ULTIMATE SPEED UOP 12 C1 Operation And Safety Notes

OIL PUMP 12 V UOP 12 C1

OIL PUMP 12 V UOP 12 C1

Operation and safety notes
Translation of the original instructions

PUMPA ZA ULJE 12 V UOP 12 C1

Upute za posluživanje i za Vašu sigurnost
Prijevod originalnih uputa

POMPĂ DE ULEI 12 V UOP 12 C1

Instrucţiuni de utilizare şi de siguranţă
Traducere a instrucțiunilor originale

IAN 292211

ПОМПА ЗА ИЗТОЧВАНЕ НА
МАСЛО И ДИЗЕЛ
12 V UOP 12 C1

Инструкции за обслужване и безопасност
Превод на оригиналната инструкция

ΑΝΤΛΙΑ ΛΑΔΙΩΝ 12 V UOP 12 C1

Υποδείξεις χειρισμού και ασφαλείας
Μετάφραση του πρωτοτύπου των οδηγιών χρήσης

ÖLPUMPE 12 V UOP 12 C1

Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung

GB/CY Operation and safety notes Page 5
HR Upute za posluživanje i za Vašu sigurnost Stranica 13
RO Instrucţiuni de utilizare şi de siguranţă Pagina 21
BG Инструкции за обслужване и безопасност Страница 29
GR/CY Υποδείξεις χειρισμού και ασφαλείας Σελίδα 39
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 47

A

1

2

3

4

B

C

8

7

6

9

8

10

1

5

11

4

5

6

IN OUT

9

10

11

Introduction ............................................................ Page 6

Intended use ............................................................ Page 6

Scope of delivery .......................................................Page 6

Description of parts ..................................................... Page 6

Appliance............................................................... Page 6

Accessories ............................................................. Page 6

Technical data .......................................................... Page 6

Safety information ..................................................... Page 7

Safety symbols ........................................................... Page 7

Safety instructions ........................................................ Page 8

Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

Attaching the hoses ....................................................... Page 10

Operation .............................................................. Page 10

Cleaning and maintenance .............................................. Page 11

Cleaning ............................................................... Page 11

Maintenance ............................................................ Page 11

Storage ................................................................ Page 11

Disposal................................................................ Page 11

Translation of the original Conformity Declaration ....................... Page 12

Warranty .............................................................. Page 12

5 GB/CY

OIL PUMP 12 V UOP 12 C1

 Introduction

We congratulate you on the purchase of your
new product. You have chosen a high quality
product. The instructions for use are part of the
product. They contain important information
concerning safety, use and disposal. Before using
the product, please familiarise yourself with all
of the safety information and instructions for use.
Only use the product as described and for the
specified applications. If you pass the product on
to anyone else, please ensure that you also pass
on all the documentation with it.

 Intended use

This appliance is intended to pump out engine oil,
diesel fuel or heating oil. It is intended for private
use only.

The appliance shall not be used for pumping out
flammable liquids like gasoline and petroleum,
transmission oil or water. Pumping out chemicals,
alkalis, foods, paints and varnishes is also not
allowed.

The appliance is not suitable for continuous
operation. It can be continuously operated for
maximum 30 minutes.

Any other use not mentioned in these instructions
may cause a damage to the appliance or
generate a serious risk of injury.

The user is solely responsible for damage or
accidents to other people or their property,
which may occur while using the appliance. The
manufacturer accepts no liability for damages
caused by improper use.

 Scope of delivery

After unpacking the appliance, check if it is
complete and if all parts are in good condition.
Remove all packing materials before use.

 Oil pump with a battery connection cable
 Suction hose
 Drain hose
 2 hose clamps
 Operating manual

 Description of parts

Appliance

On/off switch

1

Pump casing

2

Battery connecting cable

3

Positive pole clamp (+) (red)

4

Negative pole clamp (‒) (black)

5

Drain hose connector (OUT)

6

Protective caps

7

Suction hose connector (IN)

8

Accessories

Suction hose (Ø 6 mm)

9

10

Hose clamp

11

Drain hose (Ø 12 mm)

