Silvercrest SVG 2.0 A1 User Manual

USB Video Grabber

for digitising analogue video and audio recordings

USB Video Grabber

for digitising analogue video and audio recordings

User m anual and servic e inform ation

USB-Video-Grabber

för digitalisering av analoga video- och ljudinspelningar

Bruksa nvisning och serviceinformation

USB-videosovitin

analogisten video- ja audionauhoitusten digitalisointiin

Käyttöopas ja huolto-ohjeet

USB-Video-Grabber

til digitalisering af analoge videooptagelser og analoge optagelser

Brugervejledning og serviceinformation

SVG 2.0 A1

SilverCrest USB 2.0 Video Grabber SVG 2.0 A1 English

Contents

Safety Instructions .......................................................................................... 2 

Operational safety .......................................................................................... 2

Intended use .................................................................................................. 3

Children .......................................................................................................... 3

Electromagnetic Compatibility ........................................................................ 3

Back up .......................................................................................................... 4

Cleaning ......................................................................................................... 4

Conformity ...................................................................................................... 4

Disposal of old devices .................................................................................. 4

Introduction ...................................................................................................... 5

What may be reproduced? ............................................................................. 5

System requirements ..................................................................................... 5

Features of the Video Grabber ...................................................................... 5

Items supplied ................................................................................................ 6

Setup for first time use ................................................................................... 7

Installing the software .................................................................................... 7

Connection overview ...................................................................................... 8

Connecting to your PC ................................................................................... 9

Appendix ........................................................................................................ 11 

Troubleshooting ........................................................................................... 11

Technical Data ............................................................................................. 11

Warranty information .................................................................................... 12

V 1.11

English SilverCrest USB 2.0 Video Grabber SVG 2.0 A1

Safety Instructions

Before first using this device please read the following instructions carefully and take note of the safety warnings, even if you are familiar with using electronic devices. Please keep this manual safe for future reference. Please ensure that if you resell or pass on this device, you also include these instructions.

Operational safety

 Please follow the usage instructions of your computer.  Keep the device away from moisture, vibration, dust, heat and direct

sunlight to avoid system failure.

 Never open the device casing. Doing so will void the warranty and could

lead to permanent damage to the device.

 Never allow children to play unsupervised with electrical devices. Children

cannot always recognise possible hazards. Small parts may cause choking resulting in death or serious injury. Keep packaging away from children as it is a suffocation risk.

 After transport wait until the device has reached ambient temperature

before use. In extreme temperature or humidity fluctuation condensation can lead to moisture build up which can cause a short circuit.

 Always handle the cables by the connector and do not pull on the cables

themselves. Do not place any heavy objects on the cables or connectors and ensure that the cable shielding does not become cracked. Never tie a knot in a cable and do not tie cables together. Ensure that all cables are placed so that no one can trip over them and they do not cause an obstruction.

SilverCrest USB 2.0 Video Grabber SVG 2.0 A1 English

Intended use

The SilverCrest USB 2.0 Video Grabber SVG 2.0 A1 changes analogue information e.g. from a camcorder, into digital information that can be saved onto a PC and post processed. The device can only be used with a USB 2.0 port. USB 1.1 standard is not supported. The device may not be connected to a USB 1.1 port.

This is an information technology device. This product may only be used for private purposes. It is not to be used for industrial or commercial purposes. This product is not designed for medical, lifesaving or life sustaining applications. The device should not be used outside or in tropical climates. Only connection cables and external devices which are designed for this product in terms of safety, electromagnetic compatibility and shielding quality may be used in conjunction with the unit. This device fulfils all relevant norms and standards in conjunction with CE conformity. Compliance with these norms is no longer guaranteed if the device is altered in ways not sanctioned by the manufacturer. Only use accessories specified by the manufacturer. When this device is used outside Germany compliance is required with the regulations and laws of that country. When connecting ensure that the cable is not too taut and the connector plug is not stressed.

Children

Electrical devices do not belong in children's hands. Never allow children to use electrical devices unsupervised. Children cannot always recognise possible hazards. Keep packaging away from children as it is a suffocation risk.

Electromagnetic Compatibility

The Electromagnetic Compatibility Directive (EMC) must be adhered to when connecting the device. Ensure that there is a minimum distance of 1m from high frequency and magnetic sources of interference (e.g. TVs, speakers, mobile phones etc) in order to prevent malfunctions and loss of data.

English SilverCrest USB 2.0 Video Grabber SVG 2.0 A1

Back up

After each update please ensure that you back up your data to external storage media. Damage claims for lost data or for consequential losses as a result of lost data are excluded.

Cleaning

Warning! This device does not contain any parts that require servicing or cleaning. Never open the device casing as this can be hazardous. Ensure that the components do not become dirty. Do not use any solvents or corrosive or gaseous cleaning materials. Clean the device with a damp cloth if it becomes dirty.

Conformity

This device conforms to the full extent with the basic requirements and other required provisions of the EMC Directive 2004/108/EC.

The Declaration of Conformity is to be found at the end of this instruction manual.

