Parts Catalog
Pronto® M50™/ M51™
Issued: May 29, 2008
with SureStep®
After 1/19/05
Pronto® M61™
with SureStep®
MWD
Powered Wheelchair
Yes, you can. ™
Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the
bottom of the page or below specified charts.
Parts Catalog Usage Guide
To order call toll free 1-800-333-6900, or www.invacare.com
The information contained in this document is subject to change without notice. This catalog contains
service parts for Form No. 04-050. If you have any questions regarding this catalog, please contact one
of our Customer Service Representatives.
For Customer Service Support Call:
1-800-333-6900
For Faxed In Orders Call:
1-800-678-4682 or
1-440-366-0709
For Technical Service Call:
1-800-832-4707
Literature Can Be Found at:
www.invacare.com or
1-800-828-6272
SYMBOL DEFINITION
Examples:
A,B,C etc.
NOTE:
NLA
= Special Comments
= General information pertaining to that specific page
= No Longer Available
HARDWARE MEASUREMENTS
The measurements for the hardware will be listed as follows:
Screws, Bolts
Washers
Spacers
For your convenience, we have supplied an area for you to list your Invacare Representatives.
©2008 Invacare Corporation. Elyria, Ohio. Invacare, Yes, you can., the Medallion Design, Pronto, and SureStep are registered trademarks and Formula,
Diameter X Thread Count/Pitch X Length
Inside Diameter X Outside Diameter X Thickness
Inside Diameter X Outside Diameter X Length
Name Phone Numbers
MKIV, MK5, NX, SPJ, M50, M51, and M61 are trademarks of Invacare Corporation.
Form No.
04-050
1
Arms, Mtg. Front/Rear Arm Socket Asbly. & Hdwr. For M51 ADJASBA Seats with TRRO After
4/29/08
TABLE of CONTENTS
Page
Number
To order call toll free 1-800-333-6900, or www.invacare.com
Form No.
04-050
Description
A: READ THIS FIRST (THIS CATALOG IS DIFFERENT!) ...................................................... 5
Accessories - Miscellaneous .................................................................................................... 120
Accessories - Power Wheelchair Tool Kit ................................................................................ 122
Accessories - Walker Holder .................................................................................................... 121
Adapter, Seat ADJASBA and Mounting Hardware (After 4/29/08) ........................................... 33
Adapter, Seat ADJASBA and Mounting Hardware with TRRO/TRBKTS ................................. 35
Arms - ASBA & AdjASBA Seat (Adjustable Height) ................................................................. 60
Arms - ASBA & AdjASBA Seat (Fixed Height) ......................................................................... 57
Arms - Van Seat ....................................................................................................................... 54
Arms, Front/Rear Arm Socket Asbly. & Hdwr. - ADJASBA M51 After 04/29/08 ..................... 62
63
Back Cane Attaching Hardware - M51 ADJASBA (After 04/29/08) .......................................... 39
Back Canes and Spreader Bar - M51 ADJASBA (After 4/29/08) ............................................. 41
Back Canes, Spreader Bars and Attaching Hardware ............................................................. 37
Battery Harnesses .................................................................................................................... 74
Casters and Forks .................................................................................................................... 69
Electronics - MK5 NX Controllers and Battery Chargers .......................................................... 106
Electronics - MK5 SPJ/SPJ+ and MK6i SPJ+ ACC Joysticks and Mounting Hardware .......... 103
Electronics - Quad Link Assembly (Before 4/07/06) ................................................................. 108
Electronics - Quad Link Assembly (QL) (After 4/06/06) ........................................................... 111
Elevating Seat Actuator, Proximity Sensor, and Hardware ...................................................... 52
2
TABLE of CONTENTS
Page
Number
To order call toll free 1-800-333-6900, or www.invacare.com
Form No.
04-050
Description
Frame Finish, Touch Up Paint and Shroud Colors ................................................................... 6
Frame, ASBA Seat and Mounting Hardware - M50/M51 ......................................................... 27
Frame, ASBA Seat and Mounting Hardware - M50/M51 Center Post Attachment .................. 18
Frame, ASBA Seat and Mounting Hardware - M61 ................................................................. 29
Frame, Base and Van Seat Post Assembly ............................................................................. 14
Frame, Base, Bearings, & Hdwr. - M51 w/ Formula CG Tilt (CGT) & M51PR After 4/29/08 .... 10
Frame, Seat ADJASBA, Seat Pan & Hdwr. (16"-20" W x 16"-22" D) (After 4/29/08) ............... 47
Frame, Van Seat and Mounting Hardware - Center Post Attachment ..................................... 16
Frame, Van Seat and Mounting Hardware - M50/M51 ............................................................. 22
Frame, Van Seat, Mounting Hardware, and Seat Spacer Retro-fit Kit - M61 ........................... 24
Front Rigging - Adjustable Angle Footplates, AT5543 - PHW93 .............................................. 97
Front Rigging - Footboard Assembly - 90FB ............................................................................ 76
Front Rigging - Footrest and Legrest Accessories ................................................................... 100
Front Rigging - Footrest Supports, (Hemi) - PHW93 ................................................................ 85
Front Rigging - Front Rigging Hangers (Hemi) ......................................................................... 78
Front Rigging - Hanger Assembly - ADJASBA After 4/29/08 ................................................... 80
Front Rigging - Legrest Supports, (Hemi) - PH904A ................................................................ 87
Front Rigging - Legrest Supports, Articulating (Hemi) - PHAL4A ............................................. 90
Front Rigging - Pivot/Slide Tube and Composite Footplate - PHW93 ...................................... 99
Front Rigging - Pivot/Slide Tube and Footplates - PH904A and PHAL4A ............................... 95
Front Rigging - Pivot/Slide Tube and Footplates - PHW93 ...................................................... 93
3
TABLE of CONTENTS
Page
Number
To order call toll free 1-800-333-6900, or www.invacare.com
Form No.
04-050
Description
Front Rigging - Reference Chart .............................................................................................. 82
Motor, Gearbox, and Drive Wheel ............................................................................................ 72
Oxygen Holder Assembly - ADJASBA Seats After 4/29/08 ..................................................... 115
Oxygen Holder Assembly - ASBA Seat Before 4/28/08 ........................................................... 113
Oxygen Holder Assembly - Fold Down Medium Back Van Seat .............................................. 117
Oxygen Holder Assembly - Semi-Recline Van Seat & Office Style Van Seat .......................... 118
Packaging, Literature and Decals ............................................................................................ 7
Seat Height Adjustment Slide Tubes - M51 PR After 4/29/08 .................................................. 12
Seat Pan and Hardware - ASBA Center Post Mounted ........................................................... 45
Seat Release Hardware ........................................................................................................... 34
Shrouds, and Attaching Hardware ........................................................................................... 65
Shrouds, Top Assembly - M51 with Formula CG Tilt (CGT) & M51 Rehab After 4/29/08 ........ 67
TRRO and TRBKTS Option Clarification Reference ................................................................ 9
Upholstery, Back - ASBA and ADJASBA ................................................................................. 43
Van Seat Assembly .................................................................................................................. 49
Van Seat Frame and Actuator Hardware - 4 Post attachment ................................................. 31
Walking Beams and Hardware - SureStep ............................................................................... 20
4
A: READ THIS FIRST (THIS CATALOG IS DIFFERENT!)
Form No.
04-050
5
To order call toll free 1-800-333-6900, or www.invacare.com
Frame Finish
Color Number Part Number Bottle Size Color
Flat Black.6 oz104632734P
Shroud Colors
Color Number Color
Deep BlueBL (DBLM)
Candy RedRD (CRDM)
Frame Finish, Touch Up Paint and Shroud Colors
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
6
Packaging, Literature and Decals
Form No.
04-050
7
To order call toll free 1-800-333-6900, or www.invacare.com
Packaging, Literature and Decals
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127752 Carton, Tray Top 1 11
1115174 Carton, Corner Reinforcement 1 42
1127753 Carton, Cover 1 13
1015592 Bag, Poly (72" L x 35" W x 19" D) 1 14
40131X161 Insert, Plain Pad 1 15
1127755 Carton, Pad 1 16
1127756 Carton, Tray 1 17
1127754 Carton, Insert 1 28
1127296 Carton, Cover Base 1 19
1043198-NLA Tube, Paper 1 110
1127294 Insert, Carton 1 111
1127295 Tray, Carton 1 112
1125085 Manual, Owner's Manual Pronto M50/M51/M61 1 1A
1110532 Manual, Instruction, MK5 NX/NX-LP 1 1A
1125093 Instruction Sheet, Battery Installation 1 1A
1110604 Decal, Shroud M50 1 2A
1110605 Decal, Shroud M51 1 2A
1127292 Decal, Shroud M61 1 2A
1104797 Decal, Shroud Drive/Push 1 2A
1035900 Decal, Transportation 1 1A
1119281 Name Plate, Patent Numbers 1 1A
1107651 Decal, Front Battery Cover 1 1A
1107652 Decal, Rear Battery Cover 1 1A
1148076 Manual, Owner's Pronto M51 Formula CG Tilt
(CGT) Base
1 1A
A - Not Shown
NOT
E: When adjusting or replacing parts, please refer to your owner's manual for assistance.
NOTE:
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
8
TRRO and TRBKTS Option Clarification Reference
Form No.
04-050
9
To order call toll free 1-800-333-6900, or www.invacare.com
Base Frame, Bearings, & Hardware
M51 w/ Formula CG Tilt (CGT) & M51PR After 4/29/08
Form No.
04-050
10
To order call toll free 1-800-333-6900, or www.invacare.com
Base Frame, Bearings, & Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1062095 Fastener, Loop with Adhesive Back (1" Wide x 4"
Long)
1 21
40117X006 Bearing (5/8") 1 42
1110717 Ring, Tolerance 1 43
1142189 Fastener, Hook with Adhesive Back (1" x 2") 1 34
NOTE: Base Frame is a non-serviceable part.
M51 w/ Formula CG Tilt (CGT) & M51PR After 4/29/08
Form No.
04-050
11
To order call toll free 1-800-333-6900, or www.invacare.com
Seat Height Adjustment Slide Tubes
M51 PR After 4/29/08
Form No.
04-050
12
To order call toll free 1-800-333-6900, or www.invacare.com
Seat Height Adjustment Slide Tubes
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1110707 Kit, Seat Height Adjustment Slide Tubes and
Hardware
1 11 A,B
Slide Tube, Seat Height Adjustment - Rear 1 22
Screw, Socket Head Cap (5/16-18 x 1-1/2") 1 43
Locknut (5/16-18) 1 44
Slide Tube, Seat Height Adjustment - Front 1 25
1152529 Slide Tube, Seat Height Adjustment - Rear 1 22
1021344 Screw, Socket Head Cap (5/16-18 x 1-1/2") 1 43
1026158 Locknut (5/16-18) 1 44
1109215 Slide Tube, Seat Height Adjustment - Front 1 25 B
A - Includes Items 2-5
B - 300 Lb. capacity
NOTE:
M51 PR After 4/29/08
Form No.
