For Your Convenience
Online
Be sure to register your TV.
Registration: United States http://productregistration.sony.com Canada http://www.SonyStyle.ca/registration
4-170-417-13(1)
© 2010 Sony Corporation Printed in China
LCD
Digital Color TV
Operating Instructions
4-170-417-13(1)
Introducing Your New BRAVIA®
Getting Started
Operating the TV
Using Features
Using the Menus
Other Information
Sony Customer Support
U.S.A.: www.sony.com/tvsupport Canada: www.sony.ca/support
United States |
Canada |
1.800.222.SONY |
1.877.899.SONY |
Please Do Not Return the Product to the Store
KDL-60EX500 / 55EX500 / 55EX501 / 46EX400 / 46EX401 / 46EX500 / 46EX501 KDL-40EX400 / 40EX401 / 40EX500 / 40EX501 / 32EX301 / 32EX400 / 32EX500 KDL-32FA600
Owner’s Record
The model and serial numbers are located at the side and rear of the TV. Record these numbers in the spaces provided below. Refer to them whenever you call upon your Sony dealer regarding this TV.
Model Name
Serial No.
CAUTION
To prevent electric shock and blade exposure, do not use this polarized AC plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted.
Operate the TV only on 110-240 V AC.
Avoid operating the TV at temperatures below 41°F (5°C).
Licensing Information
Macintosh is a trademark of Apple Inc., registered in the U.S. and other countries.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.
Fergason Patent Properties, LLC:
U.S. Patent No. 5,717,422
U.S. Patent No. 6,816,141
Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories.
Blu-ray Disc is a trademark.
“BRAVIA” and , Motionflow, BRAVIA Sync, and are trademarks or registered marks of Sony Corporation.
“PlayStation” is a registered trademark and “PS3” is a trademark of Sony Computer Entertainment Inc.
(KDL-32FA600 only)
Cleaning
When cleaning, be sure to unplug the power cord to avoid any chance of electric shock.
•Wipe the LCD screen gently with a soft cloth.
•Stubborn stains may be removed with a cloth slightly moistened with a solution of mild soap and warm water.
•If using a chemically pretreated cloth, please follow the instruction provided on the package.
•Never use strong solvents such as a thinner, alcohol or benzine for cleaning.
•See the supplied Safety Booklet for additional information.
The 32 class has a 31.5 inch viewable image size and the 55 class has a 54.6 inch viewable image size (measured diagonally).
2
Contents
Introducing Your New BRAVIA®
Welcome to the World of BRAVIA® . . . . . . . .4
Experiencing Stunning HD with Your
BRAVIA . . . . . . . . . . . . . . . . . . . . . . . . . . .4
The Four Steps to a Stunning HD
Experience . . . . . . . . . . . . . . . . . . . . . . . . .5 TV Feature Highlights . . . . . . . . . . . . . . . . . . .5
Getting Started
Setting Up Your TV . . . . . . . . . . . . . . . . . . . . .7 Locating Inputs and Outputs . . . . . . . . . . . . . .8 Adjusting the viewing angle of the TV. . . . . .10 Connecting the TV . . . . . . . . . . . . . . . . . . . .10 Connecting Other Equipment . . . . . . . . . . . .14
When Installing the TV Against a Wall or Enclosed Area . . . . . . . . . . . . . . . . . . . . .15
Securing the TV . . . . . . . . . . . . . . . . . . . . . .16
Running Initial Setup. . . . . . . . . . . . . . . . . . .18
Using Features
BRAVIA® SyncTM with Control for HDMI . . .25 Using PIP Feature. . . . . . . . . . . . . . . . . . . . .26 Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Wide Mode . . . . . . . . . . . . . . . . . . . . . . . . . .27 Wide Mode with PC . . . . . . . . . . . . . . . . . . .28 Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 Playing back Photo/Music/Video via USB. . .29
Using the Menus
Navigating through TV Menus . . . . . . . . . . .30 Using the Picture Settings. . . . . . . . . . . . . . .31 Using the Sound Settings . . . . . . . . . . . . . . .33 Using the Screen Settings . . . . . . . . . . . . . .35 Using the Channel Settings . . . . . . . . . . . . .37 Using the Parental Lock Settings . . . . . . . . .38 Using the Setup Settings . . . . . . . . . . . . . . .41 Using the Eco Settings . . . . . . . . . . . . . . . . .45
Operating the TV
Using the Remote Control |
19 |
Other Information |
|
|
PC Input Signal Reference Chart for |
|
|||
Remote Control Button Description |
20 |
|
||
PC and HDMI IN 1/2/3/4 |
46 |
|||
TV Controls and Indicators |
24 |
|||
Using a Wall-Mount Bracket |
47 |
|||
|
|
|||
|
|
Installing the Wall-Mount Bracket . . . . . . . . . |
47 |
|
|
|
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . |
52 |
|
|
|
Important Notices . . . . . . . . . . . . . . . . . . . . . |
56 |
|
|
|
Specifications . . . . . . . . . . . . . . . . . . . . . . . . |
57 |
|
|
|
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
59 |
Customer Support |
On-line Registration |
United States |
United States |
http://www.sony.com/tvsupport |
http://productregistration.sony.com |
Canada |
Canada |
http://www.sony.ca/support |
http://www.SonyStyle.ca/registration |
|
|
3
Thank you for choosing this Sony BRAVIA® high-definition television. Use the documentations listed below to get the most out of your TV.
