CAR BATTERY CHARGER ULG 3.8 B1

CAR BATTERY CHARGER

Operating instructions

PUNJAČ AKUMULATORA ZA AUTO

Upute za upotrebu

ÎNCĂRCĂTOR BATERIE AUTO

Instrucţiuni de utilizare

ΦΟΡΤΙΣΤΗΣ ΜΠΑΤΑΡΙAΣ
ΑΥΤΟΚΙΝΗΤΟΥ

Οδηүίες χρήσης

IAN 274400

ЗАРЯДНО УСТРОЙСТВО ЗА
АВТОМОБИЛEН АКУМУЛАТОР

Ръководство за експлоатация

KFZ-BATTERIELADEGERÄT

Bedienungsanleitung

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.

Prije nego što pročitate tekst, otvorite stranicu sa slikama i upoznajte se na osnovu toga sa svim funkcijama
uređaja.

Înainte de a citi instrucţiunile, priviţi imaginile şi familiarizaţi-vă cu toate funcţiile aparatului.

Преди да прочетете отворете страницата с фигурите и след това се запознайте с всички функции
на уреда.

Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

GB / CY Operating instructions Page 1
HR Upute za upotrebu Stranica 11
RO Instrucţiuni de utilizare Pagina 19
BG Ръководство за експлоатация Cтраница 29
GR / CY Οδηүίες χρήσης Σελίδα 39
DE / AT / CH Bedienungsanleitung Seite 49

A

B

Contents

Introduction ............................................................2

Intended use ........................................................................2

Package contents ....................................................................2

Description of components .............................................................2

Technical details .....................................................................2

Safety ................................................................3

Safety information ...................................................................3

Additional safety instructions ...........................................................3

Operation .............................................................5

Before use .........................................................................5

Connecting .........................................................................5

Disconnecting .......................................................................5

Select charging mode ................................................................5

Reset/deleting settings ................................................................5

Switching between modes 1, 2, 3 and 4 ..................................................5

Mode 1 "6V" (7.3V/0.8A) ...........................................................6

Mode 2 "12V" (14.4V/0.8A). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Mode 3 "12V" (14.4V/3.8A). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Mode 4 "12V" (14.7V/3.8A). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Automatic battery recognition ..........................................................7

Pulse charging mode .................................................................7

Trickle charging .....................................................................7

Protective function of the appliance ......................................................7

Maintenance and cleaning ................................................7

Warranty .............................................................. 8

Service ................................................................ 8

Importer ..............................................................8

Disposal ............................................................... 8

Translation of the original Conformity Declaration ............................9

ULG 3.8 B1

GB│IE│CY 

│

 1 ■

CAR BATTERY CHARGER
ULG 3.8 B1

Introduction

Congratulations on the purchase of your new ap­pliance. You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.

Intended use

The Ultimate Speed ULG3.8B1 is a multi-stage
car battery charger that is suitable for charging
and trickle-charging 6V or 12V lead-acid batteries
(batteries) with electrolyte solution (WET), electro­lyte absorbent mats (AGM) or gel electrolyte (GEL).

This appliance is not suitable for charging lithium-ion
batteries. This appliance is not intended for com­mercial use and must be used indoors only.

The manufacturer accepts no responsibility for
damage(s) attributable to misuse.

Package contents

Car battery charger ULG 3.8 B1
These operating instructions

See Figure B:

Charger
Fixing holes
Mains power cable
Positive terminal clamp
Negative terminal clamp

Technical details

Rated voltage: 220–240 V ∼ 50/60 Hz

(alternating current)

Rated power
consumption: 60 W

Rated DC output
voltage: 6 V

Rated DC
output current: 0.8 A/3.8 A

Fuse (internal): 2 A
Ambient temperature: 0°C to 40°C
Protection type: IP 65
Protection class: II /

Battery type: 6 V lead-acid battery

1.2 Ah–14 Ah
12 V lead-acid battery

1.2 Ah–120 Ah

/ 12 V

(direct current)

T2A

(double insulation)

Description of components

See Figure A:

LED display "Mode 1"
LED display "Mode 2"
LED display "Mode 3"
LED display "Mode 4"
LED display "Error"
LED display "Fully charged"
LED display "Charging"
LED display "Standby mode"
"MODE" selection button

■ 2 │ GB

│IE│

CY

ULG 3.8 B1

Safety

WARNING!

► Read all safety warnings and all instruc-

tions. Failure to follow the warnings and

instructions may result in electric shock, fire
and/or serious injury.

Safety information

The charger is suitable for indoor

use only.