04-050
13
To order call toll free 1-800-333-6900, or www.invacare.com
Base Frame and Van Seat Post Assembly
Form No.
04-050
14
To order call toll free 1-800-333-6900, or www.invacare.com
Base Frame and Van Seat Post Assembly
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127300 Kit, Frame Hardware 1 11 A
Bearing (5/8") 1 42
Ring, Tolerance 1 43
Hook (1" Wide) 1 24
Fastener, Loop w/ Adhesive (1") 1 25
Screw, Socket Head Cap w/ Patch (3/8-16 x 2") 1 16
1127404 Frame Assembly, Non Elevating Seat 1 17 B
1127403 Frame 1 18
1143697 Post, Seat Pivot 1 19 D
1127268 Frame Assembly, Elevating Seat 1 110 C
1127267 Frame, Elevating Seat 1 111
A - Includes items 2-6. Although included in frame hardware kit, item 6 (Screw) is not required for chairs with elevating seat.
B - Includes items 1 and 8
C - Includes items 1 and 11
D - Effective 10/05/06, the Seat Pivot Post has been updated to give the seat the capability to lock in a 90 degree position
from straight either right or left.
NOTE:
Form No.
04-050
15
To order call toll free 1-800-333-6900, or www.invacare.com
Van Seat Models M50/M5/M61 & Solid Base Van Seats
Before 4/28/08 with Center Post attachment
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat items 1, 13, and 15 must be
ordered in addition to the seat.
Form No.
04-050
16
To order call toll free 1-800-333-6900, or www.invacare.com
Van Seat Models M50/M5/M61 & Solid Base Van Seats
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1119577 Kit, Van Seat Mounting Hardware 1 11 A,B
Screw, Hex Head Cap with Patch (1/4-20 x 1") 1 42
Washer (1/4 x 23/32 x 1/16") 1 63
Screw, Hex Head (1/4-20 x 1-1/4") 1 24
Spacer (1/4 x 5/8 x 1/4") 1 25
Spacer, Coved (1/4 x 11/16 x 1/2") 1 46
Screw, Hex Head w/Patch (1/4-20 x 2-1/2") 1 27
Plug Button, Black (1") 1 28
Locknut (5/16-18) 1 49
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410
Screw, Hex Head Cap w/ Patch (5/16-18 x 1") 1 411
Knob, Adjustment (5/16-18 x 1-1/2") 1 112
1092409 Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410
1104258 Screw, Hex Head Cap w/ Patch (5/16-18 x 1") 1 411
1116919 Bracket, Seat Mounting 1 113 C
1129722 Bracket, Seat Mounting 1 113 D
1116413 Pivot, Seat 1 114
1123391 Frame, Van Seat - 16" Wide 1 115
1116392 Frame, Van Seat - 18" Wide 1 115
1116393 Frame, Van Seat - 20" Wide 1 115
1136494 Kit, Van Seat Mounting Hardware - Office Style 1 116 E
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 417
Screw, Hex Head Cap with Patch (1/4-20 x 1-1/2") 1 418
A - Item 8, Plug Buttons, are only used in the absence of front riggings.
B - Includes items 2-12
C - Van Seats without Solid Seat Base
D - Van Seats with Solid Seat Base
E - Includes items 17-18
NOTE:
Before 4/28/08 with Center Post attachment
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat items 1, 13, and 15 must be
ordered in addition to the seat.
Form No.
04-050
17
To order call toll free 1-800-333-6900, or www.invacare.com
ASBA Seat Frame and Mounting Hardware
M50/M51 Center Post Attachment before 4/29/08
Form No.
04-050
18
To order call toll free 1-800-333-6900, or www.invacare.com
ASBA Seat Frame and Mounting Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1134543 Kit, Seat Frame Adapter Hardware 1 11 A
Screw, Hex Head Cap (5/16-18 x 1") 1 42
Screw, Hex Head (5/16-18 x 1-3/4") 1 43
Washer (5/16 x 3/4 x 1/16") 1 44
Locknut (5/16-18) 1 85
Knob, Adjustment (5/16-18 x 1-1/2") 1 16
See Chart #7 Seat Frame, ASBA 1 17
1134542 Plate, Seat Frame 1 18
1116413 Pivot, Seat 1 19
A - Includes items 2-6
NOTE:
#7 Seat Frame, ASBA
Chair Depth 16" Wide 17" Wide 18" Wide 19" Wide 20" Wide
1132437113243611324351132434113243316-17" Deep
1132446113244511324441132443113244218-19" Deep
1132455113245411324531132452113245120" Deep
M50/M51 Center Post Attachment before 4/29/08
Form No.
04-050
19
To order call toll free 1-800-333-6900, or www.invacare.com
Walking Beams and Hardware - SureStep
Form No.
04-050
20
To order call toll free 1-800-333-6900, or www.invacare.com
Walking Beams and Hardware - SureStep
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127398 Kit, SureStep Walking Beam Hardware 1 11 A
Locknut, High Profile (3/8-16) 1 12
Spring, Extension (1" I.D. x 4-1/2" Long) 1 13
Nut, Keps (5/16-18) 1 14
Locknut (1/2-20) 1 15
Washer (1/2 x 29/32 x 1/32") 1 26
Washer (9/16 x 1 x 5/8") 1 17
Bumper, Rubber 1 18
Screw, Socket Head Shoulder (1/2 x 2-1/2") 1 19
1127368 Walking Beam, SureStep - Right 1 110 B
1127369 Walking Beam, SureStep - Left 1 110 B
1127344 Bearing, Flange (1/2 x 7/8") 1 411
1109018 Tube, Pivot 1 112 C
1106485 Bushing (1/2 x 5/8") 1 413
A - Includes items 2-9
B - Includes item 11
C - Includes item 13
NOTE:
Form No.
04-050
21
To order call toll free 1-800-333-6900, or www.invacare.com
Van Seat Frame and Mounting Hardware
M50/M51
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat items 1, 13, and 15 must be
ordered in addition to the seat.
Form No.
04-050
22
To order call toll free 1-800-333-6900, or www.invacare.com
Van Seat Frame and Mounting Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1119577 Kit, Van Seat Mounting Hardware 1 11 A,B
Screw, Hex Head Cap with Patch (1/4-20 x 1") 1 42
Washer (1/4 x 23/32 x 1/16") 1 63
Screw, Hex Head (1/4-20 x 1-1/4") 1 24
Spacer (1/4 x 5/8 x 1/4") 1 25
Spacer, Coved (1/4 x 11/16 x 1/2") 1 46
Screw, Hex Head w/Patch (1/4-20 x 2-1/2") 1 27
Plug Button, Black (1") 1 28
Locknut (5/16-18) 1 49
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410
Screw, Hex Head Cap w/ Patch (5/16-18 x 1") 1 411
Knob, Adjustment (5/16-18 x 1-1/2") 1 112
1092409 Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410
1104258 Screw, Hex Head Cap w/ Patch (5/16-18 x 1") 1 411
1116919 Bracket, Seat Mounting 1 113 C
1129722 Bracket, Seat Mounting 1 113 D
1116413 Pivot, Seat 1 114
1123391 Frame, Van Seat - 16" Wide 1 115
1116392 Frame, Van Seat - 18" Wide 1 115
1116393 Frame, Van Seat - 20" Wide 1 115
1136494 Kit, Van Seat Mounting Hardware - Office Style 1 116 E
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 417
Screw, Hex Head Cap with Patch (1/4-20 x 1-1/2") 1 418
A - Item 8, Plug Buttons, are only used in the absence of front riggings.
B - Includes items 2-12
C - Van Seats without Solid Seat Base
D - Van Seats with Solid Seat Base
E - Includes items 17-18
NOTE:
M50/M51
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat items 1, 13, and 15 must be
ordered in addition to the seat.
Form No.
04-050
23
To order call toll free 1-800-333-6900, or www.invacare.com
Van Seat Frame, Mounting Hardware, and Seat Spacer
Retro-fit Kit
M61
As of 7/29/05 Seat Spacers are included on all M61 model chairs.
Form No.
04-050
24
To order call toll free 1-800-333-6900, or www.invacare.com
Van Seat Frame, Mounting Hardware, and Seat Spacer
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1136487 Kit, Van Seat Mounting Hardware 1 11 B,H,A
Screw, Hex Head Cap with Patch (1/4-20 x 1") 1 42
Washer (1/4 x 23/32 x 1/16") 1 63
Screw, Hex Head (1/4-20 x 1-1/4") 1 24
Spacer (1/4 x 5/8 x 1/4") 1 25
Spacer, Coved (1/4 x 11/16 x 1/2") 1 46
Screw, Hex Head w/Patch (1/4-20 x 2-1/2") 1 27
Plug Button, Black (1") 1 28
Locknut (5/16-18) 1 49
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410
Screw, Hex Head (5/16-18 x 3") 1 411
Knob, Adjustment (5/16-18 x 1-1/2") 1 112
1137262 Kit, Van Seat Mounting Hardware 1 11 B,I,A
Screw, Hex Head Cap with Patch (1/4-20 x 1") 1 42
Washer (1/4 x 23/32 x 1/16") 1 63
Screw, Hex Head (1/4-20 x 1-1/4") 1 24
Spacer (1/4 x 5/8 x 1/4") 1 25
Spacer, Coved (1/4 x 11/16 x 1/2") 1 46
Screw, Hex Head w/Patch (1/4-20 x 2-1/2") 1 27
Plug Button, Black (1") 1 28
Locknut (5/16-18) 1 49
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410
Screw, Hex Head (5/16-18 x 2") 1 411
Knob, Adjustment (5/16-18 x 1-1/2") 1 112
1119577 Kit, Van Seat Mounting Hardware 1 11 B,J,A
Screw, Hex Head Cap with Patch (1/4-20 x 1") 1 42
Washer (1/4 x 23/32 x 1/16") 1 63
Screw, Hex Head (1/4-20 x 1-1/4") 1 24
Spacer (1/4 x 5/8 x 1/4") 1 25
Spacer, Coved (1/4 x 11/16 x 1/2") 1 46
Screw, Hex Head w/Patch (1/4-20 x 2-1/2") 1 27
Plug Button, Black (1") 1 28
Locknut (5/16-18) 1 49
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410
Screw, Hex Head Cap w/ Patch (5/16-18 x 1") 1 411
Knob, Adjustment (5/16-18 x 1-1/2") 1 112
1116919 Bracket, Seat Mounting 1 113 C
1129722 Bracket, Seat Mounting 1 113 D
1116413 Pivot, Seat 1 114
1123391 Frame, Van Seat - 16" Wide 1 115
1116392 Frame, Van Seat - 18" Wide 1 115
Retro-fit Kit
M61
As of 7/29/05 Seat Spacers are included on all M61 model chairs.
Form No.