Safety Booklet
Contains precautionary measures to keep you and your TV safe. Read this information prior to setting up your TV.
Operating Instructions
Provides the most detailed information to operate your TV.
Quick Setup Guide
Provides TV setup information with sample connection diagrams.
The quality of the image you see on your BRAVIA TV is only as good as the quality of the signal it receives. To experience the stunning detail of your new BRAVIA TV, you need access to HD programming. Your BRAVIA TV can receive and display HD programming from:
•Over-the-air broadcasting via HD-quality antenna
•HD cable subscription
•HD satellite subscription
•Blu-ray Disc™ player or other HD compatible external equipment
Contact your cable, satellite or HD service provider for information on upgrading to HD programming.
4
Set, Source, Sound, and Setup
Along with your BRAVIA TV set, a complete HD system requires a source of HD programming, an HD sound system, and a proper connection setup. Refer to the Quick Setup Guide, enclosed separately, for connecting optional equipment.
You can enjoy crisp, clear images, smooth movement, and high-impact visuals from 1080 HD signals as shown here.
When you compare a high-definition signal to a standard analog signal, you will notice a big difference in picture quality. If black bars appear as shown here, press WIDE on the remote control to fill the screen.
Your BRAVIA comes with many convenient features, such as:
BRAVIA® SyncTM: Allows your BRAVIA TV to communicate with other Sony equipment supporting the Control for HDMI function (page 25).
Digital Media Accessibility: Use the Photo, Music, and Video icons to access photo, music, and video files from Sony USB equipment (page 29).
PIP (Picture in Picture): You can work on your PC and watch your favorite TV program simultaneously (page 26).
Favorites: Your favorite channels and inputs are at your finger tips for easy access (page 27).
Auto Wide Mode: Set your TV to automatically adjust the screen based on the signal resolution (page 27).
Input Selection: Allows you to easily switch between the connected equipment (page 28).
Motionflow: Enhance the smooth picture movements to reduce the blur (page 31). (This feature is available for models: EX500 and EX501.)
Scene Select: Allows you to easily adjust your TV to the most suitable picture and sound settings based on the scenes for the best quality result for the contents genre you are watching (page 21).
®BRAVIA New Your Introducing
(Continued) 5
Ambient Sensor: Automatically optimizes the picture settings according to the ambient light in the room. The sensor detects ambient light levels to adjust the brightness and color temperature of the picture. With this feature you can have the best picture quality under your room’s lighting conditions (page 32).
6
Some TV models are packaged with a detached Table-Top Stand so you can mount your TV to a wall right away. If you are not mounting the TV to a wall, you will need to attach the Table-Top Stand. You will need a Phillips screwdriver and the supplied screws to complete the task. Look for the attachment instructions provided with the TV.
Be sure to consider the following while setting up your TV:
• Disconnect all cables when carrying the TV.
•Carry the TV with the adequate number of people; larger size TVs require two or more people.
•Correct hand placement while carrying the TV is very important for safety and to avoid damage.
Except KDL-32FA600 model |
KDL-32FA600 model only |
• Place your palm directly underneath but do not squeeze the panel’s speaker grill area.
•Ensure your TV has adequate ventilation, see page 15.
•For best picture quality, do not expose the screen to direct illumination or sunlight.
•Avoid installing the TV in a room with reflective wall and floor materials.
•Avoid moving the TV from a cold area to a warm area. Sudden room temperature changes may cause moisture condensation. This may cause the TV to show poor picture and/or poor color. Should this occur, allow moisture to evaporate completely before powering the TV on.
