OWNER’S MANUAL

MANUEL DU PROPRIÉTAIRE

MANUAL DEL PROPIETARIO





























































BEVERAGE CENTER

1 - 8

















































Owner’s Manual...............................





























CENTRE DE BREUVAGES





MODEL • MODÈLE • MODELO























Manuel du propriétaire...................

9 - 16



DWC032A2BDB











DWC036A2BDB-6





CENTRO DE BEBIDAS

17 - 24

















Manual del propietario.................





































www.Danby.com

DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9





DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840

2019.03.25

Welcome

Welcome to the Danby family. We are proud of our quality products and we believe in dependable service. We suggest that you read this owner’s manual before plugging in your new appliance as it contains important operation information, safety information, troubleshooting and maintenance tips to ensure the reliability and longevity of your appliance.

Visit www.Danby.com to access self service tools, FAQs and much more. For additional assistance call 1-800-263-2629.

Note the information below; you will need this information to obtain service under warranty.

You must provide the original purchase receipt to validate your warranty and receive service.

Model Number: _________________________________________________

Serial Number: _________________________________________________

Date of Purchase: _______________________________________________

Need Help?

Before you call for service, here are a few things you can do to help us serve you better.

Read this owner’s manual:

It contains instructions to help you use and maintain your appliance properly.

If you receive a damaged appliance:

Immediately contact the retailer or builder that sold you the appliance.

Save time and money:

Check the troubleshooting section at the end of this manual before calling. This section will help you solve common problems that may occur.

1-800-26- Danby (1-800-263-2629)

1

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

SAFETY REQUIREMENTS

SAFETY REQUIREMENTS

DANGER: Risk of fire or explosion. Flammable refrigerant used. Do not puncture refrigerant tubing.

Do not use mechanical devices to defrost refrigerator.

Ensure that servicing is done by factory authorized service personnel, to minimize product damage or safety issues.

If the power supply cord is damaged, it must be replaced by the manufacturer, its service agent or similar qualified person in order to avoid hazard.

Consult repair manual or owner’s guide before attempting to service this product. All safety precautions must be followed.

Dispose of properly in accordance with federal or local regulations.

Follow handling instructions carefully.

Do not store explosive substances such as aerosol cans with a fl ammable propellant in this appliance.

WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

CAUTION: Children should be supervised to ensure that they do not play with the appliance.

DANGER: Risk of child entrapment. Before throwing away an old appliance:

Remove the door or lid.

Leave shelves in place so that children may not easily climb inside.

DANGER: Do not add a lock to the door or lid. This can cause child entrapment and harm.

This appliance is not intended for use by persons (including children) whose physical, sensory or mental capabilities may be different or reduced, or who lack experience or knowledge, unless such persons receive supervision or training to operate the appliance by a person responsible for their safety.

This appliance is intended to be used in household and similar applications such as:

Staff kitchen areas in shops, offices and other working environments;

Farm houses and by clients in hotels, motels and other residential type environments;

Bed and breakfast type environments;

Catering and similar non-retail applications.

GROUNDING INSTRUCTIONS

This appliance must be grounded. Grounding reduces the risk of electrical shock by providing an escape wire for the electrical current.

This appliance has a cord that has a grounding wire with a 3-prong plug. The power cord must be plugged into an outlet that is properly grounded. If the outlet is a 2-prong wall outlet, it must be replaced with a properly grounded 3-prong wall outlet. The serial rating plate indicates the voltage and frequency the appliance is designed for.

WARNING - Improper use of the grounding plug can result in a risk of electric shock. Consult a qualified electrician or service agent if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded.

Do not connect your appliance to extension cords or together with another appliance in the same wall outlet. Do not splice the power cord. Do not under any circumstances cut or remove the third ground prong from the power cord. Do not use extension cords or ungrounded (two prongs) adapters.

SAVE THESE INSTRUCTIONS!

2

INSTALLATION INSTRUCTIONS



OPERATING INSTRUCTIONS

LOCATION



FEATURES

Two people should be used when moving the appliance.

Remove interior and exterior packaging prior to installation. Wipe the outside of the appliance with a soft, dry cloth and the inside with a lukewarm wet cloth.

1.Thermostat Dial: (Externally mounted rear wall thermostat) For controlling the temperature inside the beverage center; the compressor activates as soon as the temperature rises above the desired level.

2.Tempered Glass Door: Tinted for UV protection while still allowing for easy interior viewing.

Place the appliance on a fl oor that is strong

enough to support it when it is fully loaded. 3. Magnetic Door Gaskets: Tight fitting seals retain

Do not place the appliance in direct sunlight or near sources of heat, such as a stove or heater, as this can increase electrical consumption.

