PSR-E233/YPT-230 Owner’s Manual

2

SPECIAL MESSAGE SECTION

This product utilizes batteries or an external power supply (adapter).
DO NOT connect this product to any power supply or adapter other
than one described in the manual, on the name plate, or specifically
recommended by Yamaha.

WARNING:

walk on, trip over, or roll anything over power or connecting cords of any
kind. The use of an extension cord is not recommended! If you must use an
extension cord, the minimum wire size for a 25’ cord (or less) is 18 AWG.
NOTE: The smaller the AWG number, the larger the current handling
capacity. For longer extension cords, consult a local electrician.

This product should be used only with the components supplied or; a
cart, rack, or stand that is recommended by Yamaha. If a cart, etc., is
used, please observe all safety markings and instructions that accom­pany the accessory product.

Do not place this product in a position where anyone could

SPECIFICATIONS SUBJECT TO CHANGE:

The information contained in this manual is believed to be correct at
the time of printing. However, Yamaha reserves the right to change or
modify any of the specifications without notice or obligation to update
existing units.

This product, either alone or in combination with an amplifier and
headphones or speaker/s, may be capable of producing sound levels
that could cause permanent hearing loss. DO NOT operate for long
periods of time at a high volume level or at a level that is uncomfort­able. If you experience any hearing loss or ringing in the ears, you
should consult an audiologist.
IMPORTANT: The louder the sound, the shorter the time period before
damage occurs.

Some Yamaha products may have benches and / or accessory
mounting fixtures that are either supplied with the product or as
optional accessories. Some of these items are designed to be dealer
assembled or installed. Please make sure that benches are stable and
any optional fixtures (where applicable) are well secured BEFORE
using.
Benches supplied by Yamaha are designed for seating only. No other
uses are recommended.

NOTICE:

Service charges incurred due to a lack of knowledge relating to how a
function or effect works (when the unit is operating as designed) are
not covered by the manufacturer’s warranty, and are therefore the
owners responsibility. Please study this manual carefully and consult
your dealer before requesting service.

ENVIRONMENTAL ISSUES:

Yamaha strives to produce products that are both user safe and envi­ronmentally friendly. We sincerely believe that our products and the
production methods used to produce them, meet these goals. In keep­ing with both the letter and the spirit of the law, we want you to be
aware of the following:

Battery Notice:

This product MAY contain a small non-rechargeable battery which (if
applicable) is soldered in place. The average life span of this type of bat­tery is approximately five years. When replacement becomes necessary,
contact a qualified service representative to perform the replacement.

This product may also use “household” type batteries. Some of these
may be rechargeable. Make sure that the battery being charged is a
rechargeable type and that the charger is intended for the battery being
charged.

When installing batteries, never mix old batteries with new ones, and
never mix different types of batteries. Batteries MUST be installed cor­rectly. Mismatches or incorrect installation may result in overheating and
battery case rupture.

Warning:

Do not attempt to disassemble, or incinerate any battery. Keep all bat­teries away from children. Dispose of used batteries promptly and as
regulated by the laws in your area. Note: Check with any retailer of
household type batteries in your area for battery disposal information.

Disposal Notice:

Should this product become damaged beyond repair, or for some rea­son its useful life is considered to be at an end, please observe all
local, state, and federal regulations that relate to the disposal of prod­ucts that contain lead, batteries, plastics, etc. If your dealer is unable
to assist you, please contact Yamaha directly.

NAME PLATE LOCATION:

The name plate is located on the bottom of the product. The model
number, serial number, power requirements, etc., are located on this
plate. You should record the model number, serial number, and the
date of purchase in the spaces provided below and retain this manual
as a permanent record of your purchase.

Model

Serial No.

Purchase Date

92-BP (bottom)

PLEASE KEEP THIS MANUAL

FCC INFORMATION (U.S.A.)

1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!

This product, when installed as indicated in the instructions con­tained in this manual, meets FCC requirements. Modifications not
expressly approved by Yamaha may void your authority, granted by
the FCC, to use the product.

2. IMPORTANT: When connecting this product to accessories and/

or another product use only high quality shielded cables. Cable/s
supplied with this product MUST be used. Follow all installation
instructions. Failure to follow instructions could void your FCC
authorization to use this product in the USA.

3. NOTE: This product has been tested and found to comply with the

requirements listed in FCC Regulations, Part 15 for Class “B” digital
devices. Compliance with these requirements provides a reason­able level of assurance that your use of this product in a residential
environment will not result in harmful interference with other elec­tronic devices. This equipment generates/uses radio frequencies
and, if not installed and used according to the instructions found in
the users manual, may cause interference harmful to the operation
of other electronic devices. Compliance with FCC regulations does

* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. (class B)

not guarantee that interference will not occur in all installations. If
this product is found to be the source of interference, which can be
determined by turning the unit “OFF” and “ON”, please try to elimi­nate the problem by using one of the following measures:

Relocate either this product or the device that is being affected by
the interference.

Utilize power outlets that are on different branch (circuit breaker or
fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the
antenna. If the antenna lead-in is 300 ohm ribbon lead, change the
lead-in to co-axial type cable.

If these corrective measures do not produce satisfactory results,
please contact the local retailer authorized to distribute this type of
product. If you can not locate the appropriate retailer, please con­tact Yamaha Corporation of America, Electronic Service Division,
6600 Orangethorpe Ave, Buena Park, CA90620

The above statements apply ONLY to those products distributed by
Yamaha Corporation of America or its subsidiaries.

PSR-E233/YPT-230 Owner’s Manual

3

PRECAUTIONS

Power supply/AC power adaptor

Do not open

Water warning

Fire warning

Battery

If you notice any abnormality

Power supply/AC power adaptor

Location

Connections

Handling caution

PLEASE READ CAREFULLY BEFORE PROCEEDING

* Please keep this manual in a safe place for future reference.

WARNING

Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, short­circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following:

• Do not place the power cord near heat sources such as heaters or radiators, and
do not excessively bend or otherwise damage the cord, place heavy objects on it,
or place it in a position where anyone could walk on, trip over, or roll anything
over it.

• Only use the voltage specified as correct for the instrument. The required voltage
is printed on the name plate of the instrument.

• Use the specified adaptor (page 42) only. Using the wrong adaptor can result in
damage to the instrument or overheating.

• Check the electric plug periodically and remove any dirt or dust which may have
accumulated on it.

• This instrument contains no user-serviceable parts. Do not open the instrument
or attempt to disassemble or modify the internal components in any way. If it
should appear to be malfunctioning, discontinue use immediately and have it
inspected by qualified Yamaha service personnel.

• Do not expose the instrument to rain, use it near water or in damp or wet
conditions, or place containers on it containing liquids which might spill into any
openings. If any liquid such as water seeps into the instrument, turn off the power
immediately and unplug the power cord from the AC outlet. Then have the
instrument inspected by qualified Yamaha service personnel.

• Never insert or remove an electric plug with wet hands.

• Do not put burning items, such as candles, on the unit.
A burning item may fall over and cause a fire.

• Always replace all batteries at the same time. Do not use new batteries together
with old ones.

• Do not mix battery types, such as alkaline batteries with manganese batteries, or
batteries from different makers, or different types of batteries from the same
maker, since this can cause overheating, fire, or battery fluid leakage.

• Do not tamper with or disassemble batteries.

• Do not dispose of batteries in fire.

• Do not attempt to recharge batteries that are not intended to be charged.

• Keep batteries away from children.

• If the batteries do leak, avoid contact with the leaked fluid. If the battery fluid
should come in contact with your eyes, mouth, or skin, wash immediately with
water and consult a doctor. Battery fluid is corrosive and may possibly cause loss
of sight or chemical burns.

• Always make sure all batteries are inserted in conformity with the +/- polarity
markings. Failure to do so might result in overheating, fire, or battery fluid
leakage.

• When the batteries run out, or if the instrument is not to be used for a long time,
remove the batteries from the instrument to prevent possible leakage of the battery
fluid.

• When one of the following problems occur, immediately turn off the power switch
and disconnect the electric plug from the outlet. (If you are using batteries,
remove all batteries from the instrument.) Then have the device inspected by
Yamaha service personnel.

• The power cord or plug becomes frayed or damaged.

• It emits unusual smells or smoke.

• Some object has been dropped into the instrument.

• There is a sudden loss of sound during use of the instrument.

CAUTION

Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage to the
instrument or other property. These precautions include, but are not limited to, the following:

• Do not connect the instrument to an electrical outlet using a multiple-connector.
Doing so can result in lower sound quality, or possibly cause overheating in the
outlet.

• When removing the electric plug from the instrument or an outlet, always hold the
plug itself and not the cord. Pulling by the cord can damage it.

• Remove the electric plug from the outlet when the instrument is not to be used for
extended periods of time, or during electrical storms.

• Do not place the instrument in an unstable position where it might accidentally
fall over.

• Before moving the instrument, remove all connected cables.

• When setting up the product, make sure that the AC outlet you are using is easily
accessible. If some trouble or malfunction occurs, immediately turn off the power
switch and disconnect the plug from the outlet. Even when the power switch is
turned off, electricity is still flowing to the product at the minimum level. When
you are not using the product for a long time, make sure to unplug the power cord
from the wall AC outlet.

• Use only the stand specified for the instrument. When attaching the stand or rack,
use the provided screws only. Failure to do so could cause damage to the internal
components or result in the instrument falling over.

PSR-E233/YPT-230 Owner’s Manual

4

• Before connecting the instrument to other electronic components, turn off the
power for all components. Before turning the power on or off for all components,
set all volume levels to minimum.

• Be sure to set the volumes of all components at their minimum levels and
gradually raise the volume controls while playing the instrument to set the desired
listening level.

• Do not insert a finger or hand in any gaps on the instrument.

• Never insert or drop paper, metallic, or other objects into the gaps on the panel or
keyboard. This could cause physical injury to you or others, damage to the
instrument or other property, or operational failure.

• Do not rest your weight on, or place heavy objects on the instrument, and do not
use excessive force on the buttons, switches or connectors.

• Do not use the instrument/device or headphones for a long period of time at a
high or uncomfortable volume level, since this can cause permanent hearing loss.
If you experience any hearing loss or ringing in the ears, consult a physician.

DMI-3 1/2

Yamaha cannot be held responsible for damage caused by improper use or modifications to the instrument, or data that is lost or destroyed.

Always turn the power off when the instrument is not in use.
Even when the power switch is in standby status, electricity is still flowing to the instrument at the minimum level. When you are not using the instrument for a long time, make

sure you unplug the power cord from the wall AC outlet.
Make sure to discard used batteries according to local regulations.

NOTICE

To avoid the possibility of malfunction/damage to the product, damage to data, or damage to other property, follow the
notices below.

 Handling and Maintenance

• Do not use the instrument in the vicinity of a TV, radio, stereo equipment, mobile phone, or other electric devices. Otherwise, the instrument, TV, or radio
may generate noise.

• Do not expose the instrument to excessive dust or vibrations, or extreme cold or heat (such as in direct sunlight, near a heater, or in a car during the day)
to prevent the possibility of panel disfiguration, damage to the internal components or unstable operation. (Verified operating temperature range: 5° –
40°C, or 41° – 104°F.)

• Do not place vinyl, plastic or rubber objects on the instrument, since this might discolor the panel or keyboard.

• When cleaning the instrument, use a soft, dry cloth. Do not use paint thinners, solvents, cleaning fluids, or chemical-impregnated wiping cloths.

 About copyrights

• Copying of the commercially available musical data including but not limited to MIDI data and/or audio data is strictly prohibited except for your personal
use.

• This product incorporates and bundles computer programs and contents in which Yamaha owns copyrights or with respect to which it has license to use
others’ copyrights. Such copyrighted materials include, without limitation, all computer software, style files, MIDI files, WAVE data, musical scores and
sound recordings. Any unauthorized use of such programs and contents outside of personal use is not permitted under relevant laws. Any violation of
copyright has legal consequences. DON’T MAKE, DISTRIBUTE OR USE ILLEGAL COPIES.

 About functions/data bundled with the instrument

• Some of the preset songs have been edited for length or arrangement, and may not be exactly the same as the original.

 About this manual

• The illustrations and LCD screens as shown in this manual are for instructional purposes only, and may appear somewhat different from those on your
instrument.

• The company names and product names in this manual are the trademarks or registered trademarks of their respective companies.

DMI-3 2/2

PSR-E233/YPT-230 Owner’s Manual

5

About the Manuals

Insert the music
rest into the slots
as shown.

This instrument has the following documents and instructional materials.

 Included Documents

Owner’s Manual (this book)

 Online Materials (Downloadable from the web)

The following instructional materials are available for downloading from the Yamaha website.

Yamaha Manual Library http://www.yamaha.co.jp/manual/
Access the Yamaha Manual Library, then enter your model name (PSR-E233, for example) in the Model Name
area to search the manuals.

MIDI Data Format

This document contains both the MIDI Data Format and the MIDI Implementation Chart.

MIDI Basics (only in English, French, German and Spanish)

If you want to know more about MIDI and how to use it, refer to this introductory book.

Yamaha Online Member https://member.yamaha.com/myproduct/regist/
You can refer to the music score in the Song Book (free downloadable scores). To obtain the Song Book, complete
the user registration at the above website.

Song book (only in English, French, German and Spanish)

Logos

GM System Level 1

“GM System Level 1” is an addition to the MIDI
standard which ensures that any GM-compatible
music data can be accurately played by any GM­compatible tone generator, regardless of manufac­turer. The GM mark is affixed to all software and
hardware products that support GM System Level.

XGlite

As its name implies, “XGlite” is a simplified ver­sion of Yamaha’s high-quality XG tone generation
format. Naturally, you can play back any XG song
data using an XGlite tone generator. However,
keep in mind that some songs may play back dif­ferently compared to the original data, due to the
reduced set of control parameters and effects.

Supplied Accessories Using the music rest

• Owner’s manual (this book)

• Music rest

• AC Power Adaptor

* May not be included depending on your particular area.

