VDO DAYTON PN 6000 User Manual
PN 4000
PN 6000
User Manual
Content
53
Content
General advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Safety advice and important information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Overview of device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
What's included? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Controls and connection ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
RCS 5100 remote control (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Setup and installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Display settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Screen settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Regional settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Address book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Change route – avoid traffic jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Simulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
TMC (Traffic Message Channel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Alert points displayed on the map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Position & speed/Select location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Select map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
System ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Bluetooth settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Toolbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Set route criteria/route profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Entering a destination. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Address book – Selecting an address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Geographical coordinates destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
POI – "Point of Interest" destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Guidance – Map display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Multimedia menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Music playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Picture viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Games. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Video player. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
DVB-T digital television . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
GPS and TMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
54
General advice
Safety advice and important information
Before you start to install and use this navigation system, please familiarise yourself with its
various components and functions. Please also read through the safety instructions carefully
to avoid personal injury to yourself and others.
Do not expose the navigation system to high temperatures or extreme sunlight.
Temperatures over 50°C can severely damage the navigation system, especially the
lithium ion battery. The lithium ion battery can only be charged within a temperature
range of 0-45°C. Please note the safety instructions when operating the battery!
The device is not splashproof and must therefore not be exposed to moisture, as this
may result in damage.
GPS (Global Positioning System) is a satellite-based system that supports geographical
and time-related information all around the world. The system is operated and controlled by the United States of America. The USA is also responsible for the availability
and accuracy of this system. All changes to the GPS availability and accuracy as well as
other factors from the surrounding environment can influence the operation of the
navigation system. The supplier of this system does not accept any liability whatsoever
for the availability and accuracy of GPS data.
When fixing the screen onto its mount in your vehicle, please note the following: Never adjust the screen by moving the navigation system itself; instead you should adjust
the mount. Position the screen so that you are able to glance at the display quickly and
easily. The device should also be positioned in a way that prevents reflections and
glare from the screen. The screen should not be positioned so that it obstructs your
view of things that are necessary for driving the vehicle (e.g. the view of the road or
the vehicle's instruments) or the safety systems in your vehicle.
The navigation system does not take the relative safety of the suggested routes into
consideration. Road closures, roadworks, height and weight restrictions, traffic and
weather conditions or other factors that can influence the safety and the journey time
of the route are not taken into consideration for the suggested routes. Use your own
judgement to check the suitability of the suggested routes. If required, use the
“Change Route” function to calculate alternatives to the original route. Alternatively
take the road you prefer and the software will automatically perform a re-routing
(i.e. calculate a new route based on your new position).
In certain areas, one-way streets, turning restrictions and no entry signs (e.g. pedestrian zones) cannot be accounted for. In such situations, pay particular attention to road
signs and applicable road traffic regulations.
If you need the help of the emergency services (police, fire, ambulance, etc.), do not
rely exclusively on the navigation system. Act at your own discretion and possibilities
in order to find help in such situations.
Please ensure that every person intending to use the navigation system reads this safety information and the recommendations for operating the system beforehand.
General advice
WEEE compliance
All electrical and electronic equipment must be disposed of separately from
general household waste using the sites designated by local authorities. If a
product displays this symbol of a crossed-out rubbish bin, the product is subject
to European Directive 2002/96/EC. The appropriate disposal and separate collection of used equipment serve to prevent potential harm to the environment and
to health. They are a requirement for the re-use and recycling of used electrical
and electronic equipment. For further information on disposing of your used
equipment, please contact your local authority, your refuse collection service or
the dealer you purchased the product from.
CE quality mark
This product satisfies the requirements for the CE quality mark for use in a home,
office or commercial environment.
R&TTE directive
We, Siemens VDO Trading GmbH, declare that this device complies with the essential
requirements and other pertinent regulations laid down in Directive 1999/5/EC.
The declaration of conformity can be requested from the following address:
Siemens VDO Trading GmbH, Kruppstraße 105, 60388 Frankfurt am Main, Germany.
Batteries
In many countries it is forbidden to dispose of empty batteries with normal
household waste. Please find out the regulations that apply in your area regarding the disposal of used batteries/rechargeable batteries. Please also dispose of
damaged batteries or batteries that are past their expiry date in a safe and suitable way.
