Robert Bosch Power Tools GmbH
70538 Stuttgart
GERMANY
www.bosch-pt.com
1 609 92A 4PH (2018.12) O / 102
1 609 92A 4PH
GWS Professional
710 | 750-100 | 750-100 S | 750-100 I | 750-115 | 750-115 S | 750-125 | 750-125 S
en Original instructions zh zh ko
th
id Petunjuk-Petunjuk untuk Penggun-
aan Orisinal
vi Bản gốc hướng dẫn sử dụng
fr Notice originale
ar يلصلأا ليغشتلا ليلد fa یلصا یامنهار هچرتفد
2 |
English ................................................... |
Page |
6 |
....................................................... |
16 |
|
.................................................. |
23 |
|
............................................... |
31 |
|
...................................................... |
39 |
|
Bahasa Indonesia..................................... |
Halaman |
49 |
Tiếng Việt ............................................... |
Trang |
59 |
Français .................................................. |
Page |
68 |
يبرع.................................................. |
ةحفصلا |
79 |
یسرافآ.................................................. |
هحفص |
89 |
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
| 3
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
4 | |
|
|
(2) |
(1) |
(5) |
|
(3) |
|
(6) |
|
(4) |
(8) |
(15) |
(9) |
(9) |
|
|
(10) |
(10) |
|
(14)(16) |
(11) |
|
(12) |
(12) |
(13) |
(13) |
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
| 5
(22)
(4)
(7)
(17) (17)
(18) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
(21) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
(19) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
(20)
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
6 | English
English
WARNING Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mainsoperated (corded) power tool or battery-operated (cordless) power tool.
uKeep work area clean and well lit. Cluttered or dark areas invite accidents.
uDo not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
uKeep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
uPower tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
uAvoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
uDo not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric shock.
uDo not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
uWhen operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock..
uIf operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
uStay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
uUse personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
uPrevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
uRemove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
uDo not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
uDress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
uIf devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
uDo not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
uDo not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
uDisconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
uStore idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
uMaintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
uKeep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
uUse the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be per-
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
formed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
uHave your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
uThis power tool is intended to function as a grinder, sander, wire brush or cut-off tool. Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
uOperations such as polishing are not recommended to be performed with this power tool. Operations for which the power tool was not designed may create a hazard and cause personal injury.
uDo not use accessories which are not specifically designed and recommended by the tool manufacturer.
Just because the accessory can be attached to your power tool, it does not assure safe operation.
uThe rated speed of the accessory must be at least equal to the maximum speed marked on the power tool. Accessories running faster than their rated speed can break and fly apart.
uThe outside diameter and the thickness of your accessory must be within the capacity rating of your power tool. Incorrectly sized accessories cannot be adequately guarded or controlled.
uThreaded mounting of accessories must match the grinder spindle thread. For accessories mounted by flanges, the arbour hole of the accessory must fit the locating diameter of the flange. Accessories that do not match the mounting hardware of the power tool will run out of balance, vibrate excessively and may cause loss of control.
uDo not use a damaged accessory. Before each use inspect the accessory such as abrasive wheels for chips and cracks, backing pad for cracks, tear or excess wear, wire brush for loose or cracked wires. If power tool or accessory is dropped, inspect for damage or install an undamaged accessory. After inspecting and installing an accessory, position yourself and bystanders away from the plane of the rotating accessory and run the power tool at maximum no load speed for one minute. Damaged accessories will normally break apart during this test time.
uWear personal protective equipment. Depending on application, use face shield, safety goggles or safety glasses. As appropriate, wear dust mask, hearing protectors, gloves and workshop apron capable of stopping small abrasive or workpiece fragments. The eye protection must be capable of stopping flying debris gen-
English | 7
erated by various operations . The dust mask or respirator must be capable of filtrating particles generated by your operation. Prolonged exposure to high intensity noise may cause hearing loss.
uKeep bystanders a safe distance away from work area. Anyone entering the work area must wear personal protective equipment. Fragments of workpiece or of a broken accessory may fly away and cause injury beyond immediate area of operation.
uHold the power tool by insulated gripping surfaces only, when performing an operation where the cutting accessory may contact hidden wiring or its own cord.
Cutting accessory contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock.
uPosition the cord clear of the spinning accessory. If you lose control, the cord may be cut or snagged and your hand or arm may be pulled into the spinning accessory.
uNever lay the power tool down until the accessory has come to a complete stop. The spinning accessory may grab the surface and pull the power tool out of your control.
uDo not run the power tool while carrying it at your side. Accidental contact with the spinning accessory could snag your clothing, pulling the accessory into your body.
uRegularly clean the power tool’s air vents. The motor’s fan will draw the dust inside the housing and excessive accumulation of powdered metal may cause electrical hazards.
uDo not operate the power tool near flammable materials. Sparks could ignite these materials.
uDo not use accessories that require liquid coolants.
Using water or other liquid coolants may result in electrocution or shock.
Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or any other accessory. Pinching or snagging causes rapid stalling of the rotating accessory which in turn causes the uncontrolled power tool to be forced in the direction opposite of the accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge of the wheel that is entering into the pinch point can dig into the surface of the material causing the wheel to climb out or kick out. The wheel may either jump toward or away from the operator, depending on direction of the wheel’s movement at the point of pinching. Abrasive wheels may also break under these conditions.
Kickback is the result of power tool misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below.
uMaintain a firm grip on the power tool and position your body and arm to allow you to resist kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or torque reaction
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
8 | English
during start-up. The operator can control torque reac-
tions or kickback forces, if proper precautions are taken.
uNever place your hand near the rotating accessory.
Accessory may kickback over your hand.
uDo not position your body in the area where power tool will move if kickback occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at the point of snagging.
uUse special care when working corners, sharp edges etc. Avoid bouncing and snagging the accessory.
Corners, sharp edges or bouncing have a tendency to snag the rotating accessory and cause loss of control or kickback.
uDo not attach a saw chain woodcarving blade or toothed saw blade. Such blades create frequent kickback and loss of control.
uUse only wheel types that are recommended for your power tool and the specific guard designed for the selected wheel. Wheels for which the power tool was not designed cannot be adequately guarded and are unsafe.
uThe grinding surface of centre depressed wheels must be mounted below the plane of the guard lip. An improperly mounted wheel that projects through the plane of the guard lip cannot be adequately protected.
uThe guard must be securely attached to the power tool and positioned for maximum safety, so the least amount of wheel is exposed towards the operator.
