VACUUM SEALER SV 120 A1
VACUUM SEALER
Operating instructions
VAKUUMIERER
Bedienungsanleitung
IAN 304253
ΣΥΣΚΕΥΉ ΣΦΡΆΓΙΣΉΣ ΤΡΟΦΙΜΩΝ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / NI / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 19
DE / AT / CH Bedienungsanleitung Seite 37
A
1
q
0
9
2
B
C
u
i
5
4
3
6
7
8
ew
o
p
r
a
t z
s
d
Contents
Introduction ...................................................2
Copyright ............................................................... 2
Limitation of liability ....................................................... 2
Intended use ..................................................2
Package contents and transport inspection .........................3
Unpacking .............................................................. 3
Disposal of packaging materials ............................................. 3
Description of the appliance .....................................4
Technical data .................................................4
Safety guidelines ..............................................5
Setting up and connecting .......................................7
Set-up location requirements ................................................ 7
Electrical connection ...................................................... 7
Welding a tube film .............................................8
Vacuum sealing ...............................................10
Vacuuming the tube film ...................................................10
Vacuuming sealing containers and recloseable bags ............................12
Cleaning .....................................................13
Cleaning the appliance ................................................... 13
Storage .....................................................14
Disposal .....................................................14
Kompernass Handels GmbH warranty ............................15
Service ................................................................ 16
Importer ............................................................... 16
Ordering replacement parts ....................................17
SV 120 A1
GB│IE│NI│CY
│
1 ■
Introduction
Congratulations on the purchase of your new appliance!
You have decided in favour of a modern, high-quality product. These operating
instructions are part of this product. They contain important information on safety,
usage and disposal. Before using the product, familiarise yourself with all handling
and safety guidelines. This appliance may only be used as described and for the
purposes indicated. Please also pass these operating instructions on to any future
owner(s).
Copyright
This documentation is protected by copyright.
Any reproduction, or any reprint even in the form of excerpts, as well as the rendi-
tion of figures even in modified form, is only permitted with the manufacturer’s
written consent.
Limitation of liability
All the technical information, data and instructions regarding installation, connection and operation contained in these operating instructions corresponds to the
latest information available to us at the time of printing and takes our previous
experience and know-how into account.
No claims can be derived from the details, illustrations and descriptions in these
instructions.
The manufacturer assumes no responsibility for damage caused by failure to
observe these instructions, improper use, incompetent repairs, unauthorised
modifications or for the use of non-approved replacement parts.
Intended use
This appliance is intended exclusively for the sealing and vacuum-packing of
foodstuffs in household quantities and only in private households. This device is
not intended for commercial or industrial applications or for continuous use.
It is not intended for any other use or use beyond that specified. Claims of any
kind for damage arising as a result of incorrect use will not be accepted.
The risk shall be borne solely by the user.
■ 2 │ GB
│IE│NI│
CY
SV 120 A1
Package contents and transport inspection
The appliance is supplied with the following components as standard:
▯ Vacuum Sealer
▯ 1 x film roll
▯ 1 x 60 cm tube for recloseable bag
▯ 1 x 60 cm tube for container
▯ 1 x adapter for containers with a larger valve diameter
▯ 1x replacement sealing ring
▯ These operating instructions
NOTE
► Check the package for completeness and for signs of visible damage.
► If the consignment is incomplete or damaged due to defective packaging
or carriage, contact the Service hotline (see the chapter Service).
Unpacking
♦ Remove the appliance, the tube film and the operating instructions from the
carton.
♦ Remove all packaging material.
♦ Remove the protective film from the control panel.
DANGER
► Packaging materials should not be used as a plaything. Risk of suffocation.
Disposal of packaging materials
The packaging protects the appliance from damage during carriage.
The packaging materials have been selected for their environmental friendliness
and ease of disposal, and are therefore recyclable.
Returning the packaging to the materials cycle conserves raw materials and
reduces the amount of waste that is generated. Dispose of packaging materials
that are no longer needed in accordance with applicable local regulations.
Dispose of the packaging in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging material
components for disposal if necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following meanings: 1–7: plastics,
20–22: paper and cardboard, 80–98: composites
NOTE
► If possible, keep the original packaging during the warranty period so that the
device can be properly packed for returning in the event of a warranty claim.