 Technical data

Model number UOP 12 C1
Input voltage 12 V

(direct current)
Power input 60 W
Max. running time
Max. temperature
Protection class III/
IP rating IPX4
Output (pump capacity)*:
diesel fuel / heating oil approx. 1.5 l/min
engine oil (60 °C) approx. 0.2 l/min
Max. discharge head 0.7 m
Max. permissible pressure 0.3 MPa / 3 bar
Weight (incl. accessories) approx. 890 g
Sound pressure level approx. 70 dB(A)

* The capacity may diverge from given data,
depending on the temperature and type of oil.

t

max 30 min

ϑ

max 60 °C

6 GB/CY

Safety information

BEFORE USING THE PRODUCT,
PLEASE FAMILIARISE
YOURSELF WITH ALL OF
THE SAFETY INFORMATION
AND INSTRUCTIONS FOR
USE! WHEN PASSING THIS
PRODUCT ON TO OTHERS,
PLEASE ALSO INCLUDE ALL
THE DOCUMENTS!

In the case of damage resulting
from non-compliance with
these operating instructions
the guarantee claim becomes
invalid! No liability is accepted
for consequential damage! In
the case of material damage
or personal injury caused by
incorrect handling or non­compliance with the safety
instructions, no liability is
accepted!

 Safety symbols

CAUTION: Indicates a

hazardous situation which, if
not avoided, could result in
minor or moderate injury.

EXCLAMATION MARK:
Indicates a hazardous
situation which, if not
avoided, could result in
property damage.

Please read all safety
information and instructions.
Failure to comply with the
safety information and
instructions may result in, fire
and / or severe injuries.

Wear eye protection.

Wear hand protection.

WARNING!

DANGER OF DEATH
AND ACCIDENTS
FOR TODDLERS AND
CHILDREN!

Never leave children
unsupervised with the packaging
material. The packaging
material represents a danger of
suffocation. Children frequently
underestimate the dangers. Please
keep children away from the
product at all times.

Wear breathing protection.

Pumping direction

Protection class III

Direct current

7 GB/CY

 Safety instructions

 This appliance shall not be

used by children. Keep the
appliance and its cord out
of reach of children. This
appliance can be used by
persons with reduced physical,
sensory or mental capabilities
or lack of experience and
knowledge if they have been
given supervision or instruction
concerning use of the
appliance in a safe way and
if they understand the hazards
involved. Children shall not
play with the appliance.

 Check the appliance, battery

cables and battery terminals
for damage before each use.
Use only original accessories.
Do not operate damaged or
altered appliance.

 CAUTION! Danger of

electric shock! Do not
attempt to repair the appliance
yourself. In case of malfunction,
repairs are to be conducted by
qualified personnel only.

 Make sure that the appliance

is properly installed. Always
fasten the hoses with hose
clamps to prevent potential
spills.

 The appliance should only

be supplied with a SELV
(Safety Extra Low Voltage)
corresponding to the marking
on the appliance.

 When operating vehicle

batteries, always follow the
advice of the manufacturer of
the battery and of the vehicle.

 Wear personal protective

equipment such as safety
goggles, hand gloves and
dust mask. We recommend the
use of acid and alkali-resistant
hand gloves. Use of personal
protective equipment reduces
the risk of injury.

 Be attentive and use common

sense during operation.
Never leave the appliance
unattended during use.
A moment of inattention
may result in serious injury
or damage to the appliance
and / or vehicle.

 Fuels and lubricants can be

hazardous to health. Avoid
direct skin contact and
inhalation of fumes.

 CAUTION! Danger of

burns!

8 GB/CY

Take special care when

working with vehicle batteries.
Battery acid may leak causing
serious injuries. If the battery
acid get into contact with skin
or eyes, flush it with water and
consult your physician.

 Make sure that the vehicle

is not parked on a sloped
ground, otherwise it might not
be possible to pump out all
oil. Make sure that the parking
brake is engaged.

 Grasp the terminals only by the

insulated handles. Pay attention
to correct polarity. Connect
the positive pole terminal to
the positive pole of the vehicle
battery and the negative
terminal to the negative pole
(see “Getting started”).

 Do not short-circuit the

terminals and / or connecting
cables.

 The connecting cables of this

appliance cannot be replaced.
If the connecting cables are
damaged the appliance should
be scrapped.

