TP-Link TL-SG2210P, TL-SG2216, TL-SG2424, TL-SG2424P, TL-SG2452 User Manual
TL-SG2210P/TL-SG2216/TL-SG2424/
TL-SG2424P/TL-SG2452
Gigabit Smart Switch
REV1.3.0
1910011017
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice. is a registered trademark of
TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or
registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from TP-LINK
TECHNOLOGIES CO., LTD. Copyright © 2014 TP-LINK TECHNOLOGIES CO., LTD. All rights
reserved.
http://www.tp-link.com
I
CONTENTS
Preface ………………………………………………………………………………….1
Chapter 1 Using the CLI ....................................................................................... 3
1.1 Accessing the CLI..............................................................................................................3
1.1.1. Logon by Telnet..................................................................................................3
1.1.2. Logon by SSH
1.2 CLI Command Modes......................................................................................................10
1.3 Security Levels ................................................................................................................12
1.4 Conventions ....................................................................................................................13
1.4.1 Format Conventions ..............................................................................................13
1.4.2 Special Characters ................................................................................................13
1.4.3 Parameter Format .................................................................................................13
....................................................................................................4
Chapter 2 User Interface .................................................................................... 14
enable....................................................................................................................................14
enable password ...................................................................................................................14
disable...................................................................................................................................15
configure................................................................................................................................15
exit.........................................................................................................................................16
end ........................................................................................................................................16
history....................................................................................................................................16
history clear ...........................................................................................................................17
Chapter 3 IEEE 802.1Q VLAN Commands ........................................................ 18
vlan........................................................................................................................................18
interface vlan .........................................................................................................................18
name .....................................................................................................................................19
switchport general allowed vlan.............................................................................................19
switchport pvid.......................................................................................................................20
show vlan summary...............................................................................................................20
show vlan brief ......................................................................................................................21
show vlan ..............................................................................................................................21
show interface switchport ......................................................................................................22
Chapter 4 Voice VLAN Commands.................................................................... 23
voice vlan ..............................................................................................................................23
voice vlan aging time.............................................................................................................23
II
voice vlan priority...................................................................................................................24
voice vlan mac-address.........................................................................................................24
switchport voice vlan mode ...................................................................................................25
switchport voice vlan security ................................................................................................26
show voice vlan .....................................................................................................................26
show voice vlan oui ...............................................................................................................27
show voice vlan switchport ....................................................................................................27
Chapter 5 Etherchannel Commands ................................................................. 29
channel-group .......................................................................................................................29
port-channel load-balance .....................................................................................................30
lacp system-priority ...............................................................................................................30
lacp port-priority.....................................................................................................................31
show etherchannel ................................................................................................................31
show etherchannel load-balance...........................................................................................32
show lacp ..............................................................................................................................32
show lacp sys-id ....................................................................................................................33
Chapter 6 User Management Commands ......................................................... 34
user name .............................................................................................................................34
user access-control ip-based.................................................................................................35
user access-control mac-based.............................................................................................35
user access-control port-based .............................................................................................36
user max-number ..................................................................................................................37
user idle-timeout....................................................................................................................37
show user account-list...........................................................................................................38
show user configuration.........................................................................................................38
Chapter 7 System Log Commands.................................................................... 40
logging buffer.........................................................................................................................40
logging file flash.....................................................................................................................41
logging file flash frequency ....................................................................................................41
logging file flash level ............................................................................................................42
clear logging ..........................................................................................................................42
logging host index .................................................................................................................43
show logging local-config ......................................................................................................44
show logging loghost.............................................................................................................44
show logging buffer ...............................................................................................................45
show logging flash.................................................................................................................45
III
Chapter 8 SSH Commands................................................................................. 47
ip ssh server ..........................................................................................................................47
ip ssh version ........................................................................................................................47
ip ssh timeout ........................................................................................................................48
ip ssh max-client....................................................................................................................48
ip ssh download.....................................................................................................................49
show ip ssh............................................................................................................................49
Chapter 9 SSL Commands................................................................................. 51
ip http secure-server..............................................................................................................51
ip http secure-server download certificate .............................................................................51
ip http secure-server download key.......................................................................................52
show ip http secure-server ....................................................................................................53
Chapter 10 MAC Address Commands................................................................. 54
mac address-table static........................................................................................................54
mac address-table aging-time ...............................................................................................55
mac address-table filtering ....................................................................................................55
mac address-table max-mac-count .......................................................................................56
show mac address-table address..........................................................................................57
show mac address-table aging-time......................................................................................57
show mac address-table max-mac-count interface gigabitEthernet ......................................58
show mac address-table interface gigabitEthernet................................................................58
show mac address-table mac-num........................................................................................59
show mac address-table mac................................................................................................59
show mac address-table vlan ................................................................................................60
Chapter 11 System Commands ........................................................................... 61
system-time manual ..............................................................................................................61
system-time ntp .....................................................................................................................61
system-time dst predefined ...................................................................................................63
system-time dst date .............................................................................................................64
