
Trap,3/4" TD (Watson) P0011264
Trap,1" TD (Watson) P0011265
Trap, Steam, 1/2”, Brass Angle STEAM0001
Vacuum Breaker, 1/2” 3005029
Vacuum Breaker, 3/4” 3005028
Valve, Check, 1/2” 3003000
Valve, Check, 3/4” 3003001

Sump

Coil, Tank 7800 D030034
Spark Plug, Water Level 2011002

Probe 5-3/4” Long D030374

Probe 21-1/4” Long D030040

SS Hex Nut P0030102
Dispenser, Detergent, Knight P0018005
Pump, Chemical, Rinse Aid 5001024
Drain Valve Y830020
Detergent Wand V500480001

Sump Capacities

7800 80 gal tank
7900 100 gal tank

58

Washers

7642, 7652, 7662 INDEX WASHERS

Controls See GE FANUC, VERSAMAX or

EAGLE SIGNAL 190+ Controls (Pages 45 & 46)

Switches

Power/Reset Switch (Allen Bradley only. Parts for GE
switches no longer available)

Switch, Selector, 2 position, Green 2002047

Light Unit 2015060

Lamp, LED, 120V (long lasting) 2015040

Block, Contact, N.O. 2009010
Start, PB, Green, Non-Illum 2002046
Stop, PB, Red, Non-Illum 400174
Switch, Load Trip (Electric Eye) 2002038
Switch, Load Trip (Micro) 2002016

Actuator 2002036
Switch, Door/Index Frame (Micro) 2002063

Arm, Switch 2002062
Switch, Index Cylinder (Proximity Sensor) 2002070
Switch, Elevator Cylinder w/Cable 400952
Switch, E-Stop, Keyed 401088

Extra Keys (2) 401508
Switch, E-Stop 401087
Switch, Door Safety, Sonic Compartment 2002065
Switch, Toggle, Bypass for Older Indexers 2002009

Indicators

Indicator, Red 2015045
Indicator, Blue 2015050
Indicator, Yellow 2015055
Indicator, Green 2015070
Lamp, LED, 120V (long lasting) 2015040

Contactors

Contactor (1M-5M, 7M) All Voltages 2007000
Contactor, Sonic Generators 2007009

59

Washers

7642, 7652, 7662 INDEX WASHERS Cont.

Fuses

Prewash, Wash, Rinse1, Rinse2 Pump
Drying Blower (1F-15F) – 10A 2003009
Sonic Generators (16F) – 25A 2003012
Manifold Drive Motor (17F) – 7A 2003006
Transformer, 480V (18F-19F) – 15A 400985
110V to Control System (20F) – 8A 2003007
110V to GE FANUC (21F) – 2A 2003037
Fuse (22F) – 4A 400303
Fuse (23F-25F, 27F, 32F) – 1A 2003036
Fuse (26F, 28F-31F) – 2A 2003037

Motor Overloads

Overload Relay, 6.0-9.5A (1OL-4OL) 208V 2008005
Overload Relay, 4.0-6.0A (5OL) 208V 2008004
Overload Relay, 2.5-4.0A (1OL-4OL) 480V 2008003
Overload Relay, 1.6-2.5A (5OL) 480V 2008002

Misc. Controls

Counter 2016000
Transformer, 120VAC/24VAC, .5KVA 2010002
Transformer, 240V/480V, 1.5KVA 400970
Transformer, Sonic Generator Isolation 2010018
Transformer, PC Isolation 2010019
Gauge, Temperature, Balkamp 701-1103 8003009
Gauge, Temperature, Balkamp 701-1126 8003012
Board, Liquid Level

Single Function (Prewash, Sonic) 2011000

Dual Function (Wash, Rinse1) 2011001
Master Control Relay 400629

Socket 400188
Alarm 2025004

60

Washers

7642, 7652, 7662 INDEX WASHERS Cont.

Sump Capacities

Prewash 18 gal (CW)
Sonic 30 gal (HW)
Wash 18 gal (HW)
Rinse 28 gal (HW)
DI Rinse (15-30 Second Cycle) 32 GPM

Prewash Section

Spinner Manifold, Prewash Y940347
Spark Plug, Water Level Probe 2011002
Probe Tab - 7/8 LG Y820134-2
Probe Tab - 8 LG Y820134-29
Drain Valve 3002015
Water Fill Solenoid 3001046

Rebuild Kit 9101003
Injector, Enzyme/Detergent 3023000
Pump, SMP1000 5001002

Pump Seal 9106002

Housing Gasket 9106001

Sonic Section

Generator, Sonic, 500 Watts 401122
Transducers 401127
Transducer Screen for Sump Bottom W960284
Spark Plug, Water Level Probe 2011002
Probe Tab - 7/8 LG Y820134-2
Probe Tab - 2-7/8 LG Y820134-13
Drain Valve 3002015
Water Fill Solenoid 3001044

Rebuild Kit 9101008
Injector, Enzyme/Detergent 3023000

61

Washers

7642, 7652, 7662 INDEX WASHERS Cont.

Wash Section

Manifold, Complete, LH W920323
Manifold, Complete, RH W920491
O-Rings for Manifold 1006001
Hose, Manifold 3013031
Spark Plug, Water Level Probe 2011002
Probe Tab - 1-3/8 LG Y820134-5
Probe Tab - 5-3/4 LG Y820134-22
Water Fill Solenoid 3001044

Rebuild Kit 9101008
Steam Solenoid Valve 3001050

Rebuild Kit 9101036
Trap, Steam , 1/2” 3006008
Breaker, Vacuum, 3/4” 3005029
Deterg. Pump (Conc. Sensing H3100D) 3020000

90º Bulk Fitting, Det. Injection 400113

Probe, Dual Tip, Blue 3020003
Coil, Steam Y940507
Drain Valve 3002015
Pump, SMP1000 5001002

Pump Seal 9106002

Housing Gasket 9106001

62

Washers

7642, 7652, 7662 INDEX WASHERS Cont.

