Datasheet
8/16/24-Port
Gigabit Switch
TL-SG1008 / TL-SG1016D / TL-SG1024D
Overview
The TL-SG1008/TL-SG1016D/TL-SG1024D Gigabit Ethernet Switch provides you with a
high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old
network to 1000Mbps network. All 8/16/24 ports support auto MDI/MDIX, no need to worry
about the cable type, simply plug and play. Moreover, with the innovative energy-ecient
technology, the TL-SG1008/TL-SG1016D/TL-SG1024D can save up to 75%/40%/40%* of the
power consumption and 80% of the packaging material can be recycled, making it an
eco-friendly solution for your business network.
www.tp-link.com
Copyright © 2012 TP-LINK Technologies Co., Ltd. All rights reserved.
Green Technology
Saving power 75%/40%/40%
Recyclable packaging material
High Performance
IEEE 802.3x ow control
Non-blocking switching
architecture
16/32/48 Gbps Switching
Capacity
Store and forward
Auto-MDI/MDIX
Auto-negotiation
MAC address auto-learning and
auto-aging
10KB Jumbo frame
Easy to use
Plug and Play design
Quiet/Fanless design
Datasheet
8/16/24-Port Gigabit Switch
TL-SG1008 / TL-SG1016D / TL-SG1024D
TP-LINK Green Technology
This new generation TL-SG1008/TL-SG1016D/TL-SG1024D Gigabit Switch features
the latest innovative energy-ecient technologies that can greatly expand your
network capacity with much less power. It automatically adjusts power consumption
according to the link status and cable length to limit the carbon footprint of your
network. It also complies with the EU’S RoHS, prohibiting the use of certain hazardous
materials. Besides, 80% of the packaging material can be recycled.
24 / 7
Global technical support
Details:http://www.tp-link.com/
support/Localesupport.asp
German/Austrian/Swiss users are
not included
High Performance
All 8/16/24 ports are Gigabit RJ-45 ports which can provide large le transferring and
also be compatible with 10Mbps and 100Mbps Ethernet devices. Featuring
non-blocking switching architecture, TL-SG1008/TL-SG1016D/TL-SG1024D forwards
and lters packets at full wire-speed for maximum throughput. With 10KB Jumbo
frame, the performance of large les transfers is improved signicantly. And IEEE
802.3x ow control for Full Duplex mode and backpressure for Half Duplex mode
alleviate the trac congestion and make The TL-SG1008/TL-SG1016D/TL-SG1024D
work reliably. It’s a perfect choice to update your network to Gigabit while protecting
your previous investment properly.
Easy to Use
The auto features of this gigabit switch make installation plug and play and
hassle-free. No conguring is required. Auto MDI/MDIX eliminates the need for
crossover cables. Auto-negotiation on each port senses the link speed of a network
device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal
performance.
www.tp-link.com
Copyright © 2012 TP-LINK Technologies Co., Ltd. All rights reserved.
Datasheet
Specifications
Product Picture
Model
Standards
Network Ports
Auto Negotiation
Auto MDI/MDIX
Systems
Forwarding Mode
Switch Capacity
MAC Address Table
Jumbo Frame
Flow Conrol
Fanless
Green Technology
Power Saving
LED
Dimensions
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Ordering Information
：
TL-SG1008 TL-SG1016D TL-SG1024D
IEEE 802.3,
IEEE 802.3u,
IEEE 802.3x
8*10/100/1000Mbps RJ45 ports
YES
YES
Windows 2000/XP/Vista/7
Linux/MAC OS
Store and Forward
16 Gbps
8 K
10 KB
YES
YES
YES
Up to 75%
Power、1000Mbps、Link/Act
294*180*44 mm
0°C~40°C (32°F~104°F)
-40°C~70°C (-40°F~158°F)
10%~90% non-condensing
5%~90% non-condensing
8-Port Gigabit switch
IEEE 802.3,
IEEE 802.3u,
IEEE 802.3x
16*10/100/1000Mbps RJ45 ports
YES
YES
Windows 2000/XP/Vista/7
Linux/MAC OS
Store and Forward
32 Gbps
8 K
10 KB
YES
YES
YES
Up to 40%
Power、1000Mbps、Link/Act
294*180*44 mm
0°C~40°C (32°F~104°F)
-40°C~70°C (-40°F~158°F)
10%~90% non-condensing
5%~90% non-condensing
16-Port Gigabit switch
IEEE 802.3,
IEEE 802.3u,
IEEE 802.3x
24*10/100/1000Mbps RJ45 ports
YES
YES
Windows 2000/XP/Vista/7
Linux/MAC OS
Store and Forward
48 Gbps
8 K
10 KB
YES
YES
YES
Up to 40%
Power、1000Mbps、Link/Act
294*180*44 mm
0°C~40°C (32°F~104°F)
-40°C~70°C (-40°F~158°F)
10%~90% non-condensing
5%~90% non-condensing
24-Port Gigabit switch
* Maximum power savings when compared to a TP-LINK conventional switch, the real saving rate may vary based on the usage condition.