Please check with your Yamaha dealer.

• My Yamaha Product User Registration

* The PRODUCT ID on the sheet will be needed when

you fill out the User Registration form.

PSR-E233/YPT-230 Owner’s Manual

6

Contents

About the Manuals................................................ 6

Logos.................................................................... 6

Supplied Accessories ........................................... 6

Using the music rest ............................................. 6

Introduction

Setting Up 8

Power Requirements ............................................ 8

Connecting headphones and external audio

equipment ........................................................ 9

Connecting a footswitch ....................................... 9

Turn on the power ................................................ 9

Auto Power Off function........................................ 9

Panel Controls and Terminals 10

Basic Operation and Displays 12

Basic Operation .................................................. 12

Display................................................................ 13

Reference

Try Playing a Variety of Instrument Voices 14

Function Settings 28

Select the item and change the value.................28

About MIDI 31

What is MIDI?......................................................31

Transferring Performance Data To and From

Another Instrument......................................... 31

Appendix

Troubleshooting............................................. 32

Voice List ........................................................ 33

Drum Kit List ..................................................37

Song List......................................................... 39

Style List ......................................................... 40

Effect Type List .............................................. 41

Specifications................................................. 42

Index................................................................ 43

Select and Play a Voice...................................... 14

Playing the Grand Piano Voice........................... 15

Fun Sounds ........................................................ 15

Try playing with enhanced, dynamic sound

(Ultra-Wide Stereo)........................................ 15

Play with a Style 16

Select a Style Rhythm ........................................ 16

Play Along with a Style ....................................... 17

Pattern Variation (Sections)................................ 18

Chords ................................................................ 19

Looking up Chords Using the Chord Dictionary . 20

Try Playing a Song with a Style!......................... 21

Playing Songs 22

Select and Listen to a Specific Song .................. 22

Listening to the Demo Songs ............................. 23

BGM Playback.................................................... 23

Using the Lesson Feature 24

Song Lesson....................................................... 24

A-B Repeat......................................................... 26

Mute.................................................................... 26

Using the Metronome ......................................... 27

Changing the Tempo .......................................... 27

PSR-E233/YPT-230 Owner’s Manual

7

Setting Up

WARNING

CAUTION

AC outlet

AC power

adaptor

3

2

NOTICE

WARNING

Introduction

Be sure to do the following operations BEFORE turning on the power.

Power Requirements

Although the instrument will run either from an optional AC adaptor or batteries, Yamaha recommends use of an
AC adaptor whenever possible. An AC adaptor is more environmentally friendly than batteries and does not
deplete resources.

Using an AC Power Adaptor

1 Make sure that the [ ] (Standby/On) switch of the

instrument is off (display is blank, except for nota­tion staff).

• Use the specified adaptor (page 42). The use of other
adaptors may result in irreparable damage to both the
adaptor and the instrument.

2 Connect the AC power adaptor to the power supply

jack.

3 Plug the AC adaptor into an AC outlet.

• Unplug the AC Power Adaptor when not using the
instrument, or during electrical storms.

Using Batteries

1 Open the battery compartment cover located on the

instrument’s bottom panel.

2 Insert the six new alkaline batteries, being careful

to follow the polarity markings on the side of the
compartment.

3 Replace the compartment cover, making sure that it

locks firmly in place.

For battery operation the instrument requires six 1.5V
“AA” size, LR6 or equivalent batteries. (Alkaline batter­ies are recommended.) When battery power becomes too
low for proper operation, the volume may be reduced, the
sound may be distorted, and other problems may occur.
When this happens, make sure to replace all batteries,
following the precautions listed below.

• Make sure to install the batteries with the proper orientation,
maintaining the correct polarity (as shown). Incorrect battery
installation may result in heat, fire and/or leaking of corrosive
chemicals.

• When the batteries run down, replace them with a complete set of
six new batteries. NEVER mix old and new batteries. Do not use
different kinds of batteries (e.g. alkaline and manganese) at the
same time.

• If the instrument is not to be in use for a long time, remove the
batteries from it, in order to prevent possible fluid leakage from
the battery.

NOTE

• Use alkaline batteries for this instrument. Other types of bat­teries (including rechargeable batteries) may have sudden
drops of power when battery power becomes low.

• Never connect or disconnect the AC power adaptor when the
batteries are installed in the instrument and the power is on.
Doing so will turn the power off.

PSR-E233/YPT-230 Owner’s Manual

8

Make all necessary connections BEFORE turning the power on.

CAUTION

CAUTION

CAUTION

Setting Up

Connecting headphones and

external audio equipment

You can connect the PHONES/OUTPUT jack to a set
of headphones, keyboard amplifier, stereo system,
mixer, tape recorder, or other line-level audio device
to send the instrument’s output signal to that device.

The internal speakers are automatically shut off when
a plug is inserted into this jack. The PHONES/OUT­PUT jack also functions as an external output.

NOTE

• You can set the Master equalizer (EQ) which is provided to
give you the best possible sound when listening through dif­ferent reproduction systems. The Master equalizer (EQ) can
be set in the Function settings (page 29 Function 013).

• Avoid listening with the headphones at high volume for
long periods of time; doing so may not only result in ear
fatigue, it may be damaging to your hearing.

• To prevent damage to the speakers, set the volume of the
external devices at the minimum setting and turn power off
the devices before connecting them. Failure to observe
these precautions may result in electric shock or equip­ment damage. Also, be sure to set the volumes of all
devices at their minimum levels and gradually raise the vol­ume controls while playing the instrument to set the
desired listening level.

Turn on the power

Turn down the volume by turning the [MASTER
VOLUME] control to the left and press the [ ]
(Standby/On) switch to turn on the power. While
playing the keyboard, adjust the volume level by using
the [MASTER VOLUME] control. Pressing the [ ]
(Standby/On) switch again turns the power off.

• When using a power adaptor, even when the power is off, a
small amount of electricity is still being consumed by the
instrument. When you are not using the instrument for a long
time, make sure to unplug the AC power adaptor from the wall
AC outlet, and/or remove the batteries from the instrument.

Auto Power Off function

To prevent unnecessary power consumption, this instru­ment features an Auto Power Off function that automati­cally turns the power off if the instrument is not used for
approximately 30 minutes.

To disable the Auto Power Off function
While holding down the lowest key, press the [ ]
(Standby/On) switch to turn on the power. Alternately
select “Off” in the Function settings (page 30 Func­tion 024).

Connecting a footswitch

The sustain function lets you produce a natural sustain
as you play by pressing an optional footswitch. Plug
the Yamaha FC4 or FC5 footswitch into the SUS­TAIN jack and use it to switch sustain on and off.

NOTE

• Make sure that the footswitch plug is properly connected to
the SUSTAIN jack before turning on the power.

• Do not press the footswitch while turning the power on. Doing
this changes the recognized polarity of the footswitch, result­ing in reversed footswitch operation.

NOTE

• Any settings will be restored to the factory default settings
when the power is turned off.

PSR-E233/YPT-230 Owner’s Manual

9

Panel Controls and Terminals

w

q

e

r

t

!5

!7

!6

!8

@3

Front Panel

Front Panel

q [ ] (Standby/On) switch.....................................page 9

w [MASTER VOLUME] control ................................ page 9

e [1 LISTEN & LEARN] button .............................. page 24

r [2 TIMING] button...............................................page 24

t [3 WAITING] button............................................page 24

y LESSON PART

[L] button ............................................................page 25

[R] button............................................................ page 25

u [METRONOME] button .......................................page 27

i [TEMPO/TAP] button.......................................... page 27

o [SONG] button............................................ pages 12, 22

!0 [VOICE] button ........................................... pages 12, 14

!1 [STYLE] button ........................................... pages 12, 16

!2 Number buttons [0]–[9], [+], [-] ......................... page 12

!3 [FUNCTION] button............................................page 28

!4 [DEMO/BGM] button .......................................... page 23

In the Song mode

!5 [A-B REPEAT] button.........................................page 26

!6 [REW] button...................................................... page 22

!7 [FF] button .......................................................... page 22

!8 [PAUSE] button...................................................page 22

In the Style mode

!5 [ACMP ON/OFF] button .....................................page 17

!6 [INTRO/ENDING/rit.] button ............................... page 18

!7 [MAIN/AUTO FILL] button..................................page 18

!8 [SYNC START] button ........................................ page 17

!9 [START/STOP] button ................................ pages 12, 22

@0 [PORTABLE GRAND] button............................. page 15

@1 [SOUND EFFECT] button .................................. page 15

@2 [ULTRA-WIDE STEREO] button

um Kit.............................................................. page 14

@3 Dr

........................page 15

Rear Panel

@4 MIDI IN/OUT terminals .......................................page 31

@5 SUSTAIN jack ....................................................... page 9

@6 PHONES/OUTPUT jack........................................ page 9

@7 DC IN jack ............................................................. page 8

PSR-E233/YPT-230 Owner’s Manual

10

GrandPno

001

001

GrandPno

001

001

!4

!9

!3

!1

u

!0

o

i

@2

@1@0

!2

y

@7@6@5@4

Rear Panel

Display (page 13) Song List (page 39) Style List (page 40)Voice List (page 33)

The “Press & Hold” Symbol

Buttons having this indication can
be used to call up an alternate

function when the relevant button
is pressed and held. Hold down this button
until the function is called up.

Panel Controls and Terminals

PSR-E233/YPT-230 Owner’s Manual

11

Basic Operation and Displays

GrandPno

001

001

321

Display
(page 13)

Number buttons [0]–[9]

The number buttons can be
used to directly enter a
Song, Style or Voice num­ber or parameter value.
For numbers that start with
one or two zeroes, the first
zeroes can be omitted.

Example:
Selecting Voice 002,
Grand Piano2.

Press number buttons
[0], [0], [2].

[+], [-] buttons

Press the [+] button briefly to increase the value
by 1, or press the [-] button briefly to decrease
the value by 1. Press and hold either button to
continuously increase or decrease the value in
the corresponding direction.

Press briefly to
decrease.

Press briefly to
increase.

Basic Operation

Press a button to select a basic function: Voice, Style or Song. To change the instrument voice that sounds when
you play the keyboard, press the [VOICE] button. If you want to play along with auto accompaniment, press the
[STYLE] button. If you want to listen to a song, press the [SONG] button.

Select a basic function.

1

[SONG] button ..............To select a Song.

[VOICE] button.............. To select a Voice.

[STYLE] button.............. To select a Style.

When you select a basic function, the name and number of the currently selected Song, Style or Voice is shown.

Select an item or value by using the number buttons [0]–[9], [+], [-].

2

Refer to the Song, Voice and Style Lists on pages 33–40.

Start a function or play the keyboard.

3

Voice ............................. Play the keyboard.

Song ............................. Press the [START/STOP] button to play Songs.

Style.............................. Press the [START/STOP] button to play the Style rhythm.

You can stop playback at any time by pressing the [START/STOP] button.

PSR-E233/YPT-230 Owner’s Manual

12

Basic Operation and Displays

Indicate the operating condition of the
instrument (page 12).

SONG/VOICE/STYLE

Displays the melody
and chord notes of a
Song when the Song
lesson function is in
use, or the notes of
chords you specify
when the Dictionary
function is in use. At
other times the notes
you play on the key­board are displayed.

Notation

• Any notes occurring below or
above the staff are indicated by
“8va” in the notation.

• For a few specific chords, not all
notes may be shown in the nota­tion section of the display. This is
due to space limitations in the dis­play.

NOTE

Appears when ULTRA-WIDE
STEREO is on (page 15).

Appears when the auto accompa-
niment is on (page 17).

ULTRA-WIDE STEREO

ACMP ON

Indicates the name of
the chord currently
being played back, or
the name of the chord
being played on the keyboard.

Indicates the current measure
during playback of a Song.

Chord Display

Measure

003

Indicates the Function number when
the Function is in use.

Indicates notes currently being
played. Indicates the melody and
chord notes of a Song when the Song
lesson function is in use. Also indi­cates the notes of a chord—either
when playing a chord or when using
the Dictionary function.

Function

Keyboard Display

02

Information related to the Song
tracks is shown here. (See page

26.)

Lit: Track contains data

Unlit: Track is muted or contains no data

Indicates the beat of the current
Style or Song with flashing
arrows.

Song track display

Beat Display

Display

The Main display shows all of the current basic settings for Song, Style and Voice. It also includes a range of indi­cators that show the on/off status for various functions.

001

GrandPno

003

7

PSR-E233/YPT-230 Owner’s Manual

13

GrandPno

001

001

Voic e

Grand Piano
Voic e

Ultra-Wide
Stereo

SOUND
EFFECT

Percussion and drum icons

GrandPno

001

001

Voice name
The Voice shown here becomes the
Main Voice for the instrument.

Voice number

Reference

Try Playing a Variety of Instrument Voices

This instrument features a variety of realistic, built-in voices. The grand piano Voice is
automatically selected whenever the power is turned on, but you can easily change
this to guitar, drums, or any of an extensive range of voices.

Select and Play a Voice

Press the [VOICE] button and then select the desired Voice, referring to the section “Basic Operation” on page 12
for instructions.
Refer to the Voice List on page 33.

Preset Voice Types

001–139 Instrument Voices

Various drum and percussion sounds are assigned to individual keys, from

140–152 (Drum Kit)

which they can be played. Details on the instruments and key assignments of
each Drum Kit can be found in the Drum Kit List on page 37.

153–385 XGlite Voices

One Touch Setting (OTS)

000

The One Touch Setting feature automatically selects the most suitable Voice
for you when you select a Style or Song. Simply select Voice number “000” to
activate this feature.

PSR-E233/YPT-230 Owner’s Manual

14

Try Playing a Variety of Instrument Voices

NOTE

GrandPno

001

Appears when Ultra-Wide Stereo is on.

Playing the Grand Piano Voice

When you simply want to play a piano Voice, all you have to do is press one convenient button.

Press the [PORTABLE GRAND] button.
The Voice “Grand Piano” will automatically be selected as the Main Voice.

