Fatal1ty Z270 Gaming K4 Series
Chapter 1 Introduction
Thank you for purchasing ASRock Fatal1ty Z270 Gaming K4 Series motherboard, a reliable motherboard produced under ASRock’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock’s commitment to quality and endurance.
In this documentation, Chapter 1 and 2 contains the introduction of the motherboard and step-by-step installation guides. Chapter 3 contains the operation guide of the software and utilities. Chapter 4 contains the configuration guide of the BIOS setup.
Because the motherboard specifications and the BIOS software might be updated, the content of this documentation will be subject to change without notice. In case any modifications of this documentation occur, the updated version will be available on ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.
•ASRock Fatal1ty Z270 Gaming K4 Series Motherboard (ATX Form Factor)
•ASRock Fatal1ty Z270 Gaming K4 Series Quick Installation Guide
•ASRock Fatal1ty Z270 Gaming K4 Series Support CD
•1 x I/O Panel Shield
•4 x Serial ATA (SATA) Data Cables (Optional)
•3 x Screws for M.2 Socket (Optional)
English
1 |
English
Platform |
• |
ATX Form Factor |
CPU |
• |
Supports 7th and 6th Generation Intel® CoreTM i7/i5/i3/ |
|
|
Pentium®/Celeron® Processors (Socket 1151) |
|
• |
Digi Power design |
|
• 8 Power Phase design |
|
|
• Supports Intel® Turbo Boost 2.0 Technology |
|
|
• Supports Intel® K-Series unlocked CPUs |
|
|
• Supports ASRock BCLK Full-range Overclocking |
|
Chipset |
• |
Intel® Z270 |
Memory |
• |
Dual Channel DDR4 Memory Technology |
•4 x DDR4 DIMM Slots
•Supports DDR4 3733+(OC)*/3600(OC)/3200(OC)/2933(OC) /2800(OC)/2400**/2133 non-ECC, un-buffered memory
*Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/)
** 7th Gen Intel® CPU supports DDR4 up to 2400; 6th Gen Intel® CPU supports DDR4 up to 2133.
•Supports ECC UDIMM memory modules (operate in nonECC mode)
•Max. capacity of system memory: 64GB
•Supports Intel® Extreme Memory Profile (XMP) 2.0
•15μ Gold Contact in DIMM Slots
Expansion |
• 2 x PCI Express 3.0 x16 Slots (PCIE2: x16 mode; PCIE4: x4 |
Slot |
mode)* |
|
* Supports NVMe SSD as boot disks |
|
• 4 x PCI Express 3.0 x1 Slots (Flexible PCIe) |
|
* If PCIE5 or PCIE6 is occupied, PCIE4 will run at x2 mode. |
|
• Supports AMD Quad CrossFireXTM and CrossFireXTM |
|
• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module |
|
* If M2_3 is occupied, PCIE3 will be disabled. |
|
• 15μ Gold Contact in VGA PCIe Slot (PCIE2) |
2 |
Fatal1ty Z270 Gaming K4 Series
Graphics |
• Intel® HD Graphics Built-in Visuals and the VGA outputs |
|
can be supported only with processors which are GPU |
|
integrated. |
•Supports Intel® HD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD Technology, Intel® InsiderTM, Intel® HD Graphics
•Gen9 LP, DX11.3, DX12
•HWAEncode/Decode: VP8, HEVC 8b, VP9, HEVC 10b (For 7th Gen Intel® CPU)
•HWA Encode/Decode: VP8 , HEVC 8b; GPU/SWEncode/ Decode: VP9, HEVC 10b (For 6th Gen Intel® CPU)
•Max. shared memory 1024MB
*The size of maximum shared memory may vary from different operating systems.