Rinse/DI Rinse Section

Manifold, Complete, LH W920324
Manifold, Complete, RH W920486
O-Rings for Manifold 1006001
Hose, Manifold 3013031
Spark Plug, Water Level Probe 2011002
Probe Tab - 5-3/4 LG Y820134-22
Coil, Steam Y940507
Drain Valve 3002015
Water Fill Solenoid S/S 3001049
Steam Solenoid Valve 3001050

Rebuild Kit 9101036
Trap, Steam , 1/2” 3006008
Breaker, Vacuum, 1/2” 3005029
Pump, SMP1000 (Rinse 1) 5001002

Pump Seal 9106002

Housing Gasket 9106001
Pump, Final Rinse 5001006

Pump Seal 9110000
Switch, SS Float, DI Tank 2011005
Dispenser, Lube 5001007

Rebuild Kit 400914
Injection Fitting 9108010
Foot Valve 9108009

Dryer Section

Blow Off Assembly Y860043

Hose, Blow Off Assembly Y860043
Blower, Dryer 4001000
Motor, Blower 5101010
Motor, Damper 5101003
Steam Solenoid Valve 3001051

Rebuild Kit 9101009
Trap, Steam, 3/4” 401112
Breaker, Vacuum, 3/4” 3005028

63

Washers

7642, 7652, 7662 INDEX WASHERS Cont.

Pneumatic Cylinders

Index Frame, 2” Bore (Uses Switches) 8005005

Seal Kit 9103010
Index Frame, 2-1/2” Bore (Uses Switches) 8005002

Seal Kit 9103004
Index Frame, 2-1/2” Bore (Uses Sensors) 8005007

Seal Kit 401316

Valve, Flow Control, 3/8” 401081
Door Lift 8005001

Seal Kit 401315

Valve, Flow Control, 3/8” 401081
Elevator 8005003

Seal Kit 401317

Valve, Flow Control, 3/8” 401081
Filter/Regulator Assembly 401105
Regulator, Doors Down, Elevator Down 8002002

Pneumatic Valve Stacks

Norgren, Parker, 2 Valve (Old Style) 8006004
Norgren, Parker, 3 Valve (Old Style) 8006003
ASCO, 2 Valve (New Style) Y970140
ASCO, 3 Valve 4 Coils (New Style) Y970139
ASCO, 3 Valve 5 Coils (New Style) B010008
Air Line, Black Vinyl, 3/8” (order by the foot) 3013022
Filter, Oil Removal 8002005
Lubricating Oil 400269

64

Washers

7642, 7652, 7662 INDEX WASHERS Cont.

Manifold Drive

Motor, Manifold Drive 5101004
Torque Limiter Coupling 6003000
Torque Limiter, 3/4” 6003001
Shaft, Manifold Drive Z920258
Bearing, Manifold Driveshaft 6004000
Roller Track Weldment Z860056

Doors

Latch, Access Doors 7001009
Door Link Assembly, Internal Doors Y950643
Rod, All Thread, SS, 3/8X8”, for Door Link Y920377-1
Lift Shaft 6004019
Gasket, Self Griping, Access Doors 400560
Index Frame Seals, Internal Doors Y910441

65

Washers

This page is left blank intentionally.

66

Washers

7622 – CR22 DECONTAMINATOR

Controls (See Pages 45 & 46)

The Spirit (Grey-Pro) Controller is obsolete.
Use MP-145A GE Fanuc (Y950747) to upgrade.
For GE FANUC parts, see GE FANUC Controls.

Printer, Keltron 2034000

Paper CHART0015

Ribbon 61301600006
RTD ( Use with Spirit Controller) 2012018
Probe, Temp (Use with GE Controller) 401126
Timer, BR48A601, 0-10 min 2001008
Relay, Time Delay, 5X829C 2005001
Relay, Time Delay, Cycle Complete 2005000
Relay, Latch, 32E6CAE120 2006001
Alarm, Cycle Complete 2025004

Switches

Power/Reset Switch (Allen Bradley only. Parts for GE
switches no longer available)

Switch, Selector, 2 position, Green 2002047

Light Unit 2015060

Lamp, LED, 120V (long lasting) 2015040

Block, Contact, N.O. 2009010

Wash / DI Rinse Pump Contactor

Overload Relays, Wash Pump

208V 2008006

230V 2008006

460V 2008004

Overload Relays, DI Rinse Pump

208V 2008004

230V 2008004

460V 2008003

67

2007000

Washers

7622 – CR22 DECONTAMINATOR Cont.

Booster Heater

Gauge, Temperature 2012006
Gauge, Pressure 8003003
Valve, Pressure Relief 3005011
Control, Temperature, Sterlco 3005018

DI Holding Tank

Pump, SS Teel, 1.5HP 5001006
Valve, Float
Float, Ball – 4” 9000002
Thermostat, 180F 2012014

Door

Gasket, Self Gripping (order 7ft. per door) 3021015
Latch, Door – Kason 7001016
Hinge, Door 7002003
Handle, Access Door 7001004
Spring, Door 7002015
Tube, Door Support, Lower Z880411
Tube, Door Support, Upper Z880413
Switch, Door 511410
Door Interlock Assembly W940332

Solenoid, Pull Type 2037002

Spring, Solenoid Return 400184
Window Y950508

Gasket Y950509

Locking Strip 400705

B040061

68

Washers

7622 – CR22 DECONTAMINATOR Cont.