04-050
25
To order call toll free 1-800-333-6900, or www.invacare.com
Van Seat Frame, Mounting Hardware, and Seat Spacer
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1116393 Frame, Van Seat - 20" Wide 1 115
1134660 Spacer, Seat 1 416
1136486 Kit, Van Seat Mounting Hardware - Office Style 1 117 E,H
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 418
Screw, Hex Head (1/4-20 x 3-1/2") 1 419
1136493 Kit, Van Seat Mounting Hardware - Office Style 1 117 E,I
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 418
Screw, Hex Head w/Patch (1/4-20 x 2-1/2") 1 419
1136494 Kit, Van Seat Mounting Hardware - Office Style 1 117 E,J
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 418
Screw, Hex Head Cap with Patch (1/4-20 x 1-1/2") 1 419
1116413 Pivot, Seat 1 120
1136490 Kit, Seat Spacer Retro-fit Kit 1 121
Spacer, Seat 1 421
Screw, Hex Head (1/4-20 x 3-1/2") 1 421
Screw, Hex Head w/Patch (1/4-20 x 2-1/2") 1 421
Washer, Steel (5/16 x 1-1/4 x 1/16") 1 821
Screw, Hex Head (5/16-18 x 3") 1 421
Screw, Hex Head (5/16-18 x 2") 1 421
Locknut (5/16-18) 1 421
Instruction Sheet, Seat Spacer Retro-fit Kit 1 121
1134801 Instruction Sheet, Seat Spacer Retro-fit Kit 1 1K
A - Item 8, Plug Buttons, are only used in the absence of front riggings.
B - Includes items 2-12
C - Van Seats without Solid Seat Base
D - Van Seats with Solid Seat Base
E - Includes items 18 and 19
H - This kit is used on chairs that have 2 sets of seat spacers (item 16).
I - This kit is used on chairs that have 1 set of seat spacers (item 16).
J - This kit is used on chairs that do not have any seat spacers.
K - Not Shown
NOTE:
Retro-fit Kit
M61
As of 7/29/05 Seat Spacers are included on all M61 model chairs.
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
26
ASBA Seat Frame and Mounting Hardware
M50/M51
Form No.
04-050
27
To order call toll free 1-800-333-6900, or www.invacare.com
ASBA Seat Frame and Mounting Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1134543 Kit, Seat Frame Adapter Hardware 1 11 A
Screw, Hex Head Cap (5/16-18 x 1") 1 42
Screw, Hex Head (5/16-18 x 1-3/4") 1 43
Washer (5/16 x 3/4 x 1/16") 1 44
Locknut (5/16-18) 1 85
Knob, Adjustment (5/16-18 x 1-1/2") 1 16
See Chart #7 Seat Frame, ASBA 1 17
1134542 Plate, Seat Frame 1 18
1116413 Pivot, Seat 1 19
A - Includes items 2-6
NOTE:
#7 Seat Frame, ASBA
Chair Depth 16" Wide 17" Wide 18" Wide 19" Wide 20" Wide
1132437113243611324351132434113243316-17" Deep
1132446113244511324441132443113244218-19" Deep
1132455113245411324531132452113245120" Deep
M50/M51
Form No.
04-050
28
To order call toll free 1-800-333-6900, or www.invacare.com
ASBA Seat Frame and Mounting Hardware
M61
As of 7/29/05 Seat Spacers are included on all M61 model chairs.
Note: When ordering a complete ASBA seat for the M61, the M50SEAT can be used from the configurator.
However, seat hardware (item 1) must still be ordered separately depending upon the quantity of seat
spacers being used.
Form No.
04-050
29
To order call toll free 1-800-333-6900, or www.invacare.com
ASBA Seat Frame and Mounting Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1136485 Kit, Seat Frame Hardware 1 11 A,B
Screw, Hex Head (5/16-18 x 3") 1 42
Screw, Hex Head (5/16-18 x 1-3/4") 1 43
Locknut (5/16-18) 1 84
Washer (5/16 x 3/4 x 1/16") 1 45
Knob, Adjustment (5/16-18 x 1-1/2") 1 16
1136492 Kit, Seat Frame Hardware 1 11 A,C
Screw, Hex Head (5/16-18 x 2") 1 42
Screw, Hex Head (5/16-18 x 1-3/4") 1 43
Locknut (5/16-18) 1 84
Washer (5/16 x 3/4 x 1/16") 1 45
Knob, Adjustment (5/16-18 x 1-1/2") 1 16
1134543 Kit, Seat Frame Adapter Hardware 1 11 A,D
Screw, Hex Head Cap (5/16-18 x 1") 1 42
Screw, Hex Head (5/16-18 x 1-3/4") 1 43
Washer (5/16 x 3/4 x 1/16") 1 44
Locknut (5/16-18) 1 85
Knob, Adjustment (5/16-18 x 1-1/2") 1 16
See Chart #7 Seat Frame, ASBA 1 17
1134542 Plate, Seat Frame 1 18
1134660 Spacer, Seat 1 49
1116413 Pivot, Seat 1 110
A - Includes items 2-6
B - This kit is used on chairs that have 2 sets of seat spacers.
C - This kit is used on chairs that have 1 set of seat spacers.
D - This kit is used on chairs that do not have any seat spacers.
NOTE:
#7 Seat Frame, ASBA
Chair Depth 16" Wide 17" Wide 18" Wide 19" Wide 20" Wide
1132437113243611324351132434113243316-17" Deep
1132446113244511324441132443113244218-19" Deep
1132455113245411324531132452113245120" Deep
M61
As of 7/29/05 Seat Spacers are included on all M61 model chairs.
Note: When ordering a complete ASBA seat for the M61, the M50SEAT can be used from the configurator.
However, seat hardware (item 1) must still be ordered separately depending upon the quantity of seat
spacers being used.
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
30
M51 Van Seat Frame and Actuator Hardware w/ Solid Base
after 4/29/08
Form No.
04-050
31
To order call toll free 1-800-333-6900, or www.invacare.com
M51 Van Seat Frame and Actuator Hardware w/ Solid Base
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1123423 Frame, Van Seat -16" Wide 1 11
1115343 Frame, Van Seat -18" Wide 1 11
1115344 Frame, Van Seat -20" Wide 1 11
1088897 Screw, Hex Head (1/4-20 x 1-1/4") 1 22
1026900 Washer (1/4 x 23/32 x 1/16") 1 23
1052957 Screw, Hex Head (1/4-20 x 2") 1 24
1029501 Plug Button, Black (1") 1 25
1108410 Spacer (1/4 x 5/8 x 1/4") 1 26
1116421 Hardware, Van Seat Mounting 1 17 A
A - Includes items 2-6
NOTE:
after 4/29/08
Form No.
04-050
32
To order call toll free 1-800-333-6900, or www.invacare.com
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1136009 Kit, Seat Adapter Mounting Hardware - ADJASBA 1 11 A
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 42
Locknut (5/16-18) 1 43
1106480 Adapter, Seat Frame 1 14
A - Includes items 2 and 3
NOTE:
Seat Adapter and Mounting Hardware
M51 ADJASBA Seats (After 4/29/08)
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
33
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1108068 Kit, Seat Release Hardware 1 11 A
1109219 Spring, Torsion, Right 1 12
1109220 Spring, Torsion, Left 1 13
1108239 Pin, Slotted (1/4 x 1-1/8") 1 24
1106476 Latch, Seat 1 15
A - Includes items 2-5
NOTE:
Seat Release Hardware
(For Van Seat and AdjASBA Seat After 4/29/08)
Form No.
04-050
34
To order call toll free 1-800-333-6900, or www.invacare.com
Seat Adapter and Mounting Hardware
M51 ADJASBA Seats with TRRO/TRBKTS after 4/29/08
Form No.
04-050
35
To order call toll free 1-800-333-6900, or www.invacare.com
Seat Adapter and Mounting Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1139892 Kit, Seat Adapter Mounting Hardware - ADJASBA
with TRRO/TRBKTS
1 11
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 62
Washer, Ground (11/32 x 13/16 x 1/8") 1 63
Nut, Strap 1 24
Locknut (5/16-18) 1 25
Cap, Tube (1" Square) 1 46
M51 ADJASBA Seats with TRRO/TRBKTS after 4/29/08
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
36
Back Canes, Spreader Bars and Attaching Hardware
M51 Center Post Attachment before 4/28/09 & all M61 models
Form No.
04-050
37
To order call toll free 1-800-333-6900, or www.invacare.com
Back Canes, Spreader Bars and Attaching Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
See Chart See Footnote 1 21
See Chart See Footnote 1 12
1135506 Package, Foam Hand Grips (9" Long) 10 13
1130582 Package, Plug Buttons, Black (7/8") 10 14
1070457 Kit, Back Cane Attaching Hardware 2 15 A
Screw w/ Lug (5/16-24 x 1-3/8") 1 26
Insert, Non-Threaded Back Cane
(For Back Heights 20" and Lower)
1 27
Screw, Hex Head (1/4-20 x 1-5/8") 1 48
Washer (1/4 x 23/32 x 1/16") 1 49
Locknut (1/4-20) 1 410
Spacer, Coved (1/4 x 11/16 x 1/2") 1 411
Locknut (5/16-24) 1 212
A - Includes Items 6-12
NOTE:
#1 10° Back Cane with Grip
16-20" Back Height
16" High 17" High 18" High 19" High 20" High
10455791045578104557710455761045575
#2 Spreader Bar
16-20" Wide
16" Wide 17" Wide 18" Wide 19" Wide 20" Wide
10438771043876104387510438741043873
M51 Center Post Attachment before 4/28/09 & all M61 models
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
38
Back Cane Attaching Hardware
For M51 ADJASBA Seat (After 04/29/08)
Form No.
04-050
39
To order call toll free 1-800-333-6900, or www.invacare.com
Back Cane Attaching Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1133755 Kit, Back Cane Mounting Hardware (Pair) 2 11 A
Screw, Hex Head Cap (5/16-18 x 1") 1 42
Washer, Flat (21/64 x 53/64 x 7/64") 1 43
Locknut (5/16-18) 1 44
Locknut (5/16-24) 1 25
Screw w/ Lug (5/16-24 x 1-3/8") 1 26
A - Includes items 2-6
NOTE:
For M51 ADJASBA Seat (After 04/29/08)
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
40
Back Canes and Spreader Bars
For M51 ADJASBA Seat after 4/29/08
Form No.
