UOP 12 A1
1
GB
Introduction
Information for these operating instructions
Congratulations on the purchase of your new device.
You have clearly decided in favour of a quality product. These operating instructions
are a component of the Oil Suction Pump UOP 12 A1 (henceforth designated
as the device, pump or product). They contain important information in regard to
safety, use and disposal. Before using the product, familiarise yourself with all of
these operating and safety instructions. Use the product only as described and
only for the specifi ed areas of application. In addition, pass these documents on,
together with the product, to any future owner.
Copyright
This documentation is copyright protected. Any copying or reproduction of it,
including as extracts, as well as the reproduction of images, also in an altered
state, is only permitted with the written authorisation of the manufacturer.
Limited liability
The manufacturer assumes no responsibility for damage caused by failure to observe
these operating instructions, improper use, incompetent repairs, making unauthorised modifi cations or for using unapproved replacement parts.
Intended use
This device is intended exclusively for noncommercial use in the pumping of
engine oil, diesel or fuel oil.
This product is not suitable for pumping water (no lubrication of the pump), gearbox oil (too thin-bodied) or highly fl ammable liquids (petrol and paraffi n etc.).
This device is not intended for any other use or for uses beyond those mentioned.
Claims of any kind for damage resulting from unintended use will not be accepted.
The operator alone bears liability.
2
UOP 12 A1
Warning symbols used
In these extant operation instructions the following warnings are used:
DANGER
A warning at this risk level indicates a threateningly dangerous
situation
If the risk situation is not avoided, it could lead to death or serious physical injury.
► Pay heed to the instructions in this warning to avoid the death of or serious
physical injury to people.
TAKE NOTE
A warning at this risk level indicates possible property damage.
If the situation is not avoided it could lead to property damage.
► Pay heed to the instructions in this warning to avoid property damage.
NOTICE
A notice indicates additional information that may assist you in the han-
►
dling of the device.
Safety
In this chapter you will receive important safety information regarding the handling
of the device. This device complies with the statutory safety regulations. Incorrect
usage can lead to personal injury and property damage.
GB
Basic Safety Instructions
For safe handling of the device observe the following safety information:
■ Before use check the device for visible external damage. Do not put into
operation a device that is damaged or has been dropped.
■ Damaged cables or connections should be replaced by authorised qualifi ed
persons or by the customer service department.
■ This appliance may be used by children aged 8 over and by persons with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, provided that they are under supervision or have been told how
to use of the appliance safely and are aware of the potential risks. Children
must not play with the appliance. Cleaning and user maintenance tasks must
not be carried out by children unless they are supervised.
■ A repair to the device during the warranty period may only be carried out
by a customer service department authorised by the manufacturer otherwise
no additional warranty claims can be considered for subsequent damages.
UOP 12 A1
3
GB
■ Do not perform any modifi cations or changes to the appliance yourself.
■ Protect the device against moisture and the penetration of liquids.
■ Pay heed to the instructions of the vehicle manufacturer regarding the pumping
of oil. Some vehicle manufacturers forbid pumping the oil out because the
sludging, such as from abrasion, would remain behind.
■ Be particularly careful when you are handling oil. Should oil come into con-
tact with the skin or eyes, rinse it off with water and seek medical attention.
■ Be particularly careful if you are working on a car battery. Battery acid could
leak out and cause serious injury. Should battery acid come into contact with
the skin or eyes, rinse the aff ected part off with water and seek medical attention.
■ Wear personal protective equipment. The wearing of per-
sonal protection equipment (work clothing, respirators, gloves and goggles)
reduces the risk of personal injury.
■ Ensure that your vehicle is not parked on a sloped surface, as it may not be
possible to eff ect a complete oil extraction. Ensure that the hand brake is
engaged.
■ Do not start the engine during the operation of the oil suction pump.
■ Do not pump oil at a temperature above 60°C and do not pump it when
the engine is running. The vehicle engine must be cool.
■ Always use the supplied hose clamps, otherwise the tube may fall off and
cause a spillage of the oil.
■ Do not use the device to pump petrol, paraffi n or other infl ammable liquids.
■ Be especially careful when dealing with infl ammable materials or fuels.
There is the risk of an explosion!
■ Ensure that the work area is well ventilated and that there are no open fl ames
or other ignition sources in the vicinity. Otherwise, there is risk of explosion!
■ Do not pump water, the oil suction pump will not be suffi ciently lubricated
and could overheat.
■ The device is not suitable for the storage and/or transport of fuels or other
liquids.
■ Do not pump diff erent oils into the same tank.
■ Be extra careful when operating the oil suction pump and do not leave it
unattended when it is in operation.
■ Use the oil suction pump only when the engine oil is warm.
Hot oil can melt the hose.
■ The oil suction pump must NEVER be operated without the suction hose,
otherwise the pump motor could be overloaded.
