HP LaserJet M452 User's Guide

User Guide

Color LaserJet Pro M452

www.hp.com/support/colorljM452

M452nw

M452dn

M452dw

HP Color LaserJet Pro M452

User Guide

Trademark Credits

Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws.

The information contained herein is subject to change without notice.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Edition 3, 8/2019

Adobe®, Adobe Photoshop®, Acrobat®, and PostScript

are trademarks of Adobe Systems

Incorporated.

Apple and the Apple logo are trademarks of Apple Computer, Inc., registered in the U.S. and other countries. iPod is a trademark of Apple Computer, Inc. iPod is for legal or rightholderauthorized copying only. Don't steal music.

Microsoft®, Windows®, Windows® XP, and Windows Vista® are U.S. registered trademarks of Microsoft Corporation.

UNIX® is a registered trademark of The Open Group.

Table of contents

1 Product overview ...................................................................................................................................................................................... 1

Product views ............................................................................................................................................................................ 2

Printer front view ................................................................................................................................................. 2

Printer back view .................................................................................................................................................. 3

2-line control-panel view (M452nw and M452dn models) .......................................................................... 4

Touchscreen control-panel view (M452dw model) ........................................................................................ 5

Home screen layout ........................................................................................................................ 6

How to use the touchscreen control panel ................................................................................. 7

Product specications .............................................................................................................................................................. 8

Technical specications ...................................................................................................................................... 8

Supported operating systems ........................................................................................................................... 9

Mobile printing solutions .................................................................................................................................. 10

Printer dimensions ............................................................................................................................................ 11

Power consumption, electrical specications, and acoustic emissions .................................................... 12

Operating-environment range ........................................................................................................................ 13

Printer hardware setup and software installation ............................................................................................................ 14

2 Paper trays .............................................................................................................................................................................................. 15

Load paper into Tray 1 (multipurpose tray) ....................................................................................................................... 16

Introduction ........................................................................................................................................................ 16

Load paper into Tray 1 (multipurpose tray) .................................................................................................. 16

Tray 1 paper orientation ................................................................................................................................... 18

Load paper into Tray 2 .......................................................................................................................................................... 19

Introduction ........................................................................................................................................................ 19

Load paper into Tray 2 ...................................................................................................................................... 19

Tray 2 paper orientation ................................................................................................................................... 22

Load and print envelopes ..................................................................................................................................................... 23

Introduction ........................................................................................................................................................ 23

Print envelopes .................................................................................................................................................. 23

Envelope orientation ......................................................................................................................................... 24

ENWW iii

3 Supplies, accessories, and parts .......................................................................................................................................................... 25

Order supplies, accessories, and parts ............................................................................................................................... 26

Ordering .............................................................................................................................................................. 26

Supplies and accessories ................................................................................................................................. 26

Customer self-repair parts ............................................................................................................................... 26

Replace the toner cartridges ................................................................................................................................................ 28

Introduction ........................................................................................................................................................ 28

Remove and replace the toner cartridges ..................................................................................................... 29

4 Print .......................................................................................................................................................................................................... 35

Print tasks (Windows) ............................................................................................................................................................ 36

How to print (Windows) .................................................................................................................................... 36

Automatically print on both sides (Windows) ............................................................................................... 37

Manually print on both sides (Windows) ........................................................................................................ 37

Print multiple pages per sheet (Windows) .................................................................................................... 39

Select the paper type (Windows) .................................................................................................................... 39

Additional print tasks ........................................................................................................................................ 39

Print tasks (macOS) ............................................................................................................................................................... 41

How to print (macOS) ........................................................................................................................................ 41

Automatically print on both sides (macOS) ................................................................................................... 41

Manually print on both sides (macOS) ........................................................................................................... 41

Print multiple pages per sheet (macOS) ........................................................................................................ 42

Select the paper type (macOS) ........................................................................................................................ 42

Additional print tasks ........................................................................................................................................ 42

Store print jobs on the product to print later or print privately ...................................................................................... 44

Introduction ........................................................................................................................................................ 44

Before you begin ............................................................................................................................................... 44

Set up the printer for job storage ................................................................................................................... 44

Step one: Install the USB ash drive .......................................................................................... 44

Step two: Update the print driver ............................................................................................... 45

Create a stored job (Windows) ........................................................................................................................ 45

Print a stored job ............................................................................................................................................... 47

Delete a stored job ............................................................................................................................................ 48