04-050
41
To order call toll free 1-800-333-6900, or www.invacare.com
Back Canes and Spreader Bars
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
See Chart #1 Back Cane Assemblies 1 11
1135506 Package, Foam Hand Grips (9" Long) 10 12
1134426 Package, Plug Buttons, Black (3/4") 10 13
1125709 Kit, Spreader Bar Assembly (16"-20" Wide) 1 14 A
Handle, Spreader Bar 1 25
Screw, Hex Head (1/4-20 x 1-1/2") 1 26
Spacer, Coved (1/4 x 11/16 x 1/2") 1 47
Anti-Rattle (1") 1 28
Tube, Spreader Bar Adjustable (16"-20" Wide) 1 19
Locknut (1/4-20) 1 210
1125710 Kit, Spreader Bar Assembly 20"-24" Wide 1 14 A
Handle, Spreader Bar 1 25
Screw, Hex Head (1/4-20 x 1-1/2") 1 26
Spacer, Coved (1/4 x 11/16 x 1/2") 1 47
Anti-Rattle (1") 1 28
Tube, Spreader Bar Adjustable (20"-24" Wide) 1 19
Locknut (1/4-20) 1 210
1025730 Locknut (5/16-24) 1 211
1031026 Screw w/ Lug (5/16-24 x 1-3/8") 1 212
A - Includes items 5-10
NOTE:
#1 Back Cane Assemblies
Back Cane Assemblies include Foam Grips and Plug Buttons where shown
Back
Height
Back Cane -
Push Handle
10 Deg. Bend
Right
Back Cane -
Push Handle
10 Deg. Bend
Left
Back Cane -
Push Handle
Straight for Contoura
Right
Back Cane -
Push Handle
Straight for Contoura
Left
N/AN/A1133823113382216"
N/AN/A1133825113382417"
1143335
1143334
1133827113382618"
See Note(s) A See Note(s) A
N/AN/A1133829113382819"
N/AN/A1133831113383020"
A - Chairs with Contoura Backs require 18" high back canes only. NOTE:
For M51 ADJASBA Seat after 4/29/08
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
42
Single Liners
Back Width 16"-17" High 18"-19" High 20" High
10689471045207888104517516" Wide
10689481045208104517617" Wide
10689491045209104517718" Wide
Dual Liners
Back Width 16"-17" High 18"-19" High 20" High
10689521045212104518016" Wide
10689531045213104518117" Wide
10689541045214104518218" Wide
10689551045215104518319" Wide
10689561045216104518420" Wide
10689571045217104518521" Wide
10689581045218104518622" Wide
10689591045219104518723" Wide
10689601045220104518824" Wide
Dual liner back upholstery is used with chairs that have a seat deeper than 17" or back wider than 18".
ASBA/ADJASBA Back Upholstery, Nylon
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
43
ASBA/ADJASBA Back Upholstery, Nylon
Back Upholstery Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1026298 Screws with Washers (#10 x 7/8") 2 1A
98007X005 Cable Tie (11-1/2" Long) 1 2A
See Chart Single Liners 1 1A
See Chart Dual Liners 1 1A
A - Not Shown
NOTE:
Form No.
04-050
44
To order call toll free 1-800-333-6900, or www.invacare.com
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1070459 Kit, Seat Pan Mounting Hardware 1 1A,B
Screw, Hex Head (1/4-20 x 1-5/8") 1 21
Screw, Hex Head (1/4-20 x 1-1/2") 1 42
Spacer (1/4 x 3/8 x 3/16") 1 43
Locknut (1/4-20) 1 64
1039949 Fastener, Hook Adhesive Back (2" x 16") 1 25
1044578 Fastener, Loop Adhesive Back (2" x 16") 1 25
See Chart See Footnote 1 16
A - Not Shown.
B - Includes items 1-4
NOTE:
#6 Seat Pans
Chair Depth 16" Wide 17" Wide 18" Wide 19" Wide 20" Wide
1066017106601610660151066014106601316" Deep
1066028106602710660261066025106602417" Deep
1066039106603810660371066036106603518" Deep
1066050106604910660481066047106604619" Deep
1066061106606010660591066058106605720" Deep
ASBA Seat Pan and Hardware
Center Post Mounted M51 Before 4/28/08 & M61
NOTE: Seat pan and front rigging hanger assembly share the same mounting hardware.
Form No.
04-050
45
To order call toll free 1-800-333-6900, or www.invacare.com
ASBA Seat Pan and Hardware
Center Post Mounted M51 Before 4/28/08 & M61
NOTE: Seat pan and front rigging hanger assembly share the same mounting hardware.
Form No.
04-050
46
To order call toll free 1-800-333-6900, or www.invacare.com
ADJASBA Seat Frame, Seat Pan and Hardware
(16"-20" Wide) x (16"-22" Deep) M51 After 04/29/08
Form No.
04-050
47
To order call toll free 1-800-333-6900, or www.invacare.com
ADJASBA Seat Frame, Seat Pan and Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1120288 Frame, Center Seat 1 11 D
1122475 Crossbar, Seat Frame (16"-20" Wide) 1 42
1122647 Rail, Seat Frame (16-20" Deep For Formula TRE &
16-19" Deep For ADJASBA)
1 23
1122677 Rail, Seat Frame (20-22" Deep For Formula TRE &
19-22" Deep For ADJASBA)
1 23
1124386 Seat Pan w/ Hook and Loop Fasteners
16-20" Wide x (16-20" Deep For Formula TRE &
16-19" Deep For ADJASBA)
1 14
1124666 Seat Pan w/ Hook and Loop Fasteners
16-20" Wide x (20-22" Deep For Formula TRE &
19-22" Deep For ADJASBA)
1 14
1043082 Hook Fastener, Adhesive (2" x 18") 1 25 A
1044580 Loop Fastener, Adhesive (2" x 18") 1 25 A
1043084 Hook Fastener, Adhesive (2" x 22") 1 25 B
1044584 Loop Fastener, Adhesive (2" x 22") 1 25 B
1135501 Kit, Seat Frame Assembly Hardware 1 16 C
Screw, Hex Head (1/4-20 x 3/4") 1 87
Washer (1/4 x 1/2 x 1/16") 1 28
Spacer, Coved (1/4 x 11/16 x 1/2") 1 49
Screw, Socket Head (1/4-20 x 3/4") 1 210
Pin, Roll (3/16 x 1") 1 211
1114823 Decal, Seat Adjustment Warning 1 212
A - For 16"-19" deep seats
B - For 19"-22" deep seats
C - Includes items 7-11
D - When ordering Center Seat Frame (item 1), also order 2 ea. Seat Adjustment Warning Decal (item 12).
NOTE:
(16"-20" Wide) x (16"-22" Deep) M51 After 04/29/08
Form No.
04-050
48
To order call toll free 1-800-333-6900, or www.invacare.com
Van Seat Assembly
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat please see Van Seat Frame
category for additional parts info.
Form No.
04-050
49
To order call toll free 1-800-333-6900, or www.invacare.com
Van Seat Assembly
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1106969 Backrest Extension, Van Seat - Grey Fabric 1 11
1108408 Backrest Extension, Van Seat - Grey Vinyl 1 11
1106968 Backrest Extension, Van Seat - Tan Vinyl 1 11
See Chart #2 Fold Down Van Seat Assembly (18" Wide) 1 12
See Chart #3 Van Seat Assembly (Semi-Recline) 1 13
See Chart #4 Van Seat w/ Solid Seat Base Assembly
(Semi-Recline)
1 14
1123384 Solid Seat Base, Van Seat - 16" Wide (Grey Vinyl) 1 15 A,D
1123385 Solid Seat Base, Van Seat - 18" Wide (Grey Vinyl) 1 15 A,D
1123386 Solid Seat Base, Van Seat - 20" Wide (Grey Vinyl) 1 15 A,D
See Chart #6 Office Style Van Seat Assembly 1 16 B
1127314 Backrest Extension, Semi Recline Office Style Van
Seat
1 17
1034625 Positioning Strap, Seat/Chest w/ Auto Style Push
Button Buckle
(Eyelet to Eyelet Length 61")
1 18
1127312 Package, Adjustment Knobs (5/16-18 x 3/4") 3 19
1127311 Package, Screws Socket Head Cap w/ Patch
(1/4-20 x 3/4")
4 110 C
1116413 Pivot, Seat 1 111
1092409 Washer, Steel (5/16 x 1-1/4 x 1/16") 1 412
1118458 Screw, Hex Head w/Patch (1/4-20 x 1-3/8") 1 413
1144924 Bracket, Seat Frame 18" 1 114
A - Solid Seat Base is the only item available for service parts with regard to these particular Van Seats. Seat Hinges are not
sold separately.
B - Includes items 7-14. When replacing Office Style Seat, the front rigging hanger attachment kit may need to be ordered as
well since it is not included (see Front Rigging Hanger category).
C - Package includes 4 screws, they are used to attach the Seat Positioning Strap (item 8)
D - Solid seat base is not available on Office Style Van Seats
NOTE:
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat please see Van Seat Frame
category for additional parts info.
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
50
Van Seat Assembly
#2 Fold Down Van Seat Assembly (18" Wide)
(Backrest Not Offered)
All Grey Fabric
Upholstery
All Grey Vinyl
Upholstery
All Tan Vinyl
Upholstery
N/A1108837N/A
Fold down, medium back seat has four stop angle adjustment settings that include 95, 100, 105, & 110 degrees and adjustable seat depths of
16", 17", & 18".
#3 Van Seat Assembly (Semi-Recline)
Upholstery Type
Van Seat with Backrest
16" Wide
Van Seat with Backrest
18" Wide
Van Seat with Backrest
20" Wide
110925511092541123424All Grey Fabric
110924311092421123426All Grey Vinyl
110924911092481123425All Tan Vinyl
Semi-Recline Van Seat reclines approx. 90-114 degrees. Adjustable depths are (16", 17", & 18" deep for 16" & 18" wide seats) and (18", 19",
& 20" deep for 20" wide seats). Recline release levers are standard on the right side. Left side release levers can be ordered as a special with
a new van seat.
#4 Van Seat w/ Solid Seat Base Assembly (Semi-Recline)
Upholstery Type
Van Seat with Backrest
16" Wide
Van Seat with Backrest
18" Wide
Van Seat with Backrest
20" Wide
N/AN/AN/AAll Grey Fabric
112342711234281123429All Grey Vinyl
N/AN/AN/AAll Tan Vinyl
Semi-Recline Van Seat reclines approx. 90-114 degrees. Adjustable depths are (16", 17", & 18" deep for 16" & 18" wide seats) and (18", 19",
& 20" deep for 20" wide seats). Recline release levers are standard on the right side. Left side release levers can be ordered as a special with
a new van seat.
#6 Office Style Van Seat Assembly
Charcoal Grey Vinyl Upholstery
18" Wide
Charcoal Grey Vinyl Upholstery
20" Wide
1127716
Semi-Recline Van Seat reclines approx. 90-114 degrees. Adjustable depths are 16", 17", & 18" deep. Recline release levers are standard on
the right side.
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat please see Van Seat Frame
category for additional parts info.
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
51
Elevating Seat Actuator, Proximity Sensor, and Hardware
Form No.
04-050
52
To order call toll free 1-800-333-6900, or www.invacare.com
Elevating Seat Actuator, Proximity Sensor, and Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127303 Kit, Elevating Actuator Hardware 1 11 A
Cable Tie (5-5/8" Long) 1 42
Sensor, Actuator Switch 1 13
Washer, Internal Tooth Lock (#4-40) 1 44
Screw, Phillips Pan Head (#4-40 x 7/16") 1 45
Washer (1/4 x 1/2 x 1/16") 1 46
Screw, Socket Head Cap (1/4-20 x 3/4") 1 47
Nut, Hex Keps (#4-40) 1 28
Washer (1/4 x 23/32 x 1/16") 1 49
Screw, Hex Head Cap w/ Patch (1/4-20 x 1-5/8") 1 110
1024001 Sensor, Actuator Switch 1 13
1127262 Actuator, Elevating Pivot 1 111
1127290 Harness, Proximity Sensor 1 112
A - Includes items 2-10
NOTE:
Form No.