system-time dst recurring ......................................................................................................65
hostname...............................................................................................................................66
location..................................................................................................................................66
contact-info............................................................................................................................67
ip management-vlan..............................................................................................................67
ip address..............................................................................................................................68
IV
ip address-alloc dhcp ............................................................................................................68
ip address-alloc bootp ...........................................................................................................69
reset ......................................................................................................................................69
reboot ....................................................................................................................................70
copy running-config startup-config ........................................................................................70
copy startup-config tftp ..........................................................................................................71
copy tftp startup-config ..........................................................................................................71
firmware upgrade ..................................................................................................................72
ping .......................................................................................................................................72
tracert ....................................................................................................................................73
loopback interface gigabitEthernet ........................................................................................74
show system-info...................................................................................................................74
show running-config ..............................................................................................................75
show system-time..................................................................................................................75
show system-time dst............................................................................................................75
show system-time ntp............................................................................................................76
show cable-diagnostics interface gigabitEthernet..................................................................76
Chapter 12 Ethernet Configuration Commands ................................................. 78
interface gigabitEthernet........................................................................................................78
interface range gigabitEthernet .............................................................................................78
description .............................................................................................................................79
shutdown ...............................................................................................................................79
flow-control ............................................................................................................................80
media-type.............................................................................................................................80
duplex....................................................................................................................................81
speed.....................................................................................................................................81
storm-control broadcast.........................................................................................................82
storm-control multicast ..........................................................................................................83
storm-control unicast .............................................................................................................85
storm-control rate ..................................................................................................................86
bandwidth ..............................................................................................................................87
clear counters........................................................................................................................87
show interface status.............................................................................................................88
show interface counters.........................................................................................................88
show interface description .....................................................................................................89
show interface flowcontrol .....................................................................................................89
show interface configuration..................................................................................................90
V
show storm-control ................................................................................................................90
show bandwidth.....................................................................................................................91
Chapter 13 QoS Commands................................................................................. 92
qos ........................................................................................................................................92
qos cos..................................................................................................................................93
qos dscp................................................................................................................................94
qos queue cos-map...............................................................................................................94
qos queue dscp-map.............................................................................................................95
qos queue mode....................................................................................................................97
show qos interface ................................................................................................................98
show qos cos-map ................................................................................................................98
show qos dscp-map ..............................................................................................................99
show qos queue mode ..........................................................................................................99
show qos status...................................................................................................................100
Chapter 14 Port Mirror Commands ....................................................................101
monitor session destination interface ..................................................................................101
monitor session source interface.........................................................................................102
show monitor session..........................................................................................................103
Chapter 15 Port Isolation Commands ................................................................104
port isolation ........................................................................................................................104
show port isolation interface ................................................................................................104
Chapter 16 Loopback Detection Commands.....................................................106
loopback-detection(global) ..................................................................................................106
loopback-detection interval..................................................................................................106
loopback-detection recovery-time........................................................................................ 107
loopback-detection(interface) ..............................................................................................107
loopback-detection config....................................................................................................108
loopback-detection recover .................................................................................................109
show loopback-detection global ..........................................................................................109
show loopback-detection interface ...................................................................................... 110
Chapter 17 ACL Commands................................................................................111
access-list create................................................................................................................. 111
mac access-list.................................................................................................................... 111
access-list standard............................................................................................................. 112
VI
access-list extended............................................................................................................113
rule ...................................................................................................................................... 114
access-list policy name........................................................................................................ 114
access-list policy action.......................................................................................................115
access-list bind(interface)....................................................................................................116
access-list bind(vlan)........................................................................................................... 116
show access-list ..................................................................................................................117
show access-list policy ........................................................................................................ 117
show access-list bind .......................................................................................................... 118
Chapter 18 DHCP Filtering Commands..............................................................119
ip dhcp filtering .................................................................................................................... 119
ip dhcp filtering trust ............................................................................................................ 119
show ip dhcp filtering...........................................................................................................120
show ip dhcp filtering interface ............................................................................................120
Chapter 19 PoE Commands................................................................................121
power inline consumption (global) .......................................................................................121
power profile........................................................................................................................121
power time-range ................................................................................................................122
power holiday ......................................................................................................................123
absolute...............................................................................................................................124
periodic................................................................................................................................124
holiday.................................................................................................................................125