Mobile printing ........................................................................................................................................................................ 49

Introduction ........................................................................................................................................................ 49

Wi-Fi Direct and NFC Printing (wireless models only) ................................................................................. 49

Enable or disable Wi-Fi Direct ..................................................................................................... 49

Change the printer Wi-Fi Direct name ....................................................................................... 50

HP ePrint via email ............................................................................................................................................ 51

HP ePrint software ............................................................................................................................................ 51

AirPrint ................................................................................................................................................................. 52

iv ENWW

Android embedded printing ............................................................................................................................. 52

Use walk-up USB printing (touchscreen models only) ..................................................................................................... 53

Introduction ........................................................................................................................................................ 53

Step one: Access USB les on the printer ...................................................................................................... 53

Step two: Print USB documents ...................................................................................................................... 53

Option one: Print documents ...................................................................................................... 53

Option two: Print photos .............................................................................................................. 54

5 Manage the product ............................................................................................................................................................................... 55

Use HP Web Services applications ...................................................................................................................................... 56

Change the product connection type (Windows) .............................................................................................................. 57

Advanced conguration with HP Embedded Web Server (EWS) and HP Device Toolbox (Windows) ....................... 58

Advanced conguration with HP Utility for OS X ............................................................................................................... 61

Open HP Utility ................................................................................................................................................... 61

HP Utility features ............................................................................................................................................. 61

Congure IP network settings .............................................................................................................................................. 63

Introduction ........................................................................................................................................................ 63

Printer sharing disclaimer ................................................................................................................................ 63

View or change network settings ................................................................................................................... 63

Rename the printer on a network .................................................................................................................. 64

Manually congure IPv4 TCP/IP parameters from the control panel ........................................................ 65

Product security features ..................................................................................................................................................... 67

Introduction ........................................................................................................................................................ 67

Assign or change the system password using the HP Embedded Web Server ...................................... 67

Economy conservation settings .......................................................................................................................................... 69

Introduction ........................................................................................................................................................ 69

Print with EconoMode ....................................................................................................................................... 69

Set the Sleep/Auto O After setting ............................................................................................................... 69

Set the Shut Down After delay and congure the printer to use 1 watt or less of power ..................... 70

Set the Delay Shut Down setting .................................................................................................................... 71

HP Web Jetadmin ................................................................................................................................................................... 73

Update the rmware ............................................................................................................................................................. 74

Method one: Update the rmware using the control panel ........................................................................ 74

Method two: Update the rmware using the Firmware Update Utility ..................................................... 75

6 Solve problems ....................................................................................................................................................................................... 77

Customer support .................................................................................................................................................................. 78

Control panel help system (touchscreen models only) ................................................................................................... 79

Restore the factory-set defaults ......................................................................................................................................... 80

A “Cartridge is low” or “Cartridge is very low” message displays on the printer control panel ................................. 81

Change the “Very Low” settings ...................................................................................................................... 81

ENWW v

Order supplies .................................................................................................................................................... 82

Product does not pick up paper or misfeeds ..................................................................................................................... 83

Introduction ........................................................................................................................................................ 83

The printer does not pick up paper ................................................................................................................ 83

The printer picks up multiple sheets of paper .............................................................................................. 85

Clear paper jams .................................................................................................................................................................... 89

Introduction ........................................................................................................................................................ 89

Experiencing frequent or recurring paper jams? .......................................................................................... 89

Paper jam locations ........................................................................................................................................... 91

Clear paper jams in Tray 1 ............................................................................................................................... 92

Clear paper jams in Tray 2 ............................................................................................................................... 95

Clear paper jams in the rear door and the fuser area (nw model) ............................................................ 97

Clear paper jams in the output bin ................................................................................................................. 99

Clear paper jams in the duplexer (dn and dw models only) ..................................................................... 100

Improve print quality ........................................................................................................................................................... 102

Introduction ...................................................................................................................................................... 102

Print from a dierent software program .................................................................................................... 102

Check the paper-type setting for the print job ........................................................................................... 102

Check the paper type setting (Windows) ................................................................................ 102

Check the paper type setting (OS X) ........................................................................................ 103

Check toner-cartridge status ........................................................................................................................ 103

Clean the product ............................................................................................................................................ 103

Print a cleaning page ................................................................................................................. 103

Visually inspect the toner cartridge ............................................................................................................. 104

Check paper and the printing environment ................................................................................................ 105

