OWNER’S
ELECTRO
INSTRUCTIONS
SR-608EV/648EV/688EV (Dispensor Applied)
606EV-646EV/686EV
ENGLISH
REFRIGERATOR
Before operating the unit, please read this manual throughly, and retain for future reference.
If you took out of the power supply outlet, you should plug in again after five minutes.
DA68-60306A
FEATURE
What is H.M.CYCLE(High-efficiency Multievaporator CYCLE)?
•A high efficiency cooling method adopting an independent cooler and an independent cooling fan in freezing room and refrigerating room, respectively.
•A new cooling method providing an economic energy, power cooling function and supply of high humidity cool air by independent cooler and cooling fan.
What is sensitivity technology?
•A theory for meeting the sensuous demands from consumers by supplying the cool air that suits their tastes for preserving foods. Neurofuzzy genic algorithm theory was applied so that the optimum uniform refrigeration can be maintained by automatically activating the rotating fan for distribution of cool air at the locations where foods are stored and supplying the cool air quickly to places where it is mostly needed.
What is genic algorithm (GA-FUZZY)
•A theory that senses the inside temperature of refrigerator with temperature sensor and controls it to be in an optimum state of uniform refrigeration by applying the genetic principle of natural ecosystem, i.e the law of the fittest Øs survival and training to Micom.
CONTENTS |
|
Ready to use |
|
Contents ............................................................................... |
1 |
Warnings for safety .............................................................. |
2 |
Cautions for safety ............................................................... |
4 |
Features ............................................................................... |
6 |
Ready to use ........................................................................ |
8 |
Front operating panel......................................................... |
10 |
How to use |
|
How to use freezing room.................................................. |
12 |
How to use refrigerating room ........................................... |
14 |
How to preserve the refrigerated foods............................. |
17 |
Functions of water dispenser............................................. |
19 |
Installation and cares |
|
How to clean ...................................................................... |
21 |
How to disassemble and assemble the |
|
water supply device...................................................... |
23 |
How to disassemble the accessories................................ |
26 |
How to install...................................................................... |
27 |
Before asking for service |
|
Before asking for service ................................................... |
31 |
Questions........................................................................... |
33 |
1
WARNING FOR SAFETY
This is to prevent users or other persons from being wounded or injured, by using the present product properly. Be sure to observe these contents for safety. (After reading these contents, please keep in such a safe place as to look up)
Contents of Caution/Warning
Warning |
Represents the contents that |
|
death or heavy injury of a person |
||
|
||
|
is foreseen. |
Caution |
Represents the contents that |
|
injury of a person or damage of |
||
|
||
|
material is foreseen. |
Contents of indication
Represents the contents of prohibition.
Represents the prohibition of disassembly.
Represents the prohibition of contact.
Represents what has to be observed.
Represents that a power plug has to be separated from the plug socket.
Represents earth for prevention of electric shock.
WARNING
Do not insert the power |
Set the power plug free from the |
Do not directly spray water |
plugs for many products |
back side of the refrigerator. |
inside or outside of the |
at the same time. |
• Damaged power plug may cause |
refrigerator |
• May cause abnormal generation |
fire due to overheating. |
• May cause fire or electric shock. |
of heat or fire. |
• If the power cord is damaged, |
|
|
avoid a hazard by |
|
|
replacing it through the |
|
|
manufacturer or its |
|
|
service agent or a |
|
|
similarly qualified |
|
|
person. |
|
Do not spray inflammable gas near the refrigerator.
• May cause explosion or fire.
Do not bend the power cord with excessive force or do not have the power cord pressed by heavy article.
• May cause fire or electric shock.
Do not store a volatile and inflammable substance in the refrigerator.
•Storage of benzene, thinner, alcohol, ether, LP gas, etc., may cause explosion.
ETHER GASOLINE
BENZENE
ADHESIVE
2
WARNING
Do not put a tank filled with water on the product.
•If water poured, it cause bad insulation of the electric parts which may lead to fire or electric shock.
