D-link DES-3528, DES-3552 User Manual

CLI Reference Guide

Product Model:

Layer 2 Managed Stackable Fast Ethernet Switch

Release 2.60

xStack

DES-3528/DES-3552 Series

Table of Contents

INTRODUCTION ......................................................................................................................... 5

USING THE CONSOLE CLI ........................................................................................................ 7

COMMAND SYNTAX ................................................................................................................ 10

BASIC SWITCH COMMANDS .................................................................................................. 12

MODIFY BANNER AND PROMPT COMMANDS ..................................................................... 24

SWITCH PORT COMMANDS ................................................................................................... 27

PORT SECURITY COMMANDS ............................................................................................... 31

STACKING COMMANDS .......................................................................................................... 36

NETWORK MANAGEMENT (SNMP) COMMANDS ................................................................. 40

SWITCH UTILITY COMMANDS ................................................................................................ 57

NETWORK MONITORING COMMANDS .................................................................................. 63

MULTIPLE SPANNING TREE PROTOCOL (MSTP) COMMANDS .......................................... 76

FORWARDING DATABASE COMMANDS ............................................................................... 87

TRAFFIC CONTROL COMMANDS .......................................................................................... 93

QOS COMMANDS .................................................................................................................... 97

PORT MIRRORING COMMANDS ........................................................................................... 107

VLAN COMMANDS ................................................................................................................. 110

VOICE VLAN COMMANDS ..................................................................................................... 124

SUBNET-BASED VLAN COMMANDS ................................................................................... 130

ASYMMETRIC VLAN COMMANDS ........................................................................................ 133

LINK AGGREGATION COMMANDS ...................................................................................... 135

IP–MAC-P ORT BINDING (IMPB) COMMANDS ..................................................................... 139

LIMITED IP MULTICAST ADDRESS ...................................................................................... 155

BASIC IP COMMANDS ........................................................................................................... 160

MULTICAST VLAN COMMANDS ........................................................................................... 165

IGMP / MLD SNOOPING COMMANDS .................................................................................. 179

DHCP RELAY COMMANDS ................................................................................................... 208

802.1X COMMANDS (INCLUDING GUEST VLANS) ............................................................. 221

ACCESS CONTROL LIST (ACL) COMM ANDS ..................................................................... 238

SAFEGUARD ENGINE COMMANDS ..................................................................................... 258

FILTER COMMANDS (DHCP SERVER / NETBIOS) .............................................................. 260

LAYER 3 CPU FILTER COMMANDS ..................................................................................... 265

LOOP-BACK DETECTION COMMANDS ............................................................................... 267

TRAFFIC SEGMENTATION COMMANDS ............................................................................. 271

SFLOW COMMANDS.............................................................................................................. 273

TIME AND SNTP COMMANDS ............................................................................................... 281

ARP AND GRATUITOUS ARP COMMANDS ......................................................................... 286

ROUTING TABLE COMMANDS ............................................................................................. 292

MAC NOTIFICATION COMMANDS ........................................................................................ 294

ACCESS AUTHENTICATION CONTROL COMMANDS ........................................................ 297

SECURE SHELL (SSH) COMMANDS .................................................................................... 315

SECURE SOCKETS LAYER (SSL) COMMANDS .................................................................. 321

D-LINK SINGLE IP MANAGEMENT COMMANDS ................................................................. 326

JWAC COMMANDS ................................................................................................................ 335

LINK LAYER DISCOVERY PROTOCOL (LLDP) COMMANDS ............................................. 350

Q-IN-Q COMMANDS ............................................................................................................... 363

RSPAN COMMANDS .............................................................................................................. 369

ST ATIC MAC-BASED VLAN COMMAND S ............................................................................ 373

SIMPLE RED COMMANDS ..................................................................................................... 375

MAC-BASED ACCESS CONTROL COMM ANDS LIST ......................................................... 382

WEB-BASED ACCESS CONTROL COMMANDS .................................................................. 392

POWER OVER ETHERNET (POE) COMMANDS ................................................................... 400

PPPOE CIRCUIT ID INSERTION COMMANDS ...................................................................... 404

DNS RELAY COMMANDS ...................................................................................................... 405

POLICY ROUTE COMMANDS ................................................................................................ 407

BPDU ATTACK PROTECTION COMMANDS ........................................................................ 409

ETHERNET OAM COMMANDS .............................................................................................. 413

DHCP SERVER COMMANDS ................................................................................................. 422

CABLE DIAGNOSTICS COMMANDS .................................................................................... 434

CONNECTIVITY FAULT MANAGEMENT COMMANDS ........................................................ 435

COMMAND HISTORY LIST .................................................................................................... 451

ARP SPOOFING PREVENTION COMMANDS ....................................................................... 453

AUTO-CONFIGURATION COMMANDS ................................................................................. 455

COMPOUND AUTHENTICATION COMMANDS .................................................................... 458

DEBUG SOFTWARE COMMANDS ........................................................................................ 464

DHCPV6 CLIENT COMMANDS .............................................................................................. 469

DHCPV6 RELAY COMMANDS ............................................................................................... 471

iii

D-LINK UNIDIRECTIONAL LINK DETECTION (DULD) COMMANDS................................... 476

ETHERNET RING PROTECTION SWITCHING (ERPS) COMMANDS .................................. 478

IPV6 NEIGHBOR DISCOVER COMMANDS ........................................................................... 487

IPV6 ROUTE COMMANDS ..................................................................................................... 491

LAYER 2 PROTOCOL TUNNELING (L2 PT) COMMANDS .................................................... 493

LOCAL ROUTE COMMANDS ................................................................................................. 496

MSTP DEBUG ENHANCEMENT COMM ANDS ...................................................................... 498

PING COMMANDS .................................................................................................................. 502

SHOW TECHNICAL SUPPORT COMMANDS ....................................................................... 504

TRACE ROUTE COMMANDS ................................................................................................. 507

VLAN COUNTER COMMANDS .............................................................................................. 509

APPENDIX A - P ASSWO RD RECOVERY PROCEDURE ...................................................... 512

APPENDIX B - TECHNICAL SPECIFICATIONS .................................................................... 513

APPENDIX C - MITIGATING ARP SPOOFING ATTACKS VIA PACKET CONTENT ACL ... 516

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

INTRODUCTION

The Switch can be managed through the Switch’s serial port, Telnet, or the Web-based management agent. The Command Line Interface (CLI) can be used to configure and manage the Switch via the serial port or Telnet interfaces.

