Fridge-freezer
KIS..
[en] User manual
en |
|
|
Table of contents |
|
|
1 Safety............................................ |
4 |
|
1.1 |
General information.................... |
4 |
1.2 |
Intended use............................... |
4 |
1.3 |
Restriction on user group........... |
4 |
1.4 |
Safe transport............................. |
4 |
1.5 |
Safe installation .......................... |
5 |
1.6 |
Safe use ..................................... |
6 |
1.7 |
Damaged appliance................... |
8 |
2 Preventing material damage ....... |
9 |
|
3 Environmental protection and |
|
|
saving energy............................... |
9 |
|
3.1 |
Disposing of packaging ............. |
9 |
3.2 |
Saving energy............................. |
9 |
4 Installation and connection....... |
10 |
|
4.1 |
Scope of delivery...................... |
10 |
4.2 |
Criteria for the installation |
|
|
location ..................................... |
10 |
4.3 |
Installing the appliance ............ |
11 |
4.4 |
Preparing the appliance for |
|
|
the first time.............................. |
11 |
4.5 |
Connecting the appliance to |
|
|
the electricity supply................. |
11 |
5 Familiarising yourself with |
|
|
your appliance............................ |
12 |
|
5.1 |
Appliance ................................. |
12 |
5.2 |
Control panel............................ |
13 |
6 Features...................................... |
14 |
|
6.1 |
Shelf.......................................... |
14 |
6.2 |
Variable shelf............................ |
14 |
6.3 |
Extendable shelf ....................... |
14 |
6.4 |
Fruit and vegetable con- |
|
|
tainer with humidity control ...... |
14 |
6.5 |
Flat frozen food container ........ |
15 |
6.6 |
Butter and cheese compart- |
|
|
ment.......................................... |
15 |
6.7 |
Door racks................................ |
15 |
6.8 |
Accessories.............................. |
15 |
7 Basic operation .......................... |
16 |
||
7.1 |
Switching on the appliance ...... |
16 |
|
7.2 |
Operating tips........................... |
16 |
|
7.3 |
Switching off the appliance ...... |
16 |
|
7.4 |
Setting the temperature............ |
16 |
|
8 Additional functions .................. |
16 |
||
8.1 |
Super cooling .......................... |
16 |
|
8.2 |
Automatic Super freezing......... |
17 |
|
8.3 |
Manual Super freezing ............. |
17 |
|
8.4 |
Holiday mode ........................... |
17 |
|
9 Alarm........................................... |
18 |
||
9.1 |
Door alarm ............................... |
18 |
|
9.2 |
Temperature alarm................... |
18 |
|
10 Refrigerator compartment ....... |
18 |
||
10.1 |
Tips for storing food in the |
|
|
|
|
refrigerator compartment ....... |
18 |
10.2 |
Chill zones in the refriger- |
|
|
|
|
ator compartment................... |
19 |
10.3 |
"OK" sticker ............................ |
19 |
|
11 Freezer compartment............... |
19 |
||
11.1 |
Freezing capacity ................... |
19 |
|
11.2 |
Fully utilising the freezer |
|
|
|
|
compartment volume ............. |
20 |
11.3 |
Tips for storing food in the |
|
|
|
|
freezer compartment .............. |
20 |
11.4 |
Freezing smaller amounts |
|
|
|
|
of food quickly........................ |
20 |
11.5 |
Tips for freezing fresh food .... |
20 |
|
11.6 |
Shelf life of frozen food at |
|
|
|
|
−18 °C.................................... |
20 |
11.7 |
Defrosting methods for |
|
|
|
|
frozen food ............................. |
21 |
12 Defrosting................................. |
21 |
||
12.1 |
Defrosting in the refriger- |
|
|
|
|
ator compartment................... |
21 |
12.2 |
Defrosting in the freezer |
|
|
|
|
compartment .......................... |
21 |
2
en
13 |
Cleaning and servicing............ |
22 |
|
13.1 |
Preparing the appliance for |
|
|
|
|
cleaning .................................. |
22 |
13.2 |
Cleaning the appliance .......... |
22 |
|
13.3 |
Cleaning the condensation |
|
|
|
|
channel and drainage hole .... |
23 |
13.4 |
Removing the fittings.............. |
23 |
|
14 |
Troubleshooting....................... |
25 |
|
15 |
Storage and disposal............... |
28 |
|
15.1 |
Switching off the appliance .... |
28 |
|
15.2 |
Disposing of old appliance .... |
28 |
|
16 |
Customer Service..................... |
29 |
|
16.1 |
Product number (E-Nr.) and |
|
|
|
|
production number (FD)......... |
29 |
17 |
Technical data .......................... |
29 |
|
3
en Safety
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the product information safe for future reference or for the next owner.
