Miele WS 5073 MOP-PROFI Operating instructions

Operating instructions

Washer-Extractor

WS 5073 MOP-PROFI

To avoid the risk of accidents or damage to the machine it is essential to read these instructions before installing, commissioning and using it for the first time.

en - GB

M.-Nr. 05 150 392

2 M.-Nr. 05 150 392

Contents

Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Guide to the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Washing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Preparing the wash load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Programme selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Opening the drum door at the end of the programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Dispensing detergent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Additional functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Programme changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Opening the drum door in the event of a power failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Possible reasons for increased levels of foaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Explanation of symbols on the data plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Notes for the installer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Transit fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Connection to water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Coin mechanism unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

EU Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

The washer-extractor must be installed by an approved service technician or an authorized Service Dealer.

M.-Nr. 05 150 392 3

Warning and Safety instructions

Please read the operating instructions be fore using this machine for the first time. They contain important information about the safety, use and maintenance of the machine. This way you will avoid the risk of accidents and damage to the machine.

Appropriate use of the machine

This washer extractor is only intended for

items of laundry which have not been im pregnated with dangerous or inflammable substances.

Only machine wash articles which pos

sess a care label stating they are suit able for machine washing.

It is the operator’s responsibility to en

sure that the standard of disinfection in thermal as well as chemo thermal proce dures is maintained (in accordance with § 18 IFSG) by carrying out suitable validation tests. These procedures should be checked on a regular basis, either thermo-electrically using loggers, or bacteriologically with bio indicators. The operator must pay particular attention to maintaining the correct parameters in the procedure, including temperature and with chemo thermal programmes the chemical concentration used. Disinfection programmes must not be interrupted, as this can have a limiting effect on the disinfection result.

On no account must solvents of the kind

used for dry cleaning be used in this ma chine. There may be the danger of fire or ex plosion.

Never use or store petrol or petroleum

based substances or any easily inflam mable substances near the machine. Do not use the machine lid as a resting place.

Danger of fire or explosion

Technical and electrical safety

The electrical safety of this appliance

can only be guaranteed when continuity is complete between the appliance and an effective earthing system which complies with local and national regulations. It is most important that this basic safety requirement is regularly tested by a qualified electrician. The manufacturer cannot be held responsi ble for the consequences of an inadequate earthing system.

Do not damage, remove or bypass the

safety features and controls on the ma chine.

Where there is any damage to the ma

chine or to the cable insulation the ma chine must not be used until it has been re paired.

Any removable outer panels must be in

place, and all moving or electrical parts shielded before the machine is operated.

The machine is only completely isolated

from the electricity supply either when switched off at the wall isolator, or the mains fuse is withdrawn from the socket

Repairs to machines operating with elec-

tricity, gas or steam should only be undertaken by a suitably qualified service engineer to ensure safety. Unauthorised repairs could be dangerous.

Faulty components should only be ex

changed for Miele original spare parts. Only when these parts are fitted can the safety standards of the machine be guaran teed.

The very best materials are used in the

manufacture of this machine, and every care is taken in its manufacture. However, with time, deterioration of parts can occur, especially with rubber components such as hoses. This should be borne in mind if oper ating the machine without supervision. Check the inlet hoses regularly for signs of deterioration and replace in good time, to avoid leaks and subsequent damage.

4 M.-Nr. 05 150 392

Warning and Safety instructions

Use of the machine

This washer extractor is not intended for

use by persons (including children) with reduced physical, sensory or mental capa bilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning its use by a person responsible for their safety.

Never allow children to play in, on or

near the washer extractor, or to operate it themselves. Please supervise its use by the elderly or infirm.

Remember that the door porthole glass

can become hot during the operation of the machine. Do not let children touch it.

When washing with high temperatures

steam can be emitted from the venting slot behind the machine.

Do not grip between the suspended

drum unit and the seal of the front panel cut-out during spin.

Always make sure the drum is stationary

before reaching in to remove washing. Reaching into a moving drum is extremely dangerous.

Water used for washing and rinsing must

not be used as drinking water. It must be discharged into a proper sewerage system.

The machine should only be operated

unsupervised when there is a floor drain (gully) in the direct vicinity of the machine.

