M-84PRO
Thermal Transfer Printer
OPERATOR MANUAL
PN 9001105 Rev. A
SATO America, Inc.
10350A Nations Ford Road
Charlotte, NC 28273
Main Phone: (704)644-1650
Tech Support Hotline: (704)644-1660 Tech Support Fax: (707)644-1662 E-Mail: satosales@satoamerica.com www.satoamerica.com
© Copyright 2003
SATO America, Inc.
All rights reserved. No part of this document may be reproduced or issued to third parties in any form whatsoever without the express permission of SATO America, Inc. The materials in this document is provided for general information and is subject to change without notice. SATO America, Inc. assumes no responsibilities for any errors that may appear.
Preliminary 02/01/03
TABLE OF CONTENTS
Section 1. Printer Overview
Introduction.................................................................................................. |
1-1 |
Specifications............................................................................................... |
1-2 |
Section 2. Installation |
|
|
|
Introduction.................................................................................................. |
2-1 |
Unpacking and Parts Identification.............................................................. |
2-2 |
Setting Up the Printer .................................................................................. |
2-3 |
Loading Labels and Tags............................................................................. |
2-5 |
Loading the Ribbon ..................................................................................... |
2-8 |
Operators Panel............................................................................................ |
2-10 |
Rear Panel .................................................................................................... |
2-12 |
Sensors ......................................................................................................... |
2-13 |
Section 3. CONFIGURATION |
|
|
|
Printer Dip Switch Configuration ................................................................ |
3-1 |
Default Settings............................................................................................ |
3-7 |
Potentiometer Adjustments.......................................................................... |
3-8 |
LCD Panel Printer Configuration ................................................................ |
3-10 |
Section 4. CLEANING AND MAINTENANCE |
|
|
|
Introduction.................................................................................................. |
4-1 |
Adjusting the Print Quality .......................................................................... |
4-1 |
Cleaning the Print Head, Platen and Rollers................................................ |
4-2 |
Cleaning the Label Edge Sensors ................................................................ |
4-3 |
Replacing the Print Head ............................................................................. |
4-4 |
Section 5. Troubleshooting |
|
|
|
Initial Checklist............................................................................................ |
5-1 |
Using the IEEE1284 Parallel Interface........................................................ |
5-1 |
Using the RS232C Serial Interface.............................................................. |
5-2 |
Using The Universal Serial Bus (USB) Interface........................................ |
5-3 |
Using the Lan Ethernet Interface ................................................................. |
5-3 |
Error Signals ................................................................................................ |
5-6 |
SATO M-84PRO |
PN 9001105 Rev. A |
i |
Table of Contents
Section 6. Interface Specifications
Introduction.................................................................................................. |
6-1 |
Interface Types ............................................................................................ |
6-1 |
The Receive Buffer...................................................................................... |
6-2 |
IEEE1284 Parallel Interface ........................................................................ |
6-3 |
RS232 Serial Interface ................................................................................. |
6-5 |
Universal Serial Bus (USB) Interface.......................................................... |
6-8 |
Local Area Network (LAN) Optional Interface........................................... |
6-8 |
BiDirectonal Communications .................................................................... |
6-8 |
Section 7. Optional Accessories |
|
|
|
PCMCIA Memory Cards ............................................................................. |
7-1 |
Plug-in Interface Modules ........................................................................... |
7-2 |
Cutter ........................................................................................................... |
7-3 |
Label Dispenser ........................................................................................... |
7-4 |
Label Rewinder............................................................................................ |
7-5 |
Real Time Clock .......................................................................................... |
7-6 |
Flash Memory Expansion ............................................................................ |
7-6 |
ii |
PN 9001105 Rev. A |
SATO M-84PRO |
SECTION 1.
PRINTER OVERVIEW
INTRODUCTION
The SATO M-84PRO Thermal Transfer Printers are complete, high-performance on-site labeling systems. All printer parameters are user programmable using the front panel controls and the DIP switches. All popular bar codes and 14 human-readable fonts, including a vector font and two raster fonts, are resident in memory providing literally thousands of type styles and sizes.
