Samsung T28E310EX, T24E310EW, T24E310EX, T32E310EW, T32E310EX User Manual

TE310

T24E310EW

T24E310EX

T28E310EW

T28E310EX

T32E310EW

T32E310EX

LED TV

user manual

Thank you for purchasing this Samsung product. To receive more complete service, please register your product at

www.samsung.com/register

Model _____________ Serial No. _____________

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearances. Product design and specifications may be changed without notice.

Digital TV notice

1.Functionalities related to Digital TV (DVB) are only available in countries/areas where DVB-T/T2 (MPEG2 and MPEG4 AVC) digital terrestrial signals are broadcasted or where you are able to access to a compatible DVB-C (MPEG2 and MPEG4 AAC) cable-TV service. Please check with your local dealer the possibility to receive DVB-T/T2 or DVB-C signal.

2.DVB-T/T2 is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and DVB-C is that for the broadcast transmission of digital TV over cable. However, some differentiated features like EPG (Electric Programme Guide), VOD (Video On Demand) and so on, are not included in this specification. So, they cannot be workable at this moment.

3.Although this TV set meets the latest DVB-T/T2 and DVB-C standards, as of [August, 2008], the compatibility with future DVB-T/T2 digital terrestrial and DVB-C digital cable broadcasts cannot be guaranteed.

4.Depending on the countries/areas where this TV set is used some cable-TV providers may charge an additional fee for such a service and you may be required to agree to terms and conditions of their business.

5.Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not work correctly with some cable service providers.

6.For more information, please contact your local Samsung customer care centre.

The reception quality of TV may be affected due to differences in broadcasting method between the countries. Please check the TV performance in the local SAMSUNG Authorised Dealer, or the Samsung Call Centre whether it can be improved by reconfiguring TV setting or not.

Still image warning

Avoid displaying still images (like jpeg picture files) or still image element (like TV programme logo, panorama or 4:3 image format, stock or news bar at screen bottom etc.) on the screen. Constant displaying of still picture can cause ghosting of LED screen, which will affect image quality. To reduce risk of this effect, please follow below recommendations:

•• Avoid displaying the same TV channel for long periods.

•• Always try do display any image on full screen, use TV set picture format menu for best possible match.

•• Reduce brightness and contrast values to minimum required to achieve desired picture quality, exceeded values may speed up the burnout process.

•• Frequently use all TV features designed to reduce image retention and screen burnout, refer to e-Manual for details.

English - 2

Contents
Getting Started
yy	Safety Precautions.....................................................	4
yy	Accessories and Cables..........................................	11
yy	Installing the Stand..................................................	12
yy Using the TV’s Controller (Panel Key).......................		13
yy The Standard Remote Control Buttons....................		14
yy How to use the e-Manual........................................		16
yy	Teletext Feature.......................................................	18
yy How to Navigate Menus..........................................		19
yy	Connecting the Power Cord and the Aerial or Cable
	Connection..............................................................	20
Connections
yy	Connecting to AV Devices (Blu-ray Players, DVD
	Players, etc.)............................................................	21
yy Connecting to Audio Devices ..................................		23
yy Connecting to a PC.................................................		24
yy	Connections (T24E310EW T24E310EX)..................	25
yy	Connections (T28E310EW T28E310EX)..................	26
yy	Connections (T32E310EW T32E310EX)..................	27
yy	Connecting to a COMMON INTERFACE slot (Your
	product viewing Card Slot).......................................	28
yy Changing the Input Source......................................		30
Basic Features
yy Correct posture to use the product..........................		31
yy Changing the Preset Picture Mode..........................		32
yy	Adjusting Picture Settings........................................	33
yy Changing the Picture Size........................................		34
yy Picture In Picture (PIP).............................................		35
yy Changing the Picture Options..................................		36
yy	Changing the Preset Sound Mode...........................	38

yy	Adjusting Sound Settings........................................	39
yy	Memorising Channels..............................................	43
yy Using the INFO button (Now & Next guide)..............		46
yy Using the Channel Menu.........................................		46
yy	Other Features........................................................	50
Preference Features
yy	Setting the Time......................................................	53
yy Using the Sleep Timer.............................................		54
yy	Economical Solutions..............................................	56
yy	Locking Programme................................................	57
yy	Other Features........................................................	58
yy	Support Menu.........................................................	60
yy Viewing the Contact Samsung.................................		62
Advanced Features
yy	Application..............................................................	63
yy Playing the Photos / Videos / Music.........................		65
yy	Viewing the e-Manual..............................................	68
yy Using the Sports Mode............................................		68
Other Information
yy	Troubleshooting.......................................................	69
yy Supported Subtitle and Media Play file formats........		73
yy Installing the Wall Mount..........................................		75
yy Securing the TV to the Wall......................................		84
yy Securing the Installation Space................................		85
yy	Anti-theft Kensington Lock......................................	86
yy	Licence...................................................................	87
yy	Specifications..........................................................	89
yy	Index.......................................................................	90
yy	Adaptor information.................................................	92

	Check the Symbol!
Note	Step by Step Guide
Indicates additional information.	Check here for instructions on how to open the relevant submenu
	within the OSD (on screen display).