Disinfecting and cleaning agents often

have compounds containing chlorides in them. If these agents dry on to stainless steel surfaces, the residual chlorides will at tack the steel and can cause rusting. To protect your machine from rust damage, we recommend only using chloride free dis infecting and cleaning agents for washing and disinfecting programmes and for clean ing stainless steel surfaces of the machine itself. If you are not sure about a particular agent, contact the manufacturer of that agent for advice. If you accidentally spill an agent containing chlorides on the machine it should be rinsed off with water and dried using a soft cloth.

Proprietary dyes, dye removers and

descaling agents may only be used in this machine if the manufacturer expressly states that they are suitable for use in a washing machine. Follow manufacturer’s in structions on how to use them.

Laundry that was soiled with biological

oils or fat should be washed using a suit able detergent and/or wash programme. It must also be inspected after washing. If oils or fat are not sufficiently removed they could cause the laundry to self ignite during the drying process.

Always follow the instructions of the

chemical manufacturer when using cleaning agents and special application chemicals. Only use such chemicals for the purpose and in the situation specified by the manufacturer in order to avoid the danger of adverse chemical reactions and material damage. If in doubt check the suitability of the product for use in this machine with the manufacturer before using it.

Where a chemical cleaning agent is rec-

ommended on technical application grounds, this does not imply that the manufacturer of the machine takes responsibility for the effect of the chemical on the material of the items being cleaned or on the machine. Please be aware that changes in for mulation, storage conditions etc., which may not be publicised by the chemical producer, can have a negative effect on the cleaning result.

On no account use high pressure

cleaners or hose down the machine.

Use of accessories

Accessory parts may only be fitted when

expressly approved by Miele. If other parts are used, guarantee, performance and product liability claims may be invalidated.

M.-Nr. 05 150 392 5

Warning and Safety instructions

Chlorine and component damage

Notes on using chlorine bleach and per chlorethylene

Frequent use of chlorine increases the risk of component damage.

The use of agents containing chlorine, such as sodium hypochlorite and chlorine bleach in powder form, can damage the protective surface of stainless steel and cause corro sion. Factors affecting this are chlorine con centration levels, contact time and tempera ture. It is therefore advisable to avoid the use of such agents. Oxygen based bleaching agents should be used instead.

If, however, chlorine based bleaching agents have to be used for particular types of soiling, then anti-chlorine measures must also be carried out. If this is not done irrepa rable damage can occur to components in the machine and to laundry.

Disposal of old machines or appliances

When disposing of an old washer extrac

tor first make it unusable. Disconnect from all services, cut off the cable and the plug from the cable. Make the door lock inoperative, so that chil dren cannot accidentally shut themselves in. Make appropriate arrangements for the safe disposal of the appliance.

All personnel working with this machine must be fully trained in all aspects of its use and safety.

Keep these instructions in a safe place.

Anti-chlorine treatment

Anti-chlorine treatment has to be carried out immediately after chlorine bleach has been used. Hydrogen peroxide and oxygen based cleaning and bleaching agents must only be used in programmes specified for their use. Any wash performance problems should be discussed with the manufacturer of the cleaning / bleaching product in the first in stance.

With thiosulfate, especially when used with hard water, gypsum can form, which can lead to incrustations on laundry or deposits in the machine.

The exact quantity of additives and the treat ment temperatures required must be set and tested on site in accordance with the dos age recommendations of the detergent and additive manufacturers. The laundry must also be tested to make sure it contains no active chlorine residues after processing.

6 M.-Nr. 05 150 392

Disposal of the packing material

The transport and protective packing has been selected from materials which are envi ronmentally friendly for disposal and can normally be recycled. Packaging e.g. cling film, polystyrene and plastic wrappings must be kept out of the reach of babies and young children. Danger of suffocation.

Rather than just throwing these materials away, please ensure that they are recycled.

Disposal of your old machine

Electrical and electronic machines often contain materials which, if handled or dis posed of incorrectly, could be potentially hazardous to human health and to the envi ronment. They are, however, essential for the correct functioning of your machine. Please do not therefore dispose of it with your household waste.

Caring for the environment

Please dispose of it at your local community waste collection/recycling centre, and en sure that it presents no danger to children while being stored for disposal.