Step one: Use paper that meets HP specications ............................................................... 105

Step two: Check the environment ............................................................................................ 105

Adjust color settings (Windows) ............................................................................................... 105

Adjust color settings (Windows) ................................................................................................................... 106

Calibrate the printer to align the colors ....................................................................................................... 107

Check the EconoMode settings ..................................................................................................................... 109

Try a dierent print driver .............................................................................................................................. 109

Solve wired network problems .......................................................................................................................................... 111

Introduction ...................................................................................................................................................... 111

Poor physical connection ............................................................................................................................... 111

The computer is using the incorrect IP address for the printer ............................................................... 111

The computer is unable to communicate with the printer ....................................................................... 111

The printer is using incorrect link and duplex settings for the network ................................................ 112

New software programs might be causing compatibility problems ...................................................... 112

The computer or workstation might be set up incorrectly ...................................................................... 112

The printer is disabled, or other network settings are incorrect ............................................................. 112

vi ENWW

Solve wireless network problems ..................................................................................................................................... 113

Introduction ...................................................................................................................................................... 113

Wireless connectivity checklist ..................................................................................................................... 113

The printer does not print after the wireless conguration completes ................................................. 114

The printer does not print, and the computer has a third-party rewall installed ............................... 114

The wireless connection does not work after moving the wireless router or printer .......................... 114

Cannot connect more computers to the wireless printer ........................................................................ 114

The wireless printer loses communication when connected to a VPN .................................................. 115

The network does not appear in the wireless networks list .................................................................... 115

The wireless network is not functioning ..................................................................................................... 115

Perform a wireless network diagnostic test ............................................................................................... 115

Reduce interference on a wireless network ............................................................................................... 116

Index ........................................................................................................................................................................................................... 117

ENWW vii

viii ENWW

1 Product overview

●

Product views

●

Product specications

●

Printer hardware setup and software installation

For more information:

The following information is correct at the time of publication. For current information, see www.hp.com/

support/colorljM452.

HP's all-inclusive help for the printer includes the following information:

● Install and congure

● Learn and use

● Solve problems

● Download software and rmware updates

● Join support forums

● Find warranty and regulatory information

ENWW 1

Product views

●

Printer front view

●

Printer back view

●

2-line control-panel view (M452nw and M452dn models)

●

Touchscreen control-panel view (M452dw model)

Printer front view

1 2-line control panel (nw and dn models)

2 Near eld communication (NFC) internal antenna (dw model only)

3 Walk-up USB port (for printing without a computer) (dw model only)

4 Touchscreen control panel (dw model) (tilts up for easier viewing)

5 Regulatory label (inside the front door)

6 Tray 2

7 Tray 1

8 Power on/o button

9 Front door (provides toner cartridge access)

10 Output bin extension

11 Output bin

2 Chapter 1 Product overview ENWW

Printer back view

1 Rear door (nw model only) (provides access for clearing jams)

2 Front door release button

3 Duplexer (dn and dw models only)

4 USB port for job storage

5 USB port for direct connection to a computer

6 Ethernet port

7 Power connection

ENWW Product views 3

2-line control-panel view (M452nw and M452dn models)

1 2-line control panel display This screen displays menus and printer information.

2 OK button Press the OK button for the following actions:

● Open the control-panel menus.

● Open a submenu displayed on the control-panel display.

● Select a menu item.

● Clear some errors.

● Begin a print job in response to a control-panel prompt (for example, when the

message Press [OK] to continue appears on the control-panel display).

Right arrow button

Cancel button

5 Wireless button (wireless models

only)

Back arrow button

Left arrow button

8 Ready LED The Ready light is on when the printer is ready to print. It blinks when the printer is

9 Attention LED The Attention light blinks when the printer requires user attention.

Use this button to navigate through the menus or to increase a value that appears on the display.

Press this button to cancel a print job or to exit the control panel menus.

Use this button to navigate the open the Wireless menu and wireless status information.

Use this button for the following actions:

● Exit the control-panel menus.

● Scroll back to a previous menu in a submenu list.

● Scroll back to a previous menu item in a submenu list (without saving changes to the

menu item).

Use this button to navigate through the menus or to decrease a value that appears on the display.

receiving print data, or when the printer is in sleep mode.