■ This appliance may be used by chil-

dren aged 8 years and above and
by persons with limited physical,
sensory or mental capabilities or
lack of experience and knowledge,
provided that they are under super­vision or have been told how to use
the appliance safely and are aware
of the potential risks. Children must
not play with the appliance. Clean­ing and user maintenance tasks
may not be carried out by children
unless they are supervised.

■ To avoid potential risks, damaged

mains cables should be replaced
by the manufacturer, their customer
service department or a similarly
qualified person.

Additional safety instructions

■ Do not use the charger for charging

non-rechargeable batteries.

■ Do not use the charger for charging

lithium-ion batteries.

■ Place the removed battery in a well-

ventilated location during charging.

■ The automatic mode of operation

and usage restrictions are explained
below in these operating instruc­tions.

RISK OF ELECTRIC SHOCK!

■ Do not operate the appliance with

a damaged cable, power cord or
mains plug. Damaged power cords
are hazardous to life due to the risk
of electric shock.

■ Before connecting to the mains,

make sure that the mains current is a
standard 230V~50Hz, equipped
with an earthed neutral conductor,
a 16A fuse and a residual-current
circuit breaker (RCCB).

■ Disconnect the charger from the

mains before making connections
to the battery.

■ Always connect the positive terminal

clamp (red) first.

ULG 3.8 B1

GB│IE│CY 

│

 3 ■

■ The negative pole terminal clamp

(black)

must be connected to
the chassis at a distance of at least
10 cm from the battery and the
fuel line.

■ Now connect the charger to the

power supply.

■ Disconnect the charger from the

mains power supply after charg­ing. Only then remove the terminal
clamp from the chassis. Then re­move the terminal clamp from the
chassis.

RISK OF EXPLOSION AND FIRE!

Protect yourself from a highly explosive
oxyhydrogen gas reaction!

■ Make sure that there are no sources

of open fire (flames, embers or
sparks) in the vicinity when charg­ing or discharging batteries!

■ Make sure that the positive terminal

connecting cable has no contact
with a fuel line (e.g. petrol line)!

■ Make sure that no explosive and

flammable substances, e.g. petrol
or solvents, can be ignited when
using the charger!

■ Ensure that there is adequate venti-

lation during charging.

RISK OF CHEMICAL BURNS!

■ Wear safety goggles! Wear pro-

tective gloves! If your eyes or skin
come into contact with battery acid,
rinse the affected part of the body
with plenty of clear running water
and seek immediate medical assis­tance!

■ Avoid an electric short-circuit when

connecting the charger to the bat­tery. Connect the negative terminal
connecting cable only to the nega­tive terminal of the battery or to the
coachwork. Connect the positive
terminal connecting cable only to
the positive terminal of the battery!

■ Do not set up the charger near a

fire or subject it to heat or tempera­tures exceeding 50°C for long
periods of time!

■ When attaching the charger, be

sure not to damage any lines for
fuel, electricity, braking system,
hydraulics or water with screws!

■ Do not cover the charger with

objects of any kind!

■ Protect the electrical contacts of the

battery against short-circuiting!

■ 4 │ GB

│IE│

CY

ULG 3.8 B1

■ Use the charger exclusively for

charging or trickle charging undam­aged 6V/12V lead batteries!
Frozen batteries may not be charged.

Operation

Before use

♦ Before connecting the battery charger, read the

operating instructions of the battery thoroughly.

♦ In addition, observe the vehicle manufacturer's

instructions for a permanently connected battery.
Secure the vehicle; turn off the ignition.

♦ Clean the battery terminals. Ensure that your

eyes do not come in contact with the dirt in the
process.

♦ Ensure sufficient ventilation.

Connecting

NOTE

► There are two options for connecting the

charger. Connect the negative terminal
connecting cable (black) either directly to
the negative terminal of the battery or to the
chassis. Please also bear in mind the vehicle
manufacturer's instructions.

♦ Before starting the charging or trickle charging

procedure on a permanently installed battery in
a vehicle, first disconnect the negative terminal
connecting cable (black) of the vehicle from the
negative terminal of the battery. The negative
terminal of the battery is usually connected to
the vehicle's chassis.

♦ Then disconnect the positive terminal connecting

cable (red) of the vehicle from the positive termi­nal of the battery.

♦ Clamp the positive terminal clamp (red)

charger to the positive terminal on the battery.

♦ Clamp the negative terminal clamp (black)

of the charger to the negative terminal on the
battery.

of the

♦ Connect the mains cable

charger to the power socket.

♦ If the terminal clamps are connected incorrectly,

the LED display "ERROR"

of the battery

will light up.

