Vertical Communications DXP User Manual
DXP, DXP
Plus, and
FX Series
Digital Communications System
Non-LCD Multi-line Telephone
Station User’s Guide
AW400p
1
ABC
DEF
3
2
MNO
GHI
JKL
4
6
5
WXY
TUV
PRS
9
HOLD
SPKR
708
#
OPER
T/C
MUTE
ITCM
TAP
unisyn01.cdr
COMDIAL
TRANS
TAP
CONF
DIGITECH
MUTE
SPKR
HOLD ITCM
This userguide is applicable tothe DigiTech
models 7714S-
and 7714X as well as the
**
Impression models 2122S-** and 2122X-**
non-LCD telephoneswhenused with the following digital communications systems:
DXP with Software Revision 9C
DXP or DXP Plus with Software Revision
11A and later
FX Series with Software Revision 12A and
later
NOTE: “S” in the model number means
Speakerphoneand “X” means Monitor Telephone.
CERTIFIED
ISO 9001
E
D
R
I
T
C
C
A
R
E
Accredited by the Dutch Council
for Accreditation for certification
and registration activities.
C
N
E
R
O
I
T
T
I
A
I
C
F
ANSI-RAB
G
I
R
T
S
E
D
R
A
Comdial's Quality Management System Is
Certified To The ISO 9001 Standard.
Comdial strives to design the features in our communications systems to
be fully interactive with one another. However, this is not always po ssible,
as the combinations of accessories and features are too varied and extensive
to insure total feature compatibility. Accordingly, some features identified
in this publication will not operate if some other feature is activated.
Comdial disclaims all liability relating to feature non-compatibility or
associated in any way with problems which may be encountered by
incompatible features. Notwithstanding anything contained in this
publication to the contrary, Comdial makes no representation herein as to
the compatibility of features.
2/12/97
GCA70-314 Contents
Contents
1 IntroducingtheTelephone................1-1
1.1 Introducing this Guide ........................................1-1
1.2 Introducing The Impression Model 2122S.........1-1
1.3 Introducing The Impression Model 2122X....... 1-2
1.4 Introducing The DigiTech Model 7714S............1-2
1.5 Introducing The DigiTech Model 7714X...........1-3
1.6 Using The Speakerphone....................................1-3
1.7 Understanding What The Lights Mean .............. 1-6
2 AnsweringCalls......................... 2-1
2.1 Answering Calls..................................................2-1
2.2 Answering A Subdued-Off Hook Voice
Announcement (SOHVA)...................................2-1
3 MakingCalls...........................3-1
3.1 Making Calls.......................................................3-1
3.2 Using Speed Dial ............................................... 3-3
3.3 Using Last Number Redial .................................3-3
3.4 Making A Subdued Off-Hook Voice
Announcement (SOHVA)...................................3-4
3.5 Camping On At A Station...................................3-5
4 HoldingCalls...........................4–1
4.1 Holding Calls .....................................................4-1
5 TransferringOutsideCalls................5-1
5.1 Transferring Outside Screened Calls..................5-1
5.2 Transferring Outside Unscreened Calls..............5-1
5.3 Making A Hot Transfer...................................... 5-2
5.4 Transferring Calls To Intercom Or Tie Line.......5-2
6 Conferencing........................... 6-1
6.1 Conferencing Stations Together .........................6-1
Non-LCD Station User's Guide – iii
Contents GCA70-314
7 UsingtheOtherFeatures.................7-1
7.1 Blocking Voice-Announce Calls.........................7-2
7.2 Diverting Incoming Calls To Another Station... 7-1
7.3 Forwarding Calls.................................................7-4
7.4 Making A Paging Announcement.......................7-3
7.5 Listening To a Call Over The Telephone’s
Speaker (Group Listening) .................................7-4
7.6 Muting Your Telephone.......................................7-4
7.7 Setting A Do Not Disturb Condition At Your
Station ................................................................ 7-5
7.8 Overriding A Call Or A Do Not Disturb Condition
At Another Telephone(Executive Override)......7-5