55
56
Overview of device
What's included?
Your navigation system package includes the following parts:
1 Navigation system
2 Lithium ion battery
3 Mount with suction cup for attaching the device to the windscreen
4 12 V DC cable to power the navigation system from within the vehicle
(adapter for cigarette lighter)
5 100/240 V AC adapter
You must not use any cables other than the supplied AC adapter and DC cable to
power the device and to charge the battery!
6 Quick Start guide
7 SD card with map data
8 DVB-T aerial (with cable)
9 DVB-T aerial (without cable)
9
3
1
8
2
6
5
4
What you can get as an option:
• External GPS aerial
• Additional battery pack
• Active cradle (TMC or TMC+Bluetooth)
• Car connectivity cable
• Active DVB-T aerial (for improved reception in areas where the DVB-T signal is weak)
• Steering wheel remote control (infrared)
7
Controls and connection ports
57
1
2
Top
1 Power button
• Briefly press the power button to switch the navigation system to stand-by mode
• Briefly press the button a second time to turn the system on again
• Press and hold the button for approx. 3 seconds to turn off the navigation system
• To turn the device back on again, press and hold the button for approx. 3 seconds.
The navigation system will be completely restarted.
2 Light sensor: This sensor automatically adapts the brightness of the screen according to
the surrounding light. This function can be activated/deactivated in the Settings menu.
4
5
3
Front
3 Display/touchscreen
4 Charging symbol. This status LED displays the following:
Green The device is being powered by an external supply and
battery is charged to at least 95% of total capacity.
Red The device is being powered by an external supply and
the battery is being charged.
Orange The device is being powered by an external supply and no battery is inserted.
Off The device is not being powered by an external supply.
5 Infrared sensor
This can be used in conjunction with
an RCS 5100 steering wheel remote control (accessory)
58
Controls and connection ports
10
7
6
8
9
11
Back
6 Compartment for lithium ion battery (cover)
7 External GPS port
8 Loudspeaker
9 Grooves for cradle fixation
10 DVB-T aerial port (cover)
11 Foot (extractable)
left side
12
8
9
right side
13
12 Slot for SD card
13 Earphone socket
Earphones/volume control: High volumes can damage or decrease the sensitivity of
your hearing.
14 100 V/240 V power adapter (optional) or 12 V cigarette lighter port
14
Controls and connection ports
16
59
17
15
Bottom side
15 Serial port – only for active cradle (optional)
16 USB port for connection to your PC
17 Reset button: If the navigation system stops responding to your entries, you can reset
the system by pressing this button (e.g. with a straightened-out paper clip or a pencil).
The data you have saved will NOT be lost! Restart the navigation system by pressing the
power button.
20
19
18
Mount
18 Base
19 Suction cup
20 Locking lever
Mount with suction cup may vary from the picture.
21 Passive cradle (optional)
21
60
Controls and connection ports
23
22
22 Active cradle (optional)
23 Car connectivity cable socket
24 100 V/240 V power adapter (optional) or 12 V cigarette lighter port
25 Line-out/audio
26 TMC aerial port
27 Microphone-in/Bluetooth (optional)
24
25
26
27
TMC active cradle: Features marked with this symbol are only active if you have
purchased a TMC active cradle and the navigation device is mounted in this cradle.
BT active cradle: Features marked with this symbol are only active if you have
purchased a BT active cradle and the navigation device is mounted in this cradle.
BT and TMC buttons on the user interface of the navigation device can only be used if
the device is being operated by the relevant active cradle.
Steering wheel remote control
61
RCS 5100 remote control (optional)
With the remote control placed on your steering wheel, you can easily operate the navigation system while driving. Set the mode switch (3) to Navigation.
1 If you press this button briefly the voice message will repeat itself. If you press and hold
the button the alternative route planning menu is displayed.
2 You can use the cursor keys to navigate through the menus.
In Map display, cursor left/right will zoom the map.
3 Mode switch (Navigation N / Audio A).
4 Confirm selections by pressing this button.
5 Press this button briefly to see the Map display. Pressing and holding the button opens
the Toolbar.
6 Pressing this button reduces the navigation advice volume. In setting screens with
sliders the button can be used to reduce the selected slider value.