•Three graphics output options: D-Sub, DVI-D and HDMI
•Supports Triple Monitor
•Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
•Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
•Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
•Supports HDCP with DVI-D and HDMI Ports
•Supports Full HD 1080p Blu-ray (BD) playback with DVI-D and HDMI Ports
Audio |
• 7.1 CH HD Audio with Content Protection (Realtek |
|
ALC1220 Audio Codec) |
|
• Premium Blu-ray Audio support |
|
• Supports Surge Protection (ASRock Full Spike Protection) |
|
• Nichicon Fine Gold Series Audio Caps |
|
• 120dB SNR DAC with Differential Amplifier |
|
• TI® NE5532 Premium Headset Amplifier for Front Panel |
|
Audio Connector (Supports up to 600 Ohm headsets) |
|
• Pure Power-In |
|
• Direct Drive Technology |
English
3 |
English
|
• |
PCB Isolate Shielding |
|
• Impedance Sensing on Front Out port |
|
|
• Individual PCB Layers for R/L Audio Channel |
|
|
• |
AURA RGB LED |
|
• |
Gold Audio Jacks |
|
• 15μ Gold Audio Connector |
|
|
• Supports Creative SoundBlaster Cinema3 |
|
LAN |
• |
Gigabit LAN 10/100/1000 Mb/s |
|
• Giga PHY Intel® I219V |
|
|
• Supports Wake-On-LAN |
|
|
• Supports Lightning/ESD Protection (ASRock Full Spike |
|
|
|
Protection) |
|
• Supports Energy Efficient Ethernet 802.3az |
|
|
• |
Supports PXE |
Rear Panel |
• |
2 x Antenna Ports |
I/O |
• |
1 x PS/2 Mouse/Keyboard Port |
|
• 1 x D-Sub Port |
|
|
• 1 x DVI-D Port |
|
|
• 1 x HDMI Port |
|
|
• 1 x Optical SPDIF Out Port |
|
|
• 1 x USB 2.0 Port (Supports ESD Protection (ASRock Full |
|
|
|
Spike Protection)) |
|
• 1 x Fatal1ty Mouse Port (USB 2.0) (Supports ESD Protection |
|
|
|
(ASRock Full Spike Protection)) |
|
• 3 x USB 3.0 Type-A Ports (Supports ESD Protection (ASRock |
|
|
|
Full Spike Protection)) |
|
• 1 x USB 3.0 Type-C Port (Supports ESD Protection (ASRock |
|
|
|
Full Spike Protection)) |
|
• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED |
|
|
|
LED) |
|
• HD Audio Jacks: Rear Speaker / Central / Bass / Line in / |
|
|
|
Front Speaker / Microphone (Gold Audio Jacks) |
Storage |
• |
6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, |
|
|
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology |
|
|
15 and Intel Smart Response Technology), NCQ, AHCI and |
|
|
Hot Plug* |
4 |
Fatal1ty Z270 Gaming K4 Series
*If M2_1 is occupied by a SATA-type M.2 device, SATA_5 will be disabled.
*If M2_2 is occupied by a SATA-type M.2 device, SATA_0 will be disabled.
•2 x Ultra M.2 Sockets, support type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**
**Supports Intel® OptaneTM Technology
**Supports NVMe SSD as boot disks
**Supports ASRock U.2 Kit
Connector |
• 1 x COM Port Header |
•1 x TPM Header
•1 x Chassis Intrusion Header
•1 x Power LED and Speaker Header
•1 x CPU Fan Connector (4-pin)
*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
•2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)
•1 x Chassis Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
*The Chassis Optional/Water Pump Fan supports the water cooler fan of maximum 1.5A (18W) fan power.
*CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use.
•1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
•1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
•1 x Front Panel Audio Connector (15μ Gold Audio Connector)
•1 x Thunderbolt AIC Connector (5-pin)
•1 x Thunderbolt AIC Connector (10-pin)
*Only one Thunderbolt AIC Card is supported.
•3 x USB 2.0 Headers (Support 5 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
•2 x USB 3.0 Headers (Support 4 USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
English
5 |
English
BIOS |
• |
AMI UEFI Legal BIOS with multilingual GUI support |
Feature |
• |
ACPI 6.0 Compliant wake up events |
|
• |
SMBIOS 2.7 Support |
|
• CPU, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCST, |
|
|
|
VCCSA, VCCPLL Voltage Multi-adjustment |
Hardware |
• |
Temperature Sensing: CPU, Chassis, Chassis Optional/ |
Monitor |
|
Water Pump Fans |
|
• Fan Tachometer: CPU, Chassis, Chassis Optional/Water |
|
|
|
Pump Fans |
|
• Quiet Fan (Auto adjust chassis fan speed by CPU tempera- |
|
|
|
ture): CPU, Chassis, Chassis Optional/Water Pump Fans |
|
• Fan Multi-Speed Control: CPU, Chassis, Chassis Optional/ |
|
|
|
Water Pump Fans |
|
• |
CASE OPEN detection |
|
• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, |
|
|
|
VPPM, PCH 1.0V, VCCSA, VCCST |
OS |
• |
Microsoft® Windows® 10 64-bit (For 7th Gen Intel® CPU) |
|
• Microsoft® Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64- |
|
|
|
bit (For 6th Gen Intel® CPU) |
|
* To install Windows® 7 OS, a modified installation disk with |
|
|
xHCI drivers packed into the ISO file is required. Please refer to |
|
|
page 44 for more detailed instructions. |
|
|
* For the updated Windows® 10 driver, please visit ASRock’s |
|
|
website for details: http://www.asrock.com |
|
Certifica- |
• |
FCC, CE, WHQL |
tions |
• |
ErP/EuP ready (ErP/EuP ready power supply is required) |
* For detailed product information, please visit our website: http://www.asrock.com
Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools. Overclocking may affect your system’s stability, or even cause damage to the components and devices of your system. It should be done at your own risk and expense. We are not responsible for possible damage caused by overclocking.