power inline consumption (interface)...................................................................................126
power inline priority .............................................................................................................127
power inline supply..............................................................................................................127
power inline profile ..............................................................................................................128
power inline time-range .......................................................................................................128
show power inline................................................................................................................129
show power inline configuration interface............................................................................ 129
show power inline information interface...............................................................................130
show power profile ..............................................................................................................130
show power holiday.............................................................................................................130
show power time-range .......................................................................................................131
Chapter 20 MSTP Commands .............................................................................132
spanning-tree(global)...........................................................................................................132
spanning-tree(interface) ......................................................................................................132
VII
spanning-tree common-config .............................................................................................133
spanning-tree mode.............................................................................................................134
spanning-tree mst configuration ..........................................................................................135
instance...............................................................................................................................135
name ................................................................................................................................... 136
revision................................................................................................................................136
spanning-tree mst instance .................................................................................................137
spanning-tree mst................................................................................................................137
spanning-tree priority........................................................................................................... 138
spanning-tree tc-defend.......................................................................................................139
spanning-tree timer..............................................................................................................140
spanning-tree hold-count..................................................................................................... 140
spanning-tree max-hops......................................................................................................141
spanning-tree bpdufilter....................................................................................................... 142
spanning-tree bpduguard ....................................................................................................142
spanning-tree guard loop.....................................................................................................143
spanning-tree guard root .....................................................................................................143
spanning-tree guard tc.........................................................................................................144
spanning-tree mcheck ......................................................................................................... 144
show spanning-tree active................................................................................................... 145
show spanning-tree bridge ..................................................................................................145
show spanning-tree interface ..............................................................................................146
show spanning-tree interface-security.................................................................................146
show spanning-tree mst ......................................................................................................147
Chapter 21 IGMP Commands..............................................................................149
ip igmp snooping(global) .....................................................................................................149
ip igmp snooping(interface) .................................................................................................149
ip igmp snooping immediate-leave ...................................................................................... 150
ip igmp snooping drop-unknown..........................................................................................150
ip igmp snooping vlan-config ...............................................................................................151
ip igmp snooping multi-vlan-config ......................................................................................152
ip igmp snooping filter add-id...............................................................................................153
ip igmp snooping filter(global)..............................................................................................154
ip igmp snooping filter(interface) .........................................................................................154
ip igmp snooping filter maxgroup.........................................................................................155
ip igmp snooping filter mode................................................................................................155
show ip igmp snooping........................................................................................................156
VIII
show ip igmp snooping interface .........................................................................................156
show ip igmp snooping vlan ................................................................................................157
show ip igmp snooping multi-vlan........................................................................................ 158
show ip igmp snooping groups ............................................................................................ 158
show ip igmp snooping filter ................................................................................................159
Chapter 22 SNMP Commands.............................................................................161
snmp-server ........................................................................................................................161
snmp-server view ................................................................................................................161
snmp-server group ..............................................................................................................162
snmp-server user ................................................................................................................163
snmp-server community ......................................................................................................165
snmp-server host.................................................................................................................165
snmp-server engineID .........................................................................................................167
snmp-server traps snmp...................................................................................................... 167
snmp-server traps link-status...............................................................................................168
snmp-server traps................................................................................................................169
snmp-server traps mac........................................................................................................ 170
snmp-server traps vlan........................................................................................................170
rmon history.........................................................................................................................171
rmon event ..........................................................................................................................172
rmon alarm ..........................................................................................................................173
show snmp-server ...............................................................................................................174
show snmp-server view .......................................................................................................175
show snmp-server group .....................................................................................................175
show snmp-server user .......................................................................................................176
show snmp-server community.............................................................................................176
show snmp-server host .......................................................................................................176
show snmp-server engineID................................................................................................177
show rmon history ...............................................................................................................177
show rmon event
.................................................................................................................178
show rmon alarm.................................................................................................................178
Chapter 23 LLDP Commands..............................................................................179
lldp.......................................................................................................................................179
lldp hold-multiplier................................................................................................................179
lldp timer..............................................................................................................................180
lldp med-fast-count..............................................................................................................181
IX
lldp receive ..........................................................................................................................181
lldp transmit .........................................................................................................................182
lldp snmp-trap......................................................................................................................182
lldp tlv-select........................................................................................................................183
lldp med-location .................................................................................................................184
lldp med-status ....................................................................................................................184
lldp med-tlv-select................................................................................................................185
show lldp ............................................................................................................................. 186
show lldp interface...............................................................................................................186
show lldp local-information interface....................................................................................187
show lldp neighbor-information interface .............................................................................187
show lldp traffic interface.....................................................................................................188
X
Preface
This Guide is intended for network administrator to provide referenced information about CLI
(Command Line Interface). The device mentioned in this Guide stands for
TL-SG2210P/TL-SG2216/TL-SG2424/TL-SG2424P/TL-SG2452 Gigabit Smart Switch.