4 Chapter 1 Product overview ENWW

Touchscreen control-panel view (M452dw model)

1 Touchscreen The display provides access to menus, help animations, and printer information.

2 Home page screen indicator The display indicates which Home screen the control panel is currently displaying.

Help button

Home button

Back button

NOTE: While the control panel does not have a standard Cancel button, during many printer processes a Cancel

button appears on the touchscreen. This permits users to cancel a process before the printer completes it.

Touch this button to open the control-panel help system.

Touch this button to navigate to the Home screen.

Touch this button to return to the previous screen.

ENWW Product views 5

Home screen layout

1 2

The Home screen provides access to the printer features and indicates the current status of the printer.

Return to the Home screen at any time by touching the Home button on the printer control panel.

NOTE: The features that appear on the Home screen can vary, depending on the printer conguration.

1 Reset button Touch this button to reset any temporary job settings to the default printer settings.

2 Connection Information

button

Setup button

Apps button

Supplies button

6 USB button Touch this button to open the USB Flash Drive menu.

7 Printer status This screen area provides information about the overall printer status.

8 Jobs button Touch this button to open the stored jobs feature.

Touch this button to open the Connection Information menu, which provides network information.

The button appears as either a wired network icon or a wireless network icon , depending

on the type of network to which the printer is connected.

Touch this button to open the Setup menu.

Touch this button to open the Apps menu to print directly from select Web applications.

Touch this button to view information about supplies status.

6 Chapter 1 Product overview ENWW

How to use the touchscreen control panel

Use the following actions to use the printer touchscreen control panel.

Action Description Example

Touch Touch an item on the screen to select that

item or open that menu. Also, when scrolling through menus, briey touch the screen to stop the scrolling.

Swipe Touch the screen and then move the nger

horizontally to move the screen sideways.

Scroll Touch the screen, and then, without lifting

the nger, move the nger vertically to move the screen.

Touch the Setup button to open the

Setup menu.

Swipe the Home screen to access the Setup

button.

Scroll through the Setup menu.

ENWW Product views 7

Product specications

IMPORTANT: The following specications are correct at the time of publication, but they are subject to change.

For current information, see www.hp.com/support/colorljM452.

●

Technical specications

●

Supported operating systems

●

Mobile printing solutions

●

Printer dimensions

●

Power consumption, electrical specications, and acoustic emissions

●

Operating-environment range

Technical specications

Model name

Product number

Paper handling 50-sheet multipurpose input tray

(Tray 1)

Tray 2 (250-sheet capacity)

Automatic duplex printing Not available

Connectivity 10/100/1000 Ethernet LAN

connection with IPv4 and IPv6

Hi-Speed USB 2.0

Walk-up USB port Not available Not available

Print server for wireless network

connectivity

HP near eld communication (NFC)

and Wi-Fi Direct for printing from mobile devices

Control-panel display and input 2-line control panel Not available

Touchscreen control panel Not available Not available

Print Prints 27 pages per minute (ppm)

on A4 and 28 ppm on letter-size paper

M452nw

CF388A

Not available Not available

M452dn

CF389A

Not available

M452dw

CF394A

Walk-up USB printing (no computer

required)

Job storage and PIN-protected

printing

(Requires a 16 GB or greater USB thumb drive.)

Not available Not available

8 Chapter 1 Product overview ENWW

Supported operating systems

The following information applies to the printer-specic Windows PCL 6 and OS X print drivers.

Windows: The HP Software Installer installs the HP PCL.6, HP PCL-6, or HP PCL 6 driver depending on the Windows operating system along with optional software when using the full software installer. See the software installation notes for more information.

Mac computers and OS X: Mac computers and Apple mobile devices are supported with this printer. The OS X print driver and print utility are available for download from hp.com and may also be available via Apple Software Update. The HP installer software for OS X is not included in the in-box CD. Follow these steps to download the OS X installer software:

1. Go to www.hp.com/support/colorljM452.

2. Select Support Options, and then under Download Options select Drivers, Software & Firmware.

3. Click the operating system version, and then click the Download button.

Operating system Print driver installed Notes

Windows® XP SP3 or later, 32-bit The HP PCL.6 printer-specic print

driver is installed for this operating system as part of the basic software installation. The basic installer installs the driver and scan application only.

Windows Vista®, 32-bit The HP PCL.6 printer-specic print

driver is installed for this operating system as part of the basic software installation. The basic installer installs the driver only.

Windows Server 2003 SP2 or later, 32-bit

Windows 7 SP1 or later, 32-bit and 64-bit

Windows 8, 32-bit and 64-bit The HP PCL-6 printer-specic print

The HP PCL.6 printer-specic print driver is installed for this operating system as part of the basic software installation. The basic installer installs the driver only.