Fun Sounds

You’ll be able to play various sound effects from the keyboard: barking, braying, yelling, and much more.

Press the [SOUND EFFECT] button.
Try out each key and enjoy the sounds. Don’t forget the black keys!

After trying out these sounds, press the [PORTABLE GRAND] button to reset the instrument Voice to the default
setting of Voice “Grand Piano1.”

Try playing with enhanced, dynamic sound (Ultra-Wide Stereo)

You can play the keyboard with a spacious, dynamic sound effect that gives you the sensation of hearing the sound
outside of the speakers.
Turn on the Ultra-Wide Stereo effect, and hear the sound expand around you—as if the speaker position is outside
of the instrument.

Press the [ULTRA-WIDE STEREO] button.

To turn ULTRA-WIDE STEREO off, press the [ULTRA-WIDE STEREO] button
again.

Adding other effects to the sound

You can also play the sounds of the instrument adding Reverb, Chorus and Sustain.
The best-suited Reverb and Chorus type is automatically selected whenever you select a Song or Style, but you
can select any of the available Reverb or Chorus Types. These effects can be set in the Function setting (page

29). Refer to the Reverb and Chorus Type lists on page 41 for details.

Reverb........................This effect adds the ambience of a room or concert hall to the sound.

Chorus........................This effect makes the Voice sound richer, warmer and more spacious.

Panel Sustain .............This function adds a fixed sustain to the keyboard Voices.

The sustain function can also be applied with the optional footswitch (page 9).

• The wide effect type can be
set in the Function settings
(page 29 Function 014).

SHORTCUT
You can jump directly to the
Functions Settings by press­ing and holding the [ULTRA­WIDE STEREO] button for
longer than a second.

PSR-E233/YPT-230 Owner’s Manual

15

Play with a Style

GrandPno

001

001

5

Press the [STYLE] button to access the
Style Functions (printed below).

2

1

3

NOTE

8BtModrn

001

001

Style number Style name

NOTE

This instrument has an auto accompaniment feature that produces accompaniment
(rhythm + bass + chords) in the style you choose to match chords you play with your
left hand. You can select from 100 different styles covering a range of musical genres
and time signatures.

Select a Style Rhythm

Most Styles include a rhythm part. Let’s begin by listening to just the basic rhythm. The rhythm part is played
using percussion instruments only.

Press the [STYLE] button and then select the desired Style, referring to the section “Basic Operation” on page 12
for instructions.
Refer to the Style List on page 40.

• To adjust the tempo of the
Style, see page 27.

Press the [START/STOP] button to play back the Style rhythm.
Press the [START/STOP] button a second time when you want to stop playback.

• Since the Pianist category
Styles (093–100) have no
rhythm parts, no sound will
be produced if you start
rhythm-only playback.
To use these Styles, turn on
the auto accompaniment
and play the keyboard as
described on page 17 (The
bass and chord accompani­ment parts will sound.)

PSR-E233/YPT-230 Owner’s Manual

16

Play with a Style

Appears when auto
accompaniment is on

NOTE

Split Point........default setting: 54 (F#2)

Auto

Accompaniment

range

Flashes when Sync Start is on.

NOTE

NOTE

Play Along with a Style

Here we’ll see how to add bass and chord accompaniment to the basic rhythm to produce a full, rich accompani­ment that you can play along with.

Press the [STYLE] button and select the desired Style.

1

For instructions on how to select a Style, see page 12.

Press the [ACMP ON/OFF] button to turn automatic accompani-

2

ment on.

Pressing this button a second time will turn automatic accompaniment off.

LoveSong

001

When auto accompaniment is on ...

The keys to the left of the Split Point (54; F#2) will play only chords. This is
known as the “Auto Accompaniment range.”

36 48

Press the [SYNC START] button to turn the Sync Start function on.

3

018

LoveSong

001

Start playing.

4

Style playback will begin as soon as you play a chord in the Auto Accompani-

7260

ment range of the keyboard. Try playing other chords with your left hand and
play a melody with your right hand.

Stop playing.

5

Playback will stop as soon as you press the [START/STOP] button.

You can also stop playing by pressing the [INTRO/ENDING/rit.] button so that
an appropriate ending pattern will play and then Style playback will stop (page

18).

• The Split Point setting can
be changed in the Function
settings (page 29 Function

005).

• You can also press the
[START/STOP] button to
begin the rhythm of the
selected Style. The bass
and chords will begin play­ing as soon as you play a
key in the Auto Accompani­ment range of the keyboard.

• The Style Volume can be
adjusted in the Function set­tings (page 29 Function

001).

SHORTCUT
You can jump directly to the
Functions Settings by press­ing and holding the [STYLE]
button for longer than a sec­ond.

PSR-E233/YPT-230 Owner’s Manual

17

Play with a Style

Adding an Intro

Pressing the [INTRO/ENDING/rit.] button before playing back the
Style automatically adds a short introduction before starting the
actual (Main) rhythm.
When the intro finishes playing, Style playback shifts to the Main
Section.

Adding an Ending

Press the [INTRO/ENDING/rit.] button to begin playing an ending
Section. Playback will stop when the ending has played all the way
through.

If you press the [INTRO/ENDING/rit.] button a second time (while
the ending is playing) the ending will play ritardando (the tempo will
gradually get slower).

Switching Main Sections

There are two variations on the basic pattern
(A and B).
This switches between the Main A and Main B
Sections, automatically playing a fill-in pattern
to smoothly lead into the next Section.
You can also select either the Main A or B
Section to start by pressing the [MAIN/AUTO
FILL] button before starting the Style.

Adding a Fill-in

A Fill-in pattern is automatically added before
changing to section A or B.

Pattern Variation (Sections)

The instrument features a wide variety of Style “Sections” (patterns) that allow you to vary the
arrangement of the accompaniment to match the Song you are playing.

Recommended method for using Sections

 Setup

1. Press the [STYLE] button and then select a Style.

2. Press the [ACMP ON/OFF] button to turn auto accompaniment on.

3. Press the [INTRO/ENDING/rit.] button.

4. Press the [MAIN/AUTO FILL] button to select Main A or Main B.

5. Press the [SYNC START] button to turn Sync Start on.

You’re now ready to play the intro.

 Start playing

6. As soon as you play a chord with your left hand, the Intro of the selected Style starts.

7. Press the [MAIN/AUTO FILL] button. (Switching Main Sections/Adding a Fill-in)

 Ending

8. Press the [INTRO/ENDING/rit.] button. (Adding an Ending)

An appropriate ending Sections will play and then Style playback will stop.

You can have the ending gradually slow down (ritardando) by pressing the [INTRO/ENDING/rit.] button again
while the ending is playing back.

PSR-E233/YPT-230 Owner’s Manual

18

Play with a Style

Cm

7

C

Dm

7

D

Em

7

E

Fm

7

F

Gm

7

G

GM

7

Am

7

A

B

Bm

BM

7

Cm

7

Chords

For users who are new to chords, this chart conveniently shows common chords for your reference. Since there are
many useful chords and many different ways to use them musically, refer to commercially available chord books
for further details. You can also look up chords using the Chord Dictionary function in this instrument (page 20).

 Indicates the root note.

Major Minor Seventh Minor Seventh Major Seventh

C

Cm

7

CM

7

D

E

C

F

G

A

B

7

• Inversions can be used as well as in “root” position—with the following exceptions: m7, m7b5, 6, m6, sus4, aug, dim7, 7b5, 6(9), sus2

• Inversion of the 7sus4 and m7(11) chords are not recognized if the notes are omitted.

• Sus2 chords are indicated by the root name only.

• If you play a chord which does not exist, the name of chord is not shown in the display, and the Style plays back only rhythm and bass.

Dm

Em

Fm

Gm

Am

Bm

7

7

7

7

7

7

DM

EM

FM

AM

7

7

7

7

Easy Chords

This method lets you easily play chords in the accompaniment range of the keyboard using only one, two, or three
fingers.

For root “C”

C

To play a major chord

Press the root note ()
of the chord.

Cm

To play a minor chord

Press the root note
together with the nearest
black key to the left of it.

C

7

To play a seventh chord

Press the root note
together with the nearest
white key to the left of it.

To play a minor seventh chord

Press the root note together with
the nearest white and black keys
to the left of it (three keys alto­gether).

PSR-E233/YPT-230 Owner’s Manual

19

Play with a Style

Hold for longer
than a second.

Dict.

001

Keys for chord type

dictionary

Keys for root

dictionary

The highest key

NOTE

Dict.

001

Notation of chord

Chord name (root and type)

Individual notes of chord
(keyboard)

Looking up Chords Using the Chord Dictionary

The Dictionary function is essentially a built-in “chord dictionary” that shows you the individual notes of chords.
This is convenient when you know the name of a certain chord and want to quickly learn how to play it.

Press and hold the [3 WAITING] button for longer than a second.

1

“Dict.” will appear in the display.

As an example, we’ll learn how to play a GM7 (G major seventh)

2

chord. Press the “G” key in the section of the keyboard labeled
“ROOT .” (The note doesn’t sound.)

The root note you set is shown in the display.

Press the “M7” (major seventh) key in the section of the keyboard

3

labeled “CHORD TYPE .” (The note doesn’t sound.)

The notes you should play for the specified chord (root note and chord type) are
shown in the display, both as notation and in the keyboard diagram.

To call up possible inversions of the chord, press the [+]/[-] buttons.

Try playing a chord in the auto accompaniment range (refer on

4

page 17) of the keyboard, checking the indications in the display.

When you’ve played the chord properly, a bell sound signals your success and
the chord name in the display flashes.

PSR-E233/YPT-230 Owner’s Manual

20

• Major chords are usually
indicated by the root name
only. For example, the indi­cation “C” in a score refers
to a “C Major” chord. To look
up the fingering for a major
chord press the root key and
then the M chord type key.

• These chords are not shown
in the Chord Dictionary func­tion: 6(9), M7(9), M7(

b

5, M7b5, M7aug, m7(11),

mM7(9), mM7

#

11 ),

b

5, 7b5, sus2

Play with a Style

Standard Chords

Easy Chords

Try Playing a Song with a Style!

Let’s try out the Song “Aura Lee.” For information on how to play Styles using chords, see pages 17 and 18.
Try playing chords with your left hand and play a melody with your right hand.

Practice

Aura Lee

Recommended Style: 018 LoveSong
Recommended Voice: 034 Strings 1

Composer: G. Poulton

C D

C D

G

G

F

F

A

A

G

7

G

7

PSR-E233/YPT-230 Owner’s Manual

21

Playing Songs

GrandPno

001

001

SongStart/Stop DEMO/BGM

Press the [SONG] button to access the SONG
functions (printed above the buttons).

Mirliton

004

005

Song number Song name

This instrument has 102 built-in Songs. For this instrument, the term “Song” refers to
the data that makes up a piece of music. Try selecting and listening to the various Songs.

Select and Listen to a Specific Song

Press the [SONG] button and then select the desired Song, referring to the section
“Basic Operation” on page 12 for instructions.
Refer to the Song List on page 39.

Press the [START/STOP] button to play back the Song.
You can stop playback at any time by pressing the [START/STOP] button.

NOTE

• Song number “004” is automat­ically selected whenever the
power is turned ON. When you
want to select one of the Song
numbers 001–003, use the
number buttons [0]–[9], [+], [-].

• To adjust the tempo of song
playback, see page 27.

• You can adjust the balance
between Song playback and
the notes you play on the key­board by setting the volume of
the playback sound (page 29
Function 002).

SHORTCUT
You can jump directly to the
Function settings by pressing
and holding the [SONG] button
for longer than a second.

Rewind/Fast-forward/Pause

[REW] button............Fast-reverses the Song if pressed during playback (no sound is heard during fast

reverse). Decreases the measure number if pressed while playback is stopped.

[FF] button ................Fast-forwards the Song if pressed during playback. Increases the measure number if

[PAUSE] button.........Temporarily stops playback. Press this button a second time to resume playback from

pressed while playback is stopped.

the point at which it was stopped.

22

PSR-E233/YPT-230 Owner’s Manual

Playing Songs

NOTE

Hold for longer than a second.

NOTE

Changing the Melody Voice

You can change a Song’s melody Voice to any other desired Voice.
Select the desired Voice by using the number buttons [0]–[9], [+], [-].
After selecting the Song and playing it, press and hold the [VOICE] button for longer than a second.
“SONG MELODY VOICE” appears in the display for a few seconds, the selected Voice replaces the Song’s origi­nal melody Voice.

Listening to the Demo Songs

Press the [DEMO] button.

Songs 001, 002, 003 play in sequence, and playback will continue repeatedly starting again from the first Song 001.
You can stop playback at any time by pressing the [DEMO] or [START/STOP] button.

BGM Playback

With the default setting only a few of the internal songs are played back and repeated when the [DEMO/BGM]
button is pressed. This setting can be changed so that all internal songs are played.
Four playback group settings are provided. Simply select the one that suits your needs.

Press and hold the [DEMO/BGM] button for longer than a sec-

1

ond.

“DemoGrp” will appear in the display for a few seconds, then the currently
selected repeat playback target will be displayed.

Use the [+] or [-] button to select a repeat playback group from the

2

table below.

Demo Preset songs (001–003)

Preset All preset songs (001–102)

Press the [DEMO/BGM] button.

3

The songs in the group selected play in sequence.
You can stop playback at any time by pressing the [DEMO] or [START/STOP]
button.

Random Song Playback

The Random Play mode causes the songs in the group selected for BGM playback to be played back in random
order. (Demo group Songs [Preset Songs 001–003] cannot be played at random.)

The setting of the Random Play mode can be set in the Function settings (page 30 Function 022).

• You can also set the demo
group in the Function set­tings (page 30 Function

021).

• You can select a song by
using the [+] button after
pressing the [DEMO/BGM]
button. The [-] button can be
used to go back to the
beginning of the selected
song.

PSR-E233/YPT-230 Owner’s Manual

23

Using the Lesson Feature

The notation and key positions of the model melody are
shown in the display.

