Digital Workstation
Data List
Daten-Liste
Liste des données
Lista de datos
Contents
Voice List
Voice-Liste
Liste des voix
Lista de voces .................................................. 2
Mega Voice Map
Sound-Zuordnungen der Mega Voices
Carte des voix Mega
Mapa de Mega Voice............................................16
Drum/SFX Kit List
Drum/SFX-Kit-Liste
Liste des kits de batterie/SFX
Lista de conjuntos de percusión/efectos especiales .................18
Style List
Liste der Styles
Liste des styles
Lista de estilos .................................................36
Multi Pad Bank List
Multi-Pad-Bank-Liste
Liste des banques multi-pads
Lista de bancos de Multi Pad.....................................38
Harmony/Arpeggio Type List
Liste der Harmony-/Arpeggiotypen
Liste des types d’harmonie/arpège
Lista de tipos de armonía/arpegio ................................39
Effect Type List
Liste der Effekttypen
Liste des types d’effet
Lista de tipos de efecto..........................................40
Effect Parameter List
Liste der Effektparameter
Liste des paramètres d’effets
Lista de parámetros de efectos .................................. 48
Effect Data Assign Table
Effektdaten-Zuordnungstabelle
Tableau d’assignation des données d’effets
Tabla de asignación de datos para efectos......................... 60
Parameter Chart
Parametertabelle
Tableau des paramètres
Gráfico de parámetros.......................................... 62
MIDI Data Format
MIDI-Datenformat
Format des données MIDI
Formato de datos MIDI ......................................... 69
Song System Exclusive Message List
Liste der System-Exclusive-Meldungen der Songs
Liste des messages exclusifs au système de morceaux
Lista de mensajes exclusivos del sistema de canciones ............. 86
Song Meta Event List
Liste der Meta-Events der Songs
Liste des métaévénements des morceaux
Lista de meta-eventos de canciones .............................. 86
MIDI Implementation Chart
MIDI-Implementierungstabelle
Tableau d'implémentation MIDI
Gráfico de implementacíon MIDI ................................. 87
Manual Development Department
© 2015 Yamaha Corporation
Published 09/2015 PO-A0
Voice List / Voice-Liste / Liste des voix / Lista de voces
Category Voice Name
Piano ConcertGrand 0 115 1 Live!
E.Piano SuitcaseEP 0 118 5 Cool!
Organ&Accordion WhiterBars 8 32 30 S.Art!
PSR-A3000 Data List
2
PopGrand 104 5 1 Live!
RockPiano 104 4 1 Live!
AmbientPiano 104 3 1 Live!
OctavePiano1 0 113 4 Live!
MIDIGrand 104 0 3 Live!
MIDIGrandPad 104 1 3 Live!
MIDIGrandSyn 104 1 1 Live!
PianoOrchestra 104 2 1 Live!
OctavePiano2 0 114 4 Live!
Harpsichord 8 32 113 S.Art!
GrandPiano 0 113 1 Live!
WarmGrand 0 114 1 Live!
BrightPiano 0 112 2 Live!
CocktailPiano 104 0 4 Live!
HonkyTonk 0 112 4 Regular
GrandHarpsi 0 113 7 Live!
VintageEP 0 116 5 Regular
SmoothTine 0 119 6 Regular
ElectricPiano 0 119 5 Cool!
TremoloSuitcase 0 113 5 Cool!
SweetDX 104 0 6 Cool!
BalladDX 0 124 6 Cool!
DXDynamics 0 123 6 Cool!
BalladBells 104 2 6 Cool!
MidnightDX 104 1 6 Cool!
StageEP 0 117 5 Regular
CP80Stage 0 113 3 Regular
ClaviBright 0 112 8 Regular
WahClavi 0 113 8 Regular
PhaseClavi 0 115 8 Regular
DreamDX 104 3 6 Cool!
SparkleStack 0 121 6 Cool!
GalaxyEP 0 114 5 Cool!
AllBarsOut 8 32 31 S.Art!
JazzRotary 8 32 114 S.Art!
ClassicBars 8 34 30 S.Art!
Organ-a-Go-Go 104 0 17 Cool!
CurvedBars 0 121 17 Cool!
EvenBars 0 111 17 Cool!
VintageFast 0 127 17 Cool!
RotorOrgan 0 117 19 Cool!
ClassicJazz 0 117 17 Cool!
RockRotary 8 33 114 S.Art!
ProgRockOrgan 8 33 30 S.Art!
HoldItFast 0 111 18 Cool!
R&BTremolo 0 111 19 Cool!
ScannerJazz 0 118 19 Cool!
OrganAccomp1 0 108 18 Regular
OrganAccomp2 0 107 18 Regular
OrganAccomp3 0 106 18 Regular
OrganAccomp4 0 105 18 Regular
OrganAccomp5 0 104 18 Regular
FullOrgan 0 112 20 Regular
ChapelOrgan 0 113 20 Regular
HymnOrgan 0 114 20 Regular
ChurchOrgan 0 115 20 Regular
MellowDrawbar 0 115 18 Regular
Harmonium1 0 114 21 Regular
Harmonium2 0 115 21 Regular
TwoChannels 0 109 18 Cool!
FullRocker 0 115 19 Cool!
EuroOrgan 0 118 17 Regular
FullTheatre 0 127 19 Regular
SweetTheatre 0 126 19 Regular
TibiaChorus 104 5 18 Regular
Tibia16'&4' 104 8 17 Regular
Tibia8'&4' 104 9 17 Regular
Vox&Tibia 104 10 17 Regular
Tibia8' 104 6 18 Regular
VoxHumana8' 104 7 18 Regular
Trumpet&Kinura 0 125 18 Regular
MSB LSB
Program Change
PC#
(1–128)
Voice Type
Category Voice Name
Organ&Accordion BallroomOrgan 0 115 4 Regular
WhiterBarsSlow 104 1 18 Cool!
WhiterBarsFast 104 0 18 Cool!
AllBarsOutSlow 104 1 19 Cool!
AllBarsOutFast 104 0 19 Cool!
AllBarsPhase 104 2 19 Cool!
JazzSlow 0 126 18 Cool!
JazzFast 0 127 18 Cool!
Harmonica 0 112 23 Sweet!
MasterAccordion 0 118 22 Regular
FullRegister 104 2 22 Regular
Cassotto 104 0 22 Regular
JazzAccordion 0 120 22 Regular
BluesHarp 0 114 23 Regular
TangoAccordion 0 114 24 Regular
Cajun 104 3 22 Regular
FrenchMusette 0 119 22 Regular
Steirische 0 117 22 Regular
ModernHarp 0 113 23 Regular
AccordionBass 0 121 22 Regular
Bandoneon 0 113 24 Regular
MasterBass 0 122 22 Regular
MusetteBass 0 123 22 Regular
AccordionClarinet 104 1 22 Regular
TangoBass 0 115 24 Regular
FullRegisterBass 104 5 22 Regular
CajunBass 104 6 22 Regular
Guitar RockLegend 8 34 6 S.Art!
StageLead 8 38 6 S.Art!
OverdriveWah 8 39 6 S.Art!
BluesyNight 8 55 4 S.Art!
LightChorus 8 53 4 S.Art!
ConcertGuitar 8 32 1 S.Art!
SteelGuitar 8 32 2 S.Art!
ElectroAcoustic 8 35 1 S.Art!
JazzVintage 8 38 7 S.Art!
JazzArtist 8 39 7 S.Art!
SixtiesGuitar 8 57 4 S.Art!
HalfWahLead 8 55 6 S.Art!
WahWahGuitar 8 56 6 S.Art!
SeventiesChorus 8 58 4 S.Art!
VintageSpring 8 54 4 S.Art!
FlamencoGuitar 8 33 1 S.Art!
SemiAcoustic 8 33 7 S.Art!
JazzClean 8 32 7 S.Art!
PedalSteel 8 36 4 S.Ar t!
AlohaGuitar 0 118 27 Regular
PureVintage 8 42 6 S.Art!
VintageAmp 8 40 4 S.Ar t!
GrungeGuitar 8 40 6 S.Art!
ClassicStack 8 41 6 S.Art!
CrunchGuitar 8 33 6 S.Art!
WarmSolid 8 33 4 S.Art!
CleanSolid 8 34 4 S.Art!
SlideJazzGuitar 104 0 27 Cool!
SolidJazzGuitar 8 40 7 S.Art!
SmoothJazzGuitar 8 35 7 S.Art!
NylonGuitar 8 34 1 S.Ar t!
FolkGuitar 8 33 2 S.Art!
SteelGuitar 0 117 26 Live!
12StringGuitar 0 113 26 Live!
ClassicalGuitar 0 115 25 Live!
MutedGuitar 0 119 29 Cool!
DynamicMute 0 118 29 Cool!
NylonMute 0 119 25 Live!
SteelMute 0 120 26 Live!
HardFlamenco 0 118 25 Live!
GuitarHero 8 32 6 S.Art!
SingleCoilClean 8 39 4 S.Art!
PedalSteelAmp 8 52 4 S.Art!
Slapback 104 0 28 Cool!
HalfDrive 8 37 4 S.Art!
Bass VintageRound 104 1 34 Cool!
VintagePick 104 1 35 Regular
MSB LSB
(1–128)
PC#
Voice Type
Program Change
Voice List / Voice-Liste / Liste des voix / Lista de voces
Category Voice Name
Bass VintageFlat 104 2 34 Cool!
FretlessBass 0 112 36 Cool!
SlapBass 0 112 37 Regular
AcousticBass 0 112 33 Regular
VintagePickMute 104 0 35 Cool!
VintageDyno 104 2 35 Cool!
MellowFinger 0 112 34 Regular
PickBass 0 112 35 Regular
VintageMute 104 3 34 Cool!
ElectricBass 0 114 34 Cool!
HalfMute 0 115 34 Cool!
SuperFretless 0 113 36 Regular
FusionBass 0 113 37 Regular
FunkBass 0 112 38 Regular
RockBass 0 114 35 Regular
PickDynoBass 0 113 35 Cool!
LoBass 104 0 40 Regular
DarkBass 104 1 40 Regular
MoonBass 104 0 39 Regular
KickBass 104 1 39 Regular
ClubBass 104 2 39 Regular
FatPulse 104 2 40 Regular
WazzoSaw 104 3 81 Regular
DeepPoint 104 3 39 Regular
TightBass 104 3 40 Regular
Competitor 104 4 39 Regular
1o1Sub 104 5 39 Regular
LittleBassSynth 104 6 39 Regular
TeknoBass 104 7 39 Regular
PercPunch 104 8 39 Regular
SquareBass 104 4 40 Regular
TranceBass 104 9 39 Regular
SubCutBass 104 5 40 Regular
DynoAcidBass 104 10 39 Regular
MiniSub 104 6 40 Regular
FatSineResonance 104 11 39 Regular
BalladBass 104 7 40 Regular
VelocityMaster 104 17 82 Regular
SubBass 0 114 40 Regular
HardBass 0 114 39 Regular
ResonanceBass 0 112 39 Regular
HouseBass 0 116 39 Regular
BigDrone 0 118 39 Regular
TBBass 0 117 40 Regular
Bass&Cymbal 0 114 33 Regular
LFOSynBass 0 110 102 Regular
DX100Bass 0 118 40 Regular
FatLoBass 0 119 39 Regular
RampBass 0 119 40 Regular
DarkCoreBass 0 120 40 Regular
FunkBass 0 121 40 Regular
BleepBass 0 122 40 Regular
ClickOrganBass 104 27 18 Regular
DeepSub MW 104 18 88 Regular
MultiSawBass 104 20 88 Regular
Strings ConcertStrings 8 32 50 S.Art!
StudioStrings 8 32 49 S.Art!
Strings 0 117 50 Live!
MovieStrings 0 123 49 Live!
ChamberStrings 0 112 50 Regular
Violin 0 113 41 Sweet!
Pizzicato 0 113 46 Live!
TremoloStrings 0 113 45 Live!
Spiccato 0 120 49 Live!
OrchestralHarp 104 1 47 Regular
Spiccato 8 33 49 S.Art!
Strings f 0 119 49 Live!
Strings mf 0 118 49 Live!
Strings p 0 117 49 Live!
Allegro 0 122 50 Live!
Mandolin 0 114 26 Sweet!
PizzicatoGlocken 0 115 46 Live!
TremoloBowing 8 34 49 S.Art!
DynamicStrings 0 124 49 Live!
MSB LSB
(1–128)
PC#
Voice Type
Program Change
Category Voice Name
Strings MellowHarp 104 0 47 Regular
OberStrings 0 113 52 Regular
SynthStrings1 0 112 51 Regular
SynthStrings2 0 113 51 Regular
DiscoStrings1 0 123 50 Live!
DiscoStrings2 0 124 50 Live!
SymphonicUnison 104 0 50 Regular
TheatreOrchestra 104 1 50 Regular
Hackbrett1 104 2 47 Regular
Zither1 104 1 16 Regular
Zither2 104 0 16 Regular
Banjo1 104 0 106 Regular
ErHu 0 113 111 Regular
PiPa 0 119 106 Regular
Sitar1 104 0 105 Regular
Sitar2 0 113 105 Regular
Koto 0 112 108 Regular
Shamisen 0 112 107 Regular
Banjo2 0 112 106 Regular
SoloViolin 0 112 41 Regular
Viola 0 112 42 Regular
Cello 0 112 43 Regular
Contrabass 0 112 44 Regular
Fiddle 0 112 111 Regular
Hackbrett2 0 113 47 Regular
Tutti 0 120 50 Reg ular
OrchestraHit 0 112 56 Regular
Brass BrightTrumpet 8 32 65 S.Art!
SilverTrumpet 8 33 65 S.Art!
GoldenTrumpet 8 34 65 S.Art!
BigBandTrumpet 8 37 65 S.Ar t!
TrumpetFall 8 38 65 S.Art!
Cornet 0 119 57 Sweet!
MutedTrumpet 0 114 60 Sweet!
FlugelHorn 0 118 57 Sweet!
Trombone 0 117 58 Sweet!
Trumpet 0 115 57 Sweet!
TrumpetShake 8 35 65 S.Art!
SilverTrumpet 0 121 57 Sweet!
GoldenTrumpet 0 122 57 Sweet!
MellowTrumpet 0 120 57 Sweet!
BaritoneHorn 0 113 59 Regular
Tub a 104 0 59 Re g ul ar
AlpBass 0 113 34 Regular
BaritoneHit 0 114 59 Reg ular
BigBandBrass 8 37 57 S.Ar t!
SmoothBrass 8 36 57 S.Art!
DynamicBrass 0 127 62 Live!
PowerBrass 0 121 63 Live!
AccentBrass 0 109 62 Live!
FrenchHorns 0 112 61 Live!
SymphonyBrass 0 119 61 Live!
Brass f 0 108 62 Live!
Brass mf 0 110 62 Live!
Brass p 0 111 62 Live!
BrassFalls f 8 34 57 S.Art!
BrassFalls mf 8 35 57 S.Art!
BrassBand 0 123 57 Live!
SoftHorns 0 117 61 Live!
SoftTrombones 0 118 61 Live!
BrassShake 8 32 57 S.Art!
AccentFalls 8 38 57 S.Art!
Sforzando 0 105 62 Live!
SforzandoFall 0 107 62 Live!
SymphonyHorns 0 115 61 Live!
BrassDynamics 0 106 62 Live!
PopBrass 0 117 63 Live!
HyperBrass 0 118 63 Live!
SmallBrass 0 120 61 Live!
BallroomBrass 0 113 60 Regular
OctaveBrass 0 116 63 Live!
OberBrass 0 113 64 Regular
ThinthBrass 104 0 63 Regular
BrassProfit 104 1 63 Regular
MSB LSB
(1–128)
PC#
Voice Type
PSR-A3000 Data List
Program Change
3
Voice List / Voice-Liste / Liste des voix / Lista de voces
Category Voice Name
Brass SlowPWMBr ass 104 2 63 Regular
Woodwind Saxophone 8 32 83 S.Art!
Choir&Pad GospelVoices 0 116 53 Live!
PSR-A3000 Data List
4
FastPWMBrass 104 6 63 Regular
SoftVelocityBrass 0 120 63 Regular
80sBrass 0 113 63 Regular
AnalogBrass 0 112 64 Regular
SoftAnalog 0 114 64 Regular
FunkyAnalog 0 115 63 Regular
TechnoBrass 0 114 63 Regular
OberHorns 0 115 64 Regular
FatSynthBrass 0 116 64 Regular
BigBandSax 8 35 83 S.Art!
JazzTenorSax 0 125 67 Sweet!
PopTenor 0 127 67 Sweet!
BalladTenorSax 0 126 67 Sweet!
SopranoSax 0 113 65 Sweet!
AltoSax 0 114 66 Sweet!
TenorSax 0 117 67 Sweet!
RockSax 8 33 83 S.Art!
GrowlSax 0 111 67 Sweet!
SaxSection 0 116 67 Live!
SaxSectionSoft 0 121 67 Live!
SaxSectionHard 0 122 67 Live!
SaxAppeal 0 123 67 Live!
BigBandSaxes 0 110 67 Live!
BigBandUnison 0 109 67 Live!
BigBandOctave 0 108 67 Live!
Moonlight 0 115 72 Regular
BalladSection 0 119 67 Regular
BaritoneSax 0 112 68 Regular
OrchestralFlute 104 0 74 Sweet!
OrchestralOboe 104 0 69 Sweet!
OrchestralClarinet 104 0 72 Live!
OrchBassoon 104 0 71 Sweet!
GermanClarinet 104 2 72 Regular
Flutes&Oboes 104 2 74 Regular
Clarinet&Flutes 104 1 72 Regular
Clarinet&Oboe 104 1 69 Regular
DoubleReeds 104 2 69 Regular
OrchWoodwind 104 1 71 Regular
ClassicalFlute 0 115 74 Sweet!
ClassicalOboe 0 113 69 Sweet!
JazzClarinet 0 114 72 Sweet!
EnglishHorn 0 112 70 Regular
JazzFlute 0 114 74 Sweet!
Piccolo 0 112 73 Regular
BalladPanFlute 0 113 76 Sweet!
AltoFlutes 104 1 74 Regular
FluteEnsemble 0 116 74 Regular
DiZi 0 118 74 Regular
Sheng 0 116 110 Regular
Shakuhachi 0 112 78 Regular
Bagpipe 0 112 110 Regular
Recorder 0 112 75 Regular
Ocarina 0 112 80 Regular
Whistle 0 112 79 Regular
Humming 0 118 53 Live!
HahChoir 0 114 53 Regular
SweetHeaven 0 118 89 Regular
DreamHeaven 0 121 89 Regular
Mmh 0 117 53 Live!
GothicVox 0 113 54 Regular
BellHeaven 0 119 89 Regular
PanHeaven 0 120 89 Regular
ProHeaven 0 122 89 Regular
CrossPhase 104 1 102 Regular
GalaxyPad 104 3 89 Regular
NightMotion 104 4 89 Regular
MorningDew 104 0 95 Regular
Aerosp here 10 4 1 95 Regular
NewAtmosphere 104 4 90 Regular
VPSoft 104 0 90 Regular
HotSwell 104 2 96 Regular
MSB LSB
(1–128)
Program Change
PC#
Voice Type
Category Voice Name
Choir&Pad DarkFatSaw 104 2 90 Regular
VaporPad 104 1 90 Regular
SpaceRider 104 1 96 Regular
PearlsPad 104 2 89 Regular
BreathPad 104 0 92 Regular
NobleMan 104 1 89 Regular
DouxFlange 104 3 96 Regular
LightPad 104 2 52 Regular
ButterStrings 104 2 51 Regular
MediumTunePad 104 0 51 Reg ular
NylonPad 104 0 100 Regular
DarkLight 104 3 90 Regular
AnaDayz 104 3 52 Regular
BrightPadTrance 104 4 91 Regular
OctaveStrings 104 4 51 Regular
ChillinChords 104 6 52 Regular
BrightPopPad 104 3 51 Regular
PremiumPad 104 0 52 Regular
SoftEnsemble 104 1 51 Regular
80sPad 104 1 52 Regular
BrightPadClassic 104 3 91 Regular
AmbientPad 104 0 89 Regular
BrightFatSaw 104 5 91 Regular
Trance MW 104 0 96 Regular
EarlyDigital 104 0 94 Regular
Bellsphere 104 5 89 Regular
SixthSense 104 2 102 Regular
PercPad 104 0 102 Regular
SuperDarkPad 0 119 90 Regular
AnalogPad 0 120 90 Regular
DarkAngelPad 0 121 90 Regular
LitePad 0 122 90 Regular
PopPad 0 112 91 Regular
GloriousPhase 0 114 91 Regular
AnalogSwell 0 119 96 Regular
Skydiver 0 112 102 Regular
HipaStrings 0 114 96 Regular
BrightSawPad 0 113 91 Regular
BigOctavePad 0 115 91 Regular
GoldenAge 0 115 89 Regular
Solaris 0 114 95 Regular
Insomnia 0 113 95 Regular
Mediterrain 0 114 100 Regular
OberSweep 0 115 96 Regular
TimeTravel 0 116 89 Regular
Bubblespace 0 113 102 Regular
MagicBell 8 32 121 S.Art!
MellowPad 0 117 96 Regular
NeoWarmPad 0 115 90 Regular
CyberPad 0 113 100 Reg ular
BrightOber 0 113 96 Regular
DarkPad 0 118 96 Regular
Synth ClubLead 104 3 63 Regular
HandsUp! 104 21 91 Regular
Gemini 104 20 91 Regular
PunchyChordz 104 24 91 Regular
Skyline 0 115 85 Regular
Oxygen 0 122 82 Regular
Matrix 0 123 82 Regular
WireLead 0 120 82 Regular
SoftR&B 0 119 81 Regular
EarlyLead 0 118 82 Regular
LektroCodes 104 2 85 Regular
SoftSquare 104 5 81 Regular
WildPWM 104 4 81 Regular
DetunedVintage 104 1 85 Reg ular
PWMLead 104 1 82 Regular
SimpleComp 104 12 82 Regular
BalladComp 104 6 89 Regular
HeavenBell 104 0 101 Regular
BrightPadBell 104 7 89 Regular
ResonanceComp 104 4 63 Regular
HPFDance 104 0 91 Regular
DetunedSawOctave 104 8 82 Regular
MSB LSB
(1–128)
PC#
Voice Type
Program Change
Voice List / Voice-Liste / Liste des voix / Lista de voces
Category Voice Name
Synth DancyHook 104 9 82 Regular
TrancePerc 104 5 82 Regular
Chordmaster 104 13 82 Regular
DigitalSequence 104 2 88 Regular
AnalogSeq 104 3 88 Regular
TranceSeq1 104 4 88 Regular
TranceSeq2 104 5 88 Regular
TranceSeq3 104 1 91 Regular
FaaatComp 104 4 52 Regular
FatSawHook 104 7 52 Regular
DanceChords 104 5 52 Regular
DanceHook 0 112 87 Regular
OctaveHook 0 113 87 Regular
PunchyHook 0 127 82 Regular
HipaLead 0 118 85 Regular
CryingLead 0 114 88 Regular
MouthLead 104 0 82 Regular
PunchLead 104 7 82 Regular
PercSeqFS 104 6 88 Regular
PercSeqFM1 104 7 88 Regular
PercSeqFM2 104 8 88 Regular
PercSeqSaw 104 11 82 Regular
PercSeqHipa 104 9 88 Regular
SynthSticks 104 0 107 Regular
SazFeeze 104 0 98 Regular
EasternAir 104 1 98 Regular
Xtune 104 1 88 Regular
PitchFall 104 0 104 Regular
RSSawLead1 0 104 82 Regular
RSSawLead2 0 106 82 Regular
RSTechSaw 0 108 82 Regular
RSDualSaw 0 109 82 Regular
RSWarmPad 0 113 92 Regular
RSRampLead 0 107 82 Regular
RSDistortionLead 0 114 84 Regular
RSQuackLead 0 119 85 Regular
RSSynthPad 0 123 90 Regular
RSNoisePad 0 124 90 Regular
RSAnalogPad 0 126 90 Regular
RSDualSquare 0 127 81 Regular
RSTeknoMan 0 125 90 Regular
RSShortResonance 0 116 91 Regular
RSSync1 0 105 82 Regular
RSSync2 0 119 88 Regular
BriteDecay 104 5 85 Regular
PWMPercussion 104 6 82 Regular
VinalogSaw 104 3 82 Regular
Noise 0 120 123 Regular
Percussion Vibraphone 0 112 12 Regular
JazzVibes 0 113 12 Regular
Vibes&Flutes 0 114 12 Regular
Marimba 0 112 13 Regular
Xylophone 0 112 14 Regular
Vibes&JazzGuitar 8 33 12 S.Art!
Celesta 0 112 9 Regular
Glockenspiel 0 112 10 Regular
SteelDrums 0 112 115 Regular
TubularBells 0 112 15 Regular
Kalimba 0 112 109 Regular
Dulcimer 0 112 16 Regular
Timpani 0 112 48 Regular
StackBell 104 8 89 Regular
NiceBell 104 9 89 Regular
MusicBox 0 112 11 Regular
DrumKit A3000ArabicKit1 126 0 76 SFX
A3000ArabicKit2 126 0 78 SFX
A3000MaghrebiKit 126 0 75 SFX
A3000KhaligiKit1 126 0 73 SFX
A3000KhaligiKit2 126 0 74 SFX
A3000IranianKit1 126 0 77 SFX
A3000IranianKit2 126 0 79 SFX
ArabicMixKit 126 0 65 SFX
KhaligiMixKit 126 0 66 SFX
IranianMixKit 126 0 67 SFX
MSB LSB
(1–128)
PC#
Voice Type
Program Change
Category Voice Name
DrumKit TurkishPercKit1 126 0 10 SFX
TurkishPercKit2 126 0 11 SFX
TurkishPercKit3 126 0 12 SFX
TurkishPercKit4 126 0 13 SFX
2TelliKit 126 0 14 SFX
AnkaraKit 126 0 15 SFX
Ant-MrshKit 126 0 16 SFX
AzeriPerc 126 0 17 SFX
EthnicKit 126 0 18 SFX
DavulMixKit 126 0 19 SFX
DavulKit 126 0 20 SFX
RealDrums 127 0 92 Live!Drums
HouseKit 127 0 61 Drums
AcousticKit 127 0 90 Live!Drums
RockKit 127 0 91 Live!Drums
SymphonyKit 127 0 49 Live!Drums
BassDrumKit 126 0 21 SFX
ReverseBDKit 126 0 22 SFX
PowerKit1 127 0 88 Live!Drums
PowerKit2 127 0 89 Live!Drums
BrushKit 127 0 41 Live!Drums
AnalogT8Kit 127 0 59 Drums
AnalogT9Kit 127 0 60 Drums
BreakKit 127 0 58 Drums
HipHopKit 127 0 57 Drums
DanceKit 127 0 28 Drums
StudioKit 127 0 87 Live!Drums
HitKit 127 0 5 Drums
JazzKit 127 0 33 Drums
PopLatinKit 126 0 44 Live!SFX
RoomKit 127 0 9 Drums
ElectroKit 127 0 25 Drums
AnalogKit 127 0 26 Drums
CubanKit 126 0 41 Live!SFX
TurkishKit 126 0 68 Live!SFX
IndianKit 126 0 115 SFX
ChineseKit 126 0 125 SFX
ChineseMixKit 127 0 128 SFX
SFX Kit1 126 0 1 SFX
SFX Kit2 126 0 2 SFX
NoisesKit 126 0 9 SFX
Oriental OudTremolo 8 34 22 S.Art!
KanounTremolo 8 43 112 S.Art!
WtarTremolo 8 33 105 S.Art!
SanturTremolo 8 32 16 S.Art!
Kamancheh 8 44 78 S.Art!
Nay 8 34 78 S.Art!
KawalaVibrato 8 33 78 S.Art!
MejwizLegato 8 34 112 S.Art!
ZokraLegato 8 36 112 S.Art!
MenjayraTrill 104 5 78 Regular
WtarSlap 8 32 105 S.Art!
Ta rTr e mo l o 8 3 4 1 0 5 S . Ar t !
MezwedLegato 8 40 112 S.Art!
MezwedLegatoGrace 8 39 112 S.Ar t!
KamanchehVibrato 8 43 78 S.Art!
Nay8Va1 8 35 78 S.Ar t!
Nay8Va2 8 36 78 S.Ar t!
Chabbabi 8 42 78 S.Art!
Kawala 8 32 78 S.Art!
MizmarLegato 8 38 112 S.Art!
AkustikBaglamaTrem 8 36 22 S.Art!
EsikAltiBaglamaTrem 8 37 22 S.Art!
UdVibrato 8 38 22 S.Art!
Ta rTr e mo l o 2 8 39 1 05 S. Ar t !
KemenceTrill 104 13 111 Live!
NeyGrace 8 48 78 S.Art!
TulumTremolo 8 45 112 S.Art!
Garmon 104 7 22 Regular
Klarnet 104 7 72 Regular
KavalGrace 8 49 78 S.Art!
OudTremolo 104 2 106 Regular
AzeriTar 104 15 106 Regular
Ghopooz 104 18 106 Regular
MSB LSB
(1–128)
PC#
Voice Type
PSR-A3000 Data List
Program Change
5
Voice List / Voice-Liste / Liste des voix / Lista de voces
Category Voice Name
Oriental YayliStaccato 8 47 49 S.Art!
GrupYayliStaccato 8 48 49 S.Art!
NayVibrato 8 37 78 S.Art!
NeyAnbanLegato 8 42 112 S.Art!
NeyAnbanLegTrem 8 41 112 S.Art!
MizmarLegatoTrill 8 37 112 S.Art!
ZokraLegatoTrill 8 35 112 S.Art!
KanounTremolo 104 1 108 Regular
KanounTrill 104 9 108 Regular
AzeriTarTremolo 104 14 106 Regular
GhopoozTremolo 104 19 106 Regular
ElektroBaglama 8 39 22 S.Art!
Balaban 8 34 71 S.Art!
BalabanSwell 8 32 71 S.Ar t!
KawalaTrill 104 8 78 Sweet!
ZurnaLegato 8 33 112 S.Art!
ZurnaLegatoTrill 8 32 112 S.Art!
KabakKemaneGrace 8 50 78 S.Art!
KanunTremolo 8 44 112 S.Art!
Baghlama 10411106Regular
BaghlamaTremolo 104 10 106 Regular
Watariat1 104 2 49 Live!
Mey 104 25 74 Sweet!
Zurna 104 14 112 Live!
AlgerianZurna 104 11 112 Regular
KabaZurna 104 13 112 Sweet!
Watariat2 104 3 49 Live!
Watariat3 104 4 49 Live!
Watariat4 104 5 49 Live!
Watariat5 104 7 49 Live!
Watariat6 104 8 49 Live!
Watariat7 104 9 49 Live!
Watariat8 104 10 49 Live!
Watariat9 104 11 49 Live!
OrganFlutes OrganFlutes 10 0 9 OrganFlutes
USDSmile 10 1 9 OrganFlutes
ReggaeBars 10 2 9 OrganFlutes
WarmTheatre 10 3 9 OrganFlutes
OrganPops 10 4 9 OrganFlutes
RockOrgan 10 5 9 OrganFlutes
SoulPercussion 10 6 9 OrganFlutes
GospelTruth 10 7 9 OrganFlutes
PadOrgan 10 8 9 OrganFlutes
FullOrgan 10 9 9 OrganFlutes
StringBars 10 0 10 OrganFlutes
LatinSpin 10 1 10 OrganFlutes
ShadyBars 10 2 10 OrganFlutes
FunkOrgan 10 3 10 OrganFlutes
BalladOrgan 10 4 10 OrganFlutes
RichBars 10 5 10 OrganFlutes
TrumpetBars 10 6 10 OrganFlutes
SoulBars 10 7 10 OrganFlutes
ClariBars 10 8 10 OrganFlutes
JazzSquabble 10 9 10 OrganFlutes
MSB LSB
(1–128)
PC#
Voice Type
Program Change
PSR-A3000 Data List
6
Category: Legacy
Sub Category Voice Name
Piano MIDIGrand 0 112 3 Regular
BalladStack 0 1143Regular
Harpsichord 0 112 7 Live!
E.Piano ChorusBell01206Regular
FunkEP 0 112 5 Regular
HyperTines 0 113 6 Regular
JazzChorus 0 118 6 Regular
ModernEP 0 115 6 Regular
NewTines 0 116 6 Regular
PhaseEP 0 120 5 Regular
DXModern 0 112 6 Regular
PolarisEP 0 115 5 Regular
SuperDX 0 117 6 Regular
VenusEP 0 114 6 Regular
StereoClavi 0 114 8 Regular
Organ Kinura8' 0 123 17 Regular
ReedOrgan 0 112 21 Regular
Tibia16'&4'Acmp 0 114 17 Regular
Tibia8'Acmp 0 122 18 Regular
Tibia8'&4'Acmp 0 122 17 Regular
TibiaFullAcmp 0 114 18 Regular
Trumpet16'&8' 0 124 18 Regular
Trumpet8' 0 124 17 Regular
Vox8'Acmp 0 123 18 Regular
Vox&TibiaAcmp 0 125 17 Regular
BrightDrawbar 0 116 17 Regular
ClickOrgan 0 112 18 Regular
DanceOrgan 0 113 18 Regular
DrawbarOrgan1 0 120 18 Regular
DrawbarOrgan2 0 115 17 Regular
ElectricOrgan 0 118 18 Regular
FullRocker2 104 3 19 Cool!
GospelOrgan 0 119 17 Regular
JazzOrgan1 0 112 17 Regular
JazzOrgan2 0 113 17 Regular
JazzOrgan3 0 120 17 Regular
PercOrgan 0 119 18 Regular
PurpleOrgan 0 114 19 Regular
RockOrgan1 0 112 19 Regular
RockOrgan2 0 119 19 Regular
RockOrgan3 0 113 19 Regular
RotaryDrive 0 116 19 Regular
RotarySwitch 0 110 18 Cool!
60sOrgan 0 116 18 Regular
ClassicJazz 0 126 17 OrganFlutes
Accordion Accordion 0 116 22 Regular
BallroomAcc 0 112 24 Regular
MusetteAccordion 0 112 22 Regular
SmallAccordion 0 115 22 Regular
SoftAccordion 0 114 22 Regular
TuttiAccordion 0 113 22 Regular
Guitar DynamicNylon 0 116 25 Live!
SlideNylon 0 117 25 Live!
DynamicSteel 0 116 26 Live!
SlideSteel 0 118 26 Live!
18StringGuitar 0 119 26 Regular
CampfireGuitar 0 115 26 Regular
FolkGuitar 0 112 26 Regular
JazzGuitar 0 115 27 Cool!
JazzSoloGuitar 0 116 27 Cool!
DXJazzGuitar 0 117 27 Regular
OctaveGuitar 0 113 27 Regular
70sSolidGuitar 8 38 4 S.Art!
CleanElectric 8 35 4 S.Art!
WarmElectric 8324S.Art!
70sSolidGuitar 104 1 28 Cool!
BalladSolid 0 109 28 Cool!
ChorusSolid 0 107 28 Cool!
CleanGuitar 0 112 28 Cool!
CleanSolid 104 3 28 Cool!
ElectricGuitar 0 114 29 Cool!
FunkGuitar 0 116 29 Cool!
SlapSolid 0 108 28 Cool!
SlideClean 0 117 29 Cool!
Program Change
MSB LSB
PC#
(1–128)
Voice Type
Voice List / Voice-Liste / Liste des voix / Lista de voces
Program Change
Sub Category Voice Name
Guitar SlideSolid 0 110 28 Cool!
TremoloSolid 0 111 28 Cool!
WarmSolid 104 2 28 Cool!
60sCleanGuitar 0 117 28 Regular
BrightClean 0 116 28 Regular
ChorusGuitar 0 124 28 Regular
DeepChorus 0 114 28 Regular
Electric12String 0 119 28 Regular
FunkGuitar 0 113 29 Regular
MutedGuitar 0 112 29 Regular
SolidChord 0 121 28 Regular
SolidGuitar 0 118 28 Reg ular
TremoloGuitar 0 113 28 Regular
VintageMuteEcho 0 115 29 Regular
VintageOpen 0 123 28 Regular
VintageStrum 0 126 28 Regular
VintageTrem 0 120 28 Regular
WahGuitar 0 122 28 Regular
BluesGuitar 0 117 30 Cool!
CrunchGuitar 0 113 31 Regular
DistortionGuitar 0 112 31 Regular
Feedbacker 8 33 5 S.Art!
FeedbackGuitar 0 113 30 Regular
GuitarHero 104 0 31 Cool!
HeavyRock 8 32 5 S.Art!
HeavyRock 104 1 31 Cool!
HeavyStack 0 114 31 Regular
MetalMaster 0 120 31 Regular
PowerChord 0 117 31 Regular
PowerLead 0 115 31 Cool!
VodooLead 0 116 31 Regular
HalfDrive 104 0 30 Cool!
LeadGuitar 0 114 30 Regular
OverdriveGuitar 0 112 30 Regular
RockGuitar 0 116 30 Regular
SmoothLead 0 119 27 Regular
VintageAmp 0 115 30 Regular
VintageLead 0 125 28 Cool!
PedalSteel 0 115 28 Regular
Bass 80sSynthBass 0 115 40 Regular
AnalogBass 0 112 40 Regular
ClickBass 0 115 39 Regular
DrySynthBass 0 116 40 Regular
DXFunkBass 0 113 38 Regular
HiQBass 0 113 39 Regular
PunchyBass 0 117 39 Regular
Strings BowStrings 0 116 49 Regular
ConcertoStrings 0 115 49 Regular
Marcato 0 115 50 Regular
Orchestra 0 116 50 Live!
OrchStrings 0 113 49 Regular
Pizzicato 0 112 46 Regular
SlowStrings 0 113 50 Regular
StringFalls 0 121 49 Live!
StringQuartet 0 114 50 Reg ular
Strings 0 112 49 Regular
Symphonic 0 114 49 Regular
TremoloStrings 0 112 45 Regular
Orchestra&Flute 0 119 50 Regular
Orchestra&Horns 0 118 50 Regular
Orchestra&Oboe 0 121 50 Regular
Harp 0 112 47 Regular
Sitar2 0 112 105 Regular
AnalogStrings 0 112 52 Regular
Brass JazzTrumpet 0 116 57 Regular
SoloTrumpet 0 112 57 Regular
MutedTrumpet 0 112 60 Regular
FlugelHorn 0 113 57 Regular
MellowTrombone 0 114 58 Regular
SmoothTrombone 0 118 58 Regular
SoftTrombone 0 115 58 Regular
SoloTrombone 0 112 58 Regular
Trombone 0 116 58 Regular
Tuba2 0 112 59 Regular
MSB LSB
(1–128)
PC#
Voice Type
PSR-A3000 Data List
7
Voice List / Voice-Liste / Liste des voix / Lista de voces
Category: Legacy
Sub Category Voice Name
Brass BigBandBrass 0 113 62 Regular
Woodwind SopranoSax 0 112 65 Regular
Choir&Pad AirChoir 0 112 55 Regular
Synth Adrenaline 0 113 85 Regular
PSR-A3000 Data List
8
BigBrass 0 121 62 Regular
BrassCombo 0 115 67 Regular
BrassHit 0 126 62 Regular
BrassSection 0 112 62 Regular
BreathBrass 0 116 61 Regular
BrightBrass 0 120 62 Regular
FullHorns 0 114 62 Regular
HighBrass 0 115 62 Regular
MellowBrass 0 116 62 Regular
NaturalBrass 0 124 62 Regular
Sforzando 0 125 62 Regular
SmallBrass 0 117 62 Regular
SoftBrass 0 123 62 Regular
TrumpetEns 0 122 62 Regular
MellowHorns 0 119 62 Regular
TromboneSection 0 113 58 Regular
HybridComp 0 119 63 Regular
Hybrihorn 0 113 61 Regular
Hybripad 0 114 61 Regular
PopBrass 0 118 62 Regular
SynthBrass 0 112 63 Regular
AltoSax 0 112 66 Regular
GrowlSax 0 118 67 Regular
Saxophone 104 0 67 Sweet!
TenorSax 0 112 67 Regular
SaxStack 0 124 67 Regular
SaxyMood 0 120 67 Regular
Flute 0 112 74 Regular
Oboe 0 112 69 Regular
Clarinet 0 112 72 Regular
Bassoon 0 112 71 Regular
WoodwindsEns 0 113 67 Regular
ChiffPanFlute 0 113 74 Regular
EthnicFlute 0 112 76 Regular
Choir 0 112 53 Regular
UuhChoir 0 115 53 Regular
Voices 0 113 55 Regular
VoxHumana 0 112 54 Regular
AngelVibes 0 114 99 Regular
Area51 0 112 90 Regular
Atmosphere 0 112 100 Regular
DarkMoon 0 113 90 Regular
DigitalPad 0 115 94 Regular
Disclosure 0 116 90 Regular
Dunes 0 114 90 Regular
DXPad 0 112 93 Regular
Equinox 0 112 95 Regular
EveningStars 0 117 102 Regular
Fantasia 0 112 89 Regular
FarEast 0 112 98 Regular
GlassPad 0 114 94 Regular
HahPad 0 116 95 Regular
Ionosphere 0 115 95 Regular
Messenger 0 116 96 Regular
Millennium 0 117 89 Regular
Mystery 0 113 98 Regular
PsychoPad 0 118 102 Regular
S&HGroove 0 115 102 Regular
Sirius 0 114 102 Regular
Stargate 0 114 89 Regular
Sunbeam 0 123 89 Regular
Symbiont 0 113 89 Regular
VelocityAshrami 0 116 102 Regular
Wave2001 0 112 96 Regular
XenonPad 0 112 92 Regular
AeroLead 0 112 84 Regular
Analogon 0 115 82 Regular
Attack 104 4 82 Regular
AttackSaw 0 126 82 Regular
BigLead 0 113 82 Regular
Program Change
MSB LSB
(1–128)
PC#
Voice Type
Sub Category Voice Name
Synth BigTune 0 118 90 Regular
Blaster 0 114 82 Regular
BleepLead 104 0 85 Regular
BrassHit 0 113 56 Regular
BrassyLead 104 5 63 Regular
BrightMini 0 125 81 Regular
ChorusSawLead 104 10 82 Regular
CrystalEyes 0 125 89 Regular
Fargo 0 119 82 Regular
FireWire 0 116 82 Regular
FlangeFilter 104 2 82 Regular
FunkyLead 0 121 82 Regular
FusionLead 104 15 82 Regular
HiBias 0 116 81 Regular
HipLead 0 113 81 Regular
HopLead 0 117 81 Regular
Impact 0 113 88 Regular
LFOPad 0 104 102 Regular
LFOSync1 0 108 102 Regular
LFOSync2 0 107 102 Regular
LFOSync3 0 109 102 Regular
LFOSync4 0 106 102 Regular
LFOSync5 0 105 102 Regular
MelodyMaker 0 117 90 Regular
MiniLead 0 114 81 Regular
Nomad 104 1 105 Regular
OrbitSine 0 126 81 Regular
Padbells 0 126 89 Regular
PanLead 0 122 81 Regular
Paraglide 0 114 85 Regular
PercSquare 0 123 81 Regular
PopLead 0 120 81 Regular
Portatone 0 112 85 Regular
ProLead 0 113 84 Regular
ResonantClavi 104 2 91 Regular
Robolead 0 124 82 Regular
SawLead 0 112 82 Regular
SoftMini 0 124 81 Regula r
SoftSaw 104 16 82 Regular
SquareLead 0 112 81 Regular
Stardust 0 112 99 Regular
StringBells 0 124 89 Regular
SubLead 104 0 81 Regular
SunBell 0 113 99 Regular
TalkModLead 104 0 88 Regular
TechGlide 104 14 82 Regular
TechLead 0 117 85 Regular
Tekkline 0 116 85 Regular
TinyLead 0 118 81 Regular
TranceLead 0 121 81 Regular
TrumpetSaw 0 125 82 Regular
UnderHeim 0 112 88 Regular
VinylLead 0 115 81 Regular
Warp 0 1 17 82 Regula r
DrumKit ArabicKit1 126 0 37 SFX
ArabicKit2 126 0 36 SFX
KhaligiKit 126 0 38 SFX
IranianKit 126 0 39 SFX
StandardKit1 127 0 1 Live!Drums
StandardKit2 127 0 2 Live!Drums
RockKit 127 0 17 Drums
Oriental AccordionOR 0 124 22 Regular
Gerba 0 117 112 Regular
GerbaChorus 0 121 112 Regular
AlBadou 0 120 112 Regular
Argoul 0 118 112 Regular
Balaban 104 5 71 Sweet!
BalabanSoft 104 2 71 Sweet!
BalabanStrong 104 3 71 Sweet!
BalabanSwellSoft 104 4 71 Sweet!
BalabanSwellStrong 104 6 71 Sweet!
Chabbabi 104 6 78 Regular
Dosaleh 0 112 112 Regular
KavalTrill 104 26 74 Sweet!
MSB LSB
(1–128)
PC#
Voice Type
Program Change
Category: Legacy
Sub Category Voice Name
Oriental Kawala1 104 7 78 Regular
Kawala2 104 9 78 Sweet!
Kawala3 0 113 78 Sweet!
Mejwiz 104 0 112 Regular
Menjayra 104 3 78 Regular
MenjayraOverblow 104 4 78 Regular
Mijwez 0 115 112 Regular
Mizmar1 104 1 112 Regular
Mizmar2 0 116 112 Regular
MizmarOctave 0 119 112 Regular
MizmarTrill 104 2 112 Regular
Mizwed 104 3 112 Regular
MizwedGrace 104 4 112 Regular
Nay1 104 11 78 Regular
Nay2 0 114 78 Regular
Nay3 0 115 78 Regular
NayFlutter 104 1 78 Sweet!
NayOverblow 104 2 78 Sweet!
Nay 104 0 78 Sweet!
NayTakasim 0 116 78 Regular
NeyGrace 104 24 74 Regular
NeyAnbaban 104 10 112 Regular
NeyAnbanTrill 104 9 112 Regular
Sorna1 0 122 112 Regular
Sorna2 0 113 112 Regular
Surnay 0 114 112 Regular
TulumTremolo 104 12 112 Regular
Zokra 104 5 112 Regular
ZokraTrill 104 6 112 Regular
Zurna 104 7 112 Regular
ZurnaTrill 104 8 112 Regular
Awtar1 0 117 106 Regular
Awtar2 0 118 106 Regular
AzeriTarSoft 104 16 106 Regular
AzeriTarStrong 104 17 106 Regular
BaghlamaSoft 10412106Regular
BaghlamaStrong 10413106Regular
Baglamas 0 116 106 Regular
AkustikBaglamaTrem 104 41 106 Regular
EsikAltiBaglamaTrem 104 42 106 Regular
ElektroBaglamaTrem 104 15 81 Regular
Bouzouk 0 122 26 Regular
Bouzouki 0 123 26 Regular
Oud1 104 1 106 Regular
Oud2 0 113 106 Regular
OudTremolo 0 115 106 Regular
UdTremolo 104 43 106 Regular
Saz 0 121 26 Regular
Sentir 104 3 33 Regular
Tar1 104 6 106 Regular
Tar2 0 114 106 Regular
TarSoft 104 9 106 Regular
TarStrong 104 8 106 Regular
TarTremolo1 104 7 106 Regular
TarTremolo2 104 44 106 Regular
Wtar 104 4 106 Regular
WtarSlap 104 3 106 Regular
WtarTremolo 104 5 106 Regular
KabakKemaneGrace 104 12 111 Regular
Kamancheh1 104 8 111 Live!
Kamancheh2 104 11 111 Live!
KamanchehGrace 104 9 111 Live!
KamanchehPizzicato 104 0 46 Live!
KamanchehSoft 104 1 111 Live!
KamanchehStrong 104 2 111 Live!
KamanchehTrill 104 10 111 Live!
KamanchehVibrato 104 0 111 Live!