It should be unplugged or disconnected from the mains electricity supply by a com petent person.

M.-Nr. 05 150 392 7

Guide to the machine

WS 5073 washer extractor

1 -Detergent dispenser box 7 -Cable entry for extra equipment 2 -Control panel 8 -Cable entry for dispenser pumps 3 -Drum door 9 -Cable entry for power supply 4 -Front wall panel 10 -Venting socket 5 -Flap for suds filter/drainage system 11 -Cold water connection

and emergency door release 12 -Hot water connection

6 -Four adjustable screw feet 13 -Vent screw

14 -Opening for dispenser hoses 15 -Back wall 16 -Drainage

This machine is constructed in accordance with IEC 60204-1:2005

Control panel

12 3 4

1 -Temperature and time left display 2 -Push button switches 3 -Programme sequence indicator lights 4 -Programme selector

8 M.-Nr. 05 150 392

Guide to the machine

Push button switches

a Door

Opens the drum door; releases the "With additional pre-wash" but ton, if it had been pushed in.

+n with additional Pre-wash

Can be selected with programmes A, B, D

Programme selector

Programmes

h Start

Starts the programme

Display

h min / °C

Time display h(rs)/min(s)

This display shows how long the wash programme still has to run. The m min indicator light lights up. or

Temperature °C

From 20°C the temperature is shown rising in 5°C-steps. The %°C indicator light lights up.

A Thermal Desinfection 90°C with fixed

cold pre-wash

B Chemo thermal Desinfection 60°C with

fixed cold pre-wash

C Short programme 60°C without

pre-wash (for conditioning new mops)

D Pads 40°C with fixed cold pre-wash E Separate rinse F Separate spin G Separate drain

Maximum spin speed per programme

A Thermal Desinfection B Chemo thermal

Desinfection

C Short programme D Pads F Separate spin

E Separate rinse 900 rpm.

1200 rpm.

m min Time left

%°C Temperature

M.-Nr. 05 150 392 9

Guide to the machine

Programme sequence indicator lights Detergent dispenser compartments

On / Start

Pre-wash

Main wash

Rinses Rinses

Rinses / Starch

Drain

Final spin

End

Water inlet / outlet

Compartment j - Main wash

After use, clean the detergent box thor oughly with hot water to remove detergent residues and deposits. Otherwise the items being washed may become recontaminated after the disinfection process.

10 M.-Nr. 05 150 392

Washing

Before using for the first time

The first commissioning of the machine should be carried out only by a Miele ser vice technician or an authorised Miele Service Dealer.

It is essential that the machine is installed and connected to power, water and drain age correctly.

Washing out the machine

Any residual lubricants and water from test ing still in the machine should be flushed out as follows:

Do not load any laundry in the machine.

Add a little detergent to compartment j.

^ ^ Turn the programme selector switch to the

"C Short programme 60°C".

^ Press the "h Start" button.

Preparing the wash load

Shake mops thoroughly to remove any

course soiling before placing them in the machine.

Foreign objects, (eg nails, coins, paper clips etc) can cause damage to textiles and components in the machine.

Sort the items for washing

For washing mops and floor cloths select ei ther: A Thermal Desinfection or B Chemo thermal Desinfection

For washing new mops or floor cloths for the first time select: C Short programme

For washing pads or polishing discs select: D Pads

Only wash items in this machine which are stated by the manufacturer to be machine washable on the textile care label.

^ Load laundry into the drum.

Do not exceed the following maximum weight of dry laundry:

, , , max. 7.5 kg

Size and weight of pads/cloths

40 cm / 190 g 38 50 cm / 220 g 33 60 cm / 280 g 26

80 cm / 360 g 20 110 cm / 510 g 14 130 cm / 610 g 12 160 cm / 720 g 10

maximum load capacity

M.-Nr. 05 150 392 11

Washing

Shut the drum door

Grasp the door in the open position and slam it shut, (mind your fingers). At first the door may shut with difficulty. This eases in due course.

Programme selection

Select a programme (e.g. Programme

"A Thermal Desinfection at 90°C").

Make sure no items of washing are caught when the door is closed, or they could be damaged.

^ Open the on-site stopcock. ^

Switch on the on-site main switch.