04-050
53
To order call toll free 1-800-333-6900, or www.invacare.com
Arms - Van Seat
Form No.
04-050
54
To order call toll free 1-800-333-6900, or www.invacare.com
Arms - Van Seat
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1142487 Upper Arm Assembly, Desk Length (Right/Left) 1 18 A
Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 11
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 12
Washer, Flat (5/16 x 5/8 x 1/16") 1 23
Locknut (5/16-18) 1 14
Screw, Hex Head (5/16-18 x 1-1/4") 1 15
Nut, Hex (5/16-18) 1 16
Arm Tube, Upper Adjustable Height 1 17
1139923 Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 11
1140426 Upper Arm Assembly, Full Length (Right/Left) 1 18 A
Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 11
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 12
Washer, Flat (5/16 x 5/8 x 1/16") 1 23
Locknut (5/16-18) 1 14
Screw, Hex Head (5/16-18 x 1-1/4") 1 15
Nut, Hex (5/16-18) 1 16
Arm Tube, Upper Adjustable Height 1 17
1139924 Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 11
1114910 Knob, Adjustment (5/16-18 x 3/4") 1 29
1113646 Arm Tube, Lower Adjustable Width - Right 1 110
1113647 Arm Tube, Lower Adjustable Width - Left 1 110
1142493 Arm Assembly, Desk Length Adj. Height - Right 1 111 B
1142492 Arm Assembly, Desk Length Adj. Height - Left 1 111 B
1142474 Arm Assembly, Full Length Adj. Height - Right 1 111 B
1142475 Arm Assembly, Full Length Adj. Height - Left 1 111 B
1142488 Arm Assembly, Desk Length Fixed Height - Right 1 113 C
Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 11
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 12
Washer, Flat (5/16 x 5/8 x 1/16") 1 23
Locknut (5/16-18) 1 14
Screw, Hex Head (5/16-18 x 1-1/4") 1 15
Nut, Hex (5/16-18) 1 16
Knob, Adjustment (5/16-18 x 3/4") 1 19
Arm Tube, Fixed Height - Right 1 112
1139923 Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 11
1142489 Arm Assembly, Desk Length Fixed Height - Left 1 113 C
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
55
Arms - Van Seat
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 11
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 12
Washer, Flat (5/16 x 5/8 x 1/16") 1 23
Locknut (5/16-18) 1 14
Screw, Hex Head (5/16-18 x 1-1/4") 1 15
Nut, Hex (5/16-18) 1 16
Knob, Adjustment (5/16-18 x 3/4") 1 19
Arm Tube, Fixed Height - Left 1 112
1139923 Arm Pad - Desk Length, Black Urethane (12-1/4" L
x 2-5/8" W)
1 11
1142483 Arm Assembly, Full Length Fixed Height - Right 1 113 C
Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 11
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 12
Washer, Flat (5/16 x 5/8 x 1/16") 1 23
Locknut (5/16-18) 1 14
Screw, Hex Head (5/16-18 x 1-1/4") 1 15
Nut, Hex (5/16-18) 1 16
Knob, Adjustment (5/16-18 x 3/4") 1 19
Arm Tube, Fixed Height - Right 1 112
1139924 Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 11
1142486 Arm Assembly, Full Length Fixed Height - Left 1 113 C
Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 11
Screw, Socket Head Cap with Patch (5/16-18 x
1-3/4")
1 12
Washer, Flat (5/16 x 5/8 x 1/16") 1 23
Locknut (5/16-18) 1 14
Screw, Hex Head (5/16-18 x 1-1/4") 1 15
Nut, Hex (5/16-18) 1 16
Knob, Adjustment (5/16-18 x 3/4") 1 19
Arm Tube, Fixed Height - Left 1 112
1139924 Arm Pad - Full Length, Black Urethane (15" L x
2-5/8" W)
1 11
A - Includes items 1-7
B - Includes items 8-10
C - Includes items 1-6,9, and 12
NOTE:
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
56
Arms - ASBA & AdjASBA Seat
Fixed Height
Form No.
04-050
57
To order call toll free 1-800-333-6900, or www.invacare.com
Arms - ASBA & AdjASBA Seat
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
See Chart See Footnote 1 11
1102585 Arm Pad, Full Length Black Urethane Waterfall 1 12
1110818 Arm Pads, Full Length, Urethane Waterfall
with Screws, Black (13" L x 2-5/8" W) (Pair)
2 12
1102586 Arm Pad, Desk Length Black Urethane Waterfall 1 12
1110817 Arm Pads, Desk Length, Urethane Waterfall with
Screws, Black (9" L x 2-5/8" W) (Pair)
2 12
See Chart See Footnote 1 13
1032244 Grip, Foam Hand (9" Long) 1 14
1025729 Screw, Self Tapping Pan Head (#8-32 x 3/8") 1 45
1035472 Clothing Guard, Desk Length 1 16
1044572 Clothing Guard, Full Length 16-19" Deep 1 16
1044005 Clothing Guard, Full Length 20" and Deeper 1 16
1035065 Cover, Clothing Guard with Pocket - For Fixed
Height Desk Length & Adjustable Height Full/Desk
Length
1 17
1044588 Cover, Clothing Guard with Pocket
For Fixed Height Full Length - 20" and Deeper
1 17
1055949 Screws, Phillips Pan Head (#10-32 x 1-1/8") 2 18
1094270 Screw, Phillips Pan Head (#10-32 x 1-1/4") (Pair) 2 18
1065936 Plug, Pivot 1 29
1067734 Plug Button, Black (5/8") 1 210
1025195 Locknut (1/4-20) 1 111
1068025 Clevis, Pivot 1 112
1019590 Screw, Socket Button Head (1/4-20 x 1-5/8") 1 113
1068039 Pin, Pull 1 114
1068488 Kit, Swingaway Armrest Mounting Hardware 1 115
#1 Fixed Height Arms w/o Pad
Chair Seat Depth Arm Style Part Number
1068566Desk -Right16-19"
1068567Desk -Left16-19"
1068559Full -Right16-19"
1068560Full -Left16-19"
1068540Desk -Right20"
1068541Desk -Left20"
1068528Full -Right20"
1068529Full -Left20"
Fixed Height
Form No.
04-050
58
To order call toll free 1-800-333-6900, or www.invacare.com
Arms - ASBA & AdjASBA Seat
#3 Arm Tubes - Fixed Height
Chair Seat Depth Arm Style Part Number
1068564Desk -Right16-19"
1068565Desk -Left16-19"
1068490Full -Right16-19"
1068491Full -Left16-19"
1068414Desk -Right20"
1068415Desk -Left20"
1068473Full -Right20"
1068474Full -Left20"
Fixed Height
Form No.
04-050
59
To order call toll free 1-800-333-6900, or www.invacare.com
Arms - ASBA & AdjASBA Seat
Adjustable Height
Form No.
04-050
60
To order call toll free 1-800-333-6900, or www.invacare.com
Arms - ASBA & AdjASBA Seat
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1117328 Arm Pad, Full Length, Urethane Waterfall with
Screws, Black
(13" L x 2-5/8" W)
1 11 A
1110818 Arm Pads, Full Length, Urethane Waterfall
with Screws, Black (13" L x 2-5/8" W) (Pair)
2 11
1117327 Arm Pad, Desk Length, Urethane Waterfall with
Screws, Black
(9" L x 2-5/8" W)
1 11 A
1110817 Arm Pads, Desk Length, Urethane Waterfall with
Screws, Black (9" L x 2-5/8" W) (Pair)
2 11
1071253 Arm Top, Adjustable Height with Plug Buttons - Full
Length (Black)
1 12
1070859 Arm Tube, Upper with Plug Buttons (Black) - Desk
Length
1 12
1027095 Plug Button, Black (7/8") 1 23
1055949 Screws, Phillips Pan Head (#10-32 x 1-1/8") 2 14
1094270 Screw, Phillips Pan Head (#10-32 x 1-1/4") (Pair) 2 14
1064130 Clothing Guard 1 15
47471X074 Spring, Arm Lock 1 16
1028594 Pin, Arm Lock 1 17
1032244 Grip, Foam Hand (9" Long) 1 18
1090768 Kit, Lock Handle w/Rivets (both LT & RT side) 2 19
1028645 Rivet 1 610
1065936 Plug, Pivot 1 211
1067734 Plug Button, Black (5/8") 1 212
1068416 Arm Base, Adjustable Height
16-19" Deep - Right (Black)
1 113
1068417 Arm Base, Adjustable Height
16-19" Deep - Left (Black)
1 113
1068418 Arm Base, Adjustable Height
20" and Deeper - Right (Black)
1 113
1068419 Arm Base, Adjustable Height
20" and Deeper - Left (Black)
1 113
1035065 Cover, Clothing Guard with Pocket - For Fixed
Height Desk Length & Adjustable Height Full/Desk
Length
1 114
1025195 Locknut (1/4-20) 1 115
1068025 Clevis, Pivot 1 116
1019590 Screw, Socket Button Head (1/4-20 x 1-5/8") 1 117
1068039 Pin, Pull 1 118
1068488 Kit, Swingaway Armrest Mounting Hardware 1 119
A - After 7/9/07 Invacare recommends ordering armpads in pairs to assure uniform appearance on chair
NOTE:
Adjustable Height
Form No.
04-050
61
To order call toll free 1-800-333-6900, or www.invacare.com
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1125734 Kit, Front/Rear Arm Socket Assembly Mounting
Hardware
1 11 A
Screw, Hex Head Cap with Patch (5/16-18 x 3/4") 1 22
Washer (5/16 x 3/4 x 1/16") 1 43
T-Nut (5/16-18) 1 44
Screw, Hex Head (5/16-18 x 5/8") 1 25
1122619 Socket, Front Arm - Right 1 16
1122620 Socket, Front Arm - Left 1 16
1125478 Socket, Rear Arm - Right 1 17
1125479 Socket, Rear Arm - Left 1 17
A - Includes items 2-5
NOTE:
Front/Rear Arm Socket Assembly and Hardware
M51 ADJASBA After 4/29/08
Form No.
04-050
62
To order call toll free 1-800-333-6900, or www.invacare.com
Front/Rear Arm Socket Assembly and Hardware
M51 ADJASBA Seats with TRRO Option After 4/29/08
Form No.
04-050
63
To order call toll free 1-800-333-6900, or www.invacare.com
Front/Rear Arm Socket Assembly and Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1136025 Kit, Front/Rear Arm Socket Assembly Mounting
Hardware For TRRO Option
1 11
Screw, Hex Head Cap with Patch (5/16-18 x 3/4") 1 12
Screw, Hex Head Cap with Patch (5/16-18 x 1") 1 13
Screw, Socket Head Cap (5/16-18 x 3/4") 1 14
Washer (5/16 x 3/4 x 1/16") 1 45
T-Nut (5/16-18) 1 16
T-Nut (5/16-18) 1 27
Screw, Hex Head (5/16-18 x 5/8") 1 28
1122619 Socket, Front Arm - Right 1 19
1122620 Socket, Front Arm - Left 1 19
M51 ADJASBA Seats with TRRO Option After 4/29/08
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
64
Shrouds and Attaching Hardware
Form No.