The Operator’s Manual will help you understand the basic operations of the printer such as setup, installation, configuration, cleaning and maintenance.
The M-84PRO can print labels up to four inches wide and is available in three resolurions; 203 dpi, 305 dpi and 609 dpi. The resolution is determined by the print head that is installed in the printer and can be changed in the field simply by installing the desired print head. The printer autmatically detects the resolution of the print head and loads the appropriate controlling firmware.
The M-84PRO uses the standard SATO RISC printer command codes. The only differences between it and other RISC printers are the allowable values representing the print positions on the label. These values are specified in “dots” and will vary depending upon the resolution of the printer and the amount of memory available for imaging the label. The allowable range for the various M-84PRO models is specified in a table in the “e” and PRO Printer Programming Reference.
This commonality makes it very easy to convert labels from one RISC printer to another without having to create an entirely different command stream. There are some caveats that must be observed though to compensate for the different resolution print heads. The effect of the different printer resolutions are best illustrated by taking a label designed for a 203 dpi printer and sending the command stream to the its 305 dpi counterpart. The label printed will be an exact two-thirds scale, including the fonts, bar code dimensions and line lengths/widths. The only exception is the PostNet bar code which has only one legal size and the printer resolution is automatically compensated for by the printer. Conversely, a label designed for a 305 dpi printer and sent to its 203 dpi cousin will be one-third larger. It probably will be “truncated” if the resulting label size is larger than the maximum allowable for the printer.
SATO M-84PRO |
PN 9001105 Rev. A |
Page 1-1 |
Section 1: Overview
GENERAL PRINTER SPECIFICATIONS
|
|
|
|
|
|
|
|
|
SPECIFICATION |
M-84PRO-2 |
|
M-84PRO-3 |
|
M-84PRO-6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Method |
|
Direct or Thermal Transfer |
|
|
||
|
|
|
|
|
|
|
|
|
Speed (User Selectable) |
2 to 10 ips |
|
2 to 8 ips |
|
2 to 6 ips |
|
|
|
50 to 250 mm/s |
|
50 to 200 mm/s |
|
50 to 150 mm/s |
|
|
|
|
|
|
|
|
|
|
Print Module (Dot Size) |
.0049 in. |
|
.0033 in. |
|
0017 in. |
|
|
|
.125 mm |
|
.083 mm |
|
.081 mm |
|
|
|
|
|
|
|
|
|
|
Resolution |
203 dpi |
|
305 dpi |
|
609 dpi |
|
|
|
8 d/mm |
|
12 d/mm |
|
24 d/mm |
|
|
|
|
|
|
|
|
|
|
Maximum Print Width |
|
|