Disposal of old devices

The crossed out wheelie bin symbol on a product indicates that the product is subject to European Directive 2002/96/EC. All old electric and electronic devices must be separated from normal household waste and disposed of at designated state facilities.

Disposal of old devices in this manner will prevent harm to the environment and human health hazards. For further information regarding disposal of old devices contact your local government office or the retailer where you purchased this product.

SilverCrest USB 2.0 Video Grabber SVG 2.0 A1 English

Introduction

What may be reproduced?

Please note: This device is configured so that copyright protected material cannot be recorded. It is not permitted to misuse this device to avoid copyright protection. Unless you are the copyright owner or have permission of the copyright owner, unauthorised reproduction may be a breach of national or international law and serious penalties can result.

This product contains copy protection technology which is protected by US patents and other intellectual property rights of the Macrovision Corporation. Reverse engineering or disassembly is prohibited.

System requirements

Computer PC/AT compatible Computer with sound card Processor minimum Pentium 4 with at least 1.2 GHz

Operating system Windows

XP/Vista™ or higher RAM 512 MB or more Connection USB 2.0 interface

Features of the Video Grabber

 High Speed USB 2.0 for optimal recording quality  Direct conversion into MPEG 1/2/4 format with the Power Director, ideal for

digital post processing

 Up to 25 frames per second, resolution

from up to 720 x 576 (PAL)

 Composite, S-Video analogue input  Software supports SnapShot (single picture) mode, brightness, contrast,

colour, saturation and sharpness settings

 Stereo audio recording

English SilverCrest USB 2.0 Video Grabber SVG 2.0 A1

Items supplied

1 SilverCrest USB 2.0 Video Grabber 2 Scart Adapter 3 S-Video cable 4 Audio/Video cable 5 Audio/video connector adapter 6 USB cable (Extension cable) 7 Installation and application software (not shown above) 8 User manual with warranty card (not shown above)

SilverCrest USB 2.0 Video Grabber SVG 2.0 A1 English

Setup for first time use

Installing the software

The required software (drivers and applications) must first be installed before you plug in the device.

When installing programs or drivers important files can be overwritten and altered. You should back up the contents of your hard drive before the installation of the programs, so that you can still access your original files if there is a problem with the installation.

Should your operating system be set in a way that the installation of software and drivers will only be accepted when they are signed (approved by Microsoft), an appropriate dialogue box will appear. This does not mean that the driver is defective, just that it is indicating that it does not have this Microsoft signature. You can ignore this advice. Click on 'Continue' to install the drivers.

 Insert the enclosed CD ROM into the drive and the installation menu opens

automatically.

 Install the software (Power Director) and the drivers (Device Driver)

according to the directions on the screen.

 Restart your PC after installation to finalise the procedure.

If the installation assistant does not automatically start when the CD ROM is inserted, then the auto run function of your CD drive is deactivated. Then proceed as follows:

 Click on the 'Start' button to open the Start Menu.  Click on the option 'Run...'  Insert the drive letter of your CD ROM drive, followed by a colon and the

program name 'Autorun' (e.g. D:autorun)

 Click on the 'OK' button to confirm the action.

A description of the software can be found on the CD ROM.

English SilverCrest USB 2.0 Video Grabber SVG 2.0 A1

Connection overview

Connect the adapter (5) to the Video Grabber (1). Therefore put the Mini USB connector of the adapter into the mini USB socket at the back of the Video Grabber (see illustration).

Video Grabber Connector Adapter

Snapshot Button

S-Video input Stereo Audio input (white/red) Composite Video input (yellow)

This button generates a snapshot (photo of the current video) when the

recording mode of the enclosed 'Power Director' software is activated.

SilverCrest USB 2.0 Video Grabber SVG 2.0 A1 English

Connecting to your PC

In order to record using the Video Grabber you must first install the software. If you haven't already done so, go to the chapter entitled 'Installing the software' and follow the instructions.

 Connect the adapter (5) to the Video Grabber (1) as shown in the earlier

illustration.

 Attach the video output of your source (e.g. camcorder) to the Video

Grabber. Now you have the choice of the following types of connection:

Composite Video Signal

 Connect one end of the Audio/Video cable (4) (yellow, red and white

connectors at both ends) with the video input (yellow) and the audio input (red and white) of the connection adapter.

 Connect the other end of the Audio/Video cable (4) with a free video

output (normally a yellow socket) and a free audio output (normally a red and white socket) of your source.

S-Video-Signal

 Connect one end of the S-Video cable (3) (same plug on both cable

ends) with the S-Video input (black) of the connection adapter.

 Connect the other side of the S-Video cable (3) to a free S-Video output

of your source.

Scart Adapter

When your source does not have a Video or S-Video output, you can use the enclosed Scart Adapter (2).

 Connect either the S-Video cable (3) (same plug on both cable ends) or

the Audio/Video cable (4) (yellow, red and white plug on both cable ends) to the Scart Adapter.

 Plug the Scart Adapter into a free Scart socket of your source.

