L 71479 FL L 71470 FL L 71670 FL

WASHING MACHINE

USER MANUAL

2

CONTENTS

4 SAFETY INFORMATION

6ENVIRONMENT CONCERNS

6TECHNICAL INFORMATION 7 PRODUCT DESCRIPTION

7 ACCESSORIES

8 CONTROL PANEL

12 PROGRAMMES

15 BEFORE FIRST USE

15USING THE APPLIANCE

15LOADING THE LAUNDRY

16FILLING THE DETERGENT AND ADDITIVES

17SETTING AND STARTING A PROGRAMME

18AT THE END OF THE PROGRAMME

20 HINTS AND TIPS

22 CARE AND CLEANING

27 TROUBLESHOOTING

30 INSTALLATION

SERVICE

When contacting Service, ensure that you have the following data available. The information can be found on the rating plate.

Model

PNC

Serial Number

The following symbols are used in this user manual:

Warning - Important Safety information.

General information and tips

Environmental information

Subject to change without notice

ENGLISH 3

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to keep all your AEG appliances looking spotless and working perfectly. Along with a wide range of accessories designed and built to the high quality standards you would expect, from specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…

Visit the webshop at:

www.aeg.com/shop

VISIT OUR WEBSITE FOR:

-Products

-Brochures

-User manuals

-Trouble shooter

-Service information

www.aeg.com

4

SAFETY INFORMATION

Before the installation and use, read this manual carefully:

For your safety and the safety of your property

To help the environment

For the correct operation of the ap-

pliance.

Always keep these instructions with the appliance also if you move or give it to a different person.

The manufacturer is not responsible if an incorrect installation and use causes damage.

products in, near or on the appliance. Risk of explosion or fire.

Obey the safety instructions on the detergent packaging to prevent burns to eyes, mouth and throat.

Make sure that you remove all metal objects from the laundry. Hard and sharp material can cause damage to the appliance.

Do not touch the glass of the door while a programme operates. The glass can be hot (only for front-load- ing appliances).

CHILDREN AND VULNERABLE PERSON SAFETY

Do not let persons, children included, with reduced physical sensory, reduced mental functions or lack of experience and knowledge use the appliance. They must have supervision or instruction for the operation of the appliance by a person who is responsible for their safety. Do not let children play with the appliance.

Keep all packaging away from children. There is the risk of suffocation or injury.

Keep all detergents away from children.

Keep children and pets away from the appliance when the door is open.

Before you close the appliance door, make sure that children and pets are not into the drum.

If the appliance has a child safety device, we recommend to activate it.

GENERAL SAFETY

Do not use the appliance for professional use. The appliance is only for domestic use.

Do not change the specifications of this appliance. There is the risk of injury and damage to the appliance.

Do not put flammable products or items that are wet with flammable

CARE AND CLEANING

Deactivate the appliance and disconnect the mains plug from the mains socket.

Do not use the appliance without the filters. Make sure that the installation of the filters is correct. An incorrect installation causes water leakages.

INSTALLATION

The appliance is heavy, be careful when you move it.

Do not transport your appliance without the transit bolts, you can damage internal components and cause leakages or malfunctions.

Do not install and connect a damaged appliance.

Make sure to remove all packaging and transport bolts.

Make sure that the mains plug is disconnected from the mains socket during installation.

Only a qualified person must do the electrical installation, the plumbing and the installation of the appliance. This to prevent the risks of structural damage or injury.

Do not install or use the appliance where the temperature is less than 0 °C.

When you install the appliance on a carpet floor, make sure that there is

air circulation between the appliance and the carpet. Adjust the feet to have the necessary space between the appliance and the carpet.

Water connection

Do not connect the appliance with old hoses already used. Only use new hoses.

Make sure not to cause damage to the water hoses.

Do not connect the appliance to new pipes or pipes not used for a long time. Let the water flow for some minutes, then connect the inlet hose.

The first time you use the appliance, make sure that the water hoses and the couplings do not have leakages.