Started Getting
7
Rear Panel |
|
|
Side Panel |
2 |
3 4 |
5 |
6 |
|
|
|
AUDIO |
|
|
|
|
|
|
|
R |
L (MONO) |
|
VIDEO IN |
|
|
|
1 |
|
|
|
1 |
|
|
|
|
PR |
PB |
Y |
|
|
|
|
|
AUDIO |
|
|||
|
COMPONENT IN |
|
|
|
|
|
|
CABLE/ |
(1080p/1080i/ |
2 |
|
|
|
|
VIDEO IN |
ANTENNA |
720p/480p/480i) |
R |
L |
|
|
||
|
RGB |
|
|
|
AUDIO |
2 |
|
|
|
|
|
VIDEO |
|||
DIGITAL |
PC IN |
|
|
|
|
PC/HDMI 1 |
|
|
|
|
|
|
|||
AUDIO OUT |
|
|
|
|
|
AUDIO IN |
|
(OPTICAL) |
|
|
AUDIO |
|
|
|
L |
|
|
|
|
|
1 |
||
|
AUDIO OUT |
|
|
|
|
(MONO) |
|
|
|
|
|
|
|
|
|
|
(FIX) |
|
|
|
|
|
|
|
|
|
R |
L |
|
|
AUDIO |
|
|
|
|
|
|
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
R |
|
|
|
|
|
|
IN |
|
|
2 |
SUBWOOFER |
SATELLITE |
(8 ) |
R (8 ) L |
AC IN |
SPEAKERS |
|
3 |
1*1 |
|
|
IN |
7 |
8 |
9 |
|
Item |
Description |
|
|
0
qa
9
1 AC IN |
Connect the supplied power cord to AC IN and the nearest wall outlet. |
2DIGITAL AUDIO Connects to the optical audio input of digital audio equipment that is PCM/Dolby*2 OUT (OPTICAL) Digital compatible.
3 CABLE/ |
RF input that connects to your Cable or VHF/UHF antenna. |
|
ANTENNA |
|
|
|
|
|
4 COMPONENT |
Component video provides better picture quality than the composite video. |
|
IN 2 |
Audio connection is required for the COMPONENT IN ports, connect audio (L/R). |
|
(1080p/1080i/ |
|
|
720p/480p/480i)/ |
|
|
R-AUDIO-L |
|
|
|
|
|
5 VIDEO IN 1/ |
This input port can be used as a composite video input (VIDEO 1) or as a |
|
COMPONENT |
component video input (COMPONENT 1). For composite use, connect the yellow |
|
IN 1 |
jack to Y for video and use audio L (mono) and R for audio signal. For component |
|
(1080p/1080i/ |
connection, use Y, PB, PR for video signals and also connect the audio L (mono) |
|
720p/480p/480i)/ |
and R for audio signal. |
|
R-AUDIO-L |
This TV can auto detect and switch between the VIDEO 1 and COMPONENT 1 |
|
when VIDEO 1 or COMPONENT 1 is connected. |
||
(MONO) |
||
To set to auto detection, press MENU, select Settings, and then select the Setup |
||
|
||
|
settings. Select the Video/Component 1 Selection option then set to Auto. |
*1 In the case of 32 and 40 inch models, the AC power cord is attached to the TV.
*2 Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
8
Item |
Description |
6 PC IN |
Connects to a personal computer’s video and audio output connector. Can also be |
(RGB/AUDIO) |
connected to other analog RGB equipment. See “PC Input Signal Reference Chart” |
|
on page 46 for the signals that can be displayed. |
|
For some Apple Macintosh computers, it may be necessary to use an adapter (not |
|
supplied). If an adapter is used, connect the adapter to the computer before |
|
connecting the HD15-HD15 cable. |
|
You may need to adjust the TV settings or your PC’s resolution and timing. See |
|
page 13 for information on how to setup your PC to this TV. |
|
|
7 AUDIO OUT |
Connects to the left and right audio input jacks of your analog audio equipment. |
(FIX) R/L |
You can use these outputs to listen to your TV’s audio through your stereo system. |
|
|
8 SPEAKERS |
Connects the Subwoofer and the Satellite Speakers (supplied with KDL-32FA600) |
SUBWOOFER |
to the TV. |
(8Ω) |
|
SATELLITE |
|
(8Ω)R/L |
|
(KDL-32FA600 |
|
only) |
|
|
|
9 HDMI IN 1/2/3/4 |
HDMI (High-Definition Multimedia Interface) provides an uncompressed, all- |
|
digital audio/video interface between this TV and any HDMI-equipped audio/video |
|
equipment, such as a set-top box, DVD player, and A/V receiver. HDMI supports |
|
enhanced, or high-definition video, plus digital audio. Be sure to use only an HDMI |
|
cable that bears the HDMI logo. |
|
Use the HDMI IN 1 port when connecting DVI equipment. Use a DVI-to-HDMI |
|
cable or adapter (not supplied). Equipment using a DVI connection also requires an |
|
additional audio connection using an audio cable connected to AUDIO of PC IN. |
|
|
0 USB |
Connects to USB equipment to access photo, music, and video files. |
|
|
qa VIDEO IN 2 |
Connects to the composite video output jack of video equipment. |
VIDEO/L |
If you have mono equipment, connect its audio output port to the TV’s L (MONO) |
(MONO)- |
audio input port. |
AUDIO-R |
|
|
|
Started Getting
•An HDMI or Component video (YPBPR) connection is required to view 480i, 480p, 720p, 1080i and 1080p video formats. 1080/24p is available only with HDMI connection.