Disconnecting

♦ Disconnect the appliance from the power supply.
♦ Remove the negative terminal clamp (black)

of the charger from the negative terminal on the
battery or from the chassis.

♦ Remove the positive terminal clamp (red)

the charger from the positive terminal on the
battery.

of

Select charging mode

You can choose between different charging modes
for charging various batteries at different ambient
temperatures. Unlike standard battery chargers,
this appliance has a special function for reusing an
empty rechargeable battery. You can recharge a
completely discharged battery. A protection func­tion against incorrect connection and short circuit­ing ensures safe charging. Due to the installed
electronics, the charger does not begin operation
directly after connecting the battery, but only starts
after a charging mode has been selected. This pre­vents sparking, which often occurs when connect­ing. In addition, the battery charger is controlled by
an internal MCU (microcomputer unit).

Reset/deleting settings

♦ After connection to the power supply, the appli-

ance automatically returns to its initial state and
remains in Standby mode

Switching between modes 1, 2, 3
and 4

Press the MODE selection button a corresponding
amount of times.

The appliance switches through the modes in the
following order: Standby ( ), Mode 1 ( ), Mode
2 (

), Mode 3 ( ), Mode 4 ( ) and then starts

the next cycle.

ULG 3.8 B1

GB│IE│CY 

│

 5 ■

NOTE

► If you press the MODE selection button

the charging mode automatically switches
to the next mode and begins operation in
that mode. If a 12 V battery is connected,
Mode 1 (
battery is connected, Mode 2 (
and 4 (
not disconnected from the charging station
after a full charge, the appliance remains in
trickle-charge mode, even if the user switches
over to another mode. This protects the fully
charged battery from being damaged.

) is not selectable. If a 6V

) 3 ( )

) are not selectable. If a battery is

,

Mode 1 "6V" (7.3V/0.8A)

This mode is suitable for charging 6V lead-acid
batteries with a capacity below 14Ah.

♦ Press the MODE selection button

Mode 1 ( ). After doing so, the corresponding
LED display lights up. If you do not acti­vate another process afterwards, the electronic
system will automatically activate together with
the LED display and starts the charging
process. If the procedure runs without any prob­lems, the LED display remains on during
the entire charging process, until the battery
is fully charged to 7.3V/± 0.25V. When the
battery is fully charged, the LED display
lights up and the LED display
The appliance now switches automatically to
trickle charging mode.

, to activate

goes out.

Mode 2 "12V" (14.4V/0.8A)

This mode is suitable for charging 12V lead-acid
batteries with a capacity below 14Ah.

♦ Press the MODE selection button

Mode 2 ( ). After doing so, the corresponding
LED display lights up. If you do not acti­vate another process afterwards, the electronic
system will automatically activate together with
the LED display and starts the charging
process. If the procedure runs without any
problems, the LED display remains on
during the entire charging process until the bat­tery is fully charged. When the battery is fully
charged, the LED display lights up and
the LED display goes out.

, to activate

The appliance now switches automatically to
trickle charging mode.

Mode 3 "12V" (14.4V/3.8A)

This mode is mainly used for charging 12V lead­acid batteries with a large capacity of more than
14Ah under normal conditions.

♦ Press the MODE selection button

Mode 3 (
process afterwards, the electronic system and
the LED display
the charging process. If the procedure runs
without any problems, the LED display
remains on during the entire charging process
until the battery is fully charged. When the
battery is fully charged, the LED display
lights up and the LED display goes out.
The appliance now switches automatically to
trickle charging mode.

). If you do not activate another

will activate and start

Mode 4 "12V" (14.7V/3.8A)

This mode is used for charging 12V lead-acid
batteries with a capacity of more than 14Ah in
cold conditions or for some AGM batteries with
a capacity of more than 14Ah.

♦ Press the MODE selection button

Mode 4 (
process afterwards, the electronic system and
the LED display
charging process. In this mode, the charging
current is identical to that of "Mode 3" (
If the procedure runs without any problems,
the LED display remains on during the
entire charging process until the battery is fully
charged. When the battery is fully charged,
the LED display lights up and the LED
display goes out. The appliance now
switches automatically to trickle charging mode.

). If you do not activate another

will activate and start the

, to activate

, to activate

).

■ 6 │ GB

│IE│

CY

ULG 3.8 B1

Automatic battery recognition

As soon as the charger is connected to the mains
power supply, the LED display
lights up.

The charger recognises the battery on the basis of
the following criteria:

If the voltage of the battery is less than 3.8 V or
greater than 15 V, the battery is not suitable for
charging or defective. In this case, the LED Dis­plays

,
charger remains in "Standby mode” and cannot be
switched to another charging mode by means of
the MODE selection button .