English - 3

Getting Started

Safety Precautions

Icons used for safety precautions

WARNING

Failing to follow the precautions marked with this sign may result in a serious injury or even a fatality.

CAUTION

Failing to follow the precautions marked with this sign may result in a personal injury or property damage.

Do not perform.

Must be followed.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been included with this product.

Power Related

The following images are for your reference and may differ depending on models and countries.

Warning

Avoid using a damaged power cord or plug or a loose power outlet.

•• Otherwise, it may result in electric shock or fire.

Avoid plugging in or unplugging the power supply with wet hands.

•• Otherwise, it may result in electric shock.

!

Avoid connecting multiple electric appliances to a single wall outlet.

•• Otherwise, it may result in fire due to overheating of the wall outlet.

Plug the power plug in firmly.

•• Otherwise, it may result in fire.

Make sure to connect the power cord to a grounded wall outlet (for insulation class 1 equipment only).

	•• Otherwise, it may result in
!	electric shock or injury.

Keep the power cord and the product away from a heater.

•• Otherwise, it may result in electric shock or fire.

!

Avoid bending or twisting the power cord excessively and avoid placing heavy objects on the cord.

•• Otherwise, it may result in electric shock or fire due to a damaged power cord.

If the pins of the power plug or the wall outlet are covered in dust, clean it using a dry cloth.

•• Otherwise, it may result in fire.

English - 4

Getting Started

Caution

!

Avoid unplugging the power plug while the product is operating.

•• Otherwise, it may damage the product due to electric shock.

When unplugging the power plug from the wall outlet, make sure to hold it by the plug and not by the cord.

•• Otherwise, it may result in electric shock or fire.

!

!

Installation Related

Warning

Avoid placing burning candles, mosquito coil, cigarettes on the

product.

•• Otherwise, it may result in fire.

!

Avoid installing the product in a badly-ventilated location such as inside a bookshelf or closet.

•• Otherwise, it may result in fire due to internal over-heating.

Avoid installing the product in a location that is unstable or exposed to excessive vibration such as on an unstable or slanted shelf.

•• The product may fall and this may result in damage to the product or injury.

•• If you use the product in a location exposed to excessive vibrations, it may result in a problem with the product or fire.

Make sure to use only the power cord supplied by our company. In addition, do not use the power cord of another electric appliance.

•• Otherwise, it may result in electric shock or fire.

Connect the power plug to a wall outlet that can be easily reached.

•• When a problem occurs with the product, you must unplug the power plug to cut the power off completely. You cannot cut the power off completely using only the

power button on the product.

Ask an installation engineer or relevant company to install the product onto the wall.

•• Otherwise, it may result in injury.

•• Make sure to use the specified wall mount.

Keep the plastic bags used to pack the product away from children.

•• If children place the plastic bags over their heads, they may suffocate.

Avoid installing the product in a location exposed to dust, moisture (sauna), oil, smoke or water (rain drops) and installing it within a vehicle.

•• This may result in electric shock or fire.

English - 5

Getting Started

		Avoid installing the product in a	Avoid installing the product where
		location exposed to direct sunlight	children may reach it.
		and installing the product near a	•• If a child touches the product,
		heat source such as a fireplace or
				the product may fall and this
		heater.
				may result in injury.
		•• This may shorten the product	••	Since the front part is heavier,
		life cycle or cause fire.
				install the product on a flat and
				stable surface.
		Bend the outdoor aerial cable	Install the aerial far away from any
		downwards at the location where	high voltage cables.
		it comes in the house so that	••	If the aerial touches or falls
		rainwater does not flow in.
				onto a high voltage cable, it
	!	•• If rainwater enters the product,	!	may result in electric shock
		it may result in electric shock		or fire.

or fire.

Caution

SAMSUNG

!

Do not let the product drop while moving it.

•• This may result in a problem with the product or injury.

When installing the product on a console or shelf, make sure that the front of the product does not protrude out of the console or shelf.

•• Otherwise, this may cause the product to fall off and result in a malfunction or injury.

•• Make sure to use a cabinet or shelf suitable to the size of the product.

If the product is installed in a location where the operating conditions vary considerably, a serious quality problem may occur due to the surrounding

environment. In this case, install the product only after consulting one of our service engineers about the matter.