04-050
65
To order call toll free 1-800-333-6900, or www.invacare.com
Shrouds and Attaching Hardware
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127709 Kit, Side and Inner Shroud Hardware 1 11 A
Screw, Phillips Head (1/4-20 x 11/16") 1 42
Locknut (#10-32) 1 23
Screw, Phillips Pan Head (10-32 x 1-5/8") 1 24
Screw, Phillips Pan Head (#8-16 x 5/8") 1 25
See Chart #6 Side Shroud Assembly 1 16 B
1127380 Shroud, Inner - Right 1 17
1127381 Shroud, Inner - Left 1 17
1110604 Decal, Shroud M50 1 18
1110605 Decal, Shroud M51 1 18
1127292 Decal, Shroud M61 1 18
1104797 Decal, Shroud Drive/Push 1 19
1127336 Top Shroud Assembly 1 110 C
1095489 Decal, Invacare 3-D Logo (2-1/2" L) 1 211
1079203 Decal, Warning Pinch Point 1 212
1070509 Fastener, Loop with Adhesive Back
(1" Wide x 2" Long)
1 213
1122126 Label, Battery Warning 1 114
1119281 Name Plate, Patent Numbers 1 115
1035900 Decal, Transportation 1 116
1127276 Clip, Wire with Adhesive Back 1 117
1127275 Top Shroud Assembly 1 118 D
1127383 Shroud, Front 1 119
1028484 Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 220
A - Includes items 2-5
B - Includes Decals, items 8 & 9
C - Includes items 11-16
D - Includes items 11-17
NOTE:
#6 Side Shroud Assembly
Includes Decals, items 8 & 9
Chair Model Red Blue
11273261127324M50 - Right
11273271127325M50 - Left
11273301127328M51 - Right
11273311127329M51 - Left
11273341127332M61 - Right
11273351127333M61 - Left
Form No.
04-050
66
To order call toll free 1-800-333-6900, or www.invacare.com
Top Shroud Assembly
M51 with Formula CG Tilt (CGT) & M51 Rehab After 4/29/08
Form No.
04-050
67
To order call toll free 1-800-333-6900, or www.invacare.com
Top Shroud Assembly
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1152539 Shroud, Top Rear (Black) with Decals 1 11 A
1095489 Decal, Invacare 3-D Logo (2-1/2" L) 1 12
1079203 Decal, Warning Pinch Point 1 23
1152540 Shroud, Top Front (Black) with Decals 1 14 B
1095489 Decal, Invacare 3-D Logo (2-1/2" L) 1 15
1035900 Decal, Transportation 1 16
1119281 Name Plate, Patent Numbers 1 17
1122126 Label, Battery Warning 1 18
A - Includes items 2 and 3 also
B - Includes items 5-8 also
NOTE:
M51 with Formula CG Tilt (CGT) & M51 Rehab After 4/29/08
Form No.
04-050
68
To order call toll free 1-800-333-6900, or www.invacare.com
Casters and Forks
Form No.
04-050
69
To order call toll free 1-800-333-6900, or www.invacare.com
Casters and Forks
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1106226 Kit, Fork Mounting Hardware 1 11 A
1028550 Locknut (5/8-18) 1 12
1041444 Washer (5/8 x 1-5/16 x 1/8") 1 13
1106068 Spacer, Stem (5/8 x 1-1/8 x 3/16") 1 14
40117X006 Bearing (5/8") 1 25
1110717 Ring, Tolerance 1 26
1110683 Fork and Stem 1 17
1110708 Kit, Caster Mounting Hardware 1 18 B
1025734 Locknut (7/16-20) 1 19
1025724 Washer (15/32 x 5/8 x 3/64") 1 210
1025726 Screw, Hex Head (7/16-20 x 3-1/4") 1 111
1110688 Kit, Caster Headtube with Hardware - Right 1 112 C
1110689 Kit, Caster Headtube with Hardware - Left 1 112 C
1140293 Kit, Caster Headtube with Hardware - Right
(TRRO/TRBKTS)
1 112 E,F
Screw, Socket Button Head Cap (3/8-24 x 3/4") 1 4
Bushing, Pivot Head Tube 1 2
Cap, Headtube - Right 1 1
Headtube Assembly, Caster with Bearings - Right
(TRRO/TRBKTS)
1 1
Spacer, Stem (5/8 x 1-1/8 x 3/16") 1 1
1140294 Kit, Caster Headtube with Hardware - Left
(TRRO/TRBKTS)
1 112 E,F
Screw, Socket Button Head Cap (3/8-24 x 3/4") 1 4
Bushing, Pivot Head Tube 1 2
Cap, Headtube - Left 1 1
Headtube Assembly, Caster with Bearings - Left
(TRRO/TRBKTS)
1 1
Spacer, Stem (5/8 x 1-1/8 x 3/16") 1 1
1109222 Screw, Socket Button Head Cap (3/8-24 x 3/4") 1 413
1112633 Bushing, Pivot Head Tube 1 214
1113012 Cap, Headtube - Right 1 115
1113013 Cap, Headtube - Left 1 115
1110694 Headtube Assembly with Bearings - Right 1 116 D
1110695 Headtube Assembly with Bearings - Left 1 116 D
1140289 Headtube Assembly, Caster with Bearings - Right
(TRRO/TRBKTS)
1 116 D,F
1140290 Headtube Assembly, Caster with Bearings - Left
(TRRO/TRBKTS)
1 116 D,F
1115179 Wheel with Bearings, 6 x 2" Urethane Deep Profile 1 117
1122066 Wheels with Bearings, 6 x 2" Urethane Deep Profile 2 117
Form No.
04-050
70
To order call toll free 1-800-333-6900, or www.invacare.com
Casters and Forks
A - Includes Items 2-4
B - Includes Items 9-11
C - Includes Items 13-16
D - Includes Items 5 and 6
E - Includes Items 13-16 & Stem Spacer (not shown)
F - Chairs w/ TRRO/TRBKTS option. These headtubes will have a dimple stamped on the outside for identification purposes.
NOTE:
Form No.
04-050
71
To order call toll free 1-800-333-6900, or www.invacare.com
Motor, Gearbox, and Drive Wheel
Form No.
04-050
72
To order call toll free 1-800-333-6900, or www.invacare.com
Motor, Gearbox, and Drive Wheel
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127394 Motor and Gearbox Assembly - Right 1 11 A
1127395 Motor and Gearbox Assembly - Left 1 11 A
1038361 Kit, Motor/Brake Covers with Screws 2 12 B
1123528 Kit, Motor Brush - Internal (Large) 2 13 C,D
1137265 Kit, Motor Brush w/ Cap - External 2 13 E,F
1122164 Instruction Sheet, Motor Brush Kit 1 1G
1141284 Kit, Motor Mounting Hardware 1 14 H
Screw, Socket Head (M6 x 1 x 30MM) 1 35
Screw, Socket Head Cap with Patch (M6 x 20MM) 1 36
1127397 Kit, Motor Release Lever Hardware 1 17 I
Pin, Clevis 1 18
Washer, Nylon (3/16 x 7/16 x 1/8") 1 19
Pin, Bridge 1 110
Tip, Foam, Black 1 111
Lever, Motor Release 1 112
Bushing, Snap 1 113
1102338 Kit, Drive Wheel with Mounting Hardware -
Pneumatic (10 x 3")
1 114 J
Key (6 MM x 6MM x 40 MM) 1 115
Washer (11/32 x 13/16 x 1/8") 1 116
Screw (M8 x 1-1/4 x 20MM) 1 117
Kit, Locking Tab Washers with Instruction Sheet 2 118
Tire, Pneumatic (10" x 3") 1 119
Tube, Inner (10" x 3") 1 120
Wheel, Drive with Bearings - Pneumatic (10" x 3") 1 121
1109005 Tire, Pneumatic (10" x 3") 1 119
1109028 Tube, Inner (10" x 3") 1 120
1102339 Kit, Drive Wheel with Mounting Hardware - Flat Free
(10 x 3")
1 114 J
Key (6 MM x 6MM x 40 MM) 1 115
Washer (11/32 x 13/16 x 1/8") 1 116
Screw (M8 x 1-1/4 x 20MM) 1 117
Kit, Locking Tab Washers with Instruction Sheet 1 118
Tire w/ Flat-Free (10" x 3") 1 119
Wheel, Drive with Tire and Bearings - Flat Free (10"
x 3")
1 121
1102342 Tire w/ Flat-Free (10" x 3") 1 119
A - Although motors are interchageable, they may have internal or external brushes.
B - Brake Cover is only serviceable on motors with internal brushes.
C - For motors with internal brushes.
D - Includes 2 ea. brushes and 1 ea. instruction sheet.
E - For motors with external brushes.
F - Includes 2 ea. brushes, 2 ea. brush caps, and 1 ea. instruction sheet.
G - Not Shown
H - Includes items 5 and 6.
I - Includes items 8-13.
J - Includes items 15-18, & 21.
NOTE:
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
73
Battery Harnesses
Form No.
04-050
74
To order call toll free 1-800-333-6900, or www.invacare.com
Battery Harnesses
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1127304 Kit, Battery Harnesses with Terminal Hardware 1 11 A
Cable Tie (11-1/2" Long) 1 6
Instruction Sheet, Battery Installation 1 1
Harness, Battery - Front 1 12
Harness, Battery with 75 Amp Fuse 1 13
Harness, Battery - Rear 1 14
Locknut (1/4-20) 1 45
Washer, Locking Tab 1 26
Screw, Hex Flange Whiz Lock(1/4-20 x 5/8") 1 47
Harness, Battery with 75 Amp Fuse 1 18
1116381 Cable, Battery Extension (75 Amp) (Black
Connector)
1 19 B
1127260 Harness, Actuator Sensor and Battery Charger 1 110 C
A - Includes items 2-8, Cables Ties (not shown), and Instruction Sheet (not shown).
B - Used on M50 and M51 models
C - Used on M61 models
NOTE:
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
75
Footboard Assembly - 90FB
Form No.