NOTE

Song Lesson

You can select any Song you like and use it for a left-hand, right-hand, or both-hands lesson. Song Lesson lets you
learn how to play Songs in three easy steps.

The Lesson modes:

 Lesson 1 (Listen & Learn)

There’s no need to play the keyboard in this mode. The model melody/chords (in
other words, the musical material you should learn) of the part you selected will
sound. Listen to it carefully and learn it well.

LISTEN

004

 Lesson 2 (Timing)

In this mode, try playing the notes with the correct timing. Simply concentrate on
playing each note in time with the rhythmic accompaniment. The correct notes
sound even if you play wrong notes as long as you play in time with the rhythm. Play
the notes shown in the display.

TIMING

004

 Lesson 3 (Waiting)

In this mode, try playing the correct notes. The notes you should play appear in the
score and the keyboard on the display. The Song pauses until you play the right note.
Song playback tempo will vary to match the speed you are playing at. The song will
slow down when you play wrong notes, so you can learn at your own pace and
tempo.

WAITING

004

• When you don’t want to
change the Song playback
tempo, or you want to learn
using the original tempo,
you can change the setting
in the Function settings
(page 30 Function 020).

PSR-E233/YPT-230 Owner’s Manual

24

Lesson Operation

NOTE

RightLeft

BothHand

Left-hand lesson Right-hand lesson

Both-hands lesson

NOTE

NOTE

NOTE

NOTE

Select the desired Song for your lesson.

1

For instructions on how to select a Song, see page 12.

Select the part you want to practice.

2

Press the [R] button for a right-hand lesson, [L] button for a left-hand lesson, or
press both the [R] and [L] buttons simultaneously for a both-hands lesson.
The selected part is displayed.

Using the Lesson Feature

• The following songs are
intended for use as right­hand lessons, and cannot
be used for left-hand or
both-hands lessons. If you
select a right-hand lesson
Song, a “No LPart” mes­sage is shown in the display.

Song numbers: 001

Select the Lesson mode.

3

Press any one of the [1 LISTEN & LEARN], [2 TIMING] or [3 WAITING] but­tons. Refer to the Lesson modes on page 24.

Start Lesson.

4

Song playback will begin automatically when you select the Lesson mode, and
the appropriate notes appear in the display.

Stop the Lesson mode.

5

You can stop the Lesson mode at any time by pressing the [START/STOP] but­ton.

Grade

When the Lesson Song has played all the way through in Lesson mode “2 Timing”
or “3 Waiting,” your performance will be evaluated in four levels: OK, Good, Very
Good, or Excellent.

• When the melody Voice of
the Song is changed, the
key position shown in the
display may be shifted (in
octave units), depending on
the Voice selected.

• You can select Lessons 1–3
by pressing the [LISTEN &
LEARN], [TIMING] and
[WAITING] buttons, respec­tively.

• The Split Point is fixed and it
cannot be changed. For the
left-hand lesson, it is fixed at
59 or B2; for the left-hand
chord lesson, it is fixed at 54
or F

#

2.

• Regardless of how strongly
you play the keys, the level
of the sound does not
change. As a result, your
performance may not sound
exactly like the model or
example, depending on the
selected song.

PSR-E233/YPT-230 Owner’s Manual

25

Using the Lesson Feature

Repeat playback of this section

NOTE

REPEAT

A−b

NOTE

Demo 1

001

010

Pressing one of the Track
buttons [R] or [L] will mute
the corresponding track
during Song playback.

Lit: Track contains data. Unlit: Track is muted or contains no data.

A-B Repeat

This function lets you specify a section of a Song—“A” is the start point and “B” is the end point—for repeat
playback.

AB

Play the Song and press the [A-B REPEAT] button at the beginning of the section
you want to repeat (the “A” point), then press the [A-B REPEAT] button a second
time at the end of the section you want to repeat (the “B” point). The specified A-B
section of the Song will now play repeatedly.

• The repeat start and end
points can be specified in
one-measure increments.

• You can also set the A-B
Repeat function when the
Song is stopped. Simply use
the [REW] and [FF] buttons
to select the desired mea­sures, pressing the [A-B
REPEAT] button for each
point, then start playback.

• If you want to set the start
point “A” at the very begin­ning of the Song press the
[A-B REPEAT] button before
starting playback of the
Song.

You can stop repeat playback at any time by pressing the [A-B REPEAT] button.
An “oFF REPEAT” message appears on the display. The A-B REPEAT mode will be
canceled and normal playback of the Song will continue.

• The A-B Repeat function will
be canceled when you
select another Song mode.

Mute

The Song is made up by several tracks.
You can mute Track 1 or Track 2 during Song playback. You can turn the left- and right-hand parts on or off as
desired, allowing you to listen to the corresponding part (the part that is turned on), or practice the corresponding
part (the part that is turned off) on the keyboard.

You can cancel the mute function by pressing the corresponding track buttons, [R] or [L] again during Song play­back, or by selecting any other Song.

PSR-E233/YPT-230 Owner’s Manual

26

• Track 1 can be muted by pressing the [R] button during Song playback.

• Track 2 or style track can be muted by pressing the [L] button during Song playback.

Using the Lesson Feature

NOTE

NOTE

Tempo

070

Current Tempo value

NOTE

NOTE

Using the Metronome

The instrument features a built-in metronome (a device that keeps an accurate tempo) that is convenient for prac­ticing.

Press the [METRONOME] button to start the metronome.

To stop the metronome, press the [METRONOME] button again.

You can adjust the metronome tempo by pressing the [TEMPO/TAP] button (see
next section).

Changing the Tempo

Songs and Styles can be played at any tempo you desire—fast or slow.

Press the [TEMPO/TAP] button to call up the Tempo setting in

1

the display.

• You can set the time signa­ture and the volume of the
Metronome (page 29 Func­tion 018–019).

SHORTCUT
You can jump directly to the
Function settings by press­ing and holding the [MET­RONOM E] bu tton for longer
than a second.

• The metronome time signa­ture will synchronize to a
style or song that is playing,
so these parameters cannot
be changed while a style or
song is playing.

Set the Tempo by using the number buttons [0]–[9], [+], [-].

2

Tap Start

You can supply a count-in at any tempo you like to start playback. Simply tap the
[TEMPO/TAP] button at any tempo—four times for time signatures in 4, and three
times for time signatures in 3—and the selected Song and Style rhythm will begin
playing at the tapped tempo.

You can change the tempo during Song or Style playback by pressing the button just
twice.

PSR-E233/YPT-230 Owner’s Manual

• Press the [+] and [-] buttons
simultaneously to instantly
reset the value to the default
tempo.

• In the case of a Style, the
selected Style rhythm will
begin playing at first. The
bass and chords will begin
playing as soon as you play
a chord in the auto accom­paniment range of the key­board (when auto
accompaniment is on).

27

Function Settings

NOTE

001

StyleVol

100

Val ue Function item

Function number

NOTE

Direct numeric entry.

• Decrement value by 1.

• No

• Off

• Increment value by 1.

• Yes

• On

Press simultaneously to
recall the default setting.

The [FUNCTION] button gives you access to a variety of operations related to adjusting
or enhancing the sound and making settings for connection to external devices.
For more about the available functions, see the following Function Setting List.

Select the item and change the value

Press the [FUNCTION] button a number of times until the

1

desired item appears.

Each time the [FUNCTION] button is pressed, the Function number increases
one by one.
You can also decrease the Function number by one when you press the [-] but­ton briefly while holding down the [FUNCTION] button.

If the Function includes sub-modes, the Function item appears in the display for
a few seconds, and the sub-modes will be displayed.

• The Function number will
not appear in the display
during Song, Style or metro­nome playback. The mea­sure will appear instead.

Set the value by using the number buttons [0]–[9], [+], [-].

2

• Any settings will be restored
to the factory default settings
when the power is turned
off.

• To exit the Function settings,
press one of these buttons;
[SONG], [VOICE],[STYLE]
or [GRAND PIANO].

PSR-E233/YPT-230 Owner’s Manual

28

Function Settings

Function Setting List

No. Item Display

Vol um e

001 Style Volume StyleVol 000–127 100 Determines the volume of the Style.

002 Song Volume SongVol 000–127 100 Determines the volume of the Song.

Overall

003 Transpose Transpos -12–00–12 00

004 Tuning Tuning

005 Split Point SplitPnt

Main Voice

006 Main Voice Volume M.Volume 000–127 *

007 Main Voice Octave M.Octave -2–0–2 * Determines the octave range for the Main Voice.

Main Voice Chorus

008

Send Level

Effect

009 Reverb Type Reverb 01 –10 **

010 Reverb Level RevLevel 000–127 64

011 C hor u s Typ e Chorus 1–5 **

012 Panel Sustain Sustain ON/OFF OFF

013 M a ste r EQ Type MasterEQ

014 W ide Typ e Wide 1–3 2

MIDI

015 Local On/Off Local ON/OFF ON

016 External Clock ExtClock ON/OFF OFF

017 Initial Setup Send InitSend YES/NO –

Metronome

018 Time Signature TimeSig 00–15 **

019 Metronome Volume MetroVol 000–127 100 Determines the volume of the Metronome.

M.Chorus 000–127 *

Range/

settings

427.0–453.0
(Hz)

000–127
(C-2–G8)

1 Speaker
2 Flat

Default

setting

440.0 (Hz)

54 (F#2)

1 Speaker

Description

Determines the pitch of the instrument in semitone increments.
NOTE: The pitch of the Drum Kits Voices cannot be changed.

Determines the fine tuning of the pitch of the entire instrument
in approx. 0.2Hz increments.
NOTE: The pitch of the Drum Kits Voices cannot be changed.

Sets the Split “point”—in other words, the key that separates the
auto accompaniment range and Main voice.

Determines the volume of the Main Voice to adjust the balance
between Song playback and the notes you play on the key­board.

Determines how much of the Main Voice’s signal is sent to the
Chorus effect.

Determines the Reverb type, including off (10).
Refer to the Reverb Type list on page 41.

Determines how much of the Voice’s signal is sent to the
Reverb effect.

Determines the Chorus type, including off (05).
Refer to the Chorus Type list on page 41.

Determines whether or not Panel Sustain is always applied to
the Main Voices. Panel Sustain is applied continuously when
ON, or not applied when OFF.

Sets the equalizer applied to the speaker output for optimum
sound in different listening situations.

Speaker: For listening via the instrument’s built-in speakers.
Flat: For headphones, or for listening via external speakers.

Determines the Ultra-Wide Stereo type.
Higher values produce a greater Wide effect.

Determines whether the instrument’s keyboard controls the
internal tone generator (ON) or not (OFF).

On

Both the notes played on the instrument’s keyboard and data
received via the instrument’s MIDI terminal will be played by
the internal tone generator.

Off

With this setting, the instrument itself produces no sound, but
the performance data is transmitted via the MIDI terminal.
Data received via the instrument’s MIDI terminal will also be
played by the internal tone generator.

Determines whether the instrument synchronizes to the inter­nal clock (OFF) or an external clock (ON).

Lets you send the data of the panel settings to a computer.
Use the [+] button to transmit the data.

Determines the time signature of the Metronome.
A chime will sound on the first beat of each measure while the
other beats will click. All beats will simply click with no chime at
the beginning of each measure if you set this parameter to “00”.

PSR-E233/YPT-230 Owner’s Manual

29

Function Settings

No. Item Display

Lesson

020 Your Tempo YourTem p ON/OFF ON

Demo

021 Demo Group DemoGrp

022 Demo Play Mode PlayMode

023 Demo Cancel D-Cancel ON/OFF OFF

Power Save

024 Auto Power Off AutoOff ON/OFF ON

* Different for each voice combination.
** Different for each Song or Style combination.

Range/

settings

1 DEMO
2 Preset
3 User
4 Download

1 Normal
2 Random

Default

setting

1 DEMO Determines the repeat playback group.

1 Normal Determines the repeat playback mode.

Description

Determines whether the song playback tempo matches the
speed at which you are playing (ON) or not (OFF), when using
the “Waiting” Lesson mode.

Determines whether Demo cancel is enabled or not. When this
is set to ON, the Demo Song will not play, even if the [DEMO/
BGM] button is pressed.

Determines whether the Auto Power Off function is on or off.
When this is set to ON, the instrument automatically turns the
power off if the instrument is not used for approximately 30
minutes.

PSR-E233/YPT-230 Owner’s Manual

30

About MIDI

CAUTION

PSR-E233/

YPT-230

MIDI OUT

MIDI IN

MIDI device

MIDI IN

MIDI OUT

(Rear)

USB

A USB-MIDI interface

(such as the Yamaha UX16)

PSR-E233/

YPT-230

MIDI OUTMIDI IN

The instrument features a MIDI terminals that can be connected to other MIDI instru­ments and devices for expanded musical functionality.

What is MIDI?

MIDI (Musical Instrument Digital Interface) is a world-standard interface for
communication between electronic musical instruments and music devices. When
MIDI-equipped instruments are connected via a MIDI cable, it becomes possible
to transfer performance and setting data between them for significantly enhanced
performance and production potential.

Transferring Performance Data To and From Another Instrument

By connecting the instrument to other MIDI devices or a computer, the perfor­mance data of the instrument can be used on those other MIDI devices or com­puter, and also the performance data from other MIDI devices and computer can
be received and sounded with the instrument.
A Yamaha UX16 or similar USB-MIDI interface (sold separately) will be neces­sary for MIDI connection between the instrument and a USB-equipped computer.
Make sure to purchase a Yamaha UX16 or a quality USB-MIDI interface at a
musical instrument store, computer store or electrical appliance store.
If you use the UX16 interface, install the driver supplied with the interface on your
computer.
MIDI settings such as Local Control are made in the Function settings (page 29
Function 015–017).

• Connect the instrument to
external equipment only after
turning off power for all
devices. Then, turn on the
power, first to the instrument,
then to the connected exter­nal equipment. Reverse this
order when you turn the
power off.

NOTE

• MIDI cables (sold separately)
must be used for connecting to
MIDI devices. They can be
bought at music stores, etc.

