IMPORTANT SAFETY INSTRUCTIONS
Your Elna 6200 sewing machine is designed and constructed for HOUSEHOLD use only. Read all instructions before using this machine.
DANGER– To reduce the risk of electric shock:
1.Your sewing machine should never be left unattended when plugged in. Always unplug the machine from the electrical outlet immediately after using and before cleaning.
2.Always unplug before replacing light bulb. Replace bulb with same type rated 12 Volts, 5 watts.
3.Do not reach for the machine if it has fallen into water. Unplug immediately.
4.Do not place or store machine where it can fall or be pulled into a tub or sink. Do not place it in or drop it into water or other liquid.
WARNING– To reduce the risk of burns, fire, electrical shock or injury:
1.Do not allow machine to be used as a toy. Supervision is necessary when this machine is used by or near children.
2.Use this sewing machine only for its intended use as described in this manual. Only use attachments recommended by the manufacturer as described in this manual.
3.Never operate this machine if it has a damaged cord or plug, is not working properly, has been dropped or damaged or dropped into water. Return the machine to the nearest authorized dealer or service center for examination, repair, electrical or mechanical adjustment.
4.This machine is equipped with a special connection cord which, if damaged, must be replaced by an identical cord. This can be obtained from your dealer.
5.Never operate the sewing machine with any air opening blocked. Keep ventilation openings of the sewing machine and foot control free from the accumulation of lint, dust and fibers.
6.Never drop or insert any object into any opening.
7.Do not use outdoors.
8.Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
9.To disconnect, turn machine off and remove plug from outlet.
10.Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
11.Keep fingers away from all moving parts, especially the needle.
12.Always use the proper needle plate. The wrong plate can cause the needle to break.
13.Do not use bent needles.
14.Do not pull or push fabric while stitching. This may deflect the needle causing it to break.
15.Switch the sewing machine off when making any adjustment in the needle area, such as threading needle, changing needle, threading bobbin, changing presser foot, etc.
16.Always unplug the sewing machine from the electrical outlet when removing covers, lubricating or making any other servicing adjustments mentioned in the instruction manual.
SAVE THESE INSTRUCTIONS
IMPORTANT
Be sure to keep machine away from static electricity, heat sources, humidity and direct sunlight.
USA only
Your machine comes equipped with a polarized plug (one prong wider than the other). A polarized plug reduces the risk of electrical shock. This plug is intended to fit into a polarized outlet. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not modify the plug in any way.
Use only foot control model 21371 for sewing machine model 6200 (UL, CSA).
1
TABLE OF CONTENTS
SECTION I – Machine Parts and Functions
Part Names .................................................... |
3 |
Standard Accessories .................................... |
4 |
Presser Foot and Accessory Definitions.... |
5-6 |
Extension Table and Free Arm ...................... |
6 |
Circular Sewing Pivot Points ......................... |
7 |
Using the Fine Adjustment Screw.................. |
7 |
How to Drop the Feed Dog ............................ |
7 |
Foot Pressure Dial ......................................... |
8 |
Presser Foot Lever and Additional |
|
Presser Foot Clearance ........................... |
8 |
Attaching and Removing Presser Feet .......... |
8 |
Attaching and Removing Shank .................... |
9 |
Seam Allowance Lines................................... |
9 |
Controlling Sewing Speed ............................. |
9 |
Adjusting Needle Thread Tension ................ |
10 |
SECTION II – Getting Ready to Sew |
|
Connecting Machine to Power Supply......... |
11 |
Selecting the Correct Needle and Thread ...12 |
|
Changing Needles ....................................... |
12 |
Needle Definitions........................................ |
13 |
Keys and LED Readout ......................... |
14-16 |
Winding a Bobbin................................... |
