JUICER SFE 450 C3
JUICER
Operating instructions
ENTSAFTER
Bedienungsanleitung
IAN 332479_1910
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
GB / IE / NI / CY Operating instructions Page 1 GR / CY Οδηүίες χρήσης Σελίδα 23 DE / AT / CH Bedienungsanleitung Seite 45
A
B
Contents
Introduction ...................................................2
Intended use ..................................................2
Package contents ..............................................2
Description of the appliance .....................................3
Technical data .................................................3
Safety instructions .............................................4
Assembling and operating the appliance ...........................7
Preparing the fruits/vegetables ..................................8
Juicing .......................................................8
Emptying the pulp container and the filter ........................10
Dismantling the juicer ..........................................10
Cleaning and care .............................................11
Storage .....................................................12
Troubleshooting ..............................................13
Disposal .....................................................14
Kompernass Handels GmbH warranty ............................15
Service ................................................................16
Importer ............................................................... 16
Recipes ......................................................17
Ginger shot ............................................................17
Carrot and fruit mix ......................................................18
Orange, ginger and lemon drink ........................................... 18
Green power drink ...................................................... 19
Celery and carrot juice with turmeric and orange ............................... 19
Summer drink ........................................................... 20
Apple-pear-strawberry drink ............................................... 20
Honeydew melon drink ...................................................20
Sweet fruit drink .........................................................21
Pineapple-mango drink ...................................................21
SFE 450 C3
GB│IE│NI│CY 
 1
Introduction
Congratulations on the purchase of your new appliance. You have selected a high-quality product. The operating instructions are part of this product. They contain important information on safety, usage and disposal. Before using the product, familiarise yourself with all operating and safety instruc­tions. Use the product only as described and for the specified areas of applica­tion. Please also pass on these operating instructions to any future owner.
Intended use
This appliance has been designed for the juicing of well ripened and peeled fruits and vegetables. The appliance may only be used to process foods. Use only the original attachments and accessories as described. Any other uses of or modification to the appliance is deemed to be improper and carries the risk of serious personal injury. The manufacturer accepts no responsibility for damage attributable to misuse. This appliance is intended solely for use in private house­holds. Not for commercial use.
Package contents
JuicerNylon brush (in the pusher)Operating instructions
2 │ GB
│IE│NI│
CY
SFE 450 C3
Description of the appliance
Figure A:
1 Pusher 2 Feed tube 3 Lid 4 Clamps 5 Juice tank 6 Juice outlet 7 Base 8 Power cable with mains plug 9 On/off switch (2 speed settings) 0 Cable retainer q Container (for fruit and vegetable pulp)
Figure B:
w Filter e Drive shaft r Nylon brush (in the pusher on delivery)
Figure A: t Separate juice collector (can be found in the container
for fruit and vegetable pulp on delivery)
z Foam separator
Technical data
Rated voltage 220 – 240V ~ (alternating current), 50/60 Hz Rated power 450 W CO time 30 minutes Protection class
CO time
The CO time (continuous operation time) is the amount of time an appliance can be operated without the motor overheating and becoming damaged. After the appliance has been operated for this duration of time, switch it off until the motor has cooled down.
SFE 450 C3
(double insulation)
II /
All parts of this appliance which come into contact with food are food-safe.
GB│IE│NI│CY 
 3
Safety instructions
DANGER – ELECTRIC SHOCK!
The voltage of the power source must conform to the details
given on the type plate of the appliance.
To prevent accidents, have defective plugs and/or power
cables replaced immediately by an authorised specialist technician or our Customer Service department.
Appliances which do not work properly or have been
damaged must be checked immediately and repaired by customer service.
Do not expose the appliance to rain, and never use it in
a humid or wet environment. Ensure that the power cable never becomes wet or moist during use.
Never immerse the base of the machine in water or other liquids!
WARNING! RISK OF INJURY!
Never use the appliance for purposes other than those
described in these instructions.
The appliance should always be disconnected from the
mains when unattended and before assembly, disassembly or cleaning.
This appliance may not be used by children.The appliance and its connecting cable must be kept away
from children.
This appliance may be used by persons with lim-
ited physical, sensory or mental capabilities or lack of experience and knowledge, provided that they are under supervision or have been told how to use the appliance safely and are aware of the potential risks.