The five devices of TL-SG2210P/TL-SG2216/TL-SG2424/TL-SG2424P/TL-SG2452 are sharing
this Guide. For simplicity, we will take TL-SG2424 for example throughout this Guide.
Overview of this Guide
Chapter 1: Using the CLI
Provide information about how to use the CLI, CLI Command Modes, Security Levels and some
Conventions.
Chapter 2: User Interface
Provide information about the commands used to switch between five CLI Command Modes.
Chapter 3: IEEE 802.1Q VLAN Commands
Provide information about the commands used for configuring IEEE 802.1Q VLAN.
Chapter 4: Voice VLAN Commands
Provide information about the commands used for configuring Voice VLAN.
Chapter 5: Etherchannel Commands
Provide information about the commands used for configuring LAG (Link Aggregation Group) and
LACP (Link Aggregation Control Protocol).
Chapter 6: User Management Commands
Provide information about the commands used for user management.
Chapter 7: System Log Commands
Provide information about the commands used for configuring system log.
Chapter 8: SSH Commands
Provide information about the commands used for configuring and managing SSH (Security
Shell).
Chapter 9: SSL Commands
Provide information about the commands used for configuring and managing SSL (Secure
Sockets Layer).
Chapter 10: MAC Address Commands
Provide information about the commands used for Address configuration.
1
Chapter 11: System Configuration Commands
Provide information about the commands used for configuring the System information and System
IP, reboot and reset the switch, upgrade the switch system and commands used for device
diagnose, including loopback test and cable test.
Chapter 12: Ethernet Configuration Commands
Provide information about the commands used for configuring the Bandwidth Control, Negotiation
Mode, and Storm Control for enthernet ports.
Chapter 13: QoS Commands
Provide information about the commands used for configuring the QoS function.
Chapter 14: Port Mirror Commands
Provide information about the commands used for configuring the Port Mirror function.
Chapter 15: Port Isolation Commands
Provide information about the commands used for configuring Port Isolation function.
Chapter 16: Loopback Detection Commands
Provide information about the commands used for configuring the Loopback Detection function.
Chapter 17: ACL Commands
Provide information about the commands used for configuring the ACL (Access Control List).
Chapter 18: DHCP Filtering Commands
Provide information about the commands used for configuring the DHCP Filtering function.
Chapter 19: PoE Commands
Provide information about the commands used for configuring PoE function.
Chapter 20: MSTP Commands
Provide information about the commands used for configuring the MSTP (Multiple Spanning Tree
Protocol).
Chapter 21: IGMP Commands
Provide information about the commands used for configuring the IGMP Snooping (Internet Group
Management Protocol Snooping).
Chapter 22: SNMP Commands
Provide information about the commands used for configuring the SNMP (Simple Network
Management Protocol) functions.
Chapter 23: LLDP Commands
Provide information about the commands used for configuring LLDP function.
2
Chapter 1 Using the CLI
1.1 Accessing the CLI
You can log on to the switch and access the CLI by logging on to the switch remotely by a Telnet or
SSH connection through an Ethernet port.