Extreme cold ambient temperatures may also cause the appliance to perform improperly.

Do not use the appliance near water, for example in a wet basement or near a sink.

all the cooling power and humidity levels.

4.Plastic Coated Shelves: Odor resistant, rustproof, and removable for easy cleaning.

5.Leveling Leg: Adjust to level the appliance.

6.Interior Light (not shown): Illuminates the compartment when turned on.

This appliance is intended for household use only. It is not designed for outside installation, including anywhere that is not temperature controlled (garages, porches, vehicles, etc.).

Before connecting the appliance to a power source, let it stand upright for approximately 6 hours. This will reduce the possibility of a

malfunction in the cooling system from handling during transportation.

This appliance is 44.5 cm (17.5 inches) wide by 84 cm (33.1 inches) high by 51 cm (20.1 inches) deep. Do not cover any of the ventilation openings with any material as the appliance needs adequate space to breathe.

Allow 12.7 cm (5 inches) of space between the back, sides and top of the appliance and all adjacent walls.

This appliance is intended for free-standing installation only and is not intended to be built into a cabinet or counter. Building in this appliance can cause it to malfunction.

1

2

3

4

5

INTERIOR LIGHT

The interior light can either be set to on or off. To operate the light, press the light switch on the ceiling of the appliance, on the right side of the interior light housing.

3

OPERATING INSTRUCTIONS

TEMPERATURE CONTROL

STORAGE INSTRUCTIONS

The temperature is controlled by the temperature knob on the back of the appliance.

On the graduated blue dial, the thicker, darker blue indicates colder temperatures and the thinner, lighter blue indicates warmer temperatures.

The internal temperature will vary depending on the ambient room temperature, the quantity of beverages stored, and the frequency that the door is opened.

Setting the control knob to just past the middle point of the graduated blue line should provide adequate cooling.

To turn the appliance off, turn the control knob to the “0” position.

This appliance can hold up to 36 wine bottles of 750 ml size.

Place five bottles on the first six shelves.

Place three bottles on each shelf of the two lower shelves.

LEVELING INSTRUCTIONS

There is an adjustable leg on the bottom of the appliance that can be turned up or down to ensure that the appliance is level.

1.Turn the leveling leg counter-clockwise as far as it will go, until the top of the foot is touching the bottom of the cabinet.

2.Slowly turn the leveling leg clockwise until the appliance is level.

SHELF INSTRUCTIONS

To remove a shelf from its locked position, lift the rear of the shelf upward and then slide the shelf out of the unit.

To replace the shelf, ensure it is resting securely on the support brackets and then push inward until the shelf locks into place.

Note: Do not cover shelves with aluminum foil or any other material that will prevent air circulation within the appliance as this can adversely affect internal temperature.

4

Danby DWC036A2BDB6 User Manual

OPERATING INSTRUCTIONS

DOOR REVERSAL INSTRUCTIONS

If the appliance is placed on its back or side for any length of time during this process, it must be allowed to remain upright for 6 hours before plugging it in to avoid damage to the internal components.

1.Remove the two screws from the back of the worktop, lift the back of the worktop and pull it toward the front of the appliance to remove it. Remove the worktop hinge hole cover from the left side of the worktop and move it to the hinge hole on the right side of the worktop.

2.Remove the screw from the door spindle cover and remove the upper right hinge and door from the cabinet. Remove the door spindle from the upper right hinge.

3.Remove the lower hinge hole cover from the bottom left side of the door and move it to the bottom right side of the door.

4.Remove the adjustable foot and the two screws holding the bottom hinge. Move the bottom hinge to the left side of the cabinet and install with the screws. Install the adjustable foot on the left side of the appliance and move the solid foot to the right side of the appliance.

5.The upper left hinge is in the accessory bag inside the appliance. Install the door spindle on the upper left hinge. Install the upper left

hinge and door onto the cabinet. Install the door spindle cover with a screw. Reinstall the worktop by laying it on top of the appliance and pushing it toward the back until it clicks into place and then reinstall the two screws at the back.

Note: When reinstalling the door, ensure that the top of the door is level with the top of the cabinet and that the rubber gasket makes a good seal with the cabinet all the way around.

1

2

3

4

5

5

CARE & MAINTENANCE

CLEANING

Ensure the appliance is unplugged before cleaning.

To clean the inside of the appliance, use a soft cloth and a solution of a tablespoon of baking soda to one quart of water or some mild detergent.

Wash removable shelves in a mild detergent solution, then dry and wipe with a soft cloth.