Dryer / Exhaust

Blower/Dryer 4001001
Coil, Condenser B020657
Contactor, Drying Heater

40A 2007007

25A 2007009
Element, Heating, 4KW, 208V, (Non-Vent) 2030034
Element, Heating, 4KW, 240/480V 2030038
Thermostat, Overheat, 300F 2012017
Motor, Damper 5101003

Manifold Drive

Motor, Manifold Drive 5101005
Contactor, Manifold Drive Motor 2007003
Drive Shaft Weldment Y900028
Torque Limiter, 5/8” 6003002
Coupling, Torque Limiter 6003000
Bearing, Drive Shaft, Old Style (Stein) 6004010
Bearing, Insert, Old Style (Stein) 6004015
Bearing, Drive Shaft 6004018
Hose, Manifold, Wash (1”ID X 42”Long) 3013031
Hose, Manifold, Rinse (3/4”ID X 42”Long) 3013032
Hose, Rinse Couple (3/4”ID X 4”Long) Y960611
Hose, Wash Couple (1”ID X 4”Long) Y960612
O-Ring, Manifold Tube 1006001

69

Washers

7622 – CR22 DECONTAMINATOR Cont.

Plumbing

Seal, Wash Pump 9104004
Rubber Ring, Wash Pump 9104003
Pump, DI, 1-1/2HP 5001006
Valve, Solenoid, 3/4” (Pre-Wash, Rinse) 3001046

Rebuild Kit 9101003
Valve, Solenoid, 1/2” (Sump Fill/Condense) 3001044

Rebuild Kit 9101008
Valve, Solenoid, 1/2” (Steam) 3001050

Rebuild Kit 9101036
Valve, Solenoid, 1” (DI Rinse) 3001043
Trap, Steam, 1/2” Inline (SS) 3006008
Trap, Steam, 1/2” Angle (Brass) 3006000
Dispenser, Detergent, Concen. Sensing 3002000

Probe 3020003

Squeeze Tube 9112006
Valve, Drain 3002015

Sump

Diverter Plate Z960236
Electrode, Water Level (Spark Plug) 2011002
Probe, Water Level, High Y820134
Probe, Water Level, Low 3020003
Switch, Float (GE Controls) 2011005
Bulkhead Fitting, 90 Deg., 1/4” Tubing 400288
Bulkhead Fitting, Straight, 1/4” Tubing 3020005
Coil, Steam Y940507

Sump Capacity

70

18 Gallons
(retained)

Washers

7626 – CR26 DECONTAMINATOR

Controls (See Pages 45 & 46)

The Spirit (Grey-Pro) Controller is obsolete.
Use MP-145A GE Fanuc (Y950747) to upgrade.
For GE FANUC parts, see GE FANUC Controls.

Printer, Keltron 2034000

Paper CHART0015

Ribbon 61301600006
RTD ( Use with Spirit Controller) 2012018
Probe, Temp (Use with GE Controller) 401126
Timer, BR48A601, 0-10 min 2001008
Relay, Time Delay, 5X829C 2005001
Relay, Time Delay, Cycle Complete 2005000
Relay, Latch, 32E6CAE120 2006001
Alarm, Cycle Complete 2025004

Switches

Power/Reset Switch (Allen Bradley only. Parts for GE
switches no longer available)

Switch, Selector, 2 Position, Green 2002047

Light Unit 2015060

Lamp, LED, 120V (long lasting) 2015040

Block, Contact, N.O. 2009010

Wash / DI Rinse Pump Contactor

Overload Relays, Wash Pump

208V 2008006

230V 2008006

460V 2008004

Overload Relays, DI Rinse Pump

208V 2008004

230V 2008004

460V 2008003

71

2007000

Washers

7626 – CR26 DECONTAMINATOR Cont.

Booster Heater

Gauge, Temperature 2012006
Gauge, Pressure 8003003
Valve, Pressure Relief 3005011
Control, Temperature, Sterlco 3005018

DI Holding Tank

Pump, SS Teel, 1.5HP 5001006
Valve, Float
Float, Ball – 4” 9000002
Thermostat, 180F 2012014

Door

Gasket, Self Gripping (order 7ft. per door) 3021015
Latch, Door – Kason 7001016
Hinge, Door 7002003
Spring, Door 7002015
Tube, Door Support, Lower Z880411
Tube, Door Support, Upper Z880412
Switch, Door 511410
Door Interlock Assembly W940332

Solenoid, Pull Type 2037002

Spring, Solenoid Return 400184
Window Y950508

Gasket Y950509

Locking Strip 400705
Pulley, Door (Vertical Door Only) 6005002

B040061

72

Washers

7626 – CR26 DECONTAMINATOR Cont.

Dryer / Exhaust

Blower/Dryer 4001001
Blower/Dryer (Non-Vented) 400644
Blower/Exhaust (Non-Vented) 400642
Contactor, Drying Heater

40A 2007007

25A 2007009
Element, Heating, 4KW, 208V, Non-Vented

Only 2030034
Element, Heating, 4KW, 240/480V 2030038
Thermostat, Overheat, 300F 2012017
Motor, Damper 5101003

Manifold Drive

Motor, Manifold Drive 5101001
Contactor, Manifold Drive Motor 2007003
Drive Shaft Weldment Y820056
Coupling, Drive Shaft 9204035
Coupling w/Bearings Y810215
Push Bar Y810133
Wear Sleeve X820129
Spacer, Driveshaft 9202085
Chain Attachment X960176
Torque Limiter, 3/4” 6003001
Sprocket, Torque Limiter 6001001
Sprocket, Driveshaft 6001007
Sprocket, Motor 6001005
Bearing, Drive Shaft 6004008
Hose, Manifold, Wash (1”ID X 42”Long) 3013031
Hose, Manifold, Rinse (3/4”ID X 42”Long) 3013032
Hose, Rinse Couple (3/4”ID X 4”Long) Y960611
Hose, Wash Couple (1”ID X 4”Long) Y960612
O-Ring, Manifold Tube 1006001
Assembly, Idler Z830041
Bearing, Idler Sprocket 400117
Sprocket, Idler 6001008

73

Washers

7626 – CR26 DECONTAMINATOR Cont.