1.1.1. Logon by Telnet
To log on to the switch by a Telnet connection, please take the following steps:
1. Click Start → Run to open the Run window, and type in telnet 192.168.0.1 in the prompt Run
window as Figure 1-1 and click OK.
Figure 1-1 Run Window
2. Type in the User name and Password (the factory default value for both of them are admin)
and press the Enter button to enter User EXEC Mode , which is shown as Figure 1-2.
Figure 1-2 Log in the Switch
3. Type in enable command to enter Privileged EXEC Mode.
Figure 1-3 Enter into Priviledged EXEC Mode
3
1.1.2. Logon by SSH
To log on by SSH, a Putty client software is recommended. There are two authentication modes to
set up an SSH connection:
Password Authentication Mode: It requires username and password, which are both admin by
default.
Key Authentication Mode: It requires a public key for the switch and a private key for the SSH
client software. You can generate the public key and the private key through Putty Key Generator.
Note:
Before SSH login, please follow the steps shown in Figure 1-4 to enable the SSH function through
Telnet connection.
Figure 1-4 Enable SSH function
Password Authentication Mode
1. Open the software to log on to the interface of PuTTY. Enter the IP address of the switch into
Host Name field; keep the default value 22 in the Port field; select SSH as the Connection
type.
4
Figure 1-5 SSH Connection Config
2. Click the Open button in the above figure to log on to the switch. Enter the login user name
and password to log on the switch, and then enter enable to enter Privileged EXEC Mode, so
you can continue to configure the switch.
Figure 1-6 Log on the Switch
5
Key Authentication Mode
1. Select the key type and key length, and generate SSH key.
Figure 1-7 Generate SSH Key
Note:
1. The key length is in the range of 256 to 3072 bits.
2. During the key generation, randomly moving the mouse quickly can accelerate the key
generation.
6
2. After the key is successfully generated, please save the public key and private key to a TFTP
server.
Figure 1-8 Save the Generated Key
3. Log on to the switch by Telnet and download the public key file from the TFTP server to the
switch, as the following figure shows:
7
Figure 1-9 Download the Public Key
Note:
1. The key type should accord with the type of the key file.
2. The SSH key downloading can not be interrupted.
4. After the public key is downloaded, please log on to the interface of PuTTY and enter the IP
address for login.
8
Figure 1-10 SSH Connection Config
5. Click Browse to download the private key file to SSH client software and click Open.
Figure 1-11 Download the Private Key
9
6. After successful authentication, please enter the login user name. If you log on to the switch
without entering password, it indicates that the key has been successfully downloaded.
Figure 1-12 Log on the Switch
1.2 CLI Command Modes
The CLI is divided into different command modes: User EXEC Mode, Privileged EXEC Mode,
Global Configuration Mode, Interface Configuration Mode and VLAN Configuration Mode.
Interface Configuration Mode can also be divided into Interface Ethernet, Interface
link-aggregation and some other modes, which is shown as the following diagram.
Interface Configuration Mode
Interface gigabitEthernet
User EXEC Mode
Interface link-aggregation
Interface range gigabitEthernet
password
Interface range link-aggregation
Interface vlan
Privileged EXEC
Mode
Global Configuration
Mode
……
VLAN Configuration Mode
The following table gives detailed information about the Accessing path, Prompt of each mode and
how to exit the current mode and access the next mode.
Mode
Accessing
Prompt
Path
Logout or Access the next
mode
User EXEC
Mode
Primary mode
once it is
connected with the
switch.
Use the exit command to
disconnect the switch.
TL-SG2424>
Use the enable command to
access Privileged EXEC mode.
10
Mode
Privileged
EXEC Mode
Global
Configuration
Mode
Accessing
Path
Use the enable
command to enter
this mode from
User EXEC mode.
Use the configure
command to enter
this mode from
Privileged EXEC
mode.
Prompt
TL- SG2424#
TL- SG2424 (config)#
Logout or Access the next
mode
Enter the disable or the exit
command to return to User EXEC
mode.
Enter configure command to
access Global Configuration mode.
Use the exit or the end command
or press Ctrl+Z to return to
Privileged EXEC mode.
Use the interface gigabitEthernet
port or interface range
gigabitEthernet port-list command
to access interface Configuration
mode.
Use the vlan vlan-list to access
VLAN Configuration mode.
Interface
Configuration
Mode
VLAN
Configuration
Mode
Use the interface
type number
command to enter
this mode from
Global
Configuration
mode.