The guard helps to protect operator from broken wheel fragments, accidental contact with wheel and sparks that could ignite clothing.
uWheels must be used only for recommended applications. For example: do not grind with the side of cutoff wheel. Abrasive cut-off wheels are intended for peripheral grinding, side forces applied to these wheels may cause them to shatter.
uAlways use undamaged wheel flanges that are of correct size and shape for your selected wheel. Proper wheel flanges support the wheel thus reducing the possibility of wheel breakage. Flanges for cut-off wheels may be different from grinding wheel flanges.
uDo not use worn down wheels from larger power tools. Wheel intended for larger power tool is not suitable for the higher speed of a smaller tool and may burst.
uDo not “jam” the cut-off wheel or apply excessive pressure. Do not attempt to make an excessive depth of cut. Overstressing the wheel increases the loading and susceptibility to twisting or binding of the wheel in the cut and the possibility of kickback or wheel breakage.
uDo not position your body in line with and behind the rotating wheel. When the wheel, at the point of operation, is moving away from your body, the possible kick-
back may propel the spinning wheel and the power tool
directly at you.
uWhen wheel is binding or when interrupting a cut for any reason, switch off the power tool and hold the power tool motionless until the wheel comes to a complete stop. Never attempt to remove the cut-off wheel from the cut while the wheel is in motion otherwise kickback may occur. Investigate and take corrective action to eliminate the cause of wheel binding.
uDo not restart the cutting operation in the workpiece. Let the wheel reach full speed and carefully re-enter the cut. The wheel may bind, walk up or kickback if the power tool is restarted in the workpiece.
uSupport panels or any oversized workpiece to minimize the risk of wheel pinching and kickback. Large workpieces tend to sag under their own weight. Supports must be placed under the workpiece near the line of cut and near the edge of the workpiece on both sides of the wheel.
uUse extra caution when making a “pocket cut” into existing walls or other blind areas. The protruding wheel may cut gas or water pipes, electrical wiring or objects that can cause kickback.
uDo not use excessively oversized sanding disc paper. Follow manufacturers recommendations, when selecting sanding paper. Larger sanding paper extending beyond the sanding pad presents a laceration hazard and may cause snagging, tearing of the disc, or kickback.
uBe aware that wire bristles are thrown by the brush even during ordinary operation. Do not overstress the wires by applying excessive load to the brush The wire bristles can easily penetrate light clothing and/or skin.
uIf the use of a guard is recommended for wire brushing, do not allow any interference of the wire wheel or brush with the guard. Wire wheel or brush may expand in diameter due to work load and centrifugal forces.
Wear safety goggles.
uUse suitable detectors to determine if utility lines are hidden in the work area or call the local utility company for assistance. Contact with electric lines can lead to fire and electric shock. Damaging a gas line can lead to explosion. Penetrating a water line causes property damage or may cause an electric shock.
uDo not touch grinding and cutting discs until they have cooled down. The discs can become very hot while working.
uRelease the On/Off switch and set it to the off position when the power supply is interrupted, e. g., in case of
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
a power failure or when the mains plug is pulled. This
prevents uncontrolled restarting.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place by an authorised customer service agent. The replacement plug should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible shock hazard and should never be inserted into a mains socket elsewhere.
uSecure the workpiece. A workpiece clamped with clamping devices or in a vice is held more secure than by hand.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general instructions may result in electric shock, fire and/or serious injury.
Please observe the illustrations at the beginning of this operating manual.
The power tool is intended for cutting, roughing and brushing metal and stone materials without the use of water.
A special protective guard for cutting must be used when cutting bonded abrasives.
Sufficient dust extraction must be provided when cutting stone.
With approved abrasive tools, the power tool can be used for sanding with sanding discs.
English | 9
The numbering of the product features refers to the diagram of the power tool on the graphics page.
(1) |
Spindle lock button |
|
(2) |
On/off switch |
|
(3) |
Speed preselection thumbwheel (GWS 750-100 |
|
|
S/GWS 750-115 S/GWS 750-125 S) |
|
(4) |
Auxiliary handle (insulated gripping surface) |
|
(5) |
Combination wrench for grinding spindle M14A) |
|
(6) |
Combination wrench for grinding spindle M10A) |
|
(7) |
Grinding spindle |
|
(8) |
Protective guard for grinding |
|
(9) |
Locking screw for protective guard |
|
(10) |
Mounting flange with O ring |
|
(11) |
Grinding discA) |
|
(12) |
Clamping nut |
|
(13) |
Quick-clamping nut |
A) |
|
||
(14) |
Carbide grinding headA) |
|
(15) |
Protective guard for cuttingA) |
|
(16) |
Cutting discA) |
|
(17) |
Hand guardA) |
|
(18) |
Rubber sanding padA) |
|
(19) |
Abrasive discA) |
|
(20) |
Round nutA) |
|
(21) |
Cup brushA) |
|
(22) |
Handle (insulated gripping surface) |
A)Accessories shown or described are not included with the product as standard. You can find the complete selection of accessories in our accessories range.
Angle grinder |
|
GWS 710 |
GWS 750-100 |
GWS 750-115 |
GWS 750-125 |
Article number |
|
3 601 C94 0.. |
3 601 C94 0.. |
3 601 C94 0.. |
3 601 C94 0.. |
Rated power input |
W |
750 |
750 |
750 |
750 |
Power output |
W |
380 |
380 |
380 |
380 |
Rated speed |
rpm |
11,000 |
11,000 |
11,000 |
11,000 |
Speed adjustment range |
rpm |
– |
– |
– |
– |
Max. grinding disc diameter |
mm |
125 |
100 |
115 |
125 |
Grinding spindle thread |
|
M14 |
M10 |
M14 |
M14 |
Max. thread length of grinding |
mm |
22 |
22 |
22 |
22 |
spindle |
|
|
|
|
|
Speed preselection |
|
– |
– |
– |
– |
Kickback stop |
|
– |
– |
– |
– |
Restart protection |
|
– |
– |
– |
– |
Starting current limitation |
|
– |
– |
– |
– |
Weight according to EPTA-Procedure 01:2014
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
10 | English
Angle grinder |
|
GWS 710 |
GWS 750-100 |
GWS 750-115 |
GWS 750-125 |
|
– |
with additional low-vibra- |
kg |
1.9 |
1.9 |
1.9 |
1.9 |
|
tion auxiliary handle |
|
|
|
|
|
– |
with standard auxiliary |
kg |
1.8 |
1.8 |
1.8 |
1.8 |
|
handle |
|
|
|
|
|
Protection class |
|
/ II |
/ II |
/ II |
/ II |
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.