The DES-3528/DES-3552 Series Layer 2 stackable Fast Ethernet Switch Series are members of the D-Link xStack family. Ranging from 10/100Mbps edge Switches to core gigabit Switches, the xStack Switch family has been futureproof designed to provide a stacking architecture with fault tolerance, flexibility, port density, robust security and maximum throughput with a user-friendly management interface for the networking professional.

This manual provides a reference for all of the commands contained in the CLI for the xStack 3528P, DES-3528DC, DE S-3552 and DES-3552P s eries of Switches. C onfiguration and managem ent of the Switch via the Web-based management agent is discussed in the User’s Guide.

NOTE: For the remainder of this manual, all versions of the DES-3528, DES-3528P, DES-3528DC, DES-3552 and DES-3552P Switches will be referred to as simply the Switch or the DES-3528/52 Series.

Accessing the Switch via the Serial Port

The Switch’s serial port’s default settings are as follows:

• 115200 baud

• no parity

• 8 data bits

• 1 stop bit

A computer running a terminal emulation program capable of emulating a VT-100 terminal and a serial port configured as above are then connected to the Switch’s serial port via an RS-232 DB-9 cable.

With the serial port properly connected to a management computer, the following screen should be visible. If this screen does not appear, try pressing Ctrl+r to refresh the console screen.

DES-3528, DES-

DES-3528 Fast Ethernet Switch

Command Line Interface

Firmware: Build 2.60.017

UserName:

Figure 1-1. Initial CLI screen

There is no initial username or password. Just press the Enter key twice to display the CLI input cursor − DES- 3528:admin# . This is the command line where all commands are input.

Setting the Switch’s IP Address

Each Switch must be assigned its own IP Address, which is used for communication with an SNMP network manager or other TCP/IP application (for example BOOTP, TFTP). The Switch’s default IP address is 10.90.90.90. Users can change the default Switch IP address to meet the specification of your networking address scheme.

The Switch is also assigned a unique MAC address by the factory. This MAC address cannot be changed, and can be found on the initial boot console screen – shown below.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# config ipif System ipaddress 10.24.73.21/8

DES-3528:admin#

Boot Procedure V1.00.B008

-------------------------------------------------------------------------------

Power On Self Test ........................................ 100 %

MAC Address : 00-22-B0-10-8A-00 H/W Version : A2

Please wait, loading V2.60..017 Runtime image ............. 100 %

UART init ................................................. 100 %

Device Discovery .......................................... 100 %

Configuration init ........................................ |

Figure 1-2. Boot screen

The Switch’s MAC addres s can also be found in the Web management program on the Switch Information (Basic Settings) window on the Configuration menu.

The IP address for the Sw itch must be set before it can be managed w ith the Web-based manager. The S witch IP address can be autom aticall y set using BOOTP or D HCP pro tocols, in which cas e the actua l address as signed t o the Switch must be known.

The IP address may be set using the Command Line Interface (CLI) over the console serial port as follows:

1. Starting at the command line prompt, enter the commands config ipif System ipaddress xxx.xxx.xxx.xxx/yyy.yyy.yyy.yyy. Where the x’s repres ent the IP address to be assigned to the IP inter face named System and the y’s represent the corresponding subnet mask.

2. Alternatively, users can enter con fig ipif System ip address xxx.xxx.x xx.xxx/z. Where the x’s represent the IP address to be assig ned t o the IP i nterf ace n am ed System an d the z represents the corr espondi ng num ber of subnets in CIDR notation.

The IP interface nam ed System on the Switch can be assigned an IP address and subnet mask which can then be used to connect a management station to the Switch’s Telnet or Web-based management agent.

Command: config ipif System ipaddress 10.24.73.21/8

Success.

Figure 1-3. Assigning an IP Address screen

In the above exam ple, the Switch w as assigned an IP address of 10.24 .73.21 with a sub net mask of 255.0. 0.0. The system message Success indicates that the command was executed successfully. The Switch can now be configured and managed via Telnet, S NMP MIB bro wser and the CLI or via th e Web-based management agent using t he above IP address to connect to the Switch.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

UserName:

clear fdb

USING THE CONSOLE CLI

The DES-3528/52 Series supports a console management interface that allows the user to connect to the Switch’s management agent via a serial port and a terminal or a computer running a terminal emulation program. The console can also be used over the network using the TCP/IP Telnet protocol. The console program can be used to configure the Switch to use an SNMP-based network management software over the network.

This chapter describes how to use the console interface to access the Switch, change its settings, and monitor its operation.

NOTE: Switch configuration settings are saved to non-volatile RAM using the save command. The current configuration will then be retained in the Switch’s NV-RAM , and reloa ded when t he Sw itch is rebooted. If the Switch is rebooted without using the save command, the last configuration saved to NV-RAM will be loaded.

Connecting to the Switch

The console interface is used by connecting the Switch to a VT100-compatible terminal or a computer running an ordinary terminal em ulator program (e.g., the HyperTerminal program included with the W indows operating s ystem) using an RS-232C serial cable. Your terminal parameters will need to be set to:

• VT-100 compatible

• 115200 baud

• 8 data bits

• No parity

• One stop bit

• No flow control

Users can also access the same functions over a Telnet interface. Once users have set an IP address for your Switch, users can use a Telnet program (in VT-100 compatible terminal mode) to access and control the Switch. All of the screens are identical, whether accessed from the console port or from a Telnet interface.

