COMBINATION CUTTER PSFS 250 A1
COMBINATION CUTTER
Translation of the original instructions
KOMBI-FRÄSER
Originalbetriebsanleitung
IAN 270700
ΦΡΕΖΑ-KOMBI
Μετάφραση των αυθεντικών οδηγιών λειτουργίας
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και εξοικειωθείτε με όλες τις
λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / CY Translation of the original instructions Page 1
GR / CY Μετάφραση των αυθεντικών οδηγιών λειτουργίας Σελίδα 11
DE / AT / CH Originalbetriebsanleitung Seite 21
Contents
Introduction ......................................................2
Intended use ................................................................ 2
Features ................................................................... 2
Package contents ............................................................ 2
Technical data .............................................................. 2
General Power Tool Safety Warnings ................................3
1. Work area safety .......................................................... 3
2. Electrical safety ........................................................... 3
3. Personal safety ............................................................ 3
4. Power tool use and care .................................................... 4
5. Service .................................................................. 4
Additional safety instructions for grinders and polishers .............................. 4
Additional safety instructions for routers ........................................... 4
Original accessories/auxiliary equipment ......................................... 5
Operation .......................................................5
Switching on and off .........................................................5
Adjusting the rotational speed .................................................. 5
Changing tools .............................................................. 5
Fitting abrasive belts .......................................................... 6
Adjusting the working depth .................................................... 6
Milling direction on edges ..................................................... 6
Carrying out plunge cuts ...................................................... 6
Swivelling the handle ......................................................... 6
Using the parallel guide ....................................................... 6
Sawing circles ..............................................................6
Extracting dust .............................................................. 7
Using the tool in continuous operation ............................................ 7
Maintenance and cleaning ..........................................7
Disposal .........................................................7
Warranty ........................................................8
Service ..........................................................8
Importer ........................................................8
Translation of the original Conformity Declaration ......................9
GB
IE
CY
PSFS 250 A1
1
COMBINATION CUTTER
GB
IE
PSFS 250 A1
CY
Introduction
Congratulations on the purchase of your
new appliance. You have selected a high-
quality product. The operating instructions
are part of this product. They contain important
information on safety, usage and disposal.
Before using the product, familiarise yourself with all
handling and safety guidelines. Use the product only
as described and for the range of applications specified. Please also pass these operating instructions on
to any future owner.
Intended use
This appliance is intended for the processing of
materials such as wood, plastic, fibreboard, wall
tiles, aluminium and sheet metal with the recommended tools and accessories. It is also suitable
for grinding with a range of cylindrical grinders
and for milling with milling bits of 4.8 mm shaft
diameter. Any other usage of or modification to the
appliance is deemed to be improper and carries
the risk of serious personal injury. The manufacturer
accepts no responsibility for damage(s) attributable
to misuse. Not for commercial use.
Features
Locking switch
Infinitely variable speed control
Power cable
ON/OFF switch
Wing adjusting screw
Extraction nozzle
Baseplate
Collet chuck
Wing screw (footplate)
Tensioning nut
Spindle lock button
Ventilation slits
Swivel lock
Open-ended spanner
Circular/parallel cutting attachment
Abrasive belt mandrel
Abrasive belt
Slotting cutter (HSS)
Multipurpose milling cutter (HSS)
Adapter (extraction nozzle)
Package contents
1 combination cutter PSFS 250 A1
1 rip fence with circular cutting function
1 dust extraction adapter
1 open-ended spanner
1 multipurpose milling cutter (HSS)
1 slotting cutter (HSS)
1 abrasive belt mandrel
6 abrasive belts
1 operating instructions
Technical data
Rated power input: 250 W
Rated voltage: 230 V~, 50 Hz
Idle speed: n
10000–28000 min
0
Collet capacity: 4.8 mm
Protection class: II /
Noise and vibration data:
Noise measurement value determined in accordance
with EN 60745. The A-rated noise level of the
power tool is typically as follows:
Sound pressure level: 75 dB (A)
Sound power level: 86 dB (A)
Uncertainty K: 3 dB
Wear hearing protection!
Weighted acceleration, typically:
Hand/arm vibration a
h
Uncertainty K = 1.5 m/s
< 2.5 m/s
2
2
-1
2
PSFS 250 A1
NOTE
► The vibration level specified in these instruc-
tions has been measured in accordance
with the standardised measuring procedure
specified in EN 60745 and can be used to
make equipment comparisons. The specified
vibration emission value can also be used to
make an initial exposure estimate.
WARNING!
► The vibration level varies in accordance with
the use of the power tool and may be higher
than the value specified in these instructions
in some cases. There is a risk of underestimation of the vibration load if the power tool is
used regularly in this manner. Try to keep the
vibration load as low as possible. Measures
to reduce the vibration load are, e.g. wearing
gloves and limiting the working time. Wherein
all states of operation must be included (e.g.
times when the power tool is switched off and
times where the power tool is switched on but
running without load).