17-18 |
Additional Spool Pin..................................... |
18 |
Inserting the Bobbin ..................................... |
19 |
Threading the Machine ................................ |
20 |
Built-in Needle Threader .............................. |
21 |
Drawing Up the Bobbin Thread ................... |
22 |
SECTION III – Basic Sewing |
|
Example of How to Read the Machine |
|
Set-up Information .................................. |
23 |
Straight Stitch .............................................. |
23 |
Starting to Sew ............................................ |
23 |
Finishing Off a Seam ................................... |
24 |
Cutting the Threads ..................................... |
24 |
Changing Sewing Direction ......................... |
24 |
Sewing Over Seams and on Heavy |
|
Fabrics ................................................... |
25 |
Gathering ..................................................... |
25 |
Zipper Insertion ...................................... |
26-27 |
Rolled Hem .................................................. |
28 |
Twin Needle Sewing .................................... |
29 |
Twin Needle Hem ........................................ |
29 |
Zigzag Stitch ................................................ |
30 |
Overcasting .................................................. |
30 |
How to Sew on a Button .............................. |
31 |
3-Step Zigzag............................................... |
32 |
Mending a Tear ............................................ |
32 |
Apply 7 mm (1/4") Elastic ............................ |
32 |
Blind Hem Stitches ...................................... |
33 |
Shell Tuck .................................................... |
34 |
Triple Seam.................................................. |
34 |
Stretch Seam ............................................... |
34 |
Super Stretch Stitch ..................................... |
35 |
Double Overlock Stitch ................................ |
35 |
Buttonhole Variations ............................. |
36-39 |
Corded Buttonhole ....................................... |
40 |
Super Overlock Stitch .................................. |
41 |
SECTION IV – Decorative Sewing |
|
Single Design – Auto-Lock Key ................... |
41 |
Complete Design – Auto-Lock Key .............. |
41 |
Combining Designs...................................... |
42 |
Corded Trim ................................................. |
42 |
Single Cord For Gathering Heavy Fabric |
....42 |
Satin Stitch Appliqué .................................... |
43 |
Scallop Edges .............................................. |
43 |
Circle Sewing ............................................... |
43 |
Large Scallop Border ................................... |
44 |
Twin Needle Decorative Designs................. |
44 |
SECTION V – Heirloom |
|
Pintucks ....................................................... |
45 |
Whip and Roll Hem ...................................... |
45 |
Bridging (Fagoting) ...................................... |
46 |
Hemstitches ................................................. |
46 |
Fringing ........................................................ |
47 |
Drawn Work ................................................. |
47 |
Smocking ..................................................... |
48 |
SECTION VI – Quilting |
|
Piecing Fabrics Together ............................. |
49 |
Quilt Guide ................................................... |
49 |
Patchwork .................................................... |
50 |
Quilt Stitch.................................................... |
50 |
Buttonhole Appliqué ..................................... |
51 |
SECTION VII – Taking Care of Your |
|
Machine |
|
Cleaning the Bobbin Area ............................ |
52 |
Cleaning the Hook Area and |
|
Feed Dog .......................................... |
52-53 |
Replacing the Bobbin Case ......................... |
53 |
Changing the Light Bulb .............................. |
53 |
STITCH CHART........................................... |
54 |
OPTIONAL ACCESSORIES ........................ |
55 |
TROUBLESHOOTING ................................. |
56 |
INDEX .................................................... |
57-58 |
