• This guide shows you how to connect your speakers and DVD player and enjoy multi-channel surround sound.
• For full details on using this unit, refer to the main operating instructions.
• Please be certain that this unit is unplugged from the AC outlet before making any connections.
Placing Speakers
■ If you have 5.1 ch speakers
1. Front Left
2. Front Right
3. Center
4. Surround Left
5. Surround Right
6. Subwoofer
• Be sure to connect speakers firmly
and correctly according to the channel (left and right) and the polarity (+
and -). If the connections are faulty,
no sound will be heard from the
speakers, and if the polarity of the
speaker connection is incorrect, the
sound will be unnatural and lack
bass.
■ Caution
• Be sure to use the speakers with
the impedance of 6 ohms or above.
• Do not let the bare speaker wires
touch each other or any metal part
of this unit. This could damage this
unit and/or the speakers.
• Never touch the speaker terminals
while the AC input cord is connected to the wall AC outlet. Doing so
could result in electric shocks.
Connecting Speakers
QUICK START GUIDE
1
RD-6504(AG)-Quick:RD-6504(AG)-Quick 2009-02-12 오 9:11 페이지 3
Connecting TV & DVD Player
■ Connecting a TV
• Connect the TV to the same type of Monitor video output that you did connect to the DVD player, as shown.
■ Connecting a DVD Player
• Use a Component, S-video or (composite) video cable to connect this unit's VIDEO 2 to the corresponding video
output on your DVD player, as shown.
• Use an Optical or Coaxial cable to connect this unit's OPTICAL IN or COAX IN 2 to the optical output or the coaxial
output on your DVD player. (You don't need to do both.)
• Use an Audio (analog) cable to connect this unit's VIDEO 2 (L/R) to audio output on your DVD player.
• Use a HDMI cable to connect this unit's HDMI 2 to HDMI output on your DVD player.
QUICK START GUIDE
• There are two types of video jacks (COMPONENT,(composite) VIDEO) for analog video connections and the HDMI
connector for digital video and audio connections.
Connect them to the corresponding video jacks according to their capability.
• For your reference, the exellence in picture quality is as follows : "HDMI" > "COMPONENT" > "(composite) VIDEO".
• When making COMPONENT VIDEO connections, connect "Y" to "Y", "P
to "C
R" (or "R-Y", "PR").
B/CB" to "CB" (or "B-Y", "PB") and "PR/CR"