Plumbing

Seal, Wash Pump 9104004
Rubber Ring, Wash Pump 9104003
Pump, DI, 1-1/2HP 5001006
Valve, Solenoid, 3/4” (Pre-Wash, Rinse) 3001046

Rebuild Kit 9101003
Valve, Solenoid, 1/2” (Sump Fill/Condense) 3001044

Rebuild Kit 9101008
Valve, Solenoid, 1/2” (Steam) 3001050

Rebuild Kit 9101036
Valve, Solenoid, 1” (DI Rinse) 3001043
Trap, Steam, 1/2” Inline (SS) 3006008
Trap, Steam, 1/2” Angle (Brass) 3006000
Deterg. Pump (Conc. Sensing H3100D) 3020000

Probe, Dual Tip, Blue 3020003

Squeeze Tube 9112006
Valve, Drain 3002015

Sump

Diverter Plate Z960236
Electrode, Water Level (Spark Plug) 2011002
Probe, Water Level, High Y820134
Probe, Water Level, Low 3020003
Switch, Float (GE Controls) 2011005
Bulkhead Fitting, Straight, 1/4” Tubing 3020005
Coil, Steam Y940507

Sump Capacity

74

18 Gallons
(retained)

Washers

4656 DISINFECTOR (DECOMAT)

Controls

Circuit Board (Use the part number printed on the circuit
board to ensure a correct replacement.)

Battery, CPU (Must Be Soldered) V499765300
Fuse, 200mA V499256000
Fuse, 315mA V499223600
Fuse, 10A V468840600
Transformer, Control Voltage V499502700
Sensor, Temperature V499100000
Standoffs, Ckt Board V499082500
Plug, 9 Pin V762320101
Pin, Male V468555300
Pin, Female V468555400
Black Communications Cable, 100mm V498964100
Black Communications Cable, 500mm V498964101
Black Communication Cable, 1500mm V498964102
Printer, Alfa V501865475
Cartridge, Ribbon 61301600006
Paper Roll V479398807

Detergent System

Detergent Pump Rebuild V499693300
Detergent Pump V499169205
Detergent Wand, (5' Cable & Hose) V501596800
Detergent Wand, (2.5' Cable & Hose) V501596802
Hose, Detergent V930830
Bottle, Detergent V498619000

75

Washers

4656 DISINFECTOR (DECOMAT) Cont.

Door System

Gasket V499224100
Gas Spring V499179001
Hinge LH V499176600
Hinge RH V499176601
Repair Kit, Door Support Bracket Mount V500654875
Locking Solenoid (Door w/o Glass) V499168800
Locking Solenoid (Door w/Glass) V500096500
Switch, Door Locked V499196800
Window V499938000

Gasket (Requires 2m per door) V477081400

Plumbing

Valve, Single, Cold/Hot/DI V499165402
Valve, Double, Cold V499720300
Valve, Triple, Cold V499722400
Valve for DW V498988200
Valve, Single, DI (Use With Booster Pump) V499165401
DI Boost Pump V468918101

Rebuild Kit V468943900
Valve, Solenoid, Steam 3/8" V498811604
Filter, Steam Inlet V500230000
Trap, Steam V500367900
Pump, Circulation V499212901
Pump, Drain (Catalog # DP025-215) V500362601
Pump, Drain (Catalog # BE28B4-066) V477134501

Rebuild Kit V468943900
Valve, Check, Drain V499105900

Plastic Hose Fitting V498987400

76

Washers

4656 DISINFECTOR (DECOMAT)

Dryer

Element, Heating V498906200
Blower V501866600
Pre-Filter (Large) V500576700
HEPA Filter V498906100
Protector, Overheat V499085700
Thermostat, Control V481966900
Bracket, Large V499266600
Bracket, Small V499266500
Valve, Check V499228000

Hoses

Hose, Inlet Water Valve to Chamber V498625205
Hose, Drain Tempering V498625205

Chamber

Docking Flapper Kit V500187600

Sump Heat

Coil, Steam V499009900
Coil, Electric V499136500

Element Flange V499136500
Protector, Overheat V499085700
O-Ring, Steam or Electric Coil V740483105

77

Washers

4656 DISINFECTOR (DECOMAT) Cont.

Upgrade Kits

DI Water Boost Pump V499252576
Third Detergent Pump Kit V499252675
Fourth Detergent Pump Kit V499329075
Add RS-232 Port for PC Printer V499302975
Soiled Side Printer Kit V499326676
Steam to Electric Sump Heating V499200277
Electric to Steam Sump Heating V499200476
Guide Rail Kit Single Door Machine V499295075
Guide Rail Kit Double Door Machine V499674275

Misc. Components

Barrier Trim, 4656 Y980114
Nut, Spray Arms V500249700
Retainer, Panel Stud V477273900
4656 Seismic Anchor Y960204
Adapter, 1/2” BSP Male X 1/2” NPT Male 401151
Adapter, 1/2” BSP Fem X 1/2”NPT Male 401152
Adapter, 3/4” BSP Fem X 3/4” NPT Male 401153
Adapter,3/4 BSP Fem X 3/4 MNPT,SS 401154
Adapter, 3/4” BSP Fem X 1/2” NPT Male V477048201
Hose, Water, SS Braid, 1/2” X 3/4” V499765700
Washcart Wheel (4656) V498703500
Cover, Washcart Manifold, 4656 V499218000

78

Washers

46-X DISINFECTOR (PACS-300)

Controls

Safety Overheat Thermostat (Sump) V501615300
CPU/Relay Board V500405200
Control Panel Board (Control End) V500619100

Cable V500890900
Control Panel Board (Remote End) V500619200

Cable V500890901
RTD Temp. Sensor (Dual) V500813601

Circuit Breakers

Circulation Pump (F01) V501442900
Sump Heat, Electric (F02) V501443100
Dryer Heaters (F04) V501443300

Contactors

Circulation Pump (K01) V501443700
Sump Heat, Electric (K02) V501443702
Dryer Heater (K04) V501443701

Main Power Transformer

Door Components

Door Handle V501466500
Glass Window V501723400

Gasket For Window (Sold By Meter) V477081400
Door Lock Motor V500671100
Switch, Magnetic V499694700
Spring Cylinder V501252100

Door Gaskets

46-2 & 46-4 V499224100

46-5 V501649900

79

V501185200

Washers

46-X DISINFECTOR (PACS-300) Cont.

