Invacare®Pronto®M41™Power Wheelchair
The Invacare®Pronto®M41™is the latest offering in the sleek and versatile Pronto®series of power wheel-
chairs. The M41™features the latest technology in electronics and in-line motors. This combination provides
increased efficiency and battery range, as well as an increased top speed. The M41 also features a center-
wheel drive platform, simpified SureStep®, and six wheels on the ground providing stability and maneuverability
similar to other Pronto®models. All of these features are packed into a simple, clean-looking, and easy-to-
service compact frame that provides mobility with style for people on the go!
Features
Compact size for a tight turning radius
High efficiency in-line motors for greater speed and longer battery range
SureStep®suspension with six wheels on the ground for smooth driving and
optimum stability
Charger connection conveniently located on joystick
Stylish design
3-amp off-board charger
Three seat options
Medium-back fold-down seat
High-back semi-recline van seat
High-back semi-recline van seat with solid seat pan
Auto style positioning strap
U1 batteries
300 lb. weight capacity
Colors Available
Candy Red Deep Blue
Pronto®M41™with Semi-Recline Van Seat
Pronto
®
M41™with Fold-Down Seat
Pronto®M41™Specifications
Invacare Corporation
www.invacare.com
USA
One Invacare Way Elyria, Ohio 44035-4190 (800) 333-6900
Canada
570 Matheson Blvd. E., Unit 8 Mississauga, Ontario L4Z 4G4 Canada (800) 668-5324
©2008 Invacare Corporation. All rights reserved. Trademarks are identified by the symbols ™ and ®. All trademarks are owned by or licensed to Invacare Corporation unless otherwise noted. Specifications are subject to change without notification.
Form No. 06-033 Rev. 04/08
Invacare®Pronto®M41™Power Wheelchair
Invacare
®
Pronto
®
M41
Power Wheelchair
Overall dimensions (measured with fold-down seat)
Length 34" Width (including joystick) 24" Height 33" Seat-to-floor 19"
Seat dimensions (fold-down seat) (semi-recline seat) (semi-recline seat
w/solid seat pan) Width 18" 16" - 20" 16" - 20" Depth 17" 16" - 18" 16" - 20" Seat angle 92˚ 80˚ - 115˚ 90˚ - 115˚
Weight capacity 300 lb. Wheel sizes
Front/rear casters 6" x 2" Drive wheels (Flat-free) 10.5" x 3.5"
Maximum speed 5 mph Motor 250 watts Incline capability 7˚ grade Turning radius
Front 17.75" Rear 19.5"
Weight (fold-down seat) (semi-recline seat) (semi-recline seat
w/solid seat pan) with UI batteries 161 lb. 175 lb. 180 lb. w/out batteries and foot plate 110 lb. 124 lb. 129 lb.
Ground clearance 2" Battery U1 Battery charger 3 amp off-board Per-charge battery range Up to 17 miles* Limited warranties
Base frame 60 months Seat frame 36 months Electronics 12 months Motor/gearbox 12 months
* Travel range will vary depending on user weight, speed, battery charge and terrain.