After the Switch reboots and users have logged in, the console looks like this:

DES-3528 Fast Ethernet Switch

Command Line Interface

Firmware: Build 2.60.017

Figure 2-1. Initial Console screen after logging in

Commands are entered at the command prompt, DES-3528:admin# .. There are a number of he lp f ul f eatur es i nc lu ded i n t he CLI. Entering the ? command will displa y a list of all of the top-

level commands.

cable_diag ports cfm linktrace cfm loopback clear clear address_binding dhcp_snoop binding_entry ports clear address_binding nd_snoop binding_entry ports clear arptable clear attack_log clear cfm pkt_cnt clear counters clear dhcp binding clear dhcp conflict_ip clear ethernet_oam ports

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

clear igmp_snooping data_driven_group

CTRL+C ESC q Quit SPACE n Next Page ENTER Next Entry a All

DES-3528:admin# config account

DES-3528:admin#

DES-3528:admin# config account

DES-3528:admin#

DES-3528:admin#the

save show telnet traceroute

clear igmp_snooping statistics counter clear jwac auth_state clear log clear mac_based_access_control auth_state clear mld_snooping data_driven_group

Figure 2-2. The ? Command

When users enter a command without its required parameters, the CLI will prompt users with a Next possible completions: message.

Command: config account

Next possible completions: <username>

Figure 2-3. Example Command Parameter Help

In this case, the comm and config account was entered with the parameter <username>. The CLI will then prom pt users to enter the <username> with the m ess age, Next possible completions:. Every command in the CL I has this feature, and complex commands have several layers of parameter prompting.

In addition, after typing an y given com mand plus one space, user s can see all of the next poss ible sub-commands, in sequential order, by repeatedly pressing the Tab key.

To re-enter the previo us command at the comm and prompt, press the up arr ow cursor key. The previ ous command will appear at the command prompt.

Command: config account Next possible completions: <username>

DES-3528:admin# config account Command: config account Next possible completions: <username>

Figure 2-4. Using the Up Arrow to Re-enter a Command

In the above example, the comm and config account was entered without the requ ired parameter <username>, the CLI returned the Next possible completions: <username> prompt. The up arrow cursor cont rol ke y was pressed to re-enter the previous com mand (config account) at the command prompt. Now the appropriat e username can be entered and the config account command re-executed.

All commands in the CLI function in this way. In addition, the syntax of the help prompts are the same as presented in this manual − angle brackets < > indicate a numerical value or character string, braces { } indicate optional parameters or a choice of parameters, and brackets [ ] indicate required parameters.

If a command is entered that is unrecognized by the CLI, the top-level commands will be displayed under the Available commands: prompt.

Available commands:

.. ? cable_diag cfm clear config create debug delete disable download enable login logout no ping ping6 reboot reconfig reset

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

traceroute6 upload

DES-3528:admin#

DES-3528:admin# show

DES-3528:admin#

The top-level comm ands consist of commands such as show or config. Most of these commands require one or more parameter s to narrow the top-level comm and. This is equivalent to show what? or config what? W here the what? is the next parameter.

For example, if users enter the show comm and with no additional parameters, the CLI will then displa y all of the possible next parameters.

Command: show

Next possible completions:

802.1p 802.1x access_profile account accounting acct_client address_binding arp_spoofing_prevention arpentry asymmetric_vlan attack_log auth_client auth_diagnostics auth_session_statistics auth_statistics authen authen_enable authen_login authen_policy authentication authorization autoconfig bandwidth_control bpdu_protection cfm command_history config cpu cpu_filter current_config device_status dhcp dhcp_local_relay dhcp_relay dhcp_server dhcpv6_relay dnsr dot1v_protocol_group dscp duld erps error ethernet_oam fdb filter firmware flow_meter gratuitous_arp greeting_message gvrp hol_prevention igmp_snooping ipfdb ipif ipif_ipv6_link_local_auto iproute ipv6 ipv6route jumbo_frame jwac l2protocol_tunnel lacp_port limited_multicast_addr link_aggregation lldp local_route log log_save_timing log_software_module loopdetect mac_based_access_control mac_based_access_control_local mac_based_vlan mac_notification max_mcast_group mcast_filter_profile mef_l2_protocols mef_vlan_preservation mirror mld_snooping multicast multicast_fdb packet per_queue poe policy_route port port_security port_security_entry port_vlan ports pppoe pvid qinq radius rmon router_ports rspan safeguard_engine scheduling scheduling_mechanism serial_port session sflow sim snmp sntp sred ssh ssl stack_device stack_information stacking_mode stp subnet_vlan switch syslog system_severity tech_support terminal time time_range traffic traffic_segmentation trap trusted_host utilization vlan vlan_counter vlan_precedence vlan_translation vlan_trunk voice_vlan wac

Figure 2-5. The Next Available Commands Prompt

In the above example, all of the possible next parameters for the show command are displayed. At the next command prompt, the up arrow was used to re-enter the show command, followed by the account parameter. The CLI then displays the user accounts conf igured on the S witc h.

Figure 2-6. Next possible completions: Show Command

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

COMMAND SYNTAX

The following symbols are used to describe how command entries are made and values and arguments are specified in this manual. The online help contained in the CLI and available through the console interface uses the same syntax.

NOTE: All commands are case-sensitive. Be sure to disable Caps Lock or any other unwanted function that changes text case.

Purpose Encloses a variable or value that must be specified. Syntax

Description In the above syntax example, users must supply an IP interface name in the <ipif_name

Example Command

config ipif <ipif_name 12> [{ipaddress <network_address> | vlan <vlan_name 32> | state [enable | disable}] | bootp | dhcp]

12> space, a VLAN name in the <vlan_name 32> space, and the network address in the <network_address> space. Do not type the angle brackets.

config ipif Engineering ipaddress 10.24.22.5/255.0.0.0 vlan Design state enable

[square brackets]

Purpose Encloses a required value or set of required arguments. One value or argument can be

specified. Syntax Description

Example Command

create account [admin | operator | user] <username 15>

In the above syntax example, users must specify either an admin or a user level account

to be created. Do not type the square brackets.

create account admin Tommy

| vertical bar

Purpose Separates two or more mutually exclusive items in a list, one of which must be entered. Syntax Description

Example Command

create account [admin | operator | user] <username 15>

In the above syntax example, users must specify either admin, or user. Do not type the

vertical bar.