Angle grinder |
|
GWS 750-100 S |
GWS 750-115 S |
GWS 750-125 S |
GWS 750-100 I |
|
Article number |
|
3 601 C94 1.. |
3 601 C94 1.. |
3 601 C94 1.. |
3 601 C94 2.. |
|
Rated power input |
W |
750 |
750 |
750 |
750 |
|
Power output |
W |
380 |
380 |
380 |
410 |
|
Rated speed |
rpm |
11,000 |
11,000 |
11,000 |
11,000 |
|
Speed adjustment range |
rpm |
2800–11,000 |
2800–11,000 |
2800–11,000 |
– |
|
Max. grinding disc diameter |
mm |
100 |
115 |
125 |
100 |
|
Grinding spindle thread |
|
M10 |
M14 |
M14 |
M10 |
|
Max. thread length of grinding |
mm |
22 |
22 |
22 |
22 |
|
spindle |
|
|
|
|
|
|
Speed preselection |
|
● |
● |
● |
– |
|
Kickback stop |
|
– |
– |
– |
● |
|
Restart protection |
|
● |
● |
● |
● |
|
Starting current limitation |
|
● |
● |
● |
● |
|
Weight according to EPTA-Procedure 01:2014 |
|
|
|
|||
– |
with additional low-vibra- |
kg |
1.9 |
1.9 |
1.9 |
1.9 |
|
tion auxiliary handle |
|
|
|
|
|
– |
with standard auxiliary |
kg |
1.8 |
1.8 |
1.8 |
1.8 |
|
handle |
|
|
|
|
|
Protection class |
|
/ II |
/ II |
/ II |
/ II |
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.
uPull the plug out of the socket before carrying out any work on the power tool.
Note: If the grinding disc breaks during operation or the holding fixtures on the protective guard/power tool become damaged, the power tool must be sent to the after-sales service immediately; see the "After-sales service and advice on using products" section for addresses.
Place the protective guard (8) on the spindle collar. Adjust the position of the protective guard (8) to meet the requirements of the operation. Lock the protective guard (8) by tightening the locking screw (9) using the combination wrench (5)/(6).
uAdjust the protective guard (8) such that sparking in the direction of the operator is prevented.
Note: The coding cams on the protective guard (8) ensure that only a protective guard that is suitable for the power tool can be fitted.
uAlways use the protective guard for cutting (15) when cutting bonded abrasives.
uProvide sufficient dust extraction when cutting stone.
The protective guard for cutting (15) is fitted in the same
way as the protective guard for grinding (8).
uDo not operate your power tool without the side handle (4).
Screw the side handle (4) on the left or right of the machine head depending on how your are working.
uAlways fit the hand guard (17) when working with the rubber sanding pad (18) or with the cup brush/disc brush/flap disc.
Attach the hand guard (17) to the side handle (4).
uPull the plug out of the socket before carrying out any work on the power tool.
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
uDo not touch grinding and cutting discs until they have cooled down. The discs can become very hot while working.
Clean the grinding spindle (7) and all the parts to be fitted. Lock the grinding spindle with the spindle lock button (1) before clamping and releasing the abrasive tools.
uDo not press the spindle lock button while the grinding spindle is moving. The power tool may become damaged if you do this.
Pay attention to the dimensions of the abrasive tools. The diameter of the hole must match that of the mounting flange. Do not use an adapter or reducer.
When using diamond cutting discs, ensure that the arrow indicating the direction of rotation on the diamond cutting disc matches the direction of rotation of the power tool (see the direction of rotation arrow on the machine head).
See the graphics page for fitting instructions.
To fasten the grinding/cutting disc, screw on the clamping nut (12) and tighten it with the combination wrench(5)/(6); see the "Quick-clamping nut" section.
uAfter fitting the abrasive tool, check that the abrasive tool is fitted correctly and can turn freely before switching on the power tool. Make sure that the abrasive tool does not brush against the protective guard or other parts.
Mounting flange for grinding spindle M 14:
A plastic part (O-ring) is fitted around the centring collar in the mounting flange (10). If the O-ring is missing or damaged, the mounting flange (10) must be replaced before operation
can resume.
Mounting flange for grinding spindle M 10: The mounting
flange can be used on either side.
uAlways fit the hand guard (17) when working with the flap disc.
uAlways fit the hand guard (17) when working with the rubber sanding pad (18).
See the graphics page for fitting instructions.
Screw on the round nut (20) and tighten it with the combina-
tion wrench (5)/(6).
uAlways fit the hand guard (17) when working with the cup brush or disc brush.
See the graphics page for fitting instructions.
The cup brush/disc brush must be screwed onto the grinding spindle until it rests firmly against the grinding spindle flange at the end of the grinding spindle thread. Tighten the cup brush/disc brush with an open-ended spanner.
English | 11
To change the abrasive tool easily without having to use any additional tools, you can use the quick-clamping nut (13) instead of the clamping nut (12).
uThe quick-clamping nut (13) may be used only for grinding or cutting discs.
Only use quick-clamping nuts (13) that are in good work-
ing order and not damaged.
When screwing on, make sure that the printed side of the quick-clamping nut (13) is not facing the grinding disc; the arrow must be pointing towards the index mark (23).
(23) |
head |
Press the spindle lock button (1) to lock the grinding spindle. To tighten the quick-clamping nut, turn the grinding disc firmly clockwise.
If the quick-clamping nut has been attached correctly and is not damaged, you can loosen it by hand by turning the knurled ring anticlockwise. Never loosen a
tight quick-clamping nut
with pliers. Always use
the combination wrench.
Insert the combination
wrench as shown in the fig-
ure.
Rotating the machine
uPull the plug out of the socket before carrying out any work on the power tool.
The machine head can be rotated in 90° increments. In this way, the on/off
switch can be brought into
a more favourable handling
position for particular ap-
plications, e.g. for left-
handed tool users.
Completely unscrew the four screws. Rotate the machine head carefully,
without removing it from the housing, into the new position. Screw in and retighten the four screws.
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
12 | English
You can use all the abrasive tools mentioned in these operating instructions.
The permissible speed [rpm] or the circumferential speed [m/s] of the abrasive tools used must at least match the values given in the table.