•• Places exposed to microscopic dust, chemicals, too high or low temperature, high humidity, airports or stations where the product is continuously used.

Do not place the product face down on the floor.

•• This may damage the panel of the product.

When putting the product down, handle it gently.

•• Otherwise, it may result in a problem with the product or injury.

English - 6

Getting Started

Cleaning Related

Warning

Before cleaning the product, unplug the power cord.

•• Otherwise, it may result in

electric shock or fire.

!

Caution

Avoid spraying cleansing agent directly onto the product.

•• This may result in

discolouration or cracking of the exterior of the product or !

the panel coming off.

If you can't get the product clean with just the supplied cloth, use a soft, damp cloth with a "monitorexclusive cleansing agent" and wipe the product with it.

!

•• If no monitor-exclusive cleansing agent is available, dilute a cleansing agent with water at a ratio of 1:10 before cleaning the product.

Usage Related

Warning

Since a high voltage runs through the product, never disassemble, repair or modify the product yourself.

			••	Otherwise, it may result in fire	!
				or electric shock.
			••	If the product needs to be
				fixed, contact a service centre.

When cleaning the product, do not spray water directly over the product parts.

•• Make sure that water does not enter the product.

•• Otherwise, it may result in fire, electric shock or a problem with the product.

When cleaning the product, disconnect the power cord and clean the product with the supplied cleaning cloth.

•• Avoid using chemicals such as wax, benzene, alcohol, thinner, mosquito coil, fragrance, lubrication or cleansing agent when cleaning the product.

This may result in the exterior being deformed or the print being removed.

Since the exterior of the product is easily scratched, be sure to use the supplied cleansing cloth.

To move the product, turn the power off and unplug the power cord, the aerial cable and any other wires connected to the product.

•• Otherwise, it may result in electric shock or fire due to the damaged power cord.

English - 7

Getting Started

		If the product generates a strange
		noise, a burning smell, or smoke,
		unplug the power plug immediately
		and contact a service centre.
	!	•• Otherwise, it may result in
		electric shock or fire.
		If you drop the product or the case
		is damaged, turn the power off and
		unplug the power cord. Contact a
		service centre.
		•• Otherwise, it may result in fire
		or electric shock.

When thunder or lighting occurs, unplug the power cord and under no circumstance touch the aerial cable as this is dangerous.

	!	•• Otherwise, it may result in
		electric shock or fire.

Avoid moving the product by pulling the power cord or aerial cable.

•• Otherwise, it may result in electric shock, fire or a problem with the product due to damage to the cable.

Avoid lifting up or moving the product by holding only the power

cord or signal cable.

•• Otherwise, it may result in electric shock, fire or a problem with the product due to

damage to the cable.

Take care not to block the vent by a

table cloth or curtain.

•• Otherwise, it may result in fire due to internal overheating.

GAS

100

Avoid letting children hang or climb onto the product.

•• Otherwise, it may result in the product falling and this may result in injury or death.

Avoid placing objects such as toys and cookies on top of the product.

•• If a child hangs over the product to grab an object, the object or the product may fall and this may result in injury or even death.

Avoid dropping an object over the product or cause impact to the product.

•• Otherwise, it may result in electric shock or fire.

When a gas leak occurs, do not touch the product or the power plug and ventilate immediately.

•• A spark may result in an explosion or fire.

•• During a thunder or lighting storm, do not touch the power cord or aerial cable.

Avoid using or placing inflammable spray or objects near the product.

•• This may result in an explosion or fire.

Avoid inserting metal objects such as a chopsticks, coins or hairpins, or inflammable objects into the product (the vents, ports, etc).

•• If water or substances enters the product, turn the power off, unplug the power cord and contact a service centre.

•• Otherwise, it may result in a problem with the product, electric shock or fire.

English - 8

Getting Started

Caution

!

!

Avoid placing a liquid container such as a vase, flowerpot, beverage, cosmetics or drugs, or a metal object over the product.

	•• If water or substances enter
	the product, turn the power
	off, unplug the power cord and
	contact a service centre.
	•• Otherwise, it may result in a
	problem with the product,
	electric shock or fire.
	Displaying a still image for a long
	time may create a persistent image	-_-
	or stain on the screen.
	•• If you do not use the product
	for a long time, use the	!
	power-saving mode or set the
	screensaver to the moving
	picture mode.
	Set the appropriate resolution and
	frequency for the product.
	•• Otherwise, it may result in eye
	strain.
	Watching the product from too
	close a distance continuously may
	damage your eyesight.
	It is important to give your eyes
	some rest (5 minutes every hour)
	when viewing the product screen
	for long periods of time.
	•• This will alleviate any eye strain.
	Keep the small accessories in a
	location out of the reach of children.