Children must not use the appliance as a plaything.The appliance may not be used if the rotating filter is damaged!
4 │ GB
│IE│NI│
CY
SFE 450 C3
WARNING! RISK OF INJURY!
Before changing any accessories or additional parts that
move during operation, the appliance must be switched off and disconnected from mains power.
The blades are very sharp. Handle them with care.Do not operate the appliance if the rotating sieve is
damaged.
To prevent injuries, ensure that all parts are inserted correctly.
Never put your hands or other objects into the filler opening. This could lead to grave personal injuries or serious damage to the appliance. If pieces of fruit or vegetable cannot be removed with the pusher, switch the appliance off, remove the plug from the power socket and open the appliance.
Ensure that the power plug is easily accessible in case of
emergency, and that there is no risk of tripping over the cable.
Switch off the appliance and unplug it after use. Do not
dismantle the appliance until the motor has come to a complete standstill.
Do not touch any rotating parts.Never leave the appliance unattended during operation.
Provide a stable location for the appliance.Do not operate the device if the filter, the power cable or
the plug is damaged.
Do not operate the appliance in the event of any
malfunctions or if it has been damaged in any other way or has been dropped.
The use of accessories that have not been recommended or
sold by the manufacturer can cause a fire, electric shock or injury.
SFE 450 C3
GB│IE│NI│CY 
 5
Tips for safety:
In case of danger, remove the plug from the socket
immediately.
Remain alert at all times! Always pay attention to what
you are doing and act with common sense. Never use the appliance when you are distracted or don’t feel well.
Ensure that the appliance is completely assembled before
using it for the first time. The appliance can only be started up once the clamps have been closed. Should the clamps become loose during operation, the appliance stops auto­matically.
After using the juicer, always ensure that the on/off switch is
in the "OFF" position ("0"). Do not dismantle the appliance until the motor has come to a complete standstill.
Do not use the appliance outdoors.
6 │ GB
│IE│NI│
CY
SFE 450 C3
Assembling and operating the appliance
Before using the appliance for the first time, clean all component parts
thoroughly as described in the section “Cleaning and care”.
Select a safe and secure positioning for the juicer. For optimal handling we
recommend that the appliance is positioned with the power cable 8 running from the rear of the appliance to the wall socket. All operating elements can now be directly and easily handled:
– the On/Off switch 9 at the front, – the container for fruit and vegetable pulp q on the left, – the juice outlet 6 on the right.
WARNING! RISK OF INJURY!
Ensure that the appliance is switched off and the plug 8 removed from the
wall socket before assembling the appliance.
1) Place the juice tank 5 on the appliance base 7, so that the three catches and the juice outlet 6 grip into in the recesses.
2) Place the filter w on the drive shaft e and press it down so that it audibly clicks into place. Ensure that it is firmly seated before continuing with the assembly.
3) Slide the container for fruit and vegetable pulp q from below under the outlet (see fold-out page).
4) Place the lid 3 onto the juice tank 5, so that the feed tube 2 is sitting above the blades of the filter w.
5) Ensure that the lid 3 is sitting firmly in the recess on the juice tank 5. Lift the clamps 4 and clip them into the notches on the lid 3.
6) Press the lower part of the clamps 4 against the appliance until they click into place.
7) Push the foam separator z into the juice collector t and put the lid on. Place the separate juice collector t next to the appliance so that the juice outlet 6 protrudes into the separate juice collector t.
8) Insert the plug 8 into a mains power socket.
SFE 450 C3
GB│IE│NI│CY 
 7
Preparing the fruits/vegetables
■ Important: Use only well-ripened fruit, as otherwise the filter w will get
blocked. This would require repeated cleaning of the filter w.
Wash or peel the fruits/vegetables that you wish to process.
Large seeds or stones should always be removed before filling the appliance.
Cored fruit (such as apples, pears) can be processed along with the skin and
core. Remove all other stones (peaches, plums etc.), all large seeds (melons etc.) and stalks to avoid possible damage to the appliance.
Fruits and vegetables with thick peels (e.g. citrus fruits, melons, kiwis, root
vegetables) must always be peeled first.
Remove the stalks from grapes.