Electrical connection

Make sure that the appliance is earthed.

Make sure that the electrical information on the rating plate agrees with the power supply.

Always use a correctly installed shockproof socket.

ENGLISH 5

Do not use multiple plugs and extension cables. There is a risk of fire.

Do not replace or change the mains cable. Contact the service centre.

Make sure not to cause damage to the mains plug and cable.

Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.

Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

DISCARD THE APPLIANCE

1.Disconnect the mains plug from the mains socket.

2.Cut off the mains cable and discard it.

3.Discard the door catch. This prevents children or pets to be closed in the appliance. There is a risk of suffocation (only for front-loading appliances).

6

ENVIRONMENT CONCERNS

PACKAGING MATERIALS

Recycle the materials with the symbol .

Put the packaging in applicable containers to recycle it.

ECOLOGICAL HINTS

To help the environment, use less water and energy, obey these instructions:

Set a programme without the prewash phase to wash laundry with normal soil.

Always start a washing programme with the maximum load of laundry.

If necessary, use a stain remover when you set a programme with a low temperature.

To use the correct quantity of the detergent, check the water hardness of your domestic system

TECHNICAL INFORMATION

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.

Dimensions

Width / Height / Depth

600 / 850 / 522 mm



Total depth

540 mm

Electrical connection:

Voltage

230 V



Overall power

2200 W



Fuse

10 A



Frequency

50 Hz

Level of protection against ingress of solid particles

IPX4

and moisture ensured by the protective cover, except



where the low voltage equipment has no protection



against moisture





Water supply pressure

Minimum

0,5 bar (0,05 MPa)



Maximum

8 bar (0,8 MPa)

Water supply 1)



Cold water

Maximum load

Cotton

7 kg

Spin speed

Maximum

1400 rpm (L 71479 FL)





1400 rpm (L 71470 FL)





1600 rpm (L 71670 FL)







1) Connect the water inlet hose to a water tap with a 3/4'' thread.

AEG L 71470 FL, L 71479 FL, L 71670 FL User Manual

ENGLISH 7

PRODUCT DESCRIPTION

1

2

3

8

9









10





4









5



11













6









7



12

1

Worktop

7

Feet for the appliance level



Detergent dispenser



Water drain hose

2

8



Control panel



Water inlet valve

3

9



Door handle



Mains cable

4

10



Rating plate



Transit bolts

5

11



Drain pump



Feet for the appliance level

6

12

ACCESSORIES

1



2

4

3

1 Spanner

To remove the transit bolts.

2 Plastic caps

To close the holes on the rear side of the cabinet after the removal of the transit bolts.

3 Anti-flood inlet hose

To prevent possible leakage

4 Plastic hose guide

To connect the drain hose on the edge of a sink.

8

CONTROL PANEL

1



2



3

Energiesparen Super Eco 20 Min. - 3 kg Schnell Intensiv Jeans Gardinen

Spülen

Schleudern/

Pumpen

Koch/Bunt

+Vorwäsche Extra Leise Pflegeleicht

+Vorwäsche

Leichtbügeln

Feinwäsche

Wolle/Seide

Temp.

Extra

Zeit

U./Min. Flecken Spülen

Sparen

Zeit-

Start/Pause

vorwahl

10

9

8

7

6

5

4

1

On/Off button (Ein/Aus)



Programme knob

2



Display

3



Start Pause button (Start/Pause)

4



Delay start button (Zeitvorwahl)

5



Time saving button (Zeit Sparen)

6



Extra rinse button (Extra Spülen)

7



Stain button (Flecken)

8



Spin reduction button (U./Min.)

9



Temperature button (Temp.)

10

ON OFF BUTTON 1

The AUTO Stand-by function automatically deactivates the appliance to decrease the energy consumption when:

• You do not use the appliance for 5

minutes before you press button 4 .

All settings are cancelled.

Press button 1 to activate the appliance again.

Set again the washing programme and all possible options.

