MINI OVEN SGB 1200 A1
MINI OVEN
Operating instructions
MINI-BACKOFEN
Bedienungsanleitung
ΦΟΥΡΝΑΚΙ
Οδηүίες χρήσης
IAN 270658 / 271177
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και εξοικειωθείτε με όλες τις
λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 17
DE / AT / CH Bedienungsanleitung Seite 33
A
1
2
3
4
B
8
9
5
6
7
0
q
Contents
Introduction ............................................................2
Intended use ...........................................................2
Package contents .......................................................2
Appliance description ....................................................2
Technical data ..........................................................2
Safety guidelines .......................................................3
Installation ............................................................6
Using the appliance .....................................................6
Glass door .........................................................................6
Inserting the crumb tray ...............................................................6
Using the rack ......................................................................6
Using the baking tray ................................................................7
Before initial use ........................................................7
Operating the appliance .................................................8
Function switch ......................................................................8
Temperature control ..................................................................8
Timer .............................................................................8
GB
IE
CY
Grilling and baking .....................................................8
Cleaning and care .......................................................9
Storage ..............................................................10
Troubleshooting .......................................................10
Warranty and service ..................................................11
Disposal ..............................................................11
Importer .............................................................11
Recipes ...............................................................12
SGB 1200 A1
1
Introduction
GB
IE
Congratulations on the purchase of your new
appliance.
CY
You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information on safety, usage
and disposal. Before using the product, familiarise
yourself with all handling and safety guidelines.
Use the product only as described and for the range
of applications specified. Please also pass these
operating instructions on to any future owner(s).
Intended use
The automatic oven and grill is intended exclusively
for the heating, cooking and grilling of food.
This appliance is intended solely for use in private
households. Do not use it for commercial applications.
All other uses are deemed to be improper and may
result in property damage or even in personal
injury.
Package contents
♦ Mini Oven
♦ 1 baking tray
♦ 1 rack
♦ 1 pair of tongs
♦ 1 crumb tray
♦ Operating instructions
Appliance description
Figure A:
Rails
Ventilation slits
Temperature control
Function switch
Timer
Control lamp
Extraction hooks
Inserted crumb tray
Figure B:
Rack
Baking tray
- Tongs
Technical data
Rated voltage: 220 - 240 V ~, 50Hz
Max. power consumption: 1200 W
NOTE
Check contents for completeness and damage
immediately after unpacking. Contact Customer
Services if necessary.
2
SGB 1200 A1
Safety guidelines
DANGER – RISK OF ELECTRIC SHOCK!
► Do not open the housing of the appliance or attempt to repair it.
Doing so can lead to risks and also invalidates the warranty.
Defective appliances should be repaired by the retailer or
authorized personnel only.
► To prevent accidents, have defective plugs and/or power cables
replaced immediately by an authorised specialist technician or
our Customer Service department.
► Do not allow any liquids to penetrate the housing. Do not expose
the appliance to humidity and do not use it outdoors. Additionally,
do not place liquid-filled receptacles such as vases on the appliance. There is a risk of fire and of receiving an electric shock!
If liquids permeate into the housing, unplug the appliance immediately and arrange for it to be repaired by a qualified
technician.
► Never touch the appliance, power cable or power plug with
wet hands. There is a risk of electric shock!
GB
IE
CY
NEVER immerse the appliance in water or other liquids! There
is a risk of electrocution if residual liquids come into contact
with live components during operation.
SGB 1200 A1
3
GB
IE
CY
WARNING – RISK OF INJURY!
► This appliance may be used by children of the age of 8 years or
more and by persons with reduced physical, sensory or mental
capabilities or lack of experience and/or knowledge if they are
being supervised or have been instructed with regard to the safe
use of the appliance and have understood the potential risks.
► Children must not use the appliance as a plaything.
► Cleaning and user maintenance must not be performed by children
unless they are older than 8 years of age and are supervised.
► Children younger than 8 years of age must be kept away from
the appliance and the power cable.
► Route the power cable in such a way that no one can tread on
it or trip over it.
► Never touch the glass door or the housing during use, as these
can get very hot. Use oven gloves or something similar to open
the glass door to avoid being burnt!
► Never touch the heating elements or the viewing window when
the appliance is in use, or before it has cooled down completely.
