1. Start Up
1.1 Introduction
SIPFXSO 1S1O/2S2O is a one-port/two-port FXS+FXO gateway. It
supports an innovative intelligent call rouging function that transparently routes
calls to destination either through PSTN or Internet.
SIPFXSO 1S1O/2S2O provides voice over IP and FAX over IP services
for ITSP/ISP Internet Telephony Services Provider and Office/SOHO IP -PBX
application.
Application Architecture
PBX
PBXPBX
Extension port
Extension port
FXO
FXO
FXO
IP
IP
IP
Network
Network
Network
FXS
FXS
FXS
l FXO ports can connect with PSTN Line or Extension Line of PBX
FXS
Trunk side
Trunk side
PBX
PBXPBX
Extension
Extension
FXO
FXS
FXS
FXS
FXS
l FXS ports can connect with Phone Set or Trunk Line of PBX
3
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
1.2 Features and specification
Features
- IETF RFC 3261
- Automatically Dial Path Selection (IP or PSTN)
- PSTN Line switch to telephone set when power is failure
- PPPoE support
- Behind NAT router or IP sharing device
- DNS server inquiry
- Provide Peer-to-Peer Mode (Non SIP Proxy needed) selection
- Provide In-band or RFC2833 DTMF generation/detection
- Provide call progress tone
Management Feature
- TELNET/Console port and Web Browser configuration
Certification
- UL, CE, FCC
FXS Features
- 2-wire loop start
- Programmable On-Hook voltage, Ring voltage/Cadence/Frequency, Loop
current
- Line polarity reversal generation
4
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
FXO Features
- 2-wire loop start
- Support auto-attendant (Tone or voice greeting)
- PSTN polarity reversal detection
- Disconnect tone detection
- Asking ping function with the incoming calls from PSTN side
- Record and analyze the Tone from PSTN side
Environmental
- Operation temp:0°C to 40°C
- Humidity: 10% to 90% (Non-condensing)
5
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
1.3 Accessories and equipment
u The voice gateway in 2 FXS and 2 FXO ports or 1 FXS port and 1 FXO
port models and two RJ-45 connector (WAN and LAN).
u The AC adapter.
u The CD of user manual.
u The connection cabl e in RS-232 interface.
6
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
1.4 Appearance
Front panel: The LED lights provide related system messages of the gateway.
SIPFXSO 1S1O
SIPFXSO 2S2O
Power: Light on means Gateway is power on, and vice versa.
TEL: Light on means the line is in use (off-hook), and vice versa.
LINE: Light on means the line is in use (off-hook), and vice versa.
Status:
1. LED light on means Gateway has successfully registered to Proxy when it
is in the Proxy Mode.
2. LED flash means Gateway is not registered to the Proxy when it is in the
Proxy Mode.
3. Or when Gateway is in downloading mode, LED should be flash as well.
4. LED light off means Gateway is in Peer-to-Peer Mode.
Ready:
1. Light on and slow flash means Gateway is in normal mode.
2. Light on and fast flash means Gateway is in downloading mode.
WAN: Connected to Public Ethernet
1. Line- LED light on means Gateway is physically connected to the Ethernet
correctly.
2. ACT- LED light on and flash when Ethernet data is being transmitted /
received.
LAN: Switch to another device, such as PC
1. Line- LED light on means Gateway is physically connected to the Ethernet
correctly.
2. ACT- LED light on and flash when Ethernet data is being transmitted
received.
Back panel:
7
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
SIPFXSO 1S1O
SIPFXSO 2S2O
1. Ethernet Port
LAN/WAN: 10/100 Base-T; RJ-45 socket, complied with ETHERNET
10/100base-T.
The pin-out is as following:
PIN 1, 2: Transmit
PIN 3, 6: Receive
2. COM:
RS232 console port (DB-9pin male connector)
Note: use straightforward cable to connect to your computer.
PINOUTS
Pin Name Dir Description
2 RXD
Receive Data
8
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
3 TXD
5 GND
Transmit Data
System Ground
3. TEL:
RJ-11 connector, FXS interface is for connecting the analog phone sets or
trunk line of PABX.
4. LINE:
RJ-11 connector, FXO interface is for connecting the extension line of
PABX or PSTN Line.
5. 12V DC:
Input AC 100V~120V;output DC12V.
9
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
2. How to Setup and Connect basically
2.1 System Requirement
1. One PC (a) Pentium 100 or above, 64 RAM, Windows 98 or above.
(b) Ethernet card or COM port
2. One standard straightforward RS -232 cable (female connector to Gateway
side).