Dryer

Check Valve V501225500
Air Hose 370mm V500081501
Temperature Sensor V500852000
Fan V501165000

Fuse, 6.3A (Inline) V502040200

Fuse Holder V502040100
Dryer Element V500731300
Filter 46-2 V501380400
Filter 46-4 & 46-5 V501142400
Level Switch V499178200
Pressure Diff. Sensor V500855100

Drain Pump

Detergent System

Detergent Pump Rebuild V499693300
Detergent Pump V499169205
Detergent Wand, Standard V500306404
Detergent Wand, (5' Cable & Hose) V501596800
Detergent Wand, (2.5' Cable & Hose) V501596802
Hose, Detergent V930830
Bottle, Detergent V498619000

Misc. Components

Nut, Spray Arms V500249700
Washcart Wheel (4656) V498703500

80

V500362601

Washers

8666 DISINFECTOR (DECOMAT)

Controls

Circuit Board (Use the part number printed on the circuit
board to ensure a correct replacement.)

Battery, CPU (Must Be Soldered) V499765300
Fuse, 200mA V499256000
Fuse, 315mA V499223600
Fuse, 10A V468840600
Transformer, Control Voltage V499502700
Sensor, Temperature V499100000
Standoffs, Ckt Board V499082500
Plug, 9 Pin V762320101
Pin, Male V468555300
Pin, Female V468555400
Black Communications cable, 100mm V498964100
Black Communications cable, 500mm V498964101
Black Communication cable, 1500mm V498964102
Printer, Alfa V501865475
Cartridge, Ribbon 61301600006
Paper Roll CHART0015

Detergent System

Detergent Pump Rebuild V499693300
Detergent Pump V499169205
Detergent Wand, (5' Cable & Hose) V501596800
Detergent Wand, (2.5' Cable & Hose) V501596802
Hose, Detergent V930830
Detergent Wand, 2 ft Long w/5 ft Cord
(Deco Cont.) V500480001
Detergent Wand, 2 ft Long w/5 ft Cord
(AB Cont.) V500480000
Bottle, Detergent V498619000

81

Washers

8666 DISINFECTOR (DECOMAT) Cont.

Door System

Door Gasket V477331300
Motor, Door Sealing, Linear (Old Style) V498983700
Motor, Seal Gear Motor (New Style) V500037075

Capacitor for Gear motor V500315400
Motor, Door Up/Down V499081300

Capacitor for Up/Down Motor V499689900
Chain, Door Drive V499030900
Master Link, Chain V499031000
Cable, Door Lift, SS V477336601
Pulley, Door Lift Cable V477336400
Leaf Spring, Door Open (Manual Only) V499061800
Door Guide (Round Nylon "Roller") V498956800
Window, Small (Old Style Door) V477331400

Packing for Small Window

(Req. 2m per door) V477081400
Window, Large Smoked Glass

(New Style Door) V499998000

Packing for Large Window V499990200

Door Switches

Switch, Safety, Door Up/Down
(Power Door Only) V500278500

Switch, Door Position,
Up, Down, Sealed, Unsealed V471597601

82

Washers

8666 DISINFECTOR (DECOMAT) Cont.

Drying System

Element, Heater V476907801
Blower V501866600
HEPA Filter V498906100
Pre-Filter (Small - Before Fan)* V498929602

* Pre-Filter Assembly – (New Style (Fits
between blowers and HEPA filter. Remove
small pre-filters from blower housing when
using this filter assembly.) V500551975

Pre-Filter (Large) V500560600
Thermostat, Overheat Protection V499085700
Thermostat, Control V481966900
Timer, Fan Delay V498766400
Switch, Water in Drying System
(Mach. after SN 81511) V500047800
Switch, Water in Drying System
(Mach. before SN 81511) V499013300
Valve, Non-Return V501140300

Hoses

Hose, Dryer L=370 V500081501
Hose, Dryer L=560 V500081502
Hose, Door Drain, SS V500058801
Hose, Door Drain, CS V500058802
Hose, Inlet Water Valve to Chamber V498625205
Hose, DI Water Valve to Chamber V498977100
Hose, Drain, Flexible Grey Tubing V150196700
Hose, Condenser Spray V498625203
Hose, Drain Tempering Water V499207400

83

Washers

8666 DISINFECTOR (DECOMAT) Cont.

Plumbing

Valve, Water, Hot/Single DI
(W/O Economy Tank) V499541602
Valve, Water, Cold, Double Solenoid V498941001
Valve, Water, Cold, Triple Solenoid V499743400
Valve, Steam to Sump V499535200

Rebuild Kit ZVALS0101
Filter, Steam Inlet V500230000
Trap, Steam V500367900
Pump, Circulation (Mach. Before SN81511) V477330701
Pump, Circulation (Mach. After SN 81511) V500956201
Pump, Drain/DI Boost/Economy Tank V468918101

Rebuild Kit V468943900
Valve, Check, Drain V499105900

Plastic Hose Fitting V498987400
Valve, Drain, DI Tank V500141300

Sump Heat

Coil, Steam (Mach. Before SN 81511) V499009900
Coil, Steam (Mach. After SN 81511) V500283700
Coil, Electric V499136500