NOTE: Information found in this instruction |
|
manual is current at the time of printing. Elna |
|
reserves the right to change and update |
|
specifications and information as needed. |
2
|
|
|
|
SECTION I |
|
|
|
|
|
Machine Parts and Functions |
|
|
|
|
|
Part Names |
|
|
|
|
|
1. |
Top cover (lift up and back) |
|
1 |
|
|
2. |
Stitch chart |
|
2 |
|
3. |
Top storage compartment |
|
|
|
|
|||
24 |
25 |
|
3 |
4. |
Bobbin winder spindle |
|
5. |
Bobbin winder stop |
|||
|
|
||||
|
|
|
4 |
6. |
Selection keys |
|
|
|
7. |
LED readout |
|
|
|
|
|
||
|
|
|
5 |
8. |
Side storage compartment |
|
|
|
9. |
Stitch length key |
|
|
|
|
|
||
23 |
|
|
6 |
10. |
Stitch width key |
|
|
11. |
Speed control lever |
||
|
|
|
|||
|
|
|
7 |
12. |
Up/down needle key |
|
|
|
13. |
Auto-lock key |
|
22 |
|
|
|
||
|
|
8 |
14. |
Reverse key |
|
|
|
|
|||
|
|
|
15. |
Bobbin cover plate release button |
|
|
|
|
|
||
21 |
|
|
|
16. |
Bobbin cover plate |
20 |
|
|
|
17. |
Extension table (storage box) |
|
|
|
18. |
Needle plate |
|
|
|
|
|
||
|
|
|
|
19. |
Circular sewing pivot points |
|
|
|
9 |
20. |
Needle threader |
19 |
|
|
10 |
21. |
Thread cutter |
|
|
22. |
Face plate |
||
|
|
|
11 |
23. |
Foot pressure dial |
|
|
|
|
||
18 |
|
|
12 |
24. |
Needle thread tension dial |
|
|
|
13 |
25. |
Spool pin |
|
16 15 |
|
26. |
Needle clamp screw |
|
|
|
14 |
|||
17 |
|
27. |
Needle |
||
|
|
|
|
28. |
Presser foot |
|
26 |
|
|
29. |
Shank |
|
|
|
30. |
Thumbscrew |
|
|
|
|
|
||
|
|
|
|
31. |
Carrying handle |
|
27 |
|
|
32. |
Presser foot lever |
|
|
|
|
33. |
Buttonhole lever |
|
|
|
|
34. |
Free arm |
|
28 |
|
|
35. |
Feed dog lever |
|
|
|
36. |
Machine sockets |
|
30 |
|
|
|
||
31 |
|
|
37. |
Power switch |
|
29 |
|
|
|
38. |
Flywheel (always turn towards you) |
|
|
|
32 |
|
|
38 |
|
|
33 |
|
|
|
|
|
34 |
|
|
37 |
35 |
|
36
3
2 3
1
13
12
11 |
A C |
D |
10 |
E |
F |
|
R |
H |
|
G |
|
9 |
|
|
14 15
17 18
20
4
5
6
7
8
16
19
Standard Accessories
Top Cover
(Lift up and back)
1.Seam ripper
2.Set of needles
3.Quilt guide
4.Bobbins (4 + 1 in machine = 5 total)
Side Cover
(Pull down Side Cover to open)
5.D: Hemmer foot
6.E: Zipper foot
7.F: Satin stitch foot
8.H: Multi-cord foot
9.G: Blind hem foot
10.R: Automatic buttonhole foot
11.C: Overlock foot
12.Circular sewing pivot pin
13.A: Standard metal foot (attached to machine)
Storage compartments can be tilted forward for easy access.
Extension Table (Storage Box)
Accessories are stored inside the extension table. Pull lid towards you to open the storage box.
14.Large screwdriver
15.Lint brush
16.Large spool holder
17.Small spool holder
18.Additional spool pin
19.Spool pin felt
20.Spool stand
4
Machine Box
21 |
22 |
23 |
21. Instruction book
22. Power supply cord
23. Foot control
24. Carrying bag
24
Presser Foot and Accessory Definitions
A: Standard Metal Foot
A |
This foot comes attached to your machine. It is mainly |
|
|
||
|
used for straight stitches and zigzag stitches longer than |
|
|
1.0. The button locks the foot in a horizontal position |
|
|
helping to sew over multiple layered seams. |
|
|
C: Overlock Foot |
|
C |
Prevent fabric edges from raveling by finishing the edge |
|
|
with a zigzag stitch. The wires/brush on the foot help the |
|
|
stitch lie flatter and reduce puckering. Use with medium |
|
|
weight fabrics. |
|
|
D: Hemmer Foot |
|
D |
Insert the fabric into the spiral on this foot. The spiral |
|
rolls the fabric, creating a rolled hem. An easy, |
||
|
||
|
professional way to sew hems. |
|
|
E: Zipper Foot |
|
|
Use when sewing zippers into place. The grooves on the |
|
E |
underside ensure the foot glides over the zipper coil. |
|
Attach either to the left or right of the needle to sew each |
||
|
||
|
side of the zipper. |
|
|
F: Satin Stitch Foot |
|
F |
The cutout on the underside of the foot is designed to |
|
accommodate dense stitch formation. Ideal when sewing |
||
|
satin and decorative stitches. |
5
G |
G: Blind Hem Foot |
The guide on the foot helps ensure that the needle |
|
|
catches only one or two fibers of the hem, resulting in an |
|
invisible hemline. |
H |
H: Multi-Cord Foot |
|
Design your own braids or trims. Place one to three |
|
cords in the foot and sew over cord(s) for a simple |
|
couching method. Or sew over one cord with a zigzag to |
|
gather heavier weight fabrics. |
R |