 CAUTION! Risk of fire!

Do not operate the appliance
when the engine is switched
on or is hot. Do not start the
vehicle engine during the
pumping process.

 Never use the appliance for

longer than 30 minutes in
continuous operation in order
to prevent overheating.

 CAUTION! Risk of fire! Do

not pump oil at a temperature
higher than 60 °C.

 CAUTION! Risk of fire

and explosion! Do not
operate the vehicle battery in
the proximity of an open flames
or gases. Do not smoke when
operating the vehicle battery.
Ensure good ventilation in the
work area.

 CAUTION! Risk of fire!

Do not use the appliance to
pump out flammable liquids
like gasoline and petroleum,
transmission oil, water,
aqueous solutions, other
chemicals, alkalis, foods, paints
and varnishes.

 Do not operate the appliance

dry. The appliance can
become damaged due to
insufficient lubrication.

 Collect the pumped out oil only

in approved oil containers. Do
not pump different types of oil
into the same container.

9 GB/CY

 Disconnect the appliance

from the battery terminals
immediately after operation.
Using the appliance for
extended periods of time can
completely discharge vehicle
battery.

 Do not carry the appliance by

the connecting cables or the
hoses. Keep the connecting
cables and hoses away from
hot parts of the vehicle or
sharp edges.

 Store the appliance and the

used oil in a dry place and out
of reach of children.

 Dispose of used oil and

soaked rags properly (see
“Disposal”). In order to protect
the environment, do not let
oils drain into the ground or
household drains.

 Never use a damaged

appliance! Disconnect the
appliance from the vehicle
and contact your retailer if it is
damaged.

 Never use accessories which

are not recommended by the
manufacturer. They could pose
a safety risk to the user and
might damage the appliance.
Only use original parts and
accessories.

 This product has been

classified as IPX4 and is
protected against splashing
water from any direction. Do
not immerse in water.

 CAUTION! Do not immerse

the electrical parts of the
appliance in water or other
liquids. Never hold the
appliance under running water.

 Getting started

Attaching the hoses

1. Remove the protective caps

2. Straighten the suction hose

hose 11.

3. Install the suction hose (ø 6 mm)

suction hose connector 8.

4. Install the drain hose (ø 12 mm)

drain hose connector

5. Secure both hoses

hose clamps

6. Pay attention to the pumping direction

m Make sure that the hoses

straightened to avoid damage.

10

6

, 11 with the supplied

9

.

on the appliance.

 Operation

1. Start the vehicle and run it for 5-10 minutes

to warm up the oil (60 °C is the maximum oil
temperature). This reduces viscosity of the oil
and enables to pump it out more efficiently.

m Do not pump the oil when the car

engine is running.

2. Gently insert the suction hose (ø 6 mm)

into the bottom of the oil pan.

3. Insert the drain hose (ø 12 mm)

container (e.g. oil collecting tray).

4. Set the on/off switch

position.

1

(fig. A).

7

and the drain

9

9

11

.

, 11 are

9

11

to “O” (off)

onto the

onto the

9

into a

10 GB/CY

5. Connect the positive pole clamp (red) 4 to
the positive pole (+) of the vehicle battery.

6. Connect the negative pole clamp (black)
to the negative pole (‒) of the vehicle
battery.

7. Turning on: Set the on/off switch

1

to “I”
position. The pumping begins after a short
suction period.

8. Turning off: Set the on/off switch

1

to
“O”. Turn the appliance off as soon as oil
extraction is over or after 30 minutes of
continuous operation.

9. After each use, pump through some fresh oil
to clean the appliance.

10. Disconnect both clamps

4, 5

from the

vehicle battery.

m To prevent damage let the appliance

cool for at least 10 minutes after
every 30 minutes of continuous
operation.

11. Change the oil filter and refill with new oil
according to the vehicle instructions.

12. Used oil needs to be disposed of in a way
according to “Disposal”.

 Cleaning and maintenance

m Warning! During cleaning or operation

do not immerse the electrical parts of the
appliance in water or other liquids. Never
hold the appliance under running water.