NOTE

• Preset Song data cannot be
transmitted from the instrument
by the Song Out function.

When the instrument is connected with another MIDI device, it transmits/receives performance data.

When the instrument is connected with a computer, it transmits/receives performance data.

PSR-E233/YPT-230 Owner’s Manual

31

Appendix

Troubleshooting

Problem Possible Cause and Solution

When the instrument is turned on or off, a popping
sound is temporarily produced.

When using a mobile phone, noise is produced. Using a mobile phone in close proximity to the instrument may produce inter-

There is no sound even when the keyboard is played or
when a song or style is being played back.

Not all of the voices seem to sound, or the sound seems
to be cut off.

Playing keys in the right hand area of the keyboard does
not produce any sound.

The Style or Song does not play back when the [START/
STOP] button is pressed.

The ACMP ON indicator does not appear when the
[ACMP ON/OFF] button is pressed.

The Style does not sound properly.

The footswitch (for sustain) seems to produce the oppo­site effect. For example, pressing the footswitch cuts off
the sound and releasing it sustains the sounds.

Regardless of how strongly play the keys, the level of
the sound does not change.

• The volume is too soft.

• The sound quality is poor.

• The rhythm stops unexpectedly or will not play.

• The Song, etc. does not play correctly.

Power suddenly and unexpectedly turns off. This is normal and the Auto Power Off function may have been activated

This is normal and indicates that the instrument is receiving electrical power.

ference. To prevent this, turn off the mobile phone or use it further away from
the instrument.

Check that nothing is connected to the PHONES/OUTPUT jack on the rear
panel. When a set of headphones is plugged into this jack, no sound is output.

Check the Local Control on/off. (See page 29 Function 015.)

The instrument is polyphonic up to a maximum of 32 notes. If a style or Song
is playing back at the same time, some notes/sounds may be omitted (or “sto­len”) from the accompaniment or Song.

When using the Dictionary function (page 20), the keys in the right hand area
are used only for entering the chord root and type.

Is External Clock set to ON? Make sure External Clock is set to OFF; refer to
“Function Settings” on page 29 (Function 016).

Always press the [STYLE] button first when you are going to use any style­related function.

Make sure that the Style Volume (page 29 Function 001) is set to an appropri­ate level.

Is the Split Point set at an appropriate key for the cords you are playing? Set
the Split Point at an appropriate key (page 29 Function 005).
Is the “ACMP ON” indicator showing in the display? If it is not showing press
the [ACMP ON/OFF] button so that it does show.

• The auto accompaniment will sometimes not change when related chords
are played in sequence (e.g. some minor chords followed by the minor sev­enth).

• Two-note fingerings will produce a chord based on the previously played
chord.

• Playing two same root keys in the adjacent octaves produces accompani­ment based only on the root.

The polarity of the footswitch is reversed. Make sure that the footswitch plug is
properly connected to the SUSTAIN jack before turning on the power.

Since this keyboard does not have touch response, the level of the sound
does not change in response to your playing strength.

The batteries are low or dead. Replace all six batteries with completely new
ones, or use the optional AC adaptor.

(page 9). If you need to disable the Auto Power Off function, select “Off ” in the
Function settings (page 30 Function 024).

PSR-E233/YPT-230 Owner’s Manual

32

Voice List

Maximum Polyphony

The instrument has 32-note maximum polyphony. This
means that it can play a maximum of up to 32 notes at once,
regardless of what functions are used. Auto accompaniment
uses a number of the available notes, so when auto
accompaniment is used the total number of available notes
for playing on the keyboard is correspondingly reduced. The
same applies to the Split Voice and Song functions. If the
maximum polyphony is exceeded, earlier played notes will
be cut off and the most recent notes have priority (last note
priority).

NOTE

• The Voice List includes MIDI program change numbers for each
voice. Use these program change numbers when playing the
instrument via MIDI from an external device.

• Program Numbers 001 to 128 directly relate to MIDI Program
Change Numbers 000 to 127. That is, Program Numbers and Pro­gram Change Numbers differ by a value of 1. Remember to take
this into consideration.

• Some voices may sound continuously or have a long decay after
the notes have been released while the sustain pedal (footswitch)
is held.

Panel Voice List

LSB

MIDI

Program

Change#

(1–128)

PIANO

E.PIANO

ORGAN

ACCORDION

GUITAR

BASS

STRINGS

Voice Name

Voice

Bank Select

MSB

No.

(0–127)

(0–127)

1 0 112 1 Grand Piano1
2 0 0 1 Grand Piano2
3 0 0 2 Bright Piano
4 0 0 4 Honky-tonk Piano
5 0 0 7 Harpsichord

6 0 0 5 Electric Piano 1
7 0 0 6 Electric Piano 2
8 0 0 3 Electric Grand Piano
9008Clavi

10 0 0 17 Drawba r O rgan
11 0 0 18 Percussive Organ
12 0 0 19 Ro ck O rgan
13 0 0 20 Church Organ
14 0 0 21 Reed Organ

15 0 0 22 Accordion
16 0 0 24 Tango Accordion
17 0 0 23 Harmonica

18 0 0 25 Nylon Guitar
19 0 0 26 Steel Guitar
20 0 0 27 Jazz Guitar
21 0 0 28 Clean Guitar
22 0 0 29 Muted Guitar
23 0 0 30 Overdriven Guitar
24 0 0 31 Distortion Guitar
25 0 0 32 Guitar Harmonics

26 0 0 33 Acoustic Bass
27 0 0 34 Finger Bass
28 0 0 35 Pick Bass
29 0 0 36 Fretless Bass
30 0 0 37 Slap Bass 1
31 0 0 38 Slap Bass 2
32 0 0 39 Synth Bass 1
33 0 0 40 Synth Bass 2

34 0 0 49 Strings 1
35 0 0 50 Strings 2
36 0 0 51 Synth Strings 1
37 0 0 52 Synth Strings 2

LSB

MIDI
Program
Change#

(1–128)

CHOIR

SAXOPHONE

TRUMPET

BRASS

FLUTE

SYNTH

Voi c e N a m e

Voi ce

Bank Select

MSB

No.

(0–127)

(0–127)

38 0 0 45 Tremolo Strings
39 0 0 46 Pizzicato Strings
40 0 0 41 Violin
41 0 0 42 Viola
42 0 0 43 Cello
43 0 0 44 Contrabass
44 0 0 47 Orchestral Harp
45 0 0 56 Orchestra Hit

46 0 0 53 Choir Aahs
47 0 0 54 Voice Oohs
48 0 0 55 Synth Voice

49 0 0 67 Tenor Sax
50 0 0 66 Alto Sax
51 0 0 65 Soprano Sax
52 0 0 68 Baritone Sax
53 0 0 69 Oboe
54 0 0 72 Clarinet
55 0 0 70 English Horn
56 0 0 71 Bassoon

57 0 0 57 Trumpet
58 0 0 60 Muted Trumpet
59 0 0 58 Trombone
60 0 0 61 French Horn
61 0 0 59 Tuba

62 0 0 62 Brass Section
63 0 0 63 Synth Brass 1
64 0 0 64 Synth Brass 2

65 0 0 74 Flute
66 0 0 73 Piccolo
67 0 0 76 Pan Flute
68 0 0 75 Recorder
69 0 0 77 Blown Bottle
70 0 0 78 Shakuhachi
71 0 0 79 Whistle
72 0 0 80 Ocarina

73 0 0 81 Square Lead

74 0 0 82 Sawtooth Lead
75 0 0 83 Calliope Lead
76 0 0 84 Chiff Lead

PSR-E233/YPT-230 Owner’s Manual

33

Voice List

Voice

Bank Select

MSB

No.

(0–127)

(0–127)

77 0 0 85 Charang Lead
78 0 0 86 Voice Lead
79 0 0 87 Fifths Lead
80 0 0 88 Bass & Lead
81 0 0 89 New Age Pad
82 0 0 90 Warm Pad
83 0 0 91 Poly Synth Pad
84 0 0 92 Choir Pad
85 0 0 93 Bowed Pad
86 0 0 94 Metallic Pad
87 0 0 95 Halo Pad
88 0 0 96 Sweep Pad
89 0 0 97 Rain
90 0 0 98 Sound Track
91 0 0 99 Crystal
92 0 0 100 Atmosphere
93 0 0 101 Brightness
94 0 0 102 Goblins
95 0 0 103 Echoes
96 0 0 104 Sci-Fi

97 0 0 12 Vibraphone
98 0 0 13 Marimba

99 0 0 14 Xylophone
100 0 0 115 Steel Drums
101 0 0 9 Celes ta
102 0 0 11 Mu sic Box
103 0 0 15 Tubular Bells
104 0 0 48 Timpani
105 0 0 10 Glockenspiel
106 0 0 113 Tinkle Bell
107 0 0 114 A gogo
108 0 0 116 Woodblock
109 0 0 117 Taiko Drum
110 0 0 118 Melodic Tom
111 0 0 119 Synth Drum
112 0 0 120 Reverse Cymbal

113 0 0 10 5 S i ta r
114 0 0 16 Dulcimer
115 0 0 106 Banjo
116 0 0 107 Shamisen
117 0 0 10 8 K o to
118 0 0 10 9 K a li m b a
119 0 0 110 Bagpipe
120 0 0 111 Fiddle
121 0 0 112 Shanai

122 0 112 1 Octave Piano
123 0 112 1 Piano + Strings
124 0 112 1 Piano Pad
125 0 0 6 E.P. Pad
126 0 0 49 Octave Strings
127 0 0 62 Orchestra Tutti
128 0 0 49 Octave Choir
129 0 0 53 Octave Brass
130 0 0 62 Jazz Section
131 0 0 74 Flute & Clarinet

1320 0121Fret Noise
1330 0122Breath Noise
134 0 0 123 Seashore
1350 0124Bird Tweet

MIDI

Program

LSB

Change#

(1–128)

PERCUSSION

WORLD

DUAL

SOUND EFFECTS

Voice Name

LSB

MIDI
Program
Change#

(1–128)

DRUM KITS

XGlite

Voi c e N a m e

Voi ce

Bank Select

MSB

No.

(0–127)

(0–127)

136 0 0 125 Telephone Ring
137 0 0 126 Helicopter
138 0 0 127 Applause
1390 0128Gunshot

140 127 0 1 Standard Kit 1
141 127 0 2 Standard Kit 2
142 127 0 9 Room Kit
143 127 0 17 Rock Kit
144 127 0 25 Electronic Kit
145 127 0 26 Analog Kit
146 127 0 28 Dance Kit
147 127 0 33 Jazz Kit
148 127 0 41 Brush Kit
149 127 0 49 Symphony Kit
150 126 0 1 SFX Kit 1
151 126 0 2 SFX Kit 2
152 126 0 113 Sound Effect Kit

153 0 1 1 Grand Piano KSP
154 0 40 1 Piano Strings
155 0 41 1 Dream
156 0 1 2 Bright Piano KSP
157 0 1 3 Electric Grand Piano KSP
158 0 32 3 Detuned CP80
159 0 1 4 Honky-tonk Piano KSP
160 0 1 5 Electric Piano 1 KSP
161 0 32 5 Chorus Electric Piano 1
162 0 1 6 Electric Piano 2 KSP
163 0 32 6 Chorus Electric Piano 2
164 0 41 6 DX + Analog Electric Piano
165 0 1 7 Harpsichord KSP
166 0 35 7 Harpsichord 2
167 0 1 8 Clavi KSP
168 0 64 11 Orgel
169 0 1 12 Vibraphone KSP
170 0 1 13 Marimba KSP
171 0 64 13 Sine Marimba
172 0 97 13 Balimba
173 0 98 13 Log Drums

174 0 96 15 Church Bells

175 0 97 15 Carillon

176 0 35 16 Dulcimer 2
177 0 96 16 Cimbalom
178 0 97 16 Santur
179 0 32 17 Detuned Drawbar Organ
180 0 33 17 60's Drawbar Organ 1
181 0 34 17 60's Drawbar Organ 2
182 0 35 17 70's Drawbar Organ 1
183 0 37 17 60's Drawbar Organ 3
184 0 40 17 16 +2'2/ 3
185 0 64 17 Organ Bass
186 0 65 17 70's Drawbar Organ 2
187 0 66 17 Cheezy Organ
188 0 67 17 Drawbar Organ 2
189 0 24 18 70's Percussive Organ
190 0 32 18 Detuned Percussive Organ
191 0 33 18 Light Organ
192 0 37 18 Percussive Organ 2
193 0 64 19 Rotary Organ
194 0 65 19 Slow Rotary
195 0 66 19 Fast Rotar y
196 0 32 20 Church Organ 3

PSR-E233/YPT-230 Owner’s Manual

34

Voice List

LSB

MIDI

Program

Change#

(1–128)

Voice Name

Velocity Crossfade Upright Bass

Bass & Distorted Electric Guitar

Voice

Bank Select

MSB

No.