04-050
76
To order call toll free 1-800-333-6900, or www.invacare.com
Footboard Assembly - 90FB
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1105027 Footboard Assembly 1 11 A,B
Washer, Nylon (3/8 x 3/4 x 1/16") 1 22
Washer, Flat (3/8 x 11/16 x 1/16") 1 13
Screw, Socket Head (3/8-16 x 2-1/2") 1 14
Footboard with Cover 1 15
Bushing (3/8 x 5/8 x 1/2") 1 16
Locknut, Low Profile (3/8-16) 1 17
Screw, Socket Set Flat (5/16-18 x 1") 1 18
Locknut (5/16-18) 1 19
Bracket, Footboard Support (Black) 1 110
Pin, Quick Release 1 111
Cap, Tube (1" Square) 1 112
1115378 Kit, 2" Footboard Extension 1 113 C
Locknut, Low Profile (3/8-16) 1 114
Bushing (3/8 x 5/8 x 1/2") 1 115
Washer, Nylon (3/8 x 3/4 x 1/16") 1 216
Washer, Flat (3/8 x 11/16 x 1/16") 1 117
Screw, Socket Head (3/8-16 x 2-1/2") 1 118
Cap, Tube (1" Square) 1 119
Bracket, Footboard Support 2" Extension 1 120
Bag, Zip Lip (4" x 4") 1 121
Instruction Sheet, 2" Footboard Extension 1 122
Carton, Shipper 1 123
A - Includes items 2-12
B - When ordering a footboard assembly for the first time that requires a 2" extension kit, items 5, 8, 9, 11 and 13 must be
ordered
C - Includes items 14-23
NOTE:
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
77
Front Riggings Hangers
Hemi
Form No.
04-050
78
To order call toll free 1-800-333-6900, or www.invacare.com
Front Riggings Hangers
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1149192 Kit, Front Rigging Seat Support, 18" 1 11 A
Carton, Inner 1 12
Bracket, Front Rigging Hanger 1 23
Screw, Socket Button Head w/ Patch
(1/4-20 x 3/4")
1 44
Washer (1/4 x 23/32 x 1/16") 1 45
1148879 Kit, Front Rigging Seat Support, 20" 1 11 F
Bracket, Front Rigging Hanger 1 23
Screw, Socket Button Head w/ Patch
(1/4-20 x 3/4")
1 44
Washer (1/4 x 23/32 x 1/16") 1 45
1114997 Kit, Front Rigging Hanger Attachment 1 16 B,D
Bag, Poly Zip-Lip (13" Long x 9" Wide) 1 17
Instruction Sheet, Front Rigging Hanger 1 18
Front Rigging Hanger Assembly w/ Plug Button
(Hemi) - Right
1 19
Front Rigging Hanger Assembly w/ Plug Button
(Hemi) - Left
1 110
Carton, Shipper 1 111
Screw, Hex Head (1/4-20 x 1-1/2") 1 412
Spacer (1/4 x 3/8 x 3/16") 1 413
Locknut (1/4-20) 1 414
1113045 Kit, Front Rigging Hanger Hardware 1 115 C,G
Screw, Hex Head (1/4-20 x 1-1/2") 1 416
Spacer (1/4 x 3/8 x 3/16") 1 417
Locknut (1/4-20) 1 418
Bag, Zip Lip (4" x 4") 1 119
1114766 Front Rigging Hanger Pin Style with Plug Button
(Hemi) (12-21" Deep) - Right
1 120 E,G
1114767 Front Rigging Hanger Pin Style with Plug Button
(Hemi) (12-21" Deep) - Left
1 120 E,G
1027097 Plug Button, Black (3/4") 1 121 G
A - For Office Style Seats 18". Includes items 2-5.
B - For Office Style Van Seats, Fold Down Style & Semi-Recline Van Seats. Includes items 7-14.
C - Includes items 16-19.
D - Items 5-7 and 15-17 can be ordered separately. Order item 15, part no. 1113045.
E - For ASBA Seats. Includes plug button item 21.
F - Includes Items 3-5. For Office Style Seats 20" Wide.
G - For chairs manufactured before April XX/08 with Center Post Mounting.
NOTE:
Hemi
Form No.
79
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
Front Rigging Hanger Assembly
ADJASBA After 4/29/08
Form No.
04-050
80
To order call toll free 1-800-333-6900, or www.invacare.com
Front Rigging Hanger Assembly
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1124723 Kit, Side Rail Cap Hardware (Pair) 1 11 A
Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 42
Spacer (1/4 x 3/8 x 29/32") 1 43
Cap, Side Rail End 1 24
Plug Button, Black (1") 1 25
Block, Threaded 1 26
1125726 Kit, Front Rigging Hanger Mounting Hardware (Pair) 1 17 B
Screw, Socket Head Cap w/ Patch (1/4-20 x 1-1/2") 1 48
Spacer (1/4 x 3/8 x 3/16") 1 49
Cap, Side Rail End 1 210
Block, Threaded 1 211
1124401 Front Rigging Hanger
Pin Style with Plug Button (Hemi) - Right
1 112 C
1124402 Front Rigging Hanger
Pin Style with Plug Button (Hemi) - Left
1 112 C
1134426 Package, Plug Buttons, Black (3/4") 10 113
A - Includes items 2-6
B - Includes items 8-11
C - Includes item 13
NOTE:
ADJASBA After 4/29/08
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
81
Support Assemblies
Front
Rigging
Color
Right
Color
Left
Chrome
Right
Chrome
Left
N/AN/A11147561114755PHW93
N/AN/A
8881114758
8881114757
PH904A
See Note(s) A See Note(s) A
11147621114761N/AN/APHAL4A
A - Specify 34P Flat Black Frame Finish When Ordering. NOTE:
PHW93
Pivot Slide Tubes with Footplates
Chair
Width
Aluminum
(1650)
Deluxe
Aluminum
(1450)
Extra Large
Aluminum
(1350)
Adjustable
Angle
(AT5543)
Composite
(1651)
10578691062756102639510741511074149
16" Wide
Right
10578701062757102639610741521074150
16" Wide
Left
10578791062756102639510741511074149
17-20" Wide
Right
10578801062757102639610741521074150
17-20" Wide
Left
NOTE: Pivot/ Slide Tube Mounting Hardware is Not Included.
PHAL4A
Pivot Slide Tubes with Footplates
Chair
Width
Aluminum
(1650)
Deluxe Aluminum
(1450)
Extra Large Aluminum
(1350)
103545610239241023907
16-20" Wide
Right
103545710239251023908
16-20" Wide
Left
NOTE: Pivot/ Slide Tube Mounting Hardware is Not Included.
Front Rigging Reference Chart
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
82
Front Rigging Reference Chart
PH904A
Pivot Slide Tubes with Footplates
Chair
Width
Aluminum
(1650)
Deluxe Aluminum
(1450)
Extra Large Aluminum
(1350)
105883010287231058604
16-20" Wide
Right
105883110287241058605
16-20" Wide
Left
NOTE: Pivot/ Slide Tube Mounting Hardware is Not Included.
PHW93 (2" and 4" Longer) Aluminum, Extra Large, and Adj. Angle
Pivot Slide Tubes with Footplates
Footplate
Type
16-20" Wide
Right
16-20" Wide
Left
10864971086494
Aluminum (1650)
2" Longer
10864981086495
Aluminum (1650)
4" Longer
10865171086515
Extra Large Aluminum (1350)
2" Longer
10865181086516
Extra Large Aluminum (1350)
4" Longer
10627611062760
Adjustable Angle (AT5543)
2" Longer
NOTE: Pivot/ Slide Tube Mounting Hardware is not Included.
PHW93 (2" and 4" Longer) - Composite (1651)
Pivot Slide Tubes with Footplates
Footplate
Type
16" Wide
Right
16" Wide
Left
17-20" Wide
Right
17-20" Wide
Left
1057882105788110578721057871
Composite (1651)
2" Longer
1058424105842310584221058421
Composite (1651)
4" Longer
NOTE: Pivot/ Slide Tube Mounting Hardware is not Included.
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
83
Front Rigging Reference Chart
PH904A (2" and 4" Longer)
Pivot Slide Tubes with Footplates
Footplate
Type
16-20" Wide
Right
16-20" Wide
Left
10865311086529
Aluminum (1650)
2" Longer
10865321086530
Aluminum (1650)
4" Longer
10865511086541
Extra Large Aluminum (1350)
2" Longer
10865521086542
Extra Large Aluminum (1350)
4" Longer
NOTE: Pivot/ Slide Tube Mounting Hardware is Not Incliuded.
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
84
PHW93 (Hemi) Footrest Supports
Black
For complete Footrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
04-050
85
To order call toll free 1-800-333-6900, or www.invacare.com
PHW93 (Hemi) Footrest Supports
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1020719 Anti-Rattle, Black 1 11
1025716 Screw, Phillips Pan Head (#10-32 x 11/16") 1 12
47565X057 Bushing (7/32 x 3/8 x 11/32") 1 13
1025735 Locknut (#10-32) 1 14
1026114 Screw, Phillips Pan Head (#10-32 x 1/2") 1 15
1114749 Release Handle (Black) - Right 1 16 A
1114750 Release Handle (Black) - Left 1 16 A
1028846 Rivnut (#10-32) 1 17
1028707 Spring, Release - Right 1 18
1028708 Spring, Release - Left 1 18
1006490 Tip, Plastic, Black 1 19
15680X012 Collar, Anti-Rattle (7/8") 1 110
1070759 Screw, Hex Head (1/4-20 x 1-1/2") 1 111
1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 212
1044214 Nut, Hex with Nylon Cap (1/4-20) 1 113
1020534 Insert, Threaded 1 114
1074143 Kit, Slide Tube Mounting Hardware 1 115
1114755 Footrest Support Assembly, Hemi, Black - Right 1 1B
1114756 Footrest Support Assembly, Hemi, Black - Left 1 1B
A - Includes items 2-4
B - Not Shown
NOTE:
Black
For complete Footrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
04-050
86
To order call toll free 1-800-333-6900, or www.invacare.com
PH904A (Hemi) Legrest Supports
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
04-050
87
To order call toll free 1-800-333-6900, or www.invacare.com
PH904A (Hemi) Legrest Supports
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1114749 Release Handle (Black) - Right 1 11 D
1114750 Release Handle (Black) - Left 1 11 D
1025716 Screw, Phillips Pan Head (#10-32 x 11/16") 1 12
47565X057 Bushing (7/32 x 3/8 x 11/32") 1 13
1025735 Locknut (#10-32) 1 14
1026114 Screw, Phillips Pan Head (#10-32 x 1/2") 1 15
1008935 Spring, Release - Right 1 16
1008936 Spring, Release - Left 1 16
67005X000 Rivnut (#10-32) 1 17
1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 18
1022874 Bumper 1 19
1114753 Support Bracket Assembly, Legrest (Black) - Right 1 110 E
1114754 Support Bracket Assembly, Legrest (Black) - Left 1 110 E
1006490 Tip, Plastic, Black 1 111
11919X000 Screw, Truss Head (3/8-16 x 1-1/2") 1 112
40363X000 Hex Nut (3/8"-16) 1 113
1037126 Handle, Release 1 114
1040060 Tip, Black Plastic 1 115
1058636 Washer, Nylon (25/64 x 7/8 x 1/32") 1 216
8881048851 Tube, Elevating Support (Color) - Right 1 117 A
8881048852 Tube, Elevating Support (Color) - Left 1 117 A
47328X003 Bushing, Pivot (5/16 x 7/16 x 7/8") 1 118
1037110 Screw, Hex Head (5/16-24 x 3-1/2") 1 119
1025730 Locknut (5/16-24) 1 220
1026030 Screw, Lug (5/16-24 x 1-3/8") 1 121