!

Do not press down hard on the product. The product may become deformed or damaged.

When not using the product for a long time such as leaving your

home, unplug the power cord from the wall outlet.

•• Otherwise, it may cause dust accumulation and result in fire caused by overheating or short circuit or result in an electric shock.

Avoid turning the product upside down or move the product holding only the stand.

•• This may cause the product to fall, resulting in damage to the product or injury.

Avoid using a humidifier or cooker near the product.

•• Otherwise, it may result in electric shock or fire.

Since the display panel is hot after using it for a long time, do not touch the product.

Take care when adjusting the angle of the product or the height of the stand.

•• If your hand or finger is caught, you may be injured.

•• If the product is tilted excessively, the product may fall and this may result in injury.

English - 9

Getting Started

Avoid placing a heavy object over the product.

•• Otherwise, it may result in a problem with the product or injury.

Be careful that children do not place the batteries in their mouths when removed from the remote control. Place the battery in a location that children or infants cannot reach.

•• If children have had the battery in their mouths, consult your doctor immediately.

Use only specified standard batteries. Do not use new and used batteries together.

•• This may cause a battery to break or leak and may cause fire, injury, or contamination (damage).

Do not place the adapter on top of another adapter.

•• Otherwise, it may result in fire.

Remove the vinyl cover of the adapter before using the adaptor.

•• Otherwise, it may result in fire.

Be careful that adaptor should not be in contact with water and therefore not be wet.

•• This may cause a malfunction, electric shock or fire. Do not use adaptor by the waterside or outside particularly when it rains or snows. Be careful

that adaptor should not be wet while cleaning floor with water.

!

!

!

When using headphones or earphones, do not turn the volume too high.

•• Having the sound too loud may damage your hearing.

When replacing the batteries, insert them with right polarity (+, -).

•• Otherwise, the battery may become damaged or it may cause fire, personal injury or damage due to leakage of the internal liquid.

The batteries (and rechargeable batteries) are not ordinary refuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling.

•• The customer can return used or rechargeable batteries

to a nearby public recycling centre or to a store selling the same type of the battery or rechargeable battery.

Keep power adaptor away from any other heat source.

•• Otherwise, it may result in fire.

Do not let water enter the DC power device or get the device wet.

•• An electric shock or fire may result.

•• Avoid using the product outdoors where it can be exposed to rain or snow.

•• Be careful not to get the DC power adapter wet when you wash the floor.

Always keep power adaptor in wellventilated area.

English - 10

Getting Started

Accessories and Cables

Please make sure the following items are included with your product. If any items are missing, contact your dealer.The items’ colours and shapes may vary depending on the model.

Make sure that there are no accessories hidden behind or under packing materials after you open the box.

[[[CAUTION] INSERT SECURELY LEST SHOULD BE DETACHED IN SET

•• Remote Control & Batteries (AAA x 2)	•• Warranty Card / Safety Guide / Regulatory Guide
•• Power Cord	(Depending on the model)
	•• S/W CD (User Manual)

Stand Base

Stand Connector

Make sure to rest the AC/DC Adapter flat on a table or the floor. If you place the AC/DC Adapter so that it is hanging with the AC cord input facing upwards, water or other foreign substances could enter the Adapter and cause the Adapter to malfunction.

AC/DC Adapter (Depending on the country and model)

English - 11

Getting Started

Installing the Stand

MODEL NAME: T24E310EW / T24E310EX

MODEL NAME: T28E310EW / T28E310EX / T32E310EW / T32E310EX

English - 12

Getting Started

Using the TV’s Controller (Panel Key)

The TV's Controller, a small joy stick like button on the rear left side of the TV, lets you control the TV without the remote control.

Some functions which require a PIN code may not be available.The product colour and shape may vary depending on the model.Exits the menu when pressing the controller more than 1 second.

When using the controller in the up/down/left/right directions, make sure you do not push the controller in first. If you push the controller in first it will not move in the up/down/left right directions.

Selecting the Media Play
Selecting the Menu	m	R	Selecting a Source
		P
		Return
	Power off
	Function menu
Remote control sensor				TV Controller

Standby mode

Do not leave your TV in standby mode for long periods of time (when you are away on a holiday, for example). A small amount of electric power is still consumed even when the power button is turned off. It is best to unplug the power cord.

Initial Setup

When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWERPbutton. Setup is available only when the source is set to TV.

If you connect any device to HDMI IN 1(STB) before starting the installation, Channel Source will be changed to automatically. If you do not want to select Set-top box, please select Aerial.

If You Want to Reset This Feature...