General Power
Tool Safety Warnings
WARNING!
► Read all safety warnings and all instruc-
tions. Failure to follow the warnings and
instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or batteryoperated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools cre-
ate sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, cookers
and refrigerators. There is an increased risk
of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cable suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.
GB
IE
CY
PSFS 250 A1
3
c) Prevent unintentional starting. Ensure the switch
GB
IE
CY
is in the off-position before connecting to power
source and/or battery pack, picking up or
carrying the tool. Carrying power tools with
your finger on the switch or energising power
tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Wear suitable clothing. Do not wear loose
clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
4. Power tool use and care
a) Do not overload the power tool. Use the
correct power tool for your application. The
correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch is defec-
tive. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children. Do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools with care. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking into account the working conditions and
the work to be performed. Use of the power
tool for operations other than those intended
could result in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified
repair person using only original replacement
parts. This will ensure that the safety of the
power tool is maintained.
b) If the power cord is damaged, it must be replaced
with a special cable available from the manufacturer or its customer service.
Additional safety instructions for
grinders and polishers
■ TOXIC DUSTS! Working with the tool can pro-
duce harmful/toxic dusts which represent a
health hazard for the person operating the
appliance and for anyone else in the vicinity.
■ Avoid sanding lead paint or other harmful
materials.
■ Materials containing asbestos may NOT be
processed. Asbestos is a known carcinogen.
Wear safety goggles and a protective
dust mask!
Additional safety instructions for
routers
■ Always hold the appliance using insulated
handle surfaces since the milling cutter can
damage its own power cord. Contact with a
live cable may also cause metal parts of the
appliance to become live and may result in an
electric shock.
4
PSFS 250 A1
■ Only use milling bits of the correct shaft diameter
and which are suitable for the power tool
speed.
■ Fix and secure the workpiece using clamps
or other methods to a stable base. If you hold
the workpiece in your hands or against your
body only it will remain unstable, and this can
result in loss of control.
Original accessories/auxiliary
equipment
■ Use only the accessories and additional
equipment that are specified in the operating instructions and are compatible with the
appliance.
Operation
Never use the appliance for other purposes and
only with original parts/accessories. Using attachments or accessory tools other than those recommended in the operating instructions can lead to
a risk of injury. Only use completely unrolled and
undamaged extension cables with a capacity of
at least 5 A.
WARNING!
► Do not use this power tool to make cuts in the
vicinity of installations or openings containing
live electrical cables or in walls in which live
electrical cables are possibly hidden. The
bit can conduct electrical current into the
tool which can result in the danger of an
electrical shock for the operator.
– Trigger the circuit breakers or remove the
fuse in order to ensure that the affected
power circuit is isolated.
WARNING!
► Always hold the tool by the plastic housing
and always wear protective goggles when
working with the tool.
Switching on and off
Switching on:
♦ Press the ON/OFF switch
Switching off:
♦ Release the ON/OFF switch
.
.
Adjusting the rotational speed
♦ Turn the speed control to the right to increase
the speed.
♦ Turn the speed control
the speed.
to the left to decrease
Changing tools
NOTE
► Use only multitool milling cutter accessories
with a shaft diameter of ø 4.8 mm.
♦ Press and hold the spindle lock button
♦ Loosen the tensioning nut using the
ended spanner by turning it anticlockwise.
♦ Change the tool.
♦ Block the spindle lock, and tighten the tensioning
nut
with the aid of the open-ended spanner
.
Bits:
The bits supplied can be used for the following
applications:
Multipurpose milling cutter (HSS)
Suitable for: wood, chipboard, plastic, aluminium
and sheet metal
Slotting cutter (HSS)
Suitable for: wood, chipboard, plastic
Abrasive belt
Suitable for: sanding wood
NOTE
► If you are intending to cut wall tiles and/or
process sheet metal/metal alloys, please use
appropriate accessories from your specialist
supplier.
:
:
.
open-
:
GB
IE
CY
PSFS 250 A1
5
Fitting abrasive belts
GB
IE
♦ Push the abrasive belt onto the abrasive belt
CY
mandrel
the abrasive belt mandrel in order to fix the
abrasive belt .
♦ Fit the abrasive belts
section "Replacing tools".
from above . Tighten the bolt on
Adjusting the working depth
♦ Loosen the wing adjusting screw .
♦ Push the footplate
working depth (around 3.2 mm more than the
material thickness for complete cutting). The
maximum recommended cut depth forward is
13 mm *(applies only to multipurpose milling
cutters (HSS) ).
♦ Retighten the wing adjusting screw
Milling direction on edges
Carrying out plunge cuts
♦ Introduce the bit into the workpiece at an angle
of 45°.
♦ Slowly change the angle of the bit to 90°
before starting the cut.
NOTE
► The baseplate
surface.
must be flush with the material
as described in the
down to the required
.
