User’s guide
Logitech
®
Wireless Desktop
MK300
620-001674 EMEA Med Rook.indd 1 18.2.2009 13:00:22
620-001674 EMEA Med Rook.indd 2 18.2.2009 13:00:22
Contents
WWW
www.logitech.com/support
, 70
English
Setup, 6 Features and troubleshooting, 10
Svenska
Installation, 6 Funktioner och felsökning, 22
Dansk
Installation, 6 Funktioner og problemløsning, 34
Norsk
Konfigurering, 6 Funksjoner og feilsøking, 46
Suomi
Käyttöönotto, 6 Toiminnot ja vianmääritys, 60
620-001674 EMEA Med Rook.indd 3 18.2.2009 13:00:23
Thank you!
Takk!
Kiitos!
Tack!
Tak!
620-001674 EMEA Med Rook.indd 4 18.2.2009 13:00:23
5
Logitech
®
Wireless Desktop MK300
www.logitech.com
U s e r ’ s g u i d e
Log i t ec h
®
W i r e l e s s D e s k t o p
M K 3 0 0
620-001674 EMEA Med Rook.indd 5 18.2.2009 13:00:25
Logitech® Wireless Desktop MK300
6
1
ON
ON
620-001674 EMEA Med Rook.indd 6 18.2.2009 13:00:25
7
Logitech
®
Wireless Desktop MK300
2
USB
8 in.
20 cm
3
USB
620-001674 EMEA Med Rook.indd 7 18.2.2009 13:00:28
Logitech® Wireless Desktop MK300
8
Pull
4
Svenska DRA
Dansk TRÆK
Norsk TREKK
Suomi VEDÄ
620-001674 EMEA Med Rook.indd 8 18.2.2009 13:00:29
9
Logitech
®
Wireless Desktop MK300
Svenska DRA
Dansk TRÆK
Norsk TREKK
Suomi VEDÄ
Pull
5
620-001674 EMEA Med Rook.indd 9 18.2.2009 13:00:30
10 English
Logitech
®
Wireless Desktop MK300
Keyboard features: hot keys
To enjoy all the features of your keyboard or to customize it to suit
your needs, please install the Logitech
®
SetPoint™ Software that comes
with your product.
Logitech application 1.
switcher
Internet zone2.
a. Email application
b. Internet browser
c. Internet search engine
d. Messenger
Multimedia navigation3.
a. Previous track
b. Play/pause track
c. Next track
Volume zone4.
a. Mute volume
b. Volume down
c. Volume up
Convenience zone5.
a. Windows
®
calculator
b. Battery status check (See Battery
management for more information.)
620-001674 EMEA Med Rook.indd 10 18.2.2009 13:00:31
English 11
User’s Guide
Keyboard features: hot keys
2
a
b
c
d
1
3
a
b
c
4
a
b
c
a
b
5
620-001674 EMEA Med Rook.indd 11 18.2.2009 13:00:31
12 English
Logitech
®
Wireless Desktop MK300
Keyboard features: F-keys
To enjoy all the features of your keyboard or to customize it to suit
your needs, please install the Logitech
®
SetPoint™ Software that comes
with your product.
User-friendly enhanced F-keys let you easily launch applications or control
your music. To use the enhanced functions (gray icons), press the key and the
F-Key Fn you want to use simultaneously.
1st - Press and
hold the Fn key
2nd - Press an F-key
620-001674 EMEA Med Rook.indd 12 18.2.2009 13:00:33
English 13
User’s Guide
Fn
1. key (for use with F-keys)
Productivity zone2.
Fn
+F1 Launches document application
Fn
+F2 Launches spreadsheet application
Fn
+F3 Launches presentation application
Fn
+F4 Launches calendar
Favorites zone3.
Fn
+F5 to F8 program your favorite
application, folder, or web site with
a long, simultaneous press of Fn
and the corresponding F5, F6, F7,
or F8 key (just like the presets of a car
radio).
2
1
3
Keyboard features: F-keys
620-001674 EMEA Med Rook.indd 13 18.2.2009 13:00:34
14 English
Logitech
®
Wireless Desktop MK300
Internet zone4.
Fn
+F9 Save file
Fn
+F10 Undo last operation
Fn
+F11 Redo last operation
Fn
+F12 Opens/closes CD-DVD tray
Miscellaneous5.
Fn
+ Print Screen: Contextual menu
Fn
+Pause/Break: Scroll lock
Fn
+Battery status check:
PC sleep mode
4
5
Keyboard features: F-keys
620-001674 EMEA Med Rook.indd 14 18.2.2009 13:00:34
English 15
User’s Guide
Left click1.
Right click2.
Scroll wheel – Use SetPoint software to set your preferred speed and acceleration. 3.
(See Customizing the keyboard and mouse.)
Battery-indicator light – The LED glows green for 10 seconds when the mouse is powered on. 4.
The LED blinks red when battery level drops below 10%.
Power switch – Turn off the mouse if you intend to take it with you while traveling or if you will 5.
not be using the mouse for an extended period of time.
Connect button – See 6. Troubleshooting for information about usage.
