Composite AV Cable
Composite AV Cable
Use the Composite AV Cable to connect your iPod, iPhone, or iPad to the composite video port and analog audio ports on your TV, home theater receiver, or stereo receiver. The Composite AV Cable has a USB connector that you can plug into a power source, such as a computer or a USB Power Adapter.
Before you begin connecting components, turn o the power to all your components. Remember to make all connections rmly to avoid humming and noise.
Important:  Never force a connector into a port. If the connector and port don’t join with reasonable ease, they probably don’t match. Make sure that the connector matches the port and that you have positioned the connector correctly in relation to the port.
To use the Composite AV Cable to connect iPod, iPhone, or iPad to your TV or receiver:
1 Plug the yellow video connector into the video input port on your TV or receiver.
2 Plug the white and red audio connectors into the left and right analog audio input
ports, respectively, on your TV or receiver.
3 Plug the iPod Dock Connector into your iPod, iPhone, iPad, or Universal Dock.
4 Plug the USB connector into your computer or a USB Power Adapter to keep
your iPod, iPhone, or iPad charged.
5 Turn on iPod, iPhone, or iPad and your TV or receiver to start playing.
2 English
Make sure you set your iPod, iPhone, or iPad to send a video signal out to your TV
Video (yellow)
or receiver. For more information, see the user guide for your iPod, iPhone, or iPad, available on the web at www.apple.com/support/manuals.
Left audio (white)
USB port
USB connector
iPod
Right audio (red)
Dock Connector
Television
Refer to the manual that came with your TV, receiver, or other device for the location of its ports.
Note:  If your iPod doesn’t support video, you can use the Composite AV Cable for syncing content and charging.
3English
1
2
3
4
5
4
5
Câble AV composite
Le câble AV composite vous permet de connecter votre iPod, votre iPhone ou votre iPad au port vidéo composite et aux ports audio analogiques de votre téléviseur, du récepteur de votre installation de cinéma à domicile ou de votre récepteur vidéo. Le câble AV composite dispose d’un connecteur USB que vous pouvez brancher sur une source électrique telle qu’un ordinateur ou un adapteur secteur USB.
Commencez par éteindre tous vos composants avant de les connecter. Assurez-vous qu’ils sont tous fermement connectés pour éviter tout risque de bruits parasites.
Important :  n’essayez jamais de forcer l’insertion d’un connecteur dans un port. Si vous ne parvenez pas à connecter aisément un connecteur et un port, cela est probablement dû au fait qu’ils ne concordent pas. Assurez-vous que le connecteur correspond au port choisi et que vous l’avez correctement positionné par rapport au port.
Pour utiliser le câble AV composite an de connecter un iPod, un iPhone ou un iPad à votre récepteur ou téléviseur :
1 Branchez le connecteur vidéo jaune sur le port d’entrée vidéo de votre téléviseur ou de
votre récepteur.
2 Branchez les connecteurs audio blanc et rouge respectivement sur les ports d’entrée
de gauche et de droite de votre téléviseur ou de votre récepteur.
3 Branchez le connecteur iPod Dock Connector sur votre iPod, iPhone, iPad ou Dock
universel.
4 Branchez le connecteur USB sur votre ordinateur ou un adaptateur secteur USB pour
maintenir le niveau de charge de votre iPod, iPhone ou iPad.
6 Français
5 Allumez l’iPod, l’iPhone ou l’iPad et votre téléviseur ou votre récepteur pour lancer
Vidéo (jaune)
la lecture.
Veillez à régler votre iPod, iPhone ou iPad pour envoyer un signal vidéo à votre téléviseur ou récepteur. Pour en savoir plus, consultez le guide de l’utilisateur de votre iPod, iPhone ou iPad, disponible sur le web à l’adresse www.apple.com/fr/support/manuals.
Audio gauche (blanc)
Port USB
Connecteur USB
iPod
Audio droit (rouge)
Connecteur Dock
Télévision
Pour trouver l’emplacement des ports, référez-vous au manuel fourni avec le téléviseur, le récepteur ou l’appareil concerné.
Remarque :  si votre iPod ne dispose pas de capacités vidéo, vous pouvez utiliser le câble AV composite pour la synchronisation des données et le chargement.
7Français
Composite AV-Kabel
Verwenden Sie das Composite AV-Kabel, um Ihren iPod, Ihr iPhone oder iPad mit den Composite-Video- und analogen Audioanschlüssen Ihres Fernsehgeräts bzw. Ihres Heimkino- oder Stereoempfängers zu verbinden. Das Composite AV-Kabel besitzt einen USB-Stecker, den Sie mit einer Stromquelle wie Ihrem Computer oder dem mitgelieferten USB Power Adapter (Netzteil) verbinden können.
Bevor Sie die Komponenten miteinander verbinden, schalten Sie die Stromversorgung aller Komponenten aus. Achten Sie darauf, alle Kabel fest anzuschließen, um Störgeräusche zu vermeiden.