Kamanche 0 114 41 Regular
Rababa 0 115 41 Regular
Kanoun1 104 0 108 Regular
Kanoun2 0 113 108 Regular
KanounOctave 0 114 108 Regular
KanunTremolo 104 10 108 Regular
Santoor 0 113 16 Regular
Program Change
MSB LSB
PC#
(1–128)
Voice Type
Voice List / Voice-Liste / Liste des voix / Lista de voces
Program Change
Sub Category Voice Name
Oriental Santur 104 2 16 Regular
SanturTremolo 104 3 16 Regular
Santuri 0 114 16 Regular
PizzicatoOctave 0 114 46 Regular
Watariyat1 0 125 49 Regular
Watariyat2 0 126 49 Regular
Watariyat3 0 127 49 Regular
Yayli 104 18 49 Regular
GrupYayliStaccato 104 19 49 Regular
Brass1 0 124 63 Regular
Brass2 0 122 63 Regular
Brass3 0 123 63 Regular
Solo1 0 111 81 Regular
Solo2 0 110 81 Regular
Solo3 0 109 81 Regular
Solo4 0 108 81 Regular
Solo5 0 107 81 Regular
MSB LSB
(1–128)
PC#
Voice Type
PSR-A3000 Data List
9
Voice List / Voice-Liste / Liste des voix / Lista de voces
Category: MegaVoices Category: GM&XG
Sub Category Voice Name
Guitar NylonGuitar 8 0 1 MegaVoice
Bass AcousticBass 8 0 17 MegaVoice
Strings LargeStrings 8 0 50 MegaVoice
Brass Trumpet 8 0 65 MegaVoice
Woodwind TenorSax 8 0 83 MegaVoice
PSR-A3000 Data List
10
12StringGuitar 8 1 3 MegaVoice
HiStringGuitar 8 0 3 MegaVoice
SteelGuitar 8 0 2 MegaVoice
CleanGuitar 8 0 4 MegaVoice
SingleCoilGuitar 8 3 4 MegaVoice
SolidGuitar1 8 1 4 MegaVoice
SolidGuitar2 8 2 4 MegaVoice
JazzGuitar 8 0 7 MegaVoice
DistortionGuitar 8 0 6 MegaVoice
OverdriveGuitar 8 0 5 MegaVoice
ElectricBass 8 0 18 MegaVoice
PickBass 8 0 19 MegaVoice
VintageFlat 8 2 18 MegaVoice
VintagePick 8 1 19 MegaVoice
VintageRound 8 1 18 MegaVoice
FretlessBass 8 0 20 MegaVoice
SmallStrings 8 0 49 MegaVoice
Brass 8 0 57 MegaVoice
Program Change
MSB LSB
PC#
(1–128)
Voice Type
Sub Category Voice Name
Piano GrandPiano 0 0 1 Regular
ChromaticPerc Celesta 0 0 9 Regular
Organ DrawbarOrgan 0 0 17 Regular
Program Change
Voice Type
MSB LSB
GrandPiano KSP 0 1 1 Regular
MellowGrandPiano 0 18 1 Regular
PianoStrings 0 40 1 Regular
Dream 0 41 1 Regular
BrightPiano 0 0 2 Regular
BrightPiano KSP 0 1 2 Regular
El.GrandPiano 0 0 3 Regular
El.GrandPiano KSP 0 1 3 Regular
DetunedCP80 0 32 3 Regular
LayeredCP1 0 40 3 Regular
LayeredCP2 0 41 3 Regular
Honkytonk 0 0 4 Regular
Honkytonk KSP 0 1 4 Regular
ElectricPiano1 0 0 5 Regular
ElectricPiano1 KSP 0 1 5 Regular
MellowElectricPiano 0 18 5 Regular
ChorusEP1 0 32 5 Regular
HardElectricPiano 0 40 5 Reg ular
VXfadeEl.Piano1 0 45 5 Regular
60sElectricPiano1 0 64 5 Regular
ElectricPiano2 0 0 6 Regular
ElectricPiano2 KSP 0 1 6 Regular
ChorusEP2 0 32 6 Regular
DXEPHard 0 33 6 Regular
DXLegend 0 34 6 Regular
DXPhaseEP 0 40 6 Regular
DX+AnalogEP 0 41 6 Regular
DXKotoEP 0 42 6 Regular
VXfadeEl.Piano2 0 45 6 Regular
Harpsichord 0 0 7 Regular
Harpsichord KSP 0 1 7 Regular
Harpsichord2 0 25 7 Regular
Harpsichord3 0 35 7 Regular
Clavi 0 0 8 Regular
Clavi KSP 0 1 8 Regular
ClaviWah 0 27 8 Regular
PulseClavi 0 64 8 Regular
PierceClavi 0 65 8 Regular
Glockenspiel 0 0 10 Regular
MusicBox 0 0 11 Regular
MusicBox2 0 64 11 Regular
Vibraphone 0 0 12 Regular
Vibraphone KSP 0 1 12 Regular
HardVibes 0 45 12 Regular
Marimba 0 0 13 Regular
Marimba KSP 0 1 13 Regular
SineMarimba 0 64 13 Regular
Balimba 0 97 13 Regular
LogDrums 0 98 13 Regular
Xylophone 0 0 14 Regular
TubularBells 0 0 15 Regular
ChurchBells 0 96 15 Regular
Carillon 0 97 15 Regular
Dulcimer 0 0 16 Regular
Dulcimer2 0 35 16 Regular
Cimbalom 0 96 16 Regular
Santur 0 97 16 Reg ular
DetunedDrawOrgan 0 32 17 Regular
60sDrawbarOrgan1 0 33 17 Regular
60sDrawbarOrgan2 0 34 17 Regular
70sDrawbarOrgan1 0 35 17 Regular
DrawbarOrgan2 0 36 17 Regular
60sDrawbarOrgan3 0 37 17 Regular
EvenBarOrgan 0 38 17 Regular
16+2'2_3Organ 0 40 17 Regular
OrganBass 0 64 17 Regular
70sDrawbarOrgan2 0 65 17 Regular
CheezyOrgan 0 66 17 Regular
DrawbarOrgan3 0 67 17 Regular
PercussiveOrgan1 0 0 18 Regular
70sPercussiveOrgan1 0 24 18 Regular
PC#
(1–128)
Category: GM&XG
Sub Category Voice Name
Organ DetunedPercOrgan 0 32 18 Regular
LightOrgan 0 33 18 Regular
PercussiveOrgan2 0 37 18 Regular
RockOrgan 0 0 19 Regular
RotaryOrgan 0 64 19 Regular
SlowRotary 0 65 19 Regular
FastRotary 0 66 19 Regular
ChurchOrgan 0 0 20 Regular
ChurchOrgan3 0 32 20 Regular
ChurchOrgan2 0 35 20 Regular
NotreDame 0 40 20 Regular
OrganFlute 0 64 20 Regular
TremoloOrganFlute 0 65 20 Regular
ReedOrgan 0 0 21 Regular
PuffOrgan 0 40 21 Regular
Accordion 0 0 22 Regular
Accordion Italian 0 32 22 Regular
Harmonica 0 0 23 Regular
Harmonica2 0 32 23 Regular
TangoAccordion 0 0 24 Regular
TangoAccordion2 0 64 24 Regular
Guitar NylonGuitar 0 0 25 Regular
NylonGuitar2 0 16 25 Regular
NylonGuitar3 0 25 25 Regular
VelocityGtHarmo 0 43 25 Regular
Ukulele 0 96 25 Regular
SteelGuitar 0 0 26 Regular
SteelGuitar2 0 16 26 Regular
12StrGuitar 0 35 26 Regular
Nylon&Steel 0 40 26 Regular
Steel&Body 0 41 26 Regular
Mandolin 0 96 26 Regular
JazzGuitar 0 0 27 Regular
MellowGuitar 0 18 27 Regular
JazzAmp 0 32 27 Regular
CleanGuitar 0 0 28 Regular
ChorusGuitar 0 32 28 Regular
MutedGuitar 0 0 29 Regular
FunkGuitar1 0 40 29 Regular
MuteSteelGuitar 0 41 29 Regular
FunkGuitar2 0 43 29 Regular
JazzMan 0 45 29 Regular
Overdriven 0 0 30 Regular
GuitarPinch 0 43 30 Regular
DistortionGuitar 0 0 31 Regular
FeedbackGuitar 0 40 31 Regular
FeedbackGuitar2 0 41 31 Regular
GuitarHarmonics 0 0 32 Regular
GuitarFeedback 0 65 32 Regular
GuitarHarmonics2 0 66 32 Regular
Bass AcousticBass 0 0 33 Regular
JazzRhythm 0 40 33 Regular
VXUprghtBass 0 45 33 Regular
FingerBass 0 0 34 Regular
FingerBassDark 0 18 34 Regular
FlangeBass 0 27 34 Regular
Bass&DistortionEG 0 40 34 Regular
FingerSlapBass 0 43 34 Regular
FingerBass2 0 45 34 Regular
ModulatedBass 0 65 34 Regular
PickBass 0 0 35 Regular
MutePickBass 0 28 35 Regular
FretlessBass 0 0 36 Regular
FretlessBass2 0 32 36 Regular
FretlessBass3 0 33 36 Regular
FretlessBass4 0 34 36 Regular
SynthFretless 0 96 36 Regular
SmthFretless 0 97 36 Regular
SlapBass1 0 0 37 Regular
ResonantSlap 0 27 37 Regular
PunchThumb 0 32 37 Regular
SlapBass2 0 0 38 Regular
VelocitySwitchSlap 0 43 38 Regular
SynthBass1 0 0 39 Regular
Program Change
MSB LSB
PC#
(1–128)
Voice Type
Voice List / Voice-Liste / Liste des voix / Lista de voces
Program Change
Sub Category Voice Name
Bass SynthBass1 Dark 0 18 39 Regular
FastResonantBass 0 20 39 Regular
AcidBass 0 24 39 Regular
ClaviBass 0 35 39 Regular
TechnoBass 0 40 39 Regular
Orbiter 0 64 39 Regular
SquareBass 0 65 39 Regular
RubberBass 0 66 39 Regular
Hammer 0 96 39 Reg ular
SynthBass2 0 0 40 Regular
MellowSynthBass 0 6 40 Regular
SequenceBass 0 12 40 Regular
ClickSynthBass 0 18 40 Regular
SynthBass2 Dark 0 19 40 Regular
SmoothSynthBass 0 32 40 Regular
ModulrSynthBass 0 40 40 Regular
DXBass 0 41 40 Regular
XWireBass 0 64 40 Regular
Strings Violin 0 0 41 Reg ular
SlowAttackViolin 0 8 41 Regular
Viola 0 0 42 Reg ular
Cello 0 0 43 Regular
Contrabass 0 0 44 Regular
TremoloStrings 0 0 45 Regular
SlwAtkTremStrings 0 8 45 Regular
SuspenseStrings 0 40 45 Regular
PizzicatoStrings 0 0 46 Regular
OrchestralHarp 0 0 47 Regular
YangQin 0 40 47 Regular
Timpani 0 0 48 Regular
Ensemble Strings1 0 0 49 Regular
StereoStrings 0 3 49 Regular
SlwAttackStrings 0 8 49 Regular
ArcoStrings 0 24 49 Regular
60sStrings 0 35 49 Regular
Orchestra 0 40 49 Regular
Orchestra2 0 41 49 Regular
TremoloOrchstra 0 42 49 Regular
VelocityStrings 0 45 49 Regular
Strings2 0 0 50 Regular
StereoSlowStrings 0 3 50 Reg ular
LegatoStrings 0 8 50 Regular
WarmStrings 0 40 50 Regular
Kingdom 0 41 50 Regular
70sStrings 0 64 50 Regular
Strings3 0 65 50 Regular
SynthStrings1 0 0 51 Regular
ResonantStrings 0 27 51 Regular
SynthStrings4 0 64 51 Regular
SynthStrings5 0 65 51 Regular
SynthStrings2 0 0 52 Regular
ChoirAahs 0 0 53 Regular
StereoChoir 0 3 53 Regular
ChoirAahs2 0 16 53 Regular
MellowChoir 0 32 53 Regular
ChoirStrings 0 40 53 Regular
VoiceOohs 0 0 54 Regular
SynthVoice 0 0 55 Regular
SynthVoice2 0 40 55 Regular
Choral 0 41 55 Regular
AnalogVoice 0 64 55 Regular
OrchestraHit 0 0 56 Regular
OrchestraHit2 0 35 56 Regular
Impact 0 64 56 Regular
Brass Trumpet 0 0 57 Regular
Trumpet2 0 16 57 Regular
BrightTrumpet 0 17 57 Regular
WarmTrumpet 0 32 57 Regular
Trombone 0 0 58 Regular
Trombone2 0 18 58 Regular
Tub a 0 0 59 Re gu la r
Tub a2 0 1 6 59 Re gu la r
MutedTrumpet 0 0 60 Regular
FrenchHorn 0 0 61 Regular
MSB LSB
(1–128)
PC#
Voice Type
PSR-A3000 Data List
11
Voice List / Voice-Liste / Liste des voix / Lista de voces
Category: GM&XG
Sub Category Voice Name
Brass FrenchHornSolo 0 6 61 Regular
Reed SopranoSax 0 0 65 Regular
Pipe Piccolo 0 0 73 Regular
Synth.Lead SquareLead 0 0 81 Regular
PSR-A3000 Data List
12
FrenchHorn2 0 32 61 Regular
HornOrchestra 0 37 61 Regular
BrassSection 0 0 62 Regular
Tp&TbSection 0 35 62 Regular
BrassSection2 0 40 62 Regular
HighBrass 0 41 62 Regular
MellowBrass 0 42 62 Regular
SynthBrass1 0 0 63 Regular
QuackBrass 0 12 63 Regular
ResoSynthBrass 0 20 63 Regular
PolyBrass 0 24 63 Regular
SynthBrass3 0 27 63 Regular
JumpBrass 0 32 63 Regular
AnalogVeloBrass1 0 45 63 Regular
AnalogBrass1 0 64 63 Regular
SynthBrass2 0 0 64 Regular
SoftBrass 0 18 64 Regular
SynthBrass4 0 40 64 Regular
ChoirBrass 0 41 64 Regular
AnalogVeloBrass2 0 45 64 Regular
AnalogBrass2 0 64 64 Regular
AltoSax 0 0 66 Regular
SaxSection 0 40 66 Regular
HyperAltoSax 0 43 66 Regular
TenorSax 0 0 67 Regular
BreathyTenor 0 40 67 Regular
SoftTenorSax 0 41 67 Regular
TenorSax2 0 64 67 Regular
BaritoneSax 0 0 68 Regular
Oboe 0 0 69 Regular
EnglishHorn 0 0 70 Regular
Bassoon 0 0 71 Regular
Clarinet 0 0 72 Regular
Flute 0 0 74 Regular
Recorder 0 0 75 Regular
PanFlute 0 0 76 Regular
BlownBottle 0 0 77 Regular
Shakuhachi 0 0 78 Regular
Whistle 0 0 79 Regular
Ocarina 0 0 80 Regular
SquareLead2 0 6 8 1 Regular
LMSquare 0 8 81 Regular
Hollow 0 18 81 Regular
Shroud 0 19 81 Regular
Mellow 0 64 81 Regular
SoloSine 0 65 81 Regular
SineLead 0 66 81 Regular
SawtoothLead 0 0 82 Regular
SawtoothLead2 0 6 82 Regular
ThickSaw 0 8 82 Regular
DynamicSaw 0 18 82 Regular
DigitalSaw 0 19 82 Regular
BigLead 0 20 82 Regular
HeavySynth 0 24 82 Regular
WaspySynth 0 25 82 Regular
PulseSaw 0 40 82 Regular
Dr.Lead 0 41 82 Regular
VelocityLead 0 45 82 Regular
SequencedAnalog 0 96 82 Regular
CalliopeLead 0 0 83 Regular
PureLead 0 65 83 Regular
ChiffLead 0 0 84 Regular
Rubby 0 64 84 Regular
CharangLead 0 0 85 Regular
DistortedLead 0 64 85 Regular
WireLead 0 65 85 Regular
VoiceLead 0 0 86 Regular
SynthAahs 0 24 86 Regular
VoxLead 0 64 86 Regular
FifthsLead 0 0 87 Regular
Program Change
MSB LSB
PC#
(1–128)
Voice Type
Sub Category Voice Name
Synth.Lead BigFive 0 35 87 Regular
Bass&Lead 0 0 88 Regular
Big&Low 0 16 88 Regular
Fat&Perky 0 64 88 Regular
SoftWhirl 0 65 88 Regular
Synth.Pad NewAgePad 0 0 89 Regular
Fantasy 0 64 89 Regular
WarmPad 0 0 90 Regular
ThickPad 0 16 90 Regular
SoftPad 0 17 90 Regular
SinePad 0 18 90 Regular
HornPad 0 64 90 Regular
RotaryStrings 0 65 90 Regular
PolySynthPad 0 0 91 Regular
PolyPad80 0 64 91 Regular
ClickPad 0 65 91 Regular
AnalogPad 0 66 91 Regular
SquarePad 0 67 91 Regular
ChoirPad 0 0 92 Regular
Heaven 0 64 92 Regular
Itopia 0 66 92 Regular
CCPad 0 67 92 Reg ular
BowedPad 0 0 93 Regular
Glacier 0 64 93 Regular
GlassPad 0 65 93 Regular
MetallicPad 0 0 94 Regular
TinePad 0 64 94 Regular
PanPad 0 65 94 Regular
HaloPad 0 0 95 Regular
SweepPad 0 0 96 Regular
Shwimmer 0 20 96 Regular
Converge 0 27 96 Regular
PolarPad 0 64 96 Regular
Celestial 0 66 96 Regular
Synth.Effect Rain 0 0 97 Regular
ClaviPad 0 45 97 Regular
HarmoRain 0 64 97 Regular
AfricanWind 0 65 97 Regular
Carib 0 66 97 Regular
SoundTrack 0 0 98 Regular
Prologue 0 27 98 Regular
Ancestral 0 64 98 Regular
Crystal 0 0 99 Regular
SynthDrumComp 0 12 99 Regular
Popcorn 0 14 99 Regular
TinyBells 0 18 99 Regular
RoundGlocken 0 35 99 Regular
GlockenChime 0 40 99 Regular
ClearBells 0 41 99 Regular
ChorusBells 0 42 99 Regular
SynthMallet 0 64 99 Regular
SoftCrystal 0 65 99 Regular
LoudGlocken 0 66 99 Regular
ChristmasBells 0 67 99 Regular
VibraphoneBells 0 68 99 Regular
DigitalBells 0 69 99 Regular
AirBells 0 70 99 Reg ular
BellHarp 0 71 99 Regular
Gamelimba 0 72 99 Regular
Atmosphere 0 0 100 Regular
WarmAtmosphere 0 18 100 Regular
HollwRelease 0 19 100 Regular
NylonElectricPiano 0 40 100 Regular
NylonHarp 0 64 100 Regular
HarpVox 0 65 100 Regular
AtmospherePad 0 66 100 Regular
Planet 0 67 100 Regular
Brightness 0 0 101 Regular
FantasyBells 0 64 101 Regular
Smokey 0 96 101 Regular
Goblins 0 0 102 Regular
GoblinsSynth 0 64 102 Regular
Creeper 0 65 102 Regular
RingPad 0 66 102 Regular
MSB LSB
(1–128)
PC#
Voice Type
Program Change
Category: GM&XG
Sub Category Voice Name
Synth.Effect Ritual 0 67 102 Regular
ToHeaven 0 68 102 Regular
Night 0 70 102 Regular
Glisten 0 71 102 Regular
BellChoir 0 96 102 Regular
Echoes 0 0 103 Regular
Echoes2 0 8 103 Regular
EchoPan 0 14 103 Regular
EchoBells 0 64 103 Regular
BigPan 0 65 103 Regular
SynthPiano 0 66 103 Regular
Creation 0 67 103 Regular
Stardust 0 68 103 Regular
Resonant&Panning 0 69 103 Regular
ScienceFiction 0 0 104 Regular
Starz 0 64 104 Regular
Ethnic Sitar 0 0 105 Regular
DetunedSitar 0 32 105 Regular
Sitar2 0 35 105 Regular
Tam b ra 0 9 6 1 05 Re gu la r
Tam b ou r a 0 97 10 5 Re g ul a r
Banjo 0 0 106 Regular
MutedBanjo 0 28 106 Regular
Rabab 0 96 106 Regular
Gopichant 0 97 106 Regular
Oud 0 98 106 Regular
Shamisen 0 0 107 Regular
Koto 0 0 108 Regular
Taisho-kin 0 96 108 Regular
Kanoon 0 97 108 Regular
Kalimba 0 0 109 Regular
Bagpipe 0 0 110 Regular
Fiddle 0 0 111 Regular
Shanai 0 0 112 Regular
Shanai2 0 64 112 Regular
Pungi 0 96 112 Regular
Hichiriki 0 97 112 Regular
Percussive TinkleBell 0 0 113 Regular
Bonang 0 96 113 Regular
Altair 0 97 113 Regular
GamelanGongs 0 98 113 Regular
StereoGamlan 0 99 113 Regular
RamaCymbal 0 100 113 Regular
AsianBells 0 101 113 Regular
Agogo 0 0 114 Regular
SteelDrums 0 0 115 Regular
GlassPercussion 0 97 115 Regular
ThaiBells 0 98 115 Regular
Woodblock 0 0 116 Regular
Castanets 0 96 116 Regular
Tai k oD r um 0 0 1 1 7 R eg u la r
GranCassa 0 96 117 Regular
MelodicTom 0 0 118 Regular
MelodicTom2 0 64 118 Regular
RealTom 0 65 118 Regular
RockTom 0 66 118 Regular
SynthDrum 0 0 119 Regular
AnalogTom 0 64 119 Regular
ElectroPercussion 0 65 119 Regular
ReverseCymbal 0 0 120 Regular
SoundEffect GuitarFretNoise 0 0 121 Regular
BreathNoise 0 0 122 Regular
Seashore 0 0 123 Regular
BirdTweet 0 0 124 Regular
TelephoneRing 0 0 125 Regular
Helicopter 0 0 126 Regular
Applause 0 0 127 Regular
Gunshot 0 0 128 Regular
CuttingNoise 64 0 1 Regular
CuttingNoise2 64 0 2 Regular
StringSlap 64 0 4 Regular
FluteKeyClick 64 0 17 Regular
Shower 64 0 33 Regular
Thunder 64 0 34 Regular
Program Change
MSB LSB
PC#
(1–128)
Voice Type
Voice List / Voice-Liste / Liste des voix / Lista de voces
Program Change
Sub Category Voice Name
SoundEffect Wind 64 0 35 Regular
Stream 64 0 36 Regular
Bubble 64 0 37 Regular
Feed 64 0 38 Regular
Dog 64 0 49 Regular
Horse 64 0 50 Regular
BirdTweet2 64 0 51 Regular
Ghost 64 0 55 Regular
Maou 64 0 56 Regular
PhoneCall 64 0 65 Regular
DoorSqueak 64 0 66 Regular
DoorSlam 64 0 67 Regular
ScratchCut 64 0 68 Reg ular
ScratchSplit 64 0 69 Regular
WindChime 64 0 70 Regular
TelephoneRing2 64 0 71 Regular
CarEngineIgn 64 0 81 Regular
CarTiresSqel 64 0 82 Regular
CarPassing 64 0 83 Regular
CarCrash 64 0 84 Regular
Siren 64 0 85 Regular
Train 64 0 86 Regular
JetPlane 64 0 87 Regular
Starship 64 0 88 Regular
Burst 64 0 89 Regular
RollerCoaster 64 0 90 Regular
Submarine 64 0 91 Regular
Laugh 64 0 97 Regular
Scream 64 0 98 Regular
Punch 64 0 99 Reg ular
Heartbeat 64 0 100 Regular
FootSteps 64 0 101 Regular
MachineGun 64 0 113 Regular
LaserGun 64 0 114 Regular
Explosion 64 0 115 Regular
Firework 64 0 116 Regular
MSB LSB
(1–128)
PC#
Voice Type
PSR-A3000 Data List
13
Voice List / Voice-Liste / Liste des voix / Lista de voces
Category: GM2
Sub Category Voice Name
Piano GrandPiano 121 0 1 Regular
ChromaticPerc Celesta 121 0 9 Regular
Organ DrawbarOrgan 121 0 17 Regular
Guitar NylonGuitar 121 0 25 Regular
PSR-A3000 Data List
14
GrandPiano Wide 121 1 1 Regular
GrandPiano Dark 121 2 1 Regular
BrightPiano 121 0 2 Regular
BrightPiano Wide 121 1 2 Regular
El.GrandPiano 121 0 3 Regular
El.GrandPiano Wide 121 1 3 Regular
Honkytonk 121 0 4 Regular
Honkytonk Wide 121 1 4 Regular
ElectricPiano1 121 0 5 Regular
DetunedEP1 121 1 5 Regular
EP1 VelocityMix 121 2 5 Regular
60sElectricPiano 121 3 5 Regular
ElectricPiano2 121 0 6 Regular
DetunedEP2 121 1 6 Regular
EP2 VelocityMix 121 2 6 Regular
EPLegend 121 3 6 Regular
EPPhase 121 4 6 Regular
Harpsichord 121 0 7 Regular
Harpsi OctaveMix 121 1 7 Regular
Harpsichord Wide 121 2 7 Regular
Harpsi KeyOff 121 3 7 Regular
Clavi 121 0 8 Regular
PulseClavi 121 1 8 Regular
Glockenspiel 121 0 10 Regular
MusicBox 121 0 11 Regular
Vibraphone 121 0 12 Regular
Vibraphone Wide 121 1 12 Regular
Marimba 121 0 13 Regular
Marimba Wide 121 1 13 Regular
Xylophone 121 0 14 Regular
TubularBells 121 0 15 Regular
ChurchBells 121 1 15 Regular
Carillon 121 2 15 Regular
Dulcimer 121 0 16 Regular
DetunedDrawOrgan 121 1 17 Regular
Italian60sOrgan 121 2 17 Regular
DrawbarOrgan2 121 3 17 Regular
PercussiveOrgan1 121 0 18 Regular
DetunedPercOrgan 121 1 18 Regular
PercussiveOrgan2 121 2 18 Regular
RockOrgan 121 0 19 Regular
ChurchOrgan 121 0 20 Regular
ChurchOrgan Octave 121 1 20 Regular
DetunedChurchOrgan 121 2 20 Regular
ReedOrgan 121 0 21 Regular
PuffOrgan 121 1 21 Regular
Accordion 121 0 22 Regular
Accordion2 121 1 22 Regular
Harmonica 121 0 23 Regular
TangoAccordion 121 0 24 Regular
Ukulele 121 1 25 Regular
NylonGuitar KeyOff 121 2 25 Regular
NylonGuitar2 121 3 25 Regular
SteelGuitar 121 0 26 Regular
12StrGuitar 121 1 26 Regular
Mandolin 121 2 26 Regular
Steel&Body 121 3 26 Regular
JazzGuitar 121 0 27 Regular
PedalSteelGuitar 121 1 27 Regular
CleanGuitar 121 0 28 Regular
DetunedCleanGuitar 121 1 28 Regular
MidToneGuitar 121 2 28 Regular
MutedGuitar 121 0 29 Regular
FunkGuitar 121 1 29 Regular
MutedVeloSwGuitar 121 2 29 Regular
JazzMan 121 3 29 Regular
Overdriven 121 0 30 Regular
GuitarPinch 121 1 30 Regular
Distortion 121 0 31 Regular
FeedbackGuitar 121 1 31 Regular
Program Change
MSB LSB
PC#
(1–128)
Voice Type
Sub Category Voice Name
Guitar DistortionRhythmGt 121 2 31 Regular
GuitarHarmonics 121 0 32 Regular
GuitarFeedback 121 1 32 Regular
Bass AcousticBass 121 0 33 Regular
FingerBass 121 0 34 Regular
FingerSlapBass 121 1 34 Regular
PickBass 121 0 35 Regular
FretlessBass 121 0 36 Regular
SlapBass1 121 0 37 Regular
SlapBass2 121 0 38 Regular
SynthBass1 121 0 39 Regular
WarmSyBass 121 1 39 Regular
ResoSynthBass 121 2 39 Regular
ClaviBass 121 3 39 Regular
Hammer 121 4 39 Regular
SynthBass2 121 0 40 Regular
AttackBass 121 1 40 Regular
RubberBass 121 2 40 Regular
AttackPulse 121 3 40 Regular
Strings Violin 121 0 41 Regular
SlowAttackViolin 121 1 41 Regular
Viola 121 0 42 Regular
Cello 121 0 43 Regular
Contrabass 121 0 44 Regular
TremoloStrings 121 0 45 Regular
PizzicatoStrings 121 0 46 Reg ular
OrchestralHarp 121 0 47 Regular
YangQin 121 1 47 Regular
Timpani 121 0 48 Reg ular
Ensemble Strings1 121 0 49 Regular
StringsBrass 121 1 49 Regular
60sStrings 121 2 49 Regular
Strings2 121 0 50 Regular
SynthStrings1 121 0 51 Regular
SynthStrings3 121 1 51 Regular
SynthStrings2 121 0 52 Regular
ChoirAahs 121 0 53 Regular
ChoirAahs2 121 1 53 Regular
VoiceOohs 121 0 54 Regular
Humming 121 1 54 Regular
SynthVoice 121 0 55 Regular
AnalogVoice 121 1 55 Regular
OrchestraHit 121 0 56 Regular
BassHitPlus 121 1 56 Regular
6thHit 121 2 56 Regular
EuroHit 121 3 56 Regular
Brass Trumpet 121 0 57 Regular
DarkTrumpetSoft 121 1 57 Regular
Trombone 121 0 58 Regular
Trombone2 121 1 58 Reg ular
BrightTrombone 121 2 58 Regular
Tub a 121 0 59 Re g ul ar
MutedTrumpet 121 0 60 Regular
MutedTrumpet2 121 1 60 Regular
FrenchHorn 121 0 61 Regular
FrenchHorn2 121 1 61 Regular
BrassSection 121 0 62 Regular
BrassSection2 121 1 62 Regular
SynthBrass1 121 0 63 Regular
SynthBrass3 121 1 63 Regular
AnalogSynBrass1 121 2 63 Reg ular
JumpBrass 121 3 63 Regular
SynthBrass2 121 0 64 Regular
SynthBrass4 121 1 64 Regular
AnalogSynBrass2 121 2 64 Reg ular
Reed SopranoSax 121 0 65 Regular
AltoSax 121 0 66 Reg ular
TenorSax 121 0 67 Regular
BaritoneSax 121 0 68 Regular
Oboe 121 0 69 Regular
EnglishHorn 121 0 70 Regular
Bassoon 121 0 71 Regular
Clarinet 121 0 72 Regular
MSB LSB
(1–128)
PC#
Voice Type
Program Change
Category: GM2
Sub Category Voice Name
Pipe Piccolo 121 0 73 Regular
Flute 121 0 74 Regular
Recorder 121 0 75 Regular
PanFlute 121 0 76 Regular
BlownBottle 121 0 77 Regular
Shakuhachi 121 0 78 Regular
Whistle 121 0 79 Regular
Ocarina 121 0 80 Regular
Synth.Lead SquareLead 121 0 81 Regular
SquareLead2 121 1 81 Regular
SineLead 121 2 81 Regular
SawtoothLead 121 0 82 Regular
SawtoothLead2 121 1 82 Regular
SawPulseLead 121 2 82 Regular
DoubleSawLead 121 3 82 Regular
SequencedAnalog 121 4 82 Regular
CalliopeLead 121 0 83 Regular
ChiffLead 121 0 84 Regular
CharangLead 121 0 85 Regular
WireLead 121 1 85 Regular
VoiceLead 121 0 86 Regular
FifthsLead 121 0 87 Regular
Bass&Lead 121 0 88 Regular
SoftWhirl 121 1 88 Regular
Synth.Pad NewAgePad 121 0 89 Regular
WarmPad 121 0 90 Regular
SinePad 121 1 90 Regular
PolySynthPad 121 0 91 Regular
ChoirPad 121 0 92 Regular
ItopiaPad 121 1 92 Regular
BowedPad 121 0 93 Regular
MetallicPad 121 0 94 Regular
HaloPad 121 0 95 Regular
SweepPad 121 0 96 Regular
Synth.Effect Rain 121 0 97 Regular
SoundTrack 121 0 98 Regular
Crystal 121 0 99 Regular
SynthMallet 121 1 99 Regular
Atmosphere 121 0 100 Regular
Brightness 121 0 101 Regular
Goblins 121 0 102 Regular
Echoes 121 0 103 Regular
EchoBell 121 1 103 Regular
EchoPan 121 2 103 Regular
ScienceFiction 121 0 104 Regular
Ethnic Sitar 121 0 105 Regular
Sitar2 121 1 105 Regular
Banjo 121 0 106 Regular
Shamisen 121 0 107 Regular
Koto 121 0 108 Regular
TaishoKoto 121 1 108 Regular
Kalimba 121 0 109 Regular
Bagpipe 121 0 110 Regular
Fiddle 121 0 111 Regular
Shanai 121 0 112 Regular
Percussive TinkleBell 121 0 113 Regular
Agogo 121 0 114 Regular
SteelDrums 121 0 115 Regular
Woodblock 121 0 116 Regular
Castanets 121 1 116 Regular
TaikoDrum 121 0 117 Regular
ConcertBassDrum 121 1 117 Regular
MelodicTom 121 0 118 Regular
MelodicTom2 121 1 118 Regular
SynthDrum 121 0 119 Regular
RhythmBoxTom 121 1 119 Regular
ElectricDrum 121 2 119 Regular
ReverseCymbal 121 0 120 Regular
SoundEffect GuitarFretNoise 121 0 121 Regular
GuitarCutNoise 121 1 121 Regular
StringSlap 121 2 121 Regular
BreathNoise 121 0 122 Regular
FluteKeyClick 121 1 122 Regular
Seashore 121 0 123 Regular
Program Change
MSB LSB
PC#
(1–128)
Voice Type
Voice List / Voice-Liste / Liste des voix / Lista de voces
Program Change
Sub Category Voice Name
SoundEffect Rain 121 1 123 Regular
Thunder 121 2 123 Regular
Wind 121 3 123 Regular
Stream 121 4 123 Regular
Bubble 121 5 123 Regular
BirdTweet 121 0 124 Regular
Dog 121 1 124 Regular
HorseGallop 121 2 124 Regular
BirdTweet2 121 3 124 Regular
TelephoneRing 121 0 125 Regular
TelephoneRing2 121 1 125 Regular
DoorCreaking 121 2 125 Regular
Door 121 3 125 Regular
Scratch 121 4 125 Regular
WindChime 121 5 125 Regular
Helicopter 121 0 126 Regular
CarEngine 121 1 126 Reg ular
CarStop 121 2 126 Regular
CarPass 121 3 126 Regular
CarCrash 121 4 126 Regular
Siren 121 5 126 Regular
Train 121 6 126 Regular
JetPlane 121 7 126 Regular
Starship 121 8 126 Regular
BurstNoise 121 9 126 Regular
Applause 121 0 127 Regular
Laughing 121 1 127 Regular
Screaming 121 2 127 Regular
Punch 121 3 127 Regular
Heartbeat 121 4 127 Regular
Footsteps 121 5 127 Regular
Gunshot 121 0 128 Regular
MachineGun 121 1 128 Regular
LaserGun 121 2 128 Regular
Explosion 121 3 128 Regular
Drum StandardSet 120 0 1 Drums
RoomSet 120 0 9 Drums
PowerSet 120 0 17 Drums
ElectroSet 120 0 25 Drums
AnalogSet 120 0 26 Drums
JazzSet 120 0 33 Drums
BrushSet 120 0 41 Drums
OrchestraSet 120 0 49 Drums
SFXSet 120 0 57 SFX
MSB LSB
(1–128)
PC#
Voice Type
PSR-A3000 Data List
15
Mega Voice Map / Sound-Zuordnungen der Mega Voices / Carte des voix Mega / Mapa de Mega Voice
1–127 1–127
strum noise fret noise
strum noise fret noise
pick
harmonics
strum noise fret noise
pick
harmonics
strum noise fret noise
pick
harmonics
strum noise fret noise
pick
harmonics
EFX
pick
harmonics
EFX
strum noise fret noise
pick
harmonics
pick
harmonics
Voice Name Velocity Switch Points (under B5) above C6 above C8
PC#
(1–128)
MSB LSB
1–20 21–40 41–60 61–75 76–90 91–105 106–120 121–127 1–127 1–127
open soft open med open hard dead mute hammer slide harmonics strum noise fret noise
Mega NylonGuitar
801
1–20 21–40 41–60 61–75 76–90 91–105 106–120 121–127 1–127 1–127
open soft open med open hard dead mute hammer slide harmonics strum noise fret noise
Mega SteelGuitar
802
1–89 90–127 1–127 1–127
soft hard strum noise fret noise
Mega HiStringGtr
803
soft hard
1–89 90–127
1–71 72–115 116–127
1–60 61–80 81–120 121–127 1–127
1–60 61–80 81–120 121–127 1–127
1–55 56–120 121–127 1–127
1–20 21–40 41–60 61–75 76–90 91–105 106–120 121–127 1–127 1–127
Element1(Steel) soft med hard
Mega 12StringGtr
Element2(HiString)
1–20 21–40 41–60 61–75 76–90 91–105 106–120 121–127 1–127 1–127
open soft open hard slap dead mute hammer slide
Mega CleanGuitar
1–20 21–40 41–60 61–75 76–90 91–105 106–120 121–127 1–127 1–127
open soft open hard slap dead mute hammer slide
Mega SolidGuitar1
1–20 21–40 41–60 61–75 76–90 91–105 106–120 121–127 1–127 1–127
open soft open med open hard dead mute hammer slide
Mega SolidGuitar2
open soft open med open hard dead mute hammer slide
Mega SingleCoil
Mega
open mute
OverdriveGtr
1–55 56–120 121–127 1–127
open mute
1–20 21–40 41–60 61–75 76–90 91–105 106–120 121–127 1–127 1–127
Mega
DistortionGtr
Mega JazzGuitar
open soft open hard dead harmonics EFX
open soft open med open hard dead soft dead hard hammer slide
Mega
AcousticBass
1–60 61–80 81–120 121–127 1–127
open soft open hard dead slap EFX
Mega ElectricBass
Mega
open soft open hard dead harmonics EFX
VintageRound
: No Sound
813
804
814
824
834
805
806
807
8017
8018
8118
PSR-A3000 Data List
16
Mega Voice Map / Sound-Zuordnungen der Mega Voices / Carte des voix Mega / Mapa de Mega Voice
breath noise
on noise
off noise)
C7–B7 key
(C6–B6 key
valve noise breath noise
valve noise
down
glissando
down
glissando
up
glissando
up
glissando
Voice Name Velocity Switch Points (under B5) above C6 above C8
PC#
(1–128)
MSB LSB
1–60 61–80 81–120 121–127 1–127
open soft open hard dead harmonics EFX
Mega VintageFlat
8218
1–40 41–80 81–120 121–127 1–127
open mute dead harmonics EFX
Mega PickBass
8019
1–40 41–80 81–120 121–127 1–127
open mute dead harmonics EFX
Mega VintagePick
8119
1–80 81–120 121–127 1–127
Mega
8020
open dead har monics EFX
FretlessBass
1–20 21–40 41–60 61–80 81–95 96–110 111–120 121–127
Mega
8049
p mf f legato spicato f spicato ff tremolo
SmallStrings
p mf f legato spicato f spicato ff tremolo
1–20 21–40 41–60 61–80 81–95 96–110 111–120 121–127
Mega
LargeStrings
p mf f attack scoops shake falls fast mf falls fast f
1–20 21–40 41–60 61–80 81–90 91–100 101–110 111–120 121–127
Mega Brass
mf f ff legato straight shake falls
1–20 21–40 41–60 61–80 81–100 101–110 111–120 121–127 1–127 1–127
1–20 21–40 41–60 61–80 81–100 101–127 1–127 1–127
Mega Trumpet
mp mf f legato growl falls
Mega TenorSax
: No Sound
8050
8057
8065
8083
PSR-A3000 Data List
17
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX /
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Lista de conjuntos de percusión/efectos especiales
Kit Name StandardKit1 (Legacy) StandardKit2 (Legacy) HitKit RoomKit
MSB-LSB-PC# (1–128) 127-0-1 127-0-2 127-0-5 127-0-9
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3
14 D-1 D0 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3
15 D#-1 D#0 Hi Q Hi Q Hi Q Hi Q
16 E-1 E0 Whip Slap Whip Slap Whip Slap Whip Slap
17 F-1 F0 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4
18 F#-1 F#0 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4
19 G-1 G0 Finger Snap Finger Snap Finger Snap Finger Snap
20 G#-1 G#0 Click Noise Click Noise Click Noise Click Noise
21 A-1 A0 Metronome Click Metronome Click Metronome Click Metronome Click
22 A#-1 A#0Metronome Bell Metronome Bell Metronome Bell Metronome Bell
23 B-1 B0 Seq Click L Seq Click L Seq Click L Seq Click L
24 C0 C1 Seq Click H Seq Click H Seq Click H Seq Click H
25 C#0C#1 Brush Tap Brush Tap Brush Tap Brush Tap
26 D0 D1 Brush Swirl Brush Swirl Brush Swirl Brush Swirl
27 D#0D#1Brush Slap Brush Slap Brush Slap Brush Slap
28 E0 E1 Brush Tap Swirl Brush Tap Swirl Brush Tap Swirl Brush Tap Swirl
29 F0 F1 Snare Roll Snare Roll Snare Roll Snare Roll
30 F#0F#1 Castanet Castanet Castanet Castanet
31 G0 G1 Snare Soft Snare Soft 2 Snare Electro Snare Soft
32 G#0G#1Sticks Sticks Sticks Sticks
33 A0 A1 Kick Soft Kick Soft Kick Tight L Kick Soft
34 A#0A#1 Open Rim Shot Open Rim Shot H Short Snare Pitched Open Rim Shot
35 B0 B1 Kick Tight Kick Tight Kick Wet Kick Tight
36 C1 C2 Kick Kick Short Kick Tight H Kick
37 C#1C#2 Side Stick Side Stick Light Stick Ambient Side Stick
38 D1 D2 Snare Snare Short Snare Ambient Snare Snappy
39 D#1D#2 Hand Clap Hand Clap Hand Clap Hand Clap
40 E1 E2 Snare Tight Snare Tight H Snare Tight 2 Snare Tight Snappy
41 F1 F2 Floor Tom L Floor Tom L Hybrid Tom 1 Tom Room 1
42 F#1F#2 Hi-Hat Closed 1 Hi-Hat Closed 1 Hi-Hat Closed 2 1 Hi-Hat Closed 1
43 G1 G2 Floor Tom H Floor Tom H Hybrid Tom 2 Tom Room 2
44 G#1G#2 Hi-Hat Pedal 1 Hi-Hat Pedal 1 Hi-Hat Pedal 2 1 Hi-Hat Pedal 1
45 A1 A2 Low Tom Low Tom Hybrid Tom 3 Tom Room 3
46 A#1A#2 Hi-Hat Open 1 Hi-Hat Open 1 Hi-Hat Open 2 1 Hi-Hat Open 1
47 B1 B2 Mid Tom L Mid Tom L Hybrid Tom 4 Tom Room 4
48 C2 C3 Mid Tom H Mid Tom H Hybrid Tom 5 Tom Room 5
49 C#2C#3 Crash Cymbal 1 Crash Cymbal 1 Crash Cymbal 1 Crash Cymbal 1
50 D2 D3 High Tom High Tom Hybrid Tom 6 Tom Room 6
51 D#2D#3 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1
52 E2 E3 Chinese Cymbal Chinese Cymbal Chinese Cymbal Chinese Cymbal
53 F2 F3 Ride Cymbal Cup Ride Cymbal Cup Ride Cymbal Cup Ride Cymbal Cup
54 F#2F#3Tambourine Tambourine Tambourine Light Ta m bo u ri n e
55 G2 G3 Splash Cymbal Splash Cymbal Splash Cymbal Splash Cymbal
56 G#2G#3Cowbell Cowbell Cowbell Cowbell
57 A2 A3 Crash Cymbal 2 Crash Cymbal 2 Crash Cymbal 2 Crash Cymbal 2
58 A#2A#3Vibraslap Vibraslap Vibraslap Vibraslap
59 B2 B3 Ride Cymbal 2 Ride Cymbal 2 Ride Cymbal 2 Ride Cymbal 2
60 C3 C4 Bong o H Bongo H Bongo H Bongo H
61 C#3C#4Bongo L Bongo L Bongo L Bongo L
62 D3 D4 Conga H Mute Conga H Mute Conga H Mute Conga H Mute
63 D#3D#4Conga H Open Conga H Open Conga H Open Conga H Open
64 E3 E4 Conga L Conga L Conga L Conga L
65 F3 F4 Timbale H Timbale H Timbale H Timbale H
66 F#3F#4 Timbale L Timbale L Timbale L Timbale L
67 G3 G4 Agogo H Agogo H Agogo H Agogo H
68 G#3G#4 Agogo L Agogo L Agogo L Agogo L
69 A3 A4 Cabasa Cabasa Cabasa Cabasa
70 A#3A#4 Maracas Maracas Maracas Maracas
71 B3 B4 Samba Whistle H Samba Whistle H Samba Whistle H Samba Whistle H
72 C4 C5 Samba Whistle L Samba Whistle L Samba Whistle L Samba Whistle L
73 C#4C#5Guiro Short Guiro Short Guiro Short Guiro Short
74 D4 D5 Guiro Long Guiro Long Guiro Long Guiro Long
75 D#4D#5 Claves Claves Claves Claves
76 E4 E5 Wood Block H Wood Block H Wood Block H Wood Block H
77 F4 F5 Wood Block L Wood Block L Wood Block L Wood Block L
78 F#4F#5 Cuica Mute Cuica Mute Cuica Mute Cuica Mute
79 G4 G5 Cuica Open Cuica Open Cuica Open Cuica Open
80 G#4G#5Triangle Mute 2Triangle Mute 2 Triangle Mute 2 Triangle Mute 2
81 A4 A5 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2
82 A#4A#5 Shaker Shaker Shaker Shaker
83 B4 B5 Jingle Bells Jingle Bells Jingle Bells Jingle Bells
84 C5 C6 Bell Tree Bell Tree Bell Tree Bell Tree
85 C#5C#6
86 D5 D6
87 D#5D#6
88 E5 E6
89 F5 F6
90 F#5F#6
91 G5 G6
Note
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
(*1)
Off
Alt
Group
(*2)
PSR-A3000 Data List
18
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name RockKit (Legacy) ElectroKit AnalogKit DanceKit
MSB-LSB-PC# (1–128) 127-0-17 127-0-25 127-0-26 127-0-28
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Kick Dance 1
14 D-1 D0 Surdo Open 3 Surdo Open 3 Surdo Open 3 Kick Dance 2
15 D#-1 D#0 Hi Q Hi Q Hi Q Hi Q
16 E-1 E0 Whip Slap Whip Slap Whip Slap Whip Slap
17 F-1 F0 Scratch H 4 Scratch H 4 Scratch H 4 Scratch Dance 1
18 F#-1 F#0 Scratch L 4 Scratch L 4 Scratch L 4 Scratch Dance 2
19 G-1 G0 Finger Snap Finger Snap Finger Snap Finger Snap
20 G#-1 G#0 Click Noise Click Noise Click Noise Click Noise
21 A-1 A0 Metronome Click Metronome Click Metronome Click Dance Perc 1
22 A#-1 A#0 Metronome Bell Metronom e Bell Metronome Bell Reverse Dance 1
23 B-1 B0 Seq Click L Seq Click L Seq Click L Dance Perc 2
24 C0 C1 Seq Click H Seq Click H Seq Click H Hi Q Dance 1
25 C#0C#1 Brush Tap Brush Tap Brush Tap Snare Analog 3
26 D0 D1 Brush Swirl Brush Swirl Brush Swirl Vinyl Noise
27 D#0D#1 Brush Slap Brush Slap Brush Slap Snare Analog 4
28 E0 E1 Brush Tap Swirl Reverse Cymbal Reverse Cymbal Reverse Cymbal
29 F0 F1 Snare Roll Snare Roll Snare Roll Reverse Dance 2
30 F#0F#1 Castanet Hi Q 2 Hi Q 2 Hi Q 2
31 G0 G1 Snare Noisy Snare Snappy Electro Snare Noisy 4 Snare Techno
32 G#0G#1 Sticks Sticks Sticks Snare Dance 1
33 A0 A1 Kick Soft Kick 3 Kick 3 Kick Techno Q
34 A#0A#1 Open Rim Shot Open Rim Shot Open Rim Shot Rim Gate
35 B0 B1 Kick 2 Kick Gate Kick Analog Short Kick Techno L
36 C1 C2 Kick Gate Kick Gate Heavy Kick Analog Kick Techno
37 C#1C#2 Side Stick Side Stick Side Stick Analog Side Stick Analog
38 D1 D2 Snare Rock Snare Noisy 2 Snare Analog Snare Clap
39 D#1D#2 Hand Clap Hand Clap Hand Clap Dance Clap
40 E1 E2 Snare Rock Tight Snare Noisy 3 Snare Analog 2 Snare Dry
41 F1 F2 Tom Rock 1 Tom Electro 1 Tom Analog 1 Tom Dance 1
42 F#1F#2 Hi-Hat Closed 1 Hi-Hat Closed 1 Hi-Hat Closed Analog 1 Hi-Hat Closed 3 1
43 G1 G2 Tom Rock 2 Tom Electro 2 Tom Analog 2 Tom Dance 2
44 G#1G#2 Hi-Hat Pedal 1 Hi-Hat Pedal 1 Hi-Hat Closed Analog 2 1 Hi-Hat Closed Analog 3 1
45 A1 A2 Tom Rock 3 Tom Electro 3 Tom Analog 3 Tom Dance 3
46 A#1A#2 Hi-Hat Open 1 Hi-Hat Open 1 Hi-Hat Open Analog 1 Hi-Hat Open 3 1
47 B1 B2 Tom Rock 4 Tom Electro 4 Tom Analog 4 Tom Dance 4
48 C2 C3 Tom Rock 5 Tom Electro 5 Tom Analog 5 Tom Dance 5
49 C#2C#3 Crash Cymbal 1 Crash Cymbal 1 Crash Analog Crash Analog
50 D2 D3 Tom Rock 6 Tom Electro 6 Tom Analog 6 Tom Dance 6
51 D#2D#3 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1
52 E2 E3 Chinese Cymbal Chinese Cymbal Chinese Cymbal Chinese Cymbal
53 F2 F3 Ride Cymbal Cup Ride Cymbal Cup Ride Cymbal Cup Ride Cymbal Cup
54 F#2F#3 Ta m bo u ri n e Tambourine Ta mb ou r in e Tambourine Analog
55 G2 G3 Splash Cymbal Splash Cymbal Splash Cymbal Splash Cymbal
56 G#2G#3 Cowbell Cowbell Cowbell Analog Cowbell Dance
57 A2 A3 Crash Cymbal 2 Crash Cymbal 2 Crash Cymbal 2 Crash Cymbal 2
58 A#2A#3 Vibraslap Vibraslap Vibraslap Vibraslap Analog
59 B2 B3 Ride Cymbal 2 Ride Cymbal 2 Ride Cymbal 2 Ride Analog
60 C3 C4 Bongo H Bongo H Bongo H Bongo Analog H
61 C#3C#4 Bongo L Bongo L Bongo L Bongo Analog L
62 D3 D4 Conga H Mute Conga H Mute Conga Analog H Conga Analog H
63 D#3D#4
64 E3 E4
65 F3 F4 Timbale H Timbale H Timbale H Timbale H
66 F#3F#4 Timbale L Timbale L Timbale L Timbale L
67 G3 G4 Agogo H Agogo H Agogo H Agogo H
68 G#3G#4 Agogo L Agogo L Agogo L Agogo L
69 A3 A4 Cabasa Cabasa Cabasa Cabasa
70 A#3A#4 Maracas Maracas Maracas 2 Maracas 2
71 B3 B4
72 C4 C5 Samba Whistle L Samba Whistle L Samba Whistle L Samba Whistle L
73 C#4C#5 Guiro Short Guiro Short Guiro Short Guiro Short
74 D4 D5 Guiro Long Guiro Long Guiro Long Guiro Long
75 D#4D#5 Claves Claves Claves 2 Claves 2
76 E4 E5 Wood Block H Wood Block H Wood Block H Dance Perc 3
77 F4 F5 Wood Block L Wood Block L Wood Block L Dance Perc 4
78 F#4F#5 Cuica Mute Scratch H 2 Scratch H 2 Dance Breath 1
79 G4 G5 Cuica Open Scratch L 2 Scratch L 2 Dance Breath 2
80 G#4G#5 Tria ngl e M ut e 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2
81 A4 A5 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2
82 A#4A#5 Shaker Shaker Shaker Shaker
83 B4 B5 Jingle Bells Jingle Bells Jingle Bells Jingle Bells
84 C5 C6 Bell Tree Bell Tree Bell Tree Bell Tree
85 C#5C#6
86 D5 D6
87 D#5D#6
88 E5 E6
89 F5 F6
90 F#5F#6
91 G5 G6
Note
Full Name
Conga H Open Conga H Open Conga Analog M Conga Analog M
Conga L Conga L Conga Analog L Conga Analog L
Samba Whistle H Samba Whistle H Samba Whistle H Samba Whistle H
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
19
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name JazzKit BrushKit SymphonyKit HipHop Kit
MSB-LSB-PC# (1–128) 127-0-33 127-0-41 127-0-49 127-0-57
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 5
14 D-1 D0 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 5
15 D#-1 D#0 Hi Q Hi Q Hi Q Hi Q
16 E-1 E0 Whip Slap Whip Slap Whip Slap Whip Slap
17 F-1 F0 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 6
18 F#-1 F#0 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 6
19 G-1 G0 Finger Snap Finger Snap Finger Snap Hi-Hat Closed T8 2 4
20 G#-1 G#0 Click Noise Click Noise Click Noise To m T 8 3
21 A-1 A0 Metronome Click Metronome Click Metronome Click Hi-Hat Open T8 2 4