9
For KDL-55EX500/KDL-46EX500/KDL-40EX500/KDL-32EX500/KDL-55EX501/KDL-46EX501/
KDL-40EX501
This TV can be adjusted within the angle shown below.
Adjust the angle left and right (swivel)
|
Top view |
20° |
20° |
20° |
20° |
|
Front |
5.1 Surround Sound System (KDL-32FA600 only)
Refer to the supplied Quick Setup Guide for details.
Cable System or VHF/UHF Antenna System
You can enjoy high-definition and standard-definition digital programming (if available in your area) along with standard-definition analog programming.
This TV is capable of receiving unscrambled digital programming for both cable (QAM and 8VSB) and external VHF/UHF antenna (ATSC).
Cable or VHF/UHF (or VHF only)
75-ohm coaxial cable Rear of TV CABLE/ANTENNA
•It is strongly recommended that you connect the CABLE/ANTENNA input using a 75-ohm coaxial cable to receive optimum picture quality. A 300-ohm twin lead cable can easily be affected by radio frequency interference, resulting in signal degradation.
10
Cable System and VHF/UHF Antenna System
Use an optional A-B RF switch (not supplied) to switch between the cable and over-the-air antenna programming, as indicated below.
|
A/B RF Switch |
|
Cable |
A |
Rear of TV |
|
B |
|
Antenna |
CABLE/ANTENNA |
•Be sure to set the Signal Type setting to Cable or Antenna found under the Channel settings for your input signal (see page 37).
HD Cable Box/HD Satellite Box
You can enjoy high-definition programming by subscribing to a high-definition cable service or a high-definition satellite service. For the best possible picture, make sure you connect this equipment to your TV via the HDMI or component video (with audio) input located on the back of your TV.
Shown with HDMI Connection
CATV/Satellite antenna cable
Rear of TV
AUDIO |
HD cable box/ |
R L (MONO) |
VIDEO IN |
|
HD satellite box |
|
1 |
|
|
1 |
|
PR |
PB |
Y |
|
|
AUDIO |
|||
|
COMPONENT IN |
|
|
|
CABLE/ |
(1080p/1080i/ |
|
|
|
ANTENNA |
720p/480p/480i) 2 R |
L |
|
|
|
RGB |
|
AUDIO |
|
DIGITAL |
PC IN |
|
|
PC/HDMI 1 |
AUDIO OUT |
|
|
|
AUDIO IN |
(OPTICAL) |
AUDIO |
|
|
|
|
|
|
1 |
|
|
AUDIO OUT |
|
|
|
|
|
|
|
|
|
(FIX) |
|
|
|
|
R |
L |
|
|
|
|
|
|
4 |
IN
HDMI cable
Started Getting
(Continued) 11
Shown with DVI Connection
CATV/Satellite antenna cable
Rear of TV
|
AUDIO |
|
|
|
|
R |
L (MONO) |
|
VIDEO IN |
|
1 |
|
|
1 |
|
PR |
PB |
Y |
|
|
AUDIO |
|||
|
COMPONENT IN |
|
|
|
CABLE/ |
(1080p/1080i/ |
|
|
|
720p/480p/480i) 2 R |
|
|
|
|
ANTENNA |
L |
|
|
|
|
RGB |
|
AUDIO |
|
DIGITAL |
PC IN |
|
|
PC/HDMI 1 |
AUDIO OUT |
|
|
|
AUDIO IN |
(OPTICAL) |
AUDIO |
|
|
|
|
|
|
1 |
|
|
AUDIO OUT |
|
|
|
|
|
|
|
|
|
(FIX) |
|
|
|
|
R |