■ To avoid overheating or malfunctions, the oil suction pump should never be
operated continuously for longer than 30 minutes.
4
UOP 12 A1
■ Use only the supplied connection terminals to connect the device to a car
battery.
■ Keep the connection cable away from hot parts of the engine and do not let
it hang over sharp edges.
■ Route the connection cable so that it cannot be caught up in moving parts of
the engine.
■ Disconnect the connection cable from the car battery when the device will
not be in use for longer periods of time.
■ Keep sources of ignition (e.g. naked fl ames, lighted cigars, cigarettes or
electrical sparks) away from the car battery. There is the risk of an explosion!
■ Avoid causing an electrical short-circuit when connecting the device to the
battery. Connect the positive pole terminal clamp only to the positive pole of
the battery. Connect the negative pole terminal clamp only to the negative
pole of the battery.
■ Connect the terminal clamps ("–" and "+") only to the insulated area!
Initial use
DANGER
Packaging material should not be used as a play thing. There is a risk of
►
suff ocation!
Items supplied and transport inspection
▯ Oil suction pump with connecting cable and quick contact connection
terminals
▯ Suction hose Ø 6 mm
▯ Discharge hose Ø 12 mm
▯ 2 x Hose clamps
▯ This operating manual
GB
UOP 12 A1
NOTICE
► Check the contents to ensure everything is available and for signs of visible
damage.
► If the delivery is not complete or is damaged, due to defective packaging or
through transportation, contact the Service Hotline (see chapter Service).
5
GB
Disposal of the packaging
The packaging protects the device from transport damage. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The recirculation of packaging into the material circuit saves on raw material
and reduces the amount of waste generated. Dispose of packaging material
that is no longer needed as per the regionally established regulations.
Operating components
Oil suction pump
2
On/Off switch
3
Positive connection terminal (red)
4
Minus connection terminal (black)
5
Connection for discharge hose
6
Connection for suction hose
7
Suction hose (Ø 6 mm)
8
Discharge hose (Ø 12 mm)
9
Hose clamps
Handling and operation
In this chapter you receive important information for the handling and operation
of the device.
Preparing the oil suction pump
♦ Remove the protective caps from the hose connections 5 + 6.
♦ Roll out the suction hose (Ø 6 mm) 7 and the discharge hose (Ø 12 mm) 8
and bend them straight.
♦ Press the suction hose (Ø 6 mm) 7 onto the connection for the suction
hose 6.
♦ Press the discharge hose (Ø 12 mm) 8 onto the connection for the
discharge hose 5.
♦ Thereby, bear in mind the direction of fl ow (
on the type plate of the oil suction pump .
♦ Secure both hoses with the supplied hose clamps 9.
TAKE NOTE
Ensure that the hoses are not kinked or bent, otherwise the hoses and the
►
pump could be damaged.
6
Pump direction
) given
UOP 12 A1
Pumping oil out
♦ Before starting to pump oil out, let your vehicle engine warm-up for 5 - 10
minutes (oil temperature 40°C - 60°C). This reduces the viscosity of the oil
and it can then be pumped out more effi ciently.
♦ Switch the vehicle motor off .
♦ Roll out the suction hose (Ø 6 mm) 7 and the discharge hose (Ø 12 mm) 8.
♦ Insert the suction hose (Ø 6 mm) 7 into the dipstick opening of your vehicle.
Insert it carefully down to the lowest point of the oil sump.
♦ Use a suitable container to collect the old oil and insert the discharge hose
(Ø 12 mm) 8 into the container.
♦ Ensure that the on/off switch 2 is in the position 0 (off ).
♦ First, connect the red positive-pole connection terminal (red) 3 to the
positive-pole (+) of the car battery.
♦ Then connect the black negative-pole connection terminal (black) 4 to the
negative-pole (-) of the car battery.
♦ Place the on/off switch 2 at position I (On) to switch the oil suction pump on.
♦ Pump the oil out of the engine/the oil sump.
♦ Place the on/off switch 2 at the position 0 (Off ) when no more oil fl ows
from the engine/the oil sump. Do not leave the oil suction pump running
if it is not pumping oil.
♦ Do not let the oil suction pump run for longer than 30 minutes at a time.
♦ Refi ll the engine with fresh oil as directed in your vehicle manufacturer's
instructions. Check the oil level with the dipstick.
♦ Clean the oil suction pump after the job is done by pumping a little fresh oil
through it.
♦ Dispose of the used oil as per the statutory regulations in your country
(see also the chapter Disposal).
♦ Loosen the hose clamps 9 and remove the suction hose (Ø 6 mm) 7 and
the discharge hose (Ø 12 mm)
at a dry, clean and dust-free location.
8
from the oil suction pump. Store all parts
GB
UOP 12 A1
7
GB
Cleaning
TAKE NOTE
Damage to the device!