create account admin Tommy

{braces}

Purpose Encloses an optional value or set of option al arguments. Syntax Description

Example command

reset {[config | system]} force_agree

In the above syntax example, users have the option to specify config or system. It is not

necessary to specify either optional value, however the effect of the system reset is

dependent on which, if any, value is specified. Therefore, with this example there are three

possible outcomes of performing a system reset. See the following chapter, Basic

Commands for more details about the reset command. Do not type the braces.

reset config

(parentheses)

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

(parentheses)

Purpose Indicates at least one or more of the values or arguments in the preceding syntax

enclosed by braces must be specified. Syntax Description

Example command

config dhcp_relay {hops <value 1-16> | time <sec 0-65535>}(1)

In the above syntax example, users have the option to specify hops or time or both of

them. The "(1)" following the set of braces indicates at least one argum ent or valu e within

the braces must be specified. Do not type the parentheses.

config dhcp_relay hops 3

Line Editing Key Usage

Delete Deletes the character under the cursor and then shifts the remaining characters in the line

to the left.

Backspace Deletes the character to the left of the cursor and then shifts the remaining characters in

the line to the left. Left Arrow Moves the cursor to the left. Right Arrow Moves the cursor to the right. Up Arrow Repeats the previously entered command. Each time the up arrow is pressed, the

command previous to that displayed appears. This way it is possible to review the

command history for the current session. Use the down arrow to progress sequentially

forward through the command history list. Down Arrow The down arrow will display the next command in the command history entered in the

current session. This displays each command sequentially as it was entered. Use the up

arrow to review previous commands. Tab Shifts the cursor to the next field to the left.

Multiple Page Display Control Keys

Space Displays the next page. CTRL+c Stops the display of remaining pages when multiple pages are to be displayed. ESC Stops the display of remaining pages when multiple pages are to be displayed. n Displays the next page. p Displays the previous page. q Stops the display of remaining pages when multiple pages are to be displayed. r Refreshes the pages currently displayed. a Displays the remaining pages without pausing between pages. Enter Displays the next line or table entry.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

BASIC SWITCH COMMANDS

The basic Switch commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.

Command Parameters

create account [admin | operator | power_u s er | user] <usern ame 15> config account <username> {encr ypt [plai n _tex t | sha_1] <password>} show account delete account <username> enable password

encryption

disable password

encryption show session show switch show device_status show serial_port config serial_port {baud_rate [9600 | 19200 | 38400 | 115200] | auto_ log out [ne ver | 2_m inutes | 5_ minutes |

enable clipaging disable clipaging telnet <ipaddr> {tcp_port <value 1-65535>} enable telnet <tcp_port_number 1-65535> disable telnet enable web <tcp_port_number 1-65535> disable web

10_minutes | 15_minutes]}(1)

save {[config <config_id 1-2> | log | all]} reboot {force_agree} reset {[config | system]} {force_agree} login logout clear config terminal width [default | <value 80-200>] show terminal width

Each command is listed, in detail, in the following sections.

create account

Purpose

Used to create user accounts.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# create account admin dlink

DES-3528:admin#

create account

Syntax create account [admin | operator | power_user | user] <username 15> Description

Parameters admin – Specifies that the user account wi ll be set to admin.

Restrictions

Example usage:

To create an administrator-level user account with the username “dlink”.

Command: create account admin dlink

Enter a case-sensitive new password:**** Enter the new password again for confirmation:**** Success.

This command is used to create user accounts that consist of a username of 1 to 15 characters and a password of 0 to 15 characters. Up to 8 user accounts can be created.

operator – Specifies that the user account will be set to operator. power_user – Specifies that the user account will be set to power user. user – Specifies that the user account will be set to user. <username 15> - Enter the account username here. This name can be up to 15 characters

long. Only Administrator-level users can issue this command.

Usernames can be between 1 and 15 characters. Passwords can be between 0 and 15 characters.

NOTICE: In case of lost passwords or password corruption, please refer to the D-Link website and the White Paper entitled “Password Recovery Procedure”, which will guide you through the steps necessary to resolve this issue.

config account

Purpose Syntax config account <username> {encrypt [plain_text | sha_1] <password>} Description

Parameters

Used to configure user accounts

When the password information is not specified in the command, the system will prompt the user to input the password interactively. For this case, the user can only input the plain text password.

If the password is present in the command, the user can select to input the password in the plain text form or in the encrypted form. The encryption algorithm is based on SHA-I.

<username> − Name of the account. The account must already be defined. plain_text − Select to specify the password in plain text form. sha_1 − Select to specify the password in the SHA-I enacrpted form. password − The password for the user account.

The length for of password in plain-text form and in encrypted form are different. For the plain-text form, passwords must have a minimum of 0 character and can have a maximum of 15 characters. For the encrypted form password, the length is fixed to 35 bytes long. The assword is case-sensitive.

Restrictions

Example usage:

To configure the user password of “dlink” account:

Only Administrator-level users can issue this command. Usernames can be between 1 and 15 characters. Passwords can be between 0 and 15 characters.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# config account dlink

DES-3528:admin#

DES-3528:admin# show account

DES-3528:admin#

DES-3528:admin# delete account System

DES-3528:admin#

Command: config account dlink

Enter a old password:**** Enter a case-sensitive new password:**** Enter the new password again for confirmation:**** Success.

show account

Purpose Syntax show account Description

Parameters Restrictions

Example usage:

To display the accounts that have been created:

Command: show account

Current Accounts: Username Access Level

--------------- -----------dlink Admin

Total Entries: 1

Used to display user accounts.

This command is used to display all user accounts created on the Switch. Up to 8 user accounts can exist at one time.

None. Only Administrator-level users can issue this command.

delete account

Purpose Syntax delete account <username> Description Parameters Restrictions

Example usage:

To delete the user account “System”:

Command: delete account System

Success.

enable password encryption

Purpose Syntax enable password encryption Description

Used to delete an existing user account.

This command is used to delete an existing entry. <username> − Name of the user who will be deleted. Only Administrator-level users can issue this command.