Cleaning

1. After each use, pump through some fresh oil
to clean the appliance.

2. Clean both clamps
cloth after each use. Make sure there is no
adhering battery fluid left on the appliance.

3. Keep the casing
Do not use abrasive, aggressive or chemical
cleaning agents to clean the surface of the
appliance.

4. In case of oil spillage, clean it with a soft
cloth or a paper towel.

4, 5

with a dry

2

and accessories clean.

Maintenance

5

Storage

 Before each use check the appliance and all

its accessories for any visible damage.

 Apart from the occasional cleaning, the

appliance is maintenance-free.

 When not in use, store the cleaned appliance

in a dry, secure location away from children.

 Store used oil / diesel in appropriate

containers only.

 Disposal

The packaging is made entirely of
recyclable materials, which you may
dispose of at local recycling facilities.
The Green Dot is not valid for
Germany.

Observe the marking of the packaging
materials for waste separation, which are
marked with abbreviations (a) and
numbers (b) with following meaning:
1–7: plastics / 20–22: paper and
fibreboard / 80–98: composite
materials.

The product and packaging materials
are recyclable, dispose of it separately
for better waste treatment. The Triman
logo is valid in France only.

Contact your local refuse disposal
authority for more details of how to
dispose of your worn-out product.

To help protect the environment, please
dispose of the product properly when it
has reached the end of its useful life
and not in the household waste.
Information on collection points and
their opening hours can be obtained
from your local authority.

11 GB/CY

 Translation of the original

Conformity Declaration

We, OWIM GmbH & Co. KG,
Stiftsbergstraße 1, DE-74167 Neckarsulm,
GERMANY, hereby declare under our sole
responsibility that the product: Oil Pump
12 V, UOP 12 C1, Model No.: HG03271,
Version: 10/2017, to which this declaration
refers, complies with the standards / normative
documents of
2014/30/EU, 2006/42/EC, 2011/65/EU.

Applied harmonized standards:

EN 60335-1:2012/A11:2014
EN 60335-2-41:2003/A2:2010
EN 62233:2008
EN 50498:2010
EN 62321-1:2013

Serial number: IAN 292211

Tobias König
Division Manager / Responsible for
documentation
OWIM GmbH & Co. KG, Stiftsbergstraße 1,
DE-74167 Neckarsulm, GERMANY

Neckarsulm, 04.07.2017
The declaration of conformity can also be viewed

at: www.owim.com

 Warranty

The product has been manufactured to strict
quality guidelines and meticulously examined
before delivery. In the event of product defects
you have legal rights against the retailer of this
product. Your legal rights are not limited in any
way by our warranty detailed below.

The warranty for this product is 3 years from the
date of purchase. Should this product show any
fault in materials or manufacture within 3 years
from the date of purchase, we will repair or
replace it – at our choice – free of charge to you.

The warranty period begins on the date of
purchase. Please keep the original sales receipt
in a safe location. This document is required as
your proof of purchase. This warranty becomes
void if the product has been damaged, or used
or maintained improperly.

The warranty applies to defects in material
or manufacture. This warranty does not cover
product parts subject to normal wear, thus
possibly considered consumables (e.g. batteries)
or for damage to fragile parts, e.g. switches,
rechargeable batteries or glass parts.

The object of the declaration described above
satisfies the provisions of Directive 2011/65/EU
of the European Parliament and the Council of
8 June 2011 on limiting the use of certain harmful
substances in electrical and electronic appliances.

12 GB/CY

Uvod .................................................................Stranica 14

Namjena.............................................................Stranica 14

Cjelovitost isporuke...................................................Stranica 14

Opis dijelova . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Stranica 14

Uređaj ...............................................................Stranica 14

Dodaci ...............................................................Stranica 14

Tehnički podaci .......................................................Stranica 14

Sigurnosne informacije ...............................................Stranica 15

Sigurnosni simboli ......................................................Stranica 15

Sigurnosne upute .......................................................Stranica 16

Za početak ...........................................................Stranica 18

Spajanje crijeva ........................................................Stranica 18

Uporaba .............................................................Stranica 18

Čišćenje i održavanje .................................................Stranica 19

Čišćenje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Stranica 19

Održavanje ...........................................................Stranica 19

Skladištenje ...........................................................Stranica 19