Use the vlan
vlan-list command
to enter this mode
from Global
Configuration
mode.
TL-SG2424(config-if-range)#
TL-SG2424 (config-vlan)#
TL-SG2424 (config-if)#
or
Use the end command or press
Ctrl+Z to return to Privileged EXEC
mode.
Enter exit command or the #
command to return to Global
Configuration mode.
A port number must be specified in
the interface command.
Use the end command or press
Ctrl+Z to return to Privileged EXEC
mode.
Enter the exit command or the #
command to return to Global
configuration mode.
Note:
1. The user is automatically in User EXEC Mode after the connection between the PC and the
switch is established by a Telnet/SSH connection.
2. Each command mode has its own set of specific commands. To configure some commands,
you should access the corresponding command mode firstly.
Global Configuration Mode: In this mode, global commands are provided, such as the
Spanning Tree, Schedule Mode and so on.
11
Interface Configuration Mode: In this mode, users can configure one or several ports,
different ports corresponds to different commands
a). Interface gigabitEthernet: Configure parameters for an Ethernet port, such as
Duplex-mode, flow control status.
b). Interface range gigabitEthernet: Configure parameters for several Ethernet ports.
c). Interface link-aggregation: Configure parameters for a link-aggregation, such as
broadcast storm.
d). Interface range link-aggregation: Configure parameters for multi-trunks.
e). Interface vlan: Configure parameters for the vlan-port.
Vlan Configuration Mode: In this mode, users can create a VLAN and add a specified
port to the VLAN.
3. Some commands are global, that means they can be performed in all modes:
show: display all information of switch, for example: statistic information, port information,
VLAN information.
history: Display the commands history.
1.3 Security Levels
This switch’s security is divided into two levels: User level and Admin level.
User level only allows users to do some simple operations in User EXEC Mode; Admin level
allows you to monitor, configure and manage the switch in Privileged EXEC Mode, Global
Configuration Mode, Interface Configuration Mode and VLAN Configuration Mode.
Users get the privilege to the User level once logging in by Telnet/SSH. However, Guest users are
restricted to access the CLI.
Users can enter Privileged EXEC mode from User EXEC mode by using the enable command. In
default case, no password is needed. In Global Configuration Mode, you can configure password
for Admin level by enable password command. Once password is configured, you are required to
enter it to access Privileged EXEC mode.
12
1.4 Conventions
1.4.1 Format Conventions
The following conventions are used in this Guide:
Items in square brackets [ ] are optional
Items in braces { } are required
Alternative items are grouped in braces and separated by vertical bars. For example: speed
{10 | 100 | 1000 }
Bold indicates an unalterable keyword. For example: show logging
Normal Font indicates a constant (several options are enumerated and only one can be
selected). For example: mode {dynamic | static | permanent}
Italic Font indicates a variable (an actual value must be assigned). For example: bridge
aging-time aging-time
1.4.2 Special Characters
You should pay attentions to the description below if the variable is a character string:
These six characters ” < > , \ & can not be input.
If a blank is contained in a character string, single or double quotation marks should be used,
for example ’hello world’, ”hello world”, and the words in the quotation marks will be identified
as a string. Otherwise, the words will be identified as several strings.
1.4.3 Parameter Format
Some parameters must be entered in special formats which are shown as follows:
MAC address must be enter in the format of xx:xx:xx:xx:xx:xx
One or several values can be typed for a port-list or a vlan-list using comma to separate. Use
a hyphen to designate a range of values, for instance,1/0/1,1/0/3-5,1/0/7 indicates choosing
port 1/0/1,1/0/3,1/0/4,1/0/5,1/0/7.
13
Chapter 2 User Interface
enable
Description
The enable command is used to access Privileged EXEC Mode from User
EXEC Mode.
Syntax
enable
Command Mode
User EXEC Mode
Example
If you have set the password to access Privileged EXEC Mode from User EXEC
Mode:
TL-SG2424>enable
Enter password：
TL-SG2424#
enable password
Description
The enable password command is used to set the password for users to
access Privileged EXEC Mode from User EXEC Mode. To return to the default
configuration, please use no enable password command.
Syntax
enable password password [ secret { simple | cipher } ]
no enable password
Parameter
password —— super password, which can contains 31 characters at most,
composing digits, English letters and underdashes only. By default, it is empty.
simple | cipher —— The way of displaying password in configuration file. By
default, it is “cipher”.
