ELECTRIC OVERBLANKET
ELECTRIC OVERBLANKET
Operating instructions and safety advice
IAN 290495
SWD 100 E2
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the
device.
GB / IE / NI Operating instructions and safety advice Page 5
A
B
1 2
3
Table of contents
List of pictograms used ........................................................................................................ Page 6
Introduction ................................................................................................................................... Page 6
Intended use ........................................................................................................................................ Page 7
Parts description .................................................................................................................................. Page 7
Scope of delivery ................................................................................................................................ Page 7
Technical data ..................................................................................................................................... Page 7
Important safety instructions ......................................................................................... Page 7
Safety system .............................................................................................................................. Page 9
Special features ......................................................................................................................... Page 9
Start-up .............................................................................................................................................Page 10
Switching on / off / Selecting the temperature...................................................................................Page 10
Temperature levels .............................................................................................................................. Page 10
Automatic switch-off ............................................................................................................................ Page 10
Cleaning and care .................................................................................................................... Page 10
Storage .............................................................................................................................................Page 11
Disposal ............................................................................................................................................ Page 11
Warranty / Service centre .................................................................................................Page 12
Declaration of conformity ................................................................................................. Page 12
5 GB/IE/NI
List of pictograms used
Read the instructions! Do not use bleach.
Volt (AC) Do not dry in a tumbler dryer.
Hertz (mains frequency) Do not iron.
Watt (effective power) Do not dry-clean.
Safety class II
Observe the warning and safety
instructions!
Not suitable for very young children
age 0–3 years!
Do not stick needles into it!
Do not use folded or rucked! Removable control unit
The textiles used with this heated blanket meet the high human ecological
requirements of Oeco-Tex standard 100,
as verified by the German Hohenstein
Research Institute.
Caution - Risk of electric shock!
Danger to life!
Electric Overblanket
Introduction
Automatic
shut-off
Automatic switch-off
6 Temperature levels
Illuminated function display
Breathable
Breathable
This heated blanket is machine washable. Set the washing machine to an
extra gentle washing cycle at 30 °C.
Dispose of the packaging and the
b
a
heated blanket in an environmentally
friendly way!
blanket must only be used as described and for the
stated types of use. Keep these instructions in a safe
place. If you pass the heated blanket on to others
you should also give them all of the documentation.
Please make yourself familiar with the
heated blanket before preparing it for
use or using it for the first time. To do so,
please carefully read the following operating instructions and the important safety information. The heated
6 GB/IE/NI
Introduction / Important safety instructionsIntroduction
Intended use
This heated blanket is designed to warm the human
body. It must only be used as a cover, not as a pad.
The heated blanket is not intended for use in hospitals or for commercial use. In particular it must not
be used for babies or infants, persons who are insensitive to heat, helpless persons, or animals. Any
use other than that described above or modification
of the heated blanket are not permissible and may
lead to injury and / or damage to the heated blan
The manufacturer assumes no liability for damages
caused by improper use.
ket.
Parts description
1
Control unit (see Fig. A)
2
Function display (see Fig. A)
3
Plug-in connector (see Fig. B)
Scope of delivery
Please check immediately on unpacking that the
delivery scope is complete and that the heated
blanket is in perfect condition.
1 Electric Overblanket
1 Control unit / plug-in connector
1 Set of instructions for use
Technical data
Model: SWD 100 E2
Type: B10
Power supply : 230–240 V / 50–60 Hz
Power consumption: 100 W–110 W
Dimensions: approx. 180 x 130 cm
Protection class: II /
Electric field strength: max. 5000 V / m
Magnetic field strength: max. 80 A / m
Magnetic flux density: max. 0.1 milli-Tesla
Manufacturer:
MGG Elektro GmbH
Steinstraße 27
DE-40210 Düsseldorf
GERMANY
IMPORTANT INFORMATION –
KEEP FOR FUTURE REFERENCE!
Important safety
instructions
Failure to observe the following instructions can cause personal injury
or property damage (electric shock,
burns, fire). The following safety instructions and hazard warnings are
not only intended to protect your ow
health and the health of others, but
also to prevent damage to the heated
blanket. Observe this safety advice.
If you pass the heated blanket on
to anyone else, please pass on these
operation instructions as well.
SCALDING HAZARD!
n
This heated blanket may
7 GB/IE/NI
not be used by persons insensitive
to heat and other persons in need
of protection who do not respond
to overheating (e.g. diabetics,
persons with skin changes caused
by illness or scarred skin areas in
the application area, after using
analgesics or alcohol). There is
a risk of skin burns.
This
heated blanket may not
be used for very young children
(0–3 years), as they are unable
to react to overheating. There is
a risk of skin burns.
This heated blanket may not be
used by young children (3–8
years) unless the control unit was
set by a parent or a supervising
person and the child was adequately instructed on the safe use
of the heated blanket. There otherwise is a risk of burns.
