PRO3000
Table of contents
Loading...
PRO3000
Toner and Probe
Users Guide
99 Washington Street
Melrose, MA 02176
Phone 781-665-1400
Toll Free 1-800-517-8431
TM
PN 2440799 (English) October 2005
©2005 Fluke Corporation. All rights reserved. Printed in China.
All product names are trademarks of their respective companies.
Visit us at www.TestEquipmentDepot.com
LIMITED WARRANTY AND LIMITATION OF LIABILITY
Fluke Networks guarantees this product to be free from defects
in material and workmanship for 18 months from the date of
purchase. Parts, accessories, product repairs and services are
warranted for 90 days, unless otherwise stated. Ni-Cad, Ni-MH
and Li-Ion batteries, cables or other peripherals are all
considered parts or accessories.
This warranty does not cover damage from accident, neglect,
misuse, alteration, contamination, or abnormal conditions of
operation or handling. Resellers are not authorized to extend
any other warranty on Fluke Networks’ behalf.
To obtain service during the warranty period, contact your
nearest Fluke Networks authorized service center to obtain
return authorization information, then send your defective
product to that Service Center with a description of the
problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER
WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR PURPOSE,
ARE EXPRESSED OR IMPLIED. FLUKE NETWORKS IS NOT LIABLE
FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR THEORY.
Since some states or countries do not allow the exclusion or
limitation of an implied warranty or of incidental or
consequential damages, this limitation of liability may not apply
to you.
4/04-18
Fluke Networks
PO Box 777
Everett, WA 98206-0777
USA
Contents
Title Page
Introduction ........................................................................................1
Safety Information.............................................................................1
Installing Batteries..............................................................................3
RO3000 Probe............................................................................3
The P
The PRO3000 Toner............................................................................4
Tracing Cables.....................................................................................6
Tracing Pairs ........................................................................................7
SmartTone Positive Identification....................................................8
Checking Polarity.............................................................................. 10
Checking Continuity......................................................................... 11
Using the RJ11 Modular Plug ......................................................... 11
In-House Communications (Talk Battery)...................................... 12
Replacement Parts and Accessories ............................................... 13
Registration....................................................................................... 14
Contacting Fluke Networks............................................................. 14
Specifications..................................................................................... 15
RO3000 Toner............................................................................ 15
P
RO3000 Probe............................................................................ 16
P
i
PRO3000 Toner and Probe Users Guide
ii
Introduction
The PRO3000 Toner and PRO3000 Probe helps you identify cables,
wires, and wire pairs. You connect the P
trace and follow the signal with the P
RO3000 Toner to a line, then
RO3000 Probe.
Safety Information
The following IEC symbols are used either on the test set or in the
manual:
Warning: Risk of personal injury. See the manual for details.
W
Caution: Risk of damage or destruction to equipment or
software. See the manual for details.
Warning: Risk of electric shock.
X
Earth ground
.
Conformité Européenne. Conforms to relevant European
P
Union directives.
CAN/CSA-C22.2 No. 60950-1-03
)
CAN/CSA-C22.2 No. 1010.1-92 + CSA-C22.2 No. 1010.1B-97,
UL/ANSI 3111-1
Do not put circuit boards in the garbage. Dispose of circuit
~
boards in accordance with local regulations.
WXWarning
This product is certified for indoor use only.
To avoid electrical shock, do not use the toner or probe if
they are wet. If they get wet, let them dry for 24 hours
before use.
1
PRO3000 Toner and Probe Users Guide
WXWarning
When connecting to metallic network wires, handle
alligator clips by the insulated boot.
The maximum voltage allowed across the test leads is 60
Vdc in toner and polarity modes. Do not connect to
circuits carrying AC voltage in toner or polarity mode. Do
not connect to circuits carrying AC or DC voltage in
continuity mode.
Disconnect clips from any metallic connections before
performing any maintenance. Read all instructions
completely and understand possible hazards to the end
user if maintenance is not performed by authorized
service personnel.
Do not use the toner or probe if they are damaged.
Before you use the toner or probe, inspect the case. Look
for cracks or missing plastic. Pay particular attention to
the insulation surrounding the connectors.
If this product is used in a manner not specified by the
manufacturer, the protection provided by the product
may be impaired.
2
Loading...