Clean the outside with a soft, damp cloth and some mild detergent.

It is important to keep the area clean where the door seals against the cabinet. Clean this area with a soapy cloth. Rinse with a damp cloth and let dry.

Note: Do not use cleaners containing ammonia or alcohol on the appliance. Ammonia or alcohol can damage the appearance of the appliance. Never use any commercial or abrasive cleaners or sharp objects on any part of the appliance.

POWER FAILURE

Most power failures are corrected within a few hours and should not affect the temperature of your appliance if you minimize the number of times the door is opened. If the power is going to be off for a longer period of time, take the proper steps to protect your contents.

Note: Wait 3 to 5 minutes before attempting to restart the appliance if operation has been interrupted.

DEFROST

This appliance is equipped with an automatic defrost function and does not require manual defrosting. Defrost water from the appliance is channeled into a drip tray located above the compressor. Heat transfer from the compressor causes the defrost water to evaporate.

VACATION

Short vacations: Leave the appliance operating during vacations of less than three weeks.

Long vacations: If the appliance will not be used for several months, remove all items and turn off the appliance. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door open slightly, blocking it open if necessary.

MOVING

Ensure the appliance is empty.

Secure the door with tape.

Turn the adjustable leg up to the base to avoid damage.

Protect the outside of the appliance with a blanket or similar item.

Ensure the appliance stays in the upright position during transportation.

If the appliance is placed on its back or side during transportation, upon reaching the destination, allow it to remain upright for 6 hours before plugging in to avoid damage to the internal components.

DISPOSAL

This appliance may not be treated as regular household waste, it should be taken to the appropriate waste collection point for recycling of electrical components. For information on local waste collection points, contact your local waste removal agency or government office.

6

TROUBLESHOOTING

Danby Consumer Care: 1-800-263-2629

Hours of operation:

Monday to Thursday 8:30 am - 6:00 pm Eastern Standard Time

Friday 8:30 am - 4:00 pm Eastern Standard Time

Information in this manual is subject to change without notice.

PROBLEM

POSSIBLE CAUSE

No power

• A fuse may be blown or the circuit breaker tripped



• Plug not fully inserted into the wall outlet





Internal temperature not cold enough

• Door is not shut properly or opened excessively

Appliance runs continuously

• Exhaust vent is obstructed



• Recently added a large quantity of warm contents to the



cabinet



• Close proximity to heat source or direct sunlight



• Ambient temperature or humidity is very high



• Possible system leak, evaporator fan failure or compressor



failure





Condensation on the cabinet or door

• Door is not shut properly or opened excessively



• Ambient temperature or humidity is very high





7





LIMITED “IN HOME” WARRANTY







LIMITED IN-HOME APPLIANCE WARRANTY

This

lity product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is

used under the normal operating

This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used

conditions intended by the manufacturer.



under the normal operating conditions intended by the manufacturer.



This

is av

only to the person to whom the unit was originally sold by Danby Products Limited (C ada) or Danby

Products Inc. (U.S.A.) (hereafter

This warranty is available only to the person to whom the unit was originally sold by Danby Products Limited (Canada) or Danby

Products“Danby”)Incor by. (Uan.authorizedS.A.) (hereafterdistributor“Danby”)of Danby, andor isbynonan-transferableauthorized. distributor of Danby, and is non-transferable.

TERMS OF WARRANTY

TERMS OF WARRANTY

Plastic parts are warranted for thirty (30) days from the date of purchase, with no extensions provided.

Plastic parts, are warranted for thirty (30) days only from purchase date, with no extensions provided.

First 12 months

During the first twelve (12) months, any functional parts of this product found to be defective, will be repaired or

First Year

replaced, at warrantor’s option, at no charge to the original purchaser.

at warrantor’s

During the first twelve (12) months, any functional parts of this product found to be defective, will be repaired or replaced,



option, at no charge to the ORIGINAL purchaser.







To obtain service Contact the dealer where the unit was purchased, or contact the nearest authorized Danby service depot, where

To obtain

service must be performed by a qualified service technician. If service is performed on the unit by anyone other

Danby reserves the right to l mit the bound ries of “In Home Service” to the proximity of

Authorized Service Depot

Any app

liance



than an authorized service depot, all obligations of Danby under this warranty shall be void.





Service

requiring service outside the limited boundaries of “In Home Service” , it will be the consumer’s responsibility to transport the appliance (at

Boundaries of

their own expense) to the original reta ler (point of purchase) r a service depot for repair. See “Boundaries of In Home Serv

ice” below.