6 |
Fatal1ty Z270 Gaming K4 Series
|
|
|
|
|
1 |
|
|
|
|
|
2 |
3 |
4 |
|
|
US:B2 USBT:1 |
USB20. |
/Mouse |
Keyboard PS2 |
ATX12V1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CPU_FAN1 |
|
|
|
|
|||||
|
|
|
|
|
CT1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
M2_3 |
|
|
|
|
|
|
|
|
|
|
HDMI1 |
|
|
|
|
|
|
|
|
|
-288bit,pinmodule) |
-288bit,pinmodule) |
-288bit,pinmodule) |
-288bit,pinmodule) |
ATXPWR1 |
|
USB 3.0 |
|
Top: |
|
|
|
|
|
|
|
|
|
|
|
||
T: USB3_TA_1 |
|
|
|
|
|
|
(64A1 |
(64A2 |
(64B1 |
(64B2 |
|
||||
B: USB3_TC_1 |
RJ-45 |
|
|
|
|
|
|
|
|||||||
USB 3.0 |
|
|
|
|
|
|
|
|
DDR4 |
DDR4 |
DDR4 |
DDR4 |
65USB3 |
||
T: USB1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
B: USB2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
SPDIF Optical Bottom: |
REARSPK |
Center: |
Central/Bass |
Top: |
|
|
|
|
|
|
|
|
|
|
1 |
|
|
CHA_FAN2 |
|
|
|
|
|
|
43 |
||||||
MIC Bottom: N |
FRONT |
Center: |
LINEIN |
Top: |
|
|
|
|
|
|
|
|
|
|
USB3_ |
|
|
|
|
|
|
|
|
PCI Express 3.0 |
|
|
|
|
|
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
2 |
|
RoHS |
|
|
|
|
|
|
|
|
PCIE1 |
|
|
|
|
M2 |
|
|
|
|
|
|
|
|
|
|
CT4 |
CT3 |
CT2 |
CT1 |
|
|
|
|
|
||
26 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 5 |
LAN |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
SATA |
||
|
|
|
|
|
|
|
PCIE2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CLRMOS1 |
|
|
|
|
|
|
3 |
|
|
|
|
|
|
|
|
1 |
|
|
|
|
|
|
2_ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SATA |
25 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FATAL1TY |
CMOS |
|
Intel |
|
|
SATA 0 1 |
||||
|
|
|
|
|
|
|
|
|
Battery |
|
Z270 |
|
|
|
|
|
|
AUDIO |
|
|
PCIE3 |
Z270 Gaming K4 |
|
|
|
|
|
||||
|
CODEC |
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
PCIE4 |
|
|
Ultra M.2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PCIe Gen3 x4 |
|
|
|
|
|
|
|
|
|
|
T B2 |
|
T B1 |
|
|
|
|
|
|
|
|
24 |
|
|
|
|
|
|
1 |
|
|
|
|
|
|
|
|
|
|
|
|
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PCIE5 |
|
|
|
|
CT4 |
CT3 |
CT2 |
CT1 |
|
M2 1 |
23
|
|
PCIE6 |
|
|
|
|
|
|
|
|
BIOS |
|
|
|
|
|
1 |
|
|
|
|
|
ROM |
|
|
|
|
|
USB_7 |
|
|
|
|
|
|
|
HD_AUDIO1 |
TPMS1 |
|
COM1 |
USB_5_6 |
USB_3_4 |
CHA_FAN1 |
CHA_FAN3/W_PUMP |
SPK_PLED1 |
PLED PWRBTN |
|
|
|
|
|
|
|||||||
|
CI1 |
|
|
|
RGB_LED |
|
|
|
|
|
|
1 |
|
|
1 |
1 |
1 |
1 |
|
|
1 |
1 |
|
1 |
1 |
|
|
|
|
HDLED |
RESET |
||||
|
|
|
|
|
|
|
|
|
PANEL1 |
22 |
21 |
20 |
19 |
18 |
17 |
16 |
15 |
14 |
13 |
12 |
11 |
5
6
7
8
9
10
English
7 |
No. Description
1ATX 12V Power Connector (ATX12V1)
2CPU Fan Connector (CPU_FAN1)
32 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
42 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
5ATX Power Connector (ATXPWR1)
6USB 3.0 Header (USB3_5_6)
7USB 3.0 Header (USB3_3_4)
8SATA3 Connectors (SATA_4_5)
9SATA3 Connectors (SATA_2_3) 10 SATA3 Connectors (SATA_0_1) 11 System Panel Header (PANEL1)
12 Power LED and Speaker Header (SPK_PLED1)
13 Chassis Fan / Waterpump Fan Connector (CHA_FAN3/W_PUMP) 14 Chassis Fan Connector (CHA_FAN1)