Swivelling the handle
NOTE
► Do not rotate the handle while working.
Remove the plug from the mains socket and
ensure that the swivel lock
Swivelling to the horizontal position:
♦ Press the swivel lock
♦ Rotate the handle anticlockwise
vertical to the horizontal position until the swivel
lock engages.
Swivelling to the vertical position:
♦ Press the swivel lock
♦ Rotate the handle clockwise
zontal to the vertical position until the swivel
lock engages.
is engaged.
and hold it down.
from the
and hold it down.
from the hori-
Using the parallel guide
♦ Undo the wing screw on the baseplate ,
and push the guide rod on the circular/parallel
cutting attachment through the two recesses
on the bottom of the baseplate so that the
parallel guide is facing downwards.
♦ Align the tool at the required distance from the
workpiece edge. Tighten the wing screws
order to fix the circular/parallel cutting attach-
ment to the baseplate .
Sawing circles
NOTE
► Depending on the required results, the guide
hole is placed either on the inside or the outside of the circle circumference. Inside for
a hole – outside for a disc. The radius can
be fixed approximately between 5 to 16 cm.
in
♦ Draw a circle on the workpiece.
♦ Mark the centre of the circle and drill a hole in
it (plunge cut).
♦ Drill a guide hole on the outside of the circle
(plunge cut) (guide hole diameter 3 mm).
6
PSFS 250 A1
♦ Undo the wing screw on the baseplate ,
and push the guide rod on the circular/parallel
cutting attachment
on the bottom of the baseplate so that the
centring point is facing downwards.
♦ Insert the centring point into the centre of the
circle.
♦ Adjust the circular/parallel cutting attachment
spacing so that the bit can be inserted into the
guide hole at the edge of the circle.
♦ Lock the baseplate
screws .
♦ Switch the tool on by pressing the ON/OFF
switch
♦ Push the tool slowly forwards.
and holding it down.
through the two recesses
by tightening the wing
Extracting dust
■ The tool is fitted with an extraction nozzle
for dust extraction.
♦ Insert the adapter into the extraction nozzle .
♦ Connect a vacuum cleaner to the adapter
.
Using the tool in continuous operation
Maintenance and cleaning
WARNING! RISK OF INJURY!
Always switch the appliance off
before carrying out any work on it.
The appliance is maintenance-free.
■ Always clean the appliance directly after finishing
work.
■ Use a dry cloth to clean the housing. Under
no circumstances should you use detergents,
solvents or abrasive cleaners.
■ Ensure ventilation openings are always free of
obstructions.
■ Remove any adhering swarf with a brush.
NOTE
► Spare parts which are not listed (e.g.
► carbon brushes, switches, can be ordered
using our service hotline.
Disposal
The packaging is made from environmen-
tally friendly material and can be disposed
of at your local recycling plant.
GB
IE
CY
Lock the ON/OFF switch :
♦ Press the ON/OFF switch
♦ Now press the locking switch
the ON/OFF switch .
Unlocking the ON/OFF switch
♦ Press the ON/OFF switch
PSFS 250 A1
.
and release
:
and release it.
Do not dispose of power tools in
your normal domestic waste!
European Directive 2012/19/EU requires that
worn-out power tools be collected separately and
recycled in an environmentally compatible manner.
7
Warranty
GB
IE
This appliance is provided with a 3-year
warranty valid from the date of purchase.
CY
The appliance has been manufactured with
care and inspected meticulously prior to delivery. Please retain your receipt as proof
of purchase. In the event of a warranty claim,
please contact your Customer Service unit by
telephone. This is the only way to guarantee
free return of your goods.
The warranty only covers claims for material and
manufacturing defects, not for damage sustained
during carriage, components subject to wear and
tear or damage to fragile components such as
switches or batteries. This appliance is intended
solely for private use and not for commercial purposes. The warranty shall be deemed void in cases
of misuse or improper handling, use of force and
modifications/repairs which have not been carried
out by one of our authorised Service centres. Your
statutory rights are not restricted by this warranty.
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must be
reported immediately after unpacking, but no later
than two days after the date of purchase. Repairs
carried out after expiry of the warranty period shall
be subject to charge.
Service
WARNING!
► Have the power tool repaired by the
Service Centre or a qualified electrician
and only using genuine replacement parts.
This will ensure that the safety of the appliance is maintained.
► Always ensure that the plug or the power
cord is replaced only by the manufacturer of
the appliance or by an approved customer
service provider. This will ensure that the
safety of the appliance is maintained.
Service Great Britain
Tel.: 0871 5000 720 (£ 0.10/Min.)
E-Mail: kompernass@lidl.co.uk
IAN 270700
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
IAN 270700
CY
Service Cyprus
Tel.: 8009 4409
E-Mail: kompernass@lidl.com.cy
IAN 270700
Hotline availability:
Monday to Friday from 8:00 a.m. to 8:00 p.m. (CET)
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
8
PSFS 250 A1
Loading...