Danby reserves the right to limit the boundaries of “In Home Service” to the proximity of an authorized service

in-home service

Contact your dealer from whom your unit was purchased, or contact your nearest authorized Danby service depot, where service



depot. Any appliance requiring service outside the limited boundaries of “In Home Service”, will be the consumer’s



must be performed by qualified serv ce technician.









responsibility to transport at their own expense to the original point of purchase or a service depot for repair. If the



If service is performed on the units by anyone o her than an authorized service depot,

the unit is used for commercial appli

cation, all



appliance is installed in a location that is 100 kilometers (62 miles) or more from the nearest

service

center, it must



obligations of Danby u der this w rranty shall be void.









be delivered to the nearest authorized Danby Service Depot by the purchaser.





Boundaries of

TransportationIf the appli nce ischargesinstalled intoa locationand fromthat isthe100servicekilomet rslocation(62 miles)areor morenotfromprotectedthe n arestbyservicethis warrantycenter your unitand are themust be

In Home Service

responsibilidelivered to they ofnearestthe pauthorizedrchaserDanby.

Service Depot, as service must only be performed by a technician qualified and certif

ied for



warranty service by Danby. Transportation charges to and from the service location are not protected by this warranty and are t

he

respo sibility of the purchaser.





Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other

contents of this appliance, whether due to any defect of the appliance, or its use, whether proper or improper.

Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other c

ontents of this appliance, whether due

to any defect of the appliance, or its use, whether proper or improper.

EXCLUSIONS



Save as herein provided, by Danby, there are no other warranties, conditions, representations or guarantees, express or implied, made or intended by Danby or its authorized distributors and all otherEXCLUSIONSwarranties, conditions, representations or guarantees, including any

warranties, conditions, representations or guarantees under any Sale of Goods Act or like legislation or statute is hereby expressly

Save as herein provided, Danby, there are no other warranties, conditions, representations or guarantees, express or implied, m

ade or intended by Danby or its

excluded. Save as herein provided, Danby shall not be responsible for any damages to persons or property, including the unit itself,

authorized distributors and all other warranties, conditions, representations or guarantees, including any warranties, conditio

ns, representations or guarantees

howsoever caused or any consequential damages arising from the malfunction of the unit and by the purchase of the unit, the

under any Sale of Goods Act or like legislation or statue is hereby expressly excluded. Save as herein provided, Danby shall no

t be responsible for any damages

purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or property caused by

to persons or property, including the unit itself, howsoever caused or any consequential damages arising from the malfunction o

f the unit and by the purchase of

the unit.

y caused by the unit.

the unit, the purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or propert

GENERAL PROVISIONS

GENERAL PROVISIONS

No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:

1)NoPowerwarrantyfailureor insurance. herein contained or set out shall apply when damage or repair is caused by any of the following:

2) Damage1) Powerin transitfailure. or when moving the appliance.

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.

2) Damage in transit or when moving the appliance.

4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses. conditions (ie. extremely high or low room temperature).

5)

4)

Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating con

ditions

Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).



6)



(extremely high or low room temperature).



Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, floods etc.



7)

5)

Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).



Service calls resulting in customer education.



8) Improper6) Fi e,Installationwater damage,(ietheft,. Buildingwar, riot,-inhostility,of a freeacts ofstandingGod such appliances hurricanes, floodsor usingetc. an appliance outdoors that is not approved for outdoor

application, including but not limited to: garages, patios, porches or anywhere that is not properly insulated or climate controlled).

7)

Service calls resulting in customer education.



8)

Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for out

door application).

Proof of purchase date will be required for warranty claims; retain bills of sale. In the event that warranty service is required, present

Proof of purchase date will be required for warranty claims; so, please retain bills of sale. In the event warranty service is

required, present this document to our

the proof of purchase to our authorized service depot.













AUTHORIZED SERVICE DEPOT.





























WarrantyService













In-hoHome

























Products Limited











Products Inc.

Danby Products Limited

1-

-

-

PO Box 669, Findlay,

DanbyProducts Inc.

PO

1778, Guelph, Ontario, Canada N1H 6Z9

U.S.A. 45840

POBox1778, Guelph, Ontario, Canada N1H 6Z9

1-800-263-2629

Telephone:

PO Box 669, Findlay,Ohio,U.S.A. 45840

Telephone: (519) 837-0920 FAX: (519) 837-0449



04/17



(419) 425-8627

(419) 425-8629

Telephone: (519) 837-0920 FAX: (519) 837-0449







Telephone: (419) 425-8627FAX: (419) 425-86 9

04/09

Loading...
+ 19 hidden pages