7.9 Setting Your Personal Ringing Tones................ 7-6
7.10 Using Background Music...................................7-6
7.11 Setting The Volume Control .............................. 7-7
8 UsingTheMessagingFeature............. 8-1
8.1 Using The Message Waiting Light..................... 8-1
8.2 Using LCD Messaging ...................................... 8-2
9 ProgrammingYourTelephone.............9-1
9.1 Storing Extension Numbers And
Feature Codes..................................................... 9-1
9.2 Storing Speed Dial Numbers..............................9-3
10 Operating Your TelephoneWith A DSS/BLF
Console.............................. 10–1
PublicationIndex..........................I–1
Appendix A (Quick Reference Guide). . . . . . . . . A-1
iv – Non-LCD Station User's Guide
GCA70-314 Introducing the Telephone
Introducingthe Telephone
1
1.1 Introducing This Guide
Congratulations and thank you for using an Impression or DigiTech
telephone! Once you have seen all of the options and benefits that your
new telephone offers, you will wonder how you ever did your job
without it. This guide offers helpful information for using all of the
functions of your new telephone and serves as a quick reference guide
as well. If you should need more information about a particular
function or a function that is not listed in this guide, consult the
Reference Manual, GCA 70-224 (your system attendant or telephone
system administrator should have several copies).
1.2 Introducing The Impression
Model 2122S Speakerphone
The Impression 2122S Speakerphone features a microphone that allows
you to have telephone conversations without lifting the handset.
unisyn02cdr
Programmable
Buttons
Speaker
Mute Button
Transfer or
Conference Button
Speaker Button
Message
Waiting Light
Hold Button
TAP Button
Intercom Button
GHI
PRS
SPKR
HOLD
1
ABC
4
708
OPER
DEF
3
2
MNO
JKL
6
5
WXY
TUV
9
#
T/C
MUTE
ITCM
TAP
Volume Control
Microphone Opening
Impression Model 2122S Speakerphone
Non-LCD Station User's Guide 1–1
Introducing the Telephone GCA70-314
1.3 Introducing The Impression
Model 2122X Monitor Telephone
The Impression Monitor Telephone has the same physical appearance
as the Impression Speakerphone. Although they look alike, there is one
functional difference in the way the telephones operate. The Monitor
Telephone includes a speaker that allows you to listen to incoming
calls. Although this model also features a microphone, you can only use
it to answer a call announce.
1.4 Introducing The DigiTech
Model 7714S Speakerphone
The DigiTech 7714S Speakerphone features a microphone that allows
you to have telephone conversations without lifting the handset.
Auxiliary
Jack
TAP
Button
Transfer/
Conference
Button
Speaker
Mute
Button
TRANS
CONF
Speaker
Button
SPKR
Volume
Control
Message
Waiting
Light
HOLD ITCM
Hold Button Microphone Opening
DigiTech Model 7714S Speakerphone
1–2 Non-LCD Station User's Guide
COMDIAL
DIGITECH
Programmable
Buttons
TAP
MUTE
Intercom
Button
AW400n
GCA70-314 Introducing the Telephone
1.5 Introducing The DigiTech
Model 7714X Monitor Telephone
The DigiTech Monitor Telephone has the same physical appearance as
the DigiTech Speakerphone. Although they look alike, there is one
functional difference in the way the telephones operate. The Monitor
Telephone includes a speaker that allows you to listen to incoming
calls. Although this model also features a microphone, you can only use
it to answer a call announce.
1.6 Using the Speakerphone
NOTE: The instructions in this section apply to the monitor telephone
only in call announce, hands-free answer back operation.
When using your speakerphone, the microphone and loudspeaker are
farther away from you than when you use your handset. Both the signal
from the loudspeaker and the signal to the microphone must be
strengthened. When microphones and loudspeakers are close together
(such as in a speakerphone), additional amplification typically
generates a ringing sound (public address systems do this if the volume
is too high or the microphone is too close to a loudspeaker).