^ An additional pre-wash can be selected if

required for heavily soiled and stained laundry, but only with programmes A, B and D. Press the additional pre-wash button +n.

Add detergent for the main wash to com partment j.

Press the "h Start" button. The "m min" indicator light goes out and the "%°C" indicator light comes on. The programme starts.

12 M.-Nr. 05 150 392

Washing

Temperature display

After the programme start the current suds temperature for the main wash is shown in 5°C-steps until the set temperature has been reached. The "%°C temperature" indicator light lights up.

Time display (Time left)

Once the temperature set for the main wash has been reached the time left for the programme to run shows in the display in hours and minutes.

The "m min time" left indicator light lights up.

The time left counts down in 1 minute inter vals.

If no more washing is to be done:

leave the drum door open.

switch the machine off.

turn off the stopcock(s).

Opening the drum door at the end of the programme

After the "r End" indicator lights up: ^

Press the "a Open door" button

- the drum door opens.

Take out the washing.

Only remove laundry from the ma chine once the drum has stopped turning, otherwise you may seriously injure your self.

M.-Nr. 05 150 392 13

Dispensing detergent

Water hardness levels

Hardness

range

I soft 0 – 1.3 0 - 7

II medium 1.3 – 2.5 7 - 14 III hard 2.5 – 3.8 14 - 21 IV very hard over 3.8 over 21

If you do not know the hardness level of the water in your area you should contact your local water authority for information.

Water

quality

Hardness

level in

mmol/l

German

hardness

level °d

Dispensing detergent

Add the right amount of detergent as recom mended on the packaging. It is important to avoid overdosing as it can lead to excessive foam. Use a low foaming detergent.

Temperature holding times in programmes: A Thermal Desinfection

B Chemo thermal Desinfection must be programmed in accordance with

the disinfecting agent manufacturer’s recom mendations. See programme chart, change Nos. 8 and 12.

The amount dispensed will depend on the following:

– the quantity of laundry – the water hardness level – the level of soiling.

too little detergent results in the following:

–

The laundry will not be properly clean and will in time become grey and hard to touch.

–

Greasy particles cling to the laundry.

–

Lime deposits on the heater elements.

too much detergent results in the follow ing:

–

Excessive foam.

–

Low level of agitation.

–

Poor washing, rinsing and spin results

14 M.-Nr. 05 150 392

Additional functions

Changing programme sequence

The programme can be changed at any time where it makes sense.

Turn the programme selector to the re

quired programme. The new programme

will carry on at the relevant stage. Exceptions: If the programme selector has been turned

through the "End" position r. Opting into or out of the following

programmes:

E Separate rinse

–

F Separate spin

–

G Separate drain

– breaks off the programme. The "h Start" but

ton must be pressed in again to start the re quired programme.

To repeat a programme stage

A programme stage must have been fin ished before it can be repeated:

Turn the programme selector switch to the

End position r.

When "r End" illuminates in the sequence display:

Select the new programme required.

Press the "h Start" button.

After approx. 5 seconds, turn the

programme selector switch to "r End" again.

As soon as the programme sequence indi cator light of the programme stage to be re

peated starts flashing:

Turn the selector switch to the appropriate

programme within 3 seconds.

When working through a coin unit or coin counter the programme is locked after 3 minutes and no changes are possible.

Cancelling a programme

^ Turn the programme selector to the End

position r. The indicator lights flash through the other

programme stages until the "r End" light is reached.

To omit a programme stage

Turn the programme selector to the End

position r. As soon as the programme sequence indi

cator light for the stage at which the programme should continue starts flashing:

Programmable functions

It is possible to programme additional functions or change programme sequences. See Programme changes.

Any changes to the standard machine version must be noted in the machine’s log book and also on the chart in this booklet, see "Programme changes" as a record for any subsequent servicing work . This is of particular importance for the service techni cian, when electronic units may need to be exchanged.

Turn the selector switch to the appropriate

programme within 3 seconds.

M.-Nr. 05 150 392 15

Programme changes

To change individual programmes by re programming

Programmes can be changed individually to accommodate different wash processes and methods. 20 Programmable functions can be changed with up to 4 Options.

Before starting:

The on-site mains switch must be

–

switched on. A previous programme must be com

–

pleted. The drum door must be open.