4.1 in. |
|
|
|
|
|
|
|
104 mm |
|
|
|
|
|
|
|
|
|
|
|
|
Maximum Print Length |
49.2 in. |
|
32.8 in. |
|
14.0 in. |
|
|
|
1249 mm |
|
835 mm |
|
356 mm |
|
|
|
|
|
|
|
|
|
|
MEDIA |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Minimum Width |
|
|
.87 in. |
|
|
|
|
|
|
|
22 mm |
|
|
|
|
|
|
|
|
|
|
|
|
Minimum Length |
|
|
0.24 in. (6 mm) |
|
|
|
|
Continuous |
|
|
|
|
||
|
Tear-Off |
|
|
0.63 in. (16 mm) |
|
|
|
|
Cutter |
|
|
1.18 in. (30 mm) |
|
|
|
|
Dispense |
|
|
1.18 in. (30 mm) |
|
|
|
|
|
|
|
|
|
|
|
|
Maximum Width |
|
|
5.0 in. |
|
|
|
|
|
|
|
125 mm |
|
|
|
|
|
|
|
|
|
||
|
Type |
|
Roll or Fan-Fold Die Cut Labels |
|
|
||
|
|
|
|
Thermally Sensitive |
|
|
|
|
|
|
|
|
|
|
|
|
Maximum Caliper |
|
|
0.008 in. |
|
|
|
|
|
|
|
0.21 mm |
|
|
|
|
|
|
|
|
|
|
|
|
Roll OD (max) Face-In |
|
|
8.6 in. |
|
|
|
|
|
|
|
220 mm |
|
|
|
|
|
|
|
|
|
|
|
|
Core ID (min) |
|
|
3 in |
|
|
|
|
|
|
|
76.2 mm |
|
|
|
|
|
|
|
|
|
|
|
|
SENSING |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
See-Thru |
|
|
Movable |
|
|
|
|
|
|
|
|
|
|
|
|
Reflective Eye-Mark |
|
|
Movable |
|
|
|
|
|
|
|
|
|
|
|
|
Continuous Form |
|
|
Sensor Not Used |
|
|
|
|
|
|
|
|
|
|
|
|
RIBBON |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Maximum Width |
|
|
4.4 in. (111 mm) |
|
|
|
|
|
|
|
|
|
|
|
|
Length (max) |
|
|
1475 ft. (450 m) |
|
|
|
|
|
|
|
|
|
||
|
Thickness |
|
4.5 micron, Wound Face-In |
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Page 1-2 |
PN 9001105 Rev. A |
SATO M-84PRO |
Section 1: Overview
SPECIFICATION |
|
M-84PRO All Models |
|
|
|
|
|
|
CONTROLS AND INDICATORS |
|
|
|
|
|
Power |
|
Green LED |
|
|
|
On-Line |
|
Green LED |
|
|
|
Label |
|
Red LED |
|
|
|
Ribbon |
|
Red LED |
|
|
|
Error |
|
Red LED |
|
|
|
LCD Panel |
|
2 Line x 16 Character |
|
|
|
Label Feed |
|
Front Panel |
|
|
|
Power On/Off Switch |
|
Front Panel |
|
|
|
POTENTIOMETER ADJUSTMENTS |
|
|
|
|
|
Print Darkness |
|
Front Panel |
|
|
|
Offset |
|
Front Panel |
|
|
|
Pitch |
|
Front Panel |
|
|
|
Display |
|
Front Panel |
|
|
|
INTERFACE CONNECTIONS (1) |
|
|
Parallel |
|
IEEE1284 Standard |
|
|
|
Serial |
|
RS232C (9600 to 57600 bps) Standard |
|
|
RS422/485 (9600 to 57600 bps) Optional |
|
|
Ready/Busy or X-On/X-Off Flow Control |
|
|
Bi-directional Status |
|
|
|
Universal Serial Bus |
|
USB Ver. 1.1 Standard |
|
|
|
Ethernet |
|
10/100BaseT |
|
|
|
PROCESSING |
|
|
|
|
|
CPU |
|
32 Bit RISC |
|
|
|
Flash ROM |
|
2 MB |
|
|
|
SDRAM |
|
16 MB |
|
|
|
Receive Buffer |
|
2.95 MB |
|
|
|
Memory Expansion |
|
See Options and Accessories |
|
|
|
(1) Only one interface module can be installed in a printer at a time.