This heated blanket may be used
by older children age 8 and up,
and persons with diminished
physical, sensory or mental capacities or lacking experience
and knowledge when supervised
and instructed on the safe use of
the heated blanket and understand the associated risks.
Children must be supervised to
ensure they do not play with the
heated blanket. There is a risk of
injury.
Children must not perform clean
or maintain the heated blanket
without supervision. There is a
risk of injury.
T
he heated blanket is not inte
nded
for use in hospitals or for commercial use. This poses a risk of
injuries and / or damage to the
heated blanket.
Do
not poke the heated
blanket with needles or sharp
objects. There is a risk of electric
shock.
Do
not switch on the heated
blanket whilst folded or bunched
up. The heated blanket may otherwise be damaged.
Do not use when wet! Otherwise
there is a risk of electric shock.
This heated blanket may only be
operated with the control unit
specified on the label. The heated
blanket may otherwise be damaged.
The electric and magnetic fields
emitted by this heated blanket
could possibly interfere with the
functionality of your pacemaker.
However, the levels are far below
the permissible limits: electric
8 GB/IE/NI
Important safety instructions / Safety system / Special features Important safety instructions
field strength: max. 5000 V / m,
magnetic field strength: max.
80 A / m, magnetic flux density:
max. 0.1 milli-Tesla. Therefore
please consult your physician
and the manufacturer of your
pacemaker before using this
heated blanket.
Do not pull, twist or kink the ca-
bles. The heated blanket may
otherwise be damaged.
Frequently check this heated blan-
ket for signs of wear or damage.
If signs thereof are detected, the
heated blanket was used improperly or will no longer heat up, it
must first be inspected by the manufacturer before being switched
on again.
If the mains lead to the heated
blanket is damaged it must be
replaced by the manufacturer, its
customer service centre, or a
similarly qualified person to prevent hazards.
With the heated blanket switched
on, never
– place objects on it (e.g. suit-
cases or clothes baskets),
– place a heating source such
as a hot-water bottle, heating
pad or similar items on it. The
heated blanket may otherwise
be damaged.
The electronic components inside
the control unit will heat up whilst
operating the heated blanket.
For this reason, never cover the
control unit or place it on the
heated blanket during operation.
This poses a risk of injuries and /
or damage to the heated blanket.
Always observe the information
on start-up, cleaning and care,
and storage.
If you have additional questions
on using our products, please
contact our Customer Service
Department.
Safety system
Note: The heated blanket features a safety system.
The electronic sensor technology prevents the heated
blanket from overheating across the entire surface
by automatically switching off in the event of a malfunction.
If the safety system switches the heated blanket off
automatically as a result of a malfunction, the func
2
display
up, even when the heated blanket is switched on.
Please note that, for safety reasons, the heated
satisfy the high human ecological requirements of
Oeco-Tex Standard 100, as verified by the German
Hohenstein Research Institute.
on the control unit 1 will no longer light
blanket must not be used after a fault and must
be returned to the service address indicated.
Special features
This heated blanket features a
super soft, hygienic fabric. The
textiles used in this heated blanket
tion
9 GB/IE/NI
Start-up
Note: When the heated blanket is used for the first
time, you may notice a smell of plastic; however, this
will disappear after a short time.
Level 0: off
Level 1: minimum heat
Level 2–5: customised heat
Level 6: maximum heat
To use the heated blanket, first connect the con-
trol unit
plug-in connector
1
with the heated blanket using the
3
(see Fig. B).
Switching on / off /
Selecting the temperature
Switching on:
Set the control unit 1 to level 1, 2, 3, 4, 5 or 6
to switch on the heated blanket.
Note: The function display
ter switching the heated blanket on.
Switching off:
Set the control unit 1 to level 0 to switch the
heated blanket off.
Note: The function display
Selecting the temperature:
Set the control unit to the highest temperature
setting (setting 6). This will cause the heating
blanket to warm up quickly.
2
will light up af-
2
will go off.
When operating the heated blanket for several
hours, we recommend setting the
control unit 1 to the lowest setting to
prevent the body from overheating
and to prevent potential subsequent
skin burns or a heat stroke.
Temperature levels
Set the control unit 1 to the desired tempera-
ture (see Fig. A).
Automatic switch-off
Note: The heated blanket switches itself off auto-
matically after approx. 180 minutes. The function
2
display
flashing.
To switch the heated blanket back on, first se-
If the heated blanket is no longer used
after the timer expires:
– switch off the heated blanket (level 0),
– unplug from the socket,
– disconnect the plug-in connector
control unit
on the control unit 1 will then start
lect level 0 and after approx. 5 sec. select the
desired temperature level.
3
, thus the
1
from the heated blanket.
Cleaning and care
DANGER TO
LIFE BY ELECTRIC SHOCK! Before
cleaning the heated blanket, always
unplug the mains plug from the socket and disconnect the plug-in connector
1
trol unit
Otherwise there is a risk of electric shock.