Do not install the refrigera-tor in the wet place or the place which water splashes.
•Deterioration of insulation of electric parts may cause electric shock or fire.
Do not insert the power plug with the wet hand.
• May cause electric shock.
Do not disassemble, repair or alter.
•It may cause fire or abnormal operation which leads to injury.
Pull the power plug out for exchanging the interior lamp of the refrigerator.
• It may cause electric shock.
Be sure to earth.
•If earthing is not done, it will cause breakdown and electric shock. (Please refer to page 29.)
If and when gas leaks, immediately ventilate without touching the refrigerator and the plug.
• Explosion of gas may cause fire and a burn.
Dispose refrigerator after door or door’s packing is removed, if disposition is required.
•It is dangerous for child to enter the refrigerator for play-in with door closed.
3
CAUTIONS FOR SAFETY
CAUTION
Do not store too much foodstuffs therein.
•Opening of the door may cause pouring over which may inflict a wound.
Do not store narrow and lengthy bottles or foods in a small multi-purpose room.
•It may hurt you when refrigerator door is opened and closed resulting in falling stuff down.
If the hole of the power plug socket is loose, don’t insert the power plug.
• It may cause electric shock and fire.
Do not put bottles or kinds of glass in the freezing room.
• Freezing of the contents may inflict a wound.
Do not store articles on the product.
•Opening or closing of the door may cause throwing down which may inflict a wound.
Do not plunk out the power cord by pulling the portion of it.
• It may inflict a wound.
Do not let a child be hung down from the door.
•Injury may occurs, when the product falls down or a finger is jammed in the door.
Do not store pharmaceutical products, scientific materials, etc., in the refrigerator.
•The products which temperature control shall be strict shall not be stored in the refrigerator.
4
CAUTION
Do not touch the tank and the food stuffs of the frezzing room with the wet hand.
• It may cause frostbite.
Please wipe out foreign materials of the metal option of the power plug cleanly.
• Use of it as it is may cause fire.
Do not enter the hand into the bottom surface of the product.
• Sharp edge may inflict a wound.
If you want to insert the power plug again, please insert it five minutes after pulling out of the plug socket.
•Abnormal operation of freezing device may cause breakdown of it.
Afterfive minutes
Move it by catching the upper handle of rear side and the lower handle of front side.
•Slippery is caused to hurt, when other part is grasped.
Use handle when opening and closing the refrigerator door.
•In case of using other parts than handle, it may hurt you with your finger jammed.
If the refrigerator is not to be used for a long time, pull out the power play.
• Due to deterioration of insulation, mau cause fire.
When abnormal sound, small or smoke is noticed, pull a power plug off immediately, then call service center.
5
FEATURES
X-FLOW COOLING SYSTEM FOR REDUCING THE LOSS OF COOL AIR!
Rotation cooling method
•The current cooling method has been a fixed one where the cool air comes directly out of one or 2~3 walls of refrigerator.
X-FLOW cooling refrigerator has adopted the rotating fans in all 3 rooms that make use of the sensitivity technology that rotate vigorously, allowing the cool air to be spurted out and the whole area including every corner in refrigerator to be cool instantly.
A keen watch for cool air
•When the door is open, you don’t have to worry about any change of food tastes since the rotating cool air that adopts the sensitivity technology is turning around foods without any gaps and does not allow any contact of the foods with warm air.
•You don’t have to worry about any leakage of cool air since the cool air moves around foods in center even in the case of frequent door opening.
Water dispenser for reducing the frequency of opening the door (Models applied : 608EV/648EV/688EV)
•It adopts the water dispenser that allows water supply without opening the door and therefore the frequency of opening door drops to over 30%, resulting in about 10% of power savings.(Refer to page 20)
Power saving automatic door close and warning device for door opening.
•In case the door is slightly open(within 15°) by mischiefs of children or mistakes of housewives, the door is automatically closed and prevents any loss of cool air. Also, in case of opening of over 15°, a melody for warning housewives sounds, making it a complete way for saving power(Refer to page 11).