SATO M-84PRO |
PN 9001105 Rev. A |
Page 1-3 |
Section 1: Overview
CHARACTER FONTS
|
|
|
|
|
|
|
|
|
SPECIFICATION |
|
M-84PRO-2 |
M-84PRO-3 |
|
M-84PRO-6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MATRIX FONTS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
U Font |
|
|
5 dots W x 9 dots H |
|
|
|
|
|
|
|
|
|
|
|
|
S Font |
|
|
8 dots W x 15 dots H |
|
|
|
|
|
|
|
|
|
|
|
|
M Font |
|
|
13 dots W x 20 dots H |
|
|
|
|
|
|
|
|
|||
|
XU Font |
|
5 dots H x 9 dots H (Helvetica) |
|
|||
|
|
|
|
|
|||
|
XS Font |
|
17 dots H x 17 dots W (Univers Condensed Bold) |
|
|||
|
|
|
|
|
|||
|
XM Font |
|
24 dots H x 24 dots W (Univers Condensed Bold) |
|
|||
|
|
|
|
|
|
|
|
|
OA Font (OCR-A) |
|
15 dots W x 22 dots H |
22 dots W x 33 dots H |
|
44 dots W x 66 dots H |
|
|
|
|
|
|
|
|
|
|
OB Font (OCR-B) |
|
30 Dots W x 36 dots H |
30 Dots W x 36 dots H |
|
60 dots W x 72 dots H |
|
|
|
|
|
|
|
|
|
|
AUTO SMOOTHING FONTS |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
WB |
|
|
18 dots W x 30 dots H |
|
|
|
|
|
|
|
|
|
|
|
|
WL |
|
|
28 dots H x 52 dots H |
|
|
|
|
|
|
|
|
|||
|
XB |
|
48 dots H x 48 dots W (Univers Condensed Bold) |
|
|||
|
|
|
|
|
|||
|
XL |
|
48 dots W x 48 dots H (Sans Serif) |
|
|||
|
|
|
|
|
|
|
|
|
VECTOR FONT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Proportional or Fixed Spacing |
|
|||
|
|
|
Font Size 50 x 50 dots to 999 x 999 dots |
|
|||
|
|
|
Helvetica, 10 Font Variations |
|
|||
|
|
|
|
|
|
|
|
|
AGFA® RASTER FONTS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Font A |
|
|
CG Times ®, 8 pt to 72 pt |
|
|
|
|
|
|
|
|
|||
|
Font B |
|
CG Triumvirate®, 8 pt to 72 pt |
|
|||
|
|
|
|
|
|
|
|
|
DOWNLOADABLE FONTS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bit Mapped TrueType® Fonts with Utility Program |
|
|||
|
|
|
|
|
|
|
|
|
CHARACTER CONTROL |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Expansion to 12X in either X or Y coordinates |
|
|||
|
|
|
|
Character Pitch control |
|
|
|
|
|
|
|
Line Space control |
|
|
|
|
|
|
|
Journal Print facility |
|
|
|
|
|
|
0°, 90°, 180° and 270° Rotation |
|
|||
|
|
|
|
|
|
|
|
Page 1-4 |
PN 9001105 Rev. A |
SATO M-84PRO |
|
|
Section 1: Overview |
|
BAR CODES |
|
|
|
|
|
|
|
|
BAR CODE |
M-84PRO All Models |
|
|
|
|
|
|
|
|
|
|
SYMBOLOGIES |
|
|
|
|
|
|
|
Linear Bar Codes |
Bookland (UPC/EAN Supplemental) |
|
|
|
|
|
|
|
EAN-8/EAN-13 |
|
|
|
|
|
|
|
CODABAR |
|
|
|
|
|
|
|
CODE 39 |
|
|
|
|
|
|
|
CODE 93 |
|
|
|
|
|
|
|
CODE 128 |
|
|
|
|
|
|
|
Interleaved 2 of 5 (I 2/5) |
|
|
|
|
|
|
|
Industrial 2 of 5 |
|
|
|
|
|
|
|
Matrix 2 of 5 |
|
|
|
|
|
|
|
MSI |
|
|
|
|
|
|
|
POSTNET |
|
|
|
|
|
|
|
UCC/EAN-128 |
|
|
|
|
|
|
|
UPC-A/UPC-E |
|
|
|
|
|
|
Two Dimensional |
Data Matrix |
|
|
|
|
|
|
|
Maxicode |
|
|
|
|
|
|
|
PDF417 |
|
|
|
|
|
|
|
Micro PDF |
|
|
|
|
|
|
|
Truncated PDF |
|
|
|
|
|
|
|
QR Code |
|
|
|
|
|
|
Ratios |
1:2, 1:3, 2:5, User Programmable |