The HP PCL 6 printer-specic print driver is installed for this operating system as part of the full software installation.

driver is installed for this operating system as part of the basic software installation.

The full software installation is not supported for this operating system.

Microsoft retired mainstream support for Windows XP in April

2009. HP will continue to provide best-eort support for the discontinued XP operating system.

The full software installation is not supported for this operating system.

Use UPD drivers for 64-bit operating systems.

Microsoft retired mainstream support for Windows Server 2003 in July 2010. HP will continue to provide best-eort support for the discontinued Server 2003 operating system.

Windows 8 RT support is provided through Microsoft IN OS Version 4, 32-bit driver.

Windows 8.1, 32-bit and 64-bit The HP PCL-6 printer-specic print

driver is installed for this operating system.

Windows 10 The HP PCL-6 printer-specic print

driver is installed for this operating system.

Windows 8.1 RT support is provided through Microsoft IN OS Version 4, 32-bit driver.

ENWW Product specications 9

Operating system Print driver installed Notes

Windows Server 2008 SP2, 32bit

Windows Server 2008 SP2, 64bit

Windows Server 2008 R2, SP 1, 64-bit

Windows Server 2012, 64-bit The software installer does not

Windows Server 2012 R2, 64 bit The software installer does not

OS X 10.8 Mountain Lion, OS X

10.9 Mavericks, and OS X 10.10 Yosemite

The HP PCL.6 printer-specic print driver is installed for this operating system as part of the basic software installation.

The HP PCL 6 printer-specic print driver is installed for this operating system as part of the basic software installation.

support Windows Server 2012 but the HP PCL 6 and HP PCL-6 printer- specic print drivers do support it.

The OS X print driver and print utility are available for download from hp.com and may also be available via Apple Software Update. The HP installer software for OS X is not included in the in-box CD.

Download the HP PCL 6 or PCL-6 driver from the HP Web site

www.hp.com/support/colorljM452, and use the Windows Add

Printer tool to install it.

Download the HP PCL 6 or PCL-6 driver from the HP Web site

www.hp.com/support/colorljM452, and use the Windows Add

Printer tool to install it.

For OS X, download the full installer from the support Web site for this printer.

1. Go to www.hp.com/support/colorljM452.

2. Select Support Options, and then under Download

Options select Drivers, Software & Firmware.

NOTE: For a current list of supported operating systems, go to www.hp.com/support/colorljM452 for HP's all-

inclusive help for the printer.

NOTE: For details on client and server operating systems and for HP UPD PCL6, UPD PCL 5, and UPD PS driver

support for this printer, go to www.hp.com/go/upd and click the Specications tab.

Mobile printing solutions

The printer supports the following software for mobile printing:

● HP ePrint software

NOTE: The HP ePrint Software supports the following operating systems: Windows 7 SP 1 (32-bit and 64-

bit); Windows 8 (32-bit and 64-bit); Windows 8.1 (32-bit and 64-bit); Windows 10 (32-bit and 64-bit); and OS X versions 10.8 Mountain Lion, 10.9 Mavericks, and 10.10 Yosemite.

● HP ePrint via email (Requires HP Web Services to be enabled and the printer to be registered with

HP Connected)

● HP ePrint app (Available for Android, iOS, and Blackberry)

3. Click the operating system version, and then click the

Download button.

● ePrint Enterprise app (Supported on all printers with ePrint Enterprise Server Software)

10 Chapter 1 Product overview ENWW

● HP All-in-One Remote app for iOS and Android devices

● Google Cloud Print

● AirPrint

Android Printing

●

Printer dimensions

Figure 1-1 Dimensions for the M452nw model

Printer fully closed Printer fully open

1. Height 295.7 mm (11.64 in) 295.7 mm (11.64 in)

2. Depth 453 mm (17.83 in) 1025 mm (40.35 in)

3. Width 413.6 mm (16.28 in) 413.6 mm (16.28 in)

Weight (with cartridges) 17.5 kg (38.58 lb)

Figure 1-2 Dimensions for the M452dn and M452dw models

Printer fully closed Printer fully open

1. Height 295.7 mm (11.64 in) 295.7 mm (11.64 in) (dn model)

ENWW Product specications 11

339.6 mm (13.37 in) (dw model)