Select System - Setup (Initial Setup). Enter your 4 digit PIN number. The default password is "0-0-0-0". If you want to change the PIN number, use the Change PIN function.

You should do Setup (MENU → System) again at home even though you did in shop already.

If you forget the PIN code, press the remote control buttons in the following sequence in Standby mode, which resets the PIN to “0-0-0-0”: MENU → 8 → 2 → 4 → POWER (on)

English - 13

Getting Started

The Standard Remote Control Buttons

This remote control has Braille points on the Power, Channel, and Volume buttons and can be used by visually impaired persons.

Turn the product on and off.

Display and selects the available video sources.

Give direct access to channels.

Alternately select Teletext ON, Double,

Mix or OFF.

Adjust the volume.

Display channel lists on the screen. View the Media Play.

Open the OSD (Menu).

Quickly select frequently used functions. Use this button in a specific feature.

Move the cursor, select the on-screen menu items, and change the values seen on the TV's menu.

Return to the previous menu.

E-MANUAL: Displays the e-Manual. P.SIZE: Lets you select the Picture Size.

AD/SUBT.: Turn the audio description on and off (not available in some locations). / Display digital subtitles.

Return to the previous channel.

Cut off the sound temporarily.

Change channels.

You can enter Guide menu.

Display information on the product screen.

Exit the menu.

Use these buttons according to the directions on TV’s screen.

Use these buttons in a specific feature.

English - 14

Getting Started

Installing batteries (Battery size: AAA)

Match the polarity of the batteries to the symbols in the battery compartment.

NOTE

•• Install the batteries so that the polarity of the batteries (+/-) matches the illustration in the battery compartment.

•• Use the remote control within 7 m of the product.

•• Bright light may affect the performance of the remote control. Avoid using it near fluorescent lights or neon signs.

•• The colour and shape of the remote may vary depending on the model.

English - 15

Getting Started

How to use the e-Manual

You can find instructions about your TV’s features in the e-Manual in your TV. To use, press the E-MANUAL button on your remote. Move the cursor using the up/down/right/left buttons to highlight a category, then a topic, and then press the ENTEREbutton. The e-Manual displays the page you want to see.

You can also access it through the menu: MENU → Support → e-Manual → ENTERE

To return to the e-Manual main menu, press the E-MANUAL button on the remote.

Screen Display

Currently			Basic Features
displayed video,
TV Programme,			Changing the Preset Picture Mode
etc.
			Adjusting Picture Settings
			Changing the Picture Options
			Changing the Preset Sound Mode
			Adjusting Sound Settings

}Index EEnter eExit

The category list. Press lor rbutton to select the category you want.

Displays the submenu list. Use the arrow buttons on your remote to move the cursor. Press

ENTEREbutton to select the sub-menu you want.

Operation Buttons

}Index: Displays the index screen.

EEnter: Selects a category or sub-menu. eExit: Exit the e-Manual.

<Viewing the Contents>

aTry Now: Displays the OSD menu that corresponds to the topic. To return to the e-Manual screen, press the E-MANUAL button.

bHome: Moves to the e-Manual home screen. LPage: Moves to previous or next page.

{Zoom: Magnifies a screen.

Press the {(Zoom) button to magnify the screen. You can scroll through the magnified screen by using the uor dbuttons. To return to the screen to normal size, press the RETURN button.

English - 16

Getting Started

How to toggle between an e-Manual topic and the corresponding OSD menu(s).

This function is not enabled in some menus.

You cannot use the Try Now function if the menu is not activated.

	Method 1		Method 2
1.	If you want to use the menu that corresponds to an	1.	Press the ENTEREbutton when a topic is
	e-Manual topic, press the red button to select Try		displayed. “Are you sure?” appears. Select Yes, and
	Now.		then press the ENTEREbutton. The OSD window
2.	To return to the e-Manual screen, press the		appears.
	E-MANUAL button.	2.	To return to the e-Manual screen, press the
			E-MANUAL button.

How to search for a topic on the index page

This function may not be supported depending on the language.

1.If you want to search a keyword, press the blue button to select Index.

2.Press the lor rbutton to select a character order you want.

3.Press the uor dbutton to select a keyword you want to see, and then press the ENTEREbutton.

4.You can view the corresponding e-Manual instruction screen.

To close the Index screen, press the RETURN button.

English - 17

Getting Started

Teletext Feature

The index page of the Teletext service gives you information on how to use the service. For Teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed.

You can change Teletext pages by pressing the numeric buttons on the remote control.

1 0(mode): Selects the Teletext mode (LIST/FLOF). If pressed during LIST mode, switches the mode to List save mode. In List save mode, you can save a Teletext page into a list using the 8(store) button.