|
|
|
|
|
|
Bar Height |
4 to 999 dots, User Programmable |
|
|
|
|
|
|
Rotation |
0°, 90°, 180° and 270° Rotation |
|
|
|
|
|
|
OTHER FEATURES |
|
|
|
|
|
|
|
Sequential Numbering |
Sequential numbering of both numerics and bar codes |
|
|
|
|
|
|
Custom Characters |
RAM storage for custom designed characters |
|
|
|
|
|
|
Graphics |
Dot addressable, SATO Hex/Binary, BMP or PCX formats |
|
|
|
|
|
|
Forms Overlay |
Overlay of predesigned forms in image buffer |
|
|
|
|
|
|
|
|
|
SATO M-84PRO |
PN 9001105 Rev. A |
Page 1-5 |
Section 1: Overview
PHYSICAL
|
|
|
|
|
SPECIFICATION |
M-84PRO All Models |
|
|
|
|
|
|
|
|
|
|
PHYSICAL |
|
|
|
|
|
|
|
Wide |
10.4 in. (265 mm) |
|
|
|
|
|
|
Deep |
17.1 in. (435 mm) |
|
|
|
|
|
|
High |
13.4 in.(341 mm) |
|
|
|
|
|
|
Weight |
39.7 lb. (18.0 Kg) |
|
|
|
|
|
|
POWER |
|
|
|
|
|
|
|
Input Voltage |
115/220 VAC +/-10%, 50/60 Hz +/-1% |
|
|
|
|
|
|
Power Consumption |
130W Operating, 24W Idle |
|
|
|
|
|
|
ENVIRONMENTAL |
|
|
|
|
|
|
|
Operating Temperature |
41° to 104°F (5° to 40°C) |
|
|
|
|
|
|
Storage Temperature |
23° to 140°F (-5° to 60°C) |
|
|
|
|
|
|
Storage Humidity |
30 to 90% RH Non-Condensing |
|
|
|
|
|
|
Operating Humidity |
30 to 80% RH Non-Condensing |
|
|
|
|
|
|
Electrostatic Discharge |
8kV |
|
|
|
|
|
|
REGULATORY APPROVALS |
|
|
|
|
|
|
|
Safety |
VCCI (Class B), UL, CUL, CE, FCC Class B |
|
|
|
|
|
|
RFI/EMI |
FCC Class B |
|
|
|
|
|
|
|
|
|
Page 1-6 |
PN 9001105 Rev. A |
SATO M-84PRO |
Section 1: Overview
OPTIONAL ACCESSORIES
ACCESSORIES AND OPTIONS
PCMCIA MEMORY |
One slot for PCMCIA Memory Card (up to 4 MB SRAM or 16 MB Flash |
EXPANSION |
ROM). Can be used for graphic file storage, print buffer expansion, format |
|
storage and downloaded fonts. |
|
|
FLASH ROM |
Internal 4MB Flash ROM PCB. |
EXPANSION |
|
|
|
REAL TIME CLOCK |
An internal Date/Time clock that can be used to date/time stamp labels at |
|
the time of printing. |
|
|
LABEL DISPENSER |
Internally mounted attachment allowing labels to be peeled from backing |
|
for immediate (on demand) applications. Backing not rewound. |
|
|
LABEL REWINDER |
External Option that rewinds labels onto a roll after they are printed. |
|
|
LABEL CUTTER |
An attachment allowing labels to be cut at specified intervals. Controlled |
|
through programming. |
|
|
COAX/TWINAX |
Coan/Twinax Plug-In Interface module. Coax interface emmulates an IBM |
INTERFACE |
3287-2 printer with a stndard Type A BNC connector. Twinax interface |
|
emulates IBM 5224, 5225, 5226 or 4214 printers with auto-terminate/cable |
|
through capabilities. |
|
|
PARALLEL INTERFACE |
IEEE1284 Bi-Directional Plug-In Interface Module |
|
|
SERIAL INTERFACE |
High Speed RS232 Plug-In Interface Module |
|
|
USB INTERFACE |
Universal Serial Bus Plug-In Interface Module |
|
|
ETHERNET INTERFACE |
10/100 BaseT Plug-In Interface Module |
|
|
|
|
All specifications subject to change without notice.