It is therefore important to observe the permissible rotational/circumferential speed on the label of the abrasive
tool.
|
|
max. [mm] |
[mm] |
|
|
|
|
|
D |
b |
d |
[rpm] |
[m/s] |
|
|
100 |
7 |
16.0 |
11,000 |
80 |
|
|
115 |
7 |
22.2 |
11,000 |
80 |
|
|
125 |
7 |
22.2 |
11,000 |
80 |
D |
|
100 |
– |
– |
11,000 |
80 |
|
|
|||||
|
|
115 |
– |
– |
11,000 |
80 |
|
|
125 |
– |
– |
11,000 |
80 |
|
D |
70 |
30 |
M 10 |
11,000 |
45 |
|
|
|||||
B |
|
75 |
30 |
M 14 |
11,000 |
45 |
|
|
D
The dust from materials such as lead paint, some types of wood, minerals and metal can be harmful to human health. Touching or breathing in this dust can trigger allergic reactions and/or cause respiratory illnesses in the user or in people in the near vicinity.
Certain dusts, such as oak or beech dust, are classified as carcinogenic, especially in conjunction with wood treatment additives (chromate, wood preservative). Materials containing asbestos may only be machined by specialists.
–Use a dust extraction system that is suitable for the material wherever possible.
–Provide good ventilation at the workplace.
–It is advisable to wear a P2 filter class breathing mask. The regulations on the material being machined that apply in the country of use must be observed.
uAvoid dust accumulation at the workplace. Dust can easily ignite.
uPay attention to the mains voltage. The voltage of the power source must match the voltage specified on the rating plate of the power tool. Power tools marked with 230 V can also be operated with 220 V.
uHold the tool by the insulated gripping surfaces and auxiliary handle only. The application tool could come
into contact with hidden wiring or its own cord. Contact with live wires may make metal parts of the tool live, posing a risk of electric shock.
When operating the power tool using a mobile generator that does not have sufficient reserve capacity or an adequate voltage control system with inrush current boost converter, loss of performance or atypical behaviour may occur upon switch-on.
Please check the suitability of the power generator you are using, particularly with regard to the mains voltage and frequency.
uProducts that are only sold in AUS and NZ: Use a residual current device (RCD) with a nominal residual current of 30 mA or less.
To start the power tool, push the on/off switch (2) forward. To lock the on/off switch (2) in position, push the on/off switch (2) forward and down until it clicks into place.
To switch off the power tool, release the on/off switch (2); or, if the switch is locked, briefly push the on/off switch (2) backward and down and then release it.
uAlways check abrasive tools before using them. The abrasive tool must be fitted properly and be able to move freely. Carry out a test run for at least one minute with no load. Do not use abrasive tools that are damaged, run untrue or vibrate during use. Damaged abrasive tools can burst apart and cause injuries.
If there is a sudden drop in the speed of the power tool, e.g. jamming in a separating cut, the power supply to the motor will be interrup-
ted electronically.
To restart the tool, set the on/off switch (2) to the "off" position and then switch the power tool on again.
Restart protection (GWS 750-100 S/GWS 750-115 S/
GWS 750-125 S/GWS 750-100 I)
The restart protection prevents an uncontrolled start-up of the power tool after an interruption in the power supply.
To restart the tool, set the on/off switch (2) to the "off" position and then switch the power tool on again.
Starting current limitation (GWS 750-100 S/
GWS 750-115 S/GWS 750-125 S/GWS 750-100 I)
The electronic starting current limitation restricts the power consumption when the power tool is switched on and enables operation with a 16 A fuse.
Speed preselection (GWS 750-100 S/GWS 750-115 S/
GWS 750-125 S)
You can preselect the required speed using the speed preselection thumbwheel (3), even during operation. The information in the table below describes the recommended values.
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
English | 13
Material |
Application |
Application tool |
Thumbwheel position |
Metal |
Removing paint |
Abrasive disc |
2−3 |
Wood, metal |
Brushing, removing rust |
Cup brush, abrasive disc |
3 |
Metal, stone |
Grinding |
Grinding disc |
4−6 |
Metal |
Rough grinding |
Grinding disc |
6 |
Metal |
Cutting |
Cutting disc |
6 |
The values specified for speed levels are guide values.
uThe rated speed of the accessory must be at least equal to the maximum speed marked on the power tool. Accessories running faster than their rated speed can break and fly apart.
uPull the plug out of the socket before carrying out any work on the power tool.
uExercise caution when cutting slots in structural walls; see the "Information on structures" section.
uClamp the workpiece if it is not secure under its own weight.
uDo not load the power tool so heavily that it comes to a stop.
uIf the power tool has been subjected to a heavy load, continue to run it at no-load for several minutes to cool down the accessory.
uDo not use the power tool with a cut-off stand.
uDo not touch grinding and cutting discs until they have cooled down. The discs can become very hot while working.
Rough grinding
u Never use cutting discs for rough grinding.
The best rough grinding results are achieved with a set angle of 30° to 40°. Move the power tool back and forth with moderate pressure. This will ensure that the workpiece does not become too hot or discolour and that grooves are not formed.
With the flap disc (accessory), curved surfaces and profiles can be worked. Flap discs have a considerably higher service life, lower noise levels and lower sanding temperatures than conventional sanding sheets.
uAlways use the protective guard for cutting (15) when cutting bonded abrasives.
When carrying out abrasive cutting, use a moderate feed that is suited to the material being machined. Do not exert pressure on the cutting disc and do not tilt or swing the power tool.
Do not attempt to reduce the speed of a cutting disc coming to a stop by applying pressure from the side.
The power tool must always |
work in an up-grinding mo- |
tion. Otherwise, there is a |
risk that it will be pushed |
uncontrolled out of the cut. |
For best results when cut- |
ting profiles and rectangular |
tubing, start at the smallest |
cross section. |
Cutting stone |
u Provide sufficient dust extraction when cutting stone. |
u Wear a dust mask. |
uThe power tool may be used only for dry cutting/grinding.
For best results when cutting stone, use a diamond cutting disc.
When cutting especially hard materials such as concrete with a high pebble content, the diamond cutting disc can overheat and become damaged as a result. This is clearly indicated by circular sparking, rotating with the diamond cutting disc.
If this happens, stop cutting and allow the diamond cutting disc to cool down by running the power tool for a short time at maximum speed with no load.
Working noticeably slower and with circular sparking indicate that the diamond cutting disc that has become dull. You can resharpen the disc by briefly cutting into abrasive material (e.g. lime-sand brick).
Slots in load-bearing walls are subject to DIN 1053 part 1 or country-specific regulations. These regulations must be observed under all circumstances. Seek advice from the responsible structural engineer, architect or construction supervisor before starting work.
uPull the plug out of the socket before carrying out any work on the power tool.
uTo ensure safe and efficient operation, always keep the power tool and the ventilation slots clean.
uIn extreme conditions, always use a dust extractor if possible. Blow out ventilation slots frequently and install a residual current device (RCD) upstream. When
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
14 | English
machining metals, conductive dust can settle inside the power tool, which can affect its protective insulation.