–

To access programming mode

After the drum door is shut the "+n with

pre-wash" button must be pressed in and released twice within 4 seconds.

– All the other buttons must be inoperative,

i.e. not pushed in.

-4 seconds later a " pears in the display.-

- The programme sequence indicators "Pre-wash" and "Main wash" flash.-

- Re-programming can now be carried out (see example).-

" (for Programming) ap-

–

The programme selector must be at the "r End" position.

16 M.-Nr. 05 150 392

Programme changes

Example:

The temperature holding time in the main wash in programmes A and D can be changed from 10 minutes to 5, 15 or 20 min utes.

See Programme selector setting No.8 / A on the Programme Change chart. Option 3 cor responds to 15 mins.

To change the temperature holding time to 15 minutes.

Programme selector switch settings

The following appear one after another in the display

P 1

(10 minutes),

P 3

(15 minutes).

P 2

(5 minutes),

^ Turn the programme selector to position 8.

" flashes in the display.

Press the "h Start" button 3 times.

^ Press the "a open door" button.

- Pressing the "a open door" button saves the change in memory and completes the programming process.-

Please enter this programming change in the chart on the following page.

Turn the programme selector to the End position r.

See the next page for further programme changes.

M.-Nr. 05 150 392 17

Programme changes

Programme selector setting Options Enter

No. Programme function 1 2 3 4

Additional pre-wash

prog.

change

here

1 A Wash time ABD: (mins.) no

pre-wash.

2 A Water level ABD low* high

Pre-wash

3 A Select pre-wash ABD: via

button*

4 A 90 Pre-wash wash times ABD:

(mins.)

5 A Pre-wash temperature ABD:

(°C)

6 A Pre-wash water level ABD low high*

Main wash

7 A Thermostop & heating active yes* no 8 A Temperature holding time

AD:(mins.)

9 A Water level ABCD low* high 10 B Temperature A: (°C) 90* 85 80 11 B Temperature BC: (°C) 75 70 65 60*

5* 0 13 3

cold* 40 60 35

10* 5 15 20

5* 9

yes

12 B 60 Temperature holding time

BC: (mins.)

Rinses

13 B Increase water level ABCD no slightly average* high 14 C Rinse hold no* yes

Final spin

15 C 60 Pre-spin no* yes

Special functions May only be carried out by a service technician. 16 C Prog. modification 17 C Water inlet in sep. rinse

ABCD in main wash 18 D Temperature D: (°C) 60 50 40* 30 19 D 40 Separate spin free yes* no 20 D 3 external disp. pumps comb. 1* comb. 2 comb. 3

*) Standard setting KW = cold water WW = hot water - up to 55 °C HW = hot water - over 55 °C

15 10 20*

KW*

KW+WW*

KW KW

KW-hard

KW-soft

KW+HW

18 M.-Nr. 05 150 392

Cleaning and Care

Cleaning the washing machine

Clean the casing with a mild non-abrasive detergent or soap and water. Wipe dry with a soft cloth. Clean the facia panel with a damp cloth and dry with a soft cloth. The drum and any other stainless steel parts can be cleaned using a proprietary stainless steel cleaner according to the manufac turer’s instructions.

Do not use any scouring agent or solvent cleaner.

After use, clean the detergent box thor oughly with hot water to remove detergent residues and deposits. Otherwise the items being washed may become recontaminated after the disinfection process.

Remove any deposits from the door seal with a damp cloth.

Build-up of rust

The drum and suds container are manufactured from rust-free stainless steel. It is, however, possible that water with a high iron content or foreign bodies in the wash, (e.g. paper clips or metal buttons), may lead to the formation of superficial rust spots in the drum and/or suds container, especially if the machine is not used for a long time. Stainless steel components should be cleaned regularly with a proprietary cleaning agent for stainless steel. This must be done if rust appears!

Door seals should also be regularly checked to make sure that nothing has got trapped in them. Clean them regularly.

Cleaning the filters in the water inlet

To clean the filter in the inlet hose:

Close the stopcock.

^ Carefully unscrew the knurled coupling

connecting the inlet hose to the stopcock.

^ Remove the rubber seal from the recess. ^ Using pointed pliers, take hold of the plas-

tic filter bar, remove the filter and clean.