Rail design for quick opening and closing
•It adopts a rail design in super-high humidity vegetables room and high humidity special fresh room that allows a smooth movement when lightly pulling and pushing the handle without any force and so you can quickly pull out the vegetables and fruits. Loss of cool air is prevented by the quick door opening and closing.(Refer to page 17~18)
6
SEPARATE AND INDEPENDENT COOLING OF REFRIGERATING AND FREEZING ROOMS!
Refrigerator of energy-saving type
•It adopts the high-efficiency Multi-evaporator CYCLE that makes it possible to cool the refrigerating room and freezing room separately and to reduce the power consumption and energy.
Super-power cooling technique for quick refrigeration.
•Selection of power freezing and power refrigerating by independent cooler and cooling fan allows the quick cooling and preserving the freshness of foods.(pages 13, 15)
Natural humidity vegetable room lasting 3 times longer even without vinyl wraps.
•The independent cooling method is supplying the cool air with 4°~5 times of more humidity than conventional refrigerator through the indirect cooling technique by which the cool air can not touch the vegetables and fruits directly and therefore the freshness with the same natural humidity as that of producing areas can be maintained for a long time
NATURALISM FOR REFRIGERATORS, TOO!
Refrigerator that does not destroy the ozone layer!
• It uses the new insulating materials, the new refrigerant (R-134A) whose ODP(Azone Depletion Potential) is zero
7
READY TO USE
This mark indicates the page to be referred to.
Please install the refrigerator with 1 sufficient space apart at the place
with a flat bottom surface. 27
•An incorrect leveling may cause noises and impossible cooling.
over 30cm
|
|
over |
5cm |
|
over 5cm |
|
|
3 |
Please insert the plug in an |
||
outlet. |
29 |
|
|
•The refrigerator should be grounded.
•It is desirable to connect the power 1 hour after its installation.
•When plugging in for the first time or plugging in again after pulling it out, the cooler starts operating after about 5 minutes to prevent excessive load to cooler.
Please refer to page 1 for operation in 110V area.
Please wipe and clean the 2 refrigerator.
•Please wipe and clean the inside and outside of refrigerator.
Please put foods in the 4 refrigerator.
•It is recommended that foods are put in the refrigerator that was cooled for 2~3 hours after plugging in.
8
THE CORRECT WAY OF PRESERVING FOODS.
Please keep them after washing.
Please do not store foods which are apt to go bad in low temperature.
(Examples : Bananas, Pineapples, Tomatoes etc.)
Please arrange foods with proper distance each other.
•If the exit of cool air is blocked, the storing efficiency gets low due to the bad cool air circulation.
Please store foods after dividing into small pieces.
Please place watery foods(particularly bean curds) on the front area of shelf in refrigerating room.
•It may be possible that foods placed on areas where cool air is coming out are frozen.
Please cool off the hot foods before putting them in the refrigerator.
•It reduces power consumption and also makes a better cooling.
9
FRONT OPERATING PANEL
This mark indicates the page to be referred to.
Power freezing 13
It freezes the foods in the freezing room at a high speed.
QUICK FRE. |
LO |
|
FRE. CONTROL |
|
|
|
|
|
|
DOOR |
ODOR |
QUICK |
FRE. |
|
HI |
|
ALARM |
FREE |
FRE. |
CONTROL |
|||
|
Power refrigeration 15
It cools foods in refrigerating room at a high speed down to a fixed temperature.
LO |
|
QUICK REF. |
|
|
|
||
|
|
REF. CONTROL |
|
HI |
|
QUICK HI-MOISTURE |
|
REF. |
CONTROL REF. |
||
|
Temperature control button of freezing room
It is able to adjust the temperature in freezing room. Whenever the button is pressed, the sequence of Low → Low Mid → Mid → Mid High → High is selected.
Temperature control button of refrigerating room
It is able to adjust the temperature in the refrigerating room
Whenever the button is pressed, the sequence of
Low → Low Mid → Mid → Mid High → High is selected.
10