Do not reach into the cooking chamber when the appliance is in
use. Wait until the appliance has cooled down. Otherwise, you
could sustain burns.
► Allow the appliance to cool down after use before transporting it.
► Always use oven gloves or an oven cloth when handling the
appliance while it is hot.
Caution! Hot surface!
4
SGB 1200 A1
CAUTION – MATERIAL DAMAGE!
► Do not use an external timer switch or a separate remote control
system to operate the appliance.
► Never leave the appliance unattended during operation.
► Ensure that the appliance, the power cable and the plug do not
come into contact with heat sources such as hotplates or naked
flames.
► Only operate the appliance with the original accessories supplied.
► Do not kink or crush the power cable.
► To disconnect, always remove the plug itself from the mains
power socket; do not pull on the power cable.
► Ensure that there are no highly inflammable materials in the imme-
diate vicinity of the automatic oven and grill (e.g. dishcloths, oven
cloths, etc.) when the appliance is in use.
► Never dry textiles or other objects on, above or inside the appli-
ance. There is a risk of fire!
► Do not use this baking tray for storage and processing of acidic,
alkaline or salty food.
GB
IE
CY
SGB 1200 A1
5
Installation
GB
IE
CY
WARNING! RISK OF FIRE!
► Never place the appliance beneath wall
cabinets or adjacent to curtains, wall units
or other flammable objects.
► A minimum clearance of 10 cm must be
maintained between the appliance and wall
cupboards, ceilings, walls or similar structures,
measured upwards of the appliance, and
5 cm measured laterally. For this reason the
appliance may not be used, for example, in
cupboards or similar. Otherwise there is likely
to be insufficient ventilation for the appliance,
which could result in fire or damage.
► Always place the appliance on a heat-resist-
ant surface. Failure to do so increases the risk
of fire or of the appliance being damaged.
The surface under appliance may become
discoloured and be damaged. Additionally,
permanent indentations could arise if the
appliance is placed on a soft surface.
Using the appliance
Glass door
CAUTION! PROPERTY DAMAGE!
► Do not lean on the glass door. Do not place
objects on the glass door. This can cause
damage to the door hinges.
■ Cooking some foods, especially fatty foods,
can result in increased smoke production. In this
case, do not close the glass door completely;
instead, leave it slightly open.
The glass door has a latching position so that
it remains open a little: if you carefully push
the glass door closed, it clicks into this position
shortly before closing completely.
Inserting the crumb tray
■ Push the crumb tray under the lower heating
element so that it rests flat on the bottom of the
appliance.
Using the rack
DANGER – ELECTRIC SHOCK!
► Do not place the appliance immediately adja-
cent to sources of water, e.g. sinks or basins,
or in damp cellar areas. Otherwise, there is a
risk of receiving an electric shock.
■ Place the appliance on a solid, level and heat-
resistant surface (e.g. stainless steel worktops
or natural stone worktops such as granite).
Ensure there is sufficient ventilation around the
appliance.
■ Push the appliance up against the wall, with its
rear side facing the wall. The spacers on the
back must touch the wall. Ensure that the wall is
made of heat-resistant material, e.g. tiles, natural
stone or granite.
■ Clean all components as described in the section
“Cleaning and care”.
6
WARNING! RISK OF INJURY!
► Always use the tongs -to insert the rack
into the appliance or to remove it.
■ Push the rack onto one of the 2 rails in
the cooking chamber of the appliance.
CAUTION! MATERIAL DAMAGE!
► Never place the rack directly upon the
heating elements.
■ If you slide the rack onto the lower rail, pull
this out far enough so that the edge lies just
above the extraction hooks . Thus, when you
close the glass door, the extraction hooks
grip the rack and this is pulled out the next
time you open the glass door.
SGB 1200 A1
■ To remove the hot rack , hook the tongs -
onto it as follows:
Before initial use
Once the appliance is set up correctly:
1) Insert the plug into a mains power socket.
2) Turn the temperature control clockwise to
the maximum temperature (to the limit stop).
3) Turn the function switch to “top and bottom
heat”
4) Open the glass door and leave it open for this
operation.
5) Remove any installed accessories from the
cooking chamber.
6) Turn the timer to 20 minutes.
.
GB
IE
CY
Fig. 1: Hooking the tongs - onto the rack
Using the baking tray
WARNING! RISK OF INJURY!
► Always use oven gloves or similar to insert
the hot baking tray into the appliance or
to remove it.