SV 120 A1
GB│IE│NI│CY
│
3 ■
Description of the appliance
Figure A
1 Appliance lid
2 Suction tube
3 Cable retainer
4 Welding wires
5 Lower sealing ring
6 Rear limiters
7 Front limiters
8 Lid release
9 Suction fitting
0 Upper sealing ring
q Press seal
Figure B
w Red control lamp (for monitoring sealing process)
e
button (external vacuuming/stop process)
button (seal/stop process)
r
button (vacuum/stop process)
t
z Green control lamp (for monitoring vacuuming process)
Figure C:
u Vacuum hose for bag
i Suction cup
o Adapter for connecting to appliance
p Vacuum hose for container
a Adapter for containers
s Adapter for connecting to appliance
d Adapter for containers with a large valve diameter
Technical data
Operating voltage
Power consumption 120 W
Protection class
■ 4 │ GB
│IE│NI│
CY
100 - 240 V ∼ (alternating current),
50/60 Hz
(double insulation)
II /
SV 120 A1
Safety guidelines
RISK OF ELECTRIC SHOCK
■ Prior to use, check the device for visible external damage.
Never operate an appliance that is damaged.
■ To avoid risks, arrange for a defective power cable to
be replaced by qualified technicians or by our Customer
Service Department.
■ NEVER use the appliance with a defective power cable.
■ Do not use extension cables or power socket strips that do
not meet the required safety standards.
■ Never open the appliance housing!
■ Remove the plug from the mains power socket before be-
ginning to clean the device.
■ Ensure that no moisture can penetrate the device during
cleaning.
RISK OF INJURY!
■ All repairs must be carried out by authorised special-
ist companies or by the Customer Service department.
Improper repairs may result in a risk of injury to the user
or damage to the appliance. They will also invalidate any
warranty claim.
■ The mains power socket must be easily accessible, so that
the power cable can be easily disconnected in the event
of an emergency.
SV 120 A1
GB│IE│NI│CY
│
5 ■
RISK OF INJURY!
■ Cleaning and user maintenance tasks may not be carried
out by children unless they are supervised.
■ The appliance and its connecting cable must be kept
away from children younger than 8 years old.
■ This appliance may be used by children aged 8 years
and above and by persons with limited physical, sensory
or mental capabilities or lack of experience and knowledge, provided that they are under supervision or have
been told how to use the appliance safely and are aware
of the potential risks.
■ Children must not play with the appliance!
■ Children should be supervised to ensure that they do not
play with the appliance.
■ Do not leave the appliance unsupervised when it is ready
for use. To prevent it being switched on accidentally, always unplug the appliance after use or during breaks.
CAUTION – PROPERTY DAMAGE!
■ Do not use an external timer switch or a separate remote
control system to operate the appliance.
■ 6 │ GB
│IE│NI│
CY
SV 120 A1
Setting up and connecting
Set-up location requirements
For safe and trouble-free operation of the device , the set-up location must fulfil
the following requirements:
■ When setting it up, place the appliance on a firm, flat and horizontal
surface.
■ Do not place the device in a hot, wet or extremely damp environment or in
the vicinity of flammable materials.
■ The mains power socket must be easily accessible, so that the power cable
can be easily disconnected in the event of an emergency.
Electrical connection
CAUTION
► Before you connect the appliance, compare the connection data (voltage
and frequency) on the data plate with that of your mains power network.
These data must agree so that no damage is sustained by the device.
► Ensure that the power cable is undamaged and is not routed over hot
surfaces and/or sharp edges.
► Ensure that the power cable is not taut or kinked.
► Do not let the power cable hang over edges (trip wire effect).
♦ Insert the plug into the mains mains power socket.
SV 120 A1
GB│IE│NI│CY
│
7 ■
Welding a tube film
NOTES ON THE FILM
► The film width may not exceed 30 cm. Otherwise it cannot be welded
correctly.
► Use only nylon-PE films with a structure (points or grooves) on one side and
that have a structure (points or grooves) on one side and a thickness of
approximately 0.17 - 0.29 mm (170 - 290 μ).
Otherwise the weld seam will not be tight and the appliance may be da-
maged. You can recognise films of this type from the information on the
packaging. The quality of the weld seam will vary depending on the type
and thickness of the film.
► The supplied film is suitable for temperatures between -20°C and +110°C.
1) Cut the desired length for your bag from the tube film using a pair of scissors.
Cut as straight as possible.
2) Open the appliance lid 1 by pressing the lid release 8 and opening the
lid 1 upwards.
3) Lay the open end of the bag as far into the appliance so that the opening of
the bag is located centrally under the lower sealing ring 5. The bag should
be inserted no further than the rear limiters 6 and must lie between the front
limiters 7. If the bag lies over one or both of the two limiters 7, then the
bag cannot be correctly welded.
■ 8 │ GB
│IE│NI│
CY
SV 120 A1
NOTE
► The bag opening must lie flat on the welding wire 4. Otherwise the weld-
ing does not work properly.
4) Close the appliance lid 1. The press seal q presses the bag onto the welding
wire 4, to create a smooth seam. Ensure that both corners of the appliance
lid 1 click closed. If necessary, press them down once again on the markings
and so that the appliance lid 1 clicks into place and locks shut.
5) Press the
sealing process is finished, the red control lamp w goes off.