Cut the fruit or vegetables into pieces that will fit easily into the feed tube 2.
Turmeric only needs to be washed, not peeled.
Remove the woody parts from the ginger, wash the ginger and cut it into
pieces. You don’t have to peel ginger to extract the juice.
For celery, cut off the base and remove wilted leaves. Always feed celery
with the lower, wide end first into the feed tube 2.
Wash any lettuce varieties, e.g. iceberg or loose-leaf lettuce, and fold the
individual leaves together to form small “packages”. The resulting higher pressure allows more liquid to be obtained.
NOTE
Raisins are not suitable for juicing as they contain too little juice. Rhubarb
or other fibrous vegetables/fruits are not suitable for juicing as the fibres will block the juicer.
Juicing
8 │ GB
WARNING! RISK OF INJURY!
NEVER insert your hands or other objects into the feed tube 2 when working
with the appliance. This could lead to serious injuries and/or damage to the appliance.
CAUTION! PROPERTY DAMAGE!
DO NOT operate the juicer for longer than 30 minutes (CO time) without
a break. After 30 minutes of continuous use allow the juicer to cool down. Otherwise the appliance could be damaged.
│IE│NI│
CY
SFE 450 C3
1) Switch the appliance on with the On/Off switch 9.
Use speed level 1 for juicing fruit/vegetables containing a lot of liquid. For drier fruit/vegetables, select speed level 2. You can use the following table as an orientation guide. Please bear in mind, however, that the required speed may vary depending on the ripeness of the fruit.
Fruits/vegetables Speed setting
Tomatoes 1
Honeydew melon 1
Watermelon 1
Peaches (without stone) 1
Kiwis (peeled) 1
Pears (without stalk) 1
Apricots (without stone) 1
Cucumber (peeled) 1
Garden salad 1
Pineapple (peeled) 2
Oranges (peeled) 2
SFE 450 C3
Carrots 2
Apples 2
Broccoli 2
Fennel 2
Celery 2
Ginger 2
Turmeric 2
Lemon 2
Mango 2
2) Hold the pusher 1 in one hand and feed the fruit or vegetable pieces with the other hand into the feed tube 2. Always use the pusher 1 to carefully press the fruit/vegetable pieces into the feed tube 2. While the fruit/vegetables are being processed, insert further pieces into the feed tube. Do not switch the appliance off.
GB│IE│NI│CY 
 9
NOTE
Add carrots one after the other into the feed tube 2: the top of the carrot
must be at the bottom and the pointed end at the top.
NOTE
To avoid fruit or vegetables becoming blocked in the feed tube 2, only
fill it when the appliance is switched on. If fruit or vegetable pieces get stuck in the feed tube 2 and cannot be promptly freed with the pusher 1, proceed as follows to avoid damage to the appliance:
– Switch the off appliance immediately and pull the power plug 8
from the wall socket.
– Undo the clamps 4 and remove the lid 3. – Remove the fruit or vegetable pieces causing the blockage. – Reassemble the appliance and continue with juice extraction.
3) Always switch the off appliance immediately after all of the fruit/vegetables have been processed.
CAUTION! PROPERTY DAMAGE!
To avoid blockage of the juice outlet 6 and/or damage to the appliance,
clean the juice outlet 6 and the juice tank 5 regularly and after every use.
Emptying the pulp container and the filter
You can extract juices continuously until the container for fruit and vegetable
pulp q is completely full.
WARNING! RISK OF INJURY!
Remove the plug 8 from the power outlet when emptying the filter w.
This prevents unintentional starting of the appliance.
If the extracted juice suddenly starts getting thicker, or if you hear that the motor is running more slowly, the filter w needs to be emptied. When you have removed the fruit pulp, reassemble the appliance.
Dismantling the juicer
If you wish to dismantle the juicer, e.g. to clean it, proceed as follows:
1) Remove the mains plug 8 from the socket.
2) Open the clamps 4.
3) Remove the lid 3 with the pusher 1.
4) Lift up the juice tank 5 carefully. This disengages the filter w from the drive shaft e. You can now remove the filter w from the juice tank 5.
10 │ GB
│IE│NI│
CY
SFE 450 C3
Cleaning and care
DANGER – ELECTRIC SHOCK!