Used to enable password encryption.

The user account configuration information will be stored in the configuration file, and can be

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

applied to the system later.

DES-3528:admin# enable password encryption

DES-3528:admin#

DES-3528:admin# disable password encryption

DES-3528:admin#

enable password encryption

If the password encryption is enabled, the password will be in encrypted form. When password encryption is diabled, if the user specifies the password in plain text form,

the password will be in plain text form. However, if the user specifies the password in encrypted form, or if the password has been converted to encrypted form by the last enable password encryption command, the password will still be in the encrypted form. It cannot be reverted to the plaintext.

Parameters Restrictions

Example usage:

To enable password encryption:

Command: enable password encryption

Success.

None. Only Administrator-level users can issue this command.

disable password encryption

Purpose Syntax disable password encryption Description

Used to disable password encryption.

The user account configuration information will be stored in the configuration file, and can be applied to the system later.

If the password encryption is enabled, the password will be in encrypted form. When password encryption is disabled, if the user specifies the password in plain text form,

the password will be in plan text form. However, if the user specifies the password in encrypted form, or if the password has been converted to encrypted form by the last enable password encryption command, the password will still be in the encrypted form. It cannot be reverted to the plaintext.

Parameters Restrictions

Example usage:

To disable password encryption:

Command: disable password encryption

Success.

None. Only Administrator-level users can issue this command.

show session

Purpose Syntax show session Description

Parameters Restrictions

Example usage:

Used to display a list of currently logged-in users.

This command displays a list of all the users that are logged-in at the time the command is issued.

None. Only Administrator and Operator-level users can issue this command.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# show session

CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh

DES-3528:admin# show switch

CTRL+C ESC q Quit SPACE n Next Page ENTER Next Entry a All

To display the way that the users logged in:

Command: show session

ID Live Time From Level Name

--- --------- ------------ ----- ------ 8 00:00:16.250 Serial Port 5 Anonymous

Total Entries: 1

show switch

Purpose Syntax show switch Description Parameters Restrictions

Example usage:

To display the Switch’s information:

Command: show switch

Device Type : DES-3528 Fast Ethernet Switch MAC Address : 1C-AF-F7-AD-33-20 IP Address : 10.90.90.90 (Manual) VLAN Name : default Subnet Mask : 255.0.0.0 Default Gateway : 0.0.0.0 Boot PROM Version : Build 1.00.B008 Firmware Version : Build 2.60.B010 Hardware Version : A4 Serial Number : P1UQ3A4000012 System Name : System Location : System Uptime : 0 days, 0 hours, 3 minutes, 58 seconds System Contact : Spanning Tree : Disabled GVRP : Disabled IGMP Snooping : Disabled MLD Snooping : Disabled VLAN Trunk : Disabled Telnet : Enabled (TCP 23) Web : Enabled (TCP 80) SNMP : Disabled

Used to display general information about the Switch.

This command displays information about the Switch. None. None.

show device_status

Purpose Syntax show device_status Description

Parameters

Used to display the current Switch’s power and fan status.

This command displays status of both the Switch’s internal and external power and the fan status.

None.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# show device_status

DES-3528:admin#

DES-3528:admin#show serial_port

DES-3528:admin#

show device_status

Restrictions

Example usage:

To display the Switch’s device status:

Command: show device_status

Internal Power: Active External Power: Fail

None.

show serial_port

Purpose Syntax show serial_port Description Parameters Restrictions

Example usage:

Used to display the current serial port settings.

This command displays the current serial port settings. None. None

To display the serial port setting:

Command: show serial_port

Baud Rate : 115200 Data Bits : 8 Parity Bits : None Stop Bits : 1 Auto-Logout : Never

config serial_port

Purpose Syntax config serial_port {baud_rate [9600 | 19200 | 38400 | 115200] | auto_logout [never |

Description

Parameters

Restrictions

Used to configure the serial port.

2_minutes | 5_minutes | 10_minutes | 15_minutes]}(1) This command is used to configure the serial port’s baud rate and auto logout settings. baud_rate [9600 | 19200 | 38400 | 115200] − The serial bit rate that will be used to

communicate with the management host. There are four options: 9600, 19200, 38400,

115200. Factory default setting is 115200.

never − No time limit on the length of time the console can be open with no user input. 2_minutes − The console will log out the current user if there is no user input for 2 minutes. 5_minutes − The console will log out the current user if there is no user input for 5 minutes. 10_minutes − The console will log out the current user if there is no user input for 10

minutes. 15_minutes − The console will log out the current user if there is no user input for 15

minutes. Only Administrator and Operator-level users can issue this command.

Example usage:

To configure baud rate:

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# config serial_port baud_rate 115200

DES-3528:admin#

DES-3528:admin# enable clipaging

DES-3528:admin#

DES-3528:admin# disable clipaging

DES-3528:admin#

default setting.

Command: config serial_port baud_rate 115200

Success.

NOTE: If a user configures the serial port’s baud rate, the baud rate will take effect and save immediately. Baud rate settings will not change even if the user resets or reboots the Switch. The Baud rate will only change when the user configures it again. The serial port’s baud rate setting is not stored in the Switch’s configuration file. Resetting the Switch will not restore the baud rate to the

enable clipaging

Purpose

Syntax enable clipaging Description

Parameters Restrictions

Example usage:

To enable pausing of the screen display when the show command output reaches the end of the page:

Command: enable clipaging

Success.

Used to pause the scrolling of the console screen when a command displays more than one page.

This command is used when issuing a command which causes the console screen to rapidly scroll through several pages. This command will cause the console to pause at the end of each page. The default setting is enabled.

None. Only Administrator and Operator-level users can issue this command.

disable clipaging

Purpose

Used to disable the pausing of the console screen scrolling at the end of each pa ge when a command displays more than one screen of information.

Syntax disable clipaging Description

Parameters Restrictions

Example usage:

To disable pausing of the screen display when show command output reaches the end of the page:

Command: disable clipaging

Success.

This command is used to disable the pausing of the console screen at the end of each page when a command would display more than one screen of information.