¡Do not connect the appliance if it has been damaged in transit.
1.2 Intended use
This appliance is only intended to be fully fitted in a kitchen. Only use this appliance:
¡for chilling and freezing food, and for dispensing ice.
¡In private households and in enclosed spaces in a domestic environment.
¡Up to an altitude of max. 2000 m above sea level.
1.3 Restriction on user group
This appliance may be used by children aged 8 or over and by people who have reduced physical, sensory or mental abilities or inadequate experience and/or knowledge, provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers.
Children must not play with the appliance.
Cleaning and user maintenance must not be performed by children unless they are being supervised.
Children above the age of three years old and younger than eight years old may load and unload the the fridge-freezer.
1.4 Safe transport
WARNING ‒ Risk of injury!
The high weight of the appliance may result in injury when lifted.Do not lift the appliance on your own.
4
Safety en
1.5 Safe installation
WARNING ‒ Risk of electric shock!
Improper installation is dangerous.
Connect and operate the appliance only in accordance with the specifications on the rating plate.
Connect the appliance to a power supply with alternating current only via a properly installed socket with earthing.
The protective conductor system of the domestic electrical installation must be properly installed.
Never equip the appliance with an external switching device, e.g. a timer or remote control.
When the appliance is installed, the mains plug of the power cord must be freely accessible. If free access is not possible, an all-pole isolating switch must be installed in the permanent electrical installation according to the installation regulations.
When installing the appliance, check that the power cable is not trapped or damaged.
If the insulation of the power cord is damaged, this is dangerous.Never let the power cord come into contact with heat sources.
WARNING ‒ Risk of explosion!
If the appliance's ventilation openings are sealed, a leak in the refrigeration circuit may result in a flammable mixture of gas and air.
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
WARNING ‒ Risk of fire!
It is dangerous to use an extended power cord and non-approved adapters.
Do not use extension cables or multiple socket strips.
If the power cord is too short, contact Customer Service.
Only use adapters approved by the manufacturer.
Portable multiple socket strips or portable power supply units may overheat and cause a fire.
Do not place portable multiple socket strips or power supply units on the back of the appliance.
5
en Safety
1.6 Safe use
WARNING ‒ Risk of electric shock!
An ingress of moisture can cause an electric shock.
Only use the appliance in enclosed spaces.
Never expose the appliance to intense heat or humidity.
Do not use steamor high-pressure cleaners to clean the appliance.
WARNING ‒ Risk of suffocation!
Children may put packaging material over their heads or wrap themselves up in it and suffocate.
Keep packaging material away from children.
Do not let children play with packaging material.
Children may breathe in or swallow small parts, causing them to suffocate.
Keep small parts away from children.
Do not let children play with small parts.
WARNING ‒ Risk of explosion!
Mechanical devices or other devices may damage the refrigeration circuit; flammable refrigerant may escape and explode.
To accelerate the defrosting process, do not use any other mechanical devices or devices other than those recommended by the manufacturer.
Products which contain flammable propellants and explosive substances may explode, e.g. spray cans.
Do not store products which contain flammable propellants (e.g. spray cans) or explosive substances in the appliance.
WARNING ‒ Risk of fire!
Electrical devices within the appliance may cause a fire, e.g. heaters or electric ice makers.
Do not operate electrical devices within the appliance.
6
Safety en
WARNING ‒ Risk of injury!
Containers that contain carbonated drinks may burst.
Do not store containers that contain carbonated drinks in the freezer compartment.
Injury to the eyes caused by escaping flammable refrigerant and hazardous gases.
Do not damage the tubes of the refrigerant circuit or the insulation.
WARNING ‒ Risk of cold burns!
Contact with frozen food and cold surfaces may cause burns by refrigeration.
Never put frozen food straight from the freezer compartment into your mouth.
Avoid prolonged contact of the skin with frozen food, ice and surfaces in the freezer compartment.
CAUTION ‒ Risk of harm to health!
To prevent food from being contaminated, you must observe the following instructions.
If the door is open for an extended period of time, this may lead to a considerable temperature increase in the compartments of the appliance.
Regularly clean the surfaces that may come into contact with food and accessible drain systems.
Store raw meat and fish in suitable containers in the refrigerator so that they do not touch or drip on other food.
If the fridge/freezer is empty for an extended period of time, switch off the appliance, defrost it, clean it and leave the door open to prevent the formation of mould.