Wichtig:  Versuchen Sie niemals, einen Stecker gewaltsam mit einem Anschluss zu verbinden. Lässt sich der Stecker nicht problemlos mit dem Anschluss verbinden, passen Stecker und Anschluss vermutlich nicht zueinander. Vergewissern Sie sich, dass der Stecker zum Anschluss passt und dass Sie den Stecker korrekt mit dem Anschluss ausgerichtet haben.
Gehen Sie wie folgt vor, um den iPod mithilfe des Composite AV-Kabels an Ihr Fernsehgerät oder Ihren Empfänger anzuschließen:
1 Schließen Sie den gelben Videostecker an den Videoeingang Ihres Fernsehgeräts oder
Empfängers an.
2 Schließen Sie den weißen und den roten Audiostecker an die linken und rechten
analogen Audioeingänge Ihres Fernsehgeräts oder Empfängers an.
3 Schließen Sie den iPod Dock-Stecker an Ihren iPod oder das Universal Dock an.
4 Verbinden Sie den USB-Stecker mit Ihrem Computer oder einem USB-Power Adapter
(Netzteil), damit die Batterie Ihres iPod, iPhone oder iPad aufgeladen bleibt.
8 Deutsch
5 Schalten Sie den iPod, das iPhone oder iPad und das Fernsehgerät oder den Empfänger
Video (gelb)
ein, um die Wiedergabe zu starten.
Vergewissern Sie sich, dass Sie Ihren iPod, Ihr iPhone oder iPad zum Senden eines Videosignals an Ihr Fernsehgerät bzw. Ihren Empfänger konguriert haben. Weitere Informationen nden Sie im Benutzerhandbuch für Ihr iPod, iPhone oder iPad im Internet unter: www.apple.com/de/support/manuals.
Audio links (weiß)
USB­Anschluss
-
USB Stecker
iPod
Audio rechts (rot)
Dock Connector
Fernsehgerät
Beachten Sie die Hinweise in der Dokumentation zu Ihrem Fernsehgerät, Empfänger oder anderem Gerät, um die passenden Anschlüsse zu nden.
Hinweis:  Wenn Ihr iPod keine Videounterstützung bietet, können Sie das Composite AV-Kabel zum Synchronisieren von Inhalten und zum Laden der Batterie verwenden.
9Deutsch
Cable de A/V por componentes
Utilice el cable de A/V por componentes para conectar el iPod, iPhone o iPad al puerto de vídeo por componentes y a los puertos de audio analógicos del televisor, receptor de cine en casa o receptor estéreo. El cable de A/V por componentes incluye un conector USB que puede conectar a una fuente de alimentación, como un ordenador o un adaptador de corriente USB.
Antes de empezar a conectar componentes, desconecte la alimentación de todos los componentes. Acuérdese de realizar todas las conexiones rmemente para evitar que se produzcan zumbidos y ruidos.
Importante:  No fuerce nunca un conector al enchufarlo en un puerto. Si la conexión entre el conector y el puerto no es razonablemente fácil, seguramente no se correspondan. Asegúrese de que el conector encaja con el puerto y que se ha colocado en la posición correcta.
Para utilizar el cable de A/V por componentes para conectar el iPod, iPhone o iPad al televisor o receptor:
1 Enchufe el conector de amarillo de vídeo al puerto de entrada de vídeo del televisor o
receptor.
2 Enchufe los conectores blanco y rojo de audio en los puertos de entrada de audio
analógicos izquierdo y derecho, respectivamente, del televisor o receptor.
3 Enchufe el conector iPod Dock Connector al iPod, iPhone, iPad o a la base de conexión
Universal Dock.
10 Español
4 Enchufe el conector USB a un adaptador de corriente USB para que el iPod, iPhone o
Vídeo (amarillo)
iPad permanezca cargado.
5 Encienda el iPod, iPhone o iPad y el televisor o receptor para iniciar la reproducción.
Asegúrese de ajustar el iPod, iPhone o iPad de modo que envíe una señal de vídeo de salida al televisor o receptor. Para obtener más información, consulte el manual del usuario del iPod, iPhone o iPad, que encontrará en Internet en la dirección www.apple.com/es/support/manuals.
Audio izquierdo
Puerto USB
Conector USB iPod
(blanco) Audio derecho (rojo)
Conector Dock
Televisor
Consulte el manual que acompaña al televisor, receptor u otro dispositivo para localizar sus puertos.
Nota:  Si el iPod no admite vídeo, puede utilizar el cable de A/V por componentes para sincronizar el contenido y recargar la batería.
11Español
Cavo AV composito
Utilizza il cavo AV composito per collegare iPod, iPhone o iPad alla porta video composito e alle porte audio analogico del televisore, del ricevitore dell’home theater o dello stereo. Il cavo AV composito è dotato di un connettore USB che puoi collegare alla fonte di alimentazione, come un computer o un alimentatore di corrente USB.
Prima di collegare i componenti, disattiva l’alimentazione di tutti i componenti. Ricorda di assicurarti che tutti i collegamenti siano ben saldi per evitare ronzio e altri rumori.