L |
|
|
|
|
|
|
4 |
|
|
|
|
IN |
DVI-to-HDMI cable
HD cable box/
HD satellite box
Audio cable (stereo mini plugs)
Shown with Component Connection
CATV/Satellite antenna cable
Rear of TV
AUDIO
R |
L (MONO) |
|
VIDEO IN |
|
1 |
|
|
1 |
|
PR |
PB |
Y |
||
AUDIO |
COMPONENT IN
CABLE/ |
(1080p/1080i/ |
|
|
ANTENNA |
720p/480p/480i) 2 R |
|
L |
|
RGB |
|
AUDIO |
DIGITAL |
PC IN |
|
PC/HDMI 1 |
AUDIO OUT |
|
|
AUDIO IN |
(OPTICAL) |
|
AUDIO |
|
|
|
1 |
|
|
AUDIO OUT |
|
|
|
|
|
|
|
(FIX) |
|
|
|
R |
|
L |
|
|
|
4 |
|
|
|
IN |
HD cable box/ HD satellite box
AUDIO-R (red)
AUDIO-L (white)
PR (red) |
Component video cable |
PB (blue)
Y (green)
Audio cable
•If your equipment has a DVI output and not an HDMI output, connect the DVI output to the HDMI IN 1 (with DVI-to-HDMI cable or adapter) and connect the audio output to the AUDIO IN of PC IN. For details, see page 9.
12
PC
Use the TV as a monitor for your PC by connecting an HD15-HD15 cable connection as shown below. This TV can also be connected to a PC with a DVI or HDMI output. (Refer to the separate Quick Setup Guide.)
HD15-HD15 cable (analog RGB)
Rear of TV
|
AUDIO |
L (MONO) |
|
|
R |
VIDEO IN |
|
|
1 |
|
1 |
|
PR |
PB Y |
|
|
AUDIO |
||
|
COMPONENT IN |
|
|
CABLE/ |
(1080p/1080i/ |
|
|
720p/480p/480i) 2 R |
|
|
|
ANTENNA |
L |
|
|
|
RGB |
|
AUDIO |
DIGITAL |
PC IN |
|
PC/HDMI 1 |
AUDIO OUT |
|
|
AUDIO IN |
(OPTICAL) |
AUDIO |
|
|
Audio cable |
|
1 |
|
(FIX) |
|
||
|
AUDIO OUT |
|
|
(stereo mini plugs) |
R |
L |
|
|
|
4 |
|
|
|
|
IN |
Started Getting
•Connect the PC IN jack to the PC using an HD15-HD15 cable with ferrite core (analog RGB) and audio cable (see page 9).
13
CABLE/ANTENNA Digital recorder
AUDIO |
|
|
|
|
R |
L (MONO) |
|
VIDEO IN |
|
1 |
|
|
1 |
|
PR |
PB |
Y |
||
AUDIO |
COMPONENT IN
CABLE/ |
(1080p/1080i/ |
|
720p/480p/480i) 2 R |
|
|
ANTENNA |
L |
|
RGB |
|
AUDIO |
DIGITAL |
PC IN |
|
PC/HDMI 1 |
AUDIO OUT |
|
|
AUDIO IN |
(OPTICAL) |
|
AUDIO |
|
|
|
1 |
|
|
AUDIO OUT |
|
|
|
|
|
|
|
(FIX) |
|
|
|
R |
|
L |
|
|
|
4 |
|
|
|
IN |
VCR/Game
system/ USB Camcorder
VIDEO IN 2
VIDEO
L
(MONO) |
AUDIO |
R |
2
3
IN
A/V |
Digital |
Personal |
Analog audio |
Blu-ray |
DVD |
Digital |
Digital |
Audio |
Receiver/ |
audio |
computer |
equipment |
Disc Player/ |
player |
satellite |
cable box |
system |
Home |
equipment |
|
(A/V Receiver/ |
“PS3” |
|
receiver |
|
|
Theater |
|
|
HomeTheater) |
|
|
|
|
|
• Refer to the Quick Setup Guide (supplied) when connecting other equipment to your TV.
14
Make sure that your TV has adequate ventilation. Allow enough space around the TV as shown below. Avoid operating the TV at temperatures below 41 °F (5 °C).