(0–127)

(0–127)

197 0 35 20 Church Organ 2
198 0 40 20 Notre Dame
199 0 64 20 Organ Flute
200 0 65 20 Tremolo Organ Flute
201 0 40 21 Puff Organ
202 0 32 23 Harmonica 2
203 0 64 24 Tango Accordion 2
204 0 43 25 Velocity Guitar Harmonics
205 0 96 25 Ukulele
206 0 35 26 12-string Guitar
207 0 40 26 Nylon & Steel Guitar
208 0 41 26 Steel Guitar with Body Sound
209 0 96 26 Mandolin
210 0 32 27 Jazz Amp
211 0 32 28 Chorus Guitar
212 0 40 29 Funk Guitar
213 0 41 29 Muted Steel Guitar
214 0 45 29 Jazz Man
215 0 43 30 Guitar Pinch
216 0 40 31 Feedback Guitar
217 0 41 31 Feedback Guitar 2
218 0 65 32 Guitar Feedback
219 0 66 32 Guitar Harmonics 2
220 0 40 33 Jazz Rhythm
221 0 45 33
222 0 18 34 Finger Dark
223 0 40 34
224 0 43 34 Finger Slap Bass
225 0 45 34 Finger Bass 2
226 0 65 34 Modulated Bass
227 0 28 35 Muted Pick Bass
228 0 32 36 Fretless Bass 2
229 0 33 36 Fretless Bass 3
230 0 34 36 Fretless Bass 4
231 0 32 37 Punch Thumb Bass
232 0 43 38 Velocity Switch Slap
233 0 40 39 Techno Synth Bass
234 0 6 40 Mellow Synth Bass
235 0 12 40 Sequenced Bass
236 0 18 40 Click Synth Bass
237 0 19 40 Synth Bass 2 Dark
238 0 40 40 Modular Synth Bass
239 0 41 40 DX Bass
240 0 8 41 Slow Violin
241 0 8 45 Slow Tremolo Strings
242 0 40 45 Suspense Strings
243 0 40 47 Yang Chin
244 0 3 49 Stereo Strings
245 0 8 49 Slow Strings
246 0 35 49 60's Strings
247 0 40 49 Orchestra
248 0 41 49 Orchestra 2
249 0 42 49 Tremolo Orchestra
250 0 45 49 Velocity Strings
251 0 3 50 Stereo Slow Strings
252 0 8 50 Legato Strings
253 0 40 50 Warm Strings
254 0 41 50 Kingdom
255 0 3 53 Stereo Choir
256 0 32 53 Mellow Choir
257 0 40 53 Choir Strings
258 0 40 55 Synth Voice 2
259 0 41 55 Choral

LSB

MIDI
Program
Change#

(1–128)

Voi c e N a m e

Voi ce

Bank Select

MSB

No.

(0–127)

(0–127)

260 0 64 55 Analog Voice
261 0 35 56 Orchestra Hit 2
262 0 64 56 Impact
263 0 32 57 Warm Trumpet
264 0 18 58 Trombone 2
265 0 6 61 French Horn Solo
266 0 32 61 French Horn 2
267 0 37 61 Horn Orchestra
268 0 35 62 Trumpet & Trombone Section
269 0 20 63 Resonant Synth Brass
270 0 18 64 Soft Brass
271 0 41 64 Choir Brass
272 0 40 66 Sax Section
273 0 40 67 Breathy Tenor Sax

274 0 6 81 Square Lead 2
275 0 8 81 LM Square
276 0 18 81 Hollow
277 0 19 81 Shroud
278 0 64 81 Mellow
279 0 65 81 Solo Sine
280 0 66 81 Sine Lead
281 0 6 82 Sawtooth Lead 2
282 0 8 82 Thick Sawtooth
283 0 18 82 Dynamic Sawtooth
284 0 19 82 Digital Sawtooth
285 0 20 82 Big Lead
286 0 96 82 Sequenced Analog
287 0 65 83 Pure Lead
288 0 64 85 Distorted Lead
289 0 35 87 Big Five
290 0 16 88 Big & Low
291 0 64 88 Fat & Perky
292 0 65 88 Soft Whirl
293 0 64 89 Fantasy
294 0 66 92 Itopia
295 0 65 97 African Wind
296 0 66 97 Carib
297 0 27 98 Prologue
298 0 12 99 Synth Drum Comp
299 0 14 99 Popcorn
300 0 18 99 Tiny Bells

301 0 35 99 Round Glockenspiel
302 0 40 99 Glockenspiel Chimes
303 0 41 99 Clear Bells
304 0 42 99 Chorus Bells
305 0 65 99 Soft Crystal
306 0 70 99 Air Bells
307 0 71 99 Bell Harp
308 0 72 99 Gamelimba
309 0 18 100 Warm Atmosphere

310 0 19 100 Hollow Release

311 0 40 100 Nylon Electric Piano
312 0 64 100 Nylon Harp
313 0 65 100 Harp Vox
314 0 66 100 Atmosphere Pad
315 0 64 102 Goblins Synth
316 0 65 102 Creeper
317 0 67 102 Ritual
318 0 68 102 To Heaven
319 0 70 102 Night
320 0 71 102 Glisten
321 0 96 102 Bell Choir
322 0 32 105 Detuned Sitar

PSR-E233/YPT-230 Owner’s Manual

35

Voice List

LSB

MIDI

Program

Change#

(1–128)

Voice Name

Voice

Bank Select

MSB

No.

(0–127)

(0–127)

323 0 35 105 Sitar 2
324 0 97 105 Tamboura
325 0 28 106 Muted Banjo
326 0 96 106 Rabab
327 0 97 106 Gopichant
328 0 98 106 Oud
329 0 96 108 Taisho-kin
330 0 97 108 Kanoon
331 0 96 113 Bonang
332 0 97 113 Altair
333 0 98 113 Gamelan Gongs
334 0 99 113 Stereo Gamelan Gongs
335 0 100 113 Rama Cymbal
336 0 97 115 Glass Percussion
337 0 98 115 Thai Bells
338 0 96 116 Castanets
339 0 96 117 Gran Cassa
340 0 64 118 Melodic Tom 2
341 0 65 118 Real Tom
342 0 66 118 Rock Tom
343 0 64 119 Analog Tom
344 0 65 119 Electronic Percussion
345 64 0 1 Cutting Noise
346 64 0 2 Cutting Noise 2
347 64 0 4 String Slap
348 64 0 17 Flute Key Click
34964033Shower
350 64 0 34 Thunder
35164035Wind
35264036Stream
35364037Bubble
35464038Feed
355 64 0 49 Dog
356 64 0 50 Horse
357 64 0 51 Bird Tweet 2
358 64 0 56 Maou
359 64 0 65 Phone Call
360 64 0 66 Door Squeak
361 64 0 67 Door Slam
362 64 0 68 Scratch Cut
363 64 0 69 Scratch Split
364 64 0 70 Wind Chime
365 64 0 71 Telephone Ring 2
366 64 0 81 Car Engine Ignition
367 64 0 82 Car Tires Squeal
368 64 0 83 Car Passing
369 64 0 84 Car Crash
370 64 0 85 Siren
37164086Train
372 64 0 87 Jet Plane
37364088Starship
374 64 0 89 Burst
375 64 0 90 Roller Coaster
376 64 0 91 Submarine
377 64 0 97 Laugh
37864098Scream
379 64 0 99 Punch
380 64 0 100 Heartbeat
381 64 0 101 Footsteps
382 64 0 113 Machine Gun
383 64 0 114 Laser Gun
384 64 0 115 Explosion
385 64 0 116 Firework

PSR-E233/YPT-230 Owner’s Manual

36

Drum Kit List

• “ ” indicates that the drum sound is the same as “Standard Kit 1”.

• Each percussion voice uses one note.

• The MIDI Note # and Note are actually one octave lower than keyboard Note # and Note. For example, in “140: Standard Kit 1”, the “Seq Click H”
(Note# 36/Note C1) corresponds to (Note# 24/Note C0).

• Key Off: Keys marked “O” stop sounding the instant they are released.

• Voices with the same Alternate Note Number (*1 … 4) cannot be played simultaneously. (They are designed to be played alternately with each other.)

Note# Note Note# Note

C1

C#1

D1

D#1

E1

F1

F#1

G1

G#1

A1

A#1

B1

C2

C#2

D2

D#2

E2

F2

F#2

G2

G#2

A2

A#2

B2

C3

C#3

D3

D#3

E3

F3

F#3

G3

G#3

A3

A#3

B3

C4

C#4

D4

D#4

E4

F4

F#4

G4

G#4

A4

A#4

B4

C5

C#5

D5

D#5

E5

F5

F#5

G5

G#5

A5

A#5

B5

C6

100 E 6 8 8 E 5
101 F 6 8 9 F 5
102 F# 690F# 5
103 G 6 91 G 5

MSB (0–127) / LSB (0–127) / PC (1–128) 127/0/1 127/0/2 127/0/9 127/0/17 127/0/25 127/0/26

Keyboard MIDI

25 C# 013C# -1 3 Surdo Mute
26 D 0 14 D -1 3 Surdo Open
27 D# 015D# -1 Hi Q
28 E 0 16 E -1 Whip Slap
29 F 0 17 F -1 4 Scratch Push
30 F# 018F# -1 4 Scratch Pull
31 G 0 19 G -1 Finger Snap
32 G# 020G# -1 Click Noise
33 A 0 21 A -1 Metronome Click
34 A# 022A# -1 Metronome Bell
35 B 0 23 B -1 Seq Click L
36 C 1 24 C 0 Seq Click H
37 C# 125C# 0 Brush Tap
38 D 1 26 D 0 O Brush Swirl
39 D# 127D# 0Brush Slap
40 E 1 28 E 0 O Brush Tap Swirl Reverse Cymbal Reverse Cymbal
41 F 1 29 F 0 O Snare Roll
42 F# 130F# 0 Castanet Hi Q 2 Hi Q 2
43 G 1 31 G 0 Snare H Soft Snare H Soft 2
44 G# 132G# 0Sticks
45 A 1 33 A 0 Bass Drum Soft Bass Drum H Bass Dr um H
46 A# 134A# 0 O pen Rim Shot Open Rim Shot 2
47 B 1 35 B 0 Bass Drum Hard Bass Drum H BD Rock BD Analog L
48 C 2 36 C 1 Bass Drum Bass Drum 2
49 C# 237C# 1Side Stick
50 D 2 38 D 1 Snare M Snare M 2 SD Room L SD Rock L SD Rock L Analog Snare 1
51 D# 239D# 1 Hand Clap
52 E 2 40 E 1 Snare H Hard Snare H Hard 2 SD Room H SD Rock Rim SD Rock H Analog Snare 2
53 F 2 41 F 1 Floor Tom L
54 F# 242F# 1 1 Hi-Hat Closed
55 G 2 43 G 1 Floor Tom H
56 G# 244G# 1 1 Hi-Hat Pedal
57 A 2 45 A 1 Low Tom
58 A# 246A# 11Hi-Hat Open
59 B 2 47 B 1 Mid Tom L
60 C 3 48 C 2 Mid Tom H
61 C# 349C# 2 Crash Cymbal 1
62 D 3 50 D 2 High Tom
63 D# 351D# 2 Ride Cymbal 1
64 E 3 52 E 2 Chinese Cymbal
65 F 3 53 F 2 Ride Cymbal Cup
66 F# 354F# 2 Tambourine
67 G 3 55 G 2 Splash Cymbal
68 G# 356G# 2Cowbell Analog Cowbell
69 A 3 57 A 2 Crash Cymbal 2
70 A# 358A# 2Vibraslap
71 B 3 59 B 2 Ride Cymbal 2
72 C 4 60 C 3 Bongo H
73 C# 461C# 3 Bongo L
74 D 4 62 D 3 Conga H Mute Analog Conga H
75 D# 463D# 3 Conga H Open
76 E 4 64 E 3 Conga L
77 F 4 65 F 3 Timbale H
78 F# 466F# 3Timbale L
79 G 4 67 G 3 Agogo H
80 G# 468G# 3 Agogo L
81 A 4 69 A 3 Cabasa
82 A# 470A# 3 Maraca s Analog Maracas
83 B 4 71 B 3 O Samba Whistle H
84 C 5 72 C 4 O Samba Whistle L
85 C# 573C# 4Guiro Short
86 D 5 74 D 4 O Guiro Long
87 D# 575D# 4Claves Analog Claves
88 E 5 76 E 4 Wood Block H
89 F 5 77 F 4 Wood Block L
90 F# 578F# 4Cuica Mute Scratch Push Scratch Push
91 G 5 79 G 4 Cuica Open
92 G# 580G# 4 2 Triangle Mute
93 A 5 81 A 4 2 Triangle Open
94 A# 582A# 4Shaker
95 B 5 83 B 4 Jingle Bell
96 C 6 84 C 5 Bell Tree
97 C# 685C# 5
98 D 6 86 D 5
99 D# 687D# 5

Voice No. 140 141 142 143 144 145

Key

Alternate

Off

Standard Kit 1 Standard Kit 2 Room Kit Rock Kit Electronic Kit Analog Kit

Group

SD Rock H Sn are L SD Ro ck H

BD Rock BD Gate BD Analog H

Room Tom 1 Rock Tom 1 E Tom 1 Analog Tom 1

Room Tom 2 Rock Tom 2 E Tom 2 Analog Tom 2

Room Tom 3 Rock Tom 3 E Tom 3 Analog Tom 3

Room Tom 4 Rock Tom 4 E Tom 4 Analog Tom 4
Room Tom 5 Rock Tom 5 E Tom 5 Analog Tom 5

Room Tom 6 Rock Tom 6 E Tom 6 Analog Tom 6

Scratch Pull Scratch Pull

Analog Side Stick

Analog HH Closed 1

Analog HH Closed 2

Analog HH Open

Analog Cymbal

Analog Conga M
Analog Conga L

PSR-E233/YPT-230 Owner’s Manual

37

Drum Kit List

146 147 148 149 150 151 152

127/0/28 127/0/33 127/0/41 127/0/49 126/0/1 126/0/ 2 126/0/113

Dance Kit Jazz Kit Brush Kit Symphony Kit SFX Kit 1 SFX Kit 2 Sound Effect Kit

C1

C#1

D1

Reverse Cymbal

D#1

E1

Hi Q 2

F1

AnSD Snappy SD Jazz H Light Brush Slap L

F#1

G1

AnBD Dance-1 Bass Drum L

G#1

AnSD OpenRim

A1

AnBD Dance-2 Gran Cassa

A#1

B1

AnBD Dance-3 BD Jazz BD Jazz Gran Cassa Mute Cutting Noise P hone Call Heartbeat
Analog Side Stick

C2

AnSD Q SD Jazz L Brush Slap Marching Sn M Door Slam Door Squeak

C#2

D2

AnSD Ana+Acoustic SD Jazz M Brush Tap Marching Sn H Scratch Applau se

D#2

E2

Analog Tom 1 Jazz Tom 1 Brush Tom 1 Jazz Tom 1 Wind Chime Camera
Analog HH Closed 3

F2

Analog Tom 2 Jazz Tom 2 Brush Tom 2 Jazz Tom 2 Hiccup

F#2

Analog HH Closed 4

G2

An al og Tom 3 Ja zz Tom 3 B ru sh Tom 3 Ja zz Tom 3 S tre am

G#2

Analog HH Open 2

A2

Analog Tom 4 Jazz Tom 4 Brush Tom 4 Jazz Tom 4 Rooster

A#2

B2

An al og Tom 5 Ja zz Tom 5 B ru sh Tom 5 Ja zz Tom 5 D og
Analog Cymbal

C3

An al og Tom 6 Ja zz Tom 6 B ru sh Tom 6 Ja zz Tom 6 O wl

C#3

D3

D#3

E3

F3

F#3

Analog Cowbell

G3

G#3

A3

A#3

B3

C4

Analog Conga H

C#4

Analog Conga M

D4

Analog Conga L

D#4

E4

F4

F#4

G4

G#4

Analog Maracas

A4

A#4

B4

C5

C#5

Analog Claves

D5

D#5

E5

Scratch Push

F5

Scratch Pull

F#5

G5

G#5

A5

A#5

B5

C6

Hand Cym. L Cat

Hand Cym.Short L Horse Gallop

Hand Cym. H Train Go!