2 /(Full TTX/Double TTX/mix/off): Activates the Teletext mode for the current channel. Press the button twice to overlap the Teletext mode with the current broadcasting screen. Press it one more time to exit teletext.

31(sub-page): Displays the available sub-page.

48(store): Stores the Teletext pages.

5 6(index): Displays the index (contents) page at any time while you are viewing Teletext.

6 4(size): Displays the teletext on the upper half of the screen in double-size. To move the text to the lower half of the screen, press it again. For normal display, press it once again.

7 9(hold): Holds the display at the current page, in the case that there are several secondary pages that follow automatically. To undo, press it again.

8 2(page up): Displays the next Teletext page.

9 3(page down): Displays the previous Teletext page.

05(reveal): Displays the hidden text (answers to quiz games, for example). To display the normal screen, press it again.

!7(cancel): Shrinks the Teletext display to overlap with the current broadcast.

@Colour buttons (red, green, yellow, blue): If the FASTEXT system is used by the broadcasting company, the different topics on a Teletext page are colour-coded and can be selected by pressing the coloured buttons. Press the colour corresponding to the topic of your choice. A new colour coded page is displayed. Items can be selected in the same way. To display the previous or next page, press the corresponding coloured button.

The Teletext pages are organised according to six categories

Part	Contents
A	Selected page number.
B	Broadcasting channel identity.
C	Current page number or search indications.
D	Date and time.
E	Text.
F	Status information. FASTEXT information.

A

B

C

D

E

F

English - 18

Getting Started

How to Navigate Menus

Your product’s Main and Tools menus contains functions that let you control the product’s features. For example, in the Main menu you can change the size and configuration of the picture, its brightness, its contrast and so on. There are also functions that let you control the product’s sound, channel configuration, energy use, and a host of other features. To access the main, on-screen menu, press the MENUmbutton on your remote. To access Tools menus, press the TOOLSTbutton. Tools menus are available when the TOOLSTmenu Icon is displayed on the screen.

1

2

3

4

5

1MENUmbutton: Displays the main on-screen menu.

2TOOLSTbutton: Displays the Tools menus when available.

3Eand Direction buttons: Use the Direction buttons to move the cursor and highlight an item. Use the Ebutton to select an item or confirm the setting.

4RETURNRbutton: Returns to the previous menu.

5EXITebutton: Exits the on-screen menu.

How to Operate the Main Menu (OSD - On Screen Display)

The access steps may differ depending on the menu option you select.

1	MENUm
2	u/ d
3	E
4	u/ d
5	u/ d/ l/ r
6	E
7	EXITe

The main menu options appear on the screen:

Picture, Sound, Broadcasting, Applications, System, Support.

Select a main menu option on the left side of the screen with the uor dbutton.

Press Eto access the sub-menus.

Select the desired sub-menu with the uor dbutton.

Adjust the value of an item with the l, r, u, or dbutton. The adjustment in the OSD may differ depending on the selected menu.

Press Eto confirm the selection.

Press EXITe.

English - 19

Getting Started

Connecting the Power Cord and the Aerial or Cable Connection

VHF/UHF Aerial Cable

Aerial Cable

or

Plug the power cord into a wall outlet only after you have made all other connections.

If you are connecting your product to a cable or satellite box using HDMI, Component, or Composite connections, you do not need to connect the AIR/CABLE ANT IN jack to an aerial or a cable connection.

Use caution when you move or swivel the product if the aerial cable is tightly connected. You could break the aerial jack off the product.

English - 20

Connections

Connecting to AV Devices (Blu-ray Players, DVD Players, etc.)

Using an HDMI Cable for an HD connection (up to 1080p, HD digital signals)

For the best quality HD picture, we recommend using an HDMI connection.

Use with DVD players, Blu-ray players, HD cable boxes, and HD Set-Top-Box satellite receivers.The image may differ depending on the model.

HDMI Cable

HDMI IN 1 (STB) / HDMI IN 2 (DVI)

•• For the best picture and audio quality, connect digital devices to the product using HDMI cables.

•• An HDMI cable supports digital video and audio signals, and does not require an audio cable.

––To connect the product to a digital device that does not support HDMI output, use an HDMI to DVI cable and audio cables.

•• If you connect an external device to the product that uses an older version of HDMI, the video and audio may not work. If this occurs, ask the manufacturer of the device about the HDMI version and, if it is out of date, request an upgrade.

•• Be sure to purchase a certified HDMI cable. Otherwise, the picture may not display or a connection error may occur.

•• We recommend using a basic high-speed HDMI cable or an HDMI cable that is Ethernet compatible. Note that this product does not support the Ethernet function via HDMI.