Store and handle the accessories carefully.
In order to avoid safety hazards, if the power supply cord needs to be replaced, this must be done by Bosch or by a customer service centre that is authorised to repair Bosch power tools.
After-sales Service and Advice on Using
Products
Our after-sales service can answer questions concerning product maintenance and repair, as well as spare parts. You can find exploded drawings and information on spare parts at: www.bosch-pt.com
The Bosch product use advice team will be happy to help you with any questions about our products and their accessories.
www.powertool-portal.de, the internet portal for tradespeople and DIY enthusiasts.
In all correspondence and spare parts orders, please always include the 10 digit article number given on the type plate of the product.
Cambodia
Robert Bosch (Cambodia) Co., Ltd
Unit 8BC, GT Tower, 08th Floor, Street 169,
Czechoslovakia Blvd, Sangkat Veal Vong
Khan 7 Makara, Phnom Penh
VAT TIN: 100 169 511
Tel.: +855 23 900 685
Tel.: +855 23 900 660
www.bosch.com.kh
People’s Republic of China
China Mainland
Bosch Power Tool (China) Co. Ltd.
Bosch Service Center
567, Bin Kang Road
Bin Kang District
Hangzhou, Zhejiang Province
China 310052
Tel.: (0571) 8887 5566 / 5588
Fax: (0571) 8887 6688 x 5566# / 5588#
E-mail: bsc.hz@cn.bosch.com
www.bosch-pt.com.cn
HK and Macau Special Administrative Regions
Robert Bosch Co. Ltd.
21st Floor, 625 King’s Road
North Point, Hong Kong
Customer Service Hotline: +852 2101 0235
Fax: +852 2590 9762
E-mail: info@hk.bosch.com
www.bosch-pt.com.hk
India
Bosch Service Center
69, Habibullah Road, (next to PSBB School), T. Nagar Chennai–600077
Phone: (044) 64561816
Bosch Service Center Rishyamook
85A, Panchkuin Road
New Delhi–110001
Phone: (011) 43166190
Bosch Service Center 79,
Crystal Bldg., Dr. Annie Besant Road, Worli
Mumbai–400018
Phone: (022) 39569936 / (022 )39569959 / (022) 39569967 / (022) 24952071
Indonesia
PT Robert Bosch
Palma Tower 10th Floor
Jalan RA Kartini II-S Kaveling 6
Pondok Pinang, Kebayoran Lama
Jakarta Selatan 12310
Tel.: (21) 3005-5800
www.bosch-pt.co.id
Malaysia
Robert Bosch Sdn. Bhd.(220975-V) PT/SMY
No. 8A, Jalan 13/6
46200 Petaling Jaya
Selangor
Tel.: (03) 79663194
Toll-Free: 1800 880188
Fax: (03) 79583838
E-mail: kiathoe.chong@my.bosch.com
www.bosch-pt.com.my
Pakistan
Robert Bosch Middle East FZE – Pakistan Liaison Office 2nd Floor Plaza # 10, CCA Block, DHA Phase 5 Lahore, 54810
Phone: +92(303)4444311
E-mail: Faisal.Khan@bosch.com
Philippines
Robert Bosch, Inc.
28th Floor Fort Legend Towers, 3rd Avenue corner 31st Street, Fort Bonifacio, Global City, 1634 Taguig City
Tel.: (632) 8703871
Fax: (632) 8703870
www.bosch-pt.com.ph
Singapore
Powerwell Service Centre Ptd Ltd
Bosch Authorised Service Centre (Power Tools) 4012 Ang Mo Kio Ave 10, #01-02 TECHplace Singapore 569628
Tel.: 6452 1770
Fax: 6452 1760
E-mail: ask@powerwellsc.com
www.powerwellsc.com
www.bosch-pt.com.sg
Thailand
Robert Bosch Ltd.
Liberty Square Building
No. 287, 11 Floor
Silom Road, Bangrak
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
Bangkok 10500
Tel.: 02 6393111
Fax: 02 2384783
Robert Bosch Ltd., P. O. Box 2054
Bangkok 10501
www.bosch.co.th
Bosch Service – Training Centre
La Salle Tower Ground Floor Unit No.2 10/11 La Salle Moo 16
Srinakharin Road
Bangkaew, Bang Plee
Samutprakarn 10540
Tel.: 02 7587555
Fax: 02 7587525
Vietnam
Branch of Bosch Vietnam Co., Ltd in HCMC 14th floor, Deutsches Haus, 33 Le Duan Ben Nghe Ward, District 1, Ho Chi Minh City Tel.: (028) 6258 3690
Fax: (028) 6258 3692 - 6258 3694
Hotline: (028) 6250 8555
E-mail: tuvankhachhang-pt@vn.bosch.com www.bosch-pt.com.vn
Armenia, Azerbaijan, Georgia, Kyrgyzstan, Mongolia,
Tajikistan, Turkmenistan, Uzbekistan
TOO "Robert Bosch" Power Tools, After Sales Service Rayimbek Ave., 169/1
050050, Almaty, Kazakhstan
Service e-mail: service.pt.ka@bosch.com
Official website: www.bosch.com, www.bosch-pt.com
Bahrain
Hatem Al Juffali Technical Equipment Establishment. Kingdom of Bahrain, Setra Highway, Al Aker Area Phone: +966126971777-311
Fax: +97317704257
E-mail: h.berjas@eajb.com.sa
Egypt
Unimar
20 Markaz kadmat
El tagmoa EL Aoul – New Cairo
Phone: +20 2224 76091-95
Phone: +20 2224 78072-73
Fax: +20222478075
E-mail: adelzaki@unimaregypt.com
Iran
Robert Bosch Iran
3rd Floor, No 3, Maadiran Building Aftab St., Khodami St., Vanak Sq. Tehran 1994834571
Phone: +9821 86092057
Iraq
Sahba Technology Group
Al Muthana airport road
Baghdad
Phone: +9647901906953
Phone Dubai: +97143973851
E-mail: bosch@sahbatechnology.com
English | 15
Jordan
Roots Arabia – Jordan
Nasser Bin Jameel street, Building 37 Al Rabiah 11194 Amman
Phone: +962 6 5545778
E-mail: bosch@rootsjordan.com
Kuwait
Al Qurain Automotive Trading Company
Shuwaikh Industrial Area, Block 1, Plot 16, Street 3rd P.O. Box 164 – Safat 13002
Phone: 24810844
Fax: 24810879
E-mail: josephkr@aaalmutawa.com
Lebanon
Tehini Hana & Co. S.A.R.L.