None. Only Administrator and Operator-level users can issue this command.

telnet

Purpose

Used to login the remote device system through the network.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# telnet 172.18.168.12 tcp_port 50

PassWord:

DES-3528:admin# enable telnet 23

DES-3528:admin#

telnet

Syntax telnet <ipaddr> {tcp_port <value 1-65535>} Description

Parameters

Restrictions

Example usage:

Telnet to the remote Switch:

Command: telnet 172.18.168.12 tcp_port 50

Connecting to server,please wait....

DES-3528 Gigabit Ethernet Switch Command Line Interface

This command is used when the manager want to manage the device system which isn’t on local. So can use this command to login in the remote system which is located on other side. If connect successful, some actions can be done as local.

<ipaddr> − The network ip address. This is the destination which wa nts to login. <value 1-65535> − The TCP port number. TCP ports are numbered between 1 and 65535.

The “well-known” TCP port for the Telnet protocol is 23. Only Administrator and Operator-level users can issue this command.

enable telnet

Purpose

Syntax enable telnet <tcp_port_number 1-65535> Description

Parameters

Restrictions

Example usage:

To enable Telnet and configure port number:

Command: enable telnet 23

Success.

Used to enable communication with and management of the Switch using the Telnet protocol.

This command is used to enable the Telnet protocol on the Switch. The user can specify the TCP or UDP port number the Switch will use to listen for Telnet requests.

<tcp_port_number 1-65535> − The TCP port number. TCP ports are numbered between 1 and 65535. The “well-known” TCP port for the Telnet protocol is 23.

Only Administrator and Operator-level users can issue this command.

disable telnet

Purpose Syntax disable telnet Description Parameters Restrictions

Example usage:

Used to disable the Telnet protocol on the Switch.

This command is used to disable the Telnet protocol on the Switch. None. Only Administrator and Operator-level users can issue this command.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# disable telnet

DES-3528:admin#

DES-3528:admin# enable web 80

DES-3528:admin#

DES-3528:admin# disable web

DES-3528:admin#

To disable the Telnet protocol on the Switch:

Command: disable telnet

Success.

enable web

Purpose Syntax enable web <tcp_port_number 1-65535> Description

Parameters

Restrictions

Example usage:

To enable HTTP and configure port number:

Command: enable web 80

Success.

Used to enable the HTTP-based management software on the Switch.

This command is used to enable the Web-based management software on the Switch. The user can specify the TCP port number the Switch will use to listen for Telnet requests.

<tcp_port_number 1-65535> − The TCP port number. TCP ports are numbered between 1 and 65535. The “well-known” port for the Web-based management software is 80.

Only Administrator and Operator-level users can issue this command.

disable web

Purpose Syntax disable web

Used to disable the HTTP-based management software on the Switch.

Description Parameters Restrictions

Example usage:

To disable HTTP:

Command: disable web

Success.

This command disables the Web-based management software on the Switch. None. Only Administrator and Operator-level users can issue this command.

save

Purpose Syntax save {[config <config_id 1-2> | log | all]} Description

Parameters config <config_id 1-2> – Specify to save current settings to configuration file 1 or 2.

Used to save changes in the Switch’s configuration to non-volatile RA M.

This command is used to enter the current Switch configuration into non-volatile RAM. The saved Switch configuration will be loaded into the Switch’s memory each time the Switch is restarted.

log – Specify to save current Switch log to NV-RAM.

save

all – Specify to save all configuration settings. If nothing is specified after “save”, the Switch

DES-3528:admin# save

DES-3528:admin#

DES-3528:admin# reboot

Please wait, the switch is rebooting...

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

will save all.

Restrictions

Only Administrator and Operator-level users can issue this command.

Example usage:

To save the Switch’s current configuration to non-volatile RAM:

Command: save

Saving all configurations to NV-RAM... Done.

reboot

Purpose Syntax Reboot {force_agree} Description Parameters

Restrictions

Example usage: To restart the Switch:

Used to restart the Switch.

This command is used to restart the Switch. force_agree − When force_agree is specified, the reboot command will be executed

immediatedly without further confirmation. Only Administrator-level users can issue this command.

Command: reboot Are you sure you want to proceed with the system reboot? (y|n)y

reset

Purpose Syntax reset {[config | system]} {force_agree} Description

Parameters

Used to reset the Switch to the factory default settings.

This command is used to restore the Switch’s configuration to the default settings assigned from the factory.

config − If the keyword ‘config’ is specified, all of the factory default settings are restored on the Switch including the IP address, user accounts, and the Switch history log. The Switch will not save or reboot.

system − If the keyword ‘system’ is specified all of the factory default settings are restored on the Switch. The Switch will save and reboot after the settings are changed to default. Rebooting will clear all entries in the Forwarding Data Base.

force_agree − When force_agree is specified, the reset command will be executed immediatedly without further confirmation.

If no parameter is specified, the Switch’s current IP address, user accounts, and the Switch history log are not changed. All other parameters are restored to the factory default settings. The Switch will not save or reboot.

NOTE: The serial port baud rate will not be changed by the reset command. It will not be restored to the factory default setting.

Restrictions

Example usage:

Only Administrator-level users can issue this command.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# reset config

DES-3528:admin#

DES-3528:admin# login

UserName:

DES-3528:admin# logout

To restore all of the Switch’s parameters to their default values:

Command: reset config Are users sure to proceed with system reset?(y/n)y

Success.

Purpose Syntax login Description

Parameters Restrictions

Example usage:

To initiate the login procedure:

Command: login

Used to log in a user to the Switch’s console.

This command is used to initiate the login procedure. The user will be prompted for a Username and Password.

None. None.

logout

Purpose Syntax logout Description Parameters

Used to log out a user from the Switch’s console.

This command terminates the current user’s session on the Switch’s console. None.

Restrictions

Example usage:

To terminate the current user’s console session:

None.

clear

Purpose Syntax clear Description Parameters Restrictions

Example usage:

The command is used to clear screen.

