M3065_D
Replacement Kit for Snow Sensor 095
Snow Melting
Installation & Operation Manual
Introduction
The M3065 replaces the blue sensor disk of the Snow Sensor 095.
Snow
Sensor
095
Installation
06/13
Replaces: New
It is the installers responsibility to ensure that this sensor is safely installed
according to all applicable codes and standards. tekmar is not responsible for
damages resulting from improper installation and/or maintenance.
Read this Manual BEFORE using this equipment.
Failure to read and follow all safety and use information can result in
personal injury, property damage, or damage to the equipment.
Keep this Manual for future reference.
Step 1 - Check the Contents
Check the contents of this package. If any of the contents listed are missing or damaged,
please refer to the Limited Warranty and Product Return Procedure on the back of this
brochure and contact your wholesaler or tekmar sales representative for assistance.
Type M3065 includes • One Blue Replacement Sensor Disk for Snow Sensor 095
• One Installation and Operation Manual M3065_D.
1 of 4
© 2013
M3065_D - 06/13
Step 2 - Disassembly
1. Remove the outer ring by pulling up on the
three catches.
2. Remove the three screws.
3. Remove the blue sensor disk from the
sensor enclosure.
Avoid scratching any part of the surface of
the blue sensor disk. Scratches will result
in corrosion not covered by warranty.
Step 3 - Wiring
Remove the wiring terminal block by pulling up from the blue
sensor disk. Connect the 4 conductor wire to the yellow (YEL),
blue (BLU), red (RED) and black (BLK) wiring terminations. If
the installed 4 conductor cable uses a different color code, then
make a note of the wire color versus the wiring terminal color
names. Push the wiring terminal plug onto the pins of the blue
sensor disk. At the Snow Melting Control location, connect the
corresponding wires to the yellow, blue, red and black wire
terminations.
Outer Ring
M3065
Sensor Disk
Sensor
Enclosure
Conduit Adapter
(not included)
YEL
BLU
RED
BLK
Snow Sensor 095
Aerial Mounting
Designed & Assembled in Canada
www.tekmarControls.com
Step 4 - Assembly
1. Align the blue sensor disk tekmar logo with the highest point of the sensor enclosure
body. The blue sensor disk has a notch that ensures the sensor is installed in the
correct position.
2. Insert the three screws into the holes and screw them until tight. Do not over
tighten.
3. Align the three notches of the outer ring with the sensor body and push down until
each of the three corners have snapped on tight.
Maintenance
The sensor is installed in a harsh environment. Accumulation of dirt on the surface of the
sensor may affect snow detection. The sensor should be checked on a periodic basis
and, when necessary, cleaned.
1. Remove the outer ring by pulling up on the three catches.
2. A cloth with warm soapy water can be used to clean any dirt.
3. Rinse with water.
4. Align the three notches of the outer ring with the sensor body and push down until
each of the three corners have snapped on tight.
2 of 4
© 2013 M3065_D - 06/13
Testing and Troubleshooting
If the Snow Melt Control shows an error message describing a sensor failure, perform the
following test procedure:
The 4 conductor wires at the sensor should be disconnected.
•
Use a good quality electrical testing meter with an ohm scale range of 0 to 2,000,000
•
Ohms.
Using the ohmmeter and standard testing practices, measure the resistance between:
1. The yellow (YEL) and black (BLK) wiring terminals to measure a 10 kΩ sensor and use
the Temperature vs. Resistance Table to calculate the approximate temperature reading.
Measure the surface temperature of the 095 blue sensor disk and compare versus the
yellow to black temperature reading.
2. Measure the resistance between the blue (BLU) and black (BLK) wiring terminals. When
the sensor surface is clean and dry, the reading should be 2,000,000 Ohms. When the
sensor surface is wet it should be between 10,000 and 300,000 Ohms.
3. Measure the resistance between the red (RED) and black (BLK) wiring terminals This
reading should be between 45 to 47 Ohms.
If resistance readings are outside of the normal operating range, the sensor has failed.
Temperature vs. Resistance Table
Temperature Re sistanc e
°F °C
-50 -46 490,813
-45 -43 405,710
-40 -40 336,606
-35 -37 280,279
-30 -34 234,196
-25 -32 196,358
-20 -29 165,180
-15 -26 139,402
-10 -23 118,018
-5 -21 100,221
0 -18 85,362
5 -15 72,918
10 -12 62,465
15 -9 53,658
20 -7 46,218
25 -4 39,913
30 -1 34,558
35 2 29,996
40 4 26,099
Temperature Re sistance
°F °C
45 7 22,763
50 10 19,900
55 13 17,436
60 16 15,311
65 18 13,474
70 21 11,883
75 24 10,501
80 27 9,299
85 29 8,250
90 32 7,334
95 35 6,532
100 38 5,828
105 41 5,210
110 43 4,665
115 4 6 4 ,18 4
120 49 3,760
125 52 3,383
130 54 3,050
135 57 2,754
Temperature Re sistance
°F °C
140 60 2,490
145 63 2,255
150 66 2,045
155 68 1,857
160 71 1,689
165 74 1,538
170 77 1,403
175 79 1,281
180 82 1,172
185 85 1,073
190 88 983
195 91 903
200 93 829
205 96 763
210 99 703
215 102 648
220 104 598
225 107 553
3 of 4
© 2013 M3065_D - 06/13
Technical Data
Replacement Kit for Snow Sensor 095 M3065
Literature M3065_D
Packaged weight 0.1 lbs (45 g)
Dimensions 9/16" H x 2-3/4" O.D. (16 H x 70 O.D. mm)
Operating range -40 to 122°F (-40 to 50°C)
Limited Warranty and Product Return Procedure
Limited Warranty The liability of tekmar under this warranty is limited. The Purchaser, by taking receipt of
any tekmar product (“Product”), acknowledges the terms of the Limited Warranty in effect at the time of
such Product sale and acknowledges that it has read and understands same.
