KETTLE SWK 3000 EDS B2
KETTLE
Operating instructions
RÝCHLOVARNÁ KANVICA
Návod na obsluhu
IAN 53493
CZAJNIK ELEKTRYCZNY
Instrukcja obsługi
WASSERKOCHER
Bedienungsanleitung
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę zapoznać się z wszystkimi
funkcjami urządzenia.
Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB Operating instructions Page 1
PL Instrukcja obsługi Strona 13
SK Návod na obsluhu Strana 25
DE / AT / CH Bedienungsanleitung Seite 37
6
1
5
4
2
3
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Items supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operating components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Disposal of the packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Boiling water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
In the event of scale deposits: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Inserting/removing the scale fi lter insert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
GB
Disposal of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Notes on the Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
SWK 3000 EDS B2
1
GB
Introduction
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These operating instructions
are a component of the product. They supply you with important information for
the intended use, safety and disposal. Before using the product, please familiarise
yourself with all of the operating and safety instructions. Use the appliance only as
described and only for the purposes indicated. Additionally, pass these instructions
on to whoever might acquire the appliance at a future date.
Copyright
This documentation is copyright protected.
Any copying or reproduction, including as extracts, as well as the reproduction of
images, also in an altered state, is only permitted with the written authorisation of
the manufacturer.
Intended Use
This appliance is intended for the boiling-up of water in domestic households. It is
not intended for use with other liquids or for commercial applications.
Do not use the appliance until it has been completely assembled.
This appliance is intended exclusively for use in domestic households. Do not use
the appliance for commercial applications!
WARNING
Risks from unintended use!
Risks can be engendered by the appliance if it is used for unintended purposes
and/or for other types of use.
► Use the appliance exclusively for its intended purposes.
► Observe the procedures described in these operating instructions.
Claims of an
repairs, unauthorised modifi cations or the use of non-approved spare parts will
not be acknowledged.
The operator alone bears the risk.
y kind resulting from damage caused by improper use, incompetent
2
SWK 3000 EDS B2
Items supplied
This appliance is supplied with the following components as standard:
▯ Kettle
▯ Base
▯ Scale fi lter insert
▯ Operating Manual
NOTICE
► Check the contents to ensure everything has been supplied, and for signs
of visible damage.
► Do not use the appliance until it has been completely assembled.
► If the delivery is incomplete, or it has been damaged due to defective
aging or transportation, contact the Service Hotline (see chapter
pack
Service).
Operating components
1 Unlocking button
2 ON/OFF switch with integrated control lamp
3 Base
4 Cable winder
5 Scale with integrated control lamp
6 Scale fi lter insert
GB
Technical data
Power supply 220 - 240 V ~, 50 Hz
Nominal performance 2500 - 3000 W
Capacity max. 1.7 Liter
SWK 3000 EDS B2
3
GB
Safety instructions
RISK - ELECTRICAL SHOCK!
► Ensure that the base with the electrical connections NEVER
comes into contact with water! Ensure that the base is completely
dry before use, especially if it has accidentally become wet.
► Use the kettle only with the supplied base.
► Ensure that the power cable never becomes wet or damp during
operation. Lay the cable so that it cannot be trapped or otherwise
damaged.
► To avoid risks, arrange for defective plugs and/or cables to be
replaced at once by qualifi ed technicians or our Customer Service Department, to avoid the risk of injury.
► After use, ALWAYS remove the plug from the mains power socket.
Switching the appliance off is not suffi cient, because the appliance
is under power for as long as the plug is connected to the power
socket.
► Before use check the appliance for signs of visible external damage.
Do not put into operation an appliance that is damaged or has
been dropped.
► Repairs should only be carried out by authorized specialist
companies or by the Customer Service department. Incompetent
repairs can result in signifi cant risks for the user. In addition warranty claims become void.
NEVER submerse the appliance in water or other liquids!
You could receive a fatal electric shock if residual liquids
come into contact with live components during operation.
4
SWK 3000 EDS B2
WARNING - RISK OF INJURY!
► Heat water only with the lid closed, otherwise the automatic switch-
off cannot function. Boiling water could then spray out over the rim.
► Always use the scale fi lter insert when operating the appliance.
► Hot steam clouds may be released. The kettle also becomes very
hot during use. It is always best to wear oven mitts when handling
the kettle.
► Ensure that the appliance is stood stably and vertically before
switching it on. Boiling water can cause an unstable kettle to fall over.
► Do not open the lid while the water is boiling.
► This appliance may be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and/or
knowledge if they are supervised or, in regard to the safe use of
the appliance, have been instructed in its use and have understood the potential risks.
► This appliance may be used by children aged 8 years or more if
they are supervised or, in regard to the safe use of the appliance,
have been instructed in its use and have understood the potential
risks. Cleaning and user maintenance tasks should not be carried
out by children unless they are aged 8 years or more and are supervised. The device and its connecting cable must be kept away
from children younger than 8 years old.