3. Analog telephone sets or the PBX trunk Lines.
4. PBX extension Lines or PSTN Lines.
5. Software tools – Hyper Terminal, TELNET, Web Browser.
10
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
2.2 IP Environment Set ting
User must prepare a valid IP address, complied with IP Network, for Gateway’s
proper operation.
For testing the validation of chosen IP address, using the same IP
configuration in other PC or Notebook, and then try to connect to Public
Internet (go to well-known website, receive Internet mail, or ping a specific
public IP address). If it works, use the same IP address and network
configuration for Gateway.
Please follow up the step for the configuration of your computer or notebook.
2.2.1 For Window s 2000/NT
Please make sure that the network interface of your computer is working fine
and the cross over line (RJ-45) is connecting with the computer correctly or
you could use a hub to connect with your computer and this gateway. Turn on
your computer and configure the network parameter as follow:
1Go to the start menu and enter the setting area. Click control panel .
2Enter the network configuration.
11
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
Figure 2.1: Network Configuration
3Select the Property of the LAN card.
4 Setup the ip address, subnet mask and default gateway as below:
Figure 2.2: Configure the network
5Click OK after you finished the network setup.
The default ip address, netmask and default gateway address of the gateway
is 10.1.1.3, 255.0.0.0, 10.1.1.254.
12
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
2.3 Net work configurations in your gateway
1 Key in the ip address of the gateway (http://10.1.1.3) with the browser. (see
figure 2.3)
Figure 2.3: WEB Browser
2 After key in the ip address, you have to enter the user name and password
to enter the WEB configuration. (Username: root ; No password) (see
figure 2.4)
13
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
Figure 2.4: Login the username and password
3 You will enter the main page of the configuration after key in the login name
and password correctly: (see figure 2.5)
Figure 2.5: The main WEB configuration
4 Press the Network Interface to configure the networking of your gateway.
(see figure 2.6)
14
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
Figure 2.6: The Network Interface
2.3.1 Static ip address
1 Please get the correct ip address, netmask and default gateway address
from your ISP firs t. Press the OK button if you finished. (see figure 2.7)
Figure 2.7: Configure the static ip address
15
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
2Press the commit if you finish the configuration. (see figure 2.8)
Figure 2.8: Commit the data
3Press the reboot if you want the configuration executed. (see figure 2.9)
Figure 2.9: Reboot the system
16
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
2.3.2 DHCP mode
1 Enable the DHCP if you are using the cable modem or DHCP server. (see
figure 2.10)
Figure 2.10: Enable the DHCP function
2 Please commit the data and reboot the machine after you enable the DHCP
function.
17
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
2.3.3 PPPoE mode
1Switch to the PPPoE mode and press the “OK” button. Press the Network
Interface button after the “OK” button. (see figure 2.11)
Figure 2.11: Switch to the PPPoE mode
2 Enter the Login account and password. Press the “OK” button if the
configuration is finished. (see figure 2.12)
18
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
Figure 2.12: Enter the Account and password
2 Please commit the data and reboot the machine after you finished the
configuration about the PPPoE function.
2.4 M aking a VoIP Call
There are two modes that you could configure the gateway for making VoIP
calls. One is the Peer-to-Peer mode, another is Proxy mode. The
configurations and functions are different. Please make sure about the mode
you want and follow up the step to configure your gateway.
2.4.1 Configure the gateway into the Peer-to-Peer mode
1 Enter the SIP Configuration table and change the mode to Peer-to-Peer.
Define the port numbers whatever you like. Press the “OK” button if the
configuration is all finished. (see figure 2.13)
Figure 2.13: Configure the Peer-to-Peer mode
2 Enter the Phone Book configuration table and configure the name, ip
address and phone number of the destination. (see figure 2.14)
19
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
Figure 2.14: Phone Book
【Example】
Figure 2.15: The example of Phone Book configuration
The name of the destination: test
The E164 number (phone number) of the destination: 123
The ip address of the destination: 10.1.1.100
Drop prefix: Enable – The e164 number you define will be deleted
20
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
Disable – The e164 number you define will be kept
Insert prefix: To add a number you define in this table
Press the “Add Data” button when you finished, and the new table will display
on the first index if you press the Phone Book configuration button .
4 Please Commit it and Reboot the system if the configuration is finished. (see
figure 2.16)
Phone Book is only for the Peer-to- Peer mode and could
support forty records.
Figure 2.16: To show the Phone Book record
【The application in the drop and insert function】
Input (E164) Drop Insert Output
100 Disable X 100
200 Disable 0 0200
21
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
300 Enable X X
400 Enable 500 500
※ X – Do not enter any numbers
2.4.2 Configure the gateway into the Proxy mode
1 Enter the SIP Config table and change the mode from Peer-to-Peer to Proxy.
To change the Proxy information from your service provider (Ex: The Proxy
IP, Domain and Line numbers). (see figure 2.17)
Figure 2.17: Configure the Proxy info
2 Press the OK button that is on the bottom of this page to save the
configuration.