|
|
R: Automatic Buttonhole Foot |
|
Place button in foot to determine the buttonhole size. The |
|
machine will automatically sew the corresponding |
|
buttonhole. |
|
Circular Sewing Pivot Pin |
|
The free arm has holes that are 1 cm apart from each |
|
other. Use this pivot pin to secure the fabric and sew |
|
perfect curves or circles or large scallops. |
|
Quilt Guide |
|
The quilt guide is helpful when sewing parallel, evenly |
|
spaced rows of stitching. |
|
Extension Table and Free Arm |
|
Extension Table |
|
The extension table provides more sewing space to |
|
make sewing easier. The extension table can be easily |
|
removed for free arm sewing. |
|
To Remove: |
|
Pull the end of the extension table away from the |
|
machine, as shown. |
|
To Attach: |
|
Push the table back into place to reattach the extension |
|
table. |
|
Free Arm |
|
Free arm sewing is good for circle areas like sleeves, |
|
waistbands and pant legs. If socks, knee or elbow areas |
|
need mending, the free arm will be best to use. |
6
|
|
Circular Sewing Pivot Points |
q |
|
The free arm has holes q that are 1 cm apart from each |
|
||
|
|
other. Use the holes to sew circles and scallops with the |
|
|
circular sewing pivot pin. See pages 43-44. |
|
|
|
Using the Fine Adjustment Screw
Choice of fabrics and threads may affect the stitch formation. The fine adjustment screw can be used to either lengthen or shorten the stitch.
|
|
q |
Fine adjustment screw |
|
|
w |
Standard mark |
|
q |
e Setting mark |
|
|
|
|
|
|
|
To fine tune, use a screwdriver to move the setting mark. |
|
|
|
• |
If stitches are too short r, correct by turning the |
|
|
|
screw in the direction of “+”. |
w |
|
• |
If the stitches are too long t, correct by turning the |
|
e |
|
screw in the direction of “–”. |
|
|
|
|
r |
t |
|
|
(+)(–)
How To Drop the Feed Dog
|
|
The feed dog can be dropped out of position for special |
|
w |
q |
sewing techniques: free motion embroidery, stippling, |
|
button sewing, etc. |
|||
|
|
||
|
|
The feed dog must always be up for regular sewing. |
|
|
|
Locate the feed dog lever on the back of the free arm. |
|
|
|
Slide the lever either to the right (down) q or to the left |
|
|
|
(up) w. To bring up the feed dog, hand turn the flywheel |
|
|
|
after sliding lever to the left. |
7
|
Foot Pressure Dial |
q |
Align the foot pressure dial q with the setting mark w at |
“3” for regular sewing. |
|
w |
Reduce the pressure to “2” for appliqué, cutwork, drawn |
|
work, basting and embroidery. |
|
Velours and knits with a lot of stretch may require a “1” |
|
setting. |
Presser Foot Lever and Additional Presser Foot
Clearance
Before sewing can occur, the presser foot must be lowered to close the tension discs.
Raise and lower the foot with this lever q.
You can raise the presser foot about 6.5 mm (1/4˝) higher than the normal up position for easy removal of the presser foot or to place heavy fabrics under the presser foot. Pull the presser foot lever up beyond the normal up
position.
q
|
|
Attaching and Removing Presser Feet |
|
|
|
Press the “Up/Down Needle” key until the needle is in |
|
|
|
the raised position. |
|
|
|
Turn OFF the power switch. Raise the presser foot and |
|
|
e |
press the red button q on back of the shank. The |
|
w |
presser foot will drop off. Place the selected presser foot |
||
|
|||
q |
|
so the pin e on the foot lies just under the groove w of |
|
|
the shank. Lower the presser bar and attach the foot. |
||
|
|
8
|
Attaching and Removing Shank |
|
q |
Turn OFF the power switch. Raise the presser bar. Turn |
|
the thumbscrew q counterclockwise with the screwdriver |
||
|
||
|
to remove the shank. |
|
|
To attach, match the hole in the shank w with the hole in |
|
|
the presser bar e. Put thumbscrew in hole and turn |
|
|
clockwise to tighten. |
w
e
Seam Allowance Lines
qThe lines on the needle plate, machine bed and bobbin
w |
cover plate help you measure seam width. The number |
|
indicates the distance between the center needle |
|
position (3.5) and the seam allowance line. |
|
q Center needle position |
|
w Edge of fabric |
|
e Guidelines |
|
r 90º pivot angle guideline for 5/8˝ |
e
r
Controlling Sewing Speed
Sewing speed can be varied with the foot control. The harder you press on the foot control, the faster the machine runs.