22 A#-1 A#0 Metronome Bell Metronom e Bell Metronome Bell To m T 8 6
23 B-1 B0 Seq Click L Seq Click L Seq Click L Crash T8
24 C0 C1 Seq Click H Seq Click H Seq Click H Triangle Mute 1
25 C#0C#1 Brush Tap Brush Tap Brush Tap Triangle Open 1
26 D0 D1 Brush Swirl Brush Swirl Brush Swirl Wind Chime
27 D#0D#1 Brush Slap Brush Slap Brush Slap Tambourine Light 2
28 E0 E1 Brush Tap Swirl Brush Tap Swirl Brush Tap Swirl Tambourine Light 1
29 F0 F1 Snare Roll Snare Roll Snare Roll Kick HipHop 9
30 F#0F#1 Castanet Castanet Castanet Hi-Hat Closed Tek 3
31 G0 G1 Snare Jazz H Brush Slap 2 Snare Soft Kick Gate
32 G#0G#1 Sticks Sticks Sticks Hi-Hat Open Lo-Fi 3
33 A0 A1 Kick Soft Kick Soft Kick Soft 2 Kick Gran Casa Open
34 A#0A#1 Open Rim Shot Open Rim Shot Open Rim Shot Hi-Hat Reverse Drum&Bass
35 B0 B1 Kick Tight Kick Tight Gran Cassa Kick HipHop 1
36 C1 C2 Kick Jazz Kick Jazz Gran Cassa Mute Kick Analog CR
37 C#1C#2 Side Stick Light Side Stick Light Side Stick Snare Analog Sm Rim
38 D1 D2 Snare Jazz L Brush Slap 3 Band Snare Snare HipHop 1
39 D#1D#2 Hand Clap Hand Clap Hand Clap Snare Clappy
40 E1 E2 Snare Jazz M Brush Tap 2 Band Snare 2 Snare HipHop 2
41 F1 F2 Floor Tom L To m B ru s h 1 Floor Tom L Floor Tom L
42 F#1F#2 Hi-Hat Closed 1 Hi-Hat Closed 1 Hi-Hat Closed 1 Hi-Hat Closed HipHop 2
43 G1 G2 Floor Tom H To m Br us h 2 Floor Tom H Low Tom
44 G#1G#2 Hi-Hat Pedal 1 Hi-Hat Pedal 1 Hi-Hat Pedal 1 Hi-Hat Pedal HipHop 2
45 A1 A2 Low Tom To m B ru s h 3 Low Tom Mid Tom L
46 A#1A#2 Hi-Hat Open 1 Hi-Hat Open 1 Hi-Hat Open 1 Hi-Hat Open HipHop 2
47 B1 B2 Mid Tom L Tom Br u sh 4 Mid Tom L High Tom
48 C2 C3 Mid Tom H To m B ru s h 5 Mid Tom H Ride Cymbal 3
49 C#2C#3 Crash Cymbal 1 Crash Cymbal 1 Hand Cymbal Crash Cymbal 3
50 D2 D3 High Tom To m B ru s h 6 High Tom Shaker 2
51 D#2D#3 Ride Cymbal 1 Ride Cymbal 1 Hand Cymbal Short Scratch Bass Drum Forward
52 E2 E3 Chinese Cymbal Chinese Cymbal Chinese Cymbal Scratch Bass Drum Reverse
53 F2 F3 Ride Cymbal Cup Ride Cymbal Cup Ride Cymbal Cup Kick HipHop 2
54 F#2F#3 Ta m bo u ri n e Tambourine Ta mb ou r in e Snare HipHop Rim 2
55 G2 G3 Splash Cymbal Splash Cymbal Splash Cymbal HipHop Clap 2
56 G#2G#3 Cowbell Cowbell Cowbell HipHop Snap 1
57 A2 A3 Crash Cymbal 2 Crash Cymbal 2 Hand Cymbal 2 Snare HipHop 3
58 A#2A#3 Vibraslap Vibraslap Vibraslap Electric Clap 2
59 B2 B3 Ride Cymbal 2 Ride Cymbal 2 Hand Cymbal Short 2 Kick Hip Deep
60 C3 C4 Bongo H Bongo H Bongo H Kick HipHop 3
61 C#3C#4 Bongo L Bongo L Bongo L Snare HipHop Rim 3
62 D3 D4 Conga H Mute Conga H Mute Conga H Mute Snare HipHop 5
63 D#3D#4
64 E3 E4
65 F3 F4 Timbale H Timbale H Timbale H Kick HipHop 4
66 F#3F#4
67 G3 G4
68 G#3G#4
69 A3 A4
70 A#3A#4 Maracas Maracas Maracas HipHop Flex 2
71 B3 B4
72 C4 C5
73 C#4C#5
74 D4 D5
75 D#4D#5 Claves Claves Claves Snare HipHop 11
76 E4 E5 Wood Block H Wood Block H Wood Block H Kick HipHop 10
77 F4 F5 Wood Block L Wood Block L Wood Block L Snare HipHop 7
78 F#4F#5 Cuica Mute Cuica Mute Cuica Mute HipHop Clap 5
79 G4 G5 Cuica Open Cuica Open Cuica Open Conga H Tip
80 G#4G#5 Tria ngl e M ut e 2 Triangle Mute 2 Triangle Mute 2 Conga H Heel
81 A4 A5 Triangle Open 2 Triangle Open 2 Triangle Open 2Conga H Open
82 A#4A#5 Shaker Shaker Shaker Conga L Open 1
83 B4 B5 Jingle Bells Jingle Bells Jingle Bells Conga L Open 2
84 C5 C6 Bell Tree Bell Tree Bell Tree Kick HipHop 8
85 C#5C#6 HipHop Clap 6
86 D5 D6 Snare T8 1
87 D#5D#6 Snare T8 1 H
88 E5 E6
89 F5 F6
90 F#5F#6 Hi-Hat Closed T8 2
91 G5 G6 Tom T 8 2
Note
Full Name
Conga H Open Conga H Open Conga H Open Electric Clap 1
Conga L Conga L Conga L Handbell H
Timbale L Timbale L Timbale L HipHop Clap 3
Agogo H Agogo H Agogo H HipHop Snap 2
Agogo L Agogo L Agogo L Snare HipHop Rim 5
Cabasa Cabasa Cabasa HipHop Flex 1
Samba Whistle H Samba Whistle H Samba Whistle H Shaker 2
Samba Whistle L Samba Whistle L Samba Whistle L Kick HipHop 5
Guiro Short Guiro Short Guiro Short Snare HipHop Rim 4
Guiro Long Guiro Long Guiro Long Snare HipHop 6
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
HipHop Clap 7
To m T8 1
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
20
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name BreakKit AnalogT8Kit AnalogT9Kit HouseKit
MSB-LSB-PC# (1–128) 127-0-58 127-0-59 127-0-60 127-0-61
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3W Kick
14 D-1 D0 Surdo Open 3 Surdo Open 3 Surdo Open 3 Disco Fx
15 D#-1 D#0 Hi Q Hi Q Hi Q White Noise Down 1
16 E-1 E0 Whip Slap Whip Slap Whip Slap Pink Noise Down 1
17 F-1 F0 Scratch H 4 Scratch H 4 Scratch H 4 White Noise Down 2 4
18 F#-1 F#0 Scratch L 4 Scratch L 4 Scratch L 4 Pink Noise Down 2 4
19 G-1 G0 Finger Snap Snare Hammer Snare Drum&Bass 1 White Noise Up 2
20 G#-1 G#0 Snare Break 8 Kick Zap Hard Kick Break 2 White Noise Up 1
21 A-1 A0 Snare Break 9 S nare Garg L Snare Distortion Pink Noise Up
22 A#-1 A#0 Hi-Hat Closed Break 1 Kick Tek Power Kick Tek Power White Noise Up Release
23 B-1 B0 Hi-Hat Closed Break 2 Kick Slimy Kick Distortion RM Pink Noise Up Release
24 C0 C1 Kick Break Deep Kick T8 4 Kick T9 2 Kick T9 4
25 C#0C#1 Snare Hip Snare Analog CR Snare Analog CR Snare T8 Rim
26 D0 D1 Snare Lo-Fi S nare T8 7 Snare T9 5 Snare T8 5
27 D#0D#1 Snare Clappy Snare Clap Analog Clap Analog Sm Hand Clap
28 E0 E1 Snare LdwH Mono Snare T8 6 Snare T9 Gate 1 Snare Garg L
29 F0 F1 Snare Rock Roll Tom T8 5 Snare Rock Roll Snare Roll
30 F#0F#1 Snare Gate 1 Snare T8 5 Snare T9 3 Snare T9 3
31 G0 G1 Snare Mid Kick T8 3 Snare T9 4 Snare T8 1
32 G#0G#1 Snare Break Rim S nare T8 4 Snare T9 Gate 2 Snare T9 5
33 A0 A1 Kick Break Heavy Kick T8 2 Kick T9 4 Kick T9 1
34 A#0A#1 Snare Hip Rim 4 Snare T8 3 Snare T9 6 Snare T9 Gate
35 B0 B1 Kick Break 2 T8 Kick Bass Kick T9 1 Kick T9 2
36 C1 C2 Kick Break 1 Kick T8 1 Kick T9 3 Kick T9 5
37 C#1C#2 Snare Hip Rim 1 Snare T8 Rim Snare T9 Rim Snare T9 Rim
38 D1 D2 Snare Break 3 Snare T8 2 Snare T9 1 Snare T9 1
39 D#1D#2 Snare Break 1 Clap T9 Clap T9 Clap T9
40 E1 E2 Snare Break 2 Snare T8 1 Snare T9 2 Snare T9 2
41 F1 F2 Tom Break 1 Tom T8 1 Tom T9 1 Tom T9 1
42 F#1F#2 Hi-Hat Closed Rock Soft 1 Hi-Hat Closed T8 1 Hi-Hat Closed T9 1 Hi-Hat Closed T8 1
43 G1 G2 Tom Break 2 Tom T8 2 Tom T9 2 Tom T9 2
44 G#1G#2 Hi-Hat Pedal Rock 1 Hi-Hat Pedal T8 1 Hi-Hat Pedal T9 1 Hi-Hat Pedal T9 1
45 A1 A2 Tom Break 3 Tom T8 3 Tom T9 3 Tom T9 3
46 A#1A#2 Hi-Hat Half Open Rock 1 Hi-Hat Open T8 1 Hi-Hat Open T9 1 Hi-Hat Open T9 1
47 B1 B2 Tom Break 4 Tom T8 4 Tom T9 4 Tom T9 4
48 C2 C3 Tom Break 5 Tom T8 6 Tom T9 5 Tom T9 5
49 C#2C#3 Crash Cymbal 1 Crash Cymbal T8 Crash Cymbal T9 Crash Cymbal T9
50 D2 D3 Tom Break 6 Tom T8 7 Tom T9 6 Tom T9 6
51 D#2D#3 Ride Cymbal 3 Ride Cymbal T9 Ride Cymbal T9 Ride Cymbal T9
52 E2 E3 China Cymbal 2 China Cymbal 2 China Cymbal 2 Crash Cymbal 4
53 F2 F3 Ride Cymbal Cup 2 Ride Cymbal Cup 2 Ride Cymbal Cup 2 Ride Cymbal Cup 2
54 F#2F#3 Tambourine 1 Hit Tambourine RX5 Tambourine RX5 Tambourine Hit
55 G2 G3 Splash Cymbal 2 Splash Cymbal Splash Cymbal 2 Splash Cymbal 2
56 G#2G#3 Cowbell 1 Cowbell T8 Cowbell 1 Cowbell 1
57 A2 A3 Crash Cymbal 2 Crash Cymbal 4 Crash Cymbal 4 Crash Cymbal 2
58 A#2A#3Cowbell RX11 Vibraslap Cowbell T8 Cowbell T8
59 B2 B3 Ride Cymbal 2 Ride Cymbal 3 Ride Cymbal 3 Ride Cymbal 3
60 C3 C4 Bongo H Conga T8 5 Conga T8 5 Bongo H Open One Finger
61 C#3C#4 Bongo L Conga T8 4 Conga T8 4 Bongo L Open Three Finger
62 D3 D4 Conga H Tip Conga T8 3 Conga Tip Conga H Tip
63 D#3D#4 Conga H Open Slap Conga T8 2 Conga Open Slap Conga H Slap Open
64 E3 E4 Conga H Open Conga T8 1 Conga Open Conga H Open 2
65 F3 F4 Bongo 2 H Timbale H Timbale H Timbale H
66 F#3F#4Bongo 2 L Timbale L Timbale L Timbale L
67 G3 G4 Conga Open Glass H Analog Click Agogo H
68 G#3G#4 Agogo L Glass L Conga T8 1 Agogo L
69 A3 A4 Cabasa Cabasa Cabasa Cabasa
70 A#3A#4 Maracas Slur Maracas T8 Maracas Slur 2 Maracas Slur 2
71 B3 B4 Timbale H Fx Gun 2 Fx Gun 2 Vox Drum L
72 C4 C5 Timbale L Fx Gun 1 Fx Gun 1 Vox Drum H
73 C#4C#5 Scratch H 3 Analog Shaker H Scratch H 3
74 D4 D5 Scratch Down Analog Shaker L Scratch Down Guiro Long
75 D#4D#5 Claves C laves T8 Hi Q 3 Claves
76 E4 E5 Wood Block H Hi Q 1 Hi Q 1 Wood Block H
77 F4 F5 Wood Block L Hi Q 2 Hi Q 2 Wood Block L
78 F#4F#5 Scratch H 2 Scratch H 2 Scr atch H 2 Cuica H
79 G4 G5 Scratch L 2 Scratch L 2 Scratch L 2 Cuica L
80 G#4G#5 Tria ngl e M ut e 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2
81 A4 A5 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2
82 A#4A#5 Kick Break 3 Analog Shaker Analog Shaker Analog Shaker
83 B4 B5 Kick Break 4 Sleigh Bells Jingle Bells Jingle Bells
84 C5 C6 Kick Break 5 Wind Chime Wind Chime Wind Chime
85 C#5C#6 Kick Break 6 Snare Hip 1 Snare Piccolo Snare Break Roll
86 D5 D6 Kick Break 7 Snare Hip 2 Snare T8 7 Noise Burst
87 D#5D#6 Hi-Hat Closed Break 3 Snare Hip Gate SnareRckRollDist Vox Bell
88 E5 E6 Snare Break 4 Snare Break 1 Snare Brush Mute Snare R&B 1
89 F5 F6 Snare Break 5 Kick Blip Kick Blip Hard Vox Alk
90 F#5F#6 Snare Break 6 Snare Fx 1 Snare Jungle 1 Udu High
91 G5 G6 Snare Break 7 Kick Fx Hammer Kick Sustain Filter Kick
Note
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Guiro Short
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
21
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name StudioKit PowerKit1 PowerKit2 AcousticKit
MSB-LSB-PC# (1–128) 127-0-87 127-0-88 127-0-89 127-0-90
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3
14 D-1 D0 Surdo Open 3 Surdo Open 3 Surdo Open 3 Surdo Open 3
15 D#-1 D#0 Hi Q Hi Q Hi Q Hi Q
16 E-1 E0 Whip Slap Whip Slap Whip Slap Whip Slap
17 F-1 F0 Scratch H 4 Scratch H 4 Scratch H 4 Scratch H 4
18 F#-1 F#0 Scratch L 4 Scratch L 4 Scratch L 4 Scratch L 4
19 G-1 G0 Finger Snap Finger Snap Finger Snap Finger Snap
20 G#-1 G#0 Click Noise Click Noise Click Noise Click Noise
21 A-1 A0 Metronome Click Metronome Click Metronome Click Metronome Click
22 A#-1 A#0 Metronome Bell Metronome Bell Metronome Bell Metronome Bell
23 B-1 B0 Seq Click L Seq Click L Seq Click L Seq Click L
24 C0 C1 Seq Click H Seq Click H Seq Click H Seq Click H
25 C#0C#1 Brush Tap Brush Tap Brush Tap Brush Tap
26 D0 D1 Brush Swirl Brush Swirl Brush Swirl Brush Swirl
27 D#0D#1 Brush Slap Brush Slap Brush Slap Brush Slap
28 E0 E1 Brush Tap Swirl Brush Tap Swirl Brush Tap Swirl Brush Tap Swirl
29 F0 F1 Snare Roll Snare Roll Snare Roll Snare Roll Acoustic
30 F#0F#1 Castanet Castanet Castanet Castanet
31 G0 G1 Snare Studio 2 Snare Soft Power 1 Snare Soft Power 2 Snare Soft Acoustic
32 G#0G#1 Sticks Sticks Sticks Sticks
33 A0 A1 Kick Ambience H Kick Ambient+ Kick Ambient+ Kick Soft Acoustic
34 A#0A#1 Open Rim Shot Open Rim Power 1 Open Rim Power 2 Rim Acoustic
35 B0 B1 Kick Ambience L Kick Power Open Kick Power Open Kick Mute Acoustic
36 C1 C2 Kick Studio Kick Power Mute Kick Power Mute Kick Open Acoustic
37 C#1C#2 Side Stick Side Stick Power Side Stick Power Stick Acoustic
38 D1 D2 Snare Studio M Snare Power 1 Snare Power 2 Snare Acoustic
39 D#1D#2 Hand Clap Hand Clap Power Hand Clap Power Hand Clap Power
40 E1 E2 Snare Studio L Snare Rough Snare Loose Snare Rough Acoustic
41 F1 F2 Floor Tom L Tom Power 1 Tom Power 1 Tom Acoustic 1
42 F#1F#2 Hi-Hat Closed 1 Hi-Hat Closed Power 1 Hi-Hat Closed Power+Edge 1 Hi-Hat Closed Acoustic 1
43 G1 G2 Floor Tom H Tom Power 2 Tom Power 2 Tom Acoustic 2
44 G#1G#2 Hi-Hat Pedal 1 Hi-Hat Pedal Power 1 Hi-Hat Pedal Power 1 Hi-Hat Pedal Acoustic 1
45 A1 A2 Low Tom Tom Power 3 Tom Power 3 Tom Acoustic 3
46 A#1A#2 Hi-Hat Open 1 Hi-Hat Open Power 1 Hi-Hat Open Power 1 Hi-Hat Open Acoustic 1
47 B1 B2 Mid Tom L Tom Power 4 Tom Power 4 Tom Acoustic 4
48 C2 C3 Mid Tom H Tom Power 5 Tom Power 5 Tom Acoustic 5
49 C#2C#3 Crash Cymbal 1 Crash Cymbal Acoustic 1 Crash Cymbal Acoustic 1 Crash Cymbal Acoustic 1
50 D2 D3 High Tom Tom Power 6 Tom Power 6 Tom Acoustic 6
51 D#2D#3 Ride Cymbal 1 Ride Cymbal Acoustic 1 Ride Cymbal Acoustic 1 Ride Cymbal Acoustic 1
52 E2 E3 Chinese Cymbal China Cymbal Acoustic China Cymbal Acoustic China Cymbal Acoustic
53 F2 F3 Ride Cymbal Cup
54 F#2F#3 Ta m bo u ri n e Tambourine Tambourine Tam b ou ri n e
55 G2 G3 Splash Cymbal Splash Cymbal Acoustic Splash Cymbal Acoustic Splash Cymbal Acoustic
56 G#2G#3 Cowbell Cowbell Cowbell Cowbell
57 A2 A3 Crash Cymbal 2 Crash Cymbal Acoustic 2 Crash Cymbal Acoustic 2 Crash Cymbal Acoustic 2
58 A#2A#3 Vibraslap Vibraslap Vibraslap Vibraslap
59 B2 B3 Ride Cymbal 2 Ride Cymbal Acoustic 2 Ride Cymbal Acoustic 2 Ride Cymbal Acoustic 2
60 C3 C4 Bongo H Bongo H Bongo H Bongo H
61 C#3C#4 Bongo L Bongo L Bongo L Bongo L
62 D3 D4 Conga H Mute Conga H Mute Conga H Mute Conga H Mute
63 D#3D#4 Conga H Open Conga H Open Conga H Open Conga H Open
64 E3 E4 Conga L Conga L Conga L Conga L
65 F3 F4 Timbale H Timbale H Timbale H Timbale H
66 F#3F#4 Timbale L Timbale L Timbale L Timbale L
67 G3 G4 Agogo H Agogo H Agogo H Agogo H
68 G#3G#4 Agogo L Agogo L Agogo L Agogo L
69 A3 A4 Cabasa Cabasa Cabasa Cabasa
70 A#3A#4 Maracas Maracas Maracas Maracas
71 B3 B4 Samba Whistle H Samba Whistle H Samba Whistle H Samba Whistle H
72 C4 C5 Samba Whistle L Samba Whistle L Samba Whistle L Samba Whistle L
73 C#4C#5 Guiro Short Guiro Short Guiro Short Guiro Short
74 D4 D5 Guiro Long Guiro Long Guiro Long Guiro Long
75 D#4D#5 Claves Claves Claves Claves
76 E4 E5 Wood Block H Wood Block H Wood Block H Wood Block H
77 F4 F5 Wood Block L Wood Block L Wood Block L Wood Block L
78 F#4F#5 Cuica Mute Cuica Mute Cuica Mute Cuica Mute
79 G4 G5 Cuica Open Cuica Open Cuica Open Cuica Open
80 G#4G#5 Tria ngl e M ut e 2 Triangle Mute 2 Triangle Mute 2 Triangle Mute 2
81 A4 A5 Triangle Open 2 Triangle Open 2 Triangle Open 2 Triangle Open 2
82 A#4A#5 Shaker Shaker Shaker Shaker
83 B4 B5 Jingle Bells Jingle Bells Jingle Bells Jingle Bells
84 C5 C6 Bell Tree Wind Chime Wind Chime Wind Chime
85 C#5C#6
86 D5 D6
87 D#5D#6
88 E5 E6
89 F5 F6
90 F#5F#6
91 G5 G6
Note
Full Name
Key
(*1)
Off
Alt
Group
(*2)
Ride Cymbal Cup Acoustic
Full Name
Key
(*1)
Off
Alt
Group
(*2)
Full Name
Ride Cymbal Cup Acoustic Ride Cymbal Cup Acoustic
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
22
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name RockKit RealDrums ChineseMixKit SFXKit1
MSB-LSB-PC# (1–128) 127-0-91 127-0-92 127-0-128 126-0-1
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Surdo Mute 3 Surdo Mute 3 Surdo Mute 3
14 D-1 D0 Surdo Open 3 Surdo Open 3 Surdo Open 3
15 D#-1 D#0 Hi Q Hi Q Hi Q
16 E-1 E0 Whip Slap Whip Slap Whip Slap
17 F-1 F0 Scratch H 4 Scratch H 4 Scratch H 4
18 F#-1 F#0 Scratch L 4 Scratch L 4 Scratch L 4
19 G-1 G0 Finger Snap Finger Snap Finger Snap
20 G#-1 G#0 Click Noise Click Noise Click Noise
21 A-1 A0 Metronome Click Metronome Click Metronome Click
22 A#-1 A#0 Metronome Bell Metronome Bell Metronome Bell
23 B-1 B0 Seq Click L Seq Click L Seq Click L
24 C0 C1 Seq Click H Seq Click H Seq Click H
25 C#0C#1 Brush Tap Brush Tap Brush Tap
26 D0 D1 Brush Swirl Brush Tap Swirl Brush Swirl
27 D#0D#1 Brush Slap Brush Slap Brush Slap
28 E0 E1 Brush Tap Swirl Brush Tap Swirl Brush Tap Swirl
29 F0 F1 Snare Roll Rock Snare Roll Rock Snare Roll
30 F#0F#1 Castanet Castanet Castanet
31 G0 G1 Snare Soft Rock Snare Tight Snare Soft
32 G#0G#1 Sticks Sticks Sticks
33 A0 A1 Kick Soft Rock Kick Genuine Kick Soft
34 A#0A#1 Rim Rock Rim Real Open Rim Shot
35 B0 B1 Kick Rock Heavy Kick Real 1 Kick Tight
36 C1 C2 Kick Rock Kick Real 2 Kick Cutting Noise 1
37 C#1C#2 Stick Rock Stick Real Side Stick Cutting Noise 2
38 D1 D2 Snare Rock Snare Real 1 Snare
39 D#1D#2 Hand Clap Power Clap Power Hand Clap String Slap
40 E1 E2 Snare Dry Rock Snare Real 2 Snare Tight
41 F1 F2 Tom Rock 1 Tom Real 1 Floor Tom L
42 F#1F#2 Hi-Hat Closed Rock 1 Hi-Hat Closed Real 1 Hi-Hat Closed 1
43 G1 G2 Tom Rock 2 Tom Real 2 Floor Tom H
44 G#1G#2 Hi-Hat Pedal Rock 1 Hi-Hat Pedal Real 1 Hi-Hat Pedal 1
45 A1 A2 Tom Rock 3 Tom Real 3 Low Tom
46 A#1A#2 Hi-Hat Open Rock 1 Hi-Hat Open Real 1 Hi-Hat Open 1
47 B1 B2 Tom Rock 4 Tom Real 4 Mid Tom L
48 C2 C3 Tom Rock 5 Tom Real 5 Mid Tom H
49 C#2C#3 Crash Cymbal Acoustic 1 Crash Cymbal Real 1 Crash Cymbal 1
50 D2 D3 Tom Rock 6 Tom Real 6 High Tom
51 D#2D#3 Ride Cymbal Acoustic 1 Ride Cymbal Real 1 Ride Cymbal 1
52 E2 E3 China Cymbal Acoustic China Cymbal Real China Cymbal Flute Key Click
53 F2 F3
54 F#2F#3 Ta m bo u ri n e Tambourine Tambourine
55 G2 G3 Splash Cymbal Acoustic Splash Cymbal Real Splash Cymbal
56 G#2G#3 Cowbell Cowbell Cowbell
57 A2 A3 Crash Cymbal Acoustic 2 Crash Cymbal Real 2 Crash Cymbal 2
58 A#2A#3 Vibraslap Vibraslap Vibraslap
59 B2 B3 Ride Cymbal Acoustic 2 Ride Cymbal Real 2 Ride Cymbal 2
60 C3 C4 Bongo H Bongo H Bongo H
61 C#3C#4 Bongo L Bongo L Bongo L
62 D3 D4 Conga H Mute Conga H Mute Conga H Mute
63 D#3D#4 Conga H Open Conga H Open Conga H Open
64 E3 E4 Conga L Conga L Conga L
65 F3 F4 Timbale H Timbale H Timbale H
66 F#3F#4 Timbale L Timbale L Timbale L
67 G3 G4 Agogo H Agogo H Dagu Mute 4
68 G#3G#4 Agogo L Agogo L Zhongcha Mute 5 Shower
69 A3 A4
70 A#3A#4 Maracas Maracas Zhongcha Open 5 Wind
71 B3 B4
72 C4 C5
73 C#4C#5
74 D4 D5
75 D#4D#5 Claves Claves Xiaocha Open 6
76 E4 E5 Wood Block H Wood Block H Bangzi
77 F4 F5 Wood Block L Wood Block L Muyu Low
78 F#4F#5 Cuica Mute Cuica Mute Zhongluo Mute 7
79 G4 G5 Cuica Open Cuica Open Muyu Mid-Low
80 G#4G#5 Tria ngl e M ut e 2 Triangle Mute 2 Zhongluo Open 7
81 A4 A5 Triangle Open 2 Triangle Open 2 Muyu Middle
82 A#4A#5 Shaker Shaker Xiaoluo Open
83 B4 B5 Jingle Bells Jingle Bells Muyu Mid-High
84 C5 C6 Wind Chime Wind Chime Muyu High Dog
85 C#5C#6 Horse
86 D5 D6 Bird Tweet
87 D#5D#6
88 E5 E6
89 F5 F6
90 F#5F#6 Ghost
91 G5 G6 Maou
Note
Full Name
Ride Cymbal Cup Acoustic
Cabasa Cabasa Dagu Heavy 4 Thunder
Samba Whistle H Samba Whistle H Paigu Middle Stream
Samba Whistle L Samba Whistle L Paigu Low Bubble
Guiro Short Guiro Short Xi aocha Mute 6 Feed
Guiro Long Guiro Long Bangu
Key
(*1)
Off
Alt
Group
(*2)
Full Name
Ride Cymbal Cup Real Ride Cymbal Cup
Key
(*1)
Off
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
23
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name SFXKit2 NoisesKit TurkishPercKit1 TurkishPercKit2
MSB-LSB-PC# (1–128) 126-0-2 126-0-9 126-0-10 126-0-11
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Bendir Suat Tek 1 Bendir Suat Tek 1
14 D-1 D0 Bendir Suat Dum Bendir Suat Dum
15 D#-1 D#0 Bendir Suat Tek 2 Bendir Suat Tek 2
16 E-1 E0 Bendir Suat Kap Bendir Suat Kap
17 F-1 F0 Bendir Suat Tek 3 Bendir Suat Tek 3
18 F#-1 F#0 Emn Bendir Tek1 Emn Bendir Tek 1
19 G-1 G0 Emn Bendir Dum Emn Bendir Dum
20 G#-1 G#0 Emn Bendir Tek2 Emn Bendir Tek 2
21 A-1 A0 Emn Bendir Kapali Emn Bendir Kapali
22 A#-1 A#0 Emn Bendir Tek3 Emn Bendir Tek 3
23 B-1 B0 Emn Bendir Tek4 Emn Bendir Tek 4
24 C0 C1 Ayt Def Parmak Zil Dum Ayt Def Parmak Zil Dum
25 C#0C#1 Ayt Def Parmak Zil Roll Ayt Def Parmak Zil Roll
26 D0 D1 Ayt Def Parmak Zil Tek2 Ayt Def Parmak Zil Tek2
27 D#0D#1 Ayt Def Parmak Zil Tek3 Ayt Def Parmak Zil Tek3
28 E0 E1 Ayt Def Parmak Zil Tek4 Ayt Def Parmak Zil Tek4
29 F0 F1 Mc Parmak Def Dum Mc Parmak Def Dum
30 F#0F#1 Mc Parmak Def Roll Mc Parmak Def Roll
31 G0 G1 Mc Parmak Def Tek 1 Mc Parmak Def Tek 1
32 G#0G#1 Mc Parmak Def Tek 2 Mc Parmak Def Tek 2
33 A0 A1 Mc Parmak Def Tek 3 Mc Parmak Def Tek 3
34 A#0A#1 Mc Parmak Def Tek 4 Mc Parmak Def Tek 4
35 B0 B1 Mc Parmak Def Kenar Udu Dum 1
36 C1 C2 Phone Call White Noise Ayt Open Def Dum Ayt Open Def Dum
37 C#1C#2 Door Squeak Pink Noise Ayt Open Def Roll Ayt Open Def Roll
38 D1 D2 Door Slam White Noise Down 1 Ayt Open Def Tokat Ayt Open Def Tokat
39 D#1D#2 Scratch Cut Pink Noise Down 1 Ayt Open Def Tek 1 Ayt Open Def Tek 1
40 E1 E2 Scratch Split Whi te Noise Down 2 Ayt Open Def Tek 2 Ayt Open Def Tek 2
41 F1 F2 Wind Chime Pink Noise Down 2 T Drbk Dum Udu Dum 2
42 F#1F#2 Telephone Ring White Noise Up 2 T Drbk Roll Udu Bass Tek 2
43 G1 G2 White Noise Up 1 T Drbk Tok Udu Bass Tek 3
44 G#1G#2 Pink Noise Up T Drbk Tek 1 Udu Bass Tek 4
45 A1 A2 White Noise Up Release T Drbk Tek 2 Udu Bass Tek 5
46 A#1A#2 Pink Noise Up Release T Drbk Tek 3 Udu High Tek 1
47 B1 B2 White Noise Up LFO T Drbk Tek 4 Udu High Tek 2
48 C2 C3 Pink Noise Up LFO Ayt Alm Tek 1 Mc Kemik Def Left Dum
49 C#2C#3 Ayt Alm Tek 2 Mc Kemik Def Left Tek1
50 D2 D3 Ayt Alm Tek 3 Mc Kemik Def Left Tek2
51 D#2D#3 Ayt Alm Tek 4 Mc Kemik Def Left Tek3
52 E2 E3 Car Engine Ignition Ayt Alm Tek 5 Mc Kemik Def Left Tek4
53 F2 F3 Car Tires Squeal Suat Darbuka Dum Suat Darbuka Dum
54 F#2F#3 Car Passing Suat Darbuka Roll Suat Darbuka Roll
55 G2 G3 Car Crash Suat Darbuka Tokat Suat Darbuka Tokat
56 G#2G#3Siren Suat Darbuka Tek1 Suat Darbuka Tek1
57 A2 A3 Train Suat Darbuka Tek2 Suat Darbuka Tek2
58 A#2A#3Jet Plane Suat Darbuka Tek3 Suat Darbuka Tek3
59 B2 B3 Starship Suat Darbuka Tek4 Udu High Tek 3
60 C3 C4 Burst Cajon List Cajon List
61 C#3C#4 Roller Coaster Tsm Mix List Tsm Mix List
62 D3 D4 Submarine Art Bass Bendir Dum Hallo Stereo Dum
63 D#3D#4
64 E3 E4
65 F3 F4 MC Bass Darbuka Dum MC Bass Darbuka Dum
66 F#3F#4
67 G3 G4
68 G#3G#4Laugh
69 A3 A4 Scream
70 A#3A#4 Punch MC Bass Darbuka Tek3 MC Bass Darbuka Tek3
71 B3 B4 Heart Beat
72 C4 C5 Foot Steps
73 C#4C#5
74 D4 D5
75 D#4D#5 Dansoz Zili 4 Ayt Alm Tek 3
76 E4 E5 Ayt Darbuka Roll2 Ayt Darbuka Roll2
77 F4 F5 Ayt Darbuka Dum Ayt Darbuka Dum
78 F#4F#5 Ayt Darbuka Roll1 Ayt Darbuka Roll1
79 G4 G5 Ayt Darbuka Tok Ayt Darbuka Tok
80 G#4G#5 Ayt Darbuka Tek1 Ayt D arbuka Tek1
81 A4 A5 Ayt Darbuka Tek2 Ayt Darbuka Tek2
82 A#4A#5 Ayt Darbuka Tek3 Ayt D arbuka Tek3
83 B4 B5 Ayt Darbuka Tek4 Ayt Darbuka Tek4
84 C5 C6 Machine Gun Ayt Darbuka Tek5 Ayt D arbuka Tek5
85 C#5C#6Laser Gun Art Bass Bendir Tek2 Ayt Alm Tek 4
86 D5 D6 Explosion Ayt Darbuka Trak2 MC Kemik Def List
87 D#5D#6 Firework Ayt Alm Roll 2 Ayt Alm Roll 2
88 E5 E6
89 F5 F6
90 F#5F#6 Ayt Alm Roll 1 Ayt Alm Roll 1
91 G5 G6 Ayt Alm Tokat Ayt Alm Tokat
Note
Full Name
Key
(*1)
Off
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Hallo Stereo Kapali Hallo Stereo Kapali
Art Bass Bendir Tek1 Udu High Tek 4
MC Bass Darbuka Roll1 MC Bass Darbuka Roll1
MC Bass Darbuka Tokat MC Bass Darbuka Tokat
MC Bass Darbuka Tek1 MC Bass Darbuka Tek1
MC Bass Darbuka Tek2 MC Bass Darbuka Tek2
MC Bass Darbuka Tek4 MC Bass Darbuka Tek4
Dansoz Zili 1 Udu High Tek 5
Dansoz Zili 2 Ayt Alm Tek 1
Dansoz Zili 3 Ayt Alm Tek 2
Ayt Alm Dum2 Art Bass Bendir Tek1
Ayt Alm Dum1 Ayt Alm Dum1
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
24
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name TurkishPercKit3 TurkishPercKit4 2TelliKit AnkaraKit
MSB-LSB-PC# (1–128) 126-0-12 126-0-13 126-0-14 126-0-15
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Bendir Suat Tek 1 Bendir Suat Tek 1 Cirpak Darbuka 1 Tek2 Bendir Suat Tek 1
14 D-1 D0 Bendir Suat Dum Bendir Suat Dum Cirpak Darbuka 1 Tek3 Bendir Suat Dum
15 D#-1 D#0 Bendir Suat Tek 2 Bendir Suat Tek 2 Cirpak Darbuka 1 Tek4 Bendir Suat Tek 2
16 E-1 E0 Bendir Suat Kap Bendir Suat Kap Dansoz Zili 1 Bendir Suat Kap
17 F-1 F0 Bendir Suat Tek 3 Bendir Suat Tek 3 Grup Davul Dum 1 Bendir Suat Tek 3
18 F#-1 F#0 Dansoz Zili 1 Emn Bendir Tek1 Dansoz Zili 2 Emn Bendir Tek1
19 G-1 G0 Dansoz Zili 2 Emn Bendir Dum Grup Davul Dum 2 Emn Bendir Dum
20 G#-1 G#0 Dansoz Zili 3 Emn Bendir Tek 2 Grup Davul Tek 1 Emn Bendir Tek2
21 A-1 A0 Dansoz Zili 4 Emn Bendir Kapali Grup Davul Tek 2 Emn Bendir Kapali
22 A#-1 A#0 Suat Drbk Tokat Emn Bendir Tek 3 Grup Davul Tek 3 Emn Bendir Tek3
23 B-1 B0 Ayt Alm Tek 1 Emn Bendir Tek 4 Grup Davul Tek 4 Emn Bendir Tek4
24 C0 C1 Ayt Open Def Dum Ayt Open Def Dum Ayt Open Def Dum Ayt Open Def Dum
25 C#0C#1 Ayt Alm Tek 2 Ayt Open Def Roll Ayt Open Def Roll Ayt Open Def Roll
26 D0 D1 Ayt Open Def Tokat Ayt Open Def Tokat Ayt Open Def Tokat Ayt Open Def Tokat
27 D#0D#1 Ayt Open Def Tek 1 Ayt Open Def Tek 1 Ayt Open Def Tek 1 Ayt Open Def Tek 1
28 E0 E1 Ayt Open Def Tek 2 Ayt Open Def Tek 2 Ayt Open Def Tek 2 Ayt Open Def Tek 2
29 F0 F1 T Drbk Dum Dansoz Zili 1 T Drbk Dum T Drbk Dum
30 F#0F#1 Ayt Alm Tek 3 Dansoz Zili 2 Dansoz Zili 3 T Drbk Roll
31 G0 G1 T Drbk Tok Dansoz Zili 3 Dansoz Zili 4 T Drbk Tok
32 G#0G#1 Ayt Alm Tek 4 Dansoz Zili 4 T Drbk Tek 1 T Drbk Tek 1
33 A0 A1 Tsm Mix Dum Suat Darbuka Dum T Drbk Tek 2 T Drbk Tek 2
34 A#0A#1 Tsm Mix Kapalı 2 Suat Darbuka Roll T Drbk Tek 3 T Drbk Tek 3
35 B0 B1 Tsm Mix Tek1 Suat Darbuka Tokat Stereo Bendir Dum T Drbk Tek 4
36 C1 C2 EQ Darbuka Tir 3 Suat Darbuka Tek 1 Stereo Bendir Kap EQ Darbuka Tir 3
37 C#1C#2 EQ Darbuka Tir 2 EQ Darbuka Tir 2 Stereo Bendir Tek1 EQ Darbuka Tir 2
38 D1 D2 Tsm Mix Tek 2 EQ Darbuka Tir 1 Stereo Bendir Tek2 Dansoz Zili 2
39 D#1D#2 Tsm Mix Tek 3 EQ Darbuka Roll 2 EQ Darbuka Roll 2 Dansoz Zili 3
40 E1 E2 Tsm Mix Tek 4 EQ Darbuka Dum 2 EQ Darbuka Dum2 Dansoz Zili 4
41 F1 F2 EQ Darbuka Dum1 EQ Darbuka Dum 1 EQ Darbuka Dum1 Suat Darbuka Dum
42 F#1F#2 EQ Darbuka Roll 1 EQ Darbuka Roll 1 EQ Darbuka Roll 1 Suat Darbuka Tok
43 G1 G2 EQ Darbuka Tokat EQ Darbuka Tokat EQ Darbuka Tokat Suat Darbuka Tek5
44 G#1G#2 EQ Darbuka Tek01 EQ Darbuka Tek 01 EQ Darbuka Tek01 EQ Darbuka Tek 01
45 A1 A2 EQ Darbuka Tek02 EQ Darbuka Tek 02 EQ Darbuka Tek02 EQ Darbuka Tek 02
46 A#1A#2 EQ Darbuka Tek03 EQ Darbuka Tek 03 EQ Darbuka Tek03 EQ Darbuka Tek 03
47 B1 B2 EQ Darbuka Tek04 EQ Darbuka Tek 04 EQ Darbuka Tek04 EQ Darbuka Tek 04
48 C2 C3 EQ Darbuka Tek05 EQ Darbuka Tek 05 EQ Darbuka Rak 1 EQ Darbuka Tek 05
49 C#2C#3 EQ Darbuka Tek06 EQ Darbuka Tek 06 EQ Darbuka Tek10 EQ Darbuka Tek 06
50 D2 D3 EQ Darbuka Tek07 Suat Darbuka Tek 2 Cirpak Darbuka 1 Roll EQ Darbuka Tek 07
51 D#2D#3 EQ Darbuka Tek08 Suat Darbuka Tek 3 Cirpak Darbuka 1 Dum EQ Darbuka Tek 08
52 E2 E3 EQ Darbuka Tek09 Suat Darbuka Tek 4 Vlk Davul Dum 2 EQ Darbuka Tek 09
53 F2 F3 EQ Darbuka Tek10 EQ Darbuka Tek 10 Vlk Davul Dum 1 EQ Darbuka Tek 10
54 F#2F#3 EQ Darbuka Rak 1 EQ Darbuka Rak 1 Vlk Davul Roll1 EQ Darbuka Rak 1
55 G2 G3 EQ Darbuka Rak 2 EQ Darbuka Rak 2 Vlk Davul Tek 1 EQ Darbuka Rak 2
56 G#2G#3 EQ Darbuka Rak 3 EQ Darbuka Rak 3 Vlk Davul Tek 2 EQ Darbuka Rak 3
57 A2 A3 EQ Darbuka Twin 1 EQ Darbuka Twin 1 Vlk Davul Tek 3 EQ Darbuka Twin 1
58 A#2A#3 EQ Darbuka Twin 2 EQ Darbuka Twin 2 Vlk Davul Tek 4 EQ Darbuka Twin 2
59 B2 B3 EQ Darbuka Tram 3 EQ Darbuka Tram 3 Vlk Davul Tek 5 EQ Darbuka Tram 3
60 C3 C4 EQ Darbuka Tram 2 E Q Darbuka Tram 2 Vlk Davul Tek 6 EQ Darbuka Tram 2
61 C#3C#4 EQ Darbuka Tram 1 EQ Darbuka Tram 1 Tsm Mix Dum EQ Darbuka Tram 1
62 D3 D4 Hallo Stereo Dum Ayt Alm Tek 1 Sm Davul Dum Hallo Stereo Dum
63 D#3D#4 Hallo Stereo Kapali Ayt Alm Tek 2 Sm Davul Tek1 Hallo Stereo Kapali
64 E3 E4 MC Bass Darbuka Roll2 Ayt Alm Tek 3 Sm Davul Tek2 Kasik Klik
65 F3 F4 MC Bass Darbuka Dum MC Bass Darbuka Dum Sm Davul Tek3 Kasik 1
66 F#3F#4 MC Bass Darbuka Roll1 MC Bass Darbuka Roll1 Sm Davul Tek4 Kasik 2
67 G3 G4 MC Bass Darbuka Tokat MC Bass Darbuka Tokat Sm Davul Tek5 Kasik 3
68 G#3G#4 MC Bass Darbuka Tek1 MC Bass Darbuka Tek1 Tsm Mix Tek1 Kasik 4
69 A3 A4 MC Bass Darbuka Tek2 MC Bass Darbuka Tek2 N Davul Dum3 Ayt Alm Tek 1
70 A#3A#4 MC Bass Darbuka Tek3 MC Bass Darbuka Tek3 Ams Davul Dum 1 Ayt Alm Tek 2
71 B3 B4 MC Bass Darbuka Tek4 MC Bass Darbuka Tek4 Tsm Mix Tek2 Ayt Alm Tek 3
72 C4 C5 Grup Davul THM mix List Ayt Alm Tek 4 Ams Davul Tek 1 Ayt Alm Tek 4
73 C#4C#5 Arbane Grup Art Bass List Tsm Mix Dum Ams Davul Tek 2 Finger Left 6
74 D4 D5 Ayt Darbuka Trak2 Tsm Mix Tek1 Ams Davul Tek 3 Finger Left 5
75 D#4D#5 Ayt Darbuka Roll2 Ayt Darbuka Roll2 Ams Davul Tek 4 Finger Left 4
76 E4 E5 Ayt Darbuka Trak1 Tsm Mix Tek2 Tsm Mix Tek3 Finger Left 3
77 F4 F5 Ayt Darbuka Dum Ayt Darbuka Dum Cirpak Darbuka 2 Dum Finger Left 2
78 F#4F#5 Ayt Darbuka Roll1 Ayt Darbuka Roll1 Cirpak Darbuka 2 Roll Finger Left 1
79 G4 G5 Ayt Darbuka Tok Ayt Darbuka Tok Cirpak Darbuka 2 Tok Ayt Comlek Finger7
80 G#4G#5 Ayt Darbuka Tek1 Ayt Darbuka Tek1 Cirpak Darbuka 2 Tek1 Ayt Comlek Finger6
81 A4 A5 Ayt Darbuka Tek2 Ayt Darbuka Tek2 Tsm Mix Tek4 Ayt Comlek Finger5
82 A#4A#5 Ayt Darbuka Tek3 Ayt Darbuka Tek3 N Davul Dum2 Ayt Comlek Finger4
83 B4 B5 Ayt Darbuka Tek4 Ayt Darbuka Tek4 P Davul Dum Cr Ayt Comlek Finger3
84 C5 C6 Darbuka Finger List Ayt Darbuka Tek5 P Davul Dum Ayt Comlek Finger2
85 C#5C#6 Eq Darbuka Finger List Eq Darbuka Finger List P Davul Dum Tek1 Ayt Comlek Finger1
86 D5 D6 Ayt Comlek Darbuka Finger Tsm Mix Tek3 P Davul Dum Tek2
87 D#5D#6 Ayt Alm Roll 2 Ayt Alm Roll 2 N Davul Dum3 Ayt Alm Roll 2
88 E5 E6 Ayt Alm Dum2 Tsm Mix Tek4 N Davul Tek1 Ayt Alm Dum2
89 F5 F6 Ayt Alm Dum1 Ayt Alm Dum1 N Davul Tek3 Ayt Alm Dum1
90 F#5F#6 Ayt Alm Roll 1 Ayt Alm Roll 1 N Davul Tek4 Ayt Alm Roll 1
91 G5 G6 Ayt Alm Tokat Ayt Alm Tokat N Davul Tk1 Ayt Alm Tokat
Note
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
25
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name Ant-MrshKit AzeriPerc EthnicKit DavulMixKit
MSB-LSB-PC# (1–128) 126-0-16 126-0-17 126-0-18 126-0-19
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Bendir Suat Tek 1 Bendir Suat Tek 1 Bendir Suat Tek 1 Ayt Def Parmak Zil Tek2
14 D-1 D0 Bendir Suat Dum Bendir Suat Dum Bendir Suat Dum Ayt Def Parmak Zil Tek3
15 D#-1 D#0 Bendir Suat Tek 2 Bendir Suat Tek 2 Bendir Suat Tek 2 Ayt Def Parmak Zil Tek4
16 E-1 E0 Bendir Suat Kap Bendir Suat Kap Bendir Suat Kap
17 F-1 F0 Bendir Suat Tek 3 Bendir Suat Tek 3 Bendir Suat Tek 3 Grup Davul Dum 1
18 F#-1 F#0 Ams Bendir Tek1 Emn Bendir Tek1 Emn Bendir Tek1 Grup Davul Dum Cr
19 G-1 G0 Ams Bendir Dum Emn Bendir Dum Emn Bendir Dum Grup Davul Dum 2
20 G#-1 G#0 Ams Bendir Tek2 Emn Bendir Tek2 Emn Bendir Tek2 Grup Davul Tek 1
21 A-1 A0 Ams Bendir Kapama Emn Bendir Kapali Emn Bendir Kapali Grup Davul Tek 2
22 A#-1 A#0 Ams Bendir Tek3 Emn Bendir Tek3 Emn Bendir Tek3 Grup Davul Tek 3
23 B-1 B0 Grup Davul-THM mix List Emn Bendir Tek4 Emn Bendir Tek4 Grup Davul Tek 4
24 C0 C1 Ayt Open Def Dum Ayt Def Parmak Zil Dum Ayt Def Parmak Zil Dum Ayt Open Def Dum
25 C#0C#1 Ayt Open Def Roll Ayt Def Parmak Zil Roll Ayt Def Parmak Zil Roll Ayt Open Def Roll
26 D0 D1 Ayt Open Def Tokat Ayt Def Parmak Zil Tek2 Ayt Def Parmak Zil Tek2 Ayt Open Def Tokat
27 D#0D#1 Ayt Open Def Tek 1 Ayt Def Parmak Zil Tek3 Ayt Def Parmak Zil Tek3 Ayt Open Def Tek 1
28 E0 E1 Ayt Open Def Tek 2 Ayt Def Parmak Zil Tek4 Ayt Def Parmak Zil Tek4 Ayt Open Def Tek 2
29 F0 F1 Ams Def Dum Mc Parmak Def Dum Mc Parmak Def Dum T Drbk Dum
30 F#0F#1 Ams Def Roll2 Mc Parmak Def Roll Mc Parmak Def Roll T Drbk Roll
31 G0 G1 Ams Def Tek1 Mc Parmak Def Tek 1 Mc Parmak Def Tek 1 T Drbk Tok
32 G#0G#1 Ams Def Tek2 Mc Parmak Def Tek 2 Mc Parmak Def Tek 2 T Drbk Tek 1
33 A0 A1 Ams Def Tek3 Mc Parmak Def Tek 3 Mc Parmak Def Tek 3 T Drbk Tek 2
34 A#0A#1 Ams Def Tek4 Mc Parmak Def Tek 4 Mc Parmak Def Tek 4 T Drbk Tek 3
35 B0 B1 T Drbk Tek 4 Mc Parmak Def Kenar Mc Parmak Def Kenar T Drbk Tek 4
36 C1 C2 EQ Darbuka Tir 3 Ayt Open Def Dum Ayt Open Def Dum Dansoz Zili 1
37 C#1C#2 EQ Darbuka Tir 2 Ayt Open Def Roll Ayt Open Def Roll Dansoz Zili 2
38 D1 D2 EQ Darbuka Tir 1 Ayt Open Def Tokat Ayt Open Def Tokat Dansoz Zili 3
39 D#1D#2 EQ Darbuka Roll 2 Ayt Open Def Tek 1 Ayt Open Def Tek 1 Dansoz Zili 4
40 E1 E2 EQ Darbuka Dum 2 Ayt Open Def Tek 2 Ayt Open Def Tek 2 Ayt Def Parmak Zil Dum
41 F1 F2 EQ Darbuka Dum 1 T Drbk Dum Udu Dum 2 EQ Darbuka Dum1
42 F#1F#2 EQ Darbuka Roll 1 T Drbk Roll Udu Bass Tek 2 Ayt Def Parmak Zil Tek1
43 G1 G2 EQ Darbuka Tokat T Drbk Tok Udu Bass Tek 3 EQ Darbuka Tokat
44 G#1G#2 EQ Darbuka Tek 01 T Drbk Tek 1 Udu Bass Tek 4 EQ Darbuka Tek01
45 A1 A2 EQ Darbuka Tek 02 T Drbk Tek 2 Udu Bass Tek 5 EQ Darbuka Tek02
46 A#1A#2 EQ Darbuka Tek 03 T Drbk Tek 3 Udu High Tek 1 Stereo Bendir Dum
47 B1 B2 EQ Darbuka Tek 04 T Drbk Tek 4 Udu High Tek 2 Stereo Bendir Kap
48 C2 C3 EQ Darbuka Tek 05 Mc Kemik Def Left Dum Udu High Tek 3 Stereo Bendir Tek1
49 C#2C#3 Ayt Alm Tek 1 Mc Kemik Def Left Tek1 Udu High Tek 4 Stereo Bendir Tek2
50 D2 D3 Ayt Alm Tek 2 Mc Kemik Def Left Tek2 Udu High Tek 5 Hallo Stereo Dum
51 D#2D#3 Ayt Alm Tek 3 Mc Kemik Def Left Tek3 Udu High Tek 6 Hallo Stereo Kapali
52 E2 E3 Ayt Alm Tek 4 Mc Kemik Def Left Tek4 Arbane Dum Vlk Davul Dum 2
53 F2 F3 Ayt Alm Tek 5 Davul Hand Dum Arbane Kenar Tek 1 Vlk Davul Dum 1
54 F#2F#3 EQ-Darbuka Rak 1 Davul Hand Roll Arbane Kapama Vlk Davul Roll1
55 G2 G3 Tsm Mix Dum Davul Hand Tek1 Arbane Kenar Tek 2 Vlk Davul Tek 1
56 G#2G#3 Tsm Mix Tek2 Davul Hand Tek2 Arbane Kenar Tek 3 Vlk Davul Tek 2
57 A2 A3 Tsm Mix Tek3 Davul Hand Tek3 Arbane Tek 1 Vlk Davul Tek 3
58 A#2A#3 Tsm Mix Tek4 Davul Hand Tek4 Arbane Tek 2 Vlk Davul Tek 4
59 B2 B3 Finger L 5 Davul Hand Tek5 Arbane Tek 3 Vlk Davul Tek 5
60 C3 C4 Finger L 3 Davul Hand Tek6 Arbane Tek 4 Vlk Davul Tek 6
61 C#3C#4 Finger L 1 Hallo Stereo Dum Cajon Dum 1 Sm Davul Roll
62 D3 D4 Art Bass Bendir Dum Hallo Stereo Kapali Cajon Tir 1 Sm Davul Dum
63 D#3D#4 Art Bass Bendir Tek1 Art Doli Tir2 Cajon Dum 2 Sm Davul Tek1
64 E3 E4 MC Bass Darbuka Roll2 Art Doli Dum 2 Cajon Tek 1 Sm Davul Tek2
65 F3 F4 MC Bass Darbuka Dum Ar t Doli Dum 1 Cajon Tek 2 Sm Davul Tek3
66 F#3F#4 MC Bass Darbuka Roll1 Art Doli Tir1 Cajon Tek 3 Sm Davul Tek4
67 G3 G4 MC Bass Darbuka Tokat Art Doli Tek 1 Cajon Tek 5 Sm Davul Tek5
68 G#3G#4 MC Bass Darbuka Tek1 Art Doli Tek 2 Cajon Tek 6 Sm Davul Dum Cr
69 A3 A4 MC Bass Darbuka Tek2 Art Doli Tek 3 Talking Drum Dum 1 N Davul Dum3
70 A#3A#4 MC Bass Darbuka Tek3 Art Doli Tek 4 Talking Drum Dum 2 Ams Davul Dum 1
71 B3 B4 MC Bass Darbuka Tek4 Art Doli Tek 5 Talking Drum Tek 1 Ams Davul Dum 2
72 C4 C5 Art Bass Bendir Tek2 Ar t Doli Tek 6 Talking Drum Tek 2 Ams Davul Tek 1
73 C#4C#5
74 D4 D5 Ayt Darbuka Trak2 Art Doli Tek 8 Talking Drum Tek 4 Ams Davul Tek 3
75 D#4D#5 Ayt Darbuka Roll2 Art Doli Tek 9 Talking Drum Figur 1 N Davul C Dum3
76 E4 E5 Ayt Darbuka Trak1 Ayak 1 Arbane Grup Dum 1 Mc Kemik Def Right Dum
77 F4 F5 Ayt Darbuka Dum Ayak 2 Art Bass Bendir Dum Mc Kemik Def Right Tek1
78 F#4F#5 Ayt Darbuka Roll1 Ayak 3 Art Bass Bendir Tek1 Mc Kemik Def Right Tek2
79 G4 G5 Ayt Darbuka Tok Ayak 4 Art Bass Bendir Kapalı Mc Kemik Def Right Tek3
80 G#4G#5 Ayt Darbuka Tek1 Udu Dum 1 Grup Davul Tek 4 Mc Kemik Def Right Tek4
81 A4 A5 Ayt Darbuka Tek2 Udu Bass Tek 5 Bass Bendir Dum N Davul Dum2
82 A#4A#5 Ayt Darbuka Tek3 Udu High Tek 1 Arbane Grup Ken 1 N Davul Dum3
83 B4 B5 Ayt Darbuka Tek4 Udu High Tek 2 Arbane Grup Ken 1 N Davul Tek1
84 C5 C6 Ayt Darbuka Tek5 Udu High Tek 3 Bass Bendir Tek1 N Davul Tek2
85 C#5C#6 Ayt Darbuka Roll3 Udu High Tek 4 Bass Bendir Tek2 N Davul Tek3
86 D5 D6 Ayt Darbuka Hand Roll Udu High Tek 5 Bass Bendir Tek3 N Davul Tek4
87 D#5D#6 Ayt Alm Roll 2 Udu High Tek 6 Bass Bendir Tek4 N Davul Tek5
88 E5 E6 Ayt Alm Dum2 Tsm Mix Tek1 Grup Davul Tek 1 N Davul Tk1
89 F5 F6 Ayt Alm Dum1 Tsm Mix Tek2 Grup Davul Tek 2 N Davul Tk2
90 F#5F#6 Ayt Alm Roll 1 Tsm Mix Tek3 Grup Davul Dum 1 N Davul Tk3
91 G5 G6 Ayt Alm Tokat Tsm Mix Tek4 Grup Davul Tek 3 N Davul Tk
Note
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Art Doli Tek 7 Talking Drum Tek 3 Ams Davul Tek 2
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
26
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name DavulKit BassDrumKit ReverseBDKit ArabicKit2 (Legacy)
MSB-LSB-PC# (1–128) 126-0-20 126-0-21 126-0-22 126-0-36
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Bendir Suat Tek 1 BD Electro Reverse BD Electro
14 D-1 D0 Bendir Suat Dum BD FX Gate Reverse BD Fx Gate
15 D#-1 D#0 Bendir Suat Tek 2 BD Hammer Reverse BD Hammer
16 E-1 E0 Bendir Suat Kap BD Analog Power
17 F-1 F0 Bendir Suat Tek 3 BD Analog Distortion 5
18 F#-1 F#0 Emn Bendir Tek1 BD Analog Distor tion 6
19 G-1 G0 Emn Bendir Dum BD Analog Distortion 4
20 G#-1 G#0 Emn Bendir Tek2 BD Analog Distortion 3
21 A-1 A0 Emn Bendir Kapali BD Analog Distortion 2
22 A#-1 A#0 Emn Bendir Tek3 BD Analog Tight Reverse BD Analog Tight
23 B-1 B0 Emn Bendir Tek4 BD Analog 94 Reverse BD Analog 94
24 C0 C1 Dansoz Zili 1 BD Analog Blip 2 Reverse BD Analog Blip 2 Nakarazan Dom
25 C#0C#1 Dansoz Zili 2 BD Analog Rubber 2
26 D0 D1 Dansoz Zili 3 BD Analog 93 Reverse BD Analog 93 Nakarazan Edge
27 D#0D#1 Dansoz Zili 4 BD Analog 90 Reverse BD Analog 90 Hager Dom
28 E0 E1 Ayt Open Def Tek 1 BD Analog 83 Reverse BD Analog 83 Hager Edge
29 F0 F1 T Drbk Dum BD Analog 82 Reverse BD Analog 82 Bongo H
30 F#0F#1 T Drbk Roll BD Analog 92 Bongo L
31 G0 G1 T Drbk Tok BD Analog 91 Reverse BD Analog 91 Conga H Mute
32 G#0G#1 T Drbk Tek 1 BD Analog Deep Reverse BD Analog Deep Conga H Open
33 A0 A1 T Drbk Tek 2 BD Analog Hard 2 Conga L
34 A#0A#1 T Drbk Tek 3 BD Analog Hard 1
35 B0 B1 T Drbk Tek 4 BD Analog Blip 1 Reverse BD Analog Blip 1 Zagrouda L
36 C1 C2 Ayt Alm Tek 1 BD Analog Rubber 1
37 C#1C#2 Ayt Alm Tek 2 BD Analog Loose Reverse BD Analog Loose Side Stick
38 D1 D2 Ayt Alm Tek 3 BD Synth 1 Reverse BD Synth 1 Snare Soft
39 D#1D#2 Ayt Alm Tek 4 BD Synth 2 Reverse BD Synth 2 Arabic Hand Clap
40 E1 E2 Ayt Alm Tek 5 BD Analog Distortion 1
41 F1 F2 Tsm Mix Kap1 Ripper Reverse Ripper Floor Tom L
42 F#1F#2 Tsm Mix Dum BD Analog 70 L Hi-Hat Closed 1
43 G1 G2 Tsm Mix Kap2 BD Analog 70 Reverse BD Analog 70 Floor Tom H