Printer fully closed Printer fully open

2. Depth 472.3 mm (18.59 in) 1124.4 mm (44.27 in)

3. Width 413.6 mm (16.28 in) 413.6 mm (16.28 in)

Weight (with cartridges) 18.9 kg (41.67 lb)

Figure 1-3 Dimensions for models with optional Tray 3

Printer fully closed Printer fully open

1. Height 427.7 mm (16.83 in) 427.7 mm (16.83 in) (nw and dn models)

471.6 mm (18.56 in) (dw model)

2. Depth 453 mm (17.83 in) (nw model)

472.3 mm (18.59 in) (dn and dw models)

3. Width 413.6 mm (16.28 in) 413.6 mm (16.28 in)

Weight (with cartridges) 22.7 kg (50.04 lb) (nw model)

24.1 kg (53.13 lb) (dn and dw models)

1025 mm (40.35 in) (nw model)

1124.4 mm (44.27 in) (dn and dw models)

Power consumption, electrical specications, and acoustic emissions

See www.hp.com/support/colorljM452 for current information.

CAUTION: Power requirements are based on the country/region where the printer is sold. Do not convert

operating voltages. This will damage the printer and void the printer warranty.

12 Chapter 1 Product overview ENWW

Operating-environment range

Table 1-1 Operating-environment specications

Environment Recommended Allowed

Temperature 15° to 27°C (59° to 80.6°F) 15° to 30°C (59° to 86°F)

Relative humidity 20% to 70% relative humidity (RH), non-

condensing

10% to 80% RH, non-condensing

ENWW Product specications 13

Printer hardware setup and software installation

For basic setup instructions, see the Setup Poster and Getting Started Guide that came with the printer. For additional instructions, go to HP support on the Web.

Go to www.hp.com/support/colorljM452 for HP's all-inclusive help for the printer. Find the following support:

● Install and congure

● Learn and use

●

Solve problems

● Download software and rmware updates

● Join support forums

● Find warranty and regulatory information

14 Chapter 1 Product overview ENWW

2 Paper trays

●

Load paper into Tray 1 (multipurpose tray)

●

Load paper into Tray 2

●

Load and print envelopes

For more information:

The following information is correct at the time of publication. For current information, see www.hp.com/

support/colorljM452.

HP's all-inclusive help for the printer includes the following information:

● Install and congure

● Learn and use

● Solve problems

● Download software and rmware updates

● Join support forums

● Find warranty and regulatory information

ENWW 15

Load paper into Tray 1 (multipurpose tray)

Introduction

Use Tray 1 to print single-page documents, documents that require multiple paper types, or envelopes.

●

Load paper into Tray 1 (multipurpose tray)

●

Tray 1 paper orientation

Load paper into Tray 1 (multipurpose tray)

1. Open Tray 1.

2. Press the tab on the right paper guide to move the

paper width guides outward, and then slide out the tray extension.

16 Chapter 2 Paper trays ENWW

3. Place the paper stack in the tray, and then adjust

the side guides so that they lightly touch the stack, but do not bend it. For information about how to orient the paper, see Tray 1 paper orientation

on page 18.

4. At the computer, begin the printing process from

the software application. Make sure that the driver is set to the correct paper type and size for the paper being printed from Tray 1.

ENWW Load paper into Tray 1 (multipurpose tray) 17

Tray 1 paper orientation

123

When using paper that requires a specic orientation, load it according to the information in the following table.

Paper type Output How to load paper

Letterhead or preprinted 1-sided printing Face-up

Top edge leading into the printer

Letterhead or preprinted 2-sided printing Face-down

Top edge away from the printer

Prepunched 1-sided printing or 2-sided printing Face-up

Holes toward the left side of the printer

18 Chapter 2 Paper trays ENWW

Load paper into Tray 2

Introduction

The following information describes how to load paper in Tray 2.

●

Load paper into Tray 2

●

Tray 2 paper orientation

Load paper into Tray 2

1. Open the tray.

2. Adjust the paper-width guides by squeezing the

adjustment latches on the guides and then sliding the guides to the size of the paper being used.

ENWW Load paper into Tray 2 19

3. To load legal-size paper, extend the tray front by

squeezing the front latch and pulling the front of the tray.

NOTE: When loaded with legal-size paper, Tray 2

extends from the front of the printer approximately 51 mm (2 in).

4. Load paper into the tray.

20 Chapter 2 Paper trays ENWW

+ 100 hidden pages