Mouse features: buttons and scrolling
2
1
3
4
5
6
620-001674 EMEA Med Rook.indd 15 18.2.2009 13:00:35
16 English
Logitech
®
Wireless Desktop MK300
Customizing the keyboard and mouse
Double-click the 1. Mouse and Keyboard Settings icon on the Windows® desktop
to make changes.
To customize the keyboard, click the My Keyboard tab. For the mouse, click the My Mouse tab.2.
Click to customize
the keyboard
Click to customize the mouse
620-001674 EMEA Med Rook.indd 16 18.2.2009 13:00:35
English 17
User’s Guide
For either the keyboard or mouse, a series of tabs is shown 3.
on the left.
Choose a tab, such as the keyboard 4. F-key Settings.
A picture of the keyboard is displayed showing F-keys (list 2)
to which tasks can be assigned (list 3).
In the 5. 2. Select F-key list, highlight the F-key to be
reassigned a task.
In the 6. 3. Select Task list, highlight the new task.
When you are done, click 7. OK to save the new F-key
assignments.
Select an F-key
Choose a task for
the F-key
Choose a tab
Keyboard F-key Settings tab
620-001674 EMEA Med Rook.indd 17 18.2.2009 13:00:35
18 English
Logitech
®
Wireless Desktop MK300
My Mouse tab
Customize the mouse using
this tab
For more information about customizing your keyboard and mouse, please refer to the help system.
620-001674 EMEA Med Rook.indd 18 18.2.2009 13:00:35
English 19
User’s Guide
Battery management
Your keyboard has up to 15 months of battery life, and your mouse has up
to 8 months. (Note that the mouse can work with only one battery, but with
significantly reduced battery life.)*
Battery sleep mode
Did you know that both your keyboard and mouse go into sleep mode after you stop
using them for a few minutes? This feature helps limit battery usage. Both devices are up
and running immediately once you begin using them again.
How to check the battery level for the keyboard (software required)
Press the Battery Status Check hotkey.
The SetPoint Software Keyboard Battery tab pops up. It shows the current battery level of the
keyboard.
How to check the battery level for the mouse
Option 1: • Turn the mouse off, and then on using the On/Off
slider switch on the bottom of the mouse. Look at the battery
LED on the top case. If the LED glows green for 10 seconds,
the batteries are good. If the LED blinks red, the battery level
has dropped to 10%. (You still have a few days of battery
usage left.)
Option 2: • Launch the SetPoint Software, and click the Mouse
Battery tab to see the current battery level of the mouse.
Switch
LED
Mouse bottom
* Battery life varies with usage and computing conditions. Heavy usage usually results in shorter battery life.
620-001674 EMEA Med Rook.indd 19 18.2.2009 13:00:36
20 English
Logitech
®
Wireless Desktop MK300
Troubleshooting
Keyboard and mouse are not working
Check the cable connection.
Also, try changing USB ports.
Move closer? Try moving the keyboard or mouse closer to the receiver.
Relocate the receiver. Place the receiver away from electrical devices and avoid metallic
surfaces.
Check battery installation. Also check the battery
power of each device. (See Battery management
for more information.)
Keyboard
Mouse
To open the mouse battery compartment,
press down on the compartment cover, and slide
cover toward rear of mouse.
USB
620-001674 EMEA Med Rook.indd 20 18.2.2009 13:00:37
English 21
User’s Guide
Troubleshooting
Are you experiencing slow or jerky cursor movement?
Try the mouse on a different surface (e.g., deep, dark surfaces may
affect how the cursor moves on the computer screen).
Is the mouse turned on? On the mouse bottom, move the
power slider switch right to turn on the mouse. The Battery
LED on the mouse top case should light green for 10 seconds.
(See Battery management for more information.)
Mouse bottom
Establish a connection:
Press the 1. Connect button
on the receiver.
QUICKLY 2. press the Connect
button (half second) under each
device. The mouse LED (top case)
should blink.
1
2
1
2
Connect mouse
Connect keyboard
For additional help, refer to the Customer Support telephone numbers on page 70.
Also visit www.logitech.com/comfort for
more information about using your product,
and for ergonomics.
620-001674 EMEA Med Rook.indd 21 18.2.2009 13:00:39
22 Svenska
Logitech
®
Wireless Desktop MK300
Tangentbordsfunktioner: snabbknappar
Om du vill dra nytta av tangentbordets samtliga funktioner eller anpassa
dem efter dina behov installerar du Logitech
®
-programvaran SetPoint™
(som följer med produkten).
Logitechs 1.
programväxlare
Internetzon2.
a. E-postprogram
b. Webbläsare
c. Sökmotor på internet
d. Snabbmeddelanden
Multimedienavigering3.
a. Föregående spår
b. Spela/Pausa spår
c. Nästa spår
Volymzon4.
a. Ljud av
b. Volym –
c. Volume +
Bekvämlighetszon5.
a. Windows
®
Kalkylatorn
b. Kontroll av batteristatus
(Se Batterihantering
för mer information.)
620-001674 EMEA Med Rook.indd 22 18.2.2009 13:00:40