Your speakerphone’s sound-activated switches allow either the
microphone or the loudspeaker to be on at a given time. This means
that voice sounds travel in only one direction at a particular moment.
Non-LCD Station User's Guide 1–3
Introducing the Telephone GCA70-314
1.6.1 Speakerphone User Guidelines
• Both parties cannot talk at the same time. You must wait for
silence out of your loudspeaker before talking. You must stop
talking to hear the other party.
• Background noise may prevent the sound-activated switches from
operating properly. Avoid placing the speakerphone where it will
detect sounds from typewriters, keyboards, printers, paging
systems, and other equipment.
• Speak slightly louder than normal and with a clear, authoritative
voice. For the microphone to best detect your voice, speak within
three feet of it and face the telephone.
• Raising the volume of the loudspeaker makes it easier for the
sound-activated switches in your telephone to select the distant
party’s voice. Lowering the volume of the loudspeaker makes it
easier for the switches to select your voice.
• Since the system takes several seconds to provide the bes t
switching, constant sound patterns—such as elongating your
words and playing externally-supplied music—may prevent the
sound-activated switches from operating properly.
1–4 Non-LCD Station User's Guide
GCA70-314 Introducing the Telephone
• Place the telephone on a hard surface and away from table edges.
Do not place the telephone in corners or enclosures. Do not let
obstructions come between you and the microphone. Rooms with
hard, flat surfaces that reflect sound may affect the
sound-activated switches.
• If you are using a handset and the other party is using a
speakerphone, avoid breathing heavily into your microphone.
Avoid other sounds that may affect the distant telephone’s
sound-activated switches.
• In some situations, such as when you or the distant party are in a
noisy environment, you may have to lift your handset to ensure a
clear conversation.
• When both you and the distant party use speakerphones, the
sound-activated switches can occasionally detect both voices
simultaneously, thus blocking out both voices.
Non-LCD Station User's Guide 1–5
Introducing the Telephone GCA70-314
1.7 Understanding What the Lights Mean
The lights on your telephone indicate the status of lines, features, and
intercom.
— Next to a Direct Station Select (DSS)/ Busy Lamp Field
(BLF) button:
Steady red = station is in use.
Flashing red = station is receiving a call.
Winking red = message-waiting light set for you by station
associated with that DSS button.
— Next to a line button:
Steady green = line is in use at your station.
Steady red = line is in use at another station.
Flashing red = your line is ringing.
Flashing orange = your line is ringing and will be answered
when you lift the handset.
Winking green = line is on hold at your station.
Winking red = line is on hold at another station.
Fluttering orange = line has recalled from hold at your station.
Fluttering green = a second line has recalled from hold at your
station before you have answered the first recalling line
(fluttering orange).
Fluttering red = line has recalled from hold at another station.
— Next to a fixed feature or programmable feature button:
Steady red = the feature is on.
Steady off = the feature is off.
— Next to an INTERCOM button:
Steady green with a quick flash = you are using your intercom.
Winking red = a message is set on your telephone for
others to receive when calling.
Flashing orange = another station is calling you.
— Next to the HOLD button:
Fluttering red = message awaits pick up.
Winking green = a line is on hold at your station.
— Next to the SPEAKER button:
On steady (with telephone on hook and busy) = speakerphone
mode is active.
On steady (with telephone on hook and idle) = background
music is turned on.
Flashing = feature viewing and programming is in progress.
— Next to the MUTE button:
On steady = called party cannot hear your conversation.
1–6 Non-LCD Station User's Guide
GCA70-314 Introducing the Telephone
1.7.1 Explanation Of Light P atterns
The lights on your telephone alert you to different conditions by
turning on and off in a certain pattern. You will observe the following
light patterns on your speakerphone or monitor telephone:
Flashing. The light flashes on and off at equal times (about 1/2 second
on and 1/2 second off).
Winking. In contras t to flashing, the light goes off for a very short time
compared to the time it is on.