7 Pressing this button increases the navigation advice volume. In setting screens with
sliders the button can be used to increase the selected slider value.
62
Setup and installation
Getting started
Before you can switch on the navigation
system for the first time, you must insert
the battery. This is carried out with the following steps:
• Open the battery compartment.
• Push the battery into the battery compartment with the contacts facing
downwards. You can now close the battery compartment.
• Connect the navigation system to the
12 V power supply in your vehicle. The
battery will now start to charge. It takes
approx. 8 hours to fully charge the battery.
The battery life without external power
supply is approx. 5 hours for navigation
and approx. 2 hours for DVB-T with the
PN 4000 (approx. 6 hours for navigation
and approx. 4 hours for DVB-T with the
PN 6000). The battery life also depends
on the display brightness you have selected.
• Insert the supplied SD card containing
the maps into the SD card slot.
With an active cradle you can use the
car battery/keyswitch connection in combination with the optional car connectivity
cable. The navigation device will automatically switch on or off by turning the car key
in the ignition. Once the navigation device is inserted in the active cradle and the
ignition is switched on, the battery is automatically charged.
When using a passive cradle:
• You must turn the device on and off using the power button.
• You can charge the battery by using the cigarette lighter cable
The battery must only be charged if someone is monitoring the device. Do not open
the battery by force as this may release corrosive acid. Damaged batteries or batteries
that are past their expiry date must no longer be used and should be disposed of in a
safe and suitable way.
Setup and installation
63
Installation
• Before attaching the cradle to the windscreen, clean the relevant windscreen area as
well as the cradle's suction pad, and ensure they are free from grease and dust.
• Differences between daytime and nighttime temperatures and/or humidity and moisture may cause the vacuum under the suction cup to disintegrate. Therefore you should
attach the navigation system so that it will not sustain damage if it falls off the windscreen. As a precautionary measure, you should detach the navigation system at night.
• Please do not use any cleaning agents or detergents to clean the screen and case of the
device. The best method is to use a soft, damp cloth.
The device must not be attached in a position that obscures the view. Nor should the
device be attached within the area in which the airbags open or within reach of the
head or knees in the event of a collision.
Secure the device so that it will not slide around in the event of emergency braking or
a collision.
To install the device in the vehicle, proceed as follows:
• Find a suitable place in the vehicle for attaching
the cradle. The screen should be clearly visible from
the driver's seat (with a clear view of the sky) but
the device should not obscure the driver's view.
• Press the suction cup against the windscreen and
push the lever towards the windscreen until it locks
into place.
• Attach the navigation system to the cradle.
Dismounting: To detach the device, move the
lever in the opposite direction and carefully pull
the transparent rubber end of the suction cup to
remove it from the window.
For safety reasons you should install the device and enter the required information in
the system before you start your journey or when your vehicle is stationary.
The use of the navigation system does not under any circumstances release the driver
from his/her personal responsibility. The applicable road traffic regulations and
current traffic conditions always have priority. The information provided by the device
is for orientation purposes only and is not binding.
Always check the information provided by the device (speed, remaining travelling
time, distance, recommended route).
Only look at the screen when it is safe to do so. If you need to look at the screen for a
longer period of time, stop the vehicle at an appropriate and safe place.
The touchscreen must not be operated with sharp or rough-edged objects as these can
damage it.
Furthermore, if you plan to leave the vehicle unattended for a long period of time, you
should remove the navigation system from the vehicle in order to avoid theft.
64
Settings
Configuration
• After switching on the navigation system, the
legal disclaimer screen appears.
• Tap OK after reading the screen.
• As soon as the system is ready, the Main menu
will appear on the screen.
Touchscreen: The navigation system is
equipped with a touchscreen. The icons on
the screen function as buttons and should be
tapped with your fingers.
Do not touch the screen with sharp or roughedged objects as these can damage the sensitive touchscreen display.
Main menu
The following functions are available in the Main
menu:
Destination (page 80)
Tap the Destination button to have the
navigation system to guide you from
your present location to a specific destination. A submenu opens with further
guidance functions and an address input field. For further information,
please see "Navigation" page 80.
Home/Work
The Home and Work buttons allow you to store two frequently used
addresses so you can call them up quickly.