■ Always place the baking tray on the cor-
rectly inserted rack in the cooking chamber
of the appliance.
CAUTION! MATERIAL DAMAGE!
► Never place the baking tray directly onto
the heating elements.
NOTE
► The first time the appliance heats up, a small
amount of smoke and odour may be generated due to production-related residue. This is
normal and is completely harmless.
Provide sufficient ventilation; for example, by
opening a window.
The appliance switches off automatically
after 20 minutes.
If you want to interrupt the heating process
prematurely, turn the temperature control
counter-clockwise to the limit stop and set
the function switch to
timer to “OFF”.
7) Allow the appliance to cool down, then clean
the appliance as described in the section
“Cleaning and care”.
The appliance is now ready for use.
OFF
and set the
SGB 1200 A1
7
Operating the appliance
GB
IE
Function switch
CY
You can switch on the appliance using the function
switch , and can also set three different functions:
Symbol Meaning
"Top heat"
e.g. for grilling
"Bottom heat"
e.g. for baking cakes
"Top & bottom heat"
e.g. for baking pizza
OFF
The appliance is switched off.
"OFF"
Temperature control
■ Use the temperature control to set the desired
temperature.
Timer
Use the timer to set the cooking time.
■ Set the timer to the desired cooking time.
Once the set time has elapsed, a beep sounds
and the appliance stops heating.
NOTE
You can also use the timer as a short-period
timer without the heating function.
– Set the function switch to
– Set the desired time on the timer .
The switch of the timer now rotates anticlockwise to "OFF". A beep sounds when the set time
has elapsed. The appliance does not heat up.
OFF
Grilling and baking
CAUTION! MATERIAL DAMAGE!
Never place any containers or food directly
►
onto the floor of the appliance, the heating
elements or the crumb tray .
1) Place the crumb tray in the appliance.
2) Remove the rack and baking tray from
the appliance. If required, cover these with
baking paper or grease the baking tray
with fat/oil that is suitable for baking.
NOTE
► The oven must be pre-heated appropriate
to each dish. Refer to the guidelines in the
respective recipe. Pre-heating is useful for:
– very short baking times,
– crisp crusts,
– delicate dishes that require a constant
temperature, such as soufflés.
► If no pre-heating is required, skip step 3).
3) Allow the appliance to heat up until it reaches
the desired temperature (this takes about
10 minutes, depending on the temperature
setting):
– Select the desired temperature using the
temperature control .
– Then select the required function using the
function switch .
– Use the timer to set the preheat time
(approx. 10 minutes).
– Close the glass door.
.
8
SGB 1200 A1
4) Once the warm-up period has elapsed, place
the item to be baked/grilled on the rack or
the baking tray and slide it onto one of the
rails or place the baking tray onto the
rack .
Ensure that there is sufficient clearance between
the foodstuffs and the inner walls/heating elements of the appliance.
If you use the lower rail, ensure that you insert
the rack correctly so that the extraction
hooks grip the rack .
5) Close the glass door before starting the grilling
or baking process.
6) Use the timer to set the required grilling or
baking time. The maximum grilling or baking
time is 60 minutes.
NOTE
► If the cooking time for the food to be grilled/
baked is less than 20 minutes, first set the
timer to 40 minutes and then turn it back
to the required grilling or baking time.
The control lamp shows that the appliance is
now switched on. The switch of the timer now
rotates anticlockwise to “OFF”.
The appliance switches off automatically after the
set period; there is a beep and the control lamp
goes off.
NOTE
If you want to interrupt the heating process
prematurely, turn the temperature control
anticlockwise to the limit stop and set the
function switch to
to "OFF".
7) After cooking, remove the rack using the
tongs -, or the baking tray using oven
gloves.
OFF
and set the timer
Cleaning and care
DANGER – ELECTRIC SHOCK!
Before cleaning the appliance, disconnect
►
the power plug from the mains power socket!
There is a risk of electric shock!
Never immerse the appliance in water or
any other liquid!
WARNING! RISK OF INJURY!
► Always allow the appliance to cool down
before cleaning it. Otherwise there is a risk
of sustaining burns!
■ It is best to clean the appliance and accessories
as soon as they have cooled down. This makes
food residues easier to remove.
CAUTION! MATERIAL DAMAGE!