Zbrinjavanje otpada..................................................Stranica 19

Prijevod originalnog objašnjenja sukladnosri..........................Stranica 20

Jamstvo..............................................................Stranica 20

13 HR

PUMPA ZA ULJE 12 V UOP 12 C1

 Uvod

Čestitamo vam na kupnji novog proizvoda. Time
ste se odlučili za jedan vrlo kvalitetan proizvod.
Prije prvog stavljanja u pogon, upoznajte se sa
proizvodom. Za to pomno pročitajte slijedeće
upute za uporabu i sigurnost. Koristite ovaj
proizvod u skladu s navedenim uputama te u
navedene svrhe. Sačuvajte ove upute. U slučaju
davanja proizvoda trećim osobama, izručite
također svu pripadajuću dokumentaciju.

 Opis dijelova

Uređaj

Prekidač za uključivanje/isključivanje

1

Kućište pumpe

2

Akumulatorski prilagodni kabel

3

Pozitivna štipaljka (+) (crvena)

4

Negativna štipaljka (‒) (crna)

5

Konektor za spajanje ispusnog crijeva

6

(IZLAZ)

Zaštitne kapice

7

Konektor za spajanje usisnog crijeva

8

(ULAZ)

 Namjena

Ovaj je uređaj namijenjen ispumpavanju
motornog ulja, dizelskog goriva ili loživog ulja.
Namijenjen je isključivo za privatnu uporabu.

Uređaj se ne smije koristiti za ispumpavanje
zapaljivih tekućina poput benzina ili petroleja,
ulja za mjenjače ili vode. Ispumpavanje
kemikalija, alkala, hrane, boja i lakova također
nije dopušteno.

Ovaj uređaj nije namijenjen stalnom radu. Može
neprekidno raditi najviše 30 minuta.

Svaka druga uporaba koja nije navedena u ovim
uputama može uzrokovati štetu na uređaju ili
stvoriti ozbiljnu opasnost od ozljede.

Korisnik je isključivo odgovoran za svaku štetu
ili nezgodu za druge ljude ili njihovu imovinu
do kojih može doći tijekom korištenja uređaja.
Proizvođač nije odgovoran za gubitak ili štetu
uslijed nepropisne uporabe.

 Cjelovitost isporuke

Nakon otvaranja uređaja provjerite je li potpun i
jesu li svi dijelovi u dobrom stanju. Prije uporabe
uklonite svu ambalažu.

 Uljna pumpa s akumulatorskim prilagodnim

kabelom

 Usisno crijevo
 Odvodno crijevo
 2 stezaljke za crijevo
 Upute za uporabu

Dodaci

Usisno crijevo (Ø 6 mm)

9

10

Stezaljka za crijevo

11

Odvodno crijevo (Ø 12 mm)

 Tehnički podaci

Broj modela UOP 12 C1
Ulazni napon 12 V

(istosmjerna

struja)
Ulazna snaga 60 W
Maksimalno vrijeme

t

rada

maks. 30 min
Maksimalna
temperatura
Klasa zaštite III/
IP ocjena IPX4
Izlaz (kapacitet pumpe)*:

dizelsko gorivo /
loživo ulje oko. 1,5 l/min

motorno ulje (60 °C) oko. 0,2 l/min
Maksimalna glava
za pražnjenje 0,7 m
Maksimalni dopušteni tlak 0,3 MPa / 3 bar
Težina (uklj. dodatke) oko. 890 g
Razina tlaka zvuka oko. 70 dB(A)

* Kapacitet može odstupati od navedenih
podataka ovisno o temperaturi i vrsti ulja.

ϑ

maks. 60 °C

14 HR

Sigurnosne
informacije

PRIJE UPOTREBE PROIZVODA
UPOZNAJTE SE SA SVIM
NJEGOVIM UPUTAMA ZA
KORIŠTENJE I SIGURNOSNIM
UPUTAMA. AKO PREDATE
PROIZVOD DRUGOJ
OSOBI, PREDAJTE JOJ I SVE
DOKUMENTE!
U slučaju štete koja nastane
zbog nepridržavanja ovih
uputa za rad, jamstvo postaje
nevažeće! Za posljedične štete ne

preuzima se nikakva odgovornost!
Ne preuzima se nikakva
odgovornost za materijalne štete
i tjelesne ozljede uzrokovane
nepropisnim korištenjem ili
nepoštivanjem sigurnosnih uputa!

