BMW G 650 X, G 650 XCOUNTRY, G 650 XCHALLENGE BROCHURE

BMW Motorrad

G 650 Xchallenge
G 650 Xcountry
G 650 Xmoto

The Ultimate

Riding Machine

Get Your Kicks.

Radical. Lightweight. Purist.

02 - 03

G 650 Xmoto

G 650 Xcountry

G 650 Xchallenge

G 650 Xchallenge

04 - 05

Get off the tarmac and onto the fun stuff.

Whether tearing up gravel tracks or fording

streams, the G650 Xchallenge’s 53 hp

(39 kW) and 60 Nm of torque are equal

to anything you can throw at it. So next

time nature calls, you know what your

answer will be.

Goodbye limits.

06 - 07

The new G 650 Xchallenge – designed

for extreme enduro fans who know exactly

what they want out of life. It may have an

exceptionally lightweight design, but this

motorcycle still packs plenty of punch.

And BMW Motorrad’s unique Air Damping

System ensures outstanding traction and

handling.

Follow your heart,
not the road.

08 - 09

Engine

Construction Water-cooled 4-stroke, single-cylinder engine,

Bore x stroke 100 mm x 83 mm

Capacity 652 cm

Output 53 hp (39 kW) at 7,000 rpm

Max. torque 60 Nm at 5,250 rpm

Compression ratio 11.5:1

Fuel/engine management Electronic intake pipe injection/BMW

Emission control Regulated 3-way catalytic converter,

four valves, twin overhead camshaft, dry sump lubrication

3

engine management, twin-spark ignition

compliant with EU3 emissions standard

Performance/fuel consumption

Maximum speed 165 km/h

Fuel consumption – 100 km
at a constant 90 km/h 3.6 litres

Fuel consumption – 100 km
at a constant 120 km/h 5.1 litres

Fuel type Premium unleaded, minimum 95 octane (RON)

Electrics

Alternator 280-W generator

Battery 12 V/10 Ah, maintenance-free

Transmission

Clutch Multidisc clutch in oil bath, mechanically operated

Gears Synchromesh 5-speed gearbox, built into engine housing

Drive Endless O-ring chain

Chassis/brakes

Frame Bridge-type steel tube frame with bolted die-cast

Suspension, front Upside-down telescopic fork, 45-mm diameter,

Suspension, rear Die-cast aluminium twin swinging arm, Air Damping

Travel front/rear 270 mm/270 mm

Wheelbase (unladen as per DIN standard) 1,500 mm

Castor (unladen as per DIN standard) 118 mm

Steering head angle
(unladen as per DIN standard) 62.5°

Wheels Wire spoke wheels

Rim dimensions, front 1.60 x 21”

Rim dimensions, rear 2.50 x 18”

Tyre, front 90/90 S 21

Tyre, rear 140/80 S 18

Brakes, front Single disc brake, 300-mm diameter,

Brakes, rear Single disc brake, 240-mm diameter,

ABS BMW Motorrad ABS (disconnectable) available

aluminium side sections and aluminium rear frame

adjustable compression and rebound

System, in´ nitely adjustable spring pre-load and rear
damping

double-piston µ oating caliper

single-piston µ oating caliper

as an option

Dimensions/weight

Seat height, unladen 930 mm (low seat: 910 mm)

Rider step length, unladen 2,000 mm (low seat: 1,960 mm)

Unladen weight, fully fuelled/road-ready* 156 kg

Dry weight** 144 kg

Max. permitted weight 335 kg

Max load (with standard equipment) 179 kg

Usable tank volume 9.5 litres

Of which reserve 2 litres

Length 2,205 mm

Height (not inc. mirrors) 1,255 mm

Width (inc. mirrors) 907 mm

Releva nt ´ gures refer to the DIN standard de´ nition of an unladen bike.
* As de´ ned in EU directive 93/93/EEC, ´ lled with all operating µ uids, fuelled to at least
90% of usable tank capacity.
** Unladen weight without operating µ uids.

G 650 Xchallenge

Aura White

10 - 11