,

on the device

and

flash. The

Pulse charging mode

The mode is suitable for the charging/regeneration
of empty, used and overcharged 12V lead-acid
batteries.

When the charger is connected to a battery and
the charging process starts it automatically rec­ognises the battery voltage. It will switch to pulse
charging mode if the voltage is in the range of

7.5V ± 0.5 to 10.5V ± 0.5V.
This pulse charging process is continued until the

battery voltage has increased to 10.5V ± 0.5V.
As soon as this state is reached, the charger switch-

es over to the previously selected normal charging
mode.

Now the battery can be charged quickly and safe­ly. Most empty, used or overcharged batteries can
be regenerated and reused using this procedure.

NOTE

► During the pulse charging process, the LED

display

flashes.

Trickle charging

The charge is equipped with an automatic trickle
charging function. Depending on the voltage of the
battery, the charger reacts by supplying different
charging current. The battery can remain connect­ed to the charger for a long period of time.

Protective function of the appliance

In the case of an incident such as short circuiting, a
critical voltage drop during the charging process,
an open circuit or reversed connection of the output
terminals, the charger deactivates the electronic
system and immediately switches back to its basic
state to avoid damage.

If you do not activate any settings, the system will
remain in Standby mode. If the terminals are incor­rectly connected (reverse polarity), the LED display
"ERROR" also lights up.

If the appliance becomes too hot during charging,
the power output is automatically reduced. This
also protects the appliance from damage.

Maintenance and cleaning

WARNING! Always remove the

power plug from the wall socket
before carrying out any work on
the battery charger.

The appliance is maintenance-free.

♦ Under no circumstances should solvents or other

aggressive cleaning agents be used.

♦ Clean the plastic surfaces of the appliance with

a soft, dry cloth.

ULG 3.8 B1

GB│IE│CY 

│

 7 ■

Warranty

This appliance is provided with a 3-year
warranty valid from the date of purchase.
The appliance has been manufactured with
care and inspected meticulously prior to de­livery. Please retain your receipt as proof of
purchase. In the event of a warranty claim,
please contact your Customer Service unit by
telephone. This is the only way to guarantee
free return of your goods.

The warranty only covers claims for material and
manufacturing defects, not for damage sustained
during transport, wearing parts or damage to frag­ile components such as switches or batteries. This
appliance is intended solely for private use and not
for commercial purposes. The warranty shall be
deemed void in cases of misuse or improper hand­ling, use of force and modifications/repairs which
have not been carried out by one of our authorised
Service centres. Your statutory rights are not re­stricted by this warranty. The warranty period is not
prolonged by repairs effected under the warranty.
This also applies to replaced and repaired compo­nents. Any damage and defects present at the time
of purchase must be reported immediately after
unpacking, but no later than two days after the
date of purchase. Repairs carried out after expiry
of the warranty period shall be subject to charge.

Service

Service Great Britain

Tel.: [phone] (£ 0.10/Min.)
E-Mail: [e-mail]

IAN 274400

Service Ireland

Tel.: [phone]
(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))
E-Mail: [e-mail]

IAN 274400

CY

Service Cyprus

Tel.: [phone]
E-Mail: [e-mail]

IAN 274400

Importer

KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

Disposal

The packaging is made from environmen-

tally friendly material and can be dis­posed of at your local recycling plant.

■ 8 │ GB

│IE│

CY

Do not dispose of power tools in

your normal household waste!

European Directive 2012/19/EU requires that
worn-out power tools be collected separately and
recycled in an environmentally compatible manner.

Your local community or municipal authorities can
provide information on how to dispose of the worn­out appliance.

ULG 3.8 B1

Translation of the original
Conformity Declaration

We, KOMPERNASS HANDELS GMBH, docu­ments officer: Mr. Semi Uguzlu, BURGSTR. 21,
44867 BOCHUM, GERMANY, hereby declare that
this product complies with the following standards,
normative documents and EC directives:

EC Low Voltage Directive
(2014/35/EU)

EMC (Electromagnetic Compatibility)
(2014/30/EU)

RoHS Directive
(2011/65/EU)

Related harmonised standards:

EN 60335-2-29/A2:2010
EN 60335-1:2012
EN 62233:2008

EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013

Type designation of machine:

Car battery charger ULG 3.8 B1

Year of manufacture: 05 - 2016

Serial number: IAN 274400

Bochum, 01/02/2016

Semi Uguzlu

- Quality Manager -

The right to effect technical changes in the context
of further development is reserved.