The maximum sewing speed can be varied by sliding the speed control lever. For a faster speed, slide it to the right; for a slower speed, slide it to the left.
9
Adjusting the Needle Thread Tension
Choosing the Correct Tension — Straight Stitch
q |
|
|
|
|
|
|
|
|
|
|
|
The ideal straight stitch will have threads locked between |
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
the two layers of fabric, as shown left (magnified to show |
|
|
|
|
|
|
|
|
|
|
|
|
detail). Needle thread tension can range from 3 – 5 and |
|
|
|
|
|
|
|
|
|
|
|
|
is normally set on 4. Align the 4 on the dial with the |
|
|
|
|
|
|
|
|
|
|
|
|
setting mark q. |
|
If you look at the needle thread w (top thread) and |
|
w |
bobbin thread e (bottom thread), you will notice that |
|
|
there are no gaps. Each stitch is smooth and even. |
|
|
Occasionally the needle thread tension needs to be |
|
|
adjusted to a manual setting. Examples: |
|
e |
• |
stiff or heavy fabric |
|
• sewing more than two layers of fabric |
|
|
• |
type of stitch |
|
• |
thread |
When adjusting needle thread tension, the higher numbers tighten, the lower numbers loosen.
Tension is too tight
The bobbin thread shows through on the topside of the fabric and it will feel bumpy.
Turn the dial to a lower number to loosen the needle thread tension.
Tension is too loose
The needle thread shows through on the underside of the fabric and it will feel bumpy.
Turn the dial to a higher number to tighten the needle thread tension.
Adjusting Tension for Zigzag and Satin Stitches
The upper thread tension should be slightly looser when sewing a zigzag or a satin stitch. The upper thread should appear slightly on the underside of the fabric.
10
SECTION II
qGetting Ready to Sew
Connecting Machine To Power Supply
Before connecting the power cord, make sure the voltage and frequency shown on the machine are identical to your electrical power.
e
|
To connect machine to power supply, turn off the power |
|
switch q. Insert the foot control plug w and machine |
|
plug e into the machine and the power supply plug r |
w |
into the wall socket. |
|
|
|
Your machine may come equipped with a polarized plug |
|
(one prong wider than the other). A polarized plug |
|
reduces the risk of electrical shock. This plug is intended |
|
to fit into a polarized outlet. If the plug does not fit fully |
|
into the outlet, reverse the plug. If it still does not fit, |
|
contact a qualified electrician to install the proper outlet. |
rDo not modify the plug in any way.
IMPORTANT: When using your sewing machine the first few times, place waste fabric under the presser foot and run the machine without thread for a few minutes. Wipe away excess oil.
NOTE: After turning off the machine, wait 5 seconds before turning it on again.
For Your Safety
Do not use extension cords or plug adapters. Do not touch plug with wet hands.
Always turn off the power/light switch first and then unplug from the electrical outlet. Examples:
•when leaving the machine unattended
•when cleaning the machine
Always turn off the power/light switch:
•when attaching or removing parts such as needle, presser foot, needle plate
•when threading needle or bobbin
Do not place anything on the foot control.
Do not place heavy items on cords. Do not subject cords to heat. Do not use damaged cords. Have the cord repaired immediately.
While the machine is in operation, always keep your eye on the sewing area and do not touch any moving parts such as the thread take-up lever, flywheel or needle.