UPOZORENJE!

OPASNOST OD
SMRTI NESREĆA ZA
DOJENČAD I DJECU!

Djecu nikada ne ostavljajte bez
nadzora u blizini ambalažnog
materijala. Ambalažni materijal
predstavlja opasnost od
gušenja. Djeca često podcjenjuju
opasnosti. Djecu uvijek držite
podalje od proizvoda.

Sigurnosni simboli

OPREZ: Označava

opasnost koja, ako se ne
izbjegne, može rezultirati
manjom ili srednje teškom
ozljedom.

USKLIČNIK: Označava
opasnost koja, ako se ne
izbjegne, može rezultirati
oštećenjem imovine.

Pročitajte sve sigurnosne
informacije i upute. U slučaju
nepoštivanja sigurnosnih
informacija i uputa može
doći do požara i/ili teških
ozljeda.

Nosite zaštitu za oči.

Nosite zaštitu za ruke.

Nosite zaštitu za disala.

Smjer pumpanja

Klasa zaštite III

Istosmjerna struja

15 HR

Sigurnosne upute

Ovaj uređaj ne smiju koristiti

djeca. Uređaj i njegov
kabel uvijek držite dalje od
dohvata djece. Uređaj mogu
upotrebljavati osobe smanjenih
tjelesnih, osjetilnih ili mentalnih
mogućnosti ili osobe koje ne
raspolažu iskustvom ili znanjem
ako su pod nadzorom i ako su
dobile upute o sigurnoj upotrebi
uređaja te razumiju uključene
opasnosti. Djeca se ne smiju
igrati s uređajem.

Prije svake uporabe provjerite

jesu li uređaj, akumulatorski
kabeli i terminali baterije
oštećeni. Koristite samo
originalni pribor. Nemojte
rukovati oštećenim ili
izmijenjenim uređajem.

OPREZ! Opasnost od

električnog udara! Ne
pokušavajte sami popraviti
uređaj. U slučaju kvara,
popravke treba vršiti isključivo
kvalificirano osoblje.

Provjerite je li uređaj pravilno

postavljen. Uvijek pričvrstite
crijeva pomoću stezaljki kako
biste spriječili prolijevanje.

Uređaj se smije napajati

isključivo niskim naponom
sigurne razine SELV (Safety
Extra Low Voltage) u skladu s
oznakom na uređaju.

Prilikom rukovanja

akumulatorima vozila, uvijek
se pridržavajte preporuka
proizvođača akumulatora i
vozila.

Nosite opremu za osobnu

zaštitu poput sigurnosnih
naočala, rukavica i maske za
prašinu. Preporučamo korištenje
rukavica otpornih na kiselinu
i alkale. Korištenje opreme
za osobnu zaštitu smanjuje
opasnost od ozljede.

Tijekom rada pazite i postupajte

razumno. Nikada ne ostavljajte
uređaj bez nadzora tijekom
rada. Trenutak nepažnje može
dovesti do ozbiljnih ozljeda ili
oštećenja uređaja i/ili vozila.

Goriva i maziva mogu

biti opasna po zdravlje.
Izbjegavajte izravni doticaj s
kožom i udisanje para.

OPREZ! Opasnost od

opeklina!

16 HR

Budite osobito pozorni prilikom
rada s akumulatorom vozila.
Kiselina iz akumulatora može
propustiti i uzrokovati teške
osobne ozljede. Ukoliko kiselina
iz akumulatora dođe u kontakt
s kožom ili očima, isperite
mlazom vode i posavjetujte se s
vašim liječnikom.

Pobrinite se da vozilo nije

parkirano na kosoj površni,
inače nećete moći u potpunosti
ispumpati ulje. Pobrinite se da
je parkirna kočnica aktivirana.

Terminale dirajte isključivo

putem izoliranih ručki. Obratite
pažnju na pravilan polaritet.
Pozitivni terminal spojite na
pozitivni pol akumulatora
vozila, a negativni terminal
na negativni pol (vidi “Za
početak”).

Ne pravite kratak spoj na

priključcima i/ili na spojnim
kabelima.