Element Flange V500154300
Protector, Overheat (For Electric Only) V481950101
O-Ring, Electric or Steam Coil V501823300

84

Washers

8666 DISINFECTOR (DECOMAT) Cont.

Upgrade Kits

DI Water Boost Pump V499001076
Third Detergent Pump Kit V499120875
Fourth Detergent Pump Kit V499426175
Add RS-232 Port for PC Printer V499287975

The following are for machine SN below 81511

Clean Side Printer Kit V499378775
Soiled Side Printer Kit V499206775
Steam to Electric Sump Heating V499333200
Electric to Steam Sump Heating V499108875

The following are for machine SN 81511 and above

Clean Side Printer Kit (No Unloader) V500068076
Soiled Side Printer Kit V500068075
Steam to Electric Sump Heating V500237100

Misc. Components

Barrier Trim, 8666 Y980115
Nut, Spray Arms V500249700
Spray Arm, Wash Cart V499235101
Diffuser, Vent, 8666 (Non-Vented Units) Y970393
Stud, Panel (1/4Turn) For 8666 V477273800
Retainer, Panel Stud V477273900
Seismic Anchor Y960205
Adapter, 1/2” BSP Male X 1/2” NPT Male 401151
Adapter, 1/2” BSP Fem X 1/2”NPT Male 401152
Adapter, 3/4” BSP Fem X 3/4” NPT Male 401153
Adapter,3/4 BSP Fem X 3/4 MNPT,SS 401154
Adapter, 3/4” BSP Fem X 1/2” NPT Male V477048201
Hose, Water, SS Braid, 1/2” X 3/4” V499765700

Large Washer V499215200

Small Washer V499189300
Washcart Wheel V498646800
Washcart Wheel (Tapered Stainless/AGS) V500035200

Bearing for Tapered Wheel V500165200
Cover, Washcart Manifold V498677400

85

Washers

This page is left blank intentionally.

86

Washers

8666 DISINFECTOR (PACS-300)

Controls

Safety Overheat Thermostat (Sump) V499085700
CPU/Relay Board V500405200
Control Panel Board (Control End) V500618900

Cable V500890900
Control Panel Board (Remote End) V500619000

Cable V500890901
RTD Temp. Sensor (Dual) V500813601

Circuit Breakers
F01-F05

PKZM 0-4 V500976100

PKZM 0-6.3 V500845100

PKZM 0-10 V500782500

PKZM 0-16 V499573500

PKZM 0-25 V500317000
F10 (Dryer Fans) V500266102
F11 (Controls) V500810300

Contactors K01-K05

Main Power Transformer

Dryer

Check Valve V500937700
Temperature Sensor V500852000
Fan V501061700
Dryer Element V500731300
Hepa Filter V500745800
Pressure Sensor V500855100

Door Components

Door Gasket V477331300
Glass Window V499998000

Gasket For Window (Sold By Meter) V499990200
Door Lock Motor V500037075
Switch ("Up", "Down", "Sealed") V500859900

87

V500584900

V499858400

Washers

8666 DISINFECTOR (PACS-300) Cont.

Drain Pump

Rebuild V468943900

Circulation Pump (208V-240V)

Mechanical Seal V498644701

O-Ring V499040400

Detergent System

Detergent Pump Rebuild V499693300
Detergent Pump V499169205
Detergent Wand, (5' Cable & Hose) V501596800
Detergent Wand, (2.5' Cable & Hose) V501596802
Hose, Detergent V930830
Bottle, Detergent V498619000

Booster Tank (Rinse Water Pre-Heat)

Heater Element (208V) V500821700

O-Ring V501823300
Level Sensor V500984900
Fill Solenoid Valve V499541600
Temperature Sensor V500852000
Overheat Protector V499085700

Sump

Heater Element (Electric 208V) V500821700

O-Ring V501823300
Steam Coil V500283700

O-Ring V501823300
Steam Trap V500367900
Solenoid Valve V499535200
Strainer V500230000
Overheat Protector V499085700

V468918101

V500956201

Misc. Components

Nut, Spray Arms V500249700
Washcart Wheel V498646800

88

RO Water Systems

Universal Parts

Low Pressure Switch 61301605490
Switch Contact Block 61301605504
Control Box Transformer 61301605506
Control Box Circuit Board 61301605508
Gauge 0-300 Gly. 1/4" Pnl. Mt. 61301605512
Wrench for 10" BB Housing 61301605513
Wrench for Standard Housing 61301605454

HS-200 BOILER MATE Kit Qty

Membrane Filter 3 61301605455*
Filter Sediment 5 micron 4 61301605449*
Filter Carbon Block 5 micron 4 61301605447*
Filter GAC/KDF 4 61301605450*
Filter Calcite 4 61301605516*
*Part of PM Kit 61301605518
Permeate Pump 61301605453
Flow Restrictor 750 ml 61301605473
5 Gal Storage tank 61301605471
Valve Check 1/2" Brass 61301605475
Valve Ball 1/2" Brass 61301605474