15 USB 2.0 Header (USB_3_4)
16 USB 2.0 Header (USB_5_6)
17 USB 2.0 Header (USB_7)
18 AURA RGB LED Header (RGB_LED)
19 COM Port Header (COM1)
20 TPM Header (TPMS1)
21 Chassis Intrusion Header (CI1)
22 Front Panel Audio Header (HD_AUDIO1)
23 Thunderbolt AIC Connector (TB1)
24 Thunderbolt AIC Connector (TB2)
25 Clear CMOS Jumper (CLRMOS1)
26 Chassis Fan Connector (CHA_FAN2)
English
8 |
Fatal1ty Z270 Gaming K4 Series
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
6 |
|||||
|
|
1 |
2 |
|
|
3 |
|
|
|
|
5 |
7 |
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
17 |
15 |
14 |
13 |
11 |
10 |
9 |
8 |
|
|
16 |
|
|
|
12 |
|
|
|
No. |
Description |
|
|
No. |
Description |
|
|
|
|
|
|
|
|
||||
1 |
PS/2 Mouse/Keyboard Port (PS2_KB1) |
|
10 |
USB 3.0 Ports (USB3_1_2) |
|
|
||
2 |
D-Sub Port (VGA1) |
|
|
11 |
USB 3.0 Type-A Port (USB3_TA_1) |
|||
3 |
LAN RJ-45 Port * |
|
|
12 |
USB 3.0 Type-C Port (USB3_TC_1) |
|||
4 |
Central / Bass (Orange) |
|
|
13 |
HDMI Port (HDMI1) |
|
|
|
5 |
Rear Speaker (Black) |
|
|
14 |
DVI-D Port (DVI1) |
|
|
|
6 |
Line In (Light Blue) |
|
|
15 |
Fatal1ty Mouse Port (USB_1) |
|
||
7 |
Front Speaker (Lime)** |
|
|
16 |
USB 2.0 Port (USB_2) |
|
|
|
8 |
Microphone (Pink) |
|
|
17 |
Antenna Ports |
|
|
|
9 |
Optical SPDIF Out Port |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
English
9 |
*There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
ACT/LINK LED SPEED LED
LAN Port |
|
|
|
|
|
|
Activity / Link LED |
|
Speed LED |
|
|
||
|
|
|
||||
Status |
|
Description |
|
Status |
|
Description |
Off |
|
No Link |
|
Off |
|
10Mbps connection |
|
|
|
||||
Blinking |
|
Data Activity |
|
Orange |
|
100Mbps connection |
On |
|
Link |
|
Green |
|
1Gbps connection |
|
|
|
|
|
|
|
** If you use a 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”. See the table below for connection details in accordance with the type of speaker you use.
Audio Output |
Front Speaker |
Rear Speaker |
Central / Bass |
Line In |
Channels |
(No. 7) |
(No. 5) |
(No. 4) |
(No. 6) |
2 |
V |
-- |
-- |
-- |
4 |
V |
V |
-- |
-- |
6 |
V |
V |
V |
-- |
8 |
V |
V |
V |
V |
To enable Multi-Streaming, you need to connect a front panel audio cable to the front panel audio header. After restarting your computer, you will find the “Mixer” tool on your system. Please select “Mixer ToolBox” , click “Enable playback multi-streaming”, and click “ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are allowed to select “Realtek HDA Primary output” to use the Rear Speaker, Central/Bass, and Front Speaker, or select “Realtek HDA Audio 2nd output” to use the front panel audio.
English
10 |
Fatal1ty Z270 Gaming K4 Series
This is an ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it.
Pre-installation Precautions
Take note of the following precautions before you install motherboard components or change any motherboard settings.
•Make sure to unplug the power cord before installing or removing the motherboard components. Failure to do so may cause physical injuries and damages to motherboard components.