Metal or metal-style parts in the appliance may contain aluminium. If acidic food comes into contact with aluminium in the appliance, aluminium foil ions may pass into the food.
Do not consume soiled food.
7
en Safety
1.7 Damaged appliance
WARNING ‒ Risk of electric shock!
If the appliance or the power cord is damaged, this is dangerous.
Never operate a damaged appliance.
Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains.
If the appliance or the power cord is damaged, immediately unplug the power cord or switch off the fuse in the fuse box.
Call customer services. → Page 29
Incorrect repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord of this appliance is damaged, it must be replaced by the manufacturer, the manufacturer's Customer Service or a similarly qualified person in order to prevent any risk.
WARNING ‒ Risk of fire!
If the tubes are damaged, flammable refrigerant and harmful gases may escape and ignite.
Keep naked flames and ignition sources away from the appliance.
Ventilate the room.
Switch off the appliance. → Page 16
Unplug the appliance from the mains or switch off the circuit breaker in the fuse box.
Call after-sales service. → Page 29
8
2 Preventing material damage
ATTENTION!
Using the base, runners or appliance doors as a seat surface or climbing surface may damage the appliance.
Do not stand or support yourself on the base, runners or doors.
Contamination with oil or fat may cause plastic parts and door seals to become porous.
Keep plastic parts and door seals free of oil and grease.
Metal or metal-style parts in the appliance may contain aluminium. Aluminium reacts when it comes into contact with acidic foods.
Do not store unpackaged food in the appliance.
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compatible and can be recycled.
Sort the individual components by type and dispose of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use less power.
Selecting the installation location
¡Keep the appliance out of direct sunlight.
¡Install the appliance as far away as possible from heating elements, cookers and other heat sources:
Preventing material damage en
–Maintain a 30 mm clearance to electric or gas cookers.
–Maintain a 300 mm clearance to oil or solid-fuel cookers.
¡Use a niche depth of 560 mm.
¡Never cover or block the exterior ventilation grilles.
Saving energy during use
Note: The arrangement of the fittings does not affect the energy consumption of the appliance.
¡Open the appliance only briefly.
¡Never cover or block the interior ventilation openings or the exterior ventilation grilles.
¡Transport purchased food in a cool bag and place in the appliance quickly.
¡Allow warm food and drinks to cool down before storing them.
¡Thaw frozen food in the refrigerator compartment to utilise the low temperature of the food.
¡Always leave some space between the food and to the back panel.
¡Pack the food airtight.
¡Defrost the freezer compartment regularly.
¡Open the freezer compartment door only briefly and then close it properly.
9
en Installation and connection
4 Installation and connection
You can find out where and how best to install your appliance here. You will also learn how to connect your appliance to the power supply.
4.1 Scope of delivery
After unpacking all parts, check for any transport damage and for completeness of delivery.
If you have any complaints, contact your dealer or our after-sales service → Page 29.
The delivery consists of the following:
¡Built-in appliance
¡Equipment and accessories1
¡Installation material
¡Installation instructions
¡User manual
¡Customer service directory
¡Warranty enclosure2
¡Energy label
¡Information on energy consumption and noises
4.2 Criteria for the installation location
WARNING Risk of explosion!
If the appliance is in a space that is too small, a leak in the refrigeration circuit may result in a flammable mixture of gas and air.
Only install the appliance in a
space with a volume of at least 1 m3 per 8 g refrigerant. The
volume of refrigerant is indicated on the rating plate. → "Appliance",
Fig. 1 /
5
, Page 13
The weight of the appliance ex works may be up to 75 kg depending on the model.
The subfloor must be sufficiently stable to bear the weight of the appliance.
Permitted room temperature
The permitted room temperature depends on the appliance's climate class.
The climate class can be found on the rating plate. → "Appliance", Fig.
1 /
5
, Page 13
Climate |
Permitted room tem- |
class |
perature |
SN |
10 °C to 32 °C |
N |
16 °C to 32 °C |
ST |
16 °C to 38 °C |
T |
16 °C to 43 °C |
The appliance is fully functional within the permitted room temperature.
If an appliance with climate class SN is operated at colder room temperatures, the appliance will not be damaged up to a room temperature of
5 °C.
Niche dimensions
Observe the niche dimensions if you install your appliance in the niche. If this is not the case, problems may occur when installing the appliance.
Niche depth
Install the appliance in the recommended niche depth of 560 mm.
1Depending on the appliance specifications
2Not in all countries
10
Loading...