ULG 3.8 B1

GB│IE│CY 

│

 9 ■

■ 10 │ GB

│IE│

CY

ULG 3.8 B1

Sadržaj

Uvod ................................................................12

Namjenska uporaba ................................................................12

Opseg isporuke ....................................................................12

Opis dijelova ......................................................................12

Tehnički podaci ....................................................................12

Sigurnost .............................................................13

Sigurnosne napomene ...............................................................13

Dodatne sigurnosne napomene ........................................................13

Rukovanje ............................................................14

Prije uključivanja uređaja .............................................................14

Priključivanje .......................................................................14

Odvajanje ........................................................................15

Odabir modusa punjenja .............................................................15

Resetiranje/brisanje postavki ..........................................................15

Prebacivanje između modusa 1, 2, 3 i 4 .................................................15

Modus 1 „6V“ (7,3V / 0,8A) ........................................................15

Modus 2 „12V“ (14,4V / 0,8A) ......................................................16

Modus 3 „12V“ (14,4V / 3,8A) ......................................................16

Modus 4 „12V“ (14,7V / 3,8A) ......................................................16

Automatsko prepoznavanje baterija ....................................................16

Modus impulsnog punjenja ...........................................................16

Modus održavanja punjenja ..........................................................17

Zaštitna funkcija uređaja .............................................................17

Održavanje i čišćenje ...................................................17

Jamstvo ..............................................................17

Servis ................................................................17

Uvoznik ..............................................................17

Zbrinjavanje ..........................................................18

Prijevod originalne izjave o sukladnosti ...................................18

│

HR 

ULG 3.8 B1

 11 ■

PUNJAČ AKUMULATORA ZA
AUTO ULG3.8B1

Uvod

Čestitamo na kupnji Vašeg novog uređaja. Time
ste se odlučili za vrlo kvalitetan proizvod. Upute
za rukovanje sastavni su dio ovog proizvoda. One
sadrže važne napomene za sigurnost, rukovanje i
zbrinjavanje. Prije uporabe uređaja upoznajte se sa
svim pripadajućim uputama za uporabu i svim sigur­nosnim napomenama. Proizvod koristite isključivo
na opisani način i u navedenim područjima upora­be. U slučaju predaje proizvoda trećim osobama,
priložite i predajte svu njegovu dokumentaciju.

Namjenska uporaba

Ultimate Speed ULG3.8B1 je višestupanjski uređaj
za punjenje automobilskih akumulatora, prikladan
za punjenje i održavanje punjenja 6V ili 12V olov­nih akumulatora (baterija) s otopinom elektrolita
(WET), sa spužvama koje apsorbiraju elektrolit
(AGM) ili s elektrolitom u gelu (GEL).

Uređaj nije prikladan za punjenje litij-ionskih bateri­ja! Uređaj nije namijenjen za komercijalnu uporabu
i namijenjen je isključivo za uporabu u zatvorenom
prostoru.

Proizvođač ne preuzima odgovornost za štete
nastale uslijed nenamjenskog korištenja uređaja.

Opseg isporuke

Punjač akumulatora za auto ULG3.8B1
Ove upute za uporabu

Vidi sliku B:

Punjač
Rupe za pričvršćivanje
Mrežni priključni vod
Priključna stezaljka plus pola
Priključna stezaljka minus pola

Tehnički podaci

Nazivni napon: 220 - 240 V ∼ 50/60 Hz

(izmjenična struja)
Nazivna snaga: 60 W
Nazivni izlazni

istosmjerni napon: 6 V

Nazivna izlazna
istosmjerna struja: 0,8 A / 3,8 A

Osigurač (unutarnji): 2 A
Temperatura okruženja: 0°C do 40°C
Vrsta zaštite: IP 65
Razred zaštite: II /

Tipovi akumulatora
(baterije): 6 V olovni akumulator

/ 12 V

(istosmjerna struja)

T2A

(dvostruka izolacija)

s kiselinom

1,2 Ah - 14 Ah

12 V olovni akumulator

s kiselinom

1,2 Ah - 120 Ah

Opis dijelova

Vidi sliku A:

LED indikator „Modus 1“
LED indikator „Modus 2“
LED indikator „Modus 3“
LED indikator „Modus 4“
LED indikator „Greška“
LED indikator „Potpuno napunjeno“
LED indikator „Punjenje aktivno“
LED indikator „Standby modus“
Tipka za odabir „MODE“

■ 12 │ HR

ULG 3.8 B1

Sigurnost

UPOZORENJE!

► Pročitajte sve sigurnosne napomene i upute.

Nepridržavanje sigurnosnih napomena i
uputa može uzrokovati strujni udar, požar i/ili
teške ozljede.