Always remove the mains plug 8 from the wall socket before cleaning the
appliance.
To avoid receiving an electrical shock, never submerse the motor/ appliance base 7 in water or other fluids.
WARNING! RISK OF INJURY!
Always pull out the mains plug 8 before fitting or removing accessories.
CAUTION! PROPERTY DAMAGE!
To avoid blockage of the juice outlet 6 and/or damage to the appliance,
all fruit and vegetable pulp must be regularly cleaned off the appliance and accessories. Also clean after every use.
Do not use any aggressive cleaning agents to clean the juicer. The appliance
and its accessories may not be cleaned in boiling water.
NOTE
Soiling or overflowing fruit juices should be cleaned away immediately, as
fruit stains are more difficult to remove later.
Switch the appliance on with the On/Off switch 9.
Clean the appliance housing and the power cable 8 using a lightly mois-
tened cloth.
Clean the pusher 1, the juice container 5, the separate juice collector t,
the foam separator z, the housing lid 3 and the container for fruit and vegetable pulp q in warm soapy water and rinse them carefully.
SFE 450 C3
NOTE
The pusher 1, the juice container 5, the housing lid 3, the separate
juice collector t, the foam separator z and the container for fruit and vegetable pulp q are dishwasher safe and can be cleaned in the dishwasher.
If possible, use the upper basket of the dishwasher and make sure the
components are not jammed in.
GB│IE│NI│CY 
 11
To clean the filters w, use the supplied nylon brush r:
Colouring:
Storage
If you do not intend to use the juicer for a long time, wrap the cable around the cable retainer
Turn the lid of the pusher 1 until the arrow points to the opened lock on
the pusher shaft. You can now remove the lid. The nylon brush r can be found inside the pusher 1. To re-close the lid, place it on the pusher so that the arrow points to the opened lock the closed lock
Hold the filter w (with the underside upwards) under running water and
clean it with the nylon brush r.
NOTE
The
Nevertheless, remove any fruit residues from the filter w using the cleaning brush filter w will not get clean.
If possible, use the upper basket of the dishwasher and make sure that the
filter w
is not jammed in.
Some fruits or vegetables can permanently discolour parts of the juicer.
This is not damaging and does not impair the appliance in its functions.
. The lid now sits firmly in place.
filter w
is dishwasher-safe and can be cleaned in the dishwasher.
r
beforehand. Otherwise, the fine-mesh sieve of the
0
on the underside of the juicer.
. Then turn it until the arrow points at
12 │ GB
│IE│NI│
CY
SFE 450 C3
Troubleshooting
Faults Possible causes Possible solutions
The appliance is not working.
The motor stops still while juicing or it turns noticeably more slowly or unevenly.
The pulp is moist and you obtain too little juice.
The juice wells out between the edge of the lid 3 and the juice tank 5.
The juice sprays out of the juice outlet 6.
During the processing, juice runs down the appliance base
7.
The mains plug 8 is not connected.
The appliance is not switched on. Switch the appliance on with
The clamps 4 are not secured. Close the clamps 4.
The filter w is blocked.
You are working too fast. Work a little more slowly.
The filter w is blocked.
You are working too fast. Work a little more slowly.
The filter w or the juice tank 5 is blocked.
The speed setting is too high.
You are working too fast.
The speed setting is too high.
The filter w or the juice outlet 6 is blocked.
The speed setting is too high.
Connect the appliance to a mains power socket.
the On/Off switch 9.
Switch the juicer off immediately and pull out the mains plug 8. Remove the blockage (see sec­tion "Juicing").
Clean the filter w (see section "Cleaning and Care").
Clean the filter w and the juice tank 5 (see section "Cleaning and care").
Use the on/off switch 9 to select speed level 1.
Work a little more slowly. Do not press too hard with the
pusher 1 when inserting more fruit/vegetables.
Use the on/off switch 9 to select speed level 1.
Clean the filter w and the juice outlet 6 (see section "Cleaning and Care").
Use the on/off switch 9 select speed level 1.
to
SFE 450 C3
GB│IE│NI│CY 
 13
Disposal
Do not dispose of the appliance in your normal domestic waste. This product is subject to the provisions of European Directive 2012/19/EU.