44 G#1G#2 Tsm Mix Tek1 BD Analog 80 Reverse BD Analog 81 Hi-Hat Pedal 1
45 A1 A2 Tsm Mix Tek2 BD Analog 80 Long Low Tom
46 A#1A#2 Tsm Mix Tek3 BD Dry Reverse BD Dry Hi-Hat Open 1
47 B1 B2 Tsm Mix Tek4 BD Dry Hard Mid Tom L
48 C2 C3 Hallo Stereo Dum BD Room 1 Mid Tom H
49 C#2C#3 Hallo Stereo Kapali BD Soft Reverse BD Soft Crash Cymbal 1
50 D2 D3 N Davul Tk BD Room 2 Reverse BD Room 2 High Tom
51 D#2D#3 Sm Davul Dum BD Break Lo-fi 2 Reverse BD Break Lo-fi 2 Ride Cymbal 1
52 E2 E3 Sm Davul Roll BD Break Lo-fi 1 Reverse BD Break Lo-fi 1 Crash Cymbal 2
53 F2 F3 Sm Davul Tek1 BD & Hi-Hat Open
54 F#2F#3 Sm Davul Tek2 BD Jungle 2 Ta mb o ur in e
55 G2 G3 Sm Davul Tek3 BD Jungle 1 Duhulla Tak
56 G#2G#3 Sm Davul Tek4 BD Jungle 3 Reverse BD Jungle 3 Cowbell
57 A2 A3 Sm Davul Tek5 BD D&B 1 Reverse BD D&B 1 Duhulla Sak
58 A#2A#3 Sm Davul Dum Cr BD D&B 2 Reverse BD D&B 2 Claves
59 B2 B3 EQ Darbuka Tram 3 BD RX5 1 Reverse BD RX5 1 Doff Dom
60 C3 C4 EQ Darbuka Tram 2 BD RX5 2 Reverse BD RX5 2 Katem Dom
61 C#3C#4 EQ Darbuka Tram 1 BD Room 3 Reverse BD Room 3 Katem Tak
62 D3 D4 BD Power Gate Reverse BD Power Gate Katem Sak
63 D#3D#4 Vlk Davul Roll2 BD R&B 1 Reverse BD R&B 1 Katem Tak
64 E3 E4 Vlk Davul Dum 2 BD R&B 2 Reverse BD R&B 2 Doff Tak
65 F3 F4 Vlk Davul Dum 1 BD Lo-fi Reverse BD Lo-fi Tabla Dom
66 F#3F#4 Vlk Davul Roll1 BD Hip Deep
67 G3 G4 Vlk Davul Tek 1 BD Break Deep Reverse BD Break Deep Tabla Tik
68 G#3G#4 Vlk Davul Tek 2 BD Break Heavy Reverse BD Break Heavy Tabla Tak 2
69 A3 A4 Vlk Davul Tek 3 BD Break Hard Reverse BD Break Hard Tabla Sak
70 A#3A#4 Vlk Davul Tek 4 Big Drum Reverse Big Drum Tabla Roll Edge
71 B3 B4 Vlk Davul Tek 5 Taiko Drum Reverse Taiko Drum Tabla Flam
72 C4 C5 Vlk Davul Tek 6 Surdo Open Reverse Surdo Open Sagat 1
73 C#4C#5 Vlk Davul Tik Feet 2 Reverse Feet 2 Tabel Dom
74 D4 D5 Ayt Darbuka Trak2 BD Industrial Reverse Tom Industrial Sagat 3
75 D#4D#5 Ayt Darbuka Roll2 Door Slam Reverse Door Slam Tabel Tak
76 E4 E5 Ayt Darbuka Trak1 Punch Reverse Punch Sagat 2
77 F4 F5 Ayt Darbuka Dum Heart
78 F#4F#5 Ayt Darbuka Roll1 Feet 1 Reverse Feet 1 Rik Tak 2
79 G4 G5 Ayt Darbuka Tok BD Human Reverse BD Human Rik Finger 1
80 G#4G#5 Ayt Darbuka Tek1 BD Human Deep Reverse BD Human Deep Rik Tak 1
81 A4 A5 Ayt Darbuka Tek2 Vox Buh! Reverse Vox Buh! Rik Finger 2
82 A#4A#5 Ayt Darbuka Tek3 Vox Muh! Reverse Vox Muh! Rik Brass Tremolo
83 B4 B5 Ayt Darbuka Tek4 Rik Sak
84 C5 C6 Ayt Darbuka Tek5 Rik Tik
85 C#5C#6 Ayt Darbuka Roll3
86 D5 D6 Ayt Darbuka Hand Roll
87 D#5D#6 Ayt Alm Roll 2
88 E5 E6 Ayt Alm Dum2
89 F5 F6 Ayt Alm Dum1
90 F#5F#6 Ayt Alm Roll 1
91 G5 G6 Ayt Alm Tokat
Note
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Reverse BD Analog Power
Reverse BD Analog Distor tion 6
Reverse BD Analog Distor tion 3
Reverse BD Analog Distor tion 2
Reverse BD Analog Rubber 2
Reverse BD Analog Hard 1
Reverse BD Analog Rubber 1
Reverse BD Analog Distor tion 1
Reverse BD & Hi-Hat Open
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Cabasa
Zagrouda H
Kick Soft
Snare Drum
Duhulla Dom
Tabla Tak 1
Rik Dom
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
27
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name ArabicKit1 (Legacy) KhaligiKit (Legacy) IranianKit (Legacy) CubanKit
MSB-LSB-PC# (1–128) 126-0-37 126-0-38 126-0-39 126-0-41
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Zarb Back mf Khaligi Bongo L Dom
14 D-1 D0 Zarb Tom f Khaligi Bongo L Tak
15 D#-1 D#0 Zarb Eshareh Khaligi Bongo H Sak
16 E-1 E0 Zarb Whipping Khaligi Bongo H Dom
17 F-1 F0 Tombak Tom f Tabel Lewa H Sak
18 F#-1 F#0 Neghareh Tom f Khaligi Bongo Snap
19 G-1 G0 Tombak Back f Tabel Lewa H Dom
20 G#-1 G#0 Neghareh Back f Lewa Cymbal 2
21 A-1 A0 Tombak Snap f Tabel Lewa Bg Dom 6
22 A#-1 A#0 Neghareh Pelang f Lewa Cymbal 1 Conga H Tip
23 B-1 B0 Tombak Trill Tabel Lewa Bg Tak 6 Conga H Heel
24 C0 C1 Khaligi Clap 1 Tablah Big Dom 1 1 Conga H Open
25 C#0C#1 Arabic Zalgouta Open Tablah Big Tak 1 Conga H Mute
26 D0 D1 Khaligi Clap 2 Tablah Big Sak 1 1 Conga H Slap Open
27 D#0D#1 Arabic Zalgouta Close Tablah Big Dom 2 2 Conga H Slap
28 E0 E1 Arabic Hand Clap Tablah Big Tak 2 Conga H Slap Mute
29 F0 F1 Tabel Tak 1 Tablah Big Sak 2 2 Conga L Tip
30 F#0F#1 Sagat 1 Tablah Smll Snp 2 Conga L Heel
31 G0 G1 Tabel Dom Tablah Small Dom 3 Conga L Open
32 G#0G#1 Sagat 2 Tablah Small Snap Conga L Mute
33 A0 A1 Tabel Tak 2 Tablah Small Tik 3 Conga L Slap Open
34 A#0A#1 Sagat 3 Tablah Small Sak 3 Conga L Slap
35 B0 B1 Riq Tik 3 Manjoor Conga L Sli de
36 C1 C2 Riq Tik 2 Twaisat 1 4 Daf Tom
37 C#1C#2 Riq Tik Hard 1 Twaisat 4 Open 4 Daf Chain Up
38 D1 D2 Riq Tik 1 Twaisat 5 Open 4 Daf Back Bongo H Rim
39 D#1D#2 Riq Tik Hard 2 Twaisat 2 4 Daf Chain Down Bongo H Tip
40 E1 E2 Riq Tik Hard 3 Tar Low Dom 1 Daf Chap Bongo H Heel
41 F1 F2 Riq Tish Tar Low Sak 1 Daf Full Roll Bongo H Slap
42 F#1F#2 Riq Snouj 2 Tar Segal Dom Daf Chain Roll
43 G1 G2 Riq Roll Tar Low Dom 2 Daf Whipping Roll
44 G#1G#2 Riq Snouj 1 Tar Segal Tak Clap Bongo L Rim
45 A1 A2 Riq Sak Tar Low Dom 2 Finger Snap 1 Bongo L Tip
46 A#1A#2 Riq Snouj 3 Tar Segal Sak Neghareh Roll Bongo L Heel
47 B1 B2 Riq Snouj 4 Arabic Hand Clap Neghareh Tom Bongo L Slap
48 C2 C3 Riq Tak 1 Tar High Dom 1 Neghareh Snap Timbale L
49 C#2C#3 Riq Brass 1 Tar High Sak 1 Neghareh Chap
50 D2 D3 Riq Tak 2 Tar High Dom 2 Neghareh Eshareh
51 D#2D#3 Riq Brass 2 Tar High Sak 2 Neghareh Back
52 E2 E3 Riq Dom Khaligi Clap 1 Kurdish Dohol Low
53 F2 F3 Katem Tak Doff Khaligi Clap 2 Kurdish Dohol High Paila L
54 F#2F#3 Katem Dom Merwas Solo 1 Dom Kurdish Dohol L Bz Timbale H
55 G2 G3 Katem Sak 1 Merwas Solo 2 Dom Lurish Dohol Low
56 G#2G#3 Katem Tak 1 Merwas Solo 1 Sak Lurish Dohol L Bz
57 A2 A3 Katem Sak 2 Merwas Solo 2 Sak Lurish Dohol High
58 A#2A#3 Katem Tak 2 Merwas Solo 1 Tak Tombak Full Roll
59 B2 B3 Daholla Sak 2 Merwas Solo 2 Tak Tombak Timpani Rll Paila H
60 C3 C4 Daholla Sak 1 Tar Brshm Grp Dom Tombak Tom Cowbell Top
61 C#3C#4 Daholla Tak 1 Tar Brshm Grp Sak Tombak Eshareh R
62 D3 D4 Daholla Dom Tar Brshm Grp Tak Tombak Back
63 D#3D#4 Daholla Tak 2 Tar Brshm Sl Sak Tombak Eshareh L
64 E3 E4 Tablah Prok Tar Brshm Sl Dom Tombak Snap Guiro Short
65 F3 F4 Tablah Dom 2 Tar Brshm Sl Tak Zarb Tom Guiro Long
66 F#3F#4 Tablah Roll of Edge Yahla Dom 1 Zarb Whipping
67 G3 G4 Tablah Tak Finger 4 Yahla Tak 1 Zarb Back
68 G#3G#4 Tablah Tak Trill 1 Yahla Dom 2 Zarb Eshareh Tambourine
69 A3 A4 Tablah Tak Finger 3 Yahla Tak 2 Zarb Chap
70 A#3A#4 Tablah Tak Trill 2 Nagara High Zarb Full Roll
71 B3 B4 Tablah Tak Finger 2 Nagara Low Zarb Snap
72 C4 C5 Tablah Tak Finger 1 Zeer Low Dom 1 5 Zarb Whipping Rll Maracas
73 C#4C#5 Tablah Tik 2 Zeer Low Roll 5 Dayereh Roll Shaker
74 D4 D5 Tablah Tik 4 Zeer Low Dom 2 5 Dayereh Tom Cabasa
75 D#4D#5 Tablah Tik 3 Zeer High Roll 5 Dayereh Eshareh
76 E4 E5 Tablah Tik 1 Zeer Low Dom 2 5 Dayereh Back
77 F4 F5 Tablah Tak 3 Zeer High Dom 1 5 Dayereh Snap
78 F#4F#5 Tablah Tak 1 Tabel Low Dom Dayereh Edge Roll
79 G4 G5 Tablah Tak 4 Zeer High Dom 2 5
80 G#4G#5 Tablah Tak 2 Tabel Low Tak
81 A4 A5 Tablah Sak 2 Tabel High Dom
82 A#4A#5 Tablah Tremolo Tabel High Sak
83 B4 B5 Tablah Sak 1 Tabel High Tak
84 C5 C6 Tablah Dom 1 Tabel Low Sak
85 C#5C#6 Riq Tish
86 D5 D6 Tabel Mid Dom
87 D#5D#6 Riq Snouj 1
88 E5 E6 Tabel High Dom
89 F5 F6 Tabel Low Dom
90 F#5F#6
91 G5 G6
Note
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Bongo H Open One Finger
Bongo H Open Three Finger
Bongo L Open One Finger
Bongo L Open Three Finger
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
28
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name PopLatinKit ArabicMixKit KhaligiMixKit IranianMixKit
MSB-LSB-PC# (1–128) 126-0-44 126-0-65 126-0-66 126-0-67
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Cajon Low Conga Analog H Zalgouta Open Bongo H
14 D-1 D0 Cajon Slap Conga Analog M Bell Tree Bongo L
15 D#-1 D#0 Cajon Tip Conga Analog L Zalgouta Close Conga H Open
16 E-1 E0 Claves High Vibraslap Timbale H Conga L
17 F-1 F0 Claves Low Kick Techno L Timbale L Floor Tom L
18 F#-1 F#0 Hand Clap Side Stick Arabic Mix Conga H Mute Hi-Hat Closed 1
19 G-1 G0 Snare Techno Bongo H Floor Tom H
20 G#-1 G#0 Finger Snap Guiro Long Conga H Open Hi-Hat Pedal 1
21 A-1 A0 Castanet Kick Techno Q Bongo L Low Tom
22 A#-1 A#0 Conga H Tip Open Rim Shot Conga L Hi-Hat Open 1
23 B-1 B0 Conga H Heel Funk Snare 2 Shaker Ride Cymbal 1
24 C0 C1 Conga H Open Kick Arabic Mix Tablah Dom 1 Kick
25 C#0C#1 Conga H Mute Funk Snare 1 Tablah Tak Finger 3 Side Stick
26 D0 D1 Conga H Slap Open Snare Arabic Mix Tablah Tik 3 Snare
27 D#0D#1 Conga H Slap Hand Clap Tablah Tak Finger 4 Crash Cymbal 1
28 E0 E1 Conga H Slap Mute Snare Tablah Tik 4 Snare Tight
29 F0 F1 Conga L Tip Tom Electro 1 Tablah Tik 1 Khaligi Tablah Big Dom 1 2
30 F#0F#1 Conga L Heel Hi- Hat Closed Arabic Mix 1 Tablah Tremolo Khaligi Tablah Big Sak 1 2
31 G0 G1 Conga L Open Tom Electro 2 Cowbell Khaligi Tablah Big Tak 1
32 G#0G#1 Conga L Mute Hi-Hat Half Arabic Mix 1 Hand Clap Arabic Doholla Sak1
33 A0 A1 Conga L Slap Open Tom Electro 3 Tambourine Arabic Doholla Tom
34 A#0A#1 Conga L Slap Hi-Hat Open Arabic Mix 1 Snare Tight Arabic Doholla Tak2
35 B0 B1 Conga L Slide Tom Electro 4 Kick Analog Short Arabic Doholla Tak1
36 C1 C2
37 C#1C#2
38 D1 D2 Bongo H Rim Tom Electro 6 Snare Daf Back
39 D#1D#2 Bongo H Tip Hi-Hat Open 3 1 Crash Cymbal 2 Daf Chain Down
40 E1 E2 Bongo H Heel Reverse Cymbal Side Stick Daf Chap
41 F1 F2 Bongo H Slap Timbale L Floor Tom L Daf Full Roll
42 F#1F#2
43 G1 G2
44 G#1G#2 Bongo L Rim Conga H Mute Hi-Hat Pedal 1 Clap
45 A1 A2 Bongo L Tip Tambourine Low Tom Finger Snap 1
46 A#1A#2 Bongo L Heel Conga L Hi-Hat Open 1 Neghareh Roll
47 B1 B2 Bongo L Slap Cowbell Mid Tom L Neghareh Tom
48 C2 C3 Timbale L Claves Mid Tom H Neghareh Snap
49 C#2C#3 Bongo H Finger Snap 1 Neghareh Chap
50 D2 D3 Wood Block H Chinese Cymbal Neghareh Eshareh
51 D#2D#3 Bongo L Finger Snap 2 Neghareh Back
52 E2 E3 Wood Block L Riq Brass 2 Kurdish Dohol Lo
53 F2 F3 Paila L Kurdish Dohol Low f Riq Brass 1 Kurdish Dohol Hi
54 F#2F#3 Timbale H Cabasa Riq Tish Kurdsh Dohol L Bz
55 G2 G3 Kurdish Dohol High f Riq Snouj 1 Lurish Dohol Low
56 G#2G#3 Shaker Riq Roll Lurdsh Dohol L Bz
57 A2 A3 Snap 1 Riq Snouj 2 Lurish Dohol High
58 A#2A#3 Maracas Riq Sak 1 Tombak Full Roll
59 B2 B3 Paila H Snap 2 Riq Dom Tombak Timpani Roll
60 C3 C4 Cowbell Top Khaligi Twaisat 3 4 Riq Snouj 3 Tombak Tom
61 C#3C#4 Cowbell 1 Khaligi Twaisat 1 4 Tombak Back Tombak Eshareh R
62 D3 D4 Cowbell 2 Khaligi Twaisat 2 4 Tombak Tom Tombak Back
63 D#3D#4 Cowbell 3 Khaligi Twaisat 5 Open 4 Tombak Snap Tombak Eshareh L
64 E3 E4 Guiro Short Khaligi Twaisat 4 Open 4 Tombak Eshareh R Tombak Snap
65 F3 F4 Guiro Long Khaligi Tablah Small Dom 3 Claves Zarb Tom
66 F#3F#4 Metal Guiro Short
67 G3 G4 Metal Guiro Long Khaligi Tablah Small Snap Daf Tom Zarb Back
68 G#3G#4Tambourine
69 A3 A4 Tambourim Open Khaligi Tablah Small Sak 3 Triangle Mute 2 Zarb Chap
70 A#3A#4Tambourim Mute
71 B3 B4 Tambourim Tip Khaligi Tablah Small Tik 3 Triangle Open 2 Zarb Snap
72 C4 C5 Maracas Khaligi Tablah Big Dom 1 Neghareh Tom Zarb Whipping Rll
73 C#4C#5 Shaker Khaligi Tar Segal Dom Neghareh Back Dayereh Roll
74 D4 D5 Cabasa Khaligi Tablah Big Tak 1 Neghareh Roll Dayereh Tom
75 D#4D#5 Cuica Mute Khaligi Tar Segal Tak Neghareh Snap Dayereh Eshareh
76 E4 E5 Cuica Open Khaligi Tablah Big Sak 1 Wood Block H Dayereh Back
77 F4 F5 Cowbell High 1 Tablah Dom 1 Wood Block L Dayereh Snap
78 F#4F#5 Cowbell High 2 Tablah Tak 1 Zarb Back Dayereh Edge Roll
79 G4 G5 Shekere Tablah Tremolo Zarb Tom Twaisat 4 Open 4
80 G#4G#5 Shekere Tone Tablah Tak 2 Zarb Eshareh Twaisat 2 4
81 A4 A5 Triangle Mute 1 Tablah Tik 1 Zarb Whipping Twaisat 5 Open 4
82 A#4A#5 Triangle Open 1 Tablah Sak 1 Zarb Chap Twaisat 1 4
83 B4 B5 Tablah Tik 3 Hi-Hat Closed Anlog 1 Timbale H
84 C5 C6 Wind Chime Tablah Tik 2 Hi-Hat Open Anlog 1 Timbale L
85 C#5C#6 Tar Brshm Solo Sak
86 D5 D6 Tar High Sak 1
87 D#5D#6 Khishiba Dom 1
88 E5 E6 Khishiba Dom 2
89 F5 F6 Khishiba Sak 1
90 F#5F#6 Khishiba Dom 3
91 G5 G6 Khishiba Sak 2
Note
Full Name
Bongo H Open One Finger
Bongo H Open Three Finger
Bongo L Open One Finger
Bongo L Open Three Finger
Key
(*1)
Off
Alt
Group
(*2)
Full Name
Tom Electro 5 Kick Daf Tom
Crash Cymbal 1 Crash Cymbal 1 Daf Chain Up
Conga H Open Hi-Hat Closed 1 Daf Chain Roll
Timbale H Floor Tom H Daf Whipping Roll
Khaligi Tar Barashim Group Dom
Khaligi Tar Barashim Group Sak
Khaligi Tar Barashim Group Tak
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Daf Chap Zarb Whipping
Daf Full Roll Zarb Eshareh
Daf Back Zarb Full Roll
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
29
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name TurkishKit A3000KhaligiKit1 A3000KhaligiKit2
MSB-LSB-PC# (1–128) 126-0-68 126-0-73 126-0-74
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Asma Davul Left Side Khaligi Bongo Low Dom 1 Sajat1 Open 1
14 D-1 D0 Asma Davul Right Side Khaligi Bongo Low Tak 1 Sajat1 Close 1
15 D#-1 D#0 Asma Davul Side Body Khaligi Bongo Low Sak 2 Sajat2 Open 2
16 E-1 E0 Asma Davul Both Sides Khaligi Bongo High Snap1 2 Sajat2 Close 2
17 F-1 F0 Koltuk Davul Flam Khaligi Bongo High Sak Sajat2 Hawan 2
18 F#-1 F#0 Koltuk Davul Teke Khaligi Bongo High Snap2 2 Req Open
19 G-1 G0 Koltuk Davul Tek Merjaf Group1 Dom 3 Req Sajat
20 G#-1 G#0 Koltuk Davul Dum Merjaf Group1 Sak 3 Req Dom 3
21 A-1 A0 Bendir Teke Flam Merjaf Group2 Dom 4 Req Sak 3
22 A#-1 A#0 Bendir Teke Dead Merjaf Group2 Tak Req Roll
23 B-1 B0 Bendir Tek Dead Merjaf Group2 Sak 4 Manjoor Normal
24 C0 C1 Bendir Teke Doholla1 Dom 5 Doholla2 Dom 4
25 C#0C#1 Bendir Tek Doholla1 Tak Doholla2 Tak
26 D0 D1 Bendir Slap 2 Doholla1 Sak 5 Doholla2 Sak 4
27 D#0D#1 Bendir Dum 2 Tabla1 Dom 6 Merwas Group Dom 5
28 E0 E1 Zil Right Close 3 Tabla1 Tak Merwas Group Sak 5
29 F0 F1 Zil Right Open 3 Tabla1 Sak 6 Merwas Group Tak
30 F#0F#1 Zil Left Close 4 Khaligi Conga Low Dom Merwas Dom 6
31 G0 G1 Zil Left Open 4 Tabla2 Dom 7 Merwas Sak 6
32 G#0G#1 Tef Teke Flam 5 Tabla2 Tak Merwas Tak
33 A0 A1 Tef Tek Mute 5 Tabla2 Tik Khaligi Hand Clap2
34 A#0A#1 Tef Teke Damped Tabla2 Sak 7 Khaligi Hand Clap3
35 B0 B1 Tef Tek Mute Medium Khaligi Hand Clap1 Khaligi Hand Clap4
36 C1 C2 Tef Dum Mute Marad Group1 Dom 8 Marad Group1 Dom 7
37 C#1C#2 Tef Cymbal 9 Marad Group1 Tak Marad Group1 Tak
38 D1 D2 Tef Cymbal Mute 9 Marad Group1 Sak 8 Marad Group1 Sak 7
39 D#1D#2 Tef Tremolo Marad Group2 Dom 9 Marad Group2 Dom 8
40 E1 E2 Tef Shake 1 Marad Group2 Tak Marad Group2 Tak
41 F1 F2 Tef Shake 2 Marad Group2 Sak 9 Marad Group2 Sak 8
42 F#1F#2 Tef Tek Flam Marad1 Dom 10 Kaser Flam
43 G1 G2 Tef Full Open Marad1 Tak Kaser Dom1 9
44 G#1G#2 Tef Teke Open Short Marad1 Sak 10 Kaser Sak1 9
45 A1 A2 Tef Tek Open Short Marad2 Dom 11 Kaser Dom2 10
46 A#1A#2 Tef Tek Open Marad2 Tak Kaser Sak2 10
47 B1 B2 Tef Dum Open Marad2 Sak 11 Taar Barashim Shake
48 C2 C3 Hollo Finger Dead Sajat1 Open 12 Rana Low1 Dom 11
49 C#2C#3 Hollo Slap Sajat1 Close 12 Rana Low2 Dom 12
50 D2 D3 Hollo Dum Sajat2 Open 13 Rana Low1 Tak
51 D#2D#3 Kasik 1 Sajat2 Close 13 Rana Low2 Tak
52 E2 E3 Kasik Flam 1 Sigal Marad Dom 14 Rana Low1 Sak 11
53 F2 F3 Bass Darbuka Tek Dead Sigal Marad Tak Rana Low2 Sak 12
54 F#2F#3 Bass Darbuka Tek Flam Sigal Marad Sak 14 Rana High1 Dom 13
55 G2 G3 Bass Darbuka Teke Taar Barashim Group1 Dom 15 Rana High2 Dom 14
56 G#2G#3
57 A2 A3
58 A#2A#3 Bass Darbuka Tek Taar Barashim Group2 Sak 16 Rana High1 Sak 13
59 B2 B3 Bass Darbuka Slap Taar Barashim Group2 Dom 16 Rana High2 Sak 14
60 C3 C4
61 C#3C#4 Bass Darbuka Dum 7 Taar Barashim1 Dom 17 Medando2 Dom 16
62 D3 D4 Darbuka Roll Close 6 Taar Barashim1 Sak 17 Medando1 Sak 15
63 D#3D#4 Darbuka Roll Open 6 Taar Barashim2 Dom 18 Medando2 Sak 16
64 E3 E4
65 F3 F4 Darbuka Tek Dead Sigal Taar Barashim Dom 19 Mesando Dom 17
66 F#3F#4 Darbuka Tek Damped Sigal Taar Barashim Tak Mesando Sak1 17
67 G3 G4 Darbuka Teke Open Flam Sigal Taar Barashim Sak 19 Mesando Sak2 17
68 G#3G#4 Darbuka Teke Open Taar Barashim Shake Schekanka Dom 18
69 A3 A4
70 A#3A#4
71 B3 B4 Darbuka Tek 1 Zeer1 Flam Tanak Dom 1
72 C4 C5
73 C#4C#5
74 D4 D5 Darbuka Tek 2 Zeer2 Dom2 Khaligi Conga High Sak1 19
75 D#4D#5 Darbuka Slap Medium Zeer3 Tak1 Khaligi Conga High Sak2 19
76 E4 E5 Darbuka Slap 8 Zeer3 Dom1 Khaligi Conga Low Dom 20
77 F4 F5 Darbuka Dum 8 Zeer3 Dom2 Khaligi Conga Low Sak 20
78 F#4F#5Bongo Tek Roll Zeer3 Tak2 Ras Low Dom 21
79 G4 G5 Bongo Flam Tabol Low Dom 20 Ras High Dom
80 G#4G#5 Bo ng o Te k F lam Tab ol Lo w Ta k Ra s L ow S a k 2 1
81 A4 A5 Bongo Tek Tabol Low Sak 20 Sigal Marad Dom 22
82 A#4A#5 Bongo Slap Tabol High Dom 21 Sigal Marad Tak
83 B4 B5 Bongo Flam Hi Tabol High Tak Sigal Marad Sak 22
84 C5 C6 Bongo Dum Tabol High Sak 21 Kasoor Dom 23
85 C#5C#6
86 D5 D6 Req Sajat Kheshba Dom 24
87 D#5D#6 Req Open Kheshba Sak 24
88 E5 E6
89 F5 F6
90 F#5F#6 Khaligi Conga High Dom 23 Jahla Dom 26
91 G5 G6 Khaligi Conga High Sak 23 Jahla Sak 26
Note
Full Name
Bass Darbuka Teke Other Finger
Bass Darbuka Teke Index Finger
Bass Darbuka Slap Medium
Darbuka Teke Damped Flam
Darbuka Teke Other Finger 1
Darbuka Teke Index Finger 1
Darbuka Teke Other Finger 2
Darbuka Teke Index Finger 2
Key
Alt
Off
Group
(*1)
(*2)
7 Taar Barashim Group2 Tak Medando1 Dom 15
Full Name
Taar Barashim Group1 Sak 15 Rana High1 Tak
Taar Barashim Group1 Tak Rana High2 Tak
Taar Barashim2 Sak 18 Medando Flam
Manjoor Normal Schekanka Sak 1 18
Zeer1 Dom Schekanka Sak 2 18
Zeer2 Dom1 Tanak Dom 2
Zeer2 Flam Khaligi Conga High Dom 19
Req Dom 22 Kasoor Sak 23
Req Sak 22 Jahla Group Dom 25
Req Roll Jahla Group Sak 25
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
30
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name A3000MaghrebiKit A3000ArabicKit1 A3000IranianKit1
MSB-LSB-PC# (1–128) 126-0-75 126-0-76 126-0-77
MIDI
Keyboard
Note# Note
13 C#-1 C#0 Tunisian Tabel Dom1 Sagat1 Close Udho Tom Hole 1
14 D-1 D0 Tunisian Tabel Dom2 1 Sagat2 Close 1 Udho Tom Hole Stop 1
15 D#-1 D#0 Tunisian Tabel Tak1 Sagat2 Open 1 Udho Back1
16 E-1 E0 Tunisian Tabel Tak2 Sagat3 Close 2 Udho Back2
17 F-1 F0 Tunisian Tabel Tak3 1 Sagat3 Open 2 Udho Chap Body
18 F#-1 F#0 Tunisian Tabel Dom3 1 Mazhar Dom Open 3 Udho Chap Skin
19 G-1 G0 Tunisian Tabla Dom 2 Mazhar Dom Close Udho Chap Top Hole
20 G#-1 G#0 Tunisian Tabla Tak1 Mazhar Tak Close Udho Flam Skin
21 A-1 A0 Tunisian Tabla Tak2 Mazhar Tak Open Udho Flam Body
22 A#-1 A#0 Tunisian Tabla Sak 2 Mazhar Sak Close 3 Udho Roll Body
23 B-1 B0 Tunisian Tabla Tak Mute Katem Dom1 4 Udho Roll Skin
24 C0 C1 Tunisian Bendir1 Dom1 Katem Dom2 5 Tombak Tom
25 C#0C#1 Tunisian Bendir1 Dom2 Katem Tak Open1 Tombak Chap1
26 D0 D1 Tunisian Bendir1 Tak Close1 Katem Tak Open2 Tombak Chap2
27 D#0D#1 Tunisian Bendir1 Tak Open1 Katem Sak1 4 Tombak Back1
28 E0 E1 Tunisian Bendir1 Tak Open2 Katem Sak2 5 Tombak Nail Swish
29 F0 F1 Tunisian Bendir1 Tak Mute Tabel Saaidi Dom Tombak Edge
30 F#0F#1 Tunisian Bendir1 Tak Close2 Tabel Saaidi Tak Tombak Roll 8Fingers
31 G0 G1 Tunisian Bendir1 Tak Close3 Tabel Saaidi Rim Tombak Flam1
32 G#0G#1 Tunisian Bendir1 Tak Close4 Tabel Dom Tombak Flam2
33 A0 A1 Tunisian Bendir1 Tak Open3 Tabel Tak Tombak Flam Rim
34 A#0A#1 Tunisian Bendir1 Roll Tab el Tak W ood To mb ak B a ck 2
35 B0 B1 Tunisian Bendir2 Dom Roll Riq Dom Close Tombak Slap
36 C1 C2 Tunisian Bendir2 Dom Open Riq Dom Open Daf Tom
37 C#1C#2 Tunisian Bendir2 Dom Close Riq Tak Close1 Daf Chain Up
38 D1 D2 Tunisian Bendir2 Tak Small Riq Tak Open Daf Back
39 D#1D#2 Tunisian Bendir2 Tak Open1 Riq Tak Close2 Daf Chain Down
40 E1 E2 Tunisian Bendir2 Tak Open2 Riq Tak Snouj Daf Side No Chain
41 F1 F2 Tunisian Bendir2 Tak Mute Riq Sak1 Daf Roll
42 F#1F#2 Tunisian Bendir2 Tak Close1 Riq Snouj Close1 Daf Roll Chain
43 G1 G2 Tunisian Bendir2 Tak Close2 Riq Snouj Close2 Daf Roll Rim
44 G#1G#2 Tunisian Bendir2 Tak Close3 Riq Flam Daf Slap Open
45 A1 A2 Tunisian Bendir2 Tak Open3 RIq Sak2 Daf Slap Mute
46 A#1A#2 Tunisian Bendir2 Tak Open4 Riq Snouj Roll Naghareh Roll
47 B1 B2 Darbouka Finger Roll Darbuka Dom Left Hand Naghareh Tom
48 C2 C3 Darbouka Dom Darbuka Dom Right Hand 7 Naghareh Snap
49 C#2C#3 Darbouka Tak Close1 Darbuka Tak Left Index Finger Naghareh Side
50 D2 D3 Darbouka Tak Close2 Darbuka Tak Right Index Finger Naghareh Flam 3Fingers
51 D#2D#3 Darbouka Tak Open1 Darbuka Sak1 7 Naghareh Back
52 E2 E3 Darbouka Tak Open2 Darbuka Tak Left Ring Finger Dohol Gorz
53 F2 F3 Darbouka Tak Open3 Darbuka Tak Right Ring Finger Dohol Gorz & Tarkeh
54 F#2F#3 Darbouka Tak Open4 Darbuka Tap1 Dohol Tarkeh1
55 G2 G3 Darbouka Tak Close3 Darbuka Tap2 Dohol Tarkeh2
56 G#2G#3 Darbouka Tak Close4 Darbuka Flam1 7 Req Tom & Zang
57 A2 A3 Darbouka Tak Open5 Darbuka Flam2 7 Req Chap Zang Open
58 A#2A#3 Darbouka Tak Open6 Darbuka Tak Roll 7 Req Slap
59 B2 B3 Darbouka Hand Roll Daholla Dom Left Hand Tombak Tempo Roll
60 C3 C4 Moroccan Bendir1 Dom Open Daholla Dom Right Hand 8 Tombak Tempo Tom
61 C#3C#4 Moroccan Bendir1 Dom Close Daholla Tak1 Tombak Tempo Rim Flam
62 D3 D4 Moroccan Bendir1 Tik Open Daholla Tak2 Tombak Tempo Back 1 2
63 D#3D#4 Moroccan Bendir1 Tik Close1 Daholla Tak3 Tombak Tempo Back 2 2
64 E3 E4 Moroccan Bendir1 Tik Close2 Daholla Tak4 Tombak Tempo Rim 3
65 F3 F4 Moroccan Bendir1 Zim Daholla Sak 8 Tombak Tempo Rim Muted 3
66 F#3F#4 Moroccan Bendir2 Dom Open Daholla Rak1 Tombak Tempo Slap
67 G3 G4 Moroccan Bendir2 Dom Close Daholla Rak2 Zarb Back
68 G#3G#4 Moroccan Bendir2 Tik Close1 Daholla Flam1 Zarb Flam Open
69 A3 A4 Moroccan Bendir2 Tik Close2 Daholla Flam2 Zarb Rim
70 A#3A#4 Moroccan Bendir2 Tik Open Daholla Tak Roll Zarb Slap
71 B3 B4 Moroccan Bendir2 Zim Tabla Dom & Tak Zarb Roll
72 C4 C5 Moroccan Bendir3 Dom Open Tabla Dom 9 Dayereh Tom
73 C#4C#5 Moroccan Bendir3 Edge Open Tabla Tak1 Dayereh Tom Muted
74 D4 D5 Moroccan Bendir3 Tik Close Tabla Tak2 Dayereh Rim 1
75 D#4D#5 Moroccan Bendir3 Tik Open Tabla Tak3 Dayereh Rim Muted
76 E4 E5 Moroccan Bendir3 Tik Stop Tabla Tak4 Dayereh Rim 2
77 F4 F5 Moroccan Tamtam Low Tabla Sak 9 Dayereh Snap
78 F#4F#5 Moroccan Tamtam Hi Tabla Rak1 Dayereh Rim Edge
79 G4 G5 Moroccan Taarija1 Dom Tabla Rak2 Dayereh Soft Roll
80 G#4G#5 Moroccan Taarija1 Tik Tabla Flam1 Dayereh Tom Roll
81 A4 A5 Moroccan Taarija2 Dom Tabla Flam2 Dayereh Rim Roll
82 A#4A#5 Moroccan Taarija2 Tik Tabla Tak Roll Dayereh Flam Tom
83 B4 B5 Moroccan Taarija3 Dom Djembe Dom1 Dayereh Flam Back
84 C5 C6 Algerian Bendir Deza 3 Djembe Dom2 Iranian Bendir1 Tom 6
85 C#5C#6 Algerian Bendir Tak Droit 3 Djembe Tak1 Iranian Bendir1 Rim
86 D5 D6 Algerian Bendir Tak Guche 3 Djembe Tak2 Iranian Bendir1 Rim Edge
87 D#5D#6 Algerian Bendir Kaf 3 Djembe Flame Iranian Bendir1 Slap 6
88 E5 E6 Algerian Galal Daza 4 Djembe Flame & Tak Iranian Bendir1 Back
89 F5 F6 Algerian Galal Daza Gauche 5 Arabic Zalgouta Open Iranian Bendir1 Back Flam
90 F#5F#6 Algerian Galal Taka Droite 4 Arabic Zalgouta Close Iranian Bendir1 Edge
91 G5 G6 Algerian Galal Taka Gauche 5 Arabic Hand Clap Iranian Bendir1 Roll
Note
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
31
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardKit1 No Sound
Kit Name A3000ArabicKit2 A3000IranianKit2 IndianKit ChineseKit
MSB-LSB-PC# (1–128) 126-0-78 126-0-79 126-0-115 126-0-125
MIDI
Keyboard
Note# Note
13 C#-1 C#0
14 D-1 D0
15 D#-1 D#0 Indian Hand Clap
16 E-1 E0 Dafli Open
17 F-1 F0 Dafli Slap 1
18 F#-1 F#0 Dafli Rim 1
19 G-1 G0 Duff Open
20 G#-1 G#0 Duff Slap
21 A-1 A0 Duff Rim
22 A#-1 A#0 Hatheli Long 2
23 B-1 B0 Hatheli Short 2 Da Cha 2
24 C0 C1 Bendir Large Dom Open1 Baya ge 3 Da Gu mp 2
25 C#0C#1 Bendir Large Dom Open2 Baya ke 3 Da Gu Rim
26 D0 D1 Bendir Large Dom Close Baya ghe 3 Da Gu f 2
27 D#0D#1 Bendir Large Sak1 Baya ka 3 Da Gu Hand 2
28 E0 E1 Bendir Large Sak2 Castanet Flam1 Tabla na 4 Da Gu Roll 2
29 F0 F1 Bendir Large Tak Open1 Castanet Flam2 Tabla tin 4 Pai Gu 4
30 F#0F#1 Bendir Large Tak Open2 Castanet Left Normal Tablabaya dha 3 Pai Gu 4 High
31 G0 G1 Bendir Large Flam Castanet Left Mute Dhol 1 Open Pai Gu 3
32 G#0G#1 Bendir Large Flam Element1 Castanet Left Normal L&R Dhol 1 Slap 5 Pai Gu 3 High
33 A0 A1 Bendir Large Flam Element2 Castanet Left Mute L&R Dhol 1 Mute 5 Pai Gu 2
34 A#0A#1 Bendir Large Flam Element3 Castanet Right Normal Dhol 1 Open Slap 5 Pai Gu 2 High
35 B0 B1 Bendir Large Flam & Tak Castanet Right Mute Dhol 1 Roll Pai Gu 1
36 C1 C2 Nakrazan Dom Goosha Naghareh Low 1 Dandia Short 6 Luo High 1
37 C#1C#2 Nakrazan Flam Goosha Naghareh Low Rim 1 Dandia Long 6 Gong Batter
38 D1 D2 Nakrazan Tak 1 Goosha Naghareh Low Flam 1 Chutki Jin Luo
39 D#1D#2 Nakrazan Tak 2 Goosha Naghareh High1 2 Chipri Luo High 2
40 E1 E2 Nakrazan Tak 3 Goosha Naghareh High2 2 Khanjira Open Luo Mid-Low 5
41 F1 F2 Nakrazan Gliss Down pppp Goosha Naghareh High Rim 2 Khanjira Slap Luo
42 F#1F#2 Nakrazan Gliss Down ppp Goosha Naghareh High Flam 2 Khanjira Mute Jin Luo Low 5
43 G1 G2 Nakrazan Gliss Down pp Finger Cymbal Open Left 3 Khanjira Bendup Da Cha 1 5
44 G#1G#2 Nakrazan Gliss Down p Finger Cymbal Mute Left 3 Khanjira Benddown Da Cha Effect 5
45 A1 A2 Nakrazan Noise FX Finger Cymbal Open Right 4 Dholak 1 Open Zhong Cha
46 A#1A#2 Nakrazan Roll1 Finger Cymbal Mute Right 4 Dholak 1 Mute 7 Xiao Cha Effect 1
47 B1 B2 Nakrazan Roll2 Finger Cymbal Mute L&R 4 Dholak 1 Slap 7 Xiao Cha 1
48 C2 C3 Katem2 Dom1 1 Iranian Bendir2 Tom 5 Dhol 2 Open Mang Luo Low
49 C#2C#3 Katem2 Dom2 Iranian Bendir2 Rim1 Dhol 2 Slap 8 Mang Luo Mid
50 D2 D3 Katem2 Tak Open1 Iranian Bendir2 Rim2 5 Dhol 2 Rim 8 Qing
51 D#2D#3 Katem2 Tak Open2 Iranian Bendir2 Back Mridangam na 9 Finger Bell
52 E2 E3 Katem2 Sak 1 Iranian Bendir2 Slap 5 Mridangam din 9 Luo Big
53 F2 F3 Katem2 Sak Close1 Iranian Bendir2 Rim Edge Mridangam ki 9 Mu Yu Low
54 F#2F#3 Katem2 Sak Close2 Iranian Bendir2 Edge Mute Mridangam ta 9 Mu Yu Mid-Low
55 G2 G3 Katem2 Flam1 Iranian Bendir2 Flam Rim 5 Mridangam Chapu 9 Mu Yu Mid
56 G#2G#3 Katem2 Flam2 Iranian Bendir2 Flam Back Mridangam Lo Closed 10 Mu Yu High
57 A2 A3 Katem2 Tak Close1 Iranian Bendir2 Flam Tom 5 Mridangam Lo Open 10 Nan Bang Zi Roll 3
58 A#2A#3 Katem2 Tak Close2 Iranian Bendir2 Rim Roll Chimta Normal 11 Nan Bang Zi 3
59 B2 B3 Katem2 Trem Dom Iranian Bendir2 Roll Chimta Ring 11 Ban Gu 4
60 C3 C4 Katem Medium Dom Open1 2 Tempo Edge Tom 6 Dholki Hi Open 12 Ban 4
61 C#3C#4 Katem Medium Dom Open2 3 Tempo Rim 1 Dholki Hi Mute 12 Ban Gu Roll 4
62 D3 D4 Katem Medium Dom Close1 Tempo Tom 1 Dholki Lo Open 13 Chinese Opera Voice 1
63 D#3D#4 Katem Medium Dom Close2 Tempo Tom Slap 6 Dholki Hi Slap 12 Chinese Opera Voice 2
64 E3 E4 Katem Medium Tak1 Tempo Rim 2 Dholki Lo Slide 13 Chinese Opera Voice 3
65 F3 F4 Katem Medium Tak2 Tempo Tom 2 6 Khol Open 14 Yun Luo F4
66 F#3F#4 Katem Medium Sak1 3 Tempo Back Khol Slide Yun Luo F#4
67 G3 G4 Katem Medium Sak2 2 Tempo Side 1 Khol Mute 14 Yun Luo G4
68 G#3G#4 Katem Medium Flam Tempo Side 2 Manjira Open 15 Yun Luo G#4
69 A3 A4 Katem Medium Flam Element1 Tempo Flam Rim 6 Manjira Close 15 Yun Luo A4
70 A#3A#4 Katem Medium Flam Element2 Tempo Flam Side 6 Jhanji Open 16 Yun Luo A#4
71 B3 B4 Katem Medium Flam&Tak Tempo Roll Jhanji Close 16 Yun Luo B4
72 C4 C5 Katem Small Dom Open Tempo Flam Tom 6 Mondira Open 17 Yun Luo C5
73 C#4C#5 Katem Small Dom Close1 Tempo Snap Rim Mondira Close 17 Yun Luo C#5
74 D4 D5 Katem Small Dom Close2 Tempo Snap Rim Mute Indian Bhangra Scat 1 Yun Luo D5
75 D#4D#5 Katem Small Tak1 Tempo Mute Nail 1 Indian Bhangra Scat 2 Yun Luo D#5
76 E4 E5 Katem Small Tak2 Tempo Mute Nail 2 Indian Bhangra Scat 3 Yun Luo E5
77 F4 F5 Katem Small Sak Tempo Mute Nail 3 indian Bhangra Scat 4 Yun Luo F5
78 F#4F#5 Katem Small Flam Tempo Rim Roll Khomokh Normal Yun Luo F#5
79 G4 G5 Katem Small Flam Element1 Iranian Bongo Low Tom Khomokh Mute Yun Luo G5
80 G#4G#5 Katem Small Flam Element2 Iranian Bongo High Back Left Khomokh mltatk Yun Luo G#5
81 A4 A5 Katem Small Flam Element3 Iranian Bongo High Back Right Thavil Open Yun Luo A5
82 A#4A#5 Katem Small Flam & Tak Iranian Bongo High Mute Right Thavil Slap Yun Luo A#5
83 B4 B5 Katem Small Finger Tak Iranian Bongo Low Flam Thavil Mute Yun Luo B5
84 C5 C6 Iranian Bongo High Flam Khartaal Yun Luo C6
85 C#5C#6 Iranian Bongo Low Roll Dholak 2 Open 18
86 D5 D6 Iranian Bongo High Roll Dholak 2 Slide 18
87 D#5D#6 Zangooleh Roll Dholak 2 Rim 1
88 E5 E6 Zangooleh Shot Dholak 2 Rim 2
89 F5 F6 Dholak 2 Ring
90 F#5F#6 Dholak 2 Slap
91 G5 G6
Note
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
32
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardSet No Sound
GM2 Kit
Kit Name StandardSet RoomSet PowerSet ElectroSet
MSB-LSB-PC# (1–128) 120-0-1 120-0-9 120-0-17 120-0-25
MIDI
Keyboard
Note# Note
13 C#-1 C#0
14 D-1 D0
15 D#-1 D#0
16 E-1 E0
17 F-1 F0
18 F#-1 F#0
19 G-1 G0
20 G#-1 G#0
21 A-1 A0
22 A#-1 A#0
23 B-1 B0
24 C0 C1
25 C#0C#1
26 D0 D1
27 D#0D#1 High Q High Q High Q High Q
28 E0 E1 Slap Slap Slap Slap
29 F0 F1 Scratch Push 7 Scratch Push 7 Scratch Push 7 Scratch Push 7
30 F#0F#1 Scratch Pull 7 Scratch Pull 7 Scratch Pull 7 Scratch Pull 7
31 G0 G1 Sticks Sticks Sticks Sticks
32 G#0G#1 Square Click Square Click Square Click Square Click
33 A0 A1 Metronome Click Metronome Click Metronome Click Metronome Click
34 A#0A#1Metronome Bell Metronome Bell Metronome Bell Metronome Bell
35 B0 B1 Acoustic Bass Drum Acoustic Bass Drum Acoustic Bass Drum Acoustic Bass Drum
36 C1 C2 Bass Drum 1 Bass Drum 1 Power Kick Drum Electric Bass Drum
37 C#1C#2 Side Stick Side Stick Side Stick Side Stick
38 D1 D2 Acoustic Snare Acoustic Snare Power Snare Drum Electric Snare 1
39 D#1D#2 Hand Clap Hand Clap Hand Clap Hand Clap
40 E1 E2 Electric Snare Electric Snare Electric Snare Electric Snare 2
41 F1 F2 Low Floor Tom Room Low Tom 2 Power Low Tom 2 Electric Low Tom 2
42 F#1F#2 Closed Hi-hat 1 Closed Hi-hat 1 Closed Hi-hat 1 Closed Hi-hat 1
43 G1 G2 High Floor Tom Room Low Tom 1 Power Low Tom 1 Electric Low Tom 1
44 G#1G#2 Pedal Hi-hat 1 Pedal Hi-hat 1 Pedal Hi-hat 1 Pedal Hi-hat 1
45 A1 A2 Low Tom Room Mid Tom 2 Power Mid Tom 2 Electric Mid Tom 2
46 A#1A#2 Open Hi-hat 1 Open Hi-hat 1 Open Hi-hat 1 Open Hi-hat 1
47 B1 B2 Low-Mid Tom Room Mid Tom 1 Power Mid Tom 1 Electric Mid Tom 1
48 C2 C3 High Mid Tom Room Hi Tom 2 Power Hi Tom 2 Electric Hi Tom 2
49 C#2C#3 Crash Cymbal 1 Crash Cymbal 1 Crash Cymbal 1 Crash Cymbal 1
50 D2 D3 High Tom Room Hi Tom 1 Power Hi Tom 1 Electric Hi Tom 1
51 D#2D#3 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1
52 E2 E3 Chinese Cymbal Chinese Cymbal Chinese Cymbal Reverse Cymbal
53 F2 F3 Ride Bell Ride Bell Ride Bell Ride Bell
54 F#2F#3Tambourine Tambourine Ta mb ou r in e Ta m b ou r in e
55 G2 G3 Splash Cymbal Splash Cymbal Splash Cymbal Splash Cymbal
56 G#2G#3Cowbell Cowbell Cowbell Cowbell
57 A2 A3 Crash Cymbal 2 Crash Cymbal 2 Crash Cymbal 2 Crash Cymbal 2
58 A#2A#3 Vibra-slap Vibra-slap Vibra-slap Vibra-slap
59 B2 B3 Ride Cymbal 2 Ride Cymbal 2 Ride Cymbal 2 Ride Cymbal 2
60 C3 C4 High Bongo High Bongo High Bongo High Bongo
61 C#3C#4 Low Bongo Low Bongo Low Bongo Low Bongo
62 D3 D4 Mute Hi Conga Mute Hi Conga Mute Hi Conga Mute Hi Conga
63 D#3D#4 Open Hi Conga Open Hi Conga Open Hi Conga Open Hi Conga
64 E3 E4 Low Conga Low Conga Low Conga Low Conga
65 F3 F4 High Timbale High Timbale High Timbale High Timbale
66 F#3F#4 Low Timbale Low Timbale Low Timbale Low Timbale
67 G3 G4 High Agogo High Agogo High Agogo High Agogo
68 G#3G#4 Low Agogo Low Agogo Low Agogo Low Agogo
69 A3 A4 Cabasa Cabasa Cabasa Cabasa
70 A#3A#4 Maracas Maracas Maracas Maracas
71 B3 B4 Short Whistle 2 Short Whistle 2 Short Whistle 2 Short Whistle 2
72 C4 C5 Long Whistle 2
73 C#4C#5Short Guiro 3
74 D4 D5 Long Guiro 3
75 D#4D#5 Claves Claves Claves Claves
76 E4 E5 Hi Wood Block Hi Wood Block Hi Wood Block Hi Wood Block
77 F4 F5 Low Wood Block Low Wood Block Low Wood Block Low Wood Block
78 F#4F#5Mute Cuica 4Mute Cuica 4 Mute Cuica 4 Mute Cuica 4
79 G4 G5 Open Cuica 4 Open Cuica 4 Open Cuica 4 Open Cuica 4
80 G#4G#5 Mute Triangle 5 Mute Triangle 5 Mute Triangle 5 Mute Triangle 5
81 A4 A5 Open Triangle 5 Open Triangle 5 Open Triangle 5 Open Triangle 5
82 A#4A#5 Shaker Shaker Shaker Shaker
83 B4 B5 Jingle Bell Jingle Bell Jingle Bell Jingle Bell
84 C5 C6 Bell Tree Bell Tree Bell Tree Bell Tree
85 C#5C#6 Castanets Castanets Castanets Castanets
86 D5 D6 Mute Surdo 6 Mute Surdo 6 Mute Surdo 6 Mute Surdo 6
87 D#5D#6 Open Surdo 6 Open Surdo 6 Open Surdo 6 Open Surdo 6
88 E5 E6
89 F5 F6
90 F#5F#6
91 G5 G6
Note
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Long Whistle 2 Long Whistle 2 Long Whistle 2
Short Guiro 3 Short Guiro 3 Short Guiro 3
Long Guiro 3 Long Guiro 3 Long Guiro 3
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
(*1)
Off
Alt
Group
(*2)
PSR-A3000 Data List
33
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardSet No Sound
Kit Name AnalogSet JazzSet BrushSet OrchestraSet
MSB-LSB-PC# (1–128) 120-0-26 120-0-33 120-0-41 120-0-49
MIDI
Keyboard
Note# Note
13 C#-1 C#0
14 D-1 D0
15 D#-1 D#0
16 E-1 E0
17 F-1 F0
18 F#-1 F#0
19 G-1 G0
20 G#-1 G#0
21 A-1 A0
22 A#-1 A#0
23 B-1 B0
24 C0 C1
25 C#0C#1
26 D0 D1
27 D#0D#1 High Q High Q High Q Closed Hi-hat 2 1
28 E0 E1 Slap Slap Slap Pedal Hi-hat 1
29 F0 F1 Scratch Push 7 Scratch Push 7 Scratch Push 7 Open Hi-hat 2 1
30 F#0F#1 Scratch Pull 7 Scratch Pull 7 Scratch Pull 7Ride Cymbal 1
31 G0 G1 Sticks Sticks Sticks Sticks
32 G#0G#1 Square Click Square Click Square Click Square Click
33 A0 A1 Metronome Click Metronome Click Metronome Click Metronome Click
34 A#0A#1 Metronome Bell Metronome Bell Metronome Bell Metronome Bell
35 B0 B1 Acoustic Bass Drum Jazz Kick 2 Jazz Kick 2 Concert BD 2
36 C1 C2 Analog Bass Drum Jazz Kick 1 Jazz Kick 1 Concert BD 1
37 C#1C#2 Analog Rim Shot Side Stick Side Stick Side Stick
38 D1 D2 Analog Snare 1 Acoustic Snare Brush Tap Concert SD 1
39 D#1D#2 Hand Clap Hand Clap Brush Slap Castanets
40 E1 E2 Electric Snare Electric Snare Brush Swirl Concert SD 2
41 F1 F2 Analog Low Tom 2 Low Floor Tom Low Floor Tom Timpani F
42 F#1F#2 Analog CHH 1 1 Closed Hi-hat 1 Closed Hi-hat 1Timpani F#
43 G1 G2 Analog Low Tom 1 High Floor Tom High Floor Tom Timpani G
44 G#1G#2 Analog CHH 2 1 Pedal Hi-hat 1 Pedal Hi-hat 1 Timpani G#
45 A1 A2 Analog Mid Tom 2 Low Tom Low Tom Timpani A
46 A#1A#2Analog OHH 1Open Hi-hat 1 Open Hi-hat 1Timpani A#
47 B1 B2 Analog Mid Tom 1 Low-Mid Tom Low-Mid Tom Timpani B
48 C2 C3 Analog Hi Tom 2 High Mid Tom High Mid Tom Timpani c
49 C#2C#3Analog Cymbal Crash Cymbal 1 Crash Cymbal 1 Timpani c#
50 D2 D3 Analog Hi Tom 1 High Tom High Tom Timpani d
51 D#2D#3 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1 Timpani d#
52 E2 E3 Chinese Cymbal Chinese Cymbal Chinese Cymbal Timpani e
53 F2 F3 Ride Bell Ride Bell Ride Bell Timpani f
54 F#2F#3 Ta m bo u ri n e Tambourine Ta mb ou r in e Ta m b ou r in e
55 G2 G3 Splash Cymbal Splash Cymbal Splash Cymbal Splash Cymbal
56 G#2G#3 Analog Cowbell Cowbell Cowbell Cowbell
57 A2 A3 Crash Cymbal 2 Crash Cymbal 2 Crash Cymbal 2 Concert Cymbal 2
58 A#2A#3 Vibra-slap Vibra-slap Vibra-slap Vibra-slap
59 B2 B3 Ride Cymbal 2 Ride Cymbal 2 Ride Cymbal 2 Concert Cymbal 1
60 C3 C4 High Bongo High Bongo High Bongo High Bongo
61 C#3C#4 Low Bongo Low Bongo Low Bongo Low Bongo
62 D3 D4 Analog High Conga Mute Hi Conga Mute Hi Conga Mute Hi Conga
63 D#3D#4 Analog Mid Conga Open Hi Conga Open Hi Conga Open Hi Conga
64 E3 E4 Analog Low Conga Low Conga Low Conga Low Conga
65 F3 F4 High Timbale High Timbale High Timbale High Timbale
66 F#3F#4 Low Timbale Low Timbale Low Timbale Low Timbale
67 G3 G4 High Agogo High Agogo High Agogo High Agogo
68 G#3G#4 Low Agogo Low Agogo Low Agogo Low Agogo
69 A3 A4 Cabasa Cabasa Cabasa Cabasa
70 A#3A#4 Analog Maracas Maracas Maracas Maracas
71 B3 B4 Short Whistle 2 Short Whistle 2 Short Whistle 2 Short Whistle 2
72 C4 C5
73 C#4C#5
74 D4 D5
75 D#4D#5 Analog Claves Claves Claves Claves
76 E4 E5 Hi Wood Block Hi Wood Block Hi Wood Block Hi Wood Block
77 F4 F5 Low Wood Block Low Wood Block Low Wood Block Low Wood Block
78 F#4F#5 Mute Cuica 4 Mute Cuica 4 Mute Cuica 4 Mute Cuica 4
79 G4 G5 Open Cuica 4 Open Cuica 4 Open Cuica 4 Open Cuica 4
80 G#4G#5 Mute Triangle 5 Mute Triangle 5 Mute Triangle 5 Mute Triangle 5
81 A4 A5 Open Triangle 5 Open Triangle 5 Open Triangle 5 Open Triangle 5
82 A#4A#5 Shaker Shaker Shaker Shaker
83 B4 B5 Jingle Bell Jingle Bell Jingle Bell Jingle Bell
84 C5 C6 Bell Tree Bell Tree Bell Tree Bell Tree
85 C#5C#6 Castanets Castanets Castanets Castanets
86 D5 D6 Mute Surdo 6 Mute Surdo 6 Mute Surdo 6 Mute Surdo 6
87 D#5D#6 Open Surdo 6 Open Surdo 6 Open Surdo 6 Open Surdo 6
88 E5 E6
89 F5 F6
90 F#5F#6
91 G5 G6
Note
Full Name
Long Whistle 2 Long Whistle 2 Long Whistle 2 Long Whistle 2
Short Guiro 3 Short Guiro 3 Short Guiro 3 Short Guiro 3
Long Guiro 3 Long Guiro 3 Long Guiro 3 Long Guiro 3
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Key
Off
(*1)
Alt
Group
(*2)
Full Name
Applause
Key
Off
(*1)
Alt
Group
(*2)
PSR-A3000 Data List
34
Kit Name SFXSet
*1 Key Off: Keys marked “” stop sounding the instant they are released.
*2 Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number.