1110207 Bracket, Calf Pad, Black 1 122
1025133 Spacer, Legrest Pad 1 123
04526X019 Plate, Legrest Pad 1 124
48823X008 Spring, Leaf 1 125
1113030 Bar, Ratchet 1 126
47330X003 Spacer (5/16 x 1/2 x 3/8") 1 227
1013519 Washer, Nylon (5/16 x 11/16 x 1/16") 1 128
04528X002 Bracket, Release (Chrome) 1 129
10261X000 Acorn Nut (5/16"-24) 1 130
1040831 Snap Ring 1 131
1037125 Cam, Legrest 1 132
1037485 Spring, Release 1 133
8881091764 Pad, Legrest Vinyl - Right/Left 1 134 B
1068649 Screws, Phillips Head (#10-32 x 11/16") 2 135
8881114757 Legrest Support Assembly, Hemi, Color - Right 1 1A,C
8881114758 Legrest Support Assembly, Hemi, Color - Left 1 1A,C
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
04-050
88
To order call toll free 1-800-333-6900, or www.invacare.com
PH904A (Hemi) Legrest Supports
A - Specify 34P flat black frame finish when ordering
B - Specify upholstery color U67 black when ordering
C - Not Shown
D - Includes items 2-4
E - Includes items 1-9
NOTE:
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
89
PHAL4A (Hemi) Articulating Legrest Supports
Chrome
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
04-050
90
To order call toll free 1-800-333-6900, or www.invacare.com
PHAL4A (Hemi) Articulating Legrest Supports
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 11
1022874 Bumper 1 12
1114751 Release Handle (Chrome) - Right 1 13 C
1114752 Release Handle (Chrome) - Left 1 13 C
47565X057 Bushing (7/32 x 3/8 x 11/32") 1 14
60279X003 Locknut (#10-32) 1 15
40163X008 Screw, Phillips Pan Head (#10-32 x 11/16") 1 16
1008935 Spring, Release - Right 1 17
1008936 Spring, Release - Left 1 17
67005X000 Rivnut (#10-32) 1 18
40163X002 Screw, Phillips Round Head (#10-32 x 1/2") 1 19
1114759 Tube, Legrest Support (Chrome) Hemi - Right 1 110 D
1114760 Tube, Legrest Support (Chrome) Hemi - Left 1 110 D
1027097 Plug Button, Black (3/4") 1 111
1006490 Tip, Plastic, Black 1 112
1040060 Tip, Black Plastic 1 113
1037126 Handle, Release 1 114
1049527 Washer, Nylon (3/8 x 3/4 x 1/16") 1 215
1022866 Screw, Socket Button Head (3/8-16 x 3/4") 1 216
40363X000 Hex Nut (3/8"-16) 1 317
1022846 Bar, Link, Chrome 1 118
1022877 Tube Support and Drive Link - Right 1 119
1022878 Tube Support and Drive Link - Left 1 119
1022854 Screw, Slotted Head Shoulder (1/2 x 1-1/8") 1 120
10261X000 Acorn Nut (5/16"-24) 1 121
04528X002 Bracket, Release (Chrome) 1 122
1040831 Snap Ring 1 123
47328X003 Bushing, Pivot (5/16 x 7/16 x 7/8") 1 224
42326X004 Bar, Ratchet - Right/Left 1 125
1037485 Spring, Release 1 126
1037125 Cam, Legrest 1 127
1013519 Washer, Nylon (5/16 x 11/16 x 1/16") 1 128
1024911 Decal, Smartleg 1 129
1014807 Screw, Hex Head (5/16-24 x 3-1/4") 1 130
48823X008 Spring, Leaf 1 131
47328X003 Bushing, Pivot (5/16 x 7/16 x 7/8") 1 132
1025133 Spacer, Legrest Pad 1 133
04526X019 Plate, Legrest Pad 1 134
60264X001 Locknut (5/16-24) 1 135
1025104 Bracket, Legrest (Chrome) 1 136
11232X009 Screw, Lug (5/16-24 x 1-3/8") 1 137
1022848 Slide Tube, Articulating (Chrome) - Right 1 138
Chrome
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
04-050
91
To order call toll free 1-800-333-6900, or www.invacare.com
PHAL4A (Hemi) Articulating Legrest Supports
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1022849 Slide Tube, Articulating (Chrome) - Left 1 138
1027377 Washer (#20) 1 139
1107321 Nut, Low Cap (5/16"-24) 1 140
8881091764 Pad, Legrest Vinyl - Right/Left 1 141 A
1068649 Screws, Phillips Head (#10-32 x 11/16") 2 142
1114761 Legrest Support Assembly, Articulating, Hemi,
Chrome - Right
1 1B
1114762 Legrest Support Assembly, Articulating, Hemi,
Chrome - Left
1 1B
A - Specify upholstery color U67 black when ordering.
B - Not Shown
C - Includes items 4-6
D - Includes items 1-9
NOTE:
Chrome
For complete Legrest Support Assembly part nos., see Front Riggings Reference chart.
Form No.
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
92
Pivot/Slide Tube and Footplate
PHW93
Heel loops are not included. See footrest and legrest accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference chart.
Form No.
04-050
93
To order call toll free 1-800-333-6900, or www.invacare.com
Pivot/Slide Tube and Footplate
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1027097 Plug Button, Black (3/4") 1 21
1048834 Pivot/Slide Tube with Plug Button 1 12 C,A
1098906 Pivot/Slide Tube with Plug Button - 2" Longer 1 12 C,A
1086482 Pivot/Slide Tube with Plug Button - 4" Longer 1 12 C,A
1070762 Pivot/Slide Tube with Plug Button, Deluxe Aluminum 1 12 B
44200X027 Footplate, Aluminum - Medium (7-3/4" W x 6" L) 1 13 A
1043659 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -
Right
1 13 B
1043660 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -
Left
1 13 B
44200X025 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)
- Right
1 13 C
44200X026 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)
- Left
1 13 C
1016346 Cap, Tube End (7/8") 1 14 A
1027095 Plug Button, Black (7/8") 1 14 C
1006981 Spring, Leaf 1 25 D,A
1036120 Spring 1 25 B,D
1036123 Spring, Leaf 1 15 C
40120X001 Screw, Phillips Pan Head (#8-32 x 3/8") 1 26 E
1070168 Push Plug, Footplate 1 17
A - Standard Aluminum (1650)
B - Deluxe Aluminum (1450)
C - Extra Large Aluminum (1350)
D - Two per side
E - Deluxe takes one
NOTE:
PHW93
Heel loops are not included. See footrest and legrest accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference chart.
Form No.
04-050
94
To order call toll free 1-800-333-6900, or www.invacare.com
Pivot/Slide Tube and Footplates
PH904A and PHAL4A
Heel loops are not included. See footrest and legrest accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference chart.
Form No.
04-050
95
To order call toll free 1-800-333-6900, or www.invacare.com
Pivot/Slide Tube and Footplates
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1027097 Plug Button, Black (3/4") 1 21
1100568 Pivot/Slide Tube with Plug Button (Black) 1 12 B,D,A
1100569 Pivot/Slide Tube with Plug Button
Extra Large and Standard Aluminium - 2" Longer
1 12 B,D,A
1100570 Pivot/Slide Tube with Plug Button - 4" Longer 1 12 B,D,A
1041526 Pivot/Slide Tube with Plug Button (Steel) 1 12 B,E,A
1100571 Pivot/Slide Tube with Plug Button - Deluxe 1 12 C,D
1023804 Pivot/Slide Tube w/ Plug Button 1 12 C,E
44200X027 Footplate, Aluminum - Medium (7-3/4" W x 6" L) 1 13 A
1043659 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -
Right
1 13 C
1043660 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -
Left
1 13 C
44200X025 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)
- Right
1 13 B
44200X026 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)
- Left
1 13 B
1016346 Cap, Tube End (7/8") 1 14 A
1027095 Plug Button, Black (7/8") 1 14 B
1006981 Spring, Leaf 1 15 A
1036120 Spring 1 15 C,F
1036123 Spring, Leaf 1 15 B
40120X001 Screw, Phillips Pan Head (#8-32 x 3/8") 1 26 G
1070168 Push Plug, Footplate 1 17
A - Standard Aluminum (1650)
B - Extra Large Aluminum (1350)
C - Deluxe Aluminum (1450)
D - PH904A
E - PHAL4A
F - Two per side
G - Deluxe takes one
NOTE:
PH904A and PHAL4A
Heel loops are not included. See footrest and legrest accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference chart.
Form No.
96
04-050
To order call toll free 1-800-333-6900, or www.invacare.com
AT5543 Adjustable Angle Footplates
PHW93
Heel Loops are not included. See footrest and legrest accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference charts.
Form No.
04-050
97
To order call toll free 1-800-333-6900, or www.invacare.com
AT5543 Adjustable Angle Footplates
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1062569 Footplate, Adjustable Angle - X-Large
(6-1/4" W x 8" L)
1 11
1029545 Screw, Socket Head Cap (1/4-20 x 3/4") 1 22
1058517 Clamp, Footplate 1 13
1082686 Nut, Hex Head (1/4-20 x 11/16") 1 24
1025736 Locknut (1/4-20) 1 15
1026907 Washer (1/4 x 1/2 x 1/16") 1 16
1048816 Screw, Nylon Adjustment (1/2-13 x 7/8") 1 17
1052102 Hinge, Footplate - Right 1 18
1052103 Hinge, Footplate - Left 1 18
1022831 Screw, Socket Button Head (1/4-20 x 1-7/8") 1 19
1026900 Washer (1/4 x 23/32 x 1/16") 1 110
1057855 Pivot/Slide Tube, Straight (9-7/8" Long - Steel) 1 111
1057856 Pivot/Slide Tube, Straight (11-7/8" Long - Steel) 1 111
1016301 Washer, Nylon (5/16 x 7/8 x 1/8") 1 112
1025457 Spacer, Coved (1/4 x 3/4 x 11/32") 1 113
PHW93
Heel Loops are not included. See footrest and legrest accessories.
For complete pivot/slide tube and footplate assemblies, see Front Riggings Reference charts.
Form No.
04-050
98
To order call toll free 1-800-333-6900, or www.invacare.com
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1057852 Pivot/Slide Tube, Curved End (9-7/8") (Steel) 1 11
1025457 Spacer, Coved (1/4 x 3/4 x 11/32") 1 22
1027097 Plug Button, Black (3/4") 1 13
1025195 Locknut (1/4-20) 1 14
60285X006 Screw, Socket Head Cap (1/4-20 x 2-1/4") 1 15
1026879 Footplate, Composite - Small (6" W x 6" L) 1 16
1026880 Footplate, Composite - Medium (7" W x 6" L) 1 16
1026881 Footplate, Composite - Large (8" W x 6" L) 1 16
Pivot/Slide Tube and Composite Footplate
PHW93
NOTE: Heel Loops are not included. See Footrest and Legrest Accessories.
NOTE: For complete pivot slide tube and footplate assemblies, see Front Riggings Reference chart.
Form No.
04-050
99
To order call toll free 1-800-333-6900, or www.invacare.com
Loading...