English - 21

Connections

Using a Component Cable (up to 1080p HD signals) or an Audio/Video Cable (480i analogue signals only)

Use with DVD players, Blu-ray players, cable boxes, STB satellite receivers, VCRs.The image may differ depending on the model.

Video Cable

Audio Cable

W

Y

W R B G

Audio Cable

Component Cable

R

W

(Not Supplied)

(Not Supplied)

Red

White

Y

R

W

VIDEO OUT

AUDIO OUT

Device

R W R B G

AUDIO OUT

COMPONENT OUT

Device

R B G

R-AUDIO-L

R-AUDIO-L

PR

PB

Y

Red

Blue Green

For better picture quality, we recommend the Component connection over the A/V connection.

When you connect a Video cable to COMPONENT / AV IN, the colour of the COMPONENT / AV IN [VIDEO] jack (green) will not match the video cable (yellow).

Using a Scart Cable

Available devices: DVD, VCR

The image may differ depending on the model.

EXT

In Ext. mode, DTV Out supports MPEG SD Video and Audio only.

English - 22

Connections

Connecting to Audio Devices

Using a Headphone Cable Connection

The image may differ depending on the model.

Headphone Cable

Headphones H: You can connect your headphones to the headphone output jack on your product. While the headphones are connected, the sound from the built-in speakers will be disabled.

•• The sound function may be restricted when you connect headphones to the product.

•• Headphone volume and product volume are adjusted separately.

•• The earphone jack supports only the 3 conductor tip-ring-sleeve (TRS) type.

English - 23

Connections

Connecting to a PC

Using an HDMI Cable or an HDMI to DVI Cable Connection

Your PC may not support an HDMI connection.Use your PC speakers for audio.

The image may differ depending on the model.

NOTE

•• For an HDMI to DVI cable connection, you must use the HDMI IN 2 (DVI) jack.

•• For PC's with DVI video out jacks, use an HDMI to DVI cable to connect the DVI out on the PC to the HDMI IN 2 (DVI) jack on the product. Use the PC's speakers for audio.

English - 24

Connections

Connections (T24E310EW T24E310EX)

HDMI connection	AV connection
Set top Box / BD Player / PC	BD Player

Headphone

connection

HDMI OUT	DVI OUT	AUDIO OUT		COMPONENT OUT
		R-AUDIO-L		PR	PB	Y
		R	W	R	B	G

Component connection

BD Player

AUDIO OUT		VIDEO OUT
R-AUDIO-L
R	W	Y

TV Side Panel

R

USB (5V 0.5A)

USB

1 (STB) 2 (DVI)

HDMI IN

DIGITAL

AUDIO OUT (OPTICAL)

COMMON INTERFACE

DC 14V

EXT (RGB)

W

R

B

G

R

W

Y

It supports both Component and AV connection in one port.

DC 14V

VHF/UHFA
Antenna
or	EXT

VCR or DVD

SCART connection

OPTICAL

Audio connection Cable

NOTE

•• Connecting through the HDMI cable may not be supported depending on the PC.

•• If a DVI to HDMI cable is connected to HDMI IN 2 (DVI) port, there will be no audio.

•• For set-top box connection using HDMI cable, we highly recommend you to connect the HDMI IN 1 (STB) port.

•• The headphone jack supports only the 3 conductor tip-ring-sleeve (TRS) type.

English - 25

Connections

Connections (T28E310EW T28E310EX)

HDMI connection

Set top Box / BD Player / PC

Headphone connection

HDMI OUT

TV Side Panel

USB

(5V 0.5A)

USB

1 (STB) 2 (DVI) HDMI IN

DIGITAL

AUDIO OUT (OPTICAL)

COMMON INTERFACE

VHF/UHFA

Antenna

or

OPTICAL

AV connection									Component connection
BD Player									BD Player
DVI OUT	AUDIO OUT						AUDIO OUT		VIDEO OUT
			COMPONENT OUT
	R-AUDIO-L		PR	PB	Y		R-AUDIO-L
	R	W	R	B	G		R	W	Y
	R	W	R	B	G		R	W	Y

It supports both Component and AV connection in one port.

EXT (RGB)

EXT

VCR or DVD

SCART connection

Audio connection Cable

NOTE

•• Connecting through the HDMI cable may not be supported depending on the PC.

•• If a DVI to HDMI cable is connected to HDMI IN 2 (DVI) port, there will be no audio.

•• For set-top box connection using HDMI cable, we highly recommend you to connect the HDMI IN 1 (STB) port.

•• The headphone jack supports only the 3 conductor tip-ring-sleeve (TRS) type.

English - 26

Connections

Connections (T32E310EW T32E310EX)

HDMI connection		AV connection		Component connection
Set top Box / BD Player / PC		BD Player		BD Player

X

O

X

NOTE

•• Connecting through the HDMI cable may not be supported depending on the PC.