Same as StandardSet No Sound
MSB-LSB-PC# (1–128) 120-0-57
MIDI
Keyboard
Note# Note
13 C#-1 C#0
14 D-1 D0
15 D#-1 D#0
16 E-1 E0
17 F-1 F0
18 F#-1 F#0
19 G-1 G0
20 G#-1 G#0
21 A-1 A0
22 A#-1 A#0
23 B-1 B0
24 C0 C1
25 C#0C#1
26 D0 D1
27 D#0D#1
28 E0 E1
29 F0 F1
30 F#0F#1
31 G0 G1
32 G#0G#1
33 A0 A1
34 A#0A#1
35 B0 B1
36 C1 C2
37 C#1C#2
38 D1 D2
39 D#1D#2 High Q
40 E1 E2 Slap
41 F1 F2 Scratch Push 7
42 F#1F#2 Scratch Pull 7
43 G1 G2 Sticks
44 G#1G#2 Square Click
45 A1 A2 Metronome Click
46 A#1A#2Metronome Bell
47 B1 B2 Guitar Fret
48 C2 C3 Guitar Cutting Noise Up
49 C#2C#3 Guitar Cutting Noise Down
50 D2 D3 String Slap of Double Bass
51 D#2D#3 Fl.Key Click
52 E2 E3 Laughing
53 F2 F3 Scream
54 F#2F#3 Punch
55 G2 G3 Heart Beat
56 G#2G#3 Footsteps 1
57 A2 A3 Footstep s 2
58 A#2A#3 Applause
59 B2 B3 Door Creaking
60 C3 C4 Door
61 C#3C#4 Scratch
62 D3 D4 Wind Chimes
63 D#3D#4 Car-Engine
64 E3 E4 Car-Stop
65 F3 F4 Car-Pass
66 F#3F#4 Car-Crash
67 G3 G4 Siren
68 G#3G#4Train
69 A3 A4 Jetplane
70 A#3A#4Helicopter
71 B3 B4 Starship
72 C4 C5 Gun Shot
73 C#4C#5 Machine Gun
74 D4 D5 Lasergun
75 D#4D#5Explosion
76 E4 E5 Dog
77 F4 F5 Horse-Gallop
78 F#4F#5Birds
79 G4 G5 Rain
80 G#4G#5 Thunder
81 A4 A5 Wind
82 A#4A#5 Seashore
83 B4 B5 Stream
84 C5 C6 Bubble
85 C#5C#6
86 D5 D6
87 D#5D#6
88 E5 E6
89 F5 F6
90 F#5F#6
91 G5 G6
Note
Full Name
Key
Off
(*1)
Drum/SFX Kit List / Drum/SFX-Kit-Liste / Liste des kits de batterie/SFX / Lista de conjuntos de percusión/efectos especiales
Alt
Group
(*2)
PSR-A3000 Data List
35
Style List / Liste der Styles / Liste des styles / Lista de estilos
Category Style Name
Pop&Rock 80sPowerRock
80sPopRock
80sGuitarPop
90sRockBallad
BritRockPop
Cool8Beat
Live8Beat
Classic8Beat
Uptempo8Beat
80sPop
FunkPopRock
ContempRock
AcousticRock
HardRock
PowerRock
ChartPianoShfl
ChartRockShfl
ChartGuitarPop
RockShuffle
60sVintagePop
60sGuitarPop
60sPopRock
60sVintageRock
60s8Beat
70s8Beat
BubblegumPop
BritPop
BritPopSwing
VintageGtrPop
90sGuitarPop
8BeatModern
WestCoas tPop
KoolShuffle
JazzPop
Unplugged
Ballad ModernPopBld
SoulR&B
R&BSoulBallad
8BeatBallad
70sGlamPiano
90sCoolBallad
Chillout
EasyBallad
EPBallad
EpicBallad
PowerBallad
OrganBallad
PianoBallad
ClassicPianoBld
80sEPBallad
Modern16BtBld
16BeatBallad
ContempPopBld
6-8SlowRock
6-8Orchestral
6-8Modern
12-8Ballad
LoveSong
NewR&BBallad
80sBoyBand
PopWaltz
GuitarSerenade
Dance ClubDJHouse
MiamiHouse
ElectricHouse
GangsterHouse
GrimeHouse
PianoHouse
ElectroStep
EuroDance
ProgressiveHouse
FrenchClubHouse
Electronica
FunkyHouse
Dancehall
Garage
Category Style Name
Dance Dubstep
ModernHipHop
MellowHipHop
NewHipHop
ClassicHipHop
USHipHop
FunkDisco
70sDisco
70sDiscoFunk
DiscoPhilly
80sSynthDisco
80sDisco
90sDisco
DiscoTeens
DiscoHouse
GlobalDJ's
Ibiza2010
ClubHouse
Clubdance
SynthPop
TrancePop
RetroPop
ChartPop
ModChartPop
EuroTrance
ClubBeat
6-8Trance
NewR&B
PopR&B
ChartR&B
Swing&Jazz ModernBigBand
ModBigBandShfl
ModBigBandBld
AfroCuban
AcousticJazz
JazzGuitarClub
CoolJazzBallad
InstrumentalJazz
ModernJazzBld
OrchBigBand
OrchestraSwing
DreamyBallad
EasyListening
MidnightSwing
MORSwing
JazzWaltzMed
JazzWaltzFast
BigBandFast
JumpJive
OrganGroove
FrenchJazz
Five-Four
Ragtime
Charleston
Dixieland
MoonlightBallad
Latin BrazilianSamba
BossaNova
FastBossa
SlowBossa
OrchestralBossa
SheriffReggae
HappyReggae
Axe
SambaReggae
LatinPartyPop
Cumbia
Merengue
Bachata
Guajira
CubanSon
Danzon
Bomba
Parranda
Forro
PopLatin
Category Style Name
Latin LatinDisco
PopBossa
RockChaCha
PopLatinBallad
Beguine
Salsa
RumbaFlamencos
Calypso
BoleroLento
Reggaeton
RumbaIsland
GuitarRumba
OrganBossa
World Zeibekikos
Tsifteteli
Kalamatianos
Syrtorumba
Tsamikos
Karsilamas
Hasapiko
5-8Greek
Hasaposerviko
Kamilieriko
7-8Greek
Bagio
ZitherPolka
VienneseWaltz
Flamenco
PopFlamenco
Sirtaki
HighlandWaltz
GermanWaltz
FrenchWaltz
ItalianWaltz
EnglishWaltz
MariachiWaltz
ItalianMazurka
ItalianPolka
OberPolka
OberWalzer
Zouk
Norteno
FrenchMusette
Duranguense
Grupera
Jig
Reel
ScottishPolka
SpanishPaso
USMarch
GermanMarch
6-8March
Tarantella
HullyGully
Arabic Saeidy1
ChaabiModern
Mahragan
SaidiDance
KatakoftiLeb
WehdeLeb
LaffSyria
LaffMaksoum
BaladiLeb
Saeidy2
Saeidy3
Baladi
Katakoufti
Maksoum
Karatchi
Laff1
Ayoub
WehdaSaghira
MaksoumSarih
ArabicEuro1
ArabicEuro2
Saeidy4
Category Style Name
Arabic Saeidy5
Ibrahimi
Zaffah
Hajaa
6-8Soudasi
WehdaKabira
Wehda
SaeidyDance
KaratchiDance
LaffDance1
LaffDance2
Laff2
Laff3
Rumba
Khaligi
Jerk
MasmoudiKabir
Fox
Vals e
10-8Samai
Khaligi Haiwa
Georgina1
RombaLive
BandariSeeroos1
Dosari
Sowahli1
KhebatiLive
Atbah
BandariEmirates
Khebaiti3-4
Khebaiti4-4
RumbaKhaligi1
RumbaKhaligi2
RumbaKhaligi3
Georgina2
Iraqi2
Yan ba aw i
Samri2
Bastah
Adaniat
Laiwa
Stati
Sout4-4
Sout6-4
Adani
Shakshaka
Sowahli2
Iraqi1
BandariSeeroos2
Muruba
Dazza
Samri1
Tam b ur a h
Sharh
Emarati1
Samri3
Ashori
ShaabiEmirates
Emarati2
IraqiMix
Maghrebi BadouiWahrani
HadiBerwali
RayAlaoui
LibiChaabi
Aissawi
Zayani6-8
Chaabi
KaratchiMaroc
FazzaniTunisi
Ghita
Souga
Fazzani
Iranian 6-8Pop
6-8Looti
6-8Rengi
6-8Qeri
PSR-A3000 Data List
36
Style List / Liste der Styles / Liste des styles / Lista de estilos
Category Style Name
Iranian 6-8Modern1
6-8Rap
Bandari1
BandariModern
Bastaki
Kermanshahi
KordiPop
BakhtiariMarch
6-8AzariAtma
Bandari2
6-8Azari
AzariLezgi
6-8SlowAzari
2-4Azari
Qashgai1
Qashgai2
Qashgai3
Qashgai4
Qashgai5
6-8Afqani
2-4Irani
Raghs1
Raghs2
Raghs3
6-8Tomba1
6-8IranianTomba
6-8Dance
KoocheBazaari
IranianClub1
IranianClub2
IranianSonnati
IranianClub3
RengiIranian
3-4Irani
AstaAzari
ZarbStyle
6-8Modern2
IranGeri
6-8Irani
6-8Modern3
6-8Bandari
6-8Modern4
6-8Tombak1
6-8Tombak2
6-8Tomba2
IranianDance
Tur ki s h Va hd e 1
TurkishSlow
TurkishDance
2-4Oyun
Misket
3-4Slow
6-8Slow
4-4Oriental
10-8Tsm
10-8Thm
6-8Azeri
7-8Turku
7-8Karadeniz
DoubleVahde
9-8Roman
Halay
2-4&6-8Halay
Ciftetelli1
Harmandali
9-4Zeybek
6-8Tsm
BossaNovaTR
HoronKaradeniz
SlowTR
Vahde2
Alternative
5-8Horon
RhumbaTR
6-8Halay
5-16Karadeniz
Category Style Name
Turkish 4-4Halk
7-8Rumeli
9-8Teke
Ciftetelli2
9-8Tsm
Tur kP o p
9-8Trance
Ankara
Payduska
VahdeR&B
2-4Dugun
Cokertme
Tur ku P op
AcousticLine
VahdeKorfez
9-8Disco
Dansoz
Davullu2Telli
9-8EgeOyun
9-8Thm
PSR-A3000 Data List
37
Multi Pad Bank List / Multi-Pad-Bank-Liste / Liste des banques multi-pads / Lista de bancos de Multi Pad
Category Bank Name
KeyboardPhrase PianoArp8Beat
PianoArp16Beat
PianoGlissando
LatinKeys
BoogieLoops
OrganBlues
HeavenArpeggio
TwinkleArpeggio
GuitarPhrase E.Gtr16BtCut1
E.Gtr16BtCut2
E.Gtr16BtCut3
FunkyGtr16Bt1
FunkyGtr16Bt2
FunkyGtr16Bt3
DiscoGuitar
E.Gtr16BtShfl1
E.Gtr16BtShfl2
E.Gtr16BtPick
E.Gtr8BtShfl
E.Guitar6-8
E.Gtr8BtStrm1
E.Gtr8BtStrm2
E.GtrRock1
E.GtrRock2
Steel8BtStrum1
Steel8BtStrum2
SteelBsChdSlow
SteelBsChdFast
SteelTriplet1
SteelTriplet2
SteelGuitar6-8
SteelGtrPick1
SteelGtrPick2
SteelGtrPick3
SteelGtrPick4
NylonGtrPick
NylonAccomp
NylonBossa1
NylonBossa2
FlamencoGtr
A.GtrAccomp
JazzGtrSwing
ArabicGuitar
TurkishGuitar
GreekChord
StringsPhrase StringsArpeggio
StringsBallad
StringsLegato
BaroqueStrings
StringsRun&Fall
Classical
OrchestraHit
Harpeggio1
Harpeggio2
KanounChord
BrassPhrase BigBandSwing1
BigBandSwing2
BigBandSwing3
BrassSwing
TrumpetSwing
Brass8Beat
BrassChords1
BrassChords2
BrassChords3
Falls
SynthBrassSlide
AttentionDuo
Fanfare
SynthPhrase TranceSeq1
TranceSeq2
TechnoSeq1
TechnoSeq2
TechnoSeq3
Garage
EuroDance
DanceSynth
Category Bank Name
PercussionLoop ArabicLoop1
PercussionOneshot
DrumLoop House1
ArabicLoop2
ArabicLoop3
ArabicLoop4
KhaligiLoop1
KhaligiLoop2
KhaligiLoop3
KhaligiLoop4
KhaligiLoop5
LiwaLoop
MaghrebiLoop
IranianLoop1
IranianLoop2
IranianLoop3
IranianLoop4
IranianLoop5
TurkishLoop1
TurkishLoop2
TurkishLoop3
TurkishLoop4
TurkishLoop5
TurkishLoop6
TurkishLoop7
TurkishLoop8
9-8TurkishLoop
Oriental1
Oriental2
Oriental3
Oriental4
Oriental5
Oriental6
Oriental7
Oriental8
LatinPerc1
LatinPerc2
LatinPerc3
LatinPerc4
LatinPerc5
Conga&Bongo1
CarnivalDeRio
LatinPop
Rumba&Soca
SambaPerc
Cajon1
Cajon2
Shaker&Tamb
Timbales&Tom
EthnicPerc
ArabicPerc1
ArabicPerc2
ArabicPerc3
Ta bl a h
Riq
SagatClap
KhaligiPerc1
KhaligiPerc2
KhaligiPerc3
KhaligiSagat
Sout
Ta r
Ray
IranianPerc1
IranianPerc2
Gong&Chime
BigBells
MagicBells
LatinKit1
LatinKit2
LatinKit3
Conga&Bongo2
ChineseKit2
House2
House3
ElectroStep
BigRoom
Category Bank Name
DrumLoop Tribal
BreakBeatz
HipHop1
HipHop2
HeavyShuffle
NewR&B
SnarePlay1
SnarePlay2
DrumOneshot PowerToms
PowerSnares
CrashCymbals
PowerKit1
PowerKit2
DrumEndings
DanceKit
DJ-BasicSet
DJ-SFX
ScratchBank
DJ Phrase ClubDJHouse A
ClubDJHouse B
ClubDJHouse C
ClubDJHouse D
MiamiHouse A
MiamiHouse B
MiamiHouse C
MiamiHouse D
ElectricHouse A
ElectricHouse B
ElectricHouse C
ElectricHouse D
GangsterHouse A
GangsterHouse B
GangsterHouse C
GangsterHouse D
GrimeHouse A
GrimeHouse B
GrimeHouse C
GrimeHouse D
PianoHouse A
PianoHouse B
PianoHouse C
PianoHouse D
ElectroStep A
ElectroStep B
ElectroStep C
ElectroStep D
EuroDance A
EuroDance B
EuroDance C
EuroDance D
ProgressiveHouse A
ProgressiveHouse B
ProgressiveHouse C
ProgressiveHouse D
FrenchClubHouse A
FrenchClubHouse B
FrenchClubHouse C
FrenchClubHouse D
SFX Wooshes1
Wooshes2
Breathing
Car SE
Day SE
Horror SE
Night SE
Water SE
Combination EDM Kit1
EDM Kit2
DanceMix1
DanceMix2
DanceMix3
ReggaeAccomp
Comedy
XmasLoops
IndianKit
ChineseKit1
PSR-A3000 Data List
38
Harmony/Arpeggio Type List / Liste der Harmony-/Arpeggiotypen / Liste des types d’harmonie/arpège / Lista de tipos de armonía/arpegio
Category Type
Harmony Standard Duet
Echo Echo4
Arp/Up&Down Up Octave 1
Arp/Synth
Sequence
Standard Trio
Full Chord
Rock Duet
Country Duet
Country Trio
Block
4-Way Close1
4-Way Close2
4-Way Open
1+5
Octave
Strum
Multi Assign
Echo6
Echo8
Echo12
Tremolo8
Tremolo12
Tremolo16
Tremolo32
Trill12
Trill16
Trill24
Trill32
Up Octave 2
Up Octave 3
Up Octave 4
Down Octave 1
Down Octave 2
Down Octave 3
Down Octave 4
Up&Down A Octave 1
Up&Down A Octave 2
Up&Down A Octave 3
Up&Down A Octave 4
Up&Down B Octave 1
Up&Down B Octave 2
Up&Down B Octave 3
Up&Down B Octave 4
2 Octave Up
4 Octave Up
Up&Down 1
Up&Down 2
Up&Down 3
Up&Down 4
Up&Random 1
Up&Random 2
Up&Random 3
Up&Random 4
Synth Sequence 1
Synth Sequence 2
Synth Sequence 3
Synth Sequence 4
Synth Sequence 5
Synth Sequence 6
Synth Sequence 7
Synth Sequence 8
Synth Sequence 9
Synth Sequence 10
Synth Sequence 11
Synth Sequence 12
Synth Sequence 13
Synth Sequence 14
Synth Sequence 15
Synth Sequence 16
Synth Sequence 17
Octave Sequence 1
Octave Sequence 2
Octave Sequence 3
Octave Sequence 4
Octave Sequence 5
Octave Sequence 6
Octave Sequence 7
Category Type
Arp/Synth
Sequence
Arp/Chord
Sequence
Arp/Electro Trance 1
Arp/Keyboard Piano Arpeggio 1
Octave Sequence 8
Mute Arpeggio 1
Mute Arpeggio 2
Mute Arpeggio 3
Sequence S&H1
Sequence S&H2
Poly Arpeggio 1
Poly Arpeggio 2
Syncopation 1
Syncopation 2
X-Sweep 1
X-Sweep 2
X-Sweep 3
Random Octave 1
Random Octave 2
Random Octave 3
Random Octave 4
Synth Chord 1
Synth Chord 2
Synth Chord 3
Synth Chord 4
Synth Chord 5
Synth Chord 6
Synth Chord 7
Synth Chord 8
Synth Chord 9
Synth Chord 10
Synth Chord 11
Synth Chord 12
Synth Chord 13
Synth Chord 14
Synth Chord 15
Synth Chord 16
Synth Chord 17
Trance 2
Trance 3
Trance 4
Trance 5
Trance 6
Trance 7
Trance 8
Trance 9
Trance 10
Trance 11
Trance 12
Dream Dance 1
Dream Dance 2
Techno
Acid 1
Acid 2
Acid 3
Electro 1
Electro 2
Electro 3
Electro 4
Electro 5
Electro 6
Electro 7
Electro 8
Electro 9
Electro 10
Electro 11
Electro 12
Electro 13
Piano Arpeggio 2
Piano Arpeggio 3
Piano Arpeggio 4
Piano Arpeggio 5
Piano Arpeggio 6
Piano Arpeggio 7
Piano Arpeggio 8
Piano Arpeggio 9
Piano Arpeggio 10
Piano Arpeggio 11
Category Type
Arp/Keyboard Piano Arpeggio 12
Piano Arpeggio 13
Piano Arpeggio 14
Piano Arpeggio 15
Piano Club 1
Piano Club 2
Slow Feel 1
Slow Feel 2
Analog Pop 1
Analog Pop 2
Analog Pop 3
New Gospel 1
New Gospel 2
Clavi 1
Clavi 2
Clavi 3
House Organ 1
House Organ 2
House Organ 3
Arp/Guitar Overdrive Guitar
Pop Guitar
Rock Guitar
Funk Guitar
Spanish Guitar
Cutting Guitar
Arp/Strings Strings 1
Strings 2
Strings 3
Strings 4
Strings 5
Strings 6
Strings 7
Strings 8
Strings 9
Strings 10
Strings 11
Strings 12
Strings 13
Pizzicato
PSR-A3000 Data List
39
Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto
Reverb Block
Category Type Description MSB LSB Parameter List
Reverb Real Large Hall Real reverb simulating the acoustics of a large sized hall. 1 32 REAL REVERB
Legacy Hall M Reverb simulating the acoustics of a hall. 1 6 REVERB1
--- No Effect No effect. 0 0 NO EFFECT
Real Medium Hall Real reverb simulating the acoustics of a medium sized hall. 1 33 REAL REVERB
Real Bright Hall Real reverb simulating the acoustics of a bright sounding hall. 1 34 REAL REVERB
Basic Hall Reverb simulating the acoustics of a hall. Standard setting. 1 21 REVERB1
Light Hall Reverb simulating the acoustics of a hall. Light setting. 1 22 REVERB1
Ballad Hall Reverb simulating the acoustics of a hall. For ballad type music. 1 19 REVERB2
Piano Hall Reverb simulating the acoustics of a hall. For piano sound. 1 20 REVERB2
Hall 1 Reverb simulating the acoustics of a hall. 1 0 REVERB1
Hall 2 116REVERB1
Hall 3 117REVERB1
Hall 4 118REVERB1
Hall 5 11REVERB1
Vocal Hall 1 Reverb suitable for vocals. 1 27 REVERB1
Vocal Hall 2 128REVERB1
Real Room Real reverb simulating the acoustics of a room. 2 32 REAL REVERB
Real Power Room Real reverb simulating the acoustics of a room with powerful room
Acoustic Room Reverb simulating the acoustics of a room. Standard setting. 2 20 REVERB1
Drums Room Reverb simulating the acoustics of a room. For drum sounds. 2 21 REVERB1
Stage Reverb suitable for a solo instrument. 3 16 REVERB1
Real Large Plate Real reverb simulating a large plate reverb unit. 4 32 REAL REVERB
Real Medium Plate Real reverb simulating a medium sized plate reverb unit. 4 33 REAL REVERB
Real Rattle Plate Real reverb simulating a plate reverb unit with spring rattle. 4 34 REAL REVERB
Plate Reverb simulating a plate reverb unit. 4 16 REVERB1
Hall L 17REVERB1
Atmosphere Hall A unique long reverb with atmosphere. 1 23 REVERB1
Large Hall Reverb simulating the acoustics of a hall. 1 2 REVERB2
Medium Hall 13REVERB2
Percussion Room Reverb simulating the acoustics of a room. For percussion sounds. 2 22 REVERB1
Room 1 Reverb simulating the acoustics of a room. 2 16 REVERB1
Room 2 217REVERB1
Room 3 218REVERB1
Room 4 219REVERB1
Room 5 20REVERB1
Room 6 21REVERB1
Room 7 22REVERB1
Room S 25REVERB1
Room M 26REVERB1
Room L 27REVERB1
Warm Room Reverb simulating the acoustics of a warm room. 2 3 REVERB2
White Room A unique short reverb with a bit of initial delay. 16 0 REVERB3
Woody Room Reverb simulating the acoustics of a wood-built room. 2 4 REVERB2
Stage 2 Reverb suitable for a solo instrument. 3 17 REVERB1
Stage 3 30REVERB1
Stage 4 31REVERB1
Plate 2 Reverb simulating a plate reverb unit. 4 17 REVERB1
Plate 3 40REVERB1
GM Plate 47REVERB1
Rich Plate Reverb simulating a rich plate reverb unit. 4 1 REVERB2
Tunnel Simulates a cylindrical space expanding to left and right. 17 0 REVERB3
Canyon A hypothetical acoustic space which extends without limit. 18 0 REVERB3
Basement A bit of initial delay followed by reverb with a unique resonance. 19 0 REVERB3
reflections.
233REAL REVERB
PSR-A3000 Data List
40
Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto
Chorus Block
Category Type Description MSB LSB Parameter List
Reverb Hall 1 Reverb simulating the acoustics of a hall. 1 0 REVERB1
Delay Tempo Delay 1 Tempo-synchronized delay. 21 0 TEMPO DELAY
Modulation Chorus 1 Conventional chorus program with rich, warm chorusing. 66 17 CHORUS
Legacy Hall M Reverb simulating the acoustics of a hall. 1 6 REVERB1
Hall 2 116REVERB1
Hall 3 117REVERB1
Hall 4 118REVERB1
Hall 5 11REVERB1
Acoustic Room Reverb simulating the acoustics of a room. Standard setting. 2 20 REVERB1
Drums Room Reverb simulating the acoustics of a room. For drum sounds. 2 21 REVERB1
Stage Reverb suitable for a solo instrument. 3 16 REVERB1
Plate Reverb simulating a plate reverb unit. 4 16 REVERB1
Tempo Delay 2 21 16 TEMPO DELAY
Tempo Echo Tempo-synchronized echo. 21 8 TEMPO DELAY
Tempo Cross 1 Tempo-synchronized cross delay. 22 0 TEMPO CROSS DELAY
Tempo Cross 2 22 16 TEMPO CROSS DELAY
Tempo Cross 3 22 17 TEMPO CROSS DELAY
Tempo Cross 4 22 18 TEMPO CROSS DELAY
Chorus 2 66 8 CHORUS
Symphonic Adds more stages to the modulation of Celeste. 68 16 SYMPHONIC
Flanger Creates a sound similar to that of a jet airplane. 67 8 FLANGER
Tempo Flanger Tempo-synchronized flanger. 107 0 TEMPO FLANGER
Phaser Cyclically modulates the phase to add modulation to the sound. 72 0 PHASER1
Tempo Phaser Tempo-synchronized phaser. 108 0 TEMPO PHASER
E-Piano Phaser Cyclically modulates the phase to add modulation to the sound. For
Dual Rotary Speaker Bright Simulates a rotary speaker. 99 16 ROTARY SPEAKER1
Dual Rotary Speaker Warm 99 17 ROTARY SPEAKER1
Rotary Speaker 69 16 ROTARY SPEAKER2
Tremolo Rich Tremolo effect with both volume and pitch modulation. 70 16 TREMOLO
E-Piano Tremolo 70 18 TREMOLO
Tempo Tremolo Tempo-synchronized rich Tremolo effect with both volume and pitch
Auto Pan Several panning effects that automatically shift the sound position
Tempo Auto Pan Tempo-synchronized auto pan. 121 0 TEMPO AUTO PAN1
Hall L 17REVERB1
Atmosphere Hall A unique long reverb with atmosphere. 1 23 REVERB1
Percussion Room Reverb simulating the acoustics of a room. For percussion sounds. 2 22 REVERB1
Room 1 Reverb simulating the acoustics of a room. 2 16 REVERB1
Room 2 217REVERB1
Room 3 218REVERB1
Room 4 219REVERB1
Room 5 20REVERB1
Room 6 21REVERB1
Room 7 22REVERB1
Room S 25REVERB1
Room M 26REVERB1
Room L 27REVERB1
Stage 2 Reverb suitable for a solo instrument. 3 17 REVERB1
Stage 3 30REVERB1
Stage 4 31REVERB1
Plate 2 Reverb simulating a plate reverb unit. 4 17 REVERB1
Plate 3 40REVERB1
GM Plate 47REVERB1
Karaoke 1 Echo for karaoke. 20 0 KARAOKE
Karaoke 2 20 1 KARAOKE
Karaoke 3 20 2 KARAOKE
Early Reflection 1 This effect isolates only the early reflection components of the reverb. 9 0 EARLY REFLECTION
Early Reflection 2 91EARLY REFLECTION
Chorus 3 Conventional chorus program with rich, warm chorusing. 66 16 CHORUS
Chorus 4 66 1 CHORUS
Chorus 5 65 2 CHORUS
Chorus 6 65 0 CHORUS
Chorus 7 65 1 CHORUS
Chorus 8 65 8 CHORUS
Chorus Fast 65 16 CHORUS
Chorus Lite 65 17 CHORUS
GM Chorus 1 65 3 CHORUS
GM Chorus 2 65 4 CHORUS
GM Chorus 3 65 5 CHORUS
GM Chorus 4 65 6 CHORUS
Feedback Chorus 65 7 CHORUS
Celeste 1 A 3-phase LFO adds modulation and spaciousness to the sound. 66 0 CHORUS
Celeste 2 66 2 CHORUS
Symphonic 2 Adds more stages to the modulation of Celeste. 68 0 SYMPHONIC
electric piano.
modulation.
(left, right, front, back).
72 17 PHASER1
120 0 TEMPO TREMOLO
71 16 AUTO PAN1
PSR-A3000 Data List
41
Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto
Category Type Description MSB LSB Parameter List
Legacy Ensemble Detune 1 Chorus effect without modulation, created by adding a slightly pitch-
Ensemble Detune 2 87 16 ENSEMBLE DETUNE
Flanger 2 Creates a sound similar to that of a jet airplane. 67 16 FLANGER
Flanger 3 67 17 FLANGER
Flanger 4 67 1 FLANGER
Flanger 5 67 0 FLANGER
GM Flanger 67 7 FLANGER
Phaser 2 Cyclically modulates the phase to add modulation to the sound. 72 8 PHASER2
Phaser 3 72 19 PHASER2
Tempo Phaser 2 Tempo-synchronized phaser. 108 16 TEMPO PHASER
E-Piano Phaser 2 Cyclically modulates the phase to add modulation to the sound. For
E-Piano Phaser 3 72 16 PHASER1
Dual Rotary Speaker 1 Simulates a rotary speaker. 99 0 ROTARY SPEAKER1
Dual Rotary Speaker 2 99 1 ROTARY SPEAKER1
Rotary Speaker 2 71 17 AUTO PAN1
Rotary Speaker 3 71 18 AUTO PAN1
Rotary Speaker 4 70 17 TREMOLO
Rotary Speaker 5 66 18 CHORUS
Rotary Speaker 6 69 0 ROTARY SPEAKER2
Rotary Speaker 7 71 22 AUTO PAN1
2way Rotary Speaker 86 0 2WAY ROTARY SPEAKER
Tremolo 2 Rich Tremolo effect with both volume and pitch modulation. 71 19 AUTO PAN1
Tremolo 3 70 0 TREMOLO
Guitar Tremolo 1 71 20 AUTO PAN1
Guitar Tremolo 2 70 19 TREMOLO
Vibraphone Rotor Vibraphone effect. 119 0 VIBE VIBRATE
Auto Pan 2 Several panning effects that automatically shift the sound position
Auto Pan 3 71 1 AUTO PAN2
E-Piano Auto Pan 71 21 AUTO PAN1
Tempo Auto Pan 2 Tempo-synchronized auto pan. 121 1 TEMPO AUTO PAN2
Pitch Change 1 Changes the pitch of the input signal. 80 16 PITCH CHANGE1
Pitch Change 2 80 0 PITCH CHANGE1
Pitch Change 3 80 1 PITCH CHANGE2
--- No Effect No effect. 0 0 NO EFFECT
shifted sound.
electric piano.
(left, right, front, back).
87 0 ENSEMBLE DETUNE
72 18 PHASER1
71 0 AUTO PAN1
PSR-A3000 Data List
42
Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto
DSP1–4 Block
LCD Block Name XG Block Name
DSP1 XG Variation Block
DSP2 XG Insertion1 Block
DSP3 XG Insertion2 Block
DSP4 XG Insertion3 Block
Category Type Description MSB LSB Parameter List
Reverb Hall 1 Reverb simulating the acoustics of a hall. 1 0 REVERB1
Delay Delay LCR 1 Produces three delayed sounds: L, R and C (center). 5 16 DELAY LCR
Distortion Multi FX Distortion Solo Multi effector for guitar. Setting for guitar solo. 95 32 MULTI FX
EQ & Comp Compressor Medium Compressor with medium setting. 83 16 COMPRESSOR
Modulation Chorus 1 Conventional chorus program with rich, warm chorusing. 66 17 CHORUS
Hall 2 116REVERB1
Hall 3 117REVERB1
Hall 4 118REVERB1
Hall 5 11REVERB1
Acoustic Room Reverb simulating the acoustics of a room. Standard setting. 2 20 REVERB1
Drums Room Reverb simulating the acoustics of a room. For drum sounds. 2 21 REVERB1
Stage Reverb suitable for a solo instrument. 3 16 REVERB1
Plate Reverb simulating a plate reverb unit. 4 16 REVERB1
Delay LCR 2 50DELAY LCR
Delay LR Produces two delayed sounds: L and R. Two feedback delays are
Echo Two delayed sounds (L and R), and independent feedback delays
Cross Delay 1 The feedback of the two delayed sounds is crossed. 8 0 CROSS DELAY
Cross Delay 2 816CROSS DELAY
Tempo Delay 1 Tempo-synchronized delay. 21 0 TEMPO DELAY
Tempo Delay 2 21 16 TEMPO DELAY
Tempo Echo Tempo-synchronized echo. 21 8 TEMPO DELAY
Tempo Cross 1 Tempo-synchronized cross delay. 22 0 TEMPO CROSS DELAY
Tempo Cross 2 22 16 TEMPO CROSS DELAY
Tempo Cross 3 22 17 TEMPO CROSS DELAY
Tempo Cross 4 22 18 TEMPO CROSS DELAY
Multi FX Distortion Basic Multi effector for guitar. Setting for basic distortion. 95 33 MULTI FX
Multi FX Overdrive Chorus Multi effector for guitar. Setting for overdrive & chorus. 95 34 MULTI FX
Multi FX Crunch Wah Multi effector for guitar. Setting for crunch & wah. 95 35 MULTI FX
Multi FX Oldies Delay Multi effector for guitar. Setting for vintage delay. 95 36 MULTI FX
Multi FX Vintage Echo Multi effector for guitar. Setting for vintage echo. 95 37 MULTI FX
Small Stereo Distortion Stereo distortion for guitar. Setting for distortion sound. 96 32 SMALL STEREO DIST
Small Stereo Overdrive Stereo distortion for guitar. Setting for overdrive sound. 96 33 SMALL STEREO DIST
Small Stereo Vintage Amp Stereo distortion for guitar. Setting for vintage sound. 96 34 SMALL STEREO DIST
Small Stereo Heavy Dist Stereo distor tion for guitar. Setting for heavy sound. 96 35 SMALL STEREO DIST
British Combo Classic British combo amp simulator. Setting for classic sound. 97 32 BRITISH COMBO
British Combo Top Boost British combo amp simulator. Setting for “TOP BOOST” sound. 97 33 BRITISH COMBO
British Combo Custom British combo amp simulator. Setting for custom sound. 97 34 BRITISH COMBO
British Combo Heavy British combo amp simulator. Setting for heavy sound. 97 35 BRITISH COMBO
British Legend Blues British stack amp simulator. Setting for blues sound. 98 32 BRITISH LEGEND
British Legend Heavy1 British stack amp simulator. Setting for heavy sound 1. 98 33 BRITISH LEGEND
British Legend Heavy2 British stack amp simulator. Setting for heavy sound 2. 98 34 BRITISH LEGEND
British Legend Clean British stack amp simulator. Setting for clean sound. 98 35 BRITISH LEGEND
British Legend Dirty Clean British stack amp simulator. Setting for crunch sound. 98 36 BRITISH LEGEND
V Distortion Crunch Distortion which simulates the sound of a vintage tube, fuzz effect,
V Distortion Blues 98 21 V DISTORTION
Stereo Amp Sim Solid Stereo amp simulator. 75 29 STEREO AMP SIMULATOR
Stereo Amp Sim Crunch 75 30 STEREO AMP SIMULATOR
Stereo Amp Sim Blues 75 28 STEREO AMP SIMULATOR
V Distortion Hard + Delay V Distor tion Hard and Delay are connected in series. 98 1 V DISTORTION DELAY
Compressor Heavy Compressor with heavy setting. 83 17 COMPRESSOR
Compressor Melody Compressor for the Melody part. 105 16 MULTI BAND COMP
Compressor Bass Compressor for the Bass part. 105 17 MULTI BAND COMP
EQ Telephone Equalizer effect that cuts both high and low frequencies, to simulate
3Band EQ A mono EQ with adjustable LOW, MID, and HIGH equalization. 76 0 3BAND EQ
Loop FX 1 Degrades the audio quality of the input signal. 94 16 LO FI
Loop FX 2 94 17 LO FI
Lo-Fi Drum 1 Degrades the audio quality of the input signal. Ideal for drum
Lo-Fi Drum 2 94 19 LO FI
Lo-Fi Drum 3 76 19 3BAND EQ
Lo-Fi Drum 4 76 20 3BAND EQ
Chorus 2 66 8 CHORUS
Symphonic Adds more stages to the modulation of Celeste. 68 16 SYMPHONIC
Flanger Creates a sound similar to that of a jet airplane. 67 8 FLANGER
V Flanger A simulation of an analog flanger effect. The LFO has a random
Tempo Flanger Tempo-synchronized flanger. 107 0 TEMPO FLANGER
Phaser Cyclically modulates the phase to add modulation to the sound. 72 0 PHASER1
provided.
for L and R.
etc.
the sound heard through a telephone receiver.
sounds.
setting.
60DELAY LR
70ECHO
98 18 V DISTORTION
76 17 3BAND EQ
94 18 LO FI
104 0 V FLANGER
PSR-A3000 Data List
43
Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto
Category Type Description MSB LSB Parameter List
Modulation Tempo Phaser Tempo-synchronized phaser. 108 0 TEMPO PHASER
Legacy Hall M Reverb simulating the acoustics of a hall. 1 6 REVERB1
Legacy Early Reflection 1 This effect isolates only the early reflection components of the reverb. 9 0 EARLY REFLECTION
E-Piano Phaser Cyclically modulates the phase to add modulation to the sound. For
Auto Wah Cyclically modulates the center frequency of a wah filter. 78 16 AUTO WAH
Auto Wah + Distortion Distortion can be applied to the output of Auto Wah. 78 17 AUTO WAH DISTORTION
Tempo Auto Wah Tempo-synchronized Auto Wah. 79 0 TEMPO AUTO WAH1
Touch Wah Changes the center frequency of a wah filter according to the input
Touch Wah + Distortion Distortion can be applied to the output of Touch Wah. 82 16 TOUCH WAH1
Pedal Wah Changes the center frequency of a wah filter according to “Pedal
Pedal Wah + Distortion Distortion can be applied to the output of Pedal Wah. 122 1 PEDAL WAH2
Dual Rotary Speaker Bright Simulates a rotary speaker. 99 16 ROTARY SPEAKER1
Dual Rotary Speaker Warm 99 17 ROTARY SPEAKER1
Rotary Speaker 69 16 ROTARY SPEAKER2
Tremolo Rich Tremolo effect with both volume and pitch modulation. 70 16 TREMOLO
E-Piano Tremolo 70 18 TREMOLO
Tempo Tremolo Tempo-synchronized rich Tremolo effect with both volume and pitch
Auto Pan Several panning effects that automatically shift the sound position
Tempo Auto Pan Tempo-synchronized auto pan. 121 0 TEMPO AUTO PAN1
Hall L 17REVERB1
Atmosphere Hall A unique long reverb with atmosphere. 1 23 REVERB1
Percussion Room Reverb simulating the acoustics of a room. For percussion sounds. 2 22 REVERB1
Room 1 Reverb simulating the acoustics of a room. 2 16 REVERB1
Room 2 217REVERB1
Room 3 218REVERB1
Room 4 219REVERB1
Room 5 20REVERB1
Room 6 21REVERB1
Room 7 22REVERB1
Room S 25REVERB1
Room M 26REVERB1
Room L 27REVERB1
White Room A unique short reverb with a bit of initial delay. 16 0 REVERB3
Stage 2 Reverb suitable for a solo instrument. 3 17 REVERB1
Stage 3 30REVERB1
Stage 4 31REVERB1
Plate 2 Reverb simulating a plate reverb unit. 4 17 REVERB1
Plate 3 40REVERB1
GM Plate 47REVERB1
Tunnel Simulates a cylindrical space expanding to left and right. 17 0 REVERB3
Canyon A hypothetical acoustic space which extends without limit. 18 0 REVERB3
Basement A bit of initial delay followed by reverb with a unique resonance. 19 0 REVERB3
Karaoke 1 Echo for karaoke. 20 0 KARAOKE
Karaoke 2 20 1 KARAOKE
Karaoke 3 20 2 KARAOKE
Early Reflection 2 91EARLY REFLECTION
Gate Reverb 1 Simulation of gated reverb. 10 0 GATE REVERB
Gate Reverb 2 10 16 GATE REVERB
Reverse Gate Simulation of gated reverb played back in reverse. 11 0 GATE REVERB
V Distortion Warm Distortion which simulates the sound of a vintage tube, fuzz effect,
V Distortion Classic Hard 98 23 V DISTORTION
V Distortion Classic Soft 98 20 V DISTORTION
V Distortion Metal 98 24 V DISTORTION
V Distortion Edgy 98 19 V DISTORTION
V Distortion Solid 98 25 V DISTORTION
V Distortion Clean 1 98 17 V DISTORTION
V Distortion Clean 2 98 26 V DISTORTION
V Distortion Twin 98 16 V DISTORTION
V Distortion Rockabilly 103 18 V DIST TEMPO DELAY
V Distortion Jazz Clean 98 27 V DISTORTION
V Distortion Fusion 103 19 V DIST TEMPO DELAY
V Distortion Hard 98 0 V DISTORTION
V Distortion Soft 98 2 V DISTORTION
Stereo Amp Sim Clean Stereo amp simulator. 75 27 STEREO AMP SIMULATOR
Stereo Amp Sim BluesHarp 75 31 STEREO AMP SIMULATOR
Distortion Hard 1 Hard-edge distortion. 75 16 AMP SIMULATOR1
Distortion Hard 2 75 22 AMP SIMULATOR1
Distortion Soft 1 Soft, warm distortion. 75 17 AMP SIMULATOR1
Distortion Soft 2 75 23 AMP SIMULATOR1
Distortion Heavy Heavy distortion. 73 0 DISTORTION
Overdrive Adds mild distortion to the sound. 74 0 DIST ORTION
Stereo Distortion Stereo distortion. 73 8 STEREO DISTORTION
Stereo Overdrive Stereo overdrive. 74 8 STEREO DISTORTION
electric piano.
level.
Control” parameter. (See Effect Parameter List.)
modulation.
(left, right, front, back).
etc.
72 17 PHASER1
82 0 TOUCH WAH1
122 0 PEDAL WAH1
120 0 TEMPO TREMOLO
71 16 AUTO PAN1
98 22 V DISTORTION
PSR-A3000 Data List
44
Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto
Category Type Description MSB LSB Parameter List
Legacy Stereo Distortion Hard Hard-edge stereo distortion. 75 18 STEREO AMP SIMULATOR
Stereo Distortion Soft Soft, warm soft distortion. 75 19 STEREO AMP SIMULATOR
Amp Simulator 1 A simulation of a guitar amp. 75 0 AMP SIMULATOR1
Amp Simulator 2 75 1 AMP SIMULATOR2
Stereo Amp Simulator 1 Stereo amp simulator. 75 20 STEREO AMP SIMULATOR
Stereo Amp Simulator 2 75 21 STEREO AMP SIMULATOR
Stereo Amp Simulator 3 75 8 STEREO AMP SIMULATOR
Stereo Amp Simulator 4 75 24 STEREO AMP SIMULATOR
Stereo Amp Simulator 5 75 25 STEREO AMP SIMULATOR
Stereo Amp Simulator 6 75 26 STEREO AMP SIMULATOR
Distortion + Delay 1 Distortion and Delay are connected in series. 95 16 DISTORTION DELAY
Distortion + Delay 2 95 0 DISTORTION DELAY
Overdrive + Delay 1 Overdrive and Delay are connected in series. 95 17 DISTORTION DEL AY
Overdrive + Delay 2 95 1 DISTORTION DELAY
Comp + Dist + Delay 1 Compressor, Distortion and Delay are connected in series. 96 16 COMP DIST DELAY
Comp + Dist + Delay 2 96 0 COMP DIST DELAY
Comp + OD + Delay 1 96 17 COMP DIST DELAY
Comp + OD + Delay 2 96 1 COMP DIST DELAY
V Distortion Soft + Delay V Distortion Soft and Delay are connected in series. 98 3 V DISTORTION DELAY
V Dist Hard + Tmp Delay 1 V Distortion Hard and Tempo Delay are connected in series. 103 0 V DIST TEMPO DELAY
V Dist Hard + Tmp Delay 2 103 17 V DIST TEMPO DELAY
V Dist Soft + Tmp Delay 1 V Distortion Soft and Tempo Delay are connected in series. 103 1 V DIST TEMPO DELAY
V Dist Soft + Tmp Delay 2 103 16 V DIST TEMPO DELAY
Distortion + Tempo Delay Distortion and Tempo Delay are connected in series. 100 0 DIST TEMPO DELAY
Overdrive + Tempo Delay Overdrive and Tempo Delay are connected in series. 100 1 DIST TEMPO DELAY
Comp + Distortion 1 Since a Compressor is included in the first stage, steady distortion
Comp + Distortion 2 73 1 COMP DISTORTION
Comp + Dist + Tmp Delay Compressor, Distortion and Tempo Delay are connected in series. 101 0 COMP DIST TEMPO DELAY
Comp + OD + Tmp Delay 1 Compressor, Overdrive and Tempo Delay are connected in series. 101 1 COMP DIST TEMPO DELAY
Comp + OD + Tmp Delay 2 101 16 COMP DIST TEMPO DELAY
Comp + OD + Tmp Delay 3 101 17 COMP DIST TEMPO DELAY
Comp + OD + Tmp Delay 4 101 18 COMP DIST TEMPO DELAY
Comp + OD + Tmp Delay 5 101 19 COMP DIST TEMPO DELAY
Comp + OD + Tmp Delay 6 101 20 COMP DIST TEMPO DELAY
Multiband Compressor Multi-band compressor that allows you to adjust the compression
Compressor Holds down the output level when a specified input level is
Noise Gate Gates the input when the input signal falls below a specified level. 84 0 NOISE GATE
EQ Disco Equalizer effect that boosts both high and low frequencies, as is
2Band EQ A stereo EQ with adjustable LOW and HIGH. Ideal for drum Parts. 77 0 2BAND EQ
Stereo 3Band EQ A stereo EQ with adjustable LOW, MID, and HIGH equalization. 76 18 3BAND EQ
Harmonic Enhancer 1 Adds new harmonics to the input signal to make the sound stand
Harmonic Enhancer 2 81 0 HARM ONIC ENHANCER
Isolator Controls the level of a specified frequency band of the input signal. 115 0 ISOLATOR
Chorus 3 Conventional chorus program with rich, warm chorusing. 66 16 CHORUS
Chorus 4 66 1 CHORUS
Chorus 5 65 2 CHORUS
Chorus 6 65 0 CHORUS
Chorus 7 65 1 CHORUS
Chorus 8 65 8 CHORUS
Chorus Fast 65 16 CHORUS
Chorus Lite 65 17 CHORUS
GM Chorus 1 65 3 CHORUS
GM Chorus 2 65 4 CHORUS
GM Chorus 3 65 5 CHORUS
GM Chorus 4 65 6 CHORUS
Feedback Chorus 65 7 CHORUS
Celeste 1 A 3-phase LFO adds modulation and spaciousness to the sound. 66 0 CHORUS
Celeste 2 66 2 CHORUS
Symphonic 2 Adds more stages to the modulation of Celeste. 68 0 SYMPHONIC
Ensemble Detune 1 Chorus effect without modulation, created by adding a slightly pitch-
Ensemble Detune 2 87 16 ENSEMBLE DETUNE
Ambience Chorus Chorus which added early reflection sound. 65 9 AMBIENCE CHORUS
Ambience Celeste Celeste which added early reflection sound. 66 9 AMBIENCE CHORUS
Ambience Symphonic Symphonic which added early reflection sound. 68 9 AMBIENCE SYMPHONIC
Flanger 2 Creates a sound similar to that of a jet airplane. 67 16 FLANGER
Flanger 3 67 17 FLANGER
Flanger 4 67 1 FLANGER
Flanger 5 67 0 FLANGER
GM Flanger 67 7 FLANGER
Dynamic Flanger Dynamically controlled flanger. 110 0 DYNAMIC FLANGER
Ambience Flanger Flanger which added early reflection sound. 67 9 AMBIENCE FLANGER
Phaser 2 Cyclically modulates the phase to add modulation to the sound. 72 8 PHASER2
Phaser 3 72 19 PHASER2
Tempo Phaser 2 Tempo-synchronized phaser. 108 16 TEMPO PHASER
can be produced regardless of changes in input level.
effect for individual frequency bands.
exceeded. A sense of attack can also be added to the sound.
typical in most disco music.
out.
shifted sound.
73 16 COMP DISTORTION
105 0 MULTI BAND COMP
83 0 COMPRESSOR
76 16 3BAND EQ
81 16 HA RMONIC ENHANCER
87 0 ENSEMBLE DETUNE
PSR-A3000 Data List
45
Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto
Category Type Description MSB LSB Parameter List
Legacy E-Piano Phaser 2 Cyclically modulates the phase to add modulation to the sound. For
E-Piano Phaser 3 72 16 PHASER1
Dynamic Phaser Dynamically controlled phaser. 111 0 DYNAMIC PHASER
Auto Wah 2 Cyclically modulates the center frequency of a wah filter. 78 0 AUTO WAH
Auto Wah + Distortion 2 Distortion can be applied to the output of Auto Wah. 78 1 AUTO WAH DISTORTION
Auto Wah + Dist Hard 78 21 AUTO WAH DISTORTION
Auto Wah + Dist Heavy 78 23 AUTO WAH DISTORTION
Auto Wah + Dist Lite 78 25 AUTO WAH DISTORTION
Auto Wah + Overdrive 1 Overdrive distortion can be applied to the output of Auto Wah. 78 18 AUTO WAH DISTORTION
Auto Wah + Overdrive 2 78 2 AUTO WAH DISTORTION
Auto Wah + OD Hard 78 22 AUTO WAH DISTORTION
Auto Wah + OD Heavy 78 24 AUTO WAH DISTORTION
Auto Wah + OD Lite 78 26 AUTO WAH DISTORTION
Tmp AutoWah + Dist Tempo-synchronized Auto Wah. Distortion can be applied to the
Tmp AutoWah + Dist Hard 79 21 TEMPO AUTO WAH2
Tmp AutoWah + Dist Heavy 79 23 TEMPO AUTO WAH2
Tmp AutoWah + Dist Lite 79 25 TEMPO AUTO WAH2
Tmp AutoWah + OD Tempo-synchronized Auto Wah. Overdrive distortion can be applied
Tmp AutoWah + OD Hard 79 22 TEMPO AUTO WAH2
Tmp AutoWah + OD Heavy 79 24 TEMPO AUTO WAH2
Tmp AutoWah + OD Lite 79 26 TEMPO AUTO WAH2
Touch Wah 2 Changes the center frequency of a wah filter according to the input
Touch Wah 3 82 20 TOUCH WAH2
Touch Wah + Distortion 2 Distortion can be applied to the output of Touch Wah. 82 1 TOUCH WAH1
Touch Wah + Dist Hard 82 21 TOUCH WAH2
Touch Wah + Dist Heavy 82 23 TOUCH WAH2
Touch Wah + Dist Lite 82 25 TOUCH WAH2
Touch Wah + Overdrive 1 Overdrive distortion can be applied to the output of Touch Wah. 82 17 TOUCH WAH2
Touch Wah + Overdrive 2 82 2 TOUCH WAH2
Touch Wah + OD Hard 82 22 TOUCH WAH2
Touch Wah + OD Heavy 82 24 TOUCH WAH2
Touch Wah + OD Lite 82 26 TOUCH WAH2
Wah + Dist + Delay 1 Wah, Distortion and Delay are connected in series. 97 16 WAH DISTORTION DELAY
Wah + Dist + Delay 2 97 0 WAH DISTORTION DELAY
Wah + Dist + Tmp Delay Wah, Distortion and Tempo Delay are connected in series. 102 0 WAH DIST TEMPO DELAY
Wah + Overdrive + Delay 1 Wah, Overdrive and Delay are connected in series. 97 17 WAH DISTORTION DELAY
Wah + Overdrive + Delay 2 97 1 WAH DISTORTION DELAY
Wah + OD + Tmp Delay 1 Wah, Overdrive and Tempo Delay are connected in series. 102 1 WAH DIST TEMPO DELAY
Wah + OD + Tmp Delay 2 102 16 WAH DIST TEMPO DELAY
Clavi Touch Wah Clavinet Touch Wah 82 18 TOUCH WAH2
EP Touch Wah EP Touch Wah 82 19 TOUCH WAH2
Pedal Wah + Dist Hard Distortion can be applied to the output of Pedal Wah. 122 21 PEDAL WAH2
Pedal Wah + Dist Heavy 122 23 PEDAL WAH2
Pedal Wah + Dist Lite 122 25 PEDAL WAH2
Pedal Wah + Overdrive Overdrive distortion can be applied to the output of Pedal Wah. 122 2 PEDAL WAH2
Pedal Wah + OD Hard 122 22 PEDAL WAH2
Pedal Wah + OD Heavy 122 24 PEDAL WAH2
Pedal Wah + OD Lite 122 26 PEDAL WAH2
Dual Rotary Speaker 1 Simulates a rotary speaker. 99 0 ROTARY SPEAKER1
Dual Rotary Speaker 2 99 1 ROTARY SPEAKER1
Rotary Speaker 2 71 17 AUTO PAN1
Rotary Speaker 3 71 18 AUTO PAN1
Rotary Speaker 4 70 17 TREMOLO
Rotary Speaker 5 66 18 CHORUS
Rotary Speaker 6 69 0 ROTARY SPEAKER2
Rotary Speaker 7 71 22 AUTO PAN1
2way Rotary Speaker 86 0 2WAY ROTARY SPEAKER
Dist + Rotary SP Distortion and rotary speaker connected in series. 69 1 DIST ROTARY SPEAKER
Dist + 2way Rotary SP Distortion and 2-way rotary speaker connected in series. 86 1 DIST 2WAY ROTARY SP
OD + Rotary SP Overdrive and rotary speaker connected in series. 69 2 DIST ROTARY SPEAKER
OD + 2way Rotary SP Overdrive and 2-way rotary speaker connected in series. 86 2 DIST 2WAY ROTARY SP
Amp Sim + Rotary SP Amp simulator and rotary speaker connected in series. 69 3 AMP ROTARY SPEAKER
Amp Sim + 2way Rotary SP Amp simulator and 2-way rotary speaker connected in series. 86 3 AMP 2WAY ROTARY SP
Tremolo 2 Rich Tremolo effect with both volume and pitch modulation. 71 19 AUTO PAN1
Tremolo 3 70 0 TREMOLO
Guitar Tremolo 1 71 20 AUTO PAN1
Guitar Tremolo 2 70 19 TREMOLO
Vibraphone Rotor Vibraphone effect. 119 0 VIBE VIBRATE
Auto Pan 2 Several panning effects that automatically shift the sound position
Auto Pan 3 71 1 AUTO PAN2
E-Piano Auto Pan 71 21 AUTO PAN1
Tempo Auto Pan 2 Tempo-synchronized auto pan. 121 1 TEMPO AUTO PAN2
Pitch Change 1 Changes the pitch of the input signal. 80 16 PITCH CHANGE1
Pitch Change 2 80 0 PITCH CHANGE1
Pitch Change 3 80 1 PITCH CHANGE2
Voice Cancel Attenuates the vocal part of a CD or other source. 85 0 VOICE CANCELAR
electric piano.
output.
to the output.
level.
(left, right, front, back).
72 18 PHASER1
79 1 TEMPO AUTO WAH2
79 2 TEMPO AUTO WAH2
82 8 TOUCH WAH2
71 0 AUTO PAN1
PSR-A3000 Data List
46
Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto
Category Type Description MSB LSB Parameter List
Legacy Ambience Blurs the stereo positioning of the sound to add spatial width. 88 0 AMBIENCE
--- No Effect No effect. 0 0 NO EFFECT
--- Through Bypass without applying an effect. 64 0 THRU
Talking Modulation Adds a vowel sound to the input signal. 93 0 TALKING MODULATION
Lo-Fi Degrades the audio quality of the input signal. 94 0 LO FI
Dynamic Filter Dynamically controlled filter. 109 0 DYNAMIC FILTER
Dynamic Ring Modulator Dynamically controlled Ring Modulator. 112 0 DYNAMIC RING MOD
Ring Modulator An effect that modifies the pitch by applying amplitude modulation to
the frequency of the input.
113 0 RING MODULATOR
PSR-A3000 Data List
47
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
• Parameters marked with a in the “Control” column can be controlled from an AC1
(assignable controller 1) etc. However, these only affect insertion type effects.
• Parameter 10 Dry/Wet only affects insertion type effects.
(*1) Reverb Block
(*2) Chorus Block, DSP1(Variation) Block and DSP2-4(Insertion) Block
REVERB
REAL REVERB
Block : Reverb
No. Parameter Display Min Max Table
1 Reverb Time 0.3s – 30.0s 0 69 Ta b l e# 1
2
3 Initial Delay 0.1ms – 200.0ms 0 127 Ta b le # 2
4 High Damp Frequency 1.0kHz – 18kHz, Thru 34 60 Ta b l e# 3
5
6 High Ratio 0.0 – 1.0 0 10
7
8
9
10
11
12
13 EQ Low Frequency 22Hz – 1.0kHz 1 34 Ta b l e# 3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 18.0kHz 28 59 Ta b le # 3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
REVERB1
Block : Reverb, Chorus, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Reverb Time 0.3s – 30.0s 0 69 Ta b l e# 1
2 Diffusion 0 – 10 0 10
3 Initial Delay 0.1ms – 200.0ms (*1) 0 127 Ta b le # 2
4 HPF Cutoff Thru, 22Hz – 8.0kHz 0 52 Ta bl e #3
5 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Ta b le # 3
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Reverb Delay 0.1ms – 200.0ms (*1) 0 127 Ta bl e #2
12 Density 0 – 4 0 4
13 ER/Reverb Balance E63>R – E=R – E<R63 1 127
14 High Damp 0.1 – 1.0 1 10
15 Feedback Level -63 – 0 – +63 1 127
16
REVERB2
Block : Reverb
No. Parameter Display Min Max Table Control
1 Reverb Time 0.3s – 30.0s 0 69 Ta b l e# 1
2 Diffusion 0 – 10 0 10
3 Initial Delay 0.1ms – 200.0ms 0 127 Ta b le # 2
4 HPF Cutoff Thru, 22Hz – 8.0kHz 0 52 Ta bl e #3
5 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Ta b le # 3
6
7
8
9
10
11
12
13
14 High Damp 0.1 – 1.0 1 10
15
16
0.1ms – 99.3ms (*2) 0 63
0.1ms – 99.3ms (*2) 0 63
Control
REVERB3
Block : Reverb, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Reverb Time 0.3s – 30.0s 0 69 Table#1
2 Diffusion 0 – 10 0 10
3 Initial Delay 0.1ms – 200.0ms (*1) 0 127 Table#2
4 HPF Cutoff Thru, 22Hz – 8.0kHz 0 52 Table#3
5 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
6 Width 0.5m – 30.2m (*1) 0 104 Table#4
7 Height 0.5m – 30.2m (*1) 0 104 Table#4
8 Depth 0.5m – 30.2m 0 104 Table#4
9 Wall Vary 0 – 30 0 30
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Reverb Delay 0.1ms – 200.0ms (*1) 0 127 Table#2
12 Density 0 – 4 0 4
13 ER/Reverb Balance E63>R – E=R – E<R63 1 127
14 High Damp 0.1 – 1.0 1 10
15 Feedback Level -63 – 0 – +63 1 127
16
0.1ms – 99.3ms (*2) 0 63
0.5m – 10.2m (*2) 0 37
0.5m – 20.2m (*2) 0 73
0.1ms – 99.3ms (*2) 0 63
DELAY
DELAY LCR
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Lch Delay 0.1ms – 1638.3ms 1 16383
2 Rch Delay 0.1ms – 1638.3ms 1 16383
3 Cch Delay 0.1ms – 1638.3ms 1 16383
4 Feedback Delay 0.1ms – 1638.3ms 1 16383
5 Feedback Level -63 – 0 – +63 1 127
6 Cch Level 0 – 127 0 127
7 High Damp 0.1 – 1.0 1 10
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
DELAY LR
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Lch Delay 0.1ms – 1638.3ms 1 16383
2 Rch Delay 0.1ms – 1638.3ms 1 16383
3 Feedback Delay 1 0.1ms – 1638.3ms 1 16383
4 Feedback Delay 2 0.1ms – 1638.3ms 1 16383
5 Feedback Level -63 – 0 – +63 1 127
6 High Damp 0.1 – 1.0 1 10
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
PSR-A3000 Data List
48
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
ECHO
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Lch Delay1 0.1ms – 1486.0ms 1 14860
2 Lch Feedback Level -63 – 0 – +63 1 127
3 Rch Delay1 0.1ms – 1486.0ms 1 14860
4 Rch Feedback Level -63 – 0 – +63 1 127
5 High Damp 0.1 – 1.0 1 10
6 Lch Delay2 0.1ms – 1486.0ms 1 14860
7 Rch Delay2 0.1ms – 1486.0ms 1 14860
8 Delay2 Level 0 – 127 0 127
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b l e# 3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
CROSS DELAY
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 L->R Delay 0.1ms – 1486.0ms 1 14860
2 R->L Delay 0.1ms – 1486.0ms 1 14860
3 Feedback Level -63 – 0 – +63 1 127
4 Input Select L, R, L&R 0 2
5 High Damp 0.1 – 1.0 1 10
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b l e# 3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
TEMPO DELAY
Block : Chorus, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Delay Time 32nd/3 – 4thx6 0 19 Ta bl e #5
2 Feedback Level -63 – 0 – +63 1 127
3 Feedback High Dump 0.1 – 1.0 1 10
4 L/R Diffusion -63ms – 0ms – 63ms 1 127
5 Lag -63ms – 0ms – 63ms 1 127
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58
16 EQ High Gain -12dB – 0dB – +12dB 52 76
TEMPO CROSS DELAY
Block : Chorus, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Delay Time L>R 32nd/3 – 4thx6 0 19 Ta b l e# 5
2 Delay Time R>L 32nd/3 – 4thx6 0 19 Ta b l e# 5
3 Feedback Level -63 – 0 – +63 1 127
4 Input Select L, R, L&R 0 2
5 Feedback High Dump 0.1 – 1.0 1 10
6 Lag -63ms – 0ms – 63ms 1 127
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58
16 EQ High Gain -12dB – 0dB – +12dB 52 76
ER/KARAOKE
KARAOKE
Block : Chorus, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Delay Time 0.1ms – 400.0ms 0 127 Table#6
2 Feedback Level -63 – 0 – +63 1 127
3 HPF Cutoff Thru, 22Hz – 8.0kHz 0 52 Table#3
4 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Density 0 – 3 0 3
12
13
14
15
16
EARLY REFLECTION
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Type S-H, L-H, Rdm, Rvs, Plt, Spr 0 5
2 Room Size 0.1 – 20.0 0 127 Table#7
3 Diffusion 0 – 10 0 10
4 Initial Delay 0.1ms – 200.0ms 0 127 Table#2
5 Feedback Level -63 – 0 – +63 1 127
6 HPF Cutoff Thru, 22Hz – 8.0kHz 0 52 Table#3
7 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Liveness 0 – 10 0 10
12 Density 0 – 3 0 3
13 High Damp 0.1 – 1.0 1 10
14
15
16
GATE REVERB
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Type TypeA, TypeB 0 1
2 Room Size 0.1 – 20.0 0 127 Table#7
3 Diffusion 0 – 10 0 10
4 Initial Delay 0.1ms – 200.0ms 0 127 Table#2
5 Feedback Level -63 – 0 – +63 1 127
6 HPF Cutoff Thru, 22Hz – 8.0kHz 0 52 Table#3
7 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Liveness 0 – 10 0 10
12 Density 0 – 3 0 3
13 High Damp 0.1 – 1.0 1 10
14
15
16
PSR-A3000 Data List
49
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
CHORUS
CHORUS
Block : Chorus, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Tab l e# 8
2 LFO Depth 0 – 127 0 127
3 Feedback Level -63 – 0 – +63 1 127
4 Delay Offset 0.0ms – 50ms 0 127 Ta b le # 9
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Ta b le # 3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14
15 Input Mode Mono, Stereo 0 1
16
SYMPHONIC
Block : Chorus, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Tab l e# 8
2 LFO Depth 0 – 127 0 127
3 Delay Offset 0.0ms – 50ms 0 127 Ta b le # 9
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Ta b le # 3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14
15
16
ENSEMBLE DETUNE
Block : Chorus, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Detune -50cent – 0cent – +50cent 14 114
2 Lch Initial Delay 0.0ms – 50ms 0 127 Tab l e# 9
3 Rch Initial Delay 0.0ms – 50ms 0 127 Tab l e #9
4
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b l e# 3
12 EQ Low Gain -12dB – 0dB – +12dB 52 76
13 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
14 EQ High Gain -12dB – 0dB – +12dB 52 76
15
16
AMBIENCE CHORUS
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Tab l e# 8
2 LFO PMod Depth 0 – 127 0 127
3 Feedback Level -63 – 0 – +63 1 127
4 Delay Offset 0.0ms – 50ms 0 127 Ta b le # 9
5 LFO AMod Depth 0 – 127 0 127
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14 Ambience 0 – 127 0 127
15
16 Connect Mode Amb->Cho, Cho->Amb 0 1
AMBIENCE SYMPHONIC
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Table#8
2 LFO Depth 0 – 127 0 127
3 Delay Offset 0.0ms – 50ms 0 127 Table#9
4
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14 Ambience 0 – 127 0 127
15
16 Connect Mode Amb->Sym, Sym->Amb 0 1
FLANGER
FLANGER
Block : Chorus, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Table#8
2 LFO Depth 0 – 127 0 127
3 Feedback Level -63 – 0 – +63 1 127
4 Delay Offset 0.0ms – 50ms 0 127 Table#9
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14 LFO Phase Difference -180deg – 0deg –
15
16
V FLANGER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Table#8
2 LFO Depth 0 – 127 0 127
3 LFO Wave Triangle, Sine, Random 0 2
4 Delay Offset 0.09ms – 36.21ms 0 139
5 Feedback Level -100% – 0% – +100% 0 200
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14 Modulation Phase -180deg – 0deg – +180deg 0 16
15 Feedback High Damp 0.1 – 1.0 1 10
16 Analog Feel 0 – 10 0 10
TEMPO FLANGER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 16th – 4thx16 5 29 Table#5
2 LFO Depth 0 – 127 0 127
3 Feedback Level -63 – 0 – +63 1 127
4 Delay Offset 0.0ms – 50ms 0 127 Table#9
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14 LFO Phase Difference -180deg – 0deg – +180deg 4 124
15
16
+180deg(resolution=3deg.)