The command is used to clear screen. None. None.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# clear

DES-3528:admin#

DES-3528:admin# config terminal width 120

DES-3528:admin#

DES-3528:admin#show terminal width

DES-3528:admin#

To clear screen:

Command: clear

config terminal width

Purpose Syntax config terminal width [defau lt | <value 80-200>] Description

Parameters default - The default setting of terminal width. The default value is 80.

Restrictions

Example usage: To configure the current terminal width:

Command: config terminal width 120

Success.

The command is used to set current terminal width.

The usage is described as below:

1. Users login and configure the terminal width to 120, this configuration take effect on this login section. If users implement “save” command, the configuration is saved. After users log out and log in again, the terminal width is 120.

2. If user did not save the configuration, another user login, the terminal width is default value.

3. If at the same time, two CLI sessions are running, once section configure to 120 width and save it, the other section will not be effected, unless it log out and then log in.

<value 80-200> - The terminal width which will be configured. The width is betw ee n 80 and 200 characters.

None.

show terminal width

Purpose Syntax show terminal width Description Parameters Restrictions

Example usage: To display the configuration of current terminal width:

Command: show terminal width

Global terminal width : 80 Current terminal width : 80

The command is used to display the configuration of current terminal width.

The command is used to display the configuration of current terminal width. None. None.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin#config command_prompt AtYourService

AtYourService:admin#

MODIFY BAN NER AN D PROMPT COMMANDS

Administrator level users can modify the login banner (greeting message) and command prompt by using the commands described below.

Command Parameters

config command_prompt [<string 16> | username | default] config greeting_message {default} show greeting_message

The Modify Banner and Pr om pt comm ands in the Com mand Line I nterf ace (C LI) ar e listed ( along w ith the appropr iate parameters) in the following table.

config command prompt

Purpose Syntax config command_prompt [<string 16> | username | default] Description Parameters string 16 –The command prompt can be changed by entering a new name of no more that 16

Restrictions

Example usage: To modify the command prompt to “AtYourService”:

Command: config command_prompt AtYourService

Success.

Used to configure the command prompt.

This command is used to change the command prompt.

characters.

username – The command prompt will be changed to the login username. default – The command prompt will reset to factory default command prompt.

Only Administrator and Operator-level users can issue this command. Other restrictions include:

• If the “reset” command is executed, the modified command prompt will remain modified. However, the “reset config/reset system” command will reset the command prompt to the original factory banner.

config greeting _message

Purpose Syntax config greeting _message {default} Description Parameters default – If the user enters default to the modify banner command, then the banner will be

Used to configure the login bann er (greet in g m es s age).

This command is used to modify the login banner (greeting message).

reset to the original factory banner. To open the Banner Editor, click enter after typing the config greeting_message command.

Type the information to be displayed on the banner by using the commands described on the Banner Editor:

Quit without save: Ctrl+C Save and quit: Ctrl+W Move cursor: Left/Right/Up/Down Delete line: Ctrl+D

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

Erase all setting: Ctrl+X

DES-3528:admin#config greeting_message

config greeting _message

Reload original setting: Ctrl+L

Restrictions

Example usage: To modify the banner:

Command: config greeting_message

Greeting Messages Editor ================================================================================ DES-3528 Fast Ethernet Switch Command Line Interface

<Function Key> <Control Key> Ctrl+C Quit without save left/right/ Ctrl+W Save and quit up/down Move cursor Ctrl+D Delete line Ctrl+X Erase all setting Ctrl+L Reload original setting

--------------------------------------------------------------------------------

Only Administrator and Operator-level users can issue this command. Other restrictions include:

• If the “reset” command is executed, the modified banner will remain modified. However, the “reset config/reset system” command will reset the modified banner to the original factory banner.

• The capacity of the banner is 6*80. 6 Lines and 80 characters per line.

• Ctrl+W will only save the modified banner in the DRAM. Users need to type the

“save” command to save it into FLASH.

• Only valid in threshold level.

show greeting_message

Purpose Syntax show greeting_message Description Parameters Restrictions

Example usage: To view the currently configured greeting message:

Used to view the currently configured greeting message configured on the Switch.

This command is used to view the currently configured greeting message on the Switch. None. Only Administrator and Operator-level users can issue this command.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin#show greeting_message

DES-3528:admin#

Command: show greeting_message

================================================================================ DES-3528 Fast Ethernet Switch Command Line Interface

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

SWITCH PORT COMMANDS

The Switch port commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.

Command Parameters

config ports [<portlist> | all] {medium_type [fiber | copper]} {speed [auto | 10_half | 10_full | 100_half |

100_full | 1000_full {[master | slave]}] | flow_control [enable | disable] | learning [enable | disable ] | state [enable | disable] | mdix [auto | normal | cross] | [description <desc 1-3 2 > |

clear_description]} show ports {<portlist>} {[description | err_disabled | details | media_type]} enable jumbo_frame disable jumbo_frame show jumbo_frame

Each command is listed, in detail, in the following sections.

config ports

Purpose Syntax config ports [<portlist> | all] {medium_type [fiber | copper]} {speed [auto | 10_half |

Description

Parameters

Used to configure the Switch’s port settings.

10_full | 100_half | 100_full | 1000_full {[master | slave]}] | flow_control [enable | disable] | learning [enable | disable ] | state [enable | disable] | mdix [auto | normal | cross] | [description <desc 1-32> | clear_description]}

This command is used to configure the Switch’s Ethernet ports. Only the ports listed in the <portlist> will be affected.

all − Configure all ports on the Switch. <portlist> − Specifies a port or range of ports to be configured. speed – Allows the user to adjust the speed for a port or range of ports. The user has a

choice of the following:

auto − Enables auto-negotiation for the specified range of ports. [10 | 100 | 1000] − Configures the speed in Mbps for the specified range of ports.

Gigabit ports are statically set to 1000. When setting port speed to 1000_full,user should specify master or slave mode for 1000 base TX interface, and leave the 1000_full without any master or slave setting for other interfaces.