► Children may not play with the appliance.
► Do not fi ll the kettle up to more than the MAX marking!
Otherwise boiling water may spill out!
GB
WARNING - PROPERTY DAMAGE!
► Do not use an external timing switch or a separate remote control
system to operate the appliance.
► Never leave the appliance unsupervised whilst in use.
► Ensure that the appliance, the power cable and the plug do not
come into contact with hot plates or open fl ames.
SWK 3000 EDS B2
5
GB
Preparation
Unpacking
♦ Remove all components of the appliance and the operating manual from
the carton.
♦ Remove all packing material.
Disposal of the packaging
The packaging protects the appliance against transport damage. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The recirculation of packaging into the material circuit saves on raw material and
reduces the amount of waste generated. Dispose of packaging material that is
no longer needed according to the regionally established regulations.
NOTICE
► If possible, preserve the appliance's original packaging during the warranty
vent of a warranty claim, you can pack the appliance
Initial use
Before starting the appliance up, make certain that ...
period so that, in the e
ideally for its return.
WARNING - RISK OF INJURY!
► Always and only use freshly drawn mains water in the kettle! Do not con-
y water that is not certifi ed as potable. If you do, you are taking a
sume an
risk with your health!
– the appliance, plug and power cable are in a serviceable condition
and ...
– all packaging materials have been removed from the appliance.
1)
Open the lid by pressing on the release button 1.
2) Fill the appliance with water up to the MAX marking and let it come to a
full boil once – as described in the next section.
3) After it has boiled, pour this water away.
4) Rinse the kettle out with clear water.
5) Fill the appliance with water once again, up to the MAX marking, and
then bring it to boil. When done, pour this water away also.
The appliance is now ready for use.
6
SWK 3000 EDS B2
Boiling water
RISK - ELECTRICAL SHOCK!
► Never place the electrical base 3 close to w
potentially fatal risk!
WARNING - RISK OF INJURY!
► Always use freshly drawn water. Do not consume any water that has
eady stood in the kettle for longer than one hour. Do not reboil water
alr
that has cooled down. Always pour old water away. Microbes could have
formed in it!
NOTE
► Always ensure that the ON/OFF switch 2 is turned to “
plug is unplugged and the device is standing on the base 3.
If not, the device could heat up unintendedly as soon as the mains plug is
plugged in again.
1) Lift the kettle off of the base when fi lling it!
2) Press the unlocking button 1 and open the lid.
NOTE
► When fi lling it, hold the kettle upright. This is the only way to read the
markings on the scale 5 corr
3) Fill the kettle...
– to at least the MIN mark, so that the appliance does not overheat,
– to maximum the MAX mark, so that boiling water cannot spill out.
4)
First close the lid, then place the kettle on the base 3, so that it sits securely
on the base 3.
5) Now insert the plug into the mains power socket.
6) Press the ON/OFF switch 2 downwards so that it engages.
GB
ater – this would be a
“ when the mains
ectly.
WARNING - RISK OF INJURY!
► For safety reasons you should not open the lid when the water is boiling or
xtremely hot. There is a risk of scalding.
e
7) The control lamps integrated into the scale 5 as well as the control lamp in the
ON/OFF switch 2 indicate that the appliance is now heating up.
8) As soon as the water is boiling, the appliance will switch itself off , the
ON/OFF switch 2 clicks upwards and the light goes out.
SWK 3000 EDS B2
7
GB
INFORMATION
► This appliance is fi tted with an overheating protector: if the appliance is
switched on accidentally
automatically switches itself off .
If, for example due to a non-closed lid the appliance boils dry, the appliance
switches off automatically.
In such cases fi rst allow the appliance to cool down before using it again.
Cleaning and Care
RISK - ELECTRICAL SHOCK!
► Before cleaning, ALWAYS remove the plug from the mains power socket!
e is the risk of receiving an electric shock!
Ther
► Do not open any part of the housing. There are no user-serviceable ele-
ments inside. An open housing will cr
electrical shock.
NEVER submerse the appliance in water or other liquids! You could
receive a fatal electric shock if residual liquids come into contact with
live components during operation.
WARNING - RISK OF INJURY!
► Let the appliance cool suffi
WARNING - PROPERTY DAMAGE!
► Do not use abrasive or aggressive cleaning materials. These could attack
the upper sur
■ Clean the exterior surfaces and the power cable with a slightly damp cloth.
Be sur
soiling use a mild detergent on the cloth. Ensure that there are no detergent
residues in and on the appliance before it is taken back into use.
■ Rinse the inside of the kettle out with clean water.
■ If there are any deposits in the kettle, wipe out the inside surface with a moist
cloth, or use a w
with clean water again.
faces and irreparably damage the appliance.
e to dry the appliance well before taking it back into use. For stubborn
, without any water in the kettle, the appliance
eate the risk of a potentially fatal
ciently before cleaning it. Risk of Burns!
ashing up brush or bottle brush. Then rinse the kettle out
8
SWK 3000 EDS B2
In the event of scale deposits:
Scale deposits on the bottom of the appliance lead to increased energy consumption and reduce the service life of the appliance.