Command Mode
Global Configuration Mode
14
Example
disable
Description
Syntax
Command Mode
Set the super password as admin to access Privileged EXEC Mode from User
EXEC Mode:
TL-SG2424(config)# enable password admin
The disable command is used to return to User EXEC Mode from Privileged
EXEC Mode.
disable
Privileged EXEC Mode
Example
configure
Description
Syntax
Command Mode
Example
Return to User EXEC Mode from Privileged EXEC Mode:
TL-SG2424# disable
TL-SG2424>
The configure command is used to access Global Configuration Mode from
Privileged EXEC Mode.
configure
Privileged EXEC Mode
Access Global Configuration Mode from Privileged EXEC Mode:
TL-SG2424# configure
TL-SG2424(config)#
15
exit
Description
The exit command is used to return to the previous Mode from the current
Mode.
Syntax
exit
Command Mode
Privileged EXEC Mode and Any Configuration Mode
Example
Return to Global Configuration Mode from Interface Configuration Mode, and
then return to Privileged EXEC Mode:
TL-SG2424(config-if)# exit
TL-SG2424(config)#exit
TL-SG2424#
end
Description
Syntax
Command Mode
Example
history
The end command is used to return to Privileged EXEC Mode.
end
Privileged EXEC Mode and Any Configuration Mode
Return to Privileged EXEC Mode from Interface Configuration Mode:
TL-SG2424(config-if)#end
TL-SG2424#
Description
The history command is used to show the latest 20 commands you entered in
the current mode since the switch is powered.
Syntax
history
16
Command Mode
Privileged EXEC Mode and any Configuration Mode
Example
Show the commands you have entered in the current mode:
TL-SG2424 (config)# history
history clear
Description
The history clear command is used to clear the commands you have entered in
the current mode, therefore these commands will not be shown next time you
use the history command.
1 history
Syntax
history clear
Command Mode
Privileged EXEC Mode and any Configuration Mode
Example
Clear the commands you have entered in the current mode:
TL-SG2424(config)#history clear
17
Chapter 3 IEEE 802.1Q VLAN Commands
VLAN (Virtual Local Area Network) technology is developed for the switch to divide the LAN into
multiple logical LANs flexibly. Hosts in the same VLAN can communicate with each other,
regardless of their physical locations. VLAN can enhance performance by conserving bandwidth,
and improve security by limiting traffic to specific domains.
vlan
Description
The vlan command is used to create IEEE 802.1Q VLAN and enter VLAN
Configuration Mode. To delete the IEEE 802.1Q VLAN, please use no vlan
command.
Syntax
vlan vlan-list
no vlan vlan-list
Parameter
vlan-list —— Specify IEEE 802.1Q VLAN ID list, ranging from 2 to 4094, in the
format of 2-3, 5. It is multi-optional.
Command Mode
Global Configuration Mode
Example
Create VLAN 2-10 and VLAN 100:
TL-SG2424(config)# vlan 2-10,100
Delete VLAN 2:
TL-SG2424(config)# no vlan 2
interface vlan
Description
The interface vlan command is used to create VLAN Interface and enter
Interface VLAN Mode. To delete VLAN Interface, please use no interface vlan
command.
Syntax
interface vlan vlan-id
no interface vlan vlan-id
18
Parameter
Command Mode
Example
name
Description
Syntax
vlan-id —— Specify IEEE 802.1Q VLAN ID, ranging from 1 to 4094.
Global Configuration Mode
Create VLAN Interface 2:
TL-SG2424(config)# interface vlan 2
The name command is used to assign a description to a VLAN. To clear the
description, please use no name command.
name descript
no name
Parameter
descript ——String to describe the VLAN, which contains 16 characters at most.
Command Mode
VLAN Configuration Mode（VLAN）
Example
Specify the name of VLAN 2 as “group1”:
TL-SG2424(config)# vlan 2
TL-SG2424(config-vlan)# name group1
switchport general allowed vlan
Description
Syntax
The switchport general allowed vlan command is used to add the desired
General port to IEEE 802.1Q VLAN and specify the port’s type. To delete the
corresponding VLAN(s), please use no switchport general allowed vlan
command.
switchport general allowed vlan vlan-list { tagged | untagged }
no switchport general allowed vlan vlan-list
19