[half | full] − Configures the specified range of ports as either full-duplex or half-duplex. flow_control [enable | disable] – Enable or disable flow control for the specified ports. learning [enable | disable] − Enables or disables the MAC address learning on the specified

range of ports. medium_type – Specify the medium type while the configured ports are combo ports. It’s an

optional parameter for configuring medium type combo ports. For no combo ports, user does not need to specify medium_type in the commands.

state [enable | disable] − Enables or disables the specified range of ports. description − Enter an alphanumeric string of no more than 32 characters to describe a

selected port interface.

clear description – To clear the description. mdix [auto | normal | cross] – MDIX mode can be specified as auto, normal, or cross. If set to

normal state, the port is in MDIX mode and can be connected to a port on an end node, such as a server or PC, using a straight-through cable. If set to cross state, the port is in MDI mode, and can be connected to a port on another Switch or hub that uses MDI-X ports through a straight-through cable. If set to auto state, the ports can be connected to any connections by using straight-through or cross-over cable. The ports make the necessary adjustments to accommodate either cable for correct operation.

Restrictions

Only Administrator and Operator-level users can issue this command.

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# config ports 1-3 speed 10_full learning enable state enable

DES-3528:admin#

DES-3528:admin# show ports

CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh

DES-3528:admin# show ports description Command: show ports description

Example usage:

To configure the speed of ports 1-3 of unit 1 to be 10 Mbps, full duplex, learning enabled, state enabled and flow control enabled:

flow_control enable Command: config ports 1-3 speed 10_full learning enable state enable flow_control enable

Success.

show ports

Purpose Syntax show ports {<portlis t>} {[description | err_disabled | details | media_type]} Description Parameters

Restrictions

Example usage:

To display the configuration of all ports on a Switch:

Command: show ports

Port State/ Settings Connection Address MDIX Speed/Duplex/FlowCtrl Speed/Duplex/FlowCtrl Learning

------- -------- --------------------- ---------------------- -------- 1 Enabled Auto/Disabled Link Down Enabled Auto 2 Enabled Auto/Disabled Link Down Enabled Auto 3 Enabled Auto/Disabled Link Down Enabled Auto 4 Enabled Auto/Disabled Link Down Enabled Auto 5 Enabled Auto/Disabled Link Down Enabled Auto 6 Enabled Auto/Disabled Link Down Enabled Auto 7 Enabled Auto/Disabled Link Down Enabled Auto 8 Enabled Auto/Disabled Link Down Enabled Auto 9 Enabled Auto/Disabled Link Down Enabled Auto

Used to display the current configuration of a range of ports.

This command is used to display the current configuration of a range of ports.

<portlist> − Specifies a port or range of ports to be displayed. description – Adding this parameter to the show ports command indicates that a previously

entered port description will be included in the display. err_disabled – Use this to list disabled ports including connection status and reason for being

disabled.

details – Use this to show the detail information of ports. media_type – Specifies the media type used.

None.

Example usage:

To display the configuration of all ports on a standalone Switch, with description:

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh

DES-3528:admin# show ports err_disabled

DES-3528:admin#

DES-3528:admin# show ports details

CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh

Port State/ Settings Connection Address MDIX Speed/Duplex/FlowCtrl Speed/Duplex/FlowCtrl Learning

------- -------- --------------------- ---------------------- -------- 1 Enabled Auto/Disabled Link Down Enabled Auto Description: 2 Enabled Auto/Disabled Link Down Enabled Auto Description: 3 Enabled Auto/Disabled Link Down Enabled Auto Description: 4 Enabled Auto/Disabled Link Down Enabled Auto Description: 5 Enabled Auto/Disabled Link Down Enabled Auto Description: 6 Enabled Auto/Disabled Link Down Enabled Auto Description:

Example usage:

To display disabled ports i n cludi ng c on nect ion s tat us and r eason for being disabled on a standalone Switch:

Command: show ports err_disabled

Port Port Connection Status Reason State

----- -------- --------------------- ----------------

Example usage:

To display detail information of ports on the Switch:

Command: show ports details

Port : 1

--------------------

Port Status : Link Down Description : HardWare Type : Fast Ethernet MAC Address : 00-22-B0-10-8A-01 Bandwidth : 100000Kbit Auto-Negotiation : Enabled Duplex Mode : Full Duplex Flow Control : Disabled MDI : Auto Address Learning : Enabled Last Clear of Counter : 0 hours 3 mins ago BPDU Hardware Filtering Mode: Disabled Queuing Strategy : FIFO

TX Load : 0/100, 0bits/sec, 0packets/sec RX Load : 0/100, 0bits/sec, 0packets/sec

xStack® DES-3528/DES-3552 Series Layer 2 Fast Ethernet Managed Switc h CLI Reference Guide

DES-3528:admin# enable jumbo_frame

DES-3528:admin#

DES-3528:admin# disable jumbo_frame

DES-3528:admin#

DES-3528:admin# show jumbo_frame

DES-3528:admin#

enable jumbo_frame

Purpose Syntax enable jumbo_frame Description

Parameters Restrictions

Example usage:

To enabled the jambo frame:

Command: enable jumbo_frame

The maximum size of jumbo frame is 9216 bytes. Success.

Used to enable the jumbo frame function on the Switch.

This command will allow ethernet frames larger than 1536 bytes to be processed by the Switch. The maximum size of the jumbo frame may not exceed 9220 Bytes tagged.

None. Only Administrator and Operator-level users can issue this command.

disable jumbo_frame

Purpose Syntax

Used to disable the jumbo frame function on the Switch. disable jumbo_frame

Description Parameters Restrictions

Example usage:

To disable the jumbo frame:

Command: disable jumbo_frame

Success.

This command will disable the jumbo frame function on the Switch. None. Only Administrator and Operator-level users can issue this command.

show jumbo_frame

Purpose Syntax Description Parameters Restrictions

Used to show the status of the jumbo frame function on the Switch. show jumbo_frame This command will show the status of the jumbo frame function on the Switch. None. None.

Example usage:

To show the jumbo frame status currently configured on the Switch:

Command: show jumbo_frame

Jumbo Frame State : Disabled Maximum Frame Size : 1536 Bytes

+ 492 hidden pages