Sigurnosne napomene

Punjač je prikladan isključivo za

uporabu u zatvorenim prostori­jama.

■ Ovaj uređaj smiju koristiti djeca

stara 8 godina ili više, kao i osobe
sa smanjenim fizičkim, senzornim
ili mentalnim sposobnostima ili po­manjkanjem iskustva i/ili znanja,
ukoliko su pod nadzorom ili su pri­mile poduku o sigurnom rukovanju
uređajem te su razumjele opasnosti
koje proizlaze iz uporabe uređaja.
Djeca se ne smiju igrati uređajem.
Čišćenje i servisiranje ne smiju
obavljati djeca bez odgovarajućeg
nadzora.

■ Ako dođe do oštećenja mrežnog

kabela, isti mora zamijeniti proizvo­đač, servis za kupce ili slična kvali­ficirana osoba, kako bi se izbjegle
opasnosti.

Dodatne sigurnosne napomene

■ Punjač ne koristite za punjenje bate-

rija koje se ne mogu ponovo puniti.

■ Punjač ne koristite za punjenje litij-

ionskih baterija.

■ Izvađenu bateriju za vrijeme po-

stupka punjenja postavite na dobro
prozračenu površinu.

■ Automatski rad, kao i ograničenja

uporabe, objašnjeni su u nastavku
ovih uputa za uporabu.

OPASNOST OD STRUJNOG

UDARA!

■ Uređaj ne koristite ako je oštećen

kabel, mrežni priključni vod ili mrež­ni utikač. Oštećeni mrežni priključni
vod predstavlja opasnost po život
od strujnog udara.

■ Prije priključivanja na mrežni napon,

provjerite da struja mreža odgovara
naponu od 230V∼ 50Hz, ima
uzemljeni nulti vod, osigurač od
16 A i FID (zaštitnu) sklopku.

■ Isključite mrežno napajanje punjača

prije spajanja ili odvajanja baterije.

■ Uvijek najprije priključite priključnu

stezaljku plus-pola (crvenu) .

■ Priključnu stezaljku minus-pola (crna)

treba priključiti na karoseriju na
udaljenosti od najmanje 10 cm od
baterije i voda za gorivo.

ULG 3.8 B1

■ Punjač tek nakon toga priključite na

mrežu.

│

HR 

 13 ■

■ Nakon punjenja isključite punjač s

mreže. Tek nakon toga skinite pri­ključnu stezaljku s karoserije. Nakon
toga skinite priključnu stezaljku s
baterije.

OPASNOST OD EKSPLOZIJE I

POŽARA!

Zaštitite se od reakcije plina praskavca!

minus pol akumulatora, odnosno na
karoseriju. Priključni kabel plus pola
priključite isključivo na odgovarajući
plus pol akumulatora!

■ Punjač ne stavljajte u blizinu vatre,

vrućine i ne izlažite dugotrajnom
utjecaju visokih temperatura iznad
50°C!

■ Pobrinite se da prilikom postupka

punjenja baterije u blizini nema
otvorenog izvora topline (plamen,
iskra ili žar)!

■ Pobrinite se da priključni kabel plus

pola nema kontakt s vodom za
pogonsko gorivo (npr. vodom za
benzin)!

■ Pobrinite se da se eksplozivne ili za-

paljive tvari, npr. benzin ili otapala,
ne mogu zapaliti prilikom uporabe
punjača!

■ Uvijek osigurajte dostatnu ventilaciju

tijekom punjenja.

OPASNOST OD KEMIJSKIH

OPEKLINA

■ Nosite zaštitne naočale! Nosite

zaštitne rukavice! Ukoliko oči ili
koža dođu u kontakt s kiselinom u
akumulatoru, isperite velikom količi­nom čiste tekuće vode i odmah se
za pomoć obratite liječniku!

■ Izbjegavajte električni kratki spoj

prilikom priključivanja punjača na
bateriju. Priključni kabel minus pola
priključite isključivo na odgovarajući

■ Pazite da prilikom montaže punjača

vijcima ne oštetite vodove za gorivo,
struju, kočnice, hidrauliku ili vodu!

■ Punjač ne prekrivajte predmetima!

■ Zaštitite površine električnih konta-

kata od kratkog spoja!

■ Punjač koristite isključivo za postu-

pak punjenja i održavanja punjenja
neoštećenih olovnih akumulatora
od 6V / 12V. Smrznuti akumulatori
se ne smiju puniti.

Rukovanje

Prije uključivanja uređaja

♦ Prije priključivanja punjača treba provjeriti upute

za uporabu baterije.