•• If a DVI to HDMI cable is connected to HDMI IN 2 (DVI) port, there will be no audio.

•• For set-top box connection using HDMI cable, we highly recommend you to connect the HDMI IN 1 (STB) port.

•• The headphone jack supports only the 3 conductor tip-ring-sleeve (TRS) type.

English - 27

Connections

Connecting to a COMMON INTERFACE slot (Your product viewing Card Slot)

Turn the TV off to connect or disconnect a CI card.

Using the “CI or CI+ CARD”

To watch paid channels, the “CI or CI+ CARD” must be inserted.

•• If you don’t insert the “CI or CI+ CARD”, some channels will display the message “Scrambled Signal”.

•• The pairing information containing a telephone number, the “CI or CI+ CARD” ID the Host ID and other information will be displayed in about 2~3 minutes. If an error message is displayed, please contact your service provider.

•• When the configuration of channel information has	The image may differ depending on the model.
finished, the message “Updating Completed” is displayed,
indicating the channel list is updated.
NOTE

•• You must obtain a “CI or CI+ CARD” from a local cable service provider.

•• When removing the “CI or CI+ CARD”, carefully pull it out with your hands since dropping the “CI or CI+ CARD” may cause damage to it.

•• Insert the “CI or CI+ CARD” in the direction marked on the card.

•• The location of the COMMON INTERFACE slot may be different depending on the model.

•• “CI or CI+ CARD” is not supported in some countries and regions; check with your authorised dealer.

•• If you have any problems, please contact a service provider.

•• Insert the “CI or CI+ CARD” that supports the current aerial settings. The screen will be distorted or will not be seen.

English - 28

Connections

Display Modes (D-Sub and HDMI/DVI Input)

The optimal PC display resolution for this product is 1366 x 768 @ 60 Hz (24"/28"), 1920 x 1080 @ 60 Hz ( 32"). We very strongly recommend you set the video output of your computer to the optimal resolution. You can also select one of the standard resolutions listed in the table below and the product will be automatically adjust to the resolution you choose.

If you set your computer’s video output to a resolution not listed in the table, the product screen may go blank and only the power indicator will turn on. To resolve this issue, adjust the resolution according to the following table, referring to the user guide for the graphics card.

•• Optimal resolution: 1366 x 768 pixels (24"/28"), 1920 x 1080 pixels (32")

	Mode	Resolution	Horizontal	Vertical	Pixel Clock	Sync Polarity	1366 x 768	1920 X 1080
			Frequency (KHz)	Frequency (Hz)	Frequency (MHz)	(H / V)
	IBM	720 x 400	31.469	70.087	28.322	-/+	c	c
		640 x 480	35.000	66.667	30.240	-/-	c	c
	MAC	832 x 624	49.726	74.551	57.284	-/-	c	c
		1152 x 870	68.681	75.062	100.000	-/-		c
		640 x 480	31.469	59.940	25.175	-/-	c	c
		640 x 480	37.861	72.809	31.500	-/-	c	c
		640 x 480	37.500	75.000	31.500	-/-	c	c
		800 x 600	37.879	60.317	40.000	+/+	c	c
		800 x 600	48.077	72.188	50.000	+/+	c	c
		800 x 600	46.875	75.000	49.500	+/+	c	c
		1024 x 768	48.363	60.004	65.000	-/-	c	c
		1024 x 768	56.476	70.069	75.000	-/-	c	c
	VESA	1024 x 768	60.023	75.029	78.750	+/+	c	c
		1152 x 864	67.500	75.000	108.000	+/+		c
	DMT
		1280 x 720	45.000	60.000	74.250	+/+	c	c
		1280 x 800	49.702	59.810	83.500	-/+		c
		1280 x 1024	63.981	60.020	108.000	+/+		c
		1280 x 1024	79.976	75.025	135.000	+/+		c
		1366 x 768	47.712	59.790	85.500	+/+	c	c
		1440 x 900	55.935	59.887	106.500	-/+		c
		1600 x 900RB	60.000	60.000	108.000	+/+		c
		1680 x 1050	65.290	59.954	146.250	-/+		c
		1920 x 1080	67.500	60.000	148.500	+/+		c

For an HDMI to DVI cable connection, you must use the HDMI IN 2 (DVI) jack.The interlace mode is not supported.

The set may operate abnormally if you select a non-standard video format.Separate and Composite modes are supported. SOG(Sync On Green) is not supported.

DPM(Display Power Management) Function does not work if you used in connection with the HDMI port of this product.

If an HDMI to DVI cable is connected to the HDMI IN 2 (DVI) port, the audio does not work.

English - 29