Hand Cym.Short H Starship Whoow!

Cutting Noise 2 Door Squeak Footsteps

String Slap Scratch Cut Door Slam

Telephone Ring 2 Horn

Flute Key Click Car Engine Ignition Horse Neigh

Shower Laugh
Thunder Scream
Wind Punch
Stream Heartbeat
Bubble Footsteps
Feed

Dog Machine Gun
Horse Laser Gun
Bird Tweet 2 Explosion

Car Tires Squ eal Cow
Car Passing Lion
Car Crash Scratch
Siren Yo!

Jet Plane Get up!

Burst
Roller Coa ster
Submarine

Firework

Drum Loop

Cuckoo Clock

Frog

Huuaah!

Uh!+Hit

PSR-E233/YPT-230 Owner’s Manual

38

Maou

Song List

Song No. Song Name

001 Demo 1
002 Demo 2
003 Demo 3

004

005 “Orphée aux Enfers” Ouverture (J. Offenbach)
006 Slavonic Dances No.10 (A. Dvořák)
007 La Primavera (from Le Quattro Stagioni) (A. Vivaldi)
008 Méditation (Thaïs) (J. Massenet)
009 Guillaume Tell (G. Rossini)
010 Frühlingslied (F. Mendelssohn)

012 Dolly’s Dreaming and Awakening (T. Oesten)
013 La Candeur (J.F. Burgmüller)
014 Arabesque (J.F. Burgmüller)
015 Pastorale (J.F. Burgmüller)
016 Petite Réunion (J.F. Burgmüller)
017 Innocence (J.F. Burgmüller)
018 Progrès (J.F. Burgmüller)
019 Tarentelle (J.F. Burgmüller)
020 La Chevaleresque (J.F. Burgmüller)
021 Etude op.10-3 “Chanson de l'adieu” (F. Chopin)
022 Marcia alla Turca (L.v. Beethoven)
023 Turkish March (W.A. Mozar t)
024 Valse op.64-1 “Petit Chien” (F. Chopin)
025 Menuett (L. Boccherini)
026 Nocturne op.9-2 (F. Chopin)
027 Moments Musicaux op.94-3 (F. Schubert)
028 The Entertainer (S. Joplin)
029 Prelude (Wohltemperierte Klavier 1-1) (J.S. Bach)
030 La Viollette (Streabbog)
031 Für Elise (L.v. Beethoven)

032 America the Beautiful (S.A. Ward)
033 Londonderry Air (Traditional)
034 Ring de Banjo (S.C. Foster)
035 Wenn ich ein Vöglein wär ? (Traditional)
036 Die Lorelei (F. Silcher)
037 Funiculi Funicula (L. Denza)
038 Turkey in the Straw (Traditional)
039 Old Folks at Home (S.C. Foster)
040 Jingle Bells (J.S. Pierpont)
041 Muss i denn (F. Silcher)
042 Liebesträume Nr.3 (F. Liszt)
043 Jesu, Joy Of Man’s Desiring (J.S. Bach)
044 Ode to Joy (L.v. Beethoven)
045 Song of the Pearl Fisher (G. Bizet)
046 Gavotte (F.J. Gossec)
047 String Quartet No.17 2nd mov. “Serenade” (F.J. Haydn)
048 Menuett (J.S. Bach)
049 Canon (J. Pachelbel)
050 From “The Magic Flute” (W.A Mozar t)
051 Piano Sonate op.27-2 “Mondschein” (L.v. Beethoven)
052 “The Surprise” Symphony (F.J. Haydn)
053 To a Wild Rose (E.A. MacDowell)
054 Chanson du Toreador (G. Bizet)
055 O Mio Babbino Caro (G. Puccini)

Danse des Mirlitons from “The Nutcracker”
(P.I. Tchaikovsky)

011 Ungarische Tänze Nr.5 (J. Brahms)

Top Picks

ORCHESTRA

PIANIST

PRACTICE

Song No. Song Name

056 Row Row Row Your Boat (Traditional)
057 On Top of Old Smoky (Traditional)
058 We Wish You A Merry Christmas (Traditional)
059 Scarborough Fair (Traditional)
060 Im Mai (Traditional)
061 O Christmas Tree (Traditional)
062 Mary Had a Little Lamb (Traditional)
063 Ten Little Indians (Septimus Winner)
064 Pop Goes The Weasel (Traditional)
065 Twinkle Twinkle Little Star (Traditional)
066 Close Your Hands, Open Your Hands (J.J. Rousseau)
067 The Cuckoo (Traditional)
068 O du lieber Augustin (Traditional)
069 London Bridge (Traditional)

070 Bill Bailey (Won’t You Please Come Home) (H. Cannon)
071 When Irish Eyes Are Smiling (E.R. Ball)
072 Down by the Riverside (Traditional)
073 When the Saints Go Marching In (Traditional)
074 Frühlingsstimmen (J. Strauss II)
075 Camptown Races (S.C. Foster)
076 Little Brown Jug (Joseph Winner)
077 Loch Lomond (Traditional)
078 Oh! Susanna (S.C. Foster)
079 Greensleeves (Traditional)
080 Aura Lee (G. Poulton)
081 Silent Night (F. Gruber)
082 The Danube Waves (I. Ivanovici)
083 Twinkle Twinkle Little Star (Traditional)
084 Close Your Hands, Open Your Hands (J.J. Rousseau)
085 The Cuckoo (Traditional)
086 O du lieber Augustin (Traditional)
087 London Bridge (Traditional)
088 American Patrol (F.W. Meacham)
089 Beautiful Dreamer (S.C. Foster)
090 Battle Hymn of the Republic (Traditional)
091 Home Sweet Home (H. Bishop)

092

093 Aloha Oe (Q. Liliuokalani)
094 I’ve Been Working On The Railroad (Traditional)
095 My Darling Clementine (Traditional)
096 Auld Lang Syne (Traditional)
097 Grandfather’s Clock (H.C. Work)
098 Amazing Grace (Traditional)
099 My Bonnie (H.J Fulmer)
100 Yankee Doodle (Traditional)
101 Joy to the World (G.F. Händel)
102 Ave Maria (F. Schubert)

Valse Des Fleurs (From “The Nutcracker”)
(P.I. Tchaikovsky)

DUET

CHORD LESSON

• Some songs have been edited for length or for ease in learning, and may not be exactly the same as the original.

• A song book (free downloadable scores) is available that includes scores for all internal songs (excepting Songs 1–3). To obtain the Song Book, complete
the user registration at the following website.

https://member.yamaha.com/myproduct/regist/

PSR-E233/YPT-230 Owner’s Manual

39

Style List

Style No. Style Name

8Beat

001 8BeatModern

002 60'sGtrPop

003 8BeatAdria

004 60's8Beat

005 8Beat

006 OffBeat

007 60'sRock

008 HardRock

009 RockShuffle

010 8BeatRock

16Beat

011 16Beat

012 PopShuffle

013 G uit arPop

014 16BtUptempo

015 KoolShuffle

016 HipHopLight

Ballad

017 PianoBallad

018 LoveSong

019 6/8ModernEP

020 6/8SlowRock

021 OrganBallad

022 PopBallad

023 16BeatBallad

Dance

024 EuroTrance

025 Ibiza

026 SwingHouse

027 Clubdance

028 ClubLatin

029 Garage1

030 Garage2

031 TechnoParty

032 UKPop

033 HipHopGroove

034 HipShuffle

035 HipHopPop

Disco

036 70'sDisco

037 LatinDisco

038 SaturdayNight

039 DiscoHands

Swing&Jazz

040 BigBandFast

041 BigBandBallad

042 JazzClub

043 Swing1

044 Swing2

045 Five/Four

046 Dixieland

047 Ragtime

Style No. Style Name

R&B

048 Soul

049 DetroitPop

050 6/8Soul

051 CrocoTwist

052 Rock&Roll

053 ComboBoogie

054 6/8Blues

Country

055 CountryPop

056 CountrySwing

057 Country2/4

058 Bluegrass

Latin

059 BrazilianSamba

060 BossaNova

061 Forro

062 Tijuana

063 Mambo

064 Salsa

065 Beguine

066 Reggae

Ballroom

067 VienneseWaltz

068 EnglishWaltz

069 Slowfox

070 Foxtrot

071 Quickstep

072 Tango

073 Pasodoble

074 Samba

075 ChaChaCha

076 Rumba

077 Jive

Tra d&W orl d

078 USMarch

079 6/8March

080 GermanMarch

081 PolkaPop

082 OberPolka

083 Tarantella

084 Showtune

085 ChristmasSwing

086 ChristmasWaltz

087 ScottishReel

Waltz

088 SwingWaltz

089 JazzWaltz

090 CountryWaltz

091 OberWalzer

092 Musette

Style No. Style Name

Pianist

093 Stride

094 PianoSwing

095 Arpeggio

096 Habanera

097 SlowRock

098 8BeatPianoBallad

099 6/8PianoMarch

100 PianoWaltz

PSR-E233/YPT-230 Owner’s Manual

40

Effect Type List

Reverb Types

No. Reverb Type Description

01–03 Hall 1–3 Concert hall reverb.

04–05 Room 1–2 Small room reverb.

06–07 Stage 1–2 Reverb for solo instruments.

08–09 Plate 1–2 Simulated steel plate reverb.

10 Off No effect.

Chorus Types

No. Chorus Type Description

01–02 Chorus 1–2 Conventional chorus program with rich, warm chorusing.

03–04 Flanger 1–2 This produces a rich, animated wavering effect in the sound.

05 Off No effect.

PSR-E233/YPT-230 Owner’s Manual

41

Specifications

Size/Weight

Keyboard Number of Keys 61

Display

Panel Language English

Voices

Effects

Accompaniment
Styles

Songs Preset Number of Preset Songs 102

Functions

Connectivity

Amplifiers and
Speakers

Power Supply

Included Accessories

Optional Accessories

Dimensions W x D x H 945 x 348 x 118 mm (37-3/16" x 13-11/16" x 4-5/8")
Weight 4.5 kg (9 lbs. 15 oz.) (not including batteries)

Type LCD display
Language English

Tone Generation Tone Generating Technology AWM Stereo Sampling
Polyphony Number of Polyphony (Max.) 32
Preset Number of Voices 139 panel voices + 13 drum/SFX kits + 233 XGlite voices
Compatibility GM/XGlite

Ty pe s

Funct ion

Preset

Other Features One Touch Setting (OTS) Yes

Lesson

Overall Controls

Miscellaneous Portable Grand Button Yes
Connectivity PHONES/OUTPUT, DC IN, MIDI IN/OUT, SUSTAIN
Amplifiers 2.5W + 2.5W
Speakers 12cm x 2

Power Supply

Power Consumption 7W (When using PA-130 power adaptor)
Auto Power Off Function Yes

Reverb 9 types
Chorus 4 types
Ultra-Wide Stereo 3 types
Panel Sustain Yes
Number of Preset Styles 100
Fingering Multi fingering

Style Control

Metronome Yes
Tempo Range 32 – 280
Transpose -12 – 0 – +12
Tuning 427.0 - 440.0 - 453.0 Hz

ACMP ON/OFF, SYNC START, START/STOP, INTRO/ENDING/rit.,
MAIN/AUTO FILL

[LISTEN & LEARN], [TIMING], [WAITING], [CHORD DICTIONARY],
[A-B REPEAT]

• Adaptor: Users within U.S or Europe: PA-130 or an equivalent

• Batteries:Six “AA” size, LR6 or equivalent batteries

•Music Rest

• Owner’s Manual

• My Yamaha Product User Registration

• AC Power adaptor* (PA-130 or an equivalent recommended by Yamaha)

* May not be included depending on your particular area. Please check with your

Yamaha dealer.

• Adaptor: Users within U.S or Europe: PA-130 or an equivalent

• Footswitch: FC4/FC5

• Keyboard Stand: L-2C/L-2L

• Headphones: HPE-150/HPE-30

Others: PA-3C, PA-130 or an equivalent

Others: PA-3C, PA-130 or an equivalent

* Specifications and descriptions in this owner’s manual are for information purposes only. Yamaha Corp. reserves the right to change or modify

products or specifications at any time without prior notice. Since specifications, equipment or options may not be the same in every locale, please
check with your Yamaha dealer.