P.O. Box 90-449
Jdeideh
Dora-Beirut
Phone: +9611255211
E-mail: service-pt@tehini-hana.com
Libya
El Naser for Workshop Tools
Swanee Road, Alfalah Area
Tripoli
Phone: +218 21 4811184
Oman
Malatan Trading & Contracting LLC
P.O. Box 131
Ruwi, 112 Sultanate of Oman
Phone: +968 99886794
E-mail: malatanpowertools@malatan.net
Qatar
International Construction Solutions W L L
P. O. Box 51,
Doha Phone: +974 40065458
Fax: +974 4453 8585
E-mail: csd@icsdoha.com
Saudi Arabia
Juffali Technical Equipment Co. (JTECO)
Kilo 14, Madinah Road, Al Bawadi District
Jeddah 21431
Phone: +966 2 6672222 Ext. 1528
Fax: +966 2 6676308
E-mail: roland@eajb.com.sa
Syria
Dallal Establishment for Power Tools
P.O. Box 1030
Aleppo
Phone: +963212116083
E-mail: rita.dallal@hotmail.com
United Arab Emirates
Central Motors & Equipment LLC, P.O. Box 1984 Al-Wahda Street – Old Sana Building
Sharjah
Phone: +971 6 593 2777
Fax: +971 6 533 2269
E-mail: powertools@centralmotors.ae
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
16 |
Yemen
Abualrejal Trading Corporation
Sana’a Zubiery St. Front to new Parliament Building Phone: +967-1-202010
Fax: +967-1-279029
E-mail: tech-tools@abualrejal.com
Ethiopia
Forever plc
Kebele 2,754, BP 4806,
Addis Ababa
Phone: +251 111 560 600
E-mail: foreverplc@ethionet.et
Ghana
C.WOERMANN LTD.
Nsawam Road/Avenor Junction, P.O. Box 1779 Accra Phone: +233 302 225 141
Kenya
Robert Bosch East Africa Ltd
Mpaka Road P.O. Box 856
00606 Nairobi
Nigeria
Robert Bosch Nigeria Ltd.
52–54 Isaac John Street P.O. Box
GRA Ikeja – Lagos
Republic of South Africa
Customer service
Hotline: (011) 6519600
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: (011) 4939375
Fax: (011) 4930126
E-mail: bsctools@icon.co.za
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: (031) 7012120
Fax: (031) 7012446
E-mail: bsc.dur@za.bosch.com
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: (021) 5512577
Fax: (021) 5513223
E-mail: bsc@zsd.co.za
Bosch Headquarters
Midrand, Gauteng
Tel.: (011) 6519600
Fax: (011) 6519880
E-mail: rbsa-hq.pts@za.bosch.com
Tanzania
Diesel & Autoelectric Service Ltd. 117 Nyerere Rd., P.O. Box 70839
Vingunguti 12109, Dar Es Salaam
Phone: +255 222 861 793/794
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch-pt.com.au
www.bosch-pt.co.nz
The power tool, accessories and packaging should be recycled in an environmentally friendly manner.
Do not dispose of power tools along with household waste.
!
" "
u 引
u 燃粉
u 集
u 击危
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
u 箱。
u 入
u 险。
uRCD
RCD
u 工具时
u 鞋、安全
u/
u 导致人
u 衡。
u 或长发
u 减少
u 效、
u/
u 用户手中
| 17
u 削
u 险。
u 导致危险。.
u 造成人身伤害。
u 操作安全。
u 可能会断裂并飞出。
u 制。
u 致失控。
u 在测试期间会裂开。
u 所产生的飞溅碎片。防尘面罩或呼吸器必须能过 滤操作所产生的颗粒。长时间处于高强度噪音中 可能导致失聪。
区域以外的损害。
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
18 |
险。
u 卷入旋转的附件。
u 控。
片的伤害、意外接触到砂轮以及会引燃衣物的火 花。
u 裂。
|
u |
u 燃这些材料。
u 液体冷却剂可能导致触电或电击。
滞点冲向与附件旋转相反的方向。
/
u 反转扭矩或回弹力。
u 在您的手上方发生回弹。
u 轮移动相反的方向。
u“ ”
u 工具直接推向您。
u 的因素。
u 在工件下方靠近切割线处以及砂轮两侧靠近工件 边缘处进行支撑。
u“ ”
u
u 危险。
u/
u 轮或钢丝刷在工作负荷和离心力作用下直径会变 大。
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
u 触电。
u 时砂轮会变得非常炙热。
u 的位置。
u 会比用手持握工件更牢固。
下警告和说明可能导致电击、着火和/
罩。
纸研磨。
| 19
(3)GWS 750-100 S/ GWS 750-115 S/GWS 750-125 S
(5)M14 A)
(6)M10 A)
(10)O
(11)A)
(13)A)
(14)A)
(15)A)
(16)A)
(17)A)
(18)A)
(19)A)
(20)A)
(21)A)
A) 中。本公司的附件清单中有完整的附件供应项目。
|
|
GWS 710 |
GWS 750-100 |
GWS 750-115 |
GWS 750-125 |
|
|
3 601 C94 0.. |
3 601 C94 0.. |
3 601 C94 0.. |
3 601 C94 0.. |
|
|
750 |
750 |
750 |
750 |
|
|
380 |
380 |
380 |
380 |
|
/ |
11000 |
11000 |
11000 |
11000 |
|
/ |
– |
– |
– |
– |
|
|
125 |
100 |
115 |
125 |
|
|
M14 |
M10 |
M14 |
M14 |
|
|
22 |
22 |
22 |
22 |
|
|
|
