Silvercrest SFK 36 A1 User Manual [sv]

KOMPERNASS GMBH

BURGSTRASSE 21 · D-44867 BOCHUM

www.kompernass.com

ID-Nr.: SFK 36 A1-11/11-V2

IAN: 71244

Wireless Doorbell SFK 36 A1

Wireless Doorbell

Operating instructions

Radio-ohjattu ovikello

Käyttöohje

Radiostyrd dörrklocka

Bruksanvisning

SFK 36 A1

6 7

INDEX PAGE

Intended Use 2

Items supplied 2

Technical data 3

Safety instructions 3

The appliance parts 5

Taking the appliance into use 6

Maintenance 10

Cleaning and Care 10

Disposal 11

CE Conformity 12

Importer 12

Warranty and Service 12

Read these operating instructions carefully before using the appliance for the first time and preserve this booklet for later reference. Pass this booklet on to whoever might acquire the appliance at a future date.

- 1 -

Intended Use

This appliance serves as a radio doorbell system for wireless visitor signalisation and thus makes possible the operation of a door bell without wiring. The appliance is intended for domestic use only, not for commercial or industrial applications. No warranty is provided for damages resulting from improper use of the appliance!

Items supplied

1 Receiver 1 Transmitter 2 1.5 V Batteries, Type "AA/Mignon/LR6" 1 3 V Battery, Type CR2032 1 Screw for fixing the transmitter on to the assembly plate 5 Nameplates 1 Plastic cover for the nameplate 2 Wallplugs with screws for transmitter assembly 1 Wallplug with a screw for receiver suspension 1 Operating manual

- 2 -

Technical data

Power supply Receiver: 2 x 1.5V Type "AA/Mignon/LR6" Transmitter: 1 x 3V Type CR2032 Type of transmitter protection: IP 44 Transmission frequency: 433 MHz Range: 100 m (Free-space range) Ring-tone volume: min. 73dB(A) in 1 m (on max. setting)

Safety instructions

Do not permit children to handle electrical appliances • without supervision, as they cannot correctly assess the possible dangers of injury. Check the appliance and all parts for visible damages. • If the appliance is damaged, arrange for it to be checked by Customer Services. NEVER open the appliance. There are no user-serviceable • elements inside.

Risk of accidents and injury!

This appliance is not intended for use by individuals (including • children) with restricted physical, physiological or intellectual abilities or deficiencies in experience and/or knowledge unless they are supervised by a person responsible for their safety or receive from this person instruction in how the appliance is to be used.

- 3 -

Children should be supervised to ensure that they do not play • with the appliance. Keep batteries well away from children. Children can put bat-• teries into their mouths and swallow them. If a battery is swallowed, medical assistance must be sought IMMEDIATELY.

For the handling of batteries please observe the following:

Risk of explosion!

Do not throw batteries into a fire.• Do not recharge the batteries. • Never open batteries, never solder or weld batteries. • The risk of explosions and injuries exists! Regularly check the condition of the batteries. Leaking • batteries can cause damage to the appliance. If you do not intend to use the appliance for an extended • period, remove the batteries.

Damage on the appliance

Avoid the simultaneous usage of batteries of varying • types resp. capacities. Do not use any aggressive chemical substances for • cleaning. NEVER submerse the appliance in water. Wipe it only • with a slightly damp cloth.

- 4 -

Protect the receiver against moisture. Use it only in dry • rooms, do not use it when it is raining outdoors or when close to liquids. Ensure that, when the receiver is in use, it cannot become • wet or moist and that it cannot be damaged.

The appliance parts

Receiver (Fig. A)

q Signal indicator w Speaker e r Loop for suspension of the receiver t VOL.: Button for sound volume control y u i Battery compartment - receiver o Stand a Battery compartment cover - receiver

Transmitter (Fig. B)

s d Nameplate f Indicator for signal confirmation g Battery compartment - Transmitter h Assembly plate - Transmitter

: Signal type switch (optical/acoustic)

: Button for melody selection : Synchronisation button, Receiver

Bell button

- 5 -

Taking the appliance into use

Take the appliance out of the carton and remove all packaging materials.

Inserting the batteries in the receiver

Open the battery compartment > i on the rear of the appliance.

Insert 2 x 1.5V batteries of the type "AA/Mignon/LR6" > as per the insertion markings shown in the battery compartment i.

Replace the battery compartment cover > a.

Inserting the battery in the transmitter

Remove the assembly plate > h from the transmitter. Insert a 3 V battery of type CR2032 into the battery >

compartment g. The side marked with "+" must be facing up.

Replace the assembly plate > h back onto the transmitter.

Should the performance of the appliance diminish or fall away completely, it means the batteries are exhausted. The used batteries should then be changed for new ones of the same type.