► In order to avoid irreparable damage to it, ensure that no moisture gets
inside when you are cleaning the device.
Cleaning the housing
♦ Clean the oil suction pump after every job is done by pumping a little fresh
oil through it.
♦ Clean the connection terminals after each pumping. Wipe off any possibly
present battery fl uid on the connection terminals with a dry cloth so as to
protect them from corrosion.
♦ Clean the surfaces of the device and the hoses with a soft, dry cloth.
Maintenance
♦ Before every use, check the device for visible external damage.
♦ Check the cable before each use for damage.
♦ Check the hose clamps 9 for fi rm seating.
♦ Before every use, check the insulation of the connection terminals 3 + 4.
Disposal
Disposal of the device
Do not dispose of this device in your normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU WEEE (Waste Electrical and Electronic Equipment).
Dispose of the device through an approved disposal centre or at your community
waste facility. Pay heed to the currently applicable regulations. In case of doubt,
please contact your waste disposal centre.
Disposing of used oil
NEVER allow fresh or old oil to fl ow into the ground or the drainage system.
This is illegal! To protect the environment, collect used oil in a suitable container.
Dispose of it at your local collection centre, petrol station or oil dealer.
8
UOP 12 A1
Appendix
Translation of the original declaration of conformity
We, Kompernaß Handelsgesellschaft mbH, Burgstraße 21, 44867 Bochum,
Germany, state at our own responsibility that the product complies with the
fundamental requirements and the other relevant requirements of Directive
2006/42/EC on Machinery, the Low Voltage Directive 2006/95/EC,
the EMC Directive 2004/104/EC and the RoHS Directive 2011/65/EU.
Type / Device Designation: Ultimate Speed Oil Suction Pump UOP 12 A1
Serial Number: IAN 75715
Year of Manufacture: 09/2013
Applied harmonised standards:
EN 60335-1: 2012
EN 60335-2-41 / A2: 2010
EN 62233: 2008
EN 50498: 2010
EN 50581: 2012
Bochum, dated 11.09.2013
Semi Uguzlu, Quality Manager
GB
Technical data
Input voltage 12 V
Input current approx. 5 A
Operating period (maximum) 30 minutes
Sound pressure level approx. 70 dB(A)
Environmental temperature -10°C - +40°C
Max. Oil Temperature 60°C
Max. Diesel Temperature 45°C
Pumping rate:
Diesel or Heating Oil
Motor oil
Maximum lifting height 0.7 m
Maximum permissible pressure 3 bar
Measurements (W x H x D) approx. 13 x 9 x 14 cm
Weight (with accessories) approx. 950 g
*Depending on the type of oil and its temperature, variations to these details are possible.
UOP 12 A1
approx. 1,5 l/min.*
approx. 0,2 l/min.*
9
GB
Warranty
The warranty for this appliance is for 3 years from the date of purchase. The
appliance has been manufactured with care and meticulously examined before
delivery.
Please retain your receipt as proof of purchase. In the case of a warranty claim,
please make contact by telephone with our Customer Service Department. Only
in this way can a post-free despatch for your goods be assured.
NOTICE
►
This product is for domestic use only and is not intended for commercial use. The
warranty is void in the case of abusive and improper handling, use of force and
internal tampering not carried out by our authorised service branch.
Your statutory rights are not restricted in any way by this warranty. The warranty
period is not extended by repairs made under the warranty. This applies also to
replaced and repaired parts.
Damages and defects extant at the time of purchase must be reported immediately after unpacking, resp. no later than two days after the date of purchase.
Repairs made after the lapse of the warranty period are subject to charge.
Service
Service Great Britain
Tel.: 0871 5000 720 (£ 0.10/Min.)
E-Mail: kompernass@lidl.co.uk
IAN 75715
The warranty covers only claims for material and manufacturing defects,
but not for transport damage, wearing parts or for damage to fragile
components, e.g. buttons or batteries.
10
Hotline availability: Monday to Friday 08:00 - 20:00 (CET)
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
UOP 12 A1
Obsah
Úvod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Informace k tomuto návodu k obsluze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Autorské právo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Omezení ručení . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Použití dle předpisů . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Použitá výstražná upozornění . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Bezpečnost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Základní bezpečnostní pokyny . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Uvedení do provozu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Rozsah dodání a dopravní inspekce . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Likvidace obalu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Ovládací prvky . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Obsluha a provoz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Příprava čerpadla na odsávání oleje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Odčerpávání oleje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Čištění . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Čištění krytu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Údržba . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Likvidace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Likvidace přístroje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Likvidace starého oleje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
CZ
Dodatek . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Překlad originálního prohlášení o shodě . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Technická data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Záruka . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Servis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Dovozce . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
UOP 12 A1
11
Loading...