|
|
|
|
|
– |
– |
– |
– |
|
|
– |
– |
– |
– |
|
|
– |
– |
– |
– |
|
|
– |
– |
– |
– |
EPTA-Procedure |
01:2014 |
|
|
|
|
– |
|
1.9 |
1.9 |
1.9 |
1.9 |
– |
|
1.8 |
1.8 |
1.8 |
1.8 |
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
20 |
|
|
|
GWS 710 |
GWS 750-100 |
GWS 750-115 |
GWS 750-125 |
|
|
|
/ II |
/ II |
/ II |
/ II |
|
230 |
[U] |
|
|
||
|
|
|
|
|
|
|
|
|
|
GWS 750-100 S |
GWS 750-115 S |
GWS 750-125 S |
GWS 750-100 I |
|
|
|
3 601 C94 1.. |
3 601 C94 1.. |
3 601 C94 1.. |
3 601 C94 2.. |
|
|
|
750 |
750 |
750 |
750 |
|
|
|
380 |
380 |
380 |
410 |
|
|
/ |
11000 |
11000 |
11000 |
11000 |
|
|
/ |
2800–11000 |
2800–11000 |
2800–11000 |
– |
|
|
|
100 |
115 |
125 |
100 |
|
|
|
M10 |
M14 |
M14 |
M10 |
|
|
|
22 |
22 |
22 |
22 |
|
|
|
|
|
|
|
|
|
|
● |
● |
● |
– |
|
|
|
– |
– |
– |
● |
|
|
|
● |
● |
● |
● |
|
|
|
● |
● |
● |
● |
|
EPTA-Procedure |
01:2014 |
|
|
|
|
|
– |
|
1.9 |
1.9 |
1.9 |
1.9 |
|
– |
|
1.8 |
1.8 |
1.8 |
1.8 |
|
|
|
/ II |
/ II |
/ II |
/ II |
230 [U]
/“ ”
(8)(8) (5)/(6)
(9) (8)
u(8)
(8)
(15)
(15) (8)
u (4)
(4)
u(18) / /(17)
(4) (17)
u 时砂轮会变得非常炙热。
(7) (1)
/
拧入夹紧螺母(12) /(5)/(6) “”
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
M 14(10)
O O
(10)
M 10
u (17)
u(18)
(17)
拧上圆形螺母(20) (5)/(6)
/
u/
(17)
将杯形钢丝刷//
速夹紧螺母(13) (12)
u (13)
(13) (13)
(23)
(23) |
(1)
| 21
以用手逆时针方向松开 滚花圆环。
合扳手。
90
4 4
所用磨具的许可转速[ / ] [ / ]
[ ] [ ]
|
D |
b |
d |
[ / [ / ] |
|
|
|
|
|
] |
|
|
100 |
7 |
16.0 |
11000 |
80 |
|
115 |
7 |
22.2 |
11000 |
80 |
|
125 |
7 |
22.2 |
11000 |
80 |
D |
100 |
– |
– |
11000 |
80 |
|
115 |
– |
– |
11000 |
80 |
|
125 |
– |
– |
11000 |
80 |
D |
70 |
30 |
M10 |
11000 |
45 |
B |
75 |
30 |
M14 |
11000 |
45 |
D
/
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
22 |
工含石棉的物料。
–P2
u 燃。
u 上标示的电压一致。标记为230 220
常的反应。
要使用正确的电压和电频率。
/
(2)(2) (2)(2)(2)
GWS 750-100 I
(2)
GWS 750-100 S/GWS 750-115 S/ GWS 750-125 S/GWS 750-100 I
(2)
GWS 750-100 S/
GWS 750-115 S/GWS 750-125 S/ GWS 750-100 I
16
GWS 750-100 S/GWS 750-115 S/ GWS 750-125 S
|
|
(3) |
||
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
2−3 |
|
|
|
|
3 |
|
|
|
|
4−6 |
|
|
|
|
6 |
|
|
|
|
6 |
|
u 可能会断裂并飞出。
u“”
u 时砂轮会变得非常炙热。
u
30 40
(15)
晃。
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
切线中滑出。切割型材 和方管时最好使用最小 的截面。
u/
可能因为金刚石切割片过热而导致切割片损坏。金 刚石切割片的周围会出现明显的火花。
割片。
DIN1053
u 作效率和工作安全。
uPRCD
害机器的安全性能。
www.bosch-pt.com
| 23
www.powertool-portal.de DIY10
香港北角英皇道625
21 +852 2101 0235+852 2590 9762
info@hk.bosch.com www.bosch-pt.com.hk
滨江区滨康路567 102/1F 3100520571 8887 5566 / 5588
0571 8887 6688 x 5566# / 5588#bsc.hz@cn.bosch.com
博世服务中心 中国浙江省杭州市 滨江区 滨康路567
310052 0571 8887 5566 / 5588
0571 8887 6688 x 5566# / 5588#bsc.hz@cn.bosch.com www.bosch-pt.com.cn
请勿将电动工具扔到生活垃圾中
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
24 |
|
u |
|
u |
|
|
|
|
|
u |
u |
|
|
|
|
|
|
|
u |
|
|
|
u |
|
|
|
|
|
||
u |
|
|
|
u |
|
|
|
|
|
|
|
u |
|
|
|
u |
|
u |
|
|
|
u |
|
u |
|
|
|
|
|
|
|
|
|
|
|
u |
||
u |
||
|
||
|
|
RCD RCD
u 工具時瞬間的疏忽會導致嚴重人身傷害。
u 鞋、安全帽、聽力防護等裝置能減少人身傷害。
u 已接通電源的開關上或開關處於接通時插入插頭 可能會導致危險。
u 導致人身傷害。
u 衡。
u 飾或長髮可能會捲入移動零件中。
傷。
u 效、更安全。
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
|
| 25 |
|
u |
|
|
|
|
|
u |
u 請戴上防塵面罩、聽力防護裝置、手套以及可防
u 外的附近人員受傷。
u 亦可能被捲入正在旋轉的配件中。
u 拉扯而失控。
u 會被撕裂並將配件導向自己的身體。
u 氣安全。
u 燃這些易燃物。
u 液可能導致觸電或電擊事件。
可避免此一情況。
u 作用力以及反彈力道。
u 擊中您的手。
u 燃衣物的危險。
u 進而降低砂輪破裂的風險。切割砂輪的凸緣可能 與研磨砂輪的凸緣不同。
u 加發生反彈或砂輪破損的可能性。
動工具直接推向您。
u 往上滑移或發生反彈。
u 而下垂。必須在工件下方、靠近切割線及靠近工 件邊緣的砂輪兩側加以支撐。
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
26 |
u |
|
|
|
|
|
|
||
|
||
|
u 裂、撕裂或發生反彈。
紙研磨。
(3)GWS 750-100 S GWS 750-115 S GWS 750-125 S
(5)M14 A)
(6)M10 A)
u(9)
(10)O
|
(11) |
A) |
|
|
|
|
|||
|
(12) |
|
|
|
u |
(13) |