89

RO Water Systems

HS-450-PT Kit Qty

Membrane Filter 2 X 26 1 61301605535*
Control Box Motor Relay 30 Amp 1 61301605507*
Filter Calcite 10" 4 61301605448*
O-Ring for Standard Housing 1 61301605452*
Filter Sediment 5 micron 10" BB 4 61301605460*
Filter Carbon Block 10 micron 10" BB 4 61301605456*
Filter GAC/KDF 10" BB 4 61301605458*
O-Ring for 10" BB Housing 3 61301605468*
*Part of PM Kit 61301605525
Processor Pump 125 GPH 61301605527
Processor Motor 1/2 HP 61301605496
Coupler Pump/Motor Lovejoy 61301605495
Solenoid 1/2" FPT (24VAC) 61301605488
Solenoid Plastic Body 1/2" 61301605487
24v Coil for Plastic Solenoid 61301605514
Valve Check 1/4" FPT Plastic 61301605481
Valve Check 1/4" FPT Brass 61301605475
Pressure Tank Switch 40-60psi 61301605491
Valve Needle 3/8" FPT 61301605485
Valve Check 1/2" FPT Brass 61301605476
Vessel Closure Kit 2" 61301605534
Fuse 20 Amp 61301605502
Gauge 0-100 psi Gly. 1/4" Pnl. Mt. 61301605511
Housing Filter 10" Standard 61301605451
Housing Filter 10" BB 61301605470
Blending Valve 1/2" 61301605484

90

RO Water Systems

HS-1000 Kit Qty

Membrane Filter 2.5 X 40 1 61301605463*
Control Box Motor Relay 30 Amp 1 61301605507*
Filter Calcite 10" 4 61301605448*
O-Ring for Standard Housing 1 61301605452*
Filter Sediment 5 micron 10" BB 4 61301605460*
Filter Carbon Block 10 micron 10" BB 4 61301605456*
Filter GAC/KDF 10" BB 4 61301605458*
O-Ring BB Housing 3 61301605468*
*Part of PM Kit 61301604729
Processor Pump 190 GPH 61301605493
Processor Motor 1/2 HP 61301605496
Solenoid 1/2" FPT (24VAC) 61301605488
Solenoid Plastic Body 1/2" 61301605487
24v Coil for Plastic Solenoid 61301605514
Valve Check 1/4" FPT Plastic 61301605481
Valve Check 1/4" FPT Brass 61301605475
Valve Needle 3/8" FPT 61301605485
Vessel Closure Kit 2.5" 61301605466
Fuse 20 Amp 61301605502
Housing Filter 10" Standard 61301605451
Housing Filter 10" BB 61301605470
Blending Valve 1/2" 61301605484

HS-1000-PT Only

Coupler Pump/Motor lovejoy 61301605495
Pressure Tank Switch 40-60psi 61301605491
Valve Check 1/2" FPT Brass 61301605476
Gauge 0-100 psi Gly. 1/4" Pnl. Mt. 61301605511

HS-1000-FT Only

Valve Check 3/4" FPT Brass 61301605477
Valve Check 11/4" PVC 61301605479
Horizontal Reed Float 61301605509
Tank for Repressurizer (RP-5) 61301605471
Injector for Repressurizer 61301605498
Repressurizer Pump/Motor 61301605492
Gauge 0-100psi 1/4" Btm. Mt. 61301605510
Valve Check PVC 40 1/2" 61301605480

91

RO Water Systems

HS-2400 Kit Qty

Membrane Filter 4X40 1 61301605464*
Control Box Motor Relay 30 Amp 1 61301605507*
Filter Calcite 10" 8 61301605448*
O-Ring for Standard Housing 2 61301605452*
Filter Sediment 5 micron 20" BB 4 61301605461*
Filter Carbon Block 10 micron 20" BB 4 61301605457*
Filter GAC/KDF 20" BB 4 61301605459*
O-Ring for 20" BB Housing 3 61301605469*
*Part of PM Kit 61301604730
Processor Pump 330 GPH 61301605494
Processor Motor 3/4 HP 61301605497
Solenoid 1/2" FPT (24VAC) 61301605488
Valve Check 1/4" FPT Plastic 61301605481
Valve Check 1/4" FPT Brass 61301605475
Valve Needle 3/8" FPT 61301605485
Valve Check 1/2" FPT Brass 61301605476
Valve Ball 1/2" (PT Only) 61301605517
Vessel Closure Kit 4" 61301605467
Fuse 20 Amp 61301605502
24v Coil for Plastic Solenoid 61301605514
Plastic Solenoid Body 1/2" 61301605487
Housing Filter 10" Standard 61301605451
Housing Filter 20" BB 61301605465
Blending Valve 1/2" 61301605484

HS-2400-PT Only

Tank Switch 40-60psi 61301605491
Gauge 0-100 psi Gly. 1/4" Pnl. 61301605511

HS-2400-FT Only

Horizontal Reed Float 61301605509
Valve Check PVC 80 11/4" 61301605479
Valve Check PVC 40 1/2" 61301605480
Valve Check PVC 80 1" 61301605478
Tank for Repressurizer (RP-12) 61301605472
Injector for Repressurizer 61301605498
Pump/Motor for Repressurizer 61301605498

92

RO Water Systems

HS-4800 Kit Qty

20" BB 5M Sediment filter 4 61301605461*
10" all Calcite feeder 8 61301605448*
BB "O" Ring (for housing) 1 61301605468*
Slim "O" Ring (for calcite feeder) 2 61301605452*
GAC/KDF mix bed In-Out head 1" 1 61301605536*
*Part of PM Kit 61301604731
Vertical Pump/Motor for Processor 61301605500
Brass Solenoid 3/4" 24v 61301605489
Membrane Filter 4 x 40 61301605464
Membrane Closure Kit 4" 61301605467
Valve Check PVC 1" 61301605478
TDS Monitor Panel Mt. 0-1999ppm 61301605515
Solenoid Plas 1" 24v 61301605486
Gauge 0-100 Gly. Pnl. Mt. 61301605511
Valve Labcock 1/4" 61301605482
Housing Filter 20" BB 61301605465
Gauge 0-100psi 1/4" 61301605510
Sediment 20" BB 1Micron 61301605462
Valve PVC 1/2" Panel Mt. 61301605483
Control Box Motor Relay 61301605505
Fuse 30amp 61301605503
O-Ring for 20" Housing 61301605469