♦ Osim toga, pridržavati se treba i propisa proizvo-

đača vozila za bateriju koja je stalno priključena
u vozilu. Osigurajte vozilo i isključite kontakt.

♦ Očistite polove baterije. Pazite da oči pritom ne

dođu u kontakt s prljavštinom.

♦ Uvijek osigurajte dostatnu ventilaciju.

Priključivanje

NAPOMENA

► Punjač se može priključiti na dva načina.

Priključni kabel za minus pol (crni) može se
priključiti ili izravno na minus pol akumulato­ra, ili na karoseriju. Pridržavajte se propisa
proizvođača vozila.

■ 14 │ HR

ULG 3.8 B1

♦ Prije postupka punjenja i održavanja punjenja

akumulatora stalno priključenog u vozilu, naj­prije odvojite priključni kabel minus pola (crni)
vozila s minus pola baterije. Minus-pol baterije
u pravilu je povezan s karoserijom vozila.

♦ Nakon toga odvojite priključni kabel plus pola

(crveni) vozila s plus pola baterije (akumulatora).

♦ Priključite priključnu stezaljku plus pola (crvena)

punjača na plus pol baterije.

♦ Priključite priključnu stezaljku minus pola (crna )

na minus pol baterije, odnosno na karoseriju.

♦ Priključite mrežni priključni vod

mrežnu utičnicu.

♦ U slučaju pogrešnog priključka (zamjene po-

lova) priključnih stezaljki svijetli LED indikator
„Greška“

.

punjača na

Odvajanje

♦ Odvojite uređaj od mrežnog napajanja.
♦ Skinite priključnu stezaljku minus pola (crna)

s minus pola baterije, odnosno s karoserije.

♦ Skinite priključnu stezaljku plus pola (crvena)

s plus pola baterije.

Odabir modusa punjenja

Za punjenje različitih baterija pri različitoj tem­peraturi okoline možete birati između tri različita
modusa punjenja. U usporedbi s konvencionalnim
uređajima za punjenje baterija, ovaj uređaj raspo­laže specijalnom funkcijom za ponovnu uporabu
prazne baterije/praznog akumulatora. Možete
ponovno napuniti potpuno ispražnjenu bateriju/
potpuno ispražnjeni akumulator. Zaštita od po­grešnog priključivanja i kratkog spoja omogućava
siguran postupak punjenja. Zbog ugrađene elek­tronike, uređaj za punjenje ne započinje s radom
neposredno nakon priključivanja baterije, nego tek
nakon što odaberete modus punjenja. Na taj način
sprječava se nastanak iskri, koje se često pojavljuju
prilikom priključivanja. Osim toga, punjačem uprav­lja ugrađeni MCU (mikroprocesorska jedinica).

Resetiranje/brisanje postavki

♦ Nakon priključivanja na mrežno napajanje, ure-

đaj se automatski prebacuje u osnovni položaj i
ostaje u Standby-modusu (modusu pripravnosti).

Prebacivanje između modusa
1, 2, 3 i 4

Pritisnite tipku za odabir MODE određeni broj
puta.

Uređaj prebacuje između modusa punjenja sljede­ćim redoslijedom: Standby ( ), Modus 1 ( ),
Modus 2 (
započinje sljedeći ciklus.

NAPOMENA

► Kada pritisnete tipku za odabir MODE

), Modus 3 ( ), Modus 4 ( ) i zatim

modus punjenja prelazi na sljedeći modus
i isti odmah započinje. Ako je priključena
baterija od 12 V, Modus 1 ( ) se ne može
birati. Ako je priključena baterija od 6V,
Modus 2 (
birati. Ako, međutim, bateriju nakon potpu­nog punjenja ne odvojite od punjača, ostaje
odabran modus za održavanje punjenja,
čak i ako korisnik odabere neki drugi modus.
To je korisno kako bi se potpuno napunjena
baterija zaštitila od oštećenja.

), 3 ( ) i 4 ( ) se ne mogu

Modus 1 „6V“ (7,3V / 0,8A)

Ovaj je modus prikladan za punjenje olovnih
baterija od 6V kapaciteta manjeg od 14 Ah.

♦ Pritisnite tipku za odabir MODE

odabrali modus 1 ( ). Nakon ovog postupka
zasvijetlit će odgovarajući LED indikator .
Ukoliko nakon toga ne obavljate dodatna po­dešavanja, elektronika će se uključiti zajedno s
LED indikatorom
punjenja. Ukoliko ovaj postupak prođe bez pro­blema, LED indikator
vrijeme cijelog postupka punjenja, sve dok se
baterija ne napuni na 7,3V /± 0,25V. Kada je
baterija potpuno napunjena, zasvijetliti će LED
indikator
Uređaj automatski prelazi u modus održavanja
punjenja.

i započeti će postupak

, a LED indikator

, kako biste

ostaje aktivan za

,

se gasi.