Importante:  non forzare mai un connettore in una porta. Se il connettore non entra con facilità nella porta, probabilmente non sono compatibili. Assicurati che lo spinotto del connettore sia adatto alla porta e che il connettore sia posizionato correttamente in relazione alla porta.
Per utilizzare il cavo AV composito per collegare iPod, iPhone o iPad al televisore o al ricevitore:
1 Collega il connettore video (giallo) alla porta di ingresso video del televisore o del
ricevitore.
2 Collega i connettori audio (bianco e rosso) alle porte di ingresso audio analogico di
sinistra e di destra, rispettivamente, del televisore o del ricevitore.
3 Collega iPod Dock Connector ad iPod, iPhone, iPad o al Dock universale.
4 Collega il connettore USB al computer o all’alimentatore di corrente USB per
mantenere carichi iPod, iPhone o iPad.
5 Accendi iPod, iPhone o iPad e il televisore o il ricevitore per avviare la riproduzione.
12 Italiano
Assicurati di aver impostato iPod, iPhone o iPad per inviare un segnale video in uscita
Video (giallo)
al televisore o al ricevitore. Per ulteriori informazioni, consulta il manuale utente di iPod, iPhone o iPad, disponibile sul Web all’indirizzo www.apple.com/it/support/manuals.
Audio di sinistra
Porta USB
Connettore USB
iPod
(bianco) Audio di destra (rosso)
Connettore Dock
Televisione
Consulta il manuale fornito con il televisore, il ricevitore o un altro dispositivo per individuarne le relative porte.
Nota:  se iPod non supporta i video, puoi utilizzare il cavo AV composito per sincronizzare contenuti e per caricare il dispositivo.
13Italiano
Regulatory Compliance Information
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See instructions if interference to radio or television reception is suspected.
Radio and Television Interference
The equipment described in this manual generates, uses, and can radiate radio-frequency energy. If it is not installed and used properly—that is, in strict accordance with Apple’s instructions —it may cause interference with radio and television reception.
This equipment has been tested and found to comply with the limits for a Class B digital device in accordance with the specications in Part 15 of FCC rules. These specications are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation.
You can determine whether your computer system is causing interference by turning it o. If the interference stops, it was probably caused by the computer or one of the peripheral devices.
If your computer system does cause interference to radio or television reception, try to correct the interference by using one or more of the following measures:
• Turn the television or radio antenna until the interference stops.
• Move the computer to one side or the other of the television or radio.
• Move the computer farther away from the television or radio.
• Plug the computer into an outlet that is on a dierent circuit from the television or radio. (That is, make certain the computer and the television or radio are on circuits controlled by dierent circuit breakers or fuses.)
If necessary, consult an Apple Authorized Service Provider or Apple. See the service and support information that came with your Apple product. Or, consult an experienced radio or television technician for additional suggestions.
Important:  Changes or modications to this product not authorized by Apple Inc. could void the FCC compliance and negate your authority to operate the product.
This product was tested for FCC compliance under conditions that included the use of Apple peripheral devices and Apple shielded cables and connectors between system components.
It is important that you use Apple peripheral devices and shielded cables and connectors between system components to reduce the possibility of causing interference to radios, television sets, and other electronic devices. You can obtain Apple peripheral devices and the proper shielded cables and connectors through an Apple­authorized dealer. For non-Apple peripheral devices, contact the manufacturer or dealer for assistance.
Responsible party (contact for FCC matters only):
Apple Inc. Corporate Compliance 1 Innite Loop, MS 26-A Cupertino, CA 95014
Industry Canada Statements
Complies with the Canadian ICES-003 Class B specications. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device complies with RSS 210 of Industry Canada.
This Class B device meets all requirements of the Canadian interference-causing equipment regulations.
Cet appareil numérique de la Class B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
European Compliance Statement
This product complies with the requirements of European Directives 72/23/EEC, 89/336/EEC, and 1999/5/EC.
14
Korea Class B Statement
Korea Class B Statement
Taiwan Class B Statement
Disposal and Recycling Information
When this product reaches its end of life, please dispose of it according to your local environmental laws and guidelines.
For information about Apple’s recycling programs, visit: www.apple.com/environment/recycling
2010
Türkiye
15
Brazil—Disposal Information:
Brasil:  Informações sobre eliminação e reciclagem
O símbolo indica que este produto e/ou sua bateria não devem ser descartadas no lixo doméstico. Quando decidir descartar este produto e/ou sua bateria, faça-o de acordo com as leis e diretrizes ambientais locais. Para informações sobre o programa de reciclagem da Apple, pontos de coleta e telefone de informações, visite www.apple.com/br/environment.
Apple and the Environment
Apple Inc. recognizes its responsibility to minimize the environmental impacts of its operations and products. More information is available on the web at: www.apple.com/environment
www.apple.com
© 2010 Apple Inc. All rights reserved. Apple, the Apple logo, iPhone, and iPod are trademarks of Apple Inc., registered in the U.S. and other countries. iPad is a trademark of Apple Inc.
ZM034-5591-A Printed in XXXX