4124
Table#10
Table#11
PSR-A3000 Data List
50
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
DYNAMIC FLANGER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table
1 Sensitivity 0 – 127 0 127
2 Delay Time Offset 0 – 127 0 127
3 Feedback Level -63 – 0 – +63 1 127
4 Attack Time 0.3ms – 227ms 0 127
5 Release Time 2.6ms – 2171.4ms 0 127
6 Release Curve 0 – 127 0 127
7 Direction Up, Down 0 1
8 Dyna Threshold Level 0 – 127 0 127
9 Dyna Level Offset 0 – 127 0 127
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b l e# 3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
AMBIENCE FLANGER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Tab l e# 8
2 LFO Depth 0 – 127 0 127
3 Feedback Level -63 – 0 – +63 1 127
4 Delay Offset 0.0ms – 50ms 0 127 Ta b le # 9
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14 LFO Phase Difference -180deg – 0deg –
15 Ambience 0 – 127 0 127
16 Connect Mode Amb->Flg, Flg->Amb 0 1
+180deg(resolution=3deg.)
4124
Control
Table#12
Table#13
PHASER2
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Table#8
2 LFO Depth 0 – 127 0 127
3 Phase Shift Offset 0 – 127 0 127
4 Feedback Level -63 – 0 – +63 1 127
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Stage 3 – 11 3 11
12
13 LFO Phase Difference -180deg – 0deg –
14
15
16
TEMPO PHASER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 16th – 4thx16 5 29 Table#5
2 LFO Depth 0 – 127 0 127
3 Phase Shift Offset 0 – 127 0 127
4 Feedback Level -63 – 0 – +63 1 127
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Stage 3 – 11 3 11
12
13 LFO Phase Difference -180deg – 0deg – +180deg 4 124
14
15
16
+180deg(resolution=3deg.)
4124
PHASER
PHASER1
Block : Chorus, DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Tab l e# 8
2 LFO Depth 0 – 127 0 127
3 Phase Shift Offset 0 – 127 0 127
4 Feedback Level -63 – 0 – +63 1 127
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Stage 4 – 22 4 22
12 Diffusion Mono, Stereo 0 1
13
14
15
16
DYNAMIC PHASER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table
1 Sensitivity 0 – 127 0 127
2 Dyna Level Offset 0 – 127 0 127
3 Feedback Level -63 – 0 – +63 1 127
4 Attack Time 0.3ms – 227ms 0 127
5 Release Time 2.6ms – 2171.4ms 0 127
6 Release Curve 0 – 127 0 127
7 Direction Up, Down 0 1
8 Dyna Threshold Level 0 – 127 0 127
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Stage 4, 5, 6 4 6
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
Table#12
Table#13
Control
PSR-A3000 Data List
51
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
DISTORTION/AMP SIMULATOR
V DISTORTION
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Overdrive 0% – 100% 0 100
2 Device Transistor, Vintage Tube,
3 Speaker Type Flat, Stack, Combo, Twin,
4 Presence 0 – 20 0 20
5 Output Level 0% – 100% 0 100
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14
15
16
V DIST TEMPO DELAY
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Overdrive 0% – 100% 0 100
2 Device Transistor, Vintage Tube,
3 Speaker Type Flat, Stack, Combo, Twin,
4 Presence 0 – 20 0 20
5 Output Level 0% – 100% 0 100
6 Delay Time 32nd/3 – 4thx6 0 19 Ta bl e #5
7 Delay Feedback Level -63 – 0 – +63 1 127
8 L/R Diffusion -63ms – 0ms – 63ms 1 127
9 Lag -63ms – 0ms – 63ms 1 127
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Delay Mix 0 – 127 0 127
12 Feedback High Dump 0.1 – 1.0 1 10
13
14
15
16
STEREO AMP SIMULATOR
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Drive 0 – 127 0 127
2 AMP Type Off, Stack, Combo, Tube 0 3
3 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Ta b le # 3
4 Output Level 0 – 127 0 127
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Edge(Clip Curve) 0 – 127(mild – sharp) 0 127
12
13
14
15
16
Dist1, Dist2, Fuzz
Radio, Megaphone
Dist1, Dist2, Fuzz
Radio, Megaphone
04
05
04
05
AMP SIMULATOR1
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Drive 0 – 127 0 127
2 AMP Type Off, Stack, Combo, Tube 0 3
3 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
4 Output Level 0 – 127 0 127
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Edge(Clip Curve) 0 – 127(mild – sharp) 0 127
12
13
14
15
16
DISTORTION
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Drive 0 – 127 0 127
2 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
3 EQ Low Gain -12dB – 0dB – +12dB 52 76
4 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
5 Output Level 0 – 127 0 127
6
7 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
8 EQ Mid Gain -12dB – 0dB – +12dB 52 76
9 EQ Mid Width 0.1 – 12.0 1 120
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Edge(Clip Curve) 0 – 127(mild – sharp) 0 127
12
13
14
15
16
STEREO DISTORTION
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Drive 0 – 127 0 127
2 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
3 EQ Low Gain -12dB – 0dB – +12dB 52 76
4 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
5 Output Level 0 – 127 0 127
6
7 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
8 EQ Mid Gain -12dB – 0dB – +12dB 52 76
9 EQ Mid Width 0.1 – 12.0 1 120
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Edge(Clip Curve) 0 – 127 0 127
12
13
14
15
16
AMP SIMULATOR2
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Drive 0 – 127 0 127
2 AMP Type Off, Stack, Combo, Tube,
3 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
4 Output Level 0 – 127 0 127
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14
15
16
Crunch, Hi-Gain, British
06
PSR-A3000 Data List
52
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
DISTORTION DELAY
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Lch Delay Time 0.1ms – 1638.3ms 1 16383
2 Rch Delay Time 0.1ms – 1638.3ms 1 16383
3 Delay Feedback Time 0.1ms – 1638.3ms 1 16383
4 Delay Feedback Level -63 – 0 – +63 1 127
5 Delay Mix 0 – 127 0 127
6 Dist Drive 0 – 127 0 127
7 Dist Output Level 0 – 127 0 127
8 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
9 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14
15
16
COMP DIST DELAY
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Delay Time 0.1ms – 1638.3ms 1 16383
2 Delay Feedback Level -63 – 0 – +63 1 127
3 Delay Mix 0 – 127 0 127
4 Dist Drive 0 – 127 0 127
5 Dist Output Level 0 – 127 0 127
6 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
7 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Comp. Attack 1ms – 40ms 0 19
12 Comp. Release 10ms – 680ms 0 15
13 Comp. Threshold -48dB – -6dB 79 121
14 Comp. Ratio 1.0 – 20.0 0 7
15
16
Table#14
Table#15
Table#16
COMP DISTORTION
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Drive 0 – 127 0 127
2 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
3 EQ Low Gain -12dB – 0dB – +12dB 52 76
4 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
5 Output Level 0 – 127 0 127
6
7 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
8 EQ Mid Gain -12dB – 0dB – +12dB 52 76
9 EQ Mid Width 0.1 – 12.0 1 120
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Edge(Clip Curve) 0 – 127(mild – sharp) 0 127
12 Attack 1ms – 40ms 0 19
13 Release 10ms – 680ms 0 15
14 Threshold -48dB – -6dB 79 121
15 Ratio 1.0 – 20.0 0 7
16
COMP DIST TEMPO DELAY
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Delay Time 32nd/3 – 4thx6 0 19 Table#5
2 Delay Feedback Level -63 – 0 – +63 1 127
3 Delay Mix 0 – 127 0 127
4 Dist Drive 0 – 127 0 127
5 Dist Output Level 0 – 127 0 127
6 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
7 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
8 L/R Diffusion -63ms – 0ms – 63ms 1 127
9 Lag -63ms – 0ms – 63ms 1 127
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Comp. Attack 1ms – 40ms 0 19
12 Comp. Release 10ms – 680ms 0 15
13 Comp. Threshold -48dB – -6dB 79 121
14 Comp. Ratio 1.0 – 20.0 0 7
15
16
Table#14
Table#15
Table#16
Table#14
Table#15
Table#16
V DISTORTION DELAY
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Overdrive 0% – 100% 0 100
2 Device Transistor, Vintage Tube,
3 Speaker Type Flat, Stack, Combo, Twin,
4 Presence 0 – 20 0 20
5 Output Level 0% – 100% 0 100
6 Delay Time L 0.1ms – 1638.3ms 1 16383
7 Delay Time R 0.1ms – 1638.3ms 1 16383
8 Delay Feedback Time 0.1ms – 1638.3ms 1 16383
9 Delay Feedback Level -63 – 0 – +63 1 127
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Delay Mix 0 – 127 0 127
12 Feedback High Dump 0.1 – 1.0 1 10
13
14
15
16
DIST TEMPO DELAY
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Delay Time 32nd/3 – 4thx6 0 19 Ta bl e #5
2 Delay Feedback Level -63 – 0 – +63 1 127
3 Delay Mix 0 – 127 0 127
4 Dist Drive 0 – 127 0 127
5 Dist Output Level 0 – 127 0 127
6 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
7 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
8 L/R Diffusion -63ms – 0ms – 63ms 1 127
9 Lag -63ms – 0ms – 63ms 1 127
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14
15
16
Dist1, Dist2, Fuzz
Radio, Megaphone
04
05
MULTI FX
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Comp. Sustain Off, 0.1 – 10.0 0 100
2 Wah SW Off, Wah Pedal, Auto+ Full,
3 Wah Pedal 0 – 127 0 127
4 Dist SW Off, Overdrive, Distortion1,
5 Dist Drive 0.0 – 10.0 0 100
6 Dist EQ High Boost, Mid Boost, Mid
7 Dist Tone 0.0 – 10.0 0 100
8 Dist Presence 0.0 – 10.0 0 100
9 Output 0 – 127 0 127
10
11 Speaker Type Off, Stack, Twin, Tweed,
12 LFO Speed 0.1Hz – 9.925Hz 0 127
13 Phaser SW Off, Standard, Wide, Vibe,
14 Delay SW Off, Delay M, Echo1 M,
15 Delay Ctrl 0 – 127 0 127
16 Delay Time 0 – 127 0 127
Auto+ Mid, Auto+ Light,
Auto- Full, Auto- Mid, AutoLight
Distortion2, Clean, Crunch,
Hi-Gain, Modern
Cut 1, Mid Cut 2, Mid Cut 3,
Low Cut 1, Low Cut 2, High
Cut, High/Low
Oldies, Modern, Mean, Soft,
Small, Dip1, Dip2, Metal,
Light
Tremolo
Echo2 M, Chorus M, Dl
Chorus M, Flanger1 M,
Flanger2 M, Flanger3 M,
Delay St, Echo1 St, Echo2
St, Chorus St, Dl Chorus St,
Flanger1 St, Flanger2 St,
Flanger3 St
07
07
08
012
Table#17
04
016
PSR-A3000 Data List
53
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
SMALL STEREO DIST
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Comp. SW Off, On 0 1
2 Comp. Sustain 0.0 – 10.0 0 100
3 Comp. Level 0.0 – 10.0 0 100
4 Dist Type Overdrive, Distortion1,
5 Dist Drive 0.0 – 10.0 0 100
6 Dist EQ High Boost, Mid Boost, Mid
7 Dist Tone 0.0 – 10.0 0 100
8 Dist Presence 0.0 – 10.0 0 100
9 Output 0 – 127 0 127
10
11 Speaker Type Off, Stack, Twin, Tweed,
12
13
14
15
16
BRITISH COMBO
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Mode Bright, Top Boost 0 1
2 Normal 0.0 – 10.0 0 100
3 Brilliant 0.0 – 10.0 0 100
4 Bass 0.0 – 10.0 0 100
5
6 Treble 0.0 – 10.0 0 100
7 Cut 0.0 – 10.0 0 100
8
9 Output 0 – 127 0 127
10
11 Speaker Type Off, BS 4x12, AC 2x12, AC
12 Speaker Air 0 – 2 0 2
13 Mic Posi tion Center, Edge 0 1
14
15
16
BRITISH LEGEND
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Sensitivity High, Low 0 1
2 Preamp 0.0 – 10.0 0 100
3
4 Bass 0.0 – 10.0 0 100
5 Middle 0.0 – 10.0 0 1 00
6 Treble 0.0 – 10.0 0 100
7 Presence 0.0 – 10.0 0 100
8 Master Volume 0.0 – 10.0 0 100
9 Output 0 – 127 0 127
10
11 Speaker Type Off, BS 4x12, AC 2x12, AC
12 Speaker Air 0 – 2 0 2
13 Mic Posi tion Center, Edge 0 1
14
15
16
Distortion2, Clean, Crunch,
Hi-Gain, Modern
Cut 1, Mid Cut 2, Mid Cut 3,
Low Cut 1, Low Cut 2, High
Cut, High/Low
Oldies, Modern, Mean, Soft,
Small, Dip1, Dip2, Metal,
Light
1x12, AC 4x10, BC 2x12,
AM 4x12, YC 4x12, JC 2x12,
OC 2x12, OC 1x8
1x12, AC 4x10, BC 2x12,
AM 4x12, YC 4x12, JC 2x12,
OC 2x12, OC 1x8
17
08
012
010
010
PITCH CHANGE
PITCH CHANGE1
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Pitch -24 – 0 – +24 40 88
2 Initial Delay 0.1ms – 400.0ms 0 127 Table#6
3 Fine 1 -50 – 0 – +50 14 114
4 Fine 2 -50 – 0 – +50 14 114
5 Feedback Level -63 – 0 – +63 1 127
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Pan 1 L63 – C – R63 1 127
12 Output Level 1 0 – 127 0 127
13 Pan 2 L63 – C – R63 1 127
14 Output Level 2 0 – 127 0 127
15
16
PITCH CHANGE2
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Pitch -24 – 0 – +24 40 88
2 Initial Delay 0.1ms – 400.0ms 0 127 Table#6
3 Fine 1 -50cent – 0cent – +50cent 14 114
4 Fine 2 -50cent – 0cent – +50cent 14 114
5 Feedback Level -63 – 0 – +63 1 127
6
7
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Pan 1 L63 – C – R63 1 127
12 Output Level 1 0 – 127 0 127
13 Pan 2 L63 – C – R63 1 127
14 Output Level 2 0 – 127 0 127
15
16
AUTO WAH
AUTO WAH
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Table#8
2 LFO Depth 0 – 127 0 127
3 Cutoff Frequency Offset 0 – 127 0 127
4 Resonance 1.0 – 12.0 10 120
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Drive 0 – 127 0 127
12
13
14
15
16
PSR-A3000 Data List
54
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
AUTO WAH DISTORTION
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Tab l e# 8
2 LFO Depth 0 – 127 0 127
3 Cutoff Frequency Offset 0 – 127 0 127
4 Resonance 1.0 – 12.0 10 120
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Drive 0 – 127 0 127
12 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
13 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
14 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Ta bl e # 3
15 Output Level 0 – 127 0 127
16
TEMPO AUTO WAH1
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 16th – 4thx16 5 29 Ta b l e# 5
2 LFO Depth 0 – 127 0 127
3 Cutoff Frequency Offset 0 – 127 0 127
4 Resonance 1.0 – 12.0 10 120
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Drive 0 – 127 0 127
12
13
14
15
16
TEMPO AUTO WAH2
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 16th – 4thx16 5 29 Ta b l e# 5
2 LFO Depth 0 – 127 0 127
3 Cutoff Frequency Offset 0 – 127 0 127
4 Resonance 1.0 – 12.0 10 120
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Drive 0 – 127 0 127
12 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
13 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
14 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Ta bl e # 3
15 Output Level 0 – 127 0 127
16
TOUCH WAH/PEDAL WAH
TOUCH WAH1
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Sensitivity 0 – 127 0 127
2 Cutoff Frequency Offset 0 – 127 0 127
3 Resonance 1.0 – 12.0 10 120
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Drive 0 – 127 0 127
12
13
14
15
16
TOUCH WAH2
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Sensitivity 0 – 127 0 127
2 Cutoff Frequency Offset 0 – 127 0 127
3 Resonance 1.0 – 12.0 10 120
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Drive 0 – 127 0 127
12 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
13 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
14 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
15 Output Level 0 – 127 0 127
16 Release 10ms – 680ms 52 67
WAH DISTORTION DELAY
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Delay Time 0.1ms – 1638.3ms 1 16383
2 Delay Feedback Level -63 – 0 – +63 1 127
3 Delay Mix 0 – 127 0 127
4 Dist Drive 0 – 127 0 127
5 Dist Output Level 0 – 127 0 127
6 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
7 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Wah Sensitivity 0 – 127 0 127
12 Wah Cutoff Frequency
Offset
13 Wah Resonance 1.0 – 12.0 10 120
14 Wah Release 10ms – 680ms 52 67
15
16
WAH DIST TEMPO DELAY
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Delay Time 32nd/3 – 4thx6 0 19 Table#5
2 Delay Feedback Level -63 – 0 – +63 1 127
3 Delay Mix 0 – 127 0 127
4 Dist Drive 0 – 127 0 127
5 Dist Output Level 0 – 127 0 127
6 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
7 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
8 L/R Diffusion -63ms – 0ms – 63ms 1 127
9 Lag -63ms – 0ms – 63ms 1 127
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Wah Sensitivity 0 – 127 0 127
12 Wah Cutoff Frequency
Offset
13 Wah Resonance 1.0 – 12.0 10 120
14 Wah Release 10ms – 680ms 52 67
15
16
PEDAL WAH1
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Pedal Control 0 – 127 0 127
2 Depth 0 – 127 0 127
3 Cutoff Frequency Offset 0 – 127 0 127
4 Resonance 1.0 – 12.0 10 120
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Drive 0 – 127 0 127
12
13
14
15
16
0 – 127 0 127
0 – 127 0 127
Table#18
Table#18
Table#18
PSR-A3000 Data List
55
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
PEDAL WAH2
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Pedal Control 0 – 127 0 127
2 Depth 0 – 127 0 127
3 Cutoff Frequency Offset 0 – 127 0 127
4 Resonance 1.0 – 12.0 10 120
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 Drive 0 – 127 0 127
12 Dist EQ Low Gain -12dB – 0dB – +12dB 52 76
13 Dist EQ Mid Gain -12dB – 0dB – +12dB 52 76
14 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Ta bl e # 3
15 Output Level 0 – 127 0 127
16
COMPRESSOR/NOISE GATE
COMPRESSOR
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Attack 1ms – 40ms 0 19
2 Release 10ms – 680ms 0 15
3 Threshold -48dB – -6dB 79 121
4 Ratio 1.0 – 20.0 0 7
5 Output Level 0 – 127 0 127
6
7
8
9
10
11
12
13
14
15
16
MULTI BAND COMP
Block : DSP1(Variation), DSP2-4(Insertion), Master (96step)
No. Parameter Display Min Max Table Control
1 Type Normal, Low, Mid, High,
2 Threshold Offset -32 – +32 32 96
3 Low Gain Offset -63 – 0 – +63 1 127
4 Mid Gain Offset -63 – 0 – +63 1 127
5 High Gain Offset -63 – 0 – +63 1 127
6
7
8
9
10
11
12
13
14
15
16
NOISE GATE
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Attack 1ms – 40ms 0 19
2 Release 10ms – 680ms 0 15
3 Threshold -72dB – -30dB 55 97
4 Output Level 0 – 127 0 127
5
6
7
8
9
10
11
12
13
14
15
16
Low/High, Low/Mid, Mid/
High, Full Bit, Wild, Attacky,
Low End, Hard, Basic
012
Table#14
Table#15
Table#16
Table#14
Table#15
ROTARY SPEAKER/AUTO PAN/TREMOLO
ROTARY SPEAKER1
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Rotor Speed Slow 0.00Hz – 2.65Hz 0 63 Table#8
2 Horn Speed Slow 0.00Hz – 2.65Hz 0 63 Table#8
3 Rotor Speed Fast 2.69Hz – 39.7Hz 64 127 Table#8
4 Horn Speed Fast 2.69Hz – 39.7Hz 64 127 Table#8
5 Slow-Fast Time of Rotor 0 – 127 0 127
6 Slow-Fast Time of Horn 0 – 127 0 127
7 Drive Low 0 – 127 0 127
8 Drive High 0 – 127 0 127
9 Low/High Balance L63>H – L=H – L<H63 1 127
10
11 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
12 EQ Low Gain -12dB – 0dB – +12dB 52 76
13 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
14 EQ High Gain -12dB – 0dB – +12dB 52 76
15 Mic L-R Angle 0deg – 180deg 0 60
16 Speed Control Slow, Fast 0 1
ROTARY SPEAKER2
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Table#8
2 LFO Depth 0 – 127 0 127
3
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14
15
16
AUTO PAN1
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Table#8
2 L/R Depth 0 – 127 0 127
3 F/R Depth 0 – 127 0 127
4 PAN Direction L<->R, L->R, L<-R, Lturn,
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14
15
16
TREMOLO
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Table#8
2 AM Depth 0 – 127 0 127
3 PM Depth 0 – 127 0 127
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14 LFO Phase Difference -180deg – 0deg –
15 Input Mode Mono, Stereo 0 1
16
Rturn, L/R
+180deg(resolution=3deg.)
05
4124
PSR-A3000 Data List
56
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
2WAY ROTARY SPEAKER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Rotor Speed 0.00Hz – 39.7Hz 0 127 Ta bl e # 8
2 Drive Low 0 – 127 0 127
3 Drive High 0 – 127 0 127
4 Low/High Balance L63>H – L=H – L<H63 1 127
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10
11 Crossover Frequency 100Hz – 10.0kHz 14 54 Ta bl e # 3
12 Mic L-R Angle 0deg –
13
14
15
16
DIST ROTARY SPEAKER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Tab le # 8
2 LFO Depth 0 – 127 0 127
3
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14 Drive 0 – 127 0 127
15 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Ta bl e # 3
16 Output Level 0 – 127 0 127
180deg(resolution=3deg.)
060
AMP 2WAY ROTARY SP
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Rotor Speed 0.00Hz – 39.7Hz 0 127 Table#8
2 Drive Low 0 – 127 0 127
3 Drive High 0 – 127 0 127
4 Low/High Balance L63>H – L=H – L<H63 1 127
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10
11 Crossover Frequency 100Hz – 10.0kHz 14 54 Table#3
12 Mic L-R Angle 0deg – 180deg 0 60
13 AMP Type Off, Stack, Combo, Tube 0 3
14 Drive 0 – 127 0 127
15 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Table#3
16 Output Level 0 – 127 0 127
VIBE VIBRATE
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Rotor Speed 0.00Hz – 39.7Hz 0 127 Table#8
2 AM Depth 0 – 127 0 127
3 PM Depth 0 – 127 0 127
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14 LFO Phase Difference -180deg – 0deg –
15 Input Mode Mono, Stereo 0 1
16 Rotor SW Off, On 0 1
+180deg(resolution=3deg.)
4124
DIST 2WAY ROTARY SP
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Rotor Speed 0.00Hz – 39.7Hz 0 127 Ta bl e # 8
2 Drive Low 0 – 127 0 127
3 Drive High 0 – 127 0 127
4 Low/High Balance L63>H – L=H – L<H63 1 127
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10
11 Crossover Frequency 100Hz – 10.0kHz 14 54 Ta bl e # 3
12 Mic L-R Angle 0deg – 180deg 0 60
13
14 Drive 0 – 127 0 127
15 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Ta bl e # 3
16 Output Level 0 – 127 0 127
AMP ROTARY SPEAKER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Tab le # 8
2 LFO Depth 0 – 127 0 127
3 AMP Type Off, Stack, Combo, Tube 0 3
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14 Drive 0 – 127 0 127
15 LPF Cutoff 1.0kHz – 18kHz, Thru 34 60 Ta bl e # 3
16 Output Level 0 – 127 0 127
TEMPO TREMOLO
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 16th – 4thx16 5 29 Table#5
2 AM Depth 0 – 127 0 127
3 PM Depth 0 – 127 0 127
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14 LFO Phase Difference -180deg – 0deg –
15 Input Mode Mono, Stereo 0 1
16
AUTO PAN2
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 127 Table#8
2 L/R Depth 0 – 127 0 127
3 F/R Depth 0 – 127 0 127
4 PAN Direction L<->R, L->R, L<-R, Lturn,
5 LFO Wave 0 – 28 0 28
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Table#3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14
15 Input Mode Mono, Stereo 0 1
16
+180deg(resolution=3deg.)
Rturn, L/R
4124
05
PSR-A3000 Data List
57
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
TEMPO AUTO PAN1
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 16th – 4thx16 5 29 Ta b l e# 5
2 L/R Depth 0 – 127 0 127
3 F/R Depth 0 – 127 0 127
4 PAN Direction L<->R, L->R, L<-R, Lturn,
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Ta b le # 3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14
15
16
TEMPO AUTO PAN2
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 LFO Frequency 16th – 4thx16 5 29 Ta b l e# 5
2 L/R Depth 0 – 127 0 127
3 F/R Depth 0 – 127 0 127
4 PAN Direction L<->R, L->R, L<-R, Lturn,
5 LFO Wave 0 – 28 0 28
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10
11 EQ Mid Frequency 100Hz – 10.0kHz 14 54 Ta b le # 3
12 EQ Mid Gain -12dB – 0dB – +12dB 52 76
13 EQ Mid Width 0.1 – 12.0 1 120
14
15 Input Mode Mono, Stereo 0 1
16
Rturn, L/R
Rturn, L/R
05
05
EQ/ENHANCER
3BAND EQ
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 EQ Low Gain -12dB – 0dB – +12dB 52 76
2 EQ Mid Frequency 100Hz – 16.0kHz 14 58 Ta b le # 3
3 EQ Mid Gain -12dB – 0dB – +12dB 52 76
4 EQ Mid Width 0.1 – 12.0 1 120
5 EQ High Gain -12dB – 0dB – +12dB 52 76
6 EQ Low Frequency 50Hz – 2.0kHz 8 40 Ta b le # 3
7 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
8
9
10
11
12
13
14
15 Input Mode Mono, Stereo 0 1
16
2BAND EQ
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b le # 3
2 EQ Low Gain -12dB – 0dB – +12dB 52 76
3 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
4 EQ High Gain -12dB – 0dB – +12dB 52 76
5
6
7
8
9
10
11
12
13
14
15
16
HARMONIC ENHANCER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 HPF Cutoff 500Hz – 16.0kHz 28 58
2 Drive 0 – 127 0 127
3 Mix Level 0 – 127 0 127
4
5
6
7
8
9
10
11
12
13
14
15
16
MISC
VOICE CANCELAR
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1
2
3
4
5
6
7
8
9
10
11 Low Adjust 0 – 26 0 26
12 High Adjust 0 – 26 0 26
13
14
15
16
AMBIENCE
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Delay Time 0.0ms – 50ms 0 127 Table#9
2 Output Phase Normal, Inverse 0 1
3
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 40 Table#3
7 EQ Low Gain -12dB – 0dB – +12dB 52 76
8 EQ High Frequency 500Hz – 16.0kHz 28 58 Table#3
9 EQ High Gain -12dB – 0dB – +12dB 52 76
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14
15
16
TALKING MODULATION
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 Vowel a, i, u, e, o 0 4
2 Move Speed 1 – 62 1 62
3 Drive 0 – 127 0 127
4 Output Level 0 – 127 0 127
5
6
7
8
9
10
11
12
13
14
15
16
PSR-A3000 Data List
58
Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos
LO FI
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table
1 Sampling Frequency
Control
2 Word Length 1 – 127 1 127
3 Output Gain -6dB – +36dB 0 42
4 LPF Cutoff 63Hz – 18kHz, Thru 10 60 Ta bl e # 3
5 Filter Type Thru, PowerBass, Radio,
6 LPF Resonance 1.0 – 12.0 10 120
7 Bit Assign 0 – 6 0 6
8Emphasis Off, On 0 1
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13
14
15 Input Mode Mono, Stereo 0 1
16
DYNAMIC FILTER
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table
1 Filter Type LPF(12dB), LPF(18dB),
2 Sensitivity 0 – 127 0 127
3 Dyna Level Offset 0 – 127 0 127
4 Resonance -16 – +111 0 127
5 Attack Time 0.3ms – 227ms 0 127
6 Release Time 2.6ms – 2171.4ms 0 127
7 Release Curve 0 – 127 0 127
8 Direction Up, Down 0 1
9 Dyna Threshold Level 0 – 127 0 127
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b l e# 3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
DYNAMIC RING MOD
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table
1 Sensitivity 0 – 127 0 127
2 HPF Cutoff Frequency Thru, 22Hz – 8.0kHz 0 52 Ta b le # 3
3 LPF Cutoff Frequency 1.0kHz – 18kHz, Thru 34 60 Ta b l e# 3
4 Attack Time 0.3ms – 227ms 0 127
5 Release Time 2.6ms – 2171.4ms 0 127
6 Release Curve 0 – 127 0 127
7 Direction Up, Down 0 1
8 Dyna Threshold Level 0 – 127 0 127
9 Dyna Level Offset 0 – 127 0 127
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b l e# 3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
44.1kHz – 345Hz 0 127
Tel, Clean, Low
LPF(24dB), HPF, BPF, BEF
05
05
Table#19
Table#12
Table#13
Table#12
Table#13
Control
Control
Control
ISOLATOR
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1 On/Off SW Off, On 0 1
2 Low Level 0 – 127 0 127
3 Mid Level 0 – 127 0 127
4 High Level 0 – 127 0 127
5 Low Mute Off, On 0 1
6 Mid Mute Off, On 0 1
7 High Mute Off, On 0 1
8
9
10
11
12
13
14
15
16
NO EFFECT
Block : Reverb, Chorus, DSP1(Variation)
No. Parameter Display Min Max Table Control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
THRU
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table Control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
RING MODULATOR
Block : DSP1(Variation), DSP2-4(Insertion)
No. Parameter Display Min Max Table
1 OSC Frequency Coarse 0.7Hz – 5002.6kHz 0 127
2 OSC Frequency Fine 0 – 127 0 127
3 LFO Wave Triangle, Sine 0 1
4 LFO Depth 0 – 127 0 127
5 LFO Frequency 0.00Hz – 39.7Hz 0 127 Tab le # 8
6 HPF Cutoff Frequency Thru, 22Hz – 8.0kHz 0 52 Ta b le # 3
7 LPF Cutoff Frequency 1.0kHz – 18kHz, Thru 34 60 Ta b l e# 3
8
9
10 Dry/Wet D63>W – D=W – D<W63 1 127
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 40 Ta b l e# 3
14 EQ Low Gain -12dB – 0dB – +12dB 52 76
15 EQ High Frequency 500Hz – 16.0kHz 28 58 Ta b le # 3
16 EQ High Gain -12dB – 0dB – +12dB 52 76
Table#20
Control
PSR-A3000 Data List
59
Effect Data Assign Table / Effektdaten-Zuordnungstabelle / Tableau d’assignation des données d’effets / Tabla de asignación de datos para efectos
Tab le# 1
Reverb Time [s]
Data Value Data Value Data Value
0 0.3 32 3.5 64 17.0
1 0.4 33 3.6 65 18.0
2 0.5 34 3.7 66 19.0
3 0.6 35 3.8 67 20.0
4 0.7 36 3.9 68 25.0
5 0.8 37 4.0 69 30.0
6 0.9 38 4.1
7 1.0 39 4.2
8 1.1 40 4.3
9 1.2 41 4.4
10 1.3 42 4.5
11 1.4 43 4.6
12 1.5 44 4.7
13 1.6 45 4.8
14 1.7 46 4.9
15 1.8 47 5.0
16 1.9 48 5.5
17 2.0 49 6.0
18 2.1 50 6.5
19 2.2 51 7.0
20 2.3 52 7.5
21 2.4 53 8.0
22 2.5 54 8.5
23 2.6 55 9.0
24 2.7 56 9.5
25 2.8 57 10.0
26 2.9 58 11.0
27 3.0 59 12.0
28 3.1 60 13.0
29 3.2 61 14.0
30 3.3 62 15.0
31 3.4 63 16.0
Tab le# 2
Delay Time (0.1 – 200.0 [ms])
Data Value Data Value Data Value Data Value
0 0.1 32 50.5 64 100.8 96 151.2
1 1.7 33 52.0 65 102.4 97 152.8
2 3.2 34 53.6 66 104.0 98 154.4
3 4.8 35 55.2 67 105.6 99 155.9
4 6.4 36 56.8 68 107.1 100 157.5
5 8.0 37 58.3 69 108.7 101 159.1
6 9.5 38 59.9 70 110.3 102 160.6
7 11.1 39 61.5 71 111.9 103 162.2
8 12.7 40 63.1 72 113.4 104 163.8
9 14.3 41 64.6 73 115.0 105 165.4
10 15.8 42 66.2 74 116.6 106 166.9
11 17.4 43 67.8 75 118.2 107 168.5
12 19.0 44 69.4 76 119.7 108 170.1
13 20.6 45 70.9 77 121.3 109 171.7
14 22.1 46 72.5 78 122.9 110 173.2
15 23.7 47 74.1 79 124.4 111 174.8
16 25.3 48 75.7 80 126.0 112 176.4
17 26.9 49 77.2 81 127.6 113 178.0
18 28.4 50 78.8 82 129.2 114 179.5
19 30.0 51 80.4 83 130.7 115 181.1
20 31.6 52 81.9 84 132.3 116 182.7
21 33.2 53 83.5 85 133.9 117 184.3
22 34.7 54 85.1 86 135.5 118 185.8
23 36.3 55 86.7 87 137.0 119 187.4
24 37.9 56 88.2 88 138.6 120 189.0
25 39.5 57 89.8 89 140.2 121 190.6
26 41.0 58 91.4 90 141.8 122 192.1
27 42.6 59 93.0 91 143.3 123 193.7
28 44.2 60 94.5 92 144.9 124 195.3
29 45.7 61 96.1 93 146.5 125 196.9
30 47.3 62 97.7 94 148.1 126 198.4
31 48.9 63 99.3 95 149.6 127 200.0
Tab le# 3
EQ Frequency [Hz]
Data Value Data Value
0 THRU(20) 32 800
1 22 33 900
225341.0k
328351.1k
432361.2k
536371.4k
640381.6k
745391.8k
850402.0k
956412.2k
10 63 42 2.5k
11 70 43 2.8k
12 80 44 3.2k
13 90 45 3.6k
14 100 46 4.0k
15 110 47 4.5k
16 125 48 5.0k
17 140 49 5.6k
18 160 50 6.3k
19 180 51 7.0k
20 200 52 8.0k
21 225 53 9.0k
22 250 54 10.0k
23 280 55 11.0k
24 315 56 12.0k
25 355 57 14.0k
26 400 58 16.0k
27 450 59 18.0k
28 500 60 THRU(20.0k)
29 560
30 630
31 700
Table#4
Reverb Width; Depth; Height [m]
Data Value Data Value Data Value Data Value
0 0.5 32 8.8 64 17.6 96 27.5
1 0.8 33 9.1 65 17.9 97 27.8
2 1.0 34 9.4 66 18.2 98 28.1
3 1.3 35 9.6 67 18.5 99 28.5
4 1.5 36 9.9 68 18.8 100 28.8
5 1.8 37 10.2 69 19.1 101 29.2
6 2.0 38 10.4 70 19.4 102 29.5
7 2.3 39 10.7 71 19.7 103 29.9
8 2.6 40 11.0 72 20.0 104 30.2
9 2.8 41 11.2 73 20.2
10 3.1 42 11.5 74 20.5
11 3.3 43 11.8 75 20.8
12 3.6 44 12.1 76 21.1
13 3.9 45 12.3 77 21.4
14 4.1 46 12.6 78 21.7
15 4.4 47 12.9 79 22.0
16 4.6 48 13.1 80 22.4
17 4.9 49 13.4 81 22.7
18 5.2 50 13.7 82 23.0
19 5.4 51 14.0 83 23.3
20 5.7 52 14.2 84 23.6
21 5.9 53 14.5 85 23.9
22 6.2 54 14.8 86 24.2
23 6.5 55 15.1 87 24.5
24 6.7 56 15.4 88 24.9
25 7.0 57 15.6 89 25.2
26 7.2 58 15.9 90 25.5
27 7.5 59 16.2 91 25.8
28 7.8 60 16.5 92 26.1
29 8.0 61 16.8 93 26.5
30 8.3 62 17.1 94 26.8
31 8.6 63 17.3 95 27.1
Table#5
Tem po
Data Value Data Value Data Value
0 32nd/3 32 4thX19 64 4thX51
1 64th. 33 4thX20 65 4thX52
2 32nd 34 4thX21 66 4thX53
3 16th/3 35 4thX22 67 4thX54
4 32nd. 36 4thX23 68 4thX55
5 16th374thX24694thX56
6 8th/3 38 4thX25 70 4thX57
7 16th. 39 4thX26 71 4thX58
8 8th 40 4thX27 72 4thX59
9 4th/3 41 4thX28 73 4thX60
10 8th. 42 4thX29 74 4thX61
11 4th434thX30754thX62
12 2nd/3 44 4thX31 76 4thX63
13 4th. 45 4thX32 77 4thX64
14 2nd 46 4thX33
15 Whole/3 47 4thX3 4
16 2nd. 48 4thX35
17 4thX4 49 4thX36
18 4thX5 50 4thX37
19 4thX6 51 4thX38
20 4thX7 52 4thX39
21 4thX8 53 4thX40
22 4thX9 54 4thX41
23 4thX10 55 4thX42
24 4thX11 56 4thX43
25 4thX12 57 4thX44
26 4thX13 58 4thX45
27 4thX14 59 4thX46
28 4thX15 60 4thX47
29 4thX16 61 4thX48
30 4thX17 62 4thX49
31 4thX18 63 4thX50
Table#6
Delay Time (0.1 – 400.0 [ms])
Data Value Data Value Data Value Data Value
0 0.1 32 100.9 64 201.6 96 302.4
1 3.2 33 104.0 65 204.8 97 305.5
2 6.4 34 107.2 66 207.9 98 308.7
3 9.5 35 110.3 67 211.1 99 311.8
4 12.7 36 113.5 68 214.2 100 315.0
5 15.8 37 116.6 69 217.4 101 318.1
6 19.0 38 119.8 70 220.5 102 321.3
7 22.1 39 122.9 71 223.7 103 324.4
8 25.3 40 126.1 72 226.8 104 327.6
9 28.4 41 129.2 73 230.0 105 330.7
10 31.6 42 132.4 74 233.1 106 333.9
11 34.7 43 135.5 75 236.3 107 337.0
12 37.9 44 138.6 76 239.4 108 340.2
13 41.0 45 141.8 77 242.6 109 343.3
14 44.2 46 144.9 78 245.7 110 346.5
15 47.3 47 148.1 79 248.9 111 349.6
16 50.5 48 151.2 80 252.0 112 352.8
17 53.6 49 154.4 81 255.2 113 355.9
18 56.8 50 157.5 82 258.3 114 359.1
19 59.9 51 160.7 83 261.5 115 362.2
20 63.1 52 163.8 84 264.6 116 365.4
21 66.2 53 167.0 85 267.7 117 368.5
22 69.4 54 170.1 86 270.9 118 371.7
23 72.5 55 173.3 87 274.0 119 374.8
24 75.7 56 176.4 88 277.2 120 378.0
25 78.8 57 179.6 89 280.3 121 381.1
26 82.0 58 182.7 90 283.5 122 384.3
27 85.1 59 185.9 91 286.6 123 387.4
28 88.3 60 189.0 92 289.8 124 390.6
29 91.4 61 192.2 93 292.9 125 393.7
30 94.6 62 195.3 94 296.1 126 396.9
31 97.7 63 198.5 95 299.2 127 400.0
Tab le# 7
Room Size
Data Value Data Value Data Value Data Value
0 0.1 32 5.1 64 10.1 96 15.1
1 0.3 33 5.3 65 10.3 97 15.3
2 0.4 34 5.4 66 10.4 98 15.5
3 0.6 35 5.6 67 10.6 99 15.6
4 0.7 36 5.7 68 10.8 100 15.8
5 0.9 37 5.9 69 10.9 101 15.9
6 1.0 38 6.1 70 11.1 102 16.1
7 1.2 39 6.2 71 11.2 103 16.2
8 1.4 40 6.4 72 11.4 104 16.4
9 1.5 41 6.5 73 11.5 105 16.6
10 1.7 42 6.7 74 11.7 106 16.7
11 1.8 43 6.8 75 11.9 107 16.9
12 2.0 44 7.0 76 12.0 108 17.0
13 2.1 45 7.2 77 12.2 109 17.2
14 2.3 46 7.3 78 12.3 110 17.3
15 2.5 47 7.5 79 12.5 111 17.5
16 2.6 48 7.6 80 12.6 112 17.6
17 2.8 49 7.8 81 12.8 113 17.8
18 2.9 50 7.9 82 12.9 114 18.0
19 3.1 51 8.1 83 13.1 115 18.1
20 3.2 52 8.2 84 13.3 116 18.3
21 3.4 53 8.4 85 13.4 117 18.4
22 3.5 54 8.6 86 13.6 118 18.6
23 3.7 55 8.7 87 13.7 119 18.7
24 3.9 56 8.9 88 13.9 120 18.9
25 4.0 57 9.0 89 14.0 121 19.1
26 4.2 58 9.2 90 14.2 122 19.2
27 4.3 59 9.3 91 14.4 123 19.4
28 4.5 60 9.5 92 14.5 124 19.5
29 4.6 61 9.7 93 14.7 125 19.7
30 4.8 62 9.8 94 14.8 126 19.8
31 5.0 63 10.0 95 15.0 127 20.0
Tab le# 8
LFO Frequency [Hz]
Data Value Data Value Data Value Data Value
00.00321.35 642.69968.41
10.04331.39 652.78978.75
20.08341.43 662.86989.08
30.13351.47 672.94999.42
40.17361.51 683.031009.76
50.21371.56 693.1110110.1
60.25381.60 703.2010210.8
70.29391.64 713.2810311.4
80.34401.68 723.3710412.1
90.38411.72 733.4510512.8
10 0.42 42 1.77 74 3.53 106 13.5
11 0.46 43 1.81 75 3.62 107 14.1
12 0.51 44 1.85 76 3.70 108 14.8
13 0.55 45 1.89 77 3.87 109 15.5
14 0.59 46 1.94 78 4.04 110 16.2
15 0.63 47 1.98 79 4.21 111 16.8
16 0.67 48 2.02 80 4.37 112 17.5
17 0.72 49 2.06 81 4.54 113 18.2
18 0.76 50 2.10 82 4.71 114 19.5
19 0.80 51 2.15 83 4.88 115 20.9
20 0.84 52 2.19 84 5.05 116 22.2
21 0.88 53 2.23 85 5.22 117 23.6
22 0.93 54 2.27 86 5.38 118 24.9
23 0.97 55 2.31 87 5.55 119 26.2
24 1.01 56 2.36 88 5.72 120 27.6
25 1.05 57 2.40 89 6.06 121 28.9
26 1.09 58 2.44 90 6.39 122 30.3
27 1.14 59 2.48 91 6.73 123 31.6
28 1.18 60 2.52 92 7.07 124 33.0
29 1.22 61 2.57 93 7.40 125 34.3
30 1.26 62 2.61 94 7.74 126 37.0
31 1.30 63 2.65 95 8.08 127 39.7
Tab le# 9
Modulation Delay Offset [ms]
Data Value Data Value Data Value Data Value
0 0.0 32 3.2 64 6.4 96 9.6
1 0.1 33 3.3 65 6.5 97 9.7
2 0.2 34 3.4 66 6.6 98 9.8
3 0.3 35 3.5 67 6.7 99 9.9
4 0.4 36 3.6 68 6.8 100 10.0
5 0.5 37 3.7 69 6.9 101 11.1
6 0.6 38 3.8 70 7.0 102 12.2
7 0.7 39 3.9 71 7.1 103 13.3
8 0.8 40 4.0 72 7.2 104 14.4
9 0.9 41 4.1 73 7.3 105 15.5
10 1.0 42 4.2 74 7.4 106 17.1
11 1.1 43 4.3 75 7.5 107 18.6
12 1.2 44 4.4 76 7.6 108 20.2
13 1.3 45 4.5 77 7.7 109 21.8
14 1.4 46 4.6 78 7.8 110 23.3
15 1.5 47 4.7 79 7.9 111 24.9
16 1.6 48 4.8 80 8.0 112 26.5
17 1.7 49 4.9 81 8.1 113 28.0
18 1.8 50 5.0 82 8.2 114 29.6
19 1.9 51 5.1 83 8.3 115 31.2
20 2.0 52 5.2 84 8.4 116 32.8
21 2.1 53 5.3 85 8.5 117 34.3
22 2.2 54 5.4 86 8.6 118 35.9
23 2.3 55 5.5 87 8.7 119 37.5
24 2.4 56 5.6 88 8.8 120 39.0
25 2.5 57 5.7 89 8.9 121 40.6
26 2.6 58 5.8 90 9.0 122 42.2
27 2.7 59 5.9 91 9.1 123 43.7
28 2.8 60 6.0 92 9.2 124 45.3
29 2.9 61 6.1 93 9.3 125 46.9
30 3.0 62 6.2 94 9.4 126 48.4
31 3.1 63 6.3 95 9.5 127 50.0
Table#10
V-F lan ger Delay Offset [ms]
Data Value Data Value Data Value Data Value
0 0.09 37 1.24 74 7.74 111 23.91
1 0.11 38 1.30 75 8.13 112 24.35
2 0.13 39 1.37 76 8.54 113 24.79
3 0.15 40 1.44 77 8.97 114 25.23
4 0.18 41 1.51 78 9.41 115 25.66
5 0.20 42 1.59 79 9.85 116 26.10
6 0.22 43 1.67 80 10.29 117 26.54
7 0.24 44 1.76 81 10.73 118 26.98
8 0.27 45 1.84 82 11.17 119 27.42
9 0.29 46 1.94 83 11.61 120 27.86
10 0.31 47 2.04 84 12.05 121 28.30
11 0.34 48 2.14 85 12.49 122 28.74
12 0.36 49 2.25 86 12.93 123 29.18
13 0.38 50 2.36 87 13.37 124 29.62
14 0.40 51 2.48 88 13.81 125 30.06
15 0.42 52 2.61 89 14.24 126 30.50
16 0.43 53 2.74 90 14.68 127 30.94
17 0.46 54 2.88 91 15.12 128 31.38
18 0.48 55 3.03 92 15.56 129 31.82
19 0.51 56 3.18 93 16.00 130 32.25
20 0.53 57 3.34 94 16.44 131 32.69
21 0.56 58 3.51 95 16.88 132 33.13
22 0.59 59 3.69 96 17.32 133 33.57
23 0.62 60 3.87 97 17.76 134 34.01
24 0.65 61 4.07 98 18.20 135 34.45
25 0.68 62 4.28 99 18.64 136 34.89
26 0.72 63 4.49 100 19.08 137 35.33
27 0.76 64 4.72 101 19.52 138 35.77
28 0.79 65 4.96 102 19.96 139 36.21
29 0.83 66 5.21 103 20.40
30 0.88 67 5.47 104 20.83
31 0.92 68 5.75 105 21.27
32 0.97 69 6.04 106 21.71
33 1.02 70 6.35 107 22.15
34 1.07 71 6.67 108 22.59
35 1.12 72 7.01 109 23.03
36 1.18 73 7.37 110 23.47
Table#11
V-F lan ger Modulation Phase [deg]
Data Value
0 - 180
1 - 158
2 - 135
3 - 113
4-90
5-68
6-45
7-23
80
923
10 45
11 68
12 90
13 113
14 135
15 158
16 180
Table#12
Dyna Attack Time [ms]
Data Value Data Value Data Value Data Value
0 0.3 32 54.0 64 112 96 170
1 0.9 33 56.0 65 114 97 172
2 1.8 34 58.0 66 116 98 174
3 2.7 35 60.0 67 118 99 176
4 3.6 36 61.0 68 120 100 178
5 5.4 37 63.0 69 121 101 180
6 7.2 38 65.0 70 123 102 181
7 9.0 39 67.0 71 125 103 183
8 10.0 40 69.0 72 127 104 185
9 12.0 41 70.0 73 129 105 187
10 14.0 42 72.0 74 130 106 189
11 16.0 43 74.0 75 132 107 190
12 18.0 44 76.0 76 134 108 192
13 20.0 45 78.0 77 136 109 194
14 21.0 46 80.0 78 138 110 196
15 23.0 47 81.0 79 140 111 198
16 25.0 48 83.0 80 141 112 200
17 27.0 49 85.0 81 143 113 201
18 29.0 50 87.0 82 145 114 203
19 30.0 51 89.0 83 147 115 205
20 32.0 52 90.0 84 149 116 207
21 34.0 53 92.0 85 150 117 209
22 36.0 54 94.0 86 152 118 210
23 38.0 55 96.0 87 154 119 212
24 40.0 56 98.0 88 156 120 214
25 41.0 57 100.0 89 158 121 216
26 43.0 58 101.0 90 160 122 218
27 45.0 59 103.0 91 161 123 220
28 47.0 60 105.0 92 163 124 221
29 49.0 61 107.0 93 165 125 223
30 50.0 62 109.0 94 167 126 225
31 52.0 63 110.0 95 169 127 227
PSR-A3000 Data List
60
Effect Data Assign Table / Effektdaten-Zuordnungstabelle / Tableau d’assignation des données d’effets / Tabla de asignación de datos para efectos
Tab le# 13
Dyna Release Time [ms]
Data Value Data Value Data Value Data Value
0 2.6 32 86.8 64 369.1 96 1064.0
1 3.0 33 91.2 65 390.8 97 1085.7
2 3.4 34 95.5 66 412.5 98 1107.4
3 3.9 35 99.8 67 434.2 99 1129.1
4 4.3 36 104.2 68 456.0 100 1150.8
5 4.7 37 108.5 69 477.7 101 1172.5
6 5.2 38 112.9 70 499.4 102 1194.3
7 5.6 39 117.2 71 521.1 103 1216.0
8 6.0 40 121.6 72 542.8 104 1237.7
9 6.5 41 125.9 73 564.5 105 1259.4
10 6.9 42 130.2 74 586.2 106 1281.1
11 7.3 43 134.6 75 608.0 107 1302.8
12 7.8 44 138.9 76 629.7 108 1346.3
13 8.2 45 143.3 77 651.4 109 1389.7
14 8.6 46 147.6 78 673.1 110 1433.1
15 13.0 47 152.0 79 694.8 111 1476.6
16 17.3 48 156.3 80 716.5 112 1520.0
17 21.7 49 160.6 81 738.3 113 1563.4
18 26.0 50 165.0 82 760.0 114 1606.8
19 30.4 51 169.3 83 781.7 115 1650.3
20 34.7 52 173.7 84 803.4 116 1693.7
21 39.0 53 178.0 85 825.1 117 1737.1
22 43.4 54 182.4 86 846.8 118 1780.6
23 47.7 55 186.7 87 868.5 119 1824.0
24 52.1 56 195.4 88 890.3 120 1867.4
25 56.4 57 217.1 89 912.0 121 1910.8
26 60.8 58 238.8 90 933.7 122 1954.3
27 65.1 59 260.5 91 955.4 123 1997.7
28 69.4 60 282.2 92 977.1 124 2041.1
29 73.8 61 304.0 93 998.8 125 2084.6
30 78.1 62 325.7 94 1020.5 126 2128.0
31 82.5 63 347.4 95 1042.3 127 2171.4
Tab le# 14
Compressor Attack Time [ms]
Data Value
01
12
23
34
45
56
67
78
89
910
10 12
11 14
12 16
13 18
14 20
15 23
16 26
17 30
18 35
19 40
Tab le# 15
Compressor Release Time [ms]
Data Value
010
115
225
335
445
555
665
775
885
9100
10 115
11 140
12 170
13 230
14 340
15 680
Tab le# 16
Compressor Ratio
Data Value
01.0
11.5
22.0
33.0
45.0
57.0
6 10.0
7 20.0
Tab le# 17
EgMultiFx LFO Freq [Hz]
Data Value Data Value Data Value Data Value
0 0.100 32 0.318 64 1.009 96 3.238
1 0.103 33 0.329 65 1.051 97 3.365
2 0.105 34 0.342 66 1.093 98 3.491
3 0.110 35 0.352 67 1.125 99 3.617
4 0.113 36 0.368 68 1.167 100 3.743
5 0.118 37 0.379 69 1.22 101 3.869
6 0.124 38 0.394 70 1.262 102 4.037
7 0.129 39 0.410 71 1.304 103 4.164
8 0.131 40 0.426 72 1.346 104 4.332
9 0.137 41 0.442 73 1.409 105 4.500
10 0.142 42 0.457 74 1.451 106 4.668
11 0.147 43 0.473 75 1.514 107 4.837
12 0.152 44 0.489 76 1.556 108 5.005
13 0.158 45 0.51 77 1.619 109 5.173
14 0.166 46 0.526 78 1.682 110 5.383
15 0.171 47 0.547 79 1.745 111 5.552
16 0.176 48 0.568 80 1.808 112 5.804
17 0.184 49 0.589 81 1.872 113 5.972
18 0.192 50 0.61 82 1.956 114 6.224
19 0.197 51 0.631 83 2.019 115 6.393
20 0.205 52 0.657 84 2.103 116 6.645
21 0.213 53 0.673 85 2.166 117 6.897
22 0.221 54 0.704 86 2.25 118 7.15
23 0.229 55 0.725 87 2.334 119 7.402
24 0.237 56 0.757 88 2.418 120 7.738
25 0.247 57 0.789 89 2.502 121 7.991
26 0.255 58 0.81 90 2.608 122 8.327
27 0.265 59 0.841 91 2.692 123 8.58
28 0.276 60 0.873 92 2.776 124 8.916
29 0.284 61 0.904 93 2.902 125 9.253
30 0.294 62 0.946 94 2.986 126 9.589
31 0.308 63 0.978 95 3.112 127 9.925
Tab le# 18
Wah Release Time [ms]
Data Value
010
115
225
335
445
555
665
775
885
9100
10 115
11 140
12 170
13 230
14 340
15 680
Tab le# 19
LO-FI Sampling Frequency Control [Hz]
Data Value Data Value Data Value Data Value
0 44.1k 32 1.34k 64 678.0 96 455.0
1 22.1k 33 1.30k 65 668.0 97 450.0
2 14.7k 34 1.26k 66 658.0 98 445.0
3 11.0k 35 1.23k 67 649.0 99 441.0
4 8.8k 36 1.19k 68 639.0 100 437.0
5 7.4k 37 1.16k 69 630.0 101 432.0
6 6.3k 38 1.13k 70 621.0 102 428.0
7 5.5k 39 1.10k 71 613.0 103 424.0
8 4.9k 40 1.08k 72 604.0 104 420.0
9 4.4k 41 1.05k 73 596.0
10 4.0k 42 1.03k 74 588.0
11 3.7k 43 1.00k 75 580.0
12 3.4k 44 980.0 76 573.0
13 3.2k 45 959.0 77 565.0
14 2.9k 46 938.0 78 558.0
15 2.8k 47 919.0 79 551.0
16 2.6k 48 900.0 80 544.0
17 2.5k 49 882.0 81 538.0
18 2.3k 50 865.0 82 531.0
19 2.2k 51 848.0 83 525.0
20 2.1k 52 832.0 84 519.0
21 2.0k 53 817.0 85 513.0
22 1.92k 54 802.0 86 507.0
23 1.84k 55 788.0 87 501.0
24 1.76k 56 774.0 88 496.0
25 1.70k 57 760.0 89 490.0
26 1.63k 58 747.0 90 485.0
27 1.58k 59 735.0 91 479.0
28 1.52k 60 723.0 92 474.0
29 1.47k 61 711.0 93 469.0
30 1.42k 62 700.0 94 464.0
31 1.38k 63 689.0 95 459.0
Table#20
Ring Mod OSC Freq Course [Hz]
Data Value Data Value Data Value Data Value
0 0.7 32 25.6 64 151.4 96 895.0
1 1.3 33 26.9 65 160.2 97 946.1
2 2.0 34 28.9 66 169.6 98 1000.7
3 2.7 35 30.3 67 179.0 99 1057.2
4 3.4 36 32.3 68 189.1 100 1117.7
5 4.0 37 33.6 69 199.9 101 1181.7
6 4.7 38 35.7 70 211.3 102 1249.0
7 5.4 39 37.7 71 223.4 103 1320.3
8 6.1 40 39.7 72 236.2 104 1395.7
9 6.7 41 42.4 73 249.7 105 1475.1
10 7.4 42 44.4 74 263.8 106 1559.2
11 8.1 43 47.1 75 279.3 107 1648.7
12 8.7 44 49.8 76 294.7 108 1742.9
13 9.4 45 52.5 77 311.6 109 1841.8
14 10.1 46 55.9 78 329.7 110 1947.5
15 10.8 47 59.2 79 348.6 111 2058.5
16 11.4 48 62.6 80 368.1 112 2175.6
17 12.1 49 65.9 81 389.6 113 2300.1
18 12.8 50 70.0 82 411.8 114 2431.3
19 13.5 51 73.3 83 435.4 115 2569.9
20 14.1 52 78.1 84 459.6 116 2716.6
21 14.8 53 82.1 85 485.9 117 2871.4
22 15.5 54 86.8 86 514.1 118 3035.6
23 16.2 55 92.2 87 543.1 119 3208.5
24 16.8 56 96.9 88 574.0 120 3391.6
25 17.5 57 103.0 89 607.0 121 3585.4
26 18.2 58 108.3 90 642.0 122 3790.0
27 19.5 59 115.1 91 678.3 123 4006.6
28 20.9 60 121.1 92 717.3 124 4234.8
29 21.5 61 128.5 93 757.7 125 4477.0
30 22.9 62 135.9 94 801.5 126 4732.1
31 24.2 63 143.3 95 847.2 127 5002.6
PSR-A3000 Data List
61
Parameter Chart / Parametertabelle / Tableau des paramètres / Gráfico de parámetros
System
Song Style
Registration
Parameter
VoiceSet
Setup
MIDI Setup
User Effect
Music Finder
Main
Song File XXXXX - X - XXXO SONG X -
Style File X X X O X - X - X X X O STYLE X -
Multi Pad File X X X X X - O KEYBOARD VOICE X O X O MULTI PAD X -
Part On/Off(Right1) X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Part On/Off(Right2) X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Part On/Off(Left) X X X X X - O KEYBOARD VOICE X O X O STYLE X -
Audio Player File X X X X X - X - X X X O AUDIO X
Song
Track1,2 On/Off X X X X X - O GUIDE SETTING X X X O SONG X -
Extra Tracks On/Off X X X X X - X - X X X O SONG X -
Sync. Start X X X X X - X - X X X O SONG X -
Channel On/Off X X X X X - X - X X X O SONG X -
Function Menu>Song Setting
Guide/Channel
Guide Mode O X X X X - O GUIDE SETTING X X X X - X -
Track1 Channel O X X X X - O - X X X X - X -
Track2 Channel O X X X X - O - X X X X - X -
Auto Ch Set OXXXX - X - XXXX - X -
Others
Repeat Mode O X X X X - X - X X X X - X -
Fast Forward Type O X X X X - X - X X X X - X -
Lyrics Language O X X X X - O LYRICS SETTING X X X X - X -
Quick Start OXXXX - X - XXXX - X -
Tem po
Master Tempo X X X X X - O TEMPO O X X O TEMPO X -
Creator>Song Creator
Setup
Setup Select O X X X X - X - X X X X - X -
Channel>Chord/1-16/SysEx./Lyrics>Filter
Main Filter O X X X X - X - X X X X - X -
Control Change Filter O X X X X - X - X X X X - X -
Style Filter O X X X X - X - X X X X - X -
Lyrics /Text
Background O X X X X - O LYRICS SETTING X X X X - X -
Background(Panel Setting) O X X X X - X - X X X X - X -
Text File XXXXX - X - XXXO TEXT X -
Viewer Mode O X X X X - X - X X X X - X -
Score
Left On/Off O X X X X - O SCORE SETTING X X X X - X -
Right On/Off O X X X X - O SCORE SETTING X X X X - X -
Chord On/Off O X X X X - O SCORE SETTING X X X X - X -
Lyrics On/Off OXXXX - OSCORE SETTINGXXXX - X -
Note Name On/Off O X X X X - O SCORE SETTING X X X X - X -
Color Note On/Off O X X X X - O SCORE SETTING X X X X - X -
Pedal On/Off O X X X X - O SCORE SETTING X X X X - X -
Fingering On/Off O X X X X - O SCORE SETTING X X X X - X -
Size O X X X X - O SCORE SETTING X X X X - X -
Left Ch O X X X X - O SCORE SETTING X X X X - X -
Right Ch O X X X X - O SCORE SETTING X X X X - X -
Key Signature X X X X X - O SCORE SETTING X X X X - X -
Quantize O X X X X - O SCORE SETTING X X X X - X -
Note Name O X X X X - O SCORE SETTING X X X X - X -
Style
Accompaniment On/Off X X X X X - X - X O(On) X O STYLE X -
OTS Link X X X O(On) X - X - X X X X - X -
Auto Fill In O X X X X - X - X X X X - X -
Section X X X X X - X - X X X O STYLE X -
Synchro Start X X X X X - X - X O(On) X O STYLE X -
Synchro Stop X X X X X - X - X X X O STYLE X -
Function Menu>Style Setting
Style Setting
Stop ACMP O X X X X - X - X X X O STYLE X -
Dynamics Control O X X X X - X - X X X X - X -
Synchro Stop Window O X X X X - X - X X X O STYLE X -
Section Set O X X X X - X - X X X X - X -
Tempo Hold O X X X X - X - X X X X - X -
Part On/Off O X X X X - X - X X X X - X -
Function Menu>Split Point/Chord Fingering
Split Point
Chord Detection Area O X X X X - X - X X X O STYLE X
Manual Bass O X X X X - X - X X X O STYLE X
Split Point(Left) O X X X X - X - X X X O STYLE X SPLIT POINT
PSR-A3000 Data List
62
Voice Set Group
Song
Song Setup
Group
Style Data
OTS
Multi Pad
Regist
Freeze Group
Scale Tune
Parameter Lock
Note
Group
Parameter Chart / Parametertabelle / Tableau des paramètres / Gráfico de parámetros
System
Song Style
Registration
Parameter
VoiceSet
Setup
MIDI Setup
User Effect
Music Finder
Split Point(Style) O X X X X - O GUIDE SETTING X X X O STYLE X SPLIT POINT
Chord Fingering
Fingering Type O X X X X - X - X X X O STYLE X FINGERING
Creator>Style Creator
Basic
Pattern Length X X X X X - X - O X X X - X -
Tempo XXXXX - X - OXXX - X -
Beat XXXXX - X - OXXX - X -
Param eter
Play Root XXXXX - X - OXXX - X -
Play Chord X X X X X - X - O X X X - X -
NTR XXXXX - X - OXXX - X -
NTT XXX XX - X - OXXX - X -
NTT BASS XXXXX - X - OXXX - X -
High Key XXXXX - X - OXXX - X -
Note Limit Low X X X X X - X - O X X X - X -
Note Limit High X X X X X - X - O X X X - X -
RTR XXXXX - X - OXXX - X -
Edit>Filter
Main Filter O X X X X - X - X X X X - X -
Control Change Filter O X X X X - X - X X X X - X -
Music Finder
Sort By OXXXX - X - XXXX - X -
Sort Order O X X X X - X - X X X X - X -
Style Tempo OXXXX - X - XXXX - X -
Information On/Off O X X X X - X - X X X X - X -
Search1/2 Display
Search Result X X X O X - X - X X X X - X -
Record(=Property Setting) X X X O X - X - X X X X - X -
Multi Pad
Sync Start XXXXX - X - XXXOMULTI PADX -
Creator>Multi Pad Creator