HS-4800-PT Only

Tank Pressure Switch 61301605491

HS-4800-FT Only

Valve Check Brass 1/2" 61301605476
Horizontal Reed Float 61301605509
Tank for Repressurizer (RP-12) 61301605472
Injector for Repressurizer 61301605498
Pump/Motor for Repressurizer 61301605498

93

RO Water Systems

HS-9600 Kit Qty

20" BB 5M Sediment filter 4 61301605461*
10" all Calcite feeder 8 61301605448*
BB "O" Ring (for housing) 1 61301605468*
Slim "O" Ring (for calcite feeder) 2 61301605452*
GAC/KDF mix bed In-Out head 1" 1 61301605536*
*Part of PM Kit 61301605520
Vertical Pump/Motor for Processor 61301605500
Brass Solenoid 3/4" 24v 61301605489
Membrane Filter 4 x 40 61301605464
Membrane Closure Kit 4" 61301605467
Valve Check PVC 1" 61301605478
TDS Monitor Panel Mt. 0-1999ppm 61301605515
Solenoid Plas 1" 24v 61301605486
Gauge 0-100 Gly. Pnl. Mt. 61301605511
Tank Pressure Switch 61301605491
O-Ring for 20" Housing 61301605469
Valve Labcock 1/4" 61301605482
Housing Filter 20" BB 61301605465
Gauge 0-100psi 1/4" 61301605510
Sediment 20" BB 1Micron 61301605462
Valve PVC 1/2" Panel Mt. 61301605483
Control Box Motor Relay 61301605505
Fuse 30amp 61301605503

HS-9600-FT Only

Horizontal Reed Float 61301605509
Valve Check Brass 1/2" 61301605476
O-Ring for 20" Housing 61310605469
Pump/Motor for Repressurizer 61301605499
Tank for Repressurizer 61301605472
Valve Check PVC 80 11/4" 61301605479
Solenoid 1/2" Plastic Body 61301605487
Coil for Plastic Solenoid 61301605514
Valve PVC 40 1/2" 61301605480

94

RO Water Systems

HS-15000 Kit Qty

20" BB 5M Sediment filter 4 61301605461*
10" all Calcite feeder 8 61301605448*
BB "O" Ring (for housing) 1 61301605468*
Slim "O" Ring (for calcite feeder) 2 61301605452*
GAC/KDF mix bed In-Out head 1" 2 61301605536*
*Part of PM Kit 61301605521
Pump/Motor for Processor 61301605501
Control Box Contactor 61301605505
Fuse 30amp 61301605503
TDS Monitor 0-1999 Pnl. Mt. 61301605515
Valve PVC 1/2" Pnl. Mt. 61301605483
Valve Labcock 1/4" 61301605482
Vessel Closure Kit 4" 61301605467
Membrane Filter 4 x 40 61301605464
Tank Pressure Switch 40-60psi 61301605491
Solenoid Plastic 1" 24v 61301605486
Solenoid Brass 3/4" 24v 61301605489
Valve Check PVC 1" 61301605478
Housing Filter 20" BB 61301605465
O-Ring for Housing 20" BB 61301605469

HS-15000-PT Only

Gauge 0-100psi Gly. Pnl. Mt. 61301605511

HS-15000-FT Only

Horizontal Reed Float 61301605509
Pump/Motor for Repressurizer 61301605499
Tank for Repressurizer 61301605472
Valve Check PVC 80 11/4" 61301605479
Coil for Plastic Solenoid 61301605514
Valve PVC 40 1/2" 61301605480

95

RO Water Systems

This page is left blank intentionally.

96

Surgical Tables

MAQUET 1132.0XX ALPHASTAR

Electronic Components

Battery 12V 227.0154
Charger Board 970.2083
Transformer 3113.0513
Power Cord 3113.3669

Potentiometers

Leg & Back (Short Shaft, Older) 970.2243
Leg & Back (Long Shaft, Newer) 3113.6373
Tilt 3113.0624
Longitude & Height 3113.9754

Hand Control, Cable Connected

Spiral Cable With Plugs 200.4293

Hook 7421.8394

Counter Sunk Screw (For Hook) 1118.0379

Tallow-Drop Screw (For Back Cover) 1136.0499
Infrared Hand Control 1132.91C0

Mechanical Components

Base Cover (1132.01)
Base Cover (1132.03XX W/ Red Stripe) 3113.4563
Left Leg Cover Plate Conv. Kit 3114.3619
Right Leg Cover Plate Conv. Kit 3114.3629
Body-Bound Rivet 104.1214
Hydraulic Fluid (1ltr Bottle) 3112.6369

97

1132.90C0

3113.0943

Surgical Tables

MAQUET 1133.0XX ALPHAMAX

Electronic Components

Battery 12V 227.0154
Power Cord 3113.3669
Transformer 3113.6253
Charger Board 970.2873

1133.02F2 Potentiometers

Long. Shift & Height 3113.6594
Trend. & Tilt 3113.7384
Back & Leg 3113.7394

1133.02F3 Potentiometers

Longitude Shift 231.0614
Leg 231.0634
Back 231.0644
Height 231.0654
Trendelenburg 3113.0624

Cable Connected Hand Control

Spiral Cable With Plugs 200.4293

Hook 7421.8394

Counter Sunk Screw (For Hook) 1118.0379

Tallow-Drop Screw (For Back Cover) 1136.0499
Infrared Hand Control 1133.91A0

Column Covers

Lowest (Steel) (1 Side) 3113.7461
Lower Middle (Steel) (1 Side) 3113.7471
Upper Middle (Steel) (1 Side) 3113.7481
Upper (Steel) (1 Side) 3113.7491
Top Cover, Blue (2 Sides) 8601.3353

Mechanical Components

Body-Bound Rivet 104.1414
Twin Swivel Castor 501.3392
Hydraulic Fluid (1ltr Bottle) 3112.6369
Base cover 8601.3113

98

1133.90A0
