CONTENTS
Precautions.................................................................................................................. |
|
|
1 |
Precautions & Warnings |
.............................................................................................. |
1 |
|
Lithium Battery Cell Warnings..................................................................................... |
1 |
||
Drivers and Connections............................................................................................. |
1 |
||
Other Warnings.......................................................................................................... |
|
|
1 |
Installation................................................................................................................... |
|
|
.2 |
Installation Opening................................................................................................... |
|
2 |
|
To Install the Car Radio............................................................................................... |
|
2 |
|
Electrical Connections................................................................................................... |
|
3 |
|
Control Panel Button Locations....................................................................................... |
4 |
||
General Operation......................................................................................................... |
|
|
5 |
Turn Unit On/Off......................................................................................................... |
|
|
5 |
Adjust Volume (VOL).................................................................................................. |
|
5 |
|
Adjust Menu Options (SEL)......................................................................................... |
5 |
||
Set the Clock (CLK).................................................................................................... |
|
5 |
|
Change the Source (SRC)........................................................................................... |
6 |
||
Mute on/off................................................................................................................ |
|
|
6 |
Loudness on/off......................................................................................................... |
|
|
6 |
Preset EQ(Equalizer)................................................................................................. |
|
6 |
|
USB Port................................................................................................................... |
|
|
6 |
Micro-SD Card Slot..................................................................................................... |
|
|
6 |
Hands-free Microphone |
.............................................................................................. |
6 |
|
AUX input Connector.................................................................................................. |
|
6 |
|
Reset Sytstem (Reset)................................................................................................ |
|
6 |
|
Radio Operation............................................................................................................ |
|
|
7 |
Switch Between USA area and Europe area Frequency................................................... |
7 |
||
Change Bands (BAND)................................................................................................ |
|
7 |
|
Manual Tuning ( |
/ |
)............................................................................................. |
7 |
Auto Seek Tuning ( |
/ |
)........................................................................................ |
7 |
To Store/Recall Preset Stations (1 - 6)........................................................................... |
7 |
||
Automatic Store Station / Preset Station Scan (AMS)..................................................... |
7 |
||
Local/DX.................................................................................................................... |
|
|
7 |
Stereo/Mono............................................................................................................... |
|
|
7 |
USB/SD Card Operation................................................................................................. |
|
8 |
|
To Insert a USB / SD Card............................................................................................ |
8 |
||
Eject USB/SD Card..................................................................................................... |
|
|
8 |
Play/Pause................................................................................................................. |
|
|
8 |
Next/Previous Track.................................................................................................... |
|
8 |
|
Fast Forward/Backward............................................................................................... |
|
8 |
|
Introduction Scan........................................................................................................ |
|
|
8 |
Repeating the same track........................................................................................... |
8 |
||
Playing All Tracks in Random....................................................................................... |
8 |
||
Track/Folder Navigation |
.............................................................................................. |
8 |
|
Select the track or file for playback in MP3 format........................................................... |
8 |
||
Auxiliary Input operation................................................................................................ |
|
9 |
|
Bluetooth Operation..................................................................................................... |
|
|
10 |
Pair and Connect....................................................................................................... |
|
|
10 |
Make a Call............................................................................................................... |
|
|
10 |
Redial Last Dialed Number......................................................................................... |
10 |
||
Answer a Call / Reject a Call / End a Call...................................................................... |
10 |
||
Switch Audio Between Car audio and Moble Phone....................................................... |
10 |
||
Adjust Call Volume.................................................................................................... |
|
|
10 |
Audio Streaming (A2DP)............................................................................................ |
10 |
||
Remote Control........................................................................................................... |
|
|
11 |
Specifications............................................................................................................. |
|
|
12 |
Troubleshooting........................................................................................... |
|
|
13 |
PRECAUTIONS
Precautions & Warnings
•To reduce the risk of fire, electric shock, and interfer-ence, do not attempt to repair this unit yourself. Refer all service to a qualified technician.
•Some MP3/WMA files may not be playable.
•Keep the volume at a reasonable level to avoid distracted driving. High volume levels may make it difficult to concentrate on traffic and road conditions while driving.
•If the car has been in direct sunlight for an extended period, you may need to reduce the temperature inside the car before turning on and using the unit.
•If the battery is disconnected, discharged, or changed, the preset memory of the unit will be lost and require reprogramming.
•The unit is designed to be installed in a level,horizontal position. For optimal performance, avoid installing the unit at an angle.
•Never use excessive force when removing or attaching the faceplate. Do not tightly grip the display and buttons to avoid damage.
Lithium Battery Cell Warnings
•Cell leakage may cause damage to the remote control.
•Do not throw cells into as this may cause an explosion.
•Keep battery cells out of reach of children.
Drives and connections
Never place any foreign objects into the openings of the car radio (USB jack, card slot, AUX IN connection). Otherwise you might damage the slots and connections.
Others Warnings
Do not switch on the car radio for long periods of time when the motor is switched off. This could cause the car battery to discharge and the vehicle can no longer be started.
1
INSTALLATION
Installation Opening
This unit can be installed in any dashboard Having an
opening as shown the right figure.
103 mm
182 mm
If installation angle exceeds 30 horizontal, the unit may not perform properly.
To Install the Car Radio
1.Make sure the ignition is turned off, and then disconnect the cable from the vehicle battery’s negative (-) terminal. You never want electricity running while you install this double-DIN car receiver.
2.Attach the “L ” brackets (2pcs) on the both sides of the car receiver with screws(M5 x 8BM) as shown as the below figure. The others fixing screws that fix the other terminal of the “L” metal bracket, please buy from your dealer according to the drilling of holes size.
3.Consult with you nearest dealer if installation requires the drilling of holes or other modifications of the vehicle.
4.Install the car receiver in the dashboard.
5.Connect the wire harness & the antenna to the car receiver (see “Electrical Connections”) being careful not to pinch any wires or cables.
6.Install the detachable faceplate & plastic outer trim ring onto the car receiver.
7.Reconnect the battery and run through all of the options on this car receiver to ensure that everything is working correctly.
8.Particulars will vary widely depending upon the kind of your car and the car you intend to install it in. Please choose the correct installation method according to the actual situation of your car. Always contact the car dealer or manufacturer if you have any questions.
2
Electrical Connections
WIRING DIAGRAM
1. Radio antenna socket
2. Front left PRE-AMP output (White)
3. Front right PRE-AMP output (Red)
4. Rear right PRE-AMP output (Red)
5. Rear left PRE-AMP output (White)
6. ISO Socket: 8PIN connector
7. ISO Socket: 4PIN connector
|
RR+ |
RF+ |
LF+ |
LR+ |
CAUTION |
RR- |
RF- |
LF- |
LR- |
|
|
|
|
|
+12V DC |
|
|
+ |
+ |
NEGATIVE |
|
+ |
REM |
IGN |
GROUND |
|
|
- |
|
|
B |
|
GND |
|
|
|
|
-Only use speakers with 4 ohm impedance.
-The maximum current of the Amp Remote trigger is 200mA.
3