Edit>Filter
Main Filter O X X X X - X - X X X X - X -
Control Change Filter O X X X X - X - X X X X - X -
Voi c e
Left Hold X X X X X - O KEYBOARD VOICE X O X O STYLE X -
Voice Effect(On Panel)
Touch Response X X X X X - X - X X X O VOICE X -
Harmony/Arpeggio On/Off X X X X X - O KEYBOARD VOICE X O X O HARMONY/
Poly/Mono(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Poly/Mono(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Poly/Mono(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Panel Sustain X X X X X - X - X X X O VOICE X -
DSP(Right1) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
DSP(Right2) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
DSP(Left) X X X X O Effect O KEYBOARD VOICE X O X O STYLE X -
Variation(Right1) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
Variation(Right2) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
Variation(Left) X X X X O Effect O KEYBOARD VOICE X O X O STYLE X -
Voice Open/Save>Voice Set
Voice(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Voice(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Voice(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
Common
Volume for Balance(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Volume for Balance(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Volume for Balance(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Touch Sense Depth(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Touch Sense Depth(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Touch Sense Depth(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Touch Sense Offset(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Touch Sense Offset(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Touch Sense Offset(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Part Octave for Right1/Right2 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Part Octave for Left X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Mono Type Right1 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Mono Type Right2 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Mono Type Left X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Controller
Modulation (+) Low Pass Filter Control(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation (+) Low Pass Filter Control(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Voice Set Group
Song
Song Setup
Group
Style Data
OTS
Multi Pad
Regist
ARPEGGIO
Scale Tune
Freeze Group
X-
Parameter Lock
Note
Group
PSR-A3000 Data List
63
Parameter Chart / Parametertabelle / Tableau des paramètres / Gráfico de parámetros
System
Song Style
Registration
Parameter
VoiceSet
Setup
MIDI Setup
User Effect
Music Finder
Modulation (+) Low Pass Filter Control(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Modulation (+) Amplitude Control(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation (+) Amplitude Control(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation (+) Amplitude Control(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Modulation (+) LFO PMOD Depth(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation (+) LFO PMOD Depth(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation (+) LFO PMOD Depth(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Modulation (+) LFO FMOD Depth(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation (+) LFO FMOD Depth(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation (+) LFO FMOD Depth(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Modulation (+) LFO AMOD Depth(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation (+) LFO AMOD Depth(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation (+) LFO AMOD Depth(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Modulation(-) Low Pass Filter Control(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) Low Pass Filter Control(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) Low Pass Filter Control(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Modulation(-) Amplitude Control(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) Amplitude Control(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) Amplitude Control(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Modulation(-) LFO PMOD Depth(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) LFO PMOD Depth(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) LFO PMOD Depth(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Modulation(-) LFO FMOD Depth(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) LFO FMOD Depth(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) LFO FMOD Depth(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Modulation(-) LFO AMOD Depth(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) LFO AMOD Depth(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Modulation(-) LFO AMOD Depth(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Sound
EG Attack(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
EG Attack(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
EG Attack(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
EG Decay(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
EG Decay(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
EG Decay(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
EG Release(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
EG Release(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
EG Release(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Vibrato Depth(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Vibrato Depth(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Vibrato Depth(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Vibrato Speed(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Vibrato Speed(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Vibrato Speed(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Vibrato Delay(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Vibrato Delay(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Vibrato Delay(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Effect/EQ
Panel Sustain(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Panel Sustain(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Panel Sustain(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
DSP Type(Right1) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
DSP Type(Right1) Effect Parameter X X X X O Effect O EFFECT X O X O VOICE X
DSP Type(Right2) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
DSP Type(Right2) Effect Parameter X X X X O Effect O EFFECT X O X O VOICE X
DSP Type(Left) X X X X O Effect O KEYBOARD VOICE X O X O STYLE X -
DSP Type(Left) Effect Parameter X X X X O Effect O EFFECT X O X O STYLE X
DSP Variation Value(Right1) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
DSP Variation Value(Right2) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
DSP Variation Value(Left) X X X X O Effect O KEYBOARD VOICE X O X O STYLE X -
EQ Low Freq(Right1) X X X X O EQ O KEYBOARD VOICE X O X O VOICE X -
EQ Low Freq(Right2) X X X X O EQ O KEYBOARD VOICE X O X O VOICE X -
EQ Low Freq(Left) X X X X O EQ O KEYBOARD VOICE X O X O STYLE X -
EQ High Freq(Right1) X X X X O EQ O KEYBOARD VOICE X O X O VOICE X -
EQ High Freq(Right2) X X X X O EQ O KEYBOARD VOICE X O X O VOICE X -
EQ High Freq(Left) X X X X O EQ O KEYBOARD VOICE X O X O STYLE X -
Organ Flute>Footage
Organ Flutes Footage(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Footage(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Footage(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
Organ Flutes Type(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Type(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Type(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
PSR-A3000 Data List
64
Voice Set Group
Song
Song Setup
Group
Style Data
OTS
Multi Pad
Regist
Freeze Group
Scale Tune
Parameter Lock
Note
Group
Parameter Chart / Parametertabelle / Tableau des paramètres / Gráfico de parámetros
System
Song Style
Registration
Parameter
VoiceSet
Setup
MIDI Setup
User Effect
Music Finder
Organ Vibrato On/Off(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Vibrato On/Off(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Vibrato On/Off(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
Organ Vibrato Depth(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Organ Vibrato Depth(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Organ Vibrato Depth(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Organ Flute>Volume/Attack
Organ Vibrato Speed(Right1) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Organ Vibrato Speed(Right2) X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Organ Vibrato Speed(Left) X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Organ Flutes Attack Footage(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Attack Footage(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Attack Footage(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
Organ Flutes Attack Mode(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Attack Mode(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Attack Mode(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
Organ Flutes Attack Length(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Attack Length(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Attack Length(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
Organ Flutes Response(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Response(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Response(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
Organ Flutes Volume(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Volume(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Organ Flutes Volume(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
Main>Mixing Console>Vol/Voice
Vol um e
Offset Volume Song X X X X X - X - X X X O SONG X -
Offset Volume Style X X X X X - X - X X X O STYLE X -
Volume Multi Pad X X X X X - O KEYBOARD VOICE X O X O MULTI PAD X -
Volume Left X X X X X - O KEYBOARD VOICE X O X O STYLE X -
Volume Right1 X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Volume Right2 X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Part Volume Song X X X X X - O VOLUME X X X X - X -
Part Volume Style X X X X X - X - O X X O STYLE X -
Keyboard Volume XXXXX - X - XXXO VOICE X -
WLAN Volume OXXXX - X - XXXX - X -
Audio Volume O X X X X - X - X X X O AUDIO X -
AUX In Volume OXXXX - X - XXXX - X -
PanPot
Offset Pan Style X X X X X - X - X X X O STYLE X -
Pan Multi Pad X X X X X - X - X X X O MULTI PAD X -
Pan Left X X X X X - O KEYBOARD VOICE X O X O STYLE X -
Pan Right1 X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Pan Right2 X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Part Pan Song X X X X X - O PAN X X X X - X -
Part Pan Style X X X X X - X - O X X O STYLE X -
Voi c e
Voice(Right1) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Voice(Right2) X X X X O - O KEYBOARD VOICE X O X O VOICE X -
Voice(Left) X X X X O - O KEYBOARD VOICE X O X O STYLE X -
Voice(Style Part) X X X X X - X - O X X O STYLE X
Voice(Song Part) X X X X X - O VOICE X X X X - X
Main>Mixing Console>Filter
Brightness
Brightness Song Part X X X X X - O FILTER X X X X - X -
Brightness Style Part X X X X X - X - O X X O STYLE X -
Brightness Right1 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Brightness Right2 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Brightness Left X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Harmonic Content
Harmonic Content Song Part X X X X X - O FILTER X X X X - X -
Harmonic Content Style Part X X X X X - X - O X X O STYLE X -
Harmonic Content Right1 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Harmonic Content Right2 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Harmonic Content Left X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Main>Mixing Console>Tune
Octave
Octave Right1 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Octave Right2 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Octave Left X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Tuning
Tune Right1 X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Voice Set Group
Song
Song Setup
Group
Style Data
OTS
Multi Pad
Regist
Freeze Group
Scale Tune
Parameter Lock
PSR-A3000 Data List
Note
Group
65
Parameter Chart / Parametertabelle / Tableau des paramètres / Gráfico de parámetros
System
Song Style
Registration
Parameter
VoiceSet
Setup
MIDI Setup
User Effect
Music Finder
Tune Right2 X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Tune Left X X X X X - O KEYBOARD VOICE X O X O STYLE X -
Portam ento Ti me
Portamento Time Right1 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Portamento Time Right2 X X X X O Voice O KEYBOARD VOICE X O X O VOICE X -
Portamento Time Left X X X X O Voice O KEYBOARD VOICE X O X O STYLE X -
Pitch Bend Range
Pitch Bend Range Right1 X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Pitch Bend Range Right2 X X X X X - O KEYBOARD VOICE X O X O VOICE X -
Pitch Bend Range Left X X X X X - O KEYBOARD VOICE X O X O STYLE X -
Transpose
Master Transpose X X X X X - X - X X X O TRANSPOSE X -
Song Transpose X X X X X - X - X X X O TRANSPOSE X -
Keyboard Transpose X X X X X - X - X X X O TRANSPOSE X -
Main>Mixing Console>Master Compressor
Master Compressor Type O X X X X - X - X X X X - X -
Master Compressor Threshold Offset X X O X X - X - X X X X - X -
Master Compressor Ratio Offset X X O X X - X - X X X X - X -
Master Compressor Output Gain Offset X X O X X - X - X X X X - X -
Master Compressor On/Off O X X X X - X - X X X X - X -
Main>Mixing Console>MEQ
Master EQ Type O X X X X - X - X X X X - X MASTER EQ
Master EQ Parameter X X O X X - X - X X X X - X MASTER EQ
Main>Mixing Console>EQ
EQ Low Gain
EQ Low Gain Style Part X X X X X - X - O X X O STYLE X -
EQ Low Gain Song Part X X X X X - O EQ X X X X - X -
EQ Low Gain Multi Pad X X X X X - X - X X X O MULTI PAD X -
EQ Low Gain Right1 X X X X O EQ O KEYBOARD VOICE X O X O VOICE X -
EQ Low Gain Right2 X X X X O EQ O KEYBOARD VOICE X O X O VOICE X -
EQ Low Gain Left X X X X O EQ O KEYBOARD VOICE X O X O STYLE X -
EQ Low Gain Style(Offset) X X X X X - X - X X X O STYLE X -
EQ High Gain
EQ High Gain Style Part X X X X X - X - O X X O STYLE X -
EQ High Gain Song Part X X X X X - O EQ X X X X - X -
EQ High Gain Multi Pad X X X X X - X - X X X O MULTI PAD X -
EQ High Gain Right1 X X X X O EQ O KEYBOARD VOICE X O X O VOICE X -
EQ High Gain Right2 X X X X O EQ O KEYBOARD VOICE X O X O VOICE X -
EQ High Gain Left X X X X O EQ O KEYBOARD VOICE X O X O STYLE X -
EQ High Gain Style(Offset) X X X X X - X - X X X O STYLE X -
Main>Mixing Console>Effect
Reverb Type
Reverb Type X X X X X - O EFFECT O X X O STYLE/SONG X REVERB TYPE
Reverb Return Level X X X X X - O EFFECT O X X O STYLE/SONG X REVERB
Reverb Depth
Reverb Depth Style Part X X X X X - X - O X X O STYLE X -
Reverb Depth Song Part X X X X X - O EFFECT X X X X - X
Reverb Depth Multi Pad X X X X X - X - X X X O MULTI PAD X -
Reverb Depth Right1 X X X X O Effect O KEYBOARD VOICE X O X O VOICE X
Reverb Depth Right2 X X X X O Effect O KEYBOARD VOICE X O X O VOICE X
Reverb Depth Left X X X X O Effect O KEYBOARD VOICE X O X O STYLE X -
Reverb Depth Style(Offset) X X X X X - X - X X X O STYLE X -
Chorus Type
Chorus Type X X X X X - O EFFECT O X X O STYLE/SONG X -
Chorus Return Level X X X X X - O EFFECT O X X O STYLE/SONG X CHORUS
Chorus Depth
Chorus Depth Style Part X X X X X - X - O X X O STYLE X -
Chorus Depth Song Part X X X X X - O EFFECT X X X X - X -
Chorus Depth Multi Pad X X X X X - X - X X X O MULTI PAD X -
Chorus Depth Right1 X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
Chorus Depth Right2 X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
Chorus Depth Left X X X X O Effect O KEYBOARD VOICE X O X O STYLE X -
Chorus Depth Style(Offset) X X X X X - X - X X X O STYLE X -
DSP Type
DSP1(Variation) Type X X X X X - O EFFECT O X X O STYLE/SONG X -
DSP1(Variation) Return Level X X X X X - O EFFECT O X X O STYLE/SONG X DSP RETURN
DSP2Type X X X X X - O EFFECT X X X O VOICE/
DSP3Type X X X X X - O EFFECT X X X O VOICE/
DSP Depth
DSP Depth Style Part X X X X X - X - O X X O STYLE X -
PSR-A3000 Data List
66
Voice Set Group
Song
Song Setup
Group
Style Data
OTS
Multi Pad
Regist
STYLE/SONG
STYLE/SONG
Freeze Group
Scale Tune
Parameter Lock
Group
RETURN LEVEL
RETURN LEVEL
LEVEL
X-
X-
Note
Parameter Chart / Parametertabelle / Tableau des paramètres / Gráfico de parámetros
System
Song Style
Registration
Parameter
VoiceSet
Setup
MIDI Setup
User Effect
Music Finder
DSP Depth Song Part XXX X X - O EFFECT X X XX - X -
DSP Depth Right1 X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
DSP Depth Right2 X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
DSP Depth Left X X X X O Effect O KEYBOARD VOICE X O X O STYLE X -
Insertion Type(Right1) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
Insertion Type(Right2) X X X X O Effect O KEYBOARD VOICE X O X O VOICE X -
Insertion Type(Left) X X X X O Effect O KEYBOARD VOICE X O X O STYLE X -
Insertion Type(Song) X X X X X - O EFFECT X X X X - X -
Effect Parameter(Reverb/Chorus/DSP1) X X O X X - O EFFECT X X X X - X
Effect Parameter(Reverb/Chorus/DSP2-4) X X O X X - O EFFECT X O X O VOICE/STYLE X
Main>Channel>Channel On/Off Popup
Channel On/Off(Song) X X X X X - X - X X X O SONG X -
Channel On/Off(Style) X X X X X - X - O X X O STYLE X -
Function Menu>MIDI
MIDI Template
Template No. O X X X X - X - X X X X - X -
Preset Template Name X O X X X - X - X X X X - X -
Function Menu>MIDI>EDIT
System
Local Control X O X X X - X - X X X X - X -
Clock XOXXX - X - XXXX - X -
Transmit Clock X O X X X - X - X X X X - X -
Receive Transpose X O X X X - X - X X X X - X -
Receive Start/Stop X O X X X - X - X X X X - X -
SysEx Transmit X O X X X - X - X X X X - X -
SysEx Receive X O X X X - X - X X X X - X -
Chord SysEx Transmit X O X X X - X - X X X X - X -
Chord SysEx Receive X O X X X - X - X X X X - X -
Tra nsm it
Part Select X O X X X - X - X X X X - X -
Ch Select X O X X X - X - X X X X - X -
Filter(for each part) X O X X X - X - X X X X - X -
Receive
Ch Select X O X X X - X - X X X X - X -
Part Select X O X X X - X - X X X X - X -
Filter(for each part) X O X X X - X - X X X X - X -
Bass(On Bass Note)
Bass(On Bass Note) X O X X X - X - X X X X - X -
Chord Detect
Chord Detect X O X X X - X - X X X X - X -
Function Menu>Mater Tune/Scale Tune
Master Tune
Master Tune OXXXX - X - XXXX - X -
Scale Tune
Scale Type XXXXX - X - XXXO SCALE O -
Base Note XXXXX - X - XXXO SCALE O -
Tune X X X X X - X - X X X O SCALE O -
Part Select (Right1/Right2,Left,Style,Multi Pad) X X X X X - X - X X X O SCALE O -
Function Menu>Controller
Live Control
Live Control Assign Type X X X X X - X - X X X X - X -
Live Control Assign Set 1-1 O X X X X - X - X X X X - X -
Live Control Assign Set 2-1 O X X X X - X - X X X X - X -
Live Control Assign Set 3-1 O X X X X - X - X X X X - X -
Live Control Assign Set 4-1 O X X X X - X - X X X X - X -
Live Control Assign Set 5-1 O X X X X - X - X X X X - X -
Live Control Assign Set 6-1 O X X X X - X - X X X X - X -
Live Control Assign Set 7-1 O X X X X - X - X X X X - X -
Live Control Assign Set 8-1 O X X X X - X - X X X X - X -
Live Control Assign Set 1-2 O X X X X - X - X X X X - X -
Live Control Assign Set 2-2 O X X X X - X - X X X X - X -
Live Control Assign Set 3-2 O X X X X - X - X X X X - X -
Live Control Assign Set 4-2 O X X X X - X - X X X X - X -
Live Control Assign Set 5-2 O X X X X - X - X X X X - X -
Live Control Assign Set 6-2 O X X X X - X - X X X X - X -
Live Control Assign Set 7-2 O X X X X - X - X X X X - X -
Live Control Assign Set 8-2 O X X X X - X - X X X X - X -
Foot Pedal
Pedal Function X X X X X - X - X X X O PEDAL X -
Pedal Settings X X X X X - X - X X X O PEDAL X -
Pedal Polarity O X X X X - X - X X X X - X -
Keyboard/Panel
Touch Response O X X X X - X - X X X X - X -
Voice Set Group
Song
Song Setup
Group
Style Data
OTS
Multi Pad
Regist
Freeze Group
Scale Tune
Parameter Lock
PSR-A3000 Data List
Note
Group
67
Parameter Chart / Parametertabelle / Tableau des paramètres / Gráfico de parámetros
System
Song Style
Parameter
VoiceSet
Setup
MIDI Setup
User Effect
Music Finder
Initial Touch Off Level X X X X X - X - X X X O VOICE X -
Initial Touch Part On/Off X X X X X - X - X X X O VOICE X -
Modulation(+) Part On/Off X X X X X - X - X X X O VOICE X -
Modulation(-) Part On/Off X X X X X - X - X X X O VOICE X -
Transpose Assign O X X X X - X - X X X X - X -
Function Menu>Regist Sequence/Freeze
Regist Sequence
Regist Sequence Data X X X X X - X - X X X O - X -
Regist Sequence Enable O X X X X - X - X X X X - X -
Regist(+)Pedal O X X X X - X - X X X X - X -
Regist(-)Pedal O X X X X - X - X X X X - X -
Regist Sequence End X X X X X - X - X X X O - X -
Freeze Group
Freeze Group Setting O X X X X - X - X X X X - X -
Voi ce S et
Voice Set Group Right1 On/Off O X X X X - X - X X X X - X -
Voice Set Group Right2 On/Off O X X X X - X - X X X X - X -
Voice Set Group Left On/Off O X X X X - X - X X X X - X -
Function Menu>Harmony/Arpeggio
Type XXX X O
Volume XXX X O
Speed X X X X O
Assign X X X X O
Chord Note Only X X X X O
Touch Limit X X X X O
Function Menu>Utility
Configration1
Fade In Time O X X X X - X - X X X X - X -
Fade Out Time O X X X X - X - X X X X - X -
Fade Out Hold Time O X X X X - X - X X X X - X -
Metronome Volume O X X X X - X - X X X X - X -
Metronome Sound O X X X X - X - X X X X - X -
Time Signature X X X X X - O - O X X X - X -
Tap Count Percussion X X X X X - O KEYBOARD VOICE X O X O STYLE X -
Tap Count Velocity X X X X X - O KEYBOARD VOICE X O X O STYLE X -
Auto Power Off O X X X X - X - X X X X - X -
Configration2
Speaker OXXXX - X - XXXX - X -
Display Style Tempo O X X X X - X - X X X X - X -
Display Voice Number O X X X X - X - X X X X - X -
Display Time Stamp O X X X X - X - X X X X - X -
Voice Category Button Options O X X X X - X - X X X X - X -
Popup Display Time O X X X X - X - X X X X - X -
Arpeggio Quantize O X X X X - X - X X X X - X -
Arpeggio Hold Sw O X X X X - X - X X X X - X -
Parameter Lock
Parameter Lock O X X X X - X - X X X X - X -
USB
Song Auto Open O X X X X - X - X X X X - X -
Function Menu>System
Owner
Language O X X X X - X - X X X X - X - Cannot be
Owner Name O X X X X - X - X X X X - X - Cannot be
Main Picture O X X X X - X - X X X X - X - Cannot be
Registration
Regist Memory Contents O X X X X - X - X X X X - X -
Regist Contents Name XXXXX - X - XXXO - X -
Transpose
Transpose X X X X X - X - X X X O TRANSPOSE X -
Upper Octave
Upper Octave X X X X X - X - X X X O VOICE X -
USB Audio Player
Audio Volume O X X X X - X - X X X O AUDIO X -
Audio Player Repeat Mode O X X X X - X - X X X X - X -
Voice Set Group
Harmony/
Arpeggio
Harmony/
Arpeggio
Harmony/
Arpeggio
Harmony/
Arpeggio
Harmony/
Arpeggio
Harmony/
Arpeggio
Song
O KEYBOARD VOICE X O X O HARMONY/
O KEYBOARD VOICE X O X O HARMONY/
O KEYBOARD VOICE X O X O HARMONY/
O KEYBOARD VOICE X O X O HARMONY/
O KEYBOARD VOICE X O X O HARMONY/
O KEYBOARD VOICE X O X O HARMONY/
Song Setup
Group
Style Data
OTS
Multi Pad
Registration
Regist
ARPEGGIO
ARPEGGIO
ARPEGGIO
ARPEGGIO
ARPEGGIO
ARPEGGIO
Scale Tune
Freeze Group
X-
X-
X-
X-
X-
X-
Parameter Lock
Group
Note
reset with
Factory Reset.
reset with
Factory Reset.
reset with
Factory Reset.
PSR-A3000 Data List
68
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
Many MIDI messages listed in the MIDI Data Format are expressed in decimal numbers, binary numbers and hexadecimal numbers.
Hexa-decimal numbers may include the letter “H” as a suffix. Also, “n” can freely be defined as any whole number.
To enter data/values, refer to the table below.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
0
1
2
3
4
5
6
7
8
9
00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
0000 0000
0000 0001
0000 0010
0000 0011
0000 0100
0000 0101
0000 0110
0000 0111
0000 1000
0000 1001
0000 1010
0000 1011
0000 1100
0000 1101
0000 1110
0000 1111
0001 0000
0001 0001
0001 0010
0001 0011
0001 0100
0001 0101
0001 0110
0001 0111
0001 1000
0001 1001
0001 1010
0001 1011
0001 1100
0001 1101
0001 1110
0001 1111
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
0010 0000
0010 0001
0010 0010
0010 0011
0010 0100
0010 0101
0010 0110
0010 0111
0010 1000
0010 1001
0010 1010
0010 1011
0010 1100
0010 1101
0010 1110
0010 1111
0011 0000
0011 0001
0011 0010
0011 0011
0011 0100
0011 0101
0011 0110
0011 0111
0011 1000
0011 1001
0011 1010
0011 1011
0011 1100
0011 1101
0011 1110
0011 1111
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
40
41
42
43
44
45
46
47
48
49
4A
4B
4C
4D
4E
4F
50
51
52
53
54
55
56
57
58
59
5A
5B
5C
5D
5E
5F
0100 0000
0100 0001
0100 0010
0100 0011
0100 0100
0100 0101
0100 0110
0100 0111
0100 1000
0100 1001
0100 1010
0100 1011
0100 1100
0100 1101
0100 1110
0100 1111
0101 0000
0101 0001
0101 0010
0101 0011
0101 0100
0101 0101
0101 0110
0101 0111
0101 1000
0101 1001
0101 1010
0101 1011
0101 1100
0101 1101
0101 1110
0101 1111
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
60
61
62
63
64
65
66
67
68
69
6A
6B
6C
6D
6E
6F
70
71
72
73
74
75
76
77
78
79
7A
7B
7C
7D
7E
7F
0110 0000
0110 0001
0110 0010
0110 0011
0110 0100
0110 0101
0110 0110
0110 0111
0110 1000
0110 1001
0110 1010
0110 1011
0110 1100
0110 1101
0110 1110
0110 1111
0111 0000
0111 0001
0111 0010
0111 0011
0111 0100
0111 0101
0111 0110
0111 0111
0111 1000
0111 1001
0111 1010
0111 1011
0111 1100
0111 1101
0111 1110
0111 1111
• Except the table above, for example 144–159 (decimal)/9nH/10010000–1001 1111 (binary) denotes the Note On Message for each channel (1–16). 176–191/BnH/
1011 0000–1011 1111 denotes the Control Change Message for each channel (1–16). 192-207/CnH/1100 0000–1100 1111 denotes the Program Change Message
for each channel (1–16). 240/F0H/1111 0000 denotes the start of a System Exclusive Message. 247/F7H/1111 0111 denotes the end of a System Exclusive
Message.
• aaH (hexadecimal)/0aaaaaaa (binary) denotes the data address. The address contains High, Mid, and Low.
• bbH/0bbbbbbb denotes the byte count.
• ccH/0ccccccc denotes the check sum.
• ddH/0ddddddd denotes the data/value.
PSR-A3000 Data List
69
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
MIDI CHANNEL MESSAGE (1)
[GM1]...GM Required Parameter
[GM2]...GM Level2 Required Parameter
MIDI Events Status byte 1st Data byte 2nd Data byte Voice MIDI Reception MIDI Transmission PLAY REC
Status Data (HEX) Parameter Data (HEX) Parameter Regular/
Organ Voice
Key Off
[GM1][GM2]
[GS]
Key On
[GM1][GM2]
[GS]
Control
Change
[GM2][GS]
8nH (n:Channel
Number)
9nH (n:Channel
Number)
BnH 0 (00H) Bank Select
kk Key no.
kk Key no.
1(01H)Modulation
5 (05H) Portamento
6 (06H) Data Entry
7 (07H) M ain Volume
10 (0AH) Panpot
11 (0BH) Expression
16 (10H) General
32 (20H) Bank Select
38 (26H) Data Entry
64 (40H) Sustain
65 (41H) Portamento
66 (42H) Sostenuto
67 (43H) Soft Pedal
71 (47H) Harmonic
72 (48H) Release Time
73 (49H) Attack Time
74 (4AH) Brightness
75 (4BH) Decay Time
76 (4CH) V ibrato Rate
77 (4DH) Vibrato Depth
78 (4EH) Vibrato Delay
80 (50H) General
(0–127)
(0–127)
MSB
[GM2][GS]
[GM1][GM2]
[GS]
Time
[GM2][GS]
MSB
[GM2][GS]
[GM1][GM2]
[GS]
[GM1][GM2]
[GS]
[GM1][GM2]
[GS]
Purpose
Controller
LSB
[GM2][GS]
LSB
[GM2][GS]
(Damper)
[GM1][GM2]
[GS]
[GM2][GS]
[GM2][GS]
[GM2][GS]
Content [GM2]
[GM2]
[GM2]
[GM2]
[GM2]
[GM2]
[GM2]
[GM2]
Purpose
Controller
(Articuration 1)
vv Velocity(0–127) O O O O O O X X X O X O X X
vv Key On :vv=1–127
0
0
8
8
64
104
104
118
119
120
121
126
127
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
Key Off :vv=0
Normal
(00H)
SA Voice
(00H)
MegaVoice
(08H)
SA Voice
(08H)
SFX Voice
(40H)
Normal
(68H)
SA Voice
(68H)
GS Rhythm
(76H)
GS Normal
(77H)
GM2 Rhythm
(78H)
GM2 Normal
(79H)
SFX kit
(7EH)
Drum kit
(7FH)
Data O O O O
7FH)
Data O
7FH)
Data O O O O
7FH)
Data O O O O
7FH)
L64...C...R63 O O O O
7FH)
Data O O O O
7FH)
Data O O O O
7FH)
Data O O O O
7FH)
Data O O O O
7FH)
Data O O O O
7FH)
0...63, 64...127
7FH)
(OFF, ON)
0...63, 64...127
7FH)
(OFF, ON)
0...63, 64...127
7FH)
(OFF, ON)
-64...0...+63 O O O O
7FH)
-64...0...+63 O O O O
7FH)
-64...0...+63 O O O O
7FH)
-64...0...+63 O O O O
7FH)
-64...0...+63 O O O O
7FH)
-64...0...+63 O O O O
7FH)
-64...0...+63 O O O O
7FH)
-64...0...+63 O O O O
7FH)
0: OFF
7FH)
127:ON
(Except SA
and Organ
(Except SA
and Organ
[MIDI] [Internal sequencer]
Right1/
Right2/
Left
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
(All Keyboard
Keyboard Style Extra
(Right1)
parts)
parts)
parts)
parts)
parts)
parts)
parts)
(Right1)
parts)
parts)
parts)
parts)
parts)
parts)
parts)
parts)
parts)
parts)
parts)
parts)
parts)
Song
Drum/
Natural/
OOO OOO
OOO O
OO O
Flutes)
OO O
O
Flutes)
OOO O
OOO O
O
(SA Voice
OX X XXXXOOXOO O
only)
Right1/
M.Pad
Right2/
OO
OO
XO
OO
OO
OO
OO
XO
OO
OO
XO
XO
XO
XO
OO
OO
OO
OO
OO X X X O X OO X
OO X X X O X OO X
OO X X X O X OO X
OO X X X O X OO X
Style Song
Left
OOOOX O
O
OOOOO O
OXOXOO O
OOOX OX O
OXO OO X
O
OXOXOX O
OXOOO O
OXOOO O
OXOOO O
OXOOO O
O
OOOX OO O
OOOX OO O
O
Upper
Lower
XOO O
XOO O
XOO O
XOO O
XOO O
XOO O
PLAY REW Fro m
panel
(Right1/
Right2/
Left)
OO O
PSR-A3000 Data List
70
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
[MIDI] [Internal sequencer]
MIDI Events Status byte 1st Data byte 2nd Data byte Voice MIDI Reception MIDI Transmission PLAY REC
Song
Right1/
Status Data (HEX) Parameter Data (HEX) Parameter Regular/
Control
Change
[GM2][GS]
Mode
Message
Program
Change
[GM1][GM2]
[GS]
Channel
After Touch
[GM1][GM2]
[GS]
Polyphonic
After Touch
[GS]
Pitch Bend
Change
[GM1][GM2]
[GS]
Realtime
Message
BnH 81 (51H) General
84 (54H) Portamento
91 (5BH) Effect1 Depth
93 (5DH) Effect3 Depth
94 (5EH) Effect4 Depth
96 (60H) RPN
97 (61H) RPN
98 (62H) NRPN LSB
99 (63H) N RPN MSB
100 (64H) RPN LSB
101 (65H) RPN MSB
BnH (n:Channel
Number)
CnH (n:Channel
Number)
DnH (n:Channel
Number)
AnH (n:Channel
Number)
EnH (n:Chan nel
Number)
F8H MIDI Clock
FAH St art
FBH Continue
FCH Stop
FEH Active
Sense
[GM2]
FFH System
Reset
120 (78H) All Sound O ff
121 (79H) Reset All
122 (7AH) Local Control 0
123 (7BH) All Note Off
124 (7CH) Omni Off
125 (7DH) Omni On
126 (7EH) Mono
127 (7FH) Poly
pp (00H...7
vv (00H...7
kk (00H...7
cc (00H ...7
- - - --O
- - - --O
- - - --X X---
- - - --O
- - - --O O---
- - - --X X---
Purpose
Controller
(Articuration 2)
Control
(Reverb Send
Level)
[GM2][GS]
(Chorus Send
Level)
[GM2][GS]
(Variation
Send Level)
Increment
Decrement
[GS]
[GS]
[GM2][GS]
[GM2][GS]
[GM2][GS]
Controllers
[GM1][GM2][
GS]
[GM1][GM2][
GS]
[GM2][GS]
[GM2][GS]
[GM2][GS]
[GM2][GS]
Voice Number
FH)
(0–127)
Data
FH)
Key no.
FH)
(0–127)
LSB dd (00H...
FH)
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
- - The data byte is
- - The data byte is
0–127 (00H...
0–127 (00H...
0–127 (00H...
0–127 (00H...
0 (00H) Data O O O O
0 (00H) Data O O X X X X X O X O X O X X
127
0 (00H) Data O O O O
0 (00H) Data O O*1XXXXXOXOXOXX
0 (00H) Data O O*2XXXXXOXOXOXX
0–16 (00H...
0 (00H) Data O O X X X X X O X O X O X X
- - -OOOO
- - -OOOO
vv (00H...
0: OFF
7FH)
127:ON
Key no.
7FH)
(0–127)
Data O O O O
7FH)
Data O O O O
7FH)
Data O O O O
7FH)
ignored.
ignored.
Data O O O X O O
7FH)
Data O O O X O O
7FH)
Data O O O O
7FH)
Data O O O O
7FH)
(00H)
OFF
(7FH)
ON
Data O O X X X X X O X O X O X X
10H)
Data O O X X X X X X X O X O X X
7FH)
MSB O O O O
7FH)
: Transmitted via panel operations and keyboard/controller performances. O : Available
*1: Same operation as when receiving All Note Off.
*2: Same operation as when receiving All Note Off. OMNI ON is not enabled.
Keyboard Style Extra
Drum/
Natural/
Organ Voice
XOX X XXXXOOXOO O
OOO X OOOO
OOO X OOXOXOXOXX
OOO X OOXOXOXOXX
- O X XXXXXX X
Right2/
Left
(All Keyboard
parts)
(All Keyboard
parts)
(All Keyboard
parts)
(All Keyboard
parts)
(All Keyboard
parts)
(All Keyboard
parts) (Same
operation as
when All Note
Off)
(All Keyboard
parts)
(Right1)
(All Keyboard
parts)
(All Keyboard
parts)
(Received when the Clock is set to MIDI,
USB1, USB2 or Wireless LAN.)
(Received when the Clock is set to MIDI,
USB1, USB2 or Wireless LAN.)
(Received when the Clock is set to MIDI,
USB1, USB2 or Wireless LAN.)
Right1/
M.Pad
Style Song
Upper
Right2/
Left
OO
OO
OO O O
OO
OO
OO X O X O X OX X
OO X O X O X OX X
OOO
XO X O XO X OX O
OO
(Transmitted when the Clock is set
to Internal and the Transmit Clock
(Transmitted when the Transmit
(Transmitted when the Transmit
OOOX OO O
OOOX OO O
OOOX OO O
OOOX OO O
OOOOO O
O
is set to on.)
O
Clock is set to on.)
O
Clock is set to on.)
PLAY REW Fro m
Lower
OXOX O
XOO O
XOO O
XOO X
XOO O
-- -
-- -
-- -
panel
(Right1/
Right2/
Left)
Multi Part
Recording
PSR-A3000 Data List
71
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
MIDI CHANNEL MESSAGE (2)
[GM1]...GM Required Parameter
[GM2]...GM Level2 Required Parameter
NRPN (Non Registered Parameter Number) [MIDI] [Internal sequencer]
NRPN Data Entry Parameter Data Range Voice MIDI Reception MIDI Transmission PLAY REC
MSB LSB MSB LSB Regular/
01H 08H mmH -- Vibrato Rate
01H 09H mmH -- Vibrato Depth
01H 0AH mmH -- Vibrato Delay
01H 20H mmH -- Low Pass Filter Cutoff
01H 21H mmH -- Low Pass Filter
01H 30H mmH -- EQ Bass Gain mm : 00H-40H-7FH (-64...0...+63) O O X X O X X X X O X O O X
01H 31H mmH -- EQ Treble Gain mm : 00H-40H-7FH (-64...0...+63) O O X X O X X X X O X O O X
01H 34H mmH -- EQ Bass Frequency mm : 04H-28H (32...2.0k[Hz]) O O X X X X X X X O X O O X
01H 35H mmH -- EQ Treble Frequency mm : 1CH-3AH (500...16.0k[Hz]) O O X X X X X X X O X O O X
01H 63H mmH -- EG Attack Time
01H 64H mmH -- EG Decay Time
01H 66H mmH -- EG Release
14H rrH mmH -- Drum Low Pass Filter
15H rrH mmH -- Drum Low Pass Filter
16H rrH mmH -- Drum EG Attack Rate rr : drum instrument note number
17H rrH mmH -- Drum EG Decay Rate rr : drum instrument note number
18H rrH mmH -- Drum Pitch Coarse
19H rrH mmH -- Drum Pitch Fine rr : drum instrument note number
1AH rrH mmH -- Drum Level
1CH rrH mmH -- Drum Pan
1DH rrH mmH -- Drum Reverb Send Level
1EH rrH mmH -- Drum Chorus Send Level
1FH rrH mmH -- Drum Variation Send
30H rrH mmH -- Drum EQ Bass Gain rr : drum instrument note number
31H rrH mmH -- Drum EQ Treble Gain rr : drum instrument note number
34H rrH mmH -- Drum EQ Bass Frequency rr : drum instrument note number
35H rrH mmH -- Drum EQ Treble
[GS]
[GS]
[GS]
Frequency
[GS]
Resonance
[GS]
[GS]
[GS]
[GS]
Cutoff Frequency
Resonance
[GS]
[GS]
[GS]
[GS]
[GS]
Level
Frequency
mm : 00H-40H-7FH (-64. ..0...+63) O O O X O O
mm : 00H-40H-7FH (-64. ..0...+63) O O O X O O
mm : 00H-40H-7FH (-64. ..0...+63) O O O X O O
mm : 00H-40H-7FH (-64. ..0...+63) O O X X O X X O X O X O O X
mm : 00H-40H-7FH (-64. ..0...+63) O O X X O X X O X O X O O X
mm : 00H-40H-7FH (-64. ..0...+63) O O X X O X X O X O X O O X
mm : 00H-40H-7FH (-64. ..0...+63) O O O X O O
mm : 00H-40H-7FH (-64. ..0...+63) O O X X O X X O X O X O O X
rr : drum instrument note number
mm : 00H-40H-7FH (-64. ..0...+63)O(Drum Only)
rr : drum instrument note number
mm : 00H-40H-7FH (-64. ..0...+63)O(Drum Only)
mm : 00H-40H-7FH (-64. ..0...+63)O(Drum Only)
mm : 00H-40H-7FH (-64. ..0...+63)O(Drum Only)
rr : drum instrument note number
mm : 00H-40H-7FH (-64. ..0...+63)O(Drum Only)
mm : 00H-40H-7FH (-64. ..0...+63)O(Drum Only)
rr : drum instrument note number
mm : 00H-7FH (0...127)
rr : drum instrument note number
mm : 00H, 01H-40H-7FH (RND,
L63...C...R63)
rr : drum instrument note number
mm : 00H-7FH (0...127)
rr : drum instrument note number
mm : 00H-7FH (0...127)
rr : drum instrument note number
mm : 00H-7FH (0...127)
(Variation Connection = SYSTEM)
mm : 00H, 01H-7FH (OFF, ON)
(Variation Connection = INSERTION)
mm : 00H-7FH (0...127)
mm : 00H-7FH (0...127)
mm : 04H-28H (32...2.0k[Hz])
rr : drum instrument note number
mm : 1CH-3AH (500...16.0k[Hz])
: Transmitted via panel operations and keyboard/controller performances.
NRPN MSB: 14H-35H (for drums) message is accepted as long as the channel is set with a drum voice.
Data Entry LSB: Ignored.
Organ Voice
(Drum Only)
(Drum Only)
(Drum Only)
(Drum Only)
(Drum Only)
O : Available
Song
Right1/
Drum/
Natural/
Keyboard Style Extra
Right2/
Left
Right1/
M.Pad Style Song Upper
Right2/
Left
PLAY REW From panel
Lower
OOO XOO O
OOO XOO O
OOO XOO O
OOO XOO O
OX X X XX XOOXOX X
OX X X XX XOOXOX X
OX X X XX XOOXOX X
OX X X XX XOOXOX X
OX X X XX XOOXOX X
OX X X XX XOOXOX X
O
OX X X XX XOOXOX X
O
OX X X XX XOOXOX X
O
OX X X XX XOOXOX X
O
OX X X XX XOOXOX X
O
OX X X XX XOOXOX X
X XX X XXXXXOXXX X
X XX X XXXXXOXXX X
X XX X XXXXXOXXX X
X XX X XXXXXOXXX X
(Right1/
Right2/
Left)
RPN (Registered Parameter Number) [MIDI] [Internal sequencer]
RPN Data Entry Parameter Data Range Voice MIDI Reception MIDI Transmission PLAY REC
MSB LSB MSB LSB Regular/
00H 00H mmH -- Pitch Bend Sensitivity
00H 01H mmH llH Fine Tune
00H 02H mmH -- Coarse Tune
00H 05H mmH llH Modulation Sensitivity
7FH 7FH -- -- Null
[GM1][GM2][GS]
[GM1][GM2][GS]
[GM1][GM2][GS]
[GM2]
[GM2][GS]
mm : 00H-18H (0...+24[semitones]) O O O O
mm ll : 00H 00H -100[cent]
: :
mm ll : 40H 00H 0[cent]
: :
mm ll : 7FH 7FH 100[cent]
mm : 28H-40H-58H
(-24...0...+24[semitones ])
mm: Specified in semitone steps
ll: Specified in 100/128 ce nt steps
-OOOO
: Transmitted via panel operations and keyboard/controller performances.
PSR-A3000 Data List
72
Organ Voice
O : Available
Song
Right1/
Drum/
Natural/
OOO O
OOO O
O OX X XX XXXOXOX X
Keyboard Style Extra
Right2/
Left
(All Keyboard
parts)
(All Keyboard
parts)
(All Keyboard
parts)
(All Keyboard
parts)
Right1/
M.Pad Style Song Upper
Right2/
Left
OO
OO
OOX OOOX OO X
OOX OOOX O X X
OOO XOO O
OOO XOO O
Lower
PLAY REW From panel
(Right1/
Right2/
Left)
XG PARAMETER CHANGE TABLE
* Not received when Receive System Exclusive Message Parameters is set to off.
* Not transmitted when Transmit System Exclusive Message Parameters is set to off.
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
MIDI Parameter Change table (XG SYSTEM)
[MIDI] [Internal sequencer]
Address Size Data Parameter Description XG Default Voice MIDI Reception MIDI Transmission PLAY REC
Right1/
(H) (H) (H) (H) Regular/
00 00 00
TOTAL SIZE 07
4 00-0F
01
02
03
04 1 00-7F MASTER VOLUME 0...127 7F O O
05 1 00-7F MASTER ATTENUATOR 0...127 00 X X X X X X
06 1 28-58 TRANSPOSE -24...0...+24[semitones] 40 O O
7D 1 N DRUM SETUP RESET N:Drum setup number -
7E 1 00 XG SYSTEM ON 00=XG system ON - O O
7F 1 00 ALL PARAMETER RESET 00=ON - O O
MASTER TUNE -102.4...0...+102.3[cent]
00-0F
00-0F
00-0F
1st bit3-0 bit15-12
2nd bit3-0 bit11-8
3rd bit3-0 bit7-4
4th bit3-0 bit3-0
* Panel
setting value
Song
Drum/
Natural/
Organ Voice
OO
O
(Drum Only)O(Available for extra parts and Song)
Keyboard Style Extra
Right2/
Left
(Available for extra parts and Song)
(Available for extra parts and Song)
(Available for extra parts and Song)
(Available for extra parts and Song)
Right1/
Right2/
Left
M.Pad
Style Song
Upper
PLAY REW From panel
Lower
(Right1/
Right2/
OX X
OOOX
OOOX
OOXX
OOXO
OOXX
: Transmitted via panel operations O : Available
MIDI Parameter Change table (SYSTEM INFORMATION)
Address Size Data Parameter Description Voice MIDI Reception MIDI Transmission PLAY REC
(H) (H) (H) Regular/
01 00 00
:
0D
0E
0F
TOTAL SIZE 10
E
20-7F
Model Name 1
:
:
20-7F
Model Name 14
1
1
NOT USED
NOT USED
32...127(ASCII CHARACTER)
:
32...127(ASCII CHARACTER)
Transmitted in response to Dump Request. Not received.
[MIDI] [Internal sequencer]
Right1/
Song
Drum/
Natural/
Organ Voice
-- O
Keyboard Style Extra
Right2/
Left
Right1/
M.Pad
Right2/
Left
Style Song
(Available only when receiving
requests via MIDI)
Upper
Lower
PLAY REW From panel
(Right1/
Right2/
-- -
Left)
Left)
MIDI Parameter Change table (EFFECT1)
[MIDI] [Internal sequencer]
Address Size Data Parameter Description XG Default Voice MIDI Reception MIDI Transmission PLAY REC
(H) (H) (H) (H) Regular/
02 01 00 2 00-7F
02 1 00-7F REVERB PARAMETER 1 Refer to Effect Parameter List Depends on
03 1 00-7F REVERB PARAMETER 2 Refer to Effect Parameter List Depends on
04 1 00-7F REVERB PARAMETER 3 Refer to Effect Parameter List Depends on
05 1 00-7F REVERB PARAMETER 4 Refer to Effect Parameter List Depends on
06 1 00-7F REVERB PARAMETER 5 Refer to Effect Parameter List Depends on
07 1 00-7F REVERB PARAMETER 6 Refer to Effect Parameter List Depends on
08 1 00-7F REVERB PARAMETER 7 Refer to Effect Parameter List Depends on
09 1 00-7F REVERB PARAMETER 8 Refer to Effect Parameter List Depends on
0A 1 00-7F REVERB PARAMETER 9 Refer to Effect Parameter List Depends on
0B 1 00-7F REVERB PARAMETER 10 Refer to Effect Parameter List Depends on
0C 1 00-7F REVERB RETURN
0D 1 01-7F REVERB PAN L63...C...R63 40 O O O O O X
TOTAL SIZE 0E
02 01 10 1 00-7F REVERB PARAMETER 11 Refer to Effect Parameter List Depends on
11 1 00-7F REVERB PARAMETER 12 Refer to Effect Parameter List Depends on
12 1 00-7F REVERB PARAMETER 13 Refer to Effect Parameter List Depends on
13 1 00-7F REVERB PARAMETER 14 Refer to Effect Parameter List Depends on
14 1 00-7F REVERB PARAMETER 15 Refer to Effect Parameter List Depends on
15 1 00-7F REVERB PARAMETER 16 Refer to Effect Parameter List Depends on
TOTAL SIZE 06
00-7F
REVERB TYPE MSB
REVERB TYPE LSB
Refer to Effect Parameter List
Refer to Effect Parameter List
-∞dB...0dB...+6dB(0...64...127)
01(=HALL1)00OO
Reverb Type
Reverb Type
Reverb Type
Reverb Type
Reverb Type
Reverb Type
Reverb Type
Reverb Type
Reverb Type
Reverb Type
40 O O OO O
Reverb Type
Reverb Type
Reverb Type
Reverb Type
Reverb Type
Reverb Type
: Transmitted via panel operations O : Available
Song
Right1/
Drum/
Natural/
Organ Voice
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
Keyboard Style Extra
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
Upper
PLAY REW From panel
Lower
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
(Right1/
Right2/
Left)
PSR-A3000 Data List
73
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
[MIDI] [Internal sequencer]
Address Size Data Parameter Description XG Default Voice MIDI Reception MIDI Transmission PLAY REC
Right1/
(H) (H) (H) (H) Regular/
02 01 20 2 00-7F
22 1 00-7F CHORUS PARAMETER 1 Refer to Effect Parameter List Depends on
23 1 00-7F CHORUS PARAMETER 2 Refer to Effect Parameter List Depends on
24 1 00-7F CHORUS PARAMETER 3 Refer to Effect Parameter List Depends on
25 1 00-7F CHORUS PARAMETER 4 Refer to Effect Parameter List Depends on
26 1 00-7F CHORUS PARAMETER 5 Refer to Effect Parameter List Depends on
27 1 00-7F CHORUS PARAMETER 6 Refer to Effect Parameter List Depends on
28 1 00-7F CHORUS PARAMETER 7 Refer to Effect Parameter List Depends on
29 1 00-7F CHORUS PARAMETER 8 Refer to Effect Parameter List Depends on
2A 1 00-7F CHORUS PARAMETER 9 Refer to Effect Parameter List Depends on
2B 1 00-7F CHORUS PARAMETER 10 Refer to E ffect Parameter List Depends on
2C 1 00-7F CHORUS RETURN
2D 1 01-7F CHORUS PAN L63...C...R63 40 O O O O O X
2E 1 00-7F SEND CHORUS TO REVERB
TOTAL SIZE 0F
00-7F
CHORUS TYPE MSB
CHORUS TYPE LSB
Refer to Effect Parameter List
Refer to Effect Parameter List
-∞dB...0dB...+6dB(0...64...127)
-∞dB...0dB...+6dB(0...64...127)
41(=CHORUS1)
00
Chorus Type
Chorus Type
Chorus Type
Chorus Type
Chorus Type
Chorus Type
Chorus Type
Chorus Type
Chorus Type
Chorus Type
40 O O OO O
00 O O O O O X
Song
Drum/
Natural/
Organ Voice
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
Keyboard Style Extra
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
Upper
PLAY REW From panel
Lower
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
(Right1/
Right2/
Left)
02 01 30 1 00-7F CHORUS PARAMETER 11 Refer to Effect Parameter List Depends on
31 1 00-7F CHORUS PARAMETER 12 Refer to Effect Parameter List Depends on
32 1 00-7F CHORUS PARAMETER 13 Refer to Effect Parameter List Depends on
33 1 00-7F CHORUS PARAMETER 14 Refer to Effect Parameter List Depends on
34 1 00-7F CHORUS PARAMETER 15 Refer to Effect Parameter List Depends on
35 1 00-7F CHORUS PARAMETER 16 Refer to Effect Parameter List Depends on
TOTAL SIZE 06
Address Size Data Parameter Description XG Default Voice MIDI Reception MIDI Transmission PLAY REC
(H) (H) (H) (H) Regular/
02 01 40 2 00-7F
42 2 00-7F
44 2 00-7F
46 2 00-7F
48 2 00-7F
4A 2 00-7F
4C 2 00-7F
4E 2 00-7F
50 2 00-7F
52 2 00-7F
54 2 00-7F
56 1 00-7F VARIATION RETURN
57 1 01-7F VARIATION PAN L63...C...R63 40 O O O O O X
58 1 00-7F SEND VARIATION TO REVERB
59 1 00-7F SEND VARIATION TO
5A 1 00-01 VARIATION CONNECTION INSERTION, SYSTEM 00 O O
5B 1 00-7F VARIATION PART NUMBER
5C 1 00-7F MW VARIATION CONTROL
5D 1 00-7F BEND VARIATION CONTROL
5E 1 00-7F CAT VARIATION CONTROL
5F 1 00-7F AC1 VARIATION CONTROL
60 1 00-7F AC2 VARIATION CONTROL
TOTAL SIZE 21
VARIATION TYPE MSB
00-7F
VARIATION TYPE LSB
VARIATION PARAMETER 1 MSB
VARIATION PARAMETER 1 LSB
00-7F
VARIATION PARAMETER 2 MSB
00-7F
VARIATION PARAMETER 2 LSB
VARIATION PARAMETER 3 MSB
VARIATION PARAMETER 3 LSB
00-7F
VARIATION PARAMETER 4 MSB
VARIATION PARAMETER 4 LSB
00-7F
VARIATION PARAMETER 5 MSB
VARIATION PARAMETER 5 LSB
00-7F
VARIATION PARAMETER 6 MSB
VARIATION PARAMETER 6 LSB
00-7F
VARIATION PARAMETER 7 MSB
VARIATION PARAMETER 7 LSB
00-7F
VARIATION PARAMETER 8 MSB
00-7F
VARIATION PARAMETER 8 LSB
VARIATION PARAMETER 9 MSB
VARIATION PARAMETER 9 LSB
00-7F
VARIATION PARAMETER 10 MSB
VARIATION PARAMETER 10 LSB
00-7F
CHORUS
DEPTH
DEPTH
DEPTH
DEPTH
DEPTH
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
-∞dB...0dB...+6dB(0...64...127)
-∞dB...0dB...+6dB(0...64...127)
-∞dB...0dB...+6dB(0...64...127)
Reception: Part1...16(0...15)
Transmission: Part1...16(0...15)
AD(64)
OFF(127)
-64...0...+63 40 O O O O O X
-64...0...+63 40 O O O O O X
-64...0...+63 40 O O O O O X
-64...0...+63 40 O O O O O X
-64...0...+63 40 O O O O O X
Chorus Type
Chorus Type
Chorus Type
Chorus Type
Chorus Type
Chorus Type
05(=DELAY
L,C,R)
00
Depends on
Variation Type
Depends on
Variation Type
Depends on
Variation Type
Depends on
Variation Type
Depends on
Variation Type
Depends on
Variation Type
Depends on
Variation Type
Depends on
Variation Type
Depends on
Variation Type
Depends on
Variation Type
40 O O OO O
00 O O O O O X
00 O O O O O X
7F O O OO O
OO
OO
OO
OO
OO
OO
[MIDI] [Internal sequencer]
Song
Right1/
Drum/
Natural/
Organ Voice
OO
OO OO O
OO OO O
OO OO O
OO OO O
OO OO O
OO OO O
OO OO O
OO OO O
OO OO O
OO OO O
Keyboard Style Extra
Right2/
Left
Right1/
Right2/
Left
OO O
OO O
OO O
OO O
OO O
OO O
M.Pad
Style Song
Upper
PLAY REW From panel
Lower
OO O
OO O
(Right1/
Right2/
Left)
PSR-A3000 Data List
74
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
02 01 70 1 00-7F VARIATION PARAMETER 11 Refer to Effect Parameter List Depends on
71 1 00-7F VARIATION PARAMETER 12 Refer to Effect Parameter List Depends on
72 1 00-7F VARIATION PARAMETER 13 Refer to Effect Parameter List Depends on
73 1 00-7F VARIATION PARAMETER 14 Refer to Effect Parameter List Depends on
74 1 00-7F VARIATION PARAMETER 15 Refer to Effect Parameter List Depends on
75 1 00-7F VARIATION PARAMETER 16 Refer to Effect Parameter List Depends on
TOTAL SIZE 06
Variation Type
Variation Type
Variation Type
Variation Type
Variation Type
Variation Type
OO OO O
OO
OO
OO
OO
OO
OO O
OO O
OO O
OO O
OO O
: Transmitted via panel operations O : Available
MIDI Parameter Change table (MULTI EQ)
Address Size Data Parameter Description Voice MIDI Reception MIDI Transmission PLAY REC
(H) (H) (H)
02 40 00 1 00-04 EQ TYPE flat, jazz, pops, rock, classic O O O O X X
01 1 34-4C EQ GAIN1 -12...0...+12[dB] O O
02 1 04-28 EQ FREQUENCY1 32...2.0k[Hz] O O
03 1 01-78 EQ Q1 0.1...12.0 O O O O X X
04 1 00-01 EQ SHAPE1 shelving, peaking O O O O X X
05 1 34-4C EQ GAIN2 -12...0...+12[dB] O O
06 1 0E-36 EQ FREQUENCY2 100...10.0k[Hz] O O
07 1 01-78 EQ Q2 0.1...12.0 O O
08 1 NOT USED -- ----
09 1 34-4C EQ GAIN3 -12...0...+12[dB] O O
0A 1 0E-36 EQ FREQUENCY3 100...10.0k[Hz] O O
0B 1 01-78 EQ Q3 0.1...12.0 O O
0C 1 NOT USED -- ----
0D 1 34-4C EQ GAIN4 -12...0...+12[dB] O O
0E 1 0E-36 EQ FREQUENCY4 100...10.0k[Hz] O O
0F 1 01-78 EQ Q4 0.1...12.0 O O
10 1 NOT USED -- ----
11 1 34-4C EQ GAIN5 -12...0...+12[dB] O O
12 1 1C-3A EQ FREQUENCY5 0.5k...16.0k[Hz] O O
13 1 01-78 EQ Q5 0.1...12.0 O O O O X X
14 1 00-01 EQ SHAPE5 shelving, peaking O O O O X X
TOTAL SIZE 15
* The MULTI EQ Parameter cannot be reset to
its factory setting with XG SYSTEM ON.