11
Weight |
Fabric |
Needle Type |
Needle |
|
|
|
|
Size |
|
Very |
Chiffon, Fine Lace, |
Universal |
9 (65) |
|
Light |
Organdy |
Ball Point |
9 (65) |
|
Light |
Batiste, Lawn, Crepe |
Stretch |
11 |
(75) |
|
de Chine, Challis, |
|
|
|
|
Handkerchief Linen, |
|
|
|
|
Crepe, Taffeta, Satin |
Universal |
11 |
(75) |
|
|
|
12 |
(80) |
|
Single Knits, Jersey, |
Stretch |
11 |
(75) |
|
Swimwear, Tricot |
Ball Point |
11 |
(75) |
|
Leather, Suede |
Leather |
11(75) |
|
Medium |
Flannel, Velour, Velvet, |
Universal |
14 |
(90) |
|
Velveteen, Corduroy, |
|
|
|
|
Linen, Gabardine, |
|
|
|
|
Wool, Terry, Burlap |
|
|
|
|
Double Knits, Stretch |
Ball Point |
14 |
(90) |
|
Velour, Stretch Terry, |
|
|
|
|
Sweater Knits |
|
|
|
|
Leather, Vinyl, Suede |
Leather |
14 |
(90) |
Heavy |
Denim, Sailcloth, |
Denim |
16 |
(100) |
|
Ticking |
|
|
|
|
Coating, Polar Fleece, |
Universal |
16 |
(100) |
|
Drapery, and |
|
|
|
|
Upholstery Fabrics |
|
|
|
|
Leather, Suede |
Leather |
16 |
(100) |
Very |
Canvas, Duck, |
Universal |
18 |
(110) |
Heavy |
Upholstery Fabrics |
|
|
|
|
Topstitching for |
Topstitching |
11 |
(75) |
|
Special Finish |
|
14 |
(90) |
|
|
|
|
|
Selecting the Correct Needle and Thread
There are many kinds of fabrics, threads and needles. It is important to use the correct ones together.
Always purchase good quality thread. It should be strong, smooth and even in thickness. Use the same thread for needle and bobbin. Always test thread and needle size on a scrap piece of fabric.
In general, fine threads (the larger the number, the finer the thread) and needles (the smaller the number, the finer the needle) are used for sewing lightweight fabrics and heavier threads and larger needles are used for sewing heavyweight fabrics. There are many specialty needles available from your sewing machine dealer.
Check your needles frequently for rough or blunt tips.
Snags and runs in knits, fine silks and silk-like fabrics are permanent and are often caused by damaged needles.
NOTE: A universal needle size 14/90 comes inserted in your machine.
1. |
2. |
Changing Needles |
|
||
q |
|
1. Turn ON the power switch. Press the “Up/Down |
|
Needle” key to raise the needle. Lower the presser |
|
|
|
|
|
|
foot. Turn OFF the power switch. Turn the needle |
|
|
clamp screw q counterclockwise to loosen. Remove |
|
|
the needle from the clamp. |
w |
|
2. Insert the new needle into needle clamp with the flat |
|
|
side to the back, pushing it up as far as it will go w. |
|
|
Tighten the clamp screw firmly. |
3. To determine if the needle is defective, place the flat
3. side of the needle on something flat (a needle plate, piece of glass, etc.). The gap between the needle and the flat surface should be consistent.
Never use a bent or blunt needle, as it may cause skipped stitches or thread breakage. Defective needles can ruin the fabric. Always purchase good quality needles. Change needles often.
12
Needle Definitions
The illustration identifies the main parts of a sewing machine needle.
q
|
q Body |
|
|
w Shaft |
|
|
e Long groove (round side of needle) |
|
|
r Short groove (flat side of needle) |
|
|
t Eye |
|
|
y Point |
|
w |
|
|
|
Universal – an all-purpose needle that handles most |
|
|
woven and knit fabrics. |
|
|
Ball point – the point spreads the fibers, preventing tears |
|
e |
and is especially suited for loose knits and interlock knits. |
|
|
Not recommended for embroidery. |
|
|
Stretch – specially designed to prevent skipped stitches |
|
r |
in synthetic suedes and elasticized knits (swimwear). |
|
|
||
t |
Denim – the sharp point effectively pierces densely |
|
woven fabrics such as denim and canvas. |
||
|
||
|
Topstitching – the extra sharp point penetrates layers of |
|
y |
fabrics; extra large eye and large groove accommodate |
|
|
heavyweight topstitching thread. |
|
|
Metallic – the large grooved shaft helps prevent delicate |
|
|
metallic threads from shredding. Another plus, a larger |
|
|
than average eye makes for easier threading. |
|
|
Self-Threading – the needle eye has a slit opening on |
|
|
the side to allow the thread to be easily inserted. |
|
|
Leather – the cutting point creates small holes in leather |
|
|
and suede. Holes remain after stitching is removed. |
|
|
Quilt – the tapered point easily penetrates through |
|
|
multiple layers and crossed seams. |
|
|
Wing/Hemstitch – wide flat edges (wings) extend |
|
|
outwards near the eye; they separate fibers and create |
|
|
holes for beautiful heirloom stitches. |
|
|
Twin/Double – 2 needles are joined on a crossbar and |
|
|
share a single shaft. Sews two parallel rows of stitching. |
|
|
Available in universal and ballpoint. |
13
|
|
Keys and LED Readout |
|
|
Turn ON the power switch. (Test |
t y |
u |
lights run in LED readout.) |
q
w r e
q Up/Down Needle Key
If the needle is up when you press this key, the
q needle will go down to its lowest position. The needle will continue to stop in the down position.