SATO M-84PRO |
PN 9001105 Rev. A |
Page 1-7 |
Section 1: Overview
This page left intentionally blank.
Page 1-8 |
PN 9001105 Rev. A |
SATO M-84PRO |
SECTION 2.
INSTALLATION
INTRODUCTION
This section of the manual has been written to help you install the SATO M-84PRO printers and to get started as quickly as possible. It is recommend to read each chapter in this manual before the installation or the use of the printers.
The following information is provided in this section:
•Unpacking and Parts Identification
•Setting Up the Printer
•Loading Labels or Tags
•Loading the Ribbon
•Operator Panel
SATO M-84PRO |
PN 9001105 Rev. A |
Page 2-1 |
Section 2. Installation
UNPACKING AND PARTS IDENTIFICATION
Consider the following when unpacking the printer:
•The box should stay right-side up.
•Lift the printer out of the box carefully.
•Remove the plastic covering from the printer.
•Remove the accessory items from their protective containers.
•If the printer has been stored in a cold environment, allow it to reach room temperature before powering it on.
•Set the printer on a solid, flat surface. Inspect the shipping container and printer for any signs of damage that may have occurred during shipping.
NOTE: The following illustrations are representative only. Your printer may not be packed exactly as shown here, but the unpacking steps are similar.
Page 2-2 |
PN 9001105 Rev. A |
SATO M-84PRO |
Section 2. Installation
Verify that you have the following materials when unpacking:
•Printer
•Power Cord and Extra Ribbon Core
•Operator’s Manual
•CD-ROM
Power Cord
Printer
CD-ROM
Operator Manual
Ribbon Core
SETTING UP THE PRINTER
Consider the following when setting up the printer:
•Locate a solid flat surface with adequate room to set the printer. Make sure there is enough room at the top and right-hand (facing the printer) side to provide clearance for the label access door to swing open.
•The location should be near the host computer or terminal. The maximum distance for RS232 cables is 35 feet and six feet for IEEE1284 Parallel cables. Cables can be purchased locally, and their configuration will depend upon the host system being used. A IEEE1284 compliant cable must be used to realize the full throughput potential of the printers.
•For information on interfacing the printer to a host system, see Section 5: Interface Specifications.
SATO M-84PRO |
PN 9001105 Rev. A |
Page 2-3 |
Section 2. Installation
Ribbon Rewind |
Ribbon Supply |
Spindle |
Spindle |
Top Access |
|
Door |
Side Access |
|
Door |
LCD |
|
Display |
|
DIP Switch |
|
Cover |
|
Power Switch |
|
|
Label Hold Down |
|
Label Roll Retainer |
|
Label Supply Spindle |
|
Label Guide |
|
Print Head |
|
Head Latch |
|
Platen |
Page 2-4 |
PN 9001105 Rev. A |
SATO M-84PRO |
Section 2. Installation
LOADING LABELS AND TAGS
1.Open the Top Access Door by swinging it up and to the left. Open the Side Access Door by swinging it to the rear of the printer.
2.Open the Print Head Assembly by pushing the Head Latch toward the rear of the printer. The Print Head Assembly is spring-loaded and will automatically open as soon as the Head Latch is disengaged.
3.Loosen the Label Edge Guide and push it to the outside of the printer to give the maximum label width.
4.Remove the Label Roll Retainer
Top Access Door
Side Access
Door
Label Roll Retainer
Print Head
Head Latch
Label Hold Down
Sensor Assembly
Label
Guide
Label Edge Guide
SATO M-84PRO |
PN 9001105 Rev. A |
Page 2-5 |
Section 2. Installation
5.If using roll labels (or tags), load the roll onto the Label Supply Spindle so that the printing side of the labels faces upwards as it unwinds from the roll. The labels should be wound face-in. Push the roll all the way to the inside of the printer and push the Label Roll Retainer snugly against the outside of the label roll.
6.If using fanfold labels (or tags) set them on a flat surface behind the printer. Pass the labels (printing side up) through the slot in the rear of the printer.