Installed with stand |
Installed on the wall |
|
|
|
|
|
11 7/8 inches |
|
|
|
|
|
|
11 7/8 inches |
|||||||
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
(30 cm) |
3/8 inches |
|
|
|
|
|
(30 cm) |
|||||||
4 inches |
|
|
|
|
|
4 inches |
2 |
4 inches |
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
(6 cm) |
|
|
|
|
|||||||
(10 cm) |
|
|
|
|
|
(10 cm) |
|
|
|
(10 cm) |
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 inches (10 cm)
4 inches
(10 cm)
Leave at least this much space around the set.
Leave at least this much space around the set.
Never install the TV set as follows:
Air circulation is blocked. |
Air circulation is blocked. |
Wall |
Wall |
Started Getting
•Inadequate ventilation can lead to overheating of the TV and may cause TV damage or cause a fire.
15
Sony strongly recommends taking measures to prevent the TV from toppling over. Unsecured TVs may topple and result in property damage, serious bodily injury or even death.
Preventing the TV from Toppling
Secure the TV to a wall and/or stand.
Do not allow children to play or climb on furniture and TV sets.
Avoid placing or hanging items on the TV.
Never install the TV on:
•slippery, unstable and/or uneven surfaces.
•furniture that can easily be used as steps, such as a chest of drawers.
Install the TV where it cannot be pulled, pushed, or knocked over.
Route all AC power cords and connecting cables so that they are not accessible to curious children.
Recommended Measures to Secure the TV
Consider the following measures when securing your TV to a TV stand (not supplied).
1Secure the stand for the TV.
Make sure the TV stand can adequately support the weight of the TV. Use two angle braces (not supplied) to secure the stand.
For each angle brace use the appropriate hardware to:
•attach one side of the angle brace to the wall stud.
•attach the other side to the TV stand.
Angle braces
Stand
16
2Secure the TV to the stand.
Except KDL-32FA600 model
Use the optional hardware listed below (not supplied):
•M4 × 16 mm anchor bolt (screwed into the TV’s Table-Top Stand).
•A screw or similar (attach it to the TV stand).
•Rope or chain (strong enough to support the weight of the TV). Make sure that there is no excess slack in the rope or chain.
An alternative way to secure the TV is with an optional Sony Support Belt Kit.
|
Screw hole on the |
Anchor bolt |
Table-Top Stand |
|
Screw
KDL-32FA600 model only
Use an optional Sony Support Belt Kit.
3Anchor the TV to the wall.
Use the hardware listed below (not supplied).
•Two anchor bolts, size M6 × 10-12 mm. Screw the bolts into the top-most wall-mount holes located on the rear of the TV.
•Rope or chain (attach to one anchor bolt).
•Wall-anchor (attach to the wall stud) strong enough to support the weight of the TV (pass the rope through the wall-anchor, then attach to the other anchor bolt).
Wall-anchor
Wall-mount holes
Anchor bolts
Rope or chain
Started Getting
•Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV model name.
For United States call: 1-800-488-7669 or visit: www.sony.com/accessories For Canada call: 1-877-899-7669
•Measure 2 provides minimal protection against the TV toppling over. For further protection, follow all three measures recommended above.
•If an electric screwdriver is used, set the torque to tighten at approximately 1.5 N·m {15 kgf·cm}.
17
During initial setup, you will perform the following:
•Set the language for the On Screen Display (OSD) text
•Choose your viewing environment
•Scan for digital and analog channels
Complete your cable connections before beginning the Initial Setup. Refer to the Quick Setup Guide (supplied) for sample connection diagrams.
Initial Setup
Please select your language:
English
Español
Français
Confirm
1Turn on the TV. The Initial Setup screen will appear.
2Use the remote control buttons described below to navigate through the Initial Setup.
V/v/B/b buttons:
Allow you to navigate and highlight options where applicable.
button:
Allows you to select the highlighted option and advance to the next screen.
3Auto Program will scan for available channels from the signal source directly connected to the TV’s CABLE/ANTENNA input. Follow the help text provided on the screen to run the
Auto Program.
•Select Cancel to stop or cancel the Auto Program. The Auto Program can be done at later time. To run Auto Program at a later time, press MENU, select Settings, and then select Auto Program under Channel settings.
•Connect either your cable or antenna to the TV (you can connect both using an A-B RF switch (not supplied)); for more details see page 11.
•Select your preferred aspect ratio for the screen display. Press WIDE to select Wide Mode, or press MENU and select Settings, and then set Auto Wide to On under the Screen settings. For more details, see page 27.
18