•In order to avoid damage from static electricity to the motherboard’s components, NEVER place your motherboard directly on a carpet. Also remember to use a grounded wrist strap or touch a safety grounded object before you handle the components.
•Hold components by the edges and do not touch the ICs.
•Whenever you uninstall any components, place them on a grounded anti-static pad or in the bag that comes with the components.
•When placing screws to secure the motherboard to the chassis, please do not overtighten the screws! Doing so may damage the motherboard.
English
11 |
1.Before you insert the 1151-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found. Otherwise, the CPU will be seriously damaged.
2.Unplug all power cables before installing the CPU.
1
A
B
2
English
12 |
Fatal1ty Z270 Gaming K4 Series
3 |
4 |
5
English
13 |
Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.
English
14 |
Fatal1ty Z270 Gaming K4 Series
1 |
2 |
N _FA PU C
English
15 |
This motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots, and supports Dual Channel Memory Technology.
1.For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 DIMM pairs.
2.It is unable to activate Dual Channel Memory Technology with only one or three memory module installed.
3.It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot; otherwise, this motherboard and DIMM may be damaged.
Dual Channel Memory Configuration
Priority |
DDR4_A1 |
DDR4_A2 |
DDR4_B1 |
DDR4_B2 |
1 |
|
Populated |
|
Populated |
|
|
|||
2 |
Populated |
|
Populated |
|
3 |
Populated |
Populated |
Populated |
Populated |
The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
English
16 |
Fatal1ty Z270 Gaming K4 Series
1
2
3
English
17 |
There are 6 PCI Express slots on the motherboard.
Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.
PCIe slots:
PCIE1 (PCIe 3.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE2 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards. PCIE3 (PCIe 3.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE4 (PCIe 3.0 x16 slot) is used for PCI Express x4 lane width graphics cards. PCIE5 (PCIe 3.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE6 (PCIe 3.0 x1 slot) is used for PCI Express x1 lane width cards.
*If PCIE5 or PCIE6 is occupied, PCIE4 will run at x2 mode.
*If M2_3 is occupied, PCIE3 will be disabled.
PCIe Slot Configurations
|
PCIE2 |
PCIE4 |
|
Single Graphics Card |
x16 |
N/A |
|
Two Graphics Cards in |
x16 |
x4 |
|
CrossFireXTM Mode |
|||
|
|
For a better thermal environment, please connect a chassis fan to the motherboard’s chassis fan connector (CHA_FAN1 or CHA_FAN2) when using multiple graphics cards.
English
18 |
Fatal1ty Z270 Gaming K4 Series
The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.
Clear CMOS Jumper |
|
|
|
(CLRMOS1) |
Default |
Clear CMOS |
|
(see p.7, No. 25) |
|||
|
|
CLRMOS1 allows you to clear the data in CMOS. To clear and reset the system parameters to default setup, please turn off the computer and unplug the power cord from the power supply. After waiting for 15 seconds, use a jumper cap to short pin2 and pin3 on CLRMOS1 for 5 seconds. However, please do not clear the CMOS right after you update the BIOS. If you need to clear the CMOS when you just finish updating the BIOS, you must boot up the system first, and then shut it down before you do the clear-CMOS action. Please be noted that the password, date, time, and user default profile will be cleared only if the CMOS battery is removed.
If you clear the CMOS, the case open may be detected. Please adjust the BIOS option “Clear
Status” to clear the record of previous chassis intrusion status.
English
19 |
Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard.
System Panel Header
(9-pin PANEL1)
(see p.7, No. 11)
PLED+ PLED-
PWRBTN#
GND
1
GND RESET#
GND HDLED-
HDLED+
Connect the power switch, reset switch and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables.
PWRBTN (Power Switch):
Connect to the power switch on the chassis front panel. You may configure the way to turn off your system using the power switch.
RESET (Reset Switch):
Connect to the reset switch on the chassis front panel. Press the reset switch to restart the computer if the computer freezes and fails to perform a normal restart.
PLED (System Power LED):
Connect to the power status indicator on the chassis front panel. The LED is on when the system is operating. The LED keeps blinking when the system is in S1/S3 sleep state. The LED is off when the system is in S4 sleep state or powered off (S5).
HDLED (Hard Drive Activity LED):
Connect to the hard drive activity LED on the chassis front panel. The LED is on when the hard drive is reading or writing data.
The front panel design may differ by chassis. A front panel module mainly consists of power switch, reset switch, power LED, hard drive activity LED, speaker and etc. When connecting your chassis front panel module to this header, make sure the wire assignments and the pin assignments are matched correctly.
English
20 |