If the needle is down when you press this key, the needle will go up to its highest position. The needle will continue to stop in the up position.
w Auto-Lock Key
Press this key while sewing 01 (straight stitch), 02 w (zigzag stitch) or 03 (3-step zigzag stitch) and the machine will sew a few stitches in place and stop
automatically.
*Press this key while sewing utility or decorative stitches and the machine will complete the stitch, lockstitch and stop.
e Reverse Key
If you are sewing 01 (straight stitch), 02 (zigzag e stitch) or 03 (3-step zigzag stitch), press and hold
this key. The machine will sew in reverse until you release the key.
* If you are sewing any other stitches, utility or decorative, the machine will immediately stop and sew a lockstitch when you press this key.
14
r Indicator Lights and LED Readout
a
a When this light is lit, the readout displays the selected stitch.
b When this light is lit, the readout displays the selected stitch width/needle position.
b |
c When this light is lit, the readout displays the |
|
selected stitch length. |
||
|
c
t Stitch Width and Needle Position Key
Press this key to display pre-programmed stitch width or needle position.
To decrease stitch width or move needle position to the left, press “–” side of key.
a |
b |
c |
To increase stitch width or move needle position to the right, press “+” side of key.
Stitches 01, 07 and 23 allow you to move from center needle position (3.5) to left (0.0) or right (7.0). There are 15 needle positions.
a Left position b Center position c Right position
0.0 |
3.5 |
7.0 |
15
a b c
1.0 2.2 5.0
a b c d
y Stitch Length Key
Press this key to display pre-programmed stitch length.
Depending on the stitch selected, stitch length can be set between 0.0 and 5.0.
To decrease length, press “–” side of key.
To increase stitch length, press “+” side of key.
a 1.0 Stitch length b 2.2 Stitch length c 5.0 Stitch length
NOTE: Fine fabrics should have a stitch length between 1.5 and 2.4, medium fabrics between 2.0 and 3.0 and heavier fabrics between 3.0 and 4.0.
u Stitch Selection Keys
aPress this “–” key to change digit in the LED readout 10’s column between 0 and 5. Example: If the readout is 01 and this key is pressed, the readout will change to 51.
bPress this “+” key to change digit in the LED readout 10’s column between 0 and 5. Example: If the readout is 01 and this key is pressed, the readout will change to 11.
cPress this “–” key to change digit in the LED readout 1’s column between 0 and 9. Example: If the readout is 01 and this key is pressed, the readout will change to 60.
dPress this “+” key to change digit in the LED readout 1’s column between 0 and 9. Example: If the readout is 01 and this key is pressed, the readout will change to 02.
16
|
Winding a Bobbin |
|
q |
To remove bobbin, slide bobbin cover plate release |
|
button q to the right and lift away the bobbin cover |
||
|
||
|
plate w. |
|
|
Lift out the bobbin e. |
|
|
Turn ON the power switch. |
|
|
e |
w
q Lift up the spool pin. Place the spool of thread on the
q |
|
spool pin with the thread coming off the spool as |
|
|
|
|
|
shown. Attach the spool holder and press it firmly |
|
|
against the spool of thread. |
|
|
NOTE: Spool holder needs to be changed according to |
|
A |
the type of thread spool. |
|
|
|
|
|
A. Large spool |
|
|
B. Small spool |
B
|
|
w Pull the thread towards the thread guides, under the |
w |
e |
hook and wrap it around the guide as shown. |
|
r |
e Pull the thread back around the bobbin winder thread |
|
|
guide. |
|
|
r Pass the thread through the hole in the bobbin from |
|
|
inside to the outside. Place the bobbin on the bobbin |
|
|
winder spindle. |
q
17