Descale the appliance as soon as scale deposits become apparent.
■ Before descaling, remove the scale fi lter insert 6 (see chapter “Inser
removing the scale fi lter insert”).
■ Use a descaler designed for household appliances (e.g. for coff ee machines).
Pr
oceed as detailed in the instructions provided for the use of the decalcifying
agent.
■ After descaling, rinse the appliance with lots of clean water.
Inserting/removing the scale fi lter insert
1) Open the lid.
2) Press the tab on the scale fi lter insert 6 slightly downwards and then pull the
scale fi lter insert 6 inwards and downwards so that you can pull it out of its
mounting.
3) Then pull the scale fi lter insert 6 upwards and out of the kettle.
4) Clean the scale fi lter insert 6 with a slightly moistened dishcloth and under
running water.
5) After cleaning, insert the scale fi lter insert 6 again. Ensure that it is sitting
correctly in its mounting, and that the tab has clicked into place.
NOTE
► If the scale deposits in the scale fi lter insert 6 hav
fi lter in a water-vinegar solution at a ratio of 6:1 for a few hours. The scale
deposits will dissolve themselves. Rinse the scale fi lter insert 6 with plenty
of clear water.
GB
ting/
e solidifi ed, place the
Storage
■ Allow the appliance to cool down completely before putting it into storage.
■ Wind the power cable around the cable winder 4 under the base 3.
■ Store the appliance at a dry location.
SWK 3000 EDS B2
9
GB
Troubleshooting
Problem Cause Remedy
The plug is not inserted into
a mains power socket.
The appliance
does not function.
The ON/OFF
switch 2 does
not engage.
The appliance is not
switched on.
The appliance is overheated and the overheating
protection is active.
The kettle is not on the
base 3.
The appliance is defective.
Disposal of the appliance
Do not dispose of this appliance in your normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU.
Dispose of the appliance through an approved disposal centre or at your com-
munity waste facility. Pay heed to the currently applicable regulations. In case of
doubt, consult your local disposal facility.
Notes on the Declaration of Conformity
This appliance complies, in regard to conformance with basic
requirements and other relevent regulations, with the EMV
Directive 2004/108/EC, as well as the Directive for Low
Voltage Devices 2006/95/EC.
The complete original Declaration of Conformity can be
obtained from the importer.
Insert the plug into a
mains power socket.
Switch the appliance on.
Allow the appliance to
cool down.
Place the kettle on the
base 3.
In this case, contact
Customer Services.
10
SWK 3000 EDS B2
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Warranty
The warranty for this appliance is for 3 years from the date of purchase. This
appliance has been manufactured with care and meticulously examined before
delivery.
Please retain your receipt as proof of purchase. In the case of a warranty claim,
please contact our service department by telephone. Only in this way can a
post-free despatch for your goods be assured.
NOTICE
► The warranty applies only to material or manufacturing faults, it does not
This appliance is intended solely for private domestic use, not for commercial
applications. If this product has been subjected to improper or inappropriate
handling, abuse, or modifi cations not carried out by one of our authorised sales
and service outlets, the warranty will be considered void.
This warranty does not aff ect your statutory rights.
The warranty period is not extended by repairs made under the warranty.
This applies also to replaced and repaired parts.
Damages and defects extant at the time of purchase must be reported immediately after unpacking, resp. no later than two days after the date of purchase.
Repairs carried out after lapse of the warranty period are subject to charge.
apply to tr
parts, such as switches.
ansport damage, normal wear and tear or damage to fragile
GB
Service
Service Great Britain
Tel.: 0871 5000 720 (£ 0.10/Min.)
E-Mail: kompernass@lidl.co.uk
IAN 53493
Hotline availability: Monday to Friday 08:00 - 20:00 (CET)
SWK 3000 EDS B2
11
12
SWK 3000 EDS B2
Spis treści
Wprowadzenie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Prawo autorskie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Użycie zgodne z przeznaczeniem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Zakres dostawy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Elementy obsługowe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Dane techniczne . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Wskazówki dotyczące bezpieczeństwa . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Czynności przygotowawcze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Rozpakowanie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Utylizacja opakowania . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Uruchomienie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Gotowanie wody . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Czyszczenie i pielęgnacja . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Usuwanie osadów z kamienia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Wkładanie/wyjmowanie wkładu fi ltra przeciwwapiennego . . . . . . . . . . . . . . . . . . . . . . . 21
Przechowywanie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Usuwanie usterek . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
PL
Utylizacja urządzenia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wskazówki dotyczące deklaracji zgodności WE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Gwarancja . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Serwis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
SWK 3000 EDS B2
13
Loading...