|
|
A) |
|
|
|
|
|
|
(14) |
A) |
|
|
u |
(15) |
A) |
|
|
|
(16) |
|
A) |
|
|
|
|
||
|
(17) |
A) |
|
|
u |
(18) |
A) |
|
|
|
(19) |
A) |
|
|
|
(20) |
A) |
|
|
(21) |
A) |
|
||
|
(22) |
|
|
|
A) |
||||
|
|
||||
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GWS 710 |
GWS 750-100 |
GWS 750-115 |
GWS 750-125 |
|
|
3 601 C94 0.. |
3 601 C94 0.. |
3 601 C94 0.. |
3 601 C94 0.. |
|
W |
750 |
750 |
750 |
750 |
|
W |
380 |
380 |
380 |
380 |
|
|
11000 |
11000 |
11000 |
11000 |
|
|
– |
– |
– |
– |
|
mm |
125 |
100 |
115 |
125 |
|
|
M14 |
M10 |
M14 |
M14 |
|
mm |
22 |
22 |
22 |
22 |
|
|
|
|
|
|
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
|
|
|
|
|
|
| 27 |
|
|
|
|
|
|
|
|
|
|
GWS 710 |
GWS 750-100 |
GWS 750-115 |
GWS 750-125 |
|
|
|
– |
– |
– |
– |
|
|
|
– |
– |
– |
– |
|
|
|
– |
– |
– |
– |
|
|
|
– |
– |
– |
– |
|
EPTA-Procedure |
01:2014 |
|
|
|
|
|
– |
kg |
1.9 |
1.9 |
1.9 |
1.9 |
|
|
|
|
|
|
|
|
– |
kg |
1.8 |
1.8 |
1.8 |
1.8 |
|
|
|
/ II |
/ II |
/ II |
/ II |
|
230 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GWS 750-100 S |
GWS 750-115 S |
GWS 750-125 S |
GWS 750-100 I |
|
|
|
3 601 C94 1.. |
3 601 C94 1.. |
3 601 C94 1.. |
3 601 C94 2.. |
|
|
W |
750 |
750 |
750 |
750 |
|
|
W |
380 |
380 |
380 |
410 |
|
|
|
11000 |
11000 |
11000 |
11000 |
|
|
|
2800–11000 |
2800–11000 |
2800–11000 |
– |
|
|
mm |
100 |
115 |
125 |
100 |
|
|
|
M10 |
M14 |
M14 |
M10 |
|
|
mm |
22 |
22 |
22 |
22 |
|
|
|
|
|
|
|
|
|
|
● |
● |
● |
– |
|
|
|
– |
– |
– |
● |
|
|
|
● |
● |
● |
● |
|
|
|
● |
● |
● |
● |
|
EPTA-Procedure |
01:2014 |
|
|
|
|
|
– |
kg |
1.9 |
1.9 |
1.9 |
1.9 |
|
|
|
|
|
|
|
|
– |
kg |
1.8 |
1.8 |
1.8 |
1.8 |
|
|
|
/ II |
/ II |
/ II |
/ II |
230
u 上拔出插頭。
照「顧客服務處和顧客咨詢中心」。
(8) (8) (5)
(6) (9) (8)
u(8)
(8)
u 用防護罩(15)
u 置。
(15)
(8)
u (4)
(4)
u(18) (17)
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
28 | |
|
|
|
(4) (17) |
|
|
|
|
(13) |
||
u |
(12) |
||
|
|
||
|
u (13) |
||
u |
|||
(13) |
|||
|
|||
(13) |
|||
(7) |
|||
(23) |
|||
|
|||
|
|
||
(1) |
|
||
|
(1) |
||
|
(23) |
||
|
|||
u |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
(5) (6) (12) |
|
|
|
|
|
|
|
|
u |
|
|
|
|
|
|
|
|
|
|
|
M 14 |
|
|
(10) |
|
|
O O O |
|
|
|
|
|
(10) |
||
M 10 |
u |
|
|
||
|
|
|
|
||
u |
|
|
(17) |
90 |
|
|
|
|
u (18) |
|
|
|
||
(17) |
||
|
||
|
||
|
||
(20) (5) (6) |
||
4 |
||
|
||
|
||
|
|
|
u |
4 |
|
(17) |
|
|
|
||
|
|
|
|
[ ] [m/ |
|
|
s] |
|
|
|
|
|
|
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
|
[mm] |
[mm] |
|
|
|
|
D |
b |
d |
[ |
[m/s] |
|
|
|
|
] |
|
|
100 |
7 |
16.0 |
11000 |
80 |
|
115 |
7 |
22.2 |
11000 |
80 |
|
125 |
7 |
22.2 |
11000 |
80 |
D |
100 |
– |
– |
11000 |
80 |
|
115 |
– |
– |
11000 |
80 |
|
125 |
– |
– |
11000 |
80 |
D |
70 |
30 |
M 10 |
11000 |
45 |
B |
75 |
30 |
M 14 |
11000 |
45 |
D
呼吸道疾病。
行含石棉物料的加工。
–P2
u 燃。
u 牌上標示的電壓一致。標示為230 V220 V
| 29
操作者觸電。
並且要使用正確的電壓和電力頻率。
(2)
(2) (2)(2)(2)
GWS 750-100 I
(2)
GWS 750-100 S GWS 750-115 S GWS 750-125 S GWS 750-100 I
(2)
GWS 750-100 S GWS 750-115 SGWS 750-125 S GWS 750-100 I
16 A
GWS 750-100 S GWS 750-115 S GWS 750-125 S
(3)
|
|
|
|
|
|
|
2−3 |
|
|
|
3 |
|
|
|
4−6 |
|
|
|
6 |
|
|
|
6 |
u 上拔出插頭。
Bosch Power Tools |
1 609 92A 4PH | (06.11.2018) |
30 |
u 力學的注意事項」章節。
u 件工具冷卻。
u
30° 40°
音和研磨溫度也比較低。
u 用防護罩(15)
進的力道。操作機器時勿重壓機器、勿傾斜或搖 晃。 不可用側壓的方式來制止切割砂輪繼續轉動。
的位置著手。
u 置。
鑽石切割砂輪周圍出現環狀火花確認發生這種情 況。
輪又會鋒利如初。
DIN1053 1
u 上拔出插頭。
u 提高工作品質和安全性。
uPRCD
安全性能。
www.bosch-pt.com
詢小組很樂意為您提供協助。
DIY www.powertoolportal.de
品銘牌上的10
建國北路一段90 6
10491: (02) 2515 5388
: (02) 2516 1176 www.bosch-pt.com.tw
:
Robert Bosch Power Tools GmbH
·
70538 Stuttgart / GERMANY
70538 /
配件和廢棄的包裝材料。
1 609 92A 4PH | (06.11.2018) |
Bosch Power Tools |