^ Put the filter and seal back in the reverse

order.

The filters in the inlet hose should be checked and cleaned approx. every 6 months.

Inspect the inlet hose which is subjected to high pressure while the machine is in opera tion. The hose should be replaced if there are small cracks in the surface, or if it has been otherwise damaged.

If replacing the inlet hose only use a hose able to withstand a minimum pressure of 70 bar. Miele’s own hoses meet this require ment.

The washing machine has the following fil ters to protect the inlet valves:

–

in the free end of any water inlet hose,

–

in the water inlet valve(s) for connection hose to machine.

M.-Nr. 05 150 392 19

Cleaning and Care

To clean the filter in the water inlet valve:

Using pliers, carefully loosen the ribbed

plastic nut on the inlet valve, and unscrew.

If the machine is not going to be used for a longer period of time (4 weeks or more) the drum should be rotated several times after the last use. The drum should be ro tated every 4 weeks to prevent damage to the bearings.

^ Use water pump pliers to withdraw the

plastic filter by the bar (see illustration).

^ Clean and put back in the reverse order.

The machine must not be used without the two dirt filters being put back in place.

20 M.-Nr. 05 150 392

Any work on the electrical components of this machine should only be carried out by a suitably qualified and competent person. Unauthorized repairs could be dangerous.

There are, however, minor faults which can be corrected without contacting the Service Department.

Opening the drum door in the event of a power failure

Turn the programme selector to "r End"

Close the on-site stopcocks

To remove laundry the drain valve needs to be manually opened and then the drum door manually unlocked.

Problem solving guide

Open the flap for the suds filter/drainage

system.

^ To open the drain valve loosen the vent

screw using a number 17 spanner. The vent screw is located at the rear of the ma chine. It must not be taken right out. The water will then drain out of the machine.

Warning. Some water will seep out of the screw vent (approx.100 cc), use a suitable container to catch it.

After draining the machine tighten the vent screw back up and make sure that it is se curely in position.

Press against the drum door and pull on the emergency door opening mechanism (see illustration).

Always make sure the drum is stationary before reaching in to remove washing. Reaching into a moving drum is extremely dangerous.

Close the flap for the suds filter/drainage system.

M.-Nr. 05 150 392 21

Problem solving guide

A selected programme does not begin. The "I On/ Start" indicator light does not light up.

Check that the door is properly closed, the mains plug is plugged in and that the fuse or circuit breaker has not tripped.

The check light "p" flashes, although the programme has finished as usual.

The water inlet system is partially blocked:

Stopcocks not fully opened.

Inlet hose kinked or trapped.

The water pressure is too low.

The filters in the inlet hoses are clogged

(see "Cleaning and Care").

The indicator light goes out when the programme selector switch is turned to the End position r.

The Pre-wash "i" indicator light is flash ing.

Start the programme again.

If the indicator still flashes call the Service

Department.

The Main wash indicator light "j" flashes during, or after the end of a programme.

If it also flashes on the next programme there is a technical fault.

Call the Miele Service Department.

Despite adequate water supply pressure, the machine takes a long time to fill.

The filters in the water inlet might be blocked.

^ Clean as described under the section

"Cleaning and Care".

The check light "p" is flashing, the "r End" indicator light is on, but the laundry in the machine has not been washed.

The water inlet system is turned off. ^ Turn the programme selector switch to

"r End".

Turn on the water supply at the stopcocks.

Select a programme.

Press the "h Start" button.

If little or no water is taken in during the next programme, the water pressure may be too low.

If it is adequate there may be a technical fault. In this case, call your local Miele ser vice dealer or the Miele Service Department.

Large amounts of unused detergent remain in the dispenser.

Water supply pressure is too low. ^ Clean filters (as described in the section

"Cleaning and Care").

^ Check if the water flow through the stop-

cock is 5 litres in 15 seconds.

Washing powder becomes viscous when used together with a water softener.

In future pour washing powder into the de tergent dispenser before adding water softener.

The "q" indicator light is flashing. ^

Check whether the drainage system is clogged.