7.Make sure the labels are routed under the Label Guide and through the Sensor Assembly.
8.Open the Label Hold-Down by squeezing the green tab and the release tab together. The Label Hold Down is spring loaded and will open automatically when the latch is disengaged. Feed the labels under the Label Guide, under the Label Hold Down, through the Sensor Assembly and out the front of the printer.
9.Inspect the label routing and verify that the path matches that illustrated in the Label Loading diagram. Set the Adjustable Label Guide to keep the labels against the inside of the printer.
10.Close the Label Hold-Down by pushing downward on the green tab until it latches closed.
NOTE: If the Label Dispenser option has been purchased, see Appendix A, for proper
label routing instructions.
Head
Label Roll
Label Roll Retainer
Label
Guide
Page 2-6 |
PN 9001105 Rev. A |
SATO M-84PRO |
Inside Label Edge Guides |
Label Hold Down |
|
Sensor |
Sensor |
Assembly |
Positioning |
11.Adjust the outside Label Edge Guide until it touches the outside edge of the label and tighten the thumb screw. Make sure the labels are also touching the inside edge guides.
CAUTION: Using media narrower than the maximum print width may cause excess head wear due to the label edge. See page 2-9 for precautions.
12.If the ribbon is already loaded, close the Print Head by rotating the black Head Latch toward the front of the printer until it latches closed.
13.If the ribbon is not loaded, see the following description for loading instructions.
14.Close both the Access Doors.
Section 2. Installation
Route Labels
Under Guide
Head
Latch
SATO M-84PRO |
PN 9001105 Rev. A |
Page 2-7 |
Section 2. Installation
LOADING THE RIBBON
Ribbon Rewind |
Ribbon Path |
Ribbon Roll |
||
Spindle |
|
|
|
|
Head Latch
Dispensed
Label
Label Backing |
Sensor |
Label Hold |
Label Path |
|
Assembly |
Down |
|
1.Open the Top Access Door by swinging it up and to the left and the Side Access Door by swinging it toward the rear of the printer.
Top Access Door
Side Access Door
2.Open the Print Head by rotating the Head Latch toward the rear of the printer. The Print Head is spring-loaded and will automatically open as soon as the Head Latch is disengaged.
3.Locate the extra ribbon core supplied with the printer. Place the core on the Ribbon Rewind Spindle, pushing it all the way to the inside of the spindle. Note that the new empty core of each subsequent roll becomes the next rewind core.
4.Load the ribbon onto the Ribbon Supply Spindle, also pushing it all the way to the inside of the spindle. The dull side of the ribbon should be facing down as it travels through the Print Head Assembly.
5.Feed the leader portion of the ribbon through the Print Head Assembly and up to the Ribbon Rewind Spindle following the routing shown in the diagram.
6.Load the ribbon behind and over the top of the Ribbon Rewind Spindle and tape it to the Extra Ribbon Core. Make sure it matches the ribbon path shown in the diagram.
7.Manually turn the Rewind Spindle to wrap the ribbon onto the core one to two turns to secure it.
Page 2-8 |
PN 9001105 Rev. A |
SATO M-84PRO |
8.If the labels or tags are already loaded, close the Print Head Assembly by pushing downward on the green tab until it latches closed.
9.Run a test print to ensure that the labels and ribbons were loaded correctly.
Ribbon
Core
Section 2. Installation
Tape
CAUTION: If your labels are less than the full width of the print head, the outside edge will eventually wear out a small portion of the print head, resulting in an area that will not print. Special care must be taken if you plan to use multiple widths of labels, since the damaged portion of the print head caused from edge wear on a more narrow label may affect the printing on a wider label. We suggest you plan your print formats carefully to avoid using the area of possible damage on the print head when using a wider label. The small area of damage will have no effect on printing with the undamaged part of the print head. Damage from a label edge is physical damage and is unavoidable. It is not covered by warranty. It is possible to delay such damage by always ensuring that the ribbon used is wider than the label stock. This will help to protect the print head from label edge damage.