After 5 minutes from the end of the washing programme. Refer to 'At the end of programme'.

PROGRAMME KNOB 2

Press this button to activate or deactivate the appliance. A tune sounds when the appliance is activated.

Turn this knob to set a programme. The related programme indicator comes on.

DISPLAY 3

A B C D

The display shows:

A • The maximum temperature of the programme.

ENGLISH 9

B• The default spin speed of the programme.

'No Spin'1) and 'Rinse Hold' symbols.

CThe display symbols.2)

Symbols Description

Washing phase

Rinse phases

Spin phase

Child lock

You cannot open the appliance door when the symbol is on. You cannot open the appliance door when the symbol flashes. Wait for some minutes before you open the door.

You can open the door only when the symbol goes off.

If the programme is completed but the symbol stays on:

There is water in the drum.

The 'Rinse Hold' function is on.

Delay start

D• The programme time

When the programme starts, the time decreases with steps of 1 minute.

The delay start

When you press the delay start button, the display shows the delay start time.

Alarm codes

If the appliance has a malfunction, the display shows alarm codes. Refer to 'Troubleshooting' chapter.

Err

The display shows this message for some seconds if:

You set a function that is not applicable for the programme.

You change the programme while it operates.

The indicator of the Start/Pause button 4 flashes.

When the programme is completed.

1)Only available for Spin/Drain programme.

2)The symbols appear on the display when the related phase or function is set.

START/PAUSE BUTTON

4

DELAY START BUTTON

5

Press button

4

to start or interrupt a

Press button

5

to delay the start of a

programme.





programme

from

30 minutes to 20







hours.

10

TIME SAVE BUTTON 6

Press the button 6 to decrease the programme duration.

Press one time to set 'Shortened duration' for items with daily soil.

Press two times to set 'Extra Quick' for items with almost no soil.

Some programmes accept only one of the two functions.

EXTRA RINSE BUTTON 7

Press button 7 to add rinsing phases to a programme.

Use this function for persons allergic to detergents and in areas where the water is soft.

STAIN BUTTON 8

Press button 8 to add the stain phase to a programme.

Use this function for laundry with hard stains to remove.

When you set this function, put the stain remover into compartment .

This function increases the programme duration.

This function is not available with a temperature lower than 40° C.

SPIN BUTTON 9

Press this button to:

Decrease the maximum speed of the spin phase when you set a programme.

The display shows only the spin speeds available with the set programme.

Deactivate the spin phase.

Activate the 'Rinse Hold' function. Set this function to prevent fabric creases. The appliance does not drain the water when the programme is completed.

Spin phase is off.

'Rinse Hold' function is on.

TEMPERATURE BUTTON 10

Press button 10 to change the default temperature.

- - = cold water

ACOUSTIC SIGNALS

FUNCTION

You can hear the acoustic signals when:

You activate the appliance.

You deactivate the appliance.

You press the buttons.

The programme is completed.

The appliance has a malfunction. To deactivate/activate the acoustic

signals, press button 8 and button 7 at the same time for 6 seconds.

If you deactivate the acoustic signals, they continue operate only when you press the buttons and when a malfunction occurs.

CHILD LOCK FUNCTION

This function prevents children to play with the control panel.

• To activate the function, press button

10 and button 9 at the same time

until the display shows the symbol

.

To deactivate the function, press button 10 and button 9 at the same

time until the symbol goes off. You can activate the function:

• Before you press the Start/Pause but-

ton 4 : the appliance cannot start.

After you press the Start/Pause button 4 , all the buttons and the programme knob are deactivated.

PERMANENT EXTRA RINSE FUNCTION

With this function you can keep the extra rinse function permanently on when you set a new programme.

To activate the function press button 6 and button 5 at the same time

until the indicator of button 7 is on.

ENGLISH 11

To deactivate the function press button 6 and button 5 at the same time until the indicator of button 7 is off.

Loading...
+ 25 hidden pages
