SERVICE MANUAL
COLOUR TELEVISION
AV-2104QE/SK,
AV-2104QE/VSK
BASIC CHASSIS
CW
Supplementary
The following items for the AV-2104QE/SK and AV-2104QE/VSK were changed partly from AV-2104QE. Therefore, this service manual describes only the items which differ from those of the AV-2104QE service manual.
For details other than those described in this manual, please refer to the AV-2104QE service manual (No.YA130, 2004/9).
OUTLINE
Since the production place was changed, we have issued the SERVICE MANUAL for AV-2104QE/SK and AV2104QE/VSK.
HOW TO IDENTIFY MODELS
"2104QEA-SK" and "2104QEVA-SK" are added at the bottom of the Rating label.
AV-2104QE
2104QEA-SK
Indicated 2104QEVA-SK
COPYRIGHT © 2004 Victor Company of Japan, Limited
No.YA130B
2004/11
DIFFERENCE LIST
USING P.W. BOARD (Page 3-3)
P.W.B ASS'Y Name |
AV-2104QE |
AV-2104QE/SK |
DESCRIPTION |
|
|
|
|
MAIN P.W.B |
SCW-1342A-H2 |
SCW-1371A-H2 |
Non compatible |
|
|
|
|
|
|
|
|
P.W.B ASS'Y Name |
AV-2104QE |
AV-2104QE/VSK |
DESCRIPTION |
|
|
|
|
MAIN P.W.B |
SCW-1342A-H2 |
SCW-1372A-H2 |
Non compatible |
|
|
|
|
EXPLODED VIEW PARTS LIST -1 (Page 3-4)
|
|
|
Part No. |
|
|
|
|
Ref. No. |
AV-2104QE |
|
AV-2104QE/SK |
PART NAME |
DESCRIPTION |
|
|
|
AV-2104QE/VSK |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
GG10196-004A-H |
GG10196-004A-HK |
FRONT CABINET |
|
|
|
|
|
|
|
|
|
EXPLODED VIEW PARTS LIST -2 (Page 3-5)
|
|
|
Part No. |
|
|
|
|
Ref. No. |
AV-2104QE |
|
AV-2104QE/SK |
PART NAME |
DESCRIPTION |
|
|
|
AV-2104QE/VSK |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
V01 |
A51KQK99X |
|
A51KQK99X01 |
ITC |
|
|
|
|
|
|
|
|
|
DY01 |
QQD0061-001 |
|
--- |
DEF YOKE |
Delete |
|
|
|
|
|
|
|
|
14 |
GG10049-003A-H |
GG10049-003A-HK |
REAR COVER |
|
|
|
|
|
|
|
|
|
|
17 |
QAL0608-001 |
|
--- |
PC MAGNET |
Delete |
|
|
|
|
|
|
|
|
18 |
CE42728-00A |
|
--- |
WEDGE ASSY |
Delete |
|
|
|
|
|
|
|
PRINTED WIRING BOARD PARTS LIST
MAIN P.W. BOARD ASS'Y (Page 3-11)
|
|
Part No. |
|
|
|
|
|
Ref. No. |
|
|
PART NAME |
|
DESCRIPTION |
|
AV-2104QE |
AV-2104QE/SK |
|
|||
|
|
|
|
|
|
|
|
|
SCW-1342A-H2 |
SCW-1371A-H2 |
|
|
|
|
|
|
|
|
|
|
|
D420 |
1SR124-400A-T2 |
--- |
SI DIODE |
Delete |
|
|
|
|
|
|
|
|
|
D423 |
1N4003-T2 |
GP110DE-5009-T2 |
SI DIODE |
|
|
|
|
|
|
|
|
|
|
D601 |
MA111-X |
NRSA63J-0R0X |
MG RESISTOR |
1kΩ |
1/16W J |
|
|
|
|
|
|
|
|
D816 |
MA8091/H/-X |
MTZJ9.1C-T2 |
Z DIODE |
|
|
|
|
|
|
|
|
|
|
C351 |
NDC21HJ-102X |
NDC31HJ-102X |
SI DIODE |
1000pF 50V J |
|
|
|
|
|
|
|
|
|
C727 |
NCB31HK-332X |
QCB31HK-332Z |
C CAPACITOR |
3300pF 50V K |
|
|
|
|
|
|
|
|
|
R603 |
NRSA63J-0R0X |
MA111-X |
SI DIODE |
|
|
|
|
|
|
|
|
|
|
R675 |
NRSA63J-103X |
QRE141J-103Y |
C RESISTOR |
10kΩ |
1/4W J |
|
|
|
|
|
|
|
|
R797 |
NRSA63J-102X |
NRSA02J-102X |
MG RESISTOR |
1kΩ |
1/10W J |
|
|
|
|
|
|
|
|
R798 |
NRSA63J-103X |
QRE141J-103Y |
C RESISTOR |
10kΩ |
1/4W J |
|
|
|
|
|
|
|
1-2 (No.YA130B)