► Do not use abrasive or aggressive cleaning
materials. These could damage the surface
of the appliance!
► Do not clean the components of the appli-
ance in a dishwasher!
► Do not clean the cooking chamber with an
oven spray as this may make residues on the
heating elements impossible to remove.
■ Wipe the appliance with a damp cloth. If neces-
sary, put a little mild detergent on the cloth and
wipe the appliance off afterwards with a cloth
dampened with clean water. Dry everything
properly.
■ Clean the cooking chamber and the glass door
with a damp cloth. If necessary, put a little mild
detergent on the cloth and wipe the appliance
off afterwards with a cloth dampened with
clean water. Dry everything properly.
■ Clean the tongs -, the baking tray , the
rack and the crumb tray in hot water.
Dry all parts properly after cleaning.
GB
IE
CY
SGB 1200 A1
9
Storage
GB
IE
CY
■ Wrap the power cable around the spacer on
the reverse of the appliance, which you can use
as a cable spool.
Troubleshooting
Fault Cause Solution
■ Store the cleaned appliance and its accessories
in a clean, dust-free and dry location.
The power plug is not connected to the
mains power.
The appliance is not
working.
The control
lamp comes on,
but the appliance
does not heat up.
The cooking time of
the food seems overly
long.
Smoke and odours
develop during use.
If the malfunction cannot be corrected as suggested above, or if you have found some other kind of
malfunction, please contact our Customer Service department.
The mains power socket is defective.
The appliance is defective.
The function switch is set to
The glass door has been opened often to
check the cooking progress.
The wrong temperature level has been set. Check the temperature settings.
There is detergent or food residue on the
heating elements.
OFF
.
Insert the plug into a mains power
socket.
Use a different mains power
socket.
Contact the Customer Service
department.
Turn the function switch to the
desired function.
Do not open the glass door any
more often than is absolutely
necessary.
Remove the food from the appliance and continue the cooking
process with the glass door open
until the smoke stops.
10
SGB 1200 A1
Warranty and service
The warranty for this appliance is for 3 years
from the date of purchase. The appliance has
been manufactured with care and meticulously
examined before delivery. Please retain your receipt as proof of purchase. In the case of a warranty claim, please make contact by telephone
with our Customer Service Department. Only in
this way can a post-free despatch for your goods
be assured.
The warranty covers only claims for material
and manufacturing defects, but not for transport
damage, wearing parts or for damage to fragile
components, e.g. buttons or batteries.
This product is for domestic use only and is not
intended for commercial use.
The warranty is void in the case of abusive and
improper handling, use of force and internal
tampering not carried out by our authorised service
branch.
Your statutory rights are not restricted in any
way by this warranty. The warranty period is not
extended by repairs made under the warranty. This
applies also to replaced and repaired parts.
Damages and defects extant at the time of purchase must be reported immediately after unpacking, resp. no later than two days after the date of
purchase.
Repairs made after the lapse of the warranty
period are subject to charge.
Service Great Britain
Tel.: 0871 5000 720 (£ 0.10/Min.)
E-Mail: kompernass@lidl.co.uk
IAN 270658 / 271177
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
IAN 270658 / 271177
Service Cyprus
Tel.: 8009 4409
E-Mail: kompernass@lidl.com.cy
IAN 270658 / 271177
Hotline availability:
Monday to Friday 08:00 - 20:00 (CET)
Disposal
Never dispose of the appli-
ance in the normal domestic
waste. This product is subject
to the provisions of European
Directive 2012/19/EU.
Dispose of the appliance via an approved waste
disposal company or your municipal waste disposal
facility. Please observe applicable regulations.
Please contact your waste disposal facility if you
are in any doubt.
The packaging is made of environmen-
tally friendly materials which you can
dispose of at your local recycling centre.
GB
IE
CY
SGB 1200 A1
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
11
Recipes
GB
IE
In this section, we provide you with various sample
recipes for preparing dishes. These examples are
CY
recommendations. Cooking times may vary.
These recipes are provided without guarantee.
All information on ingredients and preparation is
indicative only. Modify the suggested recipes to
taste. We hope you enjoy the recipes and wish
you “bon appetit”!
NOTE
Take note of the preparation guidelines provided
on the food packaging.