3 Switch to the Security Config page and put the user account and password
in the correct table. Please get this info from your ITSP. Press the OK
button if the configuration is finished. (see figure 2.20)
22
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
Figure 2.20: Configure the Security info
4 Press the Commit Data and Reboot System buttons when you finished the
configuration.
23
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
3. Advanced
There are too many advanced commands for the advanced users. The
following chapters are based on the application layer. Please get the info what
you need. If you need the command, please watching the chapter of Command
Line Interface.
3.1 Network Interface
Users have to configure the Network configurations in this page. This gateway
will be work while it is connecting with the internet network. Please get more
info from the following descriptions. (see figure 3.1)
Figure 3.1: Network Interface
u IP Address – Define the ip address for your networking if it is the fixed ip.
Please get this info from your ISP.
u Subnet Mask – Define the mask address for your networking. Please get
this info from your ISP.
u Default Routing Gateway – Define the default gateway for your networking.
Please get this info from your ISP.
u IP Mode – To configure the fixed or dynamic ip address for this unit.
24
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
Please configure to PPPoE if the ADSL is using the PPPoE type.
u HTTP Port – To configure the HTTP port for access this unit from the
remote side.
u DNS primary – To configure the first ip address for the DNS server.
u DNS secondary – To configure the second ip address for the DNS server.
u SNTP – Enable the SNTP server registering function if user wants to get
the correct time from the Command Line Interface.
u SNTP Server Address – Enter the correct ip address of the SNTP server
or get the incorrect time from the Command Line Interface.
u GMT – Configuring the time area for the time display in the Command
Line Interface.
u IP Sharing – Enable this function if the gateway is behind the IP sharing
device.
u IP Sharing Server Address – Enter the WAN IP address of the IP sharing
device if it is the fixed ip.
u PPPoE User Name – To configure the user name for the PPPoE
connection.
u PPPoE Password – To configure the password for the PPPoE connection.
u PPPoE IP Address – In the PPPoE mode, this table will show the ip
address that this unit gets from the ISP.
u PPPoE Destination – In the PPPoE mode, this table will show the default
gateway address that this unit gets from the ISP.
u PPPoE DNS primary – In the PPPoE mode, this table will show the DNS
ip address that this unit gets from the ISP.
u After Remote Host Disconnection – This unit will reboot and re-connect to
the ISP
25
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
3.2 SIP Config
This WEB page will help user to configure the information about the dial mode,
SIP information and the ports for the communication. Please get more info
about this configuration from the below detail descriptions. (see figure 3.2)
Figure 3.2: SIP Configuration
u Mode – Pick up the calling mode for this gateway.
n Peer-2-Peer : It only supports the peer-to-peer mode and users have
to define the phone book for this mode.
nProxy : Users have to register on the Proxy if users picked up this
option.
u Proxy IP Address – Enter the proxy ip if users pick up the proxy mode.
u Outbound Proxy – This version could support the outbound proxy, users
could define the ip address or domain name in this table.
u Proxy port – Users could change the destination port of the proxy. Before
this port changed, please make sure about that the Proxy port could be
changed in your proxy. The default value is 5060.
u Prefix String – Users could define this if the registration name was a
phonetic alphabet not the numbers.
u Line 1 Number – The phone number of the Tel 1.
u Line 2 Number – The phone number of the Line 1.
26
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
u Line 3 Number – The phone number of the Tel 2.
u Line 4 Number – The phone number of the Line 2.
u SIP port – Users could change the sip port of this unit for the registration.
u RTP port – Users could change the beginning RTP ports in this table.
u Expire – Users could change the expire time for the register message
sending.
27
FXSO SIP Gateway User Manual Document Ver.: 102
Released Dec., 2004
3.3 Security Config
Some proxy will include the security policy. The endpoint may need the user
account and password for the registration. If these are necessary, users could
put the correct account and password in the correct table. (see figure 3.3)
Figure 3.3: Security Configuration
u Line 1 Accou nt – The user name for the line 1 account.
u Line 1 Password – The password for the line 1 account.
u Line 2 Account – The user name for the line 2 account.
u Line 2 Password – The password for the line 2 account.
u Line 3 Account – The user name for the line 3 account.
u Line 3 Password – The password for the line 3 account.
u Line 4 Account – The user name for the line 4 account.
u Line 4 Password – The password for the line 4 account.
28
Loading...
+ 70 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