22 M.-Nr. 05 150 392

Problem solving guide

Possible reasons for increased levels of foaming

detergent type

–

Only use detergent formulated for use in

commercial washer extractors. Domestic laundry detergent is not suitable.

overdosing of detergent

–

Dispense detergent following the deter

gent manufacturer’s instructions on the packaging and in accordance with local water hardness levels.

detergent creates too much foam

–

Use a lower foaming detergent or contact

your detergent application specialist.

very soft water

–

In areas with hardness level 1 dispense

less detergent in accordance with the de tergent manufacturer’s instructions.

– soiling level of the laundry

^ For lightly soiled laundry dispense less de-

tergent in accordance with the detergent manufacturer’s instructions.

Laundry is either not spun at all or not spun satisfactorily.

The machine was not able to distribute the

laundry load evenly. To protect the ma chine, laundry was either only spun at a re duced speed or not at all.

The drain system may be clogged.

The "n" indicator light flashes.

The machine has switched off because of serious imbalance.

Switch the on-site mains switch off and

then on again or open the drum door with the emergency release as described in "Opening the door in a power cut".

The machine shakes during the spin cy cle.

The most likely cause is that the four machine feet are not resting securely on the floor.

^ Level the machine as described in "Notes

for the installer".

– residues, e.g. detergent are left on laun-

dry

^ Run an additional pre-wash without deter-

gent and without selecting a temperature. Laundry which has been soaked before washing must be thoroughly rinsed before running a wash programme.

–

small loads

Reduce the amount of detergent dis pensed according to the size of the load.

M.-Nr. 05 150 392 23

After sales service

Should a fault occur please contact your nearest authorized Service Dept.

When contacting the Service Department, please quote the model type, (Typ), the ma chine number, (Fabr.-Nr.) und Part-no. (M.-Nr.). These can be found on the data plate:

With the door open at the top of the door ring, or:

at the rear of the machine towards the top. Only use genuine spare parts. When order-

ing spare parts the Spare Parts Dept will also need to know the model type (Typ), machine number (Fabr.-Nr.) und Part-no. (M.-Nr.).

Please note that telephone calls may be monitored and recorded to improve our service.

24 M.-Nr. 05 150 392

Explanation of symbols on the data plate

1 Machine type 2 Machine number/year of manufacture* 3 Voltage/Frequency 4 Control fusing 5 Drive motor 6 Plate diameter*/Plate quantity* 7 Drum data 8 Drum diameter/drum depth

9 Spin speed 10 Drum volume/Laundry dry weight 11 Kinetic energy 12 Ex. time to top speed 13 Braking time 14 Heating 15 Electric heating 16 Fusing (on site) 17 Steam heating indirect* 18 Steam heating direct* 19 Gas heating* 20 Commissioning date 21 Water registration DVGW-test cert

(Water)*

22 Field for CE test symbol....

(Product-ID-No./Gas)*

*) not applicable to WS 5073

Noise emission

During wash During spin

58.5 dB 74.3 dB (measured in Germany in accordance with

DIN (IEC) 45 635, machine noise regulations

3. GSGV p1. 1.a)

M.-Nr. 05 150 392 25

Notes for the installer

The washer-extractor must be installed by an approved service technician or an au thorized Service Dealer.

Installation

Front transit fitting

A concrete floor is the most suitable installa tion surface. Please note:

The machine must be level and securely

positioned. Do not install the machine on a ‘soft’ base

such as floorboards as this could result in more vibration during the spin cycles.

If the machine is installed on a raised

plinth it should be secured using the butt straps supplied with the machine.

If there is not already a concrete plinth on-site, the Miele Spare Parts department offer a steel plinth. It must be ensured that the steel plinth is secured to the floor, (see enclosed installation plan).

To avoid the possibility of frost damage on no account install the machine in a room which is exposed to frost.

"A" (1 piece)

The front panel must be taken off, (2 internal torx T20 screws at the bottom) in order to re move the front transit fitting (3 SW-13 screws).

Rear transit fitting

Do not install the machine on carpeted flooring if the carpet pile blocks the ventilation gap at the base of the machine.

Transit fittings

Do not remove the red transit fittings marked "A", "B". and "C" until the machine has been installed in its final position.

The machine must not be moved without the transit fittings in place.

The transit fittings should be stored in a safe place for future use. They must be re-fitted if the machine is moved again.