Muffins
Ingredients for four people:
♦ 1 cup of flour
♦ 1 teaspoon of baking powder
♦ 1 egg
♦ 1 tablespoon of melted butter
♦ 1 cup of milk
♦ 3 tablespoons of sugar
♦ 1 pinch salt
♦ For variations: also nuts, chopped bananas or
chocolate flakes
Preparation:
1) Gradually mix the flour, baking powder, egg,
milk, salt and sugar together in a bowl, one
by one.
2) Melt the butter in a saucepan and mix it into
the dough.
3) Subject to taste, blend in the nuts, chocolate
flakes or mashed bananas.
4) Place the prepared dough into standard muffin
moulds and place them on the baking tray .
5) Bake the muffins at 220°C on the bottom rail
using top & bottom heat for about 15 minutes.
Hawaiian toast
Ingredients for 4 pieces of toast:
♦ 4 slices of toasting bread
♦ 1–2 tablespoons of remoulade
♦ 120 g cooked ham
♦ 1/2 tin of pineapples
♦ 4 slices of cheese for gratinating
♦ Curry
Preparation:
♦ Toast the bread slices.
♦ Spread the remoulade thinly over the pieces of
toast and lay the slices of cooked ham on top.
♦ Lay one slice of pineapple on each piece of
toast. Season with curry.
♦ Then place a slice of cheese over each of the
pineapple slices.
♦ Lay the Hawaiian toasts on the rack and
bake at 200°C for about 8 minutes on the
upper rail using top heat.
Baking deep-frozen pizza
Preparation:
♦ Place the rack on the upper rail in the cooking
chamber.
♦ Place the deep-frozen pizza, without packaging,
onto the rack .
♦ Bake the pizza, using top and bottom heat, for
about 20 minutes.
♦ Please follow the instructions on the packaging
regarding temperature.
Spritzgebäck cookies
Ingredients:
♦ 125 g butter
♦ 125 g sugar
♦ 1 packet of vanilla sugar
♦ 1 pinch salt
12
SGB 1200 A1
♦ 1 egg
♦ 1 egg white
♦ 250 g flour (type 405)
♦ 1 teaspoon of baking powder
♦ Zest of half a lemon
Preparation:
1) Beat the butter until foamy.
2) Add the sugar, vanilla sugar, lemon zest and
eggs.
3) Mix the flour, baking powder and salt and stir
into the mixture using a mixing spoon.
4) Allow the dough to stand for about 10 minutes.
5) Shape the dough as desired, e.g. with the assistance of a mincer, cookie cutters or a piping
bag.
6) Line the baking tray with baking paper and
place the cookies on this.
7) Bake the cookies on the top rail of a preheated
oven at 180°C, using top and bottom heat,
for about 10–15 minutes, until they are golden
brown.
NOTE
This quantity of dough is sufficient for several
baking trays .
Bread rolls
Ingredients:
♦ 300 g flour (or wholemeal flour)
♦ 2 heaped teaspoons of baking powder
♦ 200 g linseeds
♦ 1 egg
♦ 500 g quark or curd cheese
♦ 1 teaspoon of salt
♦ Subject to taste: caraway seeds, onions,
bacon ...
Preparation:
1) Knead all ingredients together well and then
shape into small rolls.
2) Line the baking tray with baking paper and
place the rolls on this.
3) Bake on the top rail at about 200°C for
around 30 minutes.
NOTE
This quantity of dough is sufficient for several
baking trays .
Meringues
Ingredients:
♦ 1 egg white
♦ Salt
♦ 45 g sugar
Preparation:
1) Place the chilled egg white into a fat-free mixing
bowl. Ensure that no egg yolk is mixed in with
it or the meringue will not solidify.
2) Beat the egg white at a slow speed, so that the
bubbles formed in the meringue are not too
large.
3) Add a pinch of salt to taste.
4) Gradually add in half of the sugar when the
meringue starts to solidify.
5) Then beat it at the highest speed until stiff.
6) Add the remaining sugar. This allows the
meringue to attain the required solidity.
7) Fill a piping bag fitted with a large star nozzle
with the meringue mixture and squeeze out
rosettes, slithers or other shapes onto a baking
tray lined with baking paper. Leave a little
space between each shape.
8) Pre-heat the oven and grill to about 120°C
using top and bottom heat.
9) Bake the meringues at around 120°C using
top and bottom heat for about 2 hours.
GB
IE
CY
SGB 1200 A1
13
Loading...