The tekmar Limited Warranty to the Purchaser on the Products sold hereunder is a manufacturer’s passthrough warranty which the Purchaser is authorized to pass through to its customers. Under the Limited
Warranty, each tekmar Product is warranted against defects in workmanship and materials if the Product
is installed and used in compliance with tekmar’s instructions, ordinary wear and tear excepted. The passthrough warranty period is for a period of twenty-four (24) months from the production date if the Product is
not installed during that period, or twelve (12) months from the documented date of installation if installed
within twenty-four (24) months from the production date.
The liability of tekmar under the Limited Warranty shall be limited to, at tekmar’s sole discretion: the cost of parts
and labor provided by tekmar to repair defects in materials and / or workmanship of the defective product; or to
the exchange of the defective product for a warranty replacement product; or to the granting of credit limited to the
original cost of the defective product, and such repair, exchange or credit shall be the sole remedy available from
tekmar, and, without limiting the foregoing in any way, tekmar is not responsible, in contract, tort or strict product
liability, for any other losses, costs, expenses, inconveniences, or damages, whether direct, indirect, special, secondary, incidental or consequential, arising from ownership or use of the product, or from defects in workmanship
or materials, including any liability for fundamental breach of contract.
The pass-through Limited Warranty applies only to those defective Products returned to tekmar during the warranty period. This Limited Warranty does not cover the cost of the parts or labor to remove or transport the defective Product, or to reinstall the repaired or replacement Product, all such costs and expenses being subject to
Purchaser’s agreement and warranty with its customers.
Any representations or warranties about the Products made by Purchaser to its customers which are different from
or in excess of the tekmar Limited Warranty are the Purchaser’s sole responsibility and obligation. Purchaser shall
indemnify and hold tekmar harmless from and against any and all claims, liabilities and damages of any kind or
nature which arise out of or are related to any such representations or warranties by Purchaser to its customers.
The pass-through Limited Warranty does not apply if the returned Product has been damaged by negligence by
persons other than tekmar, accident, fire, Act of God, abuse or misuse; or has been damaged by modifications,
alterations or attachments made subsequent to purchase which have not been authorized by tekmar; or if the Product was not installed in compliance with tekmar’s instructions and / or the local codes and ordinances; or if due to
defective installation of the Product; or if the Product was not used in compliance with tekmar’s instructions.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, WHICH THE GOVERNING
LAW ALLOWS PARTIES TO CONTRACTUALLY EXCLUDE, INCLUDING, WITHOUT LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, DURABILITY OR DESCRIPTION OF THE PRODUCT, ITS NON-INFRINGEMENT OF ANY RELEVANT PATENTS OR TRADEMARKS, AND
ITS COMPLIANCE WITH OR NON-VIOLATION OF ANY APPLICABLE ENVIRONMENTAL, HEALTH OR SAFETY
LEGISLATION; THE TERM OF ANY OTHER WARRANTY NOT HEREBY CONTRACTUALLY EXCLUDED IS LIMITED SUCH THAT IT SHALL NOT EXTEND BEYOND TWENTY-FOUR (24) MONTHS FROM THE PRODUCTION
DATE, TO THE EXTENT THAT SUCH LIMITATION IS ALLOWED BY THE GOVERNING LAW.
Product Warranty Return Procedure All Products that are believed to have defects in workmanship or materials
must be returned, together with a written description of the defect, to the tekmar Representative assigned to the
territory in which such Product is located. If tekmar receives an inquiry from someone other than a tekmar Representative, including an inquiry from Purchaser (if not a tekmar Representative) or Purchaser’s customers, regarding
a potential warranty claim, tekmar’s sole obligation shall be to provide the address and other contact information
regarding the appropriate Representative.
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or
other reproductive harm. For more information: www.watts.com/prop65
Product design, software and literature are Copyright ©2013 by tekmar Control Systems Ltd.,
A Watts Water Technologies Company. Head Offi ce: 5100 Silver Star Road, Vernon, B.C.
Canada V1B 3K4, 250-545-7749, Fax. 250-545-0650
All specifications are subject
to change without notice.