: Transmitted via panel operations O : Available
[MIDI] [Internal sequencer]
Song
Right1/
Regular/
Drum/
Natural/
Organ Voice
Keyboard Style Extra
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
Upper
PLAY REW From panel
Lower
(Right1/
Right2/
Left)
20 1 34 - 4C EQ GAIN6 -12 - +12[dB] O O
21 1 0E - 36 EQ FREQUENCY6 100-10.0[kHz] O O
22 1 01 - 78 EQ Q6 0.1-12.0 O O
23 1 NOT USED O O O O X X
24 1 34 - 4C EQ GAIN7 -12 - +12[dB] O O
25 1 0E - 36 EQ FREQUENCY7 100-10.0[kHz] O O
26 1 01 - 78 EQ Q7 0.1-12.0 O O
27 1 NOT USED -- ----
28 1 34 - 4C EQ GAIN8 -12 - +12[dB] O O
29 1 0E - 36 EQ FREQUENCY8 100-10.0[kHz] O O
2A 1 01 - 78 EQ Q8 0.1-12.0 O O O O X X
2B 1 NOT USED -- ----
2C 1 34 - 4C EQ GAIN9 -12 - +12[dB] O O
2D 1 0E - 36 EQ FREQUENCY9 100-10.0[kHz] O O
2E 1 01 - 78 EQ Q9 0.1-12.0 O O
2F 1 NOT USED -- ----
30 1 34 - 4C EQ GAIN10 -12 - +12[dB] O O
31 1 0 E - 36 EQ FREQUENCY10 100-10.0[kHz] O O
32 1 01 - 78 EQ Q10 0.1-12.0 O O
33 1 NOT USED O O O O X X
TOTAL SIZE 14
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
OX X
: Transmitted via panel operations O : Available
MIDI Parameter Change table (EFFECT2)
[MIDI] [Internal sequencer]
Address Size Data Parameter Description Voice MIDI Reception MIDI Transmission PLAY REC
(H) (H) (H)
03 n 00 2 00-7F
02 1 00-7F INSERTION EFFECT
03 1 00-7F INSERTION EFFECT
04 1 00-7F INSERTION EFFECT
05 1 00-7F INSERTION EFFECT
06 1 00-7F INSERTION EFFECT
INSERTION EFFECT TYPE MSB
00-7F
INSERTION EFFECT TYPE LSB
PARAMETER 1
PARAMETER 2
PARAMETER 3
PARAMETER 4
PARAMETER 5
* The EFFECT2 Parameter cannot be reset to
its factory setting with XG SYSTEM ON.
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Song
Regular/
Drum/
Natural/
Organ Voice
OO
Right1/
Keyboard Style Extra
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
Upper
PLAY REW From panel
Lower
OO O
OO O
OO O
OO O
OO O
OO O
(Right1/
Right2/
Left)
PSR-A3000 Data List
75
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
[MIDI] [Internal sequencer]
Address Size Data Parameter Description Voice MIDI Reception MIDI Transmission PLAY REC
(H) (H) (H)
07 1 00-7F INSERTION EFFECT
08 1 00-7F INSERTION EFFECT
09 1 00-7F INSERTION EFFECT
0A 1 00-7F INSERTION EFFECT
0B 1 00-7F INSERTION EFFECT
0C 1 00-7F INSERTION EFFECT PART
0D 1 00-7F MW INSERTION CONTROL
0E 1 00-7F BEND INSERTION CONTROL
0F 1 00-7F CAT INSERTION CONTROL
10 1 00-7F AC1 INSERTION CONTROL
11 1 00-7F AC2 INSERTION CONTROL
TOTAL SIZE 12
20 1 00-7F INSERTION EFFECT
21 1 00-7F INSERTION EFFECT
22 1 00-7F INSERTION EFFECT
23 1 00-7F INSERTION EFFECT
24 1 00-7F INSERTION EFFECT
25 1 00-7F INSERTION EFFECT
TOTAL SIZE 6
PARAMETER 6
PARAMETER 7
PARAMETER 8
PARAMETER 9
PARAMETER 10
NUMBER
DEPTH
DEPTH
DEPTH
DEPTH
DEPTH
PARAMETER 11
PARAMETER 12
PARAMETER 13
PARAMETER 14
PARAMETER 15
PARAMETER 16
* The EFFECT2 Parameter cannot be reset to
its factory setting with XG SYSTEM ON.
Refer to Effect Parameter List O O OO O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Reception: Part1...16(0...15)
Transmission: Part1...16(0...15)
AD(64)
OFF(127)
-64...0...+63 O O O O O X
-64...0...+63 O O O O O X
-64...0...+63 O O O O O X
-64...0...+63 O O O O O X
-64...0...+63 O O O O O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Refer to Effect Parameter List O O
Regular/
Drum/
Natural/
Organ Voice
OO OO O
Song
Right1/
Keyboard Style Extra
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
Upper
PLAY REW From panel
Lower
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
(Right1/
Right2/
Left)
30 2 00-7F
32 2 00-7F
34 2 00-7F
36 2 00-7F
38 2 00-7F
3A 2 00-7F
3C 2 00-7F
3E 2 00-7F
40 2 00-7F
42 2 00-7F
TOTAL SIZE 14
00-7F
00-7F
00-7F
00-7F
00-7F
00-7F
00-7F
00-7F
00-7F
00-7F
INSERTION EFFECT
PARAMETER 1 MSB
INSERTION EFFECT
PARAMETER 1 LSB
INSERTION EFFECT
PARAMETER 2 MSB
INSERTION EFFECT
PARAMETER 2 LSB
INSERTION EFFECT
PARAMETER 3 MSB
INSERTION EFFECT
PARAMETER 3 LSB
INSERTION EFFECT
PARAMETER 4 MSB
INSERTION EFFECT
PARAMETER 4 LSB
INSERTION EFFECT
PARAMETER 5 MSB
INSERTION EFFECT
PARAMETER 5 LSB
INSERTION EFFECT
PARAMETER 6 MSB
INSERTION EFFECT
PARAMETER 6 LSB
INSERTION EFFECT
PARAMETER 7 MSB
INSERTION EFFECT
PARAMETER 7 LSB
INSERTION EFFECT
PARAMETER 8 MSB
INSERTION EFFECT
PARAMETER 8 LSB
INSERTION EFFECT
PARAMETER 9 MSB
INSERTION EFFECT
PARAMETER 9 LSB
INSERTION EFFECT
PARAMETER 10 MSB
INSERTION EFFECT
PARAMETER 10 LSB
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
Refer to Effect Parameter List
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
OO O
: Transmitted via panel operations O : Available
The second byte of the address is considered as an Insertion effect number.
n : insertion effect number (n = 0–2)
For effect types that do not require MSB, the Parameters for Address 02-0B will be received and the Parameters for Address 30-42 will not be received.
For effect types that require MSB, the Parameters for Address 30-42 will be received and the Parameters for Address 02-0B will not be received.
Type MSB of the effect types that require Parameter MSB are: 5, 6, 7, 8, 95, 96, 97, 98, 104.
When Bulk Dumps that include Effect Type data are transmitted, the Parameters for Address 02-0B will always be transmitted. But, effects that require MSB, when the bulk dump is received the
Parameters for Address 02-0B will not be received.
PSR-A3000 Data List
76
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
MIDI Parameter Change table (MULTI PART)
Address Size Data Parameter Description XG Default Voice MIDI Reception MIDI Transmission PLAY REC
(H) (H) (H) (H) Regular/
08 nn 00 1 00-20 ELEMENT RESERVE 0...32 part10,2 6=0,
01 1 00-7F BANK SELECT MSB 0...127 part10=7F,
02 1 00-7F BANK SELECT LSB 0...127 00 O O O X O O X X X O X O O X
03 1 00-7F PROGRAM NUMBER 1...128 00 O O O X O O X X X O X O O X
04 1 00-0F,7FRcv CHANNEL 1...1 6, OFF Part No. O O X X X X X X X O X O X X
05 1 00-01 MONO/POLY MODE MONO, POLY 01 O O X X X X X X X O X O X X
06 1 00-02 SAME NOTE NUMBER KEY
07 1 00-03 PART MODE NORMAL, DRUM,
08 1 28-58 NOTE SHIFT -24...0...+24[semitones] 40 O O O X O O X X X O X O O X
090A2 00-0F
0B 1 00-7F VOLUME 0...127 64 O O O X O O X X X O X O O X
0C 1 00-7F VELOCITY SENSE DEPTH 0.. .127 40 O O O X X O
0D 1 00-7F VEL OCITY SENSE OFFSET 0...127 40 O O O X X O
0E 1 00 -7F PAN RND,L63...C.. .R63 40 O O O X O O X X X O X O O X
0F 1 00-7F NOTE LIMIT LOW C-2...G8 00 O O X X X X X X X O X O X X
10 1 00-7F NOTE LIMIT HIGH C-2...G8 7F O O X X X X X X X O X O X X
11 1 00-7F DRY LEVEL 0...127 7F O O O X O O X O O O X O O O
12 1 00-7F CHORUS SEND 0...127 00 O O O X O O X X X O X O O X
13 1 00-7F REVERB SEND 0...127 28 O O O X O O X X X O X O O X
14 1 00-7F VARIATION SEND 0...127 00 O O O X O O X X X O X O O O
15 1 00-7F VIBRATO RATE -64...0...+63 40 O O O X O O X X X O X O O X
16 1 00-7F VIBRATO DEPTH -64...0...+63 40 O O O X O O X X X O X O O X
17 1 00-7F VIBRATO DELAY -64...0...+63 40 O O O X O O X X X O X O O X
18 1 00-7F
19 1 00-7F FILTER RESONANCE -64...0...+63 40 O O O X O O X X X O X O O X
1A 1 00-7F EG ATTACK TIME -64...0...+63 40 O O O X O O X X X O X O O X
1B 1 00-7F EG DECAY TIME -64...0...+63 40 O O O X O O X X X O X O O X
1C 1 00-7F EG RELEASE TIME -64...0...+63 40 O O O X O O X X X O X O O X
1D 1 28-58 MW PITCH CONTROL -24...0...+24[semitones] 40 O O O X X O X X X O X O X X
1E 1 00-7F MW LOW PASS FILTER
1F 1 00-7F MW AMPLIT UDE CONTROL -100...0...+1 00[%] 40 O O O X X O X X X O X O X X
20 1 00-7F MW LFO PMOD DEPTH 0...127 0A O O O X X O
21 1 00-7F MW LFO FMOD DEPTH 0...127 00 O O O X X O
22 1 00-7F MW LFO AMOD DEPTH 0...127 00 O O O X X O
23 1 28-58 BEND PITCH CONTROL -24...0...+24[semitones] 42 O O O X O O X X X O X O X X
24 1 00-7F BEND LOW PASS FILTER
25 1 00-7F
26 1 00-7F BEND LFO PMOD DEPTH 0...127 00 O O O X O O X X X O X O X X
27 1 00-7F BEND LFO FMOD DEPTH 0...127 00 O O O X O O X X X O X O X X
28 1 00-7F BEND LFO AMOD DEPTH 0...127 00 O O O X O O X X X O X O X X
TOTAL SIZE 29
ON ASSIGN
DETUNE -12. 8...0...+12.7[Hz]
00-0F
FILTER CUTOFF FREQUENCY
CONTROL
CONTROL
BEND AMPLITUDE CONTROL
SINGLE, MULTI, INST(for
Drum)
DRUMS1...2
1st bit3-0 bit7-4
2nd bit3-0 bit3-0
-64...0...+63 40 O O O X O O X X X O X O O X
-9600...0...+9450[cent ] 40 O O O X X O
-9600...0...+9450[cent ] 40 O O O X O O X X X O X O X X
-100...0...+100[%] 40 O O O X O O X X X O X O X X
other parts=2
other parts=00
01 O O X X O X X X X O X O X X
part10=02,
other parts=00
08 00 O O O X O O X X X O X O X X
[MIDI] [Internal sequencer]
Song
Right1/
Keyboard Style Extra
Drum/
Natural/
Organ Voice
--------------
OOOXOOXXXOXOOX
OOXXXX X XOX O
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
Upper
PLAY REW From panel
Lower
OXOXOO O
OXOXOO O
OXOXOO O
OOOXOO O
OOOXOO O
OOOXOO O
(Right1/
Right2/
Left)
30 1 00-01 Rcv PITCH BEND OFF, ON 01 O O X X X X X X X O X O X X
31 1 00-01 Rcv CH AFTER TOUCH(CAT) OFF, ON 01 O O X X X X X X X O X O X X
32 1 00-01 Rcv PROGRAM CHANGE OFF, ON 01 O O X X X X X X X O X O X X
33 1 00-01 Rcv CONTROL CHANGE OFF, ON 01 O O X X X X X X X O X O X X
34 1 00-01 Rcv POLY AFTER
35 1 00-01 Rcv NOTE MESSAGE OFF, ON 01 O O X X X X X X X O X O X X
36 1 00-01 Rcv RPN OFF, ON 01 O O X X X X X X X O X O X X
37 1 00-01 Rcv NRPN OFF, ON XGmode=01,
38 1 00-01 Rcv MODULATION OFF, ON 01 O O X X X X X X X O X O X X
39 1 00-01 Rcv VOLUME OFF, ON 01 O O X X X X X X X O X O X X
3A 1 00-01 Rcv PAN OFF, ON 01 O O X X X X X X X O X O X X
3B 1 00-01 Rcv EXPRESSION OFF, ON 01 O O X X X X X X X O X O X X
3C 1 00-01 Rcv HOLD1 OFF, ON 01 O O X X X X X X X O X O X X
3D 1 00-01 Rcv PORTAMENTO OFF, ON 01 O O X X X X X X X O X O X X
3E 1 00-01 Rcv SOSTENUTO OFF, ON 01 O O X X X X X X X O X O X X
3F 1 00-01 Rcv SOFT PEDAL OFF, ON 01 O O X X X X X X X O X O X X
40 1 00-01 Rcv BANK SELECT OFF, ON 01 O O X X X X X X X O X O X X
41 1 00-7F SCALE TUNING C -64...0...+63[cent] 40 O O O X O O
42 1 00-7F SCALE TUNING C# -64...0...+63[cent] 40 O O O X O O
43 1 00-7F SCALE TUNING D -64...0...+63[cent] 40 O O O X O O
44 1 00-7F SCALE TUNING D# -64...0...+63[cent] 40 O O O X O O
45 1 00-7F SCALE TUNING E -64...0...+63[cent] 40 O O O X O O
46 1 00-7F SCALE TUNING F -64...0...+63[cent] 40 O O O X O O
47 1 00-7F SCALE TUNING F# -64...0...+63[cent] 40 O O O X O O
48 1 00-7F SCALE TUNING G -64...0...+63[cent] 40 O O O X O O
49 1 00-7F SCALE TUNING G# -64...0...+63[cent] 40 O O O X O O
4A 1 00-7F SCALE TUNING A -64...0...+63[cent] 40 O O O X O O
4B 1 00-7F SCALE TUNING A# -64...0...+63[cent] 40 O O O X O O
4C 1 00-7F SCALE TUNING B -64...0...+63[cent] 40 O O O X O O
4D 1 28-58 CAT PITCH CONTROL -24...0...+24[semitones] 40 O O O X X O X X X O X O X X
TOUCH(PAT)
OFF, ON 01 O O X X X X X X X O X O X X
GMmode=00
OOXXXXXXXOXOXX
OXOO O
OXOO O
OXOO O
OXOO O
OXOO O
OXOO O
OXOO O
OXOO O
OXOO O
OXOO O
OXOO O
OXOO O
PSR-A3000 Data List
77
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
4E 1 00-7F CAT LOW PASS FILTER
4F 1 00-7F CAT AMPLITUDE CONTROL -100...0...+100[%] 40 O O O X X O X X X O X O X X
50 1 00-7F CAT LFO PMOD DEPTH 0...127 00 O O O X X O X O X O X O O X
51 1 00-7F CAT LFO FMOD DEPTH 0...127 00 O O O X X O X O X O X O O X
52 1 00-7F CAT LFO AMOD DEPTH 0...127 00 O O O X X O X O X O X O O X
53 1 28-58 PAT PITCH CONTROL -24...0...+24[semitones] 40 O O X X X X X X X O X O X X
54 1 00-7F PAT LOW PASS FILTER
55 1 00-7F PAT AMPLITUDE CONTROL -100...0...+100[%] 40 O O X X X X X X X O X O X X
56 1 00-7F PAT LFO PMOD DEPTH 0...127 00 O O X X X X X X X O X O X X
57 1 00-7F PAT LFO FMOD DEPTH 0...127 00 O O X X X X X X X O X O X X
58 1 00-7F PAT LFO AMOD DEPTH 0...127 00 O O X X X X X X X O X O X X
59 1 00-5F AC1 CONTROLLER NUMBER 0...95 10 O O X X X X X X X O X O X X
5A 1 28-58 AC1 PITCH CONTROL -24...0...+24[semitones] 40 O O O X X O X X X O X O X X
5B 1 00-7F AC1 LOW PASS FILTER
5C 1 00-7F AC1 AMPLITUDE CONTROL -100...0...+100[%] 40 O O O X X O X X X O X O X X
5D 1 00-7F AC1 LFO PMOD DEPTH 0...127 00 O O O X X O
5E 1 00-7F AC1 LFO FMOD DEPTH 0...127 00 O O O X X O
5F 1 00-7F AC1 LFO AMOD DEPTH 0...127 00 O O O X X O
60 1 00-5F AC2 CONTROLLER NUMBER 0...95 11 O O O X X X X X X O X O O O
61 1 28-58 AC2 PITCH CONTROL -24...0...+24[semitones] 40 O O X X X X X X X O X O X X
62 1 00-7F AC2 LOW PASS FILTER
63 1 00-7F AC2 AMPLITUDE CONTROL -100...0...+100[%] 40 O O X X X X X X X O X O X X
64 1 00-7F AC2 LFO PMOD DEPTH 0...127 00 O O X X X X X X X O X O X X
65 1 00-7F AC2 LFO FMOD DEPTH 0...127 00 O O X X X X X X X O X O X X
66 1 00-7F AC2 LFO AMOD DEPTH 0...127 00 O O X X X X X X X O X O X X
67 1 00-01 PORTAMENTO SWITCH OFF, ON 00 O
68 1 00-7F PORTAMENTO TIME 0...127 00 O O O X X O X X X O X O O X
69 1 00-7F PITCH EG INITIAL LEVEL -64...0...+63 40 O O O X X O X X X O X O X X
6A 1 00-7F PITCH EG ATTACK TIME -64...0... +63 40 O O O X X O X X X O X O X X
6B 1 00-7F PITCH EG RELEASE LEVEL -64...0...+63 40 O O O X X O X X X O X O X X
6C 1 00-7F PITCH EG RELEASE TIME -64...0...+63 40 O O O X X O X X X O X O X X
6D 1 01-7F VELOCITY LIMIT LOW 1...127 01 O O O X X O X X X O X O X X
6E 1 01-7F VELOCITY LIMIT HIGH 1...127 7F O O O X X O X X X O X O X X
TOTAL SIZE 3F
701 NOT USED - - -- - --------- -
711 NOT USED - - -- - --------- -
72 1 00-7F EQ BASS GAIN -12dB...+12dB 40 O O O X O O
73 1 00-7F EQ TREBLE GAIN -12dB...+12dB 40 O O O X O O
TOTAL SIZE 04
CONTROL
CONTROL
CONTROL
CONTROL
-9600...0...+9450[cent ] 40 O O O X X O X O X O X O O X
-9600...0...+9450[cent ] 40 O O X X X X X X X O X O X X
-9600...0...+9450[cent ] 40 O O O X X O
OXOXOO O
OXOXOO O
OXOXOO O
OXOXOO O
-9600...0...+9450[cent ] 40 O O X X X X X X X O X O X X
OO X XO X XXOXOO X
(Except
SA Piano,
Organ
Flutes)
XOO O
XOO O
741 NOT USED - - -- - --------- -
751 NOT USED - - -- - --------- -
76 1 04-28 EQ BASS FREQUENCY 32...2.0k[Hz] 0C O O O X O O
77 1 1C-3A EQ TREBLE FREQUENCY 500...16.0k[Hz] 36 O O O X O O
781 NOT USED - - -- - --------- -
791 NOT USED - - -- - --------- -
7A1 NOT USED - - -- - --------- -
7B1 NOT USED - - -- - --------- -
7C1 NOT USED - - -- - --------- -
7D1 NOT USED - - -- - --------- -
7E1 NOT USED - - -- - --------- -
7F1 NOT USED - - -- - --------- -
TOTAL SIZE 0C
OOOXOO O
OOOXOO O
: Transmitted via panel operations O : Available
0A nn 00 1 NOT USED - - - - - - - - - - - - - - -
01 1 00-01 Mono Priority Lastest, Highest 00 O
02 1 00-01 Portamento Mono Legato Normal, Pitch Poly 00 O
TOTAL SIZE 03
40 1 00-7F MW OFFSET LEVEL CONTROL -100 - 100[%] 40 O O O X X O
41 1 00-7F
42 1 00-7F
43 1 00-7F PAT OFFSET LEVEL CONTROL -100 - 100[%] 40 O O X X X X X X X O X O O X
44 1 00-7F
45 1 00-7F AC2 OFFSET LEVEL
TOTAL SIZE 06
: Transmitted via panel operations
BEND OFFSET LEVEL CONTROL
CAT OFFSET LEVEL CONTROL
AC1 OFFSET LEVEL CONTROL
CONTROL
O : Available
-100 - 100[%] 40 O O X X X X X X X O X O O X
-100 - 100[%] 40 O O O X X O X O X O X O O X
-100 - 100[%] 40 O O O X X O OXOXOO O
-100 - 100[%] 40 O O X X X X X X X O X O O X
OX X XXXXXOXOO O
(Regular
only)
OX X XXXXXOXOO O
(Regular
only)
OXOXOO O
nn = PART NUMBER
If there is a Drum Voice assigned to the part, the following parameters are ineffective.
• BANK SELECT LSB
• PORTAMENTO
• MONO/POLY
• SCALE TUNING
• POLY AFTER TOUCH
• PITCH EG
PSR-A3000 Data List
78
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
MIDI Parameter Change table (DRUM SETUP)
Address Size Data Parameter Description XG Default Voice MIDI Reception MIDI Transmission PLAY REC
(H) (H) (H) (H) Regular/
3n rr 00 1 00-7F PITCH COARSE -64...0...+63 40
01 1 00-7F PITCH FINE -64...0...+63[cent] 40
02 1 00-7F LEVEL 0...127 Depends on
03 1 00-7F ALTERNATE GROUP OFF, 1...127 Depends on
04 1 00-7F PAN RND, L63...C...R63 Depends on
05 1 00-7F REVERB SEND 0...127 Depends on
06 1 00-7F CHORUS SEND 0...127 Depends on
07 1 00-7F VARIATION SEND 0...127 7F
08 1 00-01 KEY ASSIGN SINGLE, MULTI 00
09 1 00-01 Rcv NOTE OFF OFF, ON Depends on
0A 1 00-01 Rcv NOTE ON OFF, ON 01
0B 1 00-7F LOW PASS FILTER CUTOFF
0C 1 00-7F LOW PASS FILTER
0D 1 00-7F EG ATTACK RATE -64...0...+63 40
0E 1 00-7F EG DECAY1 RATE -64...0...+63 40
0F 1 00-7F EG DECAY2 RATE -64...0...+63 40
TOTAL SIZE 10
FREQUENCY
RESONANCE
-64...0...+63 40
-64...0...+63 40
the note
the note
the note
the note
the note
the note
[MIDI] [Internal sequencer]
Song
Right1/
Keyboard Style Extra
Drum/
Natural/
Organ Voice
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
OOXX
Upper
PLAY REW From panel
Lower
(Right1/
Right2/
Left)
20 1 00-7F EQ BASS GAIN -12...+12[dB] 40 X X O X X X
21 1 00-7F EQ TREBLE GAIN -12...+12[dB] 40 X X O X X X
22 1 NOT USED - - - - - - -
23 1 NOT USED - - - - - - -
24 1 04-28 EQ BASS FREQUENCY 32...2.0k[Hz] 0C X X O X X X
25 1 1C-3A EQ TREBLE FREQUENCY 500...16.0k[Hz] 36 X X O X X X
26 1 NOT USED - - - - - - -
27 1 NOT USED - - - - - - -
28 1 NOT USED - - - - - - -
29 1 NOT USED - - - - - - -
2A 1 NOT USED - - - - - - -
2B 1 NOT USED - - - - - - -
2C 1 NOT USED - - - - - - -
2D 1 NOT USED - - - - - - -
TOTAL SIZE 0E
70 4 00-7F SOURCE DRUM KIT
TOTAL SIZE 04
n: Drum Setup Number (0-1)
rr: note number(0D-5B)
In the following cases, the instrument will initialize all Drum Setups.
• XG SYSTEM ON received
• GM SYSTEM ON received
• GM LEVEL2 SYSTEM ON received
• GS RESET received
• DRUM SETUP RESET received (only when in XG mode)
[Note]
When a part to which a Drum Setup is assigned receives a program change, the assigned Drum Setup will be initialized.
(Bank Select MSB)
00-7F SOURC E DRUM KIT
(Bank Select LSB)
00-7F SOURC E DRUM KIT
(Program Number)
0D-5B SOURCE DRUM KIT
(Note Number)
0...127 Depends on
0...127 Depends on
0...127 Depends on
C-1...G5 Depends on
the note
the note
the note
the note
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
O
(Drum Only)O(Available only for song parts)
OOXX
OOXX
OOXX
OOXX
If the same Drum Setup is assigned to two or more parts, changes in Drum Setup parameters (including program changes) will apply to all par ts to which it is assigned.
PSR-A3000 Data List
79
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
System Exclusive Messages (1)
[GM1]...GM Required Parameter
[GM2]...GM Level2 Required Parameter
• Not received when Receive System Exclusive Message Parameters is set to off.
• Not transmitted when Transmit System Exclusive Message Parameters is set to off.
System Exclusive Messages (Universal Real Time Messages)
MIDI Event Data Format Voice MIDI Reception MIDI Transmission PLAY REC
Master
Volu me
[GM2]
Master Fine
Tun in g
[GM2]
Master
Coarse
Tun in g
[GM2]
Reverb
Parameter
[GM2]
Chorus
Parameter
[GM2]
F0 7F XN 04 01 SS TT F7 OO
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00000100 04 = Sub-ID #1=Device Cont rol Message
00000001 01 = Sub-ID #2=Master Volume
0sssssss SS = Volume LSB
0ttttttt TT = Volume MSB
11110111 F7 = End of Exclusive
F0 7F XN 04 03 SS TT F7 OO
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00000100 04 = Sub-ID #1=Device Cont rol Message
00000011 03 = Sub-ID #2=Master Fine Tuning
0sssssss SS = Fine Tuning LSB
0ttttttt TT = Fine Tuning MSB
11110111 F7 = End of Exclusive
F0 7F XN 04 04 00 TT F7 OO
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00000100 04 = Sub-ID #1=Device Cont rol Message
00000100 04 = Sub-ID #2=Master Coarse Tuning
00000000 00
0ttttttt TT = Coarse Tuning MSB
11110111 F7 = End of Exclusive
F0 7F XN 04 05 01 01 01 01 01 PP VV ... F7 OO OOOX
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00000100 04 = Sub-ID #1=Device Cont rol Message
00000101 05 = Sub-ID #2=Global Parameter Control
00000001 01 = Slot path length = 1
00000001 01 = Parameter ID width = 1
00000001 01 = Value width = 1
00000001 01 = Slot path MSB = 1
00000001 01 = Slot path LSB = 1 (Reverb)
0ppppppp PP = Parameter to be controlled.
0vvvvvvv VV = Value for the Parameter.
: :
11110111 F7 = End of Exclusive
Parameter(pp) Value(vv) Display
---------------------------------------------------------------------------------------pp=0 Reverb Type0...8 0:RoomS
pp=1 Reverb Tim e0...127 0...11.0s
F0 7F XN 04 05 01 01 01 01 02 PP VV ... F7 OO OOOX
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00000100 04 = Sub-ID #1=Device Cont rol Message
00000101 05 = Sub-ID #2=Global Parameter Control
00000001 01 = Slot path length = 1
00000001 01 = Parameter ID width = 1
00000001 01 = Value width = 1
00000001 01 = Slot path MSB = 1
00000010 02 = Slot path LSB = 2 (C horus)
0ppppppp PP = Parameter to be controlled.
0vvvvvvv VV = Value for the Parameter.
: :
11110111 F7 = End of Exclusive
Parameter(pp) Value(vv) Display
---------------------------------------------------------------------------------------pp=0 Chorus Type0...5 0:GM Chorus1
pp=1 Mod Rate 0...127 0...15.5Hz
pp=2 Mod Depth 0...127
pp=3 Feedback 0...127
pp=4 Send to Reverb 0...127
1:RoomM
2:RoomL
3:HallM
4:HallL(default)
8:GM Plate
1:GM Chorus2
2:GM Chorus3(default)
3:GM Chorus4
4:FB Chorus
5:GM Flanger
[MIDI] [Internal sequencer]
Song
Right1/
Regular/
Drum/
Natural/
Organ Voice
(Available for extra parts and Song)
(Available for extra parts and Song)
(Available for extra parts and Song)
Keyboard Style Extra
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
OOOX
OOXX
OOXX
Upper
PLAY REW From panel
Lower
(Right1/
Right2/
Left)
PSR-A3000 Data List
80
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
[MIDI] [Internal sequencer]
MIDI Event Data Format Voice MIDI Reception MIDI Transmission PLAY REC
Song
Channel
Pressure
(Aftertouch)
[GM2]
Controller
(Control
Change)
[GM2]
Key-Based
Instrument
Control
[GM2]
Regular/
Drum/
Natural/
F0 7F XN 09 01 0M PP RR ... F7 OOXXXXXXXOXOXX
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00001001 09 = Sub-ID #1=Controller Destination Setting
00000001 01 = Sub-ID #2=Controller Type:01(Channel Pressure)
0000mmmm 0M = MIDI Channel (00-0F)
0ppppppp PP = Controlled Parameter
0rrrrrrr RR = Data
: :
11110111 F7 = End of Exclusive
Make sure to set both the controlled p arameter and the range.
Parameters not set will be restored to their default values.
Control Parameter(pp) Data(RR) Description Default Value
---------------------------------------------------------------------------------------------------------------------pp=00 Pitch Control 28H–58H -24...0...+24semitones 40H
pp=01 Filter Cutoff Control 00H–7FH -9600...0...+9450cents 40H
pp=02 Amplitude Control 00H–7FH -100...0...+100% 40H
pp=03 LFO Pitch Depth 00H–7FH 0...127 00H
pp=04 LFO Filter Depth 00H–7FH 0...127 00H
pp=05 LFO Amplitude Depth 00H–7FH 0...127 00H
F0 7F XN 09 03 0M CC PP RR ... F7 OOXXXXXXXOXOXX
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00001001 09 = Sub-ID #1=Controller Destination Setting
00000011 03 = Sub-ID #2=Controller Type:03(Control Change)
0000mmmm 0M = MIDI Channel (00-0F)
0ccccccc CC = Controller Number (01H-1FH, 40H-5FH)
0ppppppp PP = Controlled Parameter
0rrrrrrr RR = Range
: :
11110111 F7 = End of Exclusive
Make sure to set both the controlled p arameter and the range.
Parameters not set will be restored to their default values.
Control Parameter(pp) Data(RR) Description Default Value
---------------------------------------------------------------------------------------------------------------------pp=00 Pitch Control 28H–58H -24...0...+24semitones 40H
pp=01 Filter Cutoff Control 00H–7FH -9600...0...+9450cents 40H
pp=02 Amplitude Control 00H–7FH -100...0...+100% 40H
pp=03 LFO Pitch Depth 00H–7FH 0...127 00H
pp=04 LFO Filter Depth 00H–7FH 0...127 00H
pp=05 LFO Amplitude Depth 00H–7FH 0...127 00H
F0 7F XN 0A 01 0M KK CC VV ... F7
11110000 F0 = Exclusive status
01111111 7F = Universal Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00001010 0A = Sub-ID #1=Key-Based Instrument Control
00000001 01 = Sub-ID #2=Controller
0000mmmm 0M = MIDI Channel (00-0F)
0kkkkkkk KK = Key Number
0ccccccc CC = Con troller Number
0vvvvvvv VV = Value
: :
11110111 F7 = End of Exclusive
Make sure to set both the controll ed number and the value.
Control Number(CC) Value(VV) Description Default Value
---------------------------------------------------------------------------------------------------------------------CC=07H Volume 00H–7FH -100...0...+100% 40H
CC=0AH Pan 00H–7FH L63...C...R63 (Preset value)
CC=5BH Reverb Send Level 00H–7FH 0...Max (Preset value)
CC=5DH Chorus Send Level 00H–7FH 0...Max (Preset value)
(absolute)
(absolute)
(absolute)
Organ Voice
O
(Drum Only)
Right1/
Keyboard Style Extra
Right2/
Left
OX X XXXXXOXOX X
Right1/
Right2/
Left
M.Pad
Style Song
Upper
PLAY REW From panel
Lower
(Right1/
Right2/
Left)
PSR-A3000 Data List
81
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
System Exclusive Messages (Universal Non-Real Time Messages)
MIDI Event Data Format Voice MIDI Reception MIDI Transmission PLAY REC
GM1 System
On
[GM1][GM2]
GM2 System
On
[GM2]
General
MIDI System
Off
[GM1][GM2]
Scale/
Octave
Tun in g
[GM2]
F0 7E XN 09 01 F7 OO
11110000 F0 = Exclusive status
01111110 7E = Universal Non-Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00001001 09 = Sub-ID #1=General M IDI Message
00000001 01 = Sub-ID #2=General M IDI On
11110111 F7 = End of Exclusive
F0 7E XN 09 03 F7 OO
11110000 F0 = Exclusive status
01111110 7E = Universal Non-Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00001001 09 = Sub-ID #1=General M IDI Message
00000011 03 = Sub-ID #2=General M IDI2 On
11110111 F7 = End of Exclusive
F0 7E XN 09 02 F7 OO
11110000 F0 = Exclusive status
01111110 7E = Universal Non-Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00001001 09 = Sub-ID #1=General M IDI Message
00000010 02 = Sub-ID #2=General M IDI Off
11110111 F7 = End of Exclusive
F0 7E XN 08 08 JJ GG MM SS ... F7 OO
11110000 F0 = Exclusive status
01111110 7E = Universal Non-Real Time
0xxxnnnn XN = When N is received N=0-F,whichever is received. X=igno red
00001000 08 = Sub-ID #1=MIDI Tuning Standard
00001000 08 = Sub-ID #2=scale/octave tuning 1byte form
0jjjjjjj JJ = Channel/option byte1
0ggggggg GG = Channel byte2 - bits0 to 6 = channel 8 to 14
0mmmmmmm MM= Channel byte2 - bits0 to 6 = channel 1 to 7
0sssssss SS = 12byte tuning offset of 12 semitones from C to B
: :
11110111 F7 = End of Exclusive
bits 0 to 1 = channel 15 to 16
bits 2 to 6 = reserved
00H means -64cent
40H means 0cent
7FH means +63cent
[MIDI] [Internal sequencer]
Song
Regular/
Drum/
Natural/
Organ Voice
(Available for extra parts and Song)
(Available for extra parts and Song)
(Available for extra parts and Song)
(Available for extra parts and Song)
Right1/
Keyboard Style Extra
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
OOXO
OOXX
OOXX
OOXX
Upper
PLAY REW From panel
Lower
(Right1/
Right2/
Left)
PSR-A3000 Data List
82
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
System Exclusive Messages (2)
• Not received when Receive System Exclusive Message Parameters is set to off.
• Not transmitted when Transmit System Exclusive Message Parameters is set to off.
System Exclusive Messages (Style)
MIDI Event Data Format Voice MIDI Reception MIDI Transmission
Section Control F0 43 7E 00 ss dd F7 -O
Tempo Control
Chord Control
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01111110 7E = Style
00000000 00 =
0sssssss ss = Switch No.
00H INTRO 1
01H INTRO 2
02H INTRO 3
03H INTRO 4
08H MAIN A
09H MAIN B
0AH M AIN C
0BH M AIN D
10H FILL IN AA
11H FILL IN BB
12H FILL IN CC
13H FILL IN DD
18H BREAK FILL
20H ENDING 1
21H ENDING 2
22H ENDING 3
23H ENDING 4
0ddddddd dd = Switch On/Off
11110111 F7 = End of Exclusive
F0 43 7E 01 t4 t3 t2 t1 F7 -O
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01111110 7E = Style
00000001 01 =
0ttttttt t4 = t empo4
0ttttttt t3 = t empo3
0ttttttt t2 = t empo2
0ttttttt t1 = t empo1
11110111
F0 43 7E tt d1 d2 d3 d4 F7 -O
Typ e1 ( tt= 02)
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01111110 7E = Style
00000010 02 = type 1
0ddddddd d1 = chord root(cr)
0ddddddd d2 = chord type(ct)
0ddddddd d3 = bass note(bn)
0ddddddd d4 = bass type(bt)
11110111 F7 = End of Exclusive
cr : Chord Root 0fffnnnn
fff: b or #, nnnn: note(root)
0000nnnn 0n bbb 0fff0000 x0 reserved
0001nnnn 1n bb 0fff0001 x1 C
0010nnnn 2n b 0fff0010 x2 D
0011nnnn 3n natural 0fff0011 x3 E
0100nnnn 4n # 0fff0100 x4 F
0101nnnn 5n ## 0fff0101 x5 G
0110nnnn 6n ### 0fff0110 x6 A
ct : Chord Type 0 - 34,127
00000000 00 0 Maj 00010010 12 18 dim7
00000001 01 1 Maj6 00010011 13 19 7th
00000010 02 2 Maj7 00010100 14 20 7sus4
00000011 03 3 Maj7(#11) 00010101 15 21 7b5
00000100 04 4 Maj(9) 00010110 16 22 7(9)
00000101 05 5 Maj7(9) 00010111 17 23 7(#11)
00000110 06 6 Maj6(9) 00011000 18 24 7(13)
00000111 07 7 aug 0001 1001 19 25 7(b9)
00001000 08 8 min 00011010 1A 26 7(b13)
00001001 09 9 min6 00011011 1B 27 7(#9)
00001010 0A 10 min7 00011100 1C 28 Maj7aug
00001011 0B 11 min7b5 00011101 1D 29 7aug
00001100
00001101 0D 13 min7(9) 00011111 1F 31 1+5
00001110 0E 14 min7(11) 0010 0000 20 32 sus4
00001111 0F 15 minMaj7 00100001 21 33 1+2+5
00010000 10 16 minMaj7(9) 00100010 22 34 cc
00010001 11 17 dim
bn : On Bass Note Same as Chord root
bt : Bass Chord Same as Chord type
* Not received when Receive Chord System Exclusive Message Parameters is set to off.
* Not transmitted when Transmit Chord System Exclusive Message Parameters is set to off.
Typ e2 ( tt= 03) -O X
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01111110 7E = Style
00000011 03 = type 2
0ddddddd dd = note1
0ddddddd dd = note2
0ddddddd dd = note3
: :
0ddddddd dd = note10
11110111 F7 = End of Exclusive
00H(Off)
7FH(On)
0fff0111 x7 B
0C 12 min(9) 0001 1110 1E 30 1+8
127:No bass chord
127:No bass chord
Regular/
Drum/
Natural/
Organ Voice
[MIDI]
Song
Right1/
Keyboard Style Extra
Right2/
Left
Right1/
Right2/
Left
M.Pad
Style Song
Upper
Lower
: Transmitted via panel operations O : Available
PSR-A3000 Data List
83
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
System Exclusive Messages (XG)
Regular/
Drum/
Natural/
Organ Voice
XG
Parameter
Change
Tab l e .
XG
Parameter
Change
Tab l e .
[MIDI]
Song
Right1/
Keyboard Style Extra
Right2/
Left
* Refer to XG Parameter Change
* Refer to XG Parameter Change
* Refer to XG Parameter Change
* Refer to XG Parameter Change
O
Tab l e.
O
Tab l e.
Tab l e.
Tab l e.
M.Pad
Right1/
Right2/
Left
* Refer to XG Parameter Change
* Refer to XG Parameter Change
* Refer to XG Parameter Change
* Refer to XG Parameter Change
Style Song
O
Tab l e.
O
Tab l e.
O
Tab l e.
O
Tab l e.
MIDI Event Data Format Voice MIDI Reception MIDI Transmission
XG Parameter Changes F0 43 1n 4C hh mm ll dd ... F7 * Refer to
XG Bulk Dump
XG Parameter Request
XG Dump Request
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0001nnnn 1n = Device Number n=always 0(when transmit), n=0-F(when recieve)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm = Address Mid
0lllllll ll = Address Low
0ddddddd dd = Data
: :
11110111 F7 = End of Exclusive
F0 43 0n 4C aa bb h h mm ll dd ... dd cc F7 * Refer to
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0000nnnn 0n = Device Number n=always 0(when transmit), n=0-F(when recieve)
01001100 4C = Model ID
0aaaaaaa aa = Byte Count MSB
0bbbbbbb bb = Byte Count LSB
0hhhhhhh hh = Address High
0mmmmmmm mm = Address Mid
0lllllll ll = Address Low
0ddddddd dd = Data
: :
0ddddddd dd = Data
0ccccccc cc = Checksum
11110111 F7 = End of Exclusive
F0 43 3n 4C hh mm ll F7 -O
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0011nnnn 3n = Device Number n=always 0(when transmit), n=0-F(when recieve)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm = Address Mid
0lllllll ll = Address Low
11110111 F7 = End of Exclusive
F0 43 2n 4C hh mm ll F7 -O
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0010nnnn 2n = Device Number n=always 0(when transmit), n=0-F(when recieve)
01001100 4C = Model ID
0hhhhhhh hh = Address High
0mmmmmmm mm = Address Mid
0lllllll ll = Address Low
11110111 F7 = End of Exclusive
Upper
Lower
PSR-A3000 Data List
84
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
System Exclusive Messages (Others)
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
01110011 73 = Clavinova ID
: :
11110111 F7 = End of Exclusive
MIDI Event Data Format Voice MIDI Reception MIDI Transmission
Internal Clock
(Clavinova compliance)
External Clock
(Clavinova compliance)
Organ Flutes data Bulk Dump
(Clavinova compliance)
Display open/close
(Clavinova compliance)
MIDI Master Tuning
Guide ON
F0 43 73 01 02 F7 -O X
00000001 01 = Model ID (Clavinova common ID)
00000010 02 = Internal Clock Substatus
F0 43 73 01 03 F7 -O X
00000001 01 = Model ID (Clavinova common ID)
00000011 03 = External Clock Substatus
F0 43 73 01 06 0B 00 00 01 06 0n [Bulk Data] sum F7 O
01H Mode l ID (Clavinova common ID)
06H Bulk ID
0BH Bulk No. (Organ Flutes data Bulk Dump)
00H,00H,01H,06H Data Length :16bytes
1st Channel No. 0nH
2nd Footage [1'] 00 - 08H
3rd [1 1/3'] 00 - 08H
4th [1 3/5'] 00 - 08H
5th [2'] 00 - 08H
6th [2 2/3'] 00 - 08H
7th [4'] 00 - 08H
8th [5 1/3'] 00 - 08H
9th [8'] 00 - 08H
10th [16'] 00 - 08H
11th [Attack 2'] 00 - 08H
12th [Attack 2 2/3'] 00 - 08H
13th [Attack 4'] 00 - 08H
14th Settings [Attack Length] 00 - 08H
15th [Response] 00 - 08H
16th [Attack Mode] 00 - 01H 00H: Each, 01H: First
17th [Wave Variation] 00 - 02H 00H: Sine, 01H: Vintage, 02H Euro
18th [Volume] 01 - 09H
19th [aux] 00H
20th [aux] 00H
21th [aux] 00H
22th [aux] 00H
sum Check Sum = 0-sum(BULK DATA)
Wave Variation: Euro
F0 43 73 01 51 00 00 02 05 A1 A2 A3 A4 dd F7 XX X
00000001 01 = Model ID (Clavinova common ID)
01010001 51 = PK/CL common variable length data
00000000 00 =
00000000 00 = Panel
00000001 02 = Display open/close
00000011 05 = Size
A1 = Display address1
A2 = Display address2
A3 = Display address3
A4 = Display address4
dd = 00 Display is opened at the time of star ting and closed at the time of
F0 43 1n 27 30 00 0 0 0m 0l cc F7 OO X
11110000 F0 = Exclusive status
01000011 43 = YAMAHA ID
0001nnnn 1n n= always 0(when transmit), n=0- F(when receive)
00100111 27 = Model ID of TG100
00110000 30 = Address High
00000000 00 = Address Mid
00000000 00 = Address Low
0000mmmm 0m = Master Tune MSB
0000llll 0l = Master Tune LSB
0ccccccc cc = don't care
11110111 F7 = End of Exclusive
F0 43 73 01 1F 00 cc dd F7 -O X
00000001 01 = Model ID (Clavinova common ID)
00011111 1F = Guide On Substatus
00000000 00 =
0ccccccc cc = Part Select Number (1/Right, 2/Left) cc 1/Right 2/Left
0ddddddd dd = Mode
11110111 F7 = End of Exclusive
stopping.
* This message is effective only for playback from an internal sequencer.
Display address Score display Lyrics display
A1 00H 00H
A2 00H 00H
A3 00H 01H
A4 00H 00H
00 On On
01 Off On
02 On Off
03 Off Off
00:Off, 01:Follow Lights, 02:An y Key, 03 :Karao Key, 04:Vocal Cue Time
06=YourTempo
Regular/
Drum/
Natural/
Organ Voice
(Organ
Flute)
[MIDI]
Song
Right1/
Keyboard Style Extra
Right2/
Left
OO X XO XXOX
Right1/
Right2/
Left
M.Pad
Style Song
Upper
Lower
: Transmitted via panel operations O : Available
PSR-A3000 Data List
85
Song System Exclusive Message List / Liste der System-Exclusive-Meldungen der Songs / Liste des messages exclusifs au système de morceaux / Lista de mensajes exclusivos del sistema de canciones
Data Format Parameter Description Note
Guide
F0 43 73 01 1F 00 cc dd F7 Guide Mode ccH = P art Select No
00H (TRACK1=ON, TRACK2=ON)
01H (TRACK1=OFF, TRACK2=ON)
02H (TRACK1=ON, TRACK2=OFF)
03H (TRACK1=OFF, TRACK2=OFF)
ddH = Mode
00H=Guide OFF
01H=Follow Lights
02H=Any Key
03H=Karao-Key
06=Your Tempo
Entered to the song from the [SONG CREATOR] SETUP display.
Score
F0 43 73 01 50 12 00 00 dd F7 Left Part indication On/Off 00H: OFF, 7FH:ON Entered to the song from the [SONG CREATOR] SETUP display.
F0 43 73 01 50 12 00 01 dd F7 Right Part indication On/Off 00H: OFF, 7FH:ON
F0 43 73 01 50 12 00 02 dd F7 Lyrics indication On/Off 00H: OFF, 7FH:ON
F0 43 73 01 50 12 00 03 dd F7 Chord indication On/Off 00H: OFF, 7FH:ON
F0 43 73 01 50 12 00 04 dd F7 N.Name indication On/Off 00H: OFF, 7FH:ON
F0 43 73 01 50 12 00 05 dd F7 Size designation 00H: SMALL, 01H:MIDDLE, 02H:LARGE, 03H:X-LARGE
F0 43 73 01 50 12 00 06 dd F7 Left Ch 00H
F0 43 73 01 50 12 00 07 dd F7 Right Ch 00H
F0 43 73 01 50 12 00 08 dd F7 Quantize triplet On/Off (00H:TripletOFF, 7FH:TripletON)
F0 43 73 01 50 12 00 09 dd F7 Quantize 00H: quarter, 01H: eighth, 02H: sixteenth, 03H: thirty-second
F0 43 73 01 50 12 00 0A dd F7 NoteName 00H:ABC, 01H:FixedDo, 02H:MovableDo
F0 43 73 01 50 12 00 0B dd F7 Color Note 00H: OFF, 7FH:ON
– 0FH=CH, 7EH=OFF, 7FH=AUTO
– 0FH=CH, 7EH=OFF, 7FH=AUTO
Style
F0 43 73 01 51 00 00 00 03 10 00 dd F7 STYLE SPLIT POINT dd=STYLE SPLIT POINT (Note Number) Entered to the song from the [SONG CREATOR] SETUP display.
F0 43 73 01 51 05 00 03 04 00 00 dd dd F7 Style No. dd dd = Style No. Entered when recording.
F0 43 7E 00 ss dd F7 Section Control Refer to the MIDI Data Format. Entered when recording.
Song Meta Event List / Liste der Meta-Events der Songs / Liste des métaévénements des morceaux / Lista de meta-eventos de canciones
Data Format Parameter Description Note
FF 05 len [Data] Lyrics len=Data lengt h, [Data]=Lyrics Data -
FF 51 03 t1 t2 t3 Set Tempo t1 t2 t3 =Tempo value B7 1B 00 – 01 D4 C0 (Tempo 5 – 500) Entered when recording.
FF 58 04 nn dd cc bb Beat nn=Numerator,
FF 59 02 sf mi Key Signature sf=-7 – 7
dd=Denominator (2n)
cc=MIDI clock per metronome clic k,
bb=Number of thirty-second notes in MIDI quarter note
mi=0: Major key, 1: minor key
YAMAHA META EVENT
FF 7F 06 43 73 0A 00 07 dd Score Start Bar ddH: Start from this measure
FF 7F len 43 73 0D 01 [Data] Keyboard Voice Voice settings for the RIGHT1 – 3 and LEFT Entered to the song from the [SONG CREATOR] SETUP display.
dd= -100 – 1, 1 – 100
YAMAHA XF META EVENT
FF 7F 07 43 7B 01 cr ct bn bt Chord Name Refer to “Chord Control” in the MIDI Data Format (System Exclusive Messages) Entered when recording.
FF 7F 05 43 7B 03 20 08 Phrase Mark Used as a marker for each phrase when executing Phrase Mark repeat playback. Used when performing the Phrase Mark repeat playback.
FF 7F 04 43 7B 04 dd Phrase Max Maximum Phrase Number Used when performing the Phrase Mark repeat playback.
FF 7F 05 43 7B 0C rr ll Guide Track Flag Sets the TRACK1 and TRACK2 parameters on the [FUNCTION] [SONG SETTING]
FF 7F len 43 7B 21 00 pp [Data] Lyrics Bitmap Specifies the background picture of the Lyrics display.
display.
rr = RIGHT CH (0: OFF, 1 – 16CH)
ll = LEFT CH (0: OFF, 1 – 16CH)
pp=Display type (0: Center, 1: Tile)
[Data]=File Path
Entered when recording.
Entered from the [Score] SETUP display.
Same as ScBar entered from the [SON G CREATOR] SYS/EX. Display
Entered when recording.
Entered to the song from the [SONG CREATOR] SETUP display.
PSR-A3000 Data List
86
MIDI Implementation Chart / MIDI-Implementierungstabelle / Tableau d'implémentation MIDI / Gráfico de implementacíon MIDI
Yamaha [ Digital Keyboard ] Date:17-Jun-2015
Model PSR-A3000 MIDI Implementation Chart Version : 1.0
Transmitted Recognized Remarks
Function...
Basic Default 1 - 16 1 - 16
Channel Changed 1 - 16 1 - 16
Default 3 3
Mode Messages x x
Altered ************** x
Note 0 - 127 0 - 127
Number : True voice ************** 0 - 127
Velocity Note ON o 9nH,v=1-127 o 9nH,v=1-127
Note OFF x 9nH,v=0 x
After Key's x o
Touch Ch's x o
Pitch Bend o o 0 - 24 semi
0,32 o o Bank Select
1,5,7,10,11 o o
16 o o
General Purpose Controller
6,38 o o Data Entry
Control 64,65,66,67 o o
71,72,73,74 o o Sound Controller
Change 80,81 o o
84 o o Portamento Cntrl
91,93,94 o o Effect Depth
96,97 x o RPN Inc,Dec
98,99 o o NRPN LSB,MSB
100,101 o o RPN LSB,MSB
Prog o 0 - 127 o 0 - 127
Change : True # **************
System Exclusive o o
: Song Pos. x x
Common : Song Sel. x x
: Tune x x
System : Clock o o
Real Time: Commands o o
:All Sound Off x o(120,126,127)
Aux :Reset All Cntrls x o(121)
:Local ON/OFF x o(122)
Mes- :All Notes Off x o(123 - 125)
sages:Active Sense o o
:Reset x x
Notes:
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON , MONO o : Yes
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF, MONO x : No
PSR-A3000 Data List
87
Loading...