Use a dry, lint-free cloth for control unit 1
cleaning and care.
RISK OF DAMAGE TO THE
in water or other liquids. It may otherwise be
damaged.
If the heated blanket is slightly soiled, use a
dampened cloth and a little liquid mild detergent, if necessary.
RISK OF DAMAGE TO THE
scouring agents to clean the heated blanket
from the heated blanket (see Fig. B).
PRODUCT OR PROPERTY!
Never immerse the control unit
PRODUCT OR PROPERTY! Never
use chemical cleaning agents or
3
, thus the con-
1
10 GB/IE/NI
Cleaning and care / Storage / Disposal Start-up / Cleaning and care
and control unit 1. The heated blanket and
control unit
1
may otherwise be damaged.
The heated blanket is machine
washable. Set the washing machine
at an extra washing cycle for deli-
cate items at 30 °C.
Use a mild detergent at the dose recommended
by the manufacturer.
Please note, frequent washing will cause wear
on the heated blanket. It should therefore be
washed no more than a maximum of 5 times in
a washing machine during its lifetime.
RISK OF DAMAGE TO THE
PRODUCT OR PROPERTY!
Please note that the heated blanket
must not be dry-cleaned, wrung out, machine
dried, mangled or ironed. These may all damage the heated blanket.
Do not bleach. Do not use any
cleaning agents containing bleach
(such as heavy duty detergents).
Do not dry in a tumbler dryer.
Do not iron.
Do not dry-clean.
the heated blanket on to dry. Otherwise there
is a risk of electric shock.
Storage
RISK OF DAMAGE TO THE
PRODUCT OR PROPERTY! Let
the heated blanket cool before putting it away. The heated blanket may otherwise
be damaged.
RISK OF DAMAGE TO THE
PRODUCT OR PROPERTY! To
prevent the heated blanket from becoming sharply creased, do not place other
objects on top of the heated blanket when it is
stored. These may all damage the heated blanket.
If you do not intend to use the heated blanket
for any length of time, store it in the original
packing in a dry place without weighing it down.
Disconnect the plug-in connector
control unit
1
from the heated blanket.
3
, thus the
Disposal
The packaging is made entirely of recyclable materials, which you may dispose
of at local recycling facilities.
Reshape the still damp heated blanket to its
original size immediately after washing and
allow to dry flat, spread across a drying rack.
RISK OF DAMAGE TO THE
PRODUCT OR PROPERTY! Do
not fasten the heated blanket with
pegs or the like to dry. These may all damage
the heated blanket.
DANGER OF ELECTRIC SHOCK!
Do not reconnect the control unit
1
with the heated blanket until the
connector
3
and the heated blanket are completely dry. Otherwise there is a risk of electric
shock.
DANGER OF ELECTRIC SHOCK!
RISK OF PROPERTY DAMAGE!
Do not under any circumstances switc
Observe the marking of the packaging
b
materials for waste separation, which
a
are marked with abbreviations (a) and
numbers (b) with following meaning:
1–7: plastics / 20–22: paper and fibreboard / 80–98: composite materials.
In accordance with European Directive
(covering waste electrical and electronic
equipment) and its transposition into
national legislation, worn-out electrical
devices must be collected separately
and taken for environmentally compatible
recycling.
h
11 GB/IE/NI
Disposal / Warranty / Service centre / Declaration of conformity
Contact your local refuse disposal
authority for more details of how to
dispose of your worn-out product.
Warranty / Ser vice centre
We provide a 3-year warranty from the date of
purchase for defects in material and manufacture
of the heated blanket.
The warranty does not cover:
· Damage from improper use.
· Wear parts.
· Damage caused by the customer.
·
If the device has been opened by an unauthoris
repair shop.
This warranty does not affect the customer‘s legal
rights. The customer must provide proof of purchase
in order for any warranty claims within the warranty
period to be honoured. Warranty claims must be
filed with MGG Elektro GmbH-, Düsseldorf, GERMANY
within 3 years from the date of purchase.
In the event of a claim, please contact
our Service Department listed below:
ed
IAN 290495
Declaration of conformity
This heated blanket complies with the requirements
of the relevant European and national guidelines.
This is confirmed by the CE mark.
The relevant declarations are held by the manufacturer.
Service Hotline (toll-free):
0800 93 10 319
(Mon–Fri: 8 am–6 pm)
service-uk@mgg-elektro.de
1800 93 92 35
(Mon–Fri: 8 am–6 pm)
service-ie@mgg-elektro.de
If we ask you to return the defective heated blanket,
please send it to the following address:
NU Service GmbH
Lessingstraße 10 b
DE-89231 Neu-Ulm
GERMANY
12 GB/IE/NI
NU Service GmbH
Lessingstraße 10 b
DE-89231 Neu-Ulm
GERMANY
Last Information Update: 06 / 2017
Ident.-No.: 07.100.315-062017-GB / IE / NI
IAN 290495
Loading...