ULG 3.8 B1

HR 

│

 15 ■

Modus 2 „12V“ (14,4V / 0,8A)

Ovaj je modus prikladan za punjenje olovnih
akumulatora s kiselinom napona 12V i kapaciteta
manjeg od 14 Ah.

♦ Pritisnite tipku za odabir MODE

odabrali modus 2 ( ). Nakon ovog postupka
zasvijetlit će odgovarajući LED indikator .
Ukoliko nakon toga ne obavljate dodatna po­dešavanja, elektronika će se uključiti zajedno s
LED indikatorom
punjenja. Ukoliko ovaj postupak prođe bez
problema, LED indikator
za vrijeme cijelog postupka punjenja, sve dok
se baterija ne napuni.

Kada je baterija potpuno napunjena, zasvijetliti
će LED indikator
se gasi. Uređaj automatski prelazi u modus
održavanja punjenja.

i započeti će postupak

, a LED indikator

, kako biste

ostaje aktivan

Modus 3 „12V“ (14,4V / 3,8A)

Ovaj se modus uglavnom koristi za punjenje olovnih
baterija napona 12V i kapaciteta većeg od 14 Ah,
pod normalnim uvjetima.

♦ Pritisnite tipku za odabir MODE

odabrali modus 3 (
obavljate dodatna podešavanja, elektronika će
se uključiti zajedno s LED indikatorom
i započeti će postupak punjenja. Ukoliko ovaj
postupak prođe bez problema, LED indikator

ostaje aktivan za vrijeme cijelog postupka
punjenja, sve dok se baterija ne napuni. Kada
je baterija potpuno napunjena, zasvijetliti će
LED indikator
se gasi. Uređaj automatski prelazi u modus
održavanja punjenja.

). Ukoliko nakon toga ne

, a LED indikator

, kako biste

Modus 4 „12V“ (14,7V / 3,8A)

Ovaj se modus koristi za punjenje olovnih baterija
od 12V kapaciteta većeg od 14 Ah u hladnim
uvjetima ili za punjenje nekih AGM baterija kapaci­teta većeg od 14 Ah.

♦ Pritisnite tipku za odabir MODE

odabrali modus 4 (
obavljate dodatna podešavanja, elektronika će
se uključiti zajedno s LED indikatorom

). Ukoliko nakon toga ne

, kako biste

i započeti će postupak punjenja. U ovom je
modusu struja punjenja ista kao u modusu 3
(

). Ukoliko ovaj postupak prođe bez pro­blema, LED indikator
vrijeme cijelog postupka punjenja, sve dok se
baterija ne napuni. Kada je baterija potpuno
napunjena, zasvijetliti će LED indikator
LED indikator
prelazi u modus održavanja punjenja.

ostaje aktivan za

se gasi. Uređaj automatski

Automatsko prepoznavanje baterija

Čim se punjač priključi na mrežu, na uređaju svijetli
LED indikator .

Punjač prepoznaje bateriju na temelju sljedećih
kriterija:

Ako je napon baterije manji od 3,8 V ili veći od
15 V, baterija je neispravna ili nije prikladna za
punjenje. U tom slučaju trepere LED indikatori

, ,
modusu“ i tipkom za odabir MODE ne može se
odabrati niti jedan drugi modus punjenja.

i . Punjač ostaje u „Standby

Modus impulsnog punjenja

Ovaj modus prikladan je za punjenje/regeneriranje
praznih, istrošenih i prenapunjenih olovnih baterija
od 12V.

Kada je punjač priključen na bateriju i uređaj za­počne s punjenjem, automatski prepoznaje napon
baterije. Prebacuje u impulsni modus punjenja
kada je napon u području od 7,5V ± 0,5 do
10,5V ± 0,5V.

Ovaj impulsni tijek punjenja nastavlja se sve dok
napon baterije ne poraste i dostigne 10,5 V ± 0,5 V.

Čim se dostigne ovo stanje, punjač prelazi u nor­malni, prethodno odabrani modus punjenja.

Sada se baterija može brzo i sigurno napuniti.
Ovim postupkom možete ponovo napuniti i koristiti
većinu praznih baterija.

NAPOMENA

► Tijekom impulsnog punjenja treperi LED

indikator

.

, a

■ 16 │ HR

ULG 3.8 B1