Dispose of the appliance via an approved waste disposal company or your municipal waste disposal facility. Please comply with all applicable regulations. Please contact your waste disposal facility if you are in any doubt.
Your local community or municipal authorities can provide information on how to dispose of the worn-out product.
Dispose of the packaging in an environmentally friendly manner. Note the labelling on the packaging and separate the packaging material components for disposal if necessary. The packaging material is labelled with abbreviations (a) and numbers (b) with the following meanings: 1–7: Plastics, 20–22: Paper and cardboard, 80–98: Composites.
The packaging is made from environmentally friendly material and can be disposed of at your local recycling plant.
14 │ GB
│IE│NI│
CY
SFE 450 C3
Kompernass Handels GmbH warranty
Dear Customer, This appliance has a 3-year warranty valid from the date of purchase. If this product
has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your receipt in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you or refund the purchase price (at our discretion). This warranty service requires that you present the defective appliance and the proof of purchase (receipt) within the three-year warranty period, along with a brief written description of the fault and of when it occurred.
If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after un­packing. Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guide­lines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or to fragile parts which could be considered as consumable parts such as switches, batteries or parts made of glass.
The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided.
This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications / repairs which have not been carried out by one of our authorised Service centres.
SFE 450 C3
GB│IE│NI│CY 
 15
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
Please have the till receipt and the item number (e.g.IAN12345) available
as proof of purchase.
You will find the item number on the type plate on the product, an engraving
on the product, on the front page of the operating instructions (below left) or on the sticker on the rear or bottom of the product.
If functional or other defects occur, please contact the service department
listed either by telephone or by e-mail.
You can return a defective product to us free of charge to the service address
that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals, product videos and installation software at www.lidl-service.com. This QR code will take you directly to the Lidl service page (www.lidl-service.com) where you can open your operating instructions by entering the item number (IAN) 123456.
Service
Service Great Britain
Tel.: 0800 404 7657 E-Mail: kompernass@lidl.co.uk
Service Ireland
Tel.: 1890 930 034 (0,08 EUR/Min., (peak)) (0,06 EUR/Min., (off peak)) E-Mail: kompernass@lidl.ie
CY
Service Cyprus
Tel.: 8009 4409 E-Mail: kompernass@lidl.com.cy
IAN 332479_1910
Importer
16 │ GB
Please note that the following address is not the service address. Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH BURGSTRASSE 21 44867 BOCHUM GERMANY www.kompernass.com
│IE│NI│
CY
SFE 450 C3
Recipes
Ginger shot
approx. 8 shots
WHAT IS A GINGER SHOT?
Ingredients
100 g ginger50 g fresh turmeric2 lemons1 orangeHoney to sweetenA pinch of pepper A little cinnamon to taste
Preparation
1) Prepare the ginger, turmeric, lemons and orange as described in the juicer
"Ginger shots" are small portions (approx. 30 ml) of a cold ginger drink
which should preferably be drunk once a day in order to exploit the concentrated benefits of ginger.
Ginger is well known for its positive properties: in addition to its high vitamin C content, ginger contains a large number of important minerals. A ginger shot can make you fit for the day, strengthen your immune system, boost your metabolism and contribute to your general well-being.
instructions.
SFE 450 C3
2) Juice everything using the juicer.
3) Mix the juices and add a pinch of pepper.
4) Sweeten the shot with honey and add some cinnamon if required.
5) Serve the ginger shots in small glasses, e.g. schnapps glasses.
NOTE
Ginger shots can be kept for approx. 4–6 days in the refrigerator in an
airtight bottle.
GB│IE│NI│CY 
 17
Carrot and fruit mix
2–3 people
Ingredients
3 apples5 carrots 3 oranges
Preparation
1) Prepare the apples, carrots and oranges as described in the juicer instructions.
2) Juice everything using the juicer.
3) Mix the juices together.
Orange, ginger and lemon drink
2–3 people
Ingredients
4 apples 5 carrots1 lemon1 piece of ginger (approx. 3 cm)
Preparation
1) Prepare the apples, carrots, lemon and ginger as described in the juicer instructions.
18 │ GB
2) Juice everything using the juicer.
3) Mix the juices together.
│IE│NI│
CY
SFE 450 C3
Loading...
+ 49 hidden pages