NOTE
► You can halt the sealing process at any time by pressing the
again. The red control lamp goes out w.
CAUTION – PROPERTY DAMAGE!
If the red control lamp w does not go out after a maximum of
10 seconds, there is a fault with the appliance.
► Remove the plug from the mains power socket immediately. Do not attempt
to repair the appliance yourself. Contact the Customer Service department.
6) Open the appliance lid 1 by pressing the lid release 8 and flipping the lid 1
upwards. Remove the bag. This is now sealed at one end.
NOTE
► Ensure that the weld seam is properly closed. A correct weld seam should
be a smooth, straight stripe without any creases.
7) Fill the bag. You must leave at least 6 cm of the bag free up to the edge to
be welded.
button r. The red control lamp w lights up. As soon as the
button r
SV 120 A1
CAUTION – PROPERTY DAMAGE!
► Fill the bag so that no food scraps or liquids can leak out during welding
and get into the appliance.
8) If you do not want to vacuum the bag, you can now weld the other, open side.
NOTE
► Wait 15 seconds before sealing the next bag to allow the appliance to
cool down.
During this cool-down phase, you cannot start the “seal” function.
GB│IE│NI│CY
│
9 ■
Vacuum sealing
Vacuuming the tube film
You can also suck the air out of the bag (vacuum) during welding:
NOTE
► Do not evacuate bags that contain only liquids. These could be sucked up
during the vacuum sealing process.
If small quantities of liquid or food do get sucked up, they will be deposited
in the small drip tray that is located between the lower sealing ring 5.
1) Lay the open end of the bag as far into the appliance so that the opening of
the bag is located centrally under the lower sealing ring 5. The bag should
be inserted no further than the rear limiters 6 and must lie between the front
limiters 7. Otherwise the vacuuming and welding will not function correctly:
■ 10 │ GB
2) Close the appliance lid 1. Ensure that both corners of the appliance lid 1
click closed. If necessary, press them down once again on the markings
and so that the appliance lid 1 clicks into place and locks shut.
NOTE
► Ensure that the upper 0 and the lower sealing rings 5 are not damaged!
Otherwise the device cannot suck the air out of the bag.
► If either one of the sealing rings 0/5 is damaged, simply pull it out of the
groove and press the replacement sealing ring into the groove.
│IE│NI│
CY
SV 120 A1
3) Press the button t. The green control lamp z lights up and the appliance
sucks the air out of the bag. As soon as all the air is sucked out, the green
control lamp z goes out and the red control lamp w lights up. The appliance
now seals the bag.
4) If both control lamps w/z have gone out, you can open the lid by pressing
the lid catch 8 and flipping the lid 1 upwards. Remove the vacuum-sealed
bag.
NOTE
► You can stop the vacuuming process at any time by pressing the button t
at any time. The green control lamp z will then go off. Press the
button t
If the appliance has already switched to the sealing process and the red
control lamp q is lit, the process can be stopped with the button r.
The appliance then stops the sealing process.
► Once you have sealed 5 bags in a row, allow the appliance to cool down
for about 1 minute.
During this cool-down phase, you cannot start the appliance. After the
cool-down phase, you can use the appliance as normal.
TIP – "SOUS-VIDE COOKING"
► As the supplied film is suitable for temperatures between -20°C and
+110°C, it can be used for the so-called "sous-vide" cooking process
(vacuum cooking).
"Sous-vide" is French and means "under vacuum".
In vacuum cooking, the food (usually fish or meat, but vegetables can
also be used) is vacuum-sealed in a bag and then cooked in water or steam
cooked at a relatively low temperature (50 to 90 C). The advantage of this is
that volatile flavours or aroma are not lost during cooking. The food does not
dry out and the vitamins and flavours are preserved. Herbs or spices that are
vacuum-sealed in the bag with the food give off a more intense flavour.
again to resume the extraction process.
SV 120 A1
GB│IE│NI│CY
│
11 ■
Vacuuming sealing containers and recloseable bags
You can vacuum seal containers and recloseable bags using the vacuum hoses
and appropriate adapters supplied with the appliance.
NOTE
► You can order suitable bags and container separately. Please refer to
Chapter "Ordering replacement parts".
► The vacuum hoses u/p, the suction cup i and the adapters a/d are
also compatible with bags and containers made by the manufacturers.
Vacuuming sealing bags:
1) Connect the vacuum hose u onto the suction fitting 9 on the appliance
using the adapter o.
2) Close the appliance lid 1. Ensure that both corners of the appliance lid 1
click closed. If necessary, press downwards again on the markings
so that the appliance lid 1 clicks into place and locks shut.
3) Close the bag to be vacuum sealed carefully. Vacuum sealing only works
properly if the bag is completely closed off. We recommend positioning the
bag so that the round extraction opening is placed on a smooth surface.
