Installation and
Operation
G5BLK
120V
15A

Contents
General Information ....................................................... | 1 |
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Inventory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation ...................................................................... | 3 |
Install the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Connect A/C Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operation ........................................................................ | 5 |
Display Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 5 |
Configuration .................................................................. | 9 |
Troubleshooting .......................................................... | 10 |
Common problems and solutions . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Contact APC APV Technical Support . . . . . . . . . . . . . . . . . . . . . . . 10
Specifications | ............................................................... 11 |
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 11 |
Español ......................................................................... | 13 |
Français (Canada) ........................................................ | 25 |
APC A/V | i |
ii | APC A/V |

General Information
Overview
The APC® AV
Inventory
Power conditioner (1) | Stabilizing feet (4) |
Safety
•Electrical Hazard: For indoor use only.
•CAUTION - Do not install this device if there is not at least 10 meters (30 feet) or more of wire between the electrical outlet and the electrical service panel.
•Risk of electric shock. Do not plug into another relocatable power tap.
•Contains always on receptacles. To reduce the risk of electric shock, disconnect the unit from the power source before servicing the equipment.
•Overloading. Do not overload the wall outlet where this device is being connected. Do not overload this device. Ensure the total load to this device does not exceed that which is listed in the Specifications section of this manual.
•Power. Ensure this device is connected to a properly grounded AC power source. Further ensure the device is plugged into a source providing the required 120 Vac. Do not use a plug adapter which defeats the ground pin of the AC plug.
•Placement. Do not install this device on any unsteady surface. Do not install this device on any heat source.
•Water and Moisture. Do not use this product near any source of water, or in an environment where the relative humidity may exceed 95%
•Polarization. This device has a polarized AC line plug having one grounding pin. This plug will only fit into the wall outlet in one orientation. This is a safety feature. Do not remove the round grounding pin.
•System Ground Terminal. The unit provides for the connection of grounding wires from all of your equipment to a central terminal lug. This ground connection eliminates ground loop problems; tie all component grounds to this screw to break any possible ground loops that can cause an audible noise.
•Servicing. There are no
•Damage Requiring Service. If any type of damage occurs to this device, immediately disconnect it from the wall outlet. Notify APC Technical Support or Customer Service at once.
•Replacement Parts. There are no components within this device that can or should be removed/replaced unless it is by an
APC A/V | 1 |