SATO M-84PRO |
PN 9001105 Rev. A |
Page 2-9 |
Section 2. Installation
OPERATOR PANEL
The M-84PRO Operator Panel consists of five LED indicators, two momentary contact switches, three DIP switches, four adjustment potentiometers and one LCD Display. All of these are accessible from the front of the printer. They are used to set the printer operating parameters and to indicate the status of the printer to the operator. After you power on the printer, familiarize yourself with the keys and indicators as it will help you understand the configuration process.
Potentiometer to adjust print darkness (fine tuning) |
|
OFFSET |
Potentiometer to adjust amount of back/forward feed for dispenser/cutter/tear- |
|
off position (+/- 3.75 mm) |
PITCH |
Potentiometer to adjust home position of the label (+/- 3.75 mm). Affects stop |
|
position of label feed, print position and dispense position. |
DISPLAY |
Potentiometer to adjust the contrast of the LCD display. |
POWER |
LED, illuminated when the power is on. |
LABEL |
LED, illuminated when the label supply is not detected. |
RIBBON |
LED, illuminated when the ribbon motion sensor does not detect any ribbon |
|
motion (ribbout out condition). |
ERROR |
LED, illuminated when there is a system fault such as an open print head. |
Page 2-10 |
PN 9001105 Rev. A |
SATO M-84PRO |
Section 2. Installation
ON LINE |
LED, illuminated when printer is ready to receive data. Toggled on/off with LINE |
|
key. |
LINE |
Momentary switch. Pressing this key toggles the printer between the on- |
|
line and off-line mode. When the printer is on-line, it is ready to receive data |
|
from the host. This key acts as a pause during a print job by taking the printer |
|
off-line. It can also be used as a Pause function key to stop the printer during |
|
the printing process. |
FEED |
Momentary switch. Pressing this key feeds one blank label when the printer is |
|
Off-Line. When the printer is On-Line, another copy of the last label will be |
|
printed (Reprint W/Feed must be enabled in the LCD panel Service Mode). |
DSW |
DIP switch array to set operational parameters of the printer. |
LCD |
2 Line x 16 Character LCD display. Used for setting operational parameters of |
|
the printer and displaying error conditions. |
SATO M-84PRO |
PN 9001105 Rev. A |
Page 2-11 |
Section 2. Installation
REAR PANEL
AC INPUT |
Input 115VAC, 50/60 Hz connector. Use cable provided. |
AC FUSE |
Input power protection. 3A/250V rating. |
INTERFACE SLOT |
Connector for Plug-In Interface Module. |
MEMORY CARD SLOT |
Connector for optional PCMCIA Memory Card. |
EXT |
External signal connector, AMP 57-60140. |
Plug-In Interface
Module
Fan-Fold
Access Panel EXT Port
Connector
PCMCIA
Card Cover
Fuse
AC Connector
Page 2-12 |
PN 9001105 Rev. A |
SATO M-84PRO |
Section 2. Installation
SENSORS
The M-84PRO printers contain three sensing units; a Ribbon End motion sensor, a Head Open microswitch and a Label Indexing Sensor.
RIBBON END SENSOR Detect motion of the Ribbon Supply Spindle and signals the printer
|
when it is turning. |
||
HEAD OPEN SENSOR |
A micro-switch that is activated when the head is unlatched. |
||
LABEL INDEXING SENSOR |
The sensing assembly contains two types of sensors, one for label gap |
||
|
and one for eye-mark sensing. The sensors are adjustable over a |
||
|
limited range. |
||
|
|
|
Label Gap Sensor |
|
|
|
|
|
|
|
Reflective Sensor |
Eye-Mark on |
|
bottom of |
|
liner. |
14 mm |
|
min |
Reflective
7 mm to 54 mm
Maximum number of print head dots is dependent upon the model.
Label Gap
The range of sensor adjustment can be increased to allow the Gap sensor to be positioned as close as 3 mm from the inside label edge. Contact SATO for information on how to make this modification.
SATO M-84PRO |
PN 9001105 Rev. A |
Page 2-13 |