PSR-E233/YPT-230 Owner’s Manual

42

Index

A

A-B Repeat ...................................26

ACMP ON/OFF ........................... 17

Auto Accompaniment ................. 17

Auto accompaniment range ........ 17

Auto Power Off ........................ 9, 30

B

Battery ............................................ 8

Beat Display ................................. 13

BGM Playback ............................23

C

Chord ............................................ 19

Chord Dictionary ......................... 20

Chord Display .............................. 13

Chorus .................................... 15, 29

Chorus Send Level ...................... 29

Chorus Type List ......................... 41

Computer ...................................... 31

D

DC IN ............................................. 8

Demo ............................................ 23

Display ......................................... 13

Drum Kit ...................................... 14

Drum Kit List ............................... 37

E

Effect Type List ........................... 41

Ending .......................................... 18

External Clock ............................. 29

F

FF .................................................. 22

Footswitch (Sustain jack) .............9

Function ........................................ 28

Function Setting List ............. 29–30

I

Initial Send ...................................29

Intro ...............................................18

L

Left ................................................25

Lesson ...........................................24

LISTEN & LEARN .....................24

Local .............................................29

M

Main/Auto fill ...............................18

Master EQ .......................................9

Master EQ Type ...........................29

Master Volume Control .................9

Measure ........................................13

Melody Voice ...............................23

Metronome ...................................27

Metronome Volume .....................29

MIDI .............................................31

Music Rest ......................................6

Mute ..............................................26

N

Notation ........................................13

O

Octave (Main) ..............................29

One Touch Setting (OTS) ............14

Option ...........................................42

P

part ................................................25

Pause .............................................22

PHONES/OUTPUT .......................9

PORTABLE GRAND ..................15

Power Adaptor ...............................8

Press and Hold for a while ..........11

S

Section .......................................... 18

Song ........................................ 12, 22

Song Book ..................................... 6

Song List ...................................... 39

Song Volume ................................ 29

Sound Effect ................................ 15

Split Point .............................. 17, 29

START/STOP .............................. 12

Style ........................................ 12, 16

Style List ...................................... 40

Style Volume ................................ 29

Supplied Accessories .............. 6, 42

Sustain (Footswitch) ..................... 9

Sustain (Panel) ....................... 15, 29

Synchro Start ............................... 17

T

Tem po ........................................... 27

TEMPO/TAP ............................... 27

Time Signature ...................... 27, 29

Timing .......................................... 24

Track ....................................... 13, 26

Transpose ..................................... 29

Tuning .......................................... 29

U

Ultra-Wide Stereo ....................... 15

V

Vo i c e ....................................... 12, 14

Voice List ..................................... 33

Volume (Song) ............................. 29

Volume (Style) ............................. 29

Volume (Voice) ............................ 29

W

Waiting ......................................... 24

G

Grade ............................................ 25

H

Headphones .................................... 9

R

Reverb .....................................15, 29

Reverb Level ................................29

Reverb Type List ..........................41

Rew ...............................................22

Rhythm ...................................12, 16

Right ..............................................25

rit.(ritardando) ..............................18

Root .........................................19–20

X

XGlite ............................................. 6

PSR-E233/YPT-230 Owner’s Manual

43

Information for Users on Collection and Disposal of Old Equipment and used Batteries

These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should
not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to applicable collection points, in accordance with
your national legislation and the Directives 2002/96/EC and 2006/66/EC.

By disposing of these products and batteries correctly, you will help to save valuable resources and prevent any potential negative effects on human
health and the environment which could otherwise arise from inappropriate waste handling.

For more infor mation about collection and recycling of old products and batteries, please contact your local municipality, your waste disposal service or
the point of sale where you purchased the items.

[For business users in the European Union]

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.

[Information on Disposal in other Countries outside the European Union]

These symbols are only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the
correct method of disposal.

Note for the battery symbol (bottom two symbol examples):

This symbol might be used in combination with a chemical symbol. In this case it complies with the requirement set by the Directive for the chemical
involved.

(weee_battery_eu_en)

OBSERVERA!

Apparaten kopplas inte ur växelströmskällan (nätet) så länge
som den ar ansluten till vägguttaget, även om själva apparaten
har stängts av.

ADVARSEL: Netspændingen til dette apparat er IKKE

afbrudt, sålænge netledningen sidder i en stikkontakt, som er
tændt — også selvom der er slukket på apparatets afbryder.

VAR OITUS: Laitteen toisiopiiriin kytketty käyttökytkin ei irroita

koko laitetta verkosta.

(standby)

The serial number of this product may be found on the bottom
of the unit. You should note this serial number in the space
provided below and retain this manual as a permanent record
of your purchase to aid identification in the event of theft.

Model No.

Serial No.

(bottom)

Entsorgung leerer Batterien (nur innerhalb
Deutschlands)

Leisten Sie einen Beitrag zum Umweltschutz. Verbrauchte Bat­terien oder Akkumulatoren dürfen nicht in den Hausmüll. Sie
können bei einer Sammelstelle für Altbatterien bzw. Sondermüll
abgegeben werden. Informieren Sie sich bei Ihrer Kommune.

(battery)

PSR-E233/YPT-230 Owner’s Manual

44

PSR-E233/YPT-230 Owner’s Manual

45

PSR-E233/YPT-230 Owner’s Manual

46

For details of products, please contact your nearest Yamaha
representative or the authorized distributor listed below.

Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha
ou au distributeur le plus proche de vous figurant dans la liste suivante.

Para obter detalhes de produtos, entre em contato com o
representante mais próximo da Yamaha ou com o distribuidor
autorizado relacionado a seguir.

Para detalles sobre productos, contacte su tienda Yamaha más
cercana o el distribuidor autorizado que se lista debajo.

Die Einzelheiten zu Produkten sind bei Ihrer unten aufgeführten
Niederlassung und bei Yamaha Vertragshändlern in den jeweiligen
Bestimmungsländern erhältlich.

Подробные сведения об инструменте можно получить у местного
представителя корпорации Yamaha или уполномоченного
дистрибьютора, указанного в следующем списке.

NORTH AMERICA

CANADA

Yamaha Canada Music Ltd.

135 Milner Avenue, Scarborough, Ontario,
M1S 3R1, Canada
Tel: [phone]

U.S.A.

Yamaha Corporation of America

6600 Orangethorpe Ave., Buena Park, Calif. 90620,
U.S.A.
Tel: [phone]

CENTRAL & SOUTH AMERICA

MEXICO

Yamaha de México S.A. de C.V.

Calz. Javier Rojo Gómez #1149,
Col. Guadalupe del Moral
C.P. 09300, México, D.F., México
Tel: [phone]

BRAZIL

Yamaha Musical do Brasil Ltda.

Rua Joaquim Floriano, 913 - 4' andar, Itaim Bibi,
CEP 04534-013 Sao Paulo, SP. BRAZIL
Tel: [phone]

ARGENTINA

Yamaha Music Latin America, S.A.
Sucursal de Argentina

Olga Cossettini 1553, Piso 4 Norte
Madero Este-C1107CEK
Buenos Aires, Argentina
Tel: [phone]

PANAMA AND OTHER LATIN
AMERICAN COUNTRIES/
CARIBBEAN COUNTRIES

Yamaha Music Latin America, S.A.

Torre Banco General, Piso 7, Urbanización Marbella,
Calle 47 y Aquilino de la Guardia,
Ciudad de Panamá, Panamá
Tel: [phone]

EUROPE

THE UNITED KINGDOM/IRELAND

Yamaha Music U.K. Ltd.

Sherbourne Drive, Tilbrook, Milton Keynes,
MK7 8BL, England
Tel: [phone]

GERMANY

Yamaha Music Europe GmbH

Siemensstraße 22-34, 25462 Rellingen, Germany
Tel: [phone]

SWITZERLAND/LIECHTENSTEIN

Yamaha Music Europe GmbH
Branch Switzerland in Zürich

Seefeldstrasse 94, 8008 Zürich, Switzerland
Tel: [phone]

AUSTRIA

Yamaha Music Europe GmbH Branch Austria

Schleiergasse 20, A-1100 Wien, Austria
Tel: [phone]

CZECH REPUBLIC/SLOVAKIA/
HUNGARY/SLOVENIA

Yamaha Music Europe GmbH Branch Austria

Schleiergasse 20, A-1100 Wien, Austria
Tel: [phone]

POLAND/LITHUANIA/LATVIA/ESTO­NIA

Yamaha Music Europe GmbH
Branch Sp.z o.o. Oddzial w Polsce

ul. 17 Stycznia 56, PL-02-146 Warszawa, Poland
Tel: [phone]

THE NETHERLANDS/
BELGIUM/LUXEMBOURG

Yamaha Music Europe Branch Benelux

Clarissenhof 5-b, 4133 AB Vianen, The Netherlands
Tel: [phone]

FRANCE

Yamaha Musique France

BP 70-77312 Marne-la-Vallée Cedex 2, France
Tel: [phone]

ITALY

Yamaha Musica Italia S.P.A.

Viale Italia 88, 20020 Lainate (Milano), Italy
Tel: [phone]

SPAIN/PORTUGAL

Yamaha Música Ibérica, S.A.

Ctra. de la Coruna km. 17, 200, 28230
Las Rozas (Madrid), Spain
Tel: [phone]

GREECE

Philippos Nakas S.A. The Music House

147 Skiathou Street, 112-55 Athens, Greece
Tel: [phone]

SWEDEN

Yamaha Scandinavia AB

J. A. Wettergrens Gata 1, Box 30053
S-400 43 Göteborg, Sweden
Tel: [phone]

DENMARK

YS Copenhagen Liaison Office

Generatorvej 6A, DK-2730 Herlev, Denmark
Tel: [phone]

FINLAND

F-Musiikki Oy

Kluuvikatu 6, P.O. Box 260,
SF-00101 Helsinki, Finland
Tel: [phone]

NORWAY

Norsk filial av Yamaha Scandinavia AB

Grini Næringspark 1, N-1345 Østerås, Norway
Tel: [phone]

ICELAND

Skifan HF

Skeifan 17 P.O. Box 8120, IS-128 Reykjavik, Iceland
Tel: [phone]

RUSSIA

Yamaha Music (Russia)

Room 37, bld. 7, Kievskaya street, Moscow,
121059, Russia
Tel: [phone]

OTHER EUROPEAN COUNTRIES

Yamaha Music Europe GmbH

Siemensstraße 22-34, 25462 Rellingen, Germany
Tel: [phone]

AFRICA

Yamaha Corporation,
Asia-Pacific Sales & Marketing Group

Nakazawa-cho 10-1, Naka-ku, Hamamatsu,
Japan 430-8650
Tel: [phone]

MIDDLE EAST

TURKEY/CYPRUS

Yamaha Music Europe GmbH

Siemensstraße 22-34, 25462 Rellingen, Germany
Tel: [phone]

OTHER COUNTRIES

Yamaha Music Gulf FZE

LOB 16-513, P.O.Box 17328, Jubel Ali,
Dubai, United Arab Emirates
Tel: [phone]

ASIA

THE PEOPLE’S REPUBLIC OF CHINA

Yamaha Music & Electronics (China) Co.,Ltd.

2F, Yunhedasha, 1818 Xinzha-lu, Jingan-qu,
Shanghai, China
Tel: [phone]

HONG KONG

Tom Lee Music Co., Ltd.

11/F., Silvercord Tower 1, 30 Canton Road,
Tsimshatsui, Kowloon, Hong Kong
Tel: [phone]

INDIA

Yamaha Music India Pvt. Ltd.

5F Ambience Corporate Tower Ambience Mall Complex
Ambience Island, NH-8, Gurgaon-122001, Haryana, India
Tel: [phone]

INDONESIA

PT. Yamaha Musik Indonesia (Distributor)
PT. Nusantik

Gedung Yamaha Music Center, Jalan Jend. Gatot
Subroto Kav. 4, Jakarta 12930, Indonesia
Tel: [phone]

KOREA

Yamaha Music Korea Ltd.

8F, 9F, Dongsung Bldg. 158-9 Samsung-Dong,
Kangnam-Gu, Seoul, Korea
Tel: [phone]

MALAYSIA

Yamaha Music (Malaysia) Sdn., Bhd.

Lot 8, Jalan Perbandaran, 47301 Kelana Jaya,
Petaling Jaya, Selangor, Malaysia
Tel: [phone]

PHILIPPINES

Yupangco Music Corporation

339 Gil J. Puyat Avenue, P.O. Box 885 MCPO,
Makati, Metro Manila, Philippines
Tel: [phone]

SINGAPORE

Yamaha Music (Asia) Pte., Ltd.

#03-11 A-Z Building
140 Paya Lebor Road, Singapore 409015
Tel: [phone]

TA IWAN

Yamaha KHS Music Co., Ltd.

3F, #6, Sec.2, Nan Jing E. Rd. Taipei.
Taiwan 104, R.O.C.
Tel: [phone]

THAILAND

Siam Music Yamaha Co., Ltd.

4, 6, 15 and 16th floor, Siam Motors Building,
891/1 Rama 1 Road, Wangmai,
Pathumwan, Bangkok 10330, Thailand
Tel: [phone]

OTHER ASIAN COUNTRIES

Yamaha Corporation,
Asia-Pacific Sales & Marketing Group

Nakazawa-cho 10-1, Naka-ku, Hamamatsu,
Japan 430-8650
Tel: [phone]

OCEANIA

AUS TRALI A

Yamaha Music Australia Pty. Ltd.

Level 1, 99 Queensbridge Street, Southbank,
Victoria 3006, Australia
Tel: [phone]

NEW ZEALAND

Music Works LTD

P.O.BOX 6246 Wellesley, Auckland 4680,
New Zealand
Tel: [phone]

COUNTRIES AND TRUST
TERRITORIES IN PACIFIC OCEAN

Yamaha Corporation,
Asia-Pacific Sales & Marketing Group

Nakazawa-cho 10-1, Naka-ku, Hamamatsu,
Japan 430-8650
Tel: [phone]

EKB54

HEAD OFFICE Yamaha Corporation, Digital Musical Instruments Division

Nakazawa-cho 10-1, Naka-ku, Hamamatsu, Japan 430-8650
Tel: [phone]

Yamaha Global Home

http://www.yamaha.com/

Yamaha Manual Library

http://www.yamaha.co.jp/manual/

U.R.G., Digital Musical Instruments Division

© 2011 Yamaha Corporation

105POTY*.*-**B0

Printed in China

WW14480