4) Press the suction cup i firmly onto the round extraction opening on the bag.
5) Press the
sucks the air out of the bag. As soon as all the air is sucked out, the green
control lamp z goes out.
6) You can now remove the suction cup i from the bag.
button e. The green control lamp z lights up and the appliance
and
■ 12 │ GB
Vacuum sealing containers:
1) Connect the vacuum hose p to the suction fitting 9 on the appliance using
the adapter s.
2) Close the appliance lid 1. Ensure that both corners of the appliance lid 1
click closed. If necessary, press downwards again on the markings
so that the appliance lid 1 clicks into place and locks shut.
3) Connect the adapter a to the appropriate container fitting. Please refer to
the container instruction manual for further information.
NOTE
► For containers with a large valve diameters, use the adapter d. This is
pressed onto the adapter for containers a.
4) Press the button e. The green control lamp z lights up and the appliance
sucks the air out of the container. As soon as all the air is sucked out, the green
control lamp z goes out.
5) You can now remove the adapters a/s from the container and the appliance.
│IE│NI│
CY
and
SV 120 A1
Cleaning
DANGER
Risk of fatal injury from electrocution!
► Remove the plug from the mains power socket before beginning to clean
the device.
► Ensure that no moisture can penetrate the device during cleaning.
CAUTION
Possible damage to the appliance.
► Do not use aggressive or abrasive cleaning agents, as these may corrode
the surface of the casing.
► Do not use any hard or sharp objects to remove any adhesive from the
welding wire 4. Otherwise the welding wire 4 or the insulation could
be damaged.
Cleaning the appliance
♦ Clean the surface of the housing of the appliance with a lightly moistened
cloth and a mild detergent.
♦ Wipe off the upper 0 and the lower sealing rings 5, as well as the press
seal q with a damp cloth. Ensure that the appliance is dry before using it again.
♦ Wipe the vacuum hoses u/p, the suction cup i and the adapters o/a/
s/d with a damp cloth. If there is heavy soiling, you can also clean these
parts in hot water with a little detergent. Ensure that all components are
completely dry before the next use.
♦ Clean the drip tray that is located between the lower sealing ring 5 in warm
water with a little detergent.
You can also clean the drip tray in the dishwasher, if required. Make
sure that the drip tray does not get jammed in the dishwasher. Use
the upper basket in the dishwasher if possible.
SV 120 A1
GB│IE│NI│CY
│
13 ■
Storage
The appliance has a built-in cable retainer 3 on the underside of the housing,
on which you can wrap the power cable when it is not in use. This prevents the
power cable from getting caught or soiled, or becoming a source of danger by
hanging loosely down.
CAUTION
Possible damage to the appliance.
Disposal
Under no circumstances should you dispose of the appliance
with the normal household waste.
This product is subject to the provisions of European Directive
2012/19/EU (Waste Electrical and Electronic Equipment).
Dispose of the appliance via an approved waste disposal company or your
municipal waste disposal facility. Please observe applicable regulations. In
case of doubt, please contact your waste disposal centre.
Your local community or municipal authorities can provide information on how to
dispose of the worn-out product.
► Do not click the appliance lid 1 closed for storage! When the appliance
lid 1 is clicked closed it exerts permanent pressure on the upper 0 and
lower sealing rings 5, as well as the press seal q. This can negatively
affect their function.
♦ Store the appliance in a clean, dry place away from direct sunlight.
■ 14 │ GB
│IE│NI│
CY
SV 120 A1
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase. If this product
has any faults, you, the buyer, have certain statutory rights. Your statutory rights
are not restricted in any way by the warranty described below.
Warranty conditions
The validity period of the warranty starts from the date of purchase. Please keep
your original receipt in a safe place. This document will be required as proof of
purchase.
If any material or production fault occurs within three years of the date of purchase
of the product, we will either repair or replace the product for you at our discretion.
This warranty service is dependent on you presenting the defective appliance
and the proof of purchase (receipt) and a short written description of the fault
and its time of occurrence.
If the defect is covered by the warranty, your product will either be repaired or
replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty.
This also applies to replaced and repaired components. Any damage and defects
present at the time of purchase must be reported immediately after unpacking.
Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines
and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not
extend to product parts subject to normal wear and tear or fragile parts such as
switches, batteries, baking moulds or parts made of glass.
The warranty does not apply if the product has been damaged, improperly used
or improperly maintained. The directions in the operating instructions for the product
regarding proper use of the product are to be strictly followed. Uses and actions
that are discouraged in the operating instructions or which are warned against
must be avoided.
This product is intended solely for private use and not for commercial purposes.
The warranty shall be deemed void in cases of misuse or improper handling, use
of force and modifications / repairs which have not been carried out by one of
our authorised Service centres.
SV 120 A1
GB│IE│NI│CY
│
15 ■
Loading...