English SilverCrest USB 2.0 Video Grabber SVG 2.0 A1

 Connect the audio output of your source to the Video Grabber. To this

purpose use the red and white RCA connectors of the Audio/Video cable (4).

 Plug the Video Grabber's USB connector into a free USB 2.0 port, ensuring

your PC is switched on. Use the enclosed extension cable (6) if necessary to extend the reach of the cable. If possible, ensure that the Video Grabber is directly connected to your PC (not via a USB Hub). Only use the device with a USB 2.0 port.

 The operating system will automatically detect the Video Grabber. Follow

the instructions on the screen.

 Use the enclosed software to record from your source. The software

provides detailed usage instructions in electronic format. Start the relevant program.

SilverCrest USB 2.0 Video Grabber SVG 2.0 A1 English

Appendix

Troubleshooting

The Video Grabber is connected but not recognised by the operating system.

Check all the connections. Are you using a supported operating system?

New USB devices have been recognised and drivers must be installed.

When a USB device is connected to a new port it receives a new ID. This normally requires driver installation, even if the driver is already installed.

The video received over the S-Video cable is in black and white.

The playback source must be switched to S-Video.

Error message saying that the video is protected.

The copyright system has been activated. This material cannot be copied.

Technical Data

Video input RCA video jack (yellow) / S-Video jack (black) Audio input RCA audio jacks (red/white) Video format PAL, NTSC Video encoding MPEG 720x576 Pixel Picture format BMP, JPG Interface USB 2.0 Dimensions 73 x 30 x 11 mm (L x W x H) Weight 14 g

English SilverCrest USB 2.0 Video Grabber SVG 2.0 A1

Warranty information

SilverCrest USB 2.0 Video Grabber SVG 2.0 A1 English

Suomi SilverCrest USB 2.0 Video Grabber SVG 2.0 A1

Sisältö

Turvallisuusohjeet ......................................................................................... 15

Käyttöturvallisuus ......................................................................................... 15

Määräystenmukainen käyttö ........................................................................ 16 

Lapset ........................................................................................................... 16

Sähkömagneettinen yhteensopivuus ........................................................... 16

Tietojen varmuuskopiointi ............................................................................ 17

Puhdistus ...................................................................................................... 17 

Vaatimustenmukaisuus ................................................................................ 17

Vanhojen laitteiden hävitys .......................................................................... 17

Johdanto ......................................................................................................... 18

Mitä saadaan toisintaa? ............................................................................... 18

Järjestelmävaatimukset ................................................................................ 18

Video Grabber -videosieppaajan ominaisuudet ........................................... 18

Toimituksen sisältö ....................................................................................... 19

Käyttöönotto ................................................................................................... 20

Ohjelmiston asennus .................................................................................... 20

Liitännän yleiskuva ....................................................................................... 21

Liitäntä tietokoneeseen ................................................................................ 22 

Liite .................................................................................................................. 24

Vianetsintä .................................................................................................... 24

Tekniset tiedot .............................................................................................. 24

Takuu ........................................................................................................... 25

Versio: 1.11

SilverCrest USB 2.0 Video Grabber SVG 2.0 A1 Suomi

Turvallisuusohjeet

Lue seuraavat ohjeet huolellisesti läpi ennen laitteen ensimmäistä käyttökertaa ja huomioi kaikki varoitukset, vaikka elektronisten laitteiden käsittely olisikin sinulle tuttua. Säilytä tätä käyttöohjetta huolellisesti tulevaa tarvetta varten. Jos myyt tai annat laitteen eteenpäin, luovuta myös ehdottomasti tämä ohje.

Käyttöturvallisuus

 Noudata tietokoneesi käyttöohjetta.  Pidä laite etäällä kosteudesta ja vältä tärinää, pölyä, kuumuutta ja suoraa

auringonpaistetta, jotta toimintahäiriöt vältetään.

 Älä koskaan avaa laitteen runkoa. Takuu raukeaa ja laite saattaa tuhoutua.  Älä koskaan anna lasten leikkiä sähkölaitteilla ilman valvontaa. Lapset eivät

aina kykene tunnistamaan mahdollisia vaaroja. Pienet osat saattavat aiheuttaa nielaistaessa hengenvaaran. Pidä pakkausmuovit lasten ulottumattomissa. Tukehtumisvaara.

 Ennen kuin otat laitteen käyttöön kuljetuksen jälkeen, odota, että se

sopeutuu ympäristölämpötilaan. Kun lämpötila- ja kosteusheilahtelut ovat suuria, lauhtuminen voi aiheuttaa kosteuden muodostumista, josta voi olla seurauksena oikosulku.

 Ota kaikista kaapeleista kiinni aina pistokkeesta, älä vedä suoraan

kaapelista. Älä laita painavia esineitä kaapelin päälle ja huomioi, ettei kaapelia taiteta erityisesti pistokkeen ja liitinten alueella. Älä koskaan tee kaapeliin solmua äläkä sido kaapelia yhteen muiden kaapeleiden kanssa. Kaikki kaapelit on asennettava siten, ettei kukaan astu niiden päälle ja etteivät ne ole kenenkään tiellä.