Spojne kabele na ovom uređaju

nije moguće promijeniti. Ako
se spojni kabeli oštete, uređaj
treba baciti.

OPREZ! Opasnost od

požara! Nemojte raditi s
uređajem dok motor radi ili je
vruć. Nemojte pokretati motor
tijekom procesa ispumpavanja.

Uređaj nikad nemojte

koristiti dulje od 30 minuta
neprestanog rada kako biste
spriječili pregrijavanje.

OPREZ! Opasnost od

požara! Nemojte ispumpavati
ulje pri temperaturi višoj od
60°C.

OPREZ! Opasnost od

požara i eksplozije!

Ne koristite akumulator
vozila u blizini otvorenih
plamenova. Ne pušite dok
rukujete akumulatorom vozila.
Osigurajte dobro prozračivanje
u radnom području.

OPREZ! Opasnost od

požara! Nemojte koristiti
uređaj za ispumpavanje
zapaljivih tekućina poput
benzina ili petroleja, ulja
za mjenjače, vode, vodenih
otopina, drugih kemikalija,
alkala, hrane, boja i lakova.

Ne rukujte uređajem tijekom

vožnje. Uređaj se može
oštetiti zbog nedovoljne
podmazanosti.

Ispumpano ulje prikupljajte

isključivo u odobrene spremnike
za ulje. Ne pumpajte različite
vrste ulja u isti spremnik.

17 HR

Odvojite uređaj s terminala

akumulatora odmah nakon
rada. Dugo korištenje uređaja
može u potpunosti isprazniti
akumulator vozila.

Ne nosite uređaj pomoću

spojnih kabela ili cijevi. Spojne
kabele i crijeva držite dalje od
vrućih dijelova vozila ili oštrih
rubova.

Uređaj i iskorišteno ulje

pohranite na suhom mjestu i
izvan dohvata djece.

Iskorišteno ulje i natopljene

krpe odložite na ispravan način
(vidi „Zbrinjavanje otpada“).
Radi zaštite okoliša nemojte
dopustiti da ulje otječe u tlo ili u
kućanske odvode.

Nikada ne koristite oštećeni

uređaj! Ako je oštećen,
iskopčajte uređaj iz vozila i
kontaktirajte vašeg trgovca.

Nikada ne koristite opremu koju

proizvođač nije preporučio.
Takvi uređaji mogu prouzročiti
opasnost po sigurnost i mogu
oštetiti uređaj. Koristite samo
originalne dijelove i dodatnu
opremu.

Ovaj je proizvod klasificiran

kao IPX4 i zaštićen je od
prskanja vode iz svih smjerova.
Ne uranjajte u vodu.

OPREZ! Ne uranjajte

električne dijelove uređaja u
vodu ili druge tekućine. Ne
držite uređaj pod tekućom
vodom.

 Za početak

Spajanje crijeva

1. Uklonite zaštitne kapice

2. Izravnajte usisno crijevo

11

crijevo

3. Postavite usisno crijevo (ø 6 mm)

konektor za usisno crijevo

4. Postavite odvodno crijevo (ø 12 mm)

konektor za odvodno crijevo

5. Oba crijeva učvrstite 9,

stezaljkama za crijevo

6. Pazite na smjer ispumpavanja

m Pazite da su crijeva

kako bi se izbjegla oštećenja.

.

na uređaju.

 Uporaba

1. Pokrenite vozilo i pustite ga da radi

5-10minuta kako bi se ulje zagrijalo
(60°C je maksimalna temperatura ulja).
Time se smanjuje viskoznost ulja i povećava
učinkovitost ispumpavanja.

m Ne ispumpavajte dok je ulje tijekom

rada motora.

2. Pažljivo umetnite usisno crijevo (ø 6 mm)

u dno posude za ulje.

3. Umetnite odvodno crijevo (ø 12 mm)

spremnik (npr. podložak za prikupljanje ulja).

4. Postavite prekidač za uključivanje/

isključivanje

1

u položaj “O” (isključeno).

10

7
9

11

.

9

(sl. A).

i odvodno

8

.

6

.

priloženim

11

,

izravnata

na

9

11

11

na

9

u

18 HR