Once you have entered your home or work address, the device will guide you to those
locations from wherever you might be. Simply tap the Home or Work button in the Main
menu. The addresses stored in these functions can be changed at any time. (See "Adding to
the address book" on page 83.)
Map display (page 65)
Tap the Map display button to call up the relevant map view before or during
guidance.
Settings
Settings (page 65)
Tap the Settings button to change basic settings e.g. language, volume, brightness, unit of measurement (kilometres or miles). A submenu appears with further
guidance settings and further navigation system functions.
Multimedia (page 85)
Tap th e Multimedia button to open the multimedia selection.
A submenu opens with further Multimedia options and applications such as
music playback or DVB-T TV.
Settings
Tap th e Settings button to make your preferred settings. The first of three
submenus is opened.
Tap the arrow button on the bottom right of the screen to scroll through the
other pages of the submenu.
Tap Back in the top left corner of the screen to exit the current screen without saving
the settings. This takes you back to the previous menu. If you tap OK the selection you
have made is saved and you return to the previous menu.
What you select here can be changed at any time. Software updates may change the
menu structure.
65
Display settings
Tap this button to open the map settings. The selected settings are marked and
activated with a green tick.
Vehicle direction: Tap this button to select your preferred map orientation. If
the green tick is set, the map display follows the travel direction of the vehicle.
If no tick is set, the map is displayed with North at the top of the screen and the
icon indicates the travel direction on the map.
3D display: Tap this button to view the map in 3D format. The map cannot be
oriented northwards in 3D format. The Vehicle direction is deactivated.
Visual advice: Tap this button to indicate changes of direction in arrow format
during Traffic Info On Route guidance.
66
Settings
Auto scale: Activate this function to automatically scale the map view. Scaling
is carried out depending on the speed, and when approaching a crossing.
Full route display: Activate this option to clearly display the full remaining
route with active guidance on the screen. The selected mode is indicated by a
green tick. If you do not wish to use Full route display, deactivate the setting. The
Zoom in/out function is not possible with this setting.
Current street: Tap this button to display the name of the street you are
currently on. The street name is displayed at the bottom of the screen.
Current city: Tap this button to display the name of the city you are currently
in. The street name is displayed at the bottom of the screen.
Next street: Tap this button to display the name of the street you will turn onto
next at the top of the screen.
Lane guidance: This function advises on lane selection for motorways and rural
roads based on the next direction change. Tap this button to use this function.
The available lanes are displayed in the Traffic Info on Route and the preferred
lane is indicated in green.
Destination arrow: Tap this button to have an arrow indicate the direction of
the selected destination – relative to the travel direction – during Traffic Info on
Route guidance.
TMC icons: Tap this button to have detailed information on TMC messages (e.g.
traffic jams) on the screen in the form of icons. Only available with the optional
TMC active cradle.
POI icons: Tap this button to have POI
categories (e.g. petrol stations or ho-
tels) displayed on the screen. When you
tap the button, the POI category list is
displayed. You can then tap the required category in order to display, for
example, the petrol stations on the
map. Please also see "POI – "Point of Interest" destination" on page 82.
Screen settings
Tap this button to make your preferred screen settings. The selected settings are
marked and activated with a green tick.
Colours: You can select various different colours for the background of the
screen display. Tap this button and select a colour scheme from the list. All of the
menus on the screen are then displayed in the chosen colour scheme.
Night/Day: By activating this button you can switch the display to Night or Day
mode. This function is not active when Automatic brightness is activated.
Brightness: A submenu opens with a tap controller for day and
night brightness. Select the desired value in percentage and confirm with OK.
Automatic brightness: If you activate this button, the brightness of the screen
is automatically adjusted using the navigation system's light sensors. Manual
Night/Day switching is deactivated.
Status bar: The status bar is always displayed at the bottom of the screen. In the
status bar settings, you can set up to six information types for which you will
receive details.
Possible information types:
•Time
•Date
• Arrival time
• Travel time
• Travel distance
• Delay (through traffic congestion,
based on TMC messages)
• Speed limit
• Speed
• Altitude
• TMC provider
• Battery status
• GPS status
• Bluetooth status
Tap field 1 to field 6 consecutively and select the desired information type from
the list that follows.
You can also change the status bar information types directly
by tapping the relevant folder in the status bar.
Settings
67
Loading...