"B" (1 piece) "C" (1 piece)

The rear panel must be taken off, (just loosen 15 internal torx T20 screws at the bot tom) in order to remove the rear transit fit tings (3 SW13 screws each).

The machine must not be moved without all the outer panels in place.

26 M.-Nr. 05 150 392

Notes for the installer

Levelling

The machine must stand level to ensure smooth operation.

The adjustable feet can compensate for an uneven base.

^ Screw the foot or feet out until the machine

stands level.

^ Hold the foot tight using a pipe wrench. ^ Tighten the counternut using a screwdriver

as indicated.

Connection to water supply

Connection must be made to the water sup ply via a stopcock which conforms with local and national regulations. This work must be carried out by a suitably qualified and com petent person.

To ensure the machine is correctly con nected please observe the installation plan and the installation instructions supplied with the machine.

See the installation diagram supplied for in structions on connection to the water supply and for drainage.

The inlet pressure hoses supplied with the machine must be used for connection to the water supply. To ensure that the hose marked 90°C lasts a long time it should not be connected to a hot water supply hotter than 70°C. If replacing an inlet hose only use a hose able to withstand a burst pressure of at least 70 bar and a water temperature of at least 90°C. This also applies to all connection parts. Miele "Original" spare parts meet this requirement. A water pressure flow rate of at least 1 bar, maximum 10 bar is essential to ensure the smooth operation of this machine. The inlet hot water temperature must not exceed 70°C.

Cold water connection

–

See Programme change No.17 on the chart.

–

See enclosed installation diagram.

Drainage

A DN 70 angle connector can be used to make connection to an on-site drainage sys tem, (sink box with odour trap).

M.-Nr. 05 150 392 27

Notes for the installer

Coin mechanism unit

The washer-extractor can be fitted with a coin unit.

It can also be connected to an existing coin unit. The correct connection cable is re quired for this. For the C 4030 / 4031, C 4050 / 4051 and C 4065 / 4070 using timed operation an AD 3 adapter is required.

The machine has to be reprogrammed for this connection. This must only be done by a Miele authorized service engineer.

The coin unit and connection cable are available at extra cost from the Miele Spare Parts Department, or from Miele specialist dealers.

Electrical connection

All electrical work must be carried out by a suitably qualified and competent person in compliance with national and local regula tions.

Connection should be made via a suitable isolator with an on-off switch located near the machine which can be used as an emer gency off switch. It should be coloured red and yellow for easy identification.

Please take note of the Installation diagram and the Wiring diagram. They are important for electrical connection.

The electrical safety of this machine is in ac cordance with IEC 335.

The minimum suds level required for activat ing the heating is given in mm column of water: WS 5073 45 mm column of water

The voltage and frequency are given on the data plate. The machine must only be connected if these match the mains supply.

3N AC 380-415 V 50 Hz The motor is fitted with an overload protec-

tion switch. For extra safety it is advisable to install a re-

sidual current device with a trip current of 30 mA.

The nominal rated load and fuse rating are given on the data plate. Ensure that these are compatible with the electricity supply.

WARNING! THIS APPLIANCE MUST BE EARTHED.

When installation and connection have been completed all removable outer pan els must be re-fitted before the machine is operated.

28 M.-Nr. 05 150 392

EU Declaration of Conformity

Document No.: 07138710 Month, year: 07.2007 Manufacturer: Miele Company Ltd., KG Address: Industriestrasse 3

D - 31275 Lehrte

Product designation: Washer-extractor Model no.: WS 5073 Brand: Miele

The product listed above complies with the conditions of the following European Directives:

EU Directive 2006/42/EG: Machinery directive

89/336/EC: EMC directive

European Standard: EN ISO 10472-1 :1997

EN ISO 10472-2 :1997 EN 60204-1 :2006 EN 61770 :1999 + Corrigendum December 2005 + A1 :2004 + A2 :2006 EN 55014–1 :2006 EN 55014–2 :1997 + A1:2001 EN 61000–3–2 :2006 EN 61000–3–3 :2006

Introduction of the CE mark: 2007

Place, date: Lehrte, 10.07.2007

Signed:

Construction & Development Management Appliance Production Management

Hr. Dr. Köckerling Hr. Krimpmann

M.-Nr. 05 150 392 29