- 6 -

Selecting the signal type

The receiver can indicate the reception of a door-ring signal either optically, acoustically or optically and acoustically. To select, bring the signal type switch e into the desired position:

- only acoustic ring indications, the selected melody sounds,

- only optical ring indications, the signal indicator blinks,

- optical and acoustic ring indications.

Adjusting the signal sound volume

To select the desired signal sound volume, press the VOL. button t repeatedly until the desired volume level is set.

Loud Medium Quiet

Selecting the call melody

There are 36 different call melodies stored in the appliance.

Repeatedly press the button for melody selection >

When the desired melody sounds, stop the selection. >

The appliance will utilise the last melody it played as the call melody.

- 7 -

Synchronising the transmitter and receiver

The transmitter and receiver of this doorbell system can communicate with each other on a variety of different frequencies. Consequently, up to 5 transmitters can be operated with one receiver. The precondition for this is that the transmitter and receiver within a system are working on the same frequency. For this, you must synchronise the appliances as follows:

Press the synchronisation button on the receiver > Now press the bell button >

s on the transmitter.

If the synchronisation has been a success, the receiver notifies you of the programmed call signal. The appliances terminate the synchronisation mode and the signal indicator q goes out. Should the receiver not react as described, repeat the synchronisation.

The transmitter shows, with a brief glowing of the indica-

tor f when being activated, the transmission of the signal to the receiver.

- 8 -

Installing the appliance

Select a suitable positioning for the transmitter, close to > your outer door.

Using the assembly plate > h of the transmitter, mark the positions required for the two boreholes (spacing approx. 68 mm) and then bore the holes for the enclosed wallplugs.

Screw the assembly plate > h onto the wall. Write the name(s) of the residents on the nameplate > d

and then place the plastic covering. Place the transmitter on the assembly plate > h and

secure it, with the enclosed small screw, to the assembly plate h.

You can install the receiver at a suitable location either > suspended by its loop r or make use of the stand o. Bear in mind that the given range refers to the free-space range. If being utilised in a building, this range is reduced quite distinctly.

To suspend the receiver, fix the enclosed screw, with the > wallplug, at a suitable location on the wall and hang the appliance from it.

- 9 -

Maintenance

Important!

NEVER open any parts of the doorbell system! Arrange for the appliance to be repaired by specialists only.

The appliance is maintenance-free. No form of maintenance, either on or in the appliance, is intended for execution by the user. In the event of malfunction or apparent damage, make contact with Customer Services. If the appliance is not to be in use for an extended period, remove the batteries.

Cleaning and Care

Important!

NEVER submerse the appliance or its components in water • or other fluids! Do not allow any liquids to penetrate into the appliance • housing. If they do, there is a risk that the appliance could be damaged.

Cleaning the appliance:

Clean the appliance only with a dry or lightly moistened > cloth. Do not use aggressive cleaning agents! These could damage the plastic upper surfaces.

In the event of the batteries leaking acids, put on a pair > of protective gloves. Then clean the battery compartment and the battery contacts with a dry cloth.

- 10 -

Disposal

Do not, under any circumstances, dispose

of the appliance in your household refuse. This appliance is subject to the provisions of European Guidelines 2002/96/EC.

Transmitter and receiver units

Arrange for the product, or parts of it, to be disposed of • by a professional disposal company or by your communal waste facility. Observe the currently applicable regulations. In case of • doubt, please contact your waste disposal centre.

Batteries/rechargeable batteries

Used batteries/rechargeable batteries may not be dis-• posed of in household waste. Batteries can contain poisons which are damaging to • the environment. Therefore, dispose of the batteries/ rechargeable batteries in accordance with statutory regulations. Every consumer is legally obligated to surrender batteries/ • rechargeable batteries to a community collection centre in their district or to a dealer. The purpose of this obligation is to ensure that batteries are disposed of in a non-polluting manner.

Dispose of all packaging materials in an environmentally friendly manner.

- 11 -

CE Conformity

This appliance conforms with the fundamental requirements and other relevant regulations of the R&TTE Directive 1999/5/EC. A complete copy of the original conformity declaration is available from the importer.

Importer

KOMPERNASS GMBH BURGSTRASSE 21 44867 BOCHUM, GERMANY

www.kompernass.com

Warranty and Service

The warranty for this appliance is for 3 years from the date of purchase. The appliance has been manufactured with care and meticulously examined before delivery. Please retain your receipt as proof of purchase. In the event of a warranty claim, please make contact by telephone with our Service Department. Only in this way can a post-free despatch for your goods be assured. The warranty covers only claims for material and manufacturing defects, but not for transport damage, for wearing parts or for damage to fragile components, e.g. buttons or batteries. This product is for private use only and is not intended for commercial use.

- 12 -