Fluttering. Afluttering light is about eight times faster than a flashing
light.
unisyn04.cdr
Line Lights
(one for each button)
Mute Light
Speaker Light
Message
Waiting Light
Hold Light
Intercom Light
Mute
Light
Speaker
Light
Message
Waiting/
Hold Light
1
ABC
3
DEF
HOLD
GHI
PRS
SPKR
4
708
2
MNO
JKL
6
5
WXY
TUV
9
#
OPER
T/C
MUTE
ITCM
TAP
unisyn01.cdr
DSS/BLF Lights
(one for each button)
Lights On The Impression Models
AW400m
COMDIAL
TRANS
TAP
CONF
MUTE
SPKR
HOLD ITCM
DIGITECH
DSS/BLF Lights
Line Lights
Intercom
Light
Lights On The DigiTech Models
Non-LCD Station User's Guide 1–7
This page remains blank intentionally.
GCA70-314 Answering Calls
2
Answering Calls
2.1 Answering Calls
• To answer a call that is ringing at your telephone,
1. If the light is flashing orange, lift handset,
—OR—
if the light is flashing red, press the line button next to it and lift
handset.
• To answer a call using the speakerphone,
1. Press flashing line or INTERCOM button.
• To answer a call that is ringing at any telephone,
1. Lift handset.
2. Press INTERCOM and dial ✳ 4 plus extension number of
ringing telephone.
• To answer a call that is ringing at a particular telephone in
your group,
1. Hear ringing.
2. Press INTERCOM and dial #4(you must have the ringing
station programmed in your call pickup group).
3. Speak toward telephone to answer call. Lift handset if you
desire privacy or if you are using a monitor telephone.
Non-LCD Station User's Guide 2–1
Answering Calls GCA70-314
• To answer a call that is ringing the loud ringer or night
transfer station,
1. Hear ringing.
2. Lift handset.
3. Press INTERCOM.
4. Dial 65 through 68 to select ringing zone (1–4) at the location
of the bell, or dial 69 to answer any ringing zone.
NOTE: This feature is known as Trunk Access FromAny Station
(TAFAS).
2.2 Answering A Subdued-Off Hook
Voice Announcement (SOHVA)
The installer may arrange your telephone to receive a subdued off-hook
voice announcement (SOHVA). If so, an intercom caller may break into
your outside call and deliver a message to your telephone receiver for
you to hear.
NOTE: While off-hook on an outside call, you will hear several quick
tone bursts followed by an announcement delivered to your
ear through the handset.
• To block a SOHVA,
1. Press INTERCOM.
2. Dial ✳ 2.
• To remove block,
1. Press INTERCOM.
2. Dial #2.
• To respond verbally,
1. Press and hold MUTE.
2. Speak into handset.
3. Release MUTE to return to distant party.
2–2 Non-LCD Station User's Guide
GCA70-314 Answering Calls
• To respond non-verbally,
1. If announcing station has an LCD speakerphone, press a pre-
programmed RESPONSE MESSAGEbuttonto send message
to calling telephone.
The message you sent will appear on the LCD of the announcing
telephone and will disconnect the call.
NOTE: Announcing station must have LCD speakerphone. If
announcing telephone is not an LCD speakerphone, the call
will immediately disconnect.
Non-LCD Station User's Guide 2–3
This page remains blank intentionally.
GCA70-314 Making Calls
3
Making Calls
3.1 Making Calls
• To make a call,
1. Lift handset and select line (unless your telephone selects it for
you), or select intercom and listen for dial tone.
2. Either dial number, use speed dial feature, use redial feature, or
press Direct Station Select (DSS) if making an intercom call.
• To access outside line using the line group feature,
1. Press INTERCOM, then dial line group access code:
9 =linegroup1,
80–89 = line groups 2 through 11,
60–64 = line groups 12 through 16.
2. Listen for outside dial tone.
3. Dial number.
4. When called party answers, lift handset.
• To queue for a line group if all lines are busy,
1. Press INTERCOM and dial line group access code
(9, 80–89,or60–64).
2. Hear busy tone.
3. Dial ✳ 6.
4. Press SPEAKER.
Non-LCD Station User's Guide 3–1
Loading...
